CCTV
Cameras
ICE Indoor Color Camera
Digital Watchdog Box Camera Series
DD-ICECM3HLN
• Economical 480 TVL color camera DD-ICEM3HLN
• Economical 540 TVL color camera DD-ICEM3ULN
• Low light color for indoor use
• 1/3" Sony Super HAD CCD
• State of the art digital signal processor & optical filters
• Accepts C or CS lenses
• Compatible with all auto iris lenses
• Durable zintec casing & cast zinc lens mount
6K-C Series
• 1/3” Sony Super HAD CCD (C233W/C232D/C232T)
• CMOS Sensor/PIXIM CHIP (C235T)
• Electronic Day and Night Mode (C233W/C232D)
• True Day and Night/IR Cut Filter (C235T/C232T)
• AGC, AWB (All Box Camera Models); BLC
(C233W/C232D/C232T)
• Available with PIXIM Technology
• 5 Year Warranty
UltraView Wide Dynamic Range Camera
DigiaCam Cost-Effective Camera
KA-KTCXP3
• Next generation Xposure technology
• 540 horizontal lines of resolution
• Improves on original UltraView low-light performance
& color balance
• Continuous real time optimization
• Dynamic range of 95dB (typical) 120dB (max)
• Optional progressive scan input
• Preset modes for different situations
• Uses less power
KA-KTCDG1
• High resolution of 480 color TVL
• Digital signal processing
• Lightweight, compact size
• 12 VDC/24 VAC
• Accepts auto iris lenses
L-Series 1/3" Color Cameras
L-Series 1/3" Monochrome Cameras
HCC334L
• 330 TVL with 50 dB S/N ratio
• 0.20 lux @ F1.2
HCC484L
• 480 TVL with 50 dB S/N ratio
• 0.40 lux @ F1.2
HCM384L
• Standard resolution
• 380 TVL with 50 dB S/N ratio, 0.05 lux @ F1.2
HCM574L
• High resolution
• 570 TVL resolution with 50 dB S/N ratio,
0.07 lux @ F1.2
•
•
•
•
BLC & AES (1/60 to 100,000 seconds)
Auto White Balance
Compatible with DD or video type Auto Iris lenses
SPS 12 VDC/24 VAC with Line Lock
• BLC & AES (1/60 to 100,000 seconds)
• Compatible with DD or video type Auto Iris lenses
• SPS 12 VDC/24 VAC with Line Lock
Hi-Resolution Color Camera with
RS485 UTP
Hi-Res Ultra Wide Dynamic Color Camera
HCU484
• Great solution for ATMs, lobbies, and warehouses where
you have high contrast and changing light conditions
• 32-bit digital processing
• 480 TVL, 0.4 lux @ F1.2
• Dynamic range: 102 dB typical/120 dB max
• OSD menu/wide dynamic preset/RS-485 control using
keyboard
• DC & manual iris lens support
• SPS 12 VDC/24 VAC with/Line Lock
HCC484TP
• 480 TV lines resolution
• Ultra low light: 0.001 lux
• Powerful backlight compensation using Black Mask BLC
• OSD menu control
• Coax & UTP output for large scale system integration
• Remote control through RS485
HCBWD Series Ultra Compact Wide Dynamic Camera
HCBWDHR37
• Includes 3.7 mm semi-pinhole lens
HCBWDHR43
• Includes 4.3 mm semi-pinhole lens
HCBWDHR00
• Used with fixed lens*
HCBWDHRVF
• Used with vari-focal lens*
HCBWDHR30
• Includes 3.0 mm semi-pinhole lens
• A wide dynamic solution for high-contrast indoor environments
where extreme backlighting makes detailed images hard to get
• 480 TVL captures clear color video
• Low-light sensitivity to 0.70 lux provides superior image quality
• Available in wide range of lenses:
* 2.9 ~ 12mm fixed lens (sold separately)
* 2.6 ~ 6, 4 ~ 9 or 9 ~ 22 mm Vari-focal Auto Iris lens (sold separately)
• Ultra compact size for discreet applications & installation in very small areas
• Mounts easily in ATMs, lobbies & warehouses
• Low cost solution
SnapPak Kits - Pre-assembled Camera Housing
• Outdoor camera installations are a snap with SnapPak. Convenient pre-assembled package with camera, back-focused lens,
housing (HHC12WM2 IP66 Environmental housing with sunshield, heater/blower) and mounting hardware - all you have to do is choose the camera you want.
HKHCD48D271
• Includes HCD484L Hi Res True Day/Night Color Camera,
HLD27V13DNL (2.7 - 13.5 mm, F1.3 DC Iris Lens)
HKHCD48D550
• Includes HCD484L Hi Res True Day/Night Color Camera,
HLD5V50DNL (5 - 50 mm, F1.6 DC Iris Lens)
HKHCC33D288
• Includes HCC334L Standard Resolution Color Camera,
HLD28V8F95L (2.8 - 8 mm, F0.95 DC Iris Lens)
120
HKHCC48D288
• Includes HCC484L Color Camera, 480 TVL,
HLD28V8F95L (2.8 - 8 mm, F0.95 DC Iris Lens)
HKHCS47D550
• Includes HCCM474M Color/Black and White Camera,
HLD5V50F13L (5 - 50 mm, F1.3 DC Iris Lens)
HKHCC48D550
• Includes HCC484L Color Camera,
HLD5V50F13L (5 - 50 mm, F1.3 DC Iris Lens)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Cameras
1/3" Super Cube Color Camera
IK-ISDA10
• The IK-ISDA10 realizes wide range of backlight
compensation with 95dB typical/120dB maximum
• It has capability to see a high contrast subject in a
natural state even in scenes of wide range illuminance
• Winner of SSI TOP #30
• 480 TVL horizontal resolution
• CS mount
• AC24V/DC12V
• 5 year warranty registering online
IK-ICD505
• 520 TV line resolution
• Minimum illumination 0.15 lux at f1.2
• Digital Day/Night operation (ACK)
• Back Light Compensation
• Automatic Electronic Shutter
• Automatic White Balance
• CS mount
• AC 24V/DC12V
• 10 year warranty, resister online
1/3" Color Camera
1/3" Color Camera
JV-TKC920BU
• 1/3" high res IT CCD with 380,000 effective pixels
• 550 TV lines of horizontal resolution
• Super LoLux™ sensitivity: 7.0 lux F1.2 (color mode), 0.48
lux F1.2 (B&W mode)
• Easy day/night function
• S/N ratio 50 dB (AGC off)
JV-TKC750U
• 1/3" IT CCD with 250,000 effective pixels
• 330 TV lines of horizontal resolution
• Minimum illumination: 0.28 lux F1.2
• Auto tracking white balance (ATW) and one touch auto
white balance (AWB)
Standard Camera
1/3" Color High Resolution Camera
RA-ECL54D
• 1/3" color CCD
• 540 lines resolution
• High sensitivity
• Electronic iris
• 12VDC/24VAC
• 3 year warranty
OG-SCCB1311
• 1/3" IT Super HAD CCD
• 540 TV Lines of Resolution
• Minimum Scene Illumination: 0.12 LUX @15 IRE, F1.2
• DC Auto Iris Lens
• Dynamic Defect Compensation
• Back Light Compensation
• ATW/AWC
• Dual Voltage: AC24V/DC12V (60Hz)
• DSP (Digital Signal Processing)
• Built-In Grand Fault isolation transformer
1/3" B/W Cameras
1/4" DSP High Performance Color Camera
SY-VCB3384
• 570 TV lines of resolution
• High sensitivity - 0.07 lux @ F1.2
• Internal/External Sync, line lock
SY-VCC3944
• More than 350 TV lines of resolution
• Minimum illumination 0.3 lux (high gain, F1.2)
• Built-in DSP circuitry
• Two types of backlight compensation
• Electronic Iris
• Internal or line lock sync
• 12 VDC/24 VAC dual power operation
• 3 year warranty
SY-VCB3454
• 400 TV lines of resolution
• High Sensitivity 0.05 lux @ F1.2
• 24VAC/12VDC dual power operation
Super High Resolution
Color Casino Camera
Super High Resolution/Sensitivity
Color Camera
SY-VCC5884E
• Super high resolution of more than 540 lines
• High sensitivity-minimum illumination of 1.0 lux
• Automatic Gain Control (on/off)
• Electronic Iris function
• Center zone backlight compensation
• Unique Compact Design - fits in 5" domes
• 12VDC/24 VAC dual power operation
• 3 year warranty
SY-VCC6594E
• More than 540 TV lines of resolution
• 0.3 lux @ F1.2 minimum illumination
• EXview™ CCD Technology
• DC & Video Auto Iris Lens Compatibility
• Smart multi-zone weighted backlight compensation
• Built-in DSP circuitry
• 3 year warranty
1/2" Exwave Color Camera
1/3" SuperHAD CCD Color Camera, Stand. Res.
SH-SSCDC80
SH-SSCDC83
• 1/2"-type CCD with Exwave HAD technology
• Horizontal resolution - 480 TV lines
• High sensitivity - 0.4 lux (F1.2, 50IRE)
• AGC: Turbo/Normal/Manual/Off switchable
• White balance;
ATW Pro/ATW/3200K/5600K/Manual switchable
• Four selectable gamma curves
• Accepts video or DC auto iris lenses
• CS mount
SH-SSCDC174
• 1/3"-type CCD with Super HAD technology
• Horizontal resolution - 330 lines
• High sensitivity - 0.8 lux (F1.2, 50IRE)
• CCD IRIS function allows the use of low cost manual iris lenses
• Backlight compensation: ON/OFF switchable
• AGC: TURBO/OFF switchable • Accepts DV auto iris lenses
• Wide range CCD IRIS function
(ON/OFF switchable, 1/60 to 1/1000,000’s)
• Wide range Auto Tracing White balance (ATW)
• CS mount • AC24V operation
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
CCTV
1/3" DPS Hyper Dynamic Color Camera
121
Cameras - Special Application Cameras - Bullet Cameras
1/3" SuperHAD
High Resolution Color Camera
CCTV
SH-SSCDC374
• 1/3"-type CCD SuperHAD
• Horizontal resolution - 480 TV lines
• High sensitivity - 0.8 lux (F1.2, 50IRE)
• CCD IRIS function allows for low cost manual iris lenses
• Backlight compensation: ON/OFF switchable
• AGC: TURBO/OFF switchable
• Wide range Auto Tracing White balance (ATW)
• Accepts DC auto iris lenses
• CS mount • AC 24V operation
SH-SSCE453
• 1/3"-type CCD with SuperExwave technology
• Advanced Digital Signal Processing (DSP) technology provides high-horizontal resolution of 540 TV lines
• High sensitivity - 0.55 lux (F1.2, 50IRE)
• CCD IRIS function allows for low cost manual iris lenses
1/60 to 1/100,000s
• Backlight compensation: ON/OFF switchable
• Selectable Auto White balance mode: ATW/ATW Pro
• DC Servo lens connection capability
• AC 24V or DC 12V operation • CS mount
Traditional Box Camera for C&CS Lenses
Wide Dynamic Range Color Camera
SO-HTINTT5
• 1/3" Sony ExView CCD
• 540 lines Super High resolution
• Intensifier amplifies and maximizes existing light to
generate pictures where other cameras can’t
• See color in the dark without IR LEDs
• 5 year warranty
TB-IK65WDA
• 520 lines of horizontal resolution
• 0.001 Lux minimum illumination
• RS-422 remote set-up from DVR
• Digital noise reduction with 53 dB signal to noise ratio
• Easy set-up: programming via menu or dip switch
• The ultimate camera for extreme lighting conditions
• Lens not included
Digital CCD Lowlight Color Camera
C1OCH Series Ultra High Resolution Camera
PE-CC3751H2
• LowLightTM Technology
• Compact Body Style
• 1/3” Format CCD Imager
• 24 VAC/12 VDC Power
• Line Lock with Phase Adjustment
• Backlight Compensation
• Horizontal Resolution of 480 TV Lines
• For Use with Direct Drive and Auto Iris Lenses or
Fixed/Manual Iris Lenses
• Removable Top/Bottom Mount
PE-C10CH
• Compact Body Style
• 1/3” Format CCD Imager
• 540 TV Lines
• 0.4 Lux Sensitivity
• Autosensing DC/Video Drive Auto Iris
• White Balance Settings for Difficult Lighting Situations
• Automatic Gain Control, Electronic Shutter Control, and
Backlight Compensation
• Flickerless mode • Eclipser Function
• Autosensing power • Internal top/bottom mount
Esprit Series Integrated Position System
1/3" CMOS Advanced WDR Camera
PE-30125MGZ2
• Integrated receiver, Pan/Tilt, and housing with no
exposed cabling
• Variable Speed - Advanced Motor Control Technology
• 360° continuous pan rotation • Zone Blanking
• Operational in 90 mph wind conditions;
can withstand wind velocity up to 130 mph
• Pan preset speed of 100° per second in 50 mph winds
and 50° per second in 90 mph winds
• Tilt range of +33° to -83° from horizontal
• Optional ImagePak® Integrated Optics Package
SY-VCCW8774
• Progressive scan 1/3" CMOS with RGB filter
• Super High Resolution of 550 TV Lines
• Advanced wide dynamic range technology
• High sensitivity - minimum illumination of 0.8 lux
• Built-in Digital Noise Reduction
• Electronic Iris • 12VDC/24VAC dual power operation
• Electronic Shutter 1/60 to 1/10,000
• Internal Sync/Line Lock
5.8GHz Wireless All-Weather IR Camera
IR Color Vandal Proof Bullet Camera
OK-MXR5847VF
• 5.8GHz real-time wireless video up to 1,000' LOS
• High-resolution 470 line color CCD with 4mm ~ 9.0mm
varifocal lens
• 8 User selectable channels for multiple camera
scenarios
• Not susceptible to interference from 2.4GHz 802.11 b/g
networks
• Extremely low current consumption
B7-CV7760D
• 1/3" Sony SuperHAD CCD
• 480TVL Resolution
• 4 - 9mm Auto Iris Varifocal Lens
• External lens adjustment
• Power/Video Cable Protected through Mounting Arm
• 12VDC/24VAC
Weather-Proof IR Bullet Camera
Digital Watchdog Bullet Camera Series
B7-CV7817D
• 380 TVL
B7-CV7827D
• 480 TVL
6K-B Series
• 1/3” Sony Super HAD CCD (6K-B1362TIR3312/
6K-B1362TIR650/6K-B1363D6K-/6K-B1363TIR/
6K-B2372TIR)
• CMOS Sensor/PIXIM CHIP (6K-B1365T)
• 1/3” Samsung CCD (6K-B3252IR)
• 3.3 ~ 12mm Varifocal Auto Iris Lens (6K-B1362TIR3312/
6K-B1365T/6K-B1363TIR/6K-B1363D)
• 6 ~ 50mm Varifocal Auto Iris Lens (6K-B1362TIR650)
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
(6K-B1372TIR/6K-B2373D/6K-B2382TIR)
• 3.6mm Fixed Lens (6K-B3252IR)
•
•
•
•
•
•
122
1/3" SuperExwave HAD Color Video Camera
1/3” Sony Super HAD CCD
Built-in 4.3mm/F1.8 Lens
Weather Proof: IP66
Radiation Distance: 75’
DC12V
Accessory: Sunshade and Bracket
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Bullet Cameras
Weatherproof Mini IR
Indoor/Outdoor Bullet Cameras
Outdoor Long Range IR Bullet Camera
F8-EZ330E
• Available in 6mm or 8mm lens, IP distance up to 98ft.
F8-EZ335E
• Available in 8mm or 16mm lens, IR distance up to 164’
* 520 TVL
* Cable Management Solution with built in heater
•
•
•
•
F8-ECZ230N4
• 4mm lens, 380 TVL
F8-ECZ230N6
• 6mm lens, 380 TVL
F8-ECZ230N8
• 8mm Lens, 380 TVL
F8-ECZ330N4
• 4mm Lens, 480 TVL
Up to 64’ of IR range
Low light sesitivity of 0.4 lux
Up to 20,000 hours of LED lifespan
Built-in heater, IP66 rated, tamper and vandal resistant
• 1/3" Interline Transfer CCD, 12VDC
• 0.3 lux standard, 0.0 lux with IRs • 45' Viewing Distance
True Day/Night Weatherproof IR Bullet
Indoor/Outdoor High Resolution
IR Bullet Camera
KA-TVCBIRHR
• 530 TVL
• 55M IR Range (40 IR LEDs)
• 6~50mm Vari Focal Lens
• AC24V/DC12V
Indoor/Outdoor Medium Resolution
IR Bullet Camera
Indoor/Outdoor Standard Resolution
IR Bullet Camera
KA-TVCBIRMR
• 480 TVL
• 25M IR Range (20 IR LEDs)
• 3.5~12mm Vari Focal Lens
• AC24V/DC12V
KA-TVCBIRSR
• 380 TVL
• 15M IR Range (18 IR LEDs)
• 4.3mm Fixed Lens
• DC12V
Day/Night Color Bullet Camera
V100 Bullet Resistant Camera
2H-68A021
• High Resolution
• 36 IR LEDs
• On Screen Display menu
• Service Monitor Output
XS-V10103
• Withstands assault of a 12 gauge shotgun
or a 9mm handgun
• Enclosure is made from machined marine grade
aluminum
• Color or B/W, standard or hi-res
• Stainless steel U-bracket for added durability
• QUICK CHANGE LENS options: 2.9 -16.0 mm
CCTV
F8-EZ550
• Built-in motorized lens controller for 6~50mm lens
(zoom & focus)
• True Day/Night with IR cut filter
• Super low light 0.002 lux/F=1.2 (SENS-UP 128x)
• Cable wires are secured inside camera housing &
bracket to eliminate messy wiring and intentional wire
damage
• Up to 164’ of IR distance
• 42 powerful high illuminating LEDs
• RS-485 control
• Weatherproof IP66 rated
Super Hi-Res IR Bullet Camera
HCD92534
• Discreet, bullet-style camera with switchable IR cut filter
and 49IR LEDs
• 2.8-10mm, F1.3 Varifocal Auto Iris IR corrected lens with
external adjustments for zoom and focus
• High Resolution Color: 530 TVL 1/3" Sony Super HAD
CCD
• DNR Technology for noise free images
• External access to OSD, zoom and focus
• Four position day/night threshold setting
• IP66 weather rated
NTC Reference Books
Keep You Informed!
Count on the National Training Center
(NTC) for certification, knowledge and
current technology.
NTC Reference Books keep you ahead of
the game!
Performance Series IR Bullet Cameras
Standard Resolution IR Bullet Cameras
HB70
• 1/3" Sony Super HAD CCD
• Day/Night
• 380 TVL
• Fixed lens: 4.3mm
• 12VDC
• Weather resistant
• 12 IR LED’s
• 50' IR range
HB71
• 1/3” Sony Super HAD CCD
• Day/Night
• 380 TVL
• Fixed lens: 6.0mm
• 12VDC
• Weather resistant
• 34 IR LED’s
• 95' IR range
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
123
Bullet Cameras
Performance Series IR Bullet Cameras
Super Hi-Resolution Bullet Cameras
HB72
• 1/3" Sony Super HAD CCD
• Day/Night
• 530 TVL
• Fixed lens: 4.3mm
• 12VDC
• Weather resistant
• 12 IR LED’s
• 50' IR range
• Super High Resolution IR Bullet Camera
HB73
• 1/3" Sony Super HAD CCD
• True Day/Night
• 550 TVL
• Digital Noise Reduction (DNR)
• Varifocal lens: 3.8mm - 9.5mm
• 12VDC
• Weather resistant
• 20 IR LED’s
• 65' IR range
IS210 Wedge/IS310 Bullet Camclosure
CCTV
PE-IS310 SERIES
PE-IS210 SERIES
PE-IS210 Series
PE-IS310 Series
• Fully-Integrated Enclosure with Camera and Lens
• 4 Camera Options:
* Day/Night Wide Dynamic Range (WDR); PixelBased Images for Accurate Color
Representation, Progressive Scan
* Day/Night High Resolution: 540 TVL
* Wide Dynamic Range (WDR); Pixel-Based Images
for Accurate Color Representation, Progressive
Scan
* High Resolution Color: 540 TVL
Standard Bullet Camera
IR Bullet Camera
RA-BC70W
• 1/3" Sony Super HAD CCD
• 540 TV lines, 0.1 lux
• 70° Field of view (3.6mm lens)
• Weatherproof housing (IP66)
• Includes 12VDC plug-in power supply
• 3 year warranty
RA-BC70WIR
• 1/3" Color Sony Super HAD CCD
• 540 lines, 50-foot range
• Weatherproof
• 70° field of view (3.6mm lens)
• 12VDC, 3 year warranty
Vari-Focal Bullet Camera
Vari-Focal Bullet Camera with IR
RA-BCVF4W
• 1/3" Color Bullet Camera
• 560 TV lines
• 4 ~ 9mm lens
• Weatherproof housing (IP66)
• Includes 12VDC plug-in power supply
• 3 year warranty
RA-BCVF4WDIR
• 1/3" Color Bullet Camera
• 560 TV lines
• 4 ~ 9mm lens
• 50' range
• Weatherproof housing (IP66)
• Includes 12VDC plug-in power supply
• 3 year warranty
Day/Night Vari-Focal Bullet Camera
1/3” High Res,Day/Night,Bullet IR Camera
RA-BCVFHQ4W
• 1/3" Color Bullet Camera
• 580 TV lines
• 4 ~ 9mm lens
• Weatherproof housing with removable hood (IP66)
• Includes 12VDC plug-in power supply swivel mount
• 3 year warranty
OG-GVBCC825
• 1/3” Super HAD CCD
• 520TV Lines Resolution
• Minimum Scene Illumination: 0.15 Lux @ 15IRE (F1.2)
• 4mm Lens
• Day/Night IR Pass Filter
• 24 Integral 850nm IR LEDs with CDS Sensor
• Auto Gain Control (AGC)
• Backlight Compensation (BLC)
• 49’ range effective with IR illumination under optimal
conditions
Color Day/Night IR Camera
Color Day/Night IR Camera
SL-1323C12DQ
• 1/3" Sony Color CCD, 4.3mm
SL-132CDW2
• 1/3" Sony Color CCD, 2.9mm
SL-1323B12DW
• 1/3" B/W, 4.3mm
SL-132CDWL6Q
• Color Day/Night IR Camera with up to 80' Range
• 6.0mm lens
SL-132CDWL8
• 8.0mm lens
SL-132CDWLD
• 12.0mm lens
SL-132CDWLH
• 16.0mm lens
•
•
•
•
124
• Varifocal Lens Options: 3mm to 9.5mm, 9mm to 22mm
• Includes Composite and Unshielded Twisted Pair (UTP)
Outputs
• Rugged, High-Impact, Vandal-Resistant,
Tamper-Resistant Hardware
• Service Connector for Video Output
• Thermostatically Controlled Heater
• 12 VDC or 24 VAC Operation, Autosensing
• Microporous Membrane Vent for Enhanced Ingress
Protection
420 TV lines
12 LEDs, 40' range
IP 68 weatherproof
Optional IR illuminator now available
(model SL-VIB10035BQ)
• 24 LEDs, Sony Color CCD
• IP 68 weatherproof
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Bullet Cameras
ELITE Cameras
B/W Weatherproof Bullet Camera
SL-EV133CDWB
• 5 ~ 50mm lens, 15 Hi-Intensity IR LEDs 200' Range
SL-EV133CDWA
• 4 ~ 9mm lens, 56 IR LEDs 100' Range
SO-CVC130R
• 1/3" B/W CCD
• Resolution 420 lines
• .02 Lux
• 3.6mm lens
• Regulated 12VDC power supply (UL) included
• 5 year warranty
•
•
•
•
•
550 TV lines for high resolution
Split-glass design to eliminate IR reflection
Wiring concealed in bracket to prevent tampering
Weatherproof IP66 for outdoor use
Dual voltage: 12VDC or 24VAC
H.E.A.T. Color Weatherproof Day/Night
Dual Voltage Bullet Camera
SO-CVC320WP
• 1/3" B/W CCD
• Resolution 420 lines - 0 Lux (LEDs on)
• 3.6mm lens
• 8 IR LEDs/CDS sensor
• Nitrogen filled • 100% waterproof
• Regulated 12VDC power supply (UL) included
• Also available in white/3' cable: SO-CVC320WPW
• Also available w/10 LEDs/60' cable: SO-CVC32WP
• 5 year warranty
SO-CVC550EX
• 1/3" color EXview image sensor
• High resolution: 480 lines
• 0.03 lux
• DC auto-iris 5-50mm lens
• 24VAC/12VDC dual voltage
• Cable through the mount
• 5 year warranty
Color Hi-Res Weatherproof Camera
Color Weatherproof Bullet Camera
with 2.9mm Lens & Sunshield
SO-CVC627
• 1/4" Color CCD day/night • 420 line resolution
• 0.1 Lux (LEDs off), 0.00 Lux (LEDs on)
• Switches to B/W in low light • 3.6mm Lens
• 20 IR LEDs controlled by CDS sensor - 45' range
• Can withstand full immersion in water to 60'
(60' cable included)
• 12VDC regulated power supply included
(UL/CSA approved)
• Also available in black (SO-CVC627B) and
white (SO-CVC627W) casing with 5' cable
• 5 year warranty
SO-CVC635N
• 1/4" color CCD
• Resolution 420 lines
• 1.0 Lux
• 2.9mm lens
• Regulated 12VDC power supply (UL) included
• Also available in B/W with mount: SO-VL128RS
• 5 year warranty
Control Series Bullet Camera with IR LEDs
Color Weatherproof Camera
SO-CVC627SCS
• Full control of major camera functions
• 540 lines of resolution
• Split glass technology
• Shutter type: manual, fixed, flickerless or auto
• Day/Night: auto, color or B/W
• BLC-adjustable sensing area or 100 points on the
screen
SO-CVC6705
• 1/4" color CCD
• 420 lines resolution • 1.0 lux sensitivity
• Miniature bullet with vari-focal lens
• 4-9mm vari-focal lens
• Fine tuning of camera coverage
• Regulated 12VDC power supply (UL & CSA listed) incl.
• Also available: Color 2.9mm lens - SO-CVC6700
• Also available: B/W 3.6mm lens - SO-CVC1700
• Also available: B/W 4-9mm lens - SO-CVC1705
• 5 year warranty
Speco Control Series Bullet Camera
with 6mm Lens
Weatherproof Day/Night Bullet Camera
SO-CVC6700SCS
• Full control of major camera functions
• 540 lines of resolution
• Shutter type: manual, fixed, flickerless or auto
• Day/Night: auto, color or B/W
• BLC-adjustable sensing area or 100 points on the
screen
• Also availlable in 4-9mm varifocal lens:
SO-CVC6705SCS
H.E.A.T. Color Weatherproof Bullet Camera
with Auto Iris Vari-focal Lens
SO-CVC870EX
• 1/3" Super-HAD CCD image sensor
• Resolution 470 lines
• 4-9mm auto iris vari-focal lens
• Turbo AGC (Automatic Gain Control)
• Cable through the mount
• Includes regulated 12VDC power supply (UL listed)
• 5 year warranty
CCTV
B/W Waterproof Camera
with 8 IR LEDs & 60 ft. Cable
SO-CVC7706DN
• 1/3" color EXview image sensor
• Ultra-high 480 line resolution with Advanced Technology
• Built-in IR LEDs;
0 lux with operating LEDs, 0.03 with existing light
• Color with IR LEDs • 4-9mm DC auto-iris lens
• 24VAC/12VDC • 24VAC line lock/adjustable phase
• Mechanical IR cut filter & coated front glass for no
IR glare
• Built-in heaters & IR LEDs
• 5 year warranty
Intensifier Series Color Bullet Camera
SO-HTINTB8
• 560 lines of resolution
• 2.8 to 12mm auto iris vari-focal lens • Weatherproof
• Wider zoom range to fit more applications
• Full OSD operation • SLC - Speco Light Compensation
• S/N ratio >50dB (weight on)
• EZ mount system simplifies operation
• RoHS compliant • See color at night
• Also available: SO-HTINTB9 50mm auto iris lens
SO-HTINTB10 9-22mm auto iris lens
• 5 year warranty
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
125
Bullet Cameras
SO-HTB10X
• 1/4" Sony Super-HAD* CAD
• 580 lines IR on, 560 line IR off
• 10X optical motorized zoom + 10X digital
• 3.8 ~ 38mm auto iris motorized lens
• On screen display
• 5 year warranty
SO-HT7816DN
• True Day/Night Camera
• 1/3" Sony Super-HAD* CAD
• 600 lines IR on, 550 line IR off
• 3.8 ~ 9.5mm auto iris motorized lens
• On screen display
• 5 year warranty
SO-HTB10X
SO-HT7816DN
Intensifier Series Bullet Cameras
Intensifier Series Bullet Camera
SO-HTINTB1
• 3-9mm lens
SO-HTINTB2
• 5-50mm lens
SO-HTB11FFIN
• Camera features focus free technology, which means no
more trips back to the installation site
• 3.5 to 10mm FOCUS FREE Auto Iris Motorized Zoom Lens
• 540 Lines
• Wall & Ceiling Mount
• Weatherproof
• 5 Year warranty
• Also available in a dome version, SO-HT7248FFI
•
•
•
•
•
Intensifier bullet camera auto iris day/night lens
540 lines
See fuller color in the dark without IR LEDS!
5 Year Warranty
IR remote control included
H.E.A.T. Color Weatherproof Day/Night
Bullet Camera w/IR, Auto Iris DC Vari-focal Lens
H.E.A.T. Color Weatherproof Day/Night
Bullet Camera with IR, External Controls
SO-HT7715DN
• 1/3" SONY ExView CCD sensor
• High resolution: 480 lines • Dual voltage operation
• LUX level dip switch adjusts day/night settings to your req.
• Split Glass Technology to avoid IR reflections
• Auto iris DC vari-focal lens (4mm - 9mm )
• Built-in IR LEDs & CDS sensor for day/night performance
- 60' IR range
• Also available in white version: SO-HT7715DNW
• 5 year warranty
SO-HT7815DN
• 1/3" SONY ExView CCD sensor • High res.: 480 lines
• Built-in IR LEDs & CDS sensor for day/night performance
- 100' IR range
• Split Glass Technology to avoid IR reflections
• Auto iris DC vari-focal lens (3mm - 9mm)
• LUX level dip switch adjusts day/night settings to your req.
• Dual voltage operation • Controls on outside of camera
• Built-in heater • See color at night
• 5 year warranty
1/3" Weatherproof Color CCD IR Camera
Economy Color Waterproof Camera
with Built-in IR LEDs & Sunshield
SO-VL11
• 1/3" interline transfer CCD
• 420 lines resolution
• 0.5 lux color (LED off), 0 lux (LED on) • Lens 4.3mm
• Economical, weatherproof color CCD IR bullet camera
• Features a Digital Signal Processor (D.S.P.)
• IR Range 60' (depending on scene reflection)
• Video S/N Ratio greater than 50dB
• Wall/ceiling mount is incluled
• 12VDC power supply required
• 5 year warranty
Weatherproof Color DSP Bullet Camera with
Vari-focal Lens and IR LEDs/Metal Housing
SO-VL67
• 4-9mm auto iris vari-focal lens is suitable for most
installations
• Color by day, B/W by night • Dual voltage
• Extreme weatherproof design is perfect for indoor or
outdoor use, IP-67 rated
• 50’ IR range* with CDS control for great pictures in
low light conditions (*depending on scene reflection)
• Mounting bracket incl. for wall, ceiling or pedestal use
• Available in white (SO-VL67W) • 5 year warranty
CCTV
SO-HTINB4
SO-HTINB4
• Intensifier technology, see full color in the dark without
IR LED’s!
• 1/3" Sony Super-HAD* CAD
• 580 lines IR on, 520 line IR off
• 3.8 ~ 9.5mm auto iris motorized lens
• On screen display
• 5 year warranty
SO-VL62
• 1/4" CCD image sensor
• Resolution: 420 lines
• 0 Lux with IR on/1.0 Lux with IR off - 16 IR LEDs
• 4mm lens • Auto electronic shutter
• Incl. regulated 12VDC power supply (UL listed) & mount
• Also available with 4-9mm lens: SO-VL66
• Also available in white version: SO-VL62W
• 5 year warranty
TCY Series Bullet Camera
HD-TCYH36IR
• 480 TVL, 12 VDC only, 3.6mm Fixed Lens
• 1/3” Sony CCD, 36’ Illuminated distance
• IR Illuminators twenty four (24) 850nm LED
• Electronic Shutter Up to 1/100,000 sec
• Weather resistant IR camera
• Aluminum alloy housing
• Includes Wall Mounting Bracket & Power Supply for Easy
Installation
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
127
CCTV
Bullet Cameras - Fixed Domes
128
TCY Series Bullet Camera
5.8GHz Wireless All-Weather IR Camera
HD-TCYH36F2
• 480 TVL, 3.6mm Fixed Lens
• 1/3” Sony CCD, 12 VDC only
• Electronic Shutter Up to 1/100,000 sec
• Weather Resistant Camera
• Aluminum alloy housing
• Includes Wall Mounting Bracket & Power Supply for Easy
Installation
OK-ZX520SR100
• 5.8GHz real-time wireless video up to 1,000' LOS
• Sony 520 line CCD color camera - 8mm lens
• 60 LED for Day/Night vision range up to 100’
• 8 User selectable channels for multiple camera
scenarios
• Not susceptible to interference from 2.4GHz 802.11 b/g
networks
Color Vandal Dome Camera
Full Line IR Vandal Proof Dome Camera
B7-CV7663(D)
B7-CV7663H(D)
• 1/3” SONY Super HAD CCD
• 4~9mm Vari-focal Lens
• 380 (7663/D)/480 (7663H/HD) TVL
• Vandal-Proof and Weather Proof: IP66
• Minimum Illumination: 0.5 lux/F1.2 (7663/D),
0.8 lux/F1.2 (7663H/HD)
• DC12/AC24V & DC12V (D Model only)
• Accessory: Wall Mount
B7-CV7665(H)
B7-CV7666(HR)
• 1/3” SONY Super HAD CCD
• 380/480 (H models)/520 (7666HR) TVL
• Built-in 4.3mm/F1.6 (665/665H) Lens/4~9mm
Vari-focal (666/666H/666HR) Lens
• Weather Proof: IP66
• Radiation Distance: 45~75 feet
• DC12V
• Dimension:
Ø46.5mm (665/665H) / Ø 119mm (666/666H/666HR)
Wide Dynamic Range Camera
Wide Dynamic Range Dome
DD-ICEHYPERDN
• 480 TVL, Wide Dynamic Range
• Low Light, color
• State of the art digital signal processor & optical filters
• Accepts C or CS lenses
• Dual voltage 12VDC/24VAC
• Durable zintec casing & cast zinc lens mount
DD-ICEDHYPERN
• Award Winning Hyper-D (wide dynamic range) Technology
• Zero smear
• High Resolution 480 TVL
• Integrated 3.8-9.5mm Varifocal Lens
• Extra video out for local focusing
• Color (1.0 lux)
• Dual voltage 12VDC/24VAC
540 TVL Day/Night Dome
Digital Watchdog Pixim Camera Series
DD-ICEDNU39N
• Day/night dome
• 1/3" Sony Super HAD CCD
• Ultra resolution 540 TVL
• Removable IR cut filter
• Integrated 3.8~9mm varifocal lens
• Extra video out for local focusing
6K-C235T
6K-D1365T
6K-V1365T
6K-B1365T
• CMOS Sensor/PIXIM CHIP; 540 TV Lines
• Powerful Wide Dynamic Range; Smear Canceling Circuit
• Auto Sensing 24 VAC/12VDC with Line Lock
• True Day and Night / IR Cut Filter; Ultra Low Light
Sensitivity
• 5 year warranty
• Available in Indoor Dome, Outdoor Vandal Resistant Dome,
Box Style and Weatherproof Bullet Housing Models
Digital Watchdog Omni Star-Light Camera
Series
Digital Watchdog Omni-Focus Camera
Series
6K-D2363TIR
6K-V1363TIR
6K-V3363D
6K-B1363D
6K-B1363TIR
• 1/3” Sony Super HAD CCD/DNR; 540 TV Lines
• 3.3 ~ 12mm Varifocal Auto Iris Lens; DSS, AGC, BLC,
AWB
• On-Screen Menu Programming with Built-In Joystick;
Sharpness Control
• Programmable Privacy Zone and Motion Detection
6K-V1372TIR
6K-D2372TIR
6K-B2372TIR
• 2TIR; 6K-D2372TIR; 6K-B2372TIR
• 1/3” Sony Super II HAD CCD; 540 TV Lines
• 70 Foot Range IR with Intelligent Camera Sync
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
• Programmable Privacy Zone and Motion Detection
• True Day and Night/IR Cut Filter; Ultra Low Light
Sensitivity
• Available in Indoor Dome, Outdoor Vandal Resistant Dome
Digital Watchdog Omni-Plus Camera Series
Digital Watchdog Omni-Plus Camera Series
6K-V1382TIR
6K-D2382TIR
6K-B2382TIR
• 1/3” Sony Super II HAD CCD; 540 TV Lines
• 70’Range IR with Intelligent Camera Sync
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
• Programmable Privacy Zone and Motion Detection
• True Day and Night/IR Cut Filter; Ultra Low Light
Sensitivity
• Available in Indoor Dome, Outdoor Vandal Resistant
Dome and Weatherproof Bullet Housing Models
• 5 year warranty
6K-V3373D
6K-D2373D
6K-B2373D
• 1/3” Sony Super II HAD CCD; 540 TV Lines
• 70’ Range IR with Intelligent Camera Sync
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
• Programmable Privacy Zone and Motion Detection
• True Day and Night/IR Cut Filter; Ultra Low Light
Sensitivity
• Available in Indoor Dome, Outdoor Vandal Resistant
Dome and Weatherproof Bullet Housing Models
• 5 year warranty
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Fixed Domes
Vandal/Rugged Dome Cameras
F8-EHD150E1
• Black & White, 3.5-8mm Lens
F8-EHD350H3
• Color, 560 TVL, 3.6-9.5mm Lens
F8-EHD525EX3
• Day/Night, 560 TVL, 3.8-9.5mm Lens
F8-EHD300N1
• Color, 4-9mm, NO HEATER
F8-EHD650TH1
• Day/Night, wide dynamic range, 4-9mm, heater
• Rugged dome camera can withstand a 10 lb. sledgehammer
• Built-in heater that allows for operation in low temperatures
(except F8-EHD300N1)
• It’s perfect for all high-profile crime-prone applications
building entrances, retail stores, and shopping malls
• 9 - 22mm option available on all models
• 2.9 - 10mm lens optional available on most models
DigiaDome and 2" Mini Dome Camera
F8-ED200N3B
• 380 TVL, 3.6mm Lens, 12VDC
F8-ED300N
• 480 TVL, 4-9mm A/I Lens, Dual Voltage
F8-ED350N1
• 520 TVL, 3.8-9.5 A/I Lens, Dual Voltage, 9-22mm option
F8-EFD300A
• Flush mount, 480 TVL, 4-9mm A/I Lens, Dual Voltage
F8-EPD200A
• Pendant mount mini dome, 380 TVL, 3.8-9.5mm lens,
dual voltage, (not shown)
KA-DGD1
KA-MD21500
• 2 inch mini-dome form factor for discreet,
high-resolution surveillance
• 480 TV lines color resolution for clear color images
• 12VDC input voltage
• Dome shroud conceals camera position
• Includes 12VDC and 24VAC adapter
• 3-axis gimble for easy installation; mount on ceiling or
wall and maintain level picture (KA-DGD1 only)
DM2/DR2 Dome Cameras
Indoor/Outdoor IR Dome Camera
KA-DM2
KA-DR2
• Digital signaling processing for excellent performance in
most lighting conditions
• “3-Axis Gimble” allows for optimization of the field of
view regardless of mounting location
• Heavy-duty indoor/outdoor & lightweight indoor options
• Polycarbonate dome with captive shroud for easy
installation, vandal resistance & to conceal camera
position
• On-screen display menu walks users through options
KA-TVDTIRMR
• 480 TVL
• 20M IR Range (28 IR LEDs)
• 3.5~8mm Vari Focal Lens
• DC12V
Indoor/Outdoor IR Dome Camera
Indoor/Outdoor IR Dome Camera
KA-TVDTIRSR
• 380 TVL
• 10M IR Range (14 IR LEDs)
• 4.3mm Fixed Lens
• DC 12V
KA-TVDTIRHR
• 530 TVL
• 20M IR Range (28 IR LEDs)
• 3.5~8mm Vari Focal Lens:
• DC12V
Indoor Dome Camera
2" Monochrome & Color
Fixed Dome Camera
2H-68A011
• High resolution
• On Screen Display menu
• Service Monitor Output
• Flush Mount and Surface Mount Kits included
CCTV
Indoor Mini Color Domes
HD2FM1
• Standard resolution B/W camera
• 380 TVL, 0.8 lux @ F2.0, 1/3" CCD
• 3.8 mm and 8 mm lens
HD2FC1
• Standard resolution color camera
• 330 TVL, 3.2 lux @ F2.0, 1/4" CCD
• Includes 3mm and 6mm lens
• 360° rotation/90° tilt adjustment
• 12VDC power input • Polarity reversal protection
PrimaView® HD16 Series Dome Camera
HD16CD480
HD16CDW480
• Vandal resistant, indoor/outdoor, lightweight
polycarbonate housing
• 5 - 50mm vari-focal auto iris lens
• Converts between surface & flush mount instantly
• Wide range of cameras, including True Day/Night and
Wide Dynamic
• 480 TVL, 1.0 lux
3" Standard Resolution
Monochrome Dome Camera
HD3VM4A
• 1/3" CCD
• 380 TVL - 0.5 lux @ F2.0
• Includes 4 - 9 mm vari-focal auto iris lens
• 360° rotation/90° tilt adjustment
• 12VDC or 24VAC power input
• Polarity reversal protection
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
129
Fixed Domes
True Day/Night Color
Super High-Res Dome Camera
High Resolution Vandal Proof Dome
HD4VC4HR
• Crisp, clear picture, 530 TVL resolution
• Widest range lens: 3.3 - 12mm
• 3-D axis gimbal
• Dual voltage
• Pre-assembled, all in one box
• Local video output for setup
CCTV
HD4D
• True Day/Night with mechanical IR cut filter for best
images, both day and night
• Super high-resolution color, 540 TVL
• Rugged dome housing is vandal resistant & weather tight (IP66)
• Digital Noise Reduction technology for noise free images
• On-Screen Display menu for easy setup
• Privacy Image Masking - 4 programmable zones
• Integrated 3.3 - 12mm (F1.5) VFAI lens, IR corrected
• Local video output for setup • Dual 12VDC/24VAC voltage
True Day/Night IR Fixed Camera
Ultra Wide Dynamic TDN Fixed Dome
HD4DIR
• True Day/Night with mechanical IR cut filter for best
images, both day and night
• Ultra high resolution color, 540 TVL
• 18 IR LEDs for illuminating the scene up to 65' (20m)
• 3.3 -12mm F1.5 IR corrected aspherical Vari-focal lens
• Digital Noise Reduction technology for noise free images
• Digital Slow Shutter
• On-Screen Display menu for easy setup
• Local video output for setup
HD4U
• 1/3" Ultra Wide Dynamic DPS imager
• 540 TVL
• True Day/Night
• Vari-focal 3.3 ~ 12mm
• 3-D Axis Gimbal
• Dual 12VDC/25VAC voltage
• IP66 weather rated
• Vandal resistant
3" Color Dome Cameras
HD3D
• Super High Resolution – 540 TVL
• True Day/Night
• 0.4 lux @ F1.3 (with AGC on, 50 IRE), 0.0 lux @ F1.3
(with external IR illumination)
• 2.8 – 10mm (F1.3) IR Corrected Aspherical Vari-focal
Auto Iris Lens
HD3CH
• Super High Resolution – 540 TVL
• 0.6 lux @ F1.3 (with AGC on, 50 IRE)
• 2.8 – 10mm (F1.3) Aspherical Vari-focal Auto Iris Lens
HD3C
• Standard Resolution – 350 TVL
• 2.8 – 10mm (F1.3) Aspherical Vari-focal Auto Iris Lens
• Additional Features (all models)
* Single model for surface mount and recessed ceiling applications
* Tamper resistant dome offers secure installation
* Polycarbonate housing and dome
* Easy to use “cable management” housing design
* Available in Off White or Black
* Pendant and wall mount kit available
3" Color Dome Cameras - Black
HD3DB
• Super High Resolution - 540 TVL
• True Day/Night
• 0.4 lux @ F1.3 (with AGC on, 50 IRE), 0.0 lux @ F1.3
(with external IR illumination)
• 2.8 - 10mm (F1.3) IR Corrected Aspherical Vari-focal
Auto Iris lens
HD3CB
• Standard Resolution - 350 TVL
• 0.2 lux @ F1.3 (with AGC on, 50 IRE)
• 2.8 - 10mm (F1.3) Aspherical Vari-focal Auto Iris lens
HD3CHB
• Super High Resolution - 540 TVL
• 0.6 lux @ F1.3 (with AGC on, 50 IRE)
• 2.8 - 10mm (F1.3) Aspherical Vari-focal Auto Iris lens
Performance Series Indoor/Outdoor Mini-Dome
Super High Resolution Color Indoor/Outdoor Fixed Dome
HD51
• 1/3" Sony Super HAD CCD
• 550 TVL
• Vari-focal lens: 4 ~ 9mm
• 3-D Axis Gimbal
• 12 VDC
• IP66 Weather Resistant
• Vandal resistant
Super High Resolution Color Indoor/Outdoor Fixed Dome
HD50
• 1/3" Sony Super HAD CCD
• 530 TVL
• Fixed lens: 3.8mm
• 3-D Axis Gimbal
• 12 VDC
• IP66 Weather Resistant
• Vandal resistant
HD51
HD50
130
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Fixed Domes
Performance Series IR Indoor/Outdoor Fixed Domes
Standard Resolution IR Indoor Fixed Dome
Standard Resolution IR Indoor Fixed Dome
HD61
• 1/3" Sony Super HAD CCD
• Day/Night
• 380 TVL
• Vari-focal lens: 4 ~ 9mm
• 12 VDC
• 3-D Axis Gimbal
• 20 IR LED’s
• 65' IR range
HD60
• 1/3" Sony Super HAD CCD
• Day/Night
• 380 TVL
• Fixed lens: 4.0mm
• 12 VDC
• Weather and vandal resistant
• 24 IR LED’s
• 50' IR range
Performance Series IR Indoor/Outdoor Mini-Domes
Super High Resolution Indoor/Outdoor IR Fixed Dome
HD73
• 1/3" Sony Super HAD CCD
• True Day/Night
• 530 TVL
• Vari-focal lens: 3.8 ~ 9.5mm
• 12 VDC
• Weather and vandal resistant
• 20 IR LED’s
• 65' IR range
HD70
• 1/3" Sony Super HAD CCD
• Day/Night
• 550 TVL
• Fixed lens: 4.0mm
• 12 VDC
• Weather and vandal resistant
• 24 IR LED’s
• 50' IR range
Performance Series Indoor Fixed Dome
Indoor Dome Camera
HD40
• 1/3" Sony Super HAD CCD
• 380 TVL
• Fixed lens: 3.8mm
• 12 VDC
• 3-D Axis Gimbal
8O-SDF445
• LUX, 2.8~10mm
• Digital D/N, service video out, indoor dome
• 12VDC/24VAC, 3-Axis, 1/3" SONY CCD, 560 TVL
• AGC on/off, BLC on/off , Flicker less on/off
CCTV
Super High Resolution Indoor/Outdoor IR Fixed Dome
Vandal Dome Camera
8O-SDF417
• LUX, 2.8~10mm
• 12VDC/24VAC, 3-Axis,1/3" SONY CCD, UTP & Coax
• Vandal/Tamper Resistant (1000kg)
• IP 67, 560 TVL, AWC, AGC on/off, BLC on/off
• Flicker less on/off, digital D/N, service video out, recess
& flush mount
8O-SDF416
• Vandal-resistant (1000kg) Dome Camera
• 560 TVL, 120dB WD range, Digital Day/Night, OSD
• Privacy Masking zones , Motion Detecter
• ALC , Video/DC/ELC, AWB, AGC, BLC,
• Flicker less, 16x Digital Zoom, Service Extra-Video Out
• Surface & Flush mount type, IP67, UT
1/3” CCD HR Day & Night Dome Camera
1/3” DPS Hyper Dynamic Dome Camera
IK-ICD609
• 540TVL (Color) / 570TVL (B/W) horizontal resolution
• Two lens types are available
* Type 31 : 2.9mm ~ 10mm F1.2
* Type 92 : 9mm ~ 22mm F1.5
• Minimum illumination 0.08 lux (Type31), 0.12 lux
(Type92)
• S/N 52dB
• True Day & Night function
• 3-axis lens direction
• Optional ceilling mount IK-XHG6929 available
IK-ISDA30
• Ultra wide dynamic range
• 480TVL horizontal resolution
• Electronic sensitivity up (max 32 times)
• OSD controller provided
• AC24V/DC12V
• Three lens types are available
* TYPE 26 : 2.6mm ~ 6mm
* Type 49 : 4mm ~ 9mm
* Type 92 : 9mm ~ 22mm
• Vandal type IK-ISDA31 also available in Type26,
Type49 and Type92
6100 Dome Camera
540 TVL Dome Cameras
I2-IVCKD6100H922
• 480 lines of resolution
• Indoor/Outdoor
• Day/Night
• IR Illuminators
• Vandal resistant
• 9 - 22 mm lens
JV-TKC215V4U
• Built -in 3.6X variable focal length auto iris lens
(F=2.8mm to 10.0 mm)
• 540 TV lines of horizontal resolution
• Triple axis rotation system for wide lens angle
adjustment
• Monitor video output (RCA) for easy camera setup
• Optional heater unit: JV-KAZH215U allows you to use in
various weather locations, IP66 (JV-TKC215VP4U)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
131
CCTV
Fixed Domes
DF5 Series DomePaksTM
DNR Mini Vandal Dome
PE-DF5 Series
• Fixed-mount dome enclosure
• Compact hi-res camera and lens in easy to order
package
• Indoor and environmental models available
• Hard ceiling, suspended ceiling and pendant
applications
• 0.090-inch injection-molded polycarbonate bubble
• Versatile and adjustable fixed mount camera bracket
• Barrel-type key locks
RA-MVC70WR
• 1/3” Color Sony Super HAD CCD
• 550 lines, 0.002 lux
• Tough aluminum housing with polycarbonate dome
(IP66)
• 3.6mm lens (wide angle 2.5mm option)
• DNR (Digital Noise Reduction) for outstanding
performance in low light conditions without the need for
added illumination
• Can be flush or surface mounted
• Audio option
• 12VDC
DNR Mid-Size Vandal Dome
DNR Indoor Dome
RA-MVCHVF4R
• 1/3” Color Sony Super HAD CCD
• 550 lines, 0.1 lux
• Tough aluminum housing with polycarbonate dome
(IP66)
• 4~9mm lens
• DNR (Digital Noise Reduction) for outstanding
performance in low light conditions without the need for
added illumination
• 3-D camera bracket, Installer Video Out
• 12VDC/24VAC
• 3 year warranty
RA-MDCHVFDR
• 1/3” Color Sony Super HAD CCD
• 550 lines, 0.1 lux
• Indoor Use Only
• 2.8~11mm lens with OSD Menu
• DNR (Digital Noise Reduction) for outstanding
performance in low light conditions without the need for
added illumination
• 3-D camera bracket, Installer Video Out
• 12VDC/24VAC
• 3 year warranty
High Impact Vandal Dome Camera
Vari-Focal Mini Dome Camera
RA-HDCVF3D
• 1/3" Color DSP Sony Super HAD CCD
• Weatherproof (IP66) with 460 lines
(580 resolution option available)
• True Day/Night moving filter (IR sensitive)
• 3.7~12mm vari-focal lens (9~22mm option)
• 3-D Camera Bracket, Installer Video Out
• 3 year warranty (heater option available)
RA-MDCVF
• 1/3" Color DSP Sony Super HAD CCD
• 3.3~12mm DC auto-iris lens
• Compact housing, easy installation
• For indoor use
• 12VDC
• 3 year warranty
High Impact IR Vandal Dome Camera
Mini Dome Camera
RA-HDCVF3DQIR
• 1/3” Sony Super HAD CCD
• 550 TV lines
• True Day/Night function
• 3.7-12mm DC auto-iris (Aspheric)
• Installer video output
• Tough weatherproof housing (IP66)
• 3 year warranty
RA-MDC70
• 1/3" Sony Super HAD CCD – DSP
• 70° Field of view (3.6mm lens)
• Compact housing, easy installation
• For indoor use
• 12VDC
• 3 year warranty
Super Compact Mini-Vandal Dome
Indoor Basic Day/Night Dome Camera
RA-MVC70W
• 1/3" Color Sony Super HAD CCD
• 550 lines, 0.1 lux,12VDC
• Tough aluminum housing (IP66)
• 3.6mm lens (70° field of view)
• Basic day/night (not IR sensitive)
• Can be flush or surface mounted
• Audio option available, 3 year warranty
RA-MDCHVFD
• 1/3" Sony Super HAD CCD
• 550 Lines, 3.3-12mm Lens. 0.1 Lux
• OSD Menu with Basic Day/Night
• 12VDC/24VAC
• 3D Camera Bracket
• 3 year warranty
Mini Vandal Vari-Focal Dome Camera
1/3" High Resolution Color, DNR, Fixed
Dome Camera
RA-MVCHVF4
• Color 1/3" Sony Super HAD CCD
• 550 lines, 0.1 lux, Basic day/night (not IR sensitive)
• Tough aluminum housing (IP66)
• 4~9mm lens, 3-D camera bracket
• OSD menu, Installer video out
• 12VDC/24VAC, 3 year warranty
132
OG-SCCB5313
• 1/3" IT Super HAD CCD
• 540 TVL of resolution
• Minimum scene illumination:
0.002 lux @ 15 IRE, sens-up x128 (F2.0)
• 3.0 mm Fixed Lens • Electronic Day & Night Function
• Digital Signal Processing • Electronic image flip
• Digital Noise Reduction • BLC/AGC
• Automatic White Balance • Dynamic Defect Reduction
• Line Lock Synchronization • 12VDC/24VAC (60Hz)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Fixed Domes
1/3" High Resolution, Color, DNR, VariFocal Dome Camera
OG-SCCB5352
• 2.5-6mm Auto Iris Lens, Electronic Day/Night
OG-SCCB5353
• 2.5-6mm Auto Iris Lens, True Day/Night with cut Filter
OG-SCCB5354
• 2.9-10mm Auto Iris Lens, Electronic Day/Night
OG-SCCB5355
• 2.9-10mm Auto Iris Lens, True Day/Night with cut Filter
• 1/3" IT Super HAD CCD • 540 TVL Resolution 3-Axis
Dome Design; DSP;DNR;DDR
1/3" Anti-Vandal, DNR, Vari-Focal
Extreme Weather Dome
OG-SCCB9374
• 1/3" Super HAD CCD
• 540 (Color)/570 (B/W) TVL of resolution
• Minimum Scene Illumination:
0.4 lux @ 15 IRE (F1.2)
• Vari-Focal Aspherical DC Auto Iris 3.8~9.5mm F1.2
lens built-in • 3 Axis Dome Design
• BLC/AGC • Flickerless • Automatic White Balance
• DIP Switch Control of Color & B/W Changing Time
• 18 IR LED with CDS Photocell Auto Switch
1/4” Vari-Focal, Color, CCD, Auto Iris Dome
OG-GVVMDC
• 1/4 Inch color CCD
• 380TV Lines Resolution
• Minimum Illumination: 0.1 Lux @ 15IRE
• 4-9mm Built-In Auto Iris Lens
• Auto White Balance
• S/N ratio of * 48dB
• 12VDC/AC24V
• Easy Installation
Vandal Resistant Dome Camera Series
Pan/Focus Color Mini Dome Camera
SY-VDCW1594V
• Wide Dynamic,1.0 lux 480 lines of resolution
SY-VDCD1584V
• Day/night, 0.5 lux, 520 lines
SY-VDCC1574V
• Color, 1.0 lux, 520 lines
SY-VCCP7574
• Indoor Mini Dome Type
SY-DP7584
• Vandal resistant version
•
•
•
•
•
Integrated 2.3x vari-focal lens - 2.6 to 6mm
360° pan adjustment and 120° tilt adjustment
IP66 compliant to fight off dust and water
Selectable dual power - 24VAC and 12 to 14VDC
3 year warranty
• Super High Resolution of more than 520 TV lines
• Minimum illumination 1.9 lux (F1.9) • UTP option
• Built-in 2.6x motorized zoom pan/focus lens F2.8-7.3mm
(F1.9-3.0)
• Built-in Motion Detection & Privacy Masking Functions
• Easy Installation - NO FOCUS ADJUSTMENTS REQUIRED
• 12VDC/24VAC dual power operation • 3 year warranty
Color Mini Dome Camera
CMOS Super Mini Dome Camera
SY-VCC9684VA
• Super High Resolution of 540 TV lines
• Min Illumination: 0.5 lux (F0.95)
• Built-in 2.9x Varifocal lens - 2.8 to 8.0 mm
• 12VDC / 24VAC Dual Power Operation
• UTP Option
• 3 year warranty
• Also available with wider (2.0 ~ 5.5mm) lens SY-VCC9684VW
SY-VCCW1072
• Progressive Scan 1/3.3" CMOS
• Wide Dynamic Range Function
• Horiz Resolution 500 TVL(WVGA), 470TVL (VGA)
• Built-in Fixed Lens (f=3.0mm / F2.0)
• Minimum illumination 1.0 lux
• Electronic Iris
• 3 year warranty
• 12VDC
Mini Vandal Dome Cameras
IR Day/Night Ball-Mount Vandal Resistant
Dome Cameras
SL-EV122CDVC
• 3.6mm Lens, 21 IR LEDs, Range up to 50'
SL-EV122CVWA
• 3.6mm Lens
• 1/3" Sony Color CCD. 420 TV lines
• Multi-axis gimbal for wall or ceiling mounting
• Miniature size: 3" x 4-1/4"
CCTV
OG-SCCB5393H
OG-SCCB5395H
• 1/3" IT Super HAD CCD • 540TV Lines Resolution
• Minimum scene illumination: 0.0009 lux Color/0.00009
Lux B/W @15 IRE, Sens-Up x128
• 2.5 - 6mm Auto Iris Lens (OG-SCCB5393H); 2.9 - 10mm
Auto Iris Lens (OG-SCCB5395H)
• Horizontal & Vertical Mirroring
• DSP (Digital Signal Processing)
• True Day & Night with moveable cut filter • Dynamic
Defect Reduction • 12 VDC/AC24V (60Hz)
1/3" Day/Night, Vandal Resistant Vari-Focal
IR Dome Camera
SL-EV122CDVQ
• Varifocal 4-9mm, 36 IR LEDs, Range up to 100'
SL-EV122CDB3
• 3.6mm Lens, 24 IR LEDs, Range up to 50'
•
•
•
•
•
•
1/3" Sony Color CCD • 420 TV Lines
Day/Night operation (0 Lux with LEDs on)
Multi-axis ball mount for wall or ceiling mounting
Weatherproof (IP66) for outdoor use
Split glass design to eliminate IR reflection
Wiring concealed in base to prevent tampering
Color and B/W Dome Cameras
Vandal-Resistant Dome Cameras
SL-EV122B4
• 4.3mm lens, 420 TV lines, 0.08 Lux, B/W
SL-E1223C12M
• 3.6mm lens, 420 TV lines, 0.1 Lux
SL-EV122CM2
• 2.9mm lens, 420 TV lines, 0.1 Lux
SL-VBCN1Q
• Corner bracket for SL-EV1223C12 or SL-EV1223B4
SL-2606NJEQ
• 3.8-9.5mm lens, 550 TV Lines
• 36 IR LEDs
SL-2605NKEQ
• 2.8-11.0mm lens, 550 TV Lines
SL-2615NKEQ
• Digital Noise Reduction
• 2.8~11.0mm lens, 520 TV lines
SL-2625NKEQ
• Wide Dynamic Range
• 2.8~11.0mm lens, 520 TV lines
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
133
CCTV
Fixed Domes
Megapixel Color Mini Dome
1/3"-Type Analog Minidome Camera CCD
SH-SNCDM110
• 1/4" complementary progressive scan CCD with
ExwavePROTM
• 1280 x 960 pixel imager
• Dual stream JPEG and MPEG-4
• Integral 2.8 ~ 10mm Auto-Iris lens
• Analog video output
• Intelligent motion detection
• PoE (802.3af), AC24V or DC12V
SH-SSCCD45
• 1/3"-type Interline Transfer CCD w/Super HAD Technology
• 540 TV Line Camera • 380,000 Effective Pixels
• Minimum Illumination: 0.9 lux
• Integrated 2.8 - 10 mm F1.3 vari-focal DC auto iris
(100.8 or 27.7)
• On/Off Switchable Backlight Compensation
• Turbo Off Switchable Auto Gain Control
• ATW - Pro/ATW White Balance Mode
• AC24V or DC12V
• S/N Ratio more than 50dB
Analog Camera - Wide Dynamic Camera
1/4" SuperHAD Color Ruggedized Mini Dome
SH-SSCCD49
• 1/3"-type Interline Transfer CCD w/DynaView Technology
• 480 TV Lines resolution
• Color 0.6 lux
• 128X DynaView Camera
• On/Off Switchable Backlight Compensation
• Turbo off Switchable Auto Gain Control
• ATW White Balance Mode • Analog Video Output
• NTSC Signal System
• Internal AC Line Lock Sync System
• AC24V or DC12V • S/N Ratio more than 50dB
SH-SSCCD73V
• 1/4"-type SuperHAD CCD
• High sensitivity - 0.9 lux, B/W: 0.2 lux (F1.0, 50IRE)
• Built-in CS-mount auto iris vari-focal lens covers a
wide range of viewing angles (F=3.0 to 8.0mm)
• Rugged design: IP66 rated • Day/Night mode
• BNC type analog composite video output
• Designed for easy mounting and installation
• AC Line Lock capability for AC operation
• Backlight compensation: ON/OFF switchable
• AGC: TURBO (up to 24dB)/OFF switchable
Rugged Analog Mini Dome
with 540 Lines Resolution
Rugged Analog Minidome w/540 Lines Resolution
SH-SSCCD77
• 1/3" Type CCD with SuperExwave Technology
• DSP technology offers 540 TV lines of resolution
• Requires IR illuminator
• 0.6 lux Color - 0.06 lux Black & White
• Day/Night function - detailed images in zero lux lighting
conditions
• On/Off Switchable Backlight Compensation
• Turbo/Off Switchable Auto Gain Control
• ATW Pro/ATW White Balance Mode
• Optional heater SH-YTHU75 for -40°F operation
SH-SSCCD75
• 1/3" Type Interline Transfer CCD w/SuperHAD Technology
• 380,000 Effective Pixels
• Color: 0.9 lux • Vandal Resistant Mini Dome Camera
• S/N Ratio more than 50dB • AC24V or DC12V
• On/Off Switchable Backlight Compensation
• Turbo Off Switchable Auto/Gain Control
• ATW - PRO/ATW White Balance Mode • Analog Video Output
• NTSC Signal System
• Internal AC/Line Lock Signal System
Intensifiers Series Dome Cameras
Intensifier Series Weatherproof,
Tamperproof Dome Bullet Camera
SO-HTINTD3
• 3-9mm lens
SO-HTINTD4
• 5-50mm lens
SO-HTIND8
• 560 lines
• 2.8 to 12mm auto iris varifocal lens
• Also available SO-HTINTD9 - 5-50mm auto iris lens &
SO-HTINTD10 - 9-22mm auto iris lens
• Advanced Noise Reduction circuitry in the Intensifier
camera coupled with the virtual 3D filter
• Full OSD operation • ROHS compliant
• SLC - Speco Light Compensation
• S/N ratio >50dB (weight on)
•
•
•
•
•
Intensifier tamper proof dome auto iris day/night lens
540 lines
See full color in the dark without IR LEDs!
Tamperproof
All camera functions can be controlled by an “Easy to
Follow” OSD control via wireless
• 5 year warranty
Intensifier Series Tamperproof/Weatherproof
Dome Camera with Chameleon Cover
SO-HT7246IHR
• See full color in the dark!
• Features a snap on cover that converts the housing from
the standard dark grey to decorator white. It can be
painted to match any décor without painting the actual
camera housing!
• Intensifier Series with Chameleon Cover
• 5 year warranty
• 540 Lines of Color Resolution Extreme resolution for extreme detail
• 2.8 ~ 11mm auto iris vari-focal lens a wider zoom to fit more applications
• Wall & Ceiling Mount Features an internal 3-axis mount for maximum versatility
• Weatherproof/Tamperproof Indoors or outdoors, meets all of your surveillance needs
• Dual Voltage Operation 12 Volts DC or 24 Volts AC with line-lock
• Voltage is auto-sensing • All menu functions controlled using internal joystick
• Also available in 9 ~ 22mm auto iris lens: SO-HT7247IHR
648 Series Color Indoor Cameras
with IR LEDs & Anti-Reflective Technology
SO-VL648IR
• 3.6mm lens
SO-VL648IRVF
• 2.8 - 11mm vari-focal lens
• 1/3" Sony SuperHAD
• Resolution 420 lines
• 5 year warranty
134
SO-CVC648IRH
• 3.6mm lens
SO-CVC648IFB/W
• 4 - 9mm vari-focal lens
• 1/3" Sony HQ-1 CCD with DSP
• Resolution 540 lines
• All models have 22 internal IR LEDs with anti-reflective
technology
• Includes 12VDC UL power supply, wall mount bracket
and mounting hardware
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Fixed Domes
Intensifier Miniature Color Dome Camera
SO-HT647HRTP
• See full color in the dark! • 1/3" Sony HQ-1
• 540 line super high resolution • 0.5 lux
• 3.6mm wide angle coverage - optional lenses available
• Wall and ceiling mountable • 4" Diameter x 2.5" H
• This tamperproof dome camera can withstand hits from
a 10 lb. sledgehammer
• Tamperproof hi-performance with chameleon cover
• Includes regulated 12VDC power supply
• Also avail.: standard 420 line res in white: SO-647TP
• 5 year warranty
High Resolution Color Dome Camera
with 2.8-11mm Auto Iris Lens
SO-CVC6146HR
• 550 lines of resolution
• 2.8 ~ 11mm auto iris varifocal lens indicating a wider
zoom range to fit more applications
• Dual voltage operation: 12VDC or 24VAC with line lock
• 3-axis mount for wall and ceiling
• RoHS compliant
• Also available in white in the Speco Control Series,
SO-CVC6146SCSW
• 5 year warranty
Intensifier Series Color Dome Camera
for Indoor Use
SO-VL6WMTDV
• 1/3" interline transfer type CCD
• Resolution 420 lines
• 1.0 Lux sensitivity
• 2.8 ~ 11mm auto iris vari-focal lens
• Weather proof & vandal resistant
• Conduit compatible - side & rear cable entry
• Includes regulated 12 VDC power supply & mount
• 5 year warranty
SO-CVC6246IHR
• See in the full color in the dark without IR LEDs!
• 540 lines resolution • 2.8 to 11mm auto iris varifocal lens
• Advanced Noise Reduction circuitry in the Intensifier
camera coupled with the virtual 3D filter that is built
into the DSP will allow your DVR to have 30% better
compression in scenes that were typically subject to
video noise
• Dual voltage operation: 12 V DC or 24V AC with line lock
• Also available in white SO-CVC624HRW
Vandal Resistant Hi-Resolution Color
Wall/Ceiling Mountable Camera
Tamperproof Color Indoor Dome Camera
Wall or Ceiling Mount
SO-CVC7WMTDV
• Image device: Sony 1/3" EZ View
• 480 line resolution
• .03 lux sensitivity
• Vandal resistant hi-res color
• 4 - 9mm auto iris vari-focal lens
• Ultra high impact dome cover, weatherproof
• Ceiling or wall mount - flush or surface
• 5 year warranty
SO-VL64TP
• 420 line resolution
• 1/4" format, 1.0 lux • 2.9mm lens
• Tamperproof indoor color dome
• Withstands blows from a 10 lb. sledgehammer
• Fully adjustable both horizontally and vertically
• Can be rotated Title angle +/- 90°
• Video Output - BNC • Requires 12V DC power supply
• Also available in white SO-VL64TPW
Economy Dome Camera
Vandal Proof, Weatherproof
Color Dome Cameras with IR LEDs
SO-VL644DC
• 1/4" Format
• 420 lines resolution
• 0.2 lux sensitivity
• Internal 3-axis mount
• Wall & ceiling mount
• 2.9 mm lens
• Video output/BNC
• Also available in white: SO-VL644DCW
• 5 year warranty
CCTV
Wall/Ceiling Mount Vandal Resistant
Economy Dome Camera
SO-VL650IRS
• Silver
SO-VL650IRW
• White
SO-VL650IRVS
• Silver/Vari-focal
SO-VL650IRVW
• White/Vari-focal
• 1/3" Sony SuperHAD • Resolution 420 lines
• 5 year warranty
CVSH Color Mini Dome Camera
Mini-Dome Camera
HD-VSH26AI24
• Super High Resolution: 520 TVL
• Sony HQ-1 Chipset
• Indoor/Outdoor, 24 VAC
• 2.6-6.0mm Varifocal Auto Iris Lens
• Weather and Vandal Resistant Housing
TB-DF03A36
• 36mm Fixed Lens
TB-DF03A8
• 8 mm Fixed Lens
TB-DF03A12
• 12 mm Fixed Lens
•
•
•
•
•
Pan 350°, Tilt 75°
Rugged, all metal housing is IP65 rated
480 TV line resolution delivers detailed images
High sensitivity 1/3-inch CCD sensor
Backlight compensation corrects problem lighting
Mini-Dome Camera with Vari-focal Lens
Vandal Resistant Day/Night Color Dome
TB-IKDF02A
• Advanced 1/3" CCD (768 x 494)
• 520 lines of horizontal resolution
• 0.5 lux with tint dome
• 2.8 ~ 10mm vari-focal lens
• 3 axis adjustable
• Back light compensation
• 12VDC/24VAC
• Compact, simple to install
TB-IKVR01A
• 480 lines of horizontal resolution
• 0.2 lux minimum illumination
• 3-8mm vari-focal auto iris lens
• 50 dB signal to noise ratio
• IP66 environmental rating
• Flush/surface mount with tint/clear cover and
tamper resistant hardware
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
135
CCTV
Fixed Domes - Covert Cameras
136
Vandal-Resistant Recessed Ceiling Dome
Exit WatchTM Covert Door Frame Camera
VL-RM7C2N
• Designed for plenum ceiling applications
• Rugged, vandal-resistant cast aluminum top with
polycarbonate dome
• Simple installation and servicing from below ceiling
• Universal mounting plate accepts most IP and Analog
cameras (Fixed & PTZ)
• Available with heater/blower for outdoor overhang
applications
CM-CVEX36
• 1/3", 525 TV lines, Sony Super HAD CCD
• Wide angle lens: 3.7mm
• Swivel bracket (included) mounts directly to door frame
• Ideal for retail, commercial and banking applications
• Provides detailed facial images
• Power supply and mounting hardware included
• Available with black or silver housing
CM-CVEX7
• Same as above, only 7" length & has smoked face plate
• Can be mounted vertically or horizontally above door
PIR Camera with Functional PIR
PIR Cameras
KA-PI450P3
• B&W, 3mm lens
KA-PI450P5
• B&W, 5mm lens
KA-PI950P3
• Color, 3mm lens
KA-PI950P5
• Color, 5mm lens
KA-PN450P3
• B&W, 3mm lens
KA-PN450P5
• B&W, 5mm lens
KA-PN950P3
• Color, 3mm lens
KA-PN950P5
• Color, 5 mm lens
• 580 TV lines resolution (black & white), 480 TV lines
resolution (color) • 0.1 lux (black & white), 1.0 lux (color)
• Accepts 12VDC or 24VAC input voltage
• 580 TV lines resolution (black & white), 480 TV lines
resolution (color) • 0.1 lux (black & white), 1.0 lux (color)
• Accepts 12VDC or 24VAC input voltage
Smoke Detector Cameras
Board Cameras
KA-SD450 Series
KA-SD950 Series
• Color or black & white
• Resembles popular models of commercial smoke
detectors
• Up to 4 side-viewing cameras and 1 down viewing
camera
• Optional upgrade kits provide additional cameras for
multicamera surveillance
GH-CLR250P
GH-CLR250S
GH-BW120P
GH-BW120S
• Both high resolution color and black & white cameras
• Pinhole (P) or Standard lens (S) available
• 12VDC
• Video & power connections included
Covert Clock Radio Series
Covert Functional Wall Clock Series
GH-2400
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Functional Sony® Dream Machine
GH-2500
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Functional all clock
• Power supply included
Covert Video Smoke Detector Series
Covert Functional Exit Signs
GH-2725
• Sideview camera
GH-2750
• Downward view camera
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Hardwired cameras - functional smoke detectors
• Wireless - non-functional
GH-3200
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Functional exit signs
• NYC Approved exits available
• Battery backup available
Functional/Non-Functional PIR
Covert Emergency Lights Series
GH-3300
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Functional or non-functional PIR’s
GH-3400
• Perfect covert camera for commercial or residential
applications
• Wireless 2.4 Ghz & 1.2Ghz Tx/Rx packages or
hardwired available
• High resolution color & black & white cameras
• Functional emergency lights
• Battery backup
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Serious surveillance?
Spyder® of course.
THESE GOVERNMENT FACILITIES RELY ON SPYDER CAMERAS... NASA; U.S. Army; Navy (yes, includes NCIS);
Air Force; Marines; V.A.; Departments of Defense, Justice, Agriculture, Transportation, Treasury and State; DEA; FAA;
FDIC; INS; IRS; Health & Human Services; U.S. Marshals; Federal Protection Agency; plus municipalities, corporations and institutions...YOU CAN RELY ON SPYDER, TOO. Check www.sperrywest.com for more models.
COVERT CAMERAS
Color, wireless & B&W available. 520 horizontal resolution. 600 resolution available. 3.6mm lens. All cameras have
5 year warranty.
.%7
Smoke Detector
Emergency Light
Loose Leaf Binder
Desktop Clock-Radio
SW0030
SW2500
SW1500
SW2200–Straight Down
SW2250–Side View
Exit Sign
SW2400
PIR-DVR
Industrial Wall Clock
SW1300
Color camera and DVR
inside records motion to
1GB SD card
Passive Infrared Detector
(includes swivel mount)
Pencil Sharpener
(nonfunctional)
Desktop Speaker
(nonfunctional)
Fire Strobe
(nonfunctional)
SW2600DVR
SW2600
SW2700
SW2800
SW2900
Thermostat
SW1600
INFRARED CAMERAS—SEE DAY/NIGHT COLOR
All cameras have 5 year ltd. warranty.
Infrared Illuminator
Varifocal, 42LED
with outside lens
controls & split glass
SWIR580c
SWIR200c
SWIR250c
SWIR510c
12LED, 40 ft. range
24LED, 65 ft. range
36LED, 95 ft. range
SWIR900c
“Big Guy”
10X zoom & varifocal,
350 ft. range
SWIR800c
160 ft. range
SWIR890IL
“The Beam”
500 ft. range
DOME CAMERAS
Color Video Intercom
.%7-/$%,
!00%!2!.#%
-!96!29
s3TAINLESSSTEELOUTDOORCAMERAUNIT
with infrared illumination
sWAYHANDSFREEAFTERANSWERING
s(IGHLYECONOMICAL
s0ANICLOCALALARM
sv4&4,#$FLATMONITOR
s0OWERSUPPLYANDWIREINCLUDED
CD35-420B
CD35-420B
CD35-420V
82 ft. IR range
Auto-iris varifocal lens
Auto-iris varifocal lens
SWCD3W-420SS
High sensitivity to low light
CD4F-420B
Discreet & vandal
resistant
SWVD200
Easy to set up and record actual crimes
Digital Surveillance Kit
New! Three year kit warranty (5 year warranty on cameras.)
Standard kit, SW1000WIPC-D, with 4 camera option shown
Other covert
Spyder® cameras
available with kit!
www.sperrywest.com
® Video Commander and Spyder are registered trademarks of Sperry West Inc.
Covert Cameras - Day/Night Cameras
Speco Control Series Board Camera
with 3.7mm Lens
Color CCTV Camera
in Non-Operating PIR Housing
SO-CVC7700PHSCS
• Full control of major camera functions
• 540 line resolution
• Shutter type: manual, fixed, flickerless or auto
• Day/Night: auto, color or B/W
• BLC-adjustable sensing area or 100 points on the
screen
S0-VL565PIR
• 1/3" color CCD camera is encased in a white
non-working PIR housing
• 1.0 lux with 420 line resolution.
• 3.6mm wide angle pinhole lens and built-in electronic
shutter
• 12V DC power supply is included
• Also available: B/W version of this camera SO-VL265PIR
MemoCam Zorro Series - Covert Camera/DVR
CCTV
5V-MCZMEGA
• Megapixel Resolution Camera
5V-MCZC
• Color Camera
5V-MCZB
• B/W Camera
5V-MCZBX
• Low-Light B/W Camera
• Covert Camera/DVR + PIR with integrated VMD
(Video Motion Detection)
•
•
•
•
•
•
•
•
•
•
•
Records images up to 640 x 480 resolution, 10 FPS
Megapixel model records images up to 1280 x 960 resolution, 3FPS
Low light model with 0.003 Lux
Hidden in hand-sized slim sensor casing
Records on removable mini SD/HC card
Smart recording with dual-technology VMD and/or PIR
Solid state device, no daily maintenance required
Weekly recording schedule built in
Examine images on any PC/pocket PC
RS-485 Communications port
Comes with RC, swivel bracket, mini SD, power adaptor + 15' cable
D-Cam 600 Series Covert Camera/PIR
True Day/Night Color Camera
5V-DC600B
• Black & White Camera
5V-DC600BX
• Low-Light Black & White Camera
5V-DC600C
• Color Camera
F8-EQ550 Series
• 560 TVL, Built-in DNR, dual voltge
• 0.002 Lux/F=1.2 (Sens-UP Shutter x 128)
• OSD Setting menu, advanced 16-bit DSP
• True Day/Night function with IR Cut Filter
• Support motion detection and privacy function
• Support either C-mount or CS-mount (optional)
•
•
•
•
•
Covert Camera with integrated Active PIR
600/T models with Video over UTP up to 600'
Quality camera + PIR hidden in sensor casing
Undetectable camera and PIR
Matching field of view for camera and PIR
High Resolution Day/Night Cameras
3D-DCBHR1032
• IR Day/Night Weather Resistant Bullet Camera
• 75' range, high resolution, 480 TV lines,
weatherproof design (IP67), 12V/24V
• IR Cut Filter
3D-DCBHR1035
• IR Day/Night Weather Resistant Bullet Camera
• 70' Range, high resolution, 480 TV lines,
weatherproof design (IP67), 12VDC
3D-DCBHR1037
• IR Day/Night Weather Resistant Bullet Camera
• 120' range, high resolution, 480 TV lines,
weatherproof design (IP67), 12V/24V
• IR Cut Filter
3D-DCBHR1535
• IR Day/Night Weather Resistant, Varifocal, Bullet Camera
• 62' range, high resolution, 480 TV lines,
4-9mm varifocal lens, 12V/24V
• IR Cut Filter
3D-DCS100033
• Digital Day/Night Professional Camera
• Ultra high resolution, 540 TV lines, digital noise reduction,
12VDC/24VAC
3D-DCBHR1535
3D-DCD210533
• Day/Night Professional Vandal Resistant, varifocal,
Dome Camera
• Ultra high resolution, 540 TV lines, DNR,
4-9mm varifocal lens, 12VDC/24VAC
3D-DCDHR2532
• Day/Night Vandal Resistant, varifocal, Dome Camera
• High resolution, 480 TV lines, 4-9mm varifocal lens,
12VDC/24VAC
3D-DCD110043
• IR Day/Night Vandal Resistant Dome Camera
• 40' IR illumination, high resolution, 480 TV lines,
weatherproof, 12V/24V
• IR Cut Filter
3D-DCD110543
• IR Day/Night Vandal Resistant, Varifocal, Dome Camera
• 82' IR illumination, high resolution, 480 TV lines,
weatherproof, 4-9mm varifocal lens, 12V/24V
• IR Cut Filter
3D-DCS100033
Hi-Performance
Wide-Dynamic Range Camera
KA-GECHDR1
KA-GECHDR1DN
• Day/Night version available
•
•
•
•
138
500 TVL color
All digital on-screen display with GUI
Easy-to-use 5-button menu for setup & configuration
Black & white mode for low light environment
Hi-Res Brick Camera
KA-GECEVR1
KA-GECEVR1DN
• Day/Night version available
•
•
•
•
•
540 TVL resolution, up to 570 in black & white
Full digital GUI with easy 5-button control
Privacy Masking & Image Flip features
Universal 12VDC/24VAC power input
Day/Night version available
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Day/Night Cameras
True Day/Night Camera Kits
HCD484-KT1
• Consists of: HCD484L camera,
HLD29V8DNL (2.9 - 8 mm, F0.95 day/night lens)
HCD484-KT2
• Consists of: HCD484L camera,
HLD27V13DNL (2.7 - 13.5 mm, F1.3 day/night lens)
HCD484-KT3
• Consists of: HCD484L camera,
HLD5V50DNL (5 - 50 mm, F1.6 day/night lens)
Super Hi-Resolution Day/Night Camera
Hi-Resolution
Miniature Day/Night Camera
HCCM474M
• Hi-resolution 1/3" CCD color camera with DSP
• 470 lines resolution
• High sensitivity (0.4 lux color, 0.1 lux b/w)
• Low light Black & White mode
• Footprint only 1.6" W x 1.6" H x 2.8" D
• On screen display for camera setup
• 12VDC/24VAC
L-Series Hi-Resolution True Day/Night
1/3” CCD HR Day & Night Color Camera
HCD484L
• 1/3" color camera
• 480 TVL with 50 dB S/N ratio
• 0.10 lux @ F1.2
• Moveable IR cut filter for True Day/Night
• RS485 remote control
• On-screen display for camera strip
• SPS 12VDC/24VAC with Line Lock
IK-ICD509
• 540TVL(Color) / 570TVL (B/W) horizontal resolution
• Minimum illumination 0.037 Lux F1.2
• S/N 52dB
• True Day & Night function
• BLC & AES function
• Automatic white balance
• Focus EZ adjustment button
• CS mount
• AC24V/DC12V
• 10 year warranty registering online
1/3" Day/Night Cameras
1/3" WDR Camera
JV-TKC925U
JV-TKC1530
• Revolutionary integrated 10-bit DSP
• Scene file function for customer’s parameter setting
• RS-422/RS-485 remote control capability for camera setting
• Free software is available for camera control
JV-TKWD310U
• 1/3" digital image device with wide dynamic range (WDR)
• 480 TV lines of horizontal resolution
• Supports video/DC iris lens control
• Innovative 14-bit DSP
• Easy day/night function
• Auto tracking white balance (ATW) single-push & manual
• Automatic gain control (AGC) on/off, maximum 34 dB
• 24 characters camera title
• AC 24V/DC 12V power supply
• 540 TV lines of horizontal resolution
• Day/Night surveillance with auto IR cut filter on/off
(Color/B&W shooting) • Built-in Menu
• Built-in display mode (CRT or LCD switchable)
• AC 24 V/DC 12 V power supply
VID Indoor/Outdoor
“LAMP” Camera with IR
CCC1390H Series
Day/Night WDR CCD Camera
NF-VIDLAMPHIR
• Day/Night Color 3.6mm, 1/3" CCD, 470 lines, 0.3 lux
• 28 Infrared LED’s give camera night vision
• 940nm IR - no visible red glow
• LED’s turn on/off automatically
• Camera and LED’s in one enclosure
• Tough weather-resistant aluminum housing
• 1 year limited warranty
• Power and Video over separate cables
• Available in Ivory
PE-CCC1390H Series
• 1/3" format Sony SS-2WD CCD imager
• 530 TV lines (Black & White); 480 TV lines (Color)
• Digital signal processing
• Auto White Balance, AGC, ESC, and Backlight
Compensation
• Autosensing DC-drive auto iris
• Wide Dynamic Range (60 dB Maximum)
• Day/Night with automatic or manual control
• Compact body style • Electronic PTZ
Day/Night Outdoor Camera with IR
1/3" True Day/Night Camera
RA-ODL55VD3IR
• 1/3" Sony Super HAD CCD DSP
• 3.7~12mm Day/Night DC auto-iris lens
• True Day/Night using moving filter technology
• 35 LED’s (850nm), 50' range
• 12VDC or 24VAC operation
• Installer video output
• Cable managed bracket
• 3 year warranty
RA-DNL62D
• Color by day, high sensitivity B&W by night
(moving filter)
• 620 lines
• 12VDC/24VAC/UTP Power
• Backlight compensation
• OSD option available
• 3 year warranty
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
CCTV
HCS544
• 540 TVL
• Digital Noise Reduction technology for noise free images
• Digital Slow Shutter for improved sensitity in low light
conditions
• On-Screen Display menu for quick camera setup
• Variable AGC Setting to adjust the level at which the
camera switches from color to black and white in low
light
• One power connection self-configures to 12VDC or
24VAC with transient surge protection
• When your security requirements demand 24/7 surveillance,
you need accurate color during the day and the highest
performing black & white images after dark
• HCD484L cameras feature:
* 1/3" CCD, 480 TV lines
* 0.1 lux @ F1.2
* Moveable IR Cut filter
* OSD menu for easy set up
* 6 zones of backlight compensation
* RS485 remote control
139
CCTV
Day/Night Cameras - Speed Domes
140
Wide Dynamic Vari-Focal Dome
1/3" High Resolution Digital Color Camera
RA-MDWVF3D
• 1/3” Pixim Wide Dynamic Digital Imager
• 540 lines, 0.6 lux
• 3.3-12mm auto-iris vari-focal lens
• True Day/Night using moving fi lter technology
• On Screen Display (OSD)
• 3-D camera bracket, installer video out
• For indoor use. Easy installation.
• Slim housing provides a ‘flush mount’ appearance
• 12VDC/24VAC operation
• 3 year warranty
OG-SCCB2311
• 1/3" Super HAD IT CCD
• 540 TVL of resolution
• Minimum scene illumination:
0.0009 lux @ 15 IRE sens-up x 128
• Electronic Day/Night function
• BLC/AGC • Automatic White Balance
• Accepts 2 types of Auto Iris lenses (DC/Video)
• DSP (Digital Signal Processing) • Digital Noise Reduction
• Built-In Ground Fault Isolation Transformer
• 12VDC/AC24V (60Hz)
1/3" High Resolution WDR Day/Night
Color Digital Camera
1/4" High Resolution Day/Night, WDR,
Motorized Zoom
OG-SCCB2315
• 1/3" Super HAD Progressive Scan CCD
• 540 (color)/570 (B/W) TVL of resolution
• True Day & Night IR Cut Filter • 24 Privacy Zones
• Wide Dynamic Range • Digital Noise Reduction
• Minimum Illumination: 0.0005 Color/0.00005 B/W lux @
15IRE, Sens-Up x256 (F1.12)
• RS-485 remote control • Motion Detection
• OSD (On Screen Display) • 12VDC/24VAC (60Hz)
OG-SCCC4335
• 1/4" Ex-View-HAD CCD
• 540 (Color); 570 (B/W) TV Lines of Resolution
• Minimum Scene Illumination: (Color) 0.001; (BW) 0.0001
LUX @15IRE with Sens up x256
• Auto Day and Night with the moving filter
• 32X Optical; 16X Digital Zoom Lens
• Wide Dynamic Range
• RS485 remote control • 16 Area Privacy Zonesl
• ATW/AWC • Digital Signal Processing
Super Hi-Res Day/Night DSP Camera
Super Hi-Res Day/Night DSP Camera
SY-VCC4794E
• More than 540 lines of resolution
• Minimum illumination:
Color: 0.18 lux with F1.2 lens,
Black & White: 0.004 lux with F1.2 lens
• EXview™ CCD technology
• Operates in Infrared Light Spectrum (930nm)
• 12VDC/24VAC dual power operation
• 3 year warranty
• Also available: SY-VCC4344 Standard Resolution Model
SY-VCC6584DN
• Super high resolution of more than 540 TV lines
• High Sensitivity-Color:0.35 lux @F1.2, B/W:0.25 @ F1.2
• Electronic Day/Night function
• Multi-zone/center-zone backlight compensation
• Electronic Iris
• Internal Sync/Line Lock
• 12VDC/214VAC dual power operation
• 3 year warranty
1/3" CMOS Advanced WDR Day/Night Camera
1/3" SuperExwave Color Video Camera, Day/Night
SY-VCCWD8874
• Progressive scan 1/3" CMOS with RGB filter
• Super High Resolution of 550 TV lines
• Advanced Wide Dynamic Technology
• High Sensitivity-Color 0.8 lx, B/W 0.08 lx (F1.2,50IRE)
• Built-in Digital Noise Reduction - Electronic Iris
• Electronic Shutter 1/60 to 1/10,000
• Internal Sync/Line Lock
• 12 VDC/24 VAC dual power operation
• 3 year warranty
SH-SSCE473
• 1/3"-type CCD with Super Exwave technology
• Advanced Digital Signal Processing (DSP) technology
provides high-horizontal resolution of 540 TV lines
• High sensitivity - Color: 0.55 lx, B/W: 0.05 lx (F1.2, 50IRE)
• Day/Night function • AGC: TURBO/OFF switchable
• Backlight compensation: ON/OFF switchable
• CCD IRIS function allows for the use of low cost
manual iris lenses
• Wide range CCD IRIS function
(ON/OFF switchable, 1/60 to 1/100,000 s)
Color Camera w/Wide Dynamic Range (DynaView™)
1/3" Day/Night Standard Resolution Color
SH-SSCDC593
• 1/3"-type CCD with DynaView technology
• Horizontal resolution-480TV lines
• High sensitivity - 0.8 lx, B/W: 0.07 lx (F1.4, 50IRE)
• Wide dynamic range with DynaView technologyideal for obtaining clear color images under severe
highlight or backlight conditions • Day/Night function
• AGC: Turbo/Normal/Manual/Off switchable
• Aperture: Sharp/Soft/Normal switchable
• White balance;
ATW Pro/ATW/3200K/5600K/Manual/Dual switchable
TB-IK6210A
• 350 lines of horizontal resolution
• 0.2 Lux @ F1.2
• 10-bit DSP technology
• 50dB signal-to-noise ratio
• Backlight compensation
• 12VDC/24VAC
• Lens not included
IR Day/Night Color Camera
1/3" Day/Night High Resolution Color
TB-IK64DNA
• 570 lines of horizontal resolution in Black & White,
480 lines of horizontal resolution in color
• 0.003 Lux @ F1.2 B/W, 0.01 Lux @ F1.0 Color
• RS-422 remote setup from DVR
• Dry contact input for day/night override control
• IR-sensitive CCD with auto-switching infrared-cut filter
for incredible low light and infrared performance
• Lens not included
TB-IK6550A
• 540 lines of horizontal resolution
• 0.2 Lux @ F1.2
• 4 backlight compensation modes
• Menu-driven programming
• 50dB signal-to-noise ratio
• 12VDC/24VAC
• Lens not included
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Day/Night Cameras - Speed Domes
1/3" Day/Night High Resolution
Color Camera
Analog Speed Dome: 18X/22X/26X/36X
B7-CV2235
• OSD Function
• Four Pattern Tours (Each One with 200s Memory)
B7-LC2235 IP Speed Dome: 18X/22X/26X/36X
• Video Compression: MJPEG / MPEG4
• Resolution: Full D1, Half D1 and CIF
• Network: IE browser and Client Software
• Audio Input / Output (RCA): 1 / 1
• Both features:
* 128 Preset Positions, 6 Cruising Tracks, 6 Privacy
Zone Masking AC24V Input
Speed Dome Color Camera
36X Day & Night Speed Dome
DD-CAMSD Series
• Up to 240 programmable preset positions
• Optional Manual/Auto shot and slow shutter function
enhances Diagonal scanning (Vector Scanning)
• Quick detachable (Hot Swappable)
• Easy DVR remote control
• 3 year warranty
• Optional 18x, 22x, 26x optical/digital zoom
• Optiomal indoor/outdoor mounts for various applications
DD-CAMSDH36O
• Pan-Tilt-Zoom with 36x zoom options; 12x digital zoom
• Coax & multi-protocol RS485 control
• IP-66 waterproof rated housing with full mounting
opions- quick mount release
• 24 privacy zones
• High Resolution 530 TVL
• Day-Color (.05 lux) Night (.01 lux)
• Vandal Resistant hemisphere & housing
• Robust die-cast internal mechanism
Low Cost PTZ Speed Domes
Legend Integrated Dome
with 26X Day/Night Camera
F8-EPTZ500
• Color, 480 TVL, 18X Zoom, indoor, power supply incl. (not shown)
F8-EPTZ900
• Color, 480 TVL, 18X Zoom, IP66 Rated, heater
F8-EPTZ1000
• Day/Night, 480 TVL, 18X Zoom, IP66 Rated, heater
F8-EPTZ3000
• Day/Night, Wide-Dynamic, 520 TVL, 30X Zoom,
IP66 Rated, heater
CCTV
TB-IK6420A
• 540 lines of horizontal resolution
• 0.2 Lux @ F1.0
• 10-bit DSP technology
• 50dB signal-to-noise ratio
• Back light compensation
• 12VDC/24VAC
• Lens not included
KA-GEAC Series
• New 26X day/night camera with removable IR cut filter
• Built-in coax and UTP video connections
• SilkTrak direct drive for smooth & precise PTZ
movement
• Comprehensive programming choices via graphical
menus provide flexibility for all applications
• EPTZ900/1000/3000 incl. power supply & arm mount!
• All PTZs have Pelco-P & Pelco-D Protocol
DaVinci Lite Mini PTZ Dome
Outdoor/Indoor & Indoor Ceiling Mount
8O-NDB100K
• Settings available on OSD (on screen display with
SRX-Pro)
• Horizontal resolution 480 TVL
• VF 2.9 ~ 42mm, 0.07~2.5 Lux
• Zoom ratio 100x (optical 10x digital 10x)
• True day/night, indoor/outdoor
• Auto flip function, 360° Quick Endless Rotation
• Auto Tracking White Balance
• Flush, surface and optional wall mount (8O-DB104WM)
8O-NMC260
8O-NLC260
8O-NQC260
• 26x zoom- 312x (optical 26x, digital 12x)
• 0.01 Lux sensitivity (monochrome)
• Built in alarms: 7 sensors-intelligent camera
• Horizontal resolution 550 TVL
• 64 preset positions, auto flip, and build in alarm
• Privacy masking, preset tours and auto pattern
Speed Dome Camera System
HD6 Series PTZ Domes
IK-PCS35
• 1/4-inch CCD 470TVL
• S/N 50dB
• 23X optical and 10X digital zoom
• Minimum illumination 0.06 lux f1.2
• Day & Night function
• 360°/second endless Pan/Tilt
• Electronic sensitivity up max 32 times
• Automatic electronic shutter (AES)
• Various optional indoor or outdoor mounts available
• AC24V
HDXANWASW
• Rugged Dome
HDXFNBACB
• Pressurized Dome
• 0.07 lux color sensitivity, 0.008 lux TDN
• 18X color, 18X TDN, 23X WDR & TDN and 25X TDN
cameras available
• Up to 12X digital zoom available
• 95 mm zoom length in 25X TDN
• 98 preshots, 10 Vectorscans, 3 tours
• Pan speed variable to 400°/sec., tilt speed to 200°/sec.
ACUIX ES PTZ Domes
Affordable Low Profile PTZ Dome
•
•
•
•
•
ACUIX ES
ACUIX ES
In-Ceiling Mount
ACUIX ES
Surface Mount
Smaller footprint than standard ACUIX domes
18X auto-focus PTZ dome with 470 TVL resolution
Fixed camera option utilizes 540 TVL resolution
In ceiling, surface mount or pendant mount options
Password protection prevents unauthorized users from
changing system settings
• Standard features include coax video and two contact
inputs
• Multi-language menus (English, French, German, Dutch,
Italian, Polish, Spanish)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
141
green savings
Save some green.
The newest member of our popular ACUIX™ PTZ dome family provides
system-wide flexibility at a competitive price. The ACUIX™ ES offers superior
ACUIX™ ES
Surface Mount
quality video with excellent color reproduction and solid low light performance,
and it works with all Honeywell DVRs, encoders and switchers. The dome is
backward compatible and works with existing PTZ controllers from Honeywell
and many other manufacturers. The On-Screen Display, step-by-step quick
install guide, and clearly labeled terminal blocks and dip switch settings make
installation a snap. First, save on the camera. Then, save on installation. And
ACUIX™ ES
Pendant
finally, save on the cost of service calls and callbacks – because ACUIX ES
is backed by the Honeywell name, you know it’s protected by the best support
and service in the industry.
ACUIX™ ES
In-Ceiling
The ACUIX PTZ line features five housing configurations and four integrated
high-resolution, auto-focus cameras for virtually any application.
For more information, please visit www.honeywellvideo.com
© 2009 Honeywell International Inc. All rights reserved.
Speed Domes
Outdoor Pendant
Indoor Pendant
In-Ceiling
CCTV
HDXWM1
HDXCMA1
HDXPMA1
HDCM1
ACUIX PTZ Speed Dome Cameras
• ACUIX Features:
* 35X Wide Dynamic Range (WDR), True Day/Night, Motion Detection, and Electronic Stabilization (HDXG series)
* 18X & 26X, 530 TVL, 128X Wide Dynamic Range (WDR), True Day/Night (HDXJ & HDXF Series)
* 18X Color, 470 TVL, (HDXA Series)
* IP66 outdoor pendant and rugged housings
* Remote firmware updates
* Secure backup of all camera settings
* Active UTP video output standard in all domes
* 4 dry contact inputs
* Up to 150 user-defined presets
* 16 preset tours of 64 presets each
* 32 Dynamic Privacy Zones
* Password protection prevents unauthorized users from altering system settings
* Built-in surge and lightning protection
* Menus are provided for English, French, German, Dutch, Italian, Polish, and Spanish
MODELS AND FEATURES
MOUNTS AND ACCESSORIES
HDXGNWASW
• Outdoor pendant 35X, Wide Dynamic, True Day/Night,
smoke, white housing
HDXGNWACW
• Outdoor pendant 35X, Wide Dynamic, True Day/Night,
smoke, white housing
HDXFNWASW
• Outdoor pendant 26X, Wide Dynamic, True Day/Night,
smoke, white housing
HDJNWASW
• Outdoor pendant 18X, Wide Dynamic, True Day/Night,
smoke, white housing
HDJNWACW
• Outdoor pendant 18X, Wide Dynamic, True Day/Night,
clear, white housing
HDXJNPASW
• Indoor Pendant, 18X, Wide Dynamic, True Day/Night,
smoke, white housing
HDXANPASW
• Indoor Pendant, 18X, Color, smoke, white housing
HDXANDASW
• In-Ceiling, 18X, Color
HDXWM1
• Indoor/Outdoor Wall Mount
HDXCMA1
• Corner Mount Adapter for HDXWM1
HDXPMA1
• Pole Mount Adapter HDXWM1
HDXPRM2
• Parapet and Roof Mount
HDCM1
• Ceiling mount for indoor pendant
HJZTP
HDCD8TP
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
143
Speed Domes
Spectra IV and Spectra IV SE Series
Dome Systems
Spectra Mini Dome System
CCTV
PE-SD4W0
PE-SDW1
• Single Model for Surface Mount and In-Ceiling Applications
• Autofocus, High Resolution Integrated Color Camera/Optics
Package
• 80X Zoom (10X Optical, 8X Digital)
• Zone and Window Blanking
• 64 Presets w/ 0.5° Preset Accuracy
• 140°/second Pan Speed
• Window Blanking
• Proportional Pan and Tilt
PE-SD4 Series
• 2 Autofocus, High Res Integrated LowLightTM Color
Camera/Optics Packages (Spectra IV)
• 3 Autofocus, High Res Integrated Camera/Optics Packages; Multiple Back Box Models (Spectra IV SE)
• Zone and Window Blanking
• Built-in Surge and Limited Lightning Protection
• Integrated Passive (UTP) Circuit
• Camera Title Overlay, 20 User-Definable Characters
• On-Screen Compass and Tilt Display
• Freeze Frame During Presets • Internal Scheduling Clock
10X Mini Speed Dome
18X Speed Dome
RA-SD10XDN2W
• 10X Optical/10X Digital Zoom
• 200° second speed
• True Day/Night (moving filter)
• Weatherproof housing with heater (IP66)
• Aluminum body, polycarbonate dome
• Pelco D/P protocol, 165 presets
• Flush, Surface, and Wall Mount options
• 24VAC
• IP version available
RA-SD18XDN
• 18X Optical/12X Digital Zoom
• 350° second speed
• True Day/Night (moving filter)
• Weatherproof housing with heater (IP66)
• Pelco D/P protocol, 165 presets
• Weatherproof housing available
• 24VAC
26X Speed Dome
1/4" Day/Night, Pan-Tilt-Zoom Dome Camera
RA-SD26XDN
• 26X Optical/12X Digital Zoom
• 350° second speed
• True Day/Night (moving filter)
• Weatherproof housing with heater (IP66)
• Pelco D/P protocol, 165 presets
• Weatherproof housing available
• 24VAC
OG-SCCC6403
• 1/4” IT Super HAD CCD
• 480 TVL of resolution
• DSP (Digital Signal Processing)
• Minimum Scene Illumination:
0.005 Color/0.0005 B/W lux @ 15 IRE, sens-up x 160
• 32X Optical Zoom plus 10X Digital Zoom
• Digital Image Stabilization • 4 Alarm Inputs, 3 Alarm Outputs
• 350º Panning, 0º ~ 90º Tilting • Hi-Speed Pan/Tilt (400°/sec)
• BLC/AGC • Motion Detection • OSD (On Screen Display)
• AC24V (60Hz)
36x WDR, Day/Night,SmartDomeTM,
PTZ Camera
Pan-Focus PTZ Mini Dome Camera
SY-VCCP9574S
• NO FOCUS ADJUSTMENTS REQUIRED
• Super High Resolution of more than 520 TV Lines
• Minimum Illumination 1.9 lux
• Built-in x2.6 Motorized Zoom Pan Focus Lens,
f=2.8-7.3mm (F=1.9-3.0)
• PTZ Operation by RS-485/Coaxial Control
• Built-in UTP Module • 3 Year Warranty
• Built-In motion detection & 4 privacy masking functions
• 12VDC/24VAC dual power operation
• Also available: SY-DP9584S - Vandel Resistant Version
OG-SCCC7478(C)
• 1/4” 410K/470K Pixels ExView - HAD Progressive Scan
CCD
• Hi Res: 540 (color)/570 (B/W) TV
• x36(f=3.4~122.4 mm) Optical Zoom Lens (x12 D-Zoom)
• Min. illumination: 0.42 lux (Color), 0.0450 lux (B/W) at
15 IRE
• Full Auto focus function
• 360˚ Endless PAN (Slip-ring), 0~180˚ Tilt
• PAN Speed (Max 360˚/sec), Tilt Speed (360˚/sec)
High Resolution PTZ Camera Systems
SY-VCC9800 Series
• 36X, Day/Night, 540 TV Lines
SY-VCC9700 Series
• 36X, Color, 540 TV Lines
SY-VCC9600 Series
• 30X, Day/Night, 540 TV Lines
SY-VCC9500 Series
• 30X, Color, 540 TV Lines
Indoor/Outdoor High Performance
Motorized Dome Camera
SO-HT650PTDZ
• Resolution 540 lines • 3X digital zoom
• 4-9mm auto iris vari-focal lens
• 64 preset positions • Motorized pan & tilt
• Remote control available: SO-RC650
• Optional mounts available: Ceiling, Wall,
Corner/Pole Adaptor & Junction Box
• 5 year warranty
• Also available SO-H650PT10X
(3.8-38mm 10X motorized optical zoom)
144
•
•
•
•
•
•
•
•
•
30X, 36X Optical Zoom and 16X Digital Zoom
High Speed Panning of 435°/sec
Preset Accuracy to +/- 0.014 of a degree
Image Stabilization Function (for SY-9800, SY-9700)
Auto Tracking Function (for SY-9800, SY-9700)
Mirror Image Function
Indoor, Outdoor, and In-Ceiling versions
IP Ready with Optional Network Board (SY-VA80LAN)
Hot swappable camera unit
Tamron DCV12 Mini-Dome Camera
TM-DCV12NRA
• 12X Optical Tamron Zoom Lens covers 3.8-45.6mm
(5-60mm 1/3” equiv.)
• High Resolution 540 TV Lines with 1/4” 380K CCD
• Tamron’s unique multiple-layer coatings minimize
ghosting and flare
• Speedy Installation with Tamron AF Install Mode
• Push button controls for field of view and focus
• Privacy Masking Function
• RS485 compatible, Dust/Water Resist (IP66)
• AC24V or DC12V
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Speed Domes - Other Cameras
Day/Night Color PTZ Dome Camera
TB-IKDP30A
• 480 lines of horizontal resolution
• 0.01 lux Minimum Illumination
• 216X zoom- 18X optical, 12X digital
• Auto focus & auto iris with manual overrides
• Focal length f=4.1 mm to 73.8 mm
• 360° continuous pan & 92° tilt
530 TVL 22x Day/Night Mini Vandal
PTZ Dome Camera
DD-CAMVSD22XB
• Day & Night Function with Mechanical IR Cut Filter
• Remotely Controllable Intelligent PTZ Camera System
• 22X Optical Zoom/11X Digital Zoom
• Pan: 360º Endless, Tilt: 0º ~ 90º
• Compact Specially Designed for Interior/Exterior (Weatherproof IP66 Rated)
• Up to 60 Programmable Preset Position
• Up to 63 Programmable ID
Digital Watchdog Vandal Dome
Camera Series
6K-D Series
• 1/3” Sony Super HAD CCD (6K-D2252DIR/
6K-D2262DIR/6K-D2362DIR/6K-D2363TIR/
6K-D2372TIR/6K-D1362D)
• 1/3” Samsung CCD (6K-D4252)
• CMOS Sensor/PIXIM CHIP (6K-D1365T)
• 3.3 ~ 12mm Varifocal Auto Iris Lens (6K-D2262DIR/
6K-D2362DIR/6K-D1365T/6K-D2363TIR/6K-D1362D)
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
(6K-D2372DIR/6K-D3282TIR/6K-D1373D)
• 3.6mm Fixed Lens (6K-D2252DIR)
6K-V Series
• 1/3” Sony Super HAD CCD (6K-V1363TIR/6K-V1372TIR/
6K-V3363D/6K-V2262D/6K-V1362DIR)
• CMOS Sensor/PIXIM CHIP (6K-V1365T)
• 3.3 ~ 12mm Varifocal Auto Iris Lens (6K-V1363TIR/
6K-V1372TIR/6K-V3363D/6K-V2262D/6K-V1362DIR/
6K-V1365T)
• 3X Zoom Omni-Focus 2.9 ~ 8.5mm Varifocal Auto Iris
(6K-V1372TIR/6K-V1382TIR/6K-V3373D)
• Programmable Privacy Zone and Motion Detection;
Mirror Image Control (6K-V1363TIR/6K-V1372TIR/
6K-V3363D/6K-V1362DIR)
Accord Integrated
Camera Positioning System
Megapixel Cameras
KA-PTZ
• Provides “on screen” video display for system set up,
unit addressing and status monitoring
• Pan/tilt preset position repeatable to 0.25°
• Self-calibrates upon power-up
• Weather-resistant housings with sunshield protect
against direct sunlight exposure
CCTV
Digital Watchdog Indoor Dome
Camera Series
KA-MP2
KA-MP3
• Record high-resolution images with a network camera
• Enlarge images to see detail when reviewing recorded
video
• Full motion, progressive scan video:
1920 X 1200 at 20 frames per second
• Day/night model automatically switches from color to
monochrome in low light
• MJPG compression with 21 levels of quality
• Easy to program for maximum flexibility in most
applications
Puck Infrared Illuminator
ExitView® Height Strip Camera
XS-SWIRWDC
XS-SWIRWAC
XS-SWIRCDC
XS-SWIRAC
• Capture images in total darkness 40' away
• 360° sweep when ceiling mounted
• Configured with 25 wide/narrow angle LED’s
• 12VDC and 24VAC models available
HSS37NS
• Silver with height strip windows, 3.7mm lens
HSB37NS
• Black with height strip windows, 3.7mm lens
Infared IR Bullet Camera
Super High Resolution Color Camera
8O-SDR431
• 18 IR LEDs
• 1 Photodiode Sensor, 30m (850nm, 30 degree)
• IR Vandal-resistant (1000kg) Dome Camera Day/Night (ICR)
• UTP, DNR, AWB, IP67
• Surface & flush Mount type, Service Extra-Video Out
• 12VDC/24VAC, 3-Axis, 1/3" SONY CCD, 560 TVL
• AGC on/off, BLC on/off , Flicker less on/off
8O- SCR363
• 3.3~12mm, 36LED (35m), ICR Day/Night,
12VDC/24VAC, IP66
8O-SCB290
• Wide Dynamic Range
• 0.0045 Lux, 12VDC/24VAC
• High resolution 530 TVL/OSD
8O-SCB231
• 0.01 Lux, 12VDC/24VAC
• High resolution 540 TVL and compact design
• DSP color camera
• 1/3" Sony CCD, indoor/outdoor use
• AGC on/off, BLC on/off, WB auto, digital D/N
Pre-Assembled Outdoor Day/Night Camera
MOD Indoor/Outdoor “LAMP” Camera
IK-PAC508OD
• 2.8mm ~ 12mm, Digital DN, 520TVL, 0.15lux
IK-PAC508OD2
• 5mm ~ 50mm, Digital DN, 520TVL, 0.015lux
IK-PAC509OD
• 2.8mm ~ 12mm, True DN, 540TVL, 0.075lux
IK-PAC509OD2
• 5mm ~ 50mm, True DN, 540TVL, 0.075lux
IK-PAC509ODH
• 2.8mm ~ 12mm, True DN, 540TVL, 0.075lux, Heater
IK-PAC509ODH2
NF-MODLAMPCI
• Color 3.7mm, 1/4" CCD, 470 lines, 0.5 lux
NF-MODLAMPHI
• Day/Night Color 3.6mm, 1/3" CCD, 580 lines, 0.8 lux
•
•
•
•
•
•
Discreet, cost effective solution for loss prevention
1/3" color CCD, 350 TVL
Available as height strip or covert black strip
Easy to install - power supply included
Available in silver or black metal housing
Optional 15° angle adapter also available for extended
field of view (HSSAM - silver or HSBAM - black)
• One Wire Video™ - Power and Modulation over Coax
• Available in Ivory
• Available in MOD, PoC, UTP, and VID
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
145
Other Cameras - Lenses
VID In-Wall “JBOX” Camera
NF-VIDJBOXCB
• Color 3.7mm, 1/4" CCD, 470 lines, 0.5 lux
NF-VIDJBOXHB
• Day/Night Color 3.6mm, 1/3" CCD, 580 lines, 0.8 lux
CCTV
• Power and Video over separate cables
• Available in Black
• Available in MOD, PoC, UTP and VID
VID Indoor/Outdoor Camera
VID Indoor Low Profile “EYE” Camera
NF-VIDCAMCW
• Color 3.7mm, 1/4" CCD, 470 lines, 0.5 lux
NF-VIDCAMHW
• Day/Night Color 3.6mm, 1/3" CCD, 580 lines, 0.8 lux
NF-VIDEYEC(X)
• Color 3.7mm, 1/4" CCD, 470 lines, 0.5 lux
NF-VIDEYEH(X)
• Day/Night Color 3.6mm, 1/3" CCD, 580 lines, 0.8 lux
• Power and Video™ over separate cables
• Available in MOD, PoC, UTP and VID
• Power and Video over separate cables
• Available in MOD, PoC, UTP and VID
X = W (white), N (nickel)
VID Indoor/Outdoor “LAMP” Camera
Category 5 Cameras
NF-VIDLAMPCI
• Color 3.7mm, 1/4" CCD, 470 lines, 0.5 lux
NF-VIDLAMPHI
• Day/Night Color 3.6mm, 1/3" CCD, 580 lines, 0.8 lux
H4-F2286WH
• B/W mini camera, indoor only
H4-F2284
• B/W bullet camera, weatherproof
H4-F2299
• Color bullet camera, weatherproof
H4-F2287
• Infrared bullet camera, weatherproof
• Power and Video over separate cables
• Available in Ivory
• Available in MOD, PoC, UTP and VID
• On-Q camera solution has the ability to easily convert
any Cat 5 outlet to support a security camera
Flush-Mount Low-Profile UFO Camera
Aspherical Vari-Focal Day/Night Lenses
SL-EV122CFVB
• White case
• 3.7mm pinhole lens
• 420 TV Lines
• 1/3" Sony Super HAD CCD
• True Day/Night
• Lens rotates for ceiling or wall mount
• No exposed screws
HLD29V8DNL
• 2.9 - 8 mm F/0.95, DC Auto Iris, IR corrected
HLD27V13DNL
• 2.7 - 13.5 mm F/1.3, DC Auto Iris, IR corrected
HLD5V50DNL
• 5 - 50 mm F/1.6, DC Auto Iris, IR corrected
Aspherical Vari-Focal Lenses
• Compact & lightweight
• Quick & accurate adjustment of image field of view and focus
HLD5V50F13L
HLM28V8F95
• 5 - 50 mm F/1.3, DC iris, long lead
• 2.8 - 8 mm F/0.95, manual iris
HLM25V6F12
HLD28V8F95L
• 2.5 - 6 mm F/1.2, manual iris
• 2.8 - 8 mm F/0.95, DC iris, long lead
HLD25V6F12L
HLM5V50F13
• 2.5 - 6 mm F/1.2, DC iris, long lead
• 5 - 50 mm F/1.3, manual iris
1/3" 3.5mm-8mm F1.4-300 Vari-Focal Lens
PX-C70319
• The most popular vari-focal lens in the industry
• Mega-pixel compatible resolution
• Super competitive pricing
146
1/3" 3-8mm F1.0-360 Day/Night
Vari-Focal Lens
PX-C70315DCP
• The original Day/Night Lens Family of Pentax
• Ultra high speed f-stop
• 93º wider view angle
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Lenses
1/3" 5-50mm F1.8-360 Vari-Focal Lens
PX-C70223DCP
• The most versatile vari-focal lens
• Ideal focal length for short-range & mid-range surveillance
• 93º to 23º view angle
PX-C7059DCPS
• Vari-Focal lens for mid-range & long-range surveillance
• 50º to 5º view angle
1/3" 1.6-3.4mm F1.4-64 Fish-Eye
Vari-Focal Lens
1/3" 2.8-6mm F1.4-300 Day/Night
Vari-Focal Lens
PX-C70100PS
• The industry’s best fish-eye vari-focal lens
• 180º horizontal and vertical view angle
• The least distortion among all the fish-eye lenses
• Ideal for wide-coverage surveillance
PX-C70220DCP
• The original Day/Night Lens Family of Pentax
• For wide-angle vari-focal use
• 96º wider view angle
1/2" 6-12mm F1.6-300 Day/Night
Vari-Focal Lens
1/2" 12-1680mm F4.0-360 55x Zoom Lens
PX-C60635DCP
• The original Day/Night Lens Family of Pentax
• Compatible up to 1/2" cameras
CCTV
1/3" 2.8-12mm F1.4-360 Vari-Focal Lens
PX-C61244
• The original long-range lens optics of Pentax
• Built in 2.5x extender
• Serial control available
• Superb optics and mechanics
The leader in High Quality Optics
Most versatile vari-focal
1/3”, 2.8-12mm
F1.4-360
Manual or DC Iris
PX-C70226/PX-C70223DCP
High quality Fish-Eye lens
1/3”, 1.6-3.4mm
F1.4-64
DC Iris
PX-C70100PS
Best 1/3” Day and Night lens
1/3”, 3-8mm
F1.0-360
Manual or DC Iris
PX-C70316/PX-C70315DCP
Best 1/2” Day and Night lens
1/2”, 6-12mm
F1.6-300
Video & DC Iris
PX-C60635DCP
Most competitive vari-focal
1/3”, 3.5-8mm
F1.4-300
DC Iris
PX-C70319
Most widely used long-range zoom
1/2”, 12-1680mm
F4-360
w/2.5X Extender
PX-C61244
Best long-range vari-focal
1/3”, 5-50mm
F1.8-360
Manual or DC Iris
PX-C91199/PX-C7059DCPS
Angle Viewer
All standard formats
1mm to 115mm
Lightweight with a carrying case
PX-C91610
www.pentaxcctvus.com
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
147
CCTV
Lenses
Angle Viewer
13M Series Megapixel Varifocal Lens
PX-91610
• All Standard Formats
• 1mm to 155mm
• Light weight with a handy carrying case
PE-13M Series
Pelco’s 13M Series megapixel varifocal lenses are a new
class of lenses specially designed to provide optimal
results when used in cameras with megapixel sensors.
These lenses enable megapixel cameras to realize the
high resolutions that standard lenses cannot deliver, with
a resolving power of up to 100 lines per millimeter. These
lenses provide excellent image quality at both the center
and at the corner of the image.
• Up to 3 Megapixels (MPx)
• CS Mount
• For use with 1/3-Inch Cameras
• Auto Iris, Manual Focus, and Zoom
Wide Angle Vari-Focal Lens
Day/Night Vari-Focal Lens
RA-L163VDC4P
• 1/3" 1.6-3.4mm F1.4
• All glass optics
• 180° field of view
• Locking screws
• 4 year warranty
RA-L212AVDC4PIR
• 1/3" 2.7-12mm F1.2
• Aspherical
• All glass optics
• Locking screws
• 4 year warranty
Day/Night Vari-Focal Lens
Mega-Pixel Day/Night
RA-L298AVDC4PIR
• 1/3" 2.9-8mm F0.95
• Aspherical
• All glass optics
• Locking screws
• 4 year warranty
RA-LM308VDCIR
• 1/3” Formatted CS Mount Lens
• 1.3 Mega-Pixel
• Day/Night IR Corrected
• 3-8mm Focal Length
• F1.4 with DC Auto-Iris
• All Glass
• 4 year warranty
Mega-Pixel Vari-Focal
Day/Night Vari-Focal Lens
RA-HM880VDCIR
• 1/3” 8~80mm F1.6
• 1.5 Mega-Pixel
• Auto Iris (Manual Iris Available)
• Day/Night IR Corrected
• C-Mount
RA-L308VDC4PIR
• 1/3" 3-8mm F1.2
• All glass optics
• Locking screws
• 4 year warranty
Day/Night Vari-Focal Lens
Day/Night Vari-Focal Lens
RA-L555VDC4PIR
• 1/3" 5-55mm F1.4
• All glass optics
• ED glass (Extra Low Dispersion)
• Locking screws
• 4 year warranty
RA-L880VDC4PIR
• 1/2" 8-80mm F1.6
• All glass optics
• ED glass (Extra Low Dispersion)
• Locking screws
• 4 year warranty
Mega-Pixel Vari-Focal Lens
1/3" 10-40 F/1.4
IR ASL Vari-Focal Lens
RA-LM212VDC4P
• 1/3" 2.8-12mm F1.4
• 1.4 Mega-Pixel
• Locking screws
• DC auto-iris with 4-pin
• Manual iris version available
• 4 year warranty
148
TM-13VG1040A
• Telephoto Day to Night IR-corrected lens
• Aspherical Optical Technology
• Fast F/1.4 aperture
• Minimum F/360 aperture
• Zoom and focus locks
• DC Iris
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Lenses - Monitors
1/3" 2.8-11 F/1.4
IR ASL Vari-Focal Lens
TM-13VG246MG
• Ultra-wideangle Vari-Focal lens
• Optimized for mega-pixel surveillance camera
applications
• Excellent for close-up image capturing
• Special multi-coating to prevent flare and ghosting
• Aspherical Optical Technology
TM-13VG2811A
• Aspherical Optical Technology
• IR-corrected for use with Day/Night cameras
• Wide to tele coverage (97° ~ 26°)
• Fast F/1.4 aperture
• Minimum F/360 aperture
• Zoom and focus locks
• DC Iris
1/3" 3.0-8mm F/1.0
Mega-Pixel Compatible Lens
1/3" 3.0-8 F/1.0
IR ASL Vari-Focal Lens
TM-13VG308MG
• Fast F/1.0 maximum aperture for cameras positioned
in dark places
• Supports mega-pixel surveillance cameras
• Special multi-coating to prevent flare and ghosting
• Aspherical Optical Technology
TM-13VG308IR
• Aspherical Optical Technology
• Day to Night near IR solution
• Fast F/1.0 aperture
• F/360 minimum aperture
• Zoom and focus locks
• DC Iris
1/3" 5-50mm F/1.4
Mega Pixel Compatible Vari-Focal Lens
9" B/W Monitor
TM-13VG550MG
• High-power Vari-Focal lens covering the typical telephoto focal length
• Supports mega-pixel surveillance cameras
• Special multi-coating to prevent flare and ghosting
• Aspherical Optical Technology
• 10X magnification with fast F/1.4 ~ F/360 aperture
• Zoom, iris and focus locks
CCTV
1/3" 2.4-6mm F/1.2
Mega-Pixel Compatible Lens
HMM9
• Black cabinet
HMM9X/P
• Gray cabinet
• 1000 TVL
• Ideal for video surveillance applications where single
camera viewing on dedicated monitors is a requirement
• 3 year warranty
• Dual rack kit AMM9RK2
12" B/W Monitor
13" CRT Monitor
HMM12
• Black cabinet
• 1000 TVL
• DC restoration
• Steel cabinet
• Rack mountable
• EIC/CCIR selectable
• 120/230 VAC
• 3 year warranty
JV-TMA13SU
JV-TMA13UCV
• 320 TV lines of horizontal resolution
• Two composite video inputs
• One Y/C input (JV-TMA13SU)
• Two audio inputs (JV-TMA13SU)
• NTSC/PAL multi-standard compatibility
• Built-in speaker (JV-TMA13SU)
14" Hi-Performance CRT Monitor
Color CRT Monitors
HMC14HR
• 400+ lines resolution/comb litler
• Universal power
(100 to 240 VAC with detachable power cord)
• Multi-channel video inputs A/B (composite, Y/C with independent settings
• Auto NTSC/PAL scan system selectable
• Auto termination BNC connector
• 2 channels of looping audio inputs
• Black cabinet
IK-VCM901
• 9” Color Monitor
• 300TVL horizontal resolution
• BNC x2, S-Video x1
• NTSC/PAL
IK-VCM14H
• 14” Color Monitor
• 350TVL horizontal resolution
• NTSC/PAL
IK-VCM200A
• 20” Color Monitor
High Perfromance 14" Color Monitor
High Resolution 15" Monitor
SY-VMC8614F
• 14” viewable CRT with 90° deflection
• More than 800 lines of horizontal resolution
• Dual TV STandard - NTSC and PAL
• Composite video and audio A/B inputs
• S-Video inputs
• Sequential A/B Inputs
KA-MVC15HS
• NTSC or PAL system selectable
• Audio in/out
• Shielded case to reduce interference
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
149
CCTV
Monitors - LCD Monitors
17" Monochrome Monitor
PMCS Monitor Series
HMM17
• 800 lines resolution
• DC restoration
• Black steel cabinet
• Rack mountable
• EIA/CCIR selectable
• 120/230 VAC
• 3 year warranty
PE-PMCS15A, PE-PMCS17A, & PE-PMCS19A
• Super-High Resolution
– PE-PMCS15A and PE-PMCS17A - 700 TV Lines
– PE-PMCS19A - 800 TV Lines
• Computer Grade Picture Tube
• Front Panel Controls
• Auto-Ranging 90-260 VAC Input
• Auto-Sensing NTSC/PAL • Built-in Speaker
• Video and Audio Input and Output
• S-VHS Input for Separate Y-C Signals
• Rack Mountable
21" Color Monitor
21" Flat CRT Color Monitor
HMC21
• 450 TVL
• Black steel cabinet
• Video A/B or Y/C
• NTSC/PAL selectable
• On-screen display (DSD)
• Universal power (100 to 240 VAC)
• 3 year warranty
JV- TM21A2U
• 2 Video Inputs (RCA)
• 1 Monitor Output (RCA)
• 2 Audio Inputs (mono)
• NTSC / PAL / SECAM Compatibility
• Remote Control Unit
• Built in Speakers
• Commercial/Industrial rated for 24/7 operation
PVM (Public View Monitor) - 20”, 26”
and 32”
Commercial Grade LCD Monitor
AV-M200LC2
AV-M201LC2WDR
AV-M260WLC
AV-M261WLCWDR
AV-M320WLC
AV-M321WLCWDR
• Compact attractive look for high visibility retail
applications
• Front facing stereo speakers with two 5.0W amplifiers
• Low-voltage 12VDC (20” models) and 24VDC
(26” & 32” models) operation
150
HD-HDDS42AV
• 42” High Definition Large Format Display, Metal Case
• Selectable Horizontal and Vertical Viewing
• 1920 x 1080 @ 60Hz
• 2000:1, 6.5ms, 500 nits, 16.7 million color
• Video input RCA connection (BNC adaptor included)
• VGA, S-Video, DVI, audio
• Wall mount option
4", 5.6" & 7" Color Test Monitor
8" RTC / 8.4" RTF Monitor Series
4O-TM4
4O-TM5
4O-TM7
• Active Matrix, TFT 4", 5.6" & 7"
• Resolution: 4"-480 x 234, 5.6"-960 x 234, 7"-1440 x 234
• 16 million true full color
• Interface: 2 x video in (RCA type), 1 x video out (RCA
type)
1 x audio in (RCA type), 1 x audio out (Jack type)
• Special feature: 4O-TM4, 5, 7 - Left & Right reverse picture
• 4O-TM7 - top & botttom reverse picture, 1 x waist belt,
1x carry belt, carry bag, battery
40-8RTC
• Resolution 800x600, Brightness 250 cd/m2, Contrast
500:1
40-8RTF
• Resolution 800x600, Brightness 600 cd/m2, Contrast
600:1
8.4" High Resolution LCD monitor
14" Professional LCD Monitor
IK-LCM840
• 800X600 Resolution
• Contrast Ratio 500 : 1
• Brightness 450cd/m2
• Wide viewing angle
• 3D comb filter
• NTSC or PAL auto selection
• AC100 ~ 240V with AC adaptor
• Optional dual rack adaptor
SH-LMD1410SC
• 14" LCD monitor
• Panel resolution: 640 X 480 (VGA)
• Accepts NTSC and PAL
• Accepts composite, Y/C, Component, and RGB signals
• 3% underscan and +5% overscan
• Switchable aspect ratio (4:3 and 16:9)
• On-screen menu for adjustment/operation
• Parallel remote control • Color temperature adjustment
• VESA mounting with 100mm spacings
• 19" EIA standard rack mountable
Flat Panel 15" Monitor
15" High Resolution TFT Color LCD Monitor
KA-KLC15HS
• 500 TV lines of resolution
• Microprocessor digital control
• Onscreen display operating controls
• Picture-in-Picture function
• 17" & 20" models are also available
(KA-KLC17HS/KA-KLC20HS)
SO-VM15LCD
• Displays up to 16.2 million colors
• Convenient front controls for on-screen programming
• VGA (D-Sub 15 pins), loop through stereo audio (RCA),
loop through video (BNC), PC audio input, video inputs
• Input signal detection provides easy connection
• 500:1 Contrast ratio • VESA compatible
• Regulated 12V DC 40W power supply (UL/CSA listed)
included
• Embedded comb filter • RoHS compliant
• Also avail. in 17" (SO-VM17LCD) & 19" (SO-VM19LCD)
• BNC In 2/Out 2 (Composite Video), S-Video In, VGA In,
PC Stereo In
• 3D Comb Filter, Deinterlace
• Trigger Sensor, Built in Speaker, Tilt Back Stand
• Optional: 4O-RMK08 Single or Dual Rack Mount bracket
with Tilt capability
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
LCD Monitors
Security Field Monitors
VP-LCD411
• Easy access BNC IN/OUT jacks
• LED brightness-longer life, better color, uses less power
• Battery pack included
• Optional desk stand (VP-MB1)
VP-LCD411
• 4" Monitor, 250 Nit Brightness
• Optional AC adaptor (VP-AC1000)
• Optional tote bag (VP-TB410)
• Order VP-LCD411KIT for unit with tote bag and AC inluded
• Order VP-LCD410 for audio and no BNC (incl. 3.5mm A/V IN/OUT jacks with cables)
VP-LCD565
• 5.6" Monitor, 300 Nit Brightness
• Optional AC adaptor (VP-AC2000)
• Optional tote bag (VP-TB565)
• Order VP-LCD565KIT for unit with tote bag and AC inluded
• Order VP-LCD562 for audio and no BNC (incl. 3.5mm A/V IN/OUT jacks with cables)
VP-LCD565
CCTV Monitors
VP-LCD801
CCTV
VP-LCD640
• Composite NTSC/PAL video
VP-LCD640
• 6.4" LCD with audio, 960 H x 234 V, 300 Nit
• Audio included (DIN cable with BNC video)
VP-LCD801
• 8” free-standing LCD in ABS housing, 350 Nit brightness
• Composite (RCA), S-Video
• Mirror and upside down image picture control
• Remote control and AC adaptor included
• Order VP-LCD800 for BNC IN/OUT
• Order VP-LCD800L for flush-mounted version
Rack Mounted Monitors
• Standard 19" Rack Mount
• BNC IN/OUT
• LED brightness-longer life, better color, uses less power
VP-LCD400X4
• Four 4" LCD in Quad rack mount, tilt 90°, occupies 2 RU
• Composite video loop through for all 4 monitors
VP-LCD560X3
• Three 5.6” in Triple rack mount, tilts 90°, occupies 3 RU
• Composite video passive loop through for all 3 monitors
VP-LCD703HD2
• Two 7" HD Dual rack mount, occupies 3 RU
• HD 1080P compatible, 16:9
• Composite, S-Video, component, RS-232, & PC
• Order VP-LCD-703HD1 for single unit in rack mount kit
VP-LCD400X4
VP-LCD560X3
VP-LCD703HD2
Small HD Monitors
VP-LCD1048HD
VP-LCD703HD
• HD 1080p compatible
• Composite video, S-Video, component, RS-232- & PC
VP-LCD703HD
• 7" HD, 16:9
• 800 x 600 resolution, 350 Nit, 300:1 contrast
• Order VP-LCD703KIT for unit with tote bag and rechargeable battery
• Order VP-LCD703HDA for Anton Bauer version
• Order VP-LCD703HDV for IDX battery version
• Order VP-LCD703HX for free-standing unit with no front controls
• Order VP-LCD703HDL for flush mount unit
• Order VP-LCD703HDX for flush mount unit with no front controls
VP-LCD1048HD
• 10.4" HD, 4:3
• 1024 H x 768 V, 350 Nit, 500:1 contrast
• Order VP-LCD1048HDL for flush mount unit
• Order VP-LCD1048HLX for flush mount with no front controls
• Order VP-LCD1048HDR for rack mount unit
VP-LCD1080HDM
• 10.4" HD, 4:3, in metal housing
• Tempered glass and screw-down DC feature
• Order VP-LCD1048HM2 for 2 units in rack mount kit
VP-LCD1048HDM
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
151
LCD Monitors
LCD TVs
VP-LCD1411T
CCTV
VP-LCD1044T
VP-LCDATSC100
• Cable ready ATSC/NTSC/Clear QAM TV tuner
• Built-in removable desk stand, external AC included
VP-LCD1044T
• 10.4" LCD TV
• 640 x 480 resolution, 450 Nit, 400:1 contrast
• Order VP-LCD1044TC unit with custom counter mount
• Order VP-LCD1044TL unit in flush mount
• Order VP-LCD1044TU unit with custom ceiling mount
• Order VP-LCD1044TW unit with custom wall mount
VP-LCD1411T
• 14" LCD TV
• 800 x 600 resolution, 400 Nit, 500:1 contrast
• Order VP-LCD1411TC unit with custom counter mount
• Order VP-LCD1411TL unit in flush mount
• Order VP-LCD1411TR unit in rack mount kit
• Order VP-LCD1411TW unit with custom wall mount
VP-ATSC100
• ATSC/NTSC/Clear QAM receiver
• Selectable DTV output resolution (up to 1080i)
• Component and composite video outputs
• Stereo audio output
• Advanced Electronic Program Guide
• 215mm (L) x 140mm (W) x 40mm (H)
• Remote control and power supply included
Mid-Size LCD Monitors with BNC
VP-LCD1700V
VP-LCD1901HD
• BNC In/Out Video, YPbPr, PC, DVI, and RS-232
• Built-in removable desk stand, external AC included
VP-LCD1510V
• 15" Monitor; 1024 H x 768 V; 500 Nit Brightness
• Order VP-LM1510V for flush mount kit
• Order VP-RM1510V for rack mount
• Order VP-PLT1000 for VESA compliant plate
VP-LCD1700V
• 17" Monitor; 1280 H x 1024 V; 350 Nit Brightness
• VESA 100mm
VP-LCD1900V
• 19" Monitor; 1280 H x 1024 V; 450 Nit Brightness
• VESA 100mm
VP-LCD1540HD
• 15.4" HD Monitor; 16:9 Ratio
• 1280 H x 800 V; 200 Nit; 550:1 Contrast
• Order VP-LCD154HDL for flush mount kit
• Order VP-LCD154HDR for rack mount
VP-LCD1901HD
• 19" HD Monitor, 16:9
• 1440 H x 900 V; 300 Nit; 800:1 Contrast
• Order VP-LCD190HDL for flush mount kit
• Order VP-LCD190HDR for rack mount
Large HD Monitors
VP-LCD2600HD
VP-LCD4200HD
• Component, S-Video, Composite, HDMI, PC, DVI, & RS-232
VP-LCD2300HD
• 23" HD Monitor, 1366 H x 768 resolution, 500 Nit brightness
• Built-in 3D MTS stereo speakers & removable desk stand
VP-LCD2600HD
• 26" HD Monitor, 1366 H x 768 resolution, 500 Nit brightness
• Built-in 3D MTS stereo speakers & removable desk stand
VP-LCD3200HD
• 32" HD Monitor; 1366 x 768; 500 Nit; 800:1 Contrast
VP-LCD4000HD
• 40" HD Monitor; 1920 x 1080; 500 Nit; 1000:1 Contrast
VP-LCD4200HD
• 42" HD Monitor; 1920 x 1080; 500 Nit; 1000:1 Contrast
VVP-LCD4700HD
• 47" HD Monitor; 1920 x 1080; 550 Nit; 1600:1 Contrast
VP-LCD5200HD
• 52" HD Monitor; 1920 x 1080; 500 Nit; 1500:1 Contrast
VP-LCD4700HD
152
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
LCD Monitors
90 Series LCD Monitors
High Resolution LCD Monitors
B7-SCM1590
B7-SCM1790
B7-SCM2090
IK-LCM1501
• 15” LCD monitor with stand
IK-LCM1701
• 17” LCD monitor with stand
IK-LCM1901
• 19” LCD monitor with stand
•
•
•
•
•
•
•
15”, 17”, 19”, 20”, 27” full line available
3D Comb Filter
Video Inputs: 2 Composite, 1 S-Video, 1 DVI, & 1 VGA
Dynamic Noise-reduction
3 Audio Inputs
High Contrast: 1000:1 (Except 1590)
8 ms Response Time
•
•
•
•
•
550TVL horizontal resolution
Composite BNCx2, S-Video, PC inputs
Video loop through BNC x2
Two audio speakers
AC100~240V Power
Rack Mountable LCD CCTV Monitors
HD-5005L13
• 15” Monitor, 1024 x 768 (XGA)
• 8ms, 16.7M, VGA Input, 500:1, 250 Nits
HD-7005L
• 17” Monitor, 1280 x 1024 (SXGA)
• 5ms, 16.7M, VGA Input, DVI, 800:1, 300 Nits
HD-L19CB32AD
HD-9005L
• 19” Monitor, 1280 x 1024 (SXGA)
• 5ms, 16.7M, VGA Input, 800:1, 300 Nits
40-15RCR
• Resolution 1024 x 768 Brightness 250cd, Contrast 700:1
40-17RCR
• Resolution 1280 x 1024 Brightness 300cd, Contrast 1000:1
40-19RCR
• Resolution 1280 x 1024 Brightness 300cd, Contrast 1000:1
Premium Line LCD CCTV Monitors (RTC)
Value Line CCTV LCD Monitors (RTV Series)
40-15RTC
• 1024 x 768 resolution
40-17RTC
• 1280 x 1024 resolution
40-19RTC
• 1280 x 1024 resolution
4O-15RTV
• 1024 x 768, 250cd/m2, 700:1
4O-17RTV
• 1280 x 1024, 300cd/m2, 1000:1
4O-19RTV
• 1280 x 1024, 300cd/m2, 700:1
• Brightness: 250 cd/m2 (15"), 300 cd/m2 (17" & 19")
• Contrast: 700:1 (15"), 1000:1 (17" & 19")
• BNC 2 In/Out 2 (Composite Video), Audio In 2/Out2 (RCA
Type, 17" & 19")
• 3D Comb Filter, Deinterlace
Basic Line CCTV LCD Monitors
(RTA Series)
4O-17RTA
• 1280 x 1024, Brightness: 300cd/m2, Contrast Ratio: 1000:1
4O-19RTA
• 1280 x 1024, Brightness: 300cd/m2, Contrast Ratio: 1000:1
• Interface: Two composite BNC In/Out, S-Video In/Out, VGA
1280 x 1024, Brightness: 300cd/m2, Contrast Ratio: 1000:1
• Special Feature: 2D Comb filter
• 16.7 Million color
• BNC In 2/Out 2 (Composite Video), S-Video In/Out, VGA
Input, Audio In/Out.
• 3D Comb Filter & DeInterlace (17" & 19"), 2D Comb
Filter (15")
• Metal Cabinet, Tilt Capability
• Interface: 2x Composite BNC video In/Out (15, 17 & 19RTV),
1x S-video In/Out, 1x RGB In, 1x Component, 1x DVI In,
1x HDMI In (17 & 19RTV), Audio In, 1x PC Stereo In
• Special feature: LCD Protection Glass, (17 & 19RTV)
• 3D Comb filter & Deinterlace
VGA (D-Sub 15 Pin) Monitors
4O-17RTLB
• 1280 x 1024, Brightness: 250cd/m2,
Contrast ratio: 600:1
4O-19RTLB
• 1280 x 1024, Brightness: 300cd/m2,
Contrast ratio: 700:1
•
•
•
•
VGA Input
Non-glare screen, Tilt Base/Stand
Optional: wall, ceiling and rack mounts
Special Order: Touch Screen, Built-in speakers
e-Series LCD Monitors
L-Series LCD Monitors
HMLCD17E2
• 17" Monitor
HMLCD19E2
• 19" LCD Monitor
HMLCD17L
• 17" Monitor
HMLCD19L
• 19" LCD Monitor
•
•
•
•
•
High-resolution: SXGA 1280 X 1024
High brightness
High Contrast Ratio
S-Video, Composite and VGA inputs
<5 ms response time
•
•
•
•
•
SXGA Resolution: 1280 X 1024
300 cd/m2 Brightness
500:1 Contrast Ratio
Composite and VGA inputs
8 ms response time
LCD Monitors
LCD Color Monitors
TB-P1730A
• 17" Monitor
TB-P1930A
• 19" Monitor
SY-VMCL2017
• 17" Monitor
SY-VMCL2019
• 19" Monitor
•
•
•
•
•
Hi Resolution 1280 x 1024 @ 60/75 hz
Picture-in-picture • 3D Comb Filter
Contrast: 500:1 (17"), 700:1 (19")
Brightness: 300 cd/m2
VGA input, Video In/Out, Audio In/Out, stereo speakers
CCTV
Computer LCD Monitors
•
•
•
•
•
•
•
1280 x 1024 (SXGA) resolution
1000:1 High Contrast Ratio
2 Composite/1-S-Video/1-VGA Inputs
Picture-in-Picture function
2 Audio Inputs • NTSC/PAL Automatic Detection
VESA100 standard mounting bracket compatible
Remote Control
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
153
LCD Monitors
Gold Series CCTV LCD Monitors
CCTV
7O-JLM150D
7O-JLM170D
7O-JLM190D
7O-JLM150D
• 15" with 1024 x 768 resolution
• Brightness 250 cd/m² Contrast Ratio 400:1
7O-JLM170D
• 17" with 1280 x 1024 resolution
• Brightness 300 cd/m² Contrast Ratio 800:1
7O-JLM190D
• 19" with 1280 x 1024 resolution
• Brightness 300 cd/m² Contrast Ratio 800:1
• 1 BNC Looping Input/Output, 1 VGA, 1 DVI-D, 1 RCA
• VESA standard 100mm mounting • Built-in speaker
05 Value Series LCD Monitors
06 Standard Series LCD Monitors
HD-TLM1705
• 17” Monitor
• Resolution: 1280 x 1024
• Composite RCA Input with RCA-BNC Adapter Included
• 300 Nits Brightness, S-Video, and VGA
• 800:1 Contrast Ratio, 5ms Response Time
• Also available in 15” and 19”
HD-TLM1706
• 17” Monitor Also available in 15” & 19”
• Resolution: 1280 x 1024
• 1000: 1 Contrast Ratio, S-Video, VGA
• 1 Composite BNC Input/Output
• Inputs On Back Of Monitor For Easy Access
• 16.7 Million Colors, 300 Nits Brightness
• Wall & Rack Mountable
19" LCD Flat Monitor
17”/19” Ultra Resolution,TFT-LCD Monitor
8O-KW19LC19W01
• Crisp picture performance
• High resolution and high contrast ratio
• NTSC/PAL auto mode
• NTSC/PAL 3D comb filter compatible
• Composite and VGA input
• 7 Language OSD control
• Panel & base detachable
• Vibrant 500:1 contrast ratio for bright images
• Fast 5.6 ms response time for excellent video
performance
OG-SMT1722
OG-SMT1922
• 1280x1024 Resolution 600TV Lines
• 1000:1 High Contrast Ratio • 300cd/m2* High
Brightness
• 5ms Response Time • BNC Loop Through, S-Video,
VGA Inputs
• Audio with VGA • Built-In Speakers • Tempered Glass
• Comb Filter • Noise Reduction • Picture-In-Picture
• Built-In Power Supply • Height Adjustable and
Swiveling Stand (HAS)
• DNIe Technology Function with BNC Connection
07 Premium Series LCD Monitors
19” LCD DVR Monitor
HD-TLM1907
• 19” Monitor
• Resolution: 1280 x 1024
• S-Video, DVI, Audio Speakers
• 2 Composite BNC Input/Output, 1 VGA Input
• 16.7 Million Colors, 450 Nits Brightness
• 500:1
• Wall, Pole and Rack Mountable
• Also available in 17”
F8-EN7519D
• 19” LCD flat screen monitor
• Razor sharp images 1280x1024
• Contrast ratio 800:1
• Color depth of 16.2 million
• 1 VGA input, 2 BNC input/output
• 2 audio input
• 2D comb filter
• Multi-language on screen menu
• Includes cable management stand
20" System Series LCD Monitor
20" LCD CCTV Monitors
HMLCD20S
• 2 Megapixel resolution, 1600 x 1200
• High brightness, 300 cd/m2
• High contrast ratio, 800:1
• 3D comb liter and de-interlace for crisp, sharp picture
• HDMI and DVI-D direct digital inputs
• 2 sets of loooping BNC composite inputs
• Remote control
4O-20RTC
• 800 x 600, 450cd/m2, 500:1
4O-20RTH
• 1600 x 1200, 300cd/m2, 700:1
• Interface:
* 2x Composite BNC In/Out, 1x S-video In/Out, 1x RGB In,
1X DVI In & HDMI In (20RTH)
* 2x Audio In/1x Audio Out, 1x PC Stereo In
• Special Feature: 3D comb filter & Deinterlace
• LCD protection glass & Metal case, PIP (20RTH)
Public View Monitor 20", 26" & 32"
4O-20PVM
• Resolution 800x600, Brightness 450 cd/m2, Contrast 500:1
4O-26PVM
• Resolution 1366x768, Brightness 450 cd/m2, Contrast
1500:1
4O-32PVM
• Resolution 1366x768, Brightness 500 cd/m2, Contrast
1000:1
•
•
•
•
•
•
26" & 32" PIP/PBP
3D comb filter, Deinterlace
Built in Camera: Tilt, Swivel, 20" Normal Camera (WDR Optional), 26" & 32" w/ WDR
LCD Protective Shield, Microwave Motion Sensor, Built in Speakers
Optional: IP Media Board, Wall & Ceiling Mount
Special Order: 24vt power, WDR Camera for 20"
• BNC In 1/Out 2 (Composite Video), Video In, Audio In
2(RCA Type), S-Video In/Out, VGA Input, 1 HDMI input,
Camera Out, Trigger Input
154
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
LCD Monitors - Recording Devices
VisionMax Public View Monitor
KA-KTCPVM20H
• 20" LCD with built-in UltraView camera
• Perfect for retail applications to let customers know they
are on camera
• Built-in 6-in-1 flashcard reader allows you to switch
between live view & promotion slides and video
• Several mounting options avialable
• Built-in speakers allow audio playback as well
• Light, sturdy construction opens up mounting options and
requires far less structural support than a CRT
• Built-in PIR detects motion and allows switching between
various inputs
• Totally customizable to meet any customer’s needs
PC LCD Monitor
ENTER FOR
A CHANCE TO
WIN A NEW
2009
CCTV
HD-W2209S
• 22” wide monitor
• 1680 x 1050 @ 60Hz
• 16.7 Million colors, 300 Nits Brightness
• 1000:1. 5ms response time
• VGA, DVI input
CHEVROLET
CORVETTE COUPE
26" & 32" Big Premium LCD CCTV Monitors
42" Big Size Premium LCD CCTV Monitors
4O-26RTC
• 1366 x 768, Brightness: 500cd/m2, Contrast Ratio: 1000:1
4O-32RTC
• 1366 x 768, Brightness: 500cd/m2, Contrast Ratio: 800:1
4O-42RTC
• Resolution: 1366 x 768, Brightness: 500cd/m2
• Contrast Ratio: 800:1
4O-42RTH
• Resolution: 1920 x 1080 (Ful HD), Brightness: 550cd/m2
• Interface:
* 2 x Video In/Out (BNC type), 1 x S-Video In/Out, RGB In
DVI In, 2 x Audio In/Out (RCA type), 1 x PC Stereo In
1x HDMI In
• Special Feature: 3D Comb filter & Deinterlacing, Remote
• LCD Protection Glass
• PIP/PBP
• Contrast Ratio: 900:1
• Interface:
* 2x Video In/Out (BNC type), 1x S-Video In/Out, 1x RGB In,
1x Component In
* 1x DVI In, 2x Audio In/Out, 1x PC stereo, 1x HDMI
• Special Feature: 3D Comb Filter & Deinterlace PIP,
Flat Panel LCD Color 200, 300, 400 Series
PE-PMCL200 Series
PE-PMCL300 Series
PE-PMCL400 Series
• Displays range in size from 15" to 19"
• 100/240 VAC 60/50 Hz auto-ranging internal power supply
• VGA input • Digital DVI input • USB Hub • PIP
• Support ranges: 1280x1024 SXGA or 1024x768 resolution
• Typical response times: 12 ms or 16ms
• Extensive max brightness depending on model
• Contrast ratio maximums 500:1 or 600:1
• 2 looping composite inputs and 1 S-video input
• 3D digital comb filter with de-interlacing for high quality video
PMP20/PMP26 Public View Monitor
Flat Panel LCD Color 500 Series
PE-PMP20 Series
PE-PMP26 Series
• Attractive Design for High Visibility Areas
• 20-inch 4:3 or 26-inch 16:9 Format LCD with Integrated
WDR Camera
• 3-D Digital Comb Filter and De-Interlace Capability
• 2 Looping Composite Inputs
• 1 Camera Output for Internal Camera Video
• Integrated Memory Card Reader
• Built-in Motion Sensor • Mirror Mode
• Sleep Mode Light Sensor • Scalable and Swappable
Picture-in-Picture (PIP) Mode
PE-500A Series
• Displays range in size from 23" to 42"
• Wide screen large format displays
• Compatible with Pelco multiviewers
• HD resolution
• Slim design
• High contrast ratio
• Brilliant colors
Falcon DR Series Digital Video Recorder
Real Time Video Casette Recorder
AV-FADR8160C
AV-FADR8250C
AV-FADR8500C
AV-DR1625DVD
AV-DR1650DVD
• 8 or 16 channel DVR with 2 audio ports
• Recording rate: 120-ips
• 1-spot monitor output
• Features video motion detection, digital zoom (2x), and
one-touch clip copy
• Remote monitoring with RAS plus via Ethernet
• 2dvr.com compatible
OG-SRV960A
• Real/Time Lapse VCR
• Recording Speeds: 6/18/30/72/120/168/240/480/960Hrs
• 300TV Lines (Color), 350TV Lines (B/W) Resolution
• Three Audio Recording Modes
• Jog/Shuttle Dial • Built-In Time/Date Generator
• Super Clear and Natural Picture
• Timer Program Recording (Ten)
• Repeat, One Shot, Series and Alarm recording
• Power Loss Memory Function • Record Check Function
• (OSD) On Screen Display
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
155
Recording Devices - Digital Video Recorders
17" LCD/DVR
Integrated Surveillance System
CCTV
3D-D17802251
• With integrated 8-channel Digital Video Recorder
and (2) high resolution cameras
• LCD MONITOR; 17" LCD surveillance display,
ultra-fast refresh and spot video output
4 Channel H.264 DVR
Four Channel DVR
B7-DVR4204HC
• H.264 Compression
• 120 fps @ CIF Resolution
• Multi-area Motion Detection
• Video Output: VGA x 1, TV (RCA) x 1, S-Video x 1
• Pentaplex Function: Recording, Live, Playback (4CH
Multi-Screen), Network and Back-up
• Video Loop
• USB Port for Hard Disk, Flash Disk, CD-R/W
• Accessory: Mouse
AV-DR4160
• Built in web server allows remote connection
• Recording rate: 120-ips
• Built-in motion detection, RS-232 text-in, alarm-in and
video-loss alarm inputs
• Chained fingerprint encryption
• Compact size – less than 2” tall
Digital Sprite 2 Hybrid NetVu Connected
BX2/BX2 CA Series
Hybrid NetVu Connected
DD-DS2PD Series
• Supports IP cameras and has PTZ camera control
• Simultaneous record, playback, image archiving and
remote viewing
• Allows JPEG recording & MPEG-4 transmission
• Available in 6, 9, 16 camera models
• VMD & video motion search
• Remote viewing via Ethernet or Dial-up connection
• Text transaction capture, record, and search
• Optional KBS3A keyboard with PTZ control and 3-axis
joystick • Up to 4 CIF recording resolutions with
authentication capability
156
• NETWORK DVR: 8-channel Triplex operation and
Independent Channel Control
• STORAGE: 250 GB ‘Surveillance Certified’ HDD with
3 year warranty
• CAMERAS; (2) high resolution weatherproof,
vandal resistant, day/night with 30' IR range
DD-BX2D Series
• 16 camera inputs with Standard & Continuous Archive
models
• Simultaneous record, playback, image archiving and
remote viewing
• Allows JPEG recording & MPEG-4 transmission
• Supports IP Cameras
• Text transaction capture, record, and search
• Optional KBS3A keyboard with PTZ control and 3-axis
joystick • Up to 4 CIF recording resolutions with
authentication capability
SD Series NetVu Connected DVR
DW716N
DD-SD Series
• 8, 12, 16 & 32 channel models
• PTZ controls (coax, serial, multiple protocols)
• USB & CD-R backup recording
• Simultaneous record, playback, image archiving &
remote viewing
• Allows JPEG recording & MPEG-4 transmission
• Text support & search, remote alarm reporting, and
video response control features
• Various control options include IR remote, KBC1 & KBC2
keyboards, USB keyboard, USB mouse
6K-716N Series
• 480 fps viewing/120 fps recording
• 16-channel video/8-channel audio recording
• 5 Programmable Spot Monitor outputs
• DHCP, Free DDNS support
• E-mail notifications to client
• One Touch Image Transmission
• One Touch Instant reverse playback
• Mouse, wireless remote controller
• Central Monitoring Software
DW916N
DW MAXII
6K-916N Series
• 480 fps view and recording
• 16 ch Audio and Video recording MPEG 4 compression
• DVD RW/USB port (memory stick storage)
• 5 programmable spot monitor outputs
• Email notification to client when events occur
• IPOT/PDA Support
• Simple & Free DDNS support
• Automatic video transfer to Remote PC on sensor event
trigger
6K-MAXII Series
• 4, 8, 16 channel
• Real Time viewing and recording
• MPEG 4 part 10 Compression
• One Touch Video Back up
• Reverse Playback and Emergency Recording
• Web-based client with multi user Access and CMS
software
• Simple and Free DDN support
• Mouse driven, IR Remote Control menus plus 5 year
limited warranty
16/32-Channel PC Based DVR
DW-MAX Standalone DVR
6K-9800 Series
• Hybrid Capable
• 16/32-channel video/16-channel audio recording
• 4 programmable Spot Monitor outputs
• HDD field upgradeable
• DVR Health Check
• Automatic Back up to Internal & External Devices.
• Pan/Tilt/Zoom controls
• Direct Access to PTZ Camera Setup Menu
• Two Way Audio (VMS to DVR)
6K-MAX Series
• 120 fps/4-channel video, 1-channel audio
• Latest MPEG-4 part 10 Compression
• Small file size for more efficient storage
• Simplest & Free DDNS set up
• EZ recording status look up
• EZ System summary screen
• Instant Reverse Playback
• Emergency Instant Recording
• Mouse, Wireless Remote Controller
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Digital Video Recorders
22" Wide Screen LCD Integrated
Surveillance System
3D-D2216501
• 16 channel network DVR and Wide Screen 22" LCD
• 480 fps viewing, 240 fps recording
• Mouse driven graphic user interface
• 500GB ‘security certified’ HDD
• Multi-function operation as a PC Monitor, TV monitor
(tuner not included), Public View Monitor and Digital
Picture Frame
• 64 Channel network software application with both
client based and web browser based operation
• Exclusive Digimerge Fortress-VisionTM 5/3/1 warranty
CCTV
VB300 Blade Series
3D-VB304251
3D-VB308251
3D-VB316251
• 4, 8 and 16 channel models
• Ultra small form factor (8.5" x 11" x 1.25")
• Stand alone, edge mount, LCD VESA mount
• H.264 compression
• 240 FPS
• Management software for unlimited DVRs
• 128 cameras per screen
• POS capable
• ATM capable
• Free DDNS by Digimerge
• Direct digital DVI output 1280 x 1024 resolution
DHU500 Series
Pentaplex Network DVR, 300GB HDD
3D-DHU504251
3D-DHU508251
3D-DHU516251
• 4, 8 and 16 Channel models
• Real time viewing, 120fps recording (480/120)
• MPEG-4 video compression
• Integrated DVD-RW optical drive
• VGA output
• Supports over 1.5TB internal storage
• Jog switch searching
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
157
Digital Recorders
ECOR Series DVR MPEG4 w/GUI Feature
Mobile Unit DVR with MPEG4
F8-ECOR4D
• With DVD burner
F8-ECOR4F
• Without DVD burner
F8-EDR410M
• 4 channel, MPEG4
F8-EDR810M60
• 8 channel, MPEG4
•
•
•
•
• Lve, record, playback, archive & remote viewing
simultaneously
• Up to 120 FPS of real time recording & playback
• User friendly GUI
• Multiple control function with USB mouse, front panel,
keyboard or IR remote controller
• Gigabit Ethernet interface for high speed remote
network viewing and controlling
120 FPS, compact size
2 audio channel, 1 USB port
Available in 60 or 120 GB
Ruggedized for mobile applications
EDR Series DVR with Hot Swap Drives and MPEG4
CCTV
• 120, 240 or 480 FPS (depending on DVR)
• USB 2.0 port on face panel, remote control included
• SCSI port on 9 & 16 ch. for large capacity expandability
• Email alarm notification, audio channels
• Up to 2TB of storage (depending on DVR)
F8-EDR920
• 9 channel, 240 FPS
• Full size DVR with 2 hot swappable drives
F8-EDR1620
• 16 channel, 240 FPS
• Full size DVR with 2 hot swappable drives
F8-EDR1640
• 16 channel, 480 FPS
• Full size DVR with 2 hot swappable drives
F8-EDR410H
• 4 channel, 120 FPS
• Half size DVR with 1 hot swappable drive
F8-EDR810H
• 8 channel, 120 FPS
• Half size DVR with 1 hot swappable drive
EDVR Series DVR with Built-in DVD Burner
•
•
•
•
•
F8-EDVR4D160
• 4-Channel, 160 GB, 120 FPS
F8-EDVR9D160
• 9-Channel, 160 GB, 120 FPS
F8-EDVR16D12
• 16-Channel, 160 GB, 120 FPS
F8-EDVR16D35
• 16-Channel, 500 GB, 480 FPS
•
•
•
•
•
Built-in DVD Burner
Available with 160, 250, 500GB and 1, 1.5 and 2 TB!
MPEG-4 compression
Individual channel FPS & Motion Detection
(2) USB 2.0 Ports on the front 1 for archiving, 1 for mouse control
SCSI port on D3 Series for large capacity expandability
10/100MB Networking Card (fast & fluid over network)
4 audio channels
IR remote control included
3 year warranty including hard drives
Digia II Series MPEG-4 Digital Recorder
KA-DIG216640
• 16-channels, 640GB
KA-DIGIA2RK
• Digia II rack mount brackets, pair
KA-DIG204160
• 4-channels, 160GB
KA-DIG209160
• 9-channels, 160GB
KA-DIG209320
• 9-channels, 320GB
KA-DIG216160
• 16-channels, 160GB
KA-DIG216320
• 16-channels, 320GB
•
•
•
•
•
•
Triplex: View, Record and Playback simultaneously
Remote playback over LAN or Internet • Secure remote configuration via web browser
USB 2.0 port for quick and easy archiving • Full duplex audio
Motion detection • Watermarking for authentication • User and Admin log-in
Daylight Savings Time AVI file export • Simple recording schedule
Real-time live display on all channels • E-mail notification upon alarm
SymSafe Hybrid Digital Recorders
KA-SYMSAFE
KA-SYMSAFE Series
• Available in 4, 8 or 16 analog channel versions
• HDD sizes of 160, 320 or 640GB
• Real-time MPEG-4 recording up to 18 channels at 2-CIF
• Hybrid DVR with 2 IP streams and 2 audio inputs
• Unique “light bar” alarm indicator
• Integrated solution: SymSuite software
• Archive via USB 2.0
• Continuous, Motion Detection, Alarm and Scheduled Recording modes
• Network bandwidth throttling
• PTZ control
• Up to 1.5 TB internal storage
• Cooling Tunnel design extends HDD life
• Video Specific hard drives for improved reliability
• CD/DVD-RW burner
• VGA and Composite Video ouput
• IR remote included
• Rack mount kit - KA-SYMSAFERK
KA-SYMSAFEPLUS
158
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Digital Video Recorders
Professional 16-Channel
Digital Video Streaming Recording
KA-SYMDEC16 Series
• Real-time recording on ALL channels @ D1 resolution
• Hybrid DVR with up to 4 IP cameras streams
• 4 audio inputs
• Sleek modern interface
• Unique alarm indicator light bar
• Integrated SymSuite solution: SymSecure, SymNav and
SymBrowser
• Up to 3 TB internal storage
•
•
•
•
•
•
Cooling TunnelTM design extends hard drive life
DVD burner
VGA, DVI and composite video outputs
Supports USB flash drive and mouse
Includes IR remote
Available in HD sizes from 32GB to 3TB
4, 10 & 16-Input
Digital Video Multiplexer/Recorder
Network Digital Video Recorder
CCTV
2H-68A001
• 4-Channel DVR connects to any analog surveillance
camera (including HAI’s models)
• Cameras may be viewed on OmniTouch 5.7 & 8,
OmniTouch Portables, over the Internet, or on a
Smartphone
• Can record based on motion or event
KA-DVMRE16 CT II Series
• WaveJetTM compression technology allows you to save
double the amount of video
• Triplex functionality - simultaneous recording, playback
and live multi-screen viewing
• Advanced search (includes retail & motion search) and
alarm features
• Ethernet capability
Fusion III DVR with V3.6 Software
Bridges the Gap Between Analog, IP and Intelligent Video
HF DVR Series
• Analog and IP recording up to 32-channels
(16 IP channels maximum)
• Global recording rates: 120, 240 & 480 ips CIF
resolution
• Integration with Honeywell video analytics; Active Alert,
Smart Impressions or People Counter
• Camera sabotage detection and advanced motion
detection
• HJZTP PTZ Controller now supported through Fusion
• Includes HFVMS - Fusion Video Management Software
(1 license)
• Wide screen display format supported (16 x 9)
• 250 GB to 4 TB of internal storage
• Honeywell IDM software integration - Enterprise level POS
Rapid EyeTM Multi-Media v7 and
Rapid EyeTM Multi-Media LT v7 Series
HRM Series
• Event Driven Digital Recording & Transmission System
• 4, 9 or 16 channel digital recording & transmission
system
• Event driven recording - 64 user definable recording rules
• 100% compatible with all RapidEyeTM Multi-Media units
• Video, audio & data recording and transmission in a
single unit
• Built-in bi-directional audio capability:
1 or 2 independent channels synchronized with video & data streams
Built-in data capture capability:
* Point-of-Sale * ATM * Alarm Panels * Any RS232 ASCII stream
• Network friendly TCP/IP capabilities over broadband and POTS
• Central station integration for video verification
• Honeywell Access Systems integration
Mobile DVR 4 Camera Kit
Mobile DVR 2 Camera Kit
HTS4049
• Includes:
* (1) HTR4 - Recorder
* (1) HTRD1HD250 - Hard Drive 250 GB
* (1) HTC70M1036 - Day/Night IR camera, 3.6 mm, audio
* (3) HTC70M1060 - Day/Night IR camera, 6 mm, audio
* (4) HTC70SBADIK - Camera Cables
* (1) HTRIF20 - Vehicle Inteface Cable - 20'
* (1) HTRDP - Remote Dashboard Panel
* (1) HTENCLHTR - Security Enclosure with
HTRRFK mounting hardware
HTS4047
• Includes:
* (1) HTR4 - Recorder
* (1) HTRD1HD250 - Hard Drive 250 GB
* (1) HTC70M1036 - Day/Night IR camera, 3.6 mm, audio
* (1) HTC70M1060 - Day/Night IR camera, 6 mm, audio
* (2) HTC70SBADIK - Camera Cables
* (1) HTRIF20 - Vehicle Inteface Cabel - 20'
* (1) HTRDP - Remote Dashboard Panel
* (1) HTENCLHTR - Security Enclosure with
HTRRFK mounting hardware
Mobile VCR Kit with GPS
Mobile VCR Kit
HTS6009
• Includes:
* (1) HTR1 - VCR
* (1) HTC70M1080 - Day/Night IR camera, 8 mm, audio
* (1) HTC70SBADIK - Camera Cable - 20'
* (1) HTRGPS - GPS Receiver
* (1) HTR1IF20 - Vehicle Inteface Cable - 20'
* (1) HTENCL - Security Enclosure
HTS6007
• Includes
* (1) HTR1 - VCR
* (1) HTC70M1080 - Day/Night IR camera, 8 mm, audio
* (1) HTC70SBADIK - camera installation kit with cables, brackets
* (1) HTENCL - security enclosure
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
159
Digital Video Recorders
HRDP Performance Series Digital Video Recorder
CCTV
HRDP4D250
• 4 Channel, 250 GB Unit
HRDP4D500
• 4 Channel, 500 GB Unit
HRDP8D250
• 8 Channel, 250 GB Unit
HRDP8D500
• 8 Channel, 500 GB Unit
HRDP8D750
• 8 Channel, 750 GB Unit
HRDP16D250
• 16 Channel, 250 GB Unit
HRDP16D500
• 16 Channel, 500 GB Unit
HRDP16D750
• 16 Channel, 750 GB Unit
HRDP16D1000
• 16 Channel, 1 Terabyte Unit
•
•
•
•
•
•
4, 8 or 16 looping video inputs
Up to 120 ips record rate
Built-in DVD-RW drive and 2 USB 2.0 ports
Robust MPEG-4 video compression
Remote access through web browser or via Remote Software (included)
PTZ dome control for a wide variety of protocols
HRSD Series Economical Multi Channel DVRs
HRSD8C250
• 8 channel, 250 GB Unit
HRSD8C500
• 8 Channel, 500 GB Unit
HRSD16C250
• 16-channel 250 GB Unit
HRSD16C750
• 16 Channel, 750 GB Unit
HRSD16C500
• 16-channel, 500 GB Unit
HRSD16C1000
• 16 Channel, 1000 GB Unit
HRSD16C1500
• 16 Channel, 1500 GB Unit
•
•
•
•
•
•
•
•
•
8 or 16 looping video inputs
Up to 120 ips recording rate
High resolution digital storage with XtraStor Technology
2 channels audio input
Easy to use USB mouse (not included) operation
VGA and BNC Main Monitor, 1 spot
Text insertion serial interface
Remote administration software (RASplus) included
Internal CD burner and 2 USB ports
HRXD Series Multi Channel DVRs
HRXD9D250
• 9-channel 250GB Unit
HRXD9D500
• 9-channel 500GB Unit
HRXD16D250
• 16-Channel 250GB Unit
HRXD16D500
• 16-channel 500 GB Unit
HRXD16D750
• 16-channel 750GB Unit
HRXD16D1000
• 16-channel 1000 GB Unit
•
•
•
•
•
•
•
•
•
•
•
160
9 or 16 looping input
Up to 240 ips recording rate
High resolution digital storage with XtraStor Technology
4 channels audio input • Infrared remote control
Front panel jog shuttle and easy to use USB Mouse
(not included) operation • 3 USB ports
VGA or BNC and SVHS Main Monitor, 4 spot
Text insertion serial interface
Remote administration software (RASplus) included
and WebGuard browser included
Internal DVD burner (16ch)/CD burner (9ch)
Network 10/100base ethernet
SCSI port for external storage
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Digital Video Recorders
Mobile Recording Kits
• Great for school bus installations
Mobile Digital Data Kit
HTS4083
• Includes:
* HTRD440 - mobile digital data recorder with
4-video channels and 80GB drive
* HTCD50MC080 - mobile digital camera
* HTENCL - recorder enclosure and cabling
Mobile Digital Video Kit
HTS1082
• Includes:
* HTRD100 - mobile digital video recorder
* HTRD1HD40 - 80 GB removable hard drive
* HTC70M1080 - mobile Day/Night camera
* HTENCL - recorder enclosure * Cabling
Mobile Video Kit
HTS6006
• Includes:
* HTR62 - mobile VCR - HTC70M1080 - Day/Night camera
* HTENCL - recorder enclosure * Cabling
Rapid EyeTM Multi-Media DSP v8 Software
4-Channel Digital Video Recorder
HRDE4F160
• 160 GB unit
• 4 video inputs
• Clip copy via USB port
• Up to 120 ips record rate
• Network 10/100 base ethernet
• Motion detection, time lapse & event recording
• Intuitive easy-to-use front panel & remote access
control (remote software included)
•
•
•
•
•
•
•
•
•
Real-time recording rates at CIF resolution
Standard DVD-RW drive
4 shock mounted field replaceable hard drives
Keyboard with USB 2.0 Port
Live Viewing using LocalView
16 loping Video Inputs
Dual Audio Channels (Bi-directional and VoIP)
16 Alarm Inputs • 8 Control Outputs
10 Serial Ports
CCTV
HRMDSP
• Event-driven Digital Recording and Transmission System
• Enhanced mouse driven • LocalView interface
• The DVD writer exports up to seven times the duration
of video clips than to a CD
• Graphical timeline shows the availability and type of
video recorded
• Multiple language support
• Wizard-based RapidConfigTM allows easy setup of the
main DVR features
HRSD4 Series
Economical 4-Channel DVR
HRSD4F250
• 250 GB unit
• 4 looping video inputs
• Up to 120 ips record rate
• High-resolution digital storage with XtraStor technology
• 1-channel audio input • Infrared remote control
• VGA or BNC Main Monitor • Text Insertion serial interface
• Remote Administration Software (RASplus) included
• Clip Copy via USB
• Network 10/100Base Ethernet
Rapid EyeTM Active Alert®
SRX Lite & UltraLite Compact Design DVR
RE Series
• 8 Channels of embedded intelligent Video Analytics
• Support for the full suite of Honeywell Video Analytics
(active alert, smart impressions, and people counter)
• Mix and match video analytics packages on per channel
basis
• Eliminates the need for additional analytics servers
• Integration of alarms with video analytic events
8O-UL601000
8O-UL601600
• 10/16 channels, 60 fps viewing, upgradable to 1 POS
channel
• Standard storage 500GB, 80GB OS, and DVD ±
8O-PL601000
8O-PL601600
• 10/16 channels, 120 fps viewing, 4 POS upgradable
• Standard storage 1TB, 80GB OS, & DVD ±
* Simultaneous recording, playback, backup, and remote
viewing
* Optional: wall mount bracket
SRX-PRO Hybrid
Veo Embedded DVR
8O-24020C00
• Supports up to 20 channels of video (16 analog & 4 IP)
• 240 frames per second
8O-24024RA00
8O-48024RA00
• Supports up to 24 channels of video (16 analog & 8 IP)
• POS integration ready (call for details)
• High frame rates and high resolution recording (240/480
frames per second)
• Search and backup in live mode & supports MJPEG,
MPEG4, and H.264 • Includes 4 channels of video
analytics
8O-V12004N00
8O-V12008N00
8O-V12016N00
• 4/8/16-channel digital video recorder
• Upgradable to 1 TB internal storage, 500 GB standard
• MPEG-4 Video compression
• Spot monitor for public view displays
• Embedded OS
• Full-function remote software client with administration
functions
• Support for continuous, motion, alarm, and
scheduled recording
4ch, 8ch, 16ch DVR
PRO Command DVR
IK-SDR404
IK-SDR308
IK-SDR316
• 4ch (IK-SDR404), 8ch (IK-SDR308), 16ch (IK-SDR316)
• HDD with 500GB, 750GB or 1TB available
• MPEG4 compression
• Resolution D1, HD1 or CIF
• NTSC/PAL, VGA, S-Video, Spot Video Output
• One audio input per each video channel
• Internet Explorer based client viewer
• Networkable
• Backup through the USD2.0 or a built-in DVD-RW
I2-PROC08605
• 320 x 240 or 704 x 480 resolution
• 60 fps
• 8 camera inputs
• Adjust frame rates and resolution per camera
• CD-R Drive
• Standard POS/ATM/Access control interface
• 2 Channels of Audio
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
161
Digital Video Recorders
PRO Command 16-Channel DVR
Wireless Video Reciver Recording Case
I2-PROC16121
• 320 x 240 or 704 x 480 resolution
• 120 fps
• 16 Camera inputs
• 4-channels of audio
• Adjust Frame Rates & Resolution by camera
• CD-R Drive
• POS/ATM/Access Control Integration Standard
GH-2300RVR
• 4-channel DVR 120GB HD 30fps recording capabilities
• 2.4Ghz & 1.2Ghz available
• 7" LCD monitor
• 2-10Amp Lithium rechargeable batteries
• High Gain antenna
• Enclosed in a protective case
• This receiver can pick up any of our wireless
transmitters
• Perfect for rapid deployment and extreme covert
operations
CCTV
Four Video Input DVR
MH-DXTL4U250
• Thin, low profile design
• Affordably priced!
• Mitsubishi proprietary video compression
• Built in 250GB and 500GB models
• 120 PPS record speed
• Long term recording
USB port for easy copy of images
PTZ of dome cameras
Built in hardware watchdog
Easy to use, easy to operate
Geared for small retail, small business & home monitoring
9-Channel DVR
16-Channel DVR
MH-DXTL4709U
• 5 year industry best DVR warranty!
• JPEG2000 video compression
• 240 PPS record
• 250GB ~ 1TB built-in HDD
• Included USB mouse for easy programming
• Expandable storage capable
MH-DXTL4516U
• 5 year industry best DVR warranty!
• JPEG2000 video compression
• 120 PPS record
• 250GB~1TB built-in HDD
• Built in CD/DVD/USB
• Included USB mouse for easy programming
• Expandable storage capable
16-Channel DVR
9-Channel DVR
MH-DXTL5000U Series
• 5 year industry best DVR warranty!
• JPEG2000 video compression
• 240 PPS record
• 500GB~2TB built in HDD
• Built in CD/DVD/USB
• Included USB mouse for easy programming
• Expandable storage capable
MH-DXTL4709U
• 5 year industry best DVR warranty!
• JPEG2000 video compression
• 240 PPS record
• 250GB ~ 1TB built-in HDD
• Included USB mouse for easy programming
• Expandable storage capable
16-Channel DVR
DX4000 Series Digital Video Recorder
MH-DXTL4716U
• 5 year industry best DVR warranty!
• JPEG2000 video compression
• 240 PPS record
• 250GB ~ 1TB built-in HDD
• Built in CD/DVD/USB
• Included USB mouse for easy programming
• Expandable storage capable
PE-DX4000 Series
• 4-channel digital video recorder
• MPEG-4 compression
• Up to 704 x 480 (NTSC), 704 x 576 (PAL) recording resolution
• Up to 120 (NTSC)/100 (PAL) images per second recording
rate at 352 x 240/352 x 288 resolution for NTSC/PAL
respectively
• Independent channel resolution, quality, & frame rate settings
• Up to 500 GB internal storage
• 4 audio inputs, 1 audio output
• 4 alarm inputs, 1 relay output
DX4500/DX4600 Series Digital Video Recorder
PE-DX4500 Series
PE-DX4600 Series
• 8- or 16- Channel Digital Video Recorder
• MPEG-4 Compression
• Up to 704 x 480 (NTSC), 704 x 576 (PAL) Recording Resolution
• Up to 480 Images per Second Recording Rate
• Up to 4 TB of Hard Drive Storage
• Partition Recording
• Channel Resolution, Quality, and Frame Rate Settings
Configurable per Individual Camera
• Picture-In-Picture for Multiscreen Live and Playback Video
162
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Remote Client with Administration Functions
Support for Continuous, Motion, Alarm, and Scheduled Recording
Local and Remote PTZ Control
Third-Party PTZ Protocols
Up to 4 Audio Inputs and 1 Audio Output
Pre- and Post-Alarm Recording
Up to 16 Alarm Inputs and Up to 4 Relay Outputs
Main Monitor for VGA or Analog Display, Analog Spot Monitor
Multilingual On-Screen Display
USB, CD-RW, or DVD±RW for Video Export
Event Notifications by E-mail, Emergency Agent, or Sounder
Time/Date, Bookmark, Event, and Pixel Search
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Digital Video Recorders
DX8100 Series Digital Video Recorder
PE-DVR5100 Series
• 4, 8, or 16 Analog Video Inputs; 16, 12 or 4 IP Camera
Inputs Respectively
• Embedded Linux Operating System
• Record video at up to 600/500 ips at CIF or 2 CIF or 4
CIF resolution
• MPEG4-Based Compression with Constrained Variable
Bit Rate Optimized for Surveillance Requirements
• Up to 2.0 TB of Internal Storage Including EnduraStor
Optimization (requires appropriate Endura software
version)
PE-DX8100 Series
• Server Dual Display of as many as 72 Cameras
Simultaneously
• Expanded ATM/POS Support for up to 16 ATM/POS Devices
• System Health Check Monitoring
• Windows® XP Embedded
• Optional MUX Card Output
• 2 Built-In Audio Channels
• Optional Layer 2 Multicasting for Web Browser Access
• 16-Channel Expansion Box Option
• Internal Storage Capacity to 4 TB
• Up to 704 x 480 Recording Resolution (4CIF)
POSWATCH PSP 4 Channel DVR 120FPS DVD-RW
POSWATCH PSE Series 16 Channel DVR
PZ-PSP4D
• 250gig, Up to 1TB w/1/8" Heat Sinked Hardrive Bay
• Fan Less Design on Non-Burner Based Version
• Mouse Controlled Display for Ease of Use
• Modern Style Menu for Fast Setup
• Easy to use Searching for End Users
• 75 Camera Remote Viewing Software
• Full Browser Control for Viewing, Playback & Archiving
• Offsite Video Storage for Central Stations Monitoring
• 1 2 3 Network Setup for Fast Installing
• Non-Burner Version Available (PZ-PSP4)
PZ-PSE1612C
PZ-PSE1648C
• 120 or 480FPS of recording w/ 8ch’s of Audio
• Offsite Video Storage for Central Stations
• 250gig, Up to 3TB’s SATA or PATA Drives
• 75 Camera Remote Viewing Software
• E-Mapping Software for Large Scale Projects
• DVD-RW/USB Backup with IR Remote Control
• Smart Search Functions for Easy Searching
• Browser Based Remote Viewing
• 3 year warranty
16 Channel Video/Audio DVR
4-Channel DVR
RA-RDP164850
• 500g Hard Drive, up to 4TB Options
• 480/480 Recording and Viewing
• MPEG4 Compression
• Windows XP embedded
• 16 Channels of audio and video
• Pos Integration (Optional)
• Windows PDA Remote View
• DVD-RW
• CMS/Remote Web View
RA-RD412250C
• 250G Hard drive
• 120 ips recording, 120ips display (real time)
• MPEG-4 compression
• True triplex operation: Display, Record, Search
• USB mouse support • Loop through video outputs
• Backup to internal CD-RW or external devices
• CMS (Central Monitoring System) software included
• Supports most popular PTZ protocols
• Full Duples 2-way radio communication
• Remote control included
16-Channel DVR
8-Channel DVR
RA-RD1612250C
• 120 ips recording, 480 ips display (real time)
• MPEG-4 compression
• True triplex operation: Display, Record, Search
• USB mouse support • Loop through video outputs
• Backup to internal CD-RW or external devices
• CMS (Central Monitoring System) software included
• Supports most popular PTZ protocols
• Full Duples 2-way radio communication
• Remote control included
RA-RD812250C
• 250G Hard drive
• 120 ips recording, 240ips display (real time)
• MPEG-4 compression
• True triplex operation: Display, Record, Search
• USB mouse support • Loop through video outputs
• Backup to internal CD-RW or external devices
• CMS (Central Monitoring System) software included
• Supports most popular PTZ protocols
• Full Duples 2-way radio communication
• Remote control included
8, 16-Channel Standalone DVR w/DVD-RW
Stay up-to-date on the latest
product information, vendor
updates, trainings, events, dealer
programs and incentives
available at your local ADI
branch. Subscribe to receive the
ADI Newsnet and ADI Update at
OG-SHR5082/5162
• 120 ips with 4-channel audio high speed video
recording
• High speed video recording network tramsmition via
dual codec
• Exclusive video processor to improve image quality
• Backup functions through USB 2.0
(USB memory, External HDD, External DVD-RW)
• Remote monitoring and control through network
• IR remote controller • Built-in DVD-RW
• Web-browser interface and client software
• 250GB HD standard
CCTV
DVR5100 Hybrid Video Recorder
www.adilink.com
4/16 Channel MPEG-4 DVR
6/9/16 Channel DVR with CD-R/RW
SY-2016H160 - 16 Channel
SY-2004H80 - 4 Channel
• Recording speeds up to 240 ips (4 channel:120 ips)
• Up to 704 x 480 recording resolution
• Live picture monitoring at 960 ips
• Easy back up via built-in CD-R/RW or USB Memory
• PTZ telemetry control, VGA video output
• Remote surveillance & control over the network
• IR Remote controller included
• 3 year warranty
SY-3706H80C - 6 Channel
SY-3709H80C - 9 Channel
SY-3716H80C - 16 Channel
• Up to 520 TV lines recording and display resolution
• 60 ips recording/playback
• 270 ips Live Picture Display at 9 ch (480 ips at 16 chan)
• Standard configurations 80GB,160GB,300GB, & 600GB
• LAN/WAN Control Capability built-in - browser based
• PTZ control of up to 9 or 16 cameras
• Built-in CD-R/RW and CF Media Slot for downloads
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
163
Digital Video Recorders
Hybrid Digital Video Recorder
PC-Based Professional 8 Channel Pentaple
SY-HB8000
• Up to 16-channel analog and 4 Network channels
• Recording speeds up to 480ips
• Up to 720 x 480 recording resolution
• Easy Back-up via built-in CD/DVD Burner or
USB Memory
• PTZ Telemetry Control
• Remote surveillance & control over the network
• 1TB, 2TB, 3TB, 4TB & 5TB internal storage capacity
SO-DVR8PCL25
• H.264, MPEG4 or MJPEG selectable compression
• Hybrid Operation – Supports Up To 4 IP Cameras
• Megapixel support for IP Cameras – many major brands
supported
• Built-In video analytics for Intelligent Recording
• Built-In DVD/RW
• Removable HDD + 3 internal units. Up To 4 TB capacity
on board
• POS compatible with most major protocols
• Available in 16 channel (SO-DVR16PCL2) version
16-Channel Triplex IP Ready DVR
CCTV
SO-DVR16TN16
• Remote monitoring, record, playback through the Internet
• EZ setup, EZ record, EZ router configuration, EZ copy, EZ DDNS
• Free DDNS
• MPEG-4 high quality compression
• Triplex operation enables simultaneous viewing live
or playback while continuing to record
• Up to 2.25 TB internal Hard drive storage
• Real time live display, recording rate up to 120 pps
• Export AVI file which can be played via Microsoft Media Player
• Digital Deterrent Ready
• Supports POS cash registers
• Built-in CD-RN, optional DVD-RW
• Email notification of events
• Free central management software supports multiple DVR’s
• 3 year warranty
16-Channel Triplex 480 fps DVR
SO-DVRTT750
• Remote monitoring, record, playback through the
internet
• EZ setup, EZ record, EZ router configuration, EZ copy,
EZ DDNS
• Free DDNS
• MPEG-4 high quality compression
• Triplex operation enables simultaneous viewing live
• Up to 2.25 TB internal hard drive storage
• Real time live display, recording rate up to 120 pps
•
•
•
•
•
•
•
Export AVI filewhich can be played via Microsoft Media Player
3 year warranty
Digital Deterrent ready
Supports POS cash registers
Built in CD-RW, optional DVD-RW
Email notification of events
Free Central Management Software supports multiple DVR’s
•
•
•
•
•
Remote monitoring, record, playback through the Internet
EZ setup, EZ record, EZ router config, EZ copy, EZ DDNS
Free DDNS
MPEG-4 high quality compression
Triplex operation enables simultaneous viewing live
or playback while continuing to record
HDD size 160 GB: other configs available up to 1.5TB internal
Recording rate up to 60 pps
USB 2.0 port for video clip exporting, supports USB thumb drive
3 year warranty
4/8/16-Channel IP Ready DVR
SO-DVR4TL160
• 4-channel IP Ready DVR
SO-DVR8TL160
• 8-channel IP Ready DVR
SO-DVR16TL160
• 16-channel IP Ready DVR
•
•
•
•
16-Channel PC
Pro Series 400 GB HDD
SO-DVRPC16P5
• 16-channel PC based DVR, 480 fps
• 480 FPS Live View and records Real Time video
• High resolution 720 x 480 image size
• Network ready for remote view video on PC
• Built-in DVD-RW
• H.264 compression saves hard drive space
• Pan/Tilt/Zoom control
164
• Windows embedded XP operating system
• Fully programmable scheduled recording
• True Hybrid DVR provides IP camera multi level
EMAP feature
• Free DDNS
• 2 year warranty
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Digital Video Recorders - Network Video
Video Digital Recorder
CCTV
SO-EZVR4
• Full Multiplexer Operation
• EZ backup to USB Thumb Drive or USB HDD
• Player and .avi conversion software download
automatically
• Most popular settings have been pre-selected for
the user. The closest thing to a p-n-p recorder in the
industry
• Triplex Operation – Play, Record & Backup at the same time
• Comes standard with a 160GB HDD
• Also available in 8 channel unit, SO-EZVR8
Surveillix® Digital Video Recorder
Surveillix® Hybrid Digital Video Recorder
TB-DVR Series
• Available in 8 & 16 channel
• Up to 2 TB internal storage
• Up to 480 pps
• Supports up to 4 removable HDD
• Available internal RAID5
• Field upgradeable (replaceable HDD)
• EVR up to 32-channel
• Optional Point of Sale or Video Analytics support
TB-HVR Series
• Up to 32 analog channels & 16 network channels
• Up to 4 TB internal storage
• Up to 480 PPS
• Recording resolution as high as 720 x 480
• Available internal RAID5
• Field upgradeable (replaceable HDD)
• Optional Point of Sale or Video Analytics support
4-16 Channel Economical DVR Kits
4G-PRC100430
• 4 input, 30 fps
4G-PRC200860
• 2-pack or 8 inputs 60 fps
4G-PRC301290
• 3-pack or 12 inputs, 90 fps
4G-PRC401612
• 4-pack or 16 inputs, 120 fps
4G-PRC43010
• 10-pack, bulk savings!
High Performance DVR Kits
4G-PRC100824
• 8 input, 240 fps
4G-PRC201624
• 2-pack, 16 inputs, 240 fps
4G-PRC302424
• 3-pack, bulk savings!
4G-PRC403224
• 4-pack, bulk savings!
•
•
•
•
•
MemoCam DV-Cop Series Miniature DVR
5V-MCDVCOP
• Miniature DVR
5V-MCDVCOPCELL
• Miniature DVR with Cellular Communications
• Stand-alone miniature DVR with advanced VMD
• Sleep mode (only 10mA) enables extended battery use
• DV-Cop/CELL model transmits SMS/email with JPG
attachments upon intrusion detection
• Records on removable mini SD/HC card up to 640 x 480, 10FPS
• RS-485 connection, 1 video output
• Small & mobile, easy to set up & use, no daily maintenance
IP Pro compact design NVRs
8O-IPP04C00
8O-IPP10C00
8O-IPP16C00
8O-IPP24C00
Models: 4/10/16/24 channel (software included)
* Standard storage 1TB, 80GB OS, & DVD +/-
IP Pro rack mount design NVRs
8O-IPP10RA00
8O-IPP16RA00
8O-IPP24RA00
166
PCI based DVR card Kits • TotalSecure Capture Cards support Windows 2000, XP or VISTA
Expand with same line of capture cards
Software motion detections, continuous recording or a mix of both and/or alarm event recording
Do-it-yourself Kit that competes with most DVR’s in the market!
Free webhosting service for remote access - NO Static IP’s required
DW-HVT IP Based Technology
Network Video Recorder
6K-H301
6K-H1204 Series
• 1, 4-channel Network Video Recorder
• 120 fps MPEG-4
• Full web browser control & Free DDNS
• Reduce installation cost
• Mobile DVR capable • Local Recording on Network-Fail
• Email notification on Alarm
• Unlimited on number of users
• USB & optional internal hard drive
8O-IPP24RB30
8O-IPP24RB30
8O-IPP24RB70
Models:
* RA00 (10/16/24 channels, software included, 1TB)
* RB30 (24 channels, software includeded, RAID 5, 4TB)
* RB70(24 channels, software included, RAID 5, 8TB)
• Supports up to 24 channels of IP and mega-pixel cameras
• High frame rates and high resolution recording
• Supports internal non RAID and RAID 5 storage
• Supports MJPEG, MPEG4, and H.264
• 80GB OS and DVD +/-
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Network Video - Housing & Mounts
500GB Network Surveillance Server
MH-DXZD6UE
• 1TB and 1.5TB models
• Can add up to 14 units to main DVR
• Playback video on PC via USB
• Industry leading 5 year limited warranty
SH-NSR1050H
• Physical storage capacity of 500GB
• Hybrid recording (Analog/IP, SD/HD)
• Open platform (Supports IP cameras of some other brands)
• Easy setup and intuitive operation
• Max. 20 cameras supported (IP/Analog total)
• Max. 16 analog cameras direct connection
• 0.5 TB Physical Storage Capacity
• HDMI outputs for Full HD displays
• Supports megapixel cameras
• Additional storage of SH-NSRES200 (2 TB) x 7 units
• Remote viewing by controller software
Network Surveillance Server
Network Surveillance Recorder
SH-NSR1100
• Physical storage capacity of 1TB
• Hybrid recording (Analog/IP, SD/HD)
• Open platform (Supports IP cameras of some other
brands)
• Easy setup and intuitive operation
• Max. 32 cameras supported (IP/Analog total)
• Max. 16 analog cameras connection (with an optional
SH-NSBKA16)
• 1 TB Physical Storage Capacity • RAID 0
• HDMI outputs for Full HD displays
• Supports megapixel cameras
SH-NSR1200
• Hybrid recording (Analog/IP, SD/HD)
• Open platform (Supports IP cameras of some other
brands)
• Easy setup and intuitive operation
• Max. 64 cameras supported (IP/Analog total)
• Max. 16 analog cameras connection (with an optional
SH-NSBKA16)
• 2 TB Physical Storage Capacity
• RAID 5
• HDMI outputs for Full HD displays
Four Channel Video Server
Camera Mount
SH-SNTV704
• Ideal for video monitoring over networks
• Camera images can be remotely monitored and controlled over existing networks (4 analog video inputs)
• Built-in web server provides user-friendly interface for
easy monitoring and control from networked PCs running a web browser
• MPEG-4/JPEG compression • Bi-directional audio
• Supports a high frame rate of 30fps/channel at high
resolution of 720 X 480 (D1) to provide clear and
smooth moving images
• Multi-user access and password protect
PR-TV24
• Expandable
• Heavy duty all metal
• Expands to 39.5"
• Maximum load: 4.4 lbs.
• Swivel Angle: 360°
• Tilt Angle: 90°
• Color: Silver
AXIS Pendant Dome Outdoor Housing
Mounting Kit for NDVR with Power Supply
Z4-25733
• Includes clear dome, heater/blower, & pendant mount
• Requires mounting hardware (sold separately)
• Use with Axis 213, 214, 231D+, 232D+ and 233D PTZ
Cameras
• Indoor version is also available (Z4-25735)
2H-68A042
• Universal Mounting Plate Assembly, with camera power
supply mounted on the backplate, includes hardware
to mount Network DVR (2H-68A001) sold separately
in Leviton or “Open House” type structured wiring
enclosures
CCTV
USB Enabled HDD Expansion Unit
* NDVR shown but not included
Universal Mounting Plate Kit for NDVR
Housings & Mounts
2H-68A041
• Universal mounting plate used to mount Network Digital
Video Recorder, (2H-68A001)
• Includes mounting plate, hardware kit & instructions
(NDVR not included)
HHC12WM Housing
• 12" housing with mount, 30 lb. load, universal head
HHC12WM2 Housing
• 12" housing w/mount, 30 lb. load, 360° head, heater & blower
HHC1200 Housing
• 12" housing only
HBC5WT Mount
• Light duty, 3-axis wall or ceiling camera mount, 165° tilt, white
HBC5BK Mount
• Light duty, 3-axis wall or ceiling camera mount, 165° tilt black
Camera Housings
ORION Tiltable Rack Mount 8" up to 19"
8O-DI36800
• Indoor camera housing
• Long model with aluminum bracket (no heater/blower)
• Dimension 16.26" x 9.84" x .69" (413 x 250 x 119mm)
8O-DI3680HB
• Outdoor camera housing
• Long model with aluminum bracket
• Heater and blower (24VAC)
• Dimension: 16.26" x 9.84" x .69"
(413mm x 250mm x 19mm)
40-RMK08
Designed to rack LCD monitors from 8" to 19" conceived
with multiple points of movement for multiple applications.
• Tiltable rack mount
• Depth adjustable: 37mm to 80mm (1.45" to 3.14")
• VESA mount support: 75 x 75mm or 100 x 100mm
• Max supporting weight: 20.94 lbs (9.5 kg)
• Black
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
167
CCTV
Housing & Mounts
Conduit Mount
Mounting Kit for Monitor and CCTV Camera
PN-85434
• Perfect solution for long camera drops using ¾” rigid
conduit or NPT pipe
• Installer determines drop length
• Fully adjustable at the camera
• Knob and set-screw adjusting options included
• Steel conduit locknuts included (2)
PN-336FPMC100
• Mounting kit for combination Flat Screen Monitor +
CCTV Camera
• Installer determines drop length using ¾” rigid conduit
or NPT pipe
• Fully adjustable at the monitor and camera
• VESA compatible (100mm) mounting plate
• Maximum weight: 40 lbs.
• Includes mounting kit and instructions
• Monitor, camera and pipe shown but not included
EH3512/EH3515 Series Enclosures
7" Diameter Dome Indoor Recessed Ceiling
PE-EH3512 Series
PE-EH3515 Series
• Low cost • Small, contemporary design
• Die cast and extruded aluminum construction
• Forward opening hinged lid • Rear link-lock latch
• Cable entry glands and mounting holes on bottom of
enclosure
• Designed for Indoor/Outdoor applications
• Easy access for servicing and installation
• Models available with factory installed low power heater,
blower and defroster, or with heater and defroster
SH-UNIID7C3
• 7" diameter dome indoor recessed ceiling housing
• Designed and engineered for Sony’s SH-SNCRX series
and SH-SNCRZ30N, SH-SNCRZ50N, SH-SNCRZ25N
cameras
• Clear Lower Dome
• White trim ring
• No electronics. Interface wiring (Ethernet, sensor I/O,
power provided by user)
• Plenum rated metal top
7" Diameter Dome Indoor Recessed Ceiling
Pendant Mount Bracket
for the SNC-DM160
SH-UNIID7T3
• 7" diameter dome indoor recessed ceiling housing
• Designed and engineered for Sony’s SH-SNCRX series
and SH-SNCRZ30N, SH-SNCRZ50N, SH-SNCRZ25N
cameras
• Tinted lower dome
• White trim ring
• No electronics. Interface wiring (Ethernet, sensor I/O,
power provided by user)
• Plenum rated metal top
• Light loss is 1.2 F-Stop maximum
168
SH-UNIMDB3
• Pendant mount bracket for the SH-SNCDM160
& SH-SNCDS60
• Wall mount; bracket included
• All aluminum construction
• Indoor or outdoor use
Dome Flush Mount Kit
CCTV Housing with Heater, Blower, Bracket
SO-DFM2
• Back box easily flush mounts into hollow walls and
ceilings
• Flush mount box is secured with the use of four EZ
mount retaining clamps
• Perfect for existing construction
• Preconfigured to fit several types of Speco tamperproof
and indoor cameras
• Contains two different size Chameleon decorator rings
for a finished look
• Rings can be painted to match any decor before
installation
SF-STI7100K
• Aluminum housing enclosure for indoor/outdoor use
• Includes heater, blower, sunshield & bracket
• Spring assisted forward opening lid with rear link-lock
latch
• Sunshield can reduce internal temperature by 4°F
• 2 UL Listed cable entry grommets on bottom
• 2 year warranty
• Also available: SF-7000K - cover and bracket only
Outdoor Aluminum Environmental Housing
2' x 2' Drop Ceiling Dome
VL-ACH13HBWM
• Aluminum body construction
• Side hinge for easy servicing
• Heater/Blower feature (24VAC or 12VDC)
• Includes combination wall & pole mount
• Universal bracket accepts many lens and camera
combinations
VL-OH081TL
• General purpose 8" dome easily replaces a 2' x 2'
ceiling tile
• One piece integral construction
• Low profile; dome extends only 4” below ceiling
• Dust cover and liner included
• Universal camera mounting bracket for fixed cameras
Vandal-Resistant Camera Housing
Universal LCD Ceiling Mount
VL-RHW75C2N
• Cast aluminum top with polycarbonate dome
• Universal mounting plates that fit most cameras
(IP or Analog)
• Heater/blower options available
• Meets IP66 standards for dust and water penetration
(pendant mount)
• Comes standard with wall mount;
pendant mount available
• Tinted or clear capsule available
V8-LCD1C
Silver finish
V8-LCD1CB
• Black finish
V8-LCD1CW
• White finish
•
•
•
•
•
Holds most 10" to 23" LCDs
Accomodates LCDs with 75 or 100mm VESA standards
Mast telescopes 17" to 27" from ceiling
Load capacity 25 lbs
Rotates 360 degrees, -5 to +30 degree tilt
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Housing & Mounts - Fiber Products
* Camera
not included
Universal Mid-Size LCD Flush Mount
V8-LCDPV
• Kit includes the following:
* V8-LCD2537C
Modified with 2 mounting points for camera bracket
* Universal 1/4" - 20" camera bracket can be
assembled several different ways
* V8-AK1 & V8-CP1 (included)
• Mast telescopes from 18" - 30"
• Holds most LCD monitors 10" - 37"
• Rotates 260° and has adjustable tilt -5° to + 30°
• Load capacity 75 lbs.
V8-LCDMIDF
• Holds most 27" to 42" LCD Monitors
• Mounting rails adjust from 2.25" to 16" (L to R) and
accomodate monitors with mounting holes up to VESA
400 x 200
• Distance from wall to back of monitor - 1"
• Load capacity - 100 lbs.
• Silver powder coat finish
DVR Lockbox with Fan
Mid-Size Flat Panel Ceiling Mount
V8-DVRLB1
• Interior dimensions 21” W x 21”D x 8” H
• Vented and includes fan for additional ventilation
• Interlocking lift off lid
• Key locked hinging front door
• Black powder coat finish
V8-LCDMIDC
• Holds most 27" to 42" Flat Panels
• Mounting rails adjust up to max of VESA 400 x 200
• Mast telescopes 23” to 35” from ceiling
• Rotates 360° and has adjustable -5 to +15 tilt
• Cable management through center of mast
• Load capacity 100 lbs./Silver powder coat finish
V8-LCDMIDCB - same with black finish
Single Channel Dual Fiber Video
Single Channel, One Fiber “Up the Coax”
AZ-M1485 Series
• Transmits/Recieves Single Channel Video w/Bi-Di Data
• Compatible with all Video, CCTV, Monitor Manufacturers
• Manchester or Bosch Data Encoding
• Data Formats: RS-485/422, Select Switch for 2W/4W
• Switch Select for Termination and Bias
• Diagnostic Indications (LED’s) Video, Power, Data, Sync,
Optical Presence
• Full Color Real Time Video Transmission
• Compatible with NTSC,RS170A, RS343A, PAL, & SECAM
• LIfetime Warranty, No Adjustments, No Maintenance
AZ-M1605 Series
• Video Transmission with Up the Coax, for PTZ,
one Multimode Fiber
• For Pelco, Videolarm and other Interval Switching
manufacturers
• Diagnostics (LED’s) Video, Power, Data, Sync, Optical
Presence
• NTSC, RS170A, RS343A, PAL, SECAM, compatible
• Rack and surface mounting
• Lifetime Warranty, No Adjustments, No Maintenance
Eight or Sixteen Channel Contact Closure
Single Channel Multi-Data Protocol
AZ-81/82 Series
• Transmission of eight or sixteen Contact Closures over
one Multimode Fiber
• Form C NO/NC Dry Contact Closures
• Selectable feature maintains Contact Status on loss of
Optical Power
• Maintains Contact Status through Power Cycle
• User control to reset all Contact Status
• High density DB26 Data Connector with adaptor to
screw terminals
• Rack or surface mounting available
• LIfetime Warranty, No Adjustments, No Maintenance
AZ-480 Series
• Bi-Directional Data Transmission for Multimode or
Singlemode Fiber
• Tranceivers operate on one or two Multimode or
one Singlemode Fibers
• Switch selectable Multi-Data Protocol Channel
• Selectable Formats: RS-485/422/232 Manchester or Bosch
• Switch selectable 2-wire or 4-wire terminations
• DC to 115 Kbs/s • Stand alone or rack mounting
• Lifetime Warranty, No Adjustments, No Maintenance
Dual Channel Muti-Data Protocol
Eight Channel One Fiber FM Video
AZ-482 Series
• Dual Channel, Bi-Directional Data Transmission
• Transceivers operate on one or two Multimode or
one Singlemode fibers
• Selectable Formats: RS485/422/232 - Manchester or Bosch
• Two switch selectable Multi-Data Protocol channels
• Switch selectable terminations. 2-wire or 4-wire
• Diagnostic (LED’s) DC Power, Data and Optical Presence
• DC to 115 Kbs/s
• Stand alone or rack mounting
• Lifetime Warranty, No Adjustments, No Maintenance
AZ-880 Series
• FM Video with Real Time Full Color Transmission
• Available for Multimode or Singlemode Fiber
• Compatible with all camera manufacturers
• Diagnostics (LED’s) Video, Power and Optical Presence
• NTSC, RS170A, RS343A, PAL, SECAM Compatible
• Wall mounting with brackets provided or rack
(1 RU EIA High) into 19" rack
• Universal Power Input:
85 to 264 VAC @ 47 to 63 Hz, 40 Watts
• LIfetime Warranty, No Adjustments, No Maintenance
Single Channel 10-Bit Digital Video
Four Channel 10-Bit Digital Video
AZ-915 Series
• 10-bit Digital Single Channel Video Transmission
• Available for Multimode and Singlemode
• Two bi-directional data channels, muti-protocols,
with contact closures
• Three bi-directional data channels. Singlemode only
• Data Formats: RS-485/422/232, switch select for 2W/4W
• Diagnostic Indications: (LED’s) Video, Power, Data,
Frame Sync,Optic Presence
• NTSC, RS-170A, RS-343A, PAL, SECAM compatible
• Rack or surface mounting • Lifetime Warranty
AZ-940 Series
• 10-bit Digital - Four Channel Video Transmission
• Available for Multimode or Singlemode Fiber
• Compatible with all camera manufacturers
• Diagnostics (LED’s) Video, Power, Data, Frame Sync,
Optical Presence
• NTSC, RS-170A, RS-343A, PAL, SECAM compatible
• Available 1-16 channel in Multimode
up to 64 channel in Singlemode
• Rack or surface mounting
• Lifetime Warranty, No Adjustment, No Maintenance
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
CCTV
Public View LCD Monitor Mount Kit
169
CCTV
Fiber Products
Fiber Equipment Subrack System
Single Channel FM Video
AZ-SR20D/2 Series
• Built-in AFI Diagnostic capability
• Rear power bus to all plug-in transmitter or receiver cards
• 19" EIA rack frame compatible
• 100 watt DC power supply included
• Up to 14 rack card spaces. Some modules require more
spaces
• Blank space slot cards for 1, 2 or 4 available
• Universal Power Input:
100 to 240 VAC @ 47 to 63Hz, 100 Watts
• Size: 7-5/8" D x 19" W x 5-1/4" High
AZ-M100/M300/M300s Series
• Transmits/Receives Single Channel of high quality FM
on Multimode Fiber
• Compatible with all Video, CCTV, & monitor manufacturers
• Full Color Real Time Video Transmission
• Small profile
• Systems Diagnostics: (LED’s) Power, Video, and Optical
Presence
• Compatible with NTSC, RS-170A,RS-343A, PAL & SECAM
• Rack (RTM) or Surface (MTM) mounting available
SR-20/2 card cage
• Lifetime Warranty, No Field Adjustments, No Maintenance
Video and Reverse Multiprotocol Data
Video Multiplexer
KA-S731DVTEST1
• One-way video and reverse multiprotocol data
transmission over one or two multimode fibers
• 8-bit video processing
• 520 TV lines video resolution
• Unique data translation function
• Field-selectable data format
• 13 dB optical budget
KA-S734DVRRST1
KA-S734DVTEST1
• Four video channels, two-way data and four one-way
contact closure channels transmitted over one
multimode fiber
• 10-bit video processing
• 500 TV lines video resolution
• Unique data translation function
• Local or remote user-configurable data format
• Relay/contact closure - 4 forward channels
Video and Universal Up-The-Coax Data
8-Channel Digital Video
KA-S739DVRRST1
KA-S739DVTEST1
• One-way video and two-way control, response and
Genlock transmission over one or two multimode fibers
• Compatible with all major up-the-coax control systems
• 800 TV lines video resolution
• Operates up to 11 miles (18 km)
• Modern, heavy-duty housing design
• SMARTS diagnostics
KA-S708VRRST
FO-S708VTEST
KA-S708VTRST
• One-way transmission of eight video channels over
one multimode fiber
• Coarse Wavelength Division Multiplexer (CWDM)
technology
• 10-bit video processing
• 500 TV Lines resolution
• Video SNR >55 dB
• 6.2 MHz video bandwidth
Four-Channel Video System
4-Channel Digital Video
FO-S704VRRST
KA-S704VTEST
• One-way transmission of four real-time,
full frame video channels over one multimode fiber
• Supports all major video formats
• 640 TV Lines resolution
• 60 dB Video SNR
• 8 MHz video bandwidth
• Optical AGC
• 13 dB optical budget
KA-S707VRRSTL
KA-S707VTESTL
KA-S707VTRSTL
• One-way transmission of four video channels over
one multimode fiber
• Digital multiplexing technology
• 10-bit video processing
• 500 TV Lines resolution
• Video SNR >55 dB
• 6.2 MHz video bandwidth
RS-232/422 Data Fiber Transceiver
RS-485 (2-wire) Data Fiber Transceiver
IF-D1010
• RS-232/422 data transceiver
• Point-to-point topology
• Transparent to data encoding
• Multimode or single-mode available
IF-D1300
• RS-485 (2-wire) data transceiver
• Point-to-point topology
• Transparent to data encoding
• Multimode or single-mode available
• Add “WDM (A/B)” for one fiber version
• Add “-R3” for rack mount version
Ethernet Transceivers
Ethernet Switches
IF-D7120
• Point-to-point transceiver
IF-D7420
• 4-Port drop-and-repeat transceiver
IF-D7600EEX
• 8-port UTP 10/100Mbps switch
IF-D7600MMX
• 8-port 10/100 Mbps switch
(6-10/100Mbps UTP ports and 2-100Mbps Fiber ports)
• IEEE 802.3 compliant
• 10/100 Mbps (auto-negotiate)
• Environmentally hardened
• Add “-R3” for rack mount version
• Add “-C” for conformal coated PCB
170
• Add “WDM (A/B)” for one fiber version
• Add “-R3” for rack mount version
• IEEE 802.3 compliant
• 10/100 Mbps (auto negotiate)
• Environmentally hardened
• Additional configurations available
• Add “-C” for conformal coated PCB
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Fiber Products
Ethernet Media Converters
FiberPakTM Video Transmission Products
IF-DED2500
• Serial data to Ethernet converter
(RS-232, 422 or RS-485 transmission over 10/100Mbps Ethernet)
IF-DECT3000
IF-DECR3000
• Contact closure to Ethernet converter
(8 one-way contact closure transmission over 10/100Mbps Ethernet)
IF-FP1101
• Fixed video transmitter and receiver kit
• Transmitter mounts directly to camera
• Receiver includes built-in AGC circuitry
• Distances up to 2.5 miles (4 km)
• Additional transmitter and receiver module
configurations available as separate part numbers
•
•
•
•
IEEE 802.3 compliant • Available with fiber or UTP ports
Environmentally hardened
Additional configurations available
Add “-C” for conformal coated PCB
AiphoneTM Intercom Fiber Module
IF-TPT1000M
• UTP video transmitter
IF-TPR2100
• 2-channel UTP video receiver
IF-TPT1900
• UTP video transmitter/data transceiver
IF-TPR1900
• UTP video receiver/data transceiver
IF-VIC5211M
• AiphoneTM intercom fiber module - Master
IF-VIC5211R
• AiphoneTM intercom fiber module - Remote
• No in-field adjust. req. • Receivers incl. built-in AGC circuitry
• Receivers are compatible with IFS and all other
manufacturers’ UTP video transmitters
• Compatible with AiphoneTM LEM, LEF, and NEM intercom
systems
• Transmits video, audio, push-to-call, and contact
closure over one fiber
• Distances up to 2.5 miles (4 km)
• Add “-R3” for rack mount version
Video with One-Way Data Fiber Transmission
DTF Direct to Fiber In-Dome Modules
IF-VT1500
• Video transmitter/data receiver
IF-VR1500
• Video receiver/data transmitter
IF-VT1500WDA
• For Honeywell
IF-VDT14100WDMAD
• For American Dynamics
IF-FP1500WDMK
• For GE Security
IF-FP1500WDM
• For Pelco
IF-FP1500WDP
• For Pelco (for Coaxitron)
• No in-field adjustments required
• Supports RS-232/422 data interfaces
• Distances up to 2.5 miles (4 km)
• Add “WDM” for one fiber version
• Add “-R3” for rack mount version
Video with “Up-the-Coax” Data Fiber
Video with Two-Way Data Fiber Transmission
IF-VT1505
• Video transmitter/data receiver
IF-VR1505
• Video receiver/data transmitter
IF-VT1910
• Video transmitter/data transceiver
IF-VR1910
• Video receiver/data transceiver
• No in-field adjustments required
• Supports Panasonic ProteusTM, Pelco CoaxitronTM, Robot,
Vicon VicoaxTM, Videolarm CoaxLynxTM, Elbex, and others
• Distances up to 1 mile (1.6 km)
• No in-field adjustments required
• Supports RS-232/422 and RS-485 (2 or 4-wire)
data interfaces
• Supports one-way contact closure
• Add “WDM” for one fiber version
• Add “-R3” for rack mount version
• Add “WDM” for one fiber version
• Add “-R3” for rack mount version
4-Channel Video Multiplexer
4-Ch. Video with 2-Ch. Data Multiplexer
IF-VT7420
IF-VR7420
• 8-bit digitally encoded video transmission
• Transmits 4 video signals over one fiber
• Distances up to 1.2 miles (2 km)
IF-VT74202DR
• Four Channel Video Transmitter with 2 Data Channels
IF-VR74202DR
• Four Channel Video Receiver with 2 Data Channels
• Add “-R3” for rack mount version
• Add “-C” for conformal coated PCB
CCTV
CopperlineTM Video UTP Transmission
• 8-bit digitally encoded video transmission
• Supports RS-232/422 and RS-485 (2 or 4-wire)
data interfaces
• Distances up to 1.2 miles (2 km)
• Add “-R3” for rack mount version
• Add “-C” for conformal coated PCB
8-Channel Video Multiplexer
Single Channel Digital Video
IF-VT7820
IF-VR7820
• Eight Channel Video Multiplexer
• 8-bit digitally encoded video transmission
• Transmits 8 video signals over one fiber
• Distances up to 1.2 miles (2 km)
M5-FDVA Series
• 8 bit digitally encoded non-compressed video
transmission (10 bit available)
• Transmitter/receiver available on a multimode or
singlemode fiber
• Compact, wall mount and 3U chassis card
configurations
• Up to 56 receivers in one 3U chassis
• Environmentally hardened
• Add “-R3” for rack mount version
• Add “-C” for conformal coated PCB
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
171
CCTV
Fiber Products - UTP
Digital Video with Two-Way Data
4-Channel Video Multiplexer
M5-FDVA1DB1 Series
• 8 bit digitally encoded non-compressed video
transmission on a single fiber (10 bit available)
• LED indicators provide quick diagnosis of all important
system parameters
• Transmitter/receiver available on multimode or
singlemode fiber
• Compact, wall mount and 3U chassis card
configurations
• Up to 14 receivers in one 3U chassis
• Environmentally hardened
M5-FDVA4 Series
• 4 channels of 8 bit digitally encoded non-compressed
video transmission on a single fiber (10 bit available)
• LED indicators provide quick diagnosis of all important
system parameters
• Transmitter/receiver available on multimode or
singlemode fiber
• Wall mount and 3U chassis card configurations
• Module requires just one slot of 3U chassis
• Environmentally hardened
Fiber Transmitter and Receiver
Tool-Less Video Balun w/Surge Protection
PE-FR85011A
PE-FT85011A
• 8-bit digitally encoded video for hi-quality video
transmission over a single fiber
• Multimode fiber support for distances up to 6 km
• Single-mode fiber support for distances up to 46 km
• Compatible with NTSC, PAL, and SECAM video standards
• 12VDC or 24VAC power supply
OG-GVVB59SP
• Installs in less than 1 minute
• Transmits video 2000' or more
• Exceptional noise & interference rejection
• No wire stripping required
• No need to hassle with screw terminals
• Provides a highly cost effective solution
• Huge savings on cabling costs
• Surge protected
• Low cost
Analog CCTV Video Converter
Analog CCTV Video + Data Converter
P6-JVDTX01
• Transmitter converts a CCTV signal from cameras to
multimode or single-mode fiber up to 10km
• BNC (75 ohm) to multimode ST connector
P6-JVDRX01
• Receiver converts the optical signal back to an analog
composite video signal
• BNC (75 ohm) to multimode ST connector
P6-SVIDF2011100
• Transports analog video and data simultaneously
over fiber to extend signal distance and provide PTZ
functionality
• Transmitter BNC (75 ohm) to 850nm MM (ST)
P6-SVIDF2011110
• Receives the video signal on fiber and converts it back
to analog video
• Receiver BNC (75 ohm) to 850nm MM (ST)
• Add (SC) to the part number for multimode SC or
(SM) for single-mode SC connector
Passive UTP Transceiver Hub with Power
AX-HUBSAT4D
• Individual field selectable 24VAC and/or 28VAC outputs
• 4 amp total output current (1 amp max per channel)
• Four (4) PTC protected outputs
• Input 115VAC 50/60Hz, .9 amp
• Data: Four (4) data/PTZ inputs
• Video: Four (4) 75 ohm video inputs
• Four (4) individual power LED indicators
172
• Part# P6-SVIDF2013100 for MM (SC) and
P6-SVIDF2012100 for SM (ST) connector
Passive UTP Transceiver Hub
with Isolated Power
AX-HUB16DI
• Transmits UTP video, RS422/RS485 data and power
over a singel CAT-5 or highter
• 16 amp total output current
• 16 channels of quality video up to distance of 750’ per
channel
• Individual electronically isolated outputs
AX-HUBWAYAV
• Video Balun combiner for 24 VAC cameras
AX-HUBWAYDV
• Video/balun combiners for 12VDC cameras
Active UTP Transceiver Hub
with Integral Power
Passive UTP Transceiver Hub
with Integral Power
AX-HUBLD16CD
• Transmits UTP video, RS422/RS485 data and power
over a single CAT-5 or higher structured cable
• 16 channels of quality video up to a distance of 3000’
per channel
• 10 amp total output current
• Built-in picture and gain controls
• Compatible with 24VAC and 12VDC fixed or PTZ
cameras via Hubway AV or Hubway DV video/balun
combiners
AX-HUB16CD
• Transmits UTP video, RS422/RS485 data and power
over a single CAT-5 or higher structured cable
• 10 amp total output current
• 16 channels of quality video up to a distance of 750’
per channel
• Compatible with 24VAC and 12VDC fixed or PTZ
cameras via Hubway AV or Hubway DV video/balun
combiners
Active UTP Transciever Hub
UTP Video Transmitter
AX-HUBLDH16
• Transmits UTP video, RS422/RS485 data and power
over a single CAT-5 or higher structured cable
• Sixteen (16) channels of video over twisted pair up to a
distance of 3000 ft. per channel
• Compatible with AC or DC PTZ or fixed cameras
• Built-in picture and gain control
• Space saving 1U EIA 19" rack mount chassis
HVB16M64TP
• 16-channel over unshielded twisted pair
• 3000' cable runs
• High immunity to noise and interference
• Stainless steel construction
• 1 RU rack height
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
UTP
Multi-Port Passive Transceiver & Hubs
Multi-Port Active Receiver Hubs
HUTP813A
• 8-channel passive transceiver
• Includes (8) 2' (60 cm) coax jumper cables
HUTP862R
• 8-channel active distribution amplifier
• Includes (8) 2' (60 cm) coax jumper cables
• Power: 160 mA @ 120/230 VAC, 50/60 Hz
HUTP1613A
• 16-channel passive transceiver
• Includes (16) 2' (60 cm) coax jumper cables
HUTP3213A
• 32-channel passive transceiver
• Includes (32) 2' (60 cm) coax jumper cables
• All 6 include rackmount hardware
HUTP1662R
• 16-channel active distribution amplifier
• Includes (16) 2' (60 cm) coax jumper cables
• Power: 160 mA @ 120/230 VAC, 50/60 Hz
HUTP3262R
• 32-channel active receiver hub
• Includes (32) 2' (60 cm) coax jumper cables
• Power: 315 mA @ 120/230 VAC, 50/60 Hz
• Multiple Camera Transmitters & Receivers
HUTP413A
• 4-channel passive transceiver
• Power: none required
CCTV
HUTP452R
• 4-channel
Single Channel Passive & Active Transceivers
HUTP214TM
• UTP passive transmitter
• Integrated 9" coax cable with male connector
• Useful for cable lengths up to 3000' when used with
active receiver (HUTP652R)
• Dimensions: 1.8" L x 1.1" diameter
• Power: none required
HUTP653T
• UTP active transmitter
• Useful for cable lengths up to 5000' when used with
active distributive amplifier or active receiver
• Dimensions: 3.0" L x 1.5" W x 1.1" H
• Power: 6W @ 24 VAC/24 VDC
HUTP652R
• UTP active receiver
• Useful for cable lengths up to 5000'
• Dimensions: 3.0" L x 1.5" W x 1.1" H
• Power: 2.4W @ 12-24 VAC/12-24 VDC
Single Channel Passive Video Transceiver
Single Channel Transceiver
NV-208AM
• Features reliable screwless UTP terminal connection
• Male BNC connection directly to camera
• Transmit up to 750', 3000' with active receiver
• Built-in transient protection
• Supports “up-the-coax” type control signal up to 750'
• Exceptional interference rejection
NV-213A
• Screw mountable
• Transmit up to 750', 3000' with active receiver
• Screw terminal connection
• Buildt-in transient protection
• Supports “up the coax” type control signal up to 750'
• Exceptional interference rejection
Single Channel Passive Video Transceiver
Single Channel
Power-Video-Data Transceiver
NV-214AM
• Features reliable screwless UTP terminal connection
• 9" mini-coax cable with Male BNC for mounting
flexibility
• Transmit up to 750', 3000' with an active receiver
• Built-in transient protection
• Supports “up-the-coax” type control signal up to 750'
• Exceptional interference rejection
NV-218APVD
• Camera power with NVT quality
• Power-Video-Data (PVD) transmission
• Connect camera power at distance via UTP
• Transmit video up to 750', 3000' with an active receiver
• Use with any NVT PVD camera power products
• 9" mini-coax cable with Male BNC for mounting
flexibility
• Exceptional interference rejection
Single Channel Power-Video Transceiver
Single Channel PowerVideo+12VDC Convert
NV-216APV
• Camera power with NVT quality
• Power-Video (PV) transmission
• Connect camera power at distance via UTP
• Transmit video up to 750', 3000' with an active receiver
• Use with any NVT PVD camera power products
• Male BNC connection directly to camera
• Exceptional interference rejection
NV-226JPVD
• Camera power with NVT Video quality
• Extended distance camera power and video routed
through UTP and RJ-45
• Use with NVT’s PVD™ Power Supply Hubs & Cable
Integrators
• Up to 3000' (1 Km) with NVT’s Active Receiver Hubs
(see distance chart)
• Up to 750' (225 m) with NVT’s Passive Receiver Hubs
• Exceptional interference rejection
• Built-in transient protection
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
173
UTP
Multi-Channel Passive Receiver Hubs
NV-813
• 8-Channel
NV-1613
• 16-Channel
NV-3213
• 32-Channel
•
•
•
•
NV-813
NV-1613
Transmit up to 750', 3000' with an active receiver
Use as a passive transmitter or a passive receiver
Built-in transient protection • Supports “up-the-coax” type control signal up to 750'
Exceptional interference protection
NV-3213
Multi-Channel Passive “Stub” Hubs
CCTV
NV-813S
• 8-Channel
NV-1613S
• 16-Channel
NV-3213S
• 32-Channel
•
•
•
•
NV-813S
NV-1613S
NV-3213S
Compact rack mountable 19" 1U high enclosure and only 1-2" deep
Built-in transient protection • Supports “up-the coax” type control signal up to 750' (225m)
Use with any NVT passive transceiver or hub at distances up to 750' (225m)
Use with any NVT active receiver or hub as a rack-mountable passive transmitter
for distances up to 3,000' (1km)
Multi-Channel Active Receiver DA Hubs
NV-862
• 8-Channel
NV-1662
• 16-Channel
NV-3262
• 32-Channel
NV-862
NV-1662
NV-3262
•
•
•
•
•
NV-862 has four channels of output for each input
NV-1662 has two channels of output for each input, NV-3262 is non-DA
Receives up to 3000' or 1 mile when used with a NV-653T
Built-in brightness & sharpness controls • Built-in transient protection & ground lifting
Exceptional interference protection
Multi-Channel Digital EQ DA Receiver Hubs
NV-872
• 8-Channel
NV-1672
• 16-Channel
NV-3272
• 32-Channel
NV-872
174
NV-1672
NV-3272
• NV-872 has four channels of output for each input
• NV-1672 has two channels of output for each input, NV-3272 is non-DA
• Continuously and automatically compensates for cable attenuation and wiring polarity,
independent of video signal image
• Distances up to 3000' (1km) when used with any passive NVT transceiver or hub
4-Channel Passive Transceiver
4-Channel Active Receiver
NV-413A
• Transmit up to 750', 3000' with an active receiver
• Built-in transient protection
• Supports “up-the-coax” type control signal up to 750'
• Exceptional interference protection
• Lifetime warranty
NV-452R
• Receives up to 3000' or 1 mile when used with a NV-653T
• Exceptional interference rejection
• Built-in brightness & sharpness controls
• Built-in transient protection & ground lifting
• RJ-45 or screw terminal video input
• Lifetime warranty
4-Ch. Power Supply Cable Integrator Hub
16-Ch. Power Supply Cable Integrator Hub
NV-4PS10PVD
• Provides Class 2 SELV camera power and pass-through
video & telemetry data connectivity for up to 4 cameras,
each via a single RJ45 4-pair UTP cable
• Independently selectable 24 or 28 VAC with1 Amp max
per channel
• Automatic-reset fault protection; transient protection
• Individual floating outputs ensure total ground-loop immunity
• Diagnostic LEDs show load/no load, miswires, and
overload conditions
• Use with the NV-216APV, NV-218APVD or the NV-226JPV
• 1.75" high x 7.25" deep x 9.25" wide, wall or desk mount
NV-16PS10PVD
• Provides Class 2 SELV camera power and pass-through
video & telemetry data connectivity for up to 16 cameras,
each via a single RJ45 4-pair UTP cable
• Independently selectable 24 or 28 VAC with1 Amp max
per channel
• Automatic-reset fault protection; transient protection
• Individual floating outputs ensure total ground-loop immunity
• Diagnostic LEDs show load/no load, miswires, and
overload conditions
• Use with the NV-216APV, NV-218APVD or the NV-226JPV
• 1 U high; 12" deep; wall, desk, or rack-mountable
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
UTP
Single Channel Active Transmitter
NV-652R
• Receives up to 3000' or 1 mile when used with a
NV-653T
• Exceptional interference rejection
• Built-in brightness & sharpness controls
• Built-in transient protection & ground lifting
• Lifetime warranty
NV-653T
• Transmit distances up to 1 mile when used with an
Active Receiver
• Exceptional interference rejection
• Built-in transient protection & ground lifting
• Lifetime warranty
4-Ch. Power Supply Passive Receiver Hub
8+16-Ch. Power Supply Passive Receiver Hub
NV-4PS13PVD
• Provides Class 2 SELV camera power while receiving
video transmission and delivering P/T/Z telemetry all
over a single 4-pair Cat5e cable
• Independently selectable 24VAC-OFF-28VAC with 1 Amp
per channel
• Automatic-reset fault protection; transient protection
• Individual floating outputs ensure total ground-loop immunity
• Diagnostic LEDs show load/no load, miswires, and
overload conditions
• Use with NV-216APV, NV-218APVD or the NV-226JPVD
• 1 U high; 9.25” wide x 7.25" deep; wall, desk, or rackmountable
NV-8PS13PVD
NV-16PS13PVD
• Provides Class 2 SELV camera power while receiving video
transmission and delivering P/T/Z telemetry all over a single
4-pair Cat5e cable
• Independently selectable 24VAC-OFF-28VAC with 1 Amp
per channel
• Individual floating outputs ensure total ground-loop immunity
• Diagnostic LEDs show load/no load, miswires, and overload
conditions
• Use with the NV-216APV, NV-218APVD or the NV-226JPVD
• 1 U high; 8" deep; wall, desk, or rack-mountable
CCTV
Single Channel Active Receiver
The Votes Are In... ADI For All Your CCTV Needs
INTRUSION
FIRE
CCTV
IP NETWORKING
ACCESS
AUDIO/VIDEO
TOOLS & HARDWARE
HOME SOLUTIONS
WIRE & CABLE
Now Available at ADI...
Along With Industry Leaders Such As...
Many other great partners are available for all your CCTV needs.
To learn more, visit http://www.adilink.com/company/linecard.php
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
175
UTP
Single Channel Units
CCTV
N1-VB37M
• Passive video balun transceiver; distances up to 750'
N1-VB37F
• Passive video balun transceiver; distances up to 750'
N1-VB31PT
• Passive video balun transceiver with mini coax; distances up to 750'
N1-VB31M
• Passive video balun transceiver with mini coax; distances up to 750'
N1-VB31AT
• Video balun transceiver with mini coax; Transmits video & power; distances up to 750'
N1-VB43ATF
• Video, power and data combiner; distances up to 750'
N1-TR515
• Active video receiver; distances up to 1,500'
N1-TR560
• Active video receiver; distances up to 6,000' (3,000' with passive transceivers)
N1-TT560
• Active video transmitter; distances up to 6,000'
Multi Channel Units
N1-VH439
• Passive 4-channel video hub; distances up to 750'
N1-VH451
• Active 4-channel video hub; distances up to 1,500'
N1-VH456
• Active 4-channel video hub; distances up to 3,000'
N1-VH839
• Passive 8-channel video hub; distances up to 750'
N1-VH839M
• Passive 8-channel video hub; distances up to 750'; RJ45 jack inputs
N1-VH851
• Active 8-channel hub; distances up to 1,500'
N1-VH851M
• Active 8-channel hub; distances up to 1,500'; RJ45 jack inputs
N1-VH856
• Active 8-channel hub; distances up to 3,000'
N1-VH856M
• Active 8-channel hub; distances up to 3,000'; RJ45 jack inputs
N1-VH1639
• Passive 16-channel video hub; distances up to 750'
N1-VH1639M
• Passive 16-channel video hub; distances up to 750'; RJ45 jack inputs
N1-VH1651
• Active 16-channel hub; distances up to 1,500'
N1-VH1651M
• Active 16-channel hub; distances up to 1,500'; RJ45 jack inputs
N1-VH1656
• Active 16-channel hub; distances up to 3,000'
N1-VH1656M
• Active 16-channel hub; distances up to 3,000'; RJ45 jack inputs
IPQuikLinks
N1-VR124COAX
• Transmits network signals over coax
• Transmits up to distances of 2,500'
• LED indicators for network signals, link status and power
• Can be used with any network device
• Can utilize previously installed cable
• BNC connectors for coax
N1-VR124UTP
• Transmits network signals over a single twisted pair
• Transmits up to distances of 1 mile
• LED indicators for network signals, link status and power
• Can be used with any network device
• Can utilize previously installed cable
• RJ11 connectors for twisted pair
176
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
UTP
32-Channel Modular Receiver Hubs
• Hot swappable modular cards
• Front panel access
• Intelligent light link indication
N1-VH3239
• Passive 32-channel hub; distances up to 750'
N1-VH3251
• Active 32-channel hub; distances up to 1,500'
N1-VH3256
• Active 32-channel hub; distances up to 3,000'
N1-VH3200
• Powered card cage
N1-VB41X8
• Receiver card; distances up to 750'
N1-TR515X8
• Receiver card; distances up to 1,500'
N1-TR560X8
• Receiver card; distances up to 3,000'
CCTV
UTPLinks
• Video, power and data transmission over one Cat 5 cable
N1-CX452
• Powered card cage
N1-CXM16
• 4-channel crossover and power insertion card
N1-CXM22
• 4-channel crossover, power insertion, and RS-422 distribution card
N1-CHM12A
• 4-channel crossover, 12 volt DC power insertion and video card
N1-CXM16
• 4-channel crossover, power insertion and video card
N1-CXM22
• 4-channel crossover, power insertion, RS-422 distribution, and video card
N1-FAN64
• Fan card for N1-CX452
N1-POE48
• 4-channel IP crossover and power insertion card
Video, Power, and Data Distribution Units
N1-PV824
• Self-contained UTP video receiver and integrated 28VAC 8 channel power supply
• Wall mounted power insertion UTP video receiver panel
• 8 UTP/RJ45 inputs
• 8 BNC video outputs
• Individually fused power outputs
• Video and power LED indicators
• UL Listed
N1-PVX44
• 4 port video, power and data distribution unit
• Video, power and data over one Cat cable
• LED’s to indicate power detection
• RJ45 jacks for quick and secure connections
• Can be used in mid-span or local network solutions
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
177
SL-EVTPB1V1T
SECO-LARM's SL-EVTPB1V1T Passive Video Balun is the fast, easy, and low-cost
way to connect a CCTV camera to a monitor, multiplexer, or video recorder. The
video balun allows the video signal of a single CCTV camera to be transmitted long
distances over low-cost Cat5e/6 unshielded twisted pair (UTP) cable. To make it
more user and installer friendly, the SL-EVTPB1V1T is compact (2 ¼" x 19/32" x
19/32"), incorporates screw terminals, and includes built-in surge protection.
SL-EVTPB1Q
Passive Video Balun
SL-EVTPBPV1T
Video Balun with Pigtail
SL-EVTPB131R
Video, Power, Data Balun
SL-EVTPB1H05 Video Balun with
Voltage Booster or Converter
SL-EVTPH164T
16-Port Passive UTP Hub
SL-EVTAB1Q
Active Video Balun Set
www.seco-larm.com
UTP - Additional CCTV Products
TW3001P Single-Channel Video Transceiver
PE-TW3001AR
PE-TW3032AR
PE-TW3008AR
• Adaptive technology eliminates manual adjustments
• Full motion color/black & white video up to 4000'
• Supports Coaxitron control up to 750'
• Compatible with all Pelco twisted pair equipped
cameras, enclosures & domes
• Built-in surge supression • Supports NSTC, PAL & SECAM
• Easy termination with removeable UTP connector
• On PE-TW3008AR4 model, each channel has 4 BNC
connectors for video output
PE-TW3001P
• No power required
• Full motion color black/white and white video up to 750'
• Supports coaxitron control (PTZ control signals) up to 750'
• Compatible with all Pelco twisted pair equipped products
• Easy termination with screw terminals
• Supports NTSC, PAL, and SECAM
Passive Video Balun
Video, Power & Data Baluns
SL-EVTPB1
• Up to 2000' for black & white and 1300' for color
• Gold-plated BNC connector for added reliability & longer life
• Uses low-cost CAT 5 cable instead of costly coaxial cables
• Small size allows the mounting of multiple baluns
behind multiplexer without pigtails
SL-EVTPBV1TQ
• Same as SL-EVTPB1 but with 6' pigtails, screws,
terminals
SL-EVTPB1V1T
• Same as SL-EVTB1 but with screw terminals and builtin surge protection
SL-EVTPB131R
• Video, Power & Data Balun
SL-EVTPB131G
• Video, Power & Data Balun with ground loop isolator
Baluns with Voltage Converter or Booster
Back UPS
SL-EVTPB1L05
• Video, Power & Data Balun with voltage converter
• Changes 12/24 VAC/VDC input voltage to a regulated
5/12/24 VDC adjustable output voltage
SL-EVTPB1H05
• Video, Power & Data Balun with voltage booster
• Compensates DC voltage drops over long cable run
• Input voltage: 7-24 VDC
• Output voltage: 12 or 24 VDC (adjustable)
• Transmit video up to 2,000’
2G-ES Series
2G-RS Series
• Provides power protection for home, home office, and
security systems
• Battery Backup
• Solutions from 350VA to 1500VA
• Safe systems shutdown software and USB connectivity
• Automatic Voltage Regulation (RS Series)
• $75,000 (ES Series) or $150,000 (RS Series)
Equipment Protection Policy
Rack Mount AC Power Supply
Rack Mount DC Power Supply
AX-R24326UL
• 32 fused protected outputs
• 24VAC @ 25A (600VA) or 28VAC @ 20A (560VA)
AX-R24163UL
• 24VAC @ 12.5A (300VA) or 28VAC @ 10A (280VA)
• 16 fused protected outputs
AX-R615416UL
• 6-15 VDC @ 4 amps
AX-R615616UL
• 6-15 VDC @ 6 amps
• Removable terminal blocks
• Individual LED output indicators
• 2U rack mount chassis for use in standard EIA 19" rack
•
•
•
•
•
•
•
•
•
•
Transmit video up to 2,000’ (610m) over Cat5
Passive operation: no power required
Built-in impedance-coupled device & noise filter
Gold-plated BNC connector
Includes DC pigtail & data wires
Multi-colored LED power output indicator
CCTV
Active Video Transmission Over UTP
16 fused protected outputs
Removable terminal blocks
Individual LED output indicators
2U rack mount chassis for use in standard EIA 19” rack
AC CCTV Power Supplies
12VDC and 24VAC CCTV Power Supply
AX-ALTV244UL
• 24VAC @ 3.5 amp (85VA) or 28VAC @ 3.0 amp (85VA)
supply current
• Four fuse protected outputs
AX-ALTV248UL
• 24VAC @ 3.5 amp (85VA) or 28VAC @ 3.0 amp (85VA)
supply current
• Eight fuse protected outputs
AX-TV2416ULX
• 24VAC @ 7.0 amp (170VA) or 28VAC @ 6.0 amp (170VA)
supply current
• Sixteen fuse protected outputs
AX-ALTV1224C
• 7 amp total supply current:
• 12VDC @ 3.5 amp and
• 24VAC @ 3.5 amp (85VA)
• Sixteen (16) fuse protected outputs
• Includes enclosure, transformer and cam lock
DC CCTV Power Supplies
Rack Mount CCTV Power Supply
AX-615DC4UL
• 6-12VDC @ 2.5A or 12-15VDC @ 2A supply current
• Four (4) Class 2 fuse protected rated power limited
outputs
AX-615DC8UL
• 6VDC-15VDC @ 4A power supply
• 8 Class 2 rated fuse protected power limited outputs
AX-615416UL
• 6VDC-15VDC @ 4A power supply
• 16 Class 2 rated fuse protected power limited outputs
AX-VERT166C
• 24VAC or 28VAC @ 14 amp total output current
• Sixteen (16) fuse protected outputs
• Selectable 115VAC/230VAC input
• Individual power LED indicators
• 1U rack mount chassis for use in standard EIA 19" rack
• Vertiline246 - same as Vertiline166 with twenty-four
(24) fuse protected outputs
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
179
CCTV
Additional CCTV Products
Digital Remote Keyboard
Coaxial Video Surge Protection
DD-KBS3A
• PTZ control with a 3-axis joystick and telemetry buttons
• Accesses and controls any feature supported on
3rd party PTZ or dome cameras
• Keyboard can be extended up to 4,900' from DVR with
485-bus cable
• KBS3A keyboard supports Dedicated Micros DS2, BX2
and D4 DVRs
• Supports multiple operator control stations
DK-IBNC28
• Protects individual fixed camera
• Use when no ground Is available
• Surges dissipated through shield to ground
• BNC connected to camera output
• 10 year limited warranty
• Available for Coax and Coaxitron video (DK-IBNC68)
PTZ Camera Surge Protection
DVR Surge Protector & UPS
DK-DP4P
• Individual Pan-Tilt-Zoom camera protection
• One product protects Power, Data and Video circuits
• 2.8V coax video let-through voltage for best protection
• Typically installs in camera housing or pole base
• Ten year limited warranty
• DK-DPBP Version Includes passive Coax-UTP Converter
• Available for Coax, Balun and UTP Video
DK-DRP16
• Complete Power, Video and CAT5e surge protection
• UPS keeps DVR running through temporary power loss
• Field-Replaceable Battery
• 16-Ch. video surge protection - Coax, Balun, UTP or Coaxitron
• 2.8V let-through on coax video - maximum protection
with no signal loss
• Surge protected RJ-45 CAT5e jack
• Dry relay contacts for remote notification
• Balun Version (DRP16B) Incl.16-Ch. Passive Balun Converter
• 3 year limited warranty
IP Video Camera Surge Protector
Fixed Camera Surge Protection
DK-MRJPOE
• For Power over Ethernet devices
• Protects 5V data and 24/48V power pairs
• RJ-45 In/Out connection, external grounding connector
• Gigabit Ethernet data rate
• Can be used at camera, midspan, hub, etc.
• Ten year limited warranty
• Also available as 2U, 12-channel rack mount,
order DK-DTKRM12POE
• Also available, DK-DTK4VP, 4-channel video surge
protection
DK-PVPB
• Individual fixed camera protection
• One product protects camera power and video circuits
• 2.8V coax video let-through voltage for best protection
• Available for Coax, Coaxitron and UTP Video
• Typically installs in camera housing or pole base
• 10 year limited warranty
Rack Mount Video Surge Protector
DK-RM16NM
• Protects 16 coax video inputs
• 2U rack height
• 2.8V let-through provides maximum protection
• Also available for coaxitron protection (DK-RM16NMC)
• Ten year limited warranty
• New! DK-DTK4VP, 4-Channel video surge protection
• Also available DK-DTK4VP, 4-channel video surge
protection
FMSystems
180
FMSystems
Ground Loop Blocker Amplifier
FM-GB60
• Eliminates Ground Loop interference
• Restore picture quality on long cable runs
• Up to 5000 foot operation
• 4 independant video channels
• For CCTV, NTSC,and Pal video standards
• Independant level and sharpness controls
• 24VDC power supply included
Two Video Cameras on One Coax Cable
Crosspoint 32
FM-TVPRVP20
• Two video signals on one coax or UTP cable
• Add and extra camera without additional cabling
• Full Frame realtime video on both channels
• The A channel allows two way PTZ control
• Can use existing 24VAC camera power
• Corrects for cable slope loss on the B channel
• A channel can be used for video or RS422/485
• Video can run in both directions simultaniously
• Full line resolution in Color or B/W
KA-KTD34816A
• 16 inputs x 4 outputs, expandable to 32 x 8
• Perfect for mid-sized CCTV installs
• Program sequence tours, tilting and dwell times
• 32 programmable alarm inputs
• Looping video inputs
Controller Keypad
Video Power Supplies
KA-KTD405
• Designed to manage an entire CCTV system
• Control & program up to 512 cameras,
• 64 multiplexers, 64 recorders & 64 monitors
• Zone system partitioning
• 3-axis joystick
0H-HPTV2404E
• 4 outputs @ 4.0A total
• Converts 110VAC to 24VAC
• Full LED diagnostics
• 3A auto fuses per output with 5A main fuse
• Replace “E” with “CBE” for 2.5A circuit breakers
0H-HPTV2408E
• 8 outputs @ 4.0A total
0H-HPTV2416E
• 16 outputs @ 8.0A total
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Additional CCTV Products
Rack Video Power Supplies
Dual Output Power Supply
0H-HPR2416UL
• 24VAC 7A with 16 outputs fused @ 3.0A each
• Full LED troubleshooting diagnostics
• Mounts in 19" EIA equipment rack
• UL/ULC Listed CCTV Equipment
0H-R24166UL
• 24/28VAC 25/20A with 16 outputs fused @ 3.0A
• 24V or 28V output selectable at front panel
0H-R24326UL
• 24/28VAC 25/20A with 32 outputs fused @ 3.0A
OH-HP1224ACD
• Sixteen (16) output AC and DC power supply
• Eight (8) AC outputs rated 24VAC @ 4.0 amp
• Eight (8) DC outputs rated 6VDC @ 4 amp,
12VDC at 4 amps or 24VDC @ 2.5 amp
• Battery backup for DC outputs
• Output circuits rated 3A, protected with Automotive
style fuses
• Full LED diagnostics
Weatherproof Enclosure
SmartPITTM
Smart Protocol Interface Translator
HASMPIT
• Field Customizable POS/ECR Interface
• IP ATM interface text Inserter
• PTZ protocol interface & translator
CCTV
OH-HPBWPX
• NEMA 4X IP66 rated weatherproof enclosure with
mounting plate
• Polycarbonate body with lockable heavy duty
stainless-steel latches
• Shipped complete with non-corrosive hardware,
mounting feet, cover and integral gasket
• Temperature Range: -40°F to 120°F (-40°C to 49°C);
indoor or outdoor use
• Enclosure Dimensions: 12" H x 10" W x 6" D
HPTV Series Power Supplies
Surge Protector
HPTV24xx
• CCTV power supply
HPTV24xxWP
• Weatherproof CCTV power supply
HPTV24xxUL
• UL Listed CCTV power supply
• 24 VAC multi-camera power supplies, indoor, NEMA 4X &
UL Listed models • 4, 8 or 16 individually auto-fused or
SmartFused • 24 VAC output, up to 16.0 amps available
• Field expandable to 32 outputs (indoor, non-UL only)
• Status indicator lights & on/off switch
• Incoming power fused on primary
HDSP1
• Highly reliable protection for power video & data
• BNC female (in and out)
• Single point grounding
• Features terminal strip connections & data
• Lightweight, low profile
• 3 year warranty
Code Distributor
VideoBloX Joystick Keyboard Kit
HDCD8TP
• 8-way bi-directional distribution box
• Half duplex RS485 or RS232 control
• Daisy-chain up to three units
• LED transmit/receive indicators
HEGS5BLXKT
• Integrated control of VideoBloX and associated domes
• LCD display
• Separate logins for operators & supervisors
• HEGS5BLXKT kit includes required RS232 to RS422
converter
CCTV System Controller
DVR/Dome/Multiplexer Controller
HEGS5000
• Integrated control of multiplexers, VCRs & domes
• Full control of Honeywell’s HSX3208L matrix switcher
• 3-axis rate proportional joystick with integral zoom
control
• Full control of all features & menus of the Ultrak range
of domes
• LCD display
HJZTP
• Control of up to 128 HD6 and RapidDome
• Control & program up to 8 HXCT and HXMT multiplexers
• Variable speed, twist-to-zoom joystick
• Preset tour programming & activation
• Soft touch backlit keys
• LCD display
Distributed Audio
Maxcom Gold
8/2 and 16/2 Matrix & Keyboard
HVB16VDA3
• Distributes up to 16 inputs to 3 outputs each
• Equal video strengths for all outputs
• Stainless finish
• 2RU, rack mount ready
HMAXD82-US
HMAX162US
HKJMMTPUS
• 8/2 or 16/2 switch
• Enhanced alarm functionality
• 4 tours per camera
• PC configurable
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
181
Additional CCTV Products
Integrated Data Manager Professional Edition
• Seamless integration between POS data & surveillance video
HAIDMPPKNI
• Entry level basic IDM ProE software package,
for 1 server site & 1 POS terminal
HAIDMPTADDNI
• License for each additional POS terminal,
requires basic IDM ProE software package
HAIDMPFPKG
• Entry level basic IDM ProE
when software factory-installed on Fusion DVR
HAIDMPTADDSW
• License for each additional POS terminal
when IDM ProE factory-installed on DVR
HAIDMP1YSP
• Basic software support & maintenance, 1 year per POS terminal
Color & Monochrome Triplex Multiplexers
CCTV
HXCT16
• 16-camera color
• Available in 4, 9 or 16 camera versions
• Triplex operations for simultaneous recording, playback
and live viewing
• Video motion detection; individual alarm outputs
VideoBloX Lite
Pre-Configured Matrix Switch
HVBL Series
• Custom configured
• Embedded CPU controller
• Up to 96 video inputs and 8 video outputs
• High density compact design
• Controls Honeywell and other manufacturers’ domes
• Four separate spot monitor outputs, 9 and 16 camera models
• Mouse or front panel control
• 3 year warranty
UltraKey Lite
ULTRAKEY
• UltraKey CCTV Keyboard
UTP Power Supply
Professional Video Security Kit
8O-EAUP2412A
• 24VAC 16 O/P + 2 AUX O/P
• Supplied Voltage: 110V
• Power output to cameras: 24 VAC
• 16 UTP video and power outputs
Standard Camera Power Supply
8O-EA24A1218
8O-EA24A6P9
8O-EA12D8P9
• 24 VAC 18 O/P 12A • 24 VAC 9 O/P 6A
• 12 VDC 9 O/P 8A
IK-KIT505ID
• In one box
• Consists of:
* (1) color camera IK-ICD505
* (1) manual iris lens
* (1) universal metal bracket
* (1) plug-in transformer
MiniLink 5.8GHz Wireless Video & Audio
MiniLink Wireless Ethernet System
M5-ML581000
• 10 user selectable channels for simultaneous multi-unit
operation
• Transmits a crisp 500+ lines of resolution picture
• Directional and omni-directional transmitter configurations available
• Mobile, flexible, versatile - easy to install - plug and play
• Crystal controlled for frequency lock
• Low power consumption for battery or solar power
• 1000', 2500', and 1 mile systems available
• FCC approved - license free - 2 year limited warranty
M5-MLWES2500
• Transmits up to 20Mbps in standard mode and
50+Mbps in turbo mode
• 8 user selectable channels, 802.11a technology
• Dip-switch selectable setup with LED indicators
• Connects with standard Ethernet devices DVRs, video servers, IP cameras, routers/hubs
• Encrypted communication for secure transmission
• Transmits in ranges up to 30 miles
• Mobile, flexible, versatile - easy to install - plug and play
DVR Lock Boxes
Rack-Mount Lock Boxes
BW-BW200
• 20" W x 20" D x 8" H
BW-BW201
• 16" W x 16" D x 5" H
BW-BW224
• 20" W x 24" D x 8" H
BW-BW225
• 20" W x 20" D x 5" H
BW-BW230
• 17.5" W x 20" D x 8" H with rack-mounting ears
BW-BW235
• 17.5" W x 20" D x 5" H with rack-mounting ears
• All units come with a 120V continuous-duty fan
(12V optional) which works in conjunction with louvers
in the front door for cooling
182
HXMT4
• 4-camera monochrome
HXMT9
• 9-camera monochrome
• Easily mounts to racks and allows installers to lock-up
and cool DVRs and/or other components
• All units come with a 120V continuous-duty fan
(12V available) which works with louvers in the
front door for cooling
• Cable ports with protective grommets and additional
knockouts are included
• Lock with two keys
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Additional CCTV Products
NEW Tower Lock Box
Security Controller Keyboard
BW-BW240
• 8" W x 20" H x 20" D
MH-DXKB5UE
• Sleek, ergonomic design
• LCD monitor for status display
• PTZ of dome cameras
• Quick and easy control of the MH-DXTL5000U,
MH-DXTL4500U and MH-DXTL4700U Series DVRs
• Don’t just rely on passwords! Protect tower DVRs
and/or CPUs from unauthorized entry
• Includes a 120V continuous-duty fan which works with
louvers in the front door for cooling
• 2 cable ports with protective grommets and additional
knockouts
• Lock with two keys
• Hinged front door and removable top for ease of use
Passive CCTV/Ground Loop Isolation Hub
5M-500031
• CCTV over Cat5E/6
• Up to 2,200' to monitor
• Up to 1,000-1,500' to DVR
• Gold-plated RCA-M
• Compact design
• Compatible with 5M-500000, 5M-500009, 5M-500015,
5M-500023, 5M-500122, 5M-500130
5M-500133
• 16-channel passive CAT 5/6 CCTV hub with ground loop
isolation
• Manage video, remote power and PTZ control over one
Cat 5E/6 cable
• Ground Loop Isolation (GLI) on each port
• Set individual ports to Power-Thru or Pass-Thru mode
• Works with MaxLab baluns 5M-500000R, 5M-500009,
5M-500022 and 5M-500024
• 1U rack height
Single Channel A/V Micro-Modulator
TriplePlay 3-Channel A/V Modulator
NF-MM70
• Adjustable Gain Control
• Viewable on multiple televisions
• Easy DIP switch programming
• UHF Channels: 14-69
• CABLE Channels: 70-94, 100-125
• Digital PLL locked audio and video
• 5 year limited warranty
NF-MM73
• Modulates 3 channels simultaneously
• Viewable on multiple televisions
• Easy DIP switch programming
• UHF Channels: 14-69
• CABLE Channels: 70-94, 100-125
• Digital PLL locked audio and video
• 5 year limited warranty
Sequencing Analog Tuner/Demodulator
Powerful Indoor/Outdoor IR Spotlight
NF-TUNER
• Provides demodulated audio and video
• Perfect for existing modulated cameras
• Composite output for quads, multiplexers, and DVR’s
• TV tuner for LCD, Plasma, or CRT monitors
• Sequences multiple channels w/selectable dwell
• VHF, UHF, & CABLE channel coverage
• Channels retained during power outage
• Compact aluminum enclosure 4”x 6”x 1”
• Includes power supply & 1 year limited warranty
NF-IRLAMP
• 64 850 nm Infrared LED’s
• 30° spot up to 50'
• Lets cameras see in complete darkness
• Tough weather-resistant aluminum housing
• Internally routed cables
• Mounts to standard electrical fixtures
• Mounts directly to walls and ceilings
• Long emitter life
• 1 year limited warranty
CM6800 Matrix Switcher/Controller
KBD300A Keyboard
PE-CM6800
• 32 video inputs, 6 video outputs
• Inputs allow for viewing and control of multiple devices
• Video inputs individually selectable for terminating or
looping with switches on rear panel
• Supports Coaxitron® and RS-422 camera control
• Windows®-based manager software
• System partitioning prevents unauthorized viewing & control
• Integrated color bar generators
• Macro Program & event timers Automated System operation
• Multiple built-in ASCII communication ports
PE-KBD300A
• Keyboard to Control
* PE-CM6700/PE-CM6800/PE-CM9760SAT Matrix
Switchers
* Genex® Multiplexer When Used with
PE-CM6700/PE-CM6800
* Up to 16 Receivers Directly from Keyboard
• Automatically Recognizes Mode of Operation
• Joystick Control of PTZ Functions
• Preset Position and Pattern Control
• Auxiliary Operation
Multiviewer
MX4016CD Genex Series Multiplexer
PE-PMVC4
• Supports 4 composite video signals
PE-PMVR2
• Supports 2 VGA or 2 DVI input signals
PE-MX4016CD
• Full Duplex Operation
• “Covert” feature allows cameras to record but not to be
displayed during Live Viewing or Playback
• Simultaneous viewing of up to 16 cameras while
recording or playing tapes
• Programmable Detection Mask and sensitivity levels
for each camera
• Standard, Auto Tracking, VCR Matching, & Custom
Compatibility Modes
• Priority or exclusive Alarm Recording and display
• Remote control via RS-485 communications port
• Displays up to 60 (PE-PMVC4) or 30 (PE-PMVR2)
image windows on a single display
• Modular design, units of 1 RU can be cascaded together
• No single point of failure
• Video source displaced in real time with no frame loss
• Windows-based GUI
• View any image full screen
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
CCTV
Modular CCTV RCA Balun
183
Additional CCTV Products
RCS Series Rack Power Supply
MCS Series 24 VAC Power Supply, Indoor
PE-RCS Series
• 1RU models to fit standard EIA 19 rack
• Removable terminal strips with clamp-down connectors
• Individual green LED indicators for each output
• 26VAC available with 8, 16 or 32 outputs
• 13" deep units for easy back access
• Fuses or self-resetting circuit breakers on each output
• Removable 3-wire grounded AC line cord
• Class 2 rated (breaker models)
• Optional locking face plate
PE-MCS Series
• 2, 5, 10, or 20 amp capacities
• Outputs for 4, 8, or 16 cameras
• Fuse or circuit breaker protection;
spare fuses included with fused models only
• 120 VAC or 230 VAC Selectable Input
• 24 VAC output or 28 VAC output for longer wire runs
• AC Power Indicator with Power On/Off Switch
• Compatible with Cameras, Domes, and Pan/Tilts
• Models with circuit breakers have Class 2 Rated outputs
LIR Series Low Voltage IR Illuminators
CCTV
RA-LIR185
• 10° beam, 850nm Semi-Covert, 195' range
RA-LIR485
• 45° beam, 850nm Semi-Covert, 130' range
RA-LIR685
• 60° beam, 850nm Semi-Covert, 90' range
RA-LIR2185
• 10° beam, 850nm Semi-Covert, 410' range
RA-LIR2485
• 45° beam, 850nm Semi-Covert, 260' range
RA-LIR2685
• 60° beam, 850nm Semi-Covert, 180' range
RA-LIR3185
• 10° beam, 850nm Semi-Covert, 820' range
RA-LIR3485
• 45° beam, 850nm Semi-Covert, 525' range
RA-LIR3685
• 60° beam, 850nm Semi-Covert, 360' range
• High performance Infrared illumination
• Built-in 12–24V AC/DC power supply (no separate PSU),
12V or 24V transformer required
• 5-Year Warranty
Complete IR Package
System Controller
RA-IR318D2
• RA-LIR3185 (10°, 45°, and 60° models available)
• RA-DNL62D - True Day/Night Camera
• RA-L212AVDC4PIR - 2.7-12mm lens
• Other lens options available
• Weatherproof Housing (IP66)
• Heater/Blower included
SY-VSP3000
• Simple camera control and DVR display change
SY-VSP8500
• Direct Keys for Camera and DVR Control
• 6 Language Menu on LCD Display
• Telemetry Controller using 3-Axis Joystick
SY-VSP9000
• Backlight graphic LCD (320 x 240) with touch screen
• Customization of up to 16 user maps
• Control system supports SSP telemetry devices and
multiple protocols
BNC to VGA Convertor
Voltage Booster and Converter
SL-VC1BAQ
• Takes a BNC video input and outputs to a VGA monitor
• Converts almost any VGA LCD Monitor into a security
monitor
• NTSC (640 x 480) or PAL (768 x 576) compatible
• On-screen display (OSD) for configuration
• 5 VDC (adapter included)
SL-STHB105TQ
• Voltage Booster, 500mA, 12 or 24 VDC Output
• 7~12 VDC Input, 12 VDC Output
• 12~24 VDC Input, 24 VDC Output
SL-STLA105TT
• Voltage Converter, .5A, 5, 12 or 24 VDC Output
SL-STLA110TT
• Voltage Converter, 1A, 5, 12 or 24 VDC Output
Video Distributor
Video Amplifiers
SL-VA1102BWQ
• 1-in 2-out Video Distributor
SL-VA1104BWQ
• 1 in 4-out Video Distributor
SL-VA2101BWQ
• 1 Video Input, 1 Video Output
SL-2404BWQ
• 4 Video Inputs, 4 Video Outputs
• Compatible with both color and B/W signals
• Transmission distance up to 3,280’ (1,000m)
• Connect to a video camera, multiplexer, DVR, etc
• Gold-plated BNC connectors
• Sharpness & brightness adjustments for each channel
• Pass-through circuit: Power output can power nearby
devices
• Distributes a single video input to multiple video outputs
• Signals are cleaned and buffered to ensure clear, crisp
video is displayed up to 1000’ (300m)
• Compatible with both color, B/W signals and NTSC or
PAL
• Pass-through power circuit
• Patented Interlocking Design (SL-VA1102BWQ only)
184
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Additional CCTV Products
DC CCTV Power Supply
SL-1SA4P4UL
• 4 outputs, 4 amps
SL-1SA4P9UL
• 9 outputs, 4 amps
SL-1SA8P16UL
• 16 outputs, 8 amps
• Individually fused (@ 1.1 amps), O/Ps with PTC
resetable fuses
• Individual status LEDs
SL-1SD2P4UL
• 4 outputs, 2 amps
SL-1SD4P9UL
• 9 outputs, 4 amps
SL-1SD6P16UL
• 16 outputs, 6 amps
• Individually fused (@ 1.1 amps), O/Ps with PTC
resetable fuses
• Individual status LEDs
12VDC CCTV Power Supplies
24/28V AC CCTV Power Supplies
YY-PS1240DC
• 4 outputs
• 3A continuous at 12VDC
YY-PS1280DC
• 8 outputs
• 3A continuous at 12VDC
YY-PS1216DC
• 16 outputs
• 6A continuous at 12VDC
YY-PS2440
• 4 outputs
• 4A continuous @ 24VAC
YY-PS2480
• 8 outputs
• 4A continuous @ 24VAC
YY-PS2416
• 16 outputs
• 8A continuous @ 24VAC
5.8GHz All-Weather
Video Transmitter & Receiver
5.8GHz All-Weather
Video Transmitter & Receiver
OK-TCO5808Q9
• 5.8GHz real-time wireless video up to 4 Miles LOS
• 8 User selectable channels for multiple camera scenarios
• Not susceptible to interference from 2.4GHz 802.11 b/g
networks
• Ready-to-Install rugged IP-67 protective enclosures
OK-TCO5808R6
• 5.8GHz real-time wireless video up to 2,000' LOS
• 8 User selectable channels for multiple camera scenarios
• Not susceptible to interference from 2.4GHz 802.11 b/g
networks
• Ready-to-Install rugged IP-67 protective enclosures
900MHz All-Weather
PTZ Data Transceivers
5.8GHz DeskTop
Video Transmitter & Receiver
OK-DT900
• License free range up to 7 miles LOS
• For use with most PTZ camera models RS-422, RS-485, RS-232
• Compatible with most PTZ camera systems
• Ready-to-Install rugged IP-67 protective enclosures
OK-TC5808
• 5.8GHz real-time wireless video up to 1,000' LOS
• 8 User selectable channels for multiple camera
scenarios
• Not susceptible to interference from 2.4GHz 802.11 b/g
networks
• Stereo audio transmission capable
Wireless Digital Elevator Camera System
RT-Wave Mobile Wireless Digital Video
OK-EVL2R5803
• Range up to 200 Floors
• Tamper-proof 480 line Sony CCD corner mount camera
• Revolutionary pre-configured plug & play design
• Delivers real-time video up to 200 floors
• No connections to elevator mechanics or traveling cable
• Digitally immune to signal interference
• Perfect for discrete commercial & industrial elevator
CCTV applications
MOBILE RT-Wave Wireless Digital Video Series
OK-RTL2R5803
• Range up to 4,000 Feet
OK-RTX2R5803
• Range up to 6,000 Feet
RT-Wave Wireless Digital Video Series
Fully Adjustable Infrared Illuminator
FIXED RT-Wave Wireless Digital Video Series
OK-RTL1R5803
• Range up to 1 Mile
OK-RTL1R5821
• Range up to 17 Miles
OK-RTL1R5829
• Range up to 55 Miles
OK-RTX1R5832
• Range up to 200 Miles
VL-IR20036
• Fully adjustable IR - one model for all applications
• Adjustable beam angle 30°, 45°, and 60°
• Adjustable power settings for illuminating various
distances: 30m - 200m
• 20,000 hour LED life cycle
• Low power requirements: 15-30VAC or 18-30VDC,
42 watts
• Surge protection, user replaceable fuse
• 5 year warranty
• Revolutionary pre-configured plug & play design
• Transmits Real-Time DVD quality video and stereo audio
• OFDM Digital immunity to signal interference
•
•
•
•
•
CCTV
AC CCTV Power Supply
Revolutionary pre-configured plug & play design
Transmits Real-Time DVD quality video and stereo audio
OFDM Digital immunity to signal interference
Extreme mobile performance up to 6,000 feet
Rugged all-weather IP-67 protected enclosure
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
185
Additional CCTV Products
Wireless Power Boxes
VL-PV18N
• 16' lowering pole with a 20" transformer base
• Only one technician is needed to service the camera
• Lowering is achieved using a variable-speed drill with
torque adjustment
• Factory wired, plug-n-play
• Accepts both Analog and IP camera systems
• Designed to withstand wind lodads of 96 - 110mph
VL-PB24L900/24/58
• Transmit wirelessly: 900mHz 2.4GHz or 5.8GHz models
• Rugged outdoor NEMA box enclosure (4x1 IP67)
• Connects directly to Videolarm wall mount enclosures
• 96 va power supply, designed for either 230 VAC or 115
VAC input with 24 VAC output
• Omni direction antenna included (5.8GHz models also
include built-in directional antenna)
CCTV
PolEvator
WHO SAYS YOU CAN’T HAVE IT ALL?
AT ADI, WE MAKE OUR MARK WITH MORE THAN ONE COLOR
Create your own masterpiece.
Ask about our full palette of custom solutions.
Commitment. Service. People.
Visit us on the web at http://www.adilink.com • Call 1-800-233-6261 for your nearest ADI location
INTRUSION
186
FIRE
CCTV
IP NETWORKING
ACCESS
AUDIO/VIDEO
TOOLS & HARDWARE
HOME SOLUTIONS
WIRE & CABLE
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adilink.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
