VIDEO INTERCOM SYSTEM
LINE-UP CATALOGUE
Flexible configurations
that work for you,
whatever
your needs
Trademarks and registered trademarks
- MIFARE is a registered trademark of NXP B.V. and is used under license.
- iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.
- Android is a trademark of Google Inc.
- SD, SDHC and SDXC Logos are trademarks of SD-3C, LLC.
- The software of the sub monitor is based in part on the work of the Independent JPEG Group.
All other trademarks identified herein are the property of their respective owners.
Important
- Safety Precaution: Carefully read the operating instructions and installation manual before using this product.
- Panasonic cannot be responsible for the performance of the network and/or other manufacturers' products used on the network.
• The actual product may vary slightly from the photograph.
• All pictures of the LCD display are simulated.
• Weights and dimensions are approximate.
• Design and specifications are subject to change without notice.
• These products may be subject to export control regulations.
DISTRIBUTED BY :
MG-DHPC016EN 1705ITP/ZZZ-SX3
System Configuration Example
VIEW AND TALK FLEXIBLY
System Units
Wireless Video Intercom System
Main Monitor Station
VL-SW251
VL-MW251
Wireless Monitor Station
VL-W605
Up to
Panasonic offers various Video Intercom System models
to flexibly suit the size of your house and your lifestyle.
4
Bedroom
Room 2
Room 1
Door Station
Repeater for
Wireless Monitor
VL-V522L
VL-FAN2
Up to
2
Living Room
Kitchen
Up to
2
Den
Panasonic
PBX
< 2 Wire >
Please consult your
dealer when connecting
with a PBX.
PBX
This image shows
the KX-NS500.
Electric lock
Electric lock
System Units
Video Intercom System
2.4 GHz Wireless Series
Smartphone Connect Series
VL-SW251
4-wire Series
VL-SVN511
VL-SF70
Main Monitor Station
VL-SVN511
VL-MVN511
2
Room 1
Room 2
Mobile Devices
Router
Living Room
< 2 Wire >
1 x Main Monitor: VL-MVN511
1 x Door Station: VL-V522L
1 x Main Monitor: VL-MF70
1 x Door Station: VL-VF580
Units
VL-SW251
VL-SVN511
VL-SF70
Door Station (Doorphone)
2
2
2
Main Monitor
1
1
3
4 (2.4 GHz)
—
—
Wireless Sub Monitor
•
Video / Picture Recording
Connectable
Electric Lock Release (Door Opener)
H: 87° V: 66°
H: 87° V: 66°
H: 51° V: 38°
—
•
Voice Changer
•
—
—
•
—/—
= Connectable
2
5-inch WQVGA
colour
VL-W605
1.8-inch
VL-FAN2
Repeater
•
up to 2
x
up to 4
Kitchen
< 4 Wire >
Switch Box
Electric lock
Electric lock
Comparison of the wiring
VL-SW251
VL-V522L
•= Connectable (same as packaged combination)
4-Entrance
(*1)
(*1, *2)
VL-SVN511
VL-MW251
VL-SF70
VL-MVN511
VL-V522L
VL-VF580
VL-MF70
VL-V555
0.3 M pixels
VL-V522L
0.3 M pixels
VL-V566
0.3 M pixels
x
x = Not connectable
Lobby Station
AC/DC
(*1, *2, *3)
VL-VF580
0.3 M pixels
VL-VF540
0.3 M pixels
•
x
x
•
x
5-inch WQVGA
colour
smartphone connect model
VL-MF70 (VL-SF70)
7-inch WVGA
colour
wired model
x
x
x
x
•
VL-MV26*4
3.5-inch QVGA
colour
wired model
x
x
x
x
x
*1 Wide/zoom settings and zoom position settings are not available.
*2 Doorphone LED light illumination settings and backlight compensation settings are not available.
*3 Outside monitoring using the doorphone is not available.
*4 Connectable to doorbell
2
Room 1
Living Room
—
Door Station
VL-554/
VL-V554U
1.0 M pixels
Up to
Switch Box*2
Compatibility of Main Monitor, Wireless Monitor and Door Station
Main Monitor (Package No.)
VL-VF580
Up to
(2)*2
*1 The main monitor must be on the same home wireless network as a smartphone/tablet (with the dedicated app installed).
*2 When connecting 2, an optional Door Station is required.
Wireless Sub Monitor (2.4 GHz)
Door Station
VL-MF70
—
•
Please contact your nearest Panasonic dealer for sales information.
Monitor
•
—/—
•
•
System Units
Video Intercom System
—/
Touch Panel / Pan & Tilt
Intercom Call
Electric lock
Bedroom
•
—/•
Viewing Angle
(add up to 2 monitors)
Please consult your
dealer when connecting
with a PBX.
3
Night Vision (LED Light)
Repeater
VL-MVN511 (VL-SVN511)
This image shows
the KX-NS500.
VL-SF70
•
•
• (2)
•
(2)*2
Panasonic PBX
VL-MW251 (VL-SW251)
PBX
VL-PS241
—
1
—/
Recording
Others
• (4)*
—/•
• (2)
•
—
Smartphone, Tablet
Devices
PBX
4
VL-RLY1
Model Number
Connectable
Kitchen
Panasonic
Up to
Den
Electric lock
Comparison Chart
Maximum
VL-V522L
Up to
Bedroom
1 x Main Monitor: VL-MW251
1 x Door Station: VL-V522L
1 x Wireless Sub Monitor: VL-W605
Door Station
VL-V590
0.3 M pixels
VL-RLY1
*1
VL-V900
1.0 M pixels
PBX
Power plug
AC/DC
(Optional Door Station)
*1
AC adaptor
AC adaptor
VL-PS241
AC/DC
PBX
x
(Optional Door Station)
AC cable
x
x
Option input x 2
(Emergency terminals)
AC/DC
x
*1 When connecting 2 E-locks, an optional Door Station is required.
*2 Switch box included with the optional VL-VF580.
x
3
2.4 GHz Wireless Series
Smartphone Connect Series
Wireless Video Intercom System
Video Intercom System
VL-SW251
VL-SVN511
5-inch
Wide Screen
5-inch
Wide Screen
Up to
4
Up to
Up to
2
2
< 2 Wire* >
< 2 Wire* >
Door Station
VL-V522L
Main Monitor Station
VL-MW251
Wireless Monitor Station
VL-W605
Door Station
VL-V522L
Main Monitor Station
VL-MVN511
* Easy installation by simply replacing existing doorbell unit Nonpolar 2-wire system.
* Easy installation by simply replacing existing doorbell unit Nonpolar 2-wire system.
Wireless Handset
Night Vision
(2.4 GHz)
Door Station is equipped with LED lights (illumination
lamp). It enables the colour display of visitors at a distance
of about 50 cm at night.
Check visitors and respond promptly from everywhere in
the home and even while you are doing something else, by
wireless handset.
E-mail Notification*2
Smartphone Connect*1
(LED Light)
The main monitor can send e-mail
with a time stamp and image of
visitors to e-mail addresses
registered in advance, enabling
you to check who has visited when
you are outside the house (even
when you are overseas).
You can use your smartphone or tablet as a sub monitor to
respond to visitors and unlock electric locks no matter where
you are in the home.
You can also monitor doorphone images when you want to
check the door entrance.
Other Features
Equipped with LED light
Answer Visitors and
Unlock the Electric Locks
Monitoring
Supports iOS and AndroidTM (free application)*
- iPhone 5 and later, iPad (iOS 7.0 or later)
- Android smartphones and tablets (Android 4.0 or later)
• Electric Lock Release Support: VL-RLY1 (12 V AC/DC, less than 1 A)
• Picture Recording (Up to 50 visitors (up to 8 still images per visitor))
• Night Vision (white coloured LED lights)
• Voice Changer
•
Wireless Network Connection
Other Features
Picture Recording
(8 Consecutive recorded images each)
Eight consecutive still images
of visitors are automatically
recorded. (Up to 50 times, 400
images in total) This ensures
that you will see every person
visiting your home. Images
can also be displayed
frame-by-frame.
•
Electric Lock Release Support : AC30 V-1 A / DC24 V-1 A
(Door Opener)
•
Voice Changer
•
Intercom Call (between main monitor and sub monitor)
In addition to smartphones/tablets,
the main monitor can also
wirelessly connect to the
wireless router for easy
connections without a cable.
Internet
VL-MVN511
* Some mobile devices may not be compatible.
* For the latest information about the app and
compatible devices, visit the following website.
Wireless network
Router
Modem
Up to
4
http://panasonic.net/pcc/support/intercom/smartphone/
Mobile devices
Options
Door Station (Doorphone)
VL-V522L
Up to
2
Options
Wireless Monitor Station
(Sub Monitor)
VL-W605
Lobby Station
VL-V590
VL-FAN2
PBX
Up to
2
Up to
4
Up to 20
main monitors
can be connected.
4
Repeater for Wireless Monitor
This image shows
the KX-NS500.
Connectable PBX Model Numbers
KX-TDA30/100/100D/200/600 series
KX-TDE100/200/600 series
KX-NS300/500/700/1000 series
Please consult your dealer when
connecting with a PBX.
Door Station (Doorphone)
VL-V555 (Surface mount)
CMOS 0.3 M pixels
Up to
2
Door Station (Doorphone)
VL-V554 (Surface mount)
CMOS 1.0 M pixels
Up to
2
Door Station (Doorphone)
VL-V522L (Surface mount)
PBX
Lobby Station
VL-V590
Up to
2
Up to 20
main monitors
can be connected.
This image shows
the KX-NS500.
*1 The main monitor must be on the same home wireless network as a smartphone/tablet (with the dedicated app installed).
It is also necessary to run the dedicated app in order to receive visitor's calls on a smartphone/tablet.
*2 To use this function, a main monitor with e-mail sender information registered must be connected to the internet.
E-mail may not be able to be sent, depending on the condition of the network.
Connectable PBX Model Numbers
KX-TDA30/100/100D/200/600 series
KX-TDE100/200/600 series
KX-NS300/500/700/1000 series
Please consult your dealer when
connecting with a PBX.
5
Multi-Entrance System
4-wire Series
Video Intercom System
1 by 4 Entrance System
VL-SF70
7-inch
Up to
Wide Screen
2
VL-VF540
Up to
3
< 4 Wire >
Stylish Door Station for
Door Station
VL-VF580
Monitor
VL-MF70
7-inch Wide Monitor
This monitor features a
7-inch wide LCD. As the
monitor, it lets you clearly
identify visitors.
Multi-family Housing or Office,
Commercial Facilities
Up to 4 groups/12 monitors can be connected to VL-VF540 and a
separate group can be set for each of the 4 call buttons. This
enables visitors to call the household they are visiting without
disturbing other households. The household can respond by
checking the visitor's face and unlocking the lobby door.
Three Monitors Connectable
A maximum of three monitor units can be connected. By installing
them in the living room and other rooms where you spend the
most time, such as a bedroom or kitchen, you can answer the
visitor immediately.
*1
Stylish and Tough
System Configuration Example
The robust body meets the dustproof
and waterproof requirements of IP54*1
and a hairline aluminium panel makes
your entranceway more stylish.
Switch
box*3
Lobby Station
VL-VF540
*1 Electric lock (user supplied)
Monitor
VL-MF70
Door Station
VL-VF580
*2
Picture Recording
*3
Up to 50 visitor images are
automatically recorded and
saved. You can check them
when you return home.
Other Features
•
Electric Lock Release Support (Door Opener) : DC12 V-1.5 A
•
Intercom Call (between monitors) * Multiple monitors required
Two Types of Mounting
*2
The system can be both attached to a wall or embedded in a wall.
Both types of mounting fixtures are included.
*2
*3
*2
Flush
Mounting box
*3
Wall
*2
Supported Models
Options
Door Station (Doorphone)
Monitor
VL-VF580
VL-MF70
Up to
Up to
2
3
Included
switch box
6
Surface
mounting base
Wall
Door Station (Doorphone)
Monitor
VL-VF580
VL-MF70
Up to
Up to
4
12
Included
switch box
Up to 4 groups/12 monitors can be connected
4 name plates
• Electric Lock Release Support (can be installed in front of each
individual home in addition to the lobby)
• Night vision with LED lights and illumination sensor
• CMOS camera (Horizontally: Approx. 51° Vertically: Approx. 38°)
•
•
*1 Water resistance is only assured if the doorphone is installed correctly according to the instructions in the Operating Instructions, and appropriate water protection measures are taken.
*2 Electric lock (user supplied)
*3 Switch box (included with the optional VL-VF580, NOT included with the VL-MF70)
7
Options
VL-SVN511
Model number and name
Model Composition
Dimensions
VL-SVN511
Model number and name
Dimensions
(Unit: mm)
VL-MVN511 x 1
(Unit: mm)
VL-V522L x 1
VL-MVN511
VL-V522L
VL-PS241
VL-RLY1
Main Monitor Station (Main monitor)
Door Station (Doorphone)
Power Supply Unit
Relay Box
161
23.5
Up to
2
99
VL-V590
VL-V566
VL-V555
Optional Lobby Station
Optional Door Station (Doorphone)
Optional Door Station (Doorphone)
78
54
131
92
104
Power consumption (approx.)
Dimensions (H x W x D)
(Excluding protruding sections)
Power consumption
Dimensions (H x W x D)
(Excluding protruding sections)
Weight
Operating environment
Power supply unit (VL-PS241)
24 V DC, 0.5 A
Supplied by the main monitor
Input: 220-240 V AC, 0.2 A (50/60 Hz)
Output: 24 V DC, 0.6 A
Supplied by the main monitor
Standby: Approx. 1.8 W
During operation: Approx. 10 W
—
—
—
186 x 161 x 23.5 mm
131 x 99 x 36.5 mm
104 x 100 x 54 mm
92 x 78 x 38 mm
485 g
200 g
215 g
130 g
Display language
Talking method
Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): up to 90 %
—
—
—
English, Arabic
—
—
—
Hands-free
Hands-free
—
—
—
—
—
169
131
Up to 20
main monitors
can be connected.
82
100 V–240 V AC, 50/60 Hz
Supplied by the main monitor
Standby: 0.02 A During operation: 0.03 A
—
—
131 x 99 x 36.5 mm
169 x 118 x 30 mm
200 g
395 g
358 x 180 x 17.3 mm
27 x 101 x 82 mm
69.5 x 101 x 82 mm (when raising the antenna) (Excluding sections embedded into the wall)
2.0 kg
Supplied by the main monitor
Ambient temperature: Approx. -15 °C to +55 °C
Ambient temperature: Approx. 0 °C to +40 °C Ambient temperature: Approx. -10 °C to +50 °C Ambient temperature: Approx. -10 °C to +50 °C
Relative humidity (non-condensing): up to 90 %
Relative humidity (non-condensing): up to 90 % Relative humidity (non-condensing): up to 90 % Relative humidity (non-condensing): up to 90 %
(tested up to -20 °C)
2.402 GHz to 2.481 GHz
—
—
—
Approx. 100 m (line-of-sight distance from the main monitor)
—
—
—
Viewing angle
—
Image sensor / camera (pixel)
—
External material
Horizontally: Approx. 87˚ Vertically: Approx. 66˚ Horizontally: Approx. 87˚ Vertically: Approx. 66˚ Horizontally: Approx. 170° Vertically: Approx. 130°
—
CMOS sensor (Approx. 0.3 M pixels)
CMOS sensor (Approx. 0.3 M pixels)
—
Flush mount (flush mounting box supplied)
Surface mount (mounting base supplied)
Surface mount (mounting base supplied) or
Flush mount (flush mounting box sold separately)
Flame retardant PS resin
Stainless steel and flame retardant ABS resin
Flame retardant ABS resin
Aluminium and flame retardant PC+PS resin
VL-SF70
Wireless transmission method
Viewing angle
IEEE 802.11 b/g/n 2.4 GHz
—
Horizontally: Approx. 87°
Vertically: Approx. 66°
—
—
Image sensor / camera (pixel)
—
CMOS sensor (Approx. 0.3 M pixels)
—
—
Minimum illuminance required
—
1 lx (within approx. 50 cm from the camera lens)
—
—
Lighting method
—
Warm white coloured LED lights, Infrared LEDs
—
—
IP rating / IK rating
—
—
Wall mount (mounting bracket supplied)
IPX3*1
Surface mount (mounting base supplied)
—
Installation method
Wall mount or attach to DIN rail
Wall mount or attach to DIN rail
Flame retardant ABS and PS resin
Flame retardant ABS resin
Flame retardant PC+ABS resin
Flame retardant ABS resin
External material
RA
OG
PR
Standby: 0.07 A During operation: 0.15 A
Installation method
Ambient temperature: Approx. -15 °C to +55 °C Ambient temperature: Approx. 0 °C to +50 °C
Ambient temperature: Approx. 0 °C to +40 °C Relative humidity (non-condensing): up to 90 %
Relative humidity (non-condensing): up to 90 %
Relative humidity (non-condensing): up to 90 %
(tested up to -20 °C)
(indoor use only)
30
AC adaptor (Product No. PQLV219)
Output: 6.5 V DC, 0.5 A
Frequency range
Transmitting range
5-inch wide colour / WQVGA (480x272 pixels)
Display
D) STA
TUS
85 g
Operating environment
118
36.5
358
M
(LE
101
Power source
99
69.5
VL-FA
N1
IN USE
38
17.3
2
Weight
Power source
180
Up to
36.5
100
186
VL-FAN2 (For VL-SW251)
Optional Repeater for Wireless Monitor
Model Composition
VL-SF70
VL-MF70 x1
VL-VF580 x1
Model number and name
Dimensions
(Unit: mm)
VL-MF70
VL-VF580
Monitor
Door Station (Doorphone)
201
Up to
101
Up to
25.5
3
35
2
135
143
VL-SW251
Model Composition
VL-SW251
VL-MW251 x 1
VL-V522L x 1
VL-MW251
Model number and name
Dimensions
(Unit: mm)
165
38
Up to
2
99
36.5
Main Body
Up to
52
4
Charger
Power consumption
Dimensions (H x W x D)
(Excluding protruding sections)
Weight
Operating environment
Display
90
131
157
Supplied by the main monitor
Ni-MH battery (3.6 V DC / 650 mAh)
AC adaptor (Product No. PQLV219)
Output: 6.5 V DC, 0.5 A
Standby: Approx. 0.04 A
During operation: Approx. 0.28 A
—
—
—
190 x 165 x 38 mm
131 x 99 x 36.5 mm
157 x 52 x 35 mm
115 x 76 x 90 mm
105 x 76 x 48 mm (using without the stand)
785 g
*2
200 g
175 g (including the battery)
115 g (including the stand)
Ambient temperature: Approx. -15 °C to +55 °C
Ambient temperature: Approx. 0 °C to +40 °C
Ambient temperature: Approx. 0 °C to +40 °C Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): up to 90 %
Relative humidity (non-condensing): up to 90 % Relative humidity (non-condensing): up to 90 %
Relative humidity (non-condensing): up to 90 %
(tested up to -20 °C)
—
1.8-inch colour display
—
English
—
Depends on main monitor
—
Talking method
Hands-free
Hands-free
Hands-free
—
Frequency range
—
Hands-free
Hands-free
Viewing angle
—
Horizontally: Approx. 51° Vertically: Approx. 38°
Image sensor / camera (pixel)
—
CMOS sensor (Approx. 0.3 M pixels)
Minimum illuminance required
—
1 lx (within approx. 50cm from the camera lens)
Lighting method
—
White coloured LED lights
IP rating / IK rating
—
IP44*1
Installation method
Wall mount (mounting bracket supplied)
Surface mount (mounting base supplied)
Flame retardant ABS resin
Flame retardant ABS resin
VL-VF540 series
Model number and name
Optional Accessories
VL-VF540
Dimensions
(Unit: mm)
*125 / 119
Door Station (Doorphone)
—
2.402 GHz to 2.481 GHz
—
—
—
Power source
Image sensor / camera (pixel)
—
CMOS sensor (Approx. 0.3 M pixels)
—
—
Power consumption
Minimum illuminance required
—
1 lx (within approx. 50 cm from the camera lens)
—
—
Lighting method
—
Warm white coloured LED lights, Infrared LEDs
—
—
IP rating / IK rating
—
IPX3*3
—
—
Installation method
Wall mount (mounting bracket supplied)
Surface mount (mounting base supplied)
—
—
Flame retardant ABS resin
Flame retardant ABS resin
ABS resin
ABS resin
Dimensions (H x W x D)
(Excluding protruding sections)
Weight
Operating environment
*41 / 15.5
4
101
35
12
201
45
87
25.5
135
*Included with the optional VL-VF580
AC adaptor (Product No. PNLV245), Output: 24 V DC, 0.5 A AC adaptor (Product No. PNLV245), Output: 24 V DC, 0.5 A
Supplied by the monitor
—
Standby: Approx. 0.5 W
During operation: Approx. 1.5 W
Standby: Approx. 1.3 W
During operation: Approx. 10 W
Surface mount: 268 x 125 x 41 mm
Flush mount: 262 x 119 x 15.5 mm
143 x 101 x 35 mm
87 x 87 x 45 mm
135 x 201 x 25.5 mm
500 g
265 g
100 g
465 g
Ambient temperature: Approx. -15 °C to +55 °C
Relative humidity (non-condensing): up to 90 % (tested up to -20 °C)
Ambient temperature: Approx. 0 °C to +40 °C
Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): from 45 % up to 90 % Relative humidity (non-condensing): from 45 % up to 90 %
—
—
Approx. 7-inch wide colour display
Hands-free
—
Hands-free
Horizontally: Approx. 51° Vertically: Approx. 38°
1 lx (within approx. 50 cm from the camera lens)
—
—
—
—
Talking method
Minimum illuminance required
87
143
Display
Viewing angle
Monitor
Up to
*Surface mount /
Flush mount
Horizontally: Approx. 87° Vertically: Approx. 66°
Switch Box
Up to
*268 / 262
—
VL-MF70
VL-VF580
Door Station (Doorphone)
2.402 GHz to 2.481 GHz
*1 When sub monitors and extension monitors are used together, a total of up to 6 sub monitors and extension monitors can be registered.
*2 Including AC cable. The weight of the AC cable differs depending on the region.
*3 Water resistance is only assured if the doorphone is installed correctly according to the instructions in the Installation Guide, and appropriate water protection measures are taken.
White coloured LED lights
—
—
IP rating / IK rating
IP54*1 / Compliant with IK07
IP44*1
—
—
Installation method
Flush mount or Surface mount
(flush mounting box and surface
mounting base supplied)
Surface mount
(mounting base supplied)
Wall mount
Wall mount
(mounting bracket supplied)
Aluminium / Flame retardant ABS resin
Flame retardant ABS resin
Flame retardant ABS resin
Flame retardant ABS resin
Lighting method
8
265 g
Ambient temperature: Approx. -15 °C to +55 °C
Relative humidity (non-condensing): up to 90 % (tested up to -20 °C)
Approx. 7-inch wide colour display
Viewing angle
External material
465 g
External material
100–240 V AC, 50/60 Hz
Supplied by the monitor
Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): from 45 % up to 90 %
Talking method
5-inch wide colour display /
WQVGA (480x272 pixels)
Display language
143 x 101 x 35 mm
Display
35
115
Power source
—
135 x 201 x 25.5 mm
Operating environment
76
190
Standby: Approx. 1.3 W During operation: Approx. 10 W
Weight
VL-W605
Wireless Monitor Station (Sub monitor)
Door Station (Doorphone)
AC adaptor (Product No. PNLV245), Output: 24 V DC, 0.5 A
Power consumption
Dimensions (H x W x D)
(Excluding protruding sections)
VL-W605 x 1
VL-V522L
Main Monitor Station (Main monitor)
Power source
External material
*1 Water resistance is only assured if the doorphone is installed correctly according to the instructions in the Operating Instructions, and appropriate water protection measures are taken.
9
One Panasonic Solution
Greater peace of mind with interconnected Panasonic IP products
IP Video Intercom
IP Camera / Network Camera
IP Camera
Monitoring
Operation Specification
- Codec Format: H.264 (Fixed)
- Image Resolution: 720p (1280x720 pixels) or less
- Frame Rate: 20 fps or less
IP Video Intercom System
for Apartment Complexes
Recommended Models*
SIP Phone
SIP Phone
NVR
Communication
Recording
Recommended Model-No.*
- KX-HDV430 (Video and Audio)**
** Requires changing Lobby Station bit rate to 1 Mbps for
optimal video quality
- KX-HDV230 (Audio)
- KX-HDV130 (Audio)
Operation Specification
- Codec Format: H.264 (Fixed)
- Image Resolution: 720p (1280x720 pixels)
- Frame Rate: 3/25/30 fps
* Consult your certified Panasonic dealer for more information.
For the latest compatible IP cameras and SIP Phones, visit http://panasonic.net/pcc/support/intercom/.
VL-VN1900
Main Features
• 3.5-inch colour LCD monitor (320x240 pixels)
- Displays the resident's name
- On-screen user guidance
• Wide angle camera
- Wide view of 120 degrees (horizontal), 72 degrees (vertical)
- Mechanical adjustment (up to +/- 15 degrees vertically)
- 2.0 M pixels provide a clear image
• E-lock unlocking function
- Unlock the public door by using an IC card (Built-in MIFARE® RFID)
- Unlock the public door by using a PIN code for each residence
Other Features
- Strong and elegant exterior with an aluminium panel
- IP55, compliant with IK07
- Phonebook (Room-No., Resident’s names)
- Theft detection buzzer
10
Recommended Models*
- E-series
WVGA (800x480 pixels)
D1 (704x576 pixels)
Lobby Station
Pure IP lobby station with a
colour LCD monitor and
wide-angle camera.
Elegant design and durable
structure with a metallic
panel.
- E-series, i-PRO series
NVR
Door Station
VL-VN1500
Room Monitor
VL-MN1000
Pure IP room monitor with 7-inch wide
LCD and touch screen.
Main Features
• 7-inch wide LCD with capacitive touch screen
- Provides a clear image on the wide screen
- Accurate and smooth operation via a capacitive touch screen
• IP camera monitor
- Monitors various areas using a Panasonic Network Camera
(Supported devices: Panasonic i-PRO series, E-series)
• Standard PoE is supported
- Power can be supplied via Ethernet cable (PoE)
- Power Supply Unit also available (VL-PS240 is sold separately)
Other Features
- Video messages from the Lobby Station: up to most recent 50
- Manual recording (videos): up to most recent 50
- Auto/manual recording (still images): up to most recent 100
- E-lock unlocking (both individual and public doors)
- 5 sensor inputs (emergency/urgency button and other sensors)
and 1 door bell input
Pure IP door station with a
wide-angle camera and RFID
reader. Simple and sleek design.
Main Features
• Wide-angle camera
- Wide view of 113° degrees (horizontal), 69° degrees (vertical)
- 1.3 M pixels provide a clear image
• E-lock unlocking function
- Unlock the individual doors by using an IC card
(Built-in MIFARE RFID)
* Relay box is required when connecting an E-lock to the door
station. (VL-RLY1 is sold separately)
• Standard PoE is supported
- Power can be supplied via Ethernet cable (PoE)
- Power Supply Unit also available (VL-PS240 is sold separately)
Other Features
- Night vision with white coloured LED lights
- Theft detection buzzer
Control Box
VL-VN1700
Up to 2000 devices* are supported.
Panasonic SIP Phone is available in the system.
* Includes setup tool for mass configuration of 2000 devices
Main Features
• Embedded SIP server
- Supports 2000 SIP devices
(Lobby Station, Door Station, Room Monitor and Panasonic SIP Phone)
• Voice mail
- Voice mails can be issued by the SIP Phone to each room or
grouped rooms
Other Features
- E-mail notification*
Even if the guard is out, voice mails from residents to the guard
station (SIP Phone) can be forwarded via e-mail, enabling quick
access to important voice mail
* External mail server and an internet connection are required.
11
System Diagram of the Apartment System
Support up to 200 devices on a system without a Control Box
Support up to 2,000 devices on a system with a Control Box
FUNCTION
FUNCTION
- 200 SIP devices are supported
- Multiple sessions are supported
- Send text mail from control room to all monitors
- Easy setup by PC tool
- 2,000 SIP devices are supported
- Multiple sessions are supported
- E-mail notification
Residence
- Send voice mail from control room to all monitors
- Easy setup by PC tool
Residence
IP Camera
Door
Station
Room
Monitors
Door
Station
E-Lock
Room
Monitors
Door
Station
E-Lock
PoE Switch
Room
Monitors
Site
Door
Station
Room
Monitors
IP Camera
E-Lock
E-Lock
Door
Station
Room
Monitors
Door
Station
Room
Monitors
1
Room
Monitors
Door
Station
E-Lock
Room
Monitors
Door
Station
E-Lock
PoE Switch
Room
Monitors
UTP CAT5e
Residence
Door
Station
Room
Monitors
Door
Station
IP Camera
Room
Monitors
E-Lock
Door
Station
E-Lock
E-Lock
Room
Monitors
Door
Station
E-Lock
Room
Monitors
Door
Station
Door
Station
Room
Monitors
Door
Station
IP Camera
Room
Monitors
E-Lock
Door
Station
Room
Monitors
Door
Station
E-Lock
E-Lock
Entrance
IP Camera
Lobby
Station
E-Lock
Parking
IP Camera
Lobby
Station
Power
Supply Unit
E-Lock
Common Area
Common
Area
IP Camera
Power
Supply Unit
E-Lock
Entrance
E-Lock
Power
Supply Unit
IP Camera
Parking
Lobby
Station
Power
Supply Unit
E-Lock
IP Camera
Common Area
Power
Supply Unit
E-Lock
Entrance
Power
Supply Unit
E-Lock
IP Camera
Parking
Lobby
Station
Power
Supply Unit
Power
Supply U
E-Lock
Switch
UTP CAT5e
Guard Station
Guard Station
SIP Phone
IP Camera
Lobby
Station
UTP CAT5e
UTP CAT5e
E-Lock
Common
Area
Lobby
Station
Switch
Switch
Room
Monitors
UTP CAT5e
Lobby
Station
Lobby
Station
Door
Station
PoE Switch
UTP CAT5e
IP Camera
Room
Monitors
IP Camera
PoE Switch
Common
Area
E-Lock
Residence
E-Lock
UTP CAT5e
Room
Monitors
UTP CAT5e
E-Lock
E-Lock
PoE Switch
Room
Monitors
Door
Station
PoE Switch
UTP CAT5e
Door
Station
Room
Monitors
IP Camera
Residence
IP Camera
Door
Station
Room
Monitors
PoE Switch
UTP CAT5e
Residence
Room
Monitors
PoE Switch
E-Lock
E-Lock
Door
Station
E-Lock
E-Lock
Residence
Door
Station
Room
Monitors
IP Camera
UTP CAT5e
Residence
IP Camera
Door
Station
E-Lock
E-Lock
PoE Switch
UTP CAT5e
Residence
SIP Phone
PC
PC
Control Box
Switch
Switch
UTP CAT5e
12
* E-lock for Door Station requires Relay Box (Sold separately. Model-No. VL-RLY1)
UTP CAT5e
13
Analogue
Video Intercom System
for Apartment Complexes
Distribution Box
Lift Controller
Extension Box
VL-V701
VL-V702
VL-V703
Functions as a distribution box or
repeater.
The function can be switched with a
DIP switch.
Controlling the destination of lifts
Controlling the destination (floor)
of visitors by linking with the lift
and lift control box.
Supported control methods
Role as a distribution box
- 1:1 control (Relay signalling)
- Binary control
A distribution box for connecting the control
box with the main monitor of each room.
A repeater box for amplifying the signal
when the control box and main monitor are
far away from each other.
Only one can be connected between the
control box and distribution box #7.
VL-V900
VL-MW251
Connectable devices
-Security camera
-Electric lock
-Access control
VL-MV26
Power Supply
Unit
Control Box
VL-V700
Features
-Easy setup (Room number registration)
-Easy connection check
(Check connections between the control box and main
monitor of each room)
-Real time monitoring
-Log (SD card recording)
Text log: More than 90,000 items (date, caller, receiver,
operation, status)
Image log: Up to 90,000 images (overwrite save) (visitors call)
Connectable devices
-PBX
-PC (for program settings)
-Monitor (for real time monitoring)
Power source
Power consumption
Dimensions (H x W x D)
(Excluding protruding sections)
Weight
Operating environment
Display
Display language
Frequency range
Installation method
External material
Supported functions
Door station
Door bell
Electric lock release support
Picture recording
Voice changer
Pan, Tilt, Zoom
Wireless monitor
Extension monitor
Repeater
Smartphone connect
E-mail notification
Intercom call
Other functions
14
VL-MVN511
Power Supply
Unit
Device for controlling the entire system
-Guidance (simple usage for visitors)
-Wide angle camera : Horizontally: approx. 170˚
Vertically: approx. 115˚
-Heat sensor: The backlight of the display and buttons are turned on
when a visitor is detected.
-4.3-inch LCD / white backlit LCD
-Blue LED backlit buttons
-White coloured LED lights for night colour vision
-Unlock with PIN-code
-Room number and name registration
-Room owner name display
Up to 18 lobby stations connectable
- Up to 3 extension boxes per control box
- Up to 6 lobby stations per extension box
Main Monitor Line Up
Lobby Station
Features
Features
*The supported control method depends on the
specifications of the lift and lift control box.
Contact the lift manufacturer for details.
Role as a repeater box
Doorphone for the public
entrance of housing
complexes. Destination
display, calling,
conversation, electric lock
Device for extending the lobby
stations.
100-240 V AC (50/60 Hz)
Power supply unit (VL-PS240)
24 V DC, 0.5 A
Power supply unit (VL-PS240)
24 V DC, 0.5 A
Standby: Approx. 1.8 W
During operation: Approx. 12 W
Standby: Approx. 1.8 W
During operation: Approx. 10 W
Standby: Approx. 1.2 W
During operation: Approx. 8 W
190 x 165 x 38 mm
186 x 161 x 23.5 mm
169 x 129 x 29 mm
485 g
330 g
Ambient temperature: Approx. 0 °C to +40 °C, Relative humidity (non-condensing): up to 90 %
5-inch wide colour / WQVGA (480x272 pixels)
3.5-inch colour / QVGA (320x240 pixels)
5-inch wide colour / WQVGA (480x272 pixels)
English, Arabic
English
English
IEEE 802.11 b/g/n 2.4 GHz
2.402 GHz to 2.481 GHz
785 g*1
Wall mount
(mounting bracket supplied)
Flame retardant ABS resin
Flame retardant ABS and PS resin
Flame retardant ABS resin
1 door station input (VL-V522L, VL-V566)
-
1 door station input (VL-V522L, VL-V566, VL-V555, VL-V554/V554U)
1 door bell input
1 door bell input
Up to 2
(for individual x 1, for public x 1)
Up to 2
(for individual x 1*2, for public x 1)
Up to 1
(for public x 1)
Up to 400 images
(up to 50 visitors (1 or 1-8 still images per visitor))
Up to 400 images
(up to 50 visitors (up to 8 still images per visitor))
Yes
Pan, Tilt, Zoom (for VL-V900)
Up to 4 (VL-W605)
Up to 2 (VL-FAN2)
-
Yes
Pan, Tilt, Zoom (for VL-V900, VL-V555, VL-V554/V554U)
Up to 4
Up to 4*3
Up to 30 images
(up to 30 visitors, 1 shot per visitor)
-
Yes
(between main monitor and sub monitor)
• Guard call
• Monitor security camera
• Guard call
• Monitor security camera
• Emergency call
*1 Including AC cable. The weight of the AC cable differs depending on the region.
*2 VL-RLY1 is required.
*3 The main monitor must be connected to a wireless router that is connected to the Internet in order to use email feature.
• Guard call
• Monitor security camera
• Emergency call
15
System Diagram of the Apartment Syste m
Total System
Control Box
Distribution Box
Room Unit
560
room units
total
1 unit
28 units
560 units
Up to
VL-V701 Dip switch
Up to
3
Entrance
Lobby Station
lobby
stations
*2 Stan dard Mode
(STD /END)
*3 Repeater Mode
(RPT/END)
REPEATER TERMINATION
ON
ON
REPEATER TERMINATION
ON
ON
REPEATER TERMINATION
ON
ON
VIDEO 2 Wire, NP
4
Power
Supply Unit
Distribution Box
Distribution Box
AUDIO 2 Wire, NP
2 Wire, NP
VL-V701
VL-V701
#7
(Up to 7)
Power
Supply Unit
Branches
Common Area
Control Box
VL-V700
(NTSC/PAL)
VIDEO 2 Wire, NP
7
AUDIO 2 Wire, NP
#1
VL-V701
Power
Supply Unit
Distribution Box
#7
(Up to 7)
VL-V701
Power
Supply Unit
#7
(Up to 7)
E-Lock
Power
Supply Unit
Access
control
Lobby Station
Coax
VL-V900
#1
2 Wire, NP
Security
Camera
E-Lock1
SD Card*
(sold separately)
* 4 GB or more capacities
are required.
AUDIO 2 Wire, NP
Power
Supply Unit
Power
Supply Unit
Access
control
Repeater Mode*3
(RPT/END)
18
Control Box - Lobby Station
Control Box - Distribution Box (Standard Mode *2)
Distribution Box (Standard Mode *1*2) - Main Monitor
Control Box - Distribution Box (Repeater Mode *3)
Distribution Box (Repeater Mode*3) - Distribution Box (Standard Mode*2)
Control Box - the farthest Lift Controller
Distribution
Box
(RPT*3)
Control
Box
Up to
4
VL-V700
lifts
Lift Controller
USB
PBX
System
Control Box
3
#1
Coax
(NTSC)
#1
#7 (Up to 7)
Distribution
Box
(STD *2)
16
Guard Station
#2
#7 (Up to 7)
Distribution
Box
(STD *1)
Distribution
Box
(STD *2)
#7 (Up to 7)
#1
Distribution
Box
(STD *1)
Control
Box
Distribution
Box
(RPT*3)
4
Lift
#1
#7 (Up to 7)
Distribution
Box
(STD *1)
Distribution
Box
(STD *2)
4
(Up to 100 floors)
Distribution
Box
(STD *2)
5
Distribution
Box
(RPT*3)
Control
Box
Power
Supply Unit
Security Control Room
3
#1
#5
(Up to 5)
Monitor
Main
Monitor
Distribution
Box
(STD *1)
5
Extension Box
VL-V703
• Up to 3 Extension Boxes can be connected to one Control Box.
Up to 6 Lobby Stations can be connected to each Extension Box.
• Extension Boxes do not operate as repeaters that allow longer distances
between the Control Box and Lobby Stations.
• Lobby Stations (VL-V900) connected to Extension Boxes (VL-V703) cannot
be called from the room units or terminals.
200 m
200 m
200 m
200 m
200 m
200 m
2
VL-V702
PC
(Setting)
(17 AWG)
100 m
100 m
100 m
100 m
100 m
100 m
5
Up to
PBX Line
(22 AWG)
Distribution
Box
(STD *1)
4
Control
Box
2 Wire, NP
Terminals
Extension Box
VL-V703
1
2
3
4
5
6
1
lobby
stations
4 or more Lobby Stations can be
installed by adding Extension Boxes.
Wire diameter
0.65 mm
1.2 mm
Wiring run
Standard Mode*1
(STD/NOR)
Power
Supply Unit
Wireless Monitor
(for VL-MW251)
* Use PE (polyethylene)-insulated cables.
No
Lobby
Station
You can extend the distance
by using the repeater mode.
Up to
System Diagram with Extension Box
VL-V701
VL-V701
Free application for
smartphone support
(for VL-MVN511)
VIDEO 2 Wire, NP
Power
Supply Unit
Extension Box
VL-V703
Distribution Box
Distribution Box
(NTSC/PAL)
Main Monitor
Wiring Distance
Standard Mode*2
(STD/END)
Power
Supply Unit
Parking
Door Station
distribution boxes
per branch
Distribution Box
2 Wire, NP
E-Lock1
Expandable options
Up to
VL-V900
Security
Camera
Room
Standard Mode*1
(STD/NOR)
Power
Supply Unit
Lobby Station
Coax
2 Wire, NP
#1
#1
E-Lock1
Access
control
20
room units per
distribution box
2 Wire, NP
(NTSC/PAL)
Security
Camera
*1 Standard Mode
(STD/NOR)
VIDEO 2 Wire, NP
AUDIO 2 Wire, NP
VL-V900
Coax
Lobby Station
VL-V900
Up to
Control
Box
#1
#5 (Up to 5)
Lift
Controller
Lift
Controller
6
17
VL-VN1900 series (IP Video Intercom System for Apartment Complexes)
VL-V900 series (Analogue Video Intercom System for Apartment Complexes)
VL-VN1900
Model number and name
Lobby Station
Dimensions
(Unit: mm)
179
Dimensions
(Unit: mm)
6
100
Power source
Dimensions (H x W x D)
(Excluding protruding sections)
Operating environment
Display
Display language
Input: 220-240 V AC, 0.2 A (50/60 Hz)
—
Standby: 3.5 W, During operation: 8.5 W
1.5 kg
230 g
3.5-inch colour display (320x240 pixels)
—
English, Arabic, French, Italian, German, Spanish and Dutch
Only user guidance supports multiple language
Resident’s names are only in English
—
10BASE-T/100BASE-TX (Auto MDI/MDI-X)
Network protocol
TCP/IP, UDP
—
UTP (cat.5e or higher)
—
Card reader (RFID)
13.56 MHz (ISO/IEC 14443 Type A (MIFARE))
—
Expanded interface
Support for electric lock releasing (entrance unlocking) x 1
—
Horizontally: Approx. 120°, Vertically: Approx. 72°
(15° angle adjusting, vertical only)
—
2.0 M pixels CMOS sensor
—
Wiring
Viewing angle
Image sensor
Minimum illuminance required
Dimensions (H x W x D)
(Excluding protruding sections)
1 lx (within approx. 50 cm from the camera lens)
Lighting method
White coloured LED lights
—
—
IP55 / Compliant with IK07
—
Flush mount (flush mounting box supplied)
Wall mount or attach to DIN rail
Aluminium
Flame retardant PC+ABS resin
External material
Model number and name
Dimensions
(Unit: mm)
• Room numbers using numbers 0 through 9 and letters A through F
• Phonebook (Room-No., Resident’s name)
• Theft detection buzzer
• Unlock lobby door via a PIN code or RFID card (MIFARE)
• Reception mode
• Display a BMP file set by the user (320x180 pixels)
—
Dimensions
(Unit: mm)
VL-VN1500
VL-MN1000
VL-VN1700
Room Monitor
Control Box
28.5
205
430
27.8
Power consumption
Dimensions (H x W x D)
(Excluding protruding sections)
Weight
Operating environment
Display
Display language
Talking method
PoE (IEEE 802.3af compliant, Class 2 device)
or Power supply unit (VL-PS240*2) 24 V DC, 0.6 A
100-240 V AC, 0.95-0.6 A, 50/60 Hz
PoE: Standby: 2.5 W / During operation: 5.1 W
VL-PS240: Standby: 2.6 W / During operation: 6.3 W
PoE: Standby: 1.9 W / During operation: 6.3 W
VL-PS240: Standby: 2.1 W / During operation: 6.2 W
Under 50 W
141 x 100 x 28.5 mm
137.5 x 205 x 27.8 mm
88 x 430 x 340 mm
250 g
550 g
4.5 kg
Ambient temperature: Approx. -10 °C to +55 °C
Relative humidity (non-condensing): up to 90 %
Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): up to 90 %
Ambient temperature: Approx. 0 °C to +40 °C
Relative humidity (non-condensing): up to 90 %
7-inch wide colour display with touch screen (800x480 pixels)
—
—
—
English, Arabic, French, Italian, German, Spanish and Dutch
—
Hands-free
Hands-free
—
10BASE-T/100BASE-TX (Auto MDI/MDI-X)
10BASE-T/100BASE-TX (Auto MDI/MDI-X)
10BASE-T/100BASE-TX/1000BASE-T (Auto MDI/MDI-X)
TCP/IP, UDP
TCP/IP, UDP
UTP (cat.5e or higher)
UTP (cat.5e or higher)
TCP/IP, UDP
UTP (cat.5e or higher)
Card reader (RFID)
13.56 MHz (ISO/IEC 14443 Type A (MIFARE))
—
Expanded interface
E-lock x 1 *Relay box VL-RLY1 is required (sold separately)
Horizontally: Approx. 113°, Vertically: Approx. 69°
Sensor input x 5 (including emergency / urgency button)
—
—
1.3 M pixels CMOS sensor
—
—
1 lx (within approx. 50 cm from the camera lens)
—
—
Lighting method
White coloured LED lights
—
—
Video / Audio format
Video: H.264, Audio: G.711
Video: H.264, Audio: G.711
—
Internal memory (video with audio can be saved)
—
Image sensor
Minimum illuminance required
Recording
IP rating / IK rating
Installation method
External material
Supported functions
18
PoE (IEEE 802.3af compliant, Class 2 device)
or Power supply unit (VL-PS240*2) 24 V DC, 0.6 A
Network interface
Viewing angle
—
IP54*1 / —
Surface mount (mounting base supplied)
PC+ABS resin
• Unlock individual doors via the RFID card (MIFARE)
• Theft detection buzzer
Flame retardant PC+ABS resin
—
—
—
—
—
Surface mount (mounting bracket supplied) or
Flush mount (mounting box VL-VN1790 sold separately)
Mountable to 19-inch racks
PC+ABS resin
Front Cabinet: ABS, Lower / Upper Cabinet: Steel
• Monitoring through the IP camera
• Emergency / Urgency call, Sensor, Door bell
• Intercom calls between monitors (family or neighbours)
• Calls to SIP Phones (guard station, reception, etc.)
• Register up to 32 IP cameras per monitor
• Register up to 18 SIP Phones per monitor
• Voice mail
• E-mail notification
• Supports up to 2000 SIP devices (embedded SIP server)
*1 Water resistance is only assured if lobby station/the doorphone installed correctly according to the instructions in the Operating Instructions, and appropriate water protection measures are taken.
*2 VL-PS240 is sold separately.
210
VL-V702 *2
VL-V700
VL-V701
Control Box
Distribution Box (Distribution mode / Repeater mode)
210
52.5
210
52.5
108.5
Power
Supply
Unit
VL-V703
Lift Controller
Extension Box
210
52.5
108.5
Power
Supply
Unit
52.5
108.5
Power
Supply
Unit
Power
Supply
Unit
Power supply unit (VL-PS240) 24 V DC, 0.2 A
Power consumption
Standby: Approx. 3.5 W
During operation: Approx. 3.7 W
137.5
Network protocol
Wiring
Stainless steel (partially ABS and PC)
• Guidance (simple usage for visitors)
• Night colour vision (white coloured LED lights)
• Heat sensor: The backlight of the display and buttons are turned on when a visitor is detected
• Display the resident’s names
• Unlock with PIN-code
—
Power source
340
Power source
—
—
108.5
88
141
1 lx (within approx. 50 cm from the camera lens)
Wall mount or attach to DIN rail
Model number and name
Door Station
100
—
(1/4 inch) CMOS sensor (approx. 1 M pixels)
—
External material
IP rating / IK rating
—
Horizontally: Approx. 170° Vertically: Approx. 115°
White coloured LED lights
Installation method
Installation method
—
—
IP55*1 / Compliant with IK07
Flush mount (flush mounting box supplied)
IP rating / IK rating
—
—
Support for electric lock releasing (entrance unlocking) x 1
VIDEO-IN (recommended Panasonic security camera) x 1
Lighting method
—
Supported functions
230 g
Ambient temperature: Approx. 0 °C to +50 °C
Relative humidity (non-condensing): up to 90 %
(indoor use only)
Hands-free
Image sensor
Minimum illuminance required
Video: H.264, Audio: G.711
116 x 100 x 54 mm
Ambient temperature: Approx. -10 °C to +55 °C
Relative humidity (non-condensing): up to 90 %
Talking method
Viewing angle
Output: 24 V DC, 0.6 A
2.0 kg
4.3-inch monochrome display (white backlit LCD)
English
Display languages
Embedded SIP server (up to 200 devices)
*1
Operating environment
Supported functions
Input: 220-240 V AC, 0.2 A (50/60 Hz)
—
During operation: Approx. 4.5 W
373 x 179 x 2.5 mm (excluding sections embedded into the wall)
Display
Video / Audio format
SIP server
Standby: Approx. 1.9 W
Weight
Expanded interface
Super wide view.
Power supply unit (VL-PS240) 24 V DC, 0.2 A
Power consumption
Ambient temperature: Approx. 0 °C to +50 °C
Relative humidity (non-condensing): up to 90 % (indoor use only)
Network interface
54
116
Power
Supply
Unit
Ambient temperature: Approx. -10 °C to +55 °C
Relative humidity (non-condensing): up to 90 %
—
—
100
Standard
90˚
373
Power source
116 x 100 x 54 mm
Hands-free
2.5
Output: 24 V DC, 0.6 A
373 x 179 x 6 mm (excluding sections embedded into the wall)
Talking method
VL-PS240
Power Supply Unit
Horizon
170˚
116
Power supply unit (VL-PS240) 24 V DC, 0.6 A
Weight
179
VL-V900
Lobby Station
54
373
Power consumption
Model number and name
Power Supply Unit (VL-PS240)
Standby: Approx. 0.4 W
During operation: Approx. 4.4 W
Standby: Approx. 1.2 W
During operation: Approx. 2.0 W
Dimensions (H x W x D)
(Excluding protruding sections)
108.5 x 210 x 52.5 mm
400 g
Weight
Operating environment
Ambient temperature: -10 °C to +50 °C
Relative humidity (non-condensing): up to 90 %
(indoor use only)
Installation method
Wall mount or attach to DIN rail
External material
ABS (flame retardant ABS resin)
Log
Supported functions
Standby: Approx. 1.5 W
During operation: Approx. 1.5 W
Save the text logs and visitors’ images in
the SD card (sold separately)
Text logs: More than 90,000 items
Images: Up to 90,000 images
USB connection (provide PC application/English)
• date and time setting (HH:MM DD/MM/YYYY)
• set the room number to the monitor
• estimate the status of the equipment in the system
• operation setting (terminal, pass code, and so on.)
SD card (SDHC/SDXC): Log function
VIDEO OUTPUT (NTSC up to 1)
RJ-11: Connect with PBX system
—
Dip switch
• Mode change
(Distribution mode/Repeater mode)
• Termination setting (Normal/Terminal)
• ID setting (1-7 by binary number)
—
Supported control methods
• 1:1 control (Relay signalling)
• Binary control
—
Extend Lobby Stations
*1 Water resistance is only assured if the lobby station is installed correctly according to the instructions in the Installation Guide, and appropriate water protection measures are taken.
*2 The supported control method depends on the specifications of the lift and lift control box. Contact the lift manufacturer for details.
19
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
