FCC DTS - LairdTech

File: R78442

EMC Test Report

Application for Grant of Equipment Authorization pursuant to

Industry Canada RSS-Gen Issue 2 / RSS 210 Issue 7

FCC Part 15 Subpart C

Model: SDC-MSD30AG

IC CERTIFICATION #: 6616A-SDCMSD30AG

FCC

APPLICANT: Summit Data Communications Inc.

526 South Main St. Suite 805

Akron, OH 44311

TEST SITE(S): Elliott Laboratories

41039 Boyce Road.

Fremont, CA. 94538-2435

IC SITE REGISTRATION #:

REPORT DATE:

2845B-3; 2845B-4, 2845B-5

March 2, 2010

FINAL TEST DATES: January 6, 8, 13, 14, 21, 22, and February 26,

2010

DRAFT

Testing Cert #2016-01

Elliott Laboratories is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report, except where noted otherwise. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories

Page 1 of 22

Elliott Laboratories -- EMC Department

REVISION HISTORY

Rev# Date Comments

Test Report

Report Date: March 2, 2010

File: R78442

DRAFT

Page 2 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

TABLE OF CONTENTS

COVER PAGE........................................................................................................................................................... 1

REVISION HISTORY .............................................................................................................................................. 2

TABLE OF CONTENTS .......................................................................................................................................... 3

SCOPE........................................................................................................................................................................ 4

OBJECTIVE .............................................................................................................................................................. 5

STATEMENT OF COMPLIANCE......................................................................................................................... 5

DEVIATIONS FROM THE STANDARDS............................................................................................................ 5

TEST RESULTS SUMMARY ................................................................................................................................. 6

DIGITAL TRANSMISSION SYSTEMS (2400 – 2483.5MH

Z

)............................................................................6

DIGITAL TRANSMISSION SYSTEMS (5725 –5850 MH

Z

)...............................................................................7

GENERAL REQUIREMENTS APPLICABLE TO ALL BANDS........................................................................8

MEASUREMENT UNCERTAINTIES..................................................................................................................9

EQUIPMENT UNDER TEST (EUT) DETAILS.................................................................................................. 10

GENERAL............................................................................................................................................................10

ANTENNA SYSTEM ..........................................................................................................................................10

ENCLOSURE.......................................................................................................................................................10

MODIFICATIONS...............................................................................................................................................10

SUPPORT EQUIPMENT.....................................................................................................................................11

EUT INTERFACE PORTS ..................................................................................................................................11

EUT OPERATION ...............................................................................................................................................11

TEST SITE............................................................................................................................................................... 12

GENERAL INFORMATION...............................................................................................................................12

CONDUCTED EMISSIONS CONSIDERATIONS ............................................................................................12

RADIATED EMISSIONS CONSIDERATIONS ................................................................................................12

MEASUREMENT INSTRUMENTATION .......................................................................................................... 13

RECEIVER SYSTEM ..........................................................................................................................................13

INSTRUMENT CONTROL COMPUTER ..........................................................................................................13

LINE IMPEDANCE STABILIZATION NETWORK (LISN).............................................................................13

FILTERS/ATTENUATORS ................................................................................................................................14

ANTENNAS.........................................................................................................................................................14

ANTENNA MAST AND EQUIPMENT TURNTABLE .....................................................................................14

INSTRUMENT CALIBRATION.........................................................................................................................14

TEST PROCEDURES ............................................................................................................................................ 15

EUT AND CABLE PLACEMENT ......................................................................................................................15

CONDUCTED

RADIATED

RADIATED

GENERAL

RECEIVER

BANDWIDTH

CONDUCTED

SPECIFICATION LIMITS

RADIATED

AND

EMISSIONS

TRANSMITTER

DRAFT

GEN ................18

OUTPUT POWER LIMITS – DIGITAL TRANSMISSION SYSTEMS ............................................................20

TRANSMIT MODE SPURIOUS RADIATED EMISSIONS LIMITS – FHSS

AND

DTS SYSTEMS...............20

SAMPLE CALCULATIONS CONDUCTED EMISSIONS .............................................................................20

SAMPLE CALCULATIONS RADIATED EMISSIONS..................................................................................21

SAMPLE CALCULATIONS FIELD STRENGTH TO EIRP CONVERSION.................................................22

APPENDIX A TEST EQUIPMENT CALIBRATION DATA .............................................................................. 1

APPENDIX B TEST DATA ..................................................................................................................................... 4

Page 3 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

SCOPE

An electromagnetic emissions test has been performed on the Summit Data

Communications Inc. model SDC-MSD30AG, pursuant to the following rules:

Industry Canada RSS-Gen Issue 2

RSS 210 Issue 7 “Low-power Licence-exempt Radiocommunication Devices (All

Frequency Bands): Category I Equipment”

FCC Part 15 Subpart C

Conducted and radiated emissions data has been collected, reduced, and analyzed within this report in accordance with measurement guidelines set forth in the following reference standards and as outlined in Elliott Laboratories test procedures:

ANSI C63.4:2003

FCC DTS Measurement Procedure KDB558074, March 2005

The intentional radiator above has been tested in a simulated typical installation to demonstrate compliance with the relevant Industry Canada performance and procedural standards.

Final system data was gathered in a mode that tended to maximize emissions by varying orientation of EUT, orientation of power and I/O cabling, antenna search height, and antenna polarization.

Every practical effort was made to perform an impartial test using appropriate test equipment of known calibration. All pertinent factors have been applied to reach the determination of compliance.

DRAFT

Page 4 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

OBJECTIVE

The primary objective of the manufacturer is compliance with the regulations outlined in the previous section.

Prior to marketing in the USA, all unlicensed transmitters and transceivers require certification. Receive-only devices operating between 30 MHz and 960 MHz are subject to either certification or a manufacturer’s declaration of conformity, with all other receive-only devices exempt from the technical requirements.

Prior to marketing in Canada, Class I transmitters, receivers and transceivers require certification. Class II devices are required to meet the appropriate technical requirements but are exempt from certification requirements.

Certification is a procedure where the manufacturer submits test data and technical information to a certification body and receives a certificate or grant of equipment authorization upon successful completion of the certification body’s review of the submitted documents. Once the equipment authorization has been obtained, the label indicating compliance must be attached to all identical units, which are subsequently manufactured.

Maintenance of compliance is the responsibility of the manufacturer. Any modification of the product which may result in increased emissions should be checked to ensure compliance has been maintained (i.e., printed circuit board layout changes, different line filter, different power supply, harnessing or I/O cable changes, etc.).

STATEMENT OF COMPLIANCE

The tested sample of Summit Data Communications Inc. model SDC-MSD30AG complied with the requirements of the following regulations:

Industry Canada RSS-Gen Issue 2

RSS 210 Issue 7 “Low-power Licence-exempt Radiocommunication Devices (All

DRAFT

The test results recorded herein are based on a single type test of Summit Data

Communications Inc. model SDC-MSD30AG and therefore apply only to the tested sample. The sample was selected and prepared by Jerry Pohmurski of Summit Data

Communications Inc.

DEVIATIONS FROM THE STANDARDS

No deviations were made from the published requirements listed in the scope of this report.

Page 5 of 22

File: R78442

Elliott Laboratories -- EMC Department

TEST RESULTS SUMMARY

DIGITAL TRANSMISSION SYSTEMS (2400 – 2483.5MHz)

FCC

Rule Part

15.247(a)

15.247 (a)

(2)

15.247 (b)

(3)

15.247(d)

RSS

Rule Part

RSS 210

A8.2

RSS 210

A8.2 (1)

RSS 210

A8.2 (4)

RSS 210

A8.2 (2)

Description

Digital Modulation

6dB Bandwidth

Output Power

(multipoint systems)

Power Spectral

Density

Test Report

Report Date: March 2, 2010

Measured Value /

Comments

Systems uses OFDM /

DSSS techniques

802.11b: 12.41 MHz

802.11g: 16.5 MHz

802.11b:

17.4 dBm

(0.056 Watts)

EIRP = 0.111 W

Note 1

802.11g:

20.9 dBm

(0.123 Watts)

EIRP = 0.245 W

Note 1

802.11b:

-6.7 dBm / MHz

802.11g:

-7.9 dBm / MHz

Limit / Requirement Result

- Complies

>500kHz Complies

1Watt, EIRP limited to 4 Watts.

Complies

8dBm/3kHz Complies

15.247(c)

RSS 210

A8.5

Antenna Port

Spurious Emissions

30MHz – 25 GHz

All emissions < -

30dBc or

<-20dBc

Note 2

< -30dBc or

< -20dBc

Note 2

Complies

15.247(c) /

15.209

RSS 210

A8.5

Radiated Spurious

Emissions

30MHz – 25 GHz

53.8dBµV/m @

4924.0MHz (-0.2dB) system.

15.207 in restricted bands, all others

< -20dBc

<-30dBc

Note 2

Note 1: EIRP calculated using antenna gain of 3 dBi for the highest EIRP multi-point

DRAFT

Complies time interval, as permitted under RSS 210 section A8.4(4). When peak power was measured, -20dBc was used.

Page 6 of 22

File: R78442

Elliott Laboratories -- EMC Department

DIGITAL TRANSMISSION SYSTEMS (5725 –5850 MHz)

FCC

Rule Part

RSS

Rule Part

Description

15.247(a)

15.247 (a)

(2)

15.247 (b)

15.247(d)

RSS 210

A8.2

RSS 210

A8.2 (1)

RSS 210

A8.2 (4)

RSS 210

A8.2 (2)

Digital Modulation

6dB Bandwidth

Output Power

(multipoint systems)

Power Spectral

Density

Test Report

Report Date: March 2, 2010

Measured Value /

Comments

Systems uses OFDM /

DSSS techniques

Limit / Requirement Result

System must utilize a digital transmission technology

>500kHz

Complies

Complies 16.5 MHz

11.5 dBm

(0.014 Watts)

EIRP = 0.063 W

Note 1

7.5 dBm / MHz

1Watt, EIRP limited to 4 Watts.

Maximum permitted is 8dBm/3kHz

Complies

Complies

15.247(c)

RSS 210

A8.5

Antenna Port

Spurious Emissions –

30MHz – 40 GHz

All spurious emissions < -30dBc

< -30dBc

Note 2

Complies

15.247(c) /

15.209

51.6dBµV/m @

5236.3MHz (-2.4dB)

15.207 in restricted bands, all others

<-30dBc

Note 2

Complies

RSS 210

A8.5

Table 2, 3

Radiated Spurious

Emissions

30MHz – 40 GHz

Note 1: EIRP calculated using antenna gain of 6.5 dBi for the highest EIRP multi-point system.

Note 2: Limit of -30dBc used because the power was measured using the UNII test procedure (maximum power averaged over a transmission burst).

DRAFT

Page 7 of 22

File: R78442

Elliott Laboratories -- EMC Department

GENERAL REQUIREMENTS APPLICABLE TO ALL BANDS

FCC Rule

Part

RSS

Rule part

Description

15.109

15.207

15.247 (b)

(5)

15.407 (f)

RSS GEN

7.2.3

Table 1

RSS GEN

Table 2

RSS 102

Receiver spurious emissions

AC Conducted

Emissions

RF Exposure

Requirements

Measured Value /

Comments

The EUT uses u.FL connectors

42.6dBµV/m

(134.9µV/m) @

3856.7MHz

(-11.4dB)

45.1dBµV @

0.176MHz (-19.6dB)

Refer to MPE calculations in

Exhibit 11, RSS 102 declaration and User

Manual statements.

-

-

-

RSP 100

RSS GEN

7.1.5

RSP 100

RSS GEN

7.1.5

RSP 100

RSS GEN

4.4.1

User Manual

User Manual

99% Bandwidth

802.11b: 16.1 MHz

802.11g: 17.2 MHz

802.1a: 17.1 MHz

Test Report

Report Date: March 2, 2010

Limit / Requirement

Result

(margin)

Refer to standard Complies

Refer to standard Complies

Refer to standard Complies

Refer to OET 65,

FCC Part 1 and RSS

102

Complies

Statement required regarding noninterference

Statement for products with detachable antenna

Information only

Complies

Complies

N/A

DRAFT

Page 8 of 22

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

MEASUREMENT UNCERTAINTIES

ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level and were calculated in accordance with

UKAS document LAB 34.

Measurement Type Frequency Range Calculated Uncertainty

(MHz) (dB)

______________________________________________________________

Conducted Emissions 0.15 to 30 ± 2.4

Radiated Emissions

Radiated Emissions

Radiated Emissions

0.015 to 30

30 to 1000

1000 to 40000

± 3.0

± 3.6

± 6.0

File: R78442

DRAFT

Page 9 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

EQUIPMENT UNDER TEST (EUT) DETAILS

GENERAL

The Summit Data Communications Inc. model SDC-MSD30AG is a 802.11ag compliant wireless LAN radio Module which is designed to provide wireless local area networking connectivity. Normally, the EUT would be embedded in various types of mobile and stationary computing devices such as handheld and vehicle mounted data terminals during operation. The EUT was, therefore, placed in this position during emissions testing to simulate the end user environment. The electrical rating of the EUT is 3.3 VDC

=/-5%. It’s typical power consumption is 400mA (1320mW) while in transmit mode,

180mA (594mW) while in receive mode and 10mA (33mW) while in standby mode.

The sample was received on November 8, 2009 and tested on January 6, 8, 13, 14, 21, 22, and February 26, 2010. The EUT consisted of the following component(s):

Company

Summit Data

Communications

Inc.

Model Description Serial Number

SDC-MSD30AG 802.11AG Mini

Compact Flash

Module with antenna connectors

ANTENNA SYSTEM

FCC ID

TWG-

SDCMSD30AG

The SDC-MSD30AG will be marketed with the following antenna options:

Monopole Antenna - 2.4 and 5GHz bands, Huber+Suhner, SOA 2459/360/5/0/V_C, 3dBi

(2.4GHz), 6.5dBi (5GHz)

Dipole Antenna #1 - 2.4 and 5GHz bands - Larsen, R380.500.314, 1.6dBi (2.4GHz),

5dBi (5GHz)

Dipole Antenna #2 - 2.4 GHz only - Cisco Air-Ant 4941 2dBi(2.4GHz)

Dipole Antenna #3 - 5GHz only - Cisco Air-Ant 5135 3.5dBi(5GHz)

Dipole Antenna #4 - 2.4GHz only - Summit SDC-CF22G - 0dBi

ENCLOSURE

The EUT does not have an enclosure as it is designed to be installed within the enclosure of a host computer or system.

MODIFICATIONS

DRAFT

No modifications were made to the EUT during the time the product was at Elliott.

Page 10 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

SUPPORT EQUIPMENT

The following equipment was used as support equipment for testing:

Company

Hewlett Packard

Model iPAQ

Description Serial Number

Handheld

FCC ID

- -

Computer

No remote support equipment was used during testing.

EUT INTERFACE PORTS

The I/O cabling configuration during testing was as follows:

Port

Connected

To iPAQ Power AC Mains

Flash Module iPAQ Module

Port

EUT OPERATION

Description

2wire

Cable(s)

Shielded or Unshielded Length(m)

Unshielded 1.5

During emissions testing the EUT was configured to transmit at the Low, Middle, and

High Channel. Testing performed at 6Mbs for 802.11g and 802.11a modes and 1Mbs for

802.11b mode.

DRAFT

Page 11 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

TEST SITE

GENERAL INFORMATION

Final test measurements were taken on January 6, 8, 13, 14, 21, 22, and February 26,

2010 at the test sites listed below. Pursuant to section 2.948 of the FCC’s Rules and section 3.3 of RSP-100, construction, calibration, and equipment data has been filed with the Commission and with industry Canada.

Site

Chamber 3

Chamber 4

Chamber 5

Registration Numbers Location

FCC Canada

769238

211948

211948

2845B-3

2845B-4

2845B-5

41039 Boyce Road

Fremont,

CA 94538-2435

ANSI C63.4:2003 recommends that ambient noise at the test site be at least 6 dB below the allowable limits. Ambient levels are below this requirement. The test site(s) contain separate areas for radiated and conducted emissions testing. Considerable engineering effort has been expended to ensure that the facilities conform to all pertinent requirements of ANSI C63.4:2003.

CONDUCTED EMISSIONS CONSIDERATIONS

Conducted emissions testing is performed in conformance with ANSI C63.4:2003.

Measurements are made with the EUT connected to the public power network through a nominal, standardized RF impedance, which is provided by a line impedance stabilization network, known as a LISN. A LISN is inserted in series with each current-carrying conductor in the EUT power cord.

RADIATED EMISSIONS CONSIDERATIONS

The FCC has determined that radiation measurements made in a shielded enclosure are not suitable for determining levels of radiated emissions. Radiated measurements are

DRAFT

Page 12 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

MEASUREMENT INSTRUMENTATION

RECEIVER SYSTEM

An EMI receiver as specified in CISPR 16-1-1 is used for emissions measurements. The receivers used can measure over the frequency range of 9 kHz up to 2000 MHz. These receivers allow both ease of measurement and high accuracy to be achieved. The receivers have Peak, Average, and CISPR (Quasi-peak) detectors built into their design so no external adapters are necessary. The receiver automatically sets the required bandwidth for the CISPR detector used during measurements. If the repetition frequency of the signal being measured is below 20Hz, peak measurements are made in lieu of

Quasi-Peak measurements.

For measurements above the frequency range of the receivers, a spectrum analyzer is utilized because it provides visibility of the entire spectrum along with the precision and versatility required to support engineering analysis. Average measurements above

1000MHz are performed on the spectrum analyzer using the linear-average method with a resolution bandwidth of 1 MHz and a video bandwidth of 10 Hz, unless the signal is pulsed in which case the average (or video) bandwidth of the measuring instrument is reduced to onset of pulse desensitization and then increased.

INSTRUMENT CONTROL COMPUTER

The receivers utilize either a Rohde & Schwarz EZM Spectrum Monitor/Controller or contain an internal Spectrum Monitor/Controller to view and convert the receiver measurements to the field strength at an antenna or voltage developed at the LISN measurement port, which is then compared directly with the appropriate specification limit. This provides faster, more accurate readings by performing the conversions described under Sample Calculations within the Test Procedures section of this report.

Results are printed in a graphic and/or tabular format, as appropriate. A personal computer is used to record all measurements made with the receivers.

The Spectrum Monitor provides a visual display of the signal being measured. In

DRAFT

This network provides for calibrated radio frequency noise measurements by the design of the internal low pass and high pass filters on the EUT and measurement ports, respectively.

Page 13 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

FILTERS/ATTENUATORS

External filters and precision attenuators are often connected between the receiving antenna or LISN and the receiver. This eliminates saturation effects and non-linear operation due to high amplitude transient events.

ANTENNAS

A loop antenna is used below 30 MHz. For the measurement range 30 MHz to 1000

MHz either a combination of a biconical antenna and a log periodic or a bi-log antenna is used. Above 1000 MHz, horn antennas are used. The antenna calibration factors to convert the received voltage to an electric field strength are included with appropriate cable loss and amplifier gain factors to determine an overall site factor, which is then programmed into the test receivers or incorporated into the test software.

ANTENNA MAST AND EQUIPMENT TURNTABLE

The antennas used to measure the radiated electric field strength are mounted on a nonconductive antenna mast equipped with a motor-drive to vary the antenna height.

Measurements below 30 MHz are made with the loop antenna at a fixed height of 1m above the ground plane.

ANSI C63.4:2003 specifies that the test height above ground for table mounted devices shall be 80 centimeters. Floor mounted equipment shall be placed on the ground plane if the device is normally used on a conductive floor or separated from the ground plane by insulating material from 3 to 12 mm if the device is normally used on a non-conductive floor. During radiated measurements, the EUT is positioned on a motorized turntable in conformance with this requirement.

INSTRUMENT CALIBRATION

All test equipment is regularly checked to ensure that performance is maintained in

DRAFT

Page 14 of 22

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

TEST PROCEDURES

EUT AND CABLE PLACEMENT

The regulations require that interconnecting cables be connected to the available ports of the unit and that the placement of the unit and the attached cables simulate the worst case orientation that can be expected from a typical installation, so far as practicable. To this end, the position of the unit and associated cabling is varied within the guidelines of

ANSI C63.4:2003, and the worst-case orientation is used for final measurements.

CONDUCTED EMISSIONS

Conducted emissions are measured at the plug end of the power cord supplied with the

EUT. Excess power cord length is wrapped in a bundle between 30 and 40 centimeters in length near the center of the cord. Preliminary measurements are made to determine the highest amplitude emission relative to the specification limit for all the modes of operation. Placement of system components and varying of cable positions are performed in each mode. A final peak mode scan is then performed in the position and mode for which the highest emission was noted on all current carrying conductors of the power cord.

LISN

EUT

LISN

AE

0.8m

File: R78442 Page 15 of 22

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

RADIATED EMISSIONS

A preliminary scan of the radiated emissions is performed in which all significant EUT frequencies are identified with the system in a nominal configuration. At least two scans are performed, one scan for each antenna polarization (horizontal and vertical; loop parallel and perpendicular to the EUT). During the preliminary scans, the EUT is rotated through 360˚, the antenna height is varied (for measurements above 30 MHz) and cable positions are varied to determine the highest emission relative to the limit. Preliminary scans may be performed in a fully anechoic chamber for the purposes of identifying the frequencies of the highest emissions from the EUT.

A speaker is provided in the receiver to aid in discriminating between EUT and ambient emissions. Other methods used during the preliminary scan for EUT emissions involve scanning with near field magnetic loops, monitoring I/O cables with RF current clamps, and cycling power to the EUT.

Final maximization is a phase in which the highest amplitude emissions identified in the spectral search are viewed while the EUT azimuth angle is varied from 0 to 360 degrees relative to the receiving antenna. The azimuth, which results in the highest emission is then maintained while varying the antenna height from one to four meters (for measurements above 30 MHz, measurements below 30 MHz are made with the loop antenna at a fixed height of 1m). The result is the identification of the highest amplitude for each of the highest peaks. Each recorded level is corrected in the receiver using appropriate factors for cables, connectors, antennas, and preamplifier gain.

When testing above 18 GHz, the receive antenna is located at 1meter from the EUT and the antenna height is restricted to a maximum of 2.5 meters.

REAR VIEW

0.4m

0.8m

File: R78442

SIDE VIEW

Typical Test Configuration for Radiated Field Strength Measurements

Page 16 of 22

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

EUT d

Antenna

The anechoic materials on the walls and ceiling ensure compliance with the normalized site attenuation requirements of CISPR 16 / CISPR 22 / ANSI C63.4 for an alternate test site at the measurement distances used.

Floor-standing equipment is placed on the floor with insulating supports between the unit and the ground plane.

Antenna height range

1 to 4 m

Test Configuration for Radiated Field Strength Measurements

Semi-Anechoic Chamber, Plan and Side Views

BANDWIDTH MEASUREMENTS

The 6dB, 20dB and/or 26dB signal bandwidth is measured in using the bandwidths recommended by ANSI C63.4. When required, the 99% bandwidth is measured using the methods detailed in RSS GEN.

File: R78442 Page 17 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

SPECIFICATION LIMITS AND SAMPLE CALCULATIONS

The limits for conducted emissions are given in units of microvolts, and the limits for radiated emissions are given in units of microvolts per meter at a specified test distance.

Data is measured in the logarithmic form of decibels relative to one microvolt, or dB microvolts (dBuV). For radiated emissions, the measured data is converted to the field strength at the antenna in dB microvolts per meter (dBuV/m). The results are then converted to the linear forms of uV and uV/m for comparison to published specifications.

For reference, converting the specification limits from linear to decibel form is accomplished by taking the base ten logarithm, then multiplying by 20. These limits in both linear and logarithmic form are as follows:

CONDUCTED EMISSIONS SPECIFICATION LIMITS: FCC 15.207; FCC 15.107(a), RSS GEN

The table below shows the limits for the emissions on the AC power line from an intentional radiator and a receiver.

Frequency

(MHz)

0.150 to 0.500

0.500 to 5.000

5.000 to 30.000

Average

Limit

(dBuV)

Linear decrease on logarithmic frequency axis between 56.0 and 46.0

46.0

50.0

Quasi Peak

Limit

(dBuV)

Linear decrease on logarithmic frequency axis between 66.0 and 56.0

56.0

60.0

DRAFT

Page 18 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

GENERAL TRANSMITTER RADIATED EMISSIONS SPECIFICATION LIMITS

The table below shows the limits for the spurious emissions from transmitters that fall in restricted bands

1

(with the exception of transmitters operating under FCC Part 15 Subpart

D and RSS 210 Annex 9), the limits for all emissions from a low power device operating under the general rules of RSS 310 (tables 3 and 4), RSS 210 (table 2) and FCC Part 15

Subpart C section 15.209.

Frequency

Range

(MHz)

Limit

(uV/m)

Limit

(dBuV/m @ 3m)

0.009-0.490 2400/F

KHz

@ 300m 67.6-20*log10(F

KHz

) @ 300m

0.490-1.705 24000/F

KHz

@ 30m 87.6-20*log10(F

KHz

) @ 30m

1.705 to 30

30 to 88

88 to 216

30 @ 30m

100 @ 3m

150 @ 3m

29.5 @ 30m

40 @ 3m

43.5 @ 3m

200 @ 3m

500 @ 3m

46.0 @ 3m

54.0 @ 3m

216 to 960

Above 960

RECEIVER RADIATED SPURIOUS EMISSIONS SPECIFICATION LIMITS

The table below shows the limits for the spurious emissions from receivers as detailed in

FCC Part 15.109, RSS 210 Table 2, RSS GEN Table 1 and RSS 310 Table 3. Note that receivers operating outside of the frequency range 30 MHz – 960 MHz are exempt from the requirements of 15.109.

Frequency

Range

(MHz)

30 to 88

88 to 216

216 to 960

Above 960

Limit

(uV/m @ 3m)

Limit

(dBuV/m @ 3m)

DRAFT

1

The restricted bands are detailed in FCC 15.203, RSS 210 Table 1 and RSS 310 Table 2

Page 19 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

OUTPUT POWER LIMITS – DIGITAL TRANSMISSION SYSTEMS

The table below shows the limits for output power and output power density. Where the signal bandwidth is less than 20 MHz the maximum output power is reduced to the power spectral density limit plus 10 times the log of the bandwidth (in MHz).

Operating Frequency

(MHz)

902 – 928

2400 – 2483.5

5725 – 5850

Output Power

1 Watt (30 dBm)

1 Watt (30 dBm)

1 Watt (30 dBm)

Power Spectral Density

8 dBm/3kHz

8 dBm/3kHz

8 dBm/3kHz

The maximum permitted output power is reduced by 1dB for every dB the antenna gain exceeds 6dBi. Fixed point-to-point applications using the 5725 – 5850 MHz band are not subject to this restriction.

TRANSMIT MODE SPURIOUS RADIATED EMISSIONS LIMITS – FHSS and DTS SYSTEMS

The limits for unwanted (spurious) emissions from the transmitter falling in the restricted bands are those specified in the general limits sections of FCC Part 15 and RSS 210. All other unwanted (spurious) emissions shall be at least 20dB below the level of the highest in-band signal level (30dB if the power is measured using the sample detector/power averaging method).

SAMPLE CALCULATIONS - CONDUCTED EMISSIONS

Receiver readings are compared directly to the conducted emissions specification limit

(decibel form) as follows:

Rr - S = M

where:

Rr = Receiver Reading in dBuV

S = Specification Limit in dBuV

DRAFT

Page 20 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

SAMPLE CALCULATIONS - RADIATED EMISSIONS

Receiver readings are compared directly to the specification limit (decibel form). The receiver internally corrects for cable loss, preamplifier gain, and antenna factor. The calculations are in the reverse direction of the actual signal flow, thus cable loss is added and the amplifier gain is subtracted. The Antenna Factor converts the voltage at the antenna coaxial connector to the field strength at the antenna elements.

A distance factor, when used for electric field measurements above 30MHz, is calculated by using the following formula:

Fd = 20*LOG10 (Dm/Ds)

where:

Fd = Distance Factor in dB

Dm = Measurement Distance in meters

Ds = Specification Distance in meters

For electric field measurements below 30MHz the extrapolation factor is either determined by making measurements at multiple distances or a theoretical value is calculated using the formula:

Fd = 40*LOG10 (Dm/Ds)

Measurement Distance is the distance at which the measurements were taken and

Specification Distance is the distance at which the specification limits are based. The antenna factor converts the voltage at the antenna coaxial connector to the field strength at the antenna elements.

DRAFT

Page 21 of 22

File: R78442

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

The margin of a given emission peak relative to the limit is calculated as follows:

Rc = Rr + Fd

and

where:

Rr = Receiver Reading in dBuV/m

Fd = Distance Factor in dB

Rc = Corrected Reading in dBuV/m

Ls = Specification Limit in dBuV/m

M = Margin in dB Relative to Spec

SAMPLE CALCULATIONS - FIELD STRENGTH TO EIRP CONVERSION

Where the radiated electric field strength is expressed in terms of the equivalent isotropic radiated power (eirp), or where a field strength measurement of output power is made in lieu of a direct measurement, the following formula is used to convert between eirp and field strength at a distance of 3m from the equipment under test:

E = 1000000 √ 30 P microvolts per meter

3 where P is the eirp (Watts)

DRAFT

Page 22 of 22

Elliott Laboratories -- EMC Department Test Report

Report Date: March 2, 2010

Appendix A Test Equipment Calibration Data

Radiated Emissions, 30 - 6,500 MHz, 11-Nov-09

EMCO

Hewlett Packard

Antenna, Horn, 1-18 GHz

SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

Radio Spurious Emissions, 11-Nov-09

3115

8564E (84125C)

786

1393

12/6/2009

4/10/2010

Hewlett Packard

EMCO

Microwave Preamplifier, 1-

26.5GHz

Antenna, Horn, 1-18 GHz 9/2/2010

Micro-Tronics

(SA40-Blu)

Band Reject Filter, 2400-2500

MHz

SpecAn 9 kHz - 40 GHz, (SA40) Hewlett Packard

Purple

Radio Spurious Emissions, 02-Dec-09

8564E (84125C) 1771 9/30/2010

Hewlett Packard

EMCO

Hewlett Packard

Microwave Preamplifier, 1-

26.5GHz

Antenna, Horn, 1-18GHz

SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

Micro-Tronics Band Reject Filter, 2400-2500

MHz

Radiated Emissions, DTS, 04-Dec-09

3115

8564E (84125C)

868

1393

6/10/2010

4/10/2010

Hewlett Packard Microwave Preamplifier, 1-

EMCO

Hewlett Packard

Micro-Tronics

26.5GHz

Antenna, Horn, 1-18GHz

SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

Band Reject Filter, 2400-2500

MHz

Radiated Emissions, 30 - 26,500 MHz, 09-Dec-09

Hewlett Packard

EMCO

Hewlett Packard

Microwave

26.5GHz

Preamplifier,

Antenna, Horn, 1-18GHz

1-

SpecAn 9 kHz - 40 GHz, FT

3115

8564E (84125C)

3115

8564E (84125C)

868

1393

868

1393

6/10/2010

4/10/2010

6/10/2010

4/10/2010

Micro-Tronics

(SA40) Blue

Band Reject Filter, 2400-2500

MHz

Radiated Emissions, 1000 - 40000MHz, 10-Dec-09

EMCO

Hewlett Packard

Micro-Tronics

Micro-Tronics

File: R78442

Antenna, Horn, 1-18 GHz 9/2/2010

(SA40-Blu)

SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

8564E (84125C) 1393 4/10/2010

Band Reject Filter, 5725-5875

MHz

Band Reject Filter, 2400-2500 BRM50702-02 1731 11/4/2010

Appendix Page 1 of 4

Elliott Laboratories -- EMC Department

Report Date:

Hewlett Packard

MHz

Microwave Preamplifier, 1-

A.H. Systems

26.5GHz

Purple System Horn, 18-40GHz

Radiated Emissions, 30 - 18,000 MHz, 06-Jan-10

SAS-574, p/n: 2581 2160

Test Report

March 2, 2010

3/17/2010

EMCO

Hewlett Packard

Micro-Tronics

Antenna, Horn, 1-18 GHz 9/2/2010

(SA40-Blu)

8564E (84125C) 1393 4/10/2010 SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

Band Reject Filter, 2400-2500

MHz

Hewlett Packard Microwave Preamplifier, 1-

26.5GHz

DTS Spurious, 1000-25,000 MHz, 08-Jan-10

EMCO

Hewlett Packard

Micro-Tronics

Hewlett Packard

Antenna, Horn, 1-18 GHz 9/2/2010

(SA40-Blu)

SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

8564E (84125C) 1393 4/10/2010

Band Reject Filter, 2400-2500

MHz

Microwave Preamplifier, 1-

26.5GHz

Radiated Emissions, 30 - 40,000 MHz, 08-Jan-10

EMCO

Hewlett Packard

Antenna, Horn, 1-18 GHz 9/2/2010

(SA40-Blu)

SpecAn 9 kHz - 40 GHz, FT 8564E (84125C) 1393 4/10/2010

Micro-Tronics

Micro-Tronics

Hewlett Packard

Hewlett Packard

Hewlett Packard

A.H. Systems

(SA40) Blue

Band Reject Filter, 2400-2500

MHz

Band Reject Filter, 5725-5875

MHz

HF Amplifier, 45 MHz -50 GHz

(with 1620)

HF Amplifier, 45 MHz -50 GHz

(with 1620)

Microwave Preamplifier, 1-

26.5GHz

83051A (84125C)

83051A (84125C)

1742

1743

5/6/2010

5/6/2010

Blue System Horn, 18-40GHz

Conducted Emissions - AC Power Ports, 14-Jan-10

SAS-574, p/n: 2581 2159 3/17/2010

1293

1401

3/18/2010

4/6/2010

EMCO

Rohde & Schwarz

LISN, 10 kHz-100 MHz

Pulse Limiter

EMI Test Receiver, 20 Hz-7

3825/2

ESH3 Z2

GHz

Radio Antenna Port (Power and Spurious Emissions), 15-Jan-10

Hewlett Packard SpecAn 9 kHz - 40 GHz, FT

(SA40) Blue

Attenuator, 10dB , 50 ohms,

25W, DC-18 GHz

8564E (84125C) 1393 4/10/2010

File: R78442 Appendix Page 2 of 4

Elliott Laboratories -- EMC Department

Radio Antenna Port (Power and Spurious Emissions), 22-Jan-10

Rohde & Schwarz

Hewlett Packard

Rohde & Schwarz

Power Meter, Single Channel NRVS

SpecAn 9 kHz - 40 GHz, FT 8564E (84125C)

(SA40) Blue

Power Sensor 100 uW - 2 Watts NRV-Z32

Power Sensor 100 uW - 10

Watts

Test Report

Report Date: March 2, 2010

1290

1393

1423

10/22/201

0

4/10/2010

10/23/201

0

File: R78442

DRAFT

Appendix Page 3 of 4

Elliott Laboratories -- EMC Department

Appendix B Test Data

T77316 48 Pages

T77317 19 Pages

Test Report

Report Date: March 2, 2010

File: R78442

DRAFT

Appendix Page 4 of 4

Client: Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Emissions Standard(s): FCC 15.247/RSS 210

Immunity Standard(s): -

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: -

Environment: -

T77316_DTS_Radiated_Final

EMC Test Data

For The

Summit Data Communications

Model

SDC-MSD30AG

Date of Last Test: 2/26/2010

DRAFT

Cover Page 1 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

RSS 210 and FCC 15.247 (DTS) Radiated Spurious Emissions

(Summit Antenna)

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated spurious emissions testing.

For radiated emissions testing the measurement antenna was located 3 meters from the EUT.

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

Ambient Conditions:

Temperature:

Rel. Humidity:

10-20 °C

30-50 %

Date of Test: Refer to each run

Test Engineer: Refer to each run

Test Location: Refer to each run

Config. Used: 1

Config Change: None

Host Unit Voltage 120V/ 60Hz

DRAFT

Page 2 of 48 T77316_DTS_Radiated_Final DTS RE-Summit-2A Module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Summary of Results - Device Operating in the 2400-2483.5 MHz Band

NOTE 1: A preliminary check of output power was performed. The port with the highest power was used for the final testing.

Preliminary tests showed no radio related emissions below 1 GHz.

NOTE 2: Preliminary scan showed that EUT located at its side has highest field strength. All test were performed with EUT at its side orientation.

Run #

1a

1b

1c

2a

2b

2c

Antenna:

Module:

Mode Channel

Power

Setting

Port

Test Performed Limit b mode b mode b mode g mode g mode g mode

Johanson 0 dBi dipole antenna (Elliott 2009-1604)

00000002A

Low

2412 MHz

Center

2437 MHz

High

2462 MHz

Low

2412 MHz

Center

2437 MHz

High

2462 MHz

19

19

19

19

17

19

19

19

19

19

DRIVER:

Main

Main

Main

Main

Main

Main

Main

Main

Main

V3.00.50

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

SCU: V2.03.18

Result / Margin

42.2dBµV/m @

2385.7MHz (-11.8dB)

48.5dBµV/m @

4824.0MHz (-5.5dB)

52.6dBµV/m @

4874.0MHz (-1.4dB)

44.9dBµV/m @

2487.9MHz (-9.1dB)

53.8dBµV/m @

4924.0MHz (-0.2dB)

52.0dBµV/m @

2389.9MHz (-2.0dB)

46.8dBµV/m @

1302.5MHz (-7.2dB)

45.8dBµV/m @

1302.5MHz (-8.2dB)

52.0dBµV/m @

2483.5MHz (-2.0dB)

45.5dBµV/m @

1302.5MHz (-8.5dB)

T77316_DTS_Radiated_Final DTS RE-Summit-2A Module Page 3 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

RSS 210 and FCC 15.247 (DTS) Radiated Spurious Emissions

(Cisco Air-Ant 4941, 2.4GHz)

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated spurious emissions testing.

For radiated emissions testing the measurement antenna was located 3 meters from the EUT.

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

Ambient Conditions:

Temperature:

Rel. Humidity:

10-20 °C

30-50 %

Date of Test: Refer to each run

Test Engineer: Refer to each run

Test Location: Refer to each run

Config. Used: 1

Config Change: None

Host Unit Voltage 120V/ 60Hz

DRAFT

Page 4 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Summary of Results - Device Operating in the 2400-2483.5 MHz Band

NOTE 1: A preliminary check of output power was performed. The port with the highest power was used for the final testing.

Preliminary tests showed no radio related emissions below 1 GHz and above 18GHz.

Run #

1a

1b

1c

2a

2b

2c

2e

Antenna:

Module:

Mode Channel

Power

Setting

Port

Test Performed Limit b mode b mode b mode g mode g mode g mode g mode

Low

2412 MHz

Center

2437 MHz

High

2462 MHz

Low

2412 MHz

Ch 2

2417 MHz

Center

2437 MHz

High

2462 MHz

19 dBm

19 dBm

19 dBm

19 dBm

19dBm

16 dBm

19dBm

19dBm

19dBm

19dBm

19dBm

Air Dipole Antenna (Elliott 2009-1387)

00000002A

DRIVER:

Main

Main

Main

Main

Main

Main

Main

Main

Main

Main

V3.00.50

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

SCU: V2.03.18

Frequency Range

1000 - 10000 MHz

10000 - 26500 MHz

Test Distance

3

1

Limit Distance

3

3

Extrapolation Factor

0.0

-9.5

Result / Margin

49.9dBµV/m @

2386.2MHz (-4.1dB)

52.5dBµV/m @

4824.0MHz (-1.5dB)

49.0dBµV/m @

4874.0MHz (-5.0dB)

46.4dBµV/m @

2487.7MHz (-7.6dB)

53.0dBµV/m @

4924.1MHz (-1.0dB)

52.6dBµV/m @

2390.0MHz (-1.4dB)

44.8dBµV/m @

1345.4MHz (-9.2dB)

48.3dBµV/m @

2389.9MHz (-5.7dB)

46.5dBµV/m @

3249.4MHz (-7.5dB)

49.2dBµV/m @

2483.6MHz (-4.8dB)

44.8dBµV/m @

1302.5MHz (-9.2dB)

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 5 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #1: Radiated Spurious Emissions, 30 - 26000 MHz. Operating Mode: 802.11b

Run #1a: Low Channel @ 2412 MHz with Power Setting of 19 dBm.

Date: 1/21/2010 Engineer: Suhaila Khushzad Location: FT Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol

15.209 / 15.247

Detector Azimuth Height Comments

MHz

2410.400

dB

μV/m

101.9

V/H

V

Limit

-

Margin Pk/QP/Avg degrees

AVG 150 meters

1.2

RB 1 MHz; VB: 10 Hz

2409.600

2410.400

2409.670

2410.400

2411.330

104.3

95.3

98.5

92.8

98.5

V

H

H

H

V

-

-

-

-

-

-

-

-

-

-

PK

AVG

PK

PK

PK

150

224

224

224

150

1.2

1.5

1.5

1.5

1.2

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

RB 100 kHz; VB: 100 kHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

98.5 dB

μV/m

68.5 dB μV/m Limit is -30dBc (UNII power measurement)

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

-4.1

AVG 150

Height Comments meters

1.2

RB 1 MHz; VB: 10 Hz

Band Edge Signal Field Strength

Frequency

MHz

2386.200

Level dB

μV/m

49.9

Pol

V/H

V

2386.470

2386.330

2386.400

57.9

45.9

56.8

V

H

H

74.0

54.0

74.0

-16.1

-8.1

-17.2

PK

AVG

PK

150

224

224

1.2

1.5

1.5

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 6 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Other Spurious Emissions

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Frequency Level

MHz

4823.970

4824.030

1306.320

1306.390

2768.460

2779.990

9648.020

9631.350

14472.010

14472.040

dB

μV/m

52.5

54.2

45.1

48.0

38.9

51.5

42.0

48.7

43.6

48.9

Pol

V/H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

Height Comments meters

V

V

V

V

V

V

H

H

V

54.0

74.0

54.0

74.0

54.0

74.0

54.0

-1.5

-19.8

-8.9

-26.0

-15.1

-22.5

-12.0

AVG

PK

AVG

PK

AVG

PK

AVG

200

200

124

124

282

282

95

1.3

1.3

1.1

1.1

1.0

1.0

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz, Note 1

V 74.0

-25.3

PK 95 1.0

RB 1 MHz; VB: 1 MHz

54.0

74.0

-10.4

-25.1

AVG

PK

248

248

1.0

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

Note 1: Restricted band limit used for emission in non-restricted band.

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 7 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1b: Center Channel @ 2437 MHz with Power Setting of 19dBm.

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Frequency Level

MHz

4873.990

4873.890

dB

μV/m

49.0

51.9

1345.380

1345.550

14622.010

14621.980

9748.050

3249.310

44.6

44.3

47.1

50.9

48.6

43.2

Pol

V/H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

Height meters

Comments

V

V

V

V

V

V

V

54.0

74.0

54.0

74.0

54.0

74.0

54.0

-5.0

-22.1

-9.4

-29.7

-6.9

-23.1

-5.4

AVG

PK

AVG

PK

AVG

PK

Peak

73

73

120

120

248

248

316

1.8

1.8

1.1

1.1

1.0

1.0

1.3

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz, note 2

RB 1 MHz; VB: 1 MHz

Peak vs Avg Limit, Note 2

V 54.0

-10.8

Peak 360 1.3

Peak vs Avg Limit

Note 1:

Note 2:

For emissions in restricted bands, the limit of 15.209 was used. For all other emissions, the limit was set 30dB below the level of the fundamental and measured in 100kHz.

Restricted band limit used for emission in non-restricted band.

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 8 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #1c: High Channel @ 2462 MHz with power setting of 19 dBm.

Date:

1/21/2010

Engineer:

Suhaila Khushzad

Location:

FT Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2461.000

dB

μV/m

99.5

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 184 meters

1.0

RB 1 MHz; VB: 10 Hz

2461.400

2460.530

2461.330

2461.730

2461.330

102.4

95.5

98.5

92.1

96.2

V

H

H

H

V

-

-

-

-

-

-

-

-

-

-

PK

AVG

PK

PK

PK

184

225

225

225

184

1.0

1.2

1.2

1.2

1.0

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

RB 100 kHz; VB: 100 kHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

96.2 dB μV/m

66.2 dB

μV/m

Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency Level Pol

MHz

2487.730

dB

μV/m

46.4

V/H

V

2495.570

2487.760

2486.880

56.9

45.8

56.7

V

15.209 / 15.247

Limit

54.0

74.0

Margin

-7.6

-17.1

Detector

Pk/QP/Avg degrees

AVG

PK

Azimuth

184

184

Height Comments meters

1.0

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

H

H

54.0

74.0

-8.2

-17.3

AVG

PK

225

225

1.2

1.2

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 9 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

4924.050

53.0

4924.050

7388.830

7383.500

2762.270

2771.170

1345.350

9848.010

14772.130

17238.470

54.5

42.0

50.4

38.9

50.9

42.9

51.1

48.6

46.8

Pol

V/H

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

-1.0

AVG 35

Height Comments meters

2.2

RB 1 MHz; VB: 10 Hz

V

V

V

V

V

V

V

74.0

54.0

74.0

54.0

74.0

54.0

54.0

-19.5

-12.0

-23.6

-15.1

-23.1

-11.1

-2.9

PK

AVG

PK

AVG

PK

Peak

Peak

35

52

52

184

184

122

334

2.2

1.4

1.4

2.2

2.2

1.0

1.3

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

Peak vs Avg Limit

Peak vs Avg Limit, note 2

V 54.0

-5.4

Peak 247 1.0

Peak vs Avg Limit, note 2

H 54.0

-7.2

Peak 45 1.0

Peak vs Avg Limit, note 2

Note 2:

Restricted band limit used for emission in non-restricted band.

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 10 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #2: Radiated Spurious Emissions, 30 - 26000 MHz. Operating Mode: 802.11g

Run #2a: Low Channel @ 2412 MHz with power setting of 16 dBm.

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2405.000

dB

μV/m

97.2

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 150 meters

1.5

RB 1 MHz; VB: 10 Hz

2405.200

2408.470

2405.270

2405.070

2405.930

104.9

97.8

90.9

98.7

88.9

V

V

H

H

H

-

-

-

-

-

-

-

-

-

-

PK

PK

AVG

PK

PK

150

150

222

222

222

1.5

1.5

1.5

1.5

1.5

RB 1 MHz; VB: 1 MHz pwr 16dBm

RB 100 kHz; VB: 100 kH pwr 16dBm

RB 1 MHz; VB: 10 Hz pwr 16dBm

RB 1 MHz; VB: 1 MHz pwr 16dBm pwr 16dBm

RB 100 kHz; VB: 100 kH pwr 16dBm

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

97.8 dB μV/m

67.8 dB

μV/m

Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency Level Pol

MHz

2390.000

dB

μV/m

52.6

V/H

V

2389.400

2390.000

2389.800

67.9

47.6

60.0

V

15.209 / 15.247

Limit

54.0

74.0

Margin

-1.4

-6.1

Detector

Pk/QP/Avg degrees

AVG

PK

Azimuth

150

150

Height Comments meters

1.5

1.5

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

H

H

54.0

74.0

-6.4

-14.0

AVG

PK

222

222

1.5

1.5

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT pwr 16dBm pwr 16dBm pwr 16dBm pwr 16dBm

Page 11 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Note 2:

Pol

V/H

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

-9.2

AVG 120

Height Comments meters

1.1

RB 1 MHz; VB: 10 Hz

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

1345.400

44.8

1345.380

4823.960

4826.430

3216.050

3215.960

47.7

40.0

51.8

47.9

50.7

V

V

V

V

V

74.0

54.0

74.0

54.0

74.0

-26.3

-14.0

-22.2

-6.1

-23.3

PK

AVG

PK

AVG

PK

Restricted band limit used for emission in non-restricted band.

120

201

201

268

268

1.1

1.2

1.2

1.2

1.2

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT pwr 19dBm pwr 19dBm pwr 19dBm pwr 19dBm pwr 19dBm pwr 19dBm

Page 12 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #2b: 2nd Channel @ 2417 MHz with Power Setting of 19 dBm.

Date:

1/21/2010

Engineer:

Suhaila Khushzad

Location:

FT Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2409.870

dB

μV/m

97.6

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 152 meters

1.2

RB 1 MHz; VB: 10 Hz

2409.800

2415.930

105.2

97.2

V

V

-

-

-

-

PK

PK

152

152

1.2

1.2

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

97.2 dB

μV/m

67.2 dB μV/m Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency

MHz

2389.870

2389.930

Level dB

μV/m

48.3

60.0

Pol

V/H

V

V

15.209 / 15.247

Limit

54.0

74.0

Detector Azimuth

Margin Pk/QP/Avg degrees

-5.7

-14.0

AVG

PK

152

152

Height Comments meters

1.2

1.2

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 13 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #2c: Center Channel @ 2437 MHz with power setting of 19dBm.

Date:

1/21/2010

Engineer:

Suhaila Khushzad

Location:

FT Chamber #4

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

1345.420

44.9

2768.190

3249.370

4874.090

1345.400

2765.140

3249.330

4876.350

38.8

46.5

39.4

48.0

50.2

49.8

51.0

Pol

15.209 / 15.247

Detector Azimuth Height Comments

V/H

V

V

V

V

V

V

Limit

54.0

54.0

54.0

54.0

74.0

74.0

Margin Pk/QP/Avg degrees

-9.1

-15.2

-7.5

-14.6

-26.0

-23.8

AVG

AVG

AVG

AVG

PK

PK

123

180

282

268

123

180 meters

1.1

1.3

1.2

1.0

1.1

1.3

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz note 2

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

V 74.0

-24.2

PK 282 1.2

RB 1 MHz; VB: 1 MHz

V 74.0

-23.0

PK 268 1.0

RB 1 MHz; VB: 1 MHz

Note 2:

Restricted band limit used for emission in non-restricted band.

T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module Page 14 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #2e: High Channel @ 2462 MHz with power setting of 19 dBm.

Date:

1/21/2010

Engineer:

Suhaila Khushzad

Location:

FT Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2455.000

dB

μV/m

95.0

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 185 meters

1.0

RB 1 MHz; VB: 10 Hz

2458.400

2455.730

2456.270

2468.600

2457.270

102.7

90.6

98.2

91.2

95.8

V

H

H

H

V

-

-

-

-

-

-

-

-

-

-

PK

AVG

PK

PK

PK

185

222

222

222

185

1.0

1.2

1.2

1.2

1.0

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

RB 100 kHz; VB: 100 kHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

95.8 dB μV/m

65.8 dB

μV/m

Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency Level Pol

MHz

2483.550

dB

μV/m

49.2

V/H

V

2483.530

2483.500

2483.690

62.0

47.6

59.6

V

15.209 / 15.247

Limit

54.0

74.0

Margin

-4.8

-12.0

Detector

Pk/QP/Avg degrees

AVG

PK

Azimuth

185

185

Height Comments meters

1.0

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

H

H

54.0

74.0

-6.4

-14.4

AVG

PK

222

222

1.2

1.2

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 15 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

1302.500

3282.500

44.8

45.6

Pol

V/H

V

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

74.0

-9.2

-28.4

Peak

Peak

125

316

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Height Comments meters

1.3

1.3

Peak reading with average limit

Peak reading with average limit

DRAFT

Page 16 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz Air Ant 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

RSS 210 and FCC 15.247 (DTS) Radiated Spurious Emissions

(Hubert & Suhner Antenna, 2.4GHz)

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated spurious emissions testing.

For radiated emissions testing the measurement antenna was located 3 meters from the EUT.

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

Ambient Conditions:

Temperature:

Rel. Humidity:

10-20 °C

30-50 %

Date of Test: Refer to each run

Test Engineer: Refer to each run

Test Location: Refer to each run

Config. Used: 1

Config Change: None

Host Unit Voltage 120V/ 60Hz

DRAFT

Page 17 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Summary of Results - Device Operating in the 2400-2483.5 MHz Band

NOTE 1: A preliminary check of output power was performed. The port with the highest power was used for the final testing.

Preliminary tests showed no radio related emissions below 1 GHz.

Run #

1a

1b

1c

2a

2b

2c

2d

2e

Mode b mode b mode b mode g mode g mode g mode g mode g mode

Channel

Low

2412 MHz

Center

2437 MHz

High

2462 MHz

Power

Setting

19 dBm

19 dBm

19 dBm

19 dBm

19dBm

Port

Main

Main

Main

Main

Main

Low

2412 MHz

16 dBm Main

19dBm Main

Ch 2

2417 MHz

Center

2437 MHz

Ch 10

2457 MHz

High

2462 MHz

19dBm

19dBm

19 dBm

16 dBm

19dBm

Main

Main

Main

Main

Test Performed

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2390 MHz)

Radiated Emissions,

1 - 26 GHz

Restricted Band Edge

(2483.5 MHz)

Restricted Band Edge

(2483.5 MHz)

Radiated Emissions,

1 - 26 GHz

Limit

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

15.247( c)

Result / Margin

51.0dBµV/m @

2386.5MHz (-3.0dB)

52.6dBµV/m @

4824.0MHz (-1.4dB)

50.4dBµV/m @

4874.1MHz (-3.6dB)

49.5dBµV/m @

2488.0MHz (-4.5dB)

49.8dBµV/m @

4924.0MHz (-4.2dB)

52.6dBµV/m @

2389.9MHz (-1.4dB)

50.2dBµV/m @

3209.2MHz (-3.8dB)

51.1dBµV/m @

2389.6MHz (-2.9dB)

47.6dBµV/m @

3245.8MHz (-6.4dB)

49.9dBµV/m @

2483.5MHz (-4.1dB)

51.9dBµV/m @

2483.5MHz (-2.1dB)

46.8dBµV/m @

3282.6MHz (-7.2dB)

T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module Page 18 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Antenna:

Module:

Hubert & Suhner monopole antenna (Elliott 2009-1388)

00000002A

DRIVER:

V3.00.50

Frequency Range

1000 - 10000 MHz

10000 - 26500 MHz

Test Distance

3

1

SCU: V2.03.18

Limit Distance

3

3

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Extrapolation Factor

0.0

-9.5

Run #1: Radiated Spurious Emissions, 30 - 26000 MHz. Operating Mode: 802.11b

Run #1a: Low Channel @ 2412 MHz with Power Setting of 19 dBm.

Date:

1/8/2010

Engineer:

John Caizzi

Location:

FT Chamber #3

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2410.400

dB

μV/m

104.8

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 217 meters

1.28

2413.200

107.9

V PK 217 1.28

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

102.0 dB

μV/m

72.0 dB μV/m Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency Level

MHz

2386.470

2385.930

dB

μV/m

51.0

58.5

Pol

V/H

V

V

15.209 / 15.247

Limit

54.0

74.0

-3.0

-15.5

Detector Azimuth

Margin Pk/QP/Avg degrees

AVG

PK

217

217

Height Comments meters

1.28

1.28

DRAFT

Page 19 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Date:

1/8/2010

Frequency Level

MHz dB

μV/m

4823.990

1318.550

52.6

43.2

4823.930

54.8

Pol

V/H

V

H

V

Engineer:

Mehran Birgani

Location:

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

74.0

-1.4

-10.8

-19.2

AVG

PK

PK

66

112

66

FT Chamber #3

Height Comments meters

1.0

1.3

1.0

Peak reading with average limit

Note 1: No significant emissions found above 10 GHz.

DRAFT

Page 20 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #1b: Center Channel @ 2437 MHz with Power Setting of 19dBm.

Date:

1/8/2010

Engineer:

Mehran Birgani

Location:

FT Chamber #3

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2435.370

dB

μV/m

107.2

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 268 meters

1.3

2436.200

2438.900

2438.070

110.3

98.2

101.5

V

H

H -

-

-

-

-

PK

AVG

PK

268

207

207

1.3

1.6

1.6

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

104.8 dB

74.8 dB

μV/m

μV/m

Limit is -30dBc (UNII power measurement)

Other Spurious Emissions

Frequency Level

MHz

4874.050

dB

μV/m

50.4

1302.500

4874.000

46.4

53.0

Pol

V/H

V

H

V

15.209 / 15.247

Limit

54.0

54.0

74.0

Margin

-3.6

-7.6

-21.0

Detector

Pk/QP/Avg degrees

AVG

PK

PK

Azimuth

86

105

86

Height meters

1.0

1.3

1.0

Comments

Peak reading with average limit

Note 1:

Note 2:

For emissions in restricted bands, the limit of 15.209 was used. For all other emissions, the limit was set 30dB below the level of the fundamental and measured in 100kHz.

No significant emissions found above 10 GHz.

DRAFT

Page 21 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #1c: High Channel @ 2462 MHz with power setting of 19 dBm.

Date:

1/8/2010

Engineer:

John Caizzi

Location:

FT Chamber #3

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2461.270

dB

μV/m

101.9

V/H

V

Limit

120.0

Margin

-18.1

Pk/QP/Avg degrees

Pk 217 meters

1.28

2460.470

2463.270

104.8

107.8

V

V

120.0

120.0

-15.2

-12.2

AVG

PK

217

217

1.28

1.28

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

101.9 dB

μV/m

71.9 dB μV/m Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency

MHz

2488.010

2491.090

Level dB

μV/m

49.5

58.0

Pol

V/H

V

V

15.209 / 15.247

Limit

54.0

74.0

Detector Azimuth

Margin Pk/QP/Avg degrees

-4.5

-16.0

AVG

PK

217

217

Height meters

1.28

1.28

Comments

DRAFT

T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module Page 22 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Date:

2/26/2010

Frequency Level

MHz dB

μV/m

4924.000

4924.010

49.8

52.5

7389.010

7382.960

9848.040

45.6

53.7

47.8

Pol

V/H

V

V

V

V

V

Engineer:

Rafael Varelas

Location:

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

74.0

54.0

-4.2

-21.5

-8.4

AVG

PK

AVG

0

0

0

74.0

54.0

-20.3

-6.2

PK

Peak

0

88

Ft Chamber #4

Height Comments meters

1.8

1.8

1.5

1.5

1.9

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

Peak reading vs avg limit, note 2

Note 2: Restricted band limit was used.

DRAFT

Page 23 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #2: Radiated Spurious Emissions, 30 - 26000 MHz. Operating Mode: 802.11g

Run #2a: Low Channel @ 2412 MHz with power setting of 16 dBm.

Date: 1/8/2010 Engineer: John Caizzi Location: FT Chamber #3

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol

15.209 / 15.247

Detector Azimuth Height Comments

MHz

2407.070

dB

μV/m

99.1

V/H

V

Limit

120.0

Margin Pk/QP/Avg degrees

-20.9

Pk 319 meters

1.00

16 dBm

2405.400

2405.400

2407.400

2404.930

2405.470

100.6

108.9

92.7

94.2

102.4

V

V

H

H

H

120.0

120.0

120.0

120.0

120.0

-19.4

-11.1

-27.3

-25.8

-17.6

AVG

PK

Pk

AVG

PK

319

319

207

207

207

1.00

1.00

1.35

1.35

1.35

16 dBm

16 dBm

16 dBm

16 dBm

16 dBm

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

99.1 dB

μV/m

69.1 dB μV/m Limit is -30dBc (UNII power measurement)

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

-1.4

AVG 319

Height Comments meters

1.00

16 dBm

Band Edge Signal Field Strength

Frequency

MHz

2389.930

Level dB

μV/m

52.6

Pol

V/H

V

2389.200

68.3

V 74.0

-5.7

PK 319 1.00

16 dBm

DRAFT

Page 24 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Other Spurious Emissions

Date:

2/26/2010

Frequency Level

MHz dB

μV/m

4824.040

3209.170

36.2

50.2

4827.780

48.6

Pol

V/H

V

V

V

Engineer:

Rafael Varelas

Location:

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

74.0

-17.8

-3.8

-25.4

AVG

Peak

PK

346

349

346

Ft Chamber #4

Height Comments meters

1.6

1.3

1.6

RB 1 MHz; VB: 10 Hz

Peak reading vs avg limit, note 2

RB 1 MHz; VB: 1 MHz

Note 1:

Note 2:

For emissions in restricted bands, the limit of 15.209 was used. For all other emissions, the limit was set 30dB below the level of the fundamental and measured in 100kHz.

Restricted band limit was used.

DRAFT

Page 25 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #2b: 2nd Channel @ 2417 MHz with Power Setting of 19 dBm.

Date:

2/26/2010

Engineer:

Rafael Varelas

Location:

Ft Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2411.700

dB

μV/m

101.4

V/H

V

Limit

120.0

Margin

-18.6

Pk/QP/Avg degrees

AVG 202 meters

1.2

RB 1 MHz; VB: 10 Hz

2413.170

2424.700

2413.200

2419.830

109.6

100.8

93.4

101.3

V

V

H

H

120.0

120.0

120.0

120.0

-10.4

-19.2

-26.6

-18.7

PK

PK

AVG

PK

202

202

138

138

1.2

1.2

1.6

1.6

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

100.8 dB

μV/m

70.8 dB μV/m Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency

MHz

2389.640

2388.880

Level dB

μV/m

51.1

64.8

Pol

V/H

V

V

2389.950

2389.840

46.6

58.7

H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

74.0

54.0

-2.9

-9.2

-7.4

AVG

PK

AVG

202

202

138

Height Comments meters

1.2

1.2

1.6

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

H 74.0

-15.3

PK 138 1.6

RB 1 MHz; VB: 1 MHz

DRAFT

Page 26 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #2c: Center Channel @ 2437 MHz with power setting of 19dBm.

Date:

2/26/2010

Engineer:

Rafael Varelas

Location:

Ft Chamber #4

Other Spurious Emissions

Frequency Level

MHz

4874.010

dB

μV/m

38.6

7310.170

3245.830

4867.770

7310.190

40.4

47.6

51.0

52.2

V

V

V

Pol

V/H

V

V

15.209 / 15.247

Limit

54.0

54.0

Margin

-15.4

-13.6

Detector

Pk/QP/Avg degrees

AVG

AVG

Azimuth

172

350

54.0

74.0

74.0

-6.4

-23.0

-21.8

Peak

PK

PK

101

172

350

Note 2:

Restricted band limit was used.

Height Comments meters

1.6

1.6

1.3

1.6

1.6

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz

Peak reading vs avg limit, note 2

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 27 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Run #2d: Center Channel @ 2457 MHz with power setting of 19dBm.

Date:

2/26/2010

Engineer:

Rafael Varelas

Location:

Ft Chamber #4

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

2450.200

dB

μV/m

100.5

V/H

V

Limit

120.0

Margin

-19.5

Pk/QP/Avg degrees

AVG 176 meters

1.5

RB 1 MHz; VB: 10 Hz

2450.700

2449.630

2450.100

2450.630

108.4

99.9

93.7

101.8

V

V

H

H

120.0

120.0

120.0

120.0

-11.6

-20.1

-26.3

-18.2

PK

PK

AVG

PK

176

176

128

128

1.5

1.5

1.6

1.6

RB 1 MHz; VB: 1 MHz

RB 100 kHz; VB: 100 kHz

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

99.9 dB

μV/m

69.9 dB μV/m Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency

MHz

2483.500

2484.840

Level dB

μV/m

49.9

64.2

Pol

V/H

V

V

2483.520

2483.800

46.0

58.7

H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

74.0

54.0

-4.1

-9.8

-8.0

AVG

PK

AVG

176

176

128

Height Comments meters

1.5

1.5

1.6

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 10 Hz

H 74.0

-15.3

PK 128 1.6

RB 1 MHz; VB: 1 MHz

DRAFT

Page 28 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #2e: High Channel @ 2462 MHz with power setting of 16 dBm.

Date:

1/8/2010

Engineer:

John Caizzi

Location:

FT Chamber #3

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency

MHz

2464.200

2467.070

Level dB

μV/m

98.0

99.3

Pol

V/H

V

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

120.0

120.0

-22.0

-20.7

Pk

AVG

254

254

Height meters

1.28

1.28

Comments

2465.530

107.2

V 120.0

-12.8

PK 254 1.28

Fundamental emission level @ 3m in 100kHz RBW:

Limit for emissions outside of restricted bands:

98.0 dB

68.0 dB

μV/m

μV/m

Limit is -30dBc (UNII power measurement)

Band Edge Signal Field Strength

Frequency Level Pol

MHz

2483.500

dB

μV/m

51.9

V/H

V

2483.800

68.8

V

15.209 / 15.247

Limit

54.0

74.0

Margin

-2.1

-5.2

Detector Azimuth

Pk/QP/Avg degrees

AVG

PK

254

254

Height meters

Comments

1.28

16 dBm

1.28

16 dBm

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

4924.130

7385.100

37.1

40.7

3282.610

4925.460

7386.480

46.8

49.4

52.5

V

V

Pol

V/H

V

V

V

DRAFT

15.209 / 15.247

Limit

54.0

54.0

54.0

-16.9

-13.3

-7.2

Detector Azimuth

Margin Pk/QP/Avg degrees

AVG

AVG

Peak

197

1

90

Height Comments meters

1.7

1.7

1.3

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz

Peak reading vs avg limit, note 2

74.0

-24.6

PK 197 1.7

RB 1 MHz; VB: 1 MHz

74.0

-21.5

PK 1 1.7

RB 1 MHz; VB: 1 MHz

Note 2:

Restricted band limit was used.

T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module Page 29 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

DRAFT

Page 30 of 48 T77316_DTS_Radiated_Final DTS RE 2.4GHz H&S 2A module

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

RSS 210 and FCC 15.247 (DTS) Radiated Spurious Emissions

(Monopole Antennas)

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated spurious emissions testing.

For radiated emissions testing the measurement antenna was located 3 meters from the EUT.

Summary of Results - Device Operating in the 5745-5805 MHz Band

NOTE: A preliminary check of output power was performed. The port with the highest power was used for the final testing. Preliminary tests showed no radio related emissions below 1 GHz.

Run # Mode Channel Port

Test Performed Limit Result / Margin

Power

Setting low -

Radiated Emissions, FCC Part 15.209 / 51.6dBµV/m @

1a a mode 19 Main

1b

1c

Antenna:

Module:

a mode

1 - 40GHz

Radiated Emissions,

15.247( c)

FCC Part 15.209 /

5785 a mode high - 5805

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

Larson antenna (Elliott 2009-2119)

Frequency Range

1000 - 10000 MHz

19

19

Main

Main v3.01.03

Test Distance

1 - 40GHz 15.247( c)

DRAFT

DRIVER:

3

SCU: v2.03.30

Limit Distance

3

Extrapolation Factor

0.0

5279.7MHz (-2.4dB)

00000002C

5745 center -

1 - 40GHz

Radiated Emissions,

15.247( c)

FCC Part 15.209 /

5236.3MHz (-2.4dB)

51.1dBµV/m @

5262.6MHz (-2.9dB)

51.6dBµV/m @

10000 - 40000 MHz 1 3 -9.5

Page 31 of 48 T77316_DTS_Radiated_Final DTS RE - 5GHz Larson Monopole

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1: Radiated Spurious Emissions, 30 - 40000 MHz. Operating Mode: 802.11a

Date:

2/26/2010

Engineer:

Rafael Varelas

Location:

Ft Chamber #4

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #3a: Low Channel @ 5745 MHz

Other Spurious Emissions

Frequency

MHz

3830.010

Level dB

μV/m

43.2

Pol

V/H

H

5060.980

11490.110

5236.270

3829.820

5058.930

11492.440

42.8

41.0

51.6

47.9

54.9

57.0

V

V

V

H

V

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

-10.8

AVG 330

54.0

54.0

54.0

74.0

74.0

74.0

-11.2

-13.0

-2.4

-26.1

-19.1

-17.0

AVG

AVG

Peak

PK

PK

PK

56

7

79

330

56

7

Note 1: Restricted band limit used.

Height Comments meters

1.8

RB 1 MHz; VB: 10 Hz

1.0

1.3

1.0

1.8

1.0

1.3

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz peak reading vs avg limit, note 1

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

DRAFT

T77316_DTS_Radiated_Final DTS RE - 5GHz Larson Monopole Page 32 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1b: Center Channel @ 5785 MHz

Other Spurious Emissions

Frequency

MHz

3856.680

4829.690

Level dB

μV/m

42.1

44.8

Pol

V/H

H

V

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

-11.9

-9.2

AVG

AVG

329

69

11568.490

5262.640

3856.620

4830.420

11566.190

37.3

51.1

47.7

56.8

54.5

V

V

H

V

V

54.0

54.0

74.0

74.0

74.0

-16.7

-2.9

-26.3

-17.2

-19.5

AVG

Peak

PK

PK

PK

9

52

329

69

9

Note 1: Restricted band limit used.

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Height Comments meters

1.8

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz

1.2

1.0

1.8

1.0

1.2

RB 1 MHz; VB: 10 Hz peak reading vs avg limit, note 1

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 33 of 48 T77316_DTS_Radiated_Final DTS RE - 5GHz Larson Monopole

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1c: High Channel @ 5805 MHz (channel 161)

Other Spurious Emissions

Frequency

MHz

Level dB

μV/m

Pol

V/H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

3870.010

5073.310

42.2

45.5

H

V

54.0

54.0

-11.8

-8.5

AVG

AVG

334

300

11611.430

5279.740

3869.850

5072.210

11611.160

36.5

51.6

47.3

57.6

53.9

V

V

H

V

V

54.0

54.0

74.0

74.0

74.0

-17.5

-2.4

-26.7

-16.4

-20.1

AVG

Peak

PK

PK

PK

135

68

334

300

135

Note 1: Restricted band limit used.

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Height Comments meters

1.8

1.0

RB 1 MHz; VB: 10 Hz

RB 1 MHz; VB: 10 Hz

1.2

1.0

1.8

1.0

1.2

RB 1 MHz; VB: 10 Hz peak reading vs avg limit, note 1

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

RB 1 MHz; VB: 1 MHz

DRAFT

Page 34 of 48 T77316_DTS_Radiated_Final DTS RE - 5GHz Larson Monopole

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

RSS 210 and FCC 15.247 (DTS) Radiated Spurious Emissions

(Hubert & Suhner Antenna, 5GHz)

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated spurious emissions testing.

For radiated emissions testing the measurement antenna was located 3 meters from the EUT.

Ambient Conditions:

Date of Test: Refer to each run

Test Engineer:

Refer to each run

Test Location: Refer to each run

Temperature:

Rel. Humidity:

10-20 °C

30-50 %

Config. Used: 1

Config Change: None

Host Unit Voltage 120V/ 60Hz

Summary of Results - Device Operating in the 5745-5805 MHz Band

NOTE: A preliminary check of output power was performed. The port with the highest power was used for the final testing. Preliminary tests showed no radio related emissions below 1 GHz.

Run #

1a

1b

Mode a mode a mode

Channel

Low

Center

Power

Setting

18

18

Port

Main

Test Performed

Radiated Emissions,

1 - 40GHz

Radiated Emissions,

Limit

FCC Part 15.209 /

15.247( c)

FCC Part 15.209 /

Result / Margin

49.2dBµV/m @

3883.3MHz (-5.1dB)

47.8dBµV/m @

1c a mode High 18 Main

1 - 40GHz

Radiated Emissions,

1 - 40GHz

15.247( c)

FCC Part 15.209 /

15.247( c)

3856.7MHz (-6.2dB)

49.2dBµV/m @

3883.3MHz (-4.8dB)

Antenna:

Module:

Hubert & Suhner monopole antenna (Elliott 2009-1388)

00000002A

DRIVER:

V3.00.50

Modifications Made During Testing

No modifications were made to the EUT during testing

SCU: V2.03.18

Deviations From The Standard

No deviations were made from the requirements of the standard.

T77316_DTS_Radiated_Final DTS RE - 5GHz H&S 2A Module Page 35 of 48

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210 Class: N/A

Frequency Range

1000 - 12000 MHz

12000 - 40000 MHz

Test Distance

3

1

Limit Distance

3

3

Run #1: Radiated Spurious Emissions, 30 - 40000 MHz. Operating Mode: 802.11a

Date:

1/8/2010

Engineer:

Mehran Birgani

Location:

FT Chamber #3

Extrapolation Factor

0.0

-9.5

Run #1a: Low Channel @ 5745 MHz with power setting of 18dBm.

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol

15.209 / 15.247

Detector Azimuth Height Comments

MHz

5745.100

dB

μV/m

97.7

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 318 meters

1.4

5745.070

104.2

V PK 318 1.4

Other Spurious Emissions

Frequency Level

MHz

3883.330

dB

μV/m

49.2

1302.500

3883.410

17231.670

44.3

52.7

45.6

V

V

H

Pol

V/H

V

15.209 / 15.247

Limit

54.0

Margin

-5.1

Detector Azimuth

Pk/QP/Avg degrees

AVG 244

54.0

74.0

74.0

-9.7

-21.3

-28.4

PK

PK

PK

341

244

237

Height Comments meters

1.4

1.0

1.4

1.0

Peak reading with average limit

Peak reading with average limit

Note 1: Signal is not in a restricted band but the more stringent restricted band limit was used.

Note 2: Near field scan showed there were no signal above 18GHz.

DRAFT

Page 36 of 48 T77316_DTS_Radiated_Final DTS RE - 5GHz H&S 2A Module

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #2b: Center Channel @ 5785 MHz with power setting of 18dBm.

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

5785.100

dB

μV/m

94.0

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 211 meters

1.1

5785.100

103.7

V PK 211 1.1

Other Spurious Emissions

Frequency Level

MHz dB

μV/m

3856.690

1306.390

47.8

44.8

3856.450

17355.060

51.3

46.5

Pol

V/H

H

H

H

H

15.209 / 15.247

Limit

54.0

54.0

74.0

74.0

Detector Azimuth

Margin Pk/QP/Avg degrees

-6.2

-9.2

-22.7

-27.5

AVG

PK

PK

PK

20

105

20

236

Height Comments meters

1.2

1.3

1.2

1.0

Peak reading with average limit

Peak reading with average limit

Note 1:

Note 2:

Signal is not in a restricted band but the more stringent restricted band limit was used.

Near field scan showed there were no signal above 18GHz.

DRAFT

T77316_DTS_Radiated_Final DTS RE - 5GHz H&S 2A Module Page 37 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: N/A

Run #1c: High Channel @ 5805 MHz with power setting of 18dBm.

Fundamental Signal Field Strength: Peak and average values measured in 1 MHz, and peak value measured in 100kHz

Frequency Level Pol 15.209 / 15.247

Detector Azimuth Height Comments

MHz

5805.100

dB

μV/m

99.4

V/H

V

Limit

-

Margin

-

Pk/QP/Avg degrees

AVG 176 meters

1.8

5804.830

104.2

V PK 176 1.8

Other Spurious Emissions

Frequency Level

MHz

3883.330

1306.340

3883.410

17417.190

dB

μV/m

49.2

44.6

52.7

44.4

Pol v/h

V

H

V

H

15.209 / 15.247

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

-4.8

-9.4

AVG

PK

246

106

74.0

74.0

-21.3

-29.6

PK

PK

246

233

Height meters

1.4

1.3

1.4

1.0

Note 1: Signal is not in a restricted band but the more stringent restricted band limit was used.

Note 2: Near field scan showed there were no signal above 18GHz.

Comments

Peak reading with average limit

Peak reading with average limit

DRAFT

T77316_DTS_Radiated_Final DTS RE - 5GHz H&S 2A Module Page 38 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class: -

Radiated Spurious Emissions

Test Specific Details

Objective: The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

General Test Configuration

The EUT and all local support equipment were located on the turntable for radiated emissions testing.

The test distance and extrapolation factor (if applicable) are detailed under each run description.

Note, preliminary testing indicates that the emissions were maximized by orientation of the EUT and elevation of the measurement antenna. Maximized testing indicated that the emissions were maximized by orientation of the EUT, elevation of the measurement antenna, and manipulation of the EUT's interface cables.

Ambient Conditions:

Temperature:

Rel. Humidity:

10-15 °C

39-50 %

Summary of Results

Note:

Module:

Run # Test Performed Limit Result Margin

1 - 2437MHz

Cisco 4941 Antenna

2 - 2437MHz

H&S Monopole Antenna

3 - 5785MHz

Larson Antenna

4- 5785MHz

H&S Monopole Antenna

RE, 30 - 8000 MHz

Maximized Emissions

RE, 1000 - 8000 MHz

Maximized Emissions

RE, 1000 - 18000 MHz

Deviations From The Standard

DRAFT

No deviations were made from the requirements of the standard.

Antenna:

Antenna:

Antenna:

Air Dipole Antenna (Elliott 2009-1387)

RSS-GEN

RSS-GEN

RSS-GEN

Pass

Pass

Pass

40.8dBµV/m (109.6µV/m) @

3249.4MHz (-13.2dB)

41.7dBµV/m (121.6µV/m) @

3249.4MHz (-12.3dB)

42.6dBµV/m (134.9µV/m) @

3856.7MHz (-11.4dB)

36.4dBµV/m (66.1µV/m) @

7410.7MHz (-17.6dB)

Larsen 5.0 dBi dipole antenna (Elliott 2009-2119)

H&S 6.5 dBi dipole antenna (Elliott 2009-1388)

SCU: V2.03.18

00000002A

DRIVER:

V3.00.50

For emission from 10-18GHz, the EUT was scanned manually. All signals were within noise floor.

T77316_DTS_Radiated_Final RE RX Mode Page 39 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class:

Run #1: Maximized readings, 30 - 8000 MHz (Cisco Air-Ant Dipole Antenna), 2437 MHz

Date: 1/13/2010 Engineer: Joseph Cadigal Location:

FT Chamber #5

Frequency Level

MHz dB

μV/m

1267.480

1872.090

3249.390

38.5

30.1

40.8

7396.310

1267.460

1871.380

36.8

43.5

42.7

3249.230

7394.990

258.689

727.943

46.0

48.0

32.7

29.8

H

H

H

V

V

V

H

Pol

V/H

V

H

H

FCC Class B

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

54.0

54.0

-15.5

-23.9

-13.2

-17.2

AVG

AVG

AVG

AVG

207

222

133

107

74.0

74.0

74.0

74.0

46.0

46.0

-30.5

-31.3

-28.0

-26.0

-13.3

-16.2

PK

PK

PK

PK

QP

QP

207

222

133

107

99

240

Height Comments meters

1.0

2.2

1.9

2.2

1.0

2.2

1.9

2.2

1.0

1.0

-

DRAFT

Page 40 of 48 T77316_DTS_Radiated_Final RE RX Mode

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

Run #1: Maximized readings, 30 - 8000 MHz (Cisco Air-Ant Dipole Antenna), 2437 MHz

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class: -

Note 1: Above 1 GHz, the FCC specifies the limit as an average measurement. In addition, the FCC states that the peak reading of any emission above 1 GHz, can not exceed the average limit by more than 20 dB.

DRAFT

Page 41 of 48 T77316_DTS_Radiated_Final RE RX Mode

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class:

Run #2: Maximized readings, 1000 - 8000 MHz (H&S Monopole Antenna), 2437 MHz

Date: 1/13/2010 Engineer: Joseph Cadigal Location:

FT Chamber #5

Frequency Level

MHz dB

μV/m

1345.420

3249.350

40.8

41.7

7352.980

1345.490

3249.190

7350.970

35.8

45.1

46.4

47.5

H

V

V

H

Pol

V/H

H

H

FCC Class B

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

-13.2

-12.3

AVG

AVG

245

126

54.0

74.0

74.0

74.0

-18.2

-28.9

-27.6

-26.5

AVG

PK

PK

PK

32

245

126

32

Height Comments meters

1.3

1.6

1.9

1.3

1.6

1.9

-

Note 1: any emission above 1 GHz, can not exceed the average limit by more than 20 dB.

T77316_DTS_Radiated_Final RE RX Mode Page 42 of 48

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class: -

Run #3: Maximized readings, 1000 - 18000 MHz, (Larson Dipole Antenna), 5785 MHz

Date: 1/13/2010 Engineer: Joseph Cadigal Location:

FT Chamber #5

Frequency Level

MHz dB

μV/m

1306.440

3856.710

41.2

42.6

8380.270

1306.380

3856.800

8380.120

37.5

44.9

47.9

50.1

Note 1:

Pol

V/H

H

H

H

H

H

H

FCC Class B

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

54.0

74.0

74.0

74.0

-12.8

-11.4

-16.5

-29.1

-26.1

-23.9

AVG

AVG

AVG

PK

PK

PK

244

0

0

244

0

0

Height meters

1.0

1.6

1.6

1.0

1.6

1.6

Comments

Above 1 GHz, the FCC specifies the limit as an average measurement. In addition, the FCC states that the peak reading of any emission above 1 GHz, can not exceed the average limit by more than 20 dB.

DRAFT

Page 43 of 48 T77316_DTS_Radiated_Final RE RX Mode

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class:

Run #4: Maximized readings, 30 - 18000 MHz (H&S Monopole Antenna), 5785 MHz

Date: 1/13/2010 Engineer: Joseph Cadigal Location:

FT Chamber #5

Frequency Level

MHz dB

μV/m

1293.390

3884.190

7410.670

27.3

31.9

36.4

1294.410

3884.870

7411.980

253.499

778.504

38.6

44.5

48.3

23.3

19.1

H

H

H

H

H

Pol

V/H

H

H

H

FCC Class B

Limit

Detector Azimuth

Margin Pk/QP/Avg degrees

54.0

54.0

54.0

74.0

-26.7

-22.1

-17.6

-35.4

AVG

AVG

AVG

PK

246

34

278

246

74.0

74.0

46.0

46.0

-29.5

-25.7

-22.7

-26.9

PK

PK

QP

QP

34

278

298

234

Height Comments meters

1.3

1.3

2.2

1.3

1.3

2.2

1.0

1.0

-

DRAFT

Page 44 of 48 T77316_DTS_Radiated_Final RE RX Mode

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

Run #4: Maximized readings, 30 - 18000 MHz (H&S Monopole Antenna), 5785 MHz

EMC Test Data

Job Number: J77268

T-Log Number:

Account Manager:

T77316

Christine Krebill

Class: -

Note 1: Above 1 GHz, the FCC specifies the limit as an average measurement. In addition, the FCC states that the peak reading of any emission above 1 GHz, can not exceed the average limit by more than 20 dB.

DRAFT

Page 45 of 48 T77316_DTS_Radiated_Final RE RX Mode

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: -

Conducted Emissions

(Elliott Laboratories Fremont Facility, Semi-Anechoic Chamber)

Test Specific Details

Objective: The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

Date of Test: 1/14/2010

Test Engineer: John Caizzi

Test Location: Fremont Chamber #5

Config. Used: 1

Config Change: none

Host Unit Voltage 120V/60Hz

General Test Configuration

For tabletop equipment, the EUT host system was located on a wooden table inside the semi-anechoic chamber, 40 cm from a vertical coupling plane and 80cm from the LISN.

Ambient Conditions:

Temperature:

Rel. Humidity:

22 °C

37 %

Summary of Results

Run #

1

Test Performed

CE, AC Power,120V/60Hz

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

Limit

EN 55022 Class B

Result

Pass

45.1dBµV @ 0.176MHz

(-19.6dB)

DRAFT

Margin

Page 46 of 48 T77316_DTS_Radiated_Final AC CE 14-Jan-10

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: -

Run #1: AC Power Port Conducted Emissions, 0.15 - 30MHz, 120V/60Hz. 802.11b, 2412 MHz, 19 dBm, H&S antenna.

DRAFT

Page 47 of 48 T77316_DTS_Radiated_Final AC CE 14-Jan-10

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Standard:

Jerry Pohmurski

FCC 15.247/RSS 210

Preliminary peak readings captured during pre-scan (peak readings vs. average limit)

Frequency

MHz

0.176

Level dB

μV

48.6

AC

Line

Line

EN 55022 Class B

Limit

54.7

Margin

-6.1

Detector Comments

QP/Ave

Peak

0.184

0.351

0.151

0.152

46.7

37.2

41.4

40.8

Line

Line

Line

Line

54.2

48.9

56.0

55.8

-7.5

-11.7

-14.6

-15.0

Peak

Peak

Peak

Peak

0.162

0.527

0.173

0.167

0.159

0.349

0.209

0.153

1.294

38.7

27.3

48.3

48.4

41.7

34.8

37.3

39.9

27.3

Line

Line

Neutral

Neutral

Neutral

Neutral

Neutral

Neutral

Neutral

55.4

46.0

54.8

55.2

55.5

49.0

53.3

55.9

46.0

-16.7

-18.7

-6.5

-6.8

-13.8

-14.2

-16.0

-16.0

-18.7

Peak

Peak

Peak

Peak

Peak

Peak

Peak

Peak

Peak

Final quasi-peak and average readings

Frequency

MHz

0.176

0.184

0.176

0.184

0.162

0.350

0.350

0.151

Level dB

μV

45.1

44.4

31.2

30.2

41.1

32.1

21.2

33.8

AC

Line

Line

EN 55022 Class B

Limit Margin

64.7

-19.6

Detector Comments

QP/Ave

QP

Line

Line

Line

Line

Line

Line

64.3

54.7

54.3

65.4

59.0

49.0

-19.9

-23.5

-24.1

-24.3

-26.9

-27.8

QP

AVG

AVG

QP

QP

AVG

Line 65.9

-32.1

QP

0.152

0.162

0.151

33.1

19.7

14.0

Line

Line

Line

65.9

55.4

55.9

-32.8

-35.7

-41.9

QP

AVG

AVG

0.152

0.173

0.167

0.159

0.349

0.173

0.167

0.349

13.6

45.1

44.8

38.7

21.5

26.0

26.1

29.7

Line

Neutral

Neutral

Neutral

Neutral

Neutral

Neutral

Neutral

55.9

64.8

65.1

65.5

49.0

54.8

55.1

59.0

-42.3

-19.7

-20.3

-26.8

-27.5

-28.8

-29.0

-29.3

AVG

QP

QP

QP

AVG

AVG

AVG

QP

0.153

0.209

0.159

0.153

0.209

35.7

27.2

15.3

14.6

11.5

Neutral

Neutral

Neutral

Neutral

Neutral

65.8

63.2

55.5

55.8

53.2

-30.1

-36.0

-40.2

-41.2

-41.7

QP

QP

AVG

AVG

AVG

T77316_DTS_Radiated_Final AC CE 14-Jan-10

EMC Test Data

Job Number: J77268

T-Log Number: T77316

Account Manager: Christine Krebill

Class: -

Page 48 of 48

Client: Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Emissions Standard(s): FCC 15.247/RSS 210

Immunity Standard(s): -

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: -

Environment: -

T77317_DTS_Conducted_Final

EMC Test Data

For The

Summit Data Communications

Model

SDC-MSD30AG

Date of Last Test: 1/22/2010

DRAFT

Cover Page 1 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

RSS 210 and FCC 15.247 (DTS) Antenna Port Measurements

Power, PSD, Bandwidth and Spurious Emissions

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

Date of Test: 1/21&22/2010

Test Engineer: Rafael Varelas & Suhaila Khushzad

Test Location: FT Chamber #5

Config. Used: 1

Config Change: None

EUT Voltage: 120V/60Hz

General Test Configuration

The EUT was connected to the spectrum analyzer or power meter via a suitable attenuator. All measurements were made on a single chain.

All measurements have been corrected to allow for the external attenuators used.

Ambient Conditions:

Temperature:

Rel. Humidity:

18.2 °C

37 %

Summary of Results

Run # Pwr setting Avg Pwr

1

2

3

3

4

100%

100%

100%

100%

100%

-

-

-

-

-

Power spectral Density (PSD)

Minimum 6dB Bandwidth

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

Test Performed

Output Power

99% Bandwidth

Spurious emissions

No deviations were made from the requirements of the standard.

Limit

15.247(b)

15.247(d)

15.247(a)

RSS GEN

15.247(b)

Pass / Fail

Pass

Pass

Result / Margin

17.4dBm

-6.7 dBm/3kHz

12.41 MHz

16.1 MHz

All signal < -30dBc

T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Page 2 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1: Output Power

Power

Setting

19

19

17

2

Frequency (MHz)

2412

2437

2462

Output Power

(dBm)

1

17.4

17.3

16.7

mW

55.5

53.2

46.7

Antenna

Gain (dBi)

3.0

3.0

3.0

Result

Pass

Pass

Pass

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

EIRP

Note 2 dBm W

20.4

20.3

19.7

0.111

0.106

0.093

Output Power

(dBm)

3

17.7

17.3

16.5

mW

58.9

53.7

44.7

Note 1:

Note 2:

Note 3:

Output power measured using a spectrum analyzer (see plots below):

RBW=1MHz, VB=3 MHz, sample detector, power averaging on (transmitted signal was continuous) and power integration over 50 MHz. Spurious limit is -30dBc because this method was used.

Power setting - the software power setting used during testing, included for reference only.

Avg power meter measurement, for reference only.

DRAFT

Page 3 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #2: Power spectral Density

Power

Setting

19

19

19

Note 1:

Frequency (MHz)

2412

2437

2462

PSD

(dBm/3kHz)

-7.9

Note 1

-6.7

-6.7

Limit Result dBm/3kHz

8.0

8.0

8.0

Pass

Pass

Pass

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Power spectral density measured using RB=3 kHz, VB=10kHz, analyzer with peak detector and with a sweep time set to ensure a dwell time of at least 1 second per 3kHz. The measurement is made at the frequency of PPSD determined from preliminary scans using RB=3kHz using multiple sweeps at a faster rate over the 6dB bandwidth of the signal.

DRAFT

Page 4 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #3: Signal Bandwidth

Note 1:

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Power

Setting

19

19

19

Frequency (MHz)

2412

2437

2462

Resolution

Bandwidth

100kHz

100kHz

100kHz

Bandwidth (MHz)

6dB

12.66

12.41

12.58

99%

16.06

16.06

16.14

99% bandwidth measured in accordance with RSS GEN, with RB > 1% of the span and VB > 3xRB

DRAFT

Page 5 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #4: Out of Band Spurious Emissions

Frequency (MHz)

2412

2437

2462

Limit

-30dBc

-30dBc

-30dBc

Plots for low channel, power setting(s) = 19

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Result

Pass

Pass

Pass

Additional plot showing compliance with -30dBc limit from 2390 MHz to 2400 MHz. Radiated measurements used to show compliance

DRAFT

Page 6 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Plots for center channel, power setting(s) = 19

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Plots for high channel, power setting(s) = 19

DRAFT

Page 7 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11b

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

RSS 210 and FCC 15.247 (DTS) Antenna Port Measurements

Power, PSD, Bandwidth and Spurious Emissions

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

Date of Test:

Test Engineer: Rafael Varelas

Test Location: FT Chamber #5

Config. Used: 1

Config Change: None

EUT Voltage: 120V/60Hz

General Test Configuration

The EUT was connected to the spectrum analyzer or power meter via a suitable attenuator. All measurements were made on a single chain.

All measurements have been corrected to allow for the external attenuators used.

Ambient Conditions:

Temperature:

Rel. Humidity:

18.2 °C

37 %

Summary of Results

Run # Pwr setting Avg Pwr

1

2

3

3

4

-

100%

100%

100%

100%

-

-

-

-

-

Test Performed

Output Power

Power spectral Density (PSD)

Minimum 6dB Bandwidth

99% Bandwidth

Spurious emissions

Limit

15.247(b)

15.247(d)

15.247(a)

RSS GEN

15.247(b)

Pass / Fail

Pass

Pass

Result / Margin

16.5dBm

-7.9 dBm/3kHz

16.5 MHz

17.2 MHz

All signal < -20dBc

Modifications Made During Testing

No modifications were made to the EUT during testing

Deviations From The Standard

No deviations were made from the requirements of the standard.

T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Page 8 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #1: Output Power

Power

Frequency (MHz)

Setting

2

19

19

2412

2437

19

2462

Output Power

(dBm)

1

20.6

20.9

20.7

mW

114.8

123.0

117.5

Antenna

Gain (dBi)

3.0

3.0

3.0

Result

Pass

Pass

Pass

Note 1:

Note 2:

Note 3:

Output power measured using a peak power meter.

Spurious limit is -20dBc because this method was used.

Power setting - the software power setting used during testing, included for reference only.

Avg power meter measurement, for reference only.

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

EIRP

Note 2 dBm W

23.6

23.9

23.7

0.229

0.245

0.234

Output Power

(dBm)

3 mW

16.3

17.4

16.0

42.7

55.0

39.8

Run #2: Power spectral Density

Power

Setting

19

19

19

Frequency (MHz)

2412

2437

2462

Note 1:

PSD

(dBm/3kHz)

-8.5

-7.9

Note 1

-9.4

Limit

Result dBm/3kHz

8.0

Pass

8.0

8.0

Pass

Pass

Power spectral density measured using RB=3 kHz, VB=10kHz, analyzer with peak detector and with a sweep time set to ensure a dwell time of at least 1 second per 3kHz. The measurement is made at the frequency of PPSD determined from preliminary scans using RB=3kHz using multiple sweeps at a faster rate over the 6dB bandwidth of the signal.

DRAFT

Page 9 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #3: Signal Bandwidth

Power

Note 1:

Setting

19

19

19

Frequency (MHz)

2412

2437

2462

Resolution

Bandwidth

100kHz

100kHz

100kHz

Bandwidth (MHz)

6dB

16.5

99%

17.22

16.58

16.58

17.22

17.22

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

99% bandwidth measured in accordance with RSS GEN, with RB > 1% of the span and VB > 3xRB

DRAFT

Page 10 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #4: Out of Band Spurious Emissions

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Frequency (MHz)

2412

2437

2462

Limit

-20dBc

-20dBc

-20dBc

Result

Pass

Pass

Pass

Note: The limit lines on the wideband plots show a -30dBc limit. Peak power measurement was use, actual limit is -20dBc.

Plots for low channel, power setting(s) = 100 %

T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Page 11 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Additional plot showing compliance with -30dBc limit from 2390 MHz to 2400 MHz. Radiated measurements used to show compliance with the limits in the restricted band below 2390 MHz.

-20dBc

Plot at power setting 19dBm

Plots for center channel, power setting(s) = 19

DRAFT

Page 12 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Plots for high channel, power setting(s) = 19

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

DRAFT

Page 13 of 19 T77317_DTS_Conducted_Final DTS 2.4GHz Antenna Port 802.11g

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact:

Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

RSS 210 and FCC 15.247 (DTS) Antenna Port Measurements

Power, PSD, Bandwidth and Spurious Emissions

Test Specific Details

Objective:

The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above.

Date of Test: 1/14/2010

Test Engineer: Joseph Cadigal

Test Location: FT Chamber#5

Config. Used: 1

Config Change: None

EUT Voltage: 120V/60Hz

General Test Configuration

The EUT was connected to the spectrum analyzer or power meter via a suitable attenuator. All measurements were made on a single chain.

All measurements have been corrected to allow for the external attenuators used.

Ambient Conditions:

Temperature:

Rel. Humidity:

10-15 °C

30-50 %

Summary of Results

Run # Pwr setting Avg Pwr

1

2

3

3

4

-

-

-

-

18.0

-

-

-

-

-

Deviations From The Standard

Test Performed

Output Power

Power spectral Density (PSD)

Minimum 6dB Bandwidth

Modifications Made During Testing

99% Bandwidth

Spurious emissions

No modifications were made to the EUT during testing

No deviations were made from the requirements of the standard.

Limit

15.247(b)

15.247(d)

15.247(a)

RSS GEN

15.247(b)

Pass / Fail

Pass

Pass

Result / Margin

15.3dBm (33.7mW)

7.5 dBm/3kHz

16.5 MHz

16.8 MHz

All signals were below the limit

T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Page 14 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Run #1: Output Power

Power

Setting

2

18.0

18.0

17.0

Frequency (MHz)

5745

5785

5805

Output Power

(dBm)

1 mW

10.5

11.5

11.5

11.2

14.1

14.1

Antenna

Gain (dBi)

6.5

6.5

6.5

Result

Pass

Pass

Pass

EIRP

Note 2 dBm W

17.0

18.0

18.0

0.050

0.063

0.063

Output Power

(dBm)

3 mW

20.5

19.6

19.5

112.2

91.2

89.1

Note 1:

Note 2:

Note 3:

Output power measured using a spectrum analyzer (see plots below):

RBW=1MHz, VB=3 MHz, sample detector, power averaging on (transmitted signal was continuous) and power integration over 50 MHz. Spurious limit is -30dBc because this method was used.

For Channel 161 (5805 MHz), the RBW=1MHz, VB=3 MHz, sample detector, max hold for at least 60 seconds (transmitted signal was not continuous) and power integration over 50 MHz.

Power setting - the software power setting used during testing, included for reference only.

Avg power meter measurement, for reference only.

DRAFT

T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Page 15 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Run #2: Power spectral Density

Power

Setting

18.0

18.0

17.0

Frequency (MHz)

5745

5785

5805

PSD

(dBm/3kHz)

2.0

-12.7

Note 1

7.5

Limit Result dBm/3kHz

8.0

Pass

8.0

8.0

Pass

Pass

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Note 1:

Power spectral density measured using RB=3 kHz, VB=10kHz, analyzer with peak detector and with a sweep time set to ensure a dwell time of at least 1 second per 3kHz. The measurement is made at the frequency of PPSD determined from preliminary scans using RB=3kHz using multiple sweeps at a faster rate over the 6dB bandwidth of the signal.

DRAFT

Page 16 of 19 T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Run #3: Signal Bandwidth

Note 1:

Power

Setting

18.0

18.0

17.0

Frequency (MHz)

5745

5785

5805

Resolution

Bandwidth

100kHz

100kHz

100kHz

Bandwidth (MHz)

6dB 99%

16.6

16.5

16.5

17.1

16.8

16.6

99% bandwidth measured in accordance with RSS GEN, with RB > 1% of the span and VB > 3xRB

Run #4: Out of Band Spurious Emissions

Frequency (MHz)

5745

5785

5805

Limit

-30dBc

-30dBc

-30dBc

Plots for low channel, power setting(s) = 18.0dBm

Result

Pass

Pass

Pass

DRAFT

T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Page 17 of 19

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Plots for center channel, power setting(s) = 18.0dBm

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

Plots for high channel, power setting(s) = 18.0dBm

DRAFT

Page 18 of 19 T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Client:

Summit Data Communications

Model: SDC-MSD30AG

Contact: Jerry Pohmurski

Standard:

FCC 15.247/RSS 210

Additional plot from 5810 - 5850 MHz showing compliance with -20dBc at the band edge.

EMC Test Data

Job Number: J77268

T-Log Number: T77317

Account Manager: Christine Krebill

Class: N/A

DRAFT

Page 19 of 19 T77317_DTS_Conducted_Final DTS 5GHz Antenna Port 802.11a

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
