Philips PET718/12, PET718/05 User manual

Philips PET718/12, PET718/05 User manual
PET714-Eng.qxd
2007.8.2
Philips Portable DVD Player PET714/718
2:48 PM
Charge your battery
Page 1
2
6 To stop playback, press 9.
1 Open the lid of the player.
2 Slide the POWER switch to ON to switch
on the DVD player.
➜ The POWER indicator turns on.
3 Press OPEN to open the disc door.
4 Remove the protective card (if any) and load a
disc with the label side facing up.
5 Close the disc door. Playback will start
automatically. If not, press 2;.
Enjoy (Disc operation)
Quick start guide
1
This portable DVD player is designed with a
built-in Ni-MH battery to supply power to the
player when you are on travel.
1 Slide the POWER switch to the OFF
position (charging of the DVD player only
possible in the power-off mode).
2 Connect the supplied power adaptor cord (or
the car adaptor) to the player and AC mains
(or the car cigarette lighter outlet) to start
charging.
➜ The CHG indicator turns red .
➜ When the battery is fully charged, the
indicator turns off.
3 Disconnect the power adaptor cord (or the
car adaptor) when the CHG indicator turns
off.
Notes:
– You can also connect the supplied power adaptor
cord (or the car adaptor) to the player and AC mains
(or the car cigarette lighter outlet) directly wherever
possible.
Note:
– Once the battery is running low (the power
indicator will flash as a prior warning), immediately
recharge it (regardless of whether you plan to use
the battery or not) in order to maximize the battery
life.
3 OPEN HERE
2
Enjoy (AV OUT)
PET714/PET718
WK731
Connecting additional equipment (TV
for example)
1 Connect the AV OUT socket on the set to the
video and audio sockets on a TV as shown
directly.
2 Switch on the TV and set to the correct
video-in channel.
➜ You can consult the owner's manual of
your TV. (If your TV does not have Audio and
Video inputs, you will need to purchase a RF
modulator. Please consult your dealer.)
White
Red
Yellow
Printed in China
