Sony DSC-TX10/B Specification

Sony DSC-TX10/B Specification
16.2MP | 4x OPTICAL ZOOM | 3.0” LCD
The Sony® DSC-TX10 lets you live life on the edge. This stylish and
innovative camera will fit perfectly into your active life. Waterproof,
shockproof, dustproof, freeze-proof, HD movies, 3D photos, Sweep
Panorama™ mode, and a touch screen, this powerful tool follows
you to the edge and proves you were there.
Rugged and Stylish
Full HD 1080/60i
Additional features:
This camera is just as much at home in the
water as on a night on the town! The sleek and
stylish TX10 fits the slimmest pocket or purse,
yet is waterproof to a depth of 16 ft, shockproof
from falls up to approximately 5 ft and dustproof
thanks to its airtight construction.15 As well,
this durable camera can even withstand
extreme weather conditions, as it is operable
in temperatures from 14- to 104-degrees
Fahrenheit. Seamlessly shifting from underwater
marvels to a night on the town, the TX10 always
makes it easy to get the best shot!
Record crystal clear movies at the highest
resolution available with capabilities for 60i
in 1080 Full HD6. This provides stunning, fast
motion video with less distortion for playback
on your HD TV.9
• Superior Auto: awesome shots, automatically
3D Still Image
• Fast capture with up to 10fps at full
16.2MP resolution
3.0” (921K dots) XtraFine
LCD™ display
3.0” (921K dots) XtraFine LCD™ technology
gives you brilliant-quality still images and
movies with easy focus.
16.2 Megapixel Back-illuminated
“Exmor R” CMOS Image Sensor
The DSC-TX10 features a 16.2 megapixel “Exmor
R” CMOS image sensor that brings out the full
resolving power of the camera’s Carl Zeiss® VarioTessar® lens to deliver extremely fast speed, high
resolution, and stunning low-light sensitivity with
improved image clarity and drastically reduced
grain. In addition, the combined “Exmor R”
CMOS sensor and BIONZ® image processor
delivers extremely fast up to 10fps, Anti-Motion
Blur, Hand-held Twilight and 1080i movie modes.
Produce awe-inspiring images with 3D still
image and 3D Sweep Panorama™ capabilities.
Images will take on a new dimension to view
the world in a whole new way.7
Intelligent Sweep
Panorama™ HR mode
With Intelligent Sweep Panorama™ HR
mode just press the shutter, pan across the
landscape and let the camera do the rest.
It automatically links together each frame to
produce a high resolution panoramic image
providing the ability to zoom in on small
details. This model even detects faces and
moving subjects to stitch intelligently different
widths to help avoid subject distortion.
Background Defocus
DSLR photographs are often beautiful because
they blur the background, putting the emphasis
on the subject. Now our point-and-shoot
cameras can deliver this signature DSLR benefit.
The system takes two shots, identifies the
background and applies a defocused background keeping the subject crisp and clear.
Sony Electronics Inc. | 16530 Via Esprillo | San Diego, CA 92127 | 1.800.222.7669 |
• Soft Skin mode reduces visible blemishes,
and wrinkles
• Natural Flash corrects color balance for
lifelike shots
• Carl Zeiss® Vario-Tessar® 4x (25mm)
optical zoom lens
• HDMI™ output for easy connectivity
• Smile Shutter™ technology automatically
captures a smile
• Face Detection technology captures
faces naturally
• Motion Detection suppresses blur in people
and other subjects
• Anti-blink, Face Priority and Red-eye
Reduction functions
• Anti-Motion Blur/Hand-held Twilight for less
grain and blur
• Backlight Correction HDR for scenes with
high-contrast (2 shots)
• Sweep Multi Angle™ for 3D-like view on the
camera’s LCD
T-SERIES Digital Still Camera
Camera Type
Image Device
Effective Pixels Resolution
Waterproof15 sleek and stylish with 3” touch screen
1/2.3” (7.77mm) “Exmor R” CMOS Sensor
Lens Type
Optical Zoom
Digital Zoom
Total Zoom
Carl Zeiss Vario-Tessar
12 elements in 10 groups
(including 6 aspheric elements,1 prism)
iAuto (F3.5-F6.3 (W)) / Program Auto (F3.5-F6.3 (W))
Still 16:9: 27-108mm / Still 4:3: 25-100mm /
Movie 16:9: 27-108mm / Movie 4:3: 33-132mm
Smart Zoom / Precision Digital Zoom / Off
Approximately 16x with Precision Digital Zoom
LCD Type
3.0” XtraFine LCD™ (921K dots)
Media Slot
MS PRO Duo™ media / SD/SDHC media10
16:9 12M (4,608 x 2,592) / 2M (1,920 x 1,080); 4:3 16M
(4,608 x 3,456), 10M (3,648 x 2,736), 5M (2,592 x 1,944),
VGA (640 x 480), 3D: 16M (4,608 x 3,456) / 16:9 (12M)
(4,608 x 2,592); Panorama 2D: 7,152 x 1,080 (238deg) /
4,912 x 1,080 (163deg) / 4,912 x 1,920 (172deg) / 3,424
x 1,920 (120deg), 3D: 7,152 x 1,080 (238deg) / 4,912 x
1,080 (163deg) / 4,912 x 1,920 (172deg) / 3,424 x 1,920
(120deg) / 1,920 x 1,080 (64deg)
1,920 x 1,080 (PS) Approx. 28Mbps Approx. 60fps
Progressive / 1,920 x 1,080 (FX) Approx. 24Mbps Approx.
60fps interlace / 1,920 x 1,080 (FH) Approx. 17Mbps
Approx. 60fps interlace / 1,440 x 1,080 (HQ) Approx.
9Mbps Approx. 60fps interlace / 1,440 x 1,080 Approx.
12Mbps Approx. 30fps, Progressive / 1,280 x 720
Approx. 6Mbps Approx. 30fps, Progressive / 640 x 480
(VGA) Approx. 3Mbps Approx. 30fps, Progressive
Stereo / Mono
Optics & Lens
Lens Construction
Aperture Range
Focal Length
35mm Equivalency
LCD & Viewfinder
Still Images
Microphone / Speaker
Intelligent Auto Focus
Macro Mode
Exposure Metering
Exposure Compensation
Backlight Correction HDR
Dynamic Range Optimizer
White Balance
9 points AF / Center Weighted AF / Spot AF /
Flexible Spot AF (Touch)
iAuto (W: Approx. 1cm (0.39’) to Infinity, T: Approx.
50cm (1.64’) to Infinity) / Program Auto: (W: Approx.
8cm (0.26’) to Infinity, T: Approx. 50cm (1.64’) to Infinity)
Multi Pattern / Center Weighted / Spot
Plus / Minus 2.0EV, 1 / 3EV step
Auto / 125 / 200 / 400 / 800 / 1600 / 3200
Auto / Daylight / Cloudy / Fluorescent 1 (White
Fluorescent Lighting) / Fluorescent 2 (Natural White
Fluorescent Lighting) / Fluorescent 3 (Day White
Fluorescent Lighting) / Incandescent / Flash /
Underwater: Auto / Underwater1 / Underwater2
iAuto (2” - 1/1,600) / Program Auto (1” - 1/1,600)
Approx. 10 fps at 16.1MP (Maximum 3 shots)
Flash Type
ISO Auto: Approx. 0.08m-Approx. 3.7m (Approx.
0.26’-Approx. 12.13’) (W) / Approx. 0.5m-Approx.
2.7m (Approx. 1.64’-Approx. 8.85’) (T), ISO3200:
up to Approx. 5.2m (Approx. 17.0) (W) / Approx.
3.8m (Approx. 12.4’) (T)
Auto / On / Slow Syncro / Off
Flash Effective Range
Flash Mode
Superior Auto
Intelligent Auto
Face Detection
Motion Detection
Blink Detection
Smile Shutter™ Technology
In-Camera Editing
TransferJet™ Technology
36 scenes still / 36 scenes movie
High Sensitivity / Twilight / Twilight Portrait / Soft
Snap / Landscape / Beach / Snow / Fireworks /
Hi-Speed Shutter / Underwater / Gourmet / Pet /
Soft Skin / Hand-held Twilight / Anti-Motion Blur /
Backlight Correction HDR
Optical SteadyShot™ image stabilization
Up to approx. 16 feet (1 hour)
-10°C/ 14°F
1.5m/ 5ft
Sweep Panorama™ HR
(Horizontal / Vertical up to 238-degrees)
Hand-held Twilight / Anti-Motion Blur /
Backlight Correction HDR
3D still image / 3D Panorama / Sweep Multi Angle
8 Faces (Auto / Touch / Child Priority / Adult Priority)
Off / 10sec. / 2sec./ portrait1 / portrait2
Trimming / Red Eye Correction / Unsharp Masking
HD Video
SD Video
Yes - USB 2.0 Hi-Speed
HDMI/Composite (1080i)
Scene Modes
Shutter Speed
Burst Mode
Image Stabilization
Multi-shot layering
Inputs & Outputs
Supplied Battery
Lithium-ion NP-BN1 3.6V
Battery Life (Approx.)27
Number of Images (Approx.) 250
Weights & Measurements
Dimensions (Approx.)
Weights (Approx.)
Supplied Software
Operating System
Service & Warranty
3 7/8” x 2 1/4” x 23/32” (95.6mm x 56.1mm x 17.9mm )
Body: 4.2 oz. (118g), With battery and Memory
Stick media: 4.7 oz. (133g)
Picture Motion Browser Ver 5.5, PMB Portable 5.5
(for Windows), PMB Portable 1.3 (for Macintosh)1
PMB and PMB Portable: Microsoft Windows XP SP3,
Windows Vista SP2, Windows 7. PMB Portable also
compatible with Macintosh OS® X (v10.4 - 10.6)
Limited Term Warranty
Limited 1 Year Parts & Labor
Battery Charger
Wrist Strap
Paint Pen
USB Cable
Lithium-ion NP-BN1
Supplied Accessories
1. PMB requires Microsoft® Windows® XP SP3/ Windows Vista® SP2/Windows 7. Software not supported
by Mac OS. Movie format is compatible with iMovie® ‘09 or later versions.
6. Records in 29 minute segments.
7. Requires 3D HDTV, HDMI™ cable (at least 10.2 Gbps) and active 3D glasses (all sold separately).
8. TransferJet™ enabled media (sold separately) and TransferJet technology required in both
9. HD viewing requires HD output adapter cable VMC-MD3 (sold separately) and HDTV with
equivalent display capability.
10. When using movie mode Memory Stick PRO Duo with MARK2 logo, Memory Stick PRO-HG,
Class 4 or higher for SD/SDHC/SDXC media are recommended.
15. W
aterproof certified to IEC60529 IPX8 standard, shock-proof Certified to MIL-STD-810F Method
516.5-Shock, dustproof certified to IEC 60529 IP5X standard, and can operate in temperatures
between 14 degrees Fahrenheit (-10 degrees Celsius) and 104-degrees Fahrenheit
(40 degrees Celsius).
27. Actual results may vary based on product settings, usage patterns and environmental conditions.
Battery capacity decreases over time and use.
3.0” LCD
© 2011 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, Sony make.believe logo, Cyber-shot, Optical SteadyShot, BIONZ, Xtra Fine LCD,
Clear Photo, Clear Photo LCD Plus, SteadyShot, Memory Stick PRO-HG, InfoLITHIUM, Party-Shot, AVCHD, Exmor, TruBlack, TransferJet, Exmor R, Smile Shutter, DVDirect, BRAVIA, Memory Stick PRO Duo, Memory
Stick Duo and the Memory Stick logo are trademarks of Sony. PlayStation is a trademark of Sony Computer Entertainment. Microsoft, Windows, and Windows Vista are trademarks of Microsoft Corporation.
Mac OS and Macintosh are trademarks of Apple Computers, Inc. Blu-ray Disc is a trademark. HDMI is a trademark of HDMI Licensing LLC. All other trademarks are trademarks of their respective owners.
