CDP-D11
CD Player
Powerful
performer.
Perfect
playback.
CD solutions from Sony.
this is not a rehearsal.
w w w.pro.sony-europe.com
The Sony CDP-D11 is a 1U rack mounting CD player.
Its up-to date design features include Instant Start of tracks,
remote controller and connectors for both RS-232C and progr
Superb audio performance is guaranteed by High Density
Main features
Flexible output interfacing
Analogue audio outlets are via
balanced XLR connectors and
unbalanced phono connectors.
Both coaxial and optical digital
outputs are also provided.
Coaxial and optical SPDIF
(IEC 958 type ll) digital outputs
Dual-mode Wired/IR wireless
remote controller supplied
(RM-DS11)
Supplied commander RM-DS11
responded to wired control
and infrared wireless control.
Wired remote control is particularly suitable for use in installations with multiple players.
Main functions
INSTANT START,
MARK&LOCATION, SPEED
CONTROL (±12.5% in 0.5%
steps).
AUTO CUE function research a
beginning of music automatically
and make PAUSE status. AUTO
PAUSE function make pause
status at the first TRACK
automatically. PROGRAM, SHUFFLE, A-B REPEAT are available.
In VARI SPEED mode, actual
play back time can be indicated.
A special "fader play" mode is
provided on the parallel interface
to automatically play tracks in
order as the fader start switch
is opened and closed.
Long-duration
sequential playback
Sequential playback from several
CDP-D11 units using the Relay
Play input and output feature.
After a first unit has at an
end, control signal go
through a jack and make
a second unit start to
playback automatically.
Supplied Remote
Control Unit RM-DS11
The RM-DS11 dual mode
remote controller connects to
the 3.5 mm Control-S jack with
a supplied 5 m cable, but also
Comprehensive
remote control
operates as a conventional IR
remote when not connected
Remote control via RS-232C
or parallel remote control ports.
Parallel remote can be userassigned to control and monitor
several functions of the machine.
to the Control-S jack.
Specifications of RM-D
Remote control
RS-232C:
Parallel remote:
Other features
* Music scans function for quick location of tracks.
* Advanced Electronic Shock Protection with 4 Mb D-RAM
buffer (2.972 msec).
* Plays both 8 cm and 12 cm CDs without an adapter.
* Headphone monitoring output with level control.
Pin connections for the
Parallel Remote
connector are as shown.
The alternative functions
are available via the Setup menu.
Relay play:
9-pin D-sub,
9-pin D-sub,
input, TTL 1
open collect
RELAY IN/O
3.5 mm lack
Programmable Remote Control Pinout Function
Pin
Preset Function
Alternativ
1
Input
PLAY
2
Input
PAUSE
PLAY/PAUSE
PLAY,
3
Input
STOP
STOP,
4
Input
AMS+
AMS+
5
Input
AMS-
EJEC
6
GND
7
Output
PLAY
PLAY,
8
Output
PAUSE
9
Output
NO DISC
NO
O
Varispeed operation, an IR wireless/wired
ammable parallel remote control.
y linear digital to analogue converters.
DS11
, male
, female
0 V max output,
tor 100 mA max
OUT/PLAY IN
kx2
ns
ve Functions
E, FADER PLAY
Y, PAUSE
, FF, REW
+, AMS-
CT OFF
Y, PAUSE
O DISC
OFF
Front Panel
Rear Panel
The space saving
design of the CDP-D11
features a slot-in
loading mechanism
designed for high
reliability and with
resistance to shock and
to high temperatures.
A three-second Advanced
ESP anti-shock memory
is also standard.
Specifications
Audio performance
Frequency response
THD
S/N ratio
Dynamic range
20 Hz - 20 kHz ±0.5 dB
< 0.01%
better than 93 dB
digital, 97 dB
analogue, 92 dB
±12.5% in 0.5% steps
High Density Linear
(8x over sampling, 1 bit with 20 bit accuracy)
Below measurable limits
Varispeed range
D/A conversion
Wow and Flutter
Outputs
Connector
Phono
ANALOGUE
LINE OUT
Rated output
Maximum
+8 dBu
+10/+24 dBu
(switchable)
-18 dBm
(optical power)
0.5 Vp-p
Load impedance
More than 10 kΩ
0 –10 mW
The level varies
32 Ω
XLR3-32
DIGITAL
OPTICAL OUT
DIGITAL
COAXIAL OUT
PHONES
Square optical
connector
Phono
Stereo Phone
More than 600 Ω
75 Ω
General
System
Laser
Sampling frequency
Power requirements
Power consumption
Operating temperature
Storage temperature
Mass
Dimensions
Supplied accessory
CD player
Semiconductor GaAIAs laser ( l780nm)
44.1 kHz
120/230 V AC, 50/60 Hz
11 W
0 ˚C to 40˚C
-20˚C to 60˚C
5.2 kg
482 (W) x 44 (H) x 350 (D) mm
Wired/Wireless Remote Commander RM-DS11
OdBu=0.775 Vrms
Mounting the unit
This unit can be attached to a standard 19 inch rack (type EIA).
After detaching the four feet on the bottom of the unit,
mount the unit on the rack.
Dimensions
( Unit: mm )
DIGITAL OUT
ANALOG(BAL)
ANALOG OUT(UNBAL)
R
RS-2320
PELAY
PARALLEL
IN
OUTPUT
LEVEL
L
REMOTE
CTRL-S
COAXIAL
OPTICAL
R
L
"US AND FOREIGN PATENTS LICENSED
FROM DOLBY LABORATORIES LICENSING
CORPORATION"
Distributed by
350
370
All rights reserved.
Reproduction in whole or in part
without written permission is prohibited.
Features and specifications are
subject to change without notice.
All non-metric mass and measures
are approximate.
Sony is a registered trademark
of Sony Corporation.
All other trademarks are property
of their respective owners.
430
482
44
AMB
LOCATE
PHONE LEVEL
DISPLAY
PLAY MODE
MIN
VARI SPEED
PHONES
EJECT
ON
OFF
MAX
A・CUE
PUSH MARK/ENTER
VARI
SPEED
COMPACT DISC PLAYER CDP-D11
44
REPEAT
©2000 Sony Corporation.
CA-CDP-D11/GB-07/01/2000
