machine number
|
DVD2381
E N J O Y T H E V I E W
®
o p e r a t i n g g u i d e / w a r r a n t y
PAGE 2
INTRODUCTION
Safety Precautions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION:
POUR EVITER LES CHOCS ELECTRIQUE, INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU
FOUD.
CAUTION:
This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference, should the unit require maintenance, contact an authorized service location-see service procedure.
Use of controls, adjustments or the performance of procedures other than those specified may result herein hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
Changes or modifications not expressly approved by Zenith Electronics Corporation could void the user’s authority to operate the equipment.
INDUSTRY CANADA REQUIREMENT:
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numéruque de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Zenith is a trademark of ZEC © Copyright Zenith Electronics Corporation 2001
RECORD YOUR MODEL NUMBER (Now, while you can see it)
The model and serial number of your new DVD player are located on the back of the DVD player cabinet. For your future convenience, we suggest that you record these numbers here:
MODEL NO.____________________________________
SERIAL NO.____________________________________
INTRODUCTION PAGE 3
Table of Contents
❏
❏
❏
❏
❏
Introduction
❏ Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . 4-5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Identification of Controls . . . . . . . . . . . . . . . . . 8-11
Front Panel/Display Window . . . . . . . . . . . . . . . . . . . . 8
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controlling the VCRs, CATVs (DBS) and TVs. . . . . . . 11
Preparing the Remote Control . . . . . . . . . . . . . . . . . . 12
Operating with the Remote Control . . . . . . . . . . . . . . 12
❏
❏
Connections
❏ Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . 13
❏ Connecting to a TV equipped with component video inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting to an Audio System . . . . . . . . . . . . . 15
Connecting to Optional Audio System . . . . . . 16-18
Enjoying Dolby Digital Sound . . . . . . . . . . . . . . . . . . . 16
Enjoying Dolby Pro Logic Surround Sound. . . . . . . . . 17
Enjoying 2 Channel Digital Stereo Sound. . . . . . . . . . 18
Enjoying DTS Sound . . . . . . . . . . . . . . . . . . . . . . . . . 18
Basic Operations
❏ Basic Playback . . . . . . . . . . . . . . . . . . . . . . . 19-21
Stopping Play . . . . . . . . . . . . . . . . . . . . . . . . . . 21
❏
Resume Play . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Last Scene Memory . . . . . . . . . . . . . . . . . . . . . 21
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Special Playback. . . . . . . . . . . . . . . . . . . . . . 22-23
Still Picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Frame Advance . . . . . . . . . . . . . . . . . . . . . . . . 22
Skipping Chapters and Tracks Forward or Back . 22
HDCD Playback . . . . . . . . . . . . . . . . . . . . . . . . 22
To Scan at Fast Forward or Fast Reverse Playback . 23
Various Speed Playback with Shuttle Ring. . . . . 24
Operation Using GUI Menu Icons
❏ General Information about GUI Menu Icons . . . . 25
❏ Detailed Description of each GUI Menu Icon . . . 26
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
Advanced Operation
❏ Using a Title Menu . . . . . . . . . . . . . . . . . . . . . . . 27
Using a DVD Menu . . . . . . . . . . . . . . . . . . . . . . 27
Changing Subtitle Language . . . . . . . . . . . . . . . 28
Changing Audio Soundtrack Language. . . . . . . . 28
Viewing from another Angle . . . . . . . . . . . . . . . . 29
Producing a 3D Surround Effect . . . . . . . . . . . . . 29
Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Storing Markers in Memory to be Viewed
(Listened to) again . . . . . . . . . . . . . . . . . . . . . . . 31
Zoom Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Program Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Playback with MP3 . . . . . . . . . . . . . . . . . . . . 34-35
❏
❏
❏
❏
❏
❏
❏
Initial Settings
❏ Selection of Initial Settings . . . . . . . . . . . . . . . . . 36
❏ Selecting Disc Languages . . . . . . . . . . . . . . . . . 37
Selecting Rating Level and Password . . . . . . 38-39
Selecting TV Aspect . . . . . . . . . . . . . . . . . . . . . . 40
Selecting Menu Language . . . . . . . . . . . . . . . . . 41
Selecting Progressive Scan . . . . . . . . . . . . . . . . 42
Selecting Digital Audio Output . . . . . . . . . . . . . . 43
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table of Languages and Their Abbreviations. . . . 45
❏
❏
❏
❏
❏
Reference
❏ Disc Requirements/Copyright Information . . . . . . 46
Before Calling Service Personnel . . . . . . . . . . . . 47
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Recommended Accessories . . . . . . . . . . . . . . . . 49
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50-51
Warranty . . . . . . . . . . . . . . . . . . . . . . . Back Cover
PAGE 4
INTRODUCTION
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL
AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing.
This unit is fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read owner’s manual
After unpacking this product, read the owner’s manual carefully, and follow all the operating and other instructions.
2. Power Sources
This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
3. Grounding or Polarization
This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
4. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
5. Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
6. Water and Moisture
Do not use this product near water-for example, near a bath tub, wash bowl, kitchen sink. or laundry tub; in a wet basement; or near a swimming pool and the like.
7. Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
8. Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, playing particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
9. Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
10. Lightning
For added protection of this product during storms, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet.
This will prevent damage to the product due to lightning and power-line surges.
11. Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
12. Attachments
Do not use attachments not recommended by the product manufacturer as they may cause hazards.
INTRODUCTION PAGE 5
IMPORTANT SAFETY INSTRUCTIONS (Cont’d)
13. Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.
14. Disc Tray
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
15. Burden
Do not place a heavy object on or step on the product. The object may fall, causing serious personal injury and serious damage to the product.
16. Connecting
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner’s manual of the other equipment carefully and follow the instructions when making any connections.
20. Laser Beam
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser beam. It may cause sight damage.
21. Disc
Do not use a cracked, deformed, or repaired disc.
These discs are easily broken and may cause serious personal injury and product malfunction.
22. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in performance-this indicates a need for service.
23. Servicing
Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
17. Sound Volume
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.
18. Sound Distortion
Do not allow the product to output distorted sound for a longtime. It may cause speaker overheating and fire.
24. Replacement parts
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
19. Headphones
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.
25. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
PAGE 6
INTRODUCTION
Precautions
Notes on handling
❏
When shipping the DVD player, always use the original shipping carton and packing materials.
For maximum protection, repack the unit as it was originally packed at the factory.
❏
Do not use volatile liquids, such as insect spray, near the DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. They will leave marks on the finish.
❏
The top and rear panels of the DVD player may become warm after a long period of use. This is normal and not a malfunction.
❏
When the DVD player is not in use, be sure to remove the disc and turn off the power.
❏
If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally.
Notes on Moisture Condensation
Moisture condensation damages the DVD player.
Please read the following carefully.
Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day.
Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the DVD player.
Ex ampl es of moistu re con densation
Optical pick-up lens
Notes on Locating
❏
When you place this DVD player near a TV, radio, or
VCR, the playback picture may become poor and the sound may be distorted. In this case, move the DVD player away from the TV, radio, or VCR.
Notes on Cleaning
Use a soft, dry cloth for cleaning.
❏
For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzine, as they may damage the surface of the
DVD player.
❏
If you use a chemical saturated cloth to clean the unit, follow that product’s instructions.
Warning: Cleaning and adjustment of lenses and/or other components of playback mechanism should be performed by a qualified service technician.
To Obtain a Clear Picture
The DVD player is a high technology, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality becomes poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every
1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.
Moisture condensation occurs during the following cases.
❏
When you bring the DVD player directly from a cold place to a warm place.
❏
When you use the DVD player in a room where you just turned on the heater, or a place where the cold wind from the air conditioner directly hits the unit.
❏
In summer, when you use the DVD player in a hot and humid place just after you move the unit from an air conditioned room.
❏
When you use the DVD player in a humid place.
It’s too warm!
❏
Do not use the DVD player when moisture condensation may occur.
If you use the DVD player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the DVD player to the wall outlet, turn on the DVD player and leave it “ON” for two or three hours. After two or three hours, the
DVD player will have warmed up and evaporated any moisture. Keep the DVD player connected to the wall outlet and moisture condensation will seldom occur.
Wait!
INTRODUCTION PAGE 7
Notes on Discs
This section shows you how to handle, clean, and store discs.
On Handling Discs
❍
Do not touch the playback side of the disc.
On Storing Discs
❍
❍
❍
Do not store discs in a place subject to direct sunlight or near heat sources.
Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.
❍
Do not attach paper or tape to discs.
On Cleaning Discs
❍
❍
❍
Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outward with a soft cloth. Always keep the disc clean.
If you cannot wipe off the dust with a soft cloth, wipe the disc lightly with a slightly moistened soft cloth and finish with a dry cloth.
Do not use any type of solvents such as thinner, benzine, commercially available cleaners or anti-static spray for vinyl LPs.
They may damage the disc.
About This Owner’s Manual
❍
❍
❍
This owner’s manual explains the basic instructions of this DVD player.
Some DVD video discs have functions that may not be explained in this owner’s manual.
Therefore, some instructions may differ from this owner’s manual, and there may be extra instructions. In this case, follow the instructions displayed on the TV screen or package.
“ ” may appear on the TV screen during operation. This icon means the function explained in this owner’s manual is not available on that specific DVD video disc.
PAGE 8
INTRODUCTION
Identification of Controls
Front Panel
POWER button and indicator
Disc tray
power/standby
SKIP/SCAN buttons
STOP button
PAUSE/STEP button
PLAY button
open/close play pause/step stop skip scan menu menu search select/ enter
Display window
Remote sensor
OPEN/CLOSE button
MENU button
ARROW buttons
SELECT/ENTER button
Display Window
Operating status indicator
CD indicator
DVD indicator
MP3 HD CD DVD TITLE CHP/TRK
PROGRAM indicator
RANDOM indicator
Repeat playback mode indicators
PROG.
RANDOM ALL A B
MP3 indicator
HDCD indicator
Angle icon indicator
Total playing time/elapsed time indicators
Chapter/Track number indicator
Title number indicator
INTRODUCTION PAGE 9
Identification of Controls (Cont’d)
Rear Panel
COAXIAL DIGITAL AUDIO OUT jack
DIGITAL
OUT
OPTICAL
AUDIO OUT2 (L/R) jacks
COMPONENT VIDEO OUT/
PROGRESSIVE SCAN jacks
AUDIO OUT1 (L/R) jacks
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L Pb L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
VIDEO OUT jack
S-VIDEO OUT jack
VIDEO OUTPUT SELECT Switch
POWER CORD
Connect to an AC 120V, 60Hz outlet only.
OPTICAL DIGITAL AUDIO OUT jack
Remove the dust protection cap from the connector and connect the optical digital cable (not supplied) firmly so that the configurations of both the cable and the connector match. Keep the dust protection cap and always reattach the cap when not using the connector to protect against dust.
Dust protection cap
PAGE 10
INTRODUCTION
Identification of Controls (Cont’d)
Remote Control
You will find instructions for each of the remote control functions in the appropriate sections of this instruction manual.
POWER button
*TITLE button
DISPLAY button
SELECT/ENTER button
***ARROW
(Volume/Channel) buttons
MARKER button
SEARCH button
SKIP (
❈
SEARCH) button
NUMBER buttons
SETUP button
SUBTITLE button
REPEAT button
CLEAR button
A-B button
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle audio program a - b random angle rev slow/scan fwd
DVD/VCR/CATV/TV
Selector Switch
OPEN/CLOSE button
RETURN
(TV INPUT) button
**MENU button
SOUND
(MUTE) button
ZOOM button
PAUSE/STEP button
SKIP (
❈
SEARCH) button
PLAY button
STOP button
PROGRAM button
ANGLE button
AUDIO button
RANDOM button
SLOW/SCAN Shuttle Ring
*TITLE button
Use the TITLE button to display the title screen included on DVD video discs. To operate a menu screen, follow the instructions in “Using a Title
Menu” (page 27).
**MENU button
Use the MENU button to display the menu screen included on DVD video discs. To operate a menu screen, follow the instructions in “Using a DVD
Menu” (page 27).
***Directional arrow buttons
(up, down, left, right) for use in highlighting a selection on a GUI menu screen, TITLE and MENU screen.
❈ Press and hold button for about two seconds for search function.
INTRODUCTION PAGE 11
Controlling the VCRs, CATVs (DBS) and TVs
Your remote control operates the common features of most, but not all, models and brands of IR (infrared) controlled VCRs, cable converters (DBS) and TVs.
1
Set the DVD/VCR/CATV/TV selector to VCR,
CATV or TV.
2
power dvd vcr catv tv open / close display title vol marker menu return searc h ch select / enter ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio random program angle
1
2
2
While holding PROGRAM button, press the number buttons to set the code number referring to the table below.
Some manufactures have more than one code number. If the remote control does not operate with the VCR, CATV or TV after setting the code number, try another number.
To control the VCR
POWER, Number (0~9), SELECT (ENTER), PLAY, SKIP
(F FWD), SKIP (REW), STOP, OPEN/CLOSE
(EJECT) and PAUSE/STEP buttons on the remote control are activated.
To control the CATV (DBS)
POWER, Number (0~9), SELECT (ENTER), RETURN (Input select) and CH E / D buttons on the remote control are activated.
To control the TV
POWER, Number (0~9), SELECT (ENTER), RETURN (Input select), CH (Channel) E / D and VOL (Volume) E / D buttons on the remote control are activated.
Brand Name
ADMIRAL
AKAI
AMARK
TV Codes by Brand
Codes
110, 113, 144, 151, 152
115
131
AOC
BELL & HOWELL
BROKSONIC
CANDLE
CENTURION
CITIZEN
CORONADO
CROWN
CURTIS MATHES
DAEWOO
115
113
140, 143
158
130
156, 157, 158, 159, 160, 161, 162
131
131
113, 115, 118, 130, 144, 151
145, 146, 147, 148, 149, 150
DAYTRON
EMERSON
FISHER
FUNAI
115, 130
110, 111, 115, 131, 140, 143
116, 125
153, 154
GENERAL ELECTRIC 102, 118, 127, 128, 133, 144, 151
HITACHI 119, 131, 132
JC PENNEY
JVC
102, 115, 124, 130, 133
109, 141
KMC
KTV
131
115, 130, 131, 138
LG (GOLDSTAR)
LODGENET
LOGIK
LXI
MAGNAVOX
115, 122, 130, 131, 133, 146
113
113
104, 116, 123, 124, 125, 131, 139
100, 106, 107, 109, 114, 115, 121
122, 130, 131, 133, 158
MAJESTIC
MARANTZ
MEMOREX
MGA/MITSUBISHI
113
103, 115
113
103, 114, 115, 130
MONTGOMERY WARD 103, 113, 114, 115, 121, 129,
130, 131, 139
NEC
PANASONIC
PHILCO
PHILIPS
PIONEER
PORTLAND
115, 130
104, 122, 127, 128, 133, 163
115, 121, 122, 130, 131, 150
121, 122
134
131
Brand Name
PROSCAN
QUASAR
RADIO SHACK
RCA
REALISTIC
SAMPO
SAMSUNG
SANYO
SCOTT
SEARS
SHARP
SIGNATURE 2000
SONY
SOUNDESIGN
SYLVANIA
TV Codes by Brand
Codes
118, 144, 151
127, 128
110, 111, 129
115, 118, 144, 151
110, 111, 129
130
104, 115, 130, 131
116, 125
115, 130
104, 116, 123, 124, 125, 131
112, 129, 131, 139
102, 113, 114, 115, 121, 129,
130, 131, 139
105
158
106, 107, 115, 121, 122, 130,
133, 158
153, 154
128
110, 113, 122, 131, 158
113, 131
130
104, 123, 124
102, 113, 114, 115, 121, 130, 131
SYMPHONIC
TATUNG
TEKNIKA
TELERENT
YORX
TOSHIBA
WARDS
XR1000
ZENITH
Brand Name
155
100, 101
Cable Converter Codes by Brand
Codes
ALLEGRO
ARCHER
CABLEVIEW
CITIZEN
CURTIS MATHES
351
336
336
336
317
EAGLE
GEMINI
306, 307, 310
302, 327, 328, 333
GENERAL ELECTRIC 353
GENERAL INSTRUMENT 324, 326, 327, 328
GOBRAND
HAMLIN
JERROLD
336
314, 330, 331
323, 324, 325, 326, 327, 329
Brand Name
Cable Converter Codes by Brand
Codes
KALE VISION
MACOM
MAGNAVOX
334
311, 312, 342
306, 307, 310, 334, 337, 338
NSC
OAK
332
301, 321, 322
PANASONIC 313, 318, 320
PARAGON 300
PHILIPS
PIONEER
PLUSER
RCA
REGAL
REGENCY
306, 307, 308, 309, 310
318, 319
336
318
310
304
SAMSUNG 318, 327, 334
SCIENTIFIC ATLANTA 317, 335, 347, 354
SLMARX
SPRUCER
STANDARD
COMPONENTS
318, 327
318, 320, 327
334
STARGATE
TELEVIEW
TEXSCAN
TOCOM
UNIDEN
UNIKA
UNIVERSAL
VID TECH
VIDEO WAY
VIEWSTAR
ZENITH
ZENITH HT-2000
Brand Name
RCA
SONY
318, 327, 328
318, 327, 336
303
315, 316
348
336
351, 352
339
300, 349
306, 307, 310
300, 305, 311
300
DBS Codes by Brand
Codes
355
356
VCR Codes by Brand
Brand Name
ZENITH
LG
Codes
200
201
Note
❍
Due to the variety of codes used by manufactures, our company cannot guarantee that the MBR remote control will operate with every model of the brands listed.
PAGE 12
INTRODUCTION
Identification of Controls (Cont’d)
Preparing the Remote Control
Insert the batteries into the remote control so you can use it to operate the DVD player.
1
Open the battery cover.
Operating with the Remote Control
This section shows you how to use the remote control.
Point the remote control at the remote sensor and press the buttons.
power/standby open/close play pause/step stop skip scan menu menu search select/ enter
2
Insert batteries (AAA size).
●
Make sure to match the + and - on the batteries to
3
the marks inside the battery compartment.
Close the cover.
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
Notes on batteries
Improper use of batteries may cause battery leakage and corrosion.
To operate the remote control correctly, follow the instructions.
Do not insert the batteries into the remote control in the wrong direction.
Do not charge, heat, open, or short-circuit the batteries.
Do not throw the batteries into fire.
Do not leave dead or exhausted batteries in the remote control.
Do not use different types of batteries together, or mix old and new batteries.
If you do not use the remote control for a long period of time, remove the batteries to avoid possible damage from battery corrosion.
If the remote control does not function correctly or if the operating range becomes reduced, replace all batteries with new ones.
If battery leakage occurs, wipe the battery liquid from the battery compartment, then insert new batteries.
The batteries should last about one year with normal use.
30
°
30
°
Within about 23 ft (about 7 m)
power dvd vcr catv tv open / close display title vol marker menu return ch select / enter searc ch zo om tv input vol sou skip pause/step play skip
Distance: About 23 ft (7 m) from the front of the remote sensor
Angle: About 30° in each direction of the front of the remote sensor
* Do not expose the remote sensor of the DVD player to a strong light source such as direct sunlight or illumination. If you do so, you may not be able to operate the DVD player with the remote control.
❍
❍
❍
❍
❍
Notes on the remote control
Point the remote control at the remote sensor on the
DVD player.
Do not drop or give the remote control a shock.
Do not leave the remote control near an extremely hot or humid place.
Do not spill water or put anything wet on the remote control.
Do not disassemble the remote control.
CONNECTIONS PAGE 13
Connecting to a TV
Connect the DVD player to your TV.
DIGITAL
OUT
OPTICAL
VIDEO OUTPUT SELECT switch
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L Pb L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
To AUDIO OUT (L/R)/VIDEO OUT
To S-VIDEO OUT
When using S-VIDEO OUT jack, set the VIDEO
OUTPUT SELECT switch to S-VIDEO.
Audio/Video cable
(Supplied)
S-video cable (Supplied)
If the TV has an S-video input, connect the DVD player with the S-video cable.
To video input To audio inputs
To S-video input
TV or monitor with audio/video inputs
❍
❍
❍
Notes
Refer to the owner’s manual of your TV as well.
Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.
Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the playback picture will be distorted because DVD video discs are copy protected.
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this
DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output” on page 43).
PAGE 14
CONNECTIONS
Connecting to a TV equipped with component video inputs
PROGRESSIVE SCAN: Some TVs or monitors are equipped with component video inputs that are capable of reproducing a progressively scanned video signal. Connecting to these inputs allows you to view the highest quality pictures with less flicker.
COMPONENT VIDEO OUT: Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy higher quality picture playback.
■
To switch the output signal (Progressive/Component)
Set the Progressive to “On” on the SETUP menu for Progressive signal, or set the Progressive to “Off” on the SETUP menu for Component video signal.
DIGITAL
OUT
OPTICAL
VIDEO OUTPUT SELECT switch
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L
R
Pb
Pr
L
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
To AUDIO OUT (L/R)
Audio cable (Supplied)
To COMPONENT VIDEO OUT/
PROGRESSIVE SCAN (Pb, Pr, Y)
When using COMPONENT VIDEO OUT/PROGRESSIVE
SCAN jack, set the VIDEO OUTPUT SELECT switch to
COMPONENT/PROGRESSIVE SCAN.
To audio inputs
Video cable (Pb, Pr, Y) (Not supplied)
To component video input or progressive scan video input
TV or monitor with component video or progressive scan inputs
❍
❍
❍
❍
Notes
Refer to the owner’s manual of your TV as well.
Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.
Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, -Y, B-Y or Y, Cb, Cr)
In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. In such a case, adjust the TV or monitor for optimum performance.
CONNECTIONS PAGE 15
Connecting to an Audio System
You can listen to the sound of audio CDs and DVD video discs in stereo.
DIGITAL
OUT
OPTICAL
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
To AUDIO OUT (L/R)
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L Pb L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
To VIDEO OUT
S-video cable (Supplied)
To S-VIDEO OUT
If the TV has an S-video input, connect the DVD player with the S-video cable.
To S-video input
Video cable (Supplied)
To video input
TV or monitor with audio/video inputs
To audio inputs
Audio cable (Supplied)
Audio system
❍
❍
❍
❍
❍
Notes
Refer to the owner’s manual of your audio system as well.
Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
If you place the DVD player near a tuner or radio, the radio broadcast sound might be distorted. In this case, move the DVD player away from the tuner and radio.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may be damaged.
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output” on page 43).
PAGE 16
CONNECTIONS
Connecting to Optional Audio System
Enjoying Dolby Digital Sound
You can enjoy the high quality dynamic sound of Dolby Digital, Dolby Pro Logic, and 2 Channel Digital Stereo.
Dolby Digital
Dolby Digital is the surround sound technology used in theatres showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the DVD player to a 6 channel receiver equipped with a Dolby Digital decoder or Dolby Digital processor.
DIGITAL
OUT
OPTICAL
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L Pb L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
To DIGITAL OUT
(COAXIAL or OPTICAL)
75 ohm coaxial cable or optical cable
Receiver equipped with a Dolby Digital decoder
To digital audio input
To S-VIDEO OUT or VIDEO OUT
S-Video cable or Video cable
Connection example
To enjoy Dolby Digital sound from this DVD player you need the following:
●
DVD recorded in Dolby Digital
● 6 channel receiver equipped with a Dolby Digital decoder, or Dolby Digital processor and power receiver
●
5 speakers and 1 sub woofer
Front speaker
(left)
Rear speaker
(left surround)
To S-video Input or Video Input
Center speaker
Front speaker
(right)
Rear speaker
(right surround)
Sub woofer
To enjoy Dolby Digital sound
You need to select “Dolby Digital” on the SETUP menu.
* Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby
Laboratories. Confidential Unpublished works. Copyright 1992-1997 Dolby
Laboratories. All rights reserved.
❍
❍
❍
❍
Notes
Refer to the owner’s manual of your audio equipment as well.
Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may be damaged.
CONNECTIONS PAGE 17
Connecting to Optional Audio System (Cont’d)
Enjoying Dolby Pro Logic Surround Sound
Dolby Pro Logic Surround
You can still enjoy the excitement of Surround Sound even if your A/V receiver does not offer Dolby Digital decoding.
If your A/V receiver has a Dolby Pro Logic decoder, refer to the following connection diagram.
DIGITAL
OUT
OPTICAL
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L
Pb
L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
Connect one or two rear speakers.
The output sound from the rear speakers will be monaural even if you connect two rear speakers.
To VIDEO OUT
Video cable
To AUDIO OUT
Audio cable
To audio input
Connection example
Receiver equipped with Dolby Pro
Logic Surround
To video input
Center speaker
Front speaker
(left)
Front speaker
(right)
TV
Rear speaker
(left)
Rear speaker
(right)
●
With a receiver equipped with Dolby Digital
Connect the equipment the same way as described in “Enjoying Dolby Digital Sound” on the previous page. Refer to that receiver’s owner’s manual and set the receiver so you can enjoy Dolby Pro Logic Surround sound.
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output” on page 43).
PAGE 18
CONNECTIONS
Connecting to Optional Audio System (Cont’d)
Enjoying 2 Channel Digital Stereo Sound
2 Channel Digital Stereo
You can enjoy the dynamic sound of 2 Channel Digital Stereo by connecting this DVD player to a receiver equipped with a digital audio input and speaker system (right and left front speakers).
75 ohm coaxial cable or optical cable
Connection example
Receiver equipped with a digital audio input
To digital audio input
(COAXIAL or OPTICAL)
DIGITAL
OUT
OPTICAL
To DIGITAL OUT
To S-VIDEO OUT or VIDEO OUT
DIGITAL
OUT
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
L Pb L
R Pr R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
To S-video Input or Video Input
S-Video cable or Video cable
Front speaker
(left)
TV
Front speaker
(right)
Enjoying DTS Sound
Introducing DTS Digital Surround TM
...the finest technology ever invented to transform existing "home theatre" systems into six discrete channels of exceptionally clear, better-than-compact disc, digital audio performance. And DTS Digital Surround is the only 5.1 surround sound format that can deliver this revolutionary 3-dimensional experience through new music recordings on compact discs, original 5.1 soundtracks on motion picture laserdiscs, and soon, a wide variety of products on DVD.
Connection example
75 ohm coaxial cable or optical cable
To DIGITAL OUT
(COAXIAL or OPTICAL)
To S-VIDEO OUT or VIDEO OUT
DIGITAL
OUT
AUDIO
OUT2
COMPONENT
VIDEO OUT
AUDIO
OUT1
To S-video Input or Video Input
S-Video cable or Video cable
DIGITAL
OUT
OPTICAL
VIDEO
OUTPUT
S-VIDEO
COAXIAL
COMPONENT /
PROGRESSIVE
SCAN
S-VIDEO
OUT
L
Pb
L
R
Pr
R
Y
PROGRESSIVE
SCAN
VIDEO
OUT
Receiver equipped with a DTS decoder
To digital audio input
Front speaker
(left)
Rear speaker
(left surround)
Center speaker
Rear speaker
(right surround)
Front speaker
(right)
Sub woofer
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
❍
❍
❍
❍
Notes
Refer to the owner’s manual of your receiver as well.
Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver power on, the speakers may be damaged.
BASIC OPERATION PAGE 19
Basic Playback
This section shows you the basics on how to play back a DVD video disc.
power/standby
3
open/close play pause/step stop skip scan menu menu search select/ enter
Preparations
●
When you want to play back DVD video discs, turn on the TV and select the video input source connected to the DVD player.
●
When you want to enjoy the sound of DVD video discs or audio
CDs from the audio system, turn on the audio system and select the input source connected to the DVD player.
●
For connection details, see pages 13 through 18.
●
Set the playback picture size according to the aspect ratio of the connected TV at the SETUP menu (TV Aspect).
●
If you do not have the necessary equipment to enjoy Dolby Digital sound, set the Digital Audio Output at the SETUP menu to “PCM”.
1
4
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
2, 4 1
Press POWER.
The DVD player turns on and the power indicator lights.
●
2
Press OPEN/CLOSE.
The disc tray opens.
You can open the disc tray by pressing this button even if the
DVD player is in standby mode.
●
3
●
Place a disc on the disc tray with the playback side down.
There are two different disc sizes. Place the disc in the correct guide on the disc tray. If the disc is out of the guide, it may damage the disc and cause the DVD player to malfunction.
Do not place anything except 3” discs or 5” discs on the disc tray.
●
4
Press PLAY.
The disc tray is automatically closed and playback begins.
If the disc is placed in upside down (and it is a single sided disc), “NO DISC” or “DISC ERROR” appears on the TV screen.
MP3 VCD HD CD DVD TITLE CHP/TRK PROG.
RANDOM ALL A B
Operating status indicator
●
If you insert an audio CD, the CD indicator lights up in the DVD display. The title number does not appear.
●
After playing back all of the chapters in the title, the DVD player automatically stops and returns to the menu screen.
When a menu screen appears on the TV screen.
In case of interactive DVDs with control, a menu screen appears on the
TV screen. Perform step 5 on page 20 to start play.
Example of interactive
DVD On-Screen Menu
PAGE 20
BASIC OPERATION
Basic Playback (Cont’d)
power dvd vcr catv tv open / close display title menu return vol marker ch select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
5
5
Press
D
/
E
/
F
/
G
and press SELECT/ENTER, or press the numeric button(s), to select the desired item.
1
2
3
4
OR
Play of the selected item now begins.
● For further information, also refer to the jacket or case of the disc you are playing.
After operation
When the unit is not in use, remove the disc and press
POWER to turn off the DVD player.
Notes
❍
Do not move the DVD player during playback. Doing so may damage the disc and the DVD player.
❍
Use the OPEN/CLOSE button on the remote control or DVD player to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the DVD player to malfunction.
❍
Do not push up the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD video player to malfunction.
❍
Keep your fingers well clear of the disc tray as it is closing. Be especially careful with children’s fingers around the closing disc tray as there is a risk of personal injury.
❍
When “ ” appears on the TV screen while a button is pressed, it means that this function is not available on the disc you are playing.
❍
Depending on the DVD disc, some operations may be different or restricted. Refer to the jacket or case of the disc you are playing.
BASIC OPERATION PAGE 21
Basic Playback (Cont’d)
STOP
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
PLAY
setup repeat clear subtitle a - b audio random program angle rev slow/scan fwd
Stopping Play
Press STOP during playback.
Resume Play
●
When play is stopped, the unit records the point where
STOP was pressed (RESUME function).
Press PLAY and play will resume from this point.
Notes
❍
This operation works only with discs for which the elapsed playing time appears in the DVD display window during stop.
❍
Resume function will be cleared when the STOP is pressed on the STOP mode.
❍
The Resume function may not be available on some DVD discs.
Last Scene Memory
This player memorizes last scene for the last disc you have watched. Settings remain in memory even if you remove the disc from the player or switch off the player. If you load a disc that has its settings memorized, Latest Stop Position is automatically recalled.
Notes
❍
Settings are stored in memory for use any time.
❍
Switching of the audio mode, etc., is automatic on some discs.
❍
This player does not memorize if you switch off the player when a DVD or title menu appears on the TV screen.
❍
The last scene memory function will be cleared when the STOP is pressed on the STOP mode.
Screen Saver
The screen saver is useful to prevent your display from becoming damaged.
The screen saver picture appears when you leave the DVD player in stop mode for about 5 minutes.
Automatic power off function
After the Screen Saver has been engaged for about 5 minutes, the DVD player will automatically turn itself off.
Screen Saver
PAGE 22
BASIC OPERATION
Special Playback
SKIP
STOP
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
PAUSE/
STEP
SKIP
PLAY
Still Picture (Pause)
Press PAUSE/STEP during playback.
● DVD
●
The player will be placed in the still picture mode.
CD
The player will be placed in the pause mode.
Frame Advance (DVD only)
Press PAUSE/STEP during still playback.
(Each time you press PAUSE/STEP, the picture advances one frame)
To resume normal playback, press PLAY.
Skipping chapters and tracks forward or back
Skipping forward
Press SKIP during playback.
A chapter (DVD) or a track (CD) is skipped each time the button is pressed.
Skipping back
Press SKIP during playback.
●
When the button is pressed once midway through a chapter/track, the player returns to the start of that chapter/track. When it is pressed again, a chapter/track is skipped each time the button is pressed.
HDCD Playback
HDCD is a process that increases the fidelity of both specially encoded HDCD discs and standard CD audio discs. When an HDCD-encoded disc is playing, the special decoder is automatically activated and the HDCD Indicator lights. No user intervention is required.
To enjoy the benefits of HDCD, your DVD Player must be connected to your A/V receiver via the Analog Audio Outputs.
However, if your A/V receiver or surround processor is equipped with built-in HDCD decoding, you may also use a Coaxial or Optical digital audio connection so that the
HDCD processing is done there.
BASIC OPERATION PAGE 23
Special Playback (Cont’d)
You can play back discs at various speeds.
SKIP
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
SKIP
PLAY
setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
To Scan at fast forward or fast reverse playback.
Press and hold SKIP or button for about two seconds during playback.
[TV screen]
X2 X2
●
The speed of advance (reverse) is relatively slow at first.
When the button is pressed again, the speed becomes faster. (Each time the button is pressed, the speed increases up to 4 steps (DVD) or 3 step (CD).)
●
The speed will be retained even after the button is released.
To return to normal playback, press PLAY.
Note
❍
The DVD player does not play back sound during the high speed reverse and forward playback of DVD video discs.
However, the DVD player plays back sound during fast forward or fast reverse playback of audio CDs.
PAGE 24
BASIC OPERATION
Various speed playback with Shuttle Ring
You can play back discs at various speeds, and resume normal playback.
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te
To play in slow-motion
During still picture mode, rotating and holding the
SHUTTLE ring to the positions indicated gives those slow modes.
●
The variable-speed slow picture will appear on the TV screen.
Release the SHUTTLE ring to resume the still picture mode.
1/8
1/16 1/16
1/8 skip pause/step play stop skip
PAUSE/
STEP
PLAY
1/2
1/4 1/4
1/2
REVERSE
DIRECTION
FORWARD
DIRECTION setup repeat clear subtitle a - b audio program random angle
SLOW/SCAN
Shuttle ring
rev slow/scan fwd
Notes
❍
The DVD player does not play back sound during slow-motion playback, the high speed reverse and
❍ forward playback of DVD video discs.
However, the DVD player plays back sound during fast forward or fast reverse playback of audio CDs.
Subtitles do not appear on the screen during scan
❍
❍ playback.
The DVD player provides four (4) scan speeds (DVD) or three (3) scan speeds (CD).
The DVD player can not play back audio CDs in slow motion.
To scan at fast forward or fast reverse.
During playback mode, rotating and holding the
SHUTTLE ring to the positions indicated gives those fast search modes.
●
The variable-speed search picture will appear on the TV screen.
Release the SHUTTLE ring to resume normal playback.
FF X16
FF X4
FF
X100
REVERSE
DIRECTION
FF
X2
G
GG
X2
GG X4
GG X16
GG
X100
FORWARD
DIRECTION
OPERATION USING GUI MENU ICONS PAGE 25
General Information about GUI menu icons
This unit features GUI Menu Icons showing disc information (title/chapter/track number, elapsed playing time, audio/subtitle language, angle, and sound) and player information (repeat play, play mode, marker, etc.). Some icons only show the indicated information.
Other icons allow the settings to be changed.
Common procedures
1
Press DISPLAY during playback.
●
Title function can be accessed from the stop mode.
power dvd vcr catv tv open / close
2
Press
D
/
E
to select the desired item.
●
The current selected item is indicated by a yellow frame on its GUI menu icons.
1
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
2, 3
3
Press
F
/
G
to select the desired setting.
●
When numbers are displayed (e.g. title number), the numeric buttons can also be used for setting instead of
F
/
G
.
●
For some functions, the setting will be registered immediately; for others, SELECT/ENTER must be pressed.
setup repeat clear subtitle a - b audio program random angle
To clear the GUI Menu Icons, press DISPLAY again.
Examples of GUI Menu Icons.
(The screens may differ depending on the disc contents.)
0:16:57
1 ENG
D
6 CH
OFF
1
1
1
NORM.
(DVD GUI)
1
0:16:57
STER.
NORM.
(CD GUI)
1/9
CHAPT
A B
OFF
(DVD and CD GUI)
PAGE 26
OPERATION USING GUI MENU ICONS
Detailed description of each GUI menu icon
You can view information about a disc and its operational status on the TV screen.
Press DISPLAY during playback.
[TV screen] DVD GUI
1
FUNCTION
(Press
D
/
E
to select desired item)
To show the current title number
and to jump to the desired title number
1
0:16:57
1 ENG
D
6 CH
OFF
To show the current chapter number
and to jump to the desired chapter number
To show the elapsed time
and directly select scenes by the desired time.
To show the current audio soundtrack language, encoding method, channel number
and to change the settings.
1
NORM.
To show the current subtitles language
and to change the setting.
To show the current angle number
and to change the angle.
To show the current sound (NORMAL or 3D SURROUND)
and to change the setting.
Press DISPLAY during playback.
[TV screen] CD GUI
1
0:16:57
STER.
NORM.
FUNCTION
(Press
D
/
E
to select desired item)
To show the current track number
and to jump to the desired track number
To show the elapsed time.
(Display only)
To show the current audio (STEREO, LEFT, RIGHT)
and to select to the desired audio channel.
To show the current sound (NORMAL or 3D SURROUND)
and to change the setting.
❍
Note
Some DVD discs may not provide all of the above GUI menu icons.
SELECTION
METHOD
/
G
, or
Numeric
SELECT/ENTER
/
G
, or Numeric
SELECT/ENTER
SKIP
Numeric
SELECT/ENTER
/
G
,
AUDIO
/
G
,
SUBTITLE
/
G
,
ANGLE
/
G
,
SOUND
SELECTION
METHOD
/
G
, or Numeric
SELECT/ENTER
SKIP
/
G
,
AUDIO
/
G
,
SOUND
ADVANCED OPERATION PAGE 27
Using a title menu
Some movie discs may contain two or more titles. If the disc has a title menu recorded on it, the TITLE button can be used to select the movie title. (The details of operation differ depending on the disc used.)
● Selecting a title may not be possible on certain DVD discs.
1
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
2
1
Press TITLE.
A list of the titles on the disc is displayed.
Pressing TITLE again to resume play from the scene when TITLE was first pressed.
• Resume play may not be possible on certain discs.
2
Press
D
/
E
/
F
/
G
and press SELECT/ENTER or
PLAY, or press the numeric button(s), to select desired title.
setup repeat subtitle a - b audio program random angle
Using a DVD menu
Some DVDs have unique menu structures called
DVD menus. For example, DVDs programmed with complex contents provide guide menus, and those recorded with various languages provide menus for audio and subtitle language. Although the DVD menu’s contents and operation differ from disc to disc, the following explains the basic operation when this feature is used.
1
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
2
The selected title now starts playing.
1
Press MENU during play.
The DVD menu available on the disc is now displayed.
1
2
3
4
Pressing MENU again resumes play from the scene when MENU was first pressed.
• Resume play may not be possible on certain discs.
2
Press
D
/
E
/
F
/
G
and press SELECT/ENTER, or press the numeric button(s), to select desired item.
setup repeat subtitle a - b audio program random angle
The selected item is now executed.
PAGE 28
ADVANCED OPERATION
Changing subtitle language
It is possible to change the subtitle language to a different language from the one selected at the initial settings. (See page 37 for further info.)
This operation works only with discs on which multiple subtitle languages are recorded.
1, 2
setup repeat clear subtitle a - b audio program random angle
1
Press SUBTITLE during playback.
When no subtitles are recorded, “OFF” will be displayed instead of the language number.
OFF
❍
❍
❍
❍
Notes
In some cases, the subtitle language is not changed to the selected one immediately.
When a disc supporting the closed caption is played, the subtitle and the closed caption may overlap each other on the TV screen. In this case, turn the subtitle off.
When the desired language is not selected even after pressing the button several times, it means that the language is not available on the disc.
When the power is turned on or the disc is removed, subtitles appears in the language selected at the initial settings. If this language is not recorded on the disc, the disc’s priority language appears.
Changing audio soundtrack language
It is possible to change the audio soundtrack language
(or encoding method, channel number) to a different language from the one selected at the initial settings in case of DVD disc. (See page 37 for further info.) This operation works only with discs on which multiple audio soundtrack languages are recorded.
And it is possible to change the audio channel in case of audio CD.
2
Press SUBTITLE repeatedly until the desired language is selected.
Number of the subtitle language being played back is shown.
1 ENG
To eliminate the On Screen Subtitles.
Press SUBTITLE repeatedly to select OFF at step 2.
1, 2
setup repeat clear subtitle a - b audio program random angle
❍
❍
❍
Notes
When the desired language is not selected even after pressing the button several times, it means that the language is not available on the disc.
When the power is turned on or the disc is removed, the language heard is the one selected at the initial settings.
If this language is not recorded on the disc, only the available language on the disc will be heard.
Some discs may not respond to Audio feature.
• DVD
1
Press AUDIO during play.
Number of the audio soundtrack language being played back.
1 ENG
D
6 CH
2
Press AUDIO repeatedly until the desired language (or encoding method, channel number) is selected.
2 FRE
D
6 CH
• CD
1
Press AUDIO during play.
STER.
2
Press AUDIO repeatedly until the desired sound is selected.
LEFT
ADVANCED OPERATION PAGE 29
Viewing from another angle
Some DVDs may contain scenes which have been shot simultaneously from a number of different angles.
For these discs, the same scene can be viewed from each of these different angles using the ANGLE button. (The recorded angles differ depending on the disc used.)
1 2 3
1
Press ANGLE during playback.
Number of angle being played back.
1
2
Press ANGLE repeatedly until the desired angle is selected.
2
setup repeat clear subtitle a - b audio program random angle
1, 2
❍
•
•
For your reference
The ANGLE indicator will blink in the DVD display window at scenes recorded at different angles to indicate that angle switching is possible.
The angle number can be programmed beforehand; the angle will be switched to the selected number when the
ANGLE indicator blinks.
Note
This function only works for discs having scenes recorded at different angles.
Producing a 3D SURROUND effect
This unit can produce a 3D Surround effect, using 3D
Surround Sound technology, which simulates multi-channel audio playback from two conventional stereo speakers instead of the five or more speakers normally required to listen to multi-channel audio from a home theatre. This feature works with DVD discs encoded with
Dolby Pro Logic and Dolby Digital audio tracks.
1
Press SOUND during playback.
Each time this button is pressed, the TV screen display changes.
NORM.
2
Press SOUND repeatedly until the desired sound is selected.
3D SUR
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
1, 2
❍
❍
❍
Notes
This 3D Surround effect may not be available on some
DVD discs, such as those recorded with a mono audio soundtrack.
Turn off the TV surround sound and other surround effects when using this 3D surround effect.
For best 3D Surround effect using only two speakers it is recommended that the two speakers be positioned approximately 8’ to 10’ apart, and the listening position should be 8’ to 10’ away from the speakers.
setup repeat clear subtitle a - b audio program random angle
PAGE 30
ADVANCED OPERATION
Repeat Play
Repeating viewing (listening)
Press REPEAT during playback.
Each time this button is pressed, the TV screen changes as shown below and the disc will repeat a chapter or title (DVD) or a track (CD).
• DVD
Repeat of chapter being played
CHAPT
Repeating sections between two specific points (A-B repeat)
1
Press A-B during play at the point where repeat play is to start (A).
A *
• You can select “OFF” at this step by pressing
CLEAR.
Repeat of title being played
TITLE
2
Press A-B during play at the point where repeat play is to be concluded (B).
OFF
Cancel repeat mode
(normal play)
A B
• CD
Repeat of track being played
TRACK
Repeat play of the selection between points A and B starts.
Repeat of entire disc contents
ALL
To return to normal play
Press A-B once “OFF” is displayed.
OFF
OFF
Cancel repeat mode
(normal play)
To enjoy program repeat play (CD)
If REPEAT is pressed during program play, repeat play is operated as below.
Repeat of the current programmed track
TRACK
ALL
Repeat of all programs
❍
❍
❍
❍
Notes
Repeat play works only with discs for which the elapsed playing time appears in the DVD display window during playback.
Repeat play may not work correctly with some DVDs.
A-B repeat play works only within a title DVD or a track
CD.
Some subtitles recorded around point A or B may fail to appear (DVD).
OFF
Cancel repeat mode
(Program play)
To return to normal play
Press REPEAT several times until “OFF” is displayed.
1
2
ADVANCED OPERATION PAGE 31
Storing markers in memory to be viewed (listened to) again
Storing a MARKER in the DVD memory is similar to marking your page in a book. It allows you to quickly return to any point on the disc.
Storing a marker in the memory
1
Press MARKER during play at the starting point to be viewed (listened to) again.
1/9
4
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
3, 4
Indicates “1/9” is stored in the memory.
Up to 9 marks can be stored in the memory.
Recalling/Clearing a marker
2
Press SEARCH during playback.
The MARKER SEARCH menu will appear on the TV screen.
MARKER SEARCH
1 2 3 4 5 6 7 8 9
3
Press
F
/
G
to select the marker to be recalled/cleared.
4
Press SELECT/ENTER to recall a marker.
Or press CLEAR to clear a marker.
Play resumes from the point corresponding to the selected marker, or the selected marker is cleared.
Notes
❍
These operations work only with discs for which the elapsed playing time appears in the DVD display window during playback or stop.
❍
Some subtitles recorded around the marker may fail to appear
(DVD).
❍
All the markers are cleared when the power is turned off or the disc is removed.
❍
The marker is not stored when the DVD or title menu is displayed on the TV screen.
PAGE 32
ADVANCED OPERATION
Zoom Feature
The Zoom function allows you to enlarge the video image and to move through the enlarged image.
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
2
1
1
2
3
Press ZOOM during playback or still playback to activate the Zoom function.
If you further press ZOOM repeatedly, the magnification level increases (6 steps).
Press
D
/
E
/
F
/
G
buttons to move through the zoomed picture.
Press CLEAR to resume normal playback.
❍
❍
Notes
Some discs may not respond to the Zoom feature.
Zoom does not work on subtitles or menus included on
DVD video discs.
3
setup repeat clear subtitle a - b audio program random angle
Random Play
Note: This function only works with karaoke DVD and
Audio CD. Random does not work with DVD movie discs.
You can playback titles or tracks in random order.
(Random playback)
The DVD player automatically selects the titles on a
DVD video karaoke disc only and plays them back randomly.
1, 2
setup repeat clear subtitle a - b audio random program angle
Random play (Karaoke DVD or CD)
1
Press RANDOM during normal playback or stop mode.
The DVD player automatically starts random playback and the RANDOM indicator in the DVD display window appears.
2
To resume normal playback, press
RANDOM.
The RANDOM indicator in the DVD display window disappears.
❍
❍
Notes
Random playback may not be possible on certain discs.
If you press the SKIP or button during random playback, the DVD player goes to another track randomly and starts playback.
Program play
The player plays the tracks on the disc in the order you specify.
Note: Program play function is possible only with audio CDs. It does not work with DVD movie discs.
ADVANCED OPERATION PAGE 33
1
Press PROGRAM on the stop mode.
The program playback screen appears on the TV screen.
Program
Step 1
Total Time
0:00:00
3
power dvd vcr catv tv open / close display title menu return vol marker ch select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
2
1
2, 3
Clear All
• To exit the screen, press PROGRAM or RETURN.
2
Press
D
/
E
/
F
/
G
and press the numeric button(s), to select the desired track number.
Program
1 5 19
Step 8
Total Time
0:08:32
Clear All
• Repeat step 2 to select another track.
• Up to 20 tracks can be programmed.
3
Press PLAY to exit the screen.
The selected track is stored in the memory and play now begins in the programmed sequence.
After playback of all tracks programmed
Play is stopped.
Clearing the program
●
To clear the programmed tracks one by one
Press
D
/
E
/
F
/
G to select the unwanted number and then press CLEAR.
●
To clear all the programmed tracks
Press
D
/
E
/
F
/
G to select “Clear All” and then press
SELECT/ENTER. Press PROGRAM or RETURN to exit the screen. (The programs are also cleared when the power is turned off or the disc is removed.)
PAGE 34
ADVANCED OPERATION
Playback with MP3
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip
2
2
To play an MP3 file repeatedly
● If you press REPEAT once during play, the cur-
●
● rent MP3 file will play repeatedly.
If you press REPEAT twice during play, the all
MP3 files on the disc will play repeatedly.
If you press REPEAT three times, the repeat play will be cancelled.
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
Prog
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
REPEAT symbol
Progr
Notes
❍
The file name is only displayed in English.
❍
If there is an impossible code to display, it will be displayed underlined (_) instead of English.
❍
This unit can play up to 256 files per disc. A disc recorded with more than 256 files cannot be played.
❍
Disc format is compatible with ISO9660 only.
❍
If you record MP3 files using the software which cannot create a FILE SYSTEM, for example “Direct-CD” etc., it is impossible to playback MP3 files. We therefore recommend that you use “Easy-CD Creator”, which creates an ISO9660 file system.
❍
A single session disc requires MP3 files in the first track. If there is no MP3 file in the 1st track, it cannot playback MP3 files. If you wish to playback MP3 files, format all the data in the disc or use a new one.
❍
If there are already data files which are not MP3 files on the CD-R disc, please, do not use that disc; use a new one instead. However, if the disc is a CD-RW disc, this does not apply.
To play an MP3 file
1
Load an MP3 disc.
The MP3 menu is displayed and playback starts automatically.
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
Program
Clear All
2
Press
D
/
E
button to select the desired MP3 file and then press PLAY to start playback of the file.
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
Program
Clear All
•
•
•
•
For your reference
Press SKIP or SKIP to play the next file or previous file during playback.
Press DISPLAY to move to the next page.
Press PAUSE/STEP to enter the pause mode, press PLAY or
PAUSE/STEP again to return to normal playback.
Press STOP to stop the playback.
ADVANCED OPERATION PAGE 35
Playback with MP3 (Cont’d)
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle
4
5
2
3
To play an MP3 file repeatedly
● If you press REPEAT button once during play,
●
● the current MP3 file will play repeatedly.
If you press REPEAT button twice during play, the all MP3 files on the program list will play repeatedly.
If you press REPEAT button three times, the repeat play will be cancelled.
Program
TRACK 2.mp3
TRACK 7.mp3
TRACK 6.mp3
TRACK 9.mp3
Program
TRACK 2.mp3
TRACK 7.mp3
TRACK 6.mp3
TRACK 9.mp3
Clear All
REPEAT symbol
Clear All
To program play an MP3 file
1
Load an MP3 disc.
The MP3 menu is displayed and playback starts automatically.
2
Press STOP to stop playback.
3
Press PROGRAM to enter the Program Edition mode in the stop mode.
The
E
mark appears on the right of the word Program on the right side of MP3 menu.
Press RETURN to exit the Program Edition mode, the
E
mark will disappear.
4
Press
D
/
E
to select the desired MP3 file and then press SELECT/ENTER to add the MP3 file to the program list.
• Repeat steps 4 to select another track.
• Up to 60 files can be programmed.
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
Program
TRACK 2.mp3
TRACK 7.mp3
TRACK 6.mp3
TRACK 9.mp3
E
Clear All
5
Press PLAY to play.
The playback now begins in the programmed sequence.
MP3
MP3-1
TRACK 1.mp3
TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3
TRACK 9.mp3
Program
TRACK 2.mp3
TRACK 7.mp3
TRACK 6.mp3
TRACK 9.mp3
Clear All
Clearing the program
●
To clear the program one by one
In the Program Edition mode, press
D
/
E
/
F
/
G to select the unwanted MP3 file on the program list and then press CLEAR.
●
To clear all the programs
In the Program Edition mode, press
D
/
E
/
F
/
G to select the “Clear All” and press SELECT/ENTER.
If you want to enter the main menu, press
F button.
After playback all tracks programmed
Play is stopped.
PAGE 36
INITIAL SETTINGS
Selection of initial settings
Once the initial settings have been completed, the player can always be operated under the same conditions (especially with DVD discs).
The settings will be retained in the memory until they are changed, even if the power is switched off.
2, 3
1
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
Selection of initial settings
1
Press SETUP in the stop or playback mode.
The SETUP menu is displayed.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
Original
English
French
German
Spanish
Italian
Chinese
Polish
Hungarian
Russian
Other — — — —
2 Press
D
/
E
to select the desired item.
The screen will show the current setting for the selected item, and the alternate setting(s).
• Disc Audio (see page 37.)
• Disc Subtitle (see page 37.)
• Disc Menu (see page 37.)
• Rating (see page 38.)
• Password (see page 39.)
• TV Aspect (see page 40.)
• Menu Language (see page 41.)
• Progressive Scan (see page 42.)
• Digital Audio Output (see page 43.)
• Others (see page 44.)
3
Press
G
and then
D
/
E
to select the desired setting and press SELECT/ENTER.
•
Some items require additional steps. (See the respective page.)
When the alternate setting is selected the screen returns to the Initial Settings display.
To exit SETUP menu
Press SETUP, RETURN or PLAY.
INITIAL SETTINGS PAGE 37
Selecting disc languages
This is to select the audio soundtrack language, subtitle language and the language used in title menus or DVD menus which will always be used for every disc to be played back.
When you play back a DVD video disc, the DVD player automatically displays the pre-selected subtitle language if it is included on the disc.
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
1, 2
1 At the setup screen, press
D
/
E
“Disc Audio” and press
G
.
to select
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
Original
English
French
German
Spanish
Italian
Chinese
Polish
Hungarian
Russian
Other — — — —
2
Press
D
/
E
to select the desired language and then press SELECT/ENTER.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
Original
English
French
German
Spanish
Italian
Chinese
Polish
Hungarian
Russian
Other — — — —
Original :The original language of each disc will be selected.
English : The English will be Selected.
Other : Another language can be selected. You can input
4-digit language code. (Refer to the language codes on page 45. Press CLEAR if an incorrect language code is entered.)
The “Disc Subtitle” and “Disc Menu” are selected by the same method.
Note
❍
If the language selected is not available on the disc, the original language designated by each disc will be selected.
PAGE 38
INITIAL SETTINGS
Selecting rating level and password
This is to prohibit the playing of specified
DVDs which are unsuitable for children.
● Some DVD discs contain a restriction level which enables parents to remove scenes or prevent playback of discs by children. DVD players are equipped with a password designed to prevent children from changing the level.
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te
1, 2
Selecting rating level (DVD only)
1
At the SETUP screen, press
D
/
E
to select
“Rating” and press
G
.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
8
5
4
7
6
3
2
1
Unlock
pause/step skip play stop skip
2
Press
D
/
E
to select the desired level and press SELECT/ENTER.
Mini glossary
setup repeat l subtitle a - b audio program random angle
MOTION PICTURE ASSOCIATION OF
AMERICA (MPAA) RATING SYSTEM
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
6
5
8 Blocked
7 Blocked
4
3
2
1
Unlock
G (General Audiences) : Content not offensive to most viewers.
PG (Parental Guidance Suggested) : Content is such that parents may not want their children to view the program.
PG-13 (Parental Guidance Suggested) :
Program is inappropriate for preteens, with a greater degree of offensive material than a PG rated program.
R (Restricted viewing) : Not for children under age 17. Strong elements of sex and/or violence.
NC-17 (Restricted Viewing) : Not for children under age 17 under any circumstances. Strong sexual content.
X (Hard Core Films) : Same as NC-17 rating.
You cannot play DVD video discs rated higher than the level you selected unless you cancel the parental lock function.
For example, when you select level 7, discs rated higher than level 7 are blocked and cannot be played.
The parent lock level is equivalent to the following USA movie ratings.
Level 7: NC-17
Level 3: PG
Level 6: R
Level 1: G
Level 4: PG 13
• Some titles do not match with the rating level described as above.
Note
Zenith Electronics Corporation is not liable for any program content that appears when using this rating system; as always, user discretion is advised.
If you change the level and enter a password, playback of all
DVDs with ratings higher than your selection will be blocked, unless the correct password is entered again. For example: if you change the level to “5”, the DVD player will not play discs with ratings of “6”, “7” or “8” unless the correct password is entered on the remote control.
INITIAL SETTINGS PAGE 39
Selecting rating level and password (Cont’d)
power dvd vcr catv tv open / close
Setting your password (DVD only)
If you change the rating level to “7” or lower, you must enter a
4-digit “password” to prevent playback of discs with higher ratings.
1
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle
2, 3
2, 3
1
2
At the SETUP screen, press
E
to select
“Password” and press
G
.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
New
— — — —
Input a 4-digit password and press
SELECT/ENTER.
Example : 1234
Do not forget your password.
slow/scan rev fwd
3
Input the 4-digit password again and press
SELECT/ENTER to verify.
Setting is finished.
●
The rating is locked. Any disc whose rating is higher than the setting, cannot be played back unless the correct password is entered.
To clear your 4-digit password
If you forget your password, to clear the current password, follow the procedure below.
To change/clear memorized password
1
2
At the SETUP screen, press
E
to select
“Password” and press
G
.
Input your password and press
SELECT/ENTER.
Change
Clear
1
2
Press SETUP.
The SETUP menu is displayed.
Enter 6-digit number “210499” by pressing number buttons.
The 4-digit password is cleared. “P CLr” appears on the display.
3
Enter a new password.
Refer to “Setting your password” section on the right.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
3
To change or clear your password, press
D
/
E
to select the “Change” or “Clear” and press
SELECT/ENTER.
To change the rating level/password, follow the steps on page 38-39 again.
PAGE 40
INITIAL SETTINGS
Selecting TV Aspect
Select the appropriate screen type according to your TV set; conventional size screen (4:3) or wide-screen (16:9).
1, 2
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
4:3 Letterbox
Cut Off
1 At the SETUP screen, press
D
/
E
Aspect” and press
G
.
to select “TV
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
4:3 Letterbox
4:3 Panscan
16:9 Wide
2
Press
D
/
E
to select the desired Aspect and press SELECT/ENTER.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
4:3 Letterbox
4:3 Panscan
16:9 Wide
4:3 Letterbox : The video material not formatted in the Pan &
Scan style is played back in the letterbox style (black bands appear at top and bottom of screen).
4:3 Panscan : Select when a conventional TV set is connected. The video material formatted in the Pan & Scan style is played back in that style (the left and right edges are cut off).
16:9 Wide : Select when a wide-screen TV set is connected.
Played in “FULL” size. (Setting the wide-screen TV to “FULL” mode is also necessary.)
* Each screen shows an example when the video material for a wide-screen is played.
(This setting does not affect the video material for conventional size.)
4:3 Panscan
16:9 Wide
INITIAL SETTINGS PAGE 41
Selecting Menu Language
Selects language for SETUP menus and displays on the TV.
1 At the SETUP screen, press
D
/
E
to select
“Menu Language” and press
G
.
1, 2
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
English
Spanish
French
2
Press
D
/
E
to select the desired Language and press SELECT/ENTER.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
English
Spanish
French
PAGE 42
INITIAL SETTINGS
Selecting Progressive Scan
If your television is high-definition or “digital ready” television, you may take advantage of the DVD
Player’s progressive scan output for the highest video resolution possible. Make the component video connections as shown on page 14 or you may connect the component video jacks directly to the component video or HD component inputs on your TV or monitor. Once the connection is made, the progressive scan circuitry must be activated by changing the SETUP menu.
Note: The progressive scan capability is not operational with standard analog component video connections.
1 At the SETUP screen, press
D
/
E
“Progressive Scan” and press
G
.
to select
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
On
Off
2
Press
D
/
E
to select the desired Progressive mode (On or Off) and press SELECT/ENTER.
1, 2
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
On
Off
Off: If you are using the COMPONENT VIDEO OUT jacks, but are connecting the DVD player to a standard
(analog) television, set the Progressive mode to “Off”.
On: If you are using the COMPONENT VIDEO OUT jacks for connection to a TV that is compatible with a progressive scan signal, set the Progressive mode to
“On”.
❍
Notes
The Progressive function only works when VIDEO OUTPUT
SELECT switch on the rear panel is set to COMPONENT/
PROGRESSIVE SCAN.
Warning
Once the setting for progressive scan output is entered, an image will only be visible on a progressive scan compatible video display. If you change the setting to “On” in error, you must reset the unit by first pressing the STOP to stop any disc that is playing. Next, press the
STOP again and hold it for five seconds before releasing it. The video output will be restored to the standard setting, and a picture will once again be visible on a conventional analog display.
INITIAL SETTINGS PAGE 43
Selecting Digital Audio Output
Each DVD disc has a variety of audio output options. Set the player’s Digital Audio Output according to the type of audio system you use.
1, 2
power dvd vcr catv tv open / close
1
At the SETUP screen, press
D
/
E
to select
Digital Audio Output and press
G
.
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
DOLBY
DIGITAL
/PCM
Stream/PCM
PCM
Sample Freq.
48 KHz
96KHz
display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
Playback
Disc
Stream/PCM
OUTPUT
Dolby Digital/
PCM
PCM
96 kHz
Linear PCM
DVD
DTS DVD
Dolby Digital
DVD
MPEG DVD
Audio CD
DTS Audio CD
PCM
DTS bit Stream DTS bit Stream
Dolby Digital bit Stream
Dolby Digital bit Stream
MPEG bit Stream PCM
PCM
DTS bit Stream
PCM
DTS bit Stream
PCM only
PCM
DTS bit Stream
PCM
PCM
PCM
DTS bit Stream
2
Press
D
/
E
to select the desired output and press SELECT/ENTER.
You can select Digital Audio Output or Sampling
Frequency item by pressing SELECT/ENTER.
■
Digital Audio Output
DOLBY DIGITAL/PCM:
Select “DOLBY DIGITAL/PCM” if an active digital output is supplied to a Dolby Digital decoder,
(or an amplifier or other equipment with Dolby Digital decoder).
Stream/PCM:
Select “Stream/PCM” if an active digital output is supplied to an amplifier or other equipment with DTS decoder, Dolby Digital decoder and
MPEG decoder.
PCM:
Select “PCM” if an active digital output is supplied to an amplifier or other equipment with linear PCM only (or MD recorder or DAT deck).
■
Sampling Frequency
To change the Sample Frequency setting, first select the desired digital audio output type as indicated above.
If your A/V receiver or surround processor is NOT capable of handling 96kHz signals, select the 48kHz option. When this choice is made, this unit will automatically convert any 96kHz signals to a 48kHz output so that your system is capable of decoding them.
If your A/V receiver or surround processor is capable of handling 96kHz signals, select the 96kHz option. When this choice is made, this unit will pass each type of signal through without any further processing.
❍
❍
❍
Notes
When you are not using the player’s digital audio output, don’t select any of the options.
If an active digital audio output signal is supplied to a receiver or other equipment without a corresponding digital decoding capability, a very loud noise may be produced which could permanently damage the speakers.
The DTS DVD disc sound is played back only when the DVD player is connected to a receiver with a DTS decoder.
PAGE 44
INITIAL SETTINGS
Others
The DRC and Vocal settings can be changed.
1 At the SETUP screen, press
D
/
E
“Others” and press
G
.
to select
1, 2
power dvd vcr catv tv open / close display title menu return ch vol marker select / enter searc h ch zo om tv input vol sou nd /mu te
Disc Audio
Disc Subtitle
Disc Menu
Rating
Password
TV Aspect
Menu Language
Progressive Scan
Digital Audio Output
5.1 Speaker Setup
Others
DRC Off
Vocal On
skip pause/step play stop skip setup repeat clear subtitle a - b audio program random angle rev slow/scan fwd
2
Press
D
/
E
to select the desired items and press SELECT/ENTER.
The setting of the selected item are changed between
On and Off.
■
DRC (Dynamic Range Compression) On/Off
On: Select this option to turn on the Dynamic Range
Compression circuitry so that the dialogue remains clear even at low volume levels.
Off: Select this option to turn off the Dynamic Range
Compression and have the soundtrack presented exactly as it was created.
■
Vocal On/Off
Set to On only when a multi-channel karaoke DVD is being played. The karaoke channels on the disc will then be mixed into a normal stereo sound.
About DRC (Dynamic Range Compression)
With the DVD format you have the opportunity to hear a program’s soundtrack in the most accurate and realistic presentation possible, thanks to the use of digital audio technology. However, in certain instances you may wish to slightly compress the dynamic range of the audio output
(the difference between the loudest sounds and the quietest ones) so that you may listen to a movie at a lower volume without losing dialogue intelligibility.
Notes
❍
The DRC function works only during playback of Dolby Digital recorded discs.
❍
The level of Dynamic Range Compression may differ depending on the DVD disc.
❍
When playing karaoke, connect appropriate audio equipment
(such as an amplifier) to the DVD video player.
INITIAL SETTINGS PAGE 45
Table of Language and Their Abbreviations
Enter the appropriate code number for the initial settings “Audio”, “Subtitle” and/or “Menu” (See page 37).
6765 Catalan
6779 Corsican
6783 Czech
6789 Welsh
6865 Danish
6869 German
6890 Bhutani
6976 Greek
6978 English
6979 Esperanto
6983 Spanish
6984 Estonian
6985 Basque
7065 Persian
7073 Finnish
7074 Fiji
Code
6565 Afar
Language
6566 Abkhazian
6570 Afrikaans
6577 Ameharic
6582 Arabic
6583 Assamese
6588 Aymara
6590 Azerbaijani
6665 Bashkir
6669 Byelorussian
6671 Bulgarian
6672 Bihari
6678 Bengali; Bangla
6679 Tibetan
6682 Breton
Code Language
7079 Faroese
7082 French
7089 Frisian
7165 Irish
7168 Scots Gaelic
7176 Galician
7178 Guarani
7185 Gujarati
7265 Hausa
7273 Hindi
7282 Croatian
7285 Hungarian
7289 Armenian
7365 Interlingua
7378 Indonesian
7383 Icelandic
7384 Italian
7387 Hebrew
7465 Japanese
7473 Yiddish
7487 Javanese
7565 Georgian
7575 Kazakh
7576 Greenlandic
7577 Cambodian
7578 Kannada
7579 Korean
7583 Kashmiri
7585 Kurdish
7589 Kirghiz
7665 Latin
Code Language
7678 Lingala
7679 Laothian
7684 Lithuanian
7686 Latvian, Lettish
7771 Malagasy
7773 Maori
7775 Macedonian
7776 Malayalam
7778 Mongolian
7779 Moldavian
7782 Marathi
7783 Malay
7784 Maltese
7789 Burmese
7865 Nauru
7869 Nepali
7876 Dutch
7879 Norwegian
7982 Oriya
8065 Panjabi
8076 Polish
8083 Pashto, Pushto
8084 Portuguese
8185 Quechua
8277 Rhaeto-Romance
8279 Rumanian
8285 Russian
8365 Sanskrit
8368 Sindhi
8372 Serbo-Croatian
8373 Singhalese
Code Language
8375 Slovak
8376 Slovenian
8377 Samoan
8378 Shona
8379 Somali
8381 Albanian
8382 Serbian
8385 Sundanese
8386 Swedish
8387 Swahili
8465 Tamil
8469 Telugu
8471 Tajik
8472 Thai
8473 Tigrinya
8475 Turkmen
8476 Tagalog
8479 Tonga
8482 Turkish
8484 Tatar
8487 Twi
8575 Ukrainian
8582 Urdu
8590 Uzbek
8673 Vietnamese
8679 Volapük
8779 Wolof
8872 Xhosa
8979 Yoruba
9072 Chinese
9085 Zulu
PAGE 46
REFERENCE
Disc Requirements/Copyright Information
Playable Discs
This DVD player can play back the following discs.
Disc mark Contents
DVD video discs
Audio CDs
Audio+Video
(moving pictures)
Audio
Disc size
12 cm
8 cm
12 cm
8 cm
Maximum playback time
Approx. 4 hours (single sided disc)
Approx. 8 hours (double sided disc)
Approx. 80 minutes (single sided disc)
Approx. 160 minutes (double sided disc)
74 minutes
20 minutes
In addition, this unit can play back a CD-R or CD-RW that contains audio titles or MP3 files. And this unit can play back a HDCD also.
You cannot playback discs other than those listed above. (Video CD, CD-ROM, CD-Extra, CD-G, photo CD, and CDi discs can not be played on this DVD player.)
, HDCD ® , High Definition Compatible Digital ® and Pacific Microsonics™ are either registered trademarks or trademarks of Pacific Microsonics, Inc., in the United States and/or other countries. HDCD system manufactured under license from Pacific Microsonics, Inc. This product is covered by one or more of the following: In the USA:
5,479,168; 5,638,074; 5,640,161; 5,808,574; 5,838,274; 5,854,600; 5,864,311; 5,872,531; and in Australia: 669114.
Other patents pending.
Region Management Information
Region Management Information: This DVD Player is designed and manufactured to respond to the Region
Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that disc.
1
The Region number of this DVD player is 1.
Notes on Unauthorized Discs
You may not be able to play back some DVD video discs on this player if they were purchased from outside your geographic area or made for business purposes.
When you try to play back an unauthorized disc, “Check Regional Code” appears on the TV screen.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material without permission.
DVD video discs are copy protected, and any recordings made from these discs will be distorted.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
REFERENCE PAGE 47
Before Calling Service Personnel
Symptoms and Correction
Check the following guide for the possible cause of a problem before contacting service.
Symptom
No power.
The power is on, but the DVD player does not work.
No picture.
No sound.
The playback picture is poor.
The DVD player does not start playback.
output.
Cause
• The power cord is disconnected.
• No disc is inserted.
• The TV is not set to receive DVD signal
• The video cable is not connected securely.
• The connected TV power is turned off.
• The equipment connected with the audio cable is not set to receive DVD signal output.
• The audio cables are not connected securely.
• The power of the equipment connected with the audio cable is turned off.
• The Digital Audio Output is set to the wrong position.
• The disc is dirty.
• No disc is inserted.
• An unplayable disc is inserted.
• The disc is placed upside down.
• The disc is not placed within the guide.
• The disc is dirty.
• A menu is on the TV screen.
• The Rating level is set.
The remote control does not work properly.
• The remote control is not pointed at the remote sensor of the DVD player.
• The remote control is too far from the
DVD player.
• There is an obstacle in the path of the remote control and the DVD player.
• The batteries in the remote control are exhausted.
Correction
• Plug the power cord into the wall outlet securely.
• Insert a disc. (Check that the DVD or, audio CD indicator in the DVD display is lit.)
• Select the appropriate video input mode on the TV so the picture from the DVD player appears on the TV screen.
• Connect the video cable into the jacks securely.
• Turn on the TV.
• Select the correct input mode of the audio receiver so you can listen to the sound from the DVD player.
• Connect the audio cable into the jacks securely.
• Turn on the equipment connected with the audio cable.
• Set the Digital Audio Output to the correct position, then turn on the DVD player again by pressing the POWER button.
• Clean the disc.
• Insert a disc. (Check that the DVD, or audio CD indicator in the DVD display is lit.)
• Insert a playable disc. (Check the disc type, color system and Regional code.)
• Place the disc with the playback side down.
• Place the disc on the disc tray correctly inside the guide.
• Clean the disc.
• Press the SETUP button to turn off the menu screen.
• Cancel the Rating function or change the rating level.
• Point the remote control at the remote sensor of the DVD player.
• Operate the remote control within about
23 ft (7 m).
• Remove the obstacle.
• Replace the batteries with new ones.
PAGE 48
REFERENCE
Specifications
DVD player/Outputs/Supplied Accessories
Power supply
Power consumption
Weight
External dimensions (W X H X D)
Signal system
Laser
Frequency range (audio)
Signal-to-noise ratio (audio)
Dynamic range (audio)
Harmonic distortion (audio)
Wow and flutter
Operating conditions
Video output
S-video output
Component video output
Audio output (digital audio)
Audio output (analog audio)
AC 120V, 60 Hz
16 W
6.6 lbs (3.0 kg)
17” X 3.5” X 9.7” (430 x 88 x 247 mm)
NTSC
Semiconductor laser, wavelength 650 nm (DVD), 780 nm (CD)
4 Hz to 20 kHz
More than 100 dB (EIAJ)
More than 90 dB (EIAJ)
0.008 %
Below measurable level (less than + 0.001 % (W.PEAK)) (EIAJ)
Temperature: 41°F to 95°F, Operation status: Horizontal
1.0 V (p-p), 75
Ω
, negative sync., RCA jack x 1
(Y) 1.0 V (p-p), 75
Ω
, negative sync., Mini DIN 4-pin x 1
(C) 0.286 V (p-p), 75
Ω
(Y) 1.0 V (p-p), 75
Ω
, negative sync., RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75
Ω
0.5 V (p-p), 75
Ω
, RCA jack x 1
2.0 Vrms(1 KHz, 0 dB), 330
Ω
, RCA jack (L, R) x 2
●
S-Video cable.............................................................................................1
●
Video cable ................................................................................................1
●
Audio cable ................................................................................................1
●
Remote control...........................................................................................1
●
Batteries .....................................................................................................2
❋
Designs and specifications are subject to change without notice.
PAGE 50
NOTES
NOTES
NOTES
NOTES PAGE 51
Your Zenith Limited Warranty
DVD PLAYER
Welcome into the Zenith family! We believe that you will be pleased with your new Zenith Entertainment Machine. Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state within the U.S.A.
ZENITH’S RESPONSIBILITY
Service Labor
During a period of 90 days from effective warranty date, Zenith will provide service labor by a Zenith authorized service center when needed as determined by Zenith, as a result of manufacturing defects.
Parts
Not Covered
New or remanufactured replacements for factory-defective parts will be supplied by a Zenith authorized service center for one year from effective warranty date . Such replacement parts are warranted for the remaining portion of the original warranty period.
This warranty covers manufacturing defects and does not cover installation, adjustment of customer controls in the home, installation or repair of home antenna systems, cable converters or cable company-supplied equipment; it also does not cover damage due to misuse, abuse, negligence, acts of God or other causes beyond the control of Zenith. Any alteration of the product after manufacture voids this warranty in its entirety.
OWNER’S RESPONSIBILITY
Effective Warranty Date
Warranty begins on the date of original consumer purchase. For your convenience, keep the dealer’s dated bill of sale or a delivery ticket as evidence of the purchase date.
Operating Guide
Carry-In Service
TV Set Performance
Important
Read your Operating Guide carefully so that you will understand the operation of your DVD Player and how to adjust the customer controls.
The video product must be taken to a U.S. or Canadian Zenith authorized service center for warranty service and must be picked up by the owner.
It is the owner’s responsibility to maintain the TV receiver with which the video product is used, and the associated antenna system, in proper operating condition.
Product Registration—Please fill out and mail your Product Registration Card. It is imperative that Zenith know how to reach you promptly if we should discover a safety problem that could affect you.
Warranty Service
For warranty service information, contact any Zenith authorized service center. Parts and service labor that are Zenith’s responsibility (see above) will be provided without charge. Other service is at the owner’s expense. If you have any problem in obtaining satisfactory warranty service, call or write the Zenith Response Center. You must provide the model number, serial number and date of purchase or date of original installation. Before you ask for warranty service, read “Before calling service personnel” in your operating guide. You might avoid a service call.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ZENITH SHALL NOT BE LIABLE FOR
ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES OR PROFITS IN
CONNECTION WITH THE PRODUCT.
Customer Service
Zenith National Response Center
201 James Record Road, Building #3
Huntsville, AL 35824
Phone: (256) 772-1515
Fax: (256) 774-4070 email: [email protected]
ZENITH ELECTRONICS CORPORATION
2000 MILLBROOK DRIVE
LINCOLNSHIRE, IL 60069
Zenith Part No. 206-03703
GS# 3835RS0018R
Printed in China
Issue O
