Training Your Puppy Unit
®
A Guide to Installing and Using Your Sony FIU-900
Fingerprint Identity Token with I/O Software’s
®
SecureSuite XS Workstation Software
Page 2
Training Your Puppy Unit
Sony Media & Application Solutions
1 Sony Drive
Park Ridge, NJ 07656
©2003 Sony Electronics Inc. All rights reserved. Features and specifications are subject to change without notice. Sony,
Memory Stick, Puppy, and the Puppy logo are trademarks of Sony. SecureSuite XS, SecureLogon, SecureLaunch, SecureFolder,
and SecureSession are products and trademarks of I/O Software, Inc. Microsoft and Windows are registered trademarks of
Microsoft Corporation. Adobe and Acrobat are trademarks of Adobe, Inc. Other trademarks are property of their respective
owners.
This product may have a possibility (of less than 0.1% according to our measurements) of granting access to persons other than
those who have registered their fingerprints. In no event shall our corporation or our representatives be liable for any incidental,
consequential, or special loss arising from granting an access to persons from other than those who have registered their
fingerprints. In no event shall our corporation or our representatives be liable for any incidental, consequential or special loss
arising from any use, defect, malfunction, or fault of this product.
When sending the fingerprint data via a communication line or storing such data in a computer, sufficient security control is
required to avoid abuse of the data.
Training Your Puppy Unit
Page 3
Introduction
Thanks for purchasing (shall we say adopting?) a Sony Puppy® fingerprint identity token. We
think you’ll find it to be easy-to-use and a convenient tool in your day-to-day interactions with
your computer. Just think…you won’t need to worry about passwords any more! And you can
be assured that your fingerprints are protected, as they are being matched and processed on the
fingerprint unit sitting on your desk.
This handy guide will assist you in setting up, using, and maintaining your Puppy unit to obtain
the best results. Note that this guide is set up in several sections:
•
•
•
•
•
•
•
•
Section 1: You and Your Puppy Fingerprint Identity Token provides general advice for
using the Puppy unit, including connection and finger placement.
Section 2: Installing the Software is a step-by-step walkthrough for SecureSuite® XS
Workstation installation.
Section 3: Enrolling Your Fingerprints on the Puppy Device discusses the registration of
your fingerprints, as well as specific usage, settings, and troubleshooting for the Puppy
unit.
Section 4: Using SecureSuite XS Workstation shows you how to easily logon to your PC,
replace your passwords, and control access to your PC and applications.
Section 5: Uninstalling the Puppy Device and SecureSuite XS Workstation Software
describes how to remove the software and hardware from your PC.
Section 6: Release Notes covers specific limitations or issues imposed by the Puppy
device and associated software.
Section 7: Frequently Asked Questions (FAQ) lists a number of common questions and
answers regarding installation and use of the FIU-900 device and SecureSuite XS
Workstation software.
Section 8: Who to Contact? provides contact information and websites for additional
information, technical support, and software updates.
Throughout this guide, you will see text and headings in blue. This indicates an important notice
that you will need to pay special attention to.
For specific questions regarding advanced settings and configuration of the SecureSuite XS
Workstation software package, please be sure to refer to the SecureSuite XS Workstation
Guide on the enclosed CD.*
*
This guide and the SecureSuite XS Workstation Guide are provided in Adobe® Acrobat® format on the CD. If
you do not already have the Adobe Acrobat® Reader® application installed, you can download the free Acrobat
Reader at www.adobe.com.
Page 4
Training Your Puppy Unit
Section 1: You and Your Puppy® Fingerprint Identity Token
If you follow some general guidelines, you will be quite happy with the performance and
capabilities of your Puppy unit.
The Unit
Following in the footsteps of the award-winning FIU-710
fingerprint identity token, Sony’s new FIU-900 product
includes all the innovative features of its predecessor in an
exciting Memory Stick™ media form factor. Just like the
FIU-710 product, the new FIU-900 fingerprint unit scans,
matches, and stores fingerprints internally, completely
independent of a PC or network server. The FIU-900
device also features a number of enhancements over the
FIU-710 model, including a 128 x 128-pixel fingerprint sensor, improved verification accuracy
of fingerprints (even when deformed by pressure on the reading element or scratched), and a
faster verification speed.
The FIU-900 was designed specifically for use with the new
MSAC-US20 Memory Stick USB reader/writer or MSACUS70 Memory Stick USB reader/writer mouse (both shown
at left), and will not work with other Memory Stick slots,
such as those on Sony VAIO™ PCs or Clie® PDAs.
The fingerprint sensor is the silver/gold square on one end of the
unit. The Puppy device offers robust fingerprint imaging
technology based on a technique known as capacitance, which
digitally reads the fingerprint without leaving ink residue on
your finger. Capacitance sensors cannot be fooled by paper
copies and do not require cleaning.
Connections
Sony’s Memory Stick media adapters connect to your
Windows® 2000/XP operating system-equipped PC with a USB
connector. During installation of the adapter, connect it
directly to your PC’s USB port. The Puppy units will not be
recognized if connected to a USB hub, and your PC may
become unstable.
A USB extension cord is perfectly acceptable for use.
Training Your Puppy Unit
Page 5
Please follow the instructions provided with your Memory Stick™ adapter to insert and
remove your FIU-900 unit correctly. So that you can use other Memory Stick media, and
retrieve files, pictures, or music, you may remove the actual FIU-900 fingerprint identity token at
any time, though we recommend that you do not unplug it when it is required for a fingerprint
check: you could cause an error. If this occurs, simply re-insert the device and provide your
fingerprint as requested. Never remove your Puppy® unit during fingerprint enrollment.
Fingerprints
Puppy units use highly robust sensing technology to take
images of your fingerprints. However, there are instances
where the units may have some difficulty reading your
fingerprint. Here are some things you can do to avoid this
situation!
1. The Puppy unit reads the patterns of ridges and
valleys on the portion of your finger between the
tip and the first bend in your finger. Do not
simply put the tip of your finger on the sensor and
hope for the unit to detect it! And don’t turn your
finger to the right or the left, or place it upside
down… use the finger guide on the adapter to
judge correct finger placement. Move or slide the
cover up first, and then place your finger flat and comfortably resting entirely on
the sensor surface, so that it touches the metal plate around the sensor itself. Your
finger should fit within the finger guide on the adapter. See the images on this page
for reference.
2. Be comfortable! Don’t try to use a finger that causes your hand to be at an
uncomfortable angle to your desktop. Enroll and use the finger that’s most convenient
and most comfortable.
3. Always be sure to register at least two fingers when setting up a user. This way, if
you’ve hurt your finger and have a bandage on it, you still have a ‘backup’ finger.
4. During enrollment (registration), do
your best to provide consistent finger
placement: THIS IS CRITICAL. Good
enrollment enables the unit to provide the
best matching possible during your daily
use of the device, and thus this process is
one of the most important steps in setting
up your Puppy unit. Don’t rush it!
5. If you typically have dry skin, the Puppy
unit may have difficulty reading your
finger. Try touching your finger to your
forehead or the side of your nose and then
placing your finger on the unit. The oils
Page 6
Training Your Puppy Unit
will help the sensor to correctly read the ridges and valleys of your fingerprint.
6. If you typically have very moist skin or tend to perspire a lot, the Puppy® unit may have
difficulty reading your finger. Try rubbing your finger on your slacks or sleeve and then
place your finger on the unit.
Training Your Puppy Unit
Page 7
Section 2: Installing the Software
Minimum System Requirements for I/O Software’s SecureSuite® XS Workstation
Authentication Software
•
•
•
•
•
•
•
Microsoft® Windows® 2000 SP1 or
Microsoft Windows XP Home Edition or Professional operating system
Pentium® III-450 processor or equivalent
128 MB RAM
30 MB of free hard disk space
Communication protocol, i.e. TCP/IP installed
Microsoft Internet Explorer 4.x
Installation
IMPORTANT: You must be an administrator or have administrative rights on your
computer in order to install the SecureSuite XS Workstation software.
IMPORTANT: If you logon to a domain and are a domain user, SecureSuite XS
Workstation will not allow you to logon using the Puppy® device without SecureSuite XS
Server present on the domain (you can still logon with a password). In order to use this
software, you will need to have a local machine account.
IMPORTANT: Prior to running the installer, please verify that you have at least one network
client installed on the target system. If you are able to access the Internet or a network, you have
a network client. This can be verified by viewing the properties of any available connection in
Network Neighborhood or My Network Places by right-clicking the connection icon and
selecting Properties. You should see Client for Microsoft Networks (or something similar).*
Before installing SecureSuite XS Workstation, close all applications and turn off your virus
scanning and detection software.
1. Complete the installation process for your Memory Stick™ media adapter (MSACUS20 or MSAC-US70) according to the directions included with those devices. Do
not insert the FIU-900 Puppy unit until prompted in Step 5.
2. Insert the SecureSuite XS Workstation CD into your CD-ROM drive. Wait for the
installation to start automatically.
3. If the software does not auto-initiate:
• Select Start from the taskbar and then click Run.
*
If the Client is not present, click the Install or Add button, then select Client and press OK. The list of available
clients will then be available. We highly recommend that you select Client for Microsoft Networks. If no
connection is available or established, please contact Sony or your administrator.
Page 8
Training Your Puppy Unit
•
Type D:\Setup.exe (where D is the drive letter for your CD-ROM drive or other
source media) and follow the onscreen instructions to begin the installation
process.
4. Follow the onscreen prompts. When the installation program asks for your Product
License Key, enter the code printed on the label attached to the CD envelope.
5. Insert your FIU-900 Puppy® unit when prompted to do so. If you are installing this
product on Windows® XP, you
may encounter warnings during the
installation of the SCAPI software
as well as the FIU-900 hardware
(see dialog boxes to the right);
simply click Continue Anyway
when you see these dialogs.
6. Restart your computer when
prompted. Note that it may take
several minutes at this first restart
for the software to finish the
installation process. Your screen
may look blank, though your mouse
cursor will be able to move. Do not
shut off your computer. Please
wait for the logon prompt to
appear.
You will enroll your fingerprints after restart;
please read Section 3 for more details.
Training Your Puppy Unit
Page 9
Section 3: Enrolling Your Fingerprints on the Puppy® Device
SecureSuite® XS Workstation and the FIU-900 Puppy Unit
The FIU-900 fingerprint identity token scans, stores, and matches fingerprints on-board the
device. This means that the Puppy unit is tied to the users that are enrolled within it. Each FIU900 device can hold a limited number of fingerprints (a family or small workgroup, for
example), or alternatively, each device can be assigned to an individual user. You can transport
the unit between SecureSuite XS Workstation-enabled client PCs in a client/server environment
only. For more on this, please refer to the SecureSuite XS Server Guide and documentation.
First-time Enrollment
IMPORTANT: Only five distinct users can use their fingerprints to access the PC. These
fingerprint users can enroll as many fingerprints as they wish. However, other users on the PC
will need to use a password-only logon.*
When you are setting up a new user, you must enter a password for the user, even if the
user will not use the password method, as Windows® interprets this user account as not
requiring security. If you are working with an existing user, you will probably already have a
password, and will not need to enter a new one.
Also, when creating a new user, be sure not to set ‘Need to Change Password at Next
Logon’ and then choose only fingerprint authentication for that user (no password). This
will cause an error and may result in Windows becoming inoperable. Set the former command
first, and then, once the new password is set, make the user a fingerprint-only user (see step 9
below).
To enroll a user with the FIU-900 fingerprint identity token:
1. On your first restart after installing SecureSuiteXS Workstation, depending on your
operating system, you will see the following:
*
Additional user licenses are available. Contact Sony for more details.
Page 10
Training Your Puppy Unit
•
If you are an administrator, you will see a dialog box containing a Manage Users tab.
You can click on the Manage Users button, or from the Start menu, select Programs,
SecureSuite, and click SecureSuite User Manager, or right-click SecureSuite icon on the
system tray and click SecureSuite User Manager. Start with Step 2.
•
If you are not an administrator, you will see a dialog box containing a My
SecureSuite Settings tab. You can click on this button, or from the Start menu,
select Programs, SecureSuite, and click My SecureSuite Settings, or right-click
SecureSuite icon on the system tray and click My SecureSuite Settings. Go to Step 3.
•
If you are running a Windows® XP Home Edition system, you will be prompted with
an Auto-Enroll dialog box, asking if you would like to add a new method. Click OK,
and then follow the directions below in Step 3.
Training Your Puppy Unit
Page 11
2. Select the user account to which you
wish to assign the fingerprint
authentication method. If you are
working on a Windows® 2000 or
XP Professional system, select
Properties from the Action menu. For
Windows XP Home systems, select
Properties from the User menu.
3. If you are a SecureSuite® XS Workstation system administrator, type your username and
password when the SecureSuite Authentication dialog appears. If you’re not the
administrator, simply enter your username and password. The Properties dialog appears.
Page 12
Training Your Puppy Unit
4. Select the Authentication Methods tab and
click the Add button. The Add Authentication
Device dialog appears.
5. Select your FIU-900 fingerprint device
from the Available Methods and Devices list.
Note that the number in parentheses should
match the serial number on the bottom of
your unit. Click OK.
6. When the Fingerprint Enrollment Wizard
appears, click Next. Select a fingerprint to
enroll by clicking its image with your
mouse, and click Next.
7. Scan your fingerprint four
default number). The first
enroll your fingerprint, and
verifies that the fingerprints
match for later use in the
process. Click Next.
Training Your Puppy Unit
times (the
three times
the fourth
sufficiently
verification
Page 13
8. At this point we recommend you click
Next, to enroll another finger. Repeat
steps 6-7.
9. Click Finish.
The Properties dialog
appears.
• Use the Add button to add an
additional
method
of
authentication.
• Use the Remove button to delete
an
enrolled
method
of
authentication.
10. If more than one method has been added, a
method priority icon will appear between each
pair of devices in the Current Methods and
Devices list view in the Authentication Methods
tab of this user’s Properties dialog. This icon
specifies the relationship between this user’s
authentication devices. Right-click this icon to
choose one of the two following relationships:
• Select AND to require the user to
authenticate with all enrolled methods
of verification.
• Select OR to allow the user to choose
any one method of verification each
time they authenticate.
If you choose AND, note that this will by default randomize your password. If
SecureSuite® XS Workstation software is uninstalled, your password will need to be reset
by an administrator. This setting can only be changed within SecureSuite System Settings
(see image below) by an administrator.
Page 14
Training Your Puppy Unit
11. To specify a method that the user will
be prompted to use first when
authenticating, select the method and
use the green method priority arrows on
the right side of the Authentication
Methods tab of the Properties dialog to
move the desired method to the top of
the list. This does not force the user to
use this authentication method or
prevent them from using other methods.
12. Click OK when finished.
Training Your Puppy Unit
Page 15
Section 4: Using SecureSuite® XS Workstation
This section provides you with the basic tools needed to use your Puppy® device with I/O
Software’s SecureSuite XS Workstation software to logon to your PC, replace passwords in
applications and Microsoft Internet Explorer, and secure your files from prying eyes. Advanced
settings and configuration instructions are explained in the SecureSuite XS Workstation Guide
on the enclosed CD.
Important: If you are concerned about losing your passwords in the event your computer
or hard drive crashes, it might be a good idea to keep a copy of your passwords in a secure
location.
SecureLogon™
Enhances the standard logon procedure for Windows® operating systems. Provide your
credentials (e.g. password, fingerprint) when prompted at logon. Assuming you have enrolled
correctly on the device following the steps in Section 3, you can log off and log back in with
your fingerprint! This application also can lock your computer after a set amount of time or
during the screensaver. Just be sure to set your screensaver to Password protected.
SecureSession® for Applications
Stores passwords and other text based information for Windows
applications and enters them when required. After entering the text
click on the SecureSession for Applications system tray icon (circled) to register the dialog and
follow the prompts.
SecureSession™ for Internet Explorer
Stores authentication information for web sites and enters it for you. Once you identify yourself
to the Puppy device, the software will automatically send your username and password, for
example, to the web site. The SecureSession Logon Helper dialog will automatically appear
when you initially submit the information for a web
form, such as a username and password. Register the
information and the Logon helper dialog will
prompt you to identify yourself to submit the
information with each subsequent visit to the
registered web form. You can also click on the
SecureSuite icon in the toolbar to access the
SecureSession application.
Page 16
Training Your Puppy Unit
SecureFolder®
Secures single files and folders.* With a simple right-click on a folder you
get the option to Secure or Unsecure it, allowing only the authenticated
user to view its contents. To work with single files just "drag and drop" the
files out of and back into a secured folder.
The first time you secure a file, you will be prompted to enter an
Emergency Recovery Passphrase. This option allows you to type a
password that can be used to access your encrypted file in the event the
SecureFolder application is uninstalled or your user account is deleted. If
you choose not to enter a password, you will have no recourse if the SecureFolder application is
uninstalled, and you will lose your encrypted files and folders. More details on this can be found
in Chapter 10 of the SecureSuite XS Workstation Guide on the enclosed CD.
SecureLaunch™
Prevents unauthorized users from running Windows® applications. Lock applications that don’t
typically have security associated with them.
From the Start menu, select Programs, SecureSuite, and click SecureSuite System Settings, or rightclick SecureSuite icon on the system tray and click SecureSuite System Settings. Select the
Applications in the left pane, then SecureLaunch. Click Add, and browse for the appropriate
executable (.exe) file. You must have administrative rights to access this feature.
*
You cannot secure files or folders in the Windows or Program Files directories, as well as certain system
configuration files, since modifying their contents can cause your programs to stop working correctly.
Training Your Puppy Unit
Page 17
Section 5: Uninstalling the Puppy® Device and SecureSuite® XS
Workstation Software
Important: You must be logged in as an Administrator to uninstall the software.
Important: Unsecure any secured folders before you uninstall SecureSuite® XS
Workstation; otherwise the data is permanently lost.
Important: Please turn off your screensaver or computer lock timer before uninstalling
SecureSuite XS Workstation. If the screensaver activates during uninstallation, you may
not be able to recover your computer.
There are two procedures for uninstalling the SecureSuite XS Workstation software and FIU-900
Puppy® fingerprint identity token. The first is a simple, software-only procedure, while the
second allows you to reset your FIU-900 unit to erase any remaining SecureSuite XS
Workstation-related data on the device. This latter option is useful if the Puppy device will be
used on a separate, new user’s computer.
Procedure #1
1. Logon as a user with Administrator privileges.
2. Click Start from the taskbar, select Settings, click on Control Panel, and double-click
the Add/Remove Programs icon.
3. Select SecureSuite XS Workstation from the list of installed programs.
4. Windows® 2000: Click the Change/Remove button. Windows XP: Click the Remove
button.
5. Windows 2000: Select the Remove option from the installation options provided. Click
Next and Finish until prompted to restart your computer. Windows XP: Click Yes when
asked if you would like to uninstall SecureSuite XS Workstation.
6. Restart your computer when prompted.
7. If you are not using any other software applications with the FIU-900 unit, you may
proceed with steps 8-13. If you will still be using the Puppy device for another
application, stop here.
8. Click Start from the taskbar, select Settings, click on Control Panel, and double-click
the Add/Remove Programs icon.
9. Select Puppy (FIU-710/900) API from the list of installed programs.
10. Windows® 2000: Click the Change/Remove button. Windows XP: Click the Remove
button.
11. Windows 2000: Select the Remove option from the installation options provided. Click
Next and Finish until prompted to restart your computer. Windows XP: Click Yes when
asked if you would like to uninstall Puppy (FIU-710/900) API.
12. You will be asked to delete some shared file(s). You may delete these files.
13. Restart your computer.
Page 18
Training Your Puppy Unit
Procedure #2
1. Logon as a user with Administrator privileges.
2. Open SecureSuite System Settings by right-clicking on the SecureSuite icon in the
system tray.
3. Click on Authentication Methods in the left pane, and then in the BioToken category,
right-click on FIU-900.
4. Choose Properties from the right-click menu.
5. Click Reset Device in the dialog box that appears.
6. Close SecureSuite System Settings.
7. Click Start from the taskbar, select Settings, click on Control Panel, and double-click
the Add/Remove Programs icon.
8. Select SecureSuite XS Workstation from the list of installed programs.
9. Windows® 2000: Click the Change/Remove button. Windows XP: Click the Remove
button.
10. Windows 2000: Select the Remove option from the installation options provided. Click
Next and Finish until prompted to restart your computer. Windows XP: Click Yes when
asked if you would like to uninstall SecureSuite XS Workstation.
11. Restart your computer when prompted.
12. If you are not using any other software applications with the FIU-900 unit, you may
proceed with steps 13-18. If you will still be using the Puppy device for another
application, stop here.
13. Click Start from the taskbar, select Settings, click on Control Panel, and double-click
the Add/Remove Programs icon.
14. Select Puppy (FIU-710/900) API from the list of installed programs.
15. Windows® 2000: Click the Change/Remove button. Windows XP: Click the Remove
button.
16. Windows 2000: Select the Remove option from the installation options provided. Click
Next and Finish until prompted to restart your computer. Windows XP: Click Yes when
asked if you would like to uninstall Puppy (FIU-710/900) API.
17. You will be asked to delete some shared file(s). You may delete these files.
18. Restart your computer.
Training Your Puppy Unit
Page 19
Section 6: Release Notes
•
SecureSuite® XS Workstation 4.01 does not support Remote Desktop functionality at
this time.
•
After recovery from hibernation or standby mode, the FIU-900 Puppy® unit might not be
recognized. If this occurs, please click Cancel or OK and unplug the device. Wait a few
seconds, plug the Puppy unit back in, wait five seconds, and then try the process again. If
the device is still not recognized, authenticate with an alternate method (i.e.: password), if
available, or restart the computer.
Page 20
Training Your Puppy Unit
Section 7: Frequently Asked Questions (FAQ)
How does the FIU-900 unit read my fingerprint?
The Puppy® device offers robust fingerprint imaging technology based on a technique known as
capacitance, which digitally reads the fingerprint without leaving ink residue on your finger.
Capacitance sensors cannot be fooled by paper copies and do not require cleaning.
How do I use the PKI functions of the FIU-900 Puppy device?
The FIU-900 unit features built-in advanced PKI encryption and digital signature functions, but
currently these functions are not explicitly available for users within SecureSuite® XS
Workstation. If you need to access the PKI functions for particular applications, or plan to use
the FIU-900 with a dedicated PKI architecture, contact Sony; Sony will be producing an
appropriate software utility in the near future.
Do I need to clean the device?
No, the Puppy unit does not require regular cleaning. However, if you notice debris (dust, etc.)
collecting in the corners of the sensor area, you can clean the sensor with a dry tissue or cloth.
Why does my computer freeze or crash when I plug in the Puppy unit?
Be sure that you are connecting the Memory Stick™ media adapter directly to your PC’s USB
port.
When do I insert the FIU-900 unit during installation?
You may plug in the device when prompted during the installation process of the SecureSuite XS
Workstation software or after installation. Do not plug the device in before the prompt, as it may
cause your installation to fail.
I plugged the FIU-900 in before the installation, but Windows® could not find the drivers,
and now SecureSuite can’t find the FIU-900. What do I do?
Follow these steps:
1.
2.
3.
4.
5.
Remove the FIU-900 unit and reboot your PC.
Go to Start Menu, Settings, Control Panel, Add/Remove Programs.
Find SecureSuite in the list of programs and click Change.
Select Modify from the list of options. Click Next.
In the Custom Installation dialog box, find Authentication Methods and be sure to
check all the boxes for the FIU-900 method. Select This feature will be installed on
local hard drive. Click Next, and then click Install.
6. Click Finish and let the computer reboot.
Training Your Puppy Unit
Page 21
7. Close the Add/Remove Programs dialog box.
8. Insert the Puppy® unit and direct the device installation routine (if prompted) to the
folder containing the “fiu900.inf” and “fiu900.sys” files.
9. Look in the Start Menu, Settings, Control Panel, Device Manager, under the Ports
(COM & LPT) heading, for the FIU-900 series driver to be sure it has installed
correctly.
10. Open SecureSuite System Settings. Double click on Authentication Methods. Rightclick in the right pane and choose Add Method. The FIU-900 should now be an option.
11. Choose the FIU-900 and click OK.
12. You will now be able to add the device as an authentication method within the
SecureSuite® XS Workstation software.
If this does not work, please uninstall the SecureSuite XS Workstation software completely,
and reinstall the software, being sure to insert the FIU-900 unit only when prompted.
Why is the FIU-900 not reading my fingerprint when I try to enroll or use the device?
Be sure…
…the FIU-900 unit is correctly inserted into the adapter and the adapter’s cable is firmly
plugged in to the adapter and the PC’s USB port.
…that your fingerprint is correctly placed on the device (see Section 1).
…if your finger is too dry, to touch your finger to your forehead or the side of your nose
and then place your finger on the unit. The oils will help the sensor to correctly read the
ridges and valleys of your fingerprint.
…if your finger is too moist, to rub your finger on your slacks or sleeve and then place
your finger on the unit.
I have a Windows® domain account, and the software will not allow me to use or enroll a
fingerprint. What’s wrong?
If you logon to a domain and are a domain user, SecureSuite XS Workstation will not allow you
to logon using the Puppy device without SecureSuite XS Server present on the domain (you can
still logon with a password). In order to use this software, you will need to have a local machine
account.
Why does my PC takes 5-10 minutes or longer to return to the logon prompt after I install
SecureSuite XS Workstation and reboot?
You probably forgot to turn off your virus detection software. Always be sure to disable antivirus software before installation.
How can I enroll more than 5 distinct users on the FIU-900?
SecureSuite XS Workstation ships with a license for 5 distinct users. In order to enable more
users, please contact Sony.
Page 22
Training Your Puppy Unit
After enrolling a new user on my system, I notice that any finger (even the wrong one!) will
allow me to access the PC. This is obviously not very secure…why is this happening??
You did not enter a password when setting up the new user. Windows® interprets the lack of a
password to mean that this user account does not require secure access. Enter a password for this
user via the User Properties dialog box and this problem should be solved.
I get an error when I verify my fingerprints after enrollment. One or more of the prints do
not match. How can I prevent this from happening?
You are not placing your finger consistently on the Puppy® unit. During enrollment be sure to
place your finger in a similar fashion per the instructions in Section 1.
Why is the choice of AND/OR settings so important during enrollment?
If you choose to make your user account an AND user, you will be required to enter both a
password and place your fingerprint before you can access your account. For security purposes
your original Windows password is then randomized within the SecureSuite® XS Workstation
architecture. If you uninstall the software, your Windows password will therefore be different
than your original password, and an administrator will need to reset it. You can change this
default setting by accessing the SecureSuite System Settings dialog box.
I have successfully enrolled my username and password for a website with SecureSession®
for Internet Explorer, but when I come back to the website, it’s not prompting me to use
my fingerprint. What’s wrong?
Sometimes, depending on your configuration, the prompt to use SecureSession will appear
behind your current Internet Explorer window. Try to minimize your active window and see if
the prompt appears.
I uninstalled and reinstalled SecureSuite XS Workstation, and now I can’t read the files I
previously encrypted with SecureFolder®. Why?
Unless you entered an Emergency Recovery Passphrase when you first used SecureFolder, there
is no way to retrieve the files. If you are concerned with losing your files in the event of a
catastrophic failure of your PC, be sure to enter a Passphrase when first using SecureFolder. See
the SecureSuite XS Workstation Guide on the software CD for more information.
Why do I need to turn off my screensaver before uninstalling the SecureSuite XS
Workstation software?
If the screensaver activates during uninstallation, the SecureSuite XS Workstation software may
not allow you to leave the screensaver, thus causing the uninstallation to fail. In this event, your
PC may not be recoverable, and you may need to reinstall Windows entirely. Always be sure to
deactivate the screensaver before uninstallation.
Training Your Puppy Unit
Page 23
I just put my computer in standby mode and then took it out of standby mode. The
SecureSuite® XS Workstation software does not recognize that the FIU-900 unit is plugged
in. What do I do?
After recovery from hibernation or standby mode, the FIU-900 Puppy® unit might not be
recognized. If this occurs, please click Cancel or OK and unplug the device. Wait a few
seconds, plug the Puppy unit back in, wait five seconds, and then try the process again. If the
device is still not recognized, authenticate with an alternate method (i.e.: password), if available,
or restart the computer.
Page 24
Training Your Puppy Unit
Section 8: Who to Contact?
If you have any problems with your Puppy® unit or the SecureSuite® XS Workstation software,
need more information on other Sony products, or have specific questions relating to your
installation, please contact Sony via the information provided below.
• Technical Support: 866-347-7669 (toll free in the US)
• Information, Software Updates: www.sony.com/puppy
• Information: 866-530-2963 (toll free in the US)
Training Your Puppy Unit
Page 25
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
