Quick start guide
MCL707
MCD700
What’s in the Box?
You should find these items upon opening the box.
Composite Video Cable
FM and MW antenna
1
User Man
Quic
k St
art
Remote Control
2
ual
Guid
e
Quick Start Guide
MCD700 QUG_Eng-55
1
User Manual
Control Cable
2005.5.18, 2:57 PM
1 Connect the speakers to the SPEAKERS (8ohm) terminals with two speaker cables. Right speaker to "R" and
left speaker to "L", red wire to "+" and silver wire to "–".
2 For radio reception, connect the supplied MW loop antenna wires to the AM AERIAL jack.
Tip
It is unnecessary to connect the FM pigtail antenna since it
is fixed to the main unit.
3 Connect the serial port marked CONTROL CABLE at the rear of the DVD player to the same port at the
rear of the power amplifier with the supplied control cable.
the VIDEO OUTPUT jack at the rear of the DVD player to the video input jack on the TV using the
4 Connect
supplied video cable (yellow).
Tip
See the User Manual for other TV connection options.
5 Connect the power cord of the DVD system to the AC power outlet.
Speaker connection for MCL707
Speaker
(Right)
FM antenna
Speaker
(Left)
MW antenna
2
4
1
5
MCD700 QUG_Eng-55
1
3
AC power cord
2
2005.5.18, 2:57 PM
Setting up the TV
1 Press STANDBY ONB on the front panel of the DVD player or B on the remote to switch the DVD system
on and then select the disc source.
MCD700 DVD/RECEIVER/POWER AMPLIFIER
STANDBY-ON
STANDBY-ON
IR SENSOR
2 Switch on the TV set and set to the correct video-in channel until the blue Philips DVD background screen
appears on the TV.
Tip
See your TV manual for more details.
Setting TV type and preferences
1 Press SYSTEM on the remote to enter the system menu.
2 Press 1 2 on the remote to enter the 'Preference Page'. Then, select the color
system matching your TV and the preferred audio, subtitle and disc menu languages
using 1 2 3 4 and OK on the remote.
3 Press 1 2 on the remote to enter the 'General Setup Page' and select the
preferred OSD language using 1 2 3 4 and OK on the remote.
Tip
You can enter the 'Preference Page' in full stop mode only.
MCD700 QUG_Eng-55
3
2005.5.18, 2:57 PM
Loading a disc
1 Select the disc source, then press OPEN•CLOSE at the top of the DVD player or 0 on the remote.
2 Load in a DVD disc with the label side facing up.
3 A disc menu pops up.
Playback
1 Use 1 2 3 4 and OK or Numeric Keypad (0-9) on the remote to select a playback feature or item.
Tip
Refer to the User Manual for playback of other types of discs.
2 Press PRESET/ÉÅ (orÉÅ on the remote) to start playback.
Types of Discs used
on this DVD System
Type
Record
Playback
Edit
DVD+RW
DVD VIDEO
VIDEO CD
Super VCD
AUDIO CD
VIDEO CD
MP3-CD
www.philips.com
WMA
MCD700 QUG_Eng-55
2005 © Koninklijie Philips Electronics N.V.
All rights reserved.
4
2005.5.18, 2:57 PM
