EN
®
TROUBLE SHOOTING
The screen is blank
• Check that the camera is powered up.
• Check that the monitor is powered up.
• Check that the video cable connecting the camera to the monitor is connected properly.
The screen image is dim
• Clean the lens (using a soft, clean cloth).
• Check that the light source is adequate.
The screen image has poor
contrast
• Adjust the monitor’s contrast knob.
• Change the position of the camera.
The screen image flickers
• Change the position of the camera.
The screen image is distorted
• Change the position of the camera.
The camera case is hot
• Check that the correct power supply is in use.
