Installation Instructions
Eng
Philips
Communication,
Security & Imaging
IMPORTANT SAFEGUARDS
1. Read Instructions - All safety and operating instructions should be read
before the unit is operated.
2. Retain Instructions - The safety and operating instructions should be
retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug the unit from the outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this unit near water - for example, in a
wet basement, near a swimming pool, in an unprotected outdoor
installation, or any area classified as a wet location.
8. Accessories - Do not place this unit on an unstable stand, tripod, bracket,
or mount. The unit may fall, causing serious injury to a person and
serious damage to the unit. Use only with a stand, tripod, bracket, or
mount recommended by the manufacturer or sold with the product.
Any mounting of the unit should follow the manufacturer’s instructions
and should use a mounting accessory recommended by the
manufacturer.
An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the appliance
and cart combination to overturn.
9. Ventilation - This unit should not be placed in a built-in installation or
rack, unless proper ventilation is provided, or the manufacturer’s
instructions have been adhered to. The equipment must not exceed its
maximum operating temperature requirements.
10. Mechanical Loading - Mounting of the equipment in a rack shall be such that
a hazardous condition is not achieved due to uneven mechanical loading.
11. Power Sources - This unit should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of
power supply you plan to use, consult your dealer or local power company.
For units intended to operate from battery power or other sources, refer to
the operating instructions.
12. Grounding or Polarization - This unit may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
Alternately, this unit may be equipped with a 3-wire grounding-type plug,
a plug having a third (grounding) pin. This plug will only fit into a
grounding-type power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
13. Power Cord Protection - Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
14. Power Lines - An outdoor system should not be located in the vicinity of
overhead power lines or other electric light or power circuits or where it
can fall into such power lines or circuits. When installing an outdoor
system, extreme care should be taken to keep from touching such power
lines or circuits, as contact with them might be fatal. U.S.A. models only refer to the National Electrical Code Article 820 regarding installation of
CATV systems.
15. Overloading - Do not overload outlets and extension cords, as this can
result in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this unit
through openings, as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid of any
kind on the unit.
2
17. Servicing - Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug the unit from the outlet andrefer
servicing to qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the unit.
c. If the unit has been exposed to water and/or inclement weather (rain,
snow, etc.).
d. If the unit does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an improper adjustment of other controls
may result in damage, often requiring extensive work by a qualified
technician, to restore the unit to its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance--this indicates
a need for service.
19. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or having the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20. Safety Check - Upon completion of any service or repairs to this unit, ask
the service technician to perform safety checks to determine that the unit is
in proper operating condition.
21. Coax Grounding - If an outside cable system is connected to the unit, be
sure the cable system is grounded. U.S.A. models only--Section 810 of the
National Electrical Code, ANSI/NFPA No. 70-1981, provides information
with respect to proper grounding of the mount and supporting structure,
grounding of the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
22. Lightning - For added protection of this unit during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the cable system. This will prevent
damage to the unit due to lightning and power line surges.
FCC & ICES INFORMATION
(U.S.A. and Canadian Models Only)
WARNING - This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules and
ICES-003 of Industry Canada. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and radiates radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense. Intentional or unintentional changes or modifications not
expressly approved by the party responsible for compliance shall not be made.
Any such changes or modifications could void the user’s authority to operate the
equipment.
If necessary, the user should consult the dealer or an experienced radio/television
technician for corrective action . The user may find the following booklet
prepared by the Federal Communications Commission helpful: “How to
Identify and Resolve Radio-TV Interference Problems.” This booklet is
available from the U.S. Government Printing Office, Washington, DC 20402,
Stock No.004-000-00345-4.
Warning: This is a Class A product. In a domestic
environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
SAFETY PRECAUTIONS
SECURITE
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT OPEN
COVERS. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with an arrowhead symbol within
an equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
DANGER : POUR ÉVITER TOUT RISQUE
D’ÉLECTROCUTION, VEUILLEZ NE PAS
OUVRIR LE BOÎTIER. IL N’Y A PAS DE
PIÈCES REMPLAÇABLES PAR L’UTILISATEUR
À L’INTÉRIEUR DU BOÎTIER. POUR TOUTE
MAINTENANCE, VEUILLEZ VOUS ADRESSER
À UN TECHNICIEN SPÉCIALISÉ.
L’éclair fléché dans un triangle équilatéral avertit
l’utilisateur de la présence d’une “tension dangereuse” non
isolée à l’intérieur de l’appareil et d’une valeur suffisante
pour présenter un risque d’électrocution aux personnes.
The exclamation point within an equilateral triangle is
intended to alert the user to presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE UNITS NOT SPECIFICALLY
DESIGNED FOR OUTDOOR USE TO RAIN OR
MOISTURE.
Attention: Installation should be performed by
qualified service personnel only in accordance with the
National Electrical Code or applicable local codes.
Le point d’exclamation contenu dans un triangle
équilatéral avertit l’utilisateur de la présence de
consignes d’utilisation et de maintenance importantes
dans la documentation qui accompagne l’appareil.
ATTENTION
POUR ÉVITER TOUT RISQUE
D’ÉLECTROCUTION OU D’INCENDIE,
VEUILLEZ NE PAS EXPOSER À LA PLUIE OU
À L’HUMIDITÉ UN APPAREIL NON CONÇU
POUR UNE UTILISATION EXTÉRIEURE.
Attention. L’installation ne doit être effectuée que par
un personnel technique qualifié conformément à la
réglementation du Code Électrique National ou à la
réglementation locale pertinente.
Power Disconnect. Units with or without ON-OFF
switches have power supplied to the unit whenever the
power cord is inserted into the power source; however,
the unit is operational only when the ON-OFF switch
is in the ON position. The power cord is the main
power disconnect for all units.
WARNING: Electrostaticsensitive device. Use proper
CMOS/MOSFET handling
precautions to avoid
electrostatic discharge.
NOTE: Grounded wrist straps
must be worn and proper ESD
safety precautions observed
when handling the electrostaticsensitive printed circuit boards.
Disjonction de l’alimentation. Les appareils avec ou sans
commutateurs ON-OFF sont alimentés à chaque fois
que le cordon d’alimentation est branché à la source
d’alimentation; toutefois, les appareils disposant de
commutateurs ON-OFF ne fonctionnent que lorsque le
commutateur ON-OFF est dans la position ON. Le
cordon d’alimentation constitue le moyen de disjonction
de l’alimentation principale de tous les appareils.
CAUTION: Lithium Battery
A T T E N T IO N
O B S E R V E
F O R
E L E C
S E N S IT
P R
H A N
T R O
IV E
E C A U T IO N S
D L IN G
S T A T IC
D E V IC E S
Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to
the battery manufacturer’s instructions
3
SICHERHEITSHINWEISE
SEGURIDAD
VORSICHT
PRECAUCIÓN
ELEKTRISCHE SPANNUNG.
NICHT ÖFFNEN!
RIESGO DE DESCARGA ELÉCTRICA
¡NO ABRIR!
VORSICHT: DAS GEHÄUSE ZUR
VERMEIDUNG VON ELEKTRISCHEN
SCHLÄGEN NICHT ÖFFNEN. DAS GERÄT
ENTHÄLT KEINE VOM BENUTZER ZU
WARTENDEN TEILE. REPARATUREN NUR
VON FACHPERSONAL AUSFÜHREN LASSEN.
Das Blitzsymbol im gleichseitigen Dreieck soll den
Benutzer auf nicht isolierte “gefährliche Spannung” im
Produkt hinweisen, die ausreichend stark sein kann,
um die Gefahr von elektrischen Schlägen für
Menschen darzustellen.
Das Ausrufungszeichen im gleichseitigen Dreieck soll
den Benutzer auf wichtige Bedienungs- und
Wartungsanweisungen in der Dokumentation
hinweisen, die dem Gerät beiliegt.
WARNUNG
ZUR VERMEIDUNG VON FEUER UND
ELEKTRISCHEN SCHLÄGEN DAS GERÄT
NICHT REGEN ODER FEUCHTIGKEIT
AUSSETZEN.
PRECAUCIÓN: PARA REDUCIR EL RIESGO
DE DESCARGA ELÉCTRICA, NO ABRA LAS
TAPAS. EN EL INTERIOR NO HAY NINGÚN
COMPONENTE REPARABLE POR EL USUARIO.
LAS REPARACIONES DEBE REALIZARLAS
PERSONAL CUALIFICADO.
El símbolo de flecha en forma de rayo situado dentro
de un triángulo equilátero pretende alertar al usuario
de la presencia de “voltaje peligroso” sin aislamiento
dentro de la caja del producto, el cual podría resultar
de una magnitud suficiente como para presentar un
riesgo de descarga eléctrica para las personas.
El punto de exclamación dentro de un triángulo equilátero
pretende alertar al usuario de la existencia de instrucciones
de funcionamiento y mantenimiento (reparación) en la
documentación suministrada con el aparato.
AVISO
PARA IMPEDIR EL RIESGO DE INCENDIO O
DESCARGA, NO EXPONGA EL APARATO A
LLUVIA O HUMEDAD
Achtung: Die Installation darf nur von qualifiziertem
Wartungspersonal gemäß dem National Electrical
Code oder den gültigen örtlichen Vorschriften
durchgeführt werden.
Abtrennen der Spannungsversorgung: Die
Spannungsversorgung zu Geräten mit und ohne
Ein/Aus-Schalter ist hergestellt, wenn das Netzkabel an
eine Netzsteckdose angeschlossen ist. Das Gerät ist
jedoch nur betriebsbereit, wenn der Ein/Aus-Schalter
eingeschaltet ist. Bei allen Geräten erfolgt das Abtrennen
der Spannungsversorgung über das Netzkabel.
4
Atención: La instalación debe realizarla personal
cualificado en cumplimiento estricto del código
eléctrico nacional (en el caso de los EE.UU.) o de los
códigos locales aplicables.
Para Desconectar la Alimentación: Unidades no
equipadas con interruptores ON/OFF, son alimentadas
cuando el cable de alimentación es conectado a la
corriente eléctrica. Las unidades equipadas con
interruptores son alimentadas de igual forma, pero
adicionalmente requieren que el interruptor esté
posicionado en ON. El cable de alimentación es el
medio principal de desconexión del equipo.
VEILIGHEIDSMAATREGELEN
SICUREZZA
VOORZICHTIG
ATTENZIONE
GEVAAR VOOR ELEKTRISCHE SCHOK.
NIET OPENEN!
PERICOLO DI SCOSSA ELETTRICA.
NON APRIRE.
VOORZICHTIG: MAAK HET APPARAAT NIET
OPEN OM DE KANS OP ELEKTRISCHE
SCHOKKEN TE VERMIJDEN. BEVAT GEEN
ONDERDELEN DIE DOOR DE GEBRUIKER
MOETEN WORDEN ONDERHOUDEN. LAAT
ONDERHOUD EN REPARATIES UITVOEREN
DOOR BEVOEGDE TECHNICI.
Het symbool ‘Bliksemflits met pijlkop’ in een
gelijkzijdige driehoek wijst de gebruiker op de
aanwezigheid in de kast van het apparaat van nietgeïsoleerde spanningen die voldoende sterk zijn om
het gevaar van elektrische schokken op te leveren.
ATTENZIONE: PER RIDURRE IL PERICOLO DI
SCOSSA ELETTRICA, NON APRIRE LE
COPERTURE. L’INTERNO NON CONTIENE
COMPONENTI CHE L’UTENTE PUÒ
RIPARARE PERSONALMENTE. RIVOLGERSI AL
PERSONALE DI ASSISTENZA QUALIFICATO
PER QUALSIASI INTERVENTO DI
RIPARAZIONE.
Il simbolo triangolare di un fulmine con la punta a
freccia intende mettere in allerta l’utente riguardo alla
presenza di tensioni pericolose non isolate all’interno
del guscio dell’unità, che potrebbero essere di intensità
sufficiente per costituire pericolo di elettrocuzione.
Het uitroepteken in een gelijkzijdige driehoek maakt
de gebruiker attent op de aanwezigheid in de bij het
apparaat behorende documentatie van belangrijke
aanwijzingen voor bediening en onderhoud.
WAARSCHUWING
TER VOORKOMING VAN BRANDGEVAAR
EN ELEKTRISCHE SCHOKKEN MAG DIT
ARMATUUR NIET AAN REGEN EN VOCHT
WORDEN BLOOTGESTELD.
Il punto esclamativo racchiuso in un triangolo equilatero
intende avvisare l’utente in merito alla presenza di
importanti istruzioni operative e di manutenzione nella
documentazione di accompagnamento all’unità.
AVVERTENZA
PER IMPEDIRE INCENDI O SCOSSA
ELETTRICA, NON ESPORRE L’UNITÀ ALLA
PIOGGIA O ALL’UMIDITÀ.
Let op: Het apparaat mag uitsluitend door bevoegde
technici geïnstalleerd worden en wel in overeenstemming
met de National Electrical Code of de daarvoor
plaatselijk geldende richtlijnen.
Precauzione: affidare l’installazione al solo personale
qualificato e nel rispetto del Codice elettrico nazionale
(USA) o dei codici locali pertinenti.
Scollegamento dell’alimentazione. Gli apparecchi con o
senza commutatori ON-OFF ricevono corrente tutte le
volte che il cavo di alimentazione è inserito nella presa
di forza; tuttavia, gli apparecchi muniti di commutatore
ON-OFF funzionano solo se quest’ultimo è in posizione
ON. Il cavo di alimentazione serve a scollegare dalla
corrente tutti gli apparecchi.
Afsluiten voeding. Apparaten met of zonder
ON-OFF-schakelaar krijgen voeding zodra het
netsnoer in de wandcontactdoos wordt gestoken; het
apparaat is echter alleen operationeel als de ON-OFFschakelaar op ON staat. Het netsnoer kan bij alle
apparaten worden gebruikt om deze uit te schakelen.
5
´
ZASADY BESPIECZE NSTAWA
MEDIDAS DE SEGURANÇA
CUIDADO
UWAGA
NIEBEZPIECZEŃSTWO PORAŻENIA PRĄDEM
ELEKTRYCZNYM. NIE OTWIERAĆ!
RISCO DE CHOQUE ELÉCTRICO.
NÃO ABRIR!
UWAGA: ZE WZGLĘDU NA
NIEBEZPIECZEŃSTWO PORAŻENIA PRĄDEM
NIE WOLNO OTWIERAĀ POKRYWY.W
ŚRODKU NIE MA ŻADNYCH ELEMENTÓW,
KTÓRE MOGĄ BYĀ NAPRAWIANE PRZEZ
UŻYTKOWNIKA. NAPRAWĘ NALEŻY
POWIERZYĀ AUTORYZOWANEMU PUNKTOWI SERWISOWEMU.
CUIDADO: PARA REDUZIR O RISCO DE
CHOQUE ELÉCTRICO, NÃO ABRA AS TAMPAS. O INTERIOR NÃO CONTÉM PEÇAS QUE
NECESSITEM DE MANUTENÇÃO. A
MANUTENÇÃO DEVE SER EFECTUADA POR
PESSOAL DE ASSISTÊNCIA TÉCNICA QUALIFICADO.
O símbolo do raio com a cabeça de uma seta dentro
de um triângulo equilátero serve para alertar o utilizar
para a presença de "corrente eléctrica perigosa" não
isolada no interior da caixa do produto que pode ser
suficiente para dar origem a choques eléctricos.
Błyskawica ze strzałką wewnątrz trójkąta równobocznego
ma za zadanie zwrócić uwagę użytkownika na obecność
nieizolowanego "niebezpiecznego napięcia" wewnątrz
obudowy urządzenia, o wielkości stwarzającej niebezpieczeństwo porażenia prądem.
O ponto de exclamação dentro de um triângulo equilátero
serve para alertar o utilizador para a presença de instruções
de funcionamento e manutenção importantes na documentação fornecida com o aparelho.
Wykrzyknik wewnątrz trójkąta równobocznego ma za
zadanie zwrócić uwagę użytkownika na ważne czynności,
związane z obsługą i konserwacją urządzenia, zamieszczone w Instrukcji obsługi.
AVISO
PARA EVITAR INCÊNDIOS OU CHOQUES
ELÉCTRICOS, NÃO EXPONHA À CHUVA OU
HUMIDADE UNIDADES NÃO ESPECIFICAMENTE CRIADAS PARA UTILIZAÇÃO NO
EXTERIOR.
OSTRZEŻENIE
ABY UNIKNĄĀ POŻARU LUB PORAŻENIA
PRĄDEM NIE WOLNO WYSTAWIAĀ NA
DZIAŁANIE DESZCZU LUB WILGOCI
URZĄDZEŃ, KTÓRE NIE ZOSTAŁY SPECJALNIE
ZAPROJEKTOWANE DO UŻYWANIA NA
OTWARTYM POWIETRZU.
Atenção: A instalação deve ser efectuada por pessoal de
assistência técnica qualificado, de acordo com o
National Electrical Code (Normas de Electricidade
Nacionais) ou a legislação local aplicável.
Uwaga: Instalację urządzenia powinien wykonać tylko
wykwalifikowany personel, zgodnie z przepisami NEC lub
odpowiednimi przepisami miejscowymi.
Desconexão da electricidade. Unidades com ou sem
interruptores ON-OFF são activadas sempre que o
cabo eléctrico for ligado a uma fonte de alimentação.
No entanto, a unidade fica operacional apenas quando
o interruptor ON-OFF se encontrar na posição ON.
Para desligar a electricidade em qualquer uma das
unidades deve ser utilizado o cabo eléctrico.
Odłączanie zasilania. Urządzenia zarówno nie posiadające, jak i posiadające wyłączniki ON-OFF znajdują się
pod napięciem, jeżeli tylko przewód zasilający jest
połączony ze źródłem zasilania. Jednakże urządzenie
działa tylko wtedy, gdy wyłącznik znajduje się w położeniu
ON. Przewód zasilający jest głównym odłącznikiem zasilania dla wszystkich rodzajów urządzeń.
Precauções a ter durante a substituição da bateria
Use apenas fontes de alimentação recomendadas. As
fontes de alimentação devem cumprir os requisitos da
da versão mais recente de IEC 65/VDE 0860.
Qualquer substituição pode causar danos na unidade
ou dar origem a incêndios ou choques eléctricos.
Wymiana baterii
Stosuj tylko zalecane baterie. Muszą one spełniać wymagania najnowszej wersji IEC 65/VDE 0860. Zamienniki
mogą uszkodzić urządzenie lub spowodować pożar czy
porażenie prądem.
6
TABLE OF CONTENTS
1 PRODUCT DESCRIPTION ..............................................................................................................................8
1.1 Models ................................................................................................................................................................8
1.2 Features................................................................................................................................................................8
2 UNPACKING......................................................................................................................................................8
2.1 Package Contents ................................................................................................................................................8
3 SYSTEM OVERVIEW ........................................................................................................................................8
4 ADIM CONNECTIONS AND CONFIGURATION........................................................................................10
4.1 DVR Configuration (See DVR manual) ............................................................................................................10
4.2 IntuiKey Keyboard and Serial Hub Connections ..............................................................................................10
4.3 ADIM PC is pre-configured as follows ..............................................................................................................10
4.4 Primary DVR Connections................................................................................................................................10
4.5 Backup DVR and Review Monitor Connections (Optional) ............................................................................10
4.6 Network Connections........................................................................................................................................11
4.7 ADIM PC Connections ....................................................................................................................................11
4.8 The PC is pre-configured with the following network parameters ....................................................................11
4.9 Setting up ADIM PC Connections....................................................................................................................11
4.10 Allegiant Connections ......................................................................................................................................11
5 ADIM CONFIGURATION ..............................................................................................................................12
5.1 Logging ON and User Levels ............................................................................................................................12
6 OPERATION ....................................................................................................................................................13
6.1 DVR Configuration Page ..................................................................................................................................13
6.2 Other Configuration..........................................................................................................................................14
6.2.1 Allegiant Status Message Monitors ..................................................................................................................................14
6.2.2 Auto-Login....................................................................................................................................................................14
6.2.3 Keyboard / Com Port Assignment ..................................................................................................................................14
6.3 Status and Monitoring Page ..............................................................................................................................15
6.4 Allegiant Camera Title Transfer Dialog ..............................................................................................................16
7 ADIM KEYBOARD OPERATION ..................................................................................................................17
7.1 Product Menu....................................................................................................................................................17
7.2 Allegiant Main Menu ........................................................................................................................................17
7.3 ADIM Controls Menu ......................................................................................................................................17
7.4 Joystick Operation ............................................................................................................................................17
7.5 Numeric Keypad Buttons ..................................................................................................................................17
7.6 Softkey Buttons ................................................................................................................................................17
7.7 Keyboard Error Handling ..................................................................................................................................17
7.8 Clearing ADIM Alarms ....................................................................................................................................17
8 TROUBLESHOOTING....................................................................................................................................18
APPENDIX A – EVENT LOGS ..........................................................................................................................19
APPENDIX B – TECHNICAL SPECS ................................................................................................................22
APPENDIX C – RECOMMENDED NETWORK SWITCHES ..........................................................................23
APPENDIX D – LIST OF COMPATIBLE DVRS ..............................................................................................23
APPENDIX E – PRIMARY, BACK-UP AND REVIEW DVRS ..........................................................................23
7
1
PRODUCT DESCRIPTION
ADIM™ is a powerful security and surveillance solution that
combines the power and features of the Philips Allegiant matrix
switcher with the speed and quality of digital video recording.
This tightly integrated solution uses the IntuiKey keyboard to
control all cameras, monitors and digital video recorders. With
the push of a button, the DVR will playback video from the
current camera and display it on the specified CCTV monitor.
The joystick can be used to fast forward, fast reverse and
navigate the menu within the DVR.
1.1 Models
ADM0101 (see package contents below)
1.2 Features
• IntuiKey Keyboard interface for all Camera, Allegiant® and
DVR functions
• One-button transition from Live to recorded video–on the
specified analog monitor
• Synchronization of DVR and Allegiant clocks
• Status monitoring and event logging
• Automatic switchover to backup DVRs
• Monitor review; playback all video that was directed to
specified review monitors
2
3
SYSTEM OVERVIEW
ADIM is an integration solution for the IntuiKey Keyboard,
Allegiant Matrix Switcher and selected Philips DVRs.
UNPACKING
Unpack carefully to prevent damage to the equipment.
Components of an ADIM system:
2.1
•
•
•
•
•
•
•
Package Contents
Item
Qty
Part Number
ADIM PC (keyboard, mouse,
monitor, power cord,
Windows NT®, ADIM and
system software, rack mounting
hardware)
1
3033743001
Software Key
1
3031874021002
Master Control software
1
30336800100
Serial Hub
1
ACCSH01
Ethernet Cable
2
3032779001
Console Cable, 10-foot
1
LTC 8506/00
Null Modem Cable, 15-foot
1
ACCNM015
Instruction Manual (this manual)
1
393589042712*
Master Control Software for
Windows Manual
1
393589012413
Allegiant matrix switcher
Hi-Qs (Revision 1.10 or higher)
Disk Arrays (optional)
ADIM PC
Serial Hub(s)
Universal IntuiKey Keyboard(s) – (Rev 1.10 or higher)
Network Switch(es) – (See Appendix C for recommended
network switches.)
NOTE: For your convenience, the Hi-Q Management Utility
and the IntuiKey Keyboard’s Installer program are pre-installed
on the ADIM PC.
* Revision of this Instruction Manual will increment as changes are
made. Please visit www.Philipscsi.com for the most current version.
8
Typical System:
Back-up Recorder
Allegiant
Video
Loop-through
Disk Array
Monitor Outputs
PHILIPS
ALLEGIANT Video Matrix
Review Monitor
Recorder
Video
Inputs
PHILIPS
PHILIPS
PHILIPS
PHILIPS
Network Switch
LAN
Network
ADIM
Maximum of
6 Keyboards
Serial Hub
IMPORTANT NOTES:
• Disk Arrays are optional. (See specific DVR for Disk Array
options.)
• Additional Serial Hubs may be used for remote keyboards.
• The ADIM system can handle a maximum of 6 keyboards;
additional Keyboards may be connected to the Allegiant for
live monitoring and camera control.
• ADIM can only be used with compatible Philips DVRs.
(See Appendix D.)
• Only one user at a time can access a particular DVR. To
avoid situations where high priority cameras are not accessible
for playback, avoid placing more than one high priority
camera on each DVR.
• The ADIM supports only one Allegiant system. The Allegiant
•
•
•
•
•
9
may be a master in a satellite configuration, with DVRs at
both master and satellite sites.
Ensure the Allegiant has sufficient inputs for all cameras, DVR
MON A outputs and optional Backup DVR MON A outputs.
Ensure the Allegiant has sufficient outputs for all Backup
DVR inputs.
This system is designed to operate on its own closed network.
The ADIM PC does not take the place of the 8900 Series PC.
An LTC 8900 Allegiant System will still require its
LTC 8943/92 PC.
The DVRs can be configured as Review Monitors, providing
playback capability only for cameras that were directed to the
specific monitors.
4
4.3
ADIM CONNECTIONS AND
CONFIGURATION
ADIM PC is pre-configured as follows:
NOTE: The installer should be familiar with the Allegiant CCTV
control system and Windows-based software, and have a general
knowledge of networking.
Serial Hub’s
Physical Port
PC COM Port
1
5
2
6
4.1 DVR Configuration (See DVR manual)
Configure each DVR with a unique IP address
3
7
4
8
•
•
•
5
9
Ensure valid IP addresses are configured
Set the DVRs recording parameters
Ensure the Hi-Q’s password is set to 1234 (this is the default
password)
4.2
IntuiKey Keyboard and Serial Hub Connections
• Connect each IntuiKey Keyboard to the Allegiant via an
RS-485 cable (not supplied).
Connect each IntuiKey Keyboard to the Serial Hub via a null
modem cable (a 15-foot cable is supplied).
•
Connect the serial hub to the network via an ethernet cable
(2 are supplied).
12*
4.4 Primary DVR Connections
• Connect the camera to the Primary DVR inputs and loop
video to the Allegiant inputs.
•
Connect the MON A output of the Primary DVRs to
Allegiant inputs.
Figure 4.1 shows the relationship of the Primary DVR outputs and
Allegiant inputs to the DVR Configuration page of the ADIM.
4.5
•
•
Backup DVR and Review Monitor Connections
(Optional)
Connect the Allegiant Monitor Outputs to the Backup or
Review DVR video inputs.
Connect the MON A output of the DVRs to an Allegiant
input.
Rear View of the Serial Hub
Inputs
101 102
PHILIPS
32
234 536
Loop Out Video
4
8
configurations in Sections 4.4 & 4.5) for future reference.
If the distance from your Keyboard to the Serial Hub exceeds
RS-232 limitations (50 feet), use a modem or additional Serial
Hub to extend the distance. (See Appendix B for the RS-232
pin out details.)
PHILIPS
11*
IMPORTANT: Please make note of your connections (COM port
IMPORTANT:
• The serial hub must be on the same network segment as the
ADIM PC.
ALLEGIANT Video Matrix
10
7
*Not Used; On the Serial Hub, keyboard cables can be
connected to Ports 1 through 6, Ports 7 & 8 are not used.
•
•
6
3
2
Mon A
1
PHILIPS
PHILIPS
PHILIPS
32
1
2
3
4
Figure 4.1
10
101
102
234
536
NA
29
4
3
2
1
Input
MO
Monitor Outputs
ALLEGIANT Video Matrix
PHILIPS
10 11 12 13
Figure 4.2
Figure 4.2 Shows the relationship of the Backup and Review
DVRs and Allegiant outputs to the DVR Configuration page of
the ADIM.
4.8
•
The PC is pre-configured with the following
network parameters
IP address: 10.10.0.10
4.6 Network Connections
• Interconnect the Serial Hub(s). ADIM PC, DVRs and
network switches.
•
Subnet mask: 255.255.255.0
•
Default Gateway: 10.10.0.1
Philips recommends that your IT department perform all
network and set up configuration.
NOTE: Connect the ADIM PC to the Network using the port
labeled LAN – Connect to Primary IP address.
NOTE: The PC is pre-configured to communicate with
the Serial Hub that is shipped with ADIM. If a different Serial
Hub is used with the system, the PC must be reconfigured.
(Refer to the Serial Hub’s instruction manual.)
Serial Hub
NOTE: A printer or other device can be connected onto the
security key, but the key may not function properly unless the
device is turned on.
4.9 Setting up ADIM PC Connections
1. Connect the keyboard and mouse “Y” adapter to the
mouse/keyboard port on back of PC. Connect the mouse
and the keyboard to the “Y” adapter.
2. Connect the PC monitor to the port labeled
“PC Monitor Connector”. Plug the PC and Monitor power
cords into the appropriate power sources, but do not turn on
the power switches yet.
3. Connect the ADIM PC to Allegiant Console Port.
• Use the console cable to connect PC COM port number 1
to the Allegiant Console port.
• Make sure that the ADIM PC is configured for the same
network segment as the Hi-Q Recorders
[10.10.0.0/255.255. 255.0/10.10.0.1 (defaults)].
4. Connect the ADIM PC to the Network Switch.
5. Turn on the power switches to the PC and the
monitor.
4.7 ADIM PC Connections
•
4.10 Allegiant Connections
• Connect the Allegiant to a PC COM Port 1 (recommended)
using the supplied Console cable.
Connect the Software Key to the parallel port of the PC.
11
5
ADIM CONFIGURATION
1. Select or create an Allegiant Server document.
The ADIM software is pre-loaded. No software installation is
required.
Open the ADIM Application by double clicking the
ADIM icon on your desktop.
5.1 Logging ON and User Levels
• Log in with a user name and password.
NOTE: ADIM will automatically open the last Allegiant
document, therefore this screen may not be seen.
•
2. If creating a new Allegiant document, select the type of
Allegiant:
If configuring the system, logon as a user with Installer or
Administrator privileges. This grants access to all areas.
NOTE: The ADIM’s user name and password are the same as
the Master Control Software for Windows.
•
User levels for ADIM and Master Control Software for
Windows:
User Level
Default User
Default
Areas of Access
Names
Passwords
Installer
Installer
1
Status, Monitoring
& Configuration
Administrator
Administrator
2
Status, Monitoring
& Configuration
Operator
Operator
3
Status, Monitoring
3. The ADIM Status and Monitoring screen is displayed as
shown in Figure 5.1.
NOTE: The PC is pre-configured to automatically log into
Windows NT and start the ADIM application. ADIM can be
configured to automatically log in, bypassing the log in dialog.
This allows automatic start up of the ADIM application when the
PC is restarted.
Figure 5.1
12
4. If it is a new document, or if the Allegiant system is not online, select <Allegiant> <<Display Allegiant Document>>:
NOTE: The green Allegiant On-line (in the lower right corner)
indicates ADIM is properly communicating with the Allegiant. It
may take up to 20 seconds for communication to be established.
6. Go to the DVR Configuration page to enter the values for
each DVR. (See Section 6; Operation.)
6
OPERATION
Elements of the ADIM document window:
Allegiant Document:
Menu Bar Tool Bar Tabs 6.1 DVR Configuration Page
•
•
5. Using the instructions in the Master Control Software For
Windows, configure the communication parameters
<<Transfer>> <<<Communication Setup>>>:
Set the communication parameters for the Allegiant and press
Go Online.
13
To edit any fields, first select the Edit button assigned to the
DVR #.
After the row is filled in, select Accept.
Items from DVR Configuration page
NOTE for Allegiant model LTC 8500:
ITEM
Explained
Default
•
Hi-Q Number
Identifies 1 to 800 Hi-Qs
(Not changeable)
Not
applicable
•
IP address
Hi-Q IP address
000.000.000.000
Primary, Monitor
Review or Backup
Determines how the Hi-Q is
configured into the system
(Primary, Backup, Review)
Primary
Enabled Status
Used to bring a Hi-Q online
Disabled
Allegiant Input
connected to Hi-Q
MON A output
Must be a valid logical camera
number within the Allegiant
document
Blank
Hi-Q (Hi-Q) input
number
Physical inputs on the Hi-Q
(Not changeable)
Not
Applicable
Blank
The logical monitor output of
Allegiant Logical
the Allegiant that is assigned to
monitor number
the physical input of the backup
connected to backup
Hi-Q
Blank
Other Configuration
6.2.1
Allegiant Status Message Monitors
6.2.2
Auto-Login
If the Enable Automatic Login checkbox is checked, upon start
of the application, ADIM is automatically logged on with User
Privileges.
6.2.3
Allegiant Logical
The logical camera number
Camera Number
within the Allegiant system that
looped with primary is assigned to the physical input
Hi-Q input
of the Primary Hi-Q
6.2
All Allegiants EXCEPT the LTC 8500 display the ADIM
messages on a third line above or below the two status lines.
The LTC 8500 does not have a third line for these messages,
however, the messages can be set to overwrite the Monitor
Title display. To do this the monitors must be set to
Monitor Title mode.
Keyboard / Com Port Assignment
Example: Connect keyboard 1 into physical port 1 on back of the
serial hub (preconfigured as COM5), etc.
The <Allegiant Status Message Monitors> area is used to
specify the Allegiant monitors that will display ADIM warning
and error messages. Enter the monitor number(s) separated by
commas (monitor ranges are specified with dashes). The monitor
number(s) must exist in the Allegiant Monitor Table.
14
Table
Heading
Explained
Field Values
ADIM
Keyboard
Logical
Keyboard
Number
1–6
COM
Port
Specify a
com port
for each
keyboard
1 – 256
(See Section 4.3 for
pre-configured values)
• COM port OK (GREEN)
• COM port not available (RED)
6.3
Status and Monitoring Page
Table Element
Hi-Q number
Hi-Q Type
Explained
Field Values
Fixed field depending on where the Hi-Q
is entered into the table
Determines configuration of the Hi-Q in the
system
1 - 800
Primary, Backup, Review Monitor
(See Appendix E for more details)
Primary:
On-Line (Green),
Off-Line (Red)
Backup:
Available (Green), Backing up a
Primary Hi-Q (Yellow)
Hi-Q Status
Indicates operational status of a Hi-Q:
On-Line and operational (Green);
Off-Line (Red);
Back-up unit that is currently backing up
a primary Hi-Q (Yellow)
Hi-Q Input Number
Physical inputs on the Hi-Q.
1 through 4
Allegiant Logical Camera Number
If a Backup Hi-Q is Backing up a Primary Hi-Q, this
field indicates the logical camera numbers that are
being recorded by the backup Hi-Qs. For Primary
Hi-Qs, this is simply the logical camera attached to
the Hi-Q.
1- 9,999
Camera Status
Field is gray when the associated Hi-Q is
Off-Line, or if the Hi-Q is a Backup Hi-Q in the
Available state.
OK (green)
NO Sync (red)
BUTTON: Switch video from selected
Primary Hi-Q to a Backup Hi-Q
BUTTON: Set Selected Backup Hi-Q
to “Available”
BUTTON: Silence Beep
BUTTON: Add Manual Event Message
ADIM Messages
This can be used to perform maintenance or repair
on a Hi-Q without loosing any recording. To
manually switch cameras to backup Hi-Q, first
select a Hi-Q, then press this button.
Frees up a Backup DVR that’s currently in use.
This DVR can subsequently be used to backup
another DVR. First, ensure that the primary Hi-Q
is operating and On-Line, then select the Backup
Hi-Q and press this button.
Silences the ADIM PC alarm (beep).
Allows a user to manually add a message to the
Event Log.
Displays the most recent information, warning,
and error events.
BUTTON: Open Log File
The Open File dialog box is displayed.
The log file names indicate the day.
(See Figures 6.1a & 6.1b)
Allegiant On-line
The lower right-hand corner of the screen
indicates On/Off-Line status of the Allegiant.
15
Green = On-Line
Red = Off-Line
Figure 6.3a
Figure 6.3b
NOTES:
• New Log files are created daily upon the occurrence of the
first event after 12:00am. Otherwise, new entries are
appended to the existing log file upon starting the
application.
• Log files are easily manipulated into MS Excel or MS Access
files for reporting. Use the TAB-delimited option to import
into other databases.
Figure 6.4a
6.4 Allegiant Camera Title Transfer Dialog
Camera titles configured for your Allegiant may be transferred to
the DVRs. Titles may be transferred in their entirety, or specific
cameras may be selected. To transfer titles, from the pull-down
FILE menu, select Allegiant from the menu, then select Allegiant
Title Transfer, as shown in Figures 6.4a and 6.4b.
NOTE: Allegiant camera titles must be downloaded to the
Allegiant before they can be transferd to DVRs.
Figure 6.4b
16
7
ADIM KEYBOARD OPERATION
7.1
Product Menu
SoftKey Display
SoftKey Descriptor
To ensure that the IntuiKey
Keyboard is properly connected
to the ADIM system, press the
IntuiKey’s Product key. The
ADIM On-Line softkey option
(see Figure 7.1) will only be
displayed if the IntuiKey
Keyboard is properly connected
and configured, and the ADIM
application is running.
Allegiant
ADIM
Keyboard
Control
Figure 7.1
Monitor
^ Up
•
•
•
Device
Lockout
Alarm
Control
Camera
Control
< Left
Quad
OSD
Stop
Pause
Menu
3
4
5
6
7
8
9
7.4 Joystick Operation
When in ADIM Controls mode, the IntuiKey Joystick can be
used for the following actions:
•
•
Navigation of the Menus Screen of the DVRs (UP, DOWN,
LEFT, RIGHT).
Proportional Playback Speed (clockwise rotation for fast
forward; counterclockwise rotation for fast reverse).
7.5 Numeric Keypad Buttons
When in ADIM Controls mode, the IntuiKey Keypad buttons
perform the following functions:
•
•
Enter corresponds to the Hi-Q’s front panel OK or Select
button.
The 1, 2, 3, and 4 keypad buttons on the keyboard emulate
the Hi-Q’s front panel buttons.
7.6 Softkey Buttons
When in ADIM Controls mode, the IntuiKey softkeys perform
the appropriate action for the specific DVR.
The Exit button performs the following actions:
•
•
•
Returns the DVR to the system (makes available for
other users).
Returns the keyboard to its previous menu.
Returns the Live camera view (direct from the Allegiant) to
the present monitor.
NOTE: Details regarding the functions of the other buttons
may be found in the IntuiKey Keyboard and Philips DVR
Instruction Manuals.
The ADIM Controls menu
is used to control the Hi-Q
(DVRRT4, DVRRT4EP)
from the IntuiKey Keyboard.
7.7 Keyboard Error Handling
If the IntuiKey keyboard fails to communicate with the system,
an error message, ADIM Communication Error (along with an
audible beep) displays on the keyboard.
Zoom
1-Touch
Alarm
Alarm
Clear
2
IntuiKey Components
Frame
Advance
Alarm
List
1
Numeric Keypad
SoftKeys
ADIM Controls Menu
Play/
Search
Shot
0
If the selected camera
Program
User
Sequence Functions
is found and the DVR is
Load
ADIM
Sequence
Controls
mapped and available,
Hold
Start
pre-recorded video from
Sequence Sequence
<Previous
Next>
the present camera is
<Sequence Sequence>
<Stop
Stop>
displayed on the selected
CCTV monitor. (The
default pre-recorded time
Figure 7.2
is 1-minute.) In addition,
the Keyboard displays the ADIM Controls menu (Figure 7.3).
If the requested camera or monitor is not mapped to a DVR
(within the ADIM), the error message, Requested Device
Not Found, (along with an audible beep) is displayed on the
Keyboard.
If the camera is found, but the DVR is in use by another
operator, the error message, DVR in Use, (along with an
audible beep) is displayed on the Keyboard.
Exit
Mon
Right >
v Down
Refer to Appendix E for more information.
7.3
Prod
Zoom
Clr
7.2
User
Log Off
Command
Script
1
MUX/DVR
Press the ADIM On-Line
softkey to bring up the
Allegiant main menu. The
ADIM Controls softkey is
now displayed.
Exit
Camera
1
Exit
NOTE: If ADIM is offline, the ADIM Controls softkey will not
appear (will be blank on the IntuiKey Keyboard).
Allegiant Main
Menu
Upon pressing the ADIM
Controls softkey, the
following occurs:
Numeric
Entry Cell
Status Display
7.8 Clearing ADIM Alarms
ADIM messages (see Appendix A) will be displayed on the
assigned CCTV monitors. Ensure the keyboard is NOT in the
ADIM Controls menu. Use the IntuiKey Keyboard’s CLR to
clear ADIM Alarm messages.
Okay
Figure 7.3
17
8
TROUBLESHOOTING
Problem
Explanation / Resolution
Keyboards are not communicating with the ADIM
Software
• Ensure that a null modem serial cable is connected between the IntuiKey keyboards and the serial
hub.
• Ensure that the appropriate communications port is properly configured for the serial hub.
• Ensure that the serial hub is connected to the network switch with a straight-through Ethernet cable.
• Ensure that the ADIM software computer is connected to the network switch with a straight-through
Ethernet cable.
NOTE: If the COM port light is green (OK), this confirms the ADIM software successfully opened the
COM port. (The COM port exists and is not in use by another application.)
Pressing ADIM Controls on the IntuiKey
results in the Allegiant monitor displaying the output
of the Hi-Q’s MON A in Live mode instead of
Playback mode. (No error messages are displayed
on the Allegiant monitor.)
• Set the Hi-Q Recorder’s password to 1234.
Keyboards display ADIM Off-line
• Ensure that the ADIM software is up and running in normal operations mode.
• Verify that the RS-232 cable from the keyboard to the serial hub is connected properly.
• The keyboard may go off-line and lose communication with ADIM if excessive conducted power
disturbance is present on the system’s serial and/or ethernet interfaces. To re-establish communication,
first identify and remove the source of the disturbance, or protect the system’s serial and/or ethernet
interfaces from the disturbance, and then close and restart the ADIM PC software.
• Verify that the serial hub and ADIM PC is on the same network segment.
Error Message 100
DVR in Use is displayed on the IntuiKey keyboard
when DVR Control is pressed on the IntuiKey
keyboard
The ADIM system has found the DVR associated with the keyboard user’s request, but another user is
presently using the DVR.
• Wait for the DVR to be released by the other user.
The user has requested playback from a device (either a camera or monitor) that could not be found in
the ADIM mapping tables.
Error Message 101
• Ensure that the ADIM mapping tables are correct.
Requested Devices Not Found is displayed on the • Ensure that the DVR associated with the requested device is on-line.
IntuiKey keyboard
• Ensure that in the case of a camera not being found that the associated DVR is marked as a playback
or backup DVR.
• Ensure that in the case of a monitor not being found, the associated DVR is marked as a review DVR.
Error Message 102
ADIM Communication Error is displayed on the
IntuiKey keyboard
Communications have failed between the ADIM PC software and the IntuiKey keyboards.
• Verify that the ADIM software is still running.
• Examine the Log file in the ADIM software to determine the reason for the communications failure.
• Ensure that the keyboard is connected to the serial hub using a 9-pin null modem cable.
• Ensure that the serial hub is turned on and functioning properly (consult the manual that came with
serial hub).
• Ensure that the keyboard is connected to the same serial port as defined in the ADIM software.
• Ensure that the ADIM system has associated a valid serial port to the keyboard.
• Ensure that the ADIM software and PC is running properly.
Error Message 103
ADIM General Error is displayed on the IntuiKey
keyboard
The ADIM software wishes to gain attention of the user due to detection of an error.
• Consult the ADIM software PC and associated log file.
Error Message 104
ADIM Mode Conflict Error is displayed on the
IntuiKey keyboard
The IntuiKey keyboard and ADIM software are not synchronized.
No action is required; the keyboard and ADIM software will automatically synchronize.
18
APPENDIX A – EVENT LOGS
Monitor
Message
Likely Source
of Error Info
Primary or Review
Hi-Q Failure
DVR Error!
Primary or Review
Hi-Q Disk Array
Failure
Backup Hi-Q
Failure
Event
Log File
Component
Type
Component ID
Entry
Type
Log Message
ADIM Software
Primary or
Review Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Error
DVR Failure
DVR Error!
Hi-Q
Primary or
Review Disk
Array
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Error
Disk Array Failure
BU DVR Error
ADIM Software
Backup Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Error
Backup DVR Failure
Hi-Q
Backup Disk
Array
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Error
Disk Array Failure*
Hi-Q Disabled
Hi-Q
ADIM Software
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Indicated DVR disabled
Hi-Q Enabled
Hi-Q
ADIM Software
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Indicated DVR Enabled
Hi-Q On-line
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Indicated DVR on-line
Hi-Q Off-line
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Indicated DVR off-line
Log File Created
ADIM Software
ADIM Software
ADIM Computer,
IP Address:
XXX.XXX.XXX.XXX
Info
Log file created
Log File Opened
for Append
ADIM Software
ADIM Software
ADIM Computer,
IP Address:
XXX.XXX.XXX.XXX
Info
Log file opened for
append
Backup Hi-Q Disk
BU DVR Error
Array Failure
Less than 500 Mbytes of
free space remains on the
PC hard disk – improper
Warning
system operation may
occur if the disk is
allowed to fill up
ADIM Software
ADIM Software
ADIM Computer,
IP Address:
XXX.XXX.XXX.XXX
ADIM Software
Started
ADIM Software
ADIM Software
ADIM Computer,
IP Address:
XXX.XXX.XXX.XXX
Info
ADIM Software started
Manual Event
ADIM Software
User
User Name,
User Number: XX
Info
User specified.
PC Hard Disk
Nearly Full
PC Disk Low
Hi-Q Hi-Temp
Warning
DVR Hi Temp
Hi-Q
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Over-temperature
warning received from
indicated Hi-Q
Hi-Q Lo-Temp
Warning
DVR Lo Temp
Hi-Q
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Under-temperature
warning received from
indicated Hi-Q
Hi-Q Low Battery
Warning
DVR Battery
Hi-Q
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Low battery warning
received from indicated
Hi-Q
Disk Array
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Disk Array disk failure
detected – disk array
operating in degraded
mode*
Disk Array
Degraded
Disk Array!
Hi-Q
19
APPENDIX A – EVENT LOGS (…continued)
Log File
Event
Monitor
Message
Likely Source
of Error Info
Component
Type
Component ID
Entry
Type
Log Message
Allegiant On-Line
ADIM Software
Allegiant
Allegiant
Info
Allegiant went On-Line
Allegiant Off-Line
ADIM Software
Allegiant
Allegiant
Info
Allegiant went Off-Line
Hi-Q
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Voltage out of spec
warning received from
indicated Hi-Q
Hi-Q Low Power
Supply Voltage
Camera Dark
Alarm
DVR Voltage
Dark
CamXXXX
Camera Failure
Fail CamXXXX
(Video Loss Alarm)
Manual Alarm
Hi-Q
Hi-Q
Hi-Q
Camera
Camera
Hi-Q
Logical Camera #
Dark Alarm for indicated
Logical Camera on DVR
Warning
#nnnn, IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Logical Camera #
Error
Camera Sync Loss Alarm
for indicated Logical
Camera on DVR #nnnn,
IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Info
Manual Alarm for
indicated Logical Camera on
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Logical Camera #
Hi-Q
Camera
Logical Camera #
Info
Auxiliary Alarm for
indicated Logical Camera on
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
ADIM Software
Keyboard
Keyboard n
Warning
Communication errors
detected for indicated
keyboard
Hi-Q
Communication
(consecutive bad
checksums)
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Communication errors
detected for
indicated Hi-Q
Hi-Q
Communication
Lost (no Q-Ping
Response)
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
No response
from indicated Hi-Q
DVR Disk Full
Hi-Q
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Hi-Q internal disk full
Info
Recording status changed to
Disabled for indicated
Logical Camera on DVR
#nnnn, IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Auxiliary Alarm
Keyboard
Communication
(consecutive bad
checksums)
Recording Status
Change 1
KBD Comms
Hi-Q
Camera
Logical Camera #
20
APPENDIX A – EVENT LOGS (…continued)
Event
Monitor
Message
Likely Source
of Error Info
Recording Status
Change 2
Hi-Q
Recording Status
Change 3
Hi-Q
Recording Status
Change 4
Hi-Q
Log File
Component
Type
Camera
Component ID
Logical Camera #
Camera
Logical Camera #
Camera
Logical Camera #
Entry
Type
Log Message
Info
Recording status changed
to Continuous for
indicated Logical Camera
on DVR #nnnn,
IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Info
Recording status changed
to Continuous with
Audio for indicated
Logical Camera on
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Info
Recording status changed
to Event Only for
indicated Logical Camera
on DVR #nnnn,
IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Recording Status
Change 5
Hi-Q
Camera
Logical Camera #
Info
Recording stopped;
Encoder problem for
indicated Logical Camera
on DVR #nnnn,
IP Address:
XXX.XXX.XXX.XXX,
DVR Camera X
Hi-Q Timeout
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Timeout -Could not go On-Line
with indicated Hi-Q
Hi-Q Delayed-OK
ADIM Software
Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Info
Timeout -Could not go On-Line
with indicated Hi-Q
Disk Array
Not Found
Disk Array!
ADIM Software
Disk Array
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
Disk Array not detected
Hi-Q DVR
Switchover
Backup OK
ADIM Software
Backup Hi-Q
DVR #nnnn, IP Address
(of Backup DVR):
XXX.XXX.XXX.XXX
Info
Successful switchover from
DVR nnnn, IP Address
XXX.XXX.XXX.XXX to
indicated Backup DVR
Hi-Q DVR
Switchover
Warning
Backup OK
ADIM Software
Backup Hi-Q
DVR #nnnn, IP Address
(of Primary DVR):
XXX.XXX.XXX.XXX
Warning
Warning message to
generate monitor message
to inform operator of
switchover.
Hi-Q DVR No
Backup Warning
No Backup!
ADIM Software
Primary Hi-Q
DVR #nnnn, IP Address:
XXX.XXX.XXX.XXX
Warning
No backup DVR was
available to backup failed
DVR
Info
The backup DVR is set
available from backing up
state of DVR nnnn, IP
Address (Primary DVR)
XXX.XXX.XXX.XXX
Info
Manual Switchover from
DVR nnnn, IP Address
XXX.XXX.XXX.XXX
was selected
Hi-Q Backup
DVR made
available
ADIM Software
Backup Hi-Q
DVR #nnnn, IP Address
(of Backup DVR):
XXX.XXX.XXX.XXX
Manual Backup
Switchover
Selected
ADIM Software
ADIM
Software
ADIM Computer,
IP Address:
XXX.XXX.XXX.XXX
nnnn = logical DVR number, no leading zeros
21
APPENDIX B – TECHNICAL SPECS
ADIM Components (included):
ACCSH01:
Industrial PC: Rack-mount industrial-grade Pentium® PC,
120 MB RAM (minimum), 8 GB hard drive
(minimum),
RocketPort Serial Hub 8-Port
Operating Temperature: 0 to 40°C
Voltage: 100 - 240 Volts AC, 50 - 60 Hertz
Dimensions: 6" x 9" x 2.5"
(152 mm x 229 mm x 63.5 mm)
Weight: 2 lbs., 5 oz., (.90 KG)
including power supply
Host Interface: Ethernet 10Base-T (10 Mbps),
RJ-45
Network Addressing Supported:
MAC (Media Access Control)
IP (Internet Protocol)
Agency Approvals: FCC Part 15 Class A
UL/C-UL Listed CE Mark
Interface: Eight (8); DB9 Male, RS-232,
RS-422 or RS-485 (selectable)
CD-ROM drive, floppy drive, keyboard, mouse,
10/100BaseT- compatible (RJ-45),
keyboard/mouse rack-mount shelf, and
Windows NT® 120/220 VAC, 50/60 Hz.
Monitor:
14-inch SVGA (including rack-mount
hardware) 120/220, VAC, 50/60 Hz
LTC 8506/00: (1) 10-foot Console Cable
Ethernet Cable: (2) 25-foot Cables
ACCNM015:
(1) RS-232 Null Modem Cable, 15-foot
Wiring diagram for the Serial Port’s RS-232 connections
D9
3
2
5
4
6
1
7
8
TD
RD
SG
DTR
DSR
CD
RTS
CTS
RD
TD
SG
DTR
DSR
CD
RTS
CTS
(1) Ethernet Serial Hub
D9
2
3
5
4
6
1
7
8
Figure 1: Null Modem Wiring Diagram
22
APPENDIX C – RECOMMENDED NETWORK SWITCHES
Approved and tested network switches for use with ADIM.
•
3Com SuperStack 4300 model
APPENDIX D – LIST OF COMPATIBLE DVRS
•
Hi-Q Series (DVRRT4, DVRRT4EP)
APPENDIX E – PRIMARY, BACKUP, AND REVIEW DVRS
Primary:
DVRs on the input of the Allegiant
Backup:
DVRs used on the output of the Allegiant. When ADIM determines a problem with a Primary DVR, the cameras designated for that
Primary DVR are switched over to the Backup DVR for recording.
Review:
DVRs used on the output of the Allegiant. These DVRs are used to record all video from a switched output of the Allegiant. The
Review DVRs are useful when reviewing an incident/suspect that involved multiple cameras being switched to a specified Monitor. It
is also useful to review alarm / event video from the output of the Allegiant.
Using the Keyboard to Playback Video from the Review DVR:
1. Select the Monitor you wish to review
2. Select camera number that corresponds to the Hi-Q’s MON A output that is connected to the Allegiant Input. (In Figure
below this would be camera number 29)
MO
NA
29
4
3
2
1
Input
•
Monitor Outputs
ALLEGIANT Video Matrix
10 11 12 13
23
PHILIPS
Windows® is a registered trademark of Microsoft Corporation.
3935 890 42712 02-39
© 2002 by Philips Electronics N.V.
© 2002 by Philips Communication, Security & Imaging, Inc.
All Rights Reserved. Philips® is a registered trademark of Philips Electronics N. A. Corp.
Updated September 25, 2002. Data subject to change without notice.
Refer to www.philipscsi.com for latest information.
Was this manual useful for you? yes no
