Discover your phone
b BeDJ key
Screen
Navigation
and,key
user guide and the product described. The devices are
meant to be connected to GSM/GPRS networks.
How to...
Switch phone On/Off
Press and hold ).
Enter PIN code
Enter your PIN code using
the keypad and press ,
or # to confirm.
Make a call
Enter the phone number on
the keypad and press (
to dial.
Answer a call
Press( when your phone
rings or open the phone.
* Optional, the camera is an accessory, not included in the
standard package and sold separately.
End a call
Press ) or close the
phone.
Philips continuously strives to improve its products.
Therefore, Philips reserves the rights to revise this user
guide or withdraw it at any time without prior notice.
Philips provides this user guide "as is" and does not
accept, except as required by applicable law, liability
for any error, omission or discrepancy between this
Set conversation
volume
Press the side key up or
down during the call.
Change the ringer
Long press b when in idle
mode to access the ringers
list.
mCamera*
and MMS key
)Hang up
(Pickup
and Wap key
and on/off key
Side keys
c Cancel key
Microphone
Keypad
Change the ringer
volume
Press the side key up or
down when in idle mode.
Activate a programmed
Voice command
Press and hold the
key.
Access the main menu
Press , in idle mode.
Launch WAP
Press and hold (.
Access the Contacts
Press-in idle mode.
Use the Contacts
Browse the list by pressing
+or-and press (
to call the selected name.
Access BeDJ
Press b in idle mode.
Access the Call list
Press+or
mode.
Go to previous menu
Press c.
Quickly return to idle
when browsing menus
Press and hold c.
Change the
language used
Press and hold 0, move
+ or - to select the
language and press ,.
Access a function
in the menu
Press ,, move <
or > to select a function,
then press , to enter the
sub-menu. Repeat to reach
the desired function.
( in idle
,
Events
Some events may modify the idle screen (missed call,
new message, etc.). Press , to access the
corresponding menu or long press c to go back to
the idle screen.
The carousel
A carousel is a circular loop of icons displayed on the
screen. Each icon represents a feature or operation of
your phone.
All icons don’t fit within the screen; the hidden ones
appear when scrolling< or >.
You access the main carousel by pressing , when
in idle mode. Use<(anti clockwise) or> (clockwise) and press , to select or activate a menu or an
option, or c to cancel.
Pressing+or-will alternate between two options, such as Activate/Deactivate, On/Off, Increase/
Decrease a value, etc.
Browse carousels and lists until you reach the desired
feature or option. When navigating in a list, a scroll
bar located on the right hand side of the screen shows
your actual position in the list. With the navigation
keys, you can then select or adjust all the functions of
your phone as described in the relevant chapter of this
user guide.
Table of contents
1. Getting started ............................................1
4. Text or number entry ......................... 10
Insert the SIM card ...........................................1
Switch on the phone ........................................2
Set date and time ..............................................2
Copy of the SIM phonebook ..........................2
Charge the battery ...........................................3
Main features ................................................4
Access and view the phonebook ...................4
Make a call ..........................................................4
Answer and end a call ......................................4
Change the ringer .............................................4
Activate the silent mode .................................4
Activate the vibra alert ....................................5
Read your mobile phone number .................5
Adjust the earpiece volume ............................5
Mute the microphone ......................................5
Unmute the microphone .................................5
Record a conversation .....................................5
Clear the call list ...............................................6
Clear the SMS list .............................................6
Clear the phonebook .......................................6
Quickly scroll a list ...........................................6
Menu tree .......................................................7
T9 ® Text input .............................................. 10
Basic text input ............................................... 11
Contacts ....................................................... 12
Settings ............................................................. 12
Contacts select .......................................... 12
Delete all .................................................. 12
Copy to phone .......................................... 12
Groups settings ........................................ 12
Add contacts in a phonebook ..................... 12
In the SIM phonebook ............................ 13
In the phone phonebook ......................... 13
Own numbers ......................................... 13
Emergency number ................................. 13
Fotocall: see & hear who’s calling .............. 13
Edit and manage contacts ............................ 14
In the SIM card ...................................... 14
In the phone ............................................ 14
Settings .......................................................... 16
Sounds .............................................................. 16
Silent ........................................................ 16
Ringer volume ......................................... 16
Ringer ...................................................... 16
Messages ringer ........................................ 16
2.
3.
5.
6.
i
Equaliser .................................................. 16
Key tones .................................................. 16
Sounds alerts ............................................ 16
Vibra alert ............................................... 17
Display .............................................................. 17
Animation ................................................ 17
Screen saver .............................................. 17
Backlight .................................................. 18
Wallpaper ................................................ 18
Contrast ................................................... 18
Hotkeys ............................................................ 18
Voice command .............................................. 19
Voice dial .......................................................... 19
Security ............................................................. 20
Public names ........................................... 20
Call barring ............................................. 20
Change codes ............................................ 20
PIN protection ......................................... 21
Network .......................................................... 21
GPRS attach ............................................ 21
Register again ........................................... 21
Preferred list ............................................. 21
Access settings ........................................... 22
Time and date ................................................. 22
Clock display ............................................ 22
Set date ..................................................... 23
Date format ............................................. 23
Time zone ................................................ 23
Daylight saving ........................................ 23
ii
7.
8.
Set time .................................................... 23
Language ........................................................... 23
Profiles .............................................................. 23
Messages ....................................................... 25
SMS .................................................................... 25
Send SMS ................................................ 25
Read SMS ................................................ 26
SMS settings ............................................ 27
SMS Archive ........................................... 28
E-Mail ................................................................ 28
Settings ..................................................... 28
Send mail ................................................. 30
Open mailbox .......................................... 30
SMS chat ........................................................... 33
Broadcast SMS ................................................ 33
MMS .................................................................. 33
New MMS .............................................. 34
MMS options ........................................... 34
Send MMS .............................................. 35
Receive an MMS ..................................... 35
Manage folders ........................................ 36
Settings ..................................................... 36
Mix music ..................................................... 38
How to... .......................................................... 38
Getting started ............................................... 38
Activate tracks ......................................... 38
Change track melodies and instruments 39
Change the tempo .................................... 39
Record a mix ................................................... 39
Start recording ......................................... 39
Manage the recording ............................. 40
Create your own style and mix .................. 40
From existing files ................................... 40
From scratch ............................................ 41
Save your own styles ..................................... 41
Receive a call ................................................... 41
9. Multimedia ................................................... 42
Sound album .................................................... 42
Picture album .................................................. 42
Demo mode .................................................... 43
Memory status ................................................ 43
Sound recording ............................................. 43
BeDJ .................................................................. 44
10. Games & Applications ...................... 45
Calculator ........................................................ 45
Alarm clock ..................................................... 45
Organiser ......................................................... 45
Euro converter ............................................... 46
Brick game ....................................................... 47
11. Call information .................................... 48
Call settings ..................................................... 48
Call list .............................................................. 49
Call counters .................................................. 50
12. Operator services ............................... 52
WAP ................................................................. 52
GSM strings ..................................................... 54
Make a second call ......................................... 55
DTMF tones .................................................... 55
Answer a second call .................................... 55
Answer a third call ........................................ 56
Conference call .............................................. 56
Explicit call transfer ....................................... 56
13. Taking pictures ...................................... 57
How to... .......................................................... 57
Preview mode settings ............................. 58
General principles ................................... 58
Picture shots ................................................... 58
Take a picture ......................................... 59
Use the self-timer .................................... 59
Review the pictures ................................. 60
Receive and make a call .......................... 60
Settings ............................................................. 60
Icons & symbols ............................................ 62
Precautions ....................................................... 63
Troubleshooting ........................................... 67
Philips authentic accessories ................. 70
iii
1 • Getting started
2.
Remove the battery by pressing the inner clips
one after the other, then pulling the battery from
the left handside.
3.
Remove the SIM card from its holder and place
it on its slot (be careful that the clipped corner of
the card is in the appropriate corner). Then push
the plastic clip holder, until it stops and
maintains the SIM card.
Read the safety instructions in the “Precautions” section
before use.
To use your phone, you must insert a valid SIM card
supplied by your GSM operator or retailer. The SIM
card contains your subscription, your mobile number,
and a memory in which you can store phone numbers
and messages (see “Contacts” page 12).
Insert the SIM card
1.
Press on the battery clip and slide the battery
cover downwards.
Make sure the phone is switched off before removing
the battery.
Getting started
1
4.
Replace the battery in its slot as shown below:
first place its right side against the right edge of
the phone and press until it clips.
Switch on the phone
To switch on the phone, press the ) key. Enter the
PIN code if required (i.e. the 4 to 8-digit secret code
of your SIM card). It is preconfigured and
communicated to you by your operator or retailer. To
personalise the PIN code, see “Change codes”
page 20.
If you enter a wrong PIN code 3 times, your SIM card
is blocked. To unblock it, you must request the PUK
code from your operator.
5.
Slide the battery door into its slots and replace
the battery cover by sliding it upwards.
Set date and time
As prompted by the phone at first switch on, set the
date by pressing the appropriate numeric keys (press
c to erase a number), then set the time.
For complete date and time options, see page 22.
Copy of the SIM phonebook
If at first switch you do not copy the SIM phonebook,
see page 12.
The mobile phone detects a SIM card that already
contains names and a message asks you if you want to
2
Getting started
copy your SIM phonebook onto the built-in
phonebook. Press c to cancel or , to accept.
The phone phonebook is always set as your default
phonebook. To switch back to the SIM phonebook,
see “Contacts select” page 12.
Charge the battery
Your phone is powered by a rechargeable battery. A
new battery is partially charged and an alarm will warn
you when the battery reaches low. If the battery is
completely flat, it will take 2 or 3 minutes of charging
for its icon to reappear.
You may lose all your personal settings if you remove
the battery when the phone is switched on.
1.
Once the battery and battery cover are clipped
on the phone, plug the connector of the charger
(supplied with the phone, in the box) into the
socket at the base of the phone on one end, then
plug it into a main AC power socket with easy
access to the other end.
Getting started
2.
The battery symbol indicates the state of charge:
- During charging the 4 charge indicators scroll;
each bar represents around 25% of charge and
it takes around 2.15 hours to fully recharge
your mobile phone.
- When all 4 bars are steady the battery is fully
charged and you can disconnect the charger.
Depending on the network and condition of
use, talk time goes from 2 to 4 hours and
standby time from 200 to 400 hours.
Keeping the charger plugged to the mobile when the
battery is fully charged doesn’t damage the battery.
The only way to turn off the charger is to unplug it, so
use an easily accessible AC power socket. You can
connect the charger to an IT supply (Belgium only).
3
2 • Main features
Access and view the phonebook
In idle mode, press-. Depending
on the selected phonebook (in SIM or
Contacts
in phone, see “Contacts” page 12), the
content that appears on the screen may vary.
To view the phonebook during a call, press ,and
select View Names List. Press c twice to return to
the in-call screen.
Make a call
1.
2.
In idle mode, enter the phone number using the
keypad. To correct an error, press c.
Press ( to dial the number and press ) to
hang up.
For an international call, press and hold * to enter
the "+" sign instead of the usual international prefix.
Answer and end a call
When receiving a call, the number of the caller may be
displayed. If you stored his/her number, his/her name
is displayed instead of the number.
4
1.
2.
3.
To answer the call, press (or open the phone
if the Active flip is On (see page 48).
To reject a call, press)or long press either side
key when the phone is closed. If you have
activated the Call Forward (see page 48), the call
is diverted to a number or voice mail.
To hang up, press )or close the phone.
The phone will not ring if in Silent mode (see below).
If you have selected Any Key Answer (see page 49),
you can accept a call by pressing any key (except )).
Change the ringer
Select Settings > Sounds > Ringer, press , and
move+or -to select a ringer in the list. Press
, to confirm your choice.
You can also access this function by a long press on
b when in idle mode.
Activate the silent mode
If you don’t want your phone to ring
when you receive a call, deactivate the
Silent
ringer by selecting Settings > Sounds >
Silent. Press-until the volume is set to On.
Main features
You can also mute the ringer when receiving a call by
pressing the side key down.
Activate the vibra alert
If you want your phone to vibrate when
you receive a call, activate the vibra alert
Vibra alert
by selecting Settings > Sounds > Vibra
alert, then On or Off.
Activating the vibra doesn’t mute the ringer. If you
want to both mute it and keep the vibra On, activate
the Silent mode as described above.
The vibra alert is automatically set to Off when you
plug the charger.
Read your mobile phone number
To read your own mobile phone number, presswhen in idle mode and select Own numbers > Show.
Your number is displayed if present on your SIM card.
If not, select New, then follow the instructions.
If your own number has been stored in the phonebook,
you can read it during a call. See “Access and view the
phonebook” page 4.
Main features
Adjust the earpiece volume
During a call, move the side key up or down to
increase/decrease the volume.
Mute the microphone
Mute
You can mute the microphone so that
your caller cannot hear you. During a
call, press ,, select Mute and press
,again.
Unmute the microphone
Unmute
To unmute the microphone during a
call, press,, select Unmute and
confirm by pressing,.
Record a conversation
In most countries, conversation
recording is subject to law regulation.
Record dialogue We advise you to notify the caller if you
intend to record the conversation you have with them
and only record if they agree. You should also keep any
recording private. 1 minute is the maximum
recording time available (see page 43).
5
To record a conversation during a call: press ,,
select Record dialogue and press,. Press
c,, or hang up to end the recording: an edit
window allows you to name the recording, which is
then available in Multimedia > Sound recording.
If you select Mute, then Record dialogue, only the
caller’s voice is recorded.
Clear the call list
Reset
To clear your call list, press , and
select Call Info > Call list > Reset. Press
,twice to reset the call list.
Clear the SMS list
To clear the whole messages list at once, press ,
and select Messages > SMS > Read SMS > Delete all
SMS. Press ,twice to reset the SMS list.
6
You can also delete all the SMS messages from the SMS
Archive menu. Deleting your SMS list is useful to free
memory space in order to receive new messages.
Clear the phonebook
To clear the content of your phonebook at once, press
, and select Contacts > Settings > Delete all.
Press , to reset the phonebook content.
This option only applies to the phonebook in your
phone, NOT to the SIM phonebook.
Quickly scroll a list
When browsing a list of (ringers, events, etc.), press
0 to scroll page per page instead of item by item.
Main features
3 • Menu tree
The table below describe the complete menu tree (first
to third levels) of your mobile phone, as well as the
page reference you should refer to for more
information concerning each feature or setting.
Security p20
Public names / Call barring / Change codes /
PIN protection
Network p21
GPRS attach / Register again / Preferred list
/ Access settings
Settings p16
Sounds p16
Silent / Ringer volume / Ringer / Messages
ringer / Equaliser / Key tones / Sounds alerts
/ Vibra alert
Display p17
Screen saver / Animation / Backlight /
Wallpaper
Hotkeys p18
List of available hotkeys
Voice command p19
List of available voice commands
Time and date p22
Clock display / Set date / Date format / Time
zone / Daylight saving / Set time
Language p23
List of available languages
Profiles p23
Messages p25
SMS p25
Send SMS / Read SMS / SMS settings / SMS
Archive
Voice dial p19
Menu tree
7
E-Mail p28
For each available mail box
Settings / Open mailbox / Send mail
Broadcast SMS p33
Reception / Topics / District codes
Demo mode p43
Sound recording p43
BeDJ p38
SMS chat p33
MMS p33
Send MMS / Receive an MMS / Manage
folders / Settings
Multimedia p42
Calculator p45
Alarm clock p45
Picture album p42
List of available pictures
Organiser p45
Sound album p42
List of available sounds
Euro converter p46
Memory status p43
8
Games & Applications p45
Brick game p47
Menu tree
Call information p48
Call settings p48
Active flip / Call forward / Mailboxes / Auto
redial / Any key answer / Call waiting / Caller
ID
Call list p49
Call list / Reset
Call counters p50
GSM counters / GPRS counters
Service numbers
The numbers available in this menu are
operator and subscription dependent, please
check with your operator.
WAP p52
Services +
This menu is operator and subscription dependent, please check with your operator.
Contacts p12
View names list p4
Settings p12
Contacts select / Delete all / Copy to phone
/ Groups settings
Operator services p52
Menu tree
9
4 • Text or number entry
Text can be entered in editing screens in two different
ways: by using T9 ® predictive Text Input, or basic
text input. Two other modes for numbers and
punctuation marks are also available. Icons appearing
on the screen show the active text mode.
T9 ® Text input
T9 ® predictive Text Input is an
intelligent editing mode for messages,
including a comprehensive dictionary.
Tegic Euro. Pat.
It allows you to quickly enter text. Press
App. 0842463
only once on the key corresponding to
each letter needed to spell a word:
keystrokes input are analysed and the word suggested
by T9 ® is displayed in the edit screen. If several words
are available according to the keys used, the word you
entered is highlighted: press< or > to browse
the list and to choose from those proposed by the T9 ®
built-in dictionary (see example below).
How to use it?
Alphabets and symbols represented by each key are as
follows:
2 to 9 To key in letters.
< or > To browse the list of candidate words.
,or 1 To confirm entry.
c
Short press to clear one entry, long
press to clear all text.
0
Shift from standard, to lower, to upper
case.
*
Shift from T9 ® to basic mode, to
numeric mode.
#
Shift to symbols and punctuation
mode.
Example: how to enter the word "home":
1.
2.
3.
10
Press 4 6 6 3
The screen displays the first word of a list: Good.
Press>to scroll and select Home.
Press , or 1 to confirm selection of the
word Home.
Text or number entry
Basic text input
If you wish to access the basic text input, press *.
This method requires multiple key presses to reach the
desired character: the letter "h" is the second letter on
the 4 key, so you must press it twice to enter "h".
Letters, numbers and symbols are located on each key
as follows:
Short press
1
space . , @ / : ; “ ’ ! ¡ ? ¿ # + - *
=%<>()&£$¥
Long press
1
2 abc2àäåæç
2
Press
3 def3éè∆Φ
3
the message is completed.
4 ghi4Γì
Example: how to enter the word "home":
4, 4 (GHI) 6, 6, 6 (MNO),
6 (MNO), 3, 3 (DEF). Press , when
5
jkl5Λ
6 mno6ñòö
6
7 pqrs7βΠΘΣ
7
8 tuv8üù
8
9
wxyz9øΩΞΨ
0 Shift letter case
Text or number entry
4
5
9
0
11
5 • Contacts
The Contacts menu allows you to select one of the two
available phonebooks: the one on your SIM card
(number of entries depending on capacity) or the one
in your phone (up to 299 names), which is the default
selected phonebook. When entering new names in the
menu Contacts, they will only be added to the
phonebook you have selected.
299 is the maximum number of names and events
cards, provided that other features (memos, sounds,
pictures, etc.) are not using a significant amount of the
phone’s memory.
Settings
phonebooks and if you delete it in the phone, it
remains unchanged in the SIM.
Delete all
Delete all
Copy to phone
Copy to phone
12
If you cancelled or aborted the
automatic copy of your SIM
phonebook at first switch, you can do it
manually: select Contacts > Settings >
Copy to phone.
Groups settings
Contacts select
Press , and select Contacts > Settings
> Contacts select. Press+ or - to
Contacts select select a phonebook. Contacts added to
the selected phonebook can then be copied into the
other, via the Copy to SIM or Copy to phone
options.
Your mobile phone only manages one phonebook at
a time and will ignore the information relative to the
other one e.g. if "Smith" is present in both
To delete all contacts at one. This
option only applies to the phonebook
in phone, NOT to the SIM
phonebook.
Groups settings
Allows you to manage groups, rename
them and link a specific melody and
picture to each group.
You link names to groups from the Contacts list. See
“Fotocall: see & hear who’s calling” page 13.
Add contacts in a phonebook
Contacts will be added to the selected phonebook.
Contacts
In the SIM phonebook
1.
2.
Press-when in idle mode and select <New>.
Enter the name and the number of your choice,
then the type of number allocated to the name
(Phone, Fax or Data) and press , to store this
name in your phonebook.
A number is limited to 40 digits, depending on your
SIM card. Entering international prefix, country &
area codes allows you to dial a number from any
location.
In the phone phonebook
1.
2.
3.
Press-when in idle mode and select <New>.
Enter the first, then last name (up to 20 latin
characters); one of the two fields can be empty,
but not both.
Then select the Number type. Numeric fields can
hold up to 40 digits and one "+" sign and
alphanumeric fields (e-mail and note) feature up
to 50 latin characters. Each contact can feature a
maximum of 5 numeric fields (e.g. 2 mobile
numbers, 3 work numbers, an e-mail address
and a text note).
If needed, choose the group you want this
contact to belong to.
Contacts
Own numbers
The Own numbers option that appears in each
phonebook should contain your own phone number.
If not, we advise that you enter your mobile number
as well as any other relevant information.
Although all its fields can be empty, the Own number
item cannot be deleted.
Emergency number
The emergency number will call the
emergency services number in your
SOS Call
country. In most cases, you can call this
number even if you haven’t yet entered your PIN.
In Europe the standard emergency number is 112, in
the UK it is 999.
Fotocall: see & hear who’s calling
This feature is only available when you select the
phonebook of your phone, NOT the SIM phonebook.
This feature allows you to personalize the groups
available with their own name ("Friends", "Office",
etc.), a given picture (from the Picture album) and a
given melody (from the Ringers list). You then link
one or several names to a group: when a name in that
13
group calls, it will appear along with the
corresponding picture, and the melody defined for
that group will ring.
1. Select Contacts > Settings > Groups setting.
Rename the group to be identified ("Friends",
"Kids", etc.) and select the Melody and the
Picture to be associated to this group.
2. Long press c to go back to idle, then - to
access the phonebook. Select a contact you wish
to link to this group, then choose Select group
and select the group of your choice.
Edit and manage contacts
Press-when in idle mode to access the Contacts
you have stored. To search for a given name:
2 to 9
#
14
Press the key for the letter that you
want to go to in the list (e.g. press
8 twice to access the letter
"U"). The first record starting
with this letter is selected in the
list.
In the SIM card
Choose a contact of your phonebook in the SIM card
and press , to access the following options:
• Call
• Copy to phone
• Send SMS
• Delete
• Voice dial
• Change
• Flash dial
• Send by MMS
Copy to phone will copy the content of your SIM
card into your phone. Selecting this option twice will
duplicate all the names.
In the phone
Choose a contact of your phonebook in phone and
press , to access the following options:
• Change name
• Select group
• Call
• Transmit
• Send SMS
• Delete
• Send by MMS
• Show
Select Show to access the list of all numbers or fields
saved for this contact then <New> to create a new
Or press #, enter the first
letters of the name you are
searching, and press , to jump
directly to that name.
Contacts
field for this contact. Select one of the fields and press
, to access a second set of options, which are:
Make default
Copy to SIM
card
Contacts
The first number you enter
becomes the default number: it
appears in first position in the
list and is automatically dialled
when pressing the pick-up key.
This option allows you to make
another number default.
Show
To display the details of the
selected field.
Change type
To change or to define the field
type of the selected number.
Alphanumeric fields (note and e-mail) can only be
changed or deleted.
To copy a contact of your phone
phonebook into the SIM card (it
is then always updated when
switching phonebooks or when
using another phone).
15
6 • Settings
Scroll through the list and wait to hear the selected
melody being played.
The Settings menu allows you to customise your
phone and change the settings related to each available
option (sounds, time and date, security, etc.). The
Profiles menu allows you to change several settings at
once (see page 23).
You will not hear the melody if the volume ringer is set
to Off or if the Silent mode was activated (see above).
Sounds
Silent
Silent
Allows you to set the Silence mode On
or Off. When this setting is On, all alerts
are deactivated and the vibra alert is
active.
The Silent mode also applies to key tones.
Ringer volume
Ringer volume
By default the ringer volume can be set
to Medium. Press+or-to set the
volume of your ringer from Silent to
Increasing.
Ringer
Ringer
16
Allows you to select a ringer tone. The
list also includes melodies you saved.
Messages ringer
Allows you to set an alert beep On or
Off, for each time you receive a new
Messages Ringer
message. When On, this option also
allows you to select the alert of your choice from the
ringers list.
Equaliser
This option allows you to choose from
different audio settings, also available
while a call is in progress (in this case,
scroll through the list and wait a few seconds to hear
the difference).
Equaliser
Key tones
Key tones
Allows you to set the key tones On or
Off. Even when set Off, DTMF are
played during calls (see page 55).
Sounds alerts
Allows you to set alert beeps On or Off
for the following items:
Sounds Alerts
Settings
•
•
•
•
when an event programmed in your Organiser is
due,
when there’s a Missed call,
when the Battery alert requires charging,
to manage the duration of your calls with a
Minute alert (the beep cannot be heard by the
caller).
This menu only allows you to set the alert sounds On
or Off, NOT the alerts themselves. E.g. setting the
Organiser alert Off will not prevent your phone from
displaying the Reminder screen (if you programmed
one), but the corresponding sound will not be played.
Vibra alert
Allows you to set the vibra alert On or
Off when receiving a call, when an event
Vibra alert
set in the organiser is due, when you
receive a message and when the alarm rings.
The vibra alert is always Off when you connect the
charger or the Cigarette Lighter Adapter.
Settings
Display
Animation
Allows you to set the animation of the
carousel menus On or Off. When On,
Animation
this option will also scroll texts, such a
message selected in the Read SMS menu.
Deactivating this function increases the autonomy of
your phone.
Screen saver
Allows you to set the screen saver On or
Off. When On, it will run a slide show
Screen saver
in idle mode, by using the jpeg file(s)
you have stored in your phone and selected.
Setting the Screen saver Off automatically activates
the Economy mode, i.e. the current time displayed on
a black background. This mode increases battery life.
Select the pictures of your choice, choose Start delay
and define a value, then choose Display period for the
timing. Press ,to activate the screen saver.
When in idle mode, the screen saver will start
according to the time limit you have set and the
timing you have set will be applied between each
picture of the slideshow.
17
You must select several pictures (up to 10) in order to
display a slide show. When selecting only one picture
to be used as screen saver, only this picture will be
displayed.
Backlight
Allows you to set a backlight Duration
by selecting one of the available values.
Backlight
Backlight is activated when receiving
incoming calls or messages, browsing menus, etc.
Deactivating this function increases battery life.
Wallpaper
Allows you to set the Wallpaper of the
main screen On or Off. When On, the
picture/s you selected is/are displayed in
Normal or Fade mode in idle mode, if you didn’t
activate a slide show.
Wallpaper
Only JPEG type pictures can be used as Wallpapers.
Contrast
Contrast
18
Allows you to choose from several levels
of contrast.
Hotkeys
Allows you to set up direct access to a
specific function by linking it to a key.
Hotkeys
A long press on the key will then
automatically activate the function or call the
associated number (Flash dial).
You can only program keys 2 to 9.
The following keys are pre-programmed: 0
(Change language), 1 (call voice mailbox) and
* (dial international call). Depending on your
service provider, other hotkeys may be predefined and
locked.
1.
2.
Select a key from 2 to 9 and press ,.
Browse the list to select the function you wish to
associate with this key and press ,. Most
choices will open the menu (e.g. Send message
or E-mail), or launch the function (such as
Calculator or Record).
If the selected key is already set, you can reprogram it:
press , twice and select Change. This will bring you
to the list of available functions.
Settings
To use the hotkeys, simply press and hold the key
corresponding to the function you want to launch or
to the number you want to dial while in idle mode.
Voice command
Voice Command
Allows you to set up direct access to a
specific function by linking it to a voice
tag.
You can associate a Voice command to most functions
supported by the Hotkeys.
1.
Select <New>, browse the list to select the
function of your choice and press ,.
2. When Press OK then speak appears, follow the
instructions displayed on the screen. When
prompted to record your voice tag, make sure
you are in a quiet environment, choose a short
and simple word and clearly pronounce it.
3. The next menu gives you access to the Delete,
Play voice tag, Change function and Change
voice options. Press c to create another voice
tag.
To use the voice command, press and hold , when
in idle mode, then say the recorded voice tag.
Settings
Voice dial
Allows you to set up a voice tag by
recording a word that will call the
Voice Dial
corresponding name when pronounced.
Proceed as described in the previous section, select the
contact of your choice in the list, then press ,.
When the phonebook in phone is selected, choose the
number of your choice in the list that is displayed.
As for Voice command, when Add voice tag? appears,
press , and follow the instructions displayed on
the screen. To use the voice dial, press and hold ,
when in idle mode, then say the voice tag
corresponding to the number you want to dial.
Up to 15 voice tags can be defined and shared between
voice dial and voice command. Recorded voice tags are
available in their respective menu and can be deleted,
played or changed.
19
Call barring
Security
Public names
Public names
Allows you to manage a specific names
list, called Public Names list, and restrict
calls to this list via the Call restriction
option.
Call
restriction
Allows you to restrict the calls to
the Public Names list. In this case,
you can only access the names of
the Public names list, as opposed to
the Contacts of the main menu.
This function is subscription
dependent and requires a PIN2
code (see page 21). This option
might also apply to WAP and
e-mail connections over GPRS.
Public names
20
Allows you to consult, edit and
modify your Public Names list. via
a PIN2 code.
Allows you to limit the use of your
phone to specific calls by letting you bar
Call barring
both outgoing and incoming calls. This
function is network dependent and requires a specific
call barring password supplied by your service
provider. Call barring can be applied both to
Incoming calls (All calls or When roaming) and to
Outgoing calls (All calls, International calls and Intl.
Exc. Home).
In all cases, the Cancel option of these menus applies to
all calls at once. The Status menu allows you to know
whether a type of call is barred or not.
Change codes
Allows you to change your PIN and
PIN 2 codes, as well as the call Barring
Change codes code. Depending on your SIM card,
some features or options may require a PIN2 secret
code, given to you by your operator.
If you enter a wrong PIN2 code 3 times, your SIM
card is blocked. To unblock it, request the PUK2 code
from your operator or retailer. If you enter an
incorrect PUK code 10 times in a row, the SIM card
Settings
will be blocked and unusable. If this happens, contact
your operator or retailer.
Always on
Your phone will always register to
the GPRS service. This option
allows faster GPRS connection.
However it will increase energy
consumption.
For data calls
Your phone will automatically
register to the GPRS service only
when required. This option
reduces energy consumption,
however it will increase the
connection delay.
PIN protection
PIN protection
This allows you to set the PIN
protection On or Off. When On, you
will be asked to enter your PIN code
when switching your phone on.
You cannot change your PIN code if this option is Off.
Network
Contact your phone operator to have full information
about GPRS availability over their network and for
an appropriate subscription. You might also need to
configure your phone with the GPRS settings supplied
by your operator, by using the menus described in this
section. Then select the bearer (GSM or GPRS) in the
menus of each application to be used (e.g. WAP,
MMS, e-mail, etc.).
GPRS attach
GPRS attach
Settings
This menu allows you to define the
attach mode of your mobile phone to
the GPRS service.
Register again
Provides you with a list of the networks
available in the area when the Manual
Register again mode is selected. Select the network you
want to register with and press , to confirm.
Preferred list
Allows you to build a network list in
order of preference. Once defined, the
Preferred list
phone will try to register on a network,
according to your preferences.
21
Access settings
GSM Settings
To change the GSM settings:
• Login,
• Password,
• Phone number needed to
establish the connection and
provided by your operator
(ISDN or Analogue),
• Inactivity time, a value of
over 30 seconds after which
the phone disconnects automatically (if a connection
was in progress)
GPRS settings
To change the GPRS settings
(same fields as the GSM settings).
The APN menu allows you to
enter the address of the external
data network you want to
connect to, a text string used to
establish the connection.
This menu allows you to create several
data profiles: when using WAP or when
Access settings sending MMS, the selected profile will
be used to connect to the GSM or GPRS network.
Options described below are operator and/or
subscription dependent. Error messages during
connections are mainly due to incorrect parameters:
contact your operator before first use, in order to have
the appropriate settings, which you may receive by
SMS in some cases. Some pre-configured profiles
might be locked, preventing re-programming and
renaming.
Select an item in the list and press , to access the
following options:
Change name
To rename the selected profile.
Show
To visualise all parameters of the
selected profile.
Time and date
Clock display
Clock display
22
Allows you to select Analogue, Digital,
Tiny or No clock time formats when
shown in idle mode.
Settings
Set date
Set date
Allows you to set the date by pressing
the appropriate numeric keys. You can
also set the date by moving
+or-.
Date format
Date format
Allows you to select one of the two
available date formats, either Western
or Thai.
Time zone
Time zone and daylight savings should be set first
(double-check date and time if previously set).
Time zone
Allows you to set the time zone you
belong to, according to GMT
(Greenwich Meridian Time).
Daylight saving
This setting only concerns countries in which time is
set according to summer/winter time (e.g. Greenwich
Meridian Time / British Summer Time).
Daylight saving
Settings
Allows you to set the daylight savings to
On (in summer time) or Off (in winter
time). If daylight saving is On and you
set the time to 12:00, it will automatically switch to
13:00 when turning the option to Off.
Set time
Set time
Allows you to set the time by pressing
the appropriate keys. You can also
increase or decrease the time minute by
minute by pressing+or-.
Language
This menu allows you to select a language for all menu
texts. Press+or-to select the language of your
choice, then press , to confirm.
A long press on 0 when in idle mode also displays
this menu.
Profiles
This menu allows you to access a group of predefined
settings, which let you quickly adapt your phone to
your environment by changing several settings at
once. For example, selecting Meeting will set your
ringer volume to silent, activate vibra and deactivate
the key tones (the other items are set according to the
settings you configured). When your meeting is over,
selecting Personal will reactivate all your usual
settings.
23
Each
box of the table refers to the settings as
stored in the Personal menu (whether you have
changed the settings or not).
When connecting an accessory, the settings Headset
and Activate car also become available. When
disconnecting the accessory, the phone goes back to
the Personal profile.
When you associate a hotkey to a profile (e.g. long press
key 3activates Silence, see “Hotkeys” page 18), also
long press this key to deactivate it and go back to the
Personal settings.
The settings listed in the column Personal, in the
following table, are default settings preset during
production. As you can change them, the personal
settings in your phone may differ from the table.
Profiles
Vibra alert
Ringer volume
Key tones
Organiser alerts
Battery low alert
Message alert
Backlight
Zoom
Any key answers
Animation
24
Personal
Autonomy
On
Medium
On
On
On
On
10 sec
Off
Off
On
Off
Medium
Outdoors
Meeting
Headset
Activate Car
High
On
Silent
Off
Medium
Medium
Off
Off
On
On
Off
Settings
7 • Messages
SMS
SMS
This menu allows you to send short
messages, with sounds, animations or
pictures, as well as manage the ones you
receive.
Sending SMS isn’t available from the idle mode when
the Instant message feature is On (see page 33). In this
case, you can only access the Answer option.
You can choose from three different types of messages:
<New>
To send a new message.
Last message
To edit, modify and re-send the last
message you have sent.
Template
To select a pre-configured message,
such as Can you ring me back at this
number. including your number, if
it is the first one of the Own num.
option (see page 13).
Press , to access the next set of options, which are
the following:
Send SMS
This menu allows you to send an SMS
to a contact of your choice, whether
Send SMS
saved in your phonebook or not (in this
case, simply select <New> in the contacts list and
enter a number).
When the phonebook in phone is selected, press ,
to send the SMS to the default number, or select
another number of your choice (see “Edit and manage
contacts” page 14).
Messages
Save
To store the current message and its
associated icon and melody if any
in the Archive menu.
Send now
To send the current message.
Add sound
To attach a melody.
Add graphic
To attach a bitmap image or an
animation.
You can send up to 2 attachments of 2 different types
together with your SMS. Animations and pictures are
exclusive: if you first select an animation, then a
25
picture, only the picture will be taken into account
and vice-versa.
Some pre-defined items are supplied as standard with
your mobile phone. Personal picture and sounds that
you have stored in the relevant menus cannot be sent
when they are copyright protected.
To edit, modify and resend the SMS to
someone (you can add a picture or a
sound).
Edit SMS
Read SMS
This menu allows you to read all types
of SMS, whether sent, received, read
and/or stored. The Delete all SMS, at the
first level, allows you to delete all messages at once.
When a message is displayed, press , to access the
following options:
Read SMS
Delete
Move to
archive
26
To delete the selected message.
To store messages in the phone
memory. You can then consult them in
Messages > SMS Archive.
Moving a message to the archive list
deletes it from the read SMS list.
If a picture or a sound was attached to
the message you edit, you must first
detach it and store it in the Picture
album or in the Sound Album. Then reattach it to your message (see page 42).
Reply
To reply to the sender.
Store
graphic(s)
To save the graphics and/or animations
that were sent together with the
message.
Forward
to
To forward the selected message
(choose the recipient in the phonebook
or enter a phone number manually).
Store
number
To save the number of the sender if it is
attached to the message,
Call back
To call the sender of the message
(operator- dependent).
Messages
No.
extracted
To extract a number included in the
message itself, if this number is
included in double quotes (several
numbers can be included and
extracted),
Store
melody
To save the melody that was sent
together with the SMS.
Validity
period
This feature is subscription dependent.
SMS settings
This menu allows you to customise your
SMS via the following options:
SMS settings
SMS
centre
To select your default SMS centre. If
not available on your SIM card, you must
enter your SMS centre number.
Signature
By default, your signature is you phone
number, added at the end of your
message (which length is consequently
reduced). You can Edit the signature,
Change and Save it.
To select the length of time your
message is to be stored in your SMS
centre. This is useful when the
recipient is not connected to the
network (and thus cannot receive your
message immediately).
Reply path
Allows you to set On or Off this option,
which allows you to transmit the
number of your SMS message centre
together with the message. Your
correspondent can then reply using
your own SMS centre and not theirs.
This speeds up the rate of transmission.
This feature is subscription dependent.
Delivery
report
Allows you to set On or Off this option,
which will automatically inform you
via SMS whether your own SMS was
received or not.
This feature is subscription dependent.
Messages
27
Auto save
SMS
Allows you to set On or Off this option,
which will automatically save messages
sent in the Archive menu.
SMS Archive
This menu allows you to consult all read
messages you saved and to Delete all
SMS Archive
archived messages at once. You save a
message by activating the Auto save SMS option (see
above), or by selecting a received message, pressing
, twice and selecting Move to Archive.
E-Mail
If not included in your phone subscription, you must
subscribe to an e-mail account and have received the
settings information from your provider. In this case,
all parameters are communicated to you by your
provider and/or operator as described below and must
be entered as given. In some cases, your operator might
also be your e-mail service provider.
This menu allows you to send an receive
e-mails, with or without attachments. If
E-mail
your phone was pre-configured, the
parameters are already set and you don’t
have to change them, except for Login, Password and
28
E-mail address which are up to you when creating an
e-mail account.
To enter specific signs such as @ or %, see page 10.
Settings
Press ,, select Messages > E-mail > E-mail 1 and
press ,. Then select Settings and press , to
access the following options:
To rename E-mail 1 and E-mail 2 boxes.
Account
name
E-mail
server
An e-mail account might be predefined
and locked, preventing renaming.
To configure the settings needed to
connect to the e-mail server of your
Internet Service Provider (ISP).
In some cases, Login, Password and
E-mail address are up to you when you
subscribe to your account. Enter them
as defined. The POP3 address is used to
receive e-mails, whereas the SMTP
address is used to send e-mails.
WARNING ! For an e-mail connection via GPRS, if your
phone operator is NOT your e-mail provider, contact them
to get the correct address of the SMTP server.
Messages
This menu features advanced settings
that you shouldn’t have to change.
Advanced
If the fields of these menus are empty, or
if you encounter connection problems,
contact your ISP.
The SMPT authenticat. menu should be
Off in most European countries: your
e-mails will NOT be sent if set to On.
Contact your provider for complete
information.
Network
access
To select the type of network used
when launching a connection, and to
configure the corresponding settings.
Bearer
• GSM or GPRS: your mobile will
only use the GSM or the GPRS
network for e-mail connections.
• GPRS first: your mobile will first
try to connect to the GPRS network, then to the GSM network if
the GPRS network isn’t available.
GSM Settings
To change the GSM settings:
• Login & Password,
• Phone number (ISDN or Analogic)
needed to establish the connection
and provided by your operator,
• Auto disconnect, a value of over 30
seconds after which the phone
disconnects automatically (if a
connection was in progress).
The lack of exchanges with the network
defines the inactivity time period
leading to auto disconnection.
GPRS settings
To change the GPRS settings (same
fields as the GSM settings). The APN
menu lets you enter the address of the
external network you will connect to.
Error messages during connections are mainly due to
incorrect parameters: contact your operator if needed
before first use, in order to have the correct settings.
Selecting this option you need to have
both GSM and GPRS settings
configured.
Messages
29
Send mail
This menu allows you to send e-mails to
one or several recipients at a time,
Send mail
including with an attachment such as a
jpeg picture. Once received, your messages can be
forwarded and the attachments visualised with the
appropriate software.
Add
Media
If you exit the Send e-mail menu before sending your
e-mail or if you cancel the sending while it takes place,
the e-mail content is deleted without being stored.
Add
contacts
If you entered e-mail addresses for
contacts saved in your phonebook in
phone (see “Add contacts in a
phonebook” page 12), this menu
allows you to select the corresponding
name in the Contacts list.
After you have added contacts, select
one of them and press,
to Change the e-mail address, Remove it
from the list, or add more contacts.
If you select the phonebook "On SIM
card", an edit window will allow you to
enter an e-mail address.
30
Allows you to design your message:
enter the Subject and Text, then press
, to access the next options:
• Add sound or Add Graphics to
attach a sound or a picture to your
e-mail,
• Send now to send it to the selected
recipient(s),
• Modify to redesign your e-mail
from scratch.
You can only attach one JPEG file at a time. To learn
how to enter text, see “Text or number entry” page 10.
If you accept an incoming call while writing an
e-mail, the menu is closed and the phone goes back to
idle when you hang up.
Open mailbox
Open mailbox
This menu allows you to connect to
your mailbox and to download the
e-mail headers from the server, then to
retrieve the corresponding e-mails.
Both mailboxes feature the same settings and options.
Configuring them differently will allow you to have
two different e-mail addresses from your phone.
Messages
1.
2.
Select Open mailbox: your phone automatically
connects to the e-mail server and downloads the
list of e-mail headers if any (five at a time).
If Next (or Previous) appears at the end (or
beginning) of the list, other e-mail headers are
pending: select one of the available options and
press , to retrieve them.
An e-mail without any attachment may be
automatically displayed in the details screen.
3.
Select a header, and press ,to display the
Details. The following status icons may appear in
regards to each header:
[No
icon]
The e-mail can be downloaded.
The e-mail size is too large, it cannot
be downloaded.
The e-mail is marked to be deleted.
4.
Press , and select Get mail to download the
e-mail. Repeat this operation to download each
e-mail corresponding to each selected header.
If the e-mail is too big (over 50 KB), it is rejected and
the download is cancelled.
Messages
5.
If the e-mail you have received contains
attachments (picture, text or another e-mail),
they are characterised by a specific icon:
Contains the details of the e-mail header
(date and time, sender’s e-mail address, etc.),
press , to display these details.
The text of the e-mail itself can be viewed as
an attachment, press , to read it (no
advanced options in this case).
A text file (text only, ".txt" format) is
attached to the e-mail, press , to read it
(no advanced options in this case).
The application needed to manage this
attachment isn’t available in your phone, or
the e-mail is too large to be uploaded.
Another e-mail is attached to the one you
received (up to five e-mails can be attached
one after the other, no advanced options in
this case).
A picture is attached to this e-mail. Select it
in the list and press , twice to store it in
your phone (you can rename it if you wish).
31
You must have stored a picture before being able to
view it via the Picture album menu. See “Picture
album” page 42 for more details. If there isn’t enough
memory to store the new picture, you must delete other
items (name, event or picture) to release enough
memory to be able to save the new picture.
A picture may not be accepted by your mobile phone
if it is too large or if it doesn’t have the right file
format. When receiving a picture via e-mail, proceed
as follows to obtain optimal results:
• The picture received must have been saved in
JPEG, BMP or GIF format.
• The size of the picture file should not exceed
50 KB.
• The optimal size is 128 x 160 pixels, in order to
be displayed correctly (use a standard picture
editing software to create the size of the picture
you want).
• Use a file name, a maximum of 10 characters.
You can then add an extension such as ".jpg".
32
6.
Select an e-mail header and press , to access
the following options:
Add to
contacts
To add the sender’s e-mail address to
your phonebook, even when you
haven’t yet downloaded his e-mail.
Select <New> to create a new contact,
or a name in the list to add or change
the e-mail address.
You must have selected the phonebook
in the phone in this case; this menu
item will NOT appear if you selected
the SIM phonebook.
Delete
To mark the e-mail to be deleted (select
this option again to unmark it). When
you exit the E-mail menu, you will be
asked to confirm deletion of the
selected item(s) from the e-mail server
Reply
To reply to the sender, which address is
automatically added to the list. Proceed
as described in “Send mail” page 30.
Forward
To forward the downloaded e-mail to
someone else. Proceed as described in
“Send mail” page 30.
Messages
Broadcast SMS
District
codes
The Broadcast SMS feature is network dependent.
This menu allows
reception of SMS
Broadcast SMS transmitted to all
network. It gives
following options:
you to manage the
broadcast regularly
subscribers on the
you access to the
Reception
To set the reception of cell broadcast
messages On or Off.
Topics
To define the type of messages you
want to receive.
• Select <New>, enter the code provided by the operator, and, if
desired, associate a name, or
• Select an existing type in the list,
which you can change or delete.
You can enter up to 15 different types
in the list. To obtain the codes
corresponding to the different types,
contact your operator.
Messages
To select the type of messages you want
to be permanently displayed on the idle
screen (in this case, enter the type in
both District code and Topics menus).
SMS chat
This menu allows you to set the SMS
chat feature On or Off. When On, any
SMS Chat
short message (SMS) you receive is
automatically displayed in idle mode.
Scroll down to read it, and quickly reply by pressing
, twice: first to enter the edition screen, then to
send your message. The phone will automatically go
back to the idle screen.
If you receive a second SMS while you are reading one,
press c to exit the first one or reply to it. The
mobile phone will then display the second message.
MMS
This menu allows you to send and
receive multimedia messages, called
MMS
MMS, featuring texts, pictures and
sounds. They can be made of one or several slides.
Whether you send it to an e-mail address or to another
mobile phone, the MMS is played in a slide show.
33
If "Memory full" appears, you must delete messages
(e.g. template, draft, received message, etc.).
Although the picture preview when creating the MMS
is (W)105 x (H)55 pixels, the maximum size of a
picture you can send is (W)640 x (H)640 pixels.
New MMS
Copyright protected picture cannot be sent.
Add
contacts
Add
Media
34
To select a name in the Contacts list, or
to insert a <New> number or e-mail
address. Then select one of the
numbers or address of that name if
several. Select a contact and press ,
to Edit it or Remove it from the list, or
add more contacts.
Sounds can be chosen from the Sound Album, or a
sound memo that you record when creating the
MMS: in this case, select <Records>, then <New> and
follow the procedure that appears on the screen.
You must have selected the phonebook
"In phone" to access an e-mail address
(see “Settings” page 12).
The following options are available:
Allows you to design your message:
1. Add a Picture, Text and/or a Sound
(move+or -to go to next or
previous icon if not automatically
selected, press , to access the
corresponding menu), and create
more slides by pressing >.
2. Send now to send the MMS to the
selected recipient(s),
3. Access the MMS Options.
You cannot attach an existing voice memo.
MMS options
Add slide
To create a new slide and add it to
your slide show. Press < or >
to browse slides once you have
created several.
You can also press>when the last
page of the message you are
currently designing is selected.
Next slide /
Previous slide
Edit subject
To move to the next/previous slide.
To edit and change or enter the
subject of your message.
Messages
Delete slide
To delete the selected page (if there
is more than one in the message).
In all cases, a progress bar allows you to follow the
sending of your message (press c to cancel).
Save MMS
as draft
To save your message as a draft, that
you can edit, complete and send
later on (see page 36).
Receive an MMS
Save
as template
To save your message as a template,
that you can use as a basis for other
MMS (e.g. "Happy birthday" type
of message, see page 36).
Preview MMS
To preview the slide show you have
created.
Slide duration
To change the value of slide
duration set in Settings > Application
settings (see page 36), and to set a
delay between each slide.
Send MMS
Once your message is complete, simply select Send
MMS and press ,. If you saved your MMS as a
draft, this option is also available from the Drafts
menu. If you have already sent the MMS, select it
from the Outbox menu and select Re-send MMS.
If the sending of a draft message fails, the message will
be moved to the Outbox menu.
Messages
If the size of the MMS to download is bigger than the
memory available in your phone, you must free
memory by deleting data (picture, sounds, etc.). See
“Memory status” page 43.
When you receive an MMS an alert message appears
on the screen to inform you. See page “Settings”
page 36 to learn about Automatic or Manual retrieval
modes.
If the sender of the message has asked for a Read
report, a prompt will ask you to press , to send it
or to press c to cancel.
Once the MMS is downloaded, select it in the Inbox
list and press > to play it. Press , to access the
following Player options:
Play
To switch back to automatic
mode: the MMS is then played
as a continuous slide show.
Next /previous
slide
To move to the next or previous
slide. You can also press < or
> when viewing the MMS in
manual mode.
35
Detach picture
To detach the picture of the
current slide and save it in the
Picture album.
Detach sound
To detach the sound of the
current slide and save it in the
Sound album.
Close
To close the MMS and go back
to the list of options.
Manage folders
Four different folders are available. The default
(active) folder is the one you last selected.
Templates
Lists all messages saved as templates.
You can Play, Edit and Delete them.
Drafts
Lists all messages saved as drafts, or
automatically saved if you quit the
MMS menu before saving or sending
your MMS. You can Play, Edit, Send
and Delete drafts.
Outbox
36
Lists the messages you have Sent or
created but Not sent yet. You can Play,
Delete or view the Details of all these
messages, Re-send or Forward them to
someone.
Inbox
Lists all the Notifications, Delivery and
Read reports, Read and Unread MMS.
You can Read or Delete notifications
and reports.
You can Play, Forward or Reply to an
MMS, display its Details or Delete it.
Notifications are automatically deleted once you have
received the full MMS. Do NOT delete notifications
before you have retrieved the MMS, or you will never
be able to do so.
Messages you have saved can only be sent from the
Draft or Outbox folders. You can NOT recover an
item (whether message, notification or report) that
you have deleted. Press c to cancel deletion.
Settings
Your phone may have been pre-configured to directly
access the services offered. If not, contact your operator
to receive the information items described in the
present section and enter them as given. With some
operators, access parameters can be set «over the air».
Messages
The following settings are available:
Retrieval
mode
Allows you to choose from:
Manual: you connect manually to the
server by selecting a notification in the
Inbox, selecting Read to downloading,
then Play.
Automatic: will place received MMS in
the Inbox. Select the MMS and
press>to play it.
This mode is deactivated when roaming.
Validity
period
To select how long your MMS will be
stored on the server, from 1 hour to 1
week (maximum). This is useful when
the recipient is not connected to the
network (and thus cannot receive your
message immediately).
Read
report
This option can be set On or Off and
informs you (via an SMS) when the
status the MMS you have sent has
changed, i.e. if it was read or deleted.
Messages
Delivery
report
This option can be set On or Off and
informs you (via an SMS) the status of
delivery, e.g. if your MMS was
received or rejected.
Auto save
This option can be set On or Off and
allows you to automatically save the
messages sent from the Outbox menu.
Slide
duration
Allows you to select the duration
between each slide of the MMS.
Network
settings
Network account is used to choose a
connection profile from the ones you
have set (see “Access settings”
page 22).
Bearer allows you to select the type of
network used when launching a
connection: GSM, GPRS or GPRS first.
Choose MMS Centre to enter the
MMS address of the server you will
connect to.
Gateway address and Gateway port will
allow you to enter both IP and Port
numbers of the server’s gateway.
37
8 • Mix music
Open the
Help screen
Press *.
With BeDJ, you can create your own sound by using
styles, or any SP-MIDI or MIDI ring tones saved in
your phone. You can then send your own mix to
friends and relatives, use it as a ringer or an alarm, etc.
Open the
Options list
Press ,.
How to...
Switch BeDJ On/
Off
Select Multimedia > BeDJ.
Press and hold c to switch
off.
Activate/deactivate
a track
Press a key from
9.
1 to
Press c to deactivate all
tracks at once.
Record the mix
(start and stop)
Press 0.
Activate the
Tempo field
Press #.
Open the track
selection list
38
Press and hold a key from
1 to 9.
Within BeDJ, the colour orange always shows the
information currently in use, or a selected item.
Getting started
Activate tracks
1.
2.
3.
4.
Launch BeDJ by selecting Multimedia > BeDJ or a
long press on b.
In the BeDJ screen that appears, the default
music style is selected (e.g. Groovy, Techno,
etc.).
In the upper left part of the screen, a small table
displays the current tempo value, the status of
the recording (Off by default) and the name of
the track.
In the bottom part of the screen, 9 tracks are
available, linked to keys 1 to 9 and which
you can mix: press the key corresponding to the
track you want to activate.
Up to 16 tracks are available: press and hold keys
Mix music
1 to 9 to open the track selection list. Key
5 is always dedicated to the voice track.
5.
The activated track appears in orange, and the
above table displays the name of the relevant
melody and instrument.
Change the tempo
1.
2.
Change track melodies and instruments
Press and hold keys 1 to 9 according to the
track you would like to change. In the list that
appears, you can change first the current melody used
by the selected track, then the instruments used in the
melody.
Melody
1.
2.
The current melody used in the selected track is
the first one highlighted in the list. Move +
or-to select another one (which is
automatically played when selected), then press
, to confirm your choice.
The name of the selected melody is displayed in
the upper part of the screen. Press > to access
the instruments list used in this melody.
Instruments
1.
2.
The current instrument used in the selected
melody is the first one highlighted in the list.
Move - or + to select the next or
previous instrument, then press , to select it.
Mix music
3.
Press # to activate the Tempo field.
The Tempo (displayed in bmp or "beats per
minute") applies to all tracks. Press the
highlighted < or > keys to increase or
decrease it.
You don’t have to save the Tempo, which is
automatically taken into account.
Press c,,or # to go back one screen.
You cannot change a Tempo while playing tracks or
during a mix recording.
Record a mix
Start recording
1.
2.
When ready to record your mix, press 0. The
timer starts and the On air red icon is selected.
While recording your mix, you can:
Press keys
1 to 9
To activate the relevant track.
Move+or -
To increase/decrease the current
track volume.
Move<or > To highlight the previous or
next track.
39
3.
Press 0 to stop recording.
The recording will stop automatically when the mix
reaches 50 KB (approximately 2 minutes). Capacity
depends on the memory available in your phone: select
Multimedia > Memory Status for memory information.
Manage the recording
As soon as you stop recording your mix, a window
automatically opens and displays the following
options for you to choose from:
in Multimedia > Sound album. You can select it as a
ringer for incoming calls and new events.
Create your own style and mix
Advanced options allow you to create and mix your
own styles of music, either directly from the BeDJ
styles available (e.g. Groove, Techno, Disco, etc.), or
from the ringers list (e.g. Bach, Cool, Dream, etc.).
The ringers list includes the MIDI files you might have
downloaded via e-mail, WAP, etc.
Remix
Allows you to record a new mix by
using the same tracks.
From existing files
Re-play
Plays the mix you just recorded.
1.
Store
Opens the Save window, for you to
name and save your mix.
2.
Send by MMS
Allows you to send your mix as part
of a multimedia message.
3.
Send by e-mail
Opens the E-Mail menu so that
you can send your mix via e-mail.
4.
The recording you save will appear under the name of
your choice in Settings > Sounds > Ringer list as well as
40
When the BeDJ screen is active, press , to
access the options list.
When selecting Mix ringers or BeDJ styles, simply
choose one of the available melodies in the list
and press , to confirm your choice.
The phone automatically goes back to the BeDJ
screen, and the melody associated to the ringer
you have selected is divided into tracks.
As described above, you can then activate and
deactivate tracks, record your mix, etc.
The number of active tracks depends on the melody
you have chosen.
Mix music
From scratch
1.
2.
3.
4.
5.
6.
When selecting Advanced, BeDJ opens a
complete new set of empty tracks.
Press and hold 1: the list of all the MIDI files
present in your phone appears on the screen.
Select one of them and press ,.
A new list appears, showing all tracks of the
selected MIDI file (max.16). Move +or to select one of them, then press , to apply it
to key 1.
Repeat these two steps to apply tracks of your
choice to keys 2 to 9 of the phone.
When ready, record your mix (see page 39).
Press , twice to go back to normal mode.
Have fun and mix: you can apply any of the 16 tracks
of any ringer of your choice to 1 to 9 key of your
Mix music
phone! This makes thousands of possibilities that allow
you to completely personalise your own mix.
Save your own styles
You can save your own Style in the BeDJ styles menu,
and reuse it later to create another mix. This new style
will contain all the tracks you have mixed, but without
the effects applied to the mix.
Receive a call
When receiving a call while BeDJ is activated, your
mobile phone will automatically mute the sound.
1. Answering the call will quit BeDJ and your
phone will return to idle when you hang up.
2. Rejecting or ignoring the call will allow you to
stay in the BeDJ screen.
41
9 • Multimedia
As SMS/
MMS ringer
To set the selected sound as
Messages ringer (this option must
be set On in Settings > Sounds, see
page 16).
Rename
To Rename the selected sound.
Sound album
This menu allows you to manage and
listen to the sounds stored in your
Sound Album mobile phone, your Own melodies,
Standard melodies or Records. When entering one
of the available sub-menus, select a sound and press
, to access the following options:
Delete
To Delete the selected sound.
Sounds in the Standard melodies
folder cannot be deleted.
Send by...
To send the selected sound via
E-mail (see page 28) or MMS (see
page 33).
You will not be able to send sounds
that are protected by a copyright.
Set as
ringer
42
To set the selected sound as Ringer.
Picture album
JPEG pictures must have the correct size and format
for your mobile phone to store and display them
correctly (see page 30).
This menu allows you to manage and
display the pictures stored in your
Picture Album mobile phone.
When entering one of the available sub-menus, the
pictures stored in your phone are displayed as a text
list. To access the graphical display, select a picture in
the list and press>. Press,to access the
following options:
Delete
To Delete the selected picture.
Rename
To Rename the selected picture.
Send by...
To send the selected picture via
E-mail (see page 28) or MMS (see
page 33).
Multimedia
Set as
wallpaper
To set the selected picture as wallpaper (this option must be set On in
Settings > Display, see page 18).
Pictures in the Standard pictures folder cannot be
deleted. New pictures are stored in Own pictures. If
there isn’t enough space to store a new picture, you
must delete some other pictures to release memory.
Demo mode
Press , to launch the Demo movie.
Demo mode
If you turned the phone on without having inserted a
SIM card, this menu is available in the first menu
level.
Memory status
This menu allows you to display the
percentage of memory available in your
Memory status phone. Several features share the mobile
capacity: pictures and sound albums, recorded memos
and voice tags for voice commands, messages you have
stored in the phone, phonebook and organiser entries,
games, etc.
Multimedia
Your mobile phone is supplied with many sounds and
pictures. You can only delete sounds or pictures in the
Picture or Sound albums, e.g. to free memory space for
your own sounds and pictures.
Press , to check the memory status. The display
shows you the percentage of memory free and the
phone’s total memory in KB. Press , again and
access the detailed list of memory used by each
feature.
If "List full" appears when saving a new item or to free
memory space, you must delete an item to be able to
create or add a new one.
Sound recording
This menu allows you to record a sound
of 1 minute maximum and up to 20
Sound recording different sounds, depending on the
Memory status.
Select <New> to record a new sound. Follow the
instructions on the screen and press , once your
sound is recorded. Select it in the list to play it, or
press , to Delete or Rename it.
Recordings saved cannot be sent by MMS.
43
BeDJ
This menu allows you to launch BeDJ:
press , (see page 38 for details).
BeDJ
44
Multimedia
10 • Games &
Applications
Calculator
Calculator
This menu provides the following
functions:
Addition
Press *.
Substraction
Press * twice.
Multiplication
Press * 3 times.
Division
Press * 4 times.
Equals
Press #.
Enter the figures using the keypad. Calculator
accuracy is to 2 decimal places and is rounded up to
the higher decimal figure. Press and hold 0 to get
the dot.
Alarm clock
Alarm clock
This menu allows you to set the alarm
clock. Enter the time, press,and
Games & Applications
select: Once, Every day or On weekdays according to
your needs. Then select one of the alarm alerts.
The alarm clock will ring even if you turned off your
phone, and even if the Ringer volume is set to Off (see
page 16). Press any key to stop the alarm ringing.
Organiser
The organiser shares the mobile capacity and memory
with other features (phonebook, picture album, sound,
etc.). To check the memory available in your phone,
select Multimedia > Memory status.
Create a new event
This menu allows to create events and
store them in your organiser. When the
organiser alert is On (see page 16), a
beep alerts you when an event is due.
1. Select the type of event to create (Holiday,
Meeting, To Do), then enter its starting and
ending date & time.
2. Name it (e.g. "Meeting with Smith"), then set a
reminder and a frequency: alerts will be triggered
at the chosen time.
Organiser
45
The reminder only applies to Meeting and To Do
events. It will be updated when changing time zones
(see “Time and date” page 22).
Delete old events
This menu allows you to delete past events. Enter the
starting date (past or future) from which all previous
events will be deleted and press ,twice to delete all
events preceding this date.
To delete all events set in your organiser, enter a
starting date several years ahead (e.g. 3rd of
December, 2010) to make sure all events preceding
this date are deleted at once.
Events views
The Day view, Week view and Month view display in
the respective format all events stored in your
organiser. To display events in these views, simply
select the view of your choice and press ,, then
move <or >to display the previous or next day,
week or month.
Note that changing time zones will impact all
organiser reminders: the event alarms will be updated
depending on the time displayed on the screen (see
“Time and date” page 22).
Euro converter
Manage events
Select an event in the list and press , to access the
following options:
Delete
To delete the selected event.
Change
To change the selected event.
Changing a repeated event will
also modify all instances of this
event.
46
-> Euro
These menus allow you to convert a
sum from or into Euros by entering the
amount and pressing ,.
The currency used for the conversion is determined by
the country where you have subscribed. The Euro
converter is available upon subscription and only in
countries using the Euro.
Games & Applications
Brick game
Destroying all bricks give you access to the next level.
Keys used are the following:
This menu can be subscription dependent. As such its
icon and content may vary.
4 and 6
To move the racket left or
right.
This menu gives you access to the brick
game, which object is to destroy the
bricks by hitting them with the ball.
* and #
To start the game by throwing the ball left or right.
0
To pause the game up to
2 minutes (after which the
screen returns to idle mode
and the game is lost).
Brick Game
Games & Applications
47
11 • Call information
Call settings
Call settings
This menu allows you to set all the call
options (call forward, waiting, etc.) and
gives you access to the menus described
hereafter:
from the call transfer, which takes place when one/
several calls are in progress.
Unconditional
Will divert all the incoming calls.
Warning! When selecting this
option, you will not receive any calls
at all until you deactivate it.
Conditional
Allows you to choose in which
circumstance(s) you want to divert
incoming calls: If no reply, If not
reachable or If busy. Each option can
be set independently.
Call forward
Status
To divert incoming calls to your mailbox or to a
number (whether in your Contacts or not) and applies
to Data calls, Voice calls and Fax calls.
Will display the status of all call
forwarding.
Mailboxes
Active flip
This option allows you to pick up an incoming call by
simply opening the phone. A beep indicates the end of
the communication when hanging up.
Before activating this option, you must enter your
voice mailboxes’ numbers (see “Mailboxes” page 48).
This feature is subscription dependent, and different
48
To enter your voice mailbox numbers (if not available
on your SIM card).
In some cases, you might have to enter two numbers:
one to listen to your mailbox, the other one to forward
calls. Contact your operator for more information on
this subject.
Call information
Auto redial
To set the auto redial On or Off. When On if the
person you are calling is busy, your phone
automatically redials this number until a successful
connection is made or until the maximum number of
attempts is reached (10). The phone beeps at the
beginning of each attempt and emits a special beep if
the connection is successful.
The time between redials increases with each attempt.
Any key answer
To accept a call by pressing any key, except )which
is used to reject a call.
Call waiting
With GSM
call
Applies to All calls, Voice calls, Fax
calls and Data calls. When this
option is active, you hear a beep if
someone tries to call you while
already on a call. Select the Status
option to find out whether the
GSM call waiting is active or not.
This function is subscription
dependent. Contact your operator.
Call information
With GPRS
call
Allows you to Activate or Deactivate
the call waiting for voice incoming
calls while a GPRS connection is
ongoing.
Caller ID
To Show or Hide your identity to your correspondent.
The Status option will inform you if this function is
activated or not.
Call list
This menu provides you with the list of
outgoing and incoming calls, attempts
Call List
at auto redialling and call details. The
calls (made, missed and received) are displayed in
chronological order with the most recent on top.
Call list
Select an item and press , to
consult the date, time, number, call
status of any selected call and to
know if it was sent or received.
Press , again to access the
options: Call this correspondent,
Send a SMS, Send by MMS, Delete the
selected call or Store the associated
number.
49
To reset the whole list at once.
Reset
If a number listed is also in your Contacts, the
corresponding name is displayed. Move+or-to
select the number to redial and press (. Press )
to hang up.
Call counters
Call counters
This menu allows you to handle the cost
and duration of your calls.
GSM counters
This menu gives you access to the options described
below.
The GSM Call Counters do not include WAP
connections. Most options mentioned below are
subscription dependent.
Total duration
To Show or Reset the time duration
of Outgoing or Incoming calls.
Last call info
To display the duration and/or cost
of your last call.
50
Info at call
end
To set On or Off the systematic
display of the length and/or cost of
each call when hanging up.
Total cost
To display the accumulated cost
and to set the counter to zero (may
be protected by PIN/PIN2 codes).
• Show will show how much has
been spent, having established
the charge rate.
• Reset allows to reset the current Total cost to 0.
• Show balance allows to check
the remaining credit (compared with previously set
limit).
• Cancel cost limit allows to cancel the cost limit.
• Cost limit lets you to enter the
cost limit used in the Show balance menu.
• Change rate allows to set or
change the rate per unit. First
enter the currency used (three
characters maximum), then
enter the cost per unit.
Call information
GPRS counters
Last PC session
This feature is subscription and network dependent.
This option will display the last connection session or
transfer volume of your PC transmission.
Last mobile session
This option will display the last connection session or
transfer volume of your mobile phone (e.g. after a
WAP connection over GPRS).
Call information
The call counters managed by your mobile phone
might differ from the ones used by your operator. You
should therefore consider the call counters displayed on
the screen as informative items, but NOT as the actual
charge rate basis.
51
12 • Operator services
Most items of this menu are subscription dependent
and specific to operators. Consequently, the menus
shown following may or may not be available.
Contact your network operator for details.
The services provided may involve making a phone
call or sending a SMS for which you may be charged.
Move + or
WAP
If your phone was preconfigured, it isn’t necessary for
you to change the settings described in this section.
With some operators, settings can be set remotely.
Select Operator Services > WAP > Homepage:
Press
(
52
and
hold
To launch WAP.
You can also select Operator
Services > WAP > Homepage
and press ,.
To browse the on-line
pages.
Press ,
To select a highlighted item.
Press c
To return to the previous
page.
Press
c
and
WAP
This menu allows you to access services
supplied with your network, such as
news, sports, weather, etc.
-
hold
To end the WAP session.
You can also select Options
> Exit and press ,.
Your mobile phone connects to the network according
to the Access settings you have defined in the menu
Settings > Network (see page 22).
Homepage
This is the link to the first WAP site you access when
launching a WAP session. In most cases, this menu
item is preconfigured and will connect to your
operator’s WAP homepage. To change this default
homepage see “Settings” page 53.
Bookmarks
This menu allows you to store your favourite WAP
site addresses, rename them and access them quickly
from the list.
Operator services
Press @ while browsing, then select Bookmarks: the
Name and URL fields will be automatically filled in
with the information of the page you are browsing.
Select Add bookmark and start entering the new name
for the edit screen to appear. Press ,, then proceed
the same way to enter the URL address.
The Manage bookmarks menu allows you to Delete
or Edit the selected bookmark.
Select
profile
All connection settings described
below apply to the selected profile.
Security
To display the list of installed
security Certificates (then display
its details or delete it), the Session
info or the Current certificate.
Rename
profile
To rename the currently selected
profile (start entering the new name
for the edit screen to appear).
Browser
options
To activate or deactivate the
downloading of images attached to
WAP pages.
Enter address
This menu allows you to enter a WAP site address, to
which you connect directly when selecting it (a quick
way to access WAP addresses without saving them as
bookmarks).
All the addresses you enter in this menu and connect
to at least once, will appear in a list. Select one of the
items and press , to reconnect to the corresponding
page, without having to re-enter its complete address.
Selecting Never will speed up the
global downloading time of the pages
browsed.
Settings
Edit
homepage
To change the Homepage name and
address.
Start entering the new name for the
edit screen to appear.
Operator services
To select one of the available
profiles, then define the connection
settings for each of them (press
</> to select / deselect).
Cache
To empty an area of the phone’s
memory where the pages browsed
during a WAP session are stored.
53
Connection
Select connection allows you to
select one of the data profiles you
have defined in Settings > Access
settings (see page 22).
Bearer allows you to select the type
of network used by the selected
profile when launching a connection
(see page 22).
Proxy address and Proxy port
allow you to define a gateway
address and port number to be used
when launching a WAP connection
using the selected profile.
Press and hold
0 to enter "."
Push inbox
This menu allows you to read and manage messages
automatically sent to you by the network and / or by
your operator. If it contains a WAP address, press
, to connect to the WAP site.
Options
While browsing, press the , key to access:
Homepage
54
Back
Brings you back to the previously
browsed page.
Forward
Takes you to the next browsed page.
Refresh
To reload the currently browsed
page from its original server.
Save as
homepage
To save the currently browsed WAP
page as the default homepage.
Save as...
To save images embedded in the
pages that are displayed in the
Picture album.
Exit
To end a WAP session.
GSM strings
The phone supports standard GSM strings that can be
used, e.g. to activate the following services:
*43#(
To activate the call
waiting.
*43#(
To activate the
feature call forward
if no reply.
To access the Homepage of the
WAP site you are browsing.
Operator services
*62#(
To activate the call
forward if not
reachable.
number is displayed at the bottom of the screen. The
second number is then dialled. You can then:
Press ,
To select Switch calls to toggle
between calls (one is put on hold and
the other one is then activated).
Press)
To hang up the active line (the call on
hold remains as such).
DTMF tones
You can send DTMF tones (or “touch tones”) to
some phone services at any time during a call by
pressing any of the keys 0 to 9, * and #.
You can also attach a DTMF sequence to a phone
number before dialling it (or storing it in the
Contacts). The phone number and the DTMF part
must be separated by a wait character.
To obtain a pause or wait character, press and hold
#. The display shows w for wait and p for pause.
For example, to hear messages (e.g. code 3) on your
answering machine (password 8421) at phone
number 12345678, you could call: 12345678w8421p3.
Answer a second call
When you receive a second call while already on the
phone, the phone emits an alert beep and the screen
displays Call waiting. You can then:
Press (
To answer the call (the first one is put
on hold). Then press , and select:
• Switch calls to toggle between
calls (one is put on hold and the
other one is then activated),
• Conference to introduce the new
caller into a conference call.
Press)
To reject the call.
Press,
To select End call to end the current
call, then answer the incoming call.
Make a second call
You can make a second call during an active call or
during a call on hold. Dial a number or select a name
in the phonebook, then press ( while already on
the phone. The first call is put on hold and the
Operator services
55
To receive a second call, you must have deactivated the
Call forward for voice calls (see page 48) and activated
the Call waiting (see page 49).
Answer a third call
While in communication and one call being on hold,
you may receive a third call. You can either end one of
the calls before being able to answer the third one or
introduce the calling party into a conference (see
below). This service is limited to two current
communications (one active and one on hold).
Conference call
You activate the conference call by
making several outgoing calls, or create
Conference
it from a multiparty call context. You
may have up to five members at the same time and
disconnected all calls at once with ).
Make a first call with someone, then a second one (see
“Make a second call” above). Press,and select
56
Conference. Repeat the process until five members are
connected.
If there is an incoming call during the conference call
and there are less than five members, you can accept
this new call and add this member to the Conference
call (if five members are already connected, you can
answer the call, but not add it to the conference).
The Conf. members options allow you to disconnect a
member of the conference by selecting Remove party,
or select Private call to have a private call with this
member only (other members are put on hold).
Explicit call transfer
You can connect an active call and a call on hold by
selecting the Transfer option. You are disconnected
when the transfer is completed.
This feature is different from the Call forward, which
takes place before you pick up the call (see page 48).
Operator services
13 • Taking pictures
The camera is an accessory, that is NOT included as
standard in the package when purchasing the phone.
Please contact you local dealer to buy a camera.
None of the settings, features or options described in
the present chapter will be available if you’re not using
a camera with your phone.
Your mobile phone supports a digital camera that allows you to take pictures, store them in your phone,
use them as wallpaper or send them to your friends
and relatives.
How to...
Activate/deactivate
the camera
Plug/unplug it into the connector as shown below.
If the camera was already
plugged, long press the m
key to reactivate it.
Zoom in/out
Press the navigation key
+or -.
Change the camera
mode
Press * to toggle between
Night and Normal mode.
Taking pictures
Change the
screen resolution
Press # to switch from
VGA to QVGA to SQVGA to
128 x 128.
Take a picture
Press m when camera
mode active.
Save the picture
Press
shot.
m right after the
Delete the picture
Press
shot.
c right after the
Access the shot
options
Press,right
shot.
Access the
camera settings
Press , when camera
mode active.
Activate/deactivate
the self-timer
Press 0.
after
the
Within any menu related to the camera, long press
c to cancel any current action and go back to idle
mode.
57
Picture shots
when the preview is displayed on the screen. You can
also press , to access any of them.
Preview mode settings
Connect the camera to display the camera preview
screen and rotate the camera up or down to get the
shot you want. The lens of the camera is automatically
focused and icons are displayed are displayed in the
bottom (Zoom, Camera mode) and on top (Selftimer, Vision).
When you plug the camera for a self-portrait, a
viewfinder allowing you to centre the shot is shown on
the external screen.
General principles
All options and key presses described in this section are
applicable only when the camera mode is active, i.e.
58
Camera mode
Two camera modes are
available: Normal and Night
mode. According to ambiant
light level, press * to
toggle between modes,
which are reflected by the
camera mode icons (sun &
moon) in the bottom of the
screen.
Picture resolution
The default picture size of
the standard format is
128 x 128. Press # to
switch to VGA (640 x 480
pixels) to Q VGA (320 x 240
pixels) or to SQ VGA
(160 x 120 pixels). The
Picture resolution you select is
displayed in the bottom right
corner of the screen.
Taking pictures
Self-timer
This option allows you to set
the Self-timer option On or
Off.
Zoom mode
This one-level zoom option
is available only in VGA
mode (640 x 480 pixels). If
you have selected this
resolution,
press
the
navigation key + or to zoom in or out.
Take a picture
1.
2.
If the self-timer option is Off, and once the
camera is activated, press mto take a picture.
The number that appears shows its row. Press
c
To ignore the picture you
have just taken and go back
to preview mode.
m
To save it in the Picture
Album.
,
To access the list of available
options: Send (by MMS, Email), Save, Modify or Take
a new picture.
Taking pictures
The number of pictures you can save varies according
to the settings: the higher the resolution is, the bigger
the file size is. A message will warn you if there isn’t
enough memory left. In this case, you must delete data
before storing a new picture.
When they are saved in the Picture album, the
pictures are named «img_1.jpg» etc. up to 999. This
does not mean you can take up to 999 pictures (see
“Review the pictures” below), but that pictures,
including the ones you delete, are numbered up to
999. Numbering will then restart from 1 on.
Use the self-timer
1.
2.
Set the self-timer option On (see above) then
press m to activate it.
The countdown starts at 5 seconds (this value
cannot be changed). A beep is played 2 seconds
before the picture is taken, then again when it’s
actually shot.
Press c to stop the timer and go back to preview
mode or press 0 to just stop the timer.
3.
Once the picture is shot, follow the instructions
starting at point 2 of the previous section.
Preview screen is not available for self-portrait. To
take a picture in self-portrait, hold the phone opened
59
at arms length with the camera and external screen
toward you, then centre your shot with the viewfinder
of the external screen, and press on the m key to take
the picture.
Settings you last define are saved and available when
reusing the camera or until you change them again.
Colour mode
Allows you to choose a mode
available from the following:
Colour, Black & white, Sepia
and Blue. The effect will be
applied to the picture
according to the mode you
chose (e.g. Sepia will take a
brown and beige picture,
giving the impression of an
old-times picture). The
default mode is Colour.
Camera mode
Allows you to choose one of
the two modes available:
Normal and Night. The
default mode is Normal.
Review the pictures
The pictures you save are automatically stored in the
Multimedia > Picture album menu. See page page 42 for
details.
Receive and make a call
When receiving a call while using the camera:
• Answering the call will quit to camera context and
your phone will return to idle when you hang up.
• Rejecting the call will also quit the camera context,
and bring you back to the preview screen.
To make a call, you must first go back to the idle
screen.
Settings
Press , while the camera mode is active to access
further settings than the ones available directly within
the preview screen.
60
Taking pictures
Sounds
Picture resolution
Taking pictures
Both Alert and Shoot sounds
can be set from this menu.
The first one occurs
2 seconds before the picture
is taken, the second one
when it’s shot.
In both cases, select On, and
press , to access the list
of available sounds. Select
one of the sounds, or <New>
to create a new sound, then
press , to activate it.
Picture quality
Allows you to choose an
image quality available
among the following: Low,
Medium, High. The default
mode is Medium.
Self-timer
See page 58.
Allows you to choose a
resolution available among
the
following:
VGA
(640 x 480 pixels), Q VGA
(320 x 240 pixels), SQ VGA
(160 x 120 pixels) and
128 x 128. The default mode
is 128 x 128.
61
Icons & symbols
In idle mode, several symbols can be displayed
simultaneously either on external screen or main inner
screen.
If the network symbol isn’t displayed, the network is
not currently available. You may be in a bad reception
area, moving to a different location may help.
SMS full - Memory for messages is full. Delete old messages to receive new ones.
Call Forward Unconditional to number All your incoming voice calls are being forwarded to a number other than voice mail.
Silent - Your phone will not ring when
receiving a call.
Call Forward to voice mailbox - All your
calls are being forwarded to voice mail.
Vibra - Your phone will vibrate when
receiving a call.
Home zone - A zone designated by your
network operator. Subscription dependent,
contact your service provider for details.
GPRS attach - Your mobile phone is
connected to the GPRS network.
SMS message - You have received a new
message.
Voice mail - You have received a new voice
mail.
62
Roaming - Displayed when your phone is
registered to a network other than your own
(especially when you’re abroad).
GSM Network: your phone is connected to
a GSM network
Reception quality: the more bars are shown
the better the reception is.
SMS Chat - option is set to On.
Battery - The bars indicate the battery level
(4 bars = full, 1 bar = low).
Memory full - The phone’s memory is full.
Delete items to store new ones.
Alarm clock activated.
MMS message - You have received a new
multimedia message.
Icons & symbols
Precautions
Radio waves
Your cellular mobile phone is a low power
radio transmitter and receiver. When it is
operating, it sends and receives radio waves.
The radio waves carry your voice or data
signal to a base station that is connected to the
telephone network. The network controls the power
at which the phone transmits.
• Your phone transmits/receives radio waves in the
GSM frequency (900 /1800MHz).
• The GSM network controls transmission power
(0.01 to 2 watts).
• Your phone complies with all relevant safety
standards.
• The CE mark on your phone shows compliancy
with European electromagnetic compatibility
(Ref. 89/336/EEC) and low voltage directives
(Ref. 73/23/EEC).
Your cellular mobile phone is your responsibility. To
avoid damage to yourself, to others or to the phone
itself, read and follow all the safety instructions and
make them known to anyone borrowing your phone.
Precautions
Furthermore to prevent unauthorised use of your
phone:
Keep your phone in a safe place and keep it
out of small children's reach.
Avoid writing down your PIN code. Try to
remember it instead.
Switch off the phone and remove the battery if you are
going to leave it unused for a long time.
Use the Security menu to change the PIN code after
purchasing the phone and to activate call restriction
options.
The design of your phone complies with all
applicable laws and regulations. However
your phone may cause interference with
other electronic devices. Consequently you
should follow all local recommendations and
regulations when using your cellular phone both at
home and when away. Regulations on the use of
cellular phones in vehicles and aircraft are
particularly stringent.
Public concern has been focused for some time on the
possible health risks for users of cellular phones. The
current research on radio wave technology, including
the GSM technology, has been reviewed and safety
standards have been drawn up to ensure protection
from exposure to radio wave energy. Your cellular
63
telephone complies with all applicable safety
standards and the Radio Equipment and
Telecommunications Terminal Equipment Directive
1999/5/EC.
Always switch off your phone
Inadequately protected or sensitive electronic
equipment may be affected by radio energy. This
interference can lead to accidents.
Before boarding an aircraft and/or when
packing the phone in your luggage: the use
of mobile phones in an aircraft may be
dangerous for the operation of the aircraft, disrupt the
mobile phones network and may be illegal.
In hospitals, clinics, other health care
centres and anywhere else where you may be
in the close vicinity of medical equipment.
In areas with a potentially explosive
atmosphere (e.g. petrol stations and also
areas where the air contains dust particles,
such as metal powders).
In a vehicle transporting flammable products (even if
the vehicle is parked) or a vehicle powered by liquefied
petroleum gas (LPG), check first that the vehicle
complies with the applicable safety rules.
64
In areas where you are requested to turn off radio
transmitting devices, such as quarries or other areas
where blasting operations are in progress.
Check with the vehicle manufacturer that
electronic equipment used in your vehicle
will not be affected by radio energy.
Users of pacemakers
If you are a user of a pacemaker:
• Always keep the phone more than 15 cm from
your pacemaker when the phone is switched on,
in order to avoid potential interference.
• Do not carry the phone in a breastpocket.
• Use the ear opposite to the pacemaker to minimise the potential interference.
• Switch off your phone if you suspect that interference is taking place.
Users of hearing aids
If you are a user of a hearing aid, consult your
physician and hearing aid manufacturer to learn
whether your particular device is susceptible to
cellular phone interference.
Precautions
network. Setting the backlight for a shorter
period of time as well as avoiding unnecessary
navigating in the menus will also help to save the
battery’s energy for longer phoning and stand-by
performances.
Performance improvement
In order to improve the performance of your phone,
reduce radio energy emission, reduce battery
consumption and ensure safe operation adhere to the
following guidelines:
For the optimal and satisfactory operation of
the phone you are recommended to use the
phone in the normal operating position
(when not using in hands-free mode or with
a hands-free accessory).
• Do not expose your phone to extreme temperatures.
• Treat the phone with care. Any misuse will void
the International Guarantee.
• Do not immerse the phone in any liquid; if your
phone is damp, switch it off, remove the battery
and let them dry for 24hrs before using them
again.
• To clean the phone, wipe it with a soft cloth.
• Placing and receiving calls consumes the same
amount of battery energy. However, the mobile
consumes less energy in idle screen when kept in
the same place. When in idle screen and while
you are moving, your phone consumes energy to
transmit updated location information to the
Precautions
Information displayed on the
battery
•
Your phone is powered by a rechargeable battery.
• Use specified charger only.
• Do not incinerate.
• Do not deform or open the battery.
• Do not allow metal objects (such as keys in your
pocket) to short circuit the battery contacts.
• Avoid exposure to excessive heat (>60°C or
140°F), moisture or caustic environments.
You should only use Philips Authentic
Accessories, as the use of any other
accessories may damage your phone and will
make all guarantees for your Philips phone
null and void.
Make sure damaged parts are replaced immediately by
a qualified technician and that they are replaced with
genuine Philips replacement parts.
65
Do not use your phone while
driving
It lowers concentration, which can be
dangerous. Adhere to the following
guidelines: Give your full attention to
driving. Pull off the road and park before
using the phone. Respect the local regulations in
countries where you drive and use your GSM phone.
If you want to use your phone in a vehicle, install the
hands-free car kit which is designed for that purpose,
still ensuring you give full attention to driving. Ensure
that your phone and car kit do not block any air bags
or other security devices fitted in your car. The use of
an alarm system to operate a vehicle's light or horn to
indicate incoming phone calls is prohibited on public
roads in some countries. Check local regulations.
EN 60950 Norm
In case of hot weather or after a prolonged exposure to
the sun (e.g. behind a window or a windscreen), the
temperature of your phone's casing might increase,
especially when featuring a metallic finish. Be very
careful in this case when picking up your phone and
also avoid using it with an ambient temperature over
40°C.
66
Environmental care
Remember to observe the local regulations
regarding the disposal of your packaging
materials, exhausted batteries and old phone
and please promote their recycling.
Philips has marked the battery and packaging with
standard symbols designed to promote the recycling
and appropriate disposal of your eventual waste.
Battery:
The crossed-out dustbin signifies that
the battery should not be disposed of
with general household waste.
Packaging:
The mobius loop symbol signifies the
labelled
packaging
material
is
recyclable.
The green point symbol signifies that a
financial contribution has been made to
the associated national packaging
recovery and recycling system (e.g.
EcoEmballage in France).
The chasing arrows symbol on the
plastic tray and plastic bag indicate that
the materials are recyclable and also
identifies the plastic material.
Precautions
Troubleshooting
The phone does
not switch on
Remove and reinstall the
battery (see page 1). Make sure
you plugged the jack of the
charger into the correct
connector (see page 3). Then
charge the phone until the
battery icon has stopped
scrolling. Finally, unplug from
the charger and try to switch
the mobile on.
The display
shows
BLOCKED
when you switch
on
Somebody tried to use your
phone but didn’t know the
PIN code nor the unblocking
code (PUK). Contact your
service provider.
The display
shows IMSI
failure
This problem is related to your
subscription. Contact your
operator.
Troubleshooting
The
symbol
is not displayed
The network connection is
lost. Either you are in a radio
shadow (in a tunnel or between
tall buildings) or you are
outside the network coverage
area. Try from another place,
try to reconnect to the network
(especially when abroad),
check that the antenna is in
place if your mobile has an
external antenna, or contact
your network operator for
assistance/information about
the network.
The display
doesn’t respond
(or the display
responds slowly)
to key presses
The display responds more
slowly
at
very
low
temperatures. This is normal
and does not affect the
operation of the phone. Take
the phone to a warmer place
and try again.
In other cases please contact
your phone supplier.
67
Your phone
doesn’t return
to the idle
screen
Press and hold c or switch
off the phone, check that the
SIM card and the battery are
installed correctly and switch it
on again.
You can’t
receive and/or
store JPEG
pictures
Your phone
doesn’t display
the phone
numbers of
incoming calls
This feature is network and
subscription dependent. If the
network doesn’t send the
caller’s number, the phone will
display Call 1 or Withheld
instead. Contact your operator
for detailed information on
this subject.
A picture may not be accepted
by your mobile phone if it is
too large, if its name is too
long, or if it doesn’t have the
correct file format. See page 30
for information on this subject.
During battery
charge, the
battery icon
shows no bar
and the outline
is flashing
Only charge the battery in an
environment
where
the
temperature does not go below
0°C (32°F) or above 50°C
(113°F). In other cases please
contact your phone supplier.
You can’t send
text messages
Some networks don’t allow
message exchanges with other
networks. First check that you
entered the number of your
SMS centre, or contact your
operator
for
detailed
information on this subject.
The display
shows SIM
failure
Check that the SIM card has
been inserted in the right
position (see page 1). If the
problem remains, your SIM
card may be damaged. Contact
your operator.
You have the
feeling that you
miss some calls
To receive all calls, make sure
that none of the features
"Conditional call forward" or
"unconditional call forward" is
activated (see page 48).
68
Troubleshooting
When
attempting to
use a feature in
the menu, the
mobile displays
NOT
ALLOWED
Some features are network
dependent. They are only
available, therefore, if the
network or your subscription
supports them. Contact your
operator
for
detailed
information on this subject.
The display
shows INSERT
YOUR SIM
CARD
Check that the SIM card has
been inserted in the right
position (see page 1). If the
problem remains, your SIM
card might be damaged.
Contact your operator.
The autonomy
of your phone
seems lower
that indicated in
the user guide
The autonomy is linked to
your settings (e.g. ringer
volume, backlight duration)
and the features you use. To
increase the autonomy, and
whenever possible, you must
deactivate features you do not
use.
Troubleshooting
Your phone
doesn’t work
well in your car
A car contains many metallic
parts that absorb electormagnetic waves which can
affect
the
phone’s
performances. A car kit is
available to provide you with
an external antenna and
enables you to make and
receive phone calls without
handling the handset.
Check with local authorities if
you are allowed to use the
phone whilst driving.
Your phone is
not charging
Make sure you plugged the
jack of the charger into the
correct connector (see “Charge
the battery” page 3). If your
battery is completely flat, it
might take several minutes of
pre-charge (up to 5 in some
cases) before the charging icon
is displayed on the screen.
69
Philips authentic
accessories
Charger
Charges your battery in any AC outlet. Small enough
to carry in a briefcase/handbag.
Universal car kit
Designed to operate your Philips mobile phone
hands-free and easy to use, this compact hands-free
solution offers a high audio quality.
Simply plug the kit into the vehicle auxiliary outlet.
In certain countries, telephoning whilst driving is
prohibited. For safe and trouble free installation, we
recommend that specialized technicians install handsfree car kits.
Deluxe headset
In-line answer button offers you a simplified
alternative to searching for the phone. Simply answer
an incoming call by pressing the button. In idle mode,
press to activate voice dial.
70
Digital camera
This 360° rotating camera allows you to take pictures,
and to store them in your phone. Supplied with
specific carry case.
Data connect kit
Easy data connection to your Philips mobile phone.
The USB cable enables high speed connection
between your phone and your computer. Just connect
your phone to the cable for an automatic organiser
and phonebook synchronization within a few
seconds. The software allows you to send faxes and
SMS, download pictures and melodies.
Carry case
Protects the phone from nicks and scratches. The belt
clip makes your phone easy to carry.
To maximise the performance of your Philips phone
and not to void the warranty, always purchase Philips
Authentic Accessories that are specially designed for
use with your phone. Philips Consumer Electronics
cannot be held liable for any damage due to use with
non authorised accessories. Ask for Philips Authentic
Accessories where you purchased your Philips Phone.
Philips authentic accessories
SAR Information to end users
THIS MODEL PHONE MEETS THE EU REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for
exposure to radio frequency (RF) energy recommended by the Council of the European Union. These limits are
part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The
guidelines were developed by independent scientific organisations through periodic and thorough evaluation of
scientific studies. The limits include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for mobile phones employs a unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit recommended by the Council of the European Union is 2.0 W/kg. Tests for SAR have
been conducted using standard operating positions with the phone transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to reach the network. In general, the closer
you are to a base station antenna, the lower the power output.
Before a phone model is available for sale to the public, compliance with the European RTTE directive must be
shown. This directive includes as one essential requirement the protection of the health and the safety for the user
and any other person. The highest SAR value for this Philips 636 / CT 6368 model phone when tested for
compliance against the standard was 0.693 W/kg. While there may be differences between the SAR levels of various
phones and at various positions, they all meet the EU requirements for RF exposure.
SAR Information to end users
SAR Information to end users
THIS MOBILE PHONE MEETS INTERNATIONAL REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for
exposure to radio frequency (RF) recommended by international guidelines (ICNIRP). These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines
were developed by independent scientific organisations through periodic and thorough evaluation of scientific
studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for mobile phones employs a unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit stated in the international guidelines is 2.0 W/kg. Tests for SAR are conducted using
standard operating positions with the phone transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power level, the actual SAR of the phone while
operating can be well below the maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the
lower the power output of the phone.
The highest SAR value for this Philips 636 / CT 6368 model phone when tested for use at the ear is 0.693 W/kg.
While there may be differences between the SAR levels of various phones and at various positions, they all meet
the relevant international guidelines for RF exposure.
SAR Information to end users
Declaration of
conformity
We,
Philips France - Mobile Telephony
4 rue du Port aux Vins - Les patios
92156 Suresnes Cedex
FRANCE
declare under our sole responsibility that the product
Philips 636
CT 6368
Cellular Mobile Radio GSM 900/GSM 1800
TAC: 352769 00
to which this declaration relates, is in conformity with
the following Standards:
EN 60950, EN 50360 and EN 301 489-07
EN 301 511 v 7.0.1
We hereby declare that all essential radio test suites
have been carried out and that the above named
product is in conformity to all the essential
requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in
Article 10 and detailed in Annex V of Directive 1999/
5/EC has been followed related to articles 3.1 and 3.2
with the involvement of the following Notified Body:
BABT, Claremont House, 34 Molesey Road, Waltonon-Thames, KT12 4RQ, UK
Identification mark: 0168
Le Mans, June 2nd, 2004
Jean-Omer Kifouani
Quality Manager
In case your Philips product is not working correctly or
is defective, please return your phone to the place of
purchase or to the Philips National Service Center.
Refer to the International Guarantee shipped in the
box for information on Service centers and technical
documentation relevant to your equipment.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
