AJ 3040 Clock Radio IM |
-
wa.
vers
= tata te Ta
+, + Sedu
ate - i
Ny ta Tay a
eat
E 0
==. -
ne
dr 1
H
a
"т м AQ ol
+
of CD
o Y,
= 4
Г) DIGITAL
>
a
be
COMPACT CASSETTE
quer
e, Cen
a PAS
TT TRA Ma A
INDEX
(E) España
Declaración de conformidad con normas
El que suscribe, en nombre y representación de:
Consumer Electronics Factory
Philips Hong Kong Ltd.
declara, bajo su propia responsabilidad, que el
equipo: Radio reloj
fabricado por: Consumer Electronics Factory
en: Far East
marca: Philips
modelo: AJ 3040
objeto de esta declaración, cumple con la norma-
tiva siguiente: Reglamento sobre Perturbaciones
Radioeléctricas, Real Decreto 138/1989, Anexo V.
Hecho en: Hong Kong, 01-08-1994
Firma: e
Nombre: T.M. Siu
Cargo: Quality Manager
—
whem
English paged =
TT
a
. =
Français раде7 ©
| &
Espanol pagina 10 =
Me
Deutsch Seite 13 £
a
Nederlands pagina 16 =
В >
Italiano pagina 19 $
Portugués página22 SZ
a —
—
7
Dansk side25 E
am |
> —
=
Svenska sida28 Е
A
Ne o
Suomi sivu 31 5
wn
er a rrr fps — a WE —— — A A к = = —
D SET
time - run - al ------------ а.
@ ALARM
off - rad - buz -------- -
@HOUR —
@ RADIO ON/
slumber
E) MIN
fd
(6) SLUMEER OFF/ _Ma=—
REPEAT ALARM X
К E BAND
@ DISPLAY — ©
TUNING €
VOLUME (O)
9 Volt type 6 F 22
TE MRL i ri MARA gp EEE =
Installation Radio/Clock
BUTTONS RADIO
(1) TIME SET switch: RADIO ON
— TIME - for setting the time
— RUN - normal position
— ALARM - for setting the alarmtime
@ ALARM switch:
— OFF - alarm off
— RADIO - for waking up by radio
— BUZZER - for waking up by buzzer
@ HOUR button - for setting the hours
@ RADIO ON/SLUMBER - to switch on the radio
(©) MIN button - for setting the minutes
6 SLUMBER OFF / REPEAT ALARM button:
— To switch off alarm temporarily
— To switch off the radio
7) Clock display with ALARM- and Pivi- indicator
(not all versions)
(3) BATTERY DOOR
(3) VOLUME contro! - for adjusting the volume
ay: TUNING dial - for locating the required station
a) BAND switch - for selecting wavebands
MAINS CONNECTION
e Check if the mains voltage as shown on the
type plate on the base of the set corresponds
to your local mains supply.
If it does not, consult your dealer or service
organisation.
« As soon as you Insert the mains plug into the
wall socket, the figures on the display G will
blink. This means that you must set the correct
time.
To disconnect the set from the mans
completely, withdraw the mains plug from the
wall socket.
For users in the UK: Please follow the
instructions on page 6.
You can use this clock radio solely as a radio
e Set the TIME SET switch 1: to RUN.
e Press the RADIO ON/SLUMBER button 14) to
switch the radio on. After 59 minutes the radio
will be switched off automatically.
e Select the waveband using the BAND switch
an.
e Locate the required transmitter using the
TUNING dial (0.
e Set the volume using the VOLUME switch (o
RADIO OFF
You can switch off the radio before the slumber
time (59 minutes) has elapsed:
e Press the SLUMBER OFF/REPEAT ALARM
button (6.
Aerials
~ For FM reception there 1s an aerial wire at the
rear of the clock radio This wire must be
extended and, if necessary adjusted slightly, in
order to obtain good reception.
- The AM aeriel is built into the clock radio. To
obtain optimum reception you may have to
adjust the position of the clock radio shghtly
CLOCK
Clock display
The clock indicates the time on the display. In
case of 12-hour clock system, the PM mdicator
will hght up {on=PM, off=AM). The ALARM
indicator comes on when you switch on the
alarm.
Adjusting the time
e Set the TIME SET switch à) to TIME
e Set the correct time using the HOUR (3) and
MINUTE (5) outtons.
e Set the TIME SET switch :1: to RUN
Alarm Slumbering
SETTING THE ALARM SLUMBER
Alarmtime The clock radio has a built-in slumber function.
* Set the TIME SET switch () to ALARM.
* Set the correct alarm time using the HOUR ®
and MINUTE G) buttons.
* Set the TIME SET switch © to RUN.
ALARM ON
The clock radio can awaken you in two ways:
Wake by radio
* Make sure the volume of the radio is loud
enough to wake you.
* Set ALARM switch @ to RADIO.
* You will be awakened at the set alarm time by
the radio.
Wake by buzzer
® Set ALARM switch (2) to BUZZER.
® At the set alarm time you will be awakened by
the buzzer.
Sn
“чл
LI IF
— CI LA
“чет
ALARM OFF
You can switch off the alarm in two ways:
Switching off the alarm for nine minutes
* Press the SLUMBER OFF/REPEAT ALARM
button (9). With this switch you temporarily
switch off the alarm. After nine minutes the
alarm (radio or buzzer) will sound again. If you
press the SLUMBER OFF/REPEAT ALARM
button (6) agaín, the same will happen. If the
SLUMBER OFF/REPEAT ALARM button © is
not pressed again, the alarm will switch itself
off after 1 hour and 59 minutes. The following
day the alarm signal will sound again at the set
alarm time.
Switching off the alarm completely
* Set the ALARM switch 6) to OFF. On the
display the ALARM indicator will disappear and
the alarm will be switched off. If you wish to be
awakened the following day again, you must
reset the ALARM switch to RADIO or BUZZER
before going to sleep.
English
This function enables you to listen to the radio
before you fall asleep. You will not have to switch
off the clock radio yourself. This will take place
automatically.
SLUMBER ON
The time you listen to the radio before you fall
asleep is called the slumber time. The slumber
time is 59 minutes.
If you wish to slumber, carry out the following:
* Make sure the TIME SET switch @) is set to
RUN.
* Press the RADIO ON/SLUMBER button @
only. The display will show that you have a
slumbertime of 59 minutes.
SLUMBER OFF
You can switch off the radio before the slumber
time has elapsed:
* Press the SLUMBER OFF/REPEAT ALARM
button (6) and the clock radio is switched off.
— If the TIME SET switch © is in position TIME or
ALARM, the slumber function will not work.
— The slumber function does not affect the alarm.
EEE ss ———
Additional
ysi6U3
POWER FAILURE
— When a power failure occurs, the complete
IMPORTANT NOTES FOR USERS IN THE U.K.
clock radio will be switched off.
As soon as the power supply returns, the
numbers on the display will start to flash. This
indicates that you must set the correct time on
the clock.
You can insert a 9 Volt pack battery (type 6F22)
in the clock radio. Should there be a power
failure, the clock will continue to function. You
will not see this, however, because the battery
does not illuminate the clock display. As soon
as the power is switched on again, the display
will indicate the correct time. For clarity: Alarm,
radio and display do not work on battery.
Before inserting the battery, connect the power
plug to the wall outlet.
Place the battery in the compartment on the
bottom of the clock radio.
Replace the battery once a year. It is not
possible to say precisely how long the battery
will last. The service life depends on how often
and for how long the power supply fails. This
varies according to country and region.
Mains plug
This apparatus 15 fitted with an approved moulded 13 Amp plug. To change a fuse in this type of plug
proceed as follows:
eo Remove fuse cover and fuse.
e Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type.
e Refit the fuse cover,
If the fitted plug 1s not suitable for your socket outlets, it should be cut off and an appropriate plug
fitted in its place.
If the mains plug contains a fuse, this should have a value of 5 Amp. If a plug without a fuse 15 used,
the fuse at the distribution board should not be greater than 5 Amp.
Note: The severed plug must be disposed to avoid a possible shock hazard should it be inserted nto a
13 Amp socket elsewhere
How to connect a plug
The wires in the mains lead are coloured with the following code” blue = neutral (N), brown = hve (L).
As these colours may not correspond with the colour markings identifying the terrunals in your plug,
proceed as follows:
e Connect the blue wire to the terminal marked N or coloured blue or black.
e Connect the brown wire to the terminal marked L or coloured brown of red
e Do not connect either wire to the earth terminal in the plug, marked E (or 4) or coloured green (or
green and yellow).
MAINTENANCE
— If you do not intend to use the clock radio for a
long time, it is better to remove the plug from
the wall socket. In addition to this, it is
advisable to remove the battery from the clock
radio. This will prevent any danger of leakage
and the clock radio will not be damaged.
Fingerprints, dust and dirt on the clock radio
should be removed using a clean and damp
soft cloth or chamois leather. When cleaning do
not use any products wich contain abrasive
agents or solvents (benzine, thinner, alcohol
etc.). These might affect the housing.
Rain, dampness and extreme heat may damage
the clock radio. For this reason it should not be
placed in full sun or close to heating elements
for any period of time.
The type-plate is located on the bottom of the
clock radio.
This product complies with the radio interference
requirements of the European Community
Before replacing the plug cover, make certain that the cord grip 1s clamped over the sheath of the lead
- not simply over the two wires.
If in doubt, consult a qualified electrician.
Notes
34
Notes
35
Notes
36
Mounting the set on a shelf
* Make two mounting holes on the shelf as idicated below.
* Mount the set on the shelf with two screws.
FRONT
DA
192 mm
|.
+ 1
E
E
LO
Sn y 9
Ея —
= | 64 mm
E
=
= BASE OF THE SET Е
E
LO
LO
©
o 4 mm
^
TS
т -
L | 108mm }
Y
[XXX 3 mm
- - » Bench thickness + 20 mm Max.
37
