VAIO® Notebook
User Guide
PCG-FX290/FX290K
VAIO Notebook User Guide
Notice to Users
© 2001 Sony Electronics Inc. All rights
reserved. This manual and the software
described herein, in whole or in part, may not
be reproduced, translated, or reduced to any
machine-readable form without prior written
approval.
SONY ELECTRONICS INC. PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN
AND HEREBY EXPRESSLY DISCLAIMS
ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE WITH
REGARD TO THIS MANUAL, THE
SOFTWARE, OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL
SONY ELECTRONICS INC. BE LIABLE
FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING
OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR
THE USE THEREOF.
Sony Electronics Inc. reserves the right to make
any modification to this manual or the
information contained herein at any time
without notice. The software described herein is
governed by the terms of a separate user license
agreement.
This product contains software owned by Sony
and licensed by third parties. Use of such
software is subject to the terms and conditions
of license agreements enclosed with this
product. Some of the software may not be
transported or used outside the United States.
Software specifications are subject to change
without notice and may not necessarily be
identical to current retail versions.
2
Updates and additions to software may require
an additional charge. Subscriptions to online
service providers may require a fee and credit
card information. Financial services may
require prior arrangements with participating
financial institutions.
As an ENERGY STAR
Partner, Sony Corporation
has determined that this
product meets the
ENERGY STAR
guidelines for energy
efficiency.
The International ENERGY STAR Office
Equipment Program is an international program
that promotes energy saving through the use of
computers and other office equipment. The
program backs the development and
dissemination of products with functions that
effectively reduce energy consumption. It is an
open system in which business proprietors can
participate voluntarily. The targeted products
are office equipment such as computers,
displays, printers, facsimiles and copiers. Their
standards and logos are uniform among
participating nations. ENERGY STAR is a U.S.
registered mark.
Sony, Handycam, i.LINK, Mavica, Media Bar,
MovieShaker, PictureGear, VAIO and the VAIO
logo are trademarks of Sony Corporation.
Microsoft, Windows Me, Windows Media,
Windows, Windows NT, and the Windows logo
are registered trademarks of Microsoft
Corporation. Intel, SpeedStep, and Pentium are
trademarks of Intel Corporation. PS/2 is a
registered trademark of IBM.
This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of
this copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering
or disassembly is prohibited. i.LINK is a SONY
trademark used only to designate that a product
contains an IEEE 1394 connector. All products
with an i.LINK connector may not
communicate with each other.
unless the telephone line has been
disconnected at the network
interface.
❑
Use caution when installing or
modifying telephone lines.
❑
Avoid using the modem during an
electrical storm.
All other trademarks are trademarks of their
respective owners.
❑
Do not use the modem or a
telephone to report a gas leak in
the vicinity of the leak.
Owner’s Record
❑
A socket outlet should be as close
as possible to the unit and easily
accessible.
The model number and serial number are
located on the bottom of your Sony VAIO®
Notebook. Refer to the model and serial
number when you call your Sony Service
Center.
!
To change the backup battery,
please contact your nearest Sony
Service Center.
!
Caution - The use of optical
instruments with this product will
increase eye hazard. As the laser
beam used in this product is
harmful to the eyes, do not
attempt to disassemble the
cabinet. Refer servicing to
qualified personnel only.
!
For CD-RW/DVD-ROM drive:
Danger - Visible and invisible
laser radiation when open. Avoid
direct exposure to beam.
!
Caution: To reduce the risk of fire,
use only No. 26 AWG or larger
telecommunication line cord.
Model Numbers: PCG-956A, PCG-9562
Serial Number:________________________
Safety Information
WARNING
❑
To prevent fire or shock hazard,
do not expose your notebook
computer to rain or moisture.
❑
To avoid electrical shock, do not
open the cabinet. Refer servicing
to qualified personnel only.
❑
Never install modem or
telephone wiring during a
lightning storm.
❑
Never install telephone jacks in
wet locations unless the jack is
specifically designed for wet
locations.
❑
Never touch uninsulated
telephone wire or terminals
AVERTISSEMENT
❑
Pour prévenir tout risque
d’incendie ou d’électrocution,
garder cet appareil à l’abri de la
pluie et de l’humidité.
3
VAIO Notebook User Guide
❑
Pour prévenir tout risque
d’électrocution, ne pas ouvrir le
châssis de cet appareil et ne
confier son entretien qu’à une
personne qualifiée.
!
Pour changer la pile de rechange,
veuillez contacter votre centre de
service Sony le plus près.
!
Avertissement - L'utilisation
d'instruments optiques avec ce
produit augmente les risques pour
les yeux. Puisque le faisceau
laser utilisé dans ce produit est
dommageable pour les yeux, ne
tentez pas de désassembler le
boîtier. Adressez-vous à un agent
de service qualifié.
❑
Ne jamais effectuer l’installation
de fil modem ou téléphone durant
un orage électrique.
❑
Ne jamais effectuer l’installation
d’une prise téléphonique dans un
endroit mouillé à moins que la
prise soit conçue à cet effet.
❑
Ne jamais toucher un fil
téléphonique à découvert ou un
terminal à moins que la ligne
téléphonique n’ait été débranché
de l’interface réseau.
!
Pour les lecteur CD-RW/DVDROM: Danger : Radiation laser
visible et invisible si ouvert.
Évitez l’exposition directe au
faisceau.
❑
Soyez très prudent lorsque vous
installez ou modifiez les lignes
téléphoniques.
!
❑
Évitez d’utiliser le modem durant
un orage électrique.
Attention : Afin de réduire les
risques d'incendie, n'utilisez
qu'un cordon de communication
N0. 26 AWG ou plus gros.
❑
N'utilisez pas le modem ni le
téléphone pour prévenir d'une
fuite de gaz vous êtes près de la
fuite.
❑
L’appareil doit être le plus près
possible d’une prise murale pour
en faciliter l’accès.
If you have questions about this product, you
can reach the Sony Customer Information
Service Center at 1-888-4SONYPC; or write to
the Sony Customer Information Service Center
at 12451 Gateway Blvd., Ft. Myers, FL 33913
or find Sony Customer Service on the web at:
http://www.sony.com/pcsupport
Regulatory Information
Declaration of Conformity
4
Trade Name:
SONY
Model No.:
PCG-956A
PCG-9562
Responsible Party:
Sony Electronics Inc.
Address:
680 Kinderkamack Rd.
Oradell, NJ 07649
Telephone:
(For FCC-related
matters only.)
201-930-6972
This device complies with Part 15 of the
FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference.
(2) This device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
❑
Reorient or relocate the receiving
antenna.
❑
Increase the separation between
the equipment and the receiver.
❑
Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
❑
Consult the dealer or an
experienced radio/TV technician
for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Only peripherals (computer input/output
devices, terminals, printers, etc.) that comply
with FCC Class B limits may be attached to this
computer product. Operation with noncompliant peripherals is likely to result in
interference to radio and television reception.
All cables used to connect peripherals must be
shielded and grounded. Operation with cables,
connected to peripherals, that are not shielded
and grounded, may result in interference to
radio and television reception.
FCC Part 68
This equipment complies with Part 68 of the
FCC rules. On the bottom of this equipment is a
label that contains, among other information,
the FCC equivalence number (REN) for this
equipment. If requested, this information must
be provided to the telephone company.
This modem uses the USOC RJ-11 telephone
jack.
The REN is used to determine the quantity of
devices which may be connected to the
telephone line. Excessive RENs on the
telephone line may result in the devices not
ringing in response to an incoming call. In
most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of
the number of devices that may be connected to
the line, as determined by the total RENs,
contact the telephone company to determine the
maximum REN for the calling area.
If the terminal equipment causes harm to the
telephone network, the telephone company will
5
VAIO Notebook User Guide
notify you in advance that temporary
discontinuance of service may be required. But
if advance notice is not practical, the telephone
company will notify the customer as soon as
possible. Also, you will be advised of your right
to file a complaint with the FCC if you believe
it is necessary.
The telephone company may make changes in
its facilities, equipment, operations or
procedures that could affect the operations of
the equipment. If this happens, the telephone
company will provide advance notice in order
for you to make the necessary modifications in
order to maintain uninterrupted service.
If trouble is experienced with this equipment,
you can reach the Sony Customer Information
Service Center at 1-888-4SONYPC; or write to
the Sony Customer Information Service Center
at 12451 Gateway Blvd., Ft. Myers, FL 33913
or find Sony Customer Service on the web at:
http://www.sony.com/pcsupport
Repair of this equipment should be made only
by a Sony Service Center or Sony authorized
agent. For the Sony Service Center nearest you,
call 1-888-4SONYPC (1-888-476-6972).
This equipment cannot be used on public coin
service provided by the telephone company.
Connection to Party Line Service is subject to
state and possible provincial tariffs. (Contact
the state or provincial utility service
commission, public service commission, or
corporation commission, for information.)
Telephone Consumer
Protection Act of 1991
(United States)
The Telephone Consumer Protection Act of
1991 makes it unlawful for any person to use a
computer or other electronic device to send any
message via a telephone facsimile machine
unless such message clearly contains, in a
margin at the top or bottom of each transmitted
6
page or on the first page of the transmission, the
date and time it is sent and an identification of
the business, other entity, or individual sending
the message, and the telephone number of the
sending machine or such business, other entity,
or individual.
In order to program this information into your
facsimile machine, see your fax software
documentation.
Telephone Consumer
Guidelines (Canada)
Please refer to your telephone directory under
‘Privacy Issues’ and/or ‘Terms of Service.’ For
more detailed information, please contact:
CRTC
Terrasses de la Chaudiére, Tour centrale
1 promenade du Portage, 5 étage Hull
PQ K1A 0N2.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet àppareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
DISPOSAL OF LITHIUM ION
BATTERY
You can return your unwanted lithium ion
batteries to your nearest Sony Service Center or
Factory Service Center.
✍ In some areas the disposal of lithium
ion batteries in household or
business trash may be prohibited.
For the Sony Service Center nearest you, call 1888-476-6972 in the United States or 1-800961-7669 in Canada.
!
Do not handle damaged or leaking
lithium ion batteries.
!
Ne pas manipuler les batteries au
lithium-ion qui fuient ou sont
endommagées.
!
Danger of explosion if battery is
incorrectly replaced. Replace only
with the same or equivalent type
recommended by the
manufacturer. Discard used
batteries according to the
manufacturer’s instructions.
!
Une batterie non conforme
présente un danger d'explosion.
La remplacer seulement par une
batterie identique ou de type
équivalent recommandé par le
fabricant. Évacuer les batteries
usées selon les directives du
fabricant.
!
The battery pack used in this
device may present a fire or
chemical burn hazard if
mistreated. Do not disassemble,
heat above 212°F (100°C) or
incinerate.
Dispose of used battery promptly.
Keep away from children.
!
La manutention incorrecte du
module de batterie de cet appareil
présente un risque d'incendie ou
de brûlures chimiques. Ne pas
démonter, incinérer ou exposer à
une température de plus de 100°C.
Évacuer promptement la batterie
usée. Garder hors de portée des
enfants.
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label identifies
certified equipment. This certification means
that the equipment meets certain
telecommunications network protective,
operational and safety requirements as
prescribed in the appropriate Terminal
Equipment Technical Requirements
document(s). The Department does not
guarantee the equipment will operate to the
user’s satisfaction.
Before installing this equipment, users should
ensure that it is permissible to be connected to
the facilities of the local telecommunications
company. The equipment must also be installed
using an acceptable method of connection.
The customer should be aware that compliance
with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be
coordinated by a representative designated by
the supplier. Equipment malfunctions or any
repairs or alterations made by the user to this
7
VAIO Notebook User Guide
equipment may give the telecommunications
company cause to request that the user
disconnect the equipment.
Users should ensure for their own protection
that the electrical ground connections of the
power utility, telephone lines and internal
metallic water pipe system, if present, are
connected together. This precaution may be
particularly important in rural areas.
Caution: Users should not attempt to make such
connections themselves, but should contact the
appropriate electric inspection authority, or
electrician, as appropriate.
NOTICE: The Ringer Equivalence Number
(REN) assigned to each terminal device
provides an indication of the maximum number
of terminals allowed to be connected to a
telephone interface. The termination on an
interface may consist of any combination of
devices subject only to the requirement that the
sum of the Ringer Equivalence Numbers of all
the devices does not exceed 5. The Ringer
Equivalence Number for this equipment is 0.2.
AVIS DE L’INDUSTRIE
CANADA
AVIS: L’étiquette d’Industrie Canada identifie
le matériel homologué.
Cette étiquette certifie que le matériel est
conforme aux normes de protection,
d’exploitation et de sécurité des réseaux de
télécommunications, comme le prescrivent les
documents concernant les exigences techniques
relatives au matériel terminal. Le Ministère
n’assure toutefois pas que le matériel
fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit
s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de
télécommunication. Le matériel doit également
être installé en suivant une méthode acceptée de
raccordement. L’abonné ne doit pas oublier
8
qu’il est possible que la conformité aux
conditions énoncées ci-dessus n’empêche pas la
dégradation du service dans certaines
situations.
Les réparations de matériel homologué doivent
être coordonnées par un représentant désigné
par le fournisseur. L’entreprise de
télécommunications peut demander à
l’utilisateur de débrancher un appareil à la suite
de réparations ou de modifications effectuées
par l’utilisateur ou à cause de mauvais
fonctionnement.
Pour sa propre protection, l’utilisateur doit
s’assurer que tous les fils de mise à la terre de la
source d’énergie électrique, des lignes
téléphoniques et des canalisations d’eau
métalliques, s’il y en a, sont raccordés
ensemble. Cette précaution est particulièrement
importante dans les régions rurales.
Avertissement: L’utilisateur ne doit pas tenter
de faire ces raccordements lui-même; il doit
avoir recours à un service d’inspection des
installations électriques, ou à un électricien,
selon le cas.
AVIS: L’indice d’équivalence de la sonnerie
(IES) assigné à chaque dispositif terminal
indique le nombre maximal de terminaux qui
peuvent être raccordés à une interface.
La terminaison d’une interface téléphonique
peut consister en une combination de quelques
dispositifs, à la seule condition que la somme
d’indices d’équivalence de la sonnerie de tous
les dispositifs n’excède pas 5. L’indice
d’équivalence de la sonnerie de ce matériel est
de 0.2.
Notice to Users 2
Welcome 13
Features 13
Unpacking Your Notebook 14
Manuals 14
Software CDs 15
Recovery CDs 15
Other 15
Ergonomic Considerations 16
Notes on Setup 17
Handling Your Notebook 18
Cleaning Your Notebook 18
Handling the LCD Screen 18
Setting Up Your VAIO® Notebook 21
Locating Controls and Connectors 21
Connecting a Power Source 27
Starting Your Computer 33
Shutting Down Your Computer 34
Using Your VAIO® Notebook 35
Using the Keyboard 35
Combinations and Functions with the Windows Key 36
Indicators 37
Indicators (continued) 38
Combinations and Functions with the Fn Key 39
Using the Touchpad 40
Using the Floppy Disk Drive 42
9
VAIO Notebook User Guide
Using the Optical Drive 45
Playing a DVD 47
Notes on CD and DVD media 49
Writing data to CD-RW/CD-R media 49
Using PC Cards 51
To insert a PC card 51
To remove a PC card 52
Using a Second Battery Pack 54
To insert a second battery pack 54
To charge the second battery pack 55
To remove the second battery pack 56
Using the Weight Saver 57
To attach the weight saver 57
To remove the Weight Saver 58
Using Smart Connect 59
Windows Me™ 59
Windows 2000 59
Power Saving Modes 60
Normal Mode 60
Standby Mode 60
To activate Standby mode 60
To return to normal mode 61
Hibernate Mode 61
To activate Hibernate mode 61
To return to normal mode 61
Connecting a Phone Line 62
Connecting to the Local Area Network (LAN) 63
Setting Up Your Ethernet Connection 63
Connecting Peripheral Devices 65
Connecting the Port Replicator 66
10
Connecting an External Mouse or Keyboard 70
Connecting a Printer 71
Connecting an External Display 71
Connecting a TV Display 75
Connecting a Universal Serial Bus (USB) Device 76
Connecting an i.LINK® Device 77
Connecting External Speakers 80
Connecting an External Microphone 81
Customizing Your VAIO® Notebook 83
Displaying the Sony Notebook Setup Screen 83
Sony Notebook Setup Tabs 84
Controlling Power Management 85
Viewing the Power Management status icons 85
Power Management Profiles 86
Power Management Commands 88
Conserving Battery Power 88
Displaying Battery Information 89
Battery Icon Descriptions 89
Displaying Detailed Battery Information 90
Selecting the Display Mode 91
Changing the Window Design of Sony Software 92
Adding Memory 95
About the Software on Your Notebook 99
Overview 99
MovieShaker™ 103
Importing Images and Sound Clips 103
11
VAIO Notebook User Guide
Create a Movie using Shaker 105
Editing Clips and Scenes 106
Saving a Movie 106
PictureGear™ 107
Managing Your Pictures 107
Creating a Photo Album 107
Using Panorama Maker 108
Making Still Images and Panoramic from MPEG 108
Software Support Information 109
Sony Service Center 111
Application, System, and Driver Recovery CDs 111
Using Your Recovery CDs 112
Using the Application Recovery CD(s) 112
Using the System Recovery CD(s) 113
Using the Driver Recovery CD(s) 114
Troubleshooting 117
Troubleshooting your notebook 117
Troubleshooting the LCD screen 121
Troubleshooting the mouse and touchpad 122
Troubleshooting drives, PC cards and peripheral devices 123
Troubleshooting software 124
Troubleshooting the modem 125
Troubleshooting audio 125
Troubleshooting the printer 126
Specifications 129
12
Welcome
Congratulations on your purchase of the Sony VAIO® notebook. Sony has
combined leading-edge technology in audio, video, computing, and
communications to provide you with state-of-the-art personal computing.
Features
✍ For a complete description of the specifications of your VAIO® Notebook, see
“Specifications”
❑
Exceptional performance — Your notebook includes a mobile Intel®
Pentium® III processor featuring Intel® SpeedStep™ technology* and a
V.90 compatible K56flex modem.†
❑
Portability — Rechargeable battery pack provides hours of use without AC
power.
❑
Sony audio and video quality — High-quality MPEG1/MPEG2 video,
which supports full-screen display and enables you to take advantage of
today’s advanced multimedia applications, games, and entertainment
software.
❑
Multimedia features — Enjoy the stereo speakers or use a headphone (not
supplied) to listen to audio and video CDs.
❑
Microsoft® Windows® operating system — Your system includes
Microsoft® Windows® Millennium Edition (Windows MeTM) or Microsoft®
Windows® 2000 Professional.
❑
Communications — Access popular online services, send e-mail, browse
the Internet, and use fax features.
❑
Optical drive (CD-RW/DVD-ROM) — The CD-RW/DVD-ROM drive
utilizes a new optical storage technology that combines the features of both a
* The processor may be reduced to a lower operating speed when operating on battery power.
† Actual upload and download speeds may vary due to line conditions, ISP support, and government regulations.
13
VAIO Notebook User Guide
CD-RW drive and DVD-ROM drive, providing increased storage capacity
and a rich multimedia computing experience. The CD-RW/DVD-ROM drive
plays DVD-ROM, CD-ROM, CD-RW, and CD-R discs.
Unpacking Your Notebook
Remove the following hardware items from the box:
Main unit*
Power cord
AC adapter
Video cable
Rechargeable
battery pack
Weight saver
* Removable floppy disk drive is in the multipurpose bay.
Manuals
❑
VAIO® Quick Start — Contains information on unpacking and setting up
your notebook, supplementary updates, and software information.
❑
Microsoft® Windows® Millennium Edition Getting Started manual or the
Microsoft® Windows® 2000 Professional Getting Started manual —
Explains how to use the basic features of this latest Windows operating
system.
14
Unpacking Your Notebook
Software CDs
❑
Microsoft® Word 2000 — Allows you to reinstall Microsoft Word to the
VAIO notebook you purchased.
Recovery CDs
❑
System Recovery CD(s) — Allows you to restore the software titles that
shipped with your computer if they become corrupted or are erased. It can
only be used to restore the hard disk of the VAIO notebook you purchased.
❑
Application Recovery CD(s) — Allows you to reinstall individual
applications or device drivers if they become corrupted or erased.
❑
Driver Recovery CD(s) — Allows you to reinstall individual device
drivers. Use it to restore corrupted or erased files.
Other
❑
Packet containing special product offers
15
VAIO Notebook User Guide
Ergonomic Considerations
You will be using your notebook computer as a portable device in a variety of
environments. Whenever possible, you should attempt to apply the following
ergonomic considerations to both stationary and portable environments.
Ergonomic Position
Computer positioned
directly in front of you
Arms at desk
level
Wrists relaxed
and flat
❑
Position of your computer — Place the computer directly in front of you as
you work. Keep your forearms horizontal, with your wrists in a neutral,
comfortable position while using the keyboard, touchpad, or external mouse.
Let your upper arms hang naturally at your sides. Take breaks during
sessions with your computer. Excessive use of the computer may strain
muscles or tendons.
❑
Furniture and posture — Sit in a chair with good back support and
armrests. Adjust the level of the chair so your feet are flat on the floor. A
footrest may make you more comfortable. Sit in a relaxed, upright posture
and avoid slouching forward or leaning far backward.
❑
Viewing angle of the computer’s display — Use the display’s tilting
feature to find the best position. You can reduce eye strain and muscle
16
Ergonomic Considerations
fatigue by adjusting the tilt of the display to the proper position. Adjust the
brightness setting of the display also.
❑
Lighting — Choose a location where windows and lights do not create glare
and reflection on the display. Use indirect lighting to avoid bright spots on
the display. You can also purchase accessories for your display that help
reduce glare. Proper lighting adds to your comfort and work effectiveness.
❑
Placement of an external display — When using an external display, set
the display at a comfortable viewing distance. Make sure the display screen
is at eye level or slightly lower when you are sitting in front of the monitor.
Notes on Setup
❑
Do not place your computer in a location subject to:
❑
Heat sources, such as radiators or air ducts
❑
Direct sunlight
❑
Excessive dust
❑
Moisture or rain
❑
Mechanical vibration or shock
❑
Strong magnets or speakers that are not magnetically shielded
❑
Ambient temperature of more than 95º F (35º C) or less than 40º F
(5º C)
❑
High humidity
❑
Do not place electronic equipment near your computer. The computer’s
electromagnetic field may cause a malfunction.
❑
Provide adequate air circulation to prevent internal heat buildup. Do not
place your computer on porous surfaces such as rugs or blankets, or near
materials such as curtains or draperies that may block its ventilation slots.
Leave a space of at least 8 inches (20 cm) behind the back panel of the
computer.
❑
If the computer is brought directly from a cold location to a warm one,
moisture may condense inside your computer. In this case, allow at least an
hour before turning on your computer. If any problems occur, unplug your
computer, and contact your Sony Service Center.
❑
The computer uses high-frequency radio signals and may cause interference
to radio or TV reception. Should this occur, relocate the computer a suitable
distance away from the set.
17
VAIO Notebook User Guide
❑
Use only specified peripheral equipment and interface cables; otherwise,
problems may result.
❑
Do not use cut or damaged connection cables.
❑
If the telephone company makes a service call to your home or office and
determines that your computer is responsible for a problem, the telephone
company may bill you for the service call. Also, if you do not disconnect
your computer when it is adversely affecting the telephone line, the
telephone company has the right to disconnect your service until you correct
the problem.
Handling Your Notebook
❑
Clean the cabinet with a soft, dry cloth or a soft cloth lightly moistened with
a mild detergent solution. Do not use any type of abrasive pad, scouring
powder, or solvent such as alcohol or benzine, as these may damage the
finish of your computer.
❑
Should any solid object or liquid fall into the computer, shut down your
computer and then unplug it. You may want to have the computer checked
by qualified personnel before operating it any further.
❑
Do not drop the computer or place heavy objects on top of the computer.
Cleaning Your Notebook
❑
Make sure to disconnect the power cord before cleaning the computer.
❑
Avoid rubbing the LCD screen as this can damage the screen. Use a soft, dry
cloth to wipe the LCD screen.
❑
Clean the computer with a soft cloth lightly moistened with a mild detergent
solution. Do not use any type of abrasive pad, scouring powder or solvent,
such as alcohol or benzine.
Handling the LCD Screen
❑
Do not leave the LCD facing the sun as it can damage the LCD. Be careful
when using the computer near a window.
❑
Do not scratch the LCD or exert pressure on it. This could cause
malfunction.
18
Ergonomic Considerations
❑
Using the computer in low temperature conditions may produce a residual
image on the screen. This is not a malfunction. When the computer returns to
normal temperature, the screen returns to normal.
❑
The screen becomes warm during operation. This is normal and does not
indicate a malfunction.
❑
The LCD is manufactured using high-precision technology. You may,
however, see tiny black points and/or bright points (red, blue, or green) that
continuously appear on the LCD. This is a normal result of the
manufacturing process and does not indicate a malfunction.
19
VAIO Notebook User Guide
20
Setting Up Your VAIO®
Notebook
This section describes all the controls and connectors on your computer, how to
connect your computer to a power source, and how to start and shut down your
computer.
Locating Controls and Connectors
Front
+
1
LCD (Liquid Crystal Display)
screen
7
Battery 1 and 2 indicators
2
Speakers
8
Hard disk drive indicator
3
Keyboard
9
Num Lock indicator
21
VAIO Notebook User Guide
4
Touchpad
10
Caps Lock indicator
5
Left/right buttons
11
Scroll Lock indicator
6
Power indicator
22
Locating Controls and Connectors
Left
1
Video out
4
i.LINK® (IEEE1394) S400
connector
2
Microphone connector
5
PC card slots
3
Headphone connector
6
Battery bay
23
VAIO Notebook User Guide
Right
1
PPK buttons
2
Power button
3
Optical drive (CD-RW/DVD-ROM drive)
4
Multipurpose bay
24
Locating Controls and Connectors
Back
cover
1
2
Modem jack
USB connectors
3
Serial connector
4
Printer connector
5
6
7
Monitor connector
Ethernet connector
DC In connector
Warning:
Only connect 10BASE-T and 100BASE-TX cables to the Ethernet network port.
Do not connect any other type of network cable or any telephone line.
Connecting cables other than those listed above may result in an electric
current overload and could cause a malfunction, excessive heat, or fire in the
connector. To connect the unit to the network, contact you network
administrator.
✍ There is a ventilation slot located between the Ethernet connector and the USB
connector. Do not cover the ventilation slot when your computer is on.
25
VAIO Notebook User Guide
Bottom
1
Multipurpose bay RELEASE lever
2
Reset switch
3
Tilt stands
26
Connecting a Power Source
Connecting a Power Source
You can use either AC power or a rechargeable battery pack as a power source.
Using the AC Adapter
1
Plug the cable attached to the AC adapter into the DC In connector on the
computer.
2
Plug one end of the power cord into the AC adapter.
3
Plug the other end of the power cord into an AC outlet.
Connecting the AC adapter
Notebook
AC adapter
(supplied)
Power cord
(supplied)
DC In
Notes on the AC Adapter
❑
Your computer operates on 100V-240V AC 50/60 Hz.
❑
Do not share the AC outlet with other power-consuming equipment, such as
a copy machine or shredder.
❑
You can purchase a power strip with a surge protector. This device prevents
damage to your computer caused by sudden power surges such as those that
may occur during an electrical storm.
❑
Do not place heavy objects on the power cord.
❑
To disconnect the cord, pull it out by the plug. Never pull the cord itself.
❑
Unplug your computer from the wall outlet if you will not be using the
computer for a long time.
❑
The LED indicator on the AC adapter may be turned on until the AC adapter
is unplugged from your notebook.
❑
When the AC adapter is not used, unplug it from the AC outlet.
27
VAIO Notebook User Guide
❑
Use only the AC adapter supplied. Do not use any other AC adapter.
Using Battery Power
You can use one or two battery packs as a source of power. The second battery
pack inserts into the multipurpose bay on the right side of the computer. (See
“Using a Second Battery Pack” ) Additional battery packs are available as a
separate option.
The battery pack that comes with your computer is not fully charged at the time
of purchase. Follow the steps below to insert and charge the battery pack.
To insert the battery pack
1
To open the battery bay, press cover down.
✍ Cover swings out but does not detach.
Battery bay
28
Connecting a Power Source
2
Insert the battery pack into the battery bay on the left side of the computer.
Inserting battery pack
Battery pack
(supplied)
Label side facing down
3
Close the cover of the battery bay until it clicks.
✍ If the port replicator is attached to your computer, do not attempt to insert or remove
the battery pack. Lifting and turning the computer with a port replicator attached could
cause a temporary loss of power.
To charge the battery pack
1
Connect the AC adapter to the computer.
2
Insert the battery pack.
The computer automatically charges the battery (the battery indicator light
flashes in a double blink pattern as the battery charges).
3
When the battery is 85% full, the battery indicator light turns off. This
process takes approximately 3 hours if your notebook’s power is on.
✍ To charge the battery completely, continue charging for an additional hour. See
“Displaying Battery Information”
29
VAIO Notebook User Guide
There are two battery indicator lights on the computer
Battery indicator lights
Battery indicator lights
Battery
Indicator
Description
1
Indicates the status of the battery pack in the battery bay on the left
side of the computer.
2
Indicates the status of the battery pack in the multipurpose bay on
the right side of the computer.
Battery
Indicator Light
Status
Description
On
The computer is using battery power.
Single blink
The battery is running out of power.
Double blink
The battery is charging.
Off
The computer is using AC power.
30
Connecting a Power Source
To remove the battery pack
1
Open the battery bay cover.
2
Pull out the battery pack.
Removing the battery pack
3
Close the cover of the battery bay.
You will lose data if you remove the battery pack while the computer is on
and not connected to the AC adapter or if you remove the battery while the
computer is in a power-saving mode
Notes on the battery
❑
To determine the remaining battery charge, see “Displaying Battery
Information”
❑
When the battery power is running low, both the battery and power
indicators blink.
❑
When the computer is directly connected to AC power and has a battery
pack in the battery bay, it uses power from the AC outlet.
❑
See “Using a Second Battery Pack” for information on installing and
charging a battery pack in the multipurpose bay.
❑
Keep the battery pack in the computer while it is directly connected to AC
power. The battery pack continues to charge while you are using the
computer.
❑
If the battery level falls below 10%, you should either attach the AC adapter
to recharge the battery or shut down your computer and insert a fully charged
battery.
31
VAIO Notebook User Guide
❑
You can extend battery life by changing the power-management modes in
the PowerPanel utility. See “Power Saving Modes”
❑
The battery pack supplied with your computer is a lithium-ion battery and
can be recharged at any time. Charging a partially discharged battery does
not affect battery life.
❑
The battery indicator light is on while you use the battery pack as a power
source. When battery life is nearly depleted, the battery indicator starts
flashing.
❑
For some software applications and some peripheral devices, your computer
may not enter Hibernate mode when the battery life is low. To avoid loss of
data when using battery power, you should save your data frequently and
manually activate a power-management mode, such as Standby or
Hibernate.
❑
Never leave the battery pack in temperatures above 140° F (60° C), such as
under direct sunlight or in a car parked in the sun.
❑
Battery life is shorter in a cold environment. This is due to decreased battery
efficiency at low temperatures.
❑
Charge the batteries at temperatures between 50° F and 80° F (10° C to
30° C). Lower temperatures require a longer charging time.
❑
While the battery is in use or being discharged, the battery pack heats up.
This is normal and is not cause for concern.
❑
Keep the battery pack away from all sources of heat.
❑
Keep the battery pack dry.
❑
Do not open or try to disassemble the battery pack.
❑
Do not expose the battery pack to any mechanical shock.
❑
If you are not using the computer for an extended period of time, remove the
battery pack from the computer to prevent damage to the battery.
❑
If, after fully charging the battery pack, the battery power is still low, the
battery pack may be reaching the end of its life and should be replaced.
❑
You do not need to discharge the battery before recharging.
❑
If you have not used the battery pack for a considerable amount of time,
recharge the battery.
32
Starting Your Computer
Starting Your Computer
1
Slide the LCD lock lever in the direction of the arrow, and lift the cover.
Opening the computer
LCD lock lever
2
Press the power button on top of the computer until the green power
indicator light turns on.
✍ (Windows Me™ only) When starting your notebook for the first time, the VAIO
InitManager dialog box will appear. Please select “OK” to begin initial setup. If you do
not execute the initial setup, you cannot use VAIO original hardware functions such as
PPK, Power Management tools, the scroll function of the touchpad, and keyboard
shortcut key combined with Fn key.
Power button
1
Power indicator
1
Power button
✍ If you hold the power button in the On position for more than four seconds, the
computer turns off.
33
VAIO Notebook User Guide
3
If necessary, adjust the brightness controls for the LCD display as follows:
❑
To decrease brightness, press Fn+F5 then the down or left arrow key.
❑
To increase brightness, press Fn+F5 then the up or right arrow key.
Shutting Down Your Computer
To avoid potential loss of data, follow these steps to shut down your computer.
1
Click the Start button on the Windows® taskbar.
2
Click Shut Down at the bottom of the Start menu to display the Shut Down
Windows dialog box.
3
Select Shut Down.
4
Click OK.
✍ Respond to any prompts warning you to save documents.
5
Wait for your computer to turn off automatically—power indicator turns off.
6
Turn off any peripherals connected to your computer.
✍ During a period of inactivity, you can conserve battery life by using Standby mode. See
“Controlling Power Management” .
If you are unable to shut down your computer.
1
2
Close or end all operations as follows:
❑
Close all applications.
❑
Remove the PC cards.
❑
Disconnect USB devices.
Restart the computer. You can restart your computer by pressing
Ctrl+Alt+Delete keys (at the same time).
✍ If you are still unable to shut down the computer, you can press the power button and
hold it for 5 seconds. This operation may result in data loss.
34
Using Your VAIO® Notebook
Using the Keyboard
Your keyboard is very similar to a typewriter’s, but the keyboard has additional
keys that perform specific computer-related tasks.
Keyboard
Print Screen key
Function keys
Escape key
Correction
keys
Shift key
Ctrl key
Applications key
Fn key
Navigation
keys
Alt key
Windows key
Numeric keypad area
Key
Description
Numeric keypad
area
Contains the keys found on a typical calculator. Use the numeric
keypad area to type numbers or to perform mathematical
calculations such as addition and subtraction. Note that you must
press the Num Lock key to activate the numeric keypad. (When
you do so, the Num Lock light will be on.)
Navigation keys
Several keys are devoted to moving the cursor on the screen.
Correction keys
The Insert, Back Space, and Delete keys enable you to make
corrections in your documents.
35
VAIO Notebook User Guide
Key
Description
Function keys
The twelve function keys along the top of the keyboard are used
to perform designated tasks. For example, in many applications,
F1 is the Help key. The task associated with each function key
may vary from one application to the next.
Escape key
The Esc (Escape) key is used to cancel commands.
Print Screen key
The Print Screen key takes an electronic snapshot of the screen
and places it in the Windows Clipboard. You can then paste the
screen shot into a document and print it.
Operator keys
Several keys are always used with at least one other key: Ctrl,
Alt, and Shift. When held down with another key, the Ctrl
(Control) and Alt (Alternate) keys offer another way to give
commands. For example, in many applications, instead of
choosing the Save command from a menu, you can hold down
Ctrl and press S (referred to as Ctrl+S). The Shift key operates
the same way as on a typewriter; it is used to produce capital
letters or special symbols such as @ and $.
Windows key
The key with the Windows logo displays the Windows Start
menu; it is the equivalent of clicking the Start button on the
taskbar. See “Combinations and Functions with the Windows
Key”.
Fn key
The Fn key is used in combination with other keys to issue
commands. See “Combinations and Functions with the Fn Key”.
Applications key
The Applications key displays a shortcut menu of contextsensitive choices. Pressing this key is the equivalent of clicking
the right mouse button.
Combinations and Functions with the Windows Key
Combination
Function
+ F1
Displays Windows Help.
+ Tab
Switches the selected button on the taskbar.
+E
Displays Windows Explorer.
+F
Displays the Windows Find: All Files window to find a file or
folder. This is the equivalent of selecting Find and then Files or
Folders from the Start menu.
36
Using the Keyboard
Combination
Function
+ Ctrl + F
Displays the Windows Find: Computer window where you can
locate other computers. This is the equivalent of selecting Find
and then Computer from the Start menu.
+M
Minimizes all displayed windows.
Shift +
+M
+R
Fn +
Returns all minimized windows to their previous size.
Displays the Run window. This is the equivalent of selecting Run
from the Start menu.
+ Insert
Displays the Properties window. This is the equivalent of doubleclicking the System icon in the Control Panel.
Indicators
Indicator
Function
Power
Light is green when the power to the computer is turned on, flashes
umber in Standby mode, and turns off when the computer is in
Hibernate mode or powered off.
Battery 1
Indicates the status of the battery inserted in the battery bay on
the left side of the computer.
1
Battery 2
Indicates the status of the battery inserted in the multipurpose
drive bay on the right side of the computer.
2
Hard disk
Lights when data is being read from or written to the hard drive.
Do not enter Standby mode or turn off the computer when this
indicator light is on.
37
VAIO Notebook User Guide
Indicators (continued)
Light
On
Off
Num Lock
The number keys in the numeric
keypad are active.
The alphanumeric character
keys in the keypad area are
active.
Caps Lock
The letters appear in uppercase as
you type. The Shift key lowers the
case of typed letters when Caps
Lock is on.
Letters appear in lower case
as you type (unless you
hold down the Shift key).
Scroll Lock
The screen scrolls differently.
(Exactly how it scrolls depends on
the specific application. It has no
effect in many applications.)
Information moves across
the display normally.
38
Using the Keyboard
Combinations and Functions with the Fn Key
Function
Fn+
(ESC)
Standby
Puts the system into Standby mode, a power- management state.
To return the system to the active state, press any key or press the
power button on your computer.
Fn+
(F3)
Mute On/Off
Toggles the built-in speaker off and on.
Fn+
(F4)
Speaker volume
Adjusts the built-in speaker volume.
To increase volume, press Fn+F4, then
or
To decrease volume, press Fn+F4, then Ð or
Fn+
(F5)
Brightness control
Adjusts the brightness of the LCD.
To increase light intensity, press Fn+F5 and then
or
To decrease light intensity, press Fn+F5 and then Ð or
Fn+ LCD /
(F7)
Switch to the
external monitor/
LCD
Toggles through the LCD, external display (connected to the
Monitor connector) and both LCD and external display.
Ð
Combinations/
Feature
.
.
Ð
Ð
Ð
Only LCD
Ð
Ð
.
.
LCD and external display
Only external display
Connect the cable before you turn on the computer, otherwise
Fn + F7 will not work.
Fn+
LCD only/
(F8)
Control TV out
(for models with
TV Out only)
Toggles between LCD-only and dual LCD/TV display modes.
Fn+
(F12)
Hibernate
Provides for the lowest level of power consumption. When you
execute this command, the state of the system and state of the
peripheral devices are written to the hard disk and the system
power is turned off. To return the system to its original state, use
the power button to turn on power.
Fn+D
Video standby
Turns off the LCD to save power. To turn the LCD back on, press
any key (Windows Me™ only).
Only LCD
LCD and external display
Only external display
Connect the cable before you turn on the computer, otherwise
Fn + F8 will not work.
✍ Some functions are not available until Windows launches.
39
VAIO Notebook User Guide
Using the Touchpad
The keyboard contains a cursor-pointing device called a touchpad. You can point
to, select, drag, and scroll objects on the screen using the built-in touchpad.
Touchpad
Pointer
Touchpad
Right button
Left button
Action
Description
Point
Slide one finger on the touchpad to place the pointer on an item
or object.
Click
Press the left button once.
Double-click
Press the left button twice.
Right-click
Press the right button once. In many applications, this action
displays a shortcut menu of context-sensitive choices.
Drag
Slide one finger while pressing the left button.
Scroll
Move your finger along the right edge of the touchpad to scroll
vertically. Move your finger along the bottom to scroll
horizontally. (The scroll function is available only with
applications that support a touchpad scroll feature.)
40
Using the Touchpad
✍ See Mouse Properties for information on touchpad features, such as clicking both
buttons simultaneously, adjusting touchpad speed, and Easy Launcher functions. To
access Mouse Properties, click the Start button, point to Settings, point to Control
Panel, and then click the Mouse icon in the Control Panel.
41
VAIO Notebook User Guide
Using the Floppy Disk Drive
Your computer comes with the floppy disk drive in the multipurpose bay.
To insert a diskette
1
Hold the diskette the label side facing up.
2
Gently push the diskette into the drive until it clicks into place.
Diskette
Floppy disk drive
42
Using the Floppy Disk Drive
To remove a diskette
❑
When you finish using the diskette, wait until the LED indicator light turns
off and then press the Eject button to remove the diskette.
Eject button
LED indicator
✍ Do not push the eject button when the LED indicator is turned on. Otherwise,
data may be lost.
To remove the floppy disk drive
1
Turn off the computer.
2
There is a RELEASE lever on the bottom of the computer. Slide this lever in
the direction of the arrow.
Multipurpose bay release lever
Multipurpose bay RELEASE lever
3
Slide the drive out of the multipurpose bay.
4
Insert the weight saver. See “Using the Weight Saver”.
43
VAIO Notebook User Guide
To reinsert the floppy disk drive
1
Turn off the computer.
2
If another device is in the multipurpose bay, remove the device. See “To
remove the second battery pack”.
3
Insert the floppy disk drive into the multipurpose bay with the VAIO label
facing up. Continue pushing the drive into the bay until the RELEASE lever
locks into place.
Inserting the floppy disk drive
Multipurpose bay
Floppy disk drive
44
Using the Optical Drive
Using the Optical Drive
Your computer comes with an optical drive (CD-RW/DVD-ROM drive).
To insert a disc
1
Turn on the computer.
✍ When the computer is in Standby or Hibernate mode, you cannot insert a disc.
See “Controlling Power Management”for more information on Standby and
Hibernate modes.
2
Press the Eject button to open the CD-RW/DVD-ROM drive.
The tray slides out.
Ejecting the tray
Eject button
3
Place an optical disc on the tray with the label side facing up. For DVDs
which can be played on both sides, the side of the disc facing up is the side
that plays.
45
VAIO Notebook User Guide
4
Push the disc onto the hub until the disc clicks securely into place.
Inserting an optical disc
Label side facing up
46
Using the Optical Drive
5
Close the tray by pushing it gently.
✍ Be sure to seat the disc firmly over the hub fingers. If you do not seat the disc firmly,
you could damage your optical drive and you may not be able to open the tray.
When you finish using a disc, wait until the LED indicator light turns off, then press the
Eject button to remove the disc.
When the computer is in power saving modes, you cannot remove a disc. See
“Controlling Power Management”for more information about power saving modes.
If the disc does not come out when you press the Eject button, turn off the computer
and insert a thin, pointed object into the manual eject hole.
Manual eject hole
Playing a DVD
To achieve optimum performance when playing DVDs, it is recommended that
your computer not be connected to the port replicator while playing DVD movies
or using DVD applications. Close any open applications before playing a DVD
movie.
✍ When playing DVD movies on battery power, set the power management profile to
DVD. With other profiles, the movies are choppy. As an alternative, you can set the
power management profile to Automatic Profile Selection, which will cause the DVD
profile to be selected automatically whenever you insert a DVD. See “Controlling
Power Management”for information on how to set the power management profile.
47
VAIO Notebook User Guide
❑
You can play DVDs using the DVD-ROM drive and the WinDVD software.
See the help file that comes with the WinDVD software for details.
Some discs recorded at 20 or 24 bits may produce noise while playing. If you have
audio devices connected, this may cause damage to your hearing and the speakers.
Reduce the volume before playing such discs.
You cannot switch between LCD and TV if you press Fn+F8 when a DVD is inserted in
the optical drive.
If you have connected a TV, follow the instructions in “Selecting the Display
Mode”.
✍ When a TV is connected to a notebook that is set to factory settings, a part of the
video screen will not appear. To view the entire screen, adjust the display
resolution to 640x 480 and refer to “Selecting the Display Mode”.
If you set the display resolution higher than the default setting (1400 x 1050, 32
bit), the DVD video may not play properly.
If the DVD video does not play properly, change the color depth to 1024x 768 High
Color (16 bit).
!
Do not switch the power saving modes while you are playing the DVD disc.
!
Do not switch between LCD and the external display while you are playing the
DVD video.
!
Change the setting to disable the screen saver and the virus checker (if it is
active).
!
Do not use memory-resident utility software to speed up disc access. This may
cause the computer to malfunction.
48
Using the Optical Drive
Notes on CD and DVD media
❑
Do not drop or bend the disc.
❑
Do not touch the surface of the disc. Fingerprints and dust on the surface of a
disc may cause read errors. Proper care of the disc is essential to maintain its
reliability. Do not use solvents such as benzine, thinner, commercially
available cleaners or anti-static spray, as they may cause damage to the disc.
❑
For normal cleaning, hold the disc by its edge and use a soft cloth to wipe the
surface from the center out.
❑
If the disc is badly soiled, moisten a soft cloth with water, wring it out well,
and use it to wipe the surface of the disc from the center out. Wipe off any
remaining moisture with a dry soft cloth
Writing data to CD-RW/CD-R media
If you use DirectCD™ to write data, you must first format the disc before writing
on a new CD-RW or CD-R. If you do not format the disc, your computer will not
recognize it.
✍ If you use Easy CD Creator® to write data to a CD-RW or CD-R, you do not have to
format the disc.
Formatting time and available capacity after formatting when you use a
74-minute CD-RW or CD-R is as follows:
Media
Formatting Time
Capacity After Formatting
CD-RW
Approximately 30 minutes
Approximately 530 MB
CD-R
Approximately 5 seconds
Approximately 620 MB
To make a CD-R to which data has been written readable on a CD-ROM drive,
you need to complete the disc when you eject it. To complete this process, follow
the instructions included with your software.
49
VAIO Notebook User Guide
✍ For optimal writing speed, deactivate the screen saver and exit anti-virus software
before writing data to a disc.
For best results, use CD-Rs that are compatible with 4x speed, as DirectCD™ and Easy
CD Creator® are preset to that speed. Your notebook does not support 1x writing
speed. If you use CD-RW or CD-R writing software other than DirectCD™, use
PowerPanel to select the DVD Profile.
When using Easy Creator® Standard, be sure to close and exit all other applications.
If your notebook computer has preinstalled Microsoft® Office applications, such as
Excel, Word, and Outlook, turn off the FindFast application.
Do not put your notebook into power saving mode while using DirectCD™ to write
data, or while using Easy CD Creator®.
Never touch the surface of the disc. Fingerprints and dust on the surface of a disc
may cause writing errors.
Do not strike or shake the computer while writing data to a disc.
Memory-resident disc utilities may cause unstable operation or data loss.
Deactivate these utilities before writing data to a disc.
Always use the AC adapter as the power source for your computer when you are
writing data to a CD-RW or CD-R. Using battery power may result in data transfer
failure.
50
Using PC Cards
Using PC Cards
Your computer includes two PC card slots. PC cards allow you to connect
portable external devices such as another hard disk drive, or to connect a
network.
✍ The PC card slots can accommodate two Type I/II PC cards, or one Type III PC card.
These slots are compatible with CardBus. Use the lower slot for Type III PC cards. You
do not need to shut down your notebook before inserting or removing a PC card.
To insert a PC card
1
Push the Release button once. The Release button pops out.
PC card release button
Release button
Release button
2
Push the Release button a second time. The PC card pops out.
When you use a Type III PC card, you need to remove both the top and
51
VAIO Notebook User Guide
bottom PC card slot protectors.
PC card slot protector
3
Insert the PC card into the PC card slot. Make sure the front label of the PC
card is facing up.
4
Push the the PC card slot gently into the connector. The PC card is
automatically detected by your system. The
(Unplug or Eject Hardware
icon) appears in the taskbar.
Inserting a PC card
Insert with the
arrow facing toward
the slot
PC card
Do not force a PC card into the slot as this may damage the connector pins.
Do not carry your computer while touching the head of a PC card (such as a
wireless LAN card), pressure or shock may damage the connector pins.
To remove a PC card
✍ If your computer is turned off, you do not have to follow these instructions.
52
Using PC Cards
1
Double-click
box appears.
in the taskbar. The “Unplug or Eject Hardware” dialog
2
Select the hardware device you wish to remove.
3
Click Stop. In the “Stop a Hardware device” dialog box, confirm that the
device can be safely removed from the system.
4
Click OK. The message, “PC Card can now be safely removed from the
system” appears.
5
Click OK again and click Close.
6
Push the Release button. The Release button pops out.
7
Push the Release button a second time. The PC card pops out. Gently grasp
the card and pull it out of the slot.
8
Insert the PC card slot protector into the empty slot.
Notes on using PC cards
❑
For some PC cards, if you alternate between normal power operation and the
Standby or Hibernate power-management modes while the card is inserted,
you may find that a device connected to your system is not recognized.
Reboot your system to correct the problem.
❑
Some PC cards may require that you disable idle devices when using the PC
card. You can use Sony Notebook Setup to disable devices. See “Displaying
the Sony Notebook Setup Screen”for details.
❑
Be sure to use the most recent software driver provided by the PC card
manufacturer.
❑
If an “!” mark appears on the Device Manager tab in the System Properties
dialog box, remove the software driver and then reinstall it.
❑
You may not be able to use some PC cards or some functions of the PC card
with this computer. If you have difficulty inserting a card, check that you are
orienting the card correctly. See the manual that came with your PC card for
more information on use.
53
VAIO Notebook User Guide
Using a Second Battery Pack
You can purchase a second rechargeable battery pack. With two battery packs,
you can extend the time that you use your computer with battery power. When
using two battery packs, the battery pack you insert first charges first. The battery
pack you insert second charges when the first battery pack is 85 percent full. You
can monitor which battery pack is charging by observing the battery indicator
lights.
To insert a second battery pack
1
If another device is in the multipurpose bay, remove the device.
2
Insert the battery pack into the multipurpose bay.
If the battery is being used, the battery 2 indicator light turns on.
Second battery in multipurpose bay
Multipurpose bay
Battery pack
Label side facing down
3
54
Attach the weight saver to the computer to stabilize the battery pack. There
is a RELEASE lever on the bottom of the weight saver. Slide the lever
toward the front of the computer to lock the weight saver. See also “Using
the Weight Saver”.
Using a Second Battery Pack
To charge the second battery pack
Using weight saver for second battery cover
Battery pack
Weight saver
Keep the battery pack in the computer while it is connected to AC power. The
battery indicator flashes while the battery is charging. See also “To charge the
battery pack” for more information.
Charging the second battery
Battery indicators
✍ To determine the amount of time the battery lasts, see “Displaying Battery
Information”
55
VAIO Notebook User Guide
To remove the second battery pack
If you attach two battery packs, you can remove either of them without shutting
down the computer. When removing one battery pack, make sure that the other
battery pack’s indicator light is on. If the indicator light of the battery pack you
are removing is on, right-click the battery icon on the task tray and click the
“Switch discharge battery” option.
1
There is a Release lever on the bottom of the weight saver. To remove the
battery pack, slide this lever in the direction of arrow 1, then slide the
RELEASE lever on the bottom of the computer in the direction of arrow 2.
Multipurpose bay release levers
Arrow 1: Weight saver Release lever
Arrow 2: RELEASE lever
2
Remove the weight saver, and then pull out the battery pack.
3
Reinsert the weight saver. See “Using the Weight Saver”.
56
Using the Weight Saver
Using the Weight Saver
The weight saver protects the multipurpose bay when it is empty.
To attach the weight saver
1
If another device is in the multipurpose bay, remove the device. See “To
remove the second battery pack”.
2
Fold out the hinged arm of the weight saver and then push on the hinged arm
to lock it into place. Slide the weight saver in the direction of the arrow until
it clicks.
Inserting the weight saver
Weight saver
(supplied)
3
Manually lock the weight saver’s Release lever.
57
VAIO Notebook User Guide
To remove the Weight Saver
1
There is a release lever on the bottom of the weight saver. To remove the
weight saver, slide this lever in the direction of arrow 1, then slide the
Release lever on the bottom of the computer in the direction of arrow 2.
Multipurpose bay release levers
Arrow 1: Weight saver Release lever
Arrow 2: RELEASE lever
2
58
After removing the weight saver, pull out the weight saver’s hinged arm and
fold it into the weight saver.
Using Smart Connect
Using Smart Connect
Windows Me™
You can connect your VAIO® notebook to another VAIO computer that has the
preinstalled Windows Me operating system or the Sony Smart Connect 3.0
software preinstalled. You may use an i.LINK*® cable (optional) to connect the
two systems and then use one computer to edit, copy, or delete files on the other
computer. You can also print from a printer that is attached to either computer.
Select the STD mode in Smart Connect 3.0 software to connect with another
computer that has Windows Me preinstalled.
Connecting with an i.LINK cable
i.LINK cable
Windows 2000
The preinstalled Smart Connect software allows you to use an i.LINK® cable
(optional) to connect your VAIO notebook to another VAIO computer that also
has Smart Connect or preinstalled Windows Me. You can then use one computer
to edit, copy or delete files on the other computer. You can also print from a
printer attached to either computer.
* i.LINK is a trademark of Sony used only to designate that a product contains an IEEE1394
connection. The i.LINK connection may vary, depending on the software applications, operating system and i.LINK-compatible devices. All products with an i.LINK connection may
not communicate with each other.
Please refer to the documentation that came with your i.LINK compatible device for information on operating conditions and proper connection. Before connecting i.LINK compatible
PC peripherals to your system, such as a CD-RW or Hard Disk Drive, confirm their operating
system compatibility and required operating conditions.
59
VAIO Notebook User Guide
See Smart Connect online help for more information.
✍ When you connect two VAIO computers, you must assign each computer a unique
name. The computers can be identified by this unique name when the two computers
are networked together.
✍ If you have previously purchased a VAIO computer or notebook that does not have the
Windows Me operating system or Smart Connect 3.0 software preinstalled, consult
the Sony website for support options (http://www.sony.com/pcsupport).
Power Saving Modes
When you use a battery as the source of power for your computer, you can take
advantage of power management settings to conserve battery life. In addition to
the normal operating mode, which allows you to turn off specific devices, your
computer has two distinct power saving modes: Standby and Hibernate. When
using battery power, be aware that the computer automatically enters Hibernate
mode when the remaining battery charge drops below 5 percent, regardless of the
power management setting you select.
✍ If the battery level falls below 10 percent, you should either attach the AC adapter to
recharge the battery or shut down your computer and insert a fully charged battery.
Normal Mode
Normal mode is the normal state of your computer when it is in use. The power
indicator light displays green when your computer is in this mode. To save
power, you can turn off a specific device such as the LCD or the hard disk.
Standby Mode
In Standby Mode the computer saves the current state of the system in RAM and
switches off power to the CPU. The umber power indicator light flashes in this
mode.
To activate Standby mode
To activate Standby mode, press the key combination Fn+Esc, or press the power
button and release it immediately. You can also use the PowerPanel utility to
enter Standby mode.
60
Power Saving Modes
To return to normal mode
Press any key to return to normal mode.
Hibernate Mode
In the Hibernate mode, the state of the system is saved on the hard drive and
power is turned off. The power indicator light is off in this mode.
To activate Hibernate mode
To activate Hibernate mode, press the key combination Fn+F12.
✍ (Windows 2000) The “Save to Disk Manager” screen appears, and then the computer
enters Hibernate mode.
✍ Do not move the notebook until its power indicator light turns off.
To return to normal mode
To return to normal mode, turn on the computer by pressing the power button.
The computer returns to its previous state.
✍ When returning from Hibernate mode, the system status stored on the hard disk is
erased and the computer starts normally if you press the power button and hold for
more than four seconds.
❑
Time required to return to normal mode
Standby requires less time than Hibernate to return to normal mode.
❑
Power consumption
Standby uses more power than Hibernate.
61
VAIO Notebook User Guide
Connecting a Phone Line
You need to connect a phone line to take advantage of online services and the
Internet.
✍ In order to register your Sony VAIO notebook, register your software online, and use
Sony Customer Support, you must connect to a phone line.
1
Plug one end of the phone cable into the modem jack on the computer.
Connecting phone cable
Modem jack
Wall jack
Phone cable (optional)
2
Plug the other end into the wall jack.
✍ Your computer does not work with party lines, cannot be connected to a coin-operated
telephone, and may not work with multiple phone lines or a private branch exchange
(PBX). Some of these connections may result in excess electrical current and could
cause a malfunction in the internal modem.
If you connect a phone line coming through a splitter, the modem or connected device
may not work properly.
62
Connecting to the Local Area Network (LAN)
Connecting to the Local Area Network (LAN)
You can connect your computer to 10BASE-T and 100BASE-TX-type networks.
For the detailed settings and devices needed to connect to the network, ask your
network administrator.
Connecting to LAN
Ethernet
adapter
Warning: Only connect 10BASE-T and 100BASE-TX cables to the
(Ethernet
network) port. Do not connect any other type of network cable or any telephone
line. Connecting cables other than those listed above may result in an electric
current overload and could cause a malfunction, excessive heat, or fire in the
connector. To connect the unit to the network, contact your network
administrator.
Note that if you enable Wake on LAN, the power saving mode will be switched
to Standby mode.
Setting Up Your Ethernet Connection
Windows Me™ models
1
Right-click Network Neighborhood and select Properties.
2
Click Add to add a client, adapter, protocol, or service.
3
Click File and Print Sharing to enable these functions.
4
Select a Primary Network Logon.
63
VAIO Notebook User Guide
5
Click the Identification tab to set the computer name, workgroup, and
computer description.
6
Click the Access Control tab to set the share level or user level access
control.
Windows 2000 models
To connect to the network
1
Right-click My Network Places and select Properties.
2
Click Advanced and select Network Identification to set the computer name,
domain, workgroup, and DNS suffix. You can also use the Network
Identification Wizard.
To set the connections, bindings, and provider order
1
Right-click My Network Places and select Properties
2
Click Advanced and select Advanced Settings. This will give you access to
Adapters and Protocol Bindings and Provider Order.
64
Connecting Peripheral Devices
You can add functionality to your computer by connecting a variety of
peripherals, as discussed in the following sections:
❑
“Connecting the Port Replicator”
❑
“Connecting an External Mouse or Keyboard”
❑
“Connecting a Printer”
❑
“Connecting an External Display”
❑
“Connecting a TV Display”
❑
“Connecting a Universal Serial Bus (USB) Device”
❑
“Connecting an i.LINK® Device”
❑
“Connecting External Speakers”
❑
“Connecting an External Microphone”
65
VAIO Notebook User Guide
Connecting the Port Replicator
Your notebook supports the use of an optional port replicator (PCGA-PRFX1).
Attaching a port replicator enables you to connect additional peripherals to your
computer.
Port replicator
2
6
4
1
5
3
1
2
3
4
Serial Port
5
Printer Port
6
Monitor Port
7
7
USB Ports
/
Port)
Mouse/Keyboard (PS/2
DC In
Network (Ethernet 10BaseT)
✍ The port replicator can be powered only with an AC power adapter. Do not remove the
AC adapter from the port replicator or the AC outlet while using the port replicator; this
may cause data damage or hardware malfunctions.
When you attach your computer to the port replicator for the first time, the installation
of the network driver starts automatically.
To attach your computer to the port replicator
To supply power to your computer while it is connected to the port replicator, you
can connect the AC adapter directly to the port replicator.
✍ When attaching your computer to the port replicator, do not attempt to insert or
remove the battery pack. Lifting and turning the computer with an attached port
replicator could cause a temporary loss of power.
66
Connecting the Port Replicator
1
Turn off your computer and disconnect all peripheral devices.
2
On the bottom of the computer, slide the port replicator connector cover
open.
Port replicator connector
Port replicator connector
3
Attach the bottom of the computer to the port replicator connector until it
clicks.
Attaching computer to port replicator
Notebook
Port replicator
67
VAIO Notebook User Guide
4
Plug the cable attached to the AC adapter into the DC IN connector on the
port replicator. Plug the power cord into the AC adapter and an AC outlet.
Connecting AC adapter to port replicator
AC adapter
Power cord
✍ Use the AC adapter that comes with your computer or the optional Sony AC
adapter.
The power indicator light turns green.
Power indicator light
Release lever
Power
Port replicator connector
5
68
Turn on the computer.
Connecting the Port Replicator
To remove your computer from the port replicator when the power is off
1
Turn off your computer and the connected peripherals.
2
Pull the levers on each side of the port replicator to disengage the computer
from the port replicator.
Disengaging computer from port replicator
Lever
3
Lift the computer away from the port replicator.
Port replicator connector cover
4
Close the port replicator connector cover on the bottom of your computer.
✍ It is extremely important to close the port replicator connector cover after removing
your computer from the port replicator. If the cover is left open, dirt may get inside and
damage the computer.
69
VAIO Notebook User Guide
Connecting an External Mouse or Keyboard
You can connect an external mouse or keyboard to the optional port replicator
using a PS/2®-style plug or adapter.
✍ Before you connect or disconnect the mouse or keyboard, turn off the computer.
You can only connect one external device at a time. Therefore, it is impossible to
connect both a PS/2 mouse and PS/2 keyboard simultaneously.
To connect an external mouse or keyboard
❑
Locate the mouse/keyboard connector on the port replicator identified by the
/
symbols.
❑
Plug the mouse or the keyboard cable into this connector with the arrow
facing up.
✍ See the manual that came with your mouse or keyboard for more information on its
installation and use.
70
Connecting a Printer
Connecting a Printer
You can connect a Windows Me/Windows 2000-compatible printer to your
computer to print documents.
To connect a printer
❑
Locate the Printer connector identified by the
symbol. Plug the printer
cable (supplied with the printer) into this port on the computer.
Printer connector
Printer
to
Printer
Power cord
Printer cable
(supplied with the printer)
✍ See the manual that came with your printer for more information on installation and
use.
If your printer stops functioning after resuming from a power-saving mode, see
“Troubleshooting the printer” .
Before using the printer, you may need to change the Printer setting in the Sony
Notebook Setup software. See “Displaying the Sony Notebook Setup Screen” .
Connecting an External Display
You can connect an external display to your notebook. For example, you can use
the computer with any of the following:
❑
Computer display (monitor) (See “To connect a computer display”.)
❑
Multimedia computer display (See “To connect a multimedia computer
display”.)
71
VAIO Notebook User Guide
❑
Projector (See “To connect a projector”.)
✍ Connect an external display before you turn on the computer.
To connect a computer display
❑
Locate the Monitor connector identified by the
symbol on the back of the
computer. Plug the display cable (not supplied) into this connector.
❑
If necessary, plug one end of the display power cord into the display, and the
other end into an AC outlet.
Connecting an external computer display
Computer display
Power cord
To
Monitor
Display cable (optional)
✍ See the manual that came with your computer display for more information on
installation and use.
To connect a multimedia computer display
You can connect the notebook to a multimedia computer display that includes
built-in speakers and a microphone.
1
Locate the Monitor connector identified by the
cable into this connector.
2
Locate the Headphone connector identified by the
speaker cable into this connector.
symbol. Plug the
3
Locate the Microphone connector identified by the
microphone cable into this connector.
symbol. Plug the
72
symbol. Plug the display
Connecting an External Display
✍ See the manual that came with your multimedia computer display for more
information on installation and use.
To connect a projector
You can use a projector, such as the Sony LCD Projector, as an external display.
Connecting a projector
Projector
To
headphone
i
To
monitor
RGB signal
cable (optional)
Power cord
Audio cable
(optional)
✍ See the manual that came with your projector for more information on its installation and
use.
To select a display
When you connect an external display to the monitor connector, you can toggle
the output between the Liquid Crystal Display (LCD), the external monitor, or
both devices.
Use the Fn+F7 keys to select a display. See also “Selecting the Display Mode” for
more information.
73
VAIO Notebook User Guide
To
Press
Result
Switch to an
external
display
Fn+F7
Toggles between the LCD, the external display
connected to the Monitor connector, or both the
LCD and external display.
Only LCD
LCD and external display
Only external display
✍ Connect the cable before you turn on the computer, otherwise Fn + 7 will not work.
74
Connecting a TV Display
Connecting a TV Display
You can enjoy playing audio/video by connecting AV devices to your computer.
See also the manuals supplied with your AV devices.
To Connect a TV
❑
Connect the computer to a TV using audio/video cables. Switch the input
channel of the TV to external input. You also need to set up the TV
configuration system.
To AC
Power cord
i
To audio input
To video input
Audio cable
(not supplied)
Video cable
(supplied)
75
VAIO Notebook User Guide
✍ See the manual that came with your peripheral device for more information on
installation and use.
✍ If you insert a DVD in your DVD drive to watch a video on your TV, the Fn+F8 key
combination might not activate the function to toggle between your LCD and TV. Take
the following steps:
1. Connect the TV to the Computer.
2. Restart the computer and wait until it finishes.
3. Toggle between your LCD and your TV with the Fn+F8 key combination.
Your image is now displayed on both LCD and TV. Re-insert your DVD to launch your
DVD software.
✍ A part of the image cannot be displayed on your TV display if the resolution of your
computer is more than 800 x 600 dots. The hidden area on your TV display can be
seen by moving the cursor on your computer. If you want to display the full image,
change the resolution of your computer to 640 x 480.
Connecting a Universal Serial Bus (USB) Device
You can connect USB devices such as an external mouse, keyboard, speaker, and
microphone to your computer.
76
Connecting an i.LINK® Device
To connect a USB device
✍ Before you connect or disconnect a mouse, turn off the computer.
The following steps describe the procedure for connecting a USB mouse to your
computer. Use the same procedure for connecting all USB devices.
❑
Locate the USB device identified by the symbol. Plug one end of the USB
cable into this port and the other end into the USB device.
Connecting USB device to USB connector
USB device
To
USB
USB connecting cable
(optional)
You can use an optional Sony USB mouse PCGA-UMS1 series (not supplied)
with this computer. Since the USB mouse software driver is preinstalled in the
computer, you simply plug the USB mouse into the USB connector to use it. One
USB connector supports one USB device.
✍ See the manual that came with your USB device for more information on its
installation and use.
Connecting an i.LINK*® Device
You can connect an i.LINK-enabled digital video camera recorder to
the i.LINK® S400 (IEEE1394) connector.
* i.LINK is a SONY trademark used to designate that a product contains an IEEE 1394 connector. All products with an i.LINK connector may not communicate with each other.
77
VAIO Notebook User Guide
To connect a digital video camera recorder
❑
Plug one end of the i.LINK cable (not supplied) into the i.LINK connector
on the left side of the computer and the other end into the DV In/Out
connector on the digital video camera recorder.
✍ i.LINK cables compatible with your VAIO notebook include cables with the following
part numbers: VMC-IL4415 (a 1.5-meter cable with a 4-pin connector at each end),
VMC-IL4615 (a 1.5 meter-cable with a 4-pin connector at one end and a 6-pin
connector at the other), and VMC-IL4408A (a 0.8-meter cable with a 4-pin connector
at each end). You can purchase these cables from your local retailer, through the Sony
VAIO® Direct Web site (http://www.sonydirect.com), or by calling 1-888-315-7669 (toll
free).
Connecting digital video camera recorder to i.LINK connector
Digital video
camera recorder
To i.LINK
To DV In/Out
78
i.LINK cable
(optional)
Connecting an i.LINK® Device
✍ The Sony digital video camera recorder is pictured; you may need to connect your
camera differently.
On Sony digital video cameras, connectors labeled “DV In/Out” or “i.LINK” are i.LINKcompatible.
See the manual that came with your digital video camera recorder for more
information on installation and use.
Do not connect more than one digital video camera at a time. The software supplied
with your computer will not recognize multiple cameras.
The i.LINK connector on the computer does not supply power to external devices. If
the external device requires power from the i.LINK connector, you cannot use the
device with the computer.
The computer supports transfer rates up to 400 Mbps; however, the actual transfer
rate is the lowest transfer rate of the external device.
The i.LINK features available may vary depending on the software applications you
use. See the documentation that came with your software for more information.
79
VAIO Notebook User Guide
Connecting External Speakers
You can enhance the sound quality of your computer by connecting external
speakers.
✍ Make sure your speakers are designed for computer use.
Turn down the volume of the speakers before you turn them on.
Do not place diskettes on the speakers; the speakers’ magnetic field may damage the
data on the diskettes.
To connect external speakers
❑
Locate the Headphone connector identified by the symbol on the side of
the computer. Plug the speaker cable into this connector.
Connecting speakers to the headphone connector
Speakers
Speaker cable
(supplied with speakers)
To Headphones
✍ See the manual that came with your speakers for more information on installation and
use.
80
Connecting an External Microphone
Connecting an External Microphone
You can enhance the quality of sound input by using an external microphone.
✍ Make sure your microphone is designed for computer use. The microphone should be
compliant with the plug-in power microphone.
To connect an external microphone
❑
Locate the Microphone connector identified by the
symbol on the side of
the computer. Plug the microphone cable into this connector.
Connecting microphone to microphone connector
Microphone
(optional)
To
Microphone
✍ See the manual that came with your microphone for more information on installation
and use.
81
VAIO Notebook User Guide
82
Customizing Your VAIO®
Notebook
You can customize the settings of your notebook. The following sections briefly
describe how to change your computer’s default settings. You can also refer to
Sony Notebook Setup Help for more detailed information.
Displaying the Sony Notebook Setup Screen
To display the Sony Notebook Setup screen:
1
Click the Start button on the Windows® taskbar.
2
Point to VAIO and click Sony Notebook Setup.
Sony Notebook Setup Screen
3
Select the tab for the item you want to change. See “Sony Notebook Setup
Tabs” .
4
After you finish making your changes, click OK.
83
VAIO Notebook User Guide
Sony Notebook Setup Tabs
Tab
Description
About This Computer
Display system information, including memory capacity, serial
number, and BIOS version.
Select printer port mode settings.
Change the volume of the sounds that play while the operating
system is loading. Select the order of drives and devices from
which you want to load the operating system. You can specify
the hard drive as well as other drives inserted into your
computer.
When you connect an optional mouse to your computer, you
can make your touchpad inactive. You can also customize the
settings of your mouse using the mouse utility.
Set the password to secure your computer.
Enable or disable ports. Disabling ports releases resources to
the system. To change the serial settings, click Advanced on
the Basic/Advanced tab.
Switch between Advanced mode (additional screens with
advanced settings) and Basic mode of display.
Printer
Initial Setting
Touchpad
Power On Password
Enable Ports
Basic/Advanced
✍ For more information about each option, click Help on the Sony Notebook Setup
screen to display the Help file.
84
Controlling Power Management
Controlling Power Management
The PowerPanel utility allows you to control the power management of your
notebook computer and provides key information about system activity and
battery life. The following sections briefly describe how to conserve your
computer’s battery power. You can also refer to PowerPanel Help for more
detailed information. To activate a profile or command, see “Displaying Battery
Information” .
Viewing the Power Management status icons
The Power Management status icons are displayed in the task tray at the lower
right side of your screen. Move the pointer over the icons to see the tool tip that
displays information about the active profile. The Battery status icon indicates of
battery power level and the CPU status icon indicates the performance level of
the CPU.
To activate the Power Management Toolbar
1
Right-click on the taskbar at the bottom of the screen.
2
Select Toolbars from the pop-up menu, and then click Power Management.
The Power Management toolbar appears on the taskbar.
The current profile icon is highlighted on the Power Management toolbar. It is
the first icon farthest to the left, and its appearance changes depending on which
power management profile is currently selected. To change the power
management profile, click the current profile icon, and then select a profile from
the pop-up list. See “Power Management Profiles” for a description of available
options.To select another power management profile, click that icon in the Power
Management toolbar.
✍ When you use the battery pack to power your notebook, your system selects the
Maximum Battery Life power management profile by default. If you select a different
power management profile while using battery power, that profile is selected
automatically the next time you use the battery pack to power your notebook.
Refer to the PowerPanel Help for information on customizing the Power Management
toolbars.
85
VAIO Notebook User Guide
You can change the power management settings, such as the system timer and the
brightness of the screen.
To customize power management settings
1
Click the Current Profile icon on the Power Management toolbar.
2
Select Edit/Create Profiles from the menu.
3
Click a profile whose setting you want to change from the list in the left
field.
4
Double-click an item whose setting you want to change from the list in the
right field.
5
Click the desired setting.
6
Click the File menu, and then click Save.
7
Click the File menu, and then click Exit.
Power Management Profiles
The PowerPanel utility provides several predefined power management profiles.
Each profile consists of a group of power management settings that are designed
to meet specific power management goals—ranging from maximum power
management to no power management. You can change the settings for any of
the predefined profiles (except for the Disable Power Management profile), or
you can create your own profile to suit your portable computing needs. The
predefined profiles are:
Icon
Description
Maximum Performance
Provides the best system performance while still conserving power.
Maximum Battery Life
Provides power saving features to give you maximum battery life and good
performance. It slows the computer and puts it into Standby mode after a
specified time period.
Disable Power Management
Turns off all power management features such as Standby and Hibernate modes.
You can not change the settings of this profile.
86
Controlling Power Management
Icon
Description
AC Power
The power management state when AC power is in use. Similar to the Power
Management Off setting. Power Management automatically loads the AC profile
unless you disable this feature.
Games
Disables the display and the Hard Disk Standby timer.
Presentation
Keeps the display on at all times while it conserves power. This option is ideal for
slide show presentations. You can establish settings for LCD (Video) Standby,
Hard Disk Standby, and Standby mode to optimize power management for your
system.
Camera
Optimizes performance and power requirements for camera usage.
DVD
Optimizes performance and power requirements for DVD usage.
Word Processing
Optimizes power management with longer timeouts on the hard disk and display
screen. You can also establish settings for LCD (Video) Standby, Hard Disk
Standby, and Standby mode to optimize power management for your system.
Spreadsheet
Optimizes performance and power requirements for spreadsheet applications.
Communications
Extends battery life by initiating a quick display timeout. The Internal modem
remains powered. You can also establish settings for LCD (Video) Standby, Hard
Disk Standby, and Standby mode to optimize power management for your
system.
Automatic Profile Selection
Automatically switches to a profile suitable for active applications.
87
VAIO Notebook User Guide
Power Management Commands
PowerPanel also provides power management commands that you can use to
activate specific power management functions and to control power for a specific
device. You can use these commands to override a profile setting or initiate an
immediate action.
Icon
Description
Standby
Puts the system into Standby mode, a power management state that saves the
state of the system and peripheral devices in memory (RAM). Power
consumption reduces to a minimum, and the system remains on. To return the
system to the active state, press any key or the power button on your computer.
Hibernate
Provides for the lowest level of power consumption. The system writes the state
of the system and peripheral devices to the hard disk and turns off the system
power. To return the system to the original state, use the power button to turn
on power. The system saves the data in the Save to Disk Partition on the hard
drive.
LCD (Video) Standby (Windows Me™ only)
Turns off the video display to save power. If you turn off the Video Standby
timer, the display remains active except when the system enters Standby mode.
The video display system is one of the largest consumers of power in the
system.
Conserving Battery Power
When using the notebook with a battery, the LCD display and the hard drive can
be set to switch off automatically to conserve battery power.
For details, see “Power Management Profiles”.
88
Displaying Battery Information
Displaying Battery Information
You can display information for each of the batteries in your computer. The
following sections briefly describe how to display your computer’s general
battery information. Refer to PowerPanel Help for more detailed information.
To activate the Battery Information toolbar
1
Right-click on the taskbar at the bottom of the screen.
2
Select Toolbars from the pop-up menu, then click Battery Information. The
Battery Information toolbar appears on the taskbar.
To view the total capacity remaining in the battery, place the pointer over the
batter status icon in the task tray on the lower right side of the screen.
Battery Information Toolbar
❑
Percentage indicator — Displays the percentage of the remaining capacity.
❑
Time indicator — Displays estimated time (hours/minutes) remaining
before the battery fully drains, also known as the time-to-empty.
Battery Icon Descriptions
Battery icon
Battery status
Charging
Fully charged
Discharging
No battery
89
VAIO Notebook User Guide
Displaying Detailed Battery Information
Double-click the battery icon on the task tray to display the Battery Information
window. The screen appears displaying the Battery tab, which contains
information such as the estimated time-to-empty and charging time.
Battery Information Window
Customizing the Battery Information toolbar and alarm system
You can customize the Battery Information toolbar and modify the alarm
settings, to suit your portable computing needs. Refer to PowerPanel Help for
more information.
90
Selecting the Display Mode
Selecting the Display Mode
This notebook uses the Intel® video controller, which enables you to select the
desired display when the notebook is connected to an external monitor. When
you connect an external display, you can switch the display mode between your
notebook’s LCD display and the external monitor.
To select the display mode, proceed as follows: (See also “Connecting an
External Display” .)
✍ Connect an external display before you turn on the computer.
1
Click the Start button, point to Settings, then point to Control Panel.
2
Click Display, to access the Display Properties window.
3
Click the Settings tab, then click the Advanced button, to display the Intel®
82815 Graphics Controller Properties dialog box.
Intel® 82815 Graphics Controller Properties Screen
91
VAIO Notebook User Guide
4
Click the Intel® 82815 Graphics Technology tab, then click the Graphics
Properties button. If you are connecting only to TV, go to step 7.
5
Click the Driver Configuration tab.
6
Make sure that the Synchronous Display Mode box is selected, then click
Apply. If you want to use the TV as a display, deselect the Synchronous
Display Mode box, then click Apply. You cannot use the TV and another
display simultaneously.
7
Click the Device tab.
8
Select the type of display.
✍ You may not be able to display the notebook LCD screen and an external display or
projector at the same time, depending on the types of computer displays and
projectors you are using.
If the display resolution of your computer is more than 800 x 600 dots, a part of the
image will not show up on your TV display. To see the hidden area, move the cursor on
your computer. To display the full image, change the display resolution settings to 640
x 480 dots.
Turn on the computer after you turn on the peripheral devices.
Changing the Window Design of Sony Software
To change the window design
1
Click the Start button, point to Settings, then point to Control Panel.
2
Click UI Design Selector.
3
Click << or >> and select the desired design.
4
Click Apply.
5
The “UI Design Selector” window design changes. The window design for
your Sony software will match the “UI Design Selector” window.
6
To try another selection, click << or >> then click OK.
7
The UI Design Selector closes and the Sony software window design
displays.
92
Selecting the Display Mode
✍ This feature is available with UI Design Selector-compatible software only.
93
VAIO Notebook User Guide
94
Adding Memory
In the future you may want to install memory modules to expand the
functionality of your computer. You can increase memory up to 512 MB
(256 MB x 2), by installing optional memory modules. 256 MB of memory is
pre-installed (256 MB x 1). You can add an expansion memory module (64 MB,
128 MB, or 256 MB) in the memory module bay. Expansion memory modules
are available as options. For memory upgrades, use only PC100 (CL2) SDRAM
SO-DIMM (gold lead contacts).
!
Make sure you observe the proper safety precautions when you install memory modules in your computer. See the bulleted list below. Be careful when adding memory.
Mistakes when installing or removing a memory module may cause a malfunction.
Before you start
❑
The procedures described below assume you are familiar with the general
terminology associated with personal computers and with common safety
practices required for using and modifying electronic equipment.
❑
Disconnect your system from its power source and from any
telecommunications links, networks, or modems before you open the system
or follow any of the procedures described below. Personal injury or
equipment damage may result from failure to take these precautions.
❑
Electrostatic discharge (ESD) can damage memory modules and other
components. Perform the procedures described below only at an ESD
workstation. If such a station is not available, do not work in a carpeted area,
and do not handle materials that produce or hold static electricity
(cellophane wrappers, for example). Ground yourself by maintaining contact
with an unpainted metal portion of the chassis while performing the
procedure.
❑
Do not open the memory module package until you are ready to install the
module. The package protects the module from ESD.
❑
Use the special bag for preventing ESD or use aluminum foil when you store
the memory module.
95
VAIO Notebook User Guide
Typical expansion memory configuration
Total System Memory (MB)
Slot 1 (MB)
Slot 2 (MB)
320
256
64
384
256
128
512
256
256
To remove a memory module
1
Shut down your computer and disconnect all peripheral devices, such as
your printer.
2
Unplug the computer and remove the battery pack(s).
3
After the computer has cooled, loosen and remove the screw that secures the
cover of the memory bay on the bottom of your computer. Use an
appropriate screwdriver.
Removing the memory module cover
Screwdriver
Screw
4
96
Touch a metal object (such as the connector panel on the back of your
computer) to discharge any static electricity.
Adding Memory
5
Remove the memory module.
Removing memory module
1
2
1
1 Pull the tabs in the direction of the arrows.
The memory module is released.
6
2 Pull the memory module in
the direction of the arrow.
Tighten the screw on the memory bay cover.
✍ Your computer comes with a memory module installed in the memory slot. To
upgrade your memory, remove this module from the slot before installing your
upgrade memory module.
To install a memory module
1
Follow steps 1 to 4 of “To remove a memory module.”
2
Remove the memory module from its packaging.
97
VAIO Notebook User Guide
3
Install the memory module.
Installing memory module
1 Slide the memory module into the slot.
4
2 Press the module into place until it clicks.
Tighten the screw on the cover of the memory bay.
To view the amount of memory
1
Restart the computer.
2
Click the Start button on the Windows status bar, point to VAIO option, and
click “Sony Notebook Setup.”
The Sony Notebook Setup screen appears.
3
98
Click the “About This Computer” tab to view the amount of system memory.
If the additional memory is not shown, repeat steps 1 through 4 in “To install
a memory module.”
About the Software on Your
Notebook
Your VAIO notebook is ready to help you work, play, learn, and communicate as
soon as you turn it on. This section gives you the following:
❑
An overview of the various software that come with your computer and the
activities you can perform with your software
❑
Software support information
❑
Details on your Sony application and system recovery CDs
Overview
Adaptec Easy CD Creator® and DirectCD™
Adaptec, Inc.
Adaptec Easy CD Creator makes it easier than ever to create music, photo, video, and data
CDs. It enables you to access music on the Internet, fine-tune your music tracks, edit and
enhance photos and videos with a pro’s touch. Save and share data with confidence. With
DirectCD, CD recording has become as easy as using a disk drive or floppy disk. You can
save files directly from your application software directly to your CD-R disc; you can drag
and drop files, rename files, delete files, and create new directories right on the CD-R.
Adobe Acrobat Reader®
Adobe Systems Inc.
Acrobat Reader software allows you to view, navigate, and print electronic documents in
Adobe Portable Document Format (PDF), an open file format that is intended to preserve
the fidelity of documents created on all major computer platforms.
Adobe PhotoDeluxe® Home Edition
Adobe Systems Inc.
Create amazing photo effects with Adobe PhotoDeluxe. Without learning complex
software, you can enhance, restore, and be creative with your photos. Includes built-in
guided activities, stock photos, clip art and templates to assist you.
99
VAIO Notebook User Guide
Adobe Premiere® LE
Adobe Systems Incorporated
Adobe Premiere LE offers an interface and editing tool for producing movies for video,
multimedia, or the Web. View source clips and edited footage simultaneously on the
monitor window. Create video clips up to three hours long with complete audio-video
synchronization.
America Online® (Windows Me only)
America Online
America Online is a popular Internet online service. Stay in touch with family and friends
with easy-to-use e-mail, manage your personal finances, get the latest news and sports
scores, and chat with thousands of others who share your interests.
ArcSoft® PhotoPrinter™ 2000 Pro
ArcSoft, Inc.
ArcSoft PhotoPrinter 2000 is an easy-to-use, advanced printing program that lets you
quickly lay out multiple images in multiple sizes on a single sheet of paper. PhotoPrinter
Pro offers a wide selection of templates including landscape, portrait, free style, mixed
sizes, custom templates and more. The application includes enhancement tools and special
effects for improving photos while giving you the ability to add text to any image.
CompuServe® 2000 (Windows Me only)
CompuServe, Inc.
CompuServe is the most comprehensive source of organized business and educational
information online today. CompuServe allows you to access the vastness of the Internet,
without wasting time wading through it. Maximize your time online with CompuServe.
DVgate™
Sony Electronics
Connect a digital video camera recorder to the i.LINK*® connector and capture your own
video clips and still images. You can edit clips from your video, add others, and combine
clips into new movie segments. You can also save your images in a variety of popular file
formats.
* i.LINK is a SONY trademark used to designate that a product contains an IEEE 1394 connector. All products with an i.LINK connector may not communicate with each other.
100
Overview
EarthLink Network TotalAccess® (Windows Me only)
EarthLink Network, Inc.
An Internet Service Provider that supplies access, information, and assistance to its
customers, introducing them to the Internet. Member benefits include e-mail, newsgroups,
a personal start page, a free 6 MB web site, a member newsletter, and 24-hour technical
support.
McAfee® VirusScan®
Network Associates, Inc.
Protect your computer from viruses. VirusScan can detect viruses from floppy disks,
Internet downloads, e-mail attachments, intranets, shared files, CD-ROMs, and online
services.
Media Bar™
Sony Electronics
Media Bar software is your all-in-one solution for audio/video playback. Media Bar
software handles all common computer multimedia formats and controls selected Sony
devices. In addition to audio/video library cataloging and playlist management, Media Bar
software includes digital video quality control and effects features. Media Bar software
seamlessly integrates a variety of new media formats with an easy-to-use software
interface.
Microsoft® Internet Explorer
Microsoft Corporation
Internet Explorer delivers the web the way you want it. It is safe, easy to use, and you can
personalize how you access the web. Outlook Express and other tools in Internet Explorer
also help you have a great experience when you are on the web.
Microsoft® Word 2000
Microsoft Corporation
Microsoft Word 2000 makes it easy to create shared Web, e-mail, and print documents for
use around the world. It embraces HTML as a first-class file format and extends Word’s
ease-of-use to the Web and e-mail. Word 2000 also extends that ease-of-use to
international users, making it simple to create multilingual documents.
MovieShaker™
Sony Electronics
Sony’s original MovieShaker software creates personal movies that have transitions,
background music and text. Just import your video clips and “shake” with a click of the
mouse. Your personal movies are easy to create and fun to share with family and friends.
(See “MovieShaker™” below.)
101
VAIO Notebook User Guide
Netscape Communicator®
Netscape Communications
Netscape Communicator is an all-in-one Internet tool that makes it easy to browse the
web, send Internet e-mail, chat, read newsgroups, and compose great web documents.
PictureGear™
Sony Electronics
This image management software displays images from your hard drive, a Sony digital
still camera, or a Sony Mavica® camera. The images appear in a convenient light-table
format, so that you can easily view the contents of an entire folder. (See “PictureGear™”
below.)
Prodigy Internet® (Windows Me only)
Prodigy Communications Corporation
An online service that helps you find what you need online faster and smarter. Prodigy
delivers powerful online content such as sports scores, stock quotes, news, and easy access
to Excite, plus quality customer service, all at a competitive price.
Quicken® 2001
Intuit, Inc.
Quicken is a fast, easy way to organize your finances. Quicken works just like your
checkbook, so it is easy to learn and use. Quicken manages all your finances, bank
accounts, credit cards, investments, and loans. You can even pay your bills online.
Smart Capture
Sony Electronics
Smart Capture is a fun new way to send multimedia messages via e-mail. Smart Capture
manages the i.LINK*® connection between your computer and a Sony Digital
Handycam® Camcorder that supports the i.LINK interface. It allows you to capture
compressed video or still images that you can save or share via e-mail. A smart solution to
computer, digital audio/video and network convergence.
Smart Connect (Windows 2000 only)
Sony Electronics
Smart Connect allows you to use an i.LINK cable to connect your VAIO computer to
another VAIO computer that supports Smart Connect. You can then use one computer to
copy, delete, and edit files on the other computer. You can also print from a printer
attached to either computer.
102
MovieShaker™
Sound Forge® XP
Sonic Foundry
Sound Forge XP allows you to put powerful audio processing tools and effects to work on
your notebook. Simply cut, copy, and paste your way to striking multimedia files for use
in everything from Web pages to desktop presentations.
WinDVD®
InterVideo, Inc.
WinDVD is a simple-to-use DVD player combining all the features you would expect to
find in a standard consumer DVD player, in addition to some very advanced functionality,
such as full VCD 2.0 support, full precision video decode, a choice of user interfaces, and
video display options. You can play DVD titles or Video CDs. WinDVD automatically
determines the type of disc in the DVD drive and uses the correct playback method.
MovieShaker™
This application can be used to create fun and innovative movies without any
knowledge of film editing. In a few simple steps, motion pictures can be
combined with special effects, still images (pictures), and music files and then
saved in a format most computers can play.
Main Window
Working Panel
Editing trays
Clip tray
Help
Product tray
Trash
Importing Images and Sound Clips
1
Click
(File Import) or
2
Find the file you want to add.
3
Select the file.
(DV Import).
103
VAIO Notebook User Guide
4
✍
104
Click Open. The file is added to the Clip tray.
Importing files over 75 seconds in length may cause MovieShaker Software to stop
responding.
MovieShaker™
Create a Movie using Shaker
After adding clip(s) to the Clip tray, you can create a short movie using the
Shaker feature. Shaker randomly select clips from the Clip tray to create a 30second scene.
1
Click the Shake tab.
2
Select a mood by clicking a face in the Shaker tray.
Shaker Tray
3
Click
. A thirty second scene is automatically generated and
saved to the Product tray.
4
To preview, switch the Work Panel to Product tray mode and press play.
✍ Scenes created with Shaker begin with black frame and after processing are placed in
the first available slot on the Product tray. Limit the number of scenes placed on the
Product tray to 10 or less. MovieShaker Software may stop responding if too many
scenes are placed on the Product tray.
105
VAIO Notebook User Guide
Editing Clips and Scenes
You can edit your movie by adding effects and text, adjusting the color and
contrast, and modifying the length of clips.
Working Panel
Sound
Color
Monitor
Speed
Effect Palette
Trim Palette
Effect Knobs
Adding effects to a scene or a clip:
1
Double-click the clip or scene to move it to the Working Panel.
2
Select the Effects tab from the Editing tray.
3
Drag and drop the Effect you want to add from the Effects tray to the Effects
palette on the Working Panel.
✍ To preview an Effect, click on the clip in the Working panel monitor. Your clip displays
with the new effect on the Effect tray monitor.
4
See help for instructions on adjusting effect duration and replaying clips/
scenes.
Saving a Movie
1
Verify that the clip(s) you want to save is on the Product tray. See Help for
more details on saving movies.
2
Click Export.
106
PictureGear™
3
Select the format in which you want the document to be saved.
4
Click Next.
5
Locate the folder to which you want the file saved.
6
Name the file.
7
Click Save.
!
Exporting movies may take a long time to complete—Save movie as DV (Digital
Video) takes the longest and Quick-Save is the fastest. MovieShaker Software
can play video files up to 65 MB in length.
✍ For DV playback and smooth video playback, we recommend the following resolution/
refresh rates: 1024 x 768/75 Hz or lower.
PictureGear™
PictureGear Software is a digital image management application that allows you
to see all the images stored in any directory on your computer. Thumbnail views
provide quick reminders of your pictures. Brighten, contrast, enhance, resize,
crop, and color-correct your pictures. Create panoramic views, animations,
screen savers, wallpaper, still pictures from MPEG, and even html photo albums.
Managing Your Pictures
Use the collection feature to manage your pictures.
1
Click the Folder tab and browse to locate your pictures.
2
Select the pictures you want to have in a collection.
3
From Collection menu, select Create New Collection.
4
Enter a name for the collection and then click okay.
Creating a Photo Album
1
Select the pictures you want to use to make an album.
2
From the Utilities menu, select Album Maker.
3
Choose the type of Album you want and click Okay.
107
VAIO Notebook User Guide
4
Now add more pictures, frames, text, and effects.
5
When you are finished, select Create Album in File menu or click the Create
Album icon on the toolbar.
6
Designate the folder you where want to save the Album.
7
Enter the Target Album name, select Thumbnails and click Okay.
8
The new album can be viewed using most internet browsers.
Using Panorama Maker
Panorama Maker stitches a group of still images into a 360 degree panoramic
picture. The source images should be the same size and overlap 20%.
How to stitch a panoramic picture:
1
Gather the source images into the same folder or collection.
2
Select the images you want to use.
✍ We recommend 12 landscaped or 16 portrait pictures.
3
From the Utilities menu select Panorama Maker.
4
Select the correct lens and click Okay. (If 35mm lens is selected the prompt,
does not appear; to select a different lens, click the lens icon.)
5
Click the panoramic icon, near the bottom of the window.
6
Click Full Stitch.
Making Still Images and Panoramic from MPEG
1
Select the MPEG file.
2
From the Movie/Sound menu, select Scene break down.
3
Then select Movie Stitch, to create a panoramic picture.
108
Software Support Information
Software Support Information
Adaptec, Inc.
Web site
http://www.adaptec.com/
phone
408-945-8600
fax
408-262-2533
Acrobat® Reader, Adobe PhotoDeluxe® Business Edition, Adobe
Premiere® LE (Adobe Systems Incorporated)
Web site
http://www.adobe.com/
phone
206-675-6126 (fee-based support)
e-mail
techdocs@adobe.com
hours
M-F, 6 AM-5 PM PT
America Online® (America Online)
Web site
http://www.aol.com
phone
800-827-3338
hours
7 days a week, 24 hours a day
CompuServe® 2000 (CompuServe, Inc.)
Web site
http://www.compuserve.com
phone
800-848-8990
EarthLink Network TotalAccess® (EarthLink Network, Inc.)
Web site
http://help.earthlink.net/techsupport/
phone
800-395-8410
e-mail
support@earthlink.net
hours
7 days a week, 24 hours a day
McAfee® VirusScan® (Network Associates, Inc.)
Web site
http://support.mcafee.com
phone
408-988-3832
e-mail
cybr@nai.com
hours
M-F 9AM-5PM Central Time
109
VAIO Notebook User Guide
Netscape Communicator® (Netscape Communications Corporation)
Web site
http://www.netscape.com/
phone
888-4SONYPC (888-476-6972)*
hours
7 days a week, 24 hours a day
PhotoPrinter™ 2000 Pro (ArcSoft, Inc.)
Web site(s)
http://www.arcsoft.com
http://www.photoisland.com
phone
510-440-9901
fax
510-440-1270
e-mail
techsupport@arcsoft.com
hours
M-F, 8:30 AM-5:30 PM PT
Prodigy Internet® (Prodigy Communications Corporation)
Web site
http://www.prodigy.com
phone
800-213-0992
hours
7 AM - 3 AM ET
Quicken® 2001 (Intuit Inc.)
Web site
http://www.intuit.com/support
phone
900-555-4688
hours
7 days a week, 24 hours a day
Windows® Operating System, Internet Explorer (Microsoft Corporation)
Web site
http://www.microsoft.com/support/
phone
888-4SONYPC (888-476-6972)*
hours
7 days a week, 24 hours a day
* Support from 1-888-4SONYPC is free of charge for 90 days after the original date of purchase.
WinDVD®
Web site
http://www.intervideo.com
phone
510-651-0888
110
Application, System, and Driver Recovery CDs
Sony Service Center
For the Sony Service Center nearest you, call 1-888-4SONYPC (1-888-4766972) or find Sony Customer Service on the Web at http://www.sony.com/
pcsupport.
Application, System, and Driver Recovery CDs
Your computer comes with the following application and system recovery CDs.
(To use your recovery CDs, see “Using Your Recovery CDs” .)
Application Recovery CD(s)
Sony Electronics
This program allows you to reinstall individual applications and device drivers. Use it to
restore corrupted or accidentally erased files.
System Recovery CD(s)
Sony Electronics
This program allows you to restore the software titles that shipped with your computer if
they become corrupted or are erased accidentally. It can be used only to restore the hard
disk of this Sony computer.
Driver Recovery CD(s)
Sony Electronics
This program allows you to reinstall individual device drivers. Use it to restore corrupted
or accidentally erased files.
111
VAIO Notebook User Guide
Using Your Recovery CDs
The following sections describe how to use the Application Recovery and
System Recovery utilities.
Using the Application Recovery CD(s)
The Application Recovery CD(s) allows you to reinstall individual applications if
they become corrupted or are accidentally erased. Reinstalling an individual
software title may correct a problem you are experiencing with your computer or
software application; you may not need to reinstall the entire contents of your
hard drive. If you need to reinstall all the software titles that shipped with your
computer, use the System Recovery CD(s). See “Using the System Recovery
CD(s)” .
You can also use the Application Recovery CD to install Windows 2000 drivers
on your computer.
✍ You must be in Windows to run the Application Recovery CD. If you have any
questions on using the Application Recovery CD, contact Sony Customer Support.
To use the Application Recovery CD(s)
1
Turn on your computer. If your computer is already on, close all
applications.
2
When the Windows desktop appears, insert the Sony Application Recovery
CD in the optical drive. The Application Recovery utility loads
automatically.
3
When the Application Recovery menu appears, select the icon for the
application you want to restore and then follow the on-screen instructions to
complete the recovery process.
✍ Your system may include one or two Application Recovery CDs. If you have two
Application Recovery CDs, insert the first CD to run the Application Recovery
program. You may be prompted to insert the second CD, depending on the application
you wish to restore.
112
Using Your Recovery CDs
Using the System Recovery CD(s)
You can reinstall software titles that shipped with your computer if they are
corrupted or erased. You may not need to recover the entire contents of your hard
drive. If you experience a problem with your computer, reinstalling an individual
device driver or software title may correct the problem. Use the Application
Recovery CD(s) to reinstall individual applications or device drivers. See “Using
the Application Recovery CD(s)” .
The System Recovery CD contains a backup copy of all the software originally
installed on your hard disk drive. It can be used only to recover the hard disk
of the notebook you purchased.
The System Recovery utility gives you Full Restore with Format, that is it
formats the hard disk drive then restores all the original software.
!
Full Restore with Format removes all the information on the hard disk drive. You
will lose any software you have installed and any other files you have created
since you started to use your computer. This means you will have to reinstall any
applications that were not included with the computer when you purchased it. If
you have any questions on using the System Recovery CD, contact Sony Customer
Support.
To use the System Recovery CD(s)
1
Insert the Sony System Recovery CD in the optical drive.
2
Shut down your computer as described in “Shutting Down Your Computer” .
3
Wait four seconds and turn on your computer.
4
Click OK to signify you have read and accept the Microsoft End-User
License Agreement.
5
When the System Recovery menu appears, follow the on-screen instructions
to complete the recovery process.
If your computer does not start from the Recovery CD
1
Press the power button and hold it for more than four seconds to turn off the
computer.
2
Turn on the computer. When the Sony logo is displayed, press the F2 key.
The BIOS setup menu screen appears.
113
VAIO Notebook User Guide
3
Press the arrow keys to select the Exit menu.
4
Press the arrow keys to select “Get Default Values” and then press the Enter
key. The message “Load default configuration now?” appears.
5
Check that “Yes” is selected, then press the Enter key.
6
Press the arrow keys to select “Exit” (Save Changes) and then press the
Enter key. The message “Save configuration changes and exit now?”
appears.
7
Check that “Yes” is selected, then press the Enter key. The computer restarts
from the Recovery CD.
✍ Your system may include one or two System Recovery CDs. If you have two System
Recovery CDs, insert the first CD to run the System Recovery program. You are
prompted to insert the second CD once the information from the first CD has been
installed.
The recovery process takes from 30 to 60 minutes to complete.
After recovering your system using the SRCD, you may be prompted to insert your
ARCD after restarting Windows. Insert the ARCD to automatically complete recovery
of your system.
Using the Driver Recovery CD(s)
The Driver Recovery CD utility allows you to reinstall individual drivers and
repair software applications if they become corrupted or are accidentally erased.
You can reinstall an individual driver to correct a problem that you are
experiencing with your computer, hardware, or software application. VAIO
Support Agent uses a vault feature on the Driver Recovery CD(s) to repair
software applications.
✍ You must be in Windows to run the Driver Recovery CD utility.
To use the Driver Recovery CD(s)
1
Turn on your computer. If your computer is already on, close all
applications.
2
When the Windows desktop appears, insert the Driver Recovery CD in the
optical drive. The Driver Recovery utility loads automatically.
114
Using Your Recovery CDs
3
When the Driver Recovery menu appears, follow the on-screen instructions
to complete the recovery process.
To repair software applications using VAIO Support Agent
The Driver Recovery CD utility has an information vault that contains the
original characteristics for the preinstalled software applications that are
protected by VAIO Support Agent.
115
VAIO Notebook User Guide
116
Troubleshooting
This section describes how to solve common problems you may encounter when
using your notebook. Many problems have simple solutions, so try these
suggestions before you contact Sony PC Support (http://www.sony.com/
pcsupport).
Troubleshooting your notebook
(Windows Me only) When starting your notebook for the first time, the VAIO
InitManager dialog box will appear. Please select “OK” to begin initial setup. If
you do not execute the initial setup, you cannot use part of VAIO original
hardware functions such as Power Management tool, scroll function of touchpad,
and keyboard shortcut key function combined with the Fn key.
My notebook does not start
❑
Check that the notebook is plugged into a power source and that it is turned
on. Check that the power indicator on the front panel of the notebook
indicates that the power is on.
❑
Check that the battery packs are inserted properly and that they are charged.
❑
Make sure there is no diskette in the floppy disk drive.
❑
Confirm that the power cord and all cables are connected firmly, as
described in “Connecting a Power Source” .
❑
If you plugged the notebook into a power strip or UPS, make sure the power
strip or UPS is turned on and working.
❑
If you are using an external display, check that it is plugged into a power
source and turned on. Check that the brightness and contrast controls are
adjusted correctly. See the manual that came with your display for details.
❑
Moisture condensation may have occurred. Do not use the notebook for at
least one hour and then turn on the notebook.
❑
Take the battery pack off the notebook, unplug the power cord and plug it
again, then turn on the power.
117
VAIO Notebook User Guide
My notebook starts, but my system doesn’t start properly
❑
When the internal backup battery is low on power, it may not start your
system properly. The message “Press <F1> to resume, <F2> to setup”
appears at the bottom of the screen. Follow these steps:
1
Press F2. The BIOS Setup menu appears.
2
Set the date (month/day/year). Press Enter.
3
Press Ð to select System Time, then set the time (hour: minute:
second). Press Enter.
4
Press Î to select Exit, then press Ð to select Get Default Values. The
message “Load default configuration now?” appears.
5
Select Yes and press Enter.
6
Select Exit (Save Changes), and then press Enter. The message “Save
Configuration changes and exit now?” appears.
7
Select Yes, and then press Enter. The notebook restarts.
My notebook starts, but the message “Operating system not found” appears
and Windows does not start
❑
Make sure there is no diskette in the floppy disk drive (non-bootable).
❑
If a non-bootable diskette is in the drive, follow these steps:
❑
118
1
Turn off the notebook, and then remove the diskette.
2
Restart the notebook and confirm that Windows starts properly.
If Windows still does not start, follow the steps below to initialize the BIOS:
1
Remove any diskette from the floppy disk drive.
2
Turn off the notebook.
3
Remove any peripheral devices connected to the notebook.
4
Turn the notebook back on.
5
Press the F2 key when the Sony logo appears. The BIOS setup menu
screen appears.
6
Press the directional arrow keys to select the Exit menu.
Troubleshooting
7
Press the arrow keys to select “Get Default Values” and then press
Enter. The message “Load default configuration now?” appears.
8
Select Yes, then press Enter.
9
Use the directional arrow keys to select “Exit” (Save Changes), and then
press Enter. The message “Save configuration changes and exit now?”
appears.
10 Select Yes, then press Enter. The notebook restarts.
If your notebook continues to display the message “Operating system not found”,
and Windows does not start, contact Sony Customer Support.
My notebook stops responding or does not shut down
It is best to shut down your notebook using the Shut Down command on the
Windows Start menu. Using other methods, including those listed here, may
result in loss of unsaved data.
❑
Try restarting the notebook. On the Windows taskbar, click the Start button,
click Shut Down, and then click Restart.
❑
(Windows Me) If you cannot restart as described in the preceding step, you
can restart the notebook by pressing Ctrl+Alt+Delete (at the same time)
twice.
(Windows 2000) If you cannot restart as described in the preceding step, you
can restart the notebook by pressing Ctrl+Alt+Delete (at the same time) and
clicking Shut Down on the Windows Security screen.
❑
If the previous step does not work, press and hold the power button for at
least four seconds. This turns off the power.
❑
(Windows Me) If your notebook stops responding while playing a CD or
DVD, stop the CD/DVD, and restart the notebook by pressing
Ctrl+Alt+Delete (at the same time) twice.
(Windows 2000) If your notebook stops responding while playing a CD or
DVD, stop the CD/DVD, and restart the notebook by pressing
Ctrl+Alt+Delete (at the same time) and clicking Shut Down on the Windows
Security screen.
❑
Unplug the notebook from the AC adapter and remove the battery pack from
your notebook.
119
VAIO Notebook User Guide
✍ Pressing Ctrl+Alt+Delete (at the same time) or turning off the notebook with the power
switch may result in data loss in files that are currently open.
My notebook does not enter the power saving mode I selected. (Windows Me
only)
❑
Click Start, point to Program, point to Accessories, point to System Tools,
and then click System Information.
The Help and Support window appears.
❑
Click System Configuration Utility under the Tools menu.
❑
Click the Advanced button on the General tab, and Confirm the following
information:
1
Enable Deep Sleep is selected with a checkmark.
2
The message “Standby function is enabled” is displayed. If the message
reads “Standby function is disabled”, click the Enable button.
3
The message “Hibernate feature is enabled” is displayed. If the message
reads “Hibernate feature is disabled”, click the Enable button.
4
Click OK and restart your notebook.
The Power Management setting is not responding
Your notebook is unstable if a lower power state, such as system hibernate is
initiated and then changed before the notebook completely enters the lower
power state. To restore the notebook to its normal operating stability:
❑
Close all open applications.
❑
Push and hold the power button for four seconds or longer to shut down
the notebook.
The sound of my notebook’s fan is too loud
Use the PowerPanel utility to change the Thermal Control Strategy setting to
Quiet. This setting slows down the CPU speed. See PowerPanel Help for more
information.
120
Troubleshooting
Troubleshooting the LCD screen
My LCD screen is blank
❑
Check that the notebook is plugged into a power source and that it is turned
on.
❑
Check that the power indicator on the notebook is on.
❑
Check that the battery pack(s) is inserted properly and that they are charged.
❑
The notebook may be in LCD (Video) Standby mode. Press any key to
activate the screen.
❑
The display mode may be set to external display mode. Press and hold the Fn
key while pressing F7 several times.
My LCD screen continues to show the previous screen.
Press the Windows key and D key twice to refresh the screen.
The image on my connected external display is not centered or sized properly
Use the controls on your external display to adjust the image. See the manual that
came with your display for more information.
I want to change the video resolution of my display
You can use independent controls to change the video resolution of your display.
❑
Click Start, point to Settings, point to Control Panel, and then click the
Display icon.
The Display Properties dialog box appears.
❑
Click on the Settings tab.
❑
Move the Screen Area slider to change your video resolution.
I cannot switch the LCD display to TV and vice versa.
Remove the DVD video disc if it is inserted in the DVD-ROM drive.
121
VAIO Notebook User Guide
Troubleshooting the mouse and touchpad
My mouse does not work
❑
If you are using an external mouse, check that the mouse is plugged into the
mouse connector. See “Connecting an External Display” for details.
❑
If you are using an optional Sony USB mouse PCGA-UMS1 series, check
that the mouse is plugged into the USB connector.
My touchpad does not work properly
❑
You may have disabled the touchpad without a mouse being connected to the
notebook. To enable the touchpad:
1
Click Start, point to Programs, and click Sony Notebook Setup.
2
Click Touchpad tab.
3
Click Use touchpad, and then click OK.
❑
You must restart the notebook to make the touchpad work again.
❑
If your touchpad is interpreting a single tap as a double-click, you must
adjust the button assignments. Follow these steps:
1
Click Start, point to Control Panel, and then click on the Mouse icon.
2
Change the button assignments in the Mouse Properties dialog box.
(One of the buttons is assigned to the double-click action.)
The pointer does not move (while using the Touchpad or Mouse)
❑
Click the Start button on the Windows taskbar, and select Shut Down to
display the Shut Down Windows dialog box, then press Enter.
❑
(Windows Me) If you cannot turn off your notebook as described in the step
above, press Ctrl+Alt+Delete (at the same time) to restart the notebook.
(Windows 2000) If you cannot turn off your notebook as described in the
step above, press Ctrl+Alt+Delete (at the same time) and click Shut Down
on the Windows® Security screen to restart the notebook.
❑
If you cannot restart your notebook as described in the step above, press and
hold the power button for more than four seconds to turn off the notebook.
❑
If the pointer does not move while playing a disc, press Ctrl+Alt+Delete to
stop playback and restart the notebook.
122
Troubleshooting
Troubleshooting drives, PC cards and peripheral devices
My floppy disk drive can not write to a diskette
❑
If the diskette is write-protected, disable the write-protect feature or use a
diskette that is not write-protected.
❑
Check that the diskette is properly inserted into the floppy disk drive.
My optical drive is not playing my CD or DVD properly
❑
Make sure the label of the disc is facing up.
❑
If the disc requires software, make sure the software is installed according to
the manufacturer’s instructions.
❑
A dirty or damaged disc may cause the notebook to stop responding while it
tries to read the disc. If necessary, restart the notebook, remove the disc, and
then check it for dirt or damage.
❑
If you see video but can not hear audio, check all of the following:
❑
Check that your optical drive does not have the mute setting enabled.
❑
Check the volume setting in the audio mixer.
❑
If you are using external speakers, check the volume settings, and then
check the connections between your external speakers and the
notebook.
❑
Click Start >Control Panel > System > Device Manager. Check that the
correct drivers are installed properly.
❑
Do not use adhesive labels to identify the CD. The label may come off while
the disc is in use in the optical drive and cause the drive to malfunction.
❑
If a region code warning appears when you try to use your optical drive, it
may be that the DVD you are trying to play is incompatible with the optical
drive. Check the region code listing on the DVD packaging.
❑
Moisture condensation may have occurred. Leave the notebook idle for at
least 1 hour with the notebook turned on.
My optical drive tray does not open
❑
Make sure the notebook is turned on.
❑
Press the Eject button on the optical drive.
123
VAIO Notebook User Guide
❑
If the Eject button does not work, open the tray by inserting a sharp, pointed
object in the hole to the right of the Eject button.
I cannot use digital video (DV) devices. The message “DV equipment seems to
be disconnected or turned off” appears.
❑
Check that the DV device is turned on and that the cables are properly
connected.
❑
If you are using multiple i.LINK devices, the combination of the connected
devices may cause unstable operation. In this case, turn off your notebook
and all connected devices. Disconnect the devices that are not in use. Check
the connections for each device, then restart your notebook.
My PC card is not working
❑
Make sure the PC card is compatible with Microsoft® Windows®.
❑
Use the Sony Notebook Setup utility to disable devices you are not currently
using.
❑
If you are using two PC cards, use the Sony Notebook Setup utility to
disable the devices you are not currently using.
Troubleshooting software
My software program stops responding or crashes
Contact the software publisher or designated provider for technical support. See
the “Software Support Information” .
When I click an application icon, the message “You must insert the application
CD into your optical drive” appears and the software does not start
❑
Some titles require specific files that are located on the application CD.
Insert the disc and try starting the program again.
❑
Make sure you place the CD in the tray with the label side facing up.
I hear background “noise” while using Windows Media Player to play my music
CDs
Sony suggests using the preinstalled Media Bar software to play audio CDs.
124
Troubleshooting
Troubleshooting the modem
My modem does not work
❑
Check that the phone line is plugged into the line jack. See “Connecting a
Phone Line” for details.
❑
Check that the phone line is working. You can check the line by plugging in
an ordinary phone and listening for a dial tone.
❑
Check that the phone number the program is dialing is correct.
❑
Check that the software you are using is compatible with the notebook’s
modem. (All preinstalled Sony programs are compatible.)
My modem connection is slow
Your notebook is equipped with a 56K/V.90 compatible modem. Many factors
may influence modem connection speed, including telephone line noise or
compatibility with telephone equipment (such as fax machines or other modems).
If you think your modem is not connecting properly to other PC-based modems,
fax machines, or your Internet Service Provider, check the following:
❑
Have your phone company check that your phone line is free from any line
noise.
❑
If your problem is fax-related, check that there are no problems with the fax
machine you are calling and that it is compatible with fax modems.
❑
If you are having a problem connecting with your Internet Service Provider,
check that the ISP is not experiencing technical problems.
❑
If you have a second phone line available, try connecting the modem to that
line.
Troubleshooting audio
My speakers have no sound
If the built-in speakers are turned off, press Fn+F3 to turn on the speakers.
You can also turn on the speakers using the Jog Dial control.
❑
If the speaker volume is turned to the minimum, press Fn+F4, and then press
or ➜ to increase the volume or you can use the Jog Dial control to control
the volume.
➜
❑
❑
If nothing is displayed when you press Fn+F3 or Fn+F4.
125
VAIO Notebook User Guide
1
Double click System in Control Panel.
2
Set the sound device to enable in Device Manager.
❑
If your notebook is powered by batteries, check that the battery packs are
inserted properly and that they are charged.
❑
If you are using an application that has its own volume control, check that
the volume is turned up.
❑
Check the volume controls in Windows®.
❑
If you connect external speakers, check that the speakers are properly
connected and the volume is turned up. If the speakers have a mute button,
make sure it is off. If the speakers are powered by batteries, check that the
batteries are inserted properly and that they are charged.
❑
If you have connected an audio cable to the Headphone connector,
disconnect the cable.
My microphone does not work
If you are using an external microphone, check that the microphone is plugged
into the Microphone connector. See “Connecting an External Microphone” for
details.
Troubleshooting the printer
I cannot print
❑
The default setting for the printer port mode is correct for most printers. If
you cannot print, try changing the printer port mode. In Sony Notebook
Setup, select the Printer tab. If the printer port mode is set to ECP, change it
to bi-directional. If the printer port mode is set to bi-directional, change it to
ECP. See “Displaying the Sony Notebook Setup Screen” for details on using
Sony Notebook Setup.
❑
Your connected printer may not function after the notebook resumes from a
power saving mode. If this occurs, follow these steps to reset the printer
connection:
Windows Me Only
126
❑
Right-click My Computer icon on the desktop, then select Properties.
❑
Click the Device Manager tab.
Troubleshooting
❑
Select Refresh, then click OK. The printer should function properly.
Windows 2000 Only
❑
Double-click My Computer icon on the desktop, then double-click on
the Control Panel folder.
❑
Double-click on the Printers folder.
❑
Right-click on the icon of the printer that is not functioning, and select
Properties to access the Properties window.
❑
Click OK to close the Properties window. The printer should function
properly.
127
VAIO Notebook User Guide
128
Specifications
Specifications
The following table details the hardware specifications for your computer.
Model
PCG-FX290/290K
Processor
Mobile® Intel®
Pentium® III 1 GHz*
featuring Intel®
SpeedStep™ Technology†
L2 Cache Memory 256 KB (CPU Integrated)
Hard Disk Drive
C/D Partition
(Approximate)
30 GB‡
40% and 60%
Standard RAM
256 MB SDRAM
(Expandable to 512 MB)
LCD Screen
15.0” SXGA+ TFT
MPEG
Available
Graphics
Intel® 815 EM Chipset
integrated Graphic
Sound Capabilities
Windows® sound system
compatible, 3D surround
Analog devices
AD1881A
Floppy Disk Drive Removable 3.5" 1.44 MB
Optical drive
CD-RW/DVD-ROM
drive:
up to 24x max. CD-ROM
reading speed.
up to 8x max. CD-R
writing speed.
up to 4x max. CD-RW
writing speed.
up to 8x max. DVD-ROM
reading speed.**
Laser Diode
Properties
Wave Length: 785 nm and
660 nm
Laser Output: 485 µW
Modem
V.90/K56flex data/fax
compatible modem††
129
VAIO Notebook User Guide
Model
PCG-FX290/290K
Drive Bay
• Supports floppy disk
drive (included)
• Supports second
rechargeable battery
(optional)
Expansion
Capabilities
Type I/II PC cards and
Type III PC card with
CardBus support
Connection
Capabilities
•
•
•
•
•
•
•
•
•
•
•
Supplied
Accessories
• Floppy disk drive
• Rechargeable battery
• AC adapter and power
cord
• Weight saver
• Video cable
Power Source
19.5V DC/AC 100-240V
Power
Management
• Energy Star compliant
• Advanced
Configuration and
Power Interface (ACPI)
Battery
• Lithium-ion
• Supports dual battery
operation
Dimensions
12.8" (w) x 2.2" (h)*** x
10.5" (d)
(324 x 54.1 x 265.5 mm)
Weight
• 7.3 lbs. (3.3 kg) (with
battery and weight
saver)
• 7.7 lbs. (3.5 kg) (with
battery and floppy disk
drive)
130
2 USB ports
i.LINK‡‡
Serial
VGA monitor
Parallel (printer)
Phone line (RJ-11)
Microphone
Headphone
TV out
Port replicator
Ethernet
Specifications
Model
PCG-FX290/290K
Operating
Temperature
40º F to 95º F (+5º C to
35º C) temperature
gradient less than 50º F
(10º C) per hour
Operating
Humidity
20% to 80% (not
condensed), provided that
humidity is less than 65%
at 95º F (35º C),
hygrometer reading of
less than 84º F (29º C)
Storage
Temperature
-4º F to 140º F (-20º C to
60º C), temperature
gradient less than 18º F (10º C) per hour
Storage Humidity
10% to 90% (not
condensed) provided that
humidity is less than 20%
at 140º F (60º C),
hygrometer reading of
less than 95º F (35º C)
*
GHz denotes microprocessor internal clock
speed; other factors may affect application
performance.
† The processor may be reduced to a lower
operating speed when operating on battery
power.
‡ The size of your hard disk may differ if you
purchased a specially configured system.
GB means one billion bytes when referring
to hard drive capacity. Accessible capacity
may vary.
** If a region code warning appears when you
are using WinDVD, it could be that the
DVD you are trying to play is incompatible
with the optical drive in your VAIO
notebook. Region code indicators such as a
“1” or “ALL” are labeled on some DVDs to
indicate what type of player can play the
discs. Unless a “1” or “ALL” is identified on
your DVDs or on the packaging, you cannot
play the disc on this player.
131
VAIO Notebook User Guide
†† Maximum speed for faxing is 14.4 kbps.
Your 56K/V.90 compatible modem is
capable of downloading at 53 kbps. Your
online service or Internet Service Provider,
however, may not support this technology
or operate at this speed.
‡‡ i.LINK is a SONY trademark used to
designate that a product contains an IEEE
1394 connector. All products with an
i.LINK connector may not communicate
with each other.
***Height measured at thickest point. The
thinnest height for PCG-FX290/290K is
1.4"
NOTE: Specifications are subject to change without notice.
132
A
About This Computer tab 84
AC adapter 21, 27
AC power 27
AC Profile power setting 87
adding
hardware 65
memory 95
peripherals 65
printers 71
adjusting
brightness 34, 39
Alt key 36
Application Recovery CD 112
Applications key 36
attaching port replicator 66
Audio tab 84
B
Basic/Advanced tab 84
battery packs 21, 28
charge status icons 89
charging 29, 55
indicator lights 30, 37, 54
inserting 28
inserting into battery bay 28
loading 28
rechargeable 27
removing 31, 54, 56
BatteryScope utility 89
brightness
adjusting 34, 39
built-in speakers
See also speakers 39
buttons
Eject 45, 47
Start (Windows 98) 34, 83
C
cables
phone 21
power cord 27
cameras
digital video recorder 78
canceling commands 36
Caps Lock
indicator light 38
CD-ROM/DVD-ROM discs
ejecting 47
inserting 45
CD-ROMs
handling 49
charge status indicator light 30
charging battery packs 29, 55
choosing
power source 28
coin-operated telephones 62
computer
customizing 83
handling 18
lithium ion battery 6
setting up 21
setup screen 83
starting 33
troubleshooting 117, 124
unpacking 14
connecting
coin-operated telephones 62
digital video recorder 78
external speakers 80
hard drives 51
microphone 81
133
VAIO Notebook User Guide
monitor 71
multimedia computer display 72
multiple phone lines 62
network 51, 66
party phone lines 62
PBX 62
phone line 62
port replicator 66
power source 27
printer 71
projector 73
USB device 76
weight saver 57
connectors
DC In 27
network 66
printer 71
Serial port 66
correction keys 36
Ctrl key 36
cursor-movement keys 36
customizing your computer 83
D
DC In 27
digital video camera 78
disconnecting port replicator 69
diskettes
troubleshooting 123
display
mode 91
options 73
selecting 73
disposal of lithium ion battery 6
Driver Recovery CD 114
drives
floppy disk 21
installing additional hard disk
DV In/Out 78
DVD-ROM drive
134
closing tray 47
opening tray 45
using 45
DVD-ROM drive tray
troubleshooting 123
DVD-ROMs
handling 49
E
Eject button 45, 47
ejecting
battery packs 56
CD-ROM/DVD-ROM discs 47
weight saver 58
Energy Star 2
ergonomic considerations 16
Escape key 36
expansion memory configuration 96
external devices
display 73
See also monitor
speakers 39, 80
F
faxes
laws governing 6
floppy disk drive 21
cable 21
disconnecting 43
troubleshooting 123
Fn key 36
combination commands 39
function keys 36
H
51
handling 18
CD-ROMs and DVD-ROMs
handling the LCD screen 18
hard drives
indicator light 37
installing additional 51
49
Help
Mouseware
safety precautions
loading
battery pack 28
41
I
i.LINK 78
IEEE-1394 78
indicator lights 37
battery 30, 37, 54
Caps Lock 38
charge status 30
hard drive 37
Num Lock 38
Scroll Lock 38
input devices 5
Insert key 36
inserting
battery pack 28
CD-ROM/DVD-ROM discs
installation 17
installing
hard drives 51
hardware 65
memory module 97
peripherals 65
interference 5
M
maintenance 18
Maximum Battery Life power setting
86
Maximum Performance power setting
86
45
K
keyboard
6
36
L
LCD
lock lever 33
selecting to display output 73
troubleshooting 121
LCD screen
handling 18
lever
LCD 33
weight saver release 56
lithium ion battery
disposal 6
memory module
expansion 96
installing 97
removing 96
microphone
connecting 81
troubleshooting 126
modem
laws governing 6
troubleshooting 125
monitor
connecting 71
selecting 73
switching among 39
mouse
troubleshooting 122
Mouse Properties screen 41
Mouseware
accessing help 41
features 41
MovieShaker instructions 103
multimedia computer display 72
multiple phone lines 62
N
navigation keys 36
network
connecting 51
connector 66
port replicator 66
135
VAIO Notebook User Guide
Notebook Computer 21
Notebook Setup tabs 84
Num Lock
indicator light 38
O
opening
DVD-ROM drive tray 45
operator keys 36
output devices 5
adding 71
P
party phone lines 62
PBX 62
PC card
inserting 51
slots 51
troubleshooting 124
phone
cable 21
connecting line 62
jack 62
laws governing 6
PictureGear 107
port replicator
connecting 66
disconnecting 69
lever 69
network 66
power 37
cord 27
switch 33
power management
settings 85
Power Management Off power setting
86
Power On
Password tab 84
power saving modes 60
136
System Hibernation 39, 61
System Idle 60
System Suspend 60
Video Standby 39
power setting
AC Profile 87
Maximum Battery Life 86
Maximum Performance 86
Power Management Off 86
System Suspend 88
Video Standby 88
power source 27
power sources 28
connecting 27
PowerPanel
activating 85
customizing toolbar 86, 88
Print Screen key 36
printer
connecting 71
port 71
Printer tab 84
projector 73
R
radio interference 5
rechargeable battery packs 27,
recharging battery packs 29
Recovery CD 112
regulatory information 4
removing
battery packs 31
floppy disk drive 43
memory module 96
replacing
battery packs 54
restoring data 112
S
Scroll Lock
28
indicator light 38
second battery pack 28, 54
selecting
display 73
LCD 73
monitor 73
power source 28
Serial connector 66
setup screen
About This Computer tab 84
Audio tab 84
Basic/Advanced tab 84
displaying 83
Power On Password tab 84
Printer tab 84
Touchpad tab 84
setup tabs 84
Shift key 36
Shut Down Windows dialog box 34
shutting down 34
Software list 99
Sony Notebook Setup screen 83
Sony Service Center 111
speakers
external 80
switching 39
troubleshooting 125
volume 39
Specifications 129
Start button 83
starting
computer 33
startup problems 34
switching
display 39
monitor 39
System Hibernation mode 39, 61
System Suspend mode 39, 60, 88
T
touchpad 40
Touchpad tab 84
troubleshooting 117
startup 34, 117
turning on
computer 33
TV
interference 5
U
unpacking the computer
USB
connecting 77
connector 77
mouse 77
14
V
ventilation slot 25
video camera 78
Video Standby mode 39
viewing the amount of memory
volume control 39
98
W
weight saver
attaching 54
connecting 57
fold-out arm 57
removing 58
window design of Sony software
Windows 98
Explorer 36
Find window 36
help 36
key 36
key combinations 36
Start button 34
taskbar 34, 119
92
137
VAIO Notebook User Guide
138
