Sony D-FJ787 User's manual
3-246-673-41 (1) D Notes on the rechargeable batteries E • To keep the original battery capacity for a long time, charge the batteries only when they are completely depleted. • If the battery is new or has not been used for a long time, it may not be charged completely until you charge and discharge it several times. • When carrying the rechargeable batteries, use the supplied battery carrying case to prevent unexpected heat. If the rechargeable batteries and the metallic objects get contacted, heat or fire may occur due to a short circuit. Label side up TV/WB/FM/AM Portable CD Player Operating Instructions Notes on using the dry batteries WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. Do not install the appliance in a confined space, such as a bookcase or built-in cabinet. D-FJ787 ©2003 Sony Corporation Printed on 100 % recycled paper using VOC (Volatile Organic Compound)-free vegetable oil based ink. Printed in Malaysia To prevent fire, do not cover the ventilation of the apparatus with newspapers, tablecloths, curtains, etc. And don’t place lighted candles on the apparatus. To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus. CAUTION “WALKMAN” is a registered trademark of Sony Corporation to represent Headphone Stereo CD player (front) Strap holes 1 2 Jog lever (u (play/ pause)•./> (AMS/ search)) A OPEN 4 VOL +*/– i (headphones) jack DC IN 4.5 V (external power input) jack 5 HOLD *There is a tactile dot beside the button. LINE OUT jack CD player (inside) Insert the # end first (for both batteries). 6 AVLS 7 G-PROTECTION Remote control 1 2 Jog lever (u (play/pause)•ENT (enter) • ./> (AMS/search)) Display on the remote control Remaining battery power “PRESET” indication Display 4 VOL +*/– Play mode 3x Playing time, radio information 90 TUNE –/BAND/TUNE + 5 HOLD Clip 8 RADIO ON/OFF qs SOUND qa DISPLAY qd P MODE/ *There is a tactile dot beside the button. Track number, preset number of radio station and radio band Sound mode Note Use only the supplied remote control. You cannot operate this CD player with the remote control supplied with other CD players. C to an AC outlet DC IN 4.5V AC power adaptor i Headphones or earphones Proper registration will enable us to send you periodic mailings about new products, services, and other important announcements. Registering your product will also allow us to contact you in the unlikely event that the product needs adjustment or modification. Thank you. Power Sources CAUTION Rechargeable batteries • INVISIBLE LASER RADIATION WHEN OPEN • DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENT Charge the rechargeable batteries before using them for the first time. • NH-7WMAA (supplied) • NH-WM2AA (NH-WMAA × 2) (not supplied) 1 Connect the AC power adaptor to an AC outlet. Use only the following batteries for your CD player: Dry batteries • LR6 (size AA) alkaline batteries Nickel Metal Hydride batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you. For more information regarding recycling of rechargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/. Caution: Do not handle damaged or leaking Nickel Metal Hydride batteries. To insert the batteries 1 Open the battery compartment lid inside your CD 3 When using the rechargeable batteries, connect the AC power adaptor to the DC IN 4.5 V jack of your CD player and an AC outlet, then press CHARGE/x to start charging. The CD player charges the batteries. In the display on the remote control, “Charging” flashes and the indicator sections of light up in succession. The CHARGE lamp on the CD player turns on. When the batteries are completely charged, the CHARGE lamp and indicator get turned off. If you press CHARGE/x after the charge has already been completed, the indicator flashes and “FULL” appears in the display. 4 Disconnect the AC power adaptor. For the customers in the USA Battery life* (approx. hours) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. (When the CD player is used on a flat and stable place.) Playing time varies depending on how the CD player is used. If you have any questions about this product, you may call: Sony Direct Response Center 1-(800)-222-7669 or write to: Sony Direct Response Center 12451 Gateway Blvd. Fort Myers, FL 33913 Declaration of Conformity Trade Name: SONY Model No.: D-FJ787 Responsible Party: Sony Electronics Inc. Address: 680 Kinderkamack Road, Oradell, NJ 07649 USA Telephone No.: 201-930-6972 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To insert a CD 1 Slide OPEN to open the lid (A). 2 Fit the CD to the pivot, then close the lid (D). G-PROTECTION on off RADIO ON Two NH-7WMAA (charged for about 2 hours**) 15 8 NH-WM2AA (charged for about 4 hours**) 32 Two Sony alkaline batteries LR6 (SG) (produced in Japan) 50 10 16 35 20 * Measured value by the standard of JEITA (Japan Electronics and Information Technology Industries Association). ** Charging time varies depending on how the rechargeable battery is used. To check the remaining power of the batteries (only when playing a CD) You can check it in the display. Replace the batteries when “ t t t Notes • The indicator sections of roughly shows the remaining battery power. One section does not always indicate one-fourth of the battery power. • Depending on operating conditions, the indicator sections of may increase or decrease. • When listening to the radio, the remaining power of the batteries is not displayed. When to replace the rechargeable batteries If the battery life becomes shorter by about half, replace the batteries with new rechargeable batteries. rechargeable batteries or dry batteries) from the CD player. To turn on the beep sound Remove the power source and then connect the power source without pressing CHARGE/x or x. Playing your favorite tracks by adding Bookmarks You can add Bookmarks to up to 99 tracks for each CD. You can use this function for up to 10 CDs. To add Bookmarks 1 During playback of the track where you want to add a Bookmark, press and hold the jog lever until “ (Bookmark)” flashes in the display. When the Bookmark has been added successfully, flashing of “ ” becomes slow. 2 Repeat step 1 to add Bookmarks to the tracks you want. To listen to the tracks with Bookmarks 1 Jog lever u (play/pause) Press to start play. Press again to pause play. To play from the first track, press for 2 seconds or more while the CD player is stopped. 1 Press P MODE/ repeatedly until “ ” flashes. 2 Press the jog lever. Flick toward . or > once to find the beginning of the current/ next track. Flick toward . or > repeatedly to find the beginning of the previous/ succeeding tracks. Hold toward . or > to go backward/ forward quickly. To remove the Bookmarks 2 Jog lever ./> (AMS*1/search) 3 CHARGE/x (x) Press to stop playing. (stop) 4 VOL+/– Press to adjust the volume. 5 HOLD Use to lock the controls on your CD player or remote control to prevent accidental button presses. HOLD on the CD player works only for the player, while HOLD on the remote control works only for the remote control. The CHARGE lamp flashes if you press any button when the HOLD function is activated. 6 AVLS*2 Set to “LIMIT” when you want to keep down the maximum volume to protect your hearing. “ ” lights up in the display and the playback of the tracks with Bookmarks starts. During playback of the track with a Bookmark, press and hold the jog lever until “ ” disappears from the display. To check the tracks with Bookmarks During playback of the tracks with Bookmarks, “ keeps flashing slowly in the display. ” Notes • During playback of the tracks with Bookmarks, tracks are played in order of track number, and not in the order you added the Bookmarks. • If you try to add Bookmarks to the tracks on the 11th CD, the Bookmarks of the CD you played back first will be erased. • If you remove all power sources, all Bookmarks stored in memory will be erased. • If you continue playing the CD player on the rechargeable batteries without charging the batteries even though “Lobatt” is displayed, all Bookmarks stored in memory will be erased. Playing tracks in your favorite order (PGM play) 8 RADIO ON/OFF Press to turn on/off the radio. You can program the CD player to play up to 64 tracks in your favorite order. 9 Jog lever BAND Press to change the band. 1 During playback, press P MODE/ 0 Jog lever TUNE –/+ 2 Flick the jog lever toward . or > to select a qa DISPLAY qs SOUND t * Beep sounds. 1 Remove the power source (AC power adaptor, Function/Operation ” flashes. t Lobatt* You can turn off the beep sound that is heard from your headphones/earphones when you operate your CD player. When listening to the radio, you cannot turn off the beep sound for the radio. Button/Switch 7 G-PROTECTION Protect against sound skipping.*3 24 To turn off the operation beep sound (Bookmarked track play) • This CD player can play CD-Rs/CD-RWs recorded in the Compact Disc Digital Audio (Audio CD) format, but playback capability may vary depending on the quality of the disc and the condition of the recording device. • This product is designed to playback discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product. player. The model number and the serial number are located at the rear of the CD player. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. D-FJ787 Serial No. ____________________________ This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Playing a CD 2 Insert the # end of two batteries, then matching the 3 to the diagram in the battery compartment insert the other end. Then, close the lid until it clicks into place. Remove the CD while pressing the pivot (E). CHARGE/x on the CD player or x on the remote control. To operate the CD player RECYCLING NICKEL METAL HYDRIDE BATTERIES To remove the CD 2 Connect the power source while pressing CD Player Notes To use the batteries (B) Owner’s Record Open the battery compartment lid. Please register this product on line at www.sony.com/ productregistration. <http://www.sony.com/productregistration> Certain countries may regulate disposal of the battery used to power this product. Please consult with your local authority. The validity of the CE marking is restricted to only those countries where it is legally enforced, mainly in the countries EEA (European Economic Area). B For the customers in the USA To use the AC power adaptor (C) For the customers in the USA 3 CHARGE/x (stop)• CHARGE lamp Product registration The use of optical instruments with this product will increase eye hazard. is a trademark of Sony Corporation. products. • Be sure to remove the AC power adaptor. • When the batteries are depleted, replace both batteries with new ones. *4 If the sound is distorted when using the SOUND function, turn down the volume. The SOUND function does not work when listening to the radio. qd P MODE/ (play mode/repeat) When listening to the radio, press to tune in to the station you want. Also press to select the preset station you want. Press to display the remaining time/ tracks. For radio: Press and hold to set the radio to the automatic presetting mode, etc. Use to emphasize bass-boosted sound. Press repeatedly to select SOUND 1 or SOUND 2. SOUND 2 enhances bass more than SOUND 1.*4 For radio: Press to switch between “Stereo” and “Mono”. Press repeatedly until the play mode you want appears in the display. No indication: Normal play “1”: Single play “SHUF”: Shuffle play “ ”: Bookmarked track play “PGM”: PGM (program) play To repeat the play mode you selected, press and hold until “ ” appears. For radio: Press to switch between the tuning mode and the preset mode. *1 AMS = Automatic Music Sensor *2 AVLS = Automatic Volume Limiter System The AVLS function does not work when listening to the radio. *3 Sound may skip: – if the CD player receives stronger continuous shock than expected, – if a dirty or scratched CD is played or – when using poor-quality CD-Rs/CD-RWs or if there is a problem with the recording device or application software. repeatedly until “PGM” appears. track. 3 Press the jog lever to enter the selected track. “000” appears and the playing order increases by one. 4 Repeat steps 2 and 3 to select the tracks in your favorite order. 5 Press and hold the jog lever until the PGM play starts. To check the program During programming: Press the jog lever repeatedly before step 5. During the PGM play: Press P MODE/ repeatedly until “PGM” flashes, then press the jog lever repeatedly. Each time you press the jog lever, the track number appears. Notes • When you finish entering the 64th track in step 3, the first selected track appears in the display. • If you select more than 64 tracks, the first selected tracks are erased. F Presetting radio stations You can preset up to 51 stations: 30 for FM, 10 for AM, 7 for TV, and 4 for WB. Presetting stations manually LINE OUT 1 Press RADIO ON/OFF to turn on the radio. 2 Press the jog lever to select a radio band. 3 Flick the jog lever toward TUNE + or TUNE – to tune When using the connecting cord If the sound is distorted, connect the device to the i jack. About the G-PROTECTION and SOUND functions when using the connecting cord • To record high quality CD sound, set the G-PROTECTION switch to “OFF.” • The SOUND function works only on the output sound from the i jack and not work on the output sound from the LINE OUT jack. in to the station you want. 4 Hold down the jog lever for 2 seconds or more until “PRESET” appears in the display. The preset number and “M” flash in the display. Connecting cord From this step on, start the next operation within 15 seconds after you finished the previous operation. If 15 seconds pass with nothing done, “PRESET” and the preset number disappear which shows that the CD player has exited the presetting mode. If this happens, start again from step 4. 5 Flick toward TUNE + or TUNE – repeatedly to select Left (white) the preset number you want to use to store the station. Right (red) 6 Press the jog lever. When the station is preset successfully, a beep sounds and “PRESET” and the preset number disappear from the display. If there is a station already stored using that number, the new station replaces the old one. Stereo system, cassette recorder, radio cassette recorder, etc. On safety • Should any solid objects or liquid fall into the CD player, unplug it and have it checked by qualified personnel before operating it any further. • Do not put any foreign objects in the DC IN 4.5 V (external power input) jack. Should any problem persist after you have made these checks, consult your nearest Sony dealer. CHARGE lamp flashes on the CD player when you press a button, and the CD does not play. c The buttons are locked. Slide HOLD back. The CD player does not start charging. c During stop, press CHARGE/x. c You press x on the remote control. Press CHARGE/x on the CD player. c The radio is turned on. You cannot preset stations automatically. c Preset stations manually. The volume does not increase even if you press VOL + repeatedly. On power sources c Set AVLS to “NORM.” • When you are not using the CD player for a long time, disconnect all power sources from the CD player. The battery compartment lid is dettached by an accidental drop, excessive force, etc. On AC power adaptor • Use only the AC power adaptor supplied. If your CD player is not supplied with the one, use the AC-E45HG AC power adaptor. Do not use any other AC power adaptor. It may cause a malfunction. c Attach it as illustrated below. Presetting stations automatically 1 Press RADIO ON/OFF to turn on the radio. 2 Press the jog lever to select a radio band. 3 Hold down DISPLAY until “A Preset” appears in the display. 4 Press the jog lever. Using the radio Using the remote control, you can enjoy TV, WB (Weather band), FM and AM programs by presetting the stations or by tuning in to the stations manually. You can preset automatically scanned stations or select your favorite stations manually. The CD player starts scanning the stations from the lower frequencies and stops when a station is received. While scanning, “A” flashes in the display. When all the receivable stations are preset, a beep sounds and “A” stops flashing, To stop scanning Listening to the radio Press RADIO ON/OFF or press x on the remote control. The radio is turned off at that time. 1 Press RADIO ON/OFF to turn on the radio. If “PRESET” is displayed, press P MODE/ make it disappear from the display. Precautions Troubleshooting to 2 Press the jog lever of the remote control until the radio band you want appears. Each time you press the button, the display on the remote control changes as follows: t FM t AM t TV t WB Playing preset radio stations 1 Press RADIO ON/OFF to turn on the radio. 2 Press the jog lever of the remote control to select a radio band. 3 Press P MODE/ 3 Flick the jog lever of the remote control toward TUNE + or TUNE – to tune in the station you want and adjust the volume. to switch your CD player to the presetting mode. 4 Flick the jog lever toward TUNE + or TUNE – to tune in to the stored station you want to listen to. To turn off the radio Press RADIO ON/OFF again. To tune in to a station quickly Flick and hold the jog lever toward TUNE + or TUNE – in step 3 until the frequency digits begin to change in the display. The CD player automatically scans the radio frequencies and stops when it finds a clear station. To improve broadcast reception For TV/WB/FM, extend the headphones or earphones cord. Headphones or earphones If you press P MODE/ again, “PRESET” disappears from the display and you can tune in to a station manually. Changing the tuning interval When using the CD player abroad, change the AM tuning interval, if necessary. 1 Press RADIO ON/OFF to turn on the radio. 2 Hold down DISPLAY until “A Preset” appears in the Polarity of the plug • Do not touch the AC power adaptor with wet hands. • Connect the AC power adaptor to an easily accessible AC outlet. Should you notice an abnormality in the AC power adaptor, disconnect it from the AC outlet immediately. On rechargeable batteries and dry batteries • Do not charge the dry batteries. • Do not throw the batteries into fire. • Do not carry the batteries with coins or other metallic objects. It can generate heat if the positive and negative terminals of the battery are accidentally contacted by a metallic object. • Do not mix rechargeable batteries with dry batteries. • Do not mix new batteries with old ones. • Do not use different types of batteries together. • When the batteries are not to be used for a long time, remove them. • If battery leakage occurs, wipe off any deposit in the battery compartment, and install new batteries. In case the deposit adheres to you, wash it off thoroughly. On the CD player • Keep the lens on the CD player clean and do not touch it. If you do so, the lens may be damaged and the CD player will not operate properly. • Do not put any heavy object on top of the CD player. The CD player and the CD may be damaged. • Do not leave the CD player in a location near heat sources, or in a place subject to direct sunlight, excessive dust or sand, moisture, rain, mechanical shock, unleveled surface, or in a car with its windows closed. • If the CD player causes interference to the radio or television reception, turn off the CD player or move it away from the radio or television. • Discs with non-standard shapes (e.g., heart, square, star) cannot be played on this CD player. Attempting to do so may damage the CD player. Do not use such discs. display. 3 Flick the jog lever toward TUNE + or TUNE – repeatedly until “Step” appears in the display. For AM, reorient the remote control itself. 4 Press the jog lever. “Step 9k” or “Step 10k” appears in the display. 5 Flick the jog lever toward TUNE + or TUNE – to select the tuning interval. Note There is a DC-DC converter attached to the headphones/ earphones cord. When listening to an AM program, keep the remote control away from the DC-DC converter, otherwise, noise may be heard. If it is hard to hear an FM broadcast Press SOUND repeatedly until “Local” appears in the display. Under the normal conditions, press SOUND repeatedly until “DX” appears in the display. 9 kHz area: Asia and Europe 10 kHz area: the U.S.A., Canada and South America Note After changing the tuning interval, you need to preset radio stations again. Connecting a stereo system (F) You can listen to CDs through a stereo system and record CDs on a cassette tape. For details, see the instruction manual that comes with the connected device. Be sure to turn off all connected devices before making connections. Notes • Before you play a CD, turn down the volume of the connected device to avoid damaging the connected speakers. • Use the AC power adaptor for recording. If you use the rechargeable batteries or dry batteries as a power source, batteries may become completely depleted during recording. • Adjust the volume properly on the connected device so that the sound will not be distorted. • When the CD player is connected to a stereo system, you cannot listen to the radio. On headphones/earphones Road safety Do not use headphones/earphones while driving, cycling, or operating any motorized vehicle. It may create a traffic hazard and is illegal in some areas. It can also be potentially dangerous to play your headsets at high volume while walking, especially at pedestrian crossings. You should exercise extreme caution or discontinue use in potentially hazardous situations. Preventing hearing damage Avoid using headphones/earphones at high volume. Hearing experts advise against continuous, loud and extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Consideration for others Keep the volume at a moderate level. This will allow you to hear outside sounds and to be considerate to the people around you. Specifications CD player System Compact disc digital audio system Laser diode properties Material: GaAlAs Wavelength: λ = 780 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) Radio Frequency range 10 kHz step: TV: 2 - 13 ch WB (weather band): 1 - 7 ch FM: 87.5 - 108.0 MHz AM: 530 - 1 710 kHz 9 kHz step: TV: 2 - 13 ch WB (weather band): 1 - 7 ch FM: 87.5 - 108.0 MHz AM: 531 - 1 710 kHz Antenna TV/WB/FM: Headphones/earphones cord antenna AM: Ferrite bar antenna built in the remote control General Power requirements For the area code of the model you purchased, check the upper left side of the bar code on the package. • Two Sony NH-7WMAA rechargeable batteries: 1.2 V DC × 2 • Sony NH-WM2AA rechargeable batteries: 1.2 V DC × 2 • Two LR6 (size AA) batteries: 1.5 V DC × 2 • AC power adaptor (DC IN 4.5 V jack): U, U2, CA, CA2, E92, MX2, TW2 and CA2/C models: 120 V, 60 Hz CED, CED/4, CE7, CE7/C, EE, EE1, E, E13 and E13/2 models: 220 - 230 V, 50/60 Hz CEK model: 230 V, 50 Hz AU2 model: 240 V, 50 Hz EU8, EU8/C, JE.W, E18, KR4 and EE8 models: 100 - 240 V, 50/60 Hz HK4 model: 230 V, 50 Hz CNA model: 220 V, 50 Hz Dimensions (w/h/d) (without projecting parts and controls) Approx. 136.0 × 19.6 × 136.0 mm (5 3⁄8 × 25⁄32 × 5 3⁄8 in.) Mass (excluding accessories) Approx. 158 g (5.6 oz) Operating temperature Maintenance To clean the casing Use a soft cloth slightly moistened in water or a mild detergent solution. Do not use alcohol, benzine or thinner. To clean the plugs If the plugs become dirty, there is no audio or noise is heard. Clean them with a dry soft cloth periodically. 5°C - 35°C (41°F - 95°F) Design and specifications are subject to change without notice. Supplied Accessories AC power adaptor (1) Headphones/earphones (1) Remote control with built-in tuner (1) Rechargeable batteries (2) Battery carrying case (1) Carrying pouch (1) This warranty is valid only in the United States.
