Samsung SSD Self-Install Photo Guide
for desktop computers
© 2013 Samsung Electronics Co.
Checking
the Product
00
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
01
02
Bracket
Package (installation program & manual
CD instruction manual, warranty)
SSD
mounting spacer
SATA cable
SSD Self-Install Photo Guide
for desktop computers
Carefully open the SSD box.
Make sure that there are no missing components!
screws
SATA to USB connector
stickers
Checking
the Product
01
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
02
Remove the CD from the black document pouch, and
insert it into the CD-ROM drive.
You can also download the guide at www.samsung.com/samsungssd .
(See next page)
03
Checking
the Product
02
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
03
You can also download the program at the official
Samsung SSD homepage.
You can also download the guide at www.samsung.com/samsungssd .
(SSD firmware, Magician software, Samsung Data Migration software)
04
Checking
the Product
03
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
04
Install the Magician program.
*Run the CD, then click the setup file in the Magician Software folder to install the program.
05
Checking
the Product
04
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
05
Install the Data Migration program.
Using Data Migration migrates all of the user's data including the OS.
This means re-installation of the OS is not necessary.
* Run the CD, then click the setup file in the Magician Software folder to install the program.
06
Checking
the Product
05
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
06
Run the Data Migration program,
and then connect the SSD to the computer.
1. On the main screen, click ‘Start’ to run the Data Migration program.
07
Checking
the Product
06
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
07
Connect the SSD to the computer.
2. Connect the SSD to the desktop computer using the SATA to USB connector.
08
Checking
the Product
07
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
08
Run the Data Migration program, and make
sure to the SSD is detected in the program.
3. The Data Migration program will automatically detect the SSD.
09
Checking
the Product
08
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
09
Click the ‘Start Migration’ button to start Data Migration.
* Data Migration migrates the data and the operating system (Windows) installed on the computer
you are using to the SSD you have purchased.
* After data migration is complete, turn off the computer and then disconnect the SSD from the
USB connector.
10
Checking
the Product
09
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
10
Open the cover of your computer.
* The details of how to open the cover differ between computer models. Refer to the service manual
for your computer to open the cover safely.
* You need to open the cover on the opposite side to remove the HDD. This is described in the next step.
11
Checking
the Product
10
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
11
Disconnect all the cables that are connected to the
original HDD (or existing SSD) in your computer.
The cables that have been disconnected from the original HDD need to be reconnected to your new SSD.
It is recommended that you mark these cables in some way so that they are not confused with other cables.
12
Checking
the Product
11
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
12
Remove the HDD by unfastening the screws
holding the HDD in the drive bay.
13
Checking
the Product
12
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
13
Attach the bracket to the SSD.
* The bracket is sold separately. (However, a bracket is included in the Desktop Kit and All-in-One Kit.)
* The bracket may not be necessary, depending on the design of your computer.
* Use four screws to fasten it securely in place.
14
Checking
the Product
12
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
13
Attach the bracket to the SSD.
* The bracket is sold separately. (However, a bracket is included in the Desktop Kit and All-in-One Kit.)
* The bracket may not be necessary, depending on the design of your computer.
* Use four screws to fasten it securely in place.
14
Checking
the Product
13
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
14
Insert the SSD, fitted with the bracket, into the location of
the original HDD (usually SATA port #0), and secure it in place.
The HDD is usually mounted in SATA port #0, because booting starts at the lowest-numbered SATA port
and then proceeds sequentially. (Port #0, port #1, port #2, and so on.)
Therefore, you need to mount your new SSD in SATA port #0 (vacated by the existing HDD), which is the
lowest-numbered SATA port.
15
Checking
the Product
13
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
14
Insert the SSD, fitted with the bracket, into the location of
the original HDD (usually SATA port #0), and secure it in place.
The HDD is usually mounted in SATA port #0, because booting starts at the lowest-numbered SATA port
and then proceeds sequentially. (Port #0, port #1, port #2, and so on.)
Therefore, you need to mount your new SSD in SATA port #0 (vacated by the existing HDD), which is the
lowest-numbered SATA port.
15
Checking
the Product
14
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
15
Connect the cables that have been disconnected
from the existing HDD to your new SSD.
16
Checking
the Product
14
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
15
Connect the cables that have been disconnected
from the existing HDD to your new SSD.
16
Checking
the Product
15
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
16
Connect the existing HDD to the port with the
next lowest number.
For example, if the SSD is connected to port #0, then connect the HDD to port #1.
17
Checking
the Product
15
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
16
Connect the existing HDD to the port with the
next lowest number.
For example, if the SSD is connected to port #0, then connect the HDD to port #1.
17
Checking
the Product
16
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
17
Connect the SATA cable and the power cable to the
reinstalled HDD.
18
Checking
the Product
16
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
17
Connect the SATA cable and the power cable to the
reinstalled HDD.
18
Checking
the Product
17
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
18
Reattach the side covers to the computer.
19
Checking
the Product
18
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
19
20
Reboot the computer, and immediately enter BIOS setup.
Entering the BIOS setup may be done differently depending on mainboard and/or computer manufacturer.
Usually, you can enter BIOS setup by pressing the Delete key or the F2 key before the boot sequence proceeds to Windows.
Checking
the Product
19
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
20
Change IDE mode to AHCI mode.
* AHCI mode is usually found under advanced options.
* Some mainboards may not support AHCI.
(In this case you should obtain a separate driver from the manufacturer of the mainboard or the OS
to maximize the performance of the SSD.)
* Once installation is completed, install necessary drivers.
21
Checking
the Product
20
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
21
When you boot up the computer, Windows will detect
the new SSD automatically, and a message will advise
you reboot the computer.
* Once the desktop computer detects the newly mounted SSD, a message will advise you reboot the computer.
This is normal, and you should reboot the computer.
22
Checking
the Product
21
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
22
After rebooting, run the Magician program
to verify that the SSD has been detected correctly.
23
Checking
the Product
22
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
23
Check the AHCI mode and SATA interface settings.
* If AHCI mode is enabled and the SSD is connected to SATA 3 as shown in the photo,
run OS Optimization setup (in the left menu).
* The SSD performs optimally when using AHCI mode and SATA 3.
24
Checking
the Product
23
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
24
If you are using SATA 2, check whether your mainboard
supports SATA 3.
* If SATA 3 is supported, turn off your computer and connect the SSD using SATA 3.
* If SATA 3 is not supported, proceed to the next step.
For more information, please contact the manufacturer of your mainboard.
25
Checking
the Product
24
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
25
After setup has completed, check OS optimization.
* Run performance benchmark and performance optimization from the left menu to ensure optimal performance.
* For more information, please refer to ‘Help’, located at the lower right corner.
26
Checking
the Product
25
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
26
Place the SSD sticker in a prominent location.
The installation and optimization of the SSD is now complete.
Thank you.
© 2013 Samsung Electronics Co.
Samsung SSD Self Installation Photo Guide
for desktop computers (reinstalling Windows)
© 2013 Samsung Electronics Co.
Checking
the Product
00
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
01
02
Bracket
Package (installation program & manual
CD instruction manual, warranty)
SSD
mounting spacer
SATA cable
SSD Self-Install Photo Guide
for desktop computers
Carefully open the SSD box.
Make sure that there are no missing components!
screws
SATA to USB connector
stickers
Checking
the Product
01
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
02
Open the cover of your computer.
* The details of how to open the cover differ between computer models. Refer to the service manual for your
computer to open the cover safely.
* You need to open the cover on the opposite side to remove the HDD. This is described in the next step.
03
Checking
the Product
02
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
03
Disconnect all the cables that are connected to the
original HDD (or existing SSD) in your computer.
The cables that have been disconnected from the original HDD need to be reconnected to your new SSD.
It is recommended that you mark these cables in some way so that they are not confused with other cables.
04
Checking
the Product
03
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
04
Remove the HDD by unfastening the screws
holding the HDD in the drive bay.
05
Checking
the Product
04
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
05
Attach the bracket to the SSD.
* The bracket is sold separately. (However, a bracket is included in the Desktop Kit and Allin-One Kit.)
* The bracket may not be necessary, depending on the design of your computer.
* Use four screws to fasten it securely in place.
06
Checking
the Product
04
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
05
Attach the bracket to the SSD.
* The bracket is sold separately. (However, a bracket is included in the Desktop Kit and Allin-One Kit.)
* The bracket may not be necessary, depending on the design of your computer.
* Use four screws to fasten it securely in place.
06
Checking
the Product
05
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
06
Insert the SSD, fitted with the bracket, into the location
of the original HDD. (usually SATA port #0), and secure it in place.
The HDD is usually mounted in SATA port #0, because booting starts at the lowest-numbered SATA port
and then proceeds sequentially. (Port #0, port #1, port #2, and so on.)
Therefore, you need to mount your new SSD in SATA port #0 (vacated by the existing HDD), which is
the lowest-numbered SATA port.
07
Checking
the Product
05
SSD Self-Install Photo Guide
for desktop computers
06
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
07
Insert the SSD, fitted with the bracket, into the location
of the original HDD. (usually SATA port #0), and secure it in place.
Checking
the Product
06
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
07
Connect the cables that have been disconnected
from the existing HDD to your new SSD.
08
Checking
the Product
06
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
07
Connect the cables that have been disconnected
from the existing HDD to your new SSD.
08
Checking
the Product
07
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
08
Connect the existing HDD to the port with
the next lowest number.
For example, if the SSD is connected to port #0, then connect the HDD to port #1.
09
Checking
the Product
07
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
08
Connect the existing HDD to the port with
the next lowest number.
For example, if the SSD is connected to port #0, then connect the HDD to port #1.
09
Checking
the Product
08
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
09
Connect the SATA cable and the power cable to
the reinstalled HDD.
10
Checking
the Product
08
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
09
Connect the SATA cable and the power cable to
the reinstalled HDD.
10
Checking
the Product
09
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
10
Reattach the side covers to the computer.
11
Checking
the Product
10
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
11
Turn on the computer, and install Windows.
12
Checking
the Product
11
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
12
13
Reboot the computer, and immediately enter BIOS setup.
Entering the BIOS setup may be done differently depending on mainboard and/or computer manufacturer.
Usually, you can enter BIOS setup by pressing the Delete key or the F2 key before the boot sequence proceeds to Windows.
Checking
the Product
12
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
13
Change IDE mode to AHCI mode.
* AHCI mode is usually found under advanced options.
* Some mainboards may not support AHCI.
(In this case you should obtain a separate driver from the manufacturer of the mainboard
or the OS to maximize the performance of the SSD.)
* Once installation is completed, install necessary drivers.
14
Checking
the Product
13
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
14
Install the Magician program using the CD provided.
* Run the CD located in the black document pouch,
then click the setup file in the Magician Software folder to install the program
* You can also download the program and the guide at www.samsung.com/samsungssd
15
Checking
the Product
14
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
15
You can also download the program at the official
Samsung SSD homepage.
You can also download the program and the guide at www.samsung.com/samsungssd
(SSD firmware, Magician software, Samsung Data Migration software)
16
Checking
the Product
15
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
16
After running the Magician program, verify that
the SSD has been detected correctly.
17
Checking
the Product
16
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
17
Check the AHCI mode and SATA interface settings.
* If AHCI mode is enabled and the SSD is connected to SATA 3 as shown in the photo,
run OS Optimization setup (in the left menu).
* The SSD performs optimally when using AHCI mode and SATA 3.
18
Checking
the Product
17
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
18
If you are using SATA 2,
check whether your mainboard supports SATA 3.
* If SATA 3 is supported, turn off your computer and connect the SSD using SATA 3.
* If SATA 3 is not supported, proceed to the next step.
For more information, please contact the manufacturer of your mainboard.
19
Checking
the Product
18
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
19
After setup has completed, check OS optimization.
* Run performance benchmark and performance optimization from the left menu to ensure optimal performance.
* For more information, please refer to ‘Help’, located at the lower right corner.
20
Checking
the Product
19
SSD Self-Install Photo Guide
for desktop computers
Installing
the Program
Data
Migration
Mounting
the SSD
Checking
SSD Mounting
20
Place the SSD sticker in a prominent location.
* The installation and optimization of the SSD is now complete.
Thank you.
© 2013 Samsung Electronics Co.

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
