Philips | HSB4383/12 | User's Manual | Philips HSB4383/12 User manual

Register your product and get support at
HSB4383/12
www.philips.com/welcome
EN User manual
FR Mode d’emploi
DA Brugervejledning
IT
DE Benutzerhandbuch
NL Gebruiksaanwijzing
ES Manual del usuario
SV Användarhandbok
Manuale utente
1 Important
Safety
Important Safety Instructions
Safety-Important notes for users in
the U.K.
Notice
Recycling
2 Your DVD Home Theater System
Introduction
What’s in the box
Overview of the main unit
Overview of the remote control
3 Connect
Place the unit
Attach speakers to the main unit
Connect TV
Connect video cables
Option 1: Connect through HDMI
Option2: Connect through SCART
Option 3: Connect through
component video
Option 4: Connect through
composite video
Connect audio cables
Connect FM antenna
Connect power
5
5
5
6
7
7
9
9
9
10
11
13
13
13
13
13
14
14
14
15
15
15
16
Play discs
Use the disc menu
Select an audio language
Select a subtitle language
Sync audio output with video play
Play from USB
Play DivX video
Play MP3/WMA/picture files
Play control
Select repeat/shuffle play options
Repeat A-B (DVD/VCD/CD/
MP3/WMA)
Search forward/backward
Resume video play from last
stopped point
Play options
Display play information
Zoom in/out image
Change the audio channel
Picture view options
Start slideshow of pictures
Rotate picture
Start musical slideshow
6 Adjust settings
Prepare the remote control
Turn on
Set up wireless connection
manually
Find the correct viewing channel
Select the correct TV system
Select menu display language
Turn on Progressive Scan
Turn off progressive scan
manually
Use Philips EasyLink
17
17
17
17
18
18
18
18
22
22
22
22
22
22
22
23
23
23
23
24
24
24
25
25
26
General setup
Switch to standby mode
Audio setup
Video setup
Preference setup
7 Tune to FM radio stations
4 Get started
20
20
20
20
20
20
21
21
21
22
22
Program radio stations automatically
Program radio stations manually
Tune to a preset radio station
Set RDS clock
Show RDS information
28
28
28
28
28
29
19
19
EN
3
English
5 Play
Contents
8 Adjust volume level and sound effect
Adjust volume level
Select a sound effect
Select a preset sound effect
Select surround sound effect
Adjust treble/bass level
Mute sound
9 Other features
Connect other devices
Listen to an audio player
10 Product information
Specifications
Amplifier
Disc
Tuner (FM)
Speakers
General information
Supported disc formats
USB playability information
11 Troubleshooting
12 Appendix
30
30
30
30
30
30
30
31
31
31
32
32
32
32
32
32
33
33
33
34
36
Mount to a wall
36
What’s in the supplied mounting kit 36
What else you’ll need
36
Mount the main unit and speakers 36
4
EN
Know these safety symbols
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
English
1 Important
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specified by the manufacturer.
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fire or electric
shock, this apparatus should not be exposed to
rain or moisture and objects filled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Safety
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
k Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
EN
5
•
•
•
Install all batteries correctly, + and - as
marked on the unit.
Do not mix batteries (old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not
used for a long time.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
q This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
Safety-Important notes for users in
the U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
As these colours may not correspond with the
colour markings identifying the terminals in your
plug, proceed as follows:
• Connect the blue wire to the terminal
marked N or coloured black.
• Connect the brown wire to the terminal
marked L or coloured red.
• Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath of
the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require
consent. see Copyright Act 1956 and The
performer’s Protection Acts 1958 to 1972.
Warning
•
•
•
•
•
•
•
Never remove the casing of this unit.
Never lubricate any part of this unit.
Place this unit on a flat, hard and stable surface.
Never place this unit on other electrical equipment.
Only use this unit indoors. Keep this unit away from
water, moisture and liquid-filled objects.
Keep this unit away from direct sunlight, naked flames
or heat.
Never look into the laser beam inside the unit.
a Remove fuse cover and fuse.
b Fix new fuse which should be a BS1362 5
Amp, A.S.T.A. or BSI approved type.
c Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board should
not be greater than 5 Amp.
Note: The severed plug must be disposed off
to avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N), brown
= live (L).
6
EN
Warning
• Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall
remain readily operable.
Wall mounting of the unit should only be
performed by qualified personnel. The unit
must only be mounted on an appropriate wall
bracket and on a wall that can safely hold the
weight of the unit. Improper wall mounting
can result in severe injury or damage. Do not
attempt to wall mount the unit yourself.
This product complies with the radio
interference requirements of the European
Community.
This product complies with the requirements
of the following directives and guidelines:
2004/108/EC + 2006/95/EC
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
When you see the crossed-out wheel bin
symbol with the chemical symbol ‘Pb’, it means
that the batteries comply with the requirement
set by the directive for lead:
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The making of unauthorized copies of copyprotected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
HDMI, and HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC.
DivX, DivX Certified, and associated logos are
trademarks of DivX, Inc. and are used under
license.
EN
7
English
Notice
Official DivX® Ultra Certified product.
Plays all versions of DivX® video (including
DivX® 6) with enhanced playback of DivX®
media files and the DivX® Media Format.
Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents
issued & pending. DTS and DTS Digital
Surround are registered trademarks and the
DTS logos and Symbol are trademarks of DTS,
Inc. © 1996-2007 DTS, Inc. All Rights Reserved.
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic and the
double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Note
• This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This apparatus includes this label:
Note
• The type plate is located on the bottom of the
apparatus.
ENERGY STAR and the ENERGY STAR mark
are registered U.S. marks.
8
EN
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.Philips.com/welcome.
This DVD Home Theater System is designed
to complement your home perfectly. Enjoy the
DVD Home Theater System with multi-channel
surround sound and excellent picture quality.
Introduction
With this unit, you can:
• watch video from DVD/VCD/SVCD or
USB devices
• enjoy audio from discs or USB devices
• view pictures from discs or USB devices
• listen to FM radio
• Control EasyLink-compliant devices
through a single remote control
• Sync audio output with the video output
You can enrich sound output with these
sound effects:
• Surround sound exprience
• Preset sound modes
The unit supports these media/disc formats:
English
2 Your DVD
Home Theater
System
Recordable
ReWritable
You can play DVD discs with the following
region codes:
DVD region code
Countries
Europe
What’s in the box
Check and identify the contents of your
package:
• Main unit
• Speakers (x 2)
• Digital wireless subwoofer
• Power adapter for the main unit
• Remote control (with batteries)
• FM wire antenna
• AV cable (red/white/yellow)
• USB extension cable
• SCART adapter
• Wall mount bracket and screws (x4)
EN
9
Overview of the main unit
HSB4383
a b c d ef g h
iR
l kj
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
i
g
•
Open the disc compartment.
•
Start or pause play.
h
i Disc compartment
a SOURCE
• Select a source.
b MP3 LINK
• Jack for an external audio device.
c
k Display panel
• Display current status.
l
•
•
Turn on the unit or switch to standby
mode.
•
•
Stop play.
Erase a preset radio station.
d
e VOL -/+
• Adjust volume.
f
/
•
•
10
j Remote control sensor
EN
Skip to the previous/next title/
chapter/track.
Select a preset radio station.
USB socket.
c
a
b
w
d
/
•
•
•
For menus: navigate up/down.
Move an enlarged picture up/down.
Rotate or invert pictures.
c
e OK
• Confirms an entry or selection.
d
f
e
•
•
•
•
f
g
h
v
OPTIONS
• Access or exit the system setup menu.
u
i
j
t
k
g
INFO
• For video/audio play, display
information about the current status
or the disc.
• For pictures, display a thumbnail view
of picture files.
• For FM radio, display RDS clock.
h
/
•
s
/ ( / )
For menus, navigate left/right.
Search within a track or disc.
Move an enlarged picture left/right.
Tune to a radio station.
•
Skip to the previous/next title/
chapter/track.
Select a preset radio station.
•
Start or pause play.
•
•
Stop play.
Erase a preset radio station.
i
l
j
r
m
q
n
p
o
k TREBLE / BASS
• Selects treble or bass mode. Press
+/- to set the level for treble or bass.
l Numeric keypad
• Select a title/chapter/track directly.
• Select a preset radio station directly.
a
•
Turn on the unit or switch to standby
mode.
m AUDIO SYNC
• Access audio delay setting.
n SOUND
• Selects a predefined sound effect.
EN
11
English
b Source selection keys
• Select a source.
Overview of the remote
control
o ZOOM
• For pictures or video: zoom in/out.
p REPEAT A-B
• Repeat a specific section within a
track/disc.
q REPEAT/PROGRAM
• Selects or turns off repeat or shuffle
mode.
• Program radio stations.
r SUBTITLE
• Select DVD or DivX subtitle language.
s SURROUND
• Enable/disable Dolby Virtual Speakers
(DVS) sound effect.
t
+/• Adjust volume.
u
•
Mute or restore volume.
v MENU/BACK
• Return to the previous screen.
• For video discs: access or exit the disc
menu.
• For video discs with playback
control(PBC): turn on/off PBC.
w AUDIO
• For VCD, select stereo, mono-left or
mono-right channel.
• For DVD/DivX video, select an audio
language.
12
EN
English
3 Connect
Place the unit
1
2
3
2
Attach the left speaker to the left side of
the main unit.
3
4
Repeat step 2 to attach the right speaker.
Place the unit near to the TV.
Keep the speakers at the normal listening
ear-level and directly parallel to the
listening area.
Place the subwoofer at the corner of the
room or at least one meter away from the
TV.
Insert the supplied studs into the holes.
Note
• To avoid magnetic interference or unwanted noise,
•
•
never place this apparatus and speakers too close to
any radiation devices.
Never place this unit in an enclosed cabinet.
Install this unit near the AC outlet where the AC power
plug can be easily reached.
Attach speakers to the main
unit
1
Place the main unit on a soft and flat
surface.
• Ensure that the rear side faces
upwards.
Connect TV
Connect video cables
With this connection, you can watch video from
the unit on the TV screen.
You can select the best video connection that
your TV supports.
• Option 1: Connect through HDMI
(for a HDMI, DVI or HDCP-compliant
TV).
EN
13
•
Option 2: Connect through SCART
(for a standard TV).
Option 3: connect through
component video (for a standard TV
or Progressive Scan TV).
Option 4: connect through composite
video (CVBS) (for a standard TV).
•
•
Option 1: Connect through HDMI
Note
• This unit is HDMI CEC compatible. It enables the
connected TV/device to control each other over HDMI.
• If your TV has only a DVI connection, connect through
a HDMI/DVI adaptor. An extra audio connection is
needed to complete this connection.
Option2: Connect through SCART
TV
HDMI IN
Connect HDMI (High Definition Multimedia
Interface), DVI (Digital Visual Interface), or
HDCP (High-bandwidth Digital Contents
Protection)-compliant TVs through HDMI
for the best picture quality. This connection
transmits both video and audio signals. Through
this connection, you can watch DVDs that
contain HD (High-Definition) content.
Note
• Some TVs do not support HDMI audio transmission.
• This connection provides the best video quality.
1
Connect an HDMI cable (not supplied) to:
• the “HDMI” socket on this unit.
• the HDMI input socket on the TV.
14
EN
SCART IN
TV
1
Connect one end of the AV cable (red/
white/yellow) to the AV input sockets on
the scart adapter.
2
Connect the other end to the AV OUT
(VIDEO OUT AUDIO R/L) sockets on the
unit, then connect the SCART adapter to
the TV.
Option 3: Connect through
component video
Connect a progressive scan TV through
component video for higher quality video.
English
Connect audio cables
TV
Pr/Cr
Pb/Cb
Y
COMPONENT VIDEO IN PUT
1
TV
Connect component video cables (red/
blue/green - not supplied) to:
• the COMPONENT VIDEO OUT (Pr/
Cr Pb/Cb Y) sockets on this unit.
• the component input sockets on the
TV.
L AUDIO OUT R
1
To play sound from the TV through this
unit, connect audio cables (red/white - not
supplied) to:
• the AUX L/R sockets on this unit.
• the audio output sockets on the TV.
Connect FM antenna
Option 4: Connect through
composite video
Tip
• This unit does not support MW radio reception.
TV
1
Connect the yellow plugs of the supplied
AV cable to:
• the VIDEO OUT socket on this unit.
• the video input socket on the TV.
FM ANT
1
Connect the supplied FM antenna to the
FM ANT socket on the unit.
EN
15
Connect power
Caution
• Risk of product damage! Ensure that the power supply
•
•
1
voltage corresponds to the voltage printed on the back
or the underside of the unit.
Risk of electric shock! When you unplug the AC power,
always pull the plug from the socket. Never pull the
cord.
Before you connect the AC power, ensure you have
completed all other connections.
Connect the power plug of the main unit
to the wall outlet.
c
b
2
Connect the power plug of the digital
wireless subwoofer to the wall outlet.
16
EN
1
Press .
» The unit switches to the last selected
source.
2
Wait for automatic setup of wireless
connection between the main unit and
subwoofer.
» [PAIRING] (pairing) flashes.
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
bottom of the apparatus. Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Prepare the remote control
» If the connection succeeds, [PAIR OK]
(pair OK) is displayed and the blue
indicator on the subwoofer lights up.
» If the connection fails, [PAIR FAIL]
(pair fail) is displayed and the green
indicator on the subwoofer lights up.
» If the wireless connection fails, set up
the connection manually.
Set up wireless connection manually
1
In Normal Standby mode (see “Adjust
Settings - General Setup - [Standby
Mode]”), press and hold
on the main
unit for 3 seconds.
» [PAIRING] (pairing) flashes.
2
Press and hold PAIR on the subwoofer for
3 seconds.
» The blue and green indicators on the
subwoofer flash alternately.
Caution
• Risk of explosion! Keep batteries away from heat,
sunshine or fire. Never discard batteries in fire.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
• Risk of product damage! When the remote control is
not used for long periods, remove the batteries.
» If wireless connection succeeds, [PAIR
OK] (pair OK) is displayed and the
blue indicators on the subwoofer lights
up.
1
2
1
2
3
3
3
Turn on the main unit again.
Open the battery compartment.
Insert two R03 or AAA batteries with
correct polarity (+/-) as indicated.
Close the battery compartment.
EN
17
English
Turn on
4 Get started
•
Note
• If the wireless connection fails again, check whether
there is any conflict or strong interference (for example,
interference from other electronic devices) around
your location. After removal of the conflict or strong
interference, repeat the above procedures.
Find the correct viewing
channel
1
2
3
Press
OPTIONS.
Select menu display language
1
2
3
4
5
Press
OPTIONS.
Select [General Setup].
Select [OSD Language] and then press .
Select a setting and then press OK.
To exit the menu, press
OPTIONS.
Press DISC to switch to disc mode.
Turn on the TV and switch to the correct
video-in channel in one of the following
ways:
• Go to the lowest channel on your TV,
then press the Channel Down button
until you see the blue screen.
• Press the source button repeatedly on
the remote control of your TV.
• The video-in channel is between the lowest and highest
channels and may be called FRONT, A/V IN, VIDEO,
HDMI etc. See the TV user manual on how to select
the correct input on the TV.
Select the correct TV system
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
18
To exit the menu, press
to turn on the unit.
Tip
1
2
3
4
5
[Multi] - For TV that is compatible
with both PAL and NTSC.
Press
OPTIONS.
Turn on Progressive Scan
Progressive scan displays twice the number of
frames per seconds than interlaced scanning
(ordinary TV system). With nearly double the
number of lines, progressive scan offers higher
picture resolution and quality.
Before you turn on this feature, ensure that:
• The TV supports progressive scan
signals.
• You have connected this unit with the
TV through component video.
1
2
Select a setting and then press OK.
• [PAL] - For TV with PAL color system.
• [NTSC] - For TV with NTSC color
system.
EN
Ensure that the TV progressive scan mode
is deactivated (see the TV user manual).
3
Switch the TV to the correct viewing
channel for this unit.
4
5
6
Press DISC.
Press
OPTIONS.
Press / to select [Video Setup] in the
menu, then press .
7
Select [Progressive] > [On], then press
OK.
» A warning message is displayed.
8
To proceed, select [Ok] and press OK.
» The progressive setup is complete.
Select [Video Setup].
Select [TV Type] and then press .
Turn on the TV.
• If a blank/distorted screen is displayed, wait for 15
seconds for auto recovery or turn off progressive scan
manually.
9
Turn on the progressive scan mode on the
TV.
Turn off progressive scan manually
1
Turn off the progressive scan mode on the
TV.
2
3
Press
OPTIONS.
Press / to select [Video Setup] in the
menu, then press .
4
Select [Progressive] > [Off], then press
OK.
5
To exit the menu, press
OPTIONS.
One touch play[Auto Wakeup TV]
When you press
, this unit will wake up
from standby mode and start disc play (if a
video disc is found in the disc compartment).
At the same time, your TV will also be turned
on and be switched to the correct viewing
channel.
One touch power-off[System Standby]
When you connect this unit to devices that
support standby mode, you can use the
remote control of this unit to switch this unit
and all connected HDMI devices to standby
mode. You can also use the remote control
from any of the connected HDMI devices to
perform one-touch standby .
One touch audio play[System Audio Control]
When you connect this unit to HDMI
CEC compliant devices, the unit can switch
automatically to play audio from the
connected device.
Use Philips EasyLink
This unit supports Philips EasyLink, which
uses the HDMI CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices
that are connected through HDMI connectors
can be controlled by a single remote control.
Note
• Philips does not guarantee 100% interoperability with
all HDMI CEC devices.
1
Turn on the HDMI CEC operations on the
TV or other connected devices. See TVs/
devices manual for details.
2
You can now enjoy the following Philips
EasyLink controls.
EN
19
English
Note
5 Play
To return to the menu during play:
1
Press MENU/BACK.
Note
Note
• To see the disc menu of a VCD disc, you must turn on
• With some disc/file types, play may differ.
PlayBack Control (PBC) feature of the disc.
Select an audio language
Play discs
Caution
You can select an audio language on DVDs,
DiVx video or VCDs.
1
• Never look at the laser beam inside the unit.
• Risk of product damage! Never play discs with
•
1
2
3
4
•
accessories such as disc stabilizer rings or disc
treatment sheets.
Never put any objects other than discs into the disc
compartment.
Note
• For some DVDs, the language can only be changed
Press DISC to select the DISC source.
from the disc menu. Press MENU/BACK to access the
menu.
Press on the main set to open the disc
compartment.
Place a disc into the disc compartment and
press
.
» Ensure that the label faces outwards.
Play starts automatically.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next title/
chapter/track, press / .
If play does not start automatically:
Select a title/chapter/track and then press
.
Tip
• To play a locked DVD, enter the 4-digit parental control
password.
Use the disc menu
When you load a DVD/(S)VCD disc, a menu
may be displayed on the TV screen.
20
During disc play, press AUDIO.
» The language options appear. If the
selected audio channels is unavailable,
the default disc audio channel is used.
EN
Select a subtitle language
You can select a subtitle language on DVDs or
DivX® Ultra discs.
• During play, press SUBTITLE.
Tip
• For some DVDs, the language can only be changed
from the disc menu. Press MENU/BACK to access the
menu.
Sync audio output with video play
If the video play is slower than the audio output
(sound does not match with the pictures), you
can delay the audio output to match the video.
1
Press and hold AUDIO SYNC until
‘AUDIO SYNC XXX’ is displayed.
» ‘XXX’ denotes the delay time.
Within five seconds, press
+/- to set
the delay time for audio output.
Play DivX video
English
2
You can play DivX files copied onto a CD-R/
RW, recordable DVD or USB device.
Play from USB
1
2
Note
• Ensure that the USB device contains playable music,
pictures or video.
1
3
Connect the supplied USB extension cable
to:
• the USB device
• the
socket
Insert a disc or connect a USB device.
Select a source:
• For discs, press DISC.
• For USB devices, press USB.
Select a title to play, then press
.
• To stop play, press .
• To pause or resume play, press
.
• To change a subtitle language, press
SUBTITLE.
Note
• You can only play DivX videos rented or purchased
through the DivX registration code of this unit.
• Subtitle files with the following filename extensions (.srt,
•
.smi, .sub, .ssa, .ass) are supported but do not appear on
the file navigation menu.
The subtitle filename has to be the same as the file
name of the video.
Play MP3/WMA/picture files
You can play MP3/WMA/picture files copied
onto a CD-R/RW, recordable DVD or USB
device.
1
2
2
Press USB to select the USB source.
» A contents menu is displayed.
3
4
Select a folder, then press OK.
Select a file to play, then press
.
• To return to the main menu, press
until the ‘Previous’ folder is selected,
then press OK.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next file, press
/ .
3
4
Insert a disc or connect a USB device.
Select a source:
• For discs, press DISC.
• For USB devices, press USB.
• A contents menu is displayed.
Select a folder, then press OK.
Select a file to play, then press
.
• To return to the main menu, press
until the ‘Previous’ folder is selected,
then press OK.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next file, press
/ .
EN
21
Play control
To cancel resume mode and stop play
completely:
Select repeat/shuffle play options
1
1
During play, press REPEAT/PROGRAM
repeatedly to select a repeat option or the
shuffle play mode.
• To resume normal play, press
REPEAT/PROGRAM repeatedly until
[Repeat Off] is displayed.
In stop mode, press
Play options
Display play information
1
During play, press INFO repeatedly to
display play information.
Repeat A-B (DVD/VCD/CD/MP3/
WMA)
Zoom in/out image
1
During music or video play, press REPEAT
A-B at the start point.
1
2
Press REPEAT A-B at the end point.
» The selected section starts to play
repeatedly.
•
To cancel repeat play, press REPEAT
A-B again.
During video/picture play, press ZOOM
repeatedly to zoom in/out the image.
• When the image is zoomed in, you
can press / / / to pan through
the image.
Change the audio channel
Note
Note
• The section A and B can be set only within the same
.
• This feature is only available for VCD/DivX play.
track/title.
1
Search forward/backward
1
During play, press / ( / ) repeatedly
to select a search speed.
• To resume play at normal speed, press
.
Resume video play from last stopped
point
Note
Picture view options
Start slideshow of pictures
1
During play, press OPTIONS.
» The thumbnails of 12 pictures are
displayed.
2
Select a file, then press
to start
slideshow play.
• To go to previous or next screen
display, press / .
• This feature is only available for video play.
1
In stop mode and when the disc has not
been removed, press OK.
22
EN
During play, press AUDIO repeatedly to
select an audio channel available on the
disc:
• Mono Left
• Mono Right
• Stereo
•
To select a picture, press the cursor
buttons.
To display the selected photo only,
press OK.
English
•
Rotate picture
1
During play, press / to rotate the
picture anti-clockwise/clockwise.
Start musical slideshow
You can play MP3/WMA music files and JPEG
photo files simultaneously to create musical
slideshow. The MP3/WMA and JPEG files must
be stored on the same disc or USB device.
1
2
Play MP3/WMA music.
Navigate to the photo folder/album and
press
to start slideshow play.
» Slideshow begins and continues till the
end of the photo folder or album.
» Audio continues to play till the end of
the disc.
» To return to the menu, press MENU/
BACK.
3
4
To stop slideshow play, press
To stop music play, press
.
again.
EN
23
6 Adjust settings
1
2
3
4
Press
OPTIONS.
Select a setup page.
Select an option and then press .
Select a setting and then press OK.
• To return to the previous menu, press
.
• To exit the menu, press OPTIONS.
[EasyLink]
If this unit is connected to HDMI CEC
compliant TV/devices, all connected devices
can respond to the following commands
simultaneously:
Option
[One
Touch
Play]
[System
Standby]
General setup
On [General Setup Page], you can set the
following options:
[Disc Lock]
Set play restriction for specific discs. Before you
start, place the disc in the disc compartment
(maximum 40 discs can be locked).
• [Lock] – Restrict access to the
current disc. You need to enter a
password to unlock and play the disc.
• [Unlock] – Play all discs.
[System
Audio
Control]
[Audio
Input
Mapping]
Tip
Description
, the TV and
When you press
this unit are turned on. Disc play
starts if there is a disc in the unit.
When you press and hold
, connected HDMI CEC devices
simultaneously switch to standby.
To disable this feature, select
[Decline].
When you play audio that is
routed from the connected
devices, this unit switches to
the corresponding audio source
automatically.
To enable this feature, select [On].
Then proceed to [Audio Input
Mapping] to scan and map all the
connected devices.
When you map the audio input
correctly, this unit switches to
the audio from the played device
automatically.
• To set or change the password, go to [Preference
Setup] > [Password].
[OSD Language]
Select the preferred language for on-screen
display.
Switch to standby mode
[Standby Mode]
Set the standby mode.
• [Normal] - power consumption <4W.
• [Low Power] - power consumption
<1W. However, it requires longer time
to power up.
24
EN
Note
• You must turn on the HDMI CEC operations on the
TV/devices before you can enjoy the EasyLink controls.
See the TV/devices manual for details.
Philips does not guarantee 100%
interoperability with all HDMI CEC compliant
devices.
[Display Dim]
Turn on or off adjustment of display brightness
level.
[Screen Saver]
The screen saver protects the TV screen
damage due to prolonged exposure to a static
image.
• [On] – Enable the screen saver.
• [Off] – Disable the screen saver.
[Sleep Timer]
Switches to standby automatically after the
preset time.
• [15 mins], [30 mins], [45 mins], [60
mins] – select the count down time
before the apparatus switches to
standby.
• [Off] – disable sleep mode.
[DivX(R) VOD Code]
Display the DivX® registration code.
Tip
• Enter this DivX registration code when you rent or
purchase video from www.divx.com/vod. The DivX
videos rented or purchased through the DivX® VOD
(Video On Demand) service can be played only on the
device to which it is registered.
Audio setup
On [Audio Setup Page], you can set the
following options:
[HDMI Audio]
When you connect this apparatus and TV with
an HDMI cable, select the audio output setting
for this connection.
• [On] – the sound is output through
both your TV and this apparatus. If
the audio format on the disc is not
supported, it is downmixed to twochannel sound (Linear-PCM).
• [Off] – disable audio output from the
TV. The sound is only output through
this apparatus.
[Night Mode]
Make loud sound level softer and soft sound
level louder so that you can watch the DVD
movies at a low volume, without disturbing
others.
•
[Off] – enjoy surround sound with its
full dynamic range.
[On] – enjoy quiet viewing at night
(DVDs only).
Video setup
On [Video Setup Page], you can set the
following options:
[TV Type]
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
• [PAL] – For TV with PAL color system.
• [NTSC] – For TV with NTSC color
system.
• [Multi] – For TV that is compatible
with both PAL and NTSC.
[TV Display]
The TV format determines the aspect ratio of
display according to the type of TV you have
connected.
4:3 Pan Scan (PS)
•
•
•
4:3 Letter Box (LB)
16:9 (Wide Screen)
[4:3 Pan Scan] – For 4:3 screen TV:
full-height display with the trimmed
sides.
[4:3 Letter Box] – For 4:3 screen TV:
wide-screen display with black bars on
the top and bottom of the screen.
[16:9 Wide Screen] – For widescreen TV: display ratio 16:9.
[Progressive]
Turn on or off progressive scan mode.
[Picture Settings]
Select a predefined set of picture color settings
or customize your personal setting.
• [Standard] – original color setting.
• [Bright] – vibrant color setting.
EN
25
English
•
•
•
[Soft] – warm color setting.
[Personal] – customize the color
setting. Adjust the level of brightness,
contrast, sharpness/tint and color
saturation.
Note
• If the language you have set is not available on the disc,
the disc uses its own default language.
• For some discs, the subtitle/audio language can only be
changed from the disc menu.
• To select the languages that are not listed in the menu,
[HDMI Video] – Select the HDMI video output
resolution that is compatible with your TV
display capability.
Option
Description
[Auto]
Detect and select
the best supported
video resolution
automatically.
Select a video
resolution that is best
supported by your TV.
See your TV manual
for details.
[480p],
[576p],
[720p],
[1080i],
[1080p]
select [Others]. Then check the Language Code list at
the back of this user manual and enter the respective
4-digit language code.
[Parental]
Restricts access to discs that are unsuitable for
children. These types of discs must be recorded
with ratings.
1) Press OK.
2) Select a rating level, then press OK.
3) Press the numeric keys to enter the
password.
Note
[Closed Caption]
Turn off or on display captions.
• [On] – show the sound effects in
subtitles. Applicable only to discs with
Closed Caption information included
and the TV that supports this feature.
• [Off] – turn off closed caption.
• Rated discs above the level you set in [Parental]
require a password to be played.
• The ratings are country-dependent. To allow all discs to
play, select ‘8’.
• Some discs have ratings printed on them but are not
recorded with ratings. This function has no effect on
such discs.
Tip
Preference setup
On [Preference Page], you can set the following
options:
[Audio]
Select the preferred audio language for disc play.
[Subtitle]
Select the preferred subtitle language for disc
play.
[Disc Menu]
Select the preferred disc menu language.
26
EN
• You can set or change the password (see [Preference
Setup] > [Password]).
[PBC]
Turns on or off the content menu of VCDs/
SVCDs with PBC (playback control) feature.
• [On] - display index menu when you load
a disc for play.
• [Off] - skip the menu and start play from
the first title.
[MP3/JPEG Nav]
Select to display the folders or display all the
files.
•
[With Menu] – display the folders of MP3/
WMA files.
[Without Menu] – display all the files.
[Password]
Set or change the password for locked discs
and play restricted DVDs.
1) Press the numeric keys to enter ‘0000’ or
your last set password at [Old Password] field.
2) Enter the new password at [New
Password] field.
3) Enter the new password again at [Confirm
PWD] field.
4) Press OK to exit the menu.
Note
• If you forget the password, enter ‘0000’ before you set
a new password.
Note
• Ensure that the subtitle file has the exact same file
name as the movie file. If for example the file name of
the movie is ‘Movie.avi’, then you will need to name the
text file ‘Movie.sub’ or ‘Movie.srt’.
[Version Info]
Display the software version of this apparatus.
Tip
• This information is required when you want to find out
if a newest software version is available at the Philips
website that you may download and install on this
apparatus.
[Default]
Resets all the settings of this apparatus to
factory default, except for [Disc Lock],
[Password] and [Parental] settings.
[DivX Subtitle]
Select a character set that supports the DivX
subtitle.
[Standard] English, Irish, Danish, Estonian,
Finnish, French, German, Italian,
Portuguese, Luxembourgish,
Norwegian (Bokmål and
Nynorsk), Spanish, Swedish,
Turkish
[Central
Polish, Czech, Slovak, Albanian,
Europe]
Hungarian, Slovene, Croatian,
Serbian (Latin script), Romanian
[Cyrillic]
Belarusian, Bulgarian, Ukrainian,
Macedonian, Russian, Serbian
[Greek]
Greek
[Hebrew] Hebrew
EN
27
English
•
7 Tune to FM
radio stations
Program radio stations
manually
Note
1
Ensure that you have connected and fully
extended the supplied FM antenna.
2
3
4
Press RADIO.
Press and hold / (
/
).
When the frequency indication starts to
change, release the button.
» The FM tuner tunes to a station with
strong reception automatically.
• You can program a maximum of 20 preset radio
stations.
1
2
Program radio stations
automatically
Press REPEAT/PROGRAM to activate
programming.
3
Press / to allocate a number from
1 to 20 to this radio station, then press
REPEAT/PROGRAM to confirm.
» The preset number and the frequency
of the preset station are displayed.
4
Repeat the above steps to program other
stations.
5
Repeat steps 3-4 to tune to more stations.
To tune to a weak station:
Press / ( / ) repeatedly until you find
optimal reception.
Tune to a radio station.
Note
• To overwrite a programmed station, store another
station in its place.
Note
• You can program a maximum of 20 preset radio
stations.
1
Press / to select a preset number to
start programing.
2
Press and hold REPEAT/PROGRAM
for 2 seconds to activate automatic
programming.
» [AUTO] (auto) is displayed briefly.
» All available stations are programmed
in the order of waveband reception
strength.
» The last programed radio station is
broadcast automatically.
Tune to a preset radio station
1
Press / to select a preset number
that you want.
Tip
• You can also use the numerical keypad to select a
preset station directly.
Set RDS clock
You can use time signal broadcast together with
the RDS signal to set the clock of the apparatus
automatically.
28
EN
Tune to a RDS radio station that transmits
time signals.
» The apparatus reads the RDS time and
sets the clock automatically.
English
1
Note
• The accuracy of the transmitted time depends on the
RDS station that transmits the time signal.
Show RDS information
RDS (Radio Data System) is a service
that allows FM stations to show additional
information. If you tune to a RDS station, a RDS
icon and the station name are displayed.
When automatic programming is used, RDS
stations are programmed first.
1
2
Tune to a RDS station.
Press INFO repeatedly to scroll through
the following information (if available):
» Station name
» Program type such as [NEWS] (news(,
[SPORT] (sport), [POP M] (pop
music)...
» Frequency
EN
29
8 Adjust volume
level and sound
effect
2
Adjust volume level
1
1
During play, press
+/- to increase/
decrease the volume level.
Select a sound effect
Note
• You cannot use different sound effects at the same
time.
Select a preset sound effect
1
During play, press SOUND repeatedly to
select:
• [CLASSIC] (Concert)
• [ROCK] (Action)
• [Sports] (Gaming)
• [Lounge] (Drama)
• [Night]
Select surround sound effect
DVS (Dolby Virtual Speaker) technology
creates a highly compelling 5.1-channel listening
experience from as few as two speakers. It is an
ideal entertainment solution for locations where
space for multiple speaker setup is limited.
1
During play, press SURROUND to turn
on/off surround sound effect.
Adjust treble/bass level
1
Press TREBLE or BASS.
30
EN
Within 5 seconds, press
+/- to set the
level for high tones (treble) or low tones
(bass).
Mute sound
During play, press
sound.
to mute/unmute
English
9 Other features
Connect other devices
Listen to an audio player
You can listen to an audio player through this
unit.
1
Connect the audio player.
• For audio players with red/white
audio output sockets:
Connect a red/white audio cable (not
supplied) to the AUX IN L/R sockets
and to the audio output sockets on
the audio player.
• For audio players with headphone
sockets:
Connect a 3.5mm audio cable (not
supplied) to the MP3 LINK socket
and to the headphone socket on the
audio player.
• For audio players with optical sockets:
Connect an optical cable (not
supplied) to the OPTICAL IN socket
and to the optical output socket on
the audio player.
2
Select the AUDIO SOURCE or MP3 LINK
source.
3
Start play on the audio player.
EN
31
10 Product
information
Note
• Product information is subject to change without prior
Tuner (FM)
Tuning Range
Tuning grid
Sensitivity
- Mono, 26dB S/N Ratio
Search Selectivity
Total Harmonic Distortion
Signal to Noise Ratio
87.5 - 108MHz
50KHz
<22 dBf
>28dBf
<3%
>50dB
notice.
Speakers
Specifications
Amplifier
Rated Output Power
Frequency Response
Signal to Noise Ratio
Aux Input
2X60+120WRMS
20 -20000 Hz, ± 3dB
>67dB
500mV RMS 20kohm
Speaker Impedance
Speaker Driver,
subwoofer
Speaker Driver, woofer
Speaker Driver, tweeter
Sensitivity
- Subwoofer
- Woofer/Tweeter
Disc
Laser Type
Disc Diameter
Video Decoding
Video DAC
Signal System
Video Format
Video S/N
Audio DAC
Total Harmonic
Distortion
Frequency
Response
S/N Ratio
32
EN
Semiconductor
12cm/8cm
MPEG-1 / MPEG-2 /
DivX
12Bits
PAL / NTSC
4:3 / 16:9
>48dB
24Bits / 96kHz
<1% (1 kHz)
4Hz - 20kHz (44.1kHz)
4Hz - 22kHz (48kHz)
4Hz - 24kHz (96kHz)
>67dBA
2x8ohm+8ohm
8” subwoofer
3” woofer
19mm tweeter
>84dB/m/W ±
4dB/m/W
>82dB/m/W ±
4dB/m/W
AC power
Operation Power
Consumption
Normal Standby Power
Consumption
Low Standby Power
Consumption
Composite Video Output
Optical Input
HDMI (CEC) Output
USB Direct
Dimensions
- Main Unit (W x H x D)
220 - 230V, 50Hz
Main unit: 50W;
Subwoofer:
100W
<4W
<1W
1.0Vp-p, 75ohm
0.5Vpp ± 0.1Vpp
75ohm
1.3a
Version 2.0
260 x 140 x 95
mm
310 x 120 x 95
- Speakers
mm
- Wireless Subwoofer Box 170 x 430 x 340
mm
(W x H x D)
Weight
13 kg
- With Packing
1 kg
- Main Unit
2 x 0.8 kg
- Speaker Box
- Wireless Subwoofer Box 6 kg
•
•
•
•
Max. MP3 track number: 999.
Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
The following formats are not supported:
• Files like *.VMA, *.AAC, *.DLF, *.M3U,
• *.PLS, *.WAV
• Non-English Album/Title name
• Discs recorded in Joliet format
• MP3 Pro and MP3 with ID3 tag
USB playability information
Compatible USB devices:
• USB flash memory (USB 2.0 or
USB1.1)
• USB flash players (USB 2.0 or USB1.1)
• memory cards (requires an additional
card reader to work with this
apparatus)
•
•
•
•
•
Supported disc formats
•
•
•
•
Digital Video Discs (DVDs)
Video CDs (VCDs)
Super Video CDs (SVCDs)
Digital Video Discs + Rewritable
(DVD+RW)
• Compact Discs (CDs)
• Picture (Kodak, JPEG) files on CDR(W)
• DivX(R) disc on CD-R(W):
• DivX 3.11, 4.x and 5.x
• WMA
Supported MP3-CD formats:
• ISO 9660
• Max. title/album name: 12 characters
• Max. title number plus album: 255.
• Max. nested directory: 8 levels.
• Max. album number: 32.
•
•
•
•
•
•
•
•
Supported formats:
USB or memory file format FAT12,
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate
WMA v9 or earlier
Directory nesting up to a maximum
of 8 levels
Number of albums/ folders: maximum
99
Number of tracks/titles: maximum 999
ID3 tag v2.0 or later
File name in Unicode UTF8
(maximum length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an
album that does not contain MP3/
WMA files, and is not be shown in the
display.
Unsupported file formats are skipped.
For example, Word documents (.doc)
or MP3 files with extension .dlf are
ignored and not played.
AAC, WAV, PCM audio files
DRM protected WMA files (.wav,
.m4a, .m4p, .mp4, .aac)
WMA files in Lossless format
EN
33
English
General information
11 Troubleshooting
Caution
No picture on HDMI connection.
• Check if the HDMI cable is faulty. Replace a
new HDMI cable.
• If this happens when you change the
HDMI video resolution, select the correct
resolution until the picture appears.
• Never remove the casing of this unit.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this unit,
check the following points before requesting
service. If the problem remains unsolved, go to
the Philips web site (www.Philips.com/support).
When you contact Philips, ensure that your
unit is nearby and the model number and serial
number are available.
No power
•
Ensure that the AC cord of the unit is
connected properly.
•
Ensure that there is power at the AC
outlet.
•
As a power-saving feature, the system
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
No picture
•
Check the video connection.
•
Turn on the TV to the correct Video-In
channel.
•
Progressive scan is activated but the TV
does not support progressive scan.
USB device not supported
•
The USB device is incompatible with the
unit. Try another one.
Cannot display some files in USB device
•
The number of folders or files in the USB
device has exceeded a certain limit. This
phenomenon is not a malfunction.
•
The formats of these files are not
supported.
34
EN
No disc detected
•
Insert a disc.
•
Check if the label side of the disc faces
outwards.
•
Wait until the moisture condensation at
the lens has cleared.
•
Replace or clean the disc.
•
Use a finalized CD or correct format disc.
Black and white or distorted picture
•
The disc does not match the TV color
system standard (PAL/NTSC).
•
Sometimes a slight picture distortion may
appear. This is not a malfunction.
•
Clean the disc.
•
A distorted picture may appear during
progressive scan setup.
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
•
The aspect ratio if fixed on the loaded
DVD disc.
•
The aspect ratio may not be changed for
some TV systems.
No sound or poor sound
•
Adjust the volume.
•
Ensure that the wireless subwoofer is
connected.
Remote control does not work
•
Before you press any function button, first
select the correct source with the remote
control.
•
Reduce the distance between the remote
control and the unit.
•
Insert the battery with its polarities (+/–
signs) aligned as indicated.
•
Replace the batteries.
•
Aim the remote control directly at the
sensor on the front of the unit.
English
Disc does not play
•
Insert a readable disc and ensure that the
label side faces outwards.
•
Check the disc type, color system and
regional code. Check for any scratches or
smudges on the disc.
•
Press OPTIONS to exit the system
setup menu.
•
Disable the password for parental control
or change the rating level.
•
Moisture has condensed inside the system.
Remove the disc and leave the system
turned on for about an hour. Disconnect
and reconnect the AC power plug, and
then turn on the system again.
•
As a power-saving feature, the system
turns off automatically 15 minutes after
disc play reaches the end and no control is
operated.
Poor radio reception
•
Increase the distance between the unit and
your TV or VCR.
•
Fully extend the FM antenna.
•
Connect an outdoor FM antenna instead.
Wireless connection fails.
•
Set up wireless connection manually (see
‘Set up wireless connection manually’ on
page 16).
Unable to select Progressive Scan
•
Ensure the component video mode is set
to [YUV].
No sound on HDMI connection.
• You may not hear any sound if the
connected device is non-HDCP compliant
or only DVI-compatible.
Audio or subtitle languages cannot be set
•
The disc is not recorded with sound or
subtitles in multiple languages.
•
The audio or subtitle language setting is
prohibited on the disc.
EN
35
12 Appendix
Mount the main unit and speakers
Caution
Mount to a wall
• To find a suitable mounting location, make the
necessary physical and wireless connections.
• Mount the main unit and speakers to a solid concrete
wall or plaster board wall only!
Caution
• Risk of product damage! Always consult professional
•
personnel to safely mount the product to a wall.
Risk of injury! Ensure that no supply ducts such as gas,
water or electricity are harmed when you drill the
holes.
You can use the supplied bracket to mount the
main unit and speakers to the wall.
1
Align the bracket in the chosen location
on a wall. Use a pencil to mark the drilling
positions.
2
Drill holes as marked.
3
Secure the wall mount bracket onto the
wall with 4 supplied screws.
What’s in the supplied mounting kit
1 x wall mount bracket for the main unit and
speakers
4 x screws
What else you’ll need
•
•
•
36
Electric drill
Screwdriver
Pencil
EN
English
4
Hook the main unit and speakers in place.
EN
37
