79 GHz UWB automotive short range radar – Spectrum allocation
and technology trends
H.-L. Bloecher1 , A. Sailer2 , G. Rollmann3 , and J. Dickmann1
1 Daimler
AG, Group Research and Advanced Engineering, 89081 Ulm, Germany
of Ulm, Institute of Microwave Techniques, 89081 Ulm, Germany
3 GR-Consulting/SARA, 71732 Tamm, Germany
2 University
Abstract. Automotive UWB (Ultra-Wideband) short range
radar (SSR) is on the market as a key technology for novel
comfort and safety systems. SiGe based 79 GHz UWB SRR
will be a definite candidate for the long term substitution of
the 24 GHz UWB SRR. This paper will give an overview of
the finished BMBF joint project KOKON and the recently
started successing project RoCC, which concentrate on the
development of this technology and sensor demonstrators.
In both projects, the responsibilities of Daimler AG deal
with application based sensor specification, test and evaluation of realized sensor demonstrators. Recent UWB SRR
frequency regulation approaches and activitites will be introduced. Furthermore, some first results of Daimler activities
within RoCC will be presented, dealing with the packaging
and operation of these sensors within the complex car environment.
