Linux Laptop−HOWTO
Linux Laptop−HOWTO
Table of Contents
Linux Laptop−HOWTO.....................................................................................................................................1
Werner Heuser <[email protected]>..........................................................................................................1
1.Preface...................................................................................................................................................1
2.Copyright, Disclaimer and Trademarks................................................................................................1
3.Which Laptop to Buy?..........................................................................................................................1
4.Laptop Distribution...............................................................................................................................2
5.Installation............................................................................................................................................2
6.Hardware In Detail................................................................................................................................2
7.Palmtops, Personal Digital Assistants − PDAs, Handheld PCs − HPCs..............................................3
8.Cellular Phones, Pagers, Calculators, Digital Cameras, Wearable Computing....................................3
9.Accessories...........................................................................................................................................3
10.Different Environments − On the Road..............................................................................................3
11.Other Resources..................................................................................................................................3
12.Repairing the Hardware......................................................................................................................4
13.Solutions with Laptops.......................................................................................................................4
14.Other Operating Systems....................................................................................................................4
15.ToDo...................................................................................................................................................4
16.Revision History.................................................................................................................................4
17.Credits.................................................................................................................................................4
18.Appendix A − Survey about Micro Linuxes.......................................................................................5
19.Appendix B − Dealing with Limited Resources or Tuning the System.............................................5
20.Appendix C − NeoMagic Chip NM20xx............................................................................................5
21.Appendix D − Annotated Bibliography..............................................................................................5
22.Appendix E − Resources for Specific Laptops...................................................................................5
1.Preface...................................................................................................................................................5
1.1 About the Author...............................................................................................................................6
1.2 Sponsoring.........................................................................................................................................6
1.3 About the Document (Mirrors, Translations, Versions, Formats, URLs).........................................6
1.4 Contact...............................................................................................................................................7
2.Copyright, Disclaimer and Trademarks................................................................................................7
3.Which Laptop to Buy?..........................................................................................................................8
3.1 Introduction........................................................................................................................................8
3.2 Portables, Laptops/Notebooks, Sub/Mini−Notebooks, Palmtops, PDAs/HPCs................................8
Portables......................................................................................................................................8
Laptops/Notebooks.....................................................................................................................9
Sub−Notebooks/Mini−Notebooks..............................................................................................9
Palmtops......................................................................................................................................9
Personal Digital Assistants (PDAs)/Handheld PCs (HPCs).......................................................9
Wearables....................................................................................................................................9
3.3 Linux Features...................................................................................................................................9
3.4 Main Hardware Features..................................................................................................................10
Weight.......................................................................................................................................10
Display......................................................................................................................................10
Batteries....................................................................................................................................10
CPU...........................................................................................................................................10
Supported CPU Families..........................................................................................................10
Miscellaneous...........................................................................................................................12
i
Linux Laptop−HOWTO
Table of Contents
Cooling......................................................................................................................................12
Keyboard Quality......................................................................................................................13
Price..........................................................................................................................................13
Power Supply............................................................................................................................13
3.5 Sources of More Information...........................................................................................................13
3.6 Linux Compatibility Check.............................................................................................................14
Related HOWTOs.....................................................................................................................14
Check Methods in General.......................................................................................................14
3.7 Writing a Device Driver...................................................................................................................15
3.8 Buying a Second Hand Laptop........................................................................................................15
3.9 No Hardware Recommendations.....................................................................................................16
4.Laptop Distribution.............................................................................................................................16
4.1 Requirements...................................................................................................................................16
4.2 Recommendation.............................................................................................................................17
5.Installation..........................................................................................................................................17
5.1 Related HOWTOs............................................................................................................................17
5.2 Prerequisites − Partitioning..............................................................................................................18
5.3 Linux Tools to Repartition a Hard Disk..........................................................................................18
GNU parted...............................................................................................................................18
ext2resize..................................................................................................................................18
fixdisktable................................................................................................................................18
Caveats......................................................................................................................................19
Multi Boot.................................................................................................................................19
5.4 Installation Methods........................................................................................................................19
5.5 From a Boot Floppy plus CD−ROM − The Usual Way..................................................................19
5.6 From a DOS or Windows Partition at the Same Machine...............................................................20
5.7 From a Second Machine With a Micro Linux On a Floppy............................................................20
Introduction...............................................................................................................................20
Prerequisites..............................................................................................................................21
Source Machine........................................................................................................................21
Destination Machine.................................................................................................................21
Configuration of the Destination Machine after the Transfer...................................................22
Miscellaneous...........................................................................................................................22
5.8 From a Second Machine With a 2.5" Hard Disk Adapter...............................................................23
5.9 From a PCMCIA Device.................................................................................................................23
5.10 From a Parallel Port Device (ZIP Drive, CD Drive).....................................................................23
5.11 From a Second Machine Using the Parallel Port − PLIP Network Install....................................23
5.12 Installing Linux on Small Machines..............................................................................................24
6.Hardware In Detail..............................................................................................................................24
6.1 PCMCIA Controller.........................................................................................................................24
Linux Compatibility Check......................................................................................................24
Related HOWTOs.....................................................................................................................24
PCMCIA Configuration − Survey............................................................................................24
Software....................................................................................................................................25
PCMCIA Controller..................................................................................................................25
PCMCIA Card..........................................................................................................................25
6.2 Infrared Port.....................................................................................................................................25
ii
Linux Laptop−HOWTO
Table of Contents
Linux Compatibility Check......................................................................................................26
SIR............................................................................................................................................26
FIR............................................................................................................................................26
Hardware Survey......................................................................................................................28
Related HOWTOs.....................................................................................................................28
IrDA Configuration − Survey...................................................................................................29
IrDA..........................................................................................................................................29
Kernel........................................................................................................................................29
Software....................................................................................................................................29
Hardware...................................................................................................................................29
Linux Remote Control − LiRC.................................................................................................29
6.3 Graphic Chip....................................................................................................................................30
Linux Compatibility Check......................................................................................................30
Video Mode..............................................................................................................................30
Text Mode.................................................................................................................................30
Related HOWTOs.....................................................................................................................30
Survey X−Servers.....................................................................................................................31
Resources..................................................................................................................................31
External Monitor.......................................................................................................................31
Miscellaneous...........................................................................................................................31
6.4 Sound...............................................................................................................................................31
Linux Compatibility Check......................................................................................................32
Related HOWTOs.....................................................................................................................32
Survey Sound Drivers...............................................................................................................32
6.5 Keyboard..........................................................................................................................................32
Linux Compatibility Check......................................................................................................32
External (Second) Keyboard.....................................................................................................33
6.6 Pointing Devices − Mice and Their Relatives.................................................................................34
Linux Compatibility Check......................................................................................................34
Related HOWTOs.....................................................................................................................34
Mice Species.............................................................................................................................34
PS/2 Mice..................................................................................................................................34
Touchpad..................................................................................................................................35
Touchscreen..............................................................................................................................36
COMPAQ Concerto Pen...........................................................................................................36
External Mouse.........................................................................................................................36
6.7 Advanced Power Management − APM...........................................................................................36
Linux Compatibility Check......................................................................................................36
Introduction...............................................................................................................................36
Kernel Land..............................................................................................................................37
User Land..................................................................................................................................37
Caveats......................................................................................................................................38
Troubleshooting........................................................................................................................38
APM and PCMCIA...................................................................................................................39
APM and Resuming X Windows..............................................................................................39
Modularization of APM............................................................................................................40
APM Resume Options..............................................................................................................40
iii
Linux Laptop−HOWTO
Table of Contents
APM and Sound........................................................................................................................40
Software Suspend.....................................................................................................................40
6.8 ACPI................................................................................................................................................40
6.9 Batteries...........................................................................................................................................41
6.10 Memory..........................................................................................................................................41
6.11 Plug−and−Play Devices (PnP).......................................................................................................41
6.12 Docking Station / Port Replicator..................................................................................................42
Definitions................................................................................................................................42
Other Solutions.........................................................................................................................42
Connection Methods.................................................................................................................42
6.13 Network Connections.....................................................................................................................44
Related HOWTOs.....................................................................................................................44
Connection Methods.................................................................................................................44
PCMCIA Network Card...........................................................................................................44
Serial Null Modem Cable.........................................................................................................44
Parallel Port NIC (Pocket Adaptor)..........................................................................................44
Parallel "Null" Modem Cable...................................................................................................45
Docking Station NIC................................................................................................................45
6.14 Modem...........................................................................................................................................45
Modem Types...........................................................................................................................45
Caveats......................................................................................................................................45
6.15 SCSI...............................................................................................................................................46
Hardware Compatibility Check................................................................................................46
Related HOWTOs.....................................................................................................................46
Survey.......................................................................................................................................46
6.16 Universal Serial Bus − USB..........................................................................................................46
Linux Compatibility Check......................................................................................................46
Miscelleaneous..........................................................................................................................46
6.17 Floppy Drive..................................................................................................................................47
Linux Compatibility Check......................................................................................................47
6.18 CD Drive........................................................................................................................................47
6.19 DVD Drive.....................................................................................................................................47
6.20 Harddisk.........................................................................................................................................48
Linux Compatibility Check......................................................................................................48
Miscellaneous...........................................................................................................................48
Form Factors.............................................................................................................................48
6.21 Video Port / ZV Port......................................................................................................................48
7.Palmtops, Personal Digital Assistants − PDAs, Handheld PCs − HPCs............................................49
8.Cellular Phones, Pagers, Calculators, Digital Cameras, Wearable Computing..................................49
8.1 Cellular Phones................................................................................................................................49
8.2 Pagers − SMS Messages..................................................................................................................50
8.3 Digital Cameras...............................................................................................................................50
8.4 Calculators.......................................................................................................................................51
8.5 Wearable Computing.......................................................................................................................51
8.6 Watches............................................................................................................................................51
9.Accessories.........................................................................................................................................52
9.1 PCMCIA Cards................................................................................................................................52
iv
Linux Laptop−HOWTO
Table of Contents
Card Families............................................................................................................................52
Linux Compatibility Check......................................................................................................52
9.2 SmartCards.......................................................................................................................................52
9.3 Memory Technology Devices − RAM and Flash Cards..................................................................53
9.4 Printers.............................................................................................................................................53
9.5 Power and Phone Plugs, Power Supply...........................................................................................53
9.6 Bags and Suitcases...........................................................................................................................54
10.Different Environments − On the Road............................................................................................55
10.1 Related HOWTOs..........................................................................................................................55
10.2 Configuration Tools.......................................................................................................................55
NetEnv......................................................................................................................................55
divine........................................................................................................................................56
Mobile IP..................................................................................................................................56
Resources..................................................................................................................................57
DHCP/BootP.............................................................................................................................57
PPPD Options...........................................................................................................................57
/etc/init.d...................................................................................................................................57
PCMCIA − Schemes.................................................................................................................57
Bootloaders...............................................................................................................................57
LILO.........................................................................................................................................57
Other Bootloaders.....................................................................................................................58
X−Windows..............................................................................................................................59
E−Mail......................................................................................................................................59
Features.....................................................................................................................................59
Configuration of sendmail........................................................................................................59
Configuration for fetchmail on Laptop.....................................................................................60
Forward E−Mail to the Laptop.................................................................................................61
Processing Incomming E−Mail with procmail.........................................................................63
Email with UUCP.....................................................................................................................64
More Info..................................................................................................................................64
10.3 Data Transport Between Different Machines................................................................................65
Hardware...................................................................................................................................65
Software....................................................................................................................................65
Version Management Software................................................................................................65
CODA Filesystem.....................................................................................................................66
WWWsync................................................................................................................................66
rsync..........................................................................................................................................66
Xfiles − file tree synchronization and cross−validation...........................................................66
sitecopy.....................................................................................................................................67
KBriefcase................................................................................................................................67
10.4 Security in Different Environments...............................................................................................67
Introduction...............................................................................................................................67
Means of Security.....................................................................................................................67
10.5 Dealing with Down Times (Cron Jobs).........................................................................................68
10.6 Noise Reduction.............................................................................................................................68
Console (Shell) and X...............................................................................................................68
PCMCIA...................................................................................................................................68
v
Linux Laptop−HOWTO
Table of Contents
Miscellaneous Applications......................................................................................................69
11.Other Resources................................................................................................................................69
12.Repairing the Hardware....................................................................................................................70
13.Solutions with Laptops.....................................................................................................................70
13.1 Introduction....................................................................................................................................70
13.2 Mobile Network Analyzer.............................................................................................................70
13.3 Mobile Router................................................................................................................................71
13.4 Hacking and Cracking Networks...................................................................................................71
13.5 Lectures..........................................................................................................................................71
13.6 Mobile Data Collecting..................................................................................................................72
Related HOWTOs.....................................................................................................................72
Applications..............................................................................................................................72
Specific Environments..............................................................................................................72
13.7 Mobile Office.................................................................................................................................72
13.8 Connection to Digital Camera.......................................................................................................72
13.9 Connection to QuickCam (Video).................................................................................................73
13.10 Connection to Television Set.......................................................................................................74
13.11 Connection to Cellular Phone......................................................................................................74
13.12 Connection to Global Positioning System (GPS)........................................................................74
13.13 Connection via Amateur Radio (HAM).......................................................................................74
13.14 Satellite Watching........................................................................................................................75
13.15 Aviation.......................................................................................................................................75
13.16 Blind or Visually Impaired Users................................................................................................75
14.Other Operating Systems..................................................................................................................75
14.1 DOS/Windows9x/NT.....................................................................................................................75
Introduction...............................................................................................................................75
DOS Tools to Repartition a Hard Disk....................................................................................76
Partition Sharing.......................................................................................................................76
Installation without CD Drive...................................................................................................76
Miscellaneous...........................................................................................................................76
14.2 BSD Unix.......................................................................................................................................77
14.3 OS/2...............................................................................................................................................77
14.4 NOVELL Netware.........................................................................................................................77
14.5 Debian GNU/Hurd (hurd−i386).....................................................................................................78
15.ToDo.................................................................................................................................................78
16.Revision History...............................................................................................................................78
17.Credits...............................................................................................................................................79
18.Appendix A − Survey about Micro Linuxes.....................................................................................81
19.Appendix B − Dealing with Limited Resources or Tuning the System...........................................82
19.1 Related HOWTOs..........................................................................................................................82
19.2 Introduction....................................................................................................................................82
19.3 Small Space....................................................................................................................................82
Introduction...............................................................................................................................82
Techniques................................................................................................................................82
19.4 Harddisk Speed..............................................................................................................................83
19.5 Small Memory...............................................................................................................................84
Related HOWTOs.....................................................................................................................84
vi
Linux Laptop−HOWTO
Table of Contents
Techniques................................................................................................................................84
19.6 Low CPU Speed.............................................................................................................................84
19.7 Power Saving Techniques..............................................................................................................85
19.8 Kernel.............................................................................................................................................86
Related HOWTOs.....................................................................................................................86
19.9 Tiny Applications and Distributions..............................................................................................86
19.10 Hardware Upgrade.......................................................................................................................87
20.Appendix C − NeoMagic Chip NM20xx..........................................................................................87
20.1 Introduction....................................................................................................................................87
20.2 Textmode 100x37..........................................................................................................................87
Survey.......................................................................................................................................88
More Details.............................................................................................................................88
Enabling Linux to Boot in 800x600.........................................................................................88
Running restoretextmode and SVGATextMode at Boot Time................................................88
Now the Key Point....................................................................................................................89
Road Map..................................................................................................................................89
21.Appendix D − Annotated Bibliography............................................................................................89
22.Appendix E − Resources for Specific Laptops.................................................................................90
22.1 IBM ThinkPad...............................................................................................................................90
22.2 Toshiba Laptops.............................................................................................................................90
22.3 COMPAQ Concerto Aero..............................................................................................................90
22.4 DELL Laptops...............................................................................................................................91
vii
Linux Laptop−HOWTO
Werner Heuser <[email protected]>
v2.2, 2 December 1999
Laptops are different from desktops/towers. They use certain hardware such as PCMCIA cards, infrared
ports, batteries, docking stations. Often their hardware is more limited (e.g. disk space, CPU speed), though
the performance gap is becoming smaller. In many instances, laptops can become a desktop replacement.
Hardware support for Linux (and other operating systems) on laptops is sometimes more limited (e.g.
graphic chips, internal modems). Laptops often use specialized hardware, hence finding a driver can be more
difficult. Laptops are often used in changing environments, so there is a need for multiple configurations and
additional security strategies. Though there are laptop related HOWTOs available already, this HOWTO
contains a concise survey of laptop related documents. Also, laptop related Linux features, such as
installation methods for laptops (via PCMCIA, without CD drive, etc.), laptop hardware features and
configurations for different (network) environments are described. Besides there are some notes on PDAs,
Handheld PCs and other mobile computer devices (digital cameras, cellular phones, calculators). And
though some caveats Linux is a better choice for laptops, than most other operating systems. Because it
supports numerous installation methods, works in many heterogenoues environments and needs smaller
resources.
1.Preface
• 1.1 About the Author
• 1.2 Sponsoring
• 1.3 About the Document (Mirrors, Translations, Versions, Formats, URLs)
• 1.4 Contact
2.Copyright, Disclaimer and Trademarks
3.Which Laptop to Buy?
• 3.1 Introduction
• 3.2 Portables, Laptops/Notebooks, Sub/Mini−Notebooks, Palmtops, PDAs/HPCs
• 3.3 Linux Features
• 3.4 Main Hardware Features
• 3.5 Sources of More Information
• 3.6 Linux Compatibility Check
• 3.7 Writing a Device Driver
Linux Laptop−HOWTO
1
Linux Laptop−HOWTO
• 3.8 Buying a Second Hand Laptop
• 3.9 No Hardware Recommendations
4.Laptop Distribution
• 4.1 Requirements
• 4.2 Recommendation
5.Installation
• 5.1 Related HOWTOs
• 5.2 Prerequisites − Partitioning
• 5.3 Linux Tools to Repartition a Hard Disk
• 5.4 Installation Methods
• 5.5 From a Boot Floppy plus CD−ROM − The Usual Way
• 5.6 From a DOS or Windows Partition at the Same Machine
• 5.7 From a Second Machine With a Micro Linux On a Floppy
• 5.8 From a Second Machine With a 2.5" Hard Disk Adapter
• 5.9 From a PCMCIA Device
• 5.10 From a Parallel Port Device (ZIP Drive, CD Drive)
• 5.11 From a Second Machine Using the Parallel Port − PLIP Network Install
• 5.12 Installing Linux on Small Machines
6.Hardware In Detail
• 6.1 PCMCIA Controller
• 6.2 Infrared Port
• 6.3 Graphic Chip
• 6.4 Sound
• 6.5 Keyboard
• 6.6 Pointing Devices − Mice and Their Relatives
• 6.7 Advanced Power Management − APM
• 6.8 ACPI
• 6.9 Batteries
• 6.10 Memory
• 6.11 Plug−and−Play Devices (PnP)
• 6.12 Docking Station / Port Replicator
• 6.13 Network Connections
• 6.14 Modem
• 6.15 SCSI
• 6.16 Universal Serial Bus − USB
• 6.17 Floppy Drive
• 6.18 CD Drive
• 6.19 DVD Drive
4.Laptop Distribution
2
Linux Laptop−HOWTO
• 6.20 Harddisk
• 6.21 Video Port / ZV Port
7.Palmtops, Personal Digital Assistants − PDAs, Handheld
PCs − HPCs
8.Cellular Phones, Pagers, Calculators, Digital Cameras,
Wearable Computing
• 8.1 Cellular Phones
• 8.2 Pagers − SMS Messages
• 8.3 Digital Cameras
• 8.4 Calculators
• 8.5 Wearable Computing
• 8.6 Watches
9.Accessories
• 9.1 PCMCIA Cards
• 9.2 SmartCards
• 9.3 Memory Technology Devices − RAM and Flash Cards
• 9.4 Printers
• 9.5 Power and Phone Plugs, Power Supply
• 9.6 Bags and Suitcases
10.Different Environments − On the Road
• 10.1 Related HOWTOs
• 10.2 Configuration Tools
• 10.3 Data Transport Between Different Machines
• 10.4 Security in Different Environments
• 10.5 Dealing with Down Times (Cron Jobs)
• 10.6 Noise Reduction
11.Other Resources
7.Palmtops, Personal Digital Assistants − PDAs, Handheld PCs − HPCs
3
Linux Laptop−HOWTO
12.Repairing the Hardware
13.Solutions with Laptops
• 13.1 Introduction
• 13.2 Mobile Network Analyzer
• 13.3 Mobile Router
• 13.4 Hacking and Cracking Networks
• 13.5 Lectures
• 13.6 Mobile Data Collecting
• 13.7 Mobile Office
• 13.8 Connection to Digital Camera
• 13.9 Connection to QuickCam (Video)
• 13.10 Connection to Television Set
• 13.11 Connection to Cellular Phone
• 13.12 Connection to Global Positioning System (GPS)
• 13.13 Connection via Amateur Radio (HAM)
• 13.14 Satellite Watching
• 13.15 Aviation
• 13.16 Blind or Visually Impaired Users
14.Other Operating Systems
• 14.1 DOS/Windows9x/NT
• 14.2 BSD Unix
• 14.3 OS/2
• 14.4 NOVELL Netware
• 14.5 Debian GNU/Hurd (hurd−i386)
15.ToDo
16.Revision History
17.Credits
12.Repairing the Hardware
4
Linux Laptop−HOWTO
18.Appendix A − Survey about Micro Linuxes
19.Appendix B − Dealing with Limited Resources or Tuning
the System
• 19.1 Related HOWTOs
• 19.2 Introduction
• 19.3 Small Space
• 19.4 Harddisk Speed
• 19.5 Small Memory
• 19.6 Low CPU Speed
• 19.7 Power Saving Techniques
• 19.8 Kernel
• 19.9 Tiny Applications and Distributions
• 19.10 Hardware Upgrade
20.Appendix C − NeoMagic Chip NM20xx
• 20.1 Introduction
• 20.2 Textmode 100x37
21.Appendix D − Annotated Bibliography
22.Appendix E − Resources for Specific Laptops
• 22.1 IBM ThinkPad
• 22.2 Toshiba Laptops
• 22.3 COMPAQ Concerto Aero
• 22.4 DELL Laptops
1.Preface
Life is the first gift, love is the second, and understanding is the third. −− Marge Piercy
18.Appendix A − Survey about Micro Linuxes
5
Linux Laptop−HOWTO
1.1 About the Author
People like either laptops or desktops. I like to work with laptops rather than with desktops. I like Linux too.
My first HOWTO was the Linux/IR−HOWTO about infrared support for Linux. My second is this one and
my third the Ecology−HOWTO, about some ways to use Linux in an ecology aware manner.
Also I have written some pages about Linux with certain laptops: Olivetti Echos 133 DM (German) (together
with Kurt Saetzler), HP OmniBook 800CT, HP OmniBook 3100 (together with Friedhelm Kueck) COMPAQ
Armada 1592 DT and COMMODORE C286LT.
During the work with the Laptop−HOWTO I have collected some surveys about laptop related hardware:
graphic chips, unofficiallysupported PCMCIA cards, internal modems and infrared chips.
But I don't claim to be a laptop guru, I just had the opportunity to install Linux on some laptops and I simply
want to share the information I collected.
Since I don't own a non−Intel based machine, this HOWTO might not contain all the details for non−Intel
systems or may contain inaccuracies. Sorry.
1.2 Sponsoring
This HOWTO is free of charge and free in the sense of the General Public Licence − GPL. Though it requires
much work and could gain more quality if I would have some more hardware. So if you have a spare laptop,
even an old one or one which requires repair, please let me know. Especially I need one with infrared port,
USB port, DVD drive, WinModem and a non Intel machine. The according chapters need a major rewrite.
For the curious, this HOWTO is written on a HP OmniBook 800CT 5/100.
Or sponsor a banner ad at my WWW pages LiLAC − Linux with Laptop Computers.
You can hire me for readings or workshops on Linux with Laptops, Repairing of Laptops and other Linux
topics, too.
1.3 About the Document (Mirrors, Translations, Versions,
Formats, URLs)
Many times I have mentioned MetaLab formerly known as SunSite. This site carries a heavy load, so do
yourself a favor, use one of the MetaLab mirrors .
For Debian/GNU Linux the mirror URLs are organized in this scheme http://www.<country code,
e.g. uk>.debian.org .
This text is included in the LINUX DOCUMENTATION PROJECT − LDP .
Richard Worwood mirrors this HOWTO at http://www.felch01.demon.co.uk/laptop−howto.html .
1.1 About the Author
6
Linux Laptop−HOWTO
Lionel, "trollhunter" Bouchpan−Lerust−Juery, <[email protected]> provides a translation into French.
You can download or browse it at http://infonomade.linuxfr.org/portables/ressourcesfr.html#howto . And he
mirrors the English version at http://infonomade.linuxfr.org/portables/ressourcesen.html#howto
He has also written a HOWTO about portables and wearables, please look at his pages
http://infonomade.linuxfr.org/index.html (French version)
http://infonomade.linuxfr.org/indexen.html (English version).
Translations into Japanese (Ryoichi Sato <[email protected]>), Italian (Alessandro Grillo
<[email protected]>), Portuguese (Gledson Evers <[email protected]> the translation
will be announced at LinuxALL) and Greek (Vassilis Rizopoulos <[email protected]>) are under
construction.
Please contact me before starting a translation to avoid double work. Since a translation is a great amount of
work, I recommend to do this work as a group.
Nearly all of the programms I mention are available as Debian/GNU Linux packages, or as RPM packages,
look up your favorite RPM server, for instance RUFUS .
The latest version of this document is available in different formats at LiLAC − Linux with Laptop
Computers .
1.4 Contact
This document isn't ready yet. If you like to write a chapter or even a smaller part by yourself, please feel free
to contact me. Also your suggestions and recommendations and critics are welcome. But please don't expect
me to solve your laptop related problems if the solution is already documented. Please read all according
manual pages, HOWTOs and WWW sites first, than you may consider to contact me or the other resources
mentioned below.
Since I want to write much more stuff about mobile computing and Linux I'm thinking about turning this
HOWTO into a book.
Werner Heuser <[email protected]>
2.Copyright, Disclaimer and Trademarks
Copyright © 1999 by Werner Heuser. This document may be distributed under the terms set forth in the LDP
license .
This is free documentation. It is distributed in the hope that it will be useful, but without any warranty. The
information in this document is correct to the best of my knowledge, but there's a always a chance I've made
some mistakes, so don't follow everything too blindly, especially if it seems wrong. Nothing here should have
a detrimental effect on your computer, but just in case I take no responsibility for any damages incurred from
the use of the information contained herein.
1.4 Contact
7
Linux Laptop−HOWTO
Some laptop manufacturers don't like to see a broken laptop with an operating system other than the one
shipped with it, and may reload MS−Windows if you complain of a hardware problem. They may even
declare the warranty void. Though IMHO this isn't legal or at least not fair. Always have a backup of both the
original configuration and your Linux installation if you have to get your laptop repaired.
Though I hope trademarks will be superfluous sometimes (you may see what I mean at Open Source
Definition) : If certain words are trademarks, the context should make it clear to whom they belong. For
example "MS Windows NT" implies that "Windows NT" belongs to Microsoft (MS). Mac is a trademark by
Apple Computer. All trademarks belong to their respective owners.
3.Which Laptop to Buy?
3.1 Introduction
Portable computers may be divided into different categories. This is a subjective decision, but I try to do so.
My groupings roughly follow the generally accepted marketing categories. The criteria could be:
1. Weight: Often expressed in terms like Portables, Laptops/Notebooks, Sub/Mini−Notebooks,
Palmtops/PDAs. There is no standard method to define the weight of a laptop, therefore the data
provided by the manufacturers (and which are given below) have to be considered as approximations.
The question is how the power supply (wether external or internal) or swappable parts like CD and
floppy drive, are included in the weight.
Most peripheral cables are appallingly heavy. If you get a subnotebook and carry it around with a
bunch of external drives, cables, and port expander dongles and power converter, you may be
lugging a heavier bag than if it were all in one box. Subnotebooks are useful mainly if you can afford
to leave all the other junk behind.
2. Supported Operations Systems: proprietary versus open
3. Price: NoName versus Brand
4. Hardware Features: display size, harddisk size, CPU speed, battery type, etc.
5. Linux Support: graphic chip, sound card, infrared controller (IrDA), internal modem, etc.
3.2 Portables, Laptops/Notebooks, Sub/Mini−Notebooks,
Palmtops, PDAs/HPCs
Portables
Weight greater than 4.0 kg (9 lbs). Features like a PC, but in a smaller box and with LCD display. Examples:
lunchbox or ruggedized laptops (e.g., http://www.bsicomputer.com/)
3.Which Laptop to Buy?
8
Linux Laptop−HOWTO
Laptops/Notebooks
Weight between 1.7 and 4.0 kg (4 to 9 lbs). Features custom hardware and usually a special CPU. Examples:
HP OmniBook 3100, COMPAQ Armada 1592DT. The terms laptop and notebook seem equivalent to me.
Sub−Notebooks/Mini−Notebooks
Weight between 1.3 and 1.7 kg (3 to 4 lbs). Features: external floppy drive, external CD drive. Examples: HP
OmniBook 800CT, Toshiba Libretto 100, COMPAQ Aero, SONY VAIO 505.
Palmtops
Weight between 0.7 and 1.3 kg (1.5 to 3 lbs). Features: proprietary commercial operating systems. Examples:
HP200LX.
Personal Digital Assistants (PDAs)/Handheld PCs (HPCs)
Weight below 0.7 kg (1.5 lbs). Features: proprietary commercial operating systems and often non−Intel CPU
with commercial operating systems like PalmOS, EPOC32, GEOS, Windows CE. Examples: Newton
Message Pad, Palm III (former Pilot), Psion Series 3 and 5, CASIO Z−7000.
Wearables
Watches, digital pens, calculators, digital cameras, cellular phones and other wearables.
3.3 Linux Features
Due to a lack of support by some hardware manufacturers, not every feature of a laptop is always supported
or fully operational. The main devices which may cause trouble are: graphic chip, IrDA port, sound card,
PCMCIA controller , PnP devices and internal modem. Please try to get as much information about these
topics before buying a laptop. But often it isn't quite easy to get the necessary information. Sometimes even
the specifications or the hotline of the manufacturer aren't able to provide the information. Therefore I have
included a Linux Compatibility Check chapter in the Hardware In Detail sections below.
Depending on your needs, you might investigate one of the vendors that provide laptops pre−loaded with
Linux. By purchasing a pre−loaded Linux laptop, much of the guesswork and time spent downloading
additional packages could be avoided. See Kenneth E. Harker's page for a list of vendors
http://www.cs.utexas.edu/users/kharker/linux−laptop/.
Laptops/Notebooks
9
Linux Laptop−HOWTO
3.4 Main Hardware Features
Besides its Linux features, there often are some main features which have to be considered when buying a
laptop. For Linux features please see the Hardware In Detail section below.
Weight
Don't underestimate the weight of a laptop. This weight is mainly influenced by:
1. screen size
2. battery type
3. internal components, such as CD drive, floppy drive
4. power supply
5. material used for the case, usually they are either from plastics or from magnesium.
Display
Laptops come with one of two types of displays: active matrix (TFT) and passive matrix (DSTN). Active
matrix displays have better color and contrast, but usually cost more and use more power. Also consider the
screen size. Laptops may be purchased with screens up to 15". A bigger screen weighs more, costs more, and
is harder to carry, but is good for a portable desktop replacement.
Batteries
The available battery types are Lithium Ion (LiIon), Nickel Metal Hydride ( NiMH) and Nickel Cadmium
(NiCd).
LiIon batteries are the most expensive ones but a lot lighter than NiCd for the same energy content, and have
minimal −− but present −− memory effects. NiMH is better than NiCd, but still rather heavy and does suffer
some (although less than NiCd) memory effects.
Unfortenately most laptops come with a proprietary battery size. So they are not interchangeable between
different models.
CPU
Supported CPU Families
For details about systems which are supported by the Linux Kernel, see the Linux FAQ . See also Current
ports of Linux OS
3.4 Main Hardware Features
10
Linux Laptop−HOWTO
1. i286: Linux doesn't support this CPU family yet. But there are some efforts at ELKS. If you like, you
may use Minix one of the predecessors of Linux. Minix supports 8088 to 286 with as little as 640K
memory. Actually there are some laptops with ELKS around, for instance the Commodore C286LT
2. i386: This covers PCs based on Intel−compatible processors, including Intel's 386, 486, Pentium,
Pentium Pro and Pentium II, and compatible processors by AMD, Cyrix and others. Most of the
currently available laptops use Intel compatible CPUs and have quite good Linux support.
3. m68k: This covers Amigas and Ataris having a Motorola 680x0 processor for x>=2; with MMU. And
the early Apple/Macintosh computers.
There was a long series of Apple PowerBooks and other laptops based on the m68k chip. Macintosh
Portable (an ugly 16−pound first attempt); PowerBook 100, 140, 170, 145, 160, 180c, 165c, 520c,
540c, 550c, 190; Duo 210, 230, 250, 270c, 280. The PowerBook Duos were available at the same
time as the PowerBooks, they were a sort of subnotebook, but were designed so that you could plug
them into a base station (a DuoDock) with more RAM, peripherals, etcetera, so that they could also
act as a desktop computer. The first PowerPC PowerBooks were the ill−starred PowerBook 5300
(after the 190) and the Duo 2300c.
For a complete list of all Macintosh computers ever made, with specifications, see Apple−History.
Note also that readers should *not* go to www.linuxppc.org for hardware compatibility with 68k
laptops−−as the name implies, LinuxPPC is only for PowerPC machines. The proper place to go for
information on running Linux on m68k Macintoshes is: linux−m68k.
In particular, their hardware compatibility list is at: linux−m68k−status and it states in regards to
laptops:
"Much like laptops of the Intel/Linux world, Mac laptops have generally different setups that can be
very hard to figure out. Also, because of a general lack of machines to test, we are only aware of
boots on the Powerbook 145, Powerbook 150, Powerbook 170, Powerbook 180, and Powerbook 190.
Even if it boots, we currently have no support for Powerbook−style ADB, the APM support, or just
about anything else on them. This means the only way to log in is with a terminal hooked up to the
serial interface, this has been tested on the 170."
"Several Powerbooks have internal IDE which is supported. PCMCIA drivers will be forthcoming if
someone can supply the necessary hardware information to write a driver. As always, an FPU is
needed also. Many of the later models have the 68LC040 processor without FPU, and many of these
processors are broken with respect to the FPU trap mechanism so they can't run regular Linux
binaries even with FPU emulation. Current status on Powerbooks 140, 160, 165, 165c, 180c, 190,
520 and Duos 210, 230, 250, 270c, 280, and 280c is unknown."
Also there are two Atari laptops, for which I don't have enough information. The following
quotations are from the Atari Gallery.
"The STacy was released shortly after the Mega ST to provide a portable means of Atari computing.
STacy computers were shipped with TOS v1.04.
Designed to replace the STacy as the defacto portable ST computer, the ST Book brought the basic
computing power of an ST to a lightweight notebook computer. This machine was only released in
Europe and Atari only shipped a very small quantity. The ST Book was shipped with TOS v2.06."
3.4 Main Hardware Features
11
Linux Laptop−HOWTO
Is there an Amiga notebook?
4. PowerPC (PPC): Although some driver support present in Intel based Linux is still missing for Linux
PPC, it is a fully usable system for Macintosh PowerBooks. See LinuxPPC for a current list of
supported machines.
BTW: The team at iMac Linux has managed to get the iMac DV to boot Linux to a usable point. You
may get information about the iBook there as well.
5. Alpha, Sparc, Sparc64 architectures: These are currently under construction. AFAIK there are only
the Tadpole SPARC and ALPHA laptops, and some other ALPHA laptops available. For a current
survey look at Kenneth E. Harker's Linux on Laptops without x86 Family Processors at
http://www.cs.utexas.edu/users/kharker/linux−laptop/non−intel.html .
6. StrongARM: a very low−power CPU found in Rebel.com's popular NetWinder (some kind of mobile
computer, too), and actively supported in the Debian project, it is also in several WinCE machines,
such as HP's Jornadas. Only the lack of tech specs prevents Linux from being ported to these tiny,
long−battery−life machines. A full−scale StrongARM−based laptop would make a superb Linux
platform, but none exists yet.
For PDAs with ARM/StrongARM CPU see the PDA chapter below.
7. MIPS: Used in SGI mainframes and Cobalt Micro intranet appliances, chips based on this
architecture are used in many Wince machines. Linux has been ported to a few of these, including the
lovely little Vadem Clio. Vadem has been admirably cooperative.
More about Linux on Wince boxes may be found at LinuxCE−FAQ.
Miscellaneous
At higher speed, a CPU consumes more power and generates more heat. Therefore, in many laptops a special
low−power CMOS CPU is used. Usually, this special CPU doesn't use as much power as a similar processor
used in a desktop. These special CPUs are also more expensive. As a side effect you may find that laptops
with a desktop CPU often have a fan which seems quite loud.
Cooling
An enormously important issue. Anything based on PPC or Pentium will generate enormous amounts of heat
which must be dissipated.Generally, this means either a fan, or a heat sink the size of the case.If it's a fan, the
air path had better not ever get blocked, or it will overhead and burn out.This means machines with a fan
mounted in the bottom are a big, big mistake: you can't use them on a soft surface.
Miscellaneous
12
Linux Laptop−HOWTO
Keyboard Quality
Though you might use your desktop computer to do longer writings, a good keyboard can save you some
headaches and finger−aches. Look especially for the location of special keys like: <ESC>, <TAB>, <Pos1>,
<End>, <PageDown>, <PageUp> and the cursor keys.
Price
Laptops are quite expensive if you compare them with desktops. So you may decide between a brand or
no−name product. Though I would like to encourage you to take a no−name product, there are some caveats.
I have experienced that laptops break often, so you are better off, when you have an after sales warranty,
which is usually only offered with brand products. Or you may decide to take a second hand machine. When
I tried this, I discovered that the laptop market is changing quite often. A new generation is released
approximately every three months (compared by CPU speed, harddisk capacity, screen size etc.). So laptops
become old very quick. But this scheme often isn't followed by the prices for second hand laptops. They seem
too expensive to me. Anyway if you plan on purchasing a second hand machine, review my
recommendations on checking the machine. For German readers there is an online market place at
http://www.hardware.de, which offers a good survey about current prices for second hand machines.
Power Supply
If you travel abroad pay attention to the voltage levels which are supported by the power supply. Also the
power supply is often one of the heavier parts of a laptop.
3.5 Sources of More Information
Specifications, manuals and manufacturer support often are not helpful. Therefore you should retrieve
information from other sources too:
1. Highly recommended is the survey by Kenneth E. Harker
http://www.cs.utexas.edu/users/kharker/linux−laptop/ .
2. ftp://tsx−11.mit.edu/pub/linux/packages/laptops/ .
3. Hardware−HOWTO
4. open hardware − The Open Hardware Certification Program http://www.debian.org/OpenHardware/
5. HARDWARE.doa.org − dedicated to the hardware aspects of (Linux) computing
http://hardware.doa.org/
6. How to Build a PC FAQ − excellent hardware overview by Billy Newsom
http://www.motherboards.org/build.html
7. Last but not least the WWW itself.
Keyboard Quality
13
Linux Laptop−HOWTO
3.6 Linux Compatibility Check
Related HOWTOs
1. Hardware−HOWTO
2. Kernel−HOWTO
3. PCMCIA−HOWTO
4. PCI−HOWTO
5. Plug−and−Play−mini−HOWTO
Check Methods in General
If you can't find the necessary information through the above mentioned sources, you are on your own.
Luckily, Linux provides many means to help. For details see the Hardware on Detail section below. In
general you may use:
1. First of all the kernel itself. Look up what kind of hardware is detected by the kernel. You get this
information during boot time or usually by dmesg or by looking into /var/log/messages.
2. If your kernel supports the /proc file system you may get detailed information about PCI devices by
cat /proc/pci Please read the kernel documentation pci.txt. You may get further information
about unknown PCI devices at the database from Craig Hart at
http://members.hyperlink.net.au/~chart. From 2.1.82 kernels on you may use the lspci command
from the pci−utils package.
3. To retrieve information about Plug−and−Play (PNP) devices use isapnp−tools .
4. Use scsi_info by David Hinds for SCSI devices or scsiinfo.
If you don't want to install a complete Linux you may retrieve this information by using a micro Linux ( see
appendix A). The package muLinux provides even a small systest program and TomsRtBt comes with
memtest. To use memtest you have to copy it on a floppy dd if=/usr/lib/memtest
of=/dev/fd0 and to reboot from this floppy.
If your laptop came with Windows, you may determine a lot of hardware settings from the installation. Boot
into DOS or Windows to get the information you need.
Using Windows9x/NT to get hardware settings, basically boot Windows, then Start −> Settings −>
Control Panel −> System −> Device Manager and write down everything, or make a hardcopy
from the display using the <PRINT> key, plus keep a log of settings, hardware, memory, etc.
Using MS−DOS and Windows3.1x you can use the command msd, which is an akronym for MicroSoft
Diagnostics. Or you might try one of the numerous DOS shareware utilities: CHECK−IT, DR.HARD and
others.
Sometimes it's difficult to know what manufacturer has built the machine or parts of it actually. The
FCC "Federal Communications Commission On−line Equipment Authorization Database may be used, if you
3.6 Linux Compatibility Check
14
Linux Laptop−HOWTO
are having problems identifying the manufacturer of a laptop or notebook computer (or other electronic
device,) this site lets you search the FCC database based on the FCC ID number you can usually find on the
equipment if it was marketed in the United States of America."
The Lothar Project is a Mandrake−related project to provide a GUIed interface to get at hardware
configuration information on Linux−based systems. It provides a library for different system informations,
too.
Many laptops are no more compatible with Windows than Linux. David Hinds, author of the PCMCIA
drivers, points out that Toshiba notebooks use a proprietary Toshiba PCMCIA bridge chip that exhibits the
same bugs under Windows as under Linux. IBM Thinkpads have serious BIOS problems that affect delivery
of events to the power management daemon apmd. These bugs also affect MS−Windows, and are listed in
IBM's documentation as considerations.
Some incompatibilities are temporary, for instance laptops that have Intel's USB chip will probably get full
USB support, eventually.
3.7 Writing a Device Driver
If you encounter a device which is not yet supported by Linux, don't forget it's also possible to write a driver
by yourself. You may look at the book from Alessandro Rubini, Andy Oram: Linux Device Drivers.
3.8 Buying a Second Hand Laptop
Some recommendations to check an used laptop, before buying it:
1. Review the surface of the case for visible damages.
2. Check the display for pixel faults. Maybe it's useful to take a magnifying glass therefore.
3. Do an IO stress−test, .e.g. with the tool bonnie.
4. You may use memtest and crashme to achieve a memory test.
5. Do a CPU stress test, e.g. with the tool Byte or by compiling a kernel.
6. Check the floppy drive by formatting a floppy.
7. Check the CD drive by reading a CD.
8. To check the battery seems difficult, because it needs some time: one charge and one work cycle.
9. To check the surface of the harddisk you may take e2fsck. There is also a Linux tool dosfsck or
the other fsck tools.
10. To test the entire disk (non−destructively), time it for performance, and determine its size, as root do:
time dd if=/dev/hda of=/dev/null bs=1024k .
11. Check wether the machine seems stolen. I have provided a survey of databases for stolen laptops.
AFAIK there is no Linux tool like the DOS tools CHECK−IT, DR. HARD, SYSDIAG and others. These
tools include many of the tests in one integrated suite. One of the best IMHO is the tool PC Diagnostics
95 made by Craig Hart http://members.hyperlink.net.au/~chart . Despite the 95 in its name it's plain DOS,
tiny (76KB programm and 199KB data) reliable and free. Unfortenately it contains no check for the IrDA
port.
3.7 Writing a Device Driver
15
Linux Laptop−HOWTO
Please note this quotation from the disclaimer: "This program is written with the target audience being a
trained, experienced technician. It is NOT designed to be used by those ignorant of computer servicing.
Displays are not pretty but functional. Information is not explained since we are not trying to educate. This
software should be considered to be just like any other tool in a tech's toolbox. It is to be applied with care, in
the right situation, in order to find answers to specific problems. If you are an end user who is less than
confident of dealing with computer hardware, this is probably not a program for you."
Laptop computers, unlike desktop machines, really do get used up. Lithium batteries are good for no more
than 400 recharge cycles, sometimes much fewer. Keyboards wear out. LCD screen backlighting grows dim.
Mouse buttons fail. Worst of all, connectors get loose as a result of vibration, causing intermittent failures
(e.g. only when you hit the <Enter> key). We have heard of a machine used on the table in a train being
shaken to unusability in one trip.
3.9 No Hardware Recommendations
It's difficult to give any recommendations for a certain laptop model in general. Your personal needs have to
be taken into account. Also the market is changing very quickly. I guess every three months a new generation
of laptops (according to harddisk space, CPU speed, display size, etc.) comes into the market. So I don't give
any model or brand specific recommendations.
4.Laptop Distribution
4.1 Requirements
From the Battery−HOWTO I got this recommendation (modified by WH):
A Message to Linux Distributors
If you happen to be a Linux distributor, thank you for reading all this. Laptops are becoming more and more
popular, but still most Linux distributions are not very well prepared for portable computing. Please make
this section of this document obsolete, and make a few changes in your distribution.
The installation routine should include a configuration, optimized for laptops. The minimal install is often not
lean enough. There are a lot of things that a laptop user does not need on the road. Just a few examples. There
is no need for three different versions of vi (as found in Suse Linux). Most portable systems do not need
printing support (they will never be connected to a printer, printing is usually done with the desktop system at
home). Quite a few laptops do not need any network support at all.
Don't forget to describe laptop−specific installation problems, e. g. how to install your distribution without a
cd−rom drive or how to setup the plip network driver.
Add better power management and seamless PCMCIA support to your distribution. Add a recompiled kernel
and an alternative set of PCMCIA drivers with apm support that the user can install on demand. Include a
3.9 No Hardware Recommendations
16
Linux Laptop−HOWTO
precompiled apmd package with your distribution.
Add support for dynamically switching network configurations. Most Linux laptops travel between locations
with different network settings (e. g. the network at home, the network at the office and the network at the
university) and have to change the network ID very often. Changing a Linux system's network ID is a pain
with most distributions.
Add a convenient PPP dialer with an address book, that does not try to start multiple copies of the PPP
daemon if you click on the button twice (e.g., the RedHat usernet tool). It would be nice to have the PPP
dialer also display the connection speed and some statistics. One nice command line dialer that autodetects
modems and PPP services is wvdial from Worldvisions http://www.worldvisions.ca/wvdial/.
4.2 Recommendation
The Debian/GNU Linux has most of the desired features for a laptop installation. The distribution has a quite
flexible installation tool. The installation process is well documented, especially concerning the methods
which are useful at laptops. All the binaries are tiny, because they are stripped. A mailing list
debian−laptop including a searchable archiv is provided. And Debian/GNU Linux is free.
At the end of August 1999 the Debian Laptop Distribution − Proposal was issued. And some more laptop
related packages and a Debian meta−package dedicated to laptops are on the way.
Note: I know other Linux distributions work well with laptops, too. I even tried some of them, see my pages
about certain laptops mentioned above.
5.Installation
5.1 Related HOWTOs
1. CDROM−HOWTO
2. Config−HOWTO
3. Diskless−mini−HOWTO
4. Installation−HOWTO
5. Pre−Installation−Checklist−mini−HOWTO
6. Update−mini−HOWTO
7. Hard−Disk−Upgrade−mini−HOWTO
8. Installation and getting started by Matt Welsh and others available at the LINUX
DOCUMENTATION PROJECT http://metalab.unc.edu/LDP
9. Installing Debian Linux 2.1 For x86 by Bruce Perens, Sven Rudolph, Igor Grobman, James Treacy,
Adam P. Harris ftp://ftp.debian.org/debian/dists/slink/main/disks−i386/current/install.html
10. Install−From−Zip−mini−HOWTO
11. ZIP−Drive−mini−HOWTO
4.2 Recommendation
17
Linux Laptop−HOWTO
5.2 Prerequisites − Partitioning
Partitioning can be done in a very sophisticated way. Currently I have only some first thoughts. I assume that
with laptops there are still some reasons (e.g. updating the firmware of PCMCIA cards and BIOS) to share
Linux and Windows9x/NT. Depending on your needs and the features of your laptop you could create the
following partitions:
• BIOS, some current BIOSes use a separate partition
• suspend to disk, some laptops support this feature
• swap space Linux
• swap space Windows9x/NT
• Linux base
• Linux /home or data
• common data between Linux and Windows9x/NT
Note this chapter isn't ready yet. Please read the according HOWTOs first.
5.3 Linux Tools to Repartition a Hard Disk
GNU parted
GNU parted allows you to create, destroy, resize and copy partitions. It currently supports ext2 and fat (fat16
and fat32) filesystems, and MS−DOS disklabels. This program can destroy data, and is not yet safe for
general use. parted is currently in its early developement stage.
ext2resize
ext2resize is a program capable of resizing (shrinking and growing) ext2 filesystems. Checks whether the
new size the user gave is feasible (i.e. whether the fs isn't too occupied to shrink it), connected to the
parted project.
fixdisktable
Something was recently published on the <linux−[email protected]> mailing list about a partition
recovery program. I have not used this, nor examined it, nor read much about it (except for the HTML page.)
It may be useful to some of you if you have problems with FIPS, Ranish Partition Manager/Utility or
Partition Magic destroying your partition information. You can find information on this partition−fixer
named "fixdisktable" at http://bmrc.berkeley.edu/people/chaffee/fat32.html . It is quite a ways down in that
page. Or look for it via ftp in ftp://bmrc.berkeley.edu/pub/linux/rescue/ and locate the latest "fixdisktable" in
that ftp directory. (Source and binary dist should be available.)
5.2 Prerequisites − Partitioning
18
Linux Laptop−HOWTO
Caveats
Before repartitioning your harddisk take care about the disk layout. Especially look for hidden disk space or
certain partitions used for suspend to disk or hibernation mode. Some laptops come with a partition which
contains some BIOS programs (e.g. COMPAQ Armada 1592DT). Search the manual carefully for tools like
PHDISK.EXE, Suspend to Disk, Diagnostic TOOLS.
Please see chapter DOS Tools to Repartition a Hard Disk, too.
By Nathan Myers from LL − LinuxLaptops: "I partitioned a 10G Thinkpad drive last week and then none of
fdisk, cfdisk, or sfdisk would read the partition table any more. It turns out I had created a partition that
started on cylinder 1024, and there's a bug common to all three programs that makes them fail in that case. (I
didn't try Disk Druid.) So, maybe you should add some advice about not starting partitions on that cylinder."
Multi Boot
Please see the Different Environments chapter, for information about booting different operating systems
from the same harddisk.
5.4 Installation Methods
From the Battery−HOWTO:"Installing and using Linux on a laptop is usually no problem at all, so go ahead
and give it a try. Unlike some other operating systems, Linux still supports and runs well on even very old
hardware, so you might give your outdated portable a new purpose in life by installing Linux on it."
One of the great benefits of Linux are its numerous and flexible installation features, which I don't want to
describe in detail. Instead I try to focus on laptop specific methods, which are necessary only in certain
circumstances.
Most current distributions support installation methods which are useful for laptops, including installation
from CD−ROM, via PCMCIA and NFS (or maybe SMB). Please see the documents which are provided with
these distributions for further details or take a look at the above mentioned manuals and HOWTOs.
5.5 From a Boot Floppy plus CD−ROM − The Usual Way
With modern laptops, the usual Linux installation (one Boot Floppy, one Support Floppy, one Packages
CD−ROM) should be no problem, if there is are floppy drive and a CD−ROM drive available. Though with
certain laptops you might get trouble if you can not simultaneously use the floppy drive and CD−ROM drive ,
or if the floppy drive is only available as a PCMCIA device, as with the Toshiba Libretto 100. Some laptops
support also booting and therefore installation completely from a CD drive, as reported for the SONY VAIO
in the VAIO−HOWTO. Note: Check the BIOS for the CD boot option and make sure your Linux distribution
comes on a bootable CD.
Certain laptops will only boot zImage kernels. bzImage kernels won't work. This is a known problem with the
IBM Thinkpad 600 and Toshiba Tecra series, for instance. Some distributions provide certain boot floppies
Caveats
19
Linux Laptop−HOWTO
for these machines or for machines with limited memory resources, Debian/GNU Linux
http://www.debian.org for instance.
5.6 From a DOS or Windows Partition at the Same Machine
This is a short description of how to install from a CD−ROM under DOS without using boot or supplemental
floppy diskettes. This is especially useful for notebooks with swappable floppy and CD−ROM
components (if both are mutually exclusive) or if they are only available as PCMCIA devices. I have taken
this method from "Installing Debian GNU/Linux 2.1 For Intel x86 − Chapter 5 Methods for Installing
Debian" http://www.debian.org :
1. Get the following files from your nearest Debian FTP mirror and put them into a directory on your
DOS partition: resc1440.bin drv1440.bin base2_1.tgz root.bin linux
install.bat and loadlin.exe.
2. Boot into DOS (not Windows) without any drivers being loaded. To do this, you have to press <F8>
at exactly the right moment.
3. Execute install.bat from that directory in DOS.
4. Reboot the system and install the rest of the distribution, you may now use all the advanced features
such as PCMCIA, PPP and others.
This should work for other distributions with similar changes. For RedHat see How to Install from CD−ROM
without Boot and Supplemental Disks .
Some new laptops may be able to boot a Linux distribution on a bootable CD−ROM (e.g., RedHat). This
would allow installation without a floppy disk drive.
5.7 From a Second Machine With a Micro Linux On a Floppy
Introduction
Because of their small or non−existent footprint, micro−Linuxes are especially suited to run on laptops,
particularly if you use a company−provided laptop running Windows9x/NT. Or for installation purposes
using another non Linux machine. There are several micro Linux distributions out there that boot from one or
two floppies and run off a ramdisk. See appendix A for a listing of distributions.
I tried the following with muLinuxhttp://mulinux.firenze.linux.it/ to clone my HP OmniBook 800 to a
COMPAQ Armada 1592DT. Thanks to Michele Andreoli, maintainer of muLinux for his support. Since
muLinux doesn't support PCMCIA yet, you may use TomsRtBt instead. In turn TomsRtBt doesn't
support PPP but provides slip. Note: Since version 7.0 muLinux provides an Add−On with PCMCIA
support.
I have described how to copy an already existing partition, but it might be also possible to achieve a
customized installation. Note: Usually you would try to achieve an installation via NFS, which is supported
by many distributions. Or if your sources are not at a Linux machine you might try the SMB protocol with
5.6 From a DOS or Windows Partition at the Same Machine
20
Linux Laptop−HOWTO
SAMBA, which is also supported by muLinux .
Prerequisites
You need two machines equipped with Linux. With the laptop (client/destination) on which you want to
install Linux use the muLinux floppy. The other machine (server/source) may be a usual Linux box or also
using muLinux. Though its low transfer rate I use a serial null modem cable because its cheap. You may
apply the according method using a PCMCIA network card and a crossover network cable or a HUB, or a
parallel "null modem" cable and PLIP. As the basic protocol I used PPP, but you may also use SLIP. For the
data−transfer I used nc. Note: this is an abbrevation for netcat, some distributions use this as the program
name. You may use ftp, tftp, rsh, ssh, dd, rcp, kermit, NFS, SMB and other programs instead.
Basic requirements are:
1. A good knowledge about using Linux. You have to know exactly what you are doing, if not you
might end destroying former installations.
2. A nullmodem serial cable.
Source Machine
At your source machine issue the following commands (attention: IP address, port number, partition and tty
are just examples!):
1. Edit /etc/ppp/options, it should contain only:
/dev/ttyS0
115200
passive
2. With muLinux versions 3.x you may even use the convenient command setup −f ppp .
3. Start PPP: pppd .
4. Configure the PPP network device: ifconfig ppp0 192.168.0.1 .
5. Add the default route: route add default gw 192.168.0.1 .
6. Check the network connection: ping 192.168.0.2, though the destination machine isn't up yet.
7. Start the transfer from another console, remember <LEFT−ALT><Fx>: cat /dev/hda2 |
gzip −c | nc −l −p 5555 .
8. After the transfer (there are no more harddisk writings) stop the ping: killall ping .
Destination Machine
At the destination machine issue:
Prerequisites
21
Linux Laptop−HOWTO
1. Edit /etc/ppp/options, it should contain only:
/dev/ttyS0
115200
passive
2. With muLinux versions >= 3.x you may even use the convenient command setup −f ppp .
3. Start PPP: pppd .
4. Configure the PPP network device: ifconfig ppp0 192.168.0.2 .
5. Add the default route: route add default gw 192.168.0.2 .
6. Check the network connection, by pinging to the source machine: ping 192.168.0.1 .
7. Change to another console and get the data from the server: nc 192.168.0.1 5555 | gzip
−dc >/dev/hda4 .
8. 400 MB may take app. 6 hours, but YMMV.
9. Stop the transfer, when it is finished with: <CTL><C> . This can probably be avoided (but I didn't
test it) by adding a timeout of 3 seconds using the −w 3 parameter for nc at the destination machine
nc −w 3 192.168.0.1 5555 | gzip −dc >/dev/hda4
10. After the transfer is completed, stop the ping: killall ping .
Configuration of the Destination Machine after the Transfer
1. Edit /etc/fstab .
2. Edit /etc/lilo.conf and /etc/lilo.msg and start lilo .
3. Set the new root device to the kernel: rdev image root_device .
Miscellaneous
1. You may use bzip2 the same way as gzip (untested).
2. Since rshd, sshd, ftpd daemons are not available with muLinux you have to build your own
daemon with nc aka netcat, as described above.
3. I had to set up both PPP sides very quick or the connection broke, I don't know why.
4. Speed optimization has to be done, asyncmap 0 or local?
5. I checked this only with a destination partition greater than the source partition. Please check
dd instead of cat therefore.
Or do the following (untested): At the destination machine cd into the root directory / and do nc
−l −p 5555 | bzip2 −dc | tar xvf −. At the source machine machine cd into the root
directory / and do tar cvf − . | bzip2 | nc −w 3 192.168.0.2 5555. This should
shorten the time needed for the operation, too. Because only the allocated blocks need to be
transfered.
6. Don't mount the destination partition.
Configuration of the Destination Machine after the Transfer
22
Linux Laptop−HOWTO
5.8 From a Second Machine With a 2.5" Hard Disk Adapter
From Adam Sulmicki [email protected] I got this hint: Most but not all harddisks in laptops are removable,
but this might be not an easy task. You could just buy one of those cheap 2.5" IDE converters/adapters which
allow you to connect this harddisk temporarily to a PC with IDE subsystem, and install Linux as usual using
that PC. You may do so using the harddisk as the first IDE drive or besides as the second IDE drive. But than
you need to be sure that lilo writes to the right partition. Also you have to make sure that you use the same
translation style as your laptop is going to use (i.e. LBA vs. LARGE vs. CHS ). You find additional
information in the Hard−Disk−Upgrade−mini−HOWTO. You might copy an existing partition, but it is also
possible to achieve a customized installation.
5.9 From a PCMCIA Device
Since I don't have a laptop which comes with a PCMCIA floppy drive (for instance Toshiba Libretto 100), I
couldn't check this method. Please see the chapter Booting from a PCMCIA Device in the
PCMCIA−HOWTO. Also I couldn't check whether booting from a PCMCIA harddisk is possible.
Anyway, when you are able to boot from a floppy and the laptop provides a PCMCIA slot, it should be
possible to use different PCMCIA cards to connect to another machine, to an external SCSI device, different
external CD and ZIP drives and others. Usually these methods are described in the documentation which is
provided with the distribution.
5.10 From a Parallel Port Device (ZIP Drive, CD Drive)
I couldn't check this method by myself, because I don't have such a device. Please check the according
Install−From−Zip−mini−HOWTO and CD−HOWTO. Also I don't know how much these installation
methods are supported by the Linux distributions or the micro Linuxes. I suppose you have to fiddle around a
bit to get this working.
5.11 From a Second Machine Using the Parallel Port − PLIP
Network Install
I got this courtesy by Nathan Myers <[email protected]>: "Many distributions support installing via a
network, using FTP, HTTP, or NFS. It is increasingly common for laptops to have only a single PCMCIA
slot, already occupied by the boot floppy drive. Usually the boot floppy image has drivers for neither the
floppy drive itself, nor the PCMCIA subsystem. Thus, the only network interface available may be the
parallel port.
Installation via the parallel port using the PLIP protocol has been demonstrated on, at least, Red Hat. All you
need is a Laplink parallel cable, cheap at any computer store. See the PLIP−mini−HOWTO for details on
setting up the connection. Note that (uniquely) the RedHat installation requires that the other end of the PLIP
connection be configured to use ARP (apparently because RedHat uses the DOS driver in their installer). On
the host, either export your CD file system on NFS, or mount it where the ftp or web daemon can find it,
5.8 From a Second Machine With a 2.5" Hard Disk Adapter
23
Linux Laptop−HOWTO
as needed for the installation."
The PLIP Install HOWTO by Gilles Lamiral describes how to install the Debian GNU−Linux distribution on
a computer without ethernet card, nor cdrom, but just a local floppy drive and a remote nfs server attached by
a Null−Modem parallel cable. The nfs server has a cdrom drive mounted and exported.
5.12 Installing Linux on Small Machines
If you have less than 8MB memory and want to install via NFS you may get the message "fork: out of
memory". To handle this problem, use fdisk to make a swap partition (fdisk should be on the install
floppy or take one of the mini Linuxes described above). Then try to boot from the install floppy again.
Before configuring the NFS connection change to another console (for instance by pressing <ALT><2>) and
issue swapon /dev/xxx (xxx = swap partition ). Thanks to Thomas Schmaltz.
6.Hardware In Detail
6.1 PCMCIA Controller
Linux Compatibility Check
With the probe command, which is included in the PCMCIA−CS package by David Hinds you can get the
type of the PCMCIA controller. Often this shows also up with cat /proc/pci .
Related HOWTOs
1. PCMCIA−HOWTO
PCMCIA Configuration − Survey
In the mailing lists where I'm a member, the question "How can I set up PCMCIA support, after the Linux
installation?" comes up sometimes. Therefore I try to give a short survey. But the authoritative source for the
latest information about the PCMCIA Card Services for Linux, including documentation, files, and generic
PCMCIA information is the Linux PCMCIA Information Page . For problems with PCMCIA and APM see
the APM chapter.
5.12 Installing Linux on Small Machines
24
Linux Laptop−HOWTO
Software
1. Read the PCMCIA HOWTO, usually included in the PCMCIA−CS package.
2. Install the newest available PCMCIA−CS package, if you take a rpm or deb package it is quite easy.
3. If necessary, install a new kernel. Note: With 2.2.x kernels PCMCIA kernel support seems no longer
necessary. I had no time to look this up yet. Please read the according documents.
4. Make sure your kernel has module support and PCMCIA support enabled (and often APM support)
5. Make sure your kernel also includes support for the cards you want to use, e.g. network support for a
NIC card, serial support for a modem card, SCSI support for a SCSI card and so on.
6. If you have a custom made kernel, don't forget to compile the PCMCIA−CS source against your
kernel.
PCMCIA Controller
1. Use the probe command to get information whether your PCMCIA controller is detected or not.
2. Edit the file /etc/sysconfig/pcmcia. It should include PCMCIA=y and the type of your PCMCIA
controller, e.g. PCIC=i82365.
3. Start the PCMCIA services typically via /etc/init.d/pcmcia start. If you get two high
beeps, everything should be fine.
4. If something doesn't work, check the messages in /var/log/messages .
PCMCIA Card
1. Check your card with cardctl ident .
2. If your card is not in /etc/pcmcia/config, edit the file /etc/pcmcia/config.opts accordingly. Take an
entry in the first file as a model. You may try every driver, just in case it might work, for instance the
pcnet_cs supports many NE2000 compatible PCMCIA network cards.
3. A list of supported cards is included in the PCMCIA−CS package. The current list you may find at
http://hyper.stanford.edu/~dhinds/pcmcia/ftp/SUPPORTED.CARDS.
Since there are not all cards mentioned I have set up a page PCMCIA Cards "Unofficially" Supported
by Linux .
4. If you use X, you can use cardinfo to insert, suspend, or restart a PCMCIA card via a nice
graphical interface.
6.2 Infrared Port
Software
25
Linux Laptop−HOWTO
Linux Compatibility Check
To get the IrDA port of your laptop working with Linux/IrDA you may use StandardInfraRed (SIR) or
FastInfraRed (FIR).
SIR
Up to 115.200bps, the infrared port emulates a serial port like the 16550A UART. This will be detected by
the kernel serial driver at boot time, or when you load the serial module. If infrared support is enabled in the
BIOS, for most laptops you will get a kernel message like:
Serial
ttyS00
ttyS01
ttyS02
driver version
at 0x03f8 (irq
at 0x3000 (irq
at 0x0300 (irq
4.25 with no serial options enabled
= 4) is a 16550A
#first serial port /dev/ttyS0
= 10) is a 16550A
#e.g. infrared port
= 3) is a 16550A
#e.g. PCMCIA modem port
FIR
If you want to use up to 4Mbps, your machine has to be equipped with a certain FIR chip. You need a certain
Linux/IrDA driver to support this chip. Therefore you need exact information about the FIR chip. You may
get this information in one of the following ways:
1. Read the specification of the machine, though it is very rare that you will find enough and reliable
information there.
2. Try to find out wether the FIR chip is a PCI device. Do a cat /proc/pci . The according files
for 2.2.x kernels are in /proc/bus/pci . Though often the PCI information is incomplete. You may find
the latest information about PCI devices and vendor numbers in the kernel documentation usually in
/usr/src/linux/Documentation or at the page of Craig Hart http://members.hyperlink.net.au/~chart .
From kernel 2.1.82 on, you may use lspci from the pci−utils package, too.
3. Use the DOS toolCTPCI330.EXE provided in ZIP format by the German computer magazine CT
http://www.heise.de/ct/ftp/pci.shtml . The information provided by this program is sometimes better
than that provided by the Linux tools.
4. Try to get information about Plug−and−Play (PnP) devices. Though I didn't use them for this
purpose yet, the isapnp tools, could be useful.
5. If you have installed the Linux/IrDA software load the FIR modules and watch the output of dmesg,
whether FIR is detected or not.
6. Another way how to figure it out explained by Thomas Davis (modified by WH): "Dig through the
FTP site of the vendor, find the Windows9x FIR drivers, and they have (for a SMC chip):
−rw−rw−r−−
−rw−rw−r−−
−rw−rw−r−−
−rw−rw−r−−
1
1
1
1
ratbert
ratbert
ratbert
ratbert
ratbert
ratbert
ratbert
ratbert
743
17021
1903
31350
Apr 3
Mar 24
Jul 18
Jun 7
1997
1997
1997
1997
smcirlap.inf
smcirlap.vxd
smcser.inf
smcser.vxd
If in doubt, always look for the .inf/.vxd drivers for Windows95. Windows95 doesn't ship with
Linux Compatibility Check
26
Linux Laptop−HOWTO
_ANY_ FIR drivers. (they are all third party, mostly from Counterpoint, who was assimilated by
ESI)."
7. Also Thomas Davis found a package of small DOS utilities made by SMC. Look at
http://www.smsc.com/ftppub/chips/appnote/ir_utils.zip . The package contains FINDCHIP.EXE.
And includes a FIRSETUP.EXE utility that is supposed to be able to set all values except the chip
address. Furthermore it contains BIOSDUMP.EXE, which produces this output:
Example 1 (from a COMPAQ Armada 1592DT)
In current devNode:
Size
= 78
Handle
= 14
ID
= 0x1105D041 = 'PNP0511' −− Generic IrDA SIR
Types: Base = 0x07, Sub = 0x00, Interface = 0x02
Comm. Device, RS−232, 16550−compatible
Attribute = 0x80
CAN be disabled
CAN be configured
BOTH Static & Dynamic configuration
Allocated Resource Descriptor Block TAG's:
TAG=0x47, Length=7 I/O Tag, 16−bit Decode
Min=0x03E8, Max=0x03E8
Align=0x00, Range=0x08
TAG=0x22, Length=2 IRQ Tag, Mask=0x0010
TAG=0x79, Length=1 END Tag, Data=0x2F
Result 1:
Irq Tag, Mask (bit mapped − ) = 0x0010 = 0000 0000 0000 0001 0000 so,
it's IRQ 4. (start at 0, count up ..), so this is a SIR only device, at IRQ=4, IO=x03e8.
Example 2 (from an unknown machine)
In current devNode:
Size
= 529
Handle
= 14
ID
= 0x10F0A34D = 'SMCF010' −− SMC IrCC
Types: Base = 0x07, Sub = 0x00, Interface = 0x02
Comm. Device, RS−232, 16550−compatible
Attribute = 0x80
CAN be disabled
CAN be configured
BOTH Static & Dynamic configuration
Allocated Resource Descriptor Block TAG's:
TAG=0x47, Length=7 I/O Tag, 16−bit Decode
Min=0x02F8, Max=0x02F8
Align=0x00, Range=0x08
TAG=0x22, Length=2 IRQ Tag, Mask=0x0008
TAG=0x47, Length=7 I/O Tag, 16−bit Decode
Min=0x02E8, Max=0x02E8
Align=0x00, Range=0x08
TAG=0x2A, Length=2 DMA Tag, Mask=0x02, Info=0x08
TAG=0x79, Length=1 END Tag, Data=0x00
Linux Compatibility Check
27
Linux Laptop−HOWTO
Result 2:
a) it's a SMC IrCC chip
b) one portion is at 0x02f8, has an io−extent of 8 bytes; irq = 3
c) another portion is at 0x02e8, io−extent of 8 bytes; dma = 1 (0x02 =0000 0010)
Thomas Davis has placed some device information at http://www.jps.net/tadavis/irda/devids.txt .
WARNING: The package is not intended for the end user, and some of the utilities could be harmful.
The only documentation in the package is in M$ Word format. Linux users may read this with
catdoc, available at http://www.fe.msk.ru/~vitus/catdoc/ .
8. Use the Device Manager of Windows9x/NT.
9. You may also use the hardware surveys mentioned below.
10. And as a last ressort, you may even open the laptop and look at the writings at the chipsets themselfs.
Hardware Survey
I have made a hardware survey at http:/www.snafu.de/~wehe/ir_misc.html. This list also contains
information about infrared capable devices which are not mentioned here (mice, printers, remote control,
transceivers, etc.).
To make this list more valuable, it is necessary to collect more information about the infrared devices in
different hardware. You can help by sending me a short e−mail containing the exact name of the hardware
you have and which type of infrared controller is used.
Please let me know also how well Linux/IrDA worked (at which tty, port and interrupt it works and the
corresponding infrared device, e.g. printer, cellular phone).
Also you can help by contributing detailed technological information about some infrared devices, which is
necessary for the development of drivers for Linux.
Related HOWTOs
1. Linux/IR−HOWTO
Hardware Survey
28
Linux Laptop−HOWTO
IrDA Configuration − Survey
IrDA
The Linux infrared support is still experimental, but rapidly improving. I try to describe the installation in a
short survey. Please read my Linux/IR−HOWTO http://www.snafu.de/~wehe/index_li.html for detailed
information.
Kernel
1. Get a 2.2.x kernel.
2. Compile it with all IrDA options enabled.
3. Also enable experimental, sysctl, serial and network support.
Software
1. Get the Linux/IrDA software irda−utils at The Linux IrDA Project .
2. Untar the package.
3. Do a make depend; make all; make install
Hardware
1. Enable the IrDA support in the BIOS.
2. Check for SIR or FIR support, as described above.
3. Start the Linux/IrDA service with irmanager −d 1 .
4. Watch the kernel output with dmesg .
Linux Remote Control − LiRC
Linux Remote Control http://fsinfo.cs.uni−sb.de/~columbus/lirc/ is maintained by Christoph Bartelmus. "Lirc
is a package that supports receiving and sending IR signals of the most common IR remote controls. It
contains a device driver for hardware connected to the serial port, a daemon that decodes and sends IR signals
using this device driver, a mouse daemon that translates IR signals to mouse movements and a couple of user
programs that allow to control your computer with a remote control." I don't have valid information about
how much infrared remote control is working with laptop infrared devices.
IrDA Configuration − Survey
29
Linux Laptop−HOWTO
6.3 Graphic Chip
Linux Compatibility Check
Video Mode
The tool SuperProbe is part of XFree86 and is able to check many graphic chips. Please read the
documentation carefully, because it might crash your hardware. From man SuperProbe:
"SuperProbe is a a program that will attempt to determine the type of video hardware installed in an
EISA/ISA/VLB−bus system by checking for known registers in various combinations at various locations
(MicroChannel and PCI machines may not be fully supported; many work with the use of the
−no_bios option). This is an error−prone process, especially on Unix (which usually has a lot more
esoteric hardware installed than MS−DOS system do), so SuperProbe may likely need help from the user.
...
At this time, SuperProbe can identify MDA, Hercules, CGA, MCGA, EGA, VGA, and an entire horde of
SVGA chipsets (see the −info option, below). It can also identify several HiColor/True−color RAMDACs in
use on SVGA boards, and the amount of video memory installed (for many chipsets). It can identify 8514/A
and some derivatives, but not XGA, or PGC (although the author intends to add those capabilities). Nor can it
identify other esoteric video hardware (like Targa, TIGA, or Microfield boards).":
For testing reasons start the X server with X 2> <error.msg>. And try to change the resolution by typing
<CTL><ALT><+> or <CTL><ALT><−>. Note: the + or − sign have to be taken from the numeric pad,
which can be emulated at the letter pad by some laptops.
Text Mode
Just watch the display and determine if it works properly. If not, try to enable different video modes at startup
time. Setting up X can sometimes be an exercise in trial and error.
Related HOWTOs
1. XFree86−HOWTO
2. XFree86−Video−Timings−HOWTO
3. XFree86−XInside−HOWTO
4. X−Big−Cursor−mini−HOWTO (useful when running X on a notebook with low contrast LCD)
5. Keyboard−and−Console−HOWTO
6. vesafb−mini−HOWTO
6.3 Graphic Chip
30
Linux Laptop−HOWTO
Survey X−Servers
You might discover that some features of your laptop are not supported by XFree86, e.g. high resolutions,
accelerated X or an external monitor. Therefore I give a survey of available X servers.
1. XFree86 http://www.xfree86.org
2. VESA Frame−Buffer−Device, available with 2.2.x kernels and XFree86 3.3.2
3. Xinside aka AcceleratedX http://www.xig.com , commercial
4. SciTech http://www.scitechsoft.com , commercial
5. Metro−X at http://www.metrolink.com, commercial .
If you can't get an appropriate X server working, but don't want to effort a commercial X server you may try
the VGA16 or the mono server included in XFree86.
Resources
You may find a survey about X windows resources at Kenneth E. Harker's page Linux on Laptops and a
survey about current graphic chips used in laptops at LiLAC − Linux with Laptop Computers.
External Monitor
There are several different methods to activate support for an external monitor: as a BIOS option or during
runtime with a keystroke e.g. <Fn>+<F4>. Maybe you have to edit /etc/XF86Config by configuring
int_disp and ext_disp. If you can't get this to work with XFree, try a demo version of the commercial
X servers mentioned above. Also check with the RedHat and SuSE WWW sites as they may have new,
binary−only, X servers that may work with your laptop.
Miscellaneous
Sometimes you may encounter a display not working properly in text mode. Currently I don't have any
recommendations, please see Keyboard−Console−HOWTO.
Take care of the backlight AFAIK this device can only bear a limited number of uptime circles. So avoid
using screensavers too much.
For problems with X windows and APM please see the APM chapter.
6.4 Sound
Survey X−Servers
31
Linux Laptop−HOWTO
Linux Compatibility Check
The only way I know to check this, is to compile the different sound drivers into the kernel and check
whether they are detected or not. The best way to do so, is to compile them as modules because it's easier to
load different parameters such as interrupts and IO ports than. For the new 2.2.x kernels, read the
/usr/src/linux/Documentation/sound/Introduction document by Wade Hampton. This document may help you
get started with sound. Also, you might try one of the commercial sound drivers mentionend below.
Related HOWTOs
1. Sound−HOWTO
2. Visual−Bell−mini−HOWTO
Survey Sound Drivers
Many new laptops come with 16−bit sound. But MWave and some other sound technologies won't work or
are very hard to get working, e.g. booting to DOS, loading a driver, then using the soundcard as a standard
SB−PRO. So you might need a commercial sound driver. With the recent announcement of Linux support by
IBM, it would be GREAT if IBM supported the MWave under Linux (hint, hint...). As a last ressort you may
try the speaker module pcsnd, which tries to emulate a soundcard.
1. Kernel Sound Driver by Hannu Savolainen
2. ALSA Advanced Linux Sound Architecture , commercial or at least non−GPL (since I found a
Debian/GNU Linux package I'm not sure anymore, about the commercial status)
3. OSS UNIX Sound System Lite / OSS, commercial or at least non−GPL (since the 2.2.x kernels I'm
not sure about the commercial status), also available from http://www.opensound.com .
6.5 Keyboard
Linux Compatibility Check
Usually there are no problems with Linux and the keyboard. Though there are two minor caveats: First the
setleds program might not work. Second the key mapping might not fit your needs. Some Unix users and
vi users expect to find the <CONTROL> key to the left of the <A> key. Many PC−type keyboards have the
<CAPS−LOCK> key there. You may use xmodmap or loadkeys to re−map the keyboard. Some laptops
(e.g., Toshiba) allow you to swap the <CAPS−LOCK> and <CONTROL> keys. Mark Alexander offered this
solution in the linux−laptop mailing list: On RedHat, it's a one−line patch to /usr/lib/kbd/keytables/us.map ,
or whatever file is referenced in /etc/sysconfig/keyboard:
*** us.map~
−−− us.map
Tue Oct 31 14:00:07 1995
Thu Aug 28 13:36:03 1997
Linux Compatibility Check
32
Linux Laptop−HOWTO
***************
*** 113,119 ****
keycode 57 = space
control keycode 57
alt
keycode 57
! keycode 58 = Caps_Lock
keycode 59 = F1
control keycode 59
alt
keycode 59
−−− 113,119 −−−−
keycode 57 = space
control keycode 57
alt
keycode 57
! keycode 58 = Control
keycode 59 = F1
control keycode 59
alt
keycode 59
space
= nul
= Meta_space
F11
= F1
= Console_1
Console_13
space
= nul
= Meta_space
F11
= F1
= Console_1
Console_13
External (Second) Keyboard
A second (or external) keyboard can be attached using the PS/2 port (I suppose this is not possible via the
serial port, since there is no keyboard controller for the serial port). Also there is one laptop with a detachable
keyboard the Siemens Scenic Mobile 800. This machine uses an infrared connection to the keyboard, but I
don't know whether this works with Linux. WARNING: Don't plug the external keyboard in while the laptop
is booted, or plug the mouse in the keyboard port and the keyboard in the mouse port. On a Toshiba, this
caused one user to have to completely shutdown the laptop, remove the keyboard/mouse, and do a cold
reboot.
For PS/2 ports there are so called Y−Cable available, which make it possible to use external mouse and
external keyboard at the same time if your laptop supports this feature.
Parport to AUX port adapter In some cases one kbd port and one aux port is not enough and you may want to
add another keyboard or mouse. You can use this adapter, together with the parkbd.c module for that.
On some laptops a splitter works to allow both mouse and keyboard to be plugged in; on others it doesn't
work at all.If you might want to use both you had better check that it works, or you may find yourself waiting
anxiously for USB support.
Sun keyboard to PC serial port adapter: Many people have dreamed having their Sun Type 5 keyboard
attached to their Linux box up to now. And with this adapter, it is finally possible. Because the standard Sun
keyboards use TTL RS232 at 1200 bps to talk to the Suns, it's very easy to make them talk to any non−Sun
computer by converting this to true RS232. All what you need is a MAX232 chip that'll take care about the
correct voltage levels, and also some chip to invert the signals (CD4049 in the pic, I've used a 7400
quad−nand myself), since the MAX232 inverts them as well, and we don't need this. This all easily fits into a
25−pin serial connector.
External (Second) Keyboard
33
Linux Laptop−HOWTO
6.6 Pointing Devices − Mice and Their Relatives
Linux Compatibility Check
You may check your mouse with the mev command from the GPM package.
Related HOWTOs
1. 3−Button−Mouse−mini−HOWTO for serial mice
2. Bus−Mouse−HOWTO
3. Kernel−HOWTO
Mice Species
1. Trackpad, Touchpad, used with the majority of current laptops
2. Trackball, e.g. COMPAQ LTE
3. Pop−up−Mouse, e.g. HP OmniBook 800
4. Trackpoint, Mouse−Pin, e.g. IBM ThinkPad and Toshiba
5. 3 Button Mice, e.g. IBM Thinkpads at least the 600s. I have heard rumor about a 3 button mouse for
Texas Instruments Travelmates, but couldn't verify this yet.
PS/2 Mice
Most of the mice used in laptops are PS/2 mice (actually I don't know one with another mouse protocol). You
may communicate with the PS/2 mouse through /dev/psaux or /dev/psmouse. If you use X windows this
device and the protocol has to be set in /etc/XF86Config, too. In earlier releases, sometimes the GPM mouse
manager and X windows had trouble sharing a mouse when enabled at the same time. But AFAIK this is no
problem anymore for the latest versions.
Speaking of Emulate3Buttons, 100ms is usually better than the 50ms allowed in most default setups of
/etc/X11/XF86Config.
Section "Pointer"
Protocol
"PS/2"
Device
"/dev/psaux"
Emulate3Buttons
Emulate3Timeout
100
EndSection
6.6 Pointing Devices − Mice and Their Relatives
34
Linux Laptop−HOWTO
Touchpad
Usually a touchpad works with the PS/2 mouse driver. A tip: I've heard that tipping with one , two or three
fingers on the touchpad simultaneously results in pressing the left, middle and respectively the right
mouse−button (by Martin Hoffmann <[email protected]−hamburg.de> for an IPC−Radiance 900).
There is also a dedicated touchpad driver available. The Synaptics Touchpad Linux Driver supports pointing
devices used in notebooks by Acer, Compaq, Dell, Gateway, Olivetti, Texas Instruments, Winbook, and
others. Other URL N.N..
The recent gpm package ( gpm >=1.8) includes the above mentioned synaptics touchpad device driver. This
device driver has been developed by H. Davies <[email protected]>. Instead of using the PS/2
compatibility mode of touchpad devices, you can now use native touchpad mode with some pretty impressive
features.
In addition to translating finger motion into mouse motion and supporting the buttons, this support currently
has several features (from the README):
• a "tap" on the TouchPad causes a left mouse click
• a "tap" followed quickly by a finger motion causes a left button drag type action.
• a "tap" in one of the corners causes an action the default configuration is upper right causes middle
mouse click and lower right causes right mouse click
• more pressure on the touch pad speeds the motion of the cursor
• a "tap" with a motion component (default > 2mm) initiates a toss and catch sequence. This is
terminated by a finger touch on the pad (the toss also ends after 1 sec since that is the idle timeout
period for the touchpad).
• if the finger moves close to an edge then the mouse motion will be continued in that direction so that
you don't need to pick up your finger and start moving again. This continued motion is pressure
sensitive (more pressure is faster motion).
These features can be enabled/disabled and many of them have time and speed parameters which can be
adjusted to the taste of the user.
It seems gpm is best known as a console biased tool. This is true, but you may use it as an X input device.
gpm is used as a repeater device. In this way you can use both the built−in synaptics touchpad with all the
features and at the same time a serial mouse (with three buttons). This all works smoothly together. X reads
the mouse events from a named pipe /dev/gpmdata in a protocol it understands, which in my case is
Mouse−Systems−Compatible (5bytes). Most 3−button mice use the default protocol. So a simple
reconfiguration in XF86Config is all that is required, after starting gpm in an appropriate way, of course.
gpm could be started on your laptop with the following arguments : /usr/bin/gpm −t synps2 −M
−t ms −m /dev/ttyS0 . Both touchpad and serial mouse work in console and X mode. You do have to
create the named pipe /dev/gpmdata yourself.
Tapping with two fingers simultaneously to simulate a middle mouse button works on Logitech touchpads
used in a few machines.
Thanks to Geert Van der Plas for most of the touchpad chapter.
Touchpad
35
Linux Laptop−HOWTO
Touchscreen
The only laptop I know which includes a touchscreen is the Fujitsu Biblo 112. It may work in PS/2 or serial
mouse compatibility mode. But I couldn't check this yet.
COMPAQ Concerto Pen
The latest version of the Linux Compaq Concerto Pen Driver is available from Joe Pfeiffer's home page.
External Mouse
For better handling, e.g. with a 3 button mouse you may use an external mouse. This usually a serial mouse
or a PS/2 mouse, according to the port your laptop offers. Usually this is no problem.
For PS/2 ports there are so called Y−Cable available, which make it possible to use external mouse and
external keyboard at the same time if your laptop supports this feature.
WARNING: Don't plug in the external mouse while powered up. If you have separate mouse and keyboard
ports, make sure you plug the mouse in the mouse port and the keyboard in the keyboard port. If you don't,
you may have to do a hard reboot of the laptop to get it to recover.
6.7 Advanced Power Management − APM
Linux Compatibility Check
From the Battery−Powered−mini−HOWTO " .. for APM to work on any notebook or energy−conscious
desktop, the system BIOS ROM in the machine must support the APM Specification standard. Furthermore,
for APM to work with the Linux operating system, the system BIOS ROM must support either the 1.0 or 1.1
version of the APM standard, and it must also support 32−bit protected mode connections. A system that
supports APM 1.1 is preferred, as it provides more features that the device driver and supporting utilities can
take advantage of."
You may get information about the APM version with the dmesg command and in the /proc/apm file.
Introduction
Features of APM according to Documentation/Configure.help: "The system time will be reset after a USER
RESUME operation, the /proc/apm device will provide battery status information, and user−space programs
will receive notification of APM events (e.g., battery status change). "
APM support consists of two parts: kernel support and user−land support.
Touchscreen
36
Linux Laptop−HOWTO
Kernel Land
For kernel support, enable the parameters in the corresponding kernel section. Some features need special
tweaking with certain machines (e.g. IBM ThinkPad) or even don't work, ("TI 4000M TravelMate and the
ACER 486/DX4/75 because they don't have compliant BIOSes"). Currently all distributions I know don't
provide a kernel with APM support enabled. So you usually have to compile your custom kernel. Please see
Kernel−HOWTO or distribution manual for details. The available APM options are (please see
Documentation/Configure.help in the kernel source tree for more details):
• CONFIG_APM_IGNORE_USER_SUSPEND Just a workaround for some NEC Versa M series
laptops.
• CONFIG_APM_DO_ENABLE Enable APM features at boot time.
• CONFIG_APM_CPU_IDLE. Puts CPU in power save mode, if there is nothing to do for the kernel.
• CONFIG_APM_DISPLAY_BLANK Some laptops can use this to turn off the LCD backlight when
the screen blanker of the Linux virtual console blanks the screen. Note that this is only used by the
virtual console screen blanker, and won't turn off the backlight when using the X Window system.
• CONFIG_APM_POWER_OFF Turns the machine completely down, when using halt. This feature
works with most laptops without problems.
• CONFIG_APM_IGNORE_MULTIPLE_SUSPEND Just a workaround for IBM ThinkPad 560.
• CONFIG_APM_IGNORE_SUSPEND_BOUNCE Just a workaround for Dell Inspiron 3200 and other
notebooks.
• CONFIG_APM_RTC_IS_GMT Stores time in Greenwich Mean Time format. It is in fact
recommended to store GMT in your real time clock (RTC) in the BIOS.
• CONFIG_APM_ALLOW_INTS Resolves some problems with Suspend to Disk for some laptops, for
instance many newer IBM ThinkPads.
Joey Hess <[email protected]> wrote at debian−[email protected] "I just installed kernel 2.2.12 on my
laptop, and was having some trouble getting apm working. it said apm disabled on user request at boot time.
Well, some grepping the kernel sources found that passing apm=on to the kernel at boot time enables it now.
I can't find any record or docs of this change.
User Land
The utilities for userland support may be found at http://worldvisions.ca/~apenwarr/apmd/. APMD is a set of
programs that control the Advanced Power Management system found in most modern laptop computers. If
you run a 2.2.x kernel and want to experiment, Gabor Kuti <[email protected]> has made a kernel
patch that allows you to hibernate any Linux system to disk, even if your computers APM BIOS doesn't
support it directly. IMHO you don't need this features if your laptop provides a function key to invoke
suspend mode directly.
When you first install Linux, you will probably have to recompile the kernel. The kernel that came with your
distribution probably does not have APM enabled.
Please see the Battery Powered Linux Mini−HOWTO by <[email protected]> Hanno Mueller and the page
of Kenneth E. Harker for detailed information.
Kernel Land
37
Linux Laptop−HOWTO
README apmd?:On laptop computers, the APM support provides access to battery status information and
may help you to conserve battery power, depending on your laptop and the APM implementation.
Rik Faith <[email protected]> has transferred maintenance of the Linux apmd package over to me, Avery
Pennarun <[email protected]> and I'm finally getting around to making a release with the many
updates we've collected since the last release back in 1996.
Here's what apmd can do:
• apmd(8): logs the battery status to syslog every now and then and handles background power
management tasks;
• apm(1): a command−line tool to print the current battery status or suspend the computer;
• xapm(1x): provides a battery meter for X;
• libapm.a: a library for writing similar APM applications.
Richard Gooch wrote: I'have had a look at the beta version of apmd, and I still don't like it, because:
• Only supports one command to run at suspend time.
• Doesn't distinguish between user and system suspends.
• doesn't provide a way to disable policy (the sync(); sleep(0) ; sync(); sleep(1);
sequence)
• Does not document extra features.
• And I'm not sure that what we want is a single super daemon. A collection of smaller daemons might
be better, since it allows people to pick and choose. A super daemon is bloat for those who only want
one small feature.
Though this topic was discussed controversly Richard Gooch has put together a package suspendd at
http://www.atnf.csiro.au/~rgooch/linux/ .
Also, have a look at apmcd (apm based crontab) at ftp://ftp.binary9.net/pub/linux/ . A tool made by Nicolas
J. Leon <[email protected]> http://mrnick.binary9.net/.
Note: I didn't check wether this features are merged into one package (apmd eventually) already.
Caveats
If you have another operating system preinstalled or use another operating system at the same disk, make sure
there is no "hibernation" or "suspend" tool installed, which could severely interfere with Linux, e.g. it might
use disk space which is occupied by Linux or vice versa.
Troubleshooting
If your machine worked with 2.0.x kernels but not with the 2.2.x series, take this advice from Klaus Franken
[email protected] : "The default changed in 2.2. Search in the init−scripts for halt and change it to
halt −p or poweroff. See man halt , if you don't have this option you need a newer version of
halt." You may find it in the SysVinit package.
Caveats
38
Linux Laptop−HOWTO
On some new machines (for instance HP Omnibook 4150 − 366 MHz model) when accessing /proc/apm, you
may get a kernel fault general protection fault: f000. Stephen Rothwell
<[email protected]> http://www.canb.auug.org.au/~sfr/ explaines: "This is your APM
BIOS attempting to use a real mode segment while in protected mode, i.e. it is a bug in your BIOS. .. We
have seen a few of these recently, except all the others are in the power off code in the BIOS wher we can
work around it by returning to real mode before attempting to power off. Here we cannot do this."
apmd−rhcn−2.4phil−1 by RedHat ftp://rhcn.redhat.com/pub/rhcn/ contains an unofficial patch for
shutting down the PCMCIA sockets before a suspend and patches for multiple batteries.
According to Documentation/Configure.help: "Some other things you should try when experiencing
seemingly random, weird problems:
1. make sure that you have enough swap space and that it is enabled.
2. pass the no−hlt option to the kernel.
3. switch on floating point emulation in the kernel and pass the no387 option to the kernel.
4. pass the floppy=nodma option to the kernel.
5. pass the mem=4M option to the kernel (thereby disabling all but the first 4 MB of RAM).
6. make sure that the CPU is not over clocked.
7. read the sig11 FAQ at http://www.bitwizard.nl/sig11/ .
8. disable the cache from your BIOS settings.
9. install a fan for the video card or exchange video RAM.
10. install a better fan for the CPU.
11. exchange RAM chips.
12. exchange the motherboard.
APM and PCMCIA
PCMCIA Card Services and Advanced Power Management (from the PCMCIA−HOWTO):
"Card Services can be compiled with support for APM (Advanced Power Management) if you've configured
your kernel with APM support. ... The PCMCIA modules will automatically be configured for APM if a
compatible version is detected on your system. Whether or not APM is configured, you can use cardctl
suspend before suspending your laptop, and cardctl resume after resuming, to cleanly shut down and
restart your PCMCIA cards. This will not work with a modem that is in use, because the serial driver isn't
able to save and restore the modem operating parameters. APM seems to be unstable on some systems. If you
experience trouble with APM and PCMCIA on your system, try to narrow down the problem to one package
or the other before reporting a bug. Some drivers, notably the PCMCIA SCSI drivers, cannot recover from a
suspend/resume cycle. When using a PCMCIA SCSI card, always use cardctl eject prior to
suspending the system.".
APM and Resuming X Windows
"Many (most?) BIOSes fail to save and restore display controller chip registers, and X has no protocol to be
notified of resume events, so on many systems suspend/resume is more−or−less incompatible with X." Linux
Laptops has created a fix for this problem.
APM and PCMCIA
39
Linux Laptop−HOWTO
Sometimes X windows and APM don't work smoothly together, the machine might even hang. A
recommendation from Steve Rader: Some linux systems have their X server hang when doing apm −s.
Folks with this affliction might want switch to the console virtual terminal then suspend chvt 1; apm
−s as root, or, more appropiately.sudo chvt 1; sudo apm −s. I have these commands in a script,
say, my−suspend and then do xapmload −−click−command my−suspend .
Modularization of APM
As far as I remember this is controversly discussed, but I don't remember the URL. It isn't a kernel feature
yet.
APM Resume Options
The new 3.0beta versions add a new feature to apmd: it can run arbitrary commands (like cardctl
suspend) when you suspend or resume your system. It also supports BIOS clocks that are set to UTC time.
APM and Sound
Lots of BIOSes fail to restore sound chip registers, so you may get a squeal of feedback when you wake up
the machine. A script in /etc/apm/event.d can use aumix to save and restore sound mixer settings.
Software Suspend
Software suspend enables the possibilty of suspendig machine. It doesn't need APM. You may suspend your
machine by either pressing Sysrq−d or with 'swsusp' or 'shutdown −z (patch for sysvinit needed). It creates an
image which is saved in your active swaps. By the next booting the kernel detects the saved image, restores
the memory from it and then it continues to run as before you've suspended. If you don't want the previous
state to continue use the 'noresume' kernel option.
6.8 ACPI
ACPI stands for Advanced Configuration and Power Interface. This is a specification by Toshiba, Intel and
Microsoft. Besides many other things it also defines power management. This is why it is often compared to
APM.
The ACPI4Linux project has started at the beginning of 1999. The ACPI4Linux project is a kernel driver
project aimed at implementing full ACPI support for Linux, including fan control, dock/undock detection and
a WindowMaker dockable temperature meter. You may reach it at ACPI4Linux.
Modularization of APM
40
Linux Laptop−HOWTO
6.9 Batteries
For information about available battery types, take a look at the Hardware Features chapter above.
Please see Battery Powered Linux Mini−HOWTO by Hanno Mueller <[email protected]>
http://www.hanno.dePower Supplies for Laptops − (Draft) for further information.
Stephen Rothwell http://www.canb.auug.org.au/~sfr/ is currently integrating a patch that will add multiple
battery support to the kernel APM.
From the mobile−update page (modified by WH): Discharge the battery. If your battery runs only for
about 20 minutes, you probably suffer from memory effects. Most laptops do not discharge the battery
properly. With low powered devices like old computer fans they can be discharged completely. This removes
memory effects. You should do so even with LiIon batteries, though they don't suffer much from memory
effext (the manual of an IBM Thinkpad says to cycle the batteries through a full charge/discharge cycle 3
times every few months or so).
WARNING: Try this at your own risk! Make sure the voltage of the fans is compatible to your battery. It
works for me.
In the US, this company has most batteries for anything and can rebuild many that are no longer
manufactured: Batteries Plus, 2045 Pleasant Hill Road, Duluth, GA 30096 +1 770 495 1644.
6.10 Memory
Unfortenately most laptops come with a proprietary memory chips. So they are not interchangeable between
different models. But this seems changing.
6.11 Plug−and−Play Devices (PnP)
The Plug and Play driver project for Linux is a project to create support within the Linux kernel (see
Linux.Org for more information) for handling Plug and Play (and other semi−PnP) devices in a clean,
consistent way. It aims to allow a driver of any type of hardware to have this hardware configured by the PnP
driver in the kernel. This driver is then notified when the device is reconfigured, or even removed from the
system, so as to allow for graceful action in these circumstances
http://www.io.com/~cdb/mirrors/lpsg/pnp−linux.html .
ISA PnP tools is another useful package.
And there is a project at RedHat http://www.redhat.com/pnp/overview.html .
The latest PCMCIA driver package (>>3.1.0) has utilities lspnp and setpnp to manipulate PNP settings.
Note that in 3.1.0 you may need this patch to compile them:
−#ifdef __GLIBC__
+#if 0 /* def __GLIBC__ */
6.9 Batteries
41
Linux Laptop−HOWTO
#include <byteswap.h>
#else
6.12 Docking Station / Port Replicator
Definitions
First some definitions. There is a difference between docking station and port replicator.
I use the term docking station for a box which contains slots to put some interface cards in, and space to put a
harddisk, etc. in. This box can be permanently connected to a PC. A port replicator is just a copy of the
laptop ports which may be connected permanently to a PC.
Other Solutions
I don't use a docking station. They seem really expensive and I can't see any usefulness. OK you have to mess
up with some more cables, but is it worth so much money? Docking stations are useful in an office
environment when you have a permanent network connection, or need the docking station's SCSI adaptor
(e.g., for a CD−R).
Also all docking stations I know are proprietary models, so if you change your laptop you have to change this
device, too. I just found one exception a docking station which connects to your laptop via IrDA the
IRDocking IR−660 by Tekram http://www.tekram.com/Hot_Products.asp?Product=IR−660 . It supports these
connectors: 10Base−T (RJ−45); PS/2 Keyboard; PS/2 Mouse; 25−Pin Printer Port (LPT); IR Transceiver;
Power (6 VDC). So it seems that a VGA port and a port to connect a desktop PC directly are missing. This
device should work with Linux/IrDA, though I couldn't check it out.
I would prefer to buy a PC instead and connect it via network to the laptop.
Or use an external display, which usually works well as described above, and an external keyboard and
mouse. If your laptop supports an extra PS/2 port you may use a cheap solution a Y cable, which connects the
PS/2 port to an external keyboard and an external monitor. Note: Your laptop probably has support for the Y
cable feature, e.g. the COMPAQ Armada 1592DT.
Connection Methods
AFAIK there are three solutions to connect a laptop to a docking station:
1. SCSI port
2. parallel port
3. (proprietary) docking port
From Martin J. Evans [email protected] "The main problem with docking stations is getting the
6.12 Docking Station / Port Replicator
42
Linux Laptop−HOWTO
operating system to detect you are docked. Fortunately, if you configure your kernel with the /proc file
system (does anyone not do this?) you can examine the devices available and thus detect a docked state. With
this in mind a few simple scripts is all you need to get your machine configured correctly in a docked state.
You may want to build support for the docking station hardware as modules instead of putting it directly into
the kernel. This will save space in your kernel but your choice probably largely depends on how often you are
docked.
1) Supporting additional disks on the docking station SCSI card
To my mind the best way of doing this is to:
1. Either build support for the SCSI card into the kernel or build it as a module.
2. Put the mount points into /etc/fstab but use the "noauto" flag to prevent them from being mounted
automatically with the mount −a flag. In this way, when you are docked you can explicitly mount
the partitions off any disk connected to the docking station SCSI card.
2) Supporting additional network adaptors in the docking station
You can use a similar method to that outlined above for the graphics card. Check the /proc filesystem in your
rc scripts to see if you are docked and then set up your network connections appropriately. "
Once you determine this information, you may use a script, similar to the following example, to configure the
connection to your docking station at startup. The script is provided by Friedhelm Kueck:
# check, if Laptop is in docking−station (4 PCMCIA slots available)
# or if it is standalone (2 slots available)
# Start after cardmgr has started
#
# Friedhelm Kueck mailto:[email protected]
# 08−Sep−1998
#
# Find No. of Sockets
SOCKETS=`tail −1 /var/run/stab | cut −d ":" −f 1`
case "$SOCKETS" in
"Socket 3")
echo Laptop is in Dockingstation ...
echo Disabeling internal LCD Display for X11
echo
cp /etc/XF86Config_extern /etc/XF86Config
#
# Setup of PCMCIA Network Interface after start of cardmge
#
echo
echo "Setting up eth0 for use at Network ..."
echo
/sbin/ifconfig eth0 10.1.9.5 netmask 255.255.0.0 broadcast 10.1.255.255
/sbin/route add −net 10.1.0.0 gw 10.1.9.5
/sbin/route add default gw 10.1.10.1
;;
6.12 Docking Station / Port Replicator
43
Linux Laptop−HOWTO
"Socket 1")
echo Laptop is standalone
echo Disabling external Monitor for X11
cp /etc/XF86Config_intern /etc/XF86Config
echo
echo Network device NOT setup
;;
esac
6.13 Network Connections
Related HOWTOs
1. PLIP−mini−HOWTO
2. NET−3−HOWTO
3. Ethernet−HOWTO
4. Term−Firewall−mini−HOWTO
Connection Methods
PCMCIA Network Card
If your laptop supports PCMCIA this is the easiest and fastest way to get network support. Make sure your
card is supported before buying one.
Serial Null Modem Cable
Probably the cheapest way to connect your laptop to another computer, but quite slow. You may use PPP or
SLIP to start the connection.
Parallel Port NIC (Pocket Adaptor)
Accton Pocket Ethernet and Linux This ethernet adaptor uses a parallel port and delivers approximately 110k
Bytes/s throughput for those notebooks that do not have PCMCIA slots.
Linux and Linksys Ethernet Adaptors A short note on the use of the Linksys parallel−port ethernet adaptor
under Linux. This is a widely available networking adaptor that doesn't require a PCMCIA slot.
6.13 Network Connections
44
Linux Laptop−HOWTO
Parallel "Null" Modem Cable
Offers more speed than a serial connection. Some laptops use chipsets that will not work with PLIP. Please
see PLIP−HOWTO for details.
Docking Station NIC
I don't have experience with a NIC in a docking station yet.
6.14 Modem
Modem Types
There are three kinds of modems available: internal, PCMCIA card or external serial port modems. But some
internal modems will NOT work with Linux such as the MWave modems (IBM) or if the laptop has a
WinModem. This is caused by non−standard hardware. So you have to use either a PCMCIA card modem or
an external modem.
Quotation from the Kernel−FAQ: "9.Why aren't WinModems supported? (REG, quoting Edward S.
Marshall) The problem is the lack of specifications for this hardware. Most companies producing so−called
WinModems refuse to provide specifications which would allow non−Microsoft operating systems to use
them. The basic issue is that they don't work like a traditional modem; they don't have a DSP, and make the
CPU do all the work. Hence, you can't talk to them like a traditional modem, and you −need− to run the
modem driver as a realtime task, or you'll have serious data loss issues under any kind of load. They're simply
a poor design."
"Win modems are lobotomized modems which expect Windows to do some of their thinking for them. If you
do not have Windows, you do not have a connection. "
Anyway, I have set up a page collecting information on laptops with internal modems at
http://www.snafu.de/~wehe/index_li.html . Maybe it's possible to run such modems with
MS−Windows9x/NT emulators like wine or VMware, but I don't know it.
Recently there is a driver for Lucent WinModems (alpha) available at SuSE − Labs and LTModem diagnostic
tool.
Caveats
WARNING: Pay attention to the different kinds of phone lines: analog and ISDN. You can't connect an
analog modem to an ISDN port and vice versa. Though there might be hybrid modems available. Connecting
to the wrong port may even destroy your modem. Trick: If you are looking for an analog phone port in an
office building which is usually wired with ISDN, take a look at the fax lines, they are often analog lines.
For tracking the packets on PPP you may use pppstats. Or pload this provides a graphical view of the
Parallel "Null" Modem Cable
45
Linux Laptop−HOWTO
traffic (in and out) of the PPP connection. It is based on athena widgets hence is very portable. It also uses
very little CPU time. The home of pload is http://www.engr.utk.edu/~mdsmith/pload/ .
6.15 SCSI
Hardware Compatibility Check
If unsure about the right SCSI support, compile a kernel with all available SCSI drivers as modules. Load
each module step by step until you get the right one.
Related HOWTOs
1. SCSI−HOWTO
Survey
AFAIK there is no laptop yet with a SCSI harddisk. Though there are two models with a built in SCSI port:
Texas Instruments TI 4000 and HP OmniBook 800. Maybe the PowerBook G3 has a SCSI disk, but I didn't
check this yet. The old Apple Powerbook Duo models had a SCSI hard disk.
For other models, if you need SCSI support you may get it by using a SCSI−PCMCIA card or via a SCSI
adapter in a docking station.
6.16 Universal Serial Bus − USB
Linux Compatibility Check
You should get information about the USB controller with cat /proc/pci and about USB devices with
cat /proc/bus/usb/devices.
Miscelleaneous
Newer laptops come with the Universal Serial Bus (USB). I haven't tried it on any of my systems because I
don't have any USB devices.
Visit http://peloncho.fis.ucm.es/~inaky/uusbd−www/ for the USB Linux home page. Also I have set up a
page collecting information about laptops and USB at LiLAC − Linux with Laptop Computers .
6.15 SCSI
46
Linux Laptop−HOWTO
6.17 Floppy Drive
Linux Compatibility Check
Usually there are no problems connecting a floppy drive to a Linux laptop. But with a laptop floppy drive you
may sometimes not be able to use every feature. I encountered the superformat command (from the
fdutils package) couldn't format more than 1.44MB with my HP OmniBook 800. You may also have
difficulty when the floppy drive and CD drive are mutually exclusive, or when the floppy drive is a PCMCIA
device (as with the Toshiba Libretto 100). With older laptops, there might be a minor problem if they use a
720K drive. AFAIK all distributions come with support for 1.44M (and sometimes 1.2M) floppies only.
Though it's possible to install Linux anyway. Please see Installation chapter. Please see kernel documentation
for boot time parameters concerning certain laptop floppy drives, for instance IBM ThinkPad. Or man
bootparam .
6.18 CD Drive
Most notebooks today come with CD drives. If floppy and CD drive are swappable they are usually mutually
exclusive. Sometimes they come as PCMCIA devices. Or as SCSI device (HP OmniBook 800). AFAIK there
are discmans available which have a port to connect them to a computer or even a SCSI port. I found an
article published by Ziff−Davis Publishing Company (September 1996 issue, but missed to note the URL)
written by Mitt Jones: "Portable PC Card CD−ROM drives transform laptops into mobile multimedia
machines", which listed: Altec Lansing AMC2000 Portable Multimedia CD−ROM Center; Axonix ProMedia
6XR; CMS PlatinumPortable; EXP CDS420 Multimedia Kit; H45 QuickPCMCIA CD; Liberty 115CD;
Panasonic KXL−D740; Sony PRD−250WN CD−ROM Discman.
6.19 DVD Drive
The Linux Video and DVD Project has made great headway since its start last February. They have just
released the source code ( http://livid.on.openprojects.net/css.tgz) so that a DVD decoder card can unlock and
read the DVD. Also provided on the site are links to various documents discussing DVD chipset
specifications. The Linux Video and DVD Project is avidly seeking help from the opensource community for
development.
Universal Disk Format (UDF) Driver: "UDF is a newer CDROM filesystem standard that's required for DVD
roms. It's meant to be a replacement for the ISO9660 filesystem used on today's CDROMs, but the immediate
impact for most will be DVD. DVD multimedia cdroms use the UDF filesystem to contain MPEG audio and
video streams. To access DVD cdroms you would need a DVD cdrom drive, the kernel driver for the cdrom
drive, some kind of MPEG video support, and a UDF filesystem driver (like this one). Some DVD cdroms
may contain both UDF filesystems and ISO9660 filesystems. In that case, you could get by without UDF
support."
6.17 Floppy Drive
47
Linux Laptop−HOWTO
6.20 Harddisk
Linux Compatibility Check
Useful programms are hdparm, dmesg, fsck and fdisk .
Miscellaneous
Be careful when using your laptop abroad. I have heard about some destroyed harddisks due to a magnetic
field emitted from the magnetic−holds at the backresttable of the seats in a german railway waggon.
Though I am quite satisfied with the quality of the harddisk in my laptop, when I removed it from the case I
unintendedly dropped it, I recommend to be very careful.
Form Factors
AFAIK there is only one form factor for harddisks used in laptops the 2.5" format. This format seems to be
available in different heights (Please note I couldn't verify this information yet):
• 18mm: laptops build before 1996 usually have drives 18mm high
• 12.7mm: I got a report about such disks but without a notebook model or manufacturer name
• 11mm: since 1996 the drives are 11mm high
• 9mm: many laptops, including the subnotebooks, now use a 9mm−high disk drive. The largest
available in this format in late 1999 is IBM 12GN.
• 9.5mm: Toshiba Libretto L70 and L100 have a 9.5mm HD
• 8.45mm: Toshiba Libretto 20, 30, 50 and 60 have 8.45mm tall HDs
• 6.35mm: Toshiba Libretto L1000 has a 6.35mm HD
It might be possible to use a hard disk wich doesn't fit with some case modifications.
Some laptops come with a removable hard disk in a tray, for instance the KAPOK 9600D. There seem to be
no SCSI drives for laptops available.
6.21 Video Port / ZV Port
Some high end laptops come with a video or ZV port (NTSC/PAL). Since I don't have a laptop with a ZV or
video port yet, I can provide only some URLs http://www.thp.uni−koeln.de/~rjkm/linux/bttv.html (driver)
http://www.mathematik.uni−kl.de/~wenk/xwintv.html (tvviewer). For further information see video4linux at
http://roadrunner.swansea.uk.linux.org/v4l.shtml. To collect information about laptops with video port I have
setup a page at http://www.snafu.de/~wehe/index_li.html . Alternatively to the ZV port you might use the
USB port.
6.20 Harddisk
48
Linux Laptop−HOWTO
7.Palmtops, Personal Digital Assistants − PDAs, Handheld
PCs − HPCs
Palmtops and PDAs are currently not much covered in this HOWTO. Anyway it may be useful therefore, too.
I just include some links, most of them are from Kenneth E. Harker's page :
1. Highly recommended is the page by Russell King ARM Linux about PDAs with ARM CPU and with
links to other Linux related PDA sites.
2. PalmOS−HOWTO (former Pilot−HOWTO) by David H. Silber.
3. Newton and Linux Mini−HOWTO .
4. Newtl: Newton/Linux Communications System Newtl allows a Linux machine to communicate with
a Newton PDA. Automatically send e−mail, print, and fax outboxes through your Linux machine,
and more.
5. PilotLink and XCoPilot PilotLink is an utility that performs data transfers from 3com PalmPilot
handheld computers to your Linux machine. XCoPilot is an emulator of the PalmPilot operating
system that runs under Linux.
6. PalmVNC is an implementation of the Virtual Network Client architecture that will allow you to use
a Linux or other UNIX machine to put up a (tiny) X Window on a 3COM PalmPilot.
7. PDAs and infrared remote control, see Hiromu Okada
8. AFAIK you can run Linux on the IBM PC110 (a tiny PC handheld that's no longer manufactured).
There's a HOWTO on it running around somewhere but I don't have an URL, instead I found a
description in LINUX REDUX July 1997 by Alan Cox.
9. For more information on Virtual Network Computing, see VNC .
10. There is also the Handheld Systems(TM) On−line Archives and a search engine about palmtop
related topics Palmtop.Net/ .
11. I have setup a small page about Linux with PDAs and Handheld PCs, too.
8.Cellular Phones, Pagers, Calculators, Digital Cameras,
Wearable Computing
Though in my opinion related to the topic, these devices are not much covered in this text, yet. For general
information about Embedded Systems, see http://www.embedded.com . For Linux information, see
ELKS and the uCLinux project. See news:comp.arch.embedded
8.1 Cellular Phones
For NOKIA cellular phones see GNOKII project . And Linux Nserver. This project aim is to produce a GPL
replacement for Nokia's Windows Nserver, and maybe improve upon it along the way. Initially it will
emulate the Windows 3.1 version (ie. allow backup, restore and install).
7.Palmtops, Personal Digital Assistants − PDAs, Handheld PCs − HPCs
49
Linux Laptop−HOWTO
openWAP is an open source project for the implementation of the Wireless Application Protocol (WAP) for
use with browsers, servers and tools. WAP is used by PDA devices, cell phones, pagers and other wireless
devices to transmit internet content to these devices. The project is still in its early stages and nothing can be
downloaded yet.
GSMLIB is a library to access GSM mobile phones through GSM modems. Features include: modification of
phonebooks stored in the mobile phone or on the SIM card, reading and writing of SMS messages stored in
the mobile phone, sending and reception of SMS messages. Additionally, some simple command line
programs are provided to use these features.
8.2 Pagers − SMS Messages
QuickPage is a client/server software package that enables you to send messages to an alphanumeric pager.
The client accepts a message from the user and forwards it to a server using SNPP. The server uses a modem
to transmit the message to the recipient's paging service using the TAP protocol (also known as the IXO
protocol).
mail2sms converts a (MIME) mail to a short message, allowing search/replace, conditional rules, date/time
dependent actions, customizing the output format, etc. The output defaults to 160 characters, which is
perfectly suitable for sending the text to a GSM telephone as an SMS message. This software does not
include any code for actually sending the text to anything else but another program or stdout.
email2sms is a filter written in Perl which converts an e−mail into a form suitable for sending as an SMS
message. Its main advantage over the alternatives is that it uses the CPAN module Lingua::EN::Squeeze to
compress the text down to as little as 40% of its original size, so you can get much more of your e−mail into
the 160 character limit imposed by SMS. It is fully MIME compatible, and has many configurable options,
including removal of quoted text. Ideal for use with procmail. A Perl script for sending the output to a typical
e−mail to SMS web gateway is included.
SMSLink implements a client/server gateway to the SMS protocol (short messages on the mobile phones). It
requires the use of dedicated hardware though (a serial GSM module). Both SMS emission and reception are
supported. The server only runs under Linux at the present time and also supports interactive mode via
telnet. The command−line client already exists for Linux, Solaris and HP−UX. A basic web interface is
provided. A Win32 client is in the works.
nmsms is a very simple program to announce incoming email to an SMS address (email address) defined at
compile time. The original From: and Subject: header are included in each mail announced.
mepl is a software for 3COM/USRobotics Messagemodems to control the self−employed−mode. This
program can be used for downloading the messages and saving or mailing them in gsm or fax−format.
8.3 Digital Cameras
For information about cellular phones and digital cameras see some links at my page about Linux with
Infrared Devices and my IR−HOWTO.
Newsgroup: rec.photo.digital .
8.2 Pagers − SMS Messages
50
Linux Laptop−HOWTO
The Flashpath adapter is a diskette like device which is used to transfer data from a digital camera to a
computer. See Flashpath for Linux and James Radley's flashpath homepage.
8.4 Calculators
Information about calculators e.g. HP−48 is at HP−Calculator.Org and Keith's HP−48 Page. HP−48 Kermit
Hints and Tips shows how to talk to the HP48 via its serial−line Kermit protocol. The HP−48 may also be
used as a Linux terminal.
See also at my page about Linux with Infrared Devices.
Backup utility for the CASIO diary. It is a package ported from DOS to allow communication to the CASIO
series of hand−held organizers. It allows backup from CASIO to your computer and restore a backup file
from your computer to the CASIO. It can also output human readable file from CASIO. Currently supports:
phone, calendar, schedule, memo, and reminder. See also http://www.aloha.net/ alank/
http://www.casioworld.com , http://home.t−online.de/home/Milan.Urosevic/ and
http://sunsite.unc.edu/pub/Linux/apps/
GtkTiLink is a program which allows you to transfer data between a Texas Instruments calculator and a
computer. It works with all cables (parallel, serial, Black and Gray TI Graph Link). It supports the TI82,
TI89, TI92 and TI92+ calculators. It can send/receive data and backups, make a capture of the calculator
screen and do remote control.
8.5 Wearable Computing
Also related to this topic but not covered yet seems wearable computing, see
http://lcs.www.media.mit.edu/projects/wearables/ , the page of Lionel, "trollhunter" Bouchpan−Lerust−Juery,
http://infonomade.linuxfr.org/indexen.html for further information and http://wearables.blu.org and
http://www.wearcomp.org/.
Sulawesi was developed due to the problems running a desktop GUI on a wearable computer. It has been
designed and implemented to tackle what has been considered to be important challenges in a wearable user
interface, the ability to accept input from any number of input devices, such as machine vision, speech
recognition, portable keyboards, GPS devices, infra−red, etc. and to allow services to manipulate the
information and generate a suitable output such as speech generation, graphics using a headmounted display,
vibrotactile stimuli, etc. The Gili user interface has been updated, more documentation has been added, and
the Spatial Reminder has been introduced.
8.6 Watches
The datalink library allows sending information to the Timex DataLink watches. The original datalink library
supports the model 150 and possibly the model 70 watch. This version has been extended to work with the
DataLink Ironman Triathlon watch. It has been tested with the SVGA output on the Ironman watch only,
other output devices and other watches may or may not work, I have no reports either way. The display must
8.4 Calculators
51
Linux Laptop−HOWTO
be a CRT display (not a LCD).
9.Accessories
9.1 PCMCIA Cards
Card Families
1. Ethernet adapter
2. Token Ring adapter
3. Ethernet + Modem / GSM
4. Fax−Modem / GSM adapter
5. SCSI adapter
6. I/O cards: RS232, LPT, RS422, RS485, GamePort, IrDA, Radio, Video
7. Memory cards
8. harddisks
9. 2.5" harddisk adapters
For desktops there are PCMCIA slots for ISA and PCI bus available.
Source: http://www.lapshop.de
Linux Compatibility Check
With the command cardctl ident you may get information about your card. Put this information into
/etc/pcmcia/config.opts if necessary. But this may not be enough to get the card to work, but works
sometimes for no−name network cards or modem cards. If you get a card to work or have written a new
driver please don't forget to announce this to the developer of the PCMCIA−CS package David Hinds . Look
the current issue of his file SUPPORTED.CARDS to get information about supported cards.
Since there are not all cards mentioned I have set up a page PCMCIA Cards "Unofficially" Supported by
Linux .
9.2 SmartCards
SmartCard reader, see Project Muscle − Movement for the Use of Smart Cards in a Linux Environment
9.Accessories
52
Linux Laptop−HOWTO
9.3 Memory Technology Devices − RAM and Flash Cards
The Linux Memory Technology Device project aims to provide a unified subsystem for handling RAM and
Flash cards (Memory Technology Devices). It is intended to be compatible with the Linux PCMCIA code, to
prevent duplication of code and effort, yet its main target is small embedded systems, so it will be possible to
compile the drivers into the kernel for use as a root filesystem, and a close eye will be kept on the memory
footprint.
9.4 Printers
Survey about small mobile printers:
1. CANON: BJC−80, for infrared connections to this printer see the links at my page about Linux and
Infrared Devices
2. CANON: BJ−30
3. HP: DeskJet 340Cbi. This is a small, portable, low−duty−cycle printer. It prints either black, or color
(3 color). I have had some problems with it loading paper. Overall, the small size and portability
make it a nice unit for use with laptops. I use the HP 500/500C driver with Linux.
4. Olivetti: JP−90
AFAIK only the HP and the BJC−80 machine have an infrared port. Pay attention to the supplied voltage of
the power supply if you plan to travel abroad. Source: http://www.lapshop.de
9.5 Power and Phone Plugs, Power Supply
When travelling abroad you might consider to take a set of different power and phone plugs with you. Also,
it's useful if you can change the input voltage of the power supply, for instance from 110V in the US to 220V
in Germany. There also power supplies for 12V batteries from cars.
Some models of power plugs:
____
/ () \
frontal view: |() ()|
−−−−−−
_
_
(_)=(_)
_
(_)
N.N.
abbrevation.:
C13
C8
??
PS/2
symbol......:
??
??
−O)−
N.N.
Caveats: Though some −O)− plug may seem to be compatible to your laptop, because of the according
physical size, take extremely care it uses the same plus−minus voltage scheme, for instance plus for the inner
ring and minus for the outer one. Often but not always there are the according symbols near the plug.
9.3 Memory Technology Devices − RAM and Flash Cards
53
Linux Laptop−HOWTO
9.6 Bags and Suitcases
You probably wonder, why I include this topic here. But shortly after using my COMPAQ Armada 1592DT I
recognized that the rear side of the machine (where the ports are arranged) was slightly damaged. Though I
have taken much care when transporting the laptop, this was caused by putting the bag on the floor. It seems
that the laptop has so much weight, that it bounces inside the bag on its own rear side. So I decided to put a
soft pad into the bag before loading the laptop. A good bag is highly recommended if you take your laptop on
trips, or take it home every night.
Laptops computers are frequently demolished in their carrying bag. The two main causes of demolition are
poking the LC display and banging the edges.A good case has very stiff sides to spread out pokes, and lots of
energy−absorbent padding around the edges to help when you whack it on the door jamb.Few cases actually
have either of these features.
More laptops are lost to theft than damage, so camouflage is a wise too. Emerson, Tom # El Monte
<[email protected]> wrote: "I use for a laptop travelling bag: a Pyrex casserole
carrier bag. Yup, you might think it odd to use a casserole bag for a laptop, but it turns out it has several
advantages:
• The one I use has a microwavable heating pad in it −− while I don't actually heat this pad (it's meant
to keep food warm while in transport), it does provide padding underneath the laptop. The carrier I
have only has a lower − heating − pad, but there is also a similar carrier that has both a lower −
heating − pad and an upper − cooling − pad − placed in the freezer to get it cold − −− the intent is
that you keep one or the other in the bag to keep your food hot or cold as desired. A secondary
advantage to the − cooling pad − pad is that if you've − chilled − it before taking the computer out for
the day, it will keep the CPU cooler while you're running the laptop...
• the top of the bag has a zipper on three sides, so it − opens − the same way as my laptop −− I don't
even need to take it out of the carrier to use the laptop
• there is enough room at the side of the bag to store the external power supply, a regular Logitech
mouseman, and the network − dongle − with BNC/TP ports − and if I had it, the modem/phone port
as well −
• there is enough clearance on top of the machine to include a handful of CD's or diskettes, if needed...
• when it's left − unattended − in a car, it's less likely to be stolen −− think about it, if you were a thief
walking through a parking lot and eyeing the contents of cars, a − laptop bag − is instantly
recognizable as holding a laptop computer −− something that can be fenced at a pretty hefty profit,
but if you saw a casserole carrier in the front seat of a car, would you think it contained anything
OTHER than a casserole? − and probably half−eaten, at that... − Unless you are a hungry thief,
chances are you'll skip this and move on...
• likewise, I've heard that keeping a laptop computer in a diaper bag is another good − camouflage −
technique −− who in their right mind is going to steal a bag of − dirty − diapers?"
9.6 Bags and Suitcases
54
Linux Laptop−HOWTO
10.Different Environments − On the Road
10.1 Related HOWTOs
1. Security−HOWTO
2. Multiboot−with−LILO−mini−HOWTO
3. Ethernet−HOWTO
4. NET−3−HOWTO
5. Offline−Mailing−mini−HOWTO
6. Plip−mini−HOWTO
7. Slip−PPP−Emulator−mini−HOWTO
10.2 Configuration Tools
NetEnv
Do you use your laptop in different network environments? At home? In the office? At a customers site?
If yes, the small package "netenv" might be useful for you. When booting your laptop it provides you with a
simple interface from which you can choose the current network environment. The first time in a new
environment, you can enter the basic data and save it for later reuse.
Netenv sets up a file containing variable assignments which describe the current environment. This can be
used by the PCMCIA setup scheme, e.g. like the one that comes with Debian/GNU Linux and perhaps others.
The netenv data can be used for things like:
1. Network Device: Configure the network device for different environments.
2. Choose a proper XF86Config: Think of using your laptop standalone with touchpad vs. connected to
a CRT monitor along with an external mouse. For example, a wheel mouse could be used when
docked, but the driver is not compatible with the normal trackpoint or touchpad.
3. Windowmanager: You can set up your windowmanager according to the current location of your
machine.
4. Printing Environment: The netenv data can easily be used to set up the printing environment.
Netenv is available as Debian/GNU Linux package as well as tarball. It depends on dialog(1) for the
menu system. It is developed by Gerd Bavendiek [email protected] you may get it at
http://www.uni−bielefeld.de/~portgym/net/netenv.html .
10.Different Environments − On the Road
55
Linux Laptop−HOWTO
divine
divine is an utility for people who use their machines in different networks all the time. "The idea is this:
• you describe the possible networks in /etc/divine.conf, including one or more machines that are
probably up (routers and NIS servers come to mind).
• at boot time, you run divine.
• divine starts a thread that injects fake arp requests into the network. The thread will try again up to
three times, pausing 1 second between retries. If the last try times out again, the thread will print an
error message, leave the interface in the original state and exit cleanly.
• the main thread just looks for arp replies and exits if one is found.
• You have one resolv.conf per network, for example /etc/resolv.conf.default and
/etc/resolv.conf.work, and divine will symlink one of them to /etc/resolv.conf for you.
• You can specify a proxy server plus port and divine will write the proxy server to /etc/proxy. This
can be evaluated inside your shell startup script, like this (zsh):
export http_proxy="http://`</etc/proxy`/"
The included perl script edit−netscape−proxy.pl will edit the proxy settings in your Netscape 4
preferences file.
• You can even specify an additional script to be run for each selection. You can use this to edit
/etc/printcap or /etc/issue or do something else I forgot.
The point about divine in contrast to other solutions is that other solutions normally use ping or
something like that. divine can check a large number of networks instantaneously, assuming that the
machines you ping answer within one second (.4 seconds are normal on Ethernets). And pinging an unknown
address will do an arp request anyway, so why not do an arp request in the first place?"
Mobile IP
From the NET3−4−HOWTO: "The term IP Mobility describes the ability of a host that is able to move its
network connection from one point on the Internet to another without changing its IP address or losing
connectivity. Usually when an IP host changes its point of connectivity it must also change its IP address. IP
Mobility overcomes this problem by allocating a fixed IP address to the mobile host and using IP
encapsulation (tunneling) with automatic routing to ensure that datagrams destined for it are routed to the
actual IP address it is currently using."
HUT Mobile IP is a dynamical, hierarchical Mobile IP system for Linux operating system. The
implementation enables a hierarchical model for IP mobility, thus decreasing the location update times as a
mobile host moves. Dynamics system has been designed Wireless LAN technology in mind, and the system
has optimized functionality for mobility in WLAN. There is now a mailing list available. You can join it by
sending subscribe on the subject line to <dynamics−user−[email protected]> − or you can simply check the
mail archive.
divine
56
Linux Laptop−HOWTO
Resources
1. Linux Mobile−IP
2. Linux Mobile IP from HP Labs Bristol by Manuel Rodríguez
3. MosquitoNet Mobile IP
4. Mobile IP at NUS
5. Linux Mobile−IP
6. Bay Area Research Wireless Access Network (BARWAN)
Sources: Kenneth E. Harker and Dag Brattli
DHCP/BootP
DHCP and BootP are also useful for working in different environments. Please see the DHCP−HOWTO and
BootP−HOWTO.
PPPD Options
The pppd command can be configured via several different files: pppd file
/etc/ppp/<your_options> .
/etc/init.d
You may even choose to do your configuration by editing the /etc/init.d files manually.
PCMCIA − Schemes
How can I have separate PCMCIA device setups for home and work? This is fairly easy using PCMCIA
scheme support. Use two configuration schemes, called home and work. For details please read the
according chapter in the PCMCIA−HOWTO by David Hinds.
Bootloaders
LILO
From http://www.mjedev.demon.co.uk/index.html <Martin J. Evans [email protected]> I have
taken this recommendation: The first point to note is that init will take any arguments of the form
name=value as environment variable assignments if they are not recognized as something else. This means
you can set environment variables from the LILO boot prompt before your rc scripts run. I set the
Resources
57
Linux Laptop−HOWTO
LOCATION environment variable depending on where I am when I boot Linux. e.g.
LILO: linux LOCATION=home
Or
LILO: linux LOCATION=work
Or simply
LILO: linux
where failing to set LOCATION means the same as LOCATION=home (i.e. my default). Instead of typing
LOCATION=place each time you boot you can add an entry to your /etc/lilo.conf file and use the append
instruction. e.g.
# Linux bootable partition
#
image = /vmlinuz
root = /dev/hda3
label = linux
read−only
# Linux bootable partition
#
# Linux bootable partition
#
image = /vmlinuz
root = /dev/hda3
label = work
read−only
append="LOCATION=work"
# Linux bootable partition
for booting Linux at home
config ends
for booting Linux at work
config ends
With the example above you can use "linux" for booting at home and "work" for booting at work.
Armed with the facility above, you can now edit the relevant rc scripts to test ENVIRONMENT before
running ifconfig, setting up route etc.
Other Bootloaders
There are several other bootloaders which are often overlooked. Besides LILO, have a look at loadlin,
CHooseOS (CHOS) (not GPL), GRand Unified Bootloader (GRUB), System Commander and take a look at
ftp://metalab.unc.edu/pub/Linux/system/boot/loaders/. The NT boot loader or OS/2 boot loader may even be
used.
Other Bootloaders
58
Linux Laptop−HOWTO
X−Windows
From Steve <[email protected]> I got a configuration for X windows with an external monitor: Note that I
have introduced a neat trick! For my nice 17" monitor I start X with no options and get the default 16−bit
1152x864 display − but when using the LCD screen I specify a 15−bit display (startx −− −bpp 15)
and get the correct 800x600 resolution automatically. This saves having to have two XConfig files.
E−Mail
A short introduction about how to setup email on a laptop used at home (dial−up) and work (ethernet) by
Peter Englmaier <[email protected]>:
Features
As a laptop user, I have special demands for my email setup. The setup described below, enables me to:
• Read my email from home using a POP email server, which is supplied by my university, but could
also be setup on a work place computer.
• Write email from home with the right return address in the email (which does not mention my
computer name).
• Read/write my email while working on a workstation without access to my laptop or the POP email
server (as a backup).
• Read my email while working on my laptop connected to the ethernet of our institut.
• Direct email while connected via ethernet (faster than the fetchmail method).
• Indirect email (over pop mail server) while not connected to the ethernet at work (either at home via
modem or somewhere else via ethernet).
• Use any emailer, e.g. elm or the simple mail command.
• Sort incomming email, delete spam, split email−collections (digests) into seperate emails
The configuration is based on sendmail, fetchmail, and a remote pop account for email.
Configuration of sendmail
This is the most complicated part. Having installed the sendmail−cf package, I created a file named
/usr/lib/sendmail−cf/laptop.mc:
divert(−1)
include(`../m4/cf.m4')
define(`confDEF_USER_ID',''8:12'')
define(`confBIND_OPTS',`−DNSRCH −DEFNAMES')
define(`confDOMAIN_NAME',''pa.uky.edu'')
<−−−− here you define your domain
OSTYPE(`linux')
undefine(`UUCP_RELAY')
undefine(`BITNET_RELAY')
define(`SMART_HOST',`server1.pa.uky.edu') <−−−− there we send outgoing email
X−Windows
59
Linux Laptop−HOWTO
define(`LUSER_RELAY',`server1.pa.uky.edu') <−−−− there we send mail to users my laptop does not k
MASQUERADE_AS(pa.uky.edu)
<−−−− again the domain, we want to be seen as
FEATURE(allmasquerade)
FEATURE(nouucp)
FEATURE(nodns)
FEATURE(nocanonify)
FEATURE(redirect)
FEATURE(always_add_domain)
FEATURE(use_cw_file)
FEATURE(local_procmail)
MAILER(procmail)
MAILER(smtp)
HACK(check_mail3,`hash −[email protected] /etc/mail/deny')
HACK(use_ip,`/etc/mail/ip_allow')
HACK(use_names,`/etc/mail/name_allow')
HACK(use_relayto,`/etc/mail/relay_allow')
HACK(check_rcpt4)
HACK(check_relay3)
This looks more complicated as it is. All it does is, that it redirectes outbound mail to server1
(SMART_HOST) and also mail for local users which are not known (LUSER_RELAY). That way, I can
write email to my colleques without using their full email address. More important: the From line in my
email points back to my MASQUARADE_AS domain and not directly to my laptop. If this where not the
case, email returned with the reply button might not reach me. You must restart sendmail for changes to
take effect. Note: this configuration is for Redhat 5.2 systems. You may have to change some details.
Now, all what is needed is to generate the /etc/sendmail.cf file m4 laptop.mc
>/etc/sendmail.cf and to add all possible domain names my laptop should respond to in
/etc/sendmail.cw:
# sendmail.cw − include all aliases for your machine here.
laptop
laptop.pa.uky.edu
128.17.18.30
guest1
guest1.somewhere.org
It is important to have all aliases in this file, otherwise sendmail will not accept the mail (and will reply we
don't relay to the sender). Finally, you must now test the setup by sending email, replying to mail for all
possible configurations. Any missconfiguration can result in loss of email.
Configuration for fetchmail on Laptop
One method to get the email into your machine is through fetchmail. Fetchmail periodically checks for
new email at one or more remote mail servers. I use the following fetchmail configuration file (in my user
home directory): fetchmailrc
set postmaster "myusername"
set daemon 900
poll pop.uky.edu with proto POP3
user "mypopusername" there with password "mypoppassword" is mylaptopusername here
Configuration for fetchmail on Laptop
60
Linux Laptop−HOWTO
Fetchmail will just get the the email and send it to sendmail which will it deliver into your
/var/spool/mail/$USER file.
Forward E−Mail to the Laptop
On my work station I have the following .forward file:
[email protected],[email protected]
Here server1 is the machine where I keep my mailbox. All email is send to the pop account to be picked up
later by my laptop (using fetchmail). However, when my laptop is connected via ethernet, I want my
email to go directly to the laptop, instead of pop:
[email protected],[email protected]
In both cases, a backup of my email is send to server1 (where I also can read it, in case I cannot get my
laptop). I keep/store all email on the laptop.
Switching is done by three script files and a crontab file (on the workstation):
forward_pop
#!/bin/sh
echo "[email protected],[email protected]" > ${HOME}/.forward
forward_laptop
#!/bin/sh
echo "[email protected],[email protected]" > ${HOME}/.forward
crontab ${HOME}/mycrontab
${HOME}/utl/check_laptop
check_laptop
#!/bin/sh
if /usr/sbin/ping −c 1 laptop >/dev/null 2>&1 ; then
:
else
# redirect mail to pop
${HOME}/utl/forward_pop
sleep 10
if /usr/sbin/ping −c 1 laptop >/dev/null 2>&1 ; then
# back to normal
${HOME}/utl/forward_laptop
else
# deactivate crontab check
/bin/crontab −l | grep −v check_laptop >${HOME}/tmp/mycrontab.tmp
Forward E−Mail to the Laptop
61
Linux Laptop−HOWTO
/bin/crontab ${HOME}/tmp/mycrontab.tmp
rm −f ${HOME}/tmp/mycrontab.tmp
fi
fi
mycrontab
# mycrontab
0,10,20,30,40,50 * * * * ${HOME}/utl/check_laptop
Each time I connect the laptop to the ethernet, I have to run forward_laptop, and each time I disconnect
I run forward_pop. In case I forget to run forward_pop, the crontab job runs it for me less then 10 minutes
later. To do all that automatically, I change the network script files on my laptop as follows:
/sbin/ifdown (this script runs, whenever a network device is stopped, new stuff between BEGIN and END)
...
fi
# BEGIN new stuff
# turn off forwarding email
mail ppe <<EOF
turning off forwarding email
device = ${DEVICE}
hostname = `hostname`
EOF
if [ "${DEVICE}" = "eth0" −a "`hostname`"
= "laptop" ]; then
su −lc "ssh −l myusername server1
utl/forward_pop" myusername >& /dev/null
fi
# END new stuff
ifconfig ${DEVICE} down
exec /etc/sysconfig/network−scripts/ifdown−post $CONFIG
Note, that the script checks for the value of hostname. In case, I am connected to a foreign ethernet, my
hostname and ip−address will be something else, e.g. guest1.
/etc/sysconfig/network−scripts/ifup−post (this script is run, whenever a network device is started)
# Notify programs that have requested notification
do_netreport
# BEGIN new stuff
# check for email −− I'm using fetchmail for this
if [ "${DEVICE}" = "eth0" −o "${DEVICE}"
= "ppp0" ]; then
su −lc fetchmail myusername >& /dev/null &
fi
# set clock if connected to ethernet, redirect email
if [ "${DEVICE}" = "eth0" −a dquot;`hostname`" = "zaphod" ]; then
( rdate −s server1 ; hwclock −−systohc −−utc ) >& /dev/null &
Forward E−Mail to the Laptop
62
Linux Laptop−HOWTO
# forward email
su −lc "ssh −l myusername gradj utl/forward_laptop" myusername >& /dev/null &
fi
# END new stuff
exit 0
Processing Incomming E−Mail with procmail
This step is completely optional. The above described sendmail configuration calls procmail for each
received email, but you could have called procmail using the .forward file (see the procmail man
page). Procmail is a handy tool to block spam and to sort incomming email.
You need to setup a .procmailrc file to use procmail. See the man page for procmail, procmailrc, and
procmailex (examples). My setup demonstrates, how to ignore certain email messages and split
email−collections (digest) into pieces:
# −− mail filtering −− procmail is called by sendmail −−
PATH=/bin:/usr/bin
MAILDIR=$HOME/Mail
LOGFILE=$MAILDIR/from
# keep in mind:
# use ":0:" when writing to a file
# use ":0" when writing to a device, e.g. /dev/null, or send email
# − make first a backup of *all* incomming email (but ignore mail tagged below) −
:0 c:
*! ^Sissa−Repro
backup
# − keep only last 50 messages
:0 ic
| cd backup && rm −f dummy `ls −t msg.* | sed −e 1,50d`
# − delete email comming through the 'postdocs' email list, when
# it is not of any interest
:0
* ^From.*postdocs
* ^From.*Ernst Richter
/dev/null
:0
* ^From.*postdocs
* ^Subject.*card charge
/dev/null
# Split mailing list from the sissa preprint server into individual emails
# − this is quite complicated :(
I can flip through the list much
#
faster and ignore preprints which have uninteresting titles. Instead of
#
having to browse through the whole list, my mailer will just present a
#
list of papers.
# 1. split it in individual messages
:0
* ^From no−[email protected]
| formail +1 −de −A "Sissa−Repro: true" −s procmail
# 2. reformat messages a bit
Processing Incomming E−Mail with procmail
63
Linux Laptop−HOWTO
# 2.1. extract 'Title:' from email−Body and add to email−header
as 'Subject:'
:0 b
* ^Sissa−Repro
*! ^Subject
TITLE=| formail −xTitle:
:0 a
|formail −A "Subject: $TITLE " −s procmail
# 2.2. store in my incomming sissa−email folder. Here, we could
#
also reject (and thereafter delete) uninteresting 'Subjects'
#
we could also mark more interesting subjects as urgend or send a copy
#
to regular mail box.
:0:
* ^Sissa−Repro
* ^Subject
*! ^replaced with
sissa
BTW, there is a tk GUI tool to configure procmail (I think it is called dotfiles).
Email with UUCP
Another possible solution for Email is to use UUCP. This software was made for disconnected machines, and
is by far the easiest solution if you have several users on your laptop (we are talking about Unix, remember?),
each with his/her own account.
Unlike what most people think, UUCP does not need a serial connection: it works fine over TCP/IP, so your
UUCP partner can be any machine on the Internet, if it is reachable from your network attachment point.
Here is the UUCP sys for a typical laptop:
system mylaptop
time any
chat "" \d\d\r\c ogin: \d\L word: \P
address uucp.mypartner.org
port TCP
More Info
Using a Laptop in Different Environments by Gerd Bavendiek . This article appeared in the August, 1997
issue of the Linux Gazette. This is an excellent, short technical article describing an easy way to setup your
Linux notebook to boot into different network and printing configurations, especially useful for those who
use their machines at home as well as other locations such as in the office, at school, or at a customer site.
Email with UUCP
64
Linux Laptop−HOWTO
10.3 Data Transport Between Different Machines
I don't have experience with this topic yet. So just a survey about some means of data transport and
maintaining data consistency between different machines.
Hardware
1. external harddisks
2. ZIP drive
Wade Hampton wrote: "You may use MS−DOS formatted ZIP and floppy discs for data transfer. You may be
able to also use LS120. If you have SCSI, you could use JAZ, MO or possibly DVD−RAM (any SCSI disc
that you could write to). I have the internal ZIP for my Toshiba 700CT. It works great (I use automount to
mount it). I use VFAT on the ZIP disks so I can move them to Windows boxes, Linux boxes, NT, give them
to coworkers, etc. One problem, I must SHUTDOWN to swap the internal CD with the ZIP."
Software
Version Management Software
Although it is certainly not their main aim, version management software like CVS (Concurrent Version
System) are a perfect tool when you work on several machines and you have trouble keeping them in sync
(something which is often called "disconnected filesystems" in the computer science literature). Unlike
programs like rsync, which are assymetric (one side is the master and its files override those of the slave),
CVS accept that you make changes on several machines, and try afterwards to merge them. Assymetric tools
are good only when you can respect a strict discipline, when you switch from one machine to another. On the
contrary, tools like CVS are more forgetful.
To synchronize two or more machines (typically a desktop and a laptop), just choose a CVS repository
somewhere on the network. It can be on one of the machines you want to synchronize or on a third host.
Anyway, this machine should be easily reachable via the network and have good disks.
Then, cvs co the module you want to work on, edit it, and cvs commit when you reached a synch point
and are connected. If you made changes on both hosts, CVS will try to merge them (it typically succeeds
automatically) or give in and ask you to resolve it by hand.
The typical limits of this solution: CVS does not deal well with binary files, so this solution is more for users
of vi or emacs than for GIMP fans. CVS has trouble with some Unix goodies like symbolic links.
For more information on CVS, see the Web page. The CVS documentation is excellent (in info format).
10.3 Data Transport Between Different Machines
65
Linux Laptop−HOWTO
CODA Filesystem
The Coda File System is a descendant of the Andrew File System. Like AFS, Coda offers
location−transparent access to a shared Unix file name−space that is mapped on to a collection of dedicated
file servers. But Coda represents a substantial improvement over AFS because it offers considerably higher
availability in the face of server and network failures. The improvement in availability is achieved using the
complementary techniques of server replication and disconnected operation. Disconnected operation proven
especially valuable in supporting portable computers http://www.coda.cs.cmu.edu/ .
WWWsync
This is a program written in Perl that will update your web pages by ftp from your local pages. This was
originally written for updating Demon home−pages, but will work with other providers which provide direct
FTP access to your web pages. I didn't check this for laptop purposes yet. You may get the program at
http://www.alfie.demon.co.uk/wwwsync/ .
rsync
rsync is a program that allows files to be copied to and from remote machines in much the same way as
rcp. It has many more options than rcp, and uses the rsync remote−update protocol to greatly speedup file
transfers when the destination file already exists. The rsync remote−update protocol allows rsync to
transfer just the differences between two sets of files across the network link.
Xfiles − file tree synchronization and cross−validation
Xfiles is an interactive utility for comparing and merging one file tree with another over a network. It
supports freeform work on several machines (no need to keep track of what files are changed on which
machine). Xfiles can also be used as a cross−validating disk <−gt; disk backup strategy (portions of a disk
may go bad at any time, with no simple indication of which files were affected. Cross−validate against a
second disk before backup to make sure you aren't backing up bad data).
A client/server program (GUI on the client) traverses a file tree and reports any files that are missing on the
server machine, missing on the client machine, or different. For each such file, the file size/sizes and
modification date(s) are shown, and a comparison (using Unix diff) can be obtained. For files that are missing
from one tree, similarly named files in that tree are reported. Inconsistent files can then be copied in either
direction or deleted on either machine. The file trees do not need to be accessible via nfs. Files checksums are
computed in parallel, so largely similar trees can be compared over a slow network link. The client and server
processes can also be run on the same machine. File selection and interaction with a revision control system
such as RCS can be handled by scripting using jpython. Requirements Java1.1 or later and JFC/Swing1.1 are
needed. Xfiles.
CODA Filesystem
66
Linux Laptop−HOWTO
sitecopy
Sitecopy is for copying locally stored websites to remote web servers. The program will upload files to the
server which have changed locally, and delete files from the server which have been removed locally, to keep
the remote site synchronized with the local site, with a single command. The aim is to remove the hassle of
uploading and deleting individual files using an FTP client. sitecopy .
KBriefcase
The KDE tool Kbriefcase tries to achieve a similar goal as the Windows briefcase, but in a different way.
Rather than pulling your files from the desktop, they are pushed to the laptop. You drag a file from the local
location to the briefcase. You are then asked for the remote path to copy it to. It will then copy the file to the
remote location and make the original read−only. When you restore and remove, the file is copied back and
write permissions are given back. The read−only status, of course, makes sure you don't start editing the file
again before you've brought your changes back from the remote location.
10.4 Security in Different Environments
Introduction
I am not a computer security expert. Please read the Security−HOWTO for more information. I just collected
some information below. Note, these means are just small steps to additional security, though I recommend
that you use them.
LASG Please read Linux Administrator's Security Guide (LASG) − FAQ by Kurt Seifried.
Means of Security
1. International Kernel Patch: The idea of the International Kernel Patch is to collect all crypto patches
so that using crypto in the kernel will be easier than today. The patch includes a number of crypto
patches including a crypto API including Blowfish, CAST−128, DES, DFC, IDEA, MARS, RC6,
Rijndael, Safer, Serpent, and Twofish, an encrypted filesystem loopback device using the crypto API,
CIPE VPN and EnSKIP patches.
2. Kennsington Lock: AFAIK proprietary lock solution with different laptops
http://www.kennsington.com
3. SmartCards: by DESKO http://www.desko.de are not available for Linux yet. The only available
laptop with a SmartCard builtin is the Siemens Scenic Mobile 800.
4. User passwords: can be easily bypassed if the intruder gets physical access to your machine
5. BIOS passwords: are also easily crackable, though sometimes harder than with desktops
6. Name plates: to reduce the possibility of theft, you may want to have a nameplate made and affixed
to the cover of the laptop. A nice one will cost you about $12, and can be made by any good trophy
sitecopy
67
Linux Laptop−HOWTO
shop. They'll glue it on for you too. You could use double−sided tape instead, but glue is more
permanent. You may even make an engravement into the laptop cover.
7. Boot loader: a boot loader may be used to put your name and phone number (or whatever text you
choose) into the boot sequence before the operating system is loaded. This provides a label that can't
be removed by editing files or even doing a simple format of the harddisk.
8. Antivirus policy: I have seen an antivir RPM somewhere. Check the BIOS for an option to
disable writing at the boot sector.
9. Database of stolen laptops: I have provided a survey of databases for stolen laptops.
10. Laptop as a security risk itself: Since a laptop can easily be used to intrude a network, it seems a good
policy to ask the system administrator for permission before connecting a laptop to a network.
11. Secure Protocol: When connecting to a remote server always use a secure protocol.
10.5 Dealing with Down Times (Cron Jobs)
A cron−like program that doesn't go by time: anacron (like "anac(h)ronistic") is a periodic command
scheduler. It executes commands at intervals specified in days. Unlike cron, it does not assume that the
system is running continuously. It can therefore be used to control the execution of daily, weekly and
monthly jobs (or anything with a period of n days), on systems that don't run 24 hours a day. When installed
and configured properly, anacron will make sure that the commands are run at the specified intervals as
closely as machine−uptime permits.
hc−cron This program is a modified version of Paul Vixie's <[email protected]> widely used
cron daemon. Like the original program it runs specified jobs at periodic intervals. However, the original
crond relies on the computer running continuously, otherwise jobs will be missed. This problem is
addressed by hc−cron, that is indended for use on home−computers that are typically turned off several
times a day; hc−cron will remember the time when it was shut down and catch up jobs that have occurred
during down time when it is started again. Felix Braun <[email protected]> is the author of the programm, it
is available at http://metalab.unc.edu /pub/Linux/system/daemons/cron .
10.6 Noise Reduction
Due to the proliferation of cellular phones and walkmans it's not quite common in our days to take care of a
quiet environment. Anyway I want to give some recommendations for the polite ones.
Console (Shell) and X
For the console setterm −blength 0 and for X xset b off turns the bell off. See also
PCMCIA−HOWTO, and much more details in the Visible−Bell−mini−Howto by Alessandro Rubini.
PCMCIA
When starting your laptop with PCMCIA−CS configured correctly, this will be shown by two high beeps. If
you want to avoid this put CARDMGR_OPTS="−q" into the PCMCIA configuration file, e.g.
10.5 Dealing with Down Times (Cron Jobs)
68
Linux Laptop−HOWTO
/etc/pcmcia.conf for Debian/GNU Linux.
To avoid the dialtones during the modem dialing add
module "serial_cs" opts "do_sound=0"
to /etc/pcmcia/config.opts (from man serial_cs). This will disable speaker output completely, but the
ATM command should let you selectively control when the speaker is active.
Miscellaneous Applications
You may configure vi with the flash option, so it will use a flash in case of an error, instead of a bell.
For at least one laptop series, the Toshiba models, there seems to be a Linux package available to control the
fan and other features.
11.Other Resources
Kenneth E. Harker maintains a quite valuable database at
http://www.cs.utexas.edu/users/kharker/linux−laptop/ . Please have a look at his site to get current
information about laptop related mailing lists, newsgroups, magazines and newsletters, WWW sites and a big
database about many different laptop pages.
To join the Linux−Laptop−Mailing−List write a mail to <[email protected]> with subscribe
linux−laptop in the subject. You will get a confirmation message than, which you have to reply
accordingly.
There is now a debian−laptop mailing list. Any questions or discussions concerning running the
Debian/GNU Linux operating system(s) on laptops are welcome. Send mail to
<debian−laptop−[email protected]> with a subject of subscribe. Or visit the
http://www.debian.org site and use the online form.
Also recently founded was Running Linux on IBM ThinkPads, to join send an email to
linux−thinkpad−[email protected], to post send mail to
linux−[email protected] . See http://www.topica.com/lists/linux−thinkpad/.
Lionel, "trollhunter" Bouchpan−Lerust−Juery, <[email protected]> has written a similar HOWTO,
please look at his laptop pages http://infonomade.linuxfr.org/index.html (French version)
http://infonomade.linuxfr.org/indexen.html (English version).
Newsgroups are comp.os.linux.portable, comp.sys.laptops .
Miscellaneous Applications
69
Linux Laptop−HOWTO
12.Repairing the Hardware
There are several different reasons that could make it necessary to open the case of a laptop.
1. repairing broken hardware
2. get some hardware info, which isn't available otherwise
3. remove the speakers (speakerrektomie, as described in Visual−Bell−mini−HOWTO)
4. install overdrive for CPU
5. change BIOS battery
6. upgrade harddisk
7. upgrade memory
Repairing a laptop can be quite expensive if you don't have a manufacturer's warranty. Sometimes
professional support is bad. But opening a laptop case can be difficult. Often the procedures to upgrade the
memory and the harddisk are described in the manual. For further details, you should try to get the
maintainance/technical manual. Just be extremely careful and make notes as to where each screw goes. You
must get most of them back in the right hole or you could ruin the machine by damaging the system board.
Also after you get all the screws to an assembly out (some will be hidden) the parts are usually held together
with plastic clips molded in, so you still must exercise care to separate them. Sometimes you need certain
tools, for instance TORX screw drivers or a solder kit. Good luck.
WARNING: Usually laptop manufacturers declare the warranty to be void if the case was opened by people
other than their own staff.
13.Solutions with Laptops
13.1 Introduction
The power and capabilities of laptops are sometimes limited as described above. But in turn, they have a
feature which desktops don't have, their mobility. I try to give a survey about applications which make sense
in connection with laptops. Since I couldn't try all of them, there is currently little documentation. If you can
provide further material, please contact me.
13.2 Mobile Network Analyzer
I'm not an expert in this field, so I just mention the tools I know. Please check also for other applications.
Besides the usual tools tcpdump, netcat, there are two applications I prefer, which may be used to
analyze network traffic:
The Multi Router Traffic Grapher (MRTG) is a tool to monitor the traffic load on network−links. MRTG
generates HTML pages containing GIF images which provide a LIVE visual representation of this traffic.
Check http://www.ee.ethz.ch/stats/mrtg/ for an example. MRTG is based on Perl and C and works under
12.Repairing the Hardware
70
Linux Laptop−HOWTO
UNIX and Windows NT.
Network Top − ntophttp://www−serra.unipi.it/~ntop/ is a Unix tool that shows the network usage, similar to
what the popular top Unix command does. ntop is based on libpcap and it has been written in a portable
way in order to virtually run on every Unix platform and on Win32 as well. ntop can be used in both
interactive or web mode. In the first case, ntop displays the network status on the user's terminal. In web
mode a web browser (e.g. netscape) can attach to ntop (that acts as a web server) and get a dump of the
network status. In the latter case, ntop can be seen as a simple RMON−like agent with an embedded web
interface.
13.3 Mobile Router
Though designed to work from a single floppy, the Linux Router Project (LRP) , seems useful in combination
with a laptop, too.
13.4 Hacking and Cracking Networks
When thinking about the powers of laptops, hacking and cracking networks may come into mind. Though I
don't want to handle this topic here, but instead recommend the Security−HOWTO.
13.5 Lectures
If you are giving lectures, readings or presentations in different places, a laptop might suit your needs. You
can combine it with an overhead display, a beamer or a second monitor. For a second monitor or a beamer
make sure it is supported by your laptop.
Though Microsoft's PowerPoint is often used for such things, there are also Linux solutions:
• pdftex creates PDF files from Tex files, which can be used toghether with certain LaTeX pakcages
for presentations, see the example screen designed users manual.
• The Web and Exerquiz Packages also a sophisticated method to create presentations with LaTex.
• PPower
• Dia is a program for creating diagrams of all kinds. The current version can do UML class diagrams,
Entity−Relationship modeling, network diagrams, and much more. The engine is very flexible and
dynamically loads diagram−types from disk. It can currently export to postscript and load/save in an
xml format.
• See also the software maps at KDE (K−Office) http://www.kde.org for the program
KPresenter and others. And GNOME http://www.gnome.org/ .
• MagicPoint or mgp, is an X11−based presentation tool. The home page is
http://www.Mew.org/mgp or ftp://ftp.Mew.org/pub/MagicPoint/ or http://jiji.mew.org/mgp/ .
• Commercial packages are:
Applixwarehttp://www.applix.com/appware/linux/slideshow/gfx011.html and Staroffice, see article
15 in LinuxFocus http://vesta.astro.amu.edu.pl/Library/Linux/LinFocus/May1998/.
13.3 Mobile Router
71
Linux Laptop−HOWTO
13.6 Mobile Data Collecting
Related HOWTOs
1. Coffee−mini−HOWTO
2. AX−25−HOWTO
3. HAM−HOWTO
4. Serial−HOWTO
5. Serial−Programming−HOWTO
Applications
A Linux laptop can be used to collect data outside an office, e.g. geodesy data, sales data, network checks,
patient data in a hospital and others. There is support for wireless data connections via cellular phone
modems and amateur radio. I am not sure whether PCMCIA radio cards are supported, see Aironet Wireless
Communications http://www.aironet.com/.
Specific Environments
There are laptops available with cases build for a rugged environment (even waterproof laptops). In some
environments, for instance in hospitals, take care of the Electro−Magnetic−Compatibility of the laptop. This
is influenced by many factors, for instance by the material used to build the case. Usually magnesium cases
shield better than the ones made of plastics.
13.7 Mobile Office
With KDE http://www.kde.org (K−Office), GNOME, http://www.gnome.org/ and the commercial products
WordPerfect, Staroffice and Applixware http://www.applix.com/ Linux has more and more business software
applications. With the corresponding hardware, e.g. a portable printer and a cellular phone which connects to
your laptop, you will have a very nice mobile office.
13.8 Connection to Digital Camera
AFAIK there are currently three methods to connect a digital camera to a laptop: the infrared port (IrDA),
serial port and maybe USB. There are also some auxiliary programs for conversion of pictures, etc.
Eric <[email protected]> wrote: "I finally succeeded in downloading pictures from my digital camera, but
not exactly the way I expected, i.e. not through USB port but using pcmcia card port and memory stick
device, part of digital camera hardware. Anyway, some interesting things to mention:
13.6 Mobile Data Collecting
72
Linux Laptop−HOWTO
Sony (pretending using a standard) uses the msdos format to store images as JPEG files ; so the best way to
have your OS recognizing them is to mount the raw device like a msdos filesystem; using mount directly
doesn't work (don't know why) but an entry in the /etc/fstab file allows you to mount the device correctly. i.e.:
/dev/hde1
/mnt/camera
msdos
user,noauto,ro
0
0
Of course, newfs before mount works too, but there is nothing to see at all ;−) I think both noauto and
ro are important flags; I tried without it and it didn't work. Somehow the mount I got seems buggy . And if
ro is missing, the camera doesn't recognize back the memory stick and it needs to be msdos−formatted.
According to the camera documentation , both pcmcia and USB port behave the same (for Mac and Windoze
− i.e. you see a file system auto mounted) − I deduce for Linux it should be the same thing too, as long as the
USB driver is installed. I think now that mounting USB raw device the way I did with pcmcia should work,
but I still couldn't find which device to use."
OpenDiS (Open Digita Support) is a library and utility program for cameras such as the Kodak DC−220,
DC−260, DC−265, and DC−280, that run Flashpoint's Digita operating system. The library is a unix
implementation of the Digita Host Interface Specification, intended for embedding Digita support in other
products such as gPhoto. The utility is a simple command−line program for standalone downloading of
photos from the cameras.
gPhoto enables you to take a photo from any digital camera, load it onto your PC running a free operating
system like GNU/Linux, print it, email it, put it on your web site, save it on your storage media in popular
graphics formats or just view it on your monitor. gPhoto sports a new HTML engine that allows the
creation of gallery themes (HTML templates with special tags) making publishing images to the world wide
web a snap. A directory browse mode is implemented making it easy to create an HTML gallery from images
already on your computer. Support for the Canon PowerShot A50, Kodak DC−240/280 USB, and Mustek
MDC−800 digital cameras.
photopc is is a library and a command−line frontend to manipulate digital still cameras based on Fujitsu
chipset and Siarra Imaging firmware. The program is known to work with Agfa, Epson and Olympus
cameras. Should also work with Sanyo, but this is untested. The cameras typically come with software for
Windows and for Mac, and no description of the protocol. With this tool, they are manageable from a UNIX
box. Bruce D. Lightner <[email protected]> has added support for Win32 and DOS platforms. Note
that the program does not have any GUI, it is plain command−line even on Windows. For a GUI, check out
the phototk program.
13.9 Connection to QuickCam (Video)
AFAIK there are currently two methods to connect a video camera to a laptop: a ZV port and maybe USB,
but I don't know how this works with Linux. I have heard rumors about using a sound card for video data
transfer to a Linux box, see http://worldvisions.ca/~apenwarr/ . I have heard rumors about a
Linux−QuickCam−mini−HOWTO, but couldn't find a reliable URL yet. Check the sane package which is
build for scanner support, this should contain support for still−grabbers as well.
kmc_remote provides a graphical interface for controlling Kodak Motion Corder fast digital cameras over a
serial connection. kmc_remote is built on the kmc_serial library, part of the kmc_utils package. kmc_remote
provides a virtual button panel and simple one−touch commands for changing system variables which would
13.9 Connection to QuickCam (Video)
73
Linux Laptop−HOWTO
involve multiple button operations on the real camera button console. Buttons, record settings (image size,
record rate, shutter speed, trigger mode, burst mode), and playback rate control should be fully functional. All
camera models are supported, as well as both PAL and NTSC video.
Intel PC Camera Pro Pack is one of the first webcams with USB ports. Also SONY has announced a webcam
with USB port. See a survey at Steve's Digicams.
13.10 Connection to Television Set
If you have a ZV port in the laptop, it should be easy to connect it to a TV set, using either NSCA or PAL,
but I don't know whether either works with Linux.
13.11 Connection to Cellular Phone
AFAIK there are two methods to connect a cellular phone to a laptop: via the infrared port (IrDA) or via the
serial port. See the Linux/IrDA project for the current status of IrDA connections. AFAIK only the Ericsson
SH888, the Nokia 8110 and the Siemens S25 provide infrared support.
13.12 Connection to Global Positioning System (GPS)
From the Hardware−HOWTO I know there is Trimble Mobile GPS available. You may also connect a GPS
via a serial port. Most GPS receivers have a data port and can connect to a PC with a special serial cable.
• dgpsip provides correct GPS location with DGPS signal from internet.
• gpsd is a daemon that listens to a GPS or Loran receiver and translates the positional data to
simplified format that can be more easily used by other programs, like chart plotters. The package
comes with a sample client that plots the location of the currently visible GPS satellites (if available)
and a speedometer. Added support for the DeLame EarthMate as well as a new 'speedometer' mini
client.
• The QtGPS package contains a piece of software for Unix/Linux/X and a GPS receiver. It performs
logging and replaying of a journey, supporting a moving−map display. QtGPS works with Lat/Long
and British OSGB (Ornance Survey) co−ordinate systems.
• GRASS (Geographic Resources Analysis Support System) is a free software raster and vector based
GIS, image processing system, graphics production system, and spatial modeling system.
13.13 Connection via Amateur Radio (HAM)
AFAIK laptops are used in HAM contests. Please see HAM−HOWTO by Terry Dawson, VK2KTJ,
<[email protected]> .
13.10 Connection to Television Set
74
Linux Laptop−HOWTO
13.14 Satellite Watching
Together with an antenna and software like seesat or sattrack you can use a laptop to locate a satellite
for visual observation. You could also use xephem on a laptop when stargazing.
13.15 Aviation
Many people are using laptops for aviation related topics. The Aviation HOWTO is an FAQ, HOWTO
like document that provides pointers to software packages that run under the Linux operating system and are
useful to private, commercial, or military pilots. The ultimate goal is to enable pilots to use the Linux
operating system for all their aviation related computing needs.
13.16 Blind or Visually Impaired Users
There are some groups of which could gain a specific profit by using laptops. For instance blind or visually
impaired people (I explicitly avoid to say handicapped people). See ACCESS−HOWTO and Blinux − Linux
for blind people for more information. BRLTTY is a program which supports different braille terminals.
Festival is a speech synthesis system. Screen and cursor magnifiers are available.
14.Other Operating Systems
14.1 DOS/Windows9x/NT
Introduction
Unfortunately, there are a few reasons which might make it necessary to put DOS/Windows and Linux
together on one laptop. Often the support for the flash ROM of PCMCIA cards and modems is not available
for Linux, or you have to retrieve hardware information, which is not visible with Linux, due to a lack of
support by some hardware manufacturers. I'm not sure wether this tasks can be achieved under an emulation
like DOS−EMU or WINE.
If you want Linux with X, Netscape, etc., and Windows95, things will be tight in a 1GB harddisk. Though I
do so with a 810MB disk.
13.14 Satellite Watching
75
Linux Laptop−HOWTO
DOS Tools to Repartition a Hard Disk
Often you get a preinstalled version of Windows on your laptop. If you just want to shrink the Windows
partition, you need a tool to resize the partition. Or you can remove the partition first, repartition, then
reinstall. Most of the following information I found at the page of Michael Egan
<[email protected]> at http://libweb.sonoma.edu/mike/fujitsu/ .
A well known and reliable, but commercial product is Partition
Magichttp://www.powerquest.com/product/pm/index.html from Power Quest.
Many people have used FIPS 15c (which may support FAT−32)
http://bmrc.berkeley.edu/people/chaffee/fips/fips.html for repartitioning FAT partition sizes.) Also, another
version from a different source is FIPS 2.0 (claims to support FAT−32)
http://www.igd.fhg.de/~aschaefe/fips/ for repartitioning FAT partition sizes.)
One more "newer" utility for repartitioning and resizing FAT partitions is Ranish Partition
Manager/Utility (FAT−32 support is claimed for this as well, Linux support is taken into account.)
http://www.users.intercom.com/~ranish/part/ .
Partition Sharing
You may share your swap space between Linux and Windows. Please see "Dealing with Limited Resources"
section. Also with Linux you can mount any kind of DOS/Windows partition. The other way round there are
also some tools, for instance at http://uranus.it.swin.edu.au/~jn/linux/ , which provides a tool to read and
write ext2 partitions from Windows9x/NT.
Also you can mount DOS drives of the type msdos, vfat and even compressed drives (Drivespace, etc.).
For long file names use vfat and if you like autoconversion ( a nice feature for text files), you may do so by
using the conv=auto option. I have used this in my /etc/fstab, but be aware this might cause some strange
behaviour sometimes, look at the kernel docs for further details.
/dev/hda8
/dos/d
vfat
user,exec,nosuid,nodev,conv=auto
0
2
Installation without CD Drive
You may use the CD drive of a desktop (or copy the content of the CD to the hard disk) and connect both
machines with a nullmodem cable. Than use a DOS boot floppy and the program INTERLNK.EXE to
connect both machines.
Miscellaneous
http://www.travsoft.com
Windows/NT offers: RAS − Remote Access Service
DOS Tools to Repartition a Hard Disk
76
Linux Laptop−HOWTO
Windows/9x/NT offers the PPTP protocol to connect to remote sites via a TCP/IP tunnel. This protocol is
also supported by Linux. PoPToP is the PPTP server solution for Linux allowing Linux servers to function
seamlessly in the PPTP VPN environment. This enables administrators to leverage the considerable benefits
of both Microsoft clients and Linux servers. The current pre−release version supports Windows 95/98/NT
PPTP clients and PPTP Linux clients. The PoPToP pre−release server is not yet fully optimised. On release,
PoPToP will be fully compliant with IETF PPTP Internet Draft and it will seamlessly support Windows
PPTP clients with the full range of encryption and authentication features.
14.2 BSD Unix
1. PicoBSD is a one floppy version of FreeBSD 3.0−current, which in its different variations allows you
to have secure dialup access, small diskless router or even a dial−in server. And all this on only one
standard 1.44MB floppy. It runs on a minimum 386SX CPU with 8MB of RAM (no HDD required!).
You probably may also use it to install BSD on a laptop as described with micro Linuxes above. You
get PicoBSD at http://www.freebsd.org/~picobsd/
2. PAO: FreeBSD Mobile Computing Package FreeBSD is a version of the UNIX operating system that
runs on PC hardware. It uses a different set of support for PCMCIA devices, APM, and other
mobility related issues.
3. The CMU Monarch Project Implementations of Mobile−IPv4 and Mobile−IPv6 for FreeBSD
4. XF86Config Archive. A database of XF86Config files used by Linux and FreeBSD users. If you
need an XF86Config file for your notebook or laptop, check out this site. (Some documents available
in Japanese only.)
5. AFAIK there is no IrDA support yet.
14.3 OS/2
At The Notebook/2 Site by Dr. Martinus you may find information about different notebooks and PCMCIA
cards working with OS/2.
14.4 NOVELL Netware
The client side with DOS/Windows9x style operating systems seems to be no problem, since there are many
PCMCIA cards with drivers for Netware available. For Linux connections see the mars_nwe package. Also
the Caldera Linux distribtion is well known for its Novell support.
I hadn't time to build a Netware server on a laptop yet and couldn't check wether there are network
connections possible (PCMCIA driver for Netware server).
14.2 BSD Unix
77
Linux Laptop−HOWTO
14.5 Debian GNU/Hurd (hurd−i386)
The GNU Hurd is a totally new operating system being put together by the GNU group. In fact, the GNU
Hurd is the final component which makes it possible to built an entirely GNU OS −− and Debian GNU/Hurd
is going to be one such (possibly even the first) GNU OS. The current project is founded on the i386
architecture, but expect the others to follow soon.
The GNU Hurd Hardware Compatibility Guide states that Hurd should work on laptops, but PCMCIA
support isn't ready yet.
15.ToDo
1. mention the corresponding kernel options in the Linux Compatibility Check sections
2. write more Hardware sections
16.Revision History
v0.1 13 January 1999, first draft
v0.2 15 January 1999, minor changes
v0.3 28 January 1999, APM chapter started, minor changes
v0.4 8 February, APM chapter rewritten, removed some lint
v0.5 17 February 1999, added small USB chapter, added Dealing with Limited Resources chapter, added
Solutions with Laptops chapter, minor editorial changes, released draft to the public
v1.0 19 February 1999, added Sound and Keyboard chapter, minor changes, release to the LDP
v1.1 28 February 1999, spelling, grammar, style checked and many additional information added by W.
Wade Hampton, added CD Drive, Harddisk and Kernel chapters, many minor changes
v1.2 5 March 1999, added Debian−Laptop−Mailing−List, added information about apmcd and
suspendd to APM chapter, changed some URLs, minor changes
v1.3 8 March 1999, minor changes
v1.4 25 March 1999, added ACPI information, added chapters Appendix C − NeoMagic Chip NM20xx by
Cedric Adjih and Appendix D − Annotated Bibliography , minor changes
v1.5 4 April 1999, added chapters about setting up E−Mail by Peter Englmaier and Noise Reduction, minor
14.5 Debian GNU/Hurd (hurd−i386)
78
Linux Laptop−HOWTO
changes
v1.6 26 June 1999, rewrite of APM chapter, added install method via LapLink cable, URLs changed or
added, spell checking, minor changes
v1.7 28 September 1999, changed <htmlurl ..> SGML tags to <url ..>, ACPI chapter separated, touchpad
chapter separated and improved, preface rewritten, added information about divine, noflushd and
parted, new chapter Linux Tools to Repartition a Hard Disk, added appendix E about specific laptops,
some URLs updated, minor changes
v2.0 2 October 1999, added information about gphoto, kmc_utils, Memory Technology Devices and
HUT Mobile IP; changed structur of document (moved chapters Accessories, Laptop Distribution and chapter
about partitioning), new DVD chapter, started Aviation chapter, started OS/2 chapter, started Blind and
Visually Impaired Users chapter, changed entity &tilde; in URLs to ~ to improve SGML−Tools PS output
(otherwise ~ is missing), link to new Lucent WinModem driver, minor additions and changes
v2.1 2 November 1999, added information about email with UUCP, the use of CVS and other tools to
synchronize two machines, the noatime mount option, GPS systems, presentation tools, and hard disk form
factors, started chapter about the Hurd, changed URL of PCMCIA−CS package and LDP, reworked credits
chapter, reworked APM chapter, minor changes
v2.2 2 December 1999, reorganized the chapters about Cellular Phones, Pagers, Calculators, Digital Cameras,
Wearable Computing and Noise Reduction, many minor changes and bug fixes
17.Credits
I would like to thank the many people who assisted with corrections and suggestions. Their contributions
have made this work far better than I could ever have done alone. Especially I would like to thank, in order of
appearance:
• First of all Kenneth E. Harker <[email protected]>, from his page Linux on Laptops I have
included much material into this HOWTO, but didn't always quote him verbatim.
• The other HOWTO authors from the LINUX DOCUMENTATION PROJECT − LDP.
• The members of the Linux/IrDA Project.
• The members of the Linux−Laptop Mailing List.
• The members of the Debian−Laptop Mailing List.
• The visitors and contributors of my LiLAC − Linux with Laptop Computers pages.
• David Hinds, the maintainer of the PCMCIA−CS package.
• Frank Schneider <[email protected]−ONLINE.DE>.
• Stefan Martig <[email protected]>.
• Michele Andreoli, maintainer of muLinux.
• Klaus Franken <[email protected]>.
• W. Wade, Hampton <[email protected]>, did much of spell, grammar and style checking and
added many valuable information.
• Anderson MacKay <[email protected]>, RLUG − Rice University Linux User Group , gave many
different detailed recommendations.
17.Credits
79
Linux Laptop−HOWTO
• Sean 'Shaleh' Perry, <[email protected]>, Debian maintainer of anacron and other packages, for
Debian support.
• Bob Toxen <[email protected]>.
• Peter Sprenger <[email protected]>.
• Felix Braun <[email protected]>.
• Steve Rader <[email protected]>.
• Richard Worwood <[email protected]>, for mirroring of the HOWTO.
• Marcel Ovidiu Vlad <[email protected]>.
• Ludger Berse <[email protected]>.
• Cedric Adjih <[email protected]>, wrote the chapter about the NeoMagic chipset.
• Peter Englmaier <[email protected]>, provided the chapter about a sophisticated email setup.
• Michael Wiedmann <[email protected]−berlin.de>, PIA − X11 based PalmPilot Address Manager ,
found many spelling errors and more.
• Adam Spiers <[email protected]>.
• Lionel, "trollhunter" Bouchpan−Lerust−Juery, <[email protected]>, for providing the French
translation and information about wearables .
• Nathan Myers <[email protected]>, from LL − LinuxLaptops for numerous additions.
• Ben Attias <[email protected]>.
• Igor Pesando <[email protected]>.
• Geert Van der Plas <[email protected]>, provided information about the
touchpad driver included in the GPM.
• Chandran Shukla <[email protected]>.
• Harald Milz <[email protected]>, from SuSE provided numerous additions.
• Ingo Dietzel <[email protected]>, for his patience with the project.
• Emerson, Tom # El Monte <[email protected]>, for his idea about laptop bags.
• Thomas Traber <[email protected]>.
• Bill Gjestvang <[email protected]>.
• Leandro Noferin <[email protected]>, for proofreading the italian parts.
• Stephane Bortzmeyer <[email protected]> for his suggestions about email with UUCP, the use
of CVS or related tools to synchronize two machines, and the noatime mount option.
• Peter Teuben <[email protected]>, for some suggestions about hard disks.
• Guido Germano <[email protected]>, for information about the Macintosh Powerbook 145B.
• Joel Eriksson <[email protected]>, for information about Atari laptops.
• Gilles Lamiral <[email protected]> for providing the PLIP Install−HOWTO.
• Alessandro Grillo <[email protected]>, started the Italian translation.
• Gledson Evers <[email protected]>, started the Portuguese translation.
• Dan Kegel <[email protected]>, pointed me to the Toshiba Linux page.
• Jaime Robles <[email protected]>, gave me some information about the HAM−HOWTO.
• LuftHans <[email protected]>, announced this HOWTO to the maintainer of the
Hardware−HOWTO.
• Jari Malinen <[email protected]>, for support with HUT Mobile IP.
• John Beimler <[email protected]>, provided the URL of photopc.
• Steven G. Johnson <[email protected]>, provided the information about Apple/Macintosh m86k
machines.
• Ulrich Oelmann <[email protected]−clausthal.de>, gave valuable additions about the installation
with muLinux.
• Lucio Pileggi <[email protected]>, provided information about the Siemens S25 cellular phone.
• Eric <[email protected]> wrote how to transfer pictures from a digital camera.
• Sorry, but probably I have forgotten to mention everybody who helped.
17.Credits
80
Linux Laptop−HOWTO
18.Appendix A − Survey about Micro Linuxes
Because of their small or non−existent footprint, micro−Linuxes are especially suited to run on laptops −−
particularly if you use a company−provided laptop running Windows9x/NT. Or for installation purposes
using another non Linux machine. There are several micro Linux distributions out there that boot from one or
two floppies and run off a ramdisk.
See http://www.linuxhq.com or http://www.txdirect.net/users/mdfranz/tinux.html for details. You may find a
FAQ and a mailing list about boot−floppies at http://os.inf.tu−dresden.de/~sr1/boot−floppies/faq.html . Also
a BootDisk−HOWTO is available. Thanks to Matthew D. Franz maintainer of Trinux for this tips and
collecting most of the following URLs. See also the content of Console/Mini Distributions at FreshMeat.
1. MuLinux by Michele Andreoli
2. tomsrtbt http://www.toms.net/~toehser/rb/ "The most Linux on one floppy. (distribution or panic
disk)." by Tom Oehser
3. Trinux http://www.trinux.org "A Linux Security Toolkit" by Matthew D. Franz
4. LRP "Linux Router Project" http://www.psychosis.com/linux−router/
5. hal91 http://home.sol.no/~okolaas/hal91.html
6. floppyfw http://www.zelow.no/floppyfw/ by Thomas Lundquist
7. minilinux http://alberti.crs4.it/softw are/mini−linux/ (seems no more valid) or
http://www.kiarchive.ru/pub/linux/mini−linux/
8. monkey http://www.spsselib.hiedu.cz/monkey/docs/english.htm
9. DLX http://www.wu−wien.ac.at/usr/h93/h9301726/dlx.html by Erich Boem
10. C−RAMDISK http://metalab.unc.edu/pub/Linux/kernel/images/
11. BABEL http://celsius−software.hypermart.net/babel/ "A mini−distribution to run games"
12. Xdenu http://xdenu.tcm.hut.fi/ , quotating Alan Cox: "Xdenu is a small distribution program that
installs as a set of DOS zips onto a DOS partition and gives you a complete X11 client workstation."
13. LOAF http://www.ecks.org/loaf/
14. pocket−linux http://pocket−linux.coven.vmh.net/
15. FLUF http://www.upce.cz/~kolo/fluf.htm
16. YARD http://www.croftj.net/~fawcett/yard/
17. TLinux http://members.xoom.com/ror4/tlinux/
18. ODL http://linux.apostols.org/guru/wen/
19. SmallLinux by Steven Gibson http://smalllinux.netpedia.net/ Three disk micro−distribution of Linux
and utilities. Based on kernel 1.2.11. Root disk is ext2 format and has fdisk and mkfs.ext2 so
that a harddisk install can be done. Useful to boot up on old machines with less than 4MB of RAM.
20. cLIeNUX by Rick Hohensee client−use−oriented Linux distribution ftp://ftp.blueznet.com
/pub/colorg
21. linux−lite by Paul Gortmaker for very small systems with less than 2MB RAM and 10MB harddisk
space (1.x.x kernel) http://metalab.unc.edu/pub/Linux/kernel
22. See also the packages at MetaLab formerly known as SunSite
http://metalab.unc.edu/pub/Linux/system/recovery/!INDEX.html and the Boot−Disk−HOWTO
23. You may also consider some of the boot floppies provided by various distributions falling into this
category, e.g. the boot/rescue floppy of Debian/GNU Linux.
24. If you like to build your own flavour of a boot floppy you may do so manually, as described in the
BootDisk−HOWTO or using some helper tools, for instance mkrboot (provided at least as a
Debian/GNU Linux package) or pcinitrd, which is part of the PCMCIA−CS package by David
Hinds.
25. Also you might try to build your Linux system on a ZIP drive. This is described in the
18.Appendix A − Survey about Micro Linuxes
81
Linux Laptop−HOWTO
ZIP−Install−mini−HOWTO.
19.Appendix B − Dealing with Limited Resources or Tuning
the System
19.1 Related HOWTOs
1. LBX−HOWTO
2. Small−Memory−HOWTO
19.2 Introduction
As mentioned in the introduction laptops sometimes have less resources if you compare them to desktops. To
deal with limited space, memory, CPU speed and battery power, I have written this chapter.
19.3 Small Space
Introduction
There are different types of techniques to gain more disk space, such as sharing of space, freeing unused or
redundant space, filesystem tuning and compression. Note: some of these techniques use memory instead of
space. As you will see, there are many small steps necessary to free some space.
Techniques
1. Stripping: Though many distributions come with stripped binaries today it is useful to check this. For
details see man strip. To find every unstripped file you can use the file command or more
convenient the tool findstrip. Attention: don't strip libraries, sometimes the wrong symbols are
removed due to a bad programming technique. Or use the −−strip−unneeded option.
2. Perforation: zum(1)reads a file list on stdin and attempts to perforate these files. Perforation means,
that series of null bytes are replaced by lseek, thus giving the file system a chance of not allocating
real disk space for those bytes. Example: find . −type f | xargs zum
3. Remove Odd Files and Duplicates: Check your system for core files, emacs recovery files <#FILE#>
vi recovery files <FILE>.swp, RPM recovery files <FILE>.rpmorig and patch recovery files. Find
19.Appendix B − Dealing with Limited Resources or Tuning the System
82
Linux Laptop−HOWTO
duplicates, you may try finddup. Choose a system to name your backup, temporary and test files,
e.g. with a signature at the end.
4. Clean Temporary Files: , e.g. /tmp, there is even a tool tmpwatch.
5. Shorten the Log Files: usually the files in /var/log.
6. Remove Files: Remove files which are not "necessary" under all circumstances such as man pages,
documentation /usr/doc and sources e.g. /usr/src .
7. Unnecessary Libraries: You may use the binstats package to find unused libraries (Thanks to
Tom Ed White).
8. Filesystem: Choose a filesystem which treats disk space economically e.g. rsfs. Tune your
filesystem e.g. tune2fs. Choose an appropriate partition and block size.
9. Reduce Kernel Size: Either by using only the necessary kernel features and/or making a compressed
kernel image bzImage.
10. Compression: I didn't check this but AFAIK you may compress your filesystem with gzip and
decompress it on the fly. Alternatively you may choose to compress only certain files. You can even
execute compressed files with zexec
11. Compressed Filesystems:
− For e2fs filesystems there is a compression version available e2compr , see
http://debs.fuller.edu/e2compr/ .
− DMSDOS which enables your machine to access Windows95 compressed drives (drivespace,
doublestacker). If you don't need DOS/Windows95 compatibility, i.e. if you want to compress
Linux−only data, this is really discouraged by the author of the program. See
http://fb9nt−ln.uni−duisburg.de/mitarbeiter/gockel/software/dmsdos/ .
12. Partition Sharing: You may share swap−space (see Swap−Space−HOWTO) or data partitions
between different OS (see mount). For mounting MS−DOS Windows95 compressed drives
(doublespace, drivespace) you may use
dmsdos http://metalab.unc.edu/pub/Linux/system/filesystems/dosfs/.
13. Libraries: Take another (older) library, for instance libc5 , this library seems to be smaller than
libc6 aka glibc2 .
14. Kernel: If your needs are fitted with an older kernel version, you can save some space.
15. GUI: Avoid as much Graphical User Interface (GUI) as possible.
16. Tiny Distributions: There are some distributions available which fit from one 3.5" floppy to 10MB
disk space and fit for small memories, too. See appendix A and below.
17. External Storage Devices (Hard Disks, ZIP Drives, NFS, SAMBA): Since many notebooks may be
limited in their expandability, using the parallel port is an attractive option. There are external
harddisks and ZIP Drives available. Usually they are also connectable via PCMCIA. Another way is
using the resources of another machine through NFS or SAMBA etc.
19.4 Harddisk Speed
Use the tool hdparm to set up better harddisk performance. Though I have seen laptop disk enabled with
striping, I can't see a reason to do so, because IMHO aka RAID0 striping needs at least two different disks to
increase performance.
See UNIX and LINUX Computing Journal: Tunable Filesystem Parameters in /proc How to increase,
decrease and reconfigure filsystem behavior from within /proc.
19.4 Harddisk Speed
83
Linux Laptop−HOWTO
19.5 Small Memory
Related HOWTOs
1. Small−Memory−mini−HOWTO by Todd Burgess <[email protected] >
http://eddie.cis.uoguelph.ca/~tburgess
2. Modules−mini−HOWTO
3. Kerneld−mini−HOWTO
Techniques
Check the memory usage with free and top.
Mergemem Project . Many programs contain memory areas of the same content that remain undetected by the
operating system. Typically, these areas contain data that have been generated on startup and remain
unchanged for longer periods. With mergemem such areas are detected and shared. The sharing is performed
on the operating system level and is invisible to the user level programs. mergemem is particularily useful if
you run many instances of interpreters and emulators (like Java or Prolog) that keep their code in private data
areas. But also other programs can take advantage albeit to a lesser degree.
You may also reduce the kernel size as much as possible by removing any feature which is not necessary for
your needs and by modularizing the kernel as much as possible.
Also you may shutdown every service or daemon which is not needed, e.g. lpd, mountd, nfsd and close
some virtual consoles. Please see Small−Memory−mini−HOWTO for details.
And of coarse use swap space, when possible.
If possible you use the resources of another machine, for instance with X, VNC or even telnet. For more
information on Virtual Network Computing (VNC), see http://http://www.uk.research.att.com/vnc/ .
19.6 Low CPU Speed
You may want to overdrive the CPU speed but this can damage your hardware and I don't have experience
with it. For some examples look at Adorable Toshiba Libretto − Overclocking
http://www.cerfnet.com/~adorable/libretto.html.
19.5 Small Memory
84
Linux Laptop−HOWTO
19.7 Power Saving Techniques
1. If you don't need infrared support, disable it in the BIOS or shutdown the IrDA device driver. There
are also some IrDA features of the kernel which are useful for saving power.
2. PCMCIA services consume much power, so shut them down if you don't need them.
3. I'm not sure to which extend the backlight consumes power. WARNING: AFAIK this device can
only bear a limited number of uptime circles. So avoid using screensavers.
4. For some examples to build batteries with increased uptime up to 8 hours look at Adorable Toshiba
Libretto http://www.cerfnet.com/~adorable/libretto.html.
5. For information about APM look at the APM chapter above.
6. A hacked rclock . Booker C. Bense has hacked the rclock program to include a simple battery power
meter on the clock face.
7. xbatstat. A battery level status checker for Linux and X.
8. The "noatime" option when mouting filesystems tells the kernel to not update the access
time information of the file. This information, although sometimes useful, is not used by most people
(do you know that ls −lu gives you the access time?). Therefore, you can safely disable it, then
preventing disk access each time you cat a file. Here is an example of a /etc/fstab with this
power−saving option:
/dev/hda7 /var ext2 defaults,noatime 0 2
9. hdparmhdparm is a Linux IDE disk utility that lets you set spin−down timeouts and other disk
parameters. It works also for some SCSI features.
10. Mobile Update Daemon This is a drop−in replacement for the standard update daemon,
mobile−update minimizes disk spin ups and reduces disk uptime. It flushes buffers only when
other disk activity is present. To ensure a consistent file system call sync manually. Otherwise files
may be lost on power failure. mobile−update does not use APM. So it works also on older
systems.
11. noflushd: noflushd monitors disk activity and spins down disks that have been idle for more than
<timeout> seconds. It requires a kernel >=2.2.11 . Useful in combination with hdparm and
mount with noatime option to bring down disk activity.
12. Toshiba Linux Utilities This is a set of Linux utilities for controlling the fan, supervisor passwords,
and hot key functions of Toshiba Pentium notebooks. There is a KDE package Klibreta, too.
13. At Kenneth E. Harker's page there is a recommendation for LCDproc LCDProc . "LCDproc is a
small piece of software that will enable your Linux box to display live system information on a 20x4
line backlit LCD display. This program shows, among other things, battery status on notebooks." I
tried this package and found that it connects only to the external Matrix−Orbital 20x4 LCD display
http://www.matrix−orbital.com/, which is a LCD display connected to a serial port. I can't see any
use for a laptop yet.
14. Diald: Dial Daemon . The Diald daemon provides on demand Internet connectivity using the SLIP or
PPP protocols. Diald can automatically dial in to a remote host when needed or bring down dial−up
connections that are inactive.
15. KDE http://www.kde.org provides KAPM, Kbatmon and Kcmlaptop. Written by Paul Campbell
kcmlaptop is a set of KDE control panels that implements laptop computer support functions, it
includes a dockable battery status monitor for laptops − in short a little icon in the KDE status bar
that shows how much battery time you have left. It also will warn you when power is getting low and
allows you to configure power saving options. Similar packages you may find at the GNOME project
http://www.gnome.org/ . See the software maps at both sites.
19.7 Power Saving Techniques
85
Linux Laptop−HOWTO
16. Please see Battery Powered Linux Mini−HOWTO by Hanno Mueller, [email protected]
http://www.lava.de/~hanno/ for more information.
19.8 Kernel
Related HOWTOs
• Kernel−HOWTO
• BootPrompt−HOWTO
Many kernel features are related to laptops. For instance APM, IrDA, PCMCIA and some options for certain
laptops, e.g. IBM ThinkPads. In some distributions they not configured. And the kernel is usually bigger than
necessary. So it's seems a good idea to customize the kernel. Though this task might seem difficult for the
beginner it is highly recommended. Since this involves dangerous operations you need to be careful. But, if
you can install a better kernel successfully, you've earned your intermediate Linux sysadmin merit badge. −
Since this topic is already covered in other documents I want handle this here.
19.9 Tiny Applications and Distributions
A small collection yet, but I'm looking for more information.
1. BOA − "Lightweight and High Performance WebServer. boa is a single−tasking HTTP server. That
means that unlike traditional web servers, it does not fork for each incoming connection, nor does it
fork many copies of itself to handle multiple connections. It internally multiplexes all of the ongoing
HTTP connections, and forks only for CGI programs (which must be separate processes.)
Preliminary tests show boa is capable of handling several hundred hits per second on a 100 MHz
Pentium."
2. MGR − a graphical windows system, which uses much less resources than X.
3. Low Bandwidth X:
Alan Cox in LINUX REDUX February 1998 " .. there are two that handle normal applications very
nicely. LBX (Low Bandwidth X) is the official application of the X Consortium (now OpenGroup
www.opengroup.org). Dxpc http://ccwf.cc.utexas.edu/~zvonler/dxpc is the alternative most people
prefer. These systems act as proxy X11 servers and compress datastreams by well over 50 percent for
normal requests, often reaching a reduction to 25 percent of the original bandwidth usage. With dxpc,
X windows applications are quite usable over a 28.8 modem link or across the Internet."
4. blackbox − "This is a window manager for X. It is similar in many respects to such popular packages
as Window Maker, Enlightenment, and FVWM2. You might be interested in this package if you are
tired of window managers that are a heavy drain on your system resources, but you still want an
attractive and modern−looking interface."
5. xfce − xfce is a lightweight and stable desktop environment for various UNIX systems.
19.8 Kernel
86
Linux Laptop−HOWTO
6. linux−lite − distribution based on a 1.x.x kernel for systems with only 2MB memory and 10MB
harddisk. URL see above.
7. smallLinux − http://smalllinux.netpedia.net/ . Three disk micro−distribution of Linux and utilities.
Based on kernel 1.2.11. Root disk is ext2 format and has fdisk and mkfs.ext2 so that a harddisk
install can be done. Useful to boot up on old machines with less than 4MB of RAM.
8. cLIeNUX − client−use−oriented Linux distribution.
9. minix − not a Linux but a UNIX useful for very small systems, such as 286 CPU and 640K RAM
http://www.cs.vu.nl/~ast/minix.html . There is even X support named mini−x by David I. Bell
ftp://ftp.linux.org.uk/pub/linux/alan/ .
10. screen − tiny but powerful console manager. John M. Fisk <[email protected]> in
LINUX GAZETTE July 1, 1996 :"It's a GUI, GUI, GUI, GUI world! " −− or so the major OS
manufacturers would have you belief. Truth is, that while this is increasingly the case, there are times
when the command line interface (CLI) is still a very good choice for getting things done. It's fast,
generally efficient, and is a good choice on memory or CPU constrained machines. And don't forget
that there are still a lot of very nifty things that can be done at the console."
11. tinyirc − "A tiny, stripped down IRC Client. Doesn't have most of the more advance commands in the
ircII family of IRC Clients, nor does it have any color, but it works, and it's tiny."
19.10 Hardware Upgrade
You may also take into account to upgrade the hardware itself, though this may have some caveats, see
chapter Open a Laptop Case above. If you need a survey about the possibilities, you can take a look at
http://www.upgrade.de, this page is also available in French and English.
20.Appendix C − NeoMagic Chip NM20xx
20.1 Introduction
Hence the NeoMagic chipset series NM20xx is one of the most used graphic chips in laptops in our times, I
will spent a few words on them. Though a long time this chip was only supported by commercial X servers,
since the middle of 1998 RedHat provided a binary X server manufactured by PrecisionInsight. Since version
3.3.3 this X server is also available by XFree86.
20.2 Textmode 100x37
This chapter is a courtesy of Cedric Adjih < [email protected] >. I changed some minor parts.
An apparently little known fact about the Neomagic chipset NM20xx is that you can run text mode in 100x37
(i.e. 800x600). This text mode is very nice (as opposed to the 80x25 which is ugly). I tried this with a HP
OmniBook 800 and suppose it might work with other laptops using the NeoMagic chip, too. The following
that I wrote was much longer than I expected so I wrote it as a kind of mini−howto :−) :
19.10 Hardware Upgrade
87
Linux Laptop−HOWTO
The main problem is that is a bit difficult to set up, and if you're going wrong with
SVGATextMode/restoretextmode some results on the LCD might be frightening. Although I didn't manage to
break my LCD with many many attempts going wrong, DISCLAMER: THIS MIGHT DAMAGE YOUR
HARDWARE. YOU HAVE BEEN WARNED. FOLLOW THE FOLLOWING INSTRUCTIONS AT
YOUR OWN RISKS. I'M NOT RESPONSIBLE IF SOMETHING BAD HAPPENS.
Survey
You need to do three main steps:
1. Enable Linux to boot in 800x600 textmode. The problem is that you won't see any text before the
following two steps aren't done.
2. Automatically run restoretextmode with correct register data.
3. Automatically run SVGATextMode.
More Details
All the files I have modified, are available for now at
http://starship.python.net/crew/adjih/data/cda−omni−trick.tar.gz
Enabling Linux to Boot in 800x600
Recent kernels (2.2.x) need to be compiled with CONFIG_VIDEO_GFX_HACK defined. Default is off.
(look in /usr/src/linux−2.2.x/arch/i386/boot/video.S)
This is done by passing the parameter vga=770 to older kernels or vga=7 to 2.2.x kernels. Example with
lilo.conf:
image=/boot/bzImage−modif
label=22
append="svgatextmode=100x37x8_SVGA" #explained later
vga=7
read−only
Running restoretextmode and SVGATextMode at Boot Time
You must arrange to run restoretextmode <name of some textreg.dat file> and
SVGATextMode 100x37x8_SVGA at boot time.
An example textreg.dat for restoretextmode (obtained using savetextmode) is in my tar archive in tmp/,
and an example /etc/TextConfig.
Since I'm lazy, I've simply put SVGATextMode and restoretextmode in the /etc/rc.boot/kbd file from
Survey
88
Linux Laptop−HOWTO
my Debian/GNU Linux which get executed at boot time (also available in the tar archive).
Now the Key Point
Annoying things will be displayed if you don't use the right SVGATextMode in the right video text mode:
this is why I also pass the environmental variable "svgatextmode=100x37x8_SVGA" (arbitrary name)
to the kernel (using append=xxx in lilo.conf) when I also set vga=7: the script /etc/rc.boot/kbd tests this
variable and calls restoretextmode and SVGATextMode IF AND ONLY IF.
Road Map
1. Recompile the kernel 2.2.x with CONFIG_VIDEO_GFX_HACK
2. Insert the restoretextmode with the correct parameter in the initialisation script, with no other changes.
3. Boot with normal text mode (80x25) but restoretextmode: you should see the screen going to 100x37,
but with only 80x25 usable. Don't use SVGATextMode yet.
4. It is much better to conditionnalize your initialize code as I did, to keep the possibility of booting in
both modes: you may test this now with some reboots (starting restoretextmode or not).
5. Boot with 100x37 text mode using parameter vga=7 (lilo.conf), you should see white background at
some point, but the characters will be black on black. This is ok. You'll have to reboot blindly now.
6. Insert the <path>/SVGATextMode 100x37x8_SVGA after the restoretextmode in initialization
scripts.
7. Reboot with vga=7 (lilo.conf)
8. Should be OK now. Enjoy.
21.Appendix D − Annotated Bibliography
• Linux guides and HOWTOs, available at the Linux Documentation Project (LDP)
http://metalab.unc.edu/LDP . These sources of information are highly recommended.
• I found two books about PC hardware which contain a dedicated chapter about repairing laptops.
Author: Scott Mueller Title: Upgrading and Repairing PCs Publisher: QUE Corporation. Author:
Marc Misani Title: The Complete Hardware Upgrade and Maintainance Guide Publisher: unknown
Both books don't know about Linux and both are quite short about laptops. The book by Marc Minasi
provides a little more information about laptops.
• Authors: Alessandro Rubini, Andy Oram Title: Linux Device Drivers
• Author: Stephen J. Bigelow Title: Maintain and Repair Your Notebook, Palmtop, or Pen Computer
Publisher: McGraw Hill Text, September 1993 Review by Booknews, Inc. , January 1, 1994: A guide
to performing routine maintenance and simple repairs to notebook, palmtop and pen computers.
Covers such topics as how to diagnose and replace faulty LCD and plasma displays, and how to
protect circuitry from electrostatic damage. Written with beginners in mind −− but some hardware
experience would be helpful in understanding the subtleties and cautions involved. Annotation
copyright Book News, Inc. Portland, Or. Though this book seems outdated I don't know a newer one.
• Author: Frank van Gilluwe Title: The Undocumented PC Publisher: Addison Wesley Developers
Now the Key Point
89
Linux Laptop−HOWTO
Press Review by Craig Hart: There are two editions. Edition 1 has a purple cover, edition 2 has a grey
marble background photo with brown−on−yellow text panel. Edition 2 is not much better than
edition one − only about 10%; of the information has changed, although a lot of typographical errors
have been corrected. This is an excellent book, because it not only lists the raw data required to
program something, but it has lot's of explanations, how−to's and example programs.
• Authors: Gerald Reischl / Heinz Sundt Title: Die mobile Revolution Publisher: Frankfurt:
Ueberreuter 1999 Some speculations about the future of mobile communication.
22.Appendix E − Resources for Specific Laptops
Certain laptops have found some more enthusiastic Linux users, than other models. This list is probably not
comprehensive:
22.1 IBM ThinkPad
ThinkPad Configuration Tool for Linux tpctl
Mailing list linux−thinkpad.
22.2 Toshiba Laptops
Toshiba Linux Utilities This is a set of Linux utilities for controlling the fan, supervisor passwords, and hot
key functions of Toshiba Pentium notebooks. There is a KDE package Klibreta, too.
See also Toshiba Linux Utilities
Mailing lists: linux−on−portege , Linux on Toshiba Satellite 40xx linux−tosh−40xx
<[email protected]>.
Toshiba itself offers now Toshiba Linux Support.
22.3 COMPAQ Concerto Aero
COMPAQ Concerto Fan's Home Page and Aero−FAQ.
The latest version of the Linux Compaq Concerto Pen Driver is available from Joe Pfeiffer's home page.
22.Appendix E − Resources for Specific Laptops
90
Linux Laptop−HOWTO
22.4 DELL Laptops
Mailing list at linux−dell−laptops
22.4 DELL Laptops
91
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
