DocAve 6 Service Pack 3 SQL Server Data Manager User Guide

DocAve 6 Service Pack 3 SQL Server Data Manager User Guide
®
DocAve 6 SQL Server
Data Manager
User Guide
Service Pack 3
Revision A
Issued July 2013
DocAve 6: SQL Server Data Manager
1
Table of Contents
About DocAve SQL Server Data Manager ..................................................................................................... 4
Complementary Products ............................................................................................................................. 4
Submitting Documentation Feedback to AvePoint ...................................................................................... 4
Before You Begin........................................................................................................................................... 5
Configuration ............................................................................................................................................ 5
Agents ....................................................................................................................................................... 5
Required Permissions ............................................................................................................................... 5
Local System Permissions ..................................................................................................................... 6
Getting Started.............................................................................................................................................. 7
Launching SQL Server Data Manager........................................................................................................ 7
User Interface Overview ............................................................................................................................... 8
About the Staging Policy ............................................................................................................................... 9
Staging Policy Configuration Interface.......................................................................................................... 9
Managing Staging Policies......................................................................................................................... 9
Configuring Staging Policies .................................................................................................................... 10
Configuring the Specify Location Interface ......................................................................................... 11
About the Filter Policy................................................................................................................................. 11
Managing Filter Policies .......................................................................................................................... 12
Configuring Filter Policies ....................................................................................................................... 12
SQL Backup Analysis Builder ....................................................................................................................... 14
About InstaMount....................................................................................................................................... 16
Restore Analyzed SQL Backup Data ............................................................................................................ 16
Configuring a Restore Job ....................................................................................................................... 17
Site Collection Level Restore....................................................................................................................... 21
Checking a Job Status .................................................................................................................................. 22
Appendix A – Accessing Hot Key Mode ...................................................................................................... 23
Analyze Tab ............................................................................................................................................. 23
Staging Policy Configuration Interface.................................................................................................... 23
Filter Policy Configuration Interface ....................................................................................................... 24
2
DocAve 6: SQL Server Data Manager
Restore Tab ............................................................................................................................................. 24
Appendix B – SharePoint Object Security and Property ............................................................................. 25
Appendix C – Examples of Filter Policies .................................................................................................... 26
Appendix D – Advanced Settings in Configuration Files ............................................................................. 31
Index............................................................................................................................................................ 32
Notices and Copyright Information ............................................................................................................ 34
DocAve 6: SQL Server Data Manager
3
About DocAve SQL Server Data Manager
SQL Server Data Manager is a recovery solution for Microsoft SharePoint. DocAve provides full fidelity
analysis and restore, from an individual item to an entire SharePoint environment with all of its farmlevel components.
Complementary Products
Many products and product suites on the DocAve 6 platform work in conjunction with one another. The
following products are recommended for use with SQL Server Data Manager:
•
DocAve Granular Backup and Restore to back up all farm content and restore content
down to the item level
•
DocAve Replicator for SharePoint for copying SharePoint content within the same
SharePoint farm or from one SharePoint farm to another
•
DocAve Content Manager for SharePoint for restructuring or moving SharePoint content
•
DocAve Report Center for SharePoint to examine pain points in the SharePoint
infrastructure and report on SharePoint user behavior and changes
•
DocAve Data Protection for setting backup and restore points prior to adjusting
SharePoint governance policies in this product
Submitting Documentation Feedback to AvePoint
AvePoint encourages customers to provide feedback regarding our product documentation. You can
Submit Your Feedback on our website.
4
DocAve 6: SQL Server Data Manager
Before You Begin
Refer to the sections for system and farm requirements that must be in place prior to installing and
using DocAve SQL Server Data Manager.
Configuration
In order to use DocAve SQL Server Data Manager, the DocAve 6 platform must be installed and
configured properly on your farm. SQL Server Data Manager will not function without DocAve 6 present
on the farm.
Agents
DocAve Agents are responsible for running DocAve jobs and interacting with the SharePoint object
model. DocAve Agent must be installed on a SQL Server and at least one of the Web front-end servers.
For instructions on installing the DocAve Platform, DocAve Manager, and DocAve Agents, refer to the
DocAve 6 Installation Guide.
Required Permissions
To install and use SQL Server Data Manager properly, ensure that the Agent account has the following
permissions.
Agent accounts configured on the SharePoint servers where DocAve Agents are installed:
•
SharePoint Permissions – This permission must be manually configured prior to using
DocAve 6 SQL Server Data Manager; it is not automatically configured.
o
Member of the Farm Administrators group
*Note: For SharePoint 2013, the SQL Server Data Manager requires the Agent account
to have Full Control of all zones of the Web application.
When restoring the backed up SharePoint 2013 personal site, the Agent account used to
run the Restore job must also have the following permissions:
•
o
Full Control to the User Profile Service Application related to the Web
application where the personal site resides
o
Security account of the application pool used by the Web application where the
personal site resides
SQL Permissions – These permissions must be manually configured prior to using
DocAve 6 SQL Server Data Manager; they are not automatically configured.
DocAve 6: SQL Server Data Manager
5
o
Database Role of db_owner for all the databases related with SharePoint,
including SharePoint Content Database, Configuration Database, and Central
Administration Database
o
Server Role of public for the SQL Server
o
Database Role of db_owner for the temporary databases that store the
analyzed data
Users who access the databases of the staging policy:
•
SQL Permissions
o
Server Role of processadmin for the SQL Server
o
SQL Instance Permission: Control Server
o
Server Role of dbcreator for the SQL Server
Agent accounts configured on the SQL Servers where DocAve Agents are installed:
•
Local System Permissions
o
•
Member of the Administrators group
SQL Permissions
o
Database Role of db_owner for the temporary databases that store the
analyzed data
o
Server Role of public for the SQL Server
Local System Permissions
The following Local System Permissions are automatically configured during DocAve 6 installation. The
User must be a member of the following local groups:
6
•
IIS WPG (for IIS 6.0) or IIS IUSRS (for IIS 7.0)
•
Performance Monitor Users
•
DocAve Users have the following permissions (the group is created by DocAve
automatically):
o
Full Control to the Registry of
HKEY_LOCAL_MACHINE\SOFTWARE\AvePoint\DocAve6
o
Full Control to the Registry of
HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services\eventlog
o
Full Control to the Communication Certificate
o
Permission of Log on as a batch job (it can be found within Control Panel >
Administrative Tools > Local Security Policy > Security Settings > Local Policies
> User Rights Assignment)
o
Full Control Permission for DocAve Agent installation directory
DocAve 6: SQL Server Data Manager
Getting Started
Refer to the sections below for important information on getting started with SQL Server Data Manager.
Launching SQL Server Data Manager
To launch SQL Server Data Manager and access its functionality, complete the following steps:
1. Log in to DocAve. If you are already in the software, click the DocAve tab.
2. From the DocAve tab, click Data Protection to view the Data Protection modules.
3. Click SQL Server Data Manager to launch this module.
Figure 1: DocAve module launch window.
DocAve 6: SQL Server Data Manager
7
User Interface Overview
The SQL Server Data Manager interface launches with the Analyze tab active. This tab displays the
dashboard and allows for quick access to a list of the SQL Server Data Manager features.
Figure 2: SQL Server Data Manager user interface.
1. The ribbon shows the available actions for SQL Server Data Manager.
2. The workspace shows explanations and the content that is used during the configuration of
actions performed in DocAve products.
8
DocAve 6: SQL Server Data Manager
About the Staging Policy
The staging policy determines where temporary databases generated during the analysis process. Create
a staging policy to specify a temporary database location and SQL backup files locations.
Staging Policy Configuration Interface
To access Staging Policy Configuration for DocAve in the SQL Server Data Manager interface, click
Staging Policy in the Settings group on the Analyze tab. Click Close on the ribbon to close the Staging
Policy Configuration interface.
In the Staging Policy Configuration interface, you will see a list of previously configured staging policies.
You can customize how these staging policies are displayed in the following ways:
•
Search – Filter the staging policies displayed by the keyword you designate; the keyword
must be contained in a column value. At the top of the viewing pane, enter the keyword
for the staging policy you want to display. You can select to Search all pages or Search
current page.
•
Manage columns ( ) – Manage which columns are displayed in the list so that only the
information you want to see is displayed. Click the manage columns buton ( ), and then
check the checkbox next to the column name to have that column shown in the list.
•
Hide the column ( ) – Click the hide the column button ( ) in the column title to hide
the column.
Managing Staging Policies
In Staging Policy Configuration interface, you can create a new staging policy, edit a previously
configured staging policy, or delete a previously configured staging policy. For details on creating or
editing a staging policy, see the Configuring Staging Policies section of this guide.
Click Edit on the ribbon to change the configurations for this staging policy. For details on editing
configurations for staging policy, see the Configuring Staging Policies section of this guide.
To delete a staging policy for DocAve, select it from the list of previously configured staging policies, and
then click Delete on the ribbon. A confirmation window will pop up and ask if you are sure you want to
proceed with the deletion. Click OK to delete the selected staging policy, or click Cancel to return
without deleting it.
DocAve 6: SQL Server Data Manager
9
Configuring Staging Policies
To configure a staging policy, complete the following steps:
1. Click Staging Policy in the Settings group on the Analyze tab. The Staging Policy Configuration
window appears.
2. Click Create from the Manage group. The Create a New Staging Policy page appears. Configure
the following settings:
a. Staging Policy Name – Enter a staging policy name and optional Description for the
staging policy.
b. Platform Type – Describe the software platform that is going to use this staging policy.
c. Database Access Credentials – Choose the SQL Server that you want to use for this
staging policy and specify the credentials to access the specified SQL Server.
o
SQL agent name – All of the DocAve Agents that are installed on the SQL
database servers are listed in the drop-down box.
o
SQL instance name – All of the instances in the SQL Agent selected above are
listed in the drop-down box.
o
Database Authentication (for accessing database within SharePoint)

Windows authentication (recommended) (the default option) – Use
this method to confirm the user identity using Windows.

SQL authentication – SQL Server confirms the user identity according to
the entered Account and Password. The specified account must be
added to the sysadmin role in SQL Server.
Click Validation Test to verify the access to the SQL Server.
d. Temporary Database Configuration – Set up the configuration of the temporary
database.
10
o
Minimum amount of free space to leave – Specify the minimum amount of free
space to leave for the database file location and log file location. DocAve
ensures that the entered amount exists in the corresponding location before
starting a job. If the free space specified here does not exist in the specified
location before a job starts, or if the entered amount will not exist after the
temporary database is stored to the specified location, then the corresponding
job will fail.
o
Temporary database file location – Specify a local path on the SQL Server to
store the temporary database data file (.mdf). The format of the path is C:\data.
The default location is the database data default location of SQL Server, for
example, C:\Program Files\Microsoft SQL
Server\MSSQL10_50.MSSQLSERVER\MSSQL\Data.
DocAve 6: SQL Server Data Manager
o
Temporary log file location – Specify a local path on the SQL Server to store the
temporary database log file (.ldf). The format of the path is C:\data. The default
location is the database log default location of SQL Server, for example,
C:\Program Files\Microsoft SQL
Server\MSSQL10_50.MSSQLSERVER\MSSQL\Data.
Click Validation Test to verify the access to the SQL Server.
e. SQL Backup Data Location – Specify the location of the SQL backup files.
Click Specify Location and the Specify Location interface appears. For more information,
see the Configuring the Specify Location Interface section of this guide.
f.
Priority Settings – Select the action when the number threshold of temporary databases
has been met or exceeds.
o
Fail Current Job – The restore job of the backup files will fail immediately.
o
Fail Other Jobs – One database of the oldest staging jobs will be deleted before
staging the new temporary database.
*Note: Make sure the xp_cmdshell function is enabled in the SQL instance selected in the Staging Policy,
or make sure the user that logs on the SQL instance service has the Read and Write permissions to the
specified UNC path in the Staging Policy.
Configuring the Specify Location Interface
Click Specify Location on the Staging Policy Configuration window in the SQL Backup Data Location
field and the Specify Location interface appears. To specify the Source Path of the SQL backup files,
configure the following settings:
1. Enter the UNC Path.
2. Enter the Username.
3. Enter the Password.
4. Click Validation Test to verify the access to the server.
5. Click OK.
About the Filter Policy
Filter Policy allows you to set up filter rules so you can control what objects and data within any file
system level appear so that you can target content more precisely. By setting up and saving filter
policies, you can apply the same filter policies to different plans without having to recreate them each
time.
DocAve 6: SQL Server Data Manager
11
To access Filter Policy Configuration for DocAve in the SQL Server Data Manager interface, click Filter
Policy in the Settings group on the Analyze tab. Click Close on the ribbon to close the Filter Policy
Configuration interface.
In the Filter Policy Configuration interface, you will see a list of previously configured filter policies. You
can customize how these filter policies are displayed in the following ways:
•
Search – Filter the filter policies displayed by the keyword you designate; the keyword
must be contained in a column value. At the top of the viewing pane, enter the keyword
for the filter policy you want to display. You can select to Search all pages or Search
current page.
•
Manage columns ( ) – Manage which columns are displayed in the list so that only the
information you want to see is displayed. Click , and then check the checkbox next to
the column name to have that column shown in the list.
•
Hide the column ( ) – Click
•
Filter the column ( ) – Filter which item in the list is displayed. Unlike Search, you can
filter whichever item you want, rather than search based on a keyword. Click the
icon of the column you want to filter, and then check the checkbox next to the item
name to have that item shown in the list. To remove all filters, click Clear Filter.
in the column title to hide the column.
Managing Filter Policies
In the Filter Policy Configuration interface, you can create a new filter policy, view details about a filter
policy, edit a previously configured filter policy, or delete a previously configured filter policy. For details
on creating or editing a filter policy, see the Configuring Filter Policies section of this guide.
Click Edit on the ribbon to change the configurations for this filter policy. For details on editing
configurations for filter policy, see the Configuring Filter Policies section of this guide.
To view a filter policy for DocAve, select it from the list of previously configured filter policies, and then
click View Details on the ribbon. To delete a filter policy for DocAve, select it from the list of previously
configured filter policies, and then click Delete on the ribbon. A confirmation window will pop up and
ask if you are sure you want to proceed with the deletion. Click OK to delete the selected filter policy, or
click Cancel to return without deleting it.
Configuring Filter Policies
To create a new filter policy, click Create from the Manage group. To modify a previously configured
filter policy, select the filter policy, then click Edit on the ribbon. In the Create Filter Policy or Edit Filter
Policy interface, configure the following settings:
1. Name and Description – Enter a Name for the filter policy. Then enter an optional Description
for future reference.
12
DocAve 6: SQL Server Data Manager
2. Criteria – Select specific objects or data within each file system level (file and folder). Each level
has a unique set of rules that can be applied to enhance configurations.
*Note: Refer to Appendix C – Examples of Filter Policies for examples of filter policies that users
can configure.
a. Click Add a Filter Level Group to add a new rule of the specified level and then click Add
a Criterion to add criteria for the new rule by completing the fields below, and click
to delete the rule that is no longer needed.
o
Rule – Select the new rule you want to create from the drop-down list.
o
Condition – Select the condition for the rule.
o
Value – Enter a value you want the rule to use in the text box.
b. To add more filters to the filter policy, repeat the previous step.
*Note: Depending on the filters you enter, you can change the logical relationships
between the filter rules. There are currently two logical relationships: And and Or. By
default, the logic is set to And. To change the logical relationship, click on the logical
relationship link. The And logical relationship means that the content which meets all
the rules will be filtered and included in the result. The Or logic means that the content
which meets any one of the rules will be filtered and included in the result.
3. Basic Filter Condition – View the logical relationship of the filter rules in this area.
For example, if the logical relationship is ((1 And 2) Or 3) in the Basic Filter Condition area, the
contents that meet both the filter rule 1 and filter rule 2, or meet the filter rule 3, will be filtered
out.
4. Click Save to save the configurations and return to the Filter Policy interface, or click Cancel to
return to the Filter Policy interface without saving any changes.
DocAve 6: SQL Server Data Manager
13
SQL Backup Analysis Builder
Click SQL Backup Analysis Builder from the Manage group. The wizard mode page appears. Configure
the following settings:
1. Analysis Options – Choose a staging policy, a filter policy, and a method of analysis for the job
you are about to run.
•
Staging Policy – Determines where temporary databases generated during the analysis
process. Create a staging policy to specify a temporary database location and SQL
backup files locations. You may select a previously-created staging policy from the dropdown menu, or click New Staging Policy from the drop-down menu to create a new one.
For detailed information, refer to Configuring Staging Policies.
•
Filter Policy – Controls what objects and data within any file system level are analyzed
so that you can target content more precisely. The default filter policy is set to be none.
You may select a previously-created filter policy from the drop-down menu, or click New
Filter Policy from the drop-down menu to create a new one. For detailed information on
configuring a filter policy, refer to Configuring Filter Policies.
•
Use InstaMount for Analysis – Select Yes or No for whether or not to use InstaMount
when analyzing the SQL backups of the content databases. InstaMount makes item-level
restore more efficient, as it uses a mapping file to record the relationship between the
InstaMount temporary database and the backup data. Note that the user of InstaMount
requires minimal disk space. Refer to About InstaMount for more information.
2. Data Selection – Select the SQL backup files that you want to restore data from.
a. Click Find SQL Backup Files on the left pane of the interface, the Find SQL Backup Files
window pops up.
b. In the left pane of the pop-up window, click the SQL instance to load the tree structure.
c. Click the node in the tree to load the corresponding backup files in the right pane of the
pop-up window.
d. Select the backup files that you want to analyze by selecting the corresponding
checkboxes.
e. Click OK to save the selection.
f.
In the Analyze tab, the paths of the selected backup files are available. Select one
backup file at a time, and click it to load the corresponding content databases of the
backup file.
g. Select content databases to analyze by selecting the checkbox.
3. Schedule – Configure a schedule for this job.
•
14
Notification – To inform specified users of the Backup Files Analysis job, configure the
Notification settings. Select a previously-configured notification profile from the Select
DocAve 6: SQL Server Data Manager
a profile with address only drop-down list, or choose to create a new e-mail notification
profile by clicking the New Notification Profile link. Click View to view the detailed
configuration of the selected notification profile.
•
Schedule Selection – Choose whether to run the job immediately, or configure a custom
start time.
o
No schedule – Select this option to run the job immediately when you finish the
settings of this job.
o
Configure the schedule myself – Select this option and the Schedule Settings
section appears under the Schedule Selection section.
•
Schedule Settings – Specify a start date and time to run this job.
•
Description – Enter an optional description for this job.
4. Overview – Review and edit your configurations for this job.
5. Click Finish to run this job immediately or running this job at the time specified in the Schedule
Settings section.
DocAve 6: SQL Server Data Manager
15
About InstaMount
It is recommended that you enable the InstaMount function to restore items that are small in file size.
The InstaMount function can be enabled in an analysis job. The InstaMount mapping file is generated
from backup data; it is used to generate the temporary files used by the InstaMount function.
Restore Analyzed SQL Backup Data
To run a Restore Analyzed SQL Backup job, complete the following steps:
1. Select the Restore tab and click Restore in the Manage group. The Restore Analyzed SQL
Backup Data tab appears.
1. Job Selection – Configure the options in the Filter By area to limit the scope of backup data. The
default filter rule is to filter the analysis jobs in the last seven days.
•
Time Range – Filter backup data by completion time range using the drop-down list.
o
All jobs – Select this option to display all Finished/Finished with Exception
Backup Files Analysis jobs.
o
Analysis jobs start within – Select this option to specify a time period. All of the
Finished/Finished with Exception Backup Files Analysis jobs whose start time is
in the specified time period are displayed.
2. After selecting the filters, click the Filter button in the Filter By area or on the ribbon. All analysis
jobs that meet the selected filter rules are listed in the calendar. If desired, click Reset in the
Filter By area or click Reset on the ribbon to clear all filters and display all Finished/Finished with
Exception analysis jobs.
3. Select the analysis job that you want to restore by clicking the job. Additional actions that can be
performed:
•
Place the mouse cursor over an analysis job to display job information such as the Job
ID, InstaMount Enabled, and Job Status. Click Day, Week, or Month to change the view
to see all the available jobs during that time period.
•
Click the page turn button (
page.
) on the top-left corner of the calendar to turn the
4. Now that you’ve selected an analysis job containing data you want to restore, click Next to
continue with instructions on building the job:
16
DocAve 6: SQL Server Data Manager
Configuring a Restore Job
To configure a restore job, complete the following steps:
1. Refer to Restore Analyzed SQL Backup Data to begin building the job.
2. Data Selection – Select the database that includes the granular content to restore.
3. Click the Global Setting for Restoring Content, Property and Security link and configure the
Item Level Settings:
a. Granular Content – Select the Restore granular content checkbox to restore the
granular content. If you do not select this checkbox, the tree in the Backup Data pane
can only be expanded down to the site collection level and you cannot select granular
content. Refer to Site Collection Level Restore for detailed information.
o
Container Selection ─ Select the Global setting for container configuration
checkbox to enable the container’s global settings.

Restore container – Restore the container and select the Security
checkbox if you want to restore the container’s security settings, and/or
select the Property checkbox if you want to restore the container’s
property settings. For more information, refer to Appendix B –
SharePoint Object Security and Property.

Only restore security – Only restore the container’s security settings.
You can specify the Conflict resolution as Merge or Replace. Merge will
add the security of the container in the backup to the conflict container
in the destination. Replace will delete the security of the conflict
container in the destination first, and then add the security of the
container in the backup to the conflict container in the destination.
*Note: Once you select Only restore security option, the Container
level conflict resolution configuration field in the Restore Settings page
will be hidden from the interface and you will not be able to configure
the Container level conflict resolution though that page.
o
Content Selection ─ Select the Global setting for restoring content checkbox to
enable the content’s global settings.

Restore content – Restore the content. Additionally, select the Security
checkbox if you want to restore the content’s security settings along
with. For more information, refer to Appendix B – SharePoint Object
Security and Property.

Only restore security – Only restore the content’s security settings. You
can specify the Conflict resolution as Merge or Replace. Merge will add
the security settings of the content in the backup into the conflict
content in the destination. Replace will delete the security settings of
the conflict content in the destination first, and then add the security of
the content in the backup to the conflict content in the destination.
DocAve 6: SQL Server Data Manager
17
*Note: Once you select Only restore security option, the Content level
conflict resolution configuration field in the Restore Settings page will
be hidden from the interface and you will not be able to configure the
Content level conflict resolution though that page.
4. Expand the tree and locate the content you want to restore. The detailed information can be
viewed in the Item Browser pop-up window. Select the objects to be restored under this node.
When finished, click Next. The Destination Settings page appears.
5. Destination Settings – Choose a destination to restore the data, specify an agent to perform the
restore job, select an action of how the data is restored, and configure the mapping settings to
update the metadata, securities, and language while storing to an alternate location.
*Note: It is not supported to restore the data backed up from SharePoint 2010 to SharePoint
2013 or to restore the data backed up from SharePoint 2013 to SharePoint 2010. Make sure that
the source node and the destination node are in the same version of SharePoint. If the site
within SharePoint 2013 is a SharePoint 2010 mode site, it can only be restored to the same
mode site.
a. Destination – Choose the destination for the restore job. You can either select an
existing node on the tree or select a manually-created node. To create a node in the
destination SharePoint manually, select a node with a blank text box, and then enter the
URL of the destination node into the text box following the format displayed in the text
box. If you are creating a new site collection, you will be asked to select one existing
managed path from the drop-down list. Click Create Container beside the text box to
create the node in the destination farm. Alternatively, click Create Container in the
Manage group on the Restore Analyzed SQL Backup Data tab to create the
corresponding node.
b. Agent – Specify the Agent that will perform the restore job.
c. Action – Select how the SQL backup data will be restored to the destination.
o
Merge – Add the backup data to the destination node.
o
Attach – Restore the backup data as children beneath the selected node.
d. Mapping Settings (Optional) – Configure whether to specify the mapping settings to
map the user, domain, or language to the destination.
18
o
User mapping – If desired, configure the user mapping to map the backed up
user to the destination user. For specific instructions on setting up the user
mapping, refer to the DocAve 6 Control Panel Reference Guide.
o
Domain mapping – If desired, configure the domain mapping to map the backed
up domain to the destination domain. For specific instructions on setting up the
domain mapping, refer to the DocAve 6 Control Panel Reference Guide.
o
Language mapping – If desired, configure the language mapping to display a
destination node in a different language than the language of the backed-up
DocAve 6: SQL Server Data Manager
data. For specific instructions on setting up the language mapping, refer to the
DocAve 6 Control Panel Reference Guide.
Click Next when finished. The Restore Settings page appears.
6. Restore Settings – Configure how the content will be restored.
a. Conflict Resolution –Select an option to dictate how to resolve conflicts at the container
level and content level.
o
Container level conflict resolution – Set the conflict resolution on the site
collection, site, list, and folder level.

Skip – Ignores the source container that is the same as the destination
one.

Merge – Combines the settings and properties of the source and
destination container. If there is a conflict, the source overwrites the
destination.

Replace – Deletes the destination container and then restores the
source to the destination. If the selected container is a root site,
Replace function empties the root site instead of deleting it and
restores the source to the destination. This option can only be used at
folder/list/site/site collection level.
*Note: A discussion board item is considered a folder, so it is restored as a
container.
o
Content level conflict resolution – Sets the conflict resolution on the item level.

Skip – Ignores the source item/document that has the same item
ID/document name as the destination item/document. l

Overwrite – Copies the source item/document to the destination by
overwriting the destination item/document with same item
ID/document name.

Overwrite by Last Modified Time – Keeps the conflict item\document
which has the latest modified time and overwrites the older one.

Append an Item/Document Name with a Suffix – Keeps both of the
conflict items/documents and add a suffix (_1, _2, _3…) to the name of
the conflict source item/document.

Append a New Version – Adds the conflict source item/document to
the destination as a new version of the conflict destination
item/document.
b. Include Data in Recycle Bin – Choose whether to compare the data in the backup with
the data in the destination SharePoint farm’s recycle bin. If you select Skip either at the
Container level or Content level, or select Append an Item/Document Name with a
suffix or Append a New Version in Content level, the Include Recycle Bin Data option is
DocAve 6: SQL Server Data Manager
19
available to configure. If you select Yes in this field, and the selected content in the
backup still exists in the recycle bin of the destination SharePoint farm, then the
selected content in the backup is not restored.
c. Include Detailed Job Report for All Items – Selecting Yes generates a detailed job report
for all the items. Selecting No still generates a job report for list, site, or site collection
level.
d. Workflow – Decide how the backed-up workflows are restored.
o
Include workflow definition – Only restores the definition of the backed-up
workflows.
o
Include workflow instance – Restores the state, history, and tasks for each
item.
*Note: All workflow instances whose status was In Progress when backed up
will be Cancelled when restored to the destination.
e. Item Dependent Columns and Content Types – Choose whether to restore itemdependent columns and content types.
*Note: If the dependent column or content type does not exist in the destination, then
that column or content type will not be restored. If this is the case, use this option to
restore them.
o
o
20
Restore the item-dependent columns and content types to maintain item
integrity – Whether the item is restored and the dependent column or content
type is created in the corresponding list/library are depended on the option
selected below:

Do not restore the columns and content types, or the corresponding
items – The columns, content types, and the corresponding items will
not be restored if the columns and content types in the destination are
conflicted with the backed up columns and content types.

Overwrite the columns and content types – The columns and content
types will overwrite the destination conflicted columns and content
types, and the corresponding items will be restored.

Append the columns to the destination – The columns and items will
be restored to the destination if the columns and content types in the
destination are conflicted with the backup up columns and content
types.
Do not restore item-dependent columns and content types – The item
dependent columns and dependent content types will not be restored. When
selecting this option, make sure the dependent columns and content types exist
in the destination. Otherwise, the item cannot be restored.
DocAve 6: SQL Server Data Manager
f.
Exclude User/Group Without Permission ─ If you select Yes, the users/groups that have
no permissions will not be restored. By default, No is selected.
g. Version Settings – Choose the Version Settings for the content being restored to
SharePoint. To improve performance, limit the versions restored. Restore all versions
restores all the versions of the backup data; while Restore the latest versions only
restores the latest several Major or Major and Minor versions of the backup data as
specified. The other versions are not restored.
*Note: The latest version does not take the current version into account.
h. Notification – Configure the email Notification settings. Select a previously-configured
notification profile from the Select a profile with address only drop-down list. You can
also choose to create a new e-mail notification profile by clicking the New Notification
Profile link. Click View to view the detailed configuration of the selected notification
profile.
When finished configuring Restore Settings, click Next. The Schedule page appears.
7. Schedule – Choose whether or not to create the restore job based on a schedule. Select Restore
at the end of the wizard to run the job immediately after finishing the restore wizard. To
configure the schedule yourself, select Configure the schedule myself and select a start date
and time in Schedule Settings field. If desired, enter an optional Description to distinguish the
restore job from others.
When finished, click Next. The Overview page appears.
8. Review and edit the job selections. To make changes, click Edit in the middle of the row. This
links to the corresponding setting page, allowing you to edit the configuration.
9. Click Finish to save the job’s configuration. If the restore job does not have a schedule, Finish
runs the job immediately. If the restore job is set to run on a schedule, Finish saves the restore
job’s configuration without running it.
Site Collection Level Restore
Deselecting the Restore Granular Content checkbox disables granular content selection. This restore
method can only be used for a granular restore that is performed at the site collection level. If the whole
site collection needs to be restored, enable the Site Collection Level Restore feature by deselecting the
Restore Granular Content checkbox. In this case, the restore will be similar to an STSADM site collection
level restore. It is faster and can maintain internal document IDs. The restored data and its data
structure are much closer to the original data and structure.
*Note: If you do not select Restore Granular Content, the tree in the Backup Data pane can only be
expanded down to the site collection level, so granular content cannot be selected.
DocAve 6: SQL Server Data Manager
21
For a granular restore performed at the site collection level, deselecting the Restore Granular Content
feature can be executed only when no site collection in the destination has the same URL or ID as the
site collection selected in the backup data.
Checking a Job Status
SQL Server Data Manager contains a Job Monitor button where users can view the status of jobs. This is
useful for monitoring jobs or troubleshooting for errors.
Refer to the DocAve 6 Job Monitor Reference Guide for more information.
22
DocAve 6: SQL Server Data Manager
Appendix A – Accessing Hot Key Mode
In order to work faster and improve your productivity, DocAve supports hot key mode for you to
perform corresponding actions quickly by only using your keyboard. To access hot key mode from the
SQL Server Data Manager interface, press the key combination of Ctrl +Alt + Z on your keyboard.
The following table provides a list of hot keys for the Analyze page of the SQL Server Data Manager
interface. Each time you want to go back to the Home page, press Ctrl + Alt + Z on your keyboard. For
example, continue pressing A to go back to the Analyze tab of SQL Server Data Manager.
Operation Interface
Analyze
Restore
DocAve Home Page
DocAve Online Community
Control Panel
Job Monitor
Plan Group
Account Information
Help and About
A
R
1
2
3
4
5
9
0
Hot Key
Analyze Tab
The following is a list of hot keys for the Analyze tab functions.
Operation Interface
Analyze SQL Backup Builder
A
Staging Policy
Filter Policy
Job Monitor
S
F
J
Hot Key
Staging Policy
Filter Policy
Back
Next
Finish
Cancel
S
F
B
N
FN
C
Staging Policy Configuration Interface
The following is a list of hot keys for the Staging Policy Configuration interface functions.
Create
Operation Interface
Edit
DocAve 6: SQL Server Data Manager
C
E
Hot Key
Save
Cancel
Save
Cancel
O
B
O
B
23
Delete
Close
Operation Interface
D
X
Hot Key
Filter Policy Configuration Interface
The following is a list of hot keys for the Filter Policy Configuration interface functions.
Create
Operation Interface
C
View Details
V
Edit
E
Delete
Close
D
X
Hot Key
Save
Cancel
Edit
Cancel
Save
Cancel
O
C
E
C
O
C
Hot Key
Create Container
Advanced Search
Filter
Reset
Back
Next
Finish
Cancel
CC
AS
FL
R
B
N
FN
CX
Restore Tab
The following is a list of hot keys for the Restore tab functions.
Restore
Job Monitor
24
Operation Interface
R
J
DocAve 6: SQL Server Data Manager
Appendix B – SharePoint Object Security and Property
Refer to the table below for the detailed information of security and property of each SharePoint object.
Type
Security
Property
SharePoint
Object
Attributes of the SharePoint Object Belonging to the Specified Type
Site Collection
Users and groups of the site collection
Site
Mappings of the users and their permissions, permission levels, groups,
users
List
Mappings of the users and their permissions, users, groups
Folder/Item/File
Mappings of the users and their permissions, users, groups
Site Collection
Basic information used to create the site collection, other information of
the site collection, site features
Site
Basic information used to create the site, other information of the site, site
columns, site content types, navigation, site features, triggers for the users’
actions in the site
List
Basic information used to create the List, other information of the list, list
columns, list content types, triggers for the users’ actions in the list, alert
Folder/Item/File
Properties of the folder/item/file, alert
DocAve 6: SQL Server Data Manager
25
Appendix C – Examples of Filter Policies
*Note: The Equals condition is not case sensitive.
Hierarchy
Level
File
Rule
Name
Condition
Value
Contains
test
Does Not Contain
test
Equals
test
Does Not Equal
test
Matches
te*t
te?t
Does Not Match
te*t
te?t
26
Result
The file whose name
contains test will be filtered
and included in the results.
The file whose name does
not contain test will be
filtered and included in the
results.
The file whose name is test
will be filtered and
included in the results.
The file whose name is not
test will be filtered and
included in the results.
The file whose name begins
with te and ends with t will
be filtered and included in
the results. For example,
teABct will be filtered and
included in the results.
The file whose name is the
same as te?t except
character ? will be filtered
and included in the results.
For example, test will be
filtered and included in the
results.
All the files except those
whose names begin with te
and end with t will be
filtered and included in the
results. For example,
DocAve will be filtered and
included in the results.
All the files except those
whose names are the same
as te?t except character ?
will be filtered and
included in the results. For
example, DocAve will be
filtered and included in the
results.
DocAve 6: SQL Server Data Manager
Hierarchy
Level
Rule
Size
Modified
Time
Created
Time
Condition
Value
>=
1MB
<=
1MB
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
Within
5 Days
Older Than
5 Days
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
DocAve 6: SQL Server Data Manager
Result
The file whose size is not
smaller than 1MB will be
filtered and included in the
result. For example, a 2MB
file will be filtered and
included in the result.
The file whose size is not
bigger than 5 will be
filtered and included in the
result. For example, a
500KB file will be filtered
and included in the result.
The file which is modified
before 12:15:50
11/11/2011 will be filtered
and included in the result.
The file which is modified
after 12:15:50 11/11/2011
will be filtered and
included in the result.
The file which is modified
on 12:15:50 11/11/2011
will be filtered and
included in the result.
The file which is modified
in last 5 days will be
filtered and included in the
result.
The file which is modified 5
days ago will be filtered
and included in the result.
The file which is created
before 12:15:50
11/11/2011 will be filtered
and included in the result.
The file which is created
after 12:15:50 11/11/2011
will be filtered and
included in the result.
The file which is created on
12:15:50 11/11/2011 will
be filtered and included in
the result.
27
Hierarchy
Level
Rule
Last
Accessed
Time
Folder
28
Name
Condition
Value
Result
Within
5 Days
The file which is created in
last 5 days will be filtered
and included in the result.
The file which is created 5
days ago will be filtered
and included in the result.
The file whose last
accessed time is before
12:15:50 11/11/2011 will
be filtered and included in
the result.
The file whose last
accessed time is after
12:15:50 11/11/2011 will
be filtered and included in
the result.
The file whose last
accessed time is on
12:15:50 11/11/2011 will
be filtered and included in
the result.
The file whose last
accessed time is in last 5
days will be filtered and
included in the result.
Older Than
5 Days
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
Within
5 Days
Older Than
5 Days
The file whose last
accessed time is 5 days ago
will be filtered and
included in the result.
Contains
test
Does Not Contain
test
Equals
test
Does Not Equal
test
The folder whose name
contains test will be filtered
and included in the results.
The folder whose name
does not contain test will
be filtered and included in
the results.
The folder whose name is
test will be filtered and
included in the results.
The folder whose name is
not test will be filtered and
included in the results.
DocAve 6: SQL Server Data Manager
Hierarchy
Level
Rule
Condition
Matches
Value
te*t
te?t
Does Not Match
te*t
te?t
Modified
Time
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
Within
5 Days
DocAve 6: SQL Server Data Manager
Result
The folder whose name
begins with te and ends
with t will be filtered and
included in the results. For
example, teABct will be
filtered and included in the
results.
The folder whose name is
the same as te?t except
character ? will be filtered
and included in the results.
For example, test will be
filtered and included in the
results.
All the folders except those
whose names begin with te
and end with t will be
filtered and included in the
results. For example,
DocAve will be filtered and
included in the results.
All the folders except those
whose names are the same
as te?t except character ?
will be filtered and
included in the results. For
example, DocAve will be
filtered and included in the
results.
The folder which is
modified before 12:15:50
11/11/2011 will be filtered
and included in the result.
The folder which is
modified after 12:15:50
11/11/2011 will be filtered
and included in the result.
The folder which is
modified on 12:15:50
11/11/2011 will be filtered
and included in the result.
The folder which is
modified in last 5 days will
be filtered and included in
the result.
29
Hierarchy
Level
Rule
Created
Time
Last
Accessed
Time
30
Condition
Value
Older Than
5 Days
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
Within
5 Days
Older Than
5 Days
Before
2011-11-11
12:15:50
After
2011-11-11
12:15:50
On
2011-11-11
12:15:50
Within
5 Days
Older Than
5 Days
Result
The folder which is
modified 5 days ago will be
filtered and included in the
result.
The folder which is created
before 12:15:50
11/11/2011 will be filtered
and included in the result.
The folder which is created
after 12:15:50 11/11/2011
will be filtered and
included in the result.
The folder which is created
on 12:15:50 11/11/2011
will be filtered and
included in the result.
The folder which is created
in last 5 days will be filtered
and included in the result.
The folder which is created
5 days ago will be filtered
and included in the result.
The folder whose last
accessed time is before
12:15:50 11/11/2011 will
be filtered and included in
the result.
The folder whose last
accessed time is after
12:15:50 11/11/2011 will
be filtered and included in
the result.
The folder whose last
accessed time is on
12:15:50 11/11/2011 will
be filtered and included in
the result.
The folder whose last
accessed time is in last 5
days will be filtered and
included in the result.
The folder whose last
accessed time is 5 days ago
will be filtered and
included in the result.
DocAve 6: SQL Server Data Manager
Appendix D – Advanced Settings in Configuration Files
Configure the SP2010PlatformConfiguration.xml file to specify the maximum number of the temporary
databases can be created and specify the Web application URL for the backup data analysis.
1. Go to the machines with DocAve Agent installed and open the
…\AvePoint\DocAve6\Agent\data\SP2010\Platform directory to find the
SP2010PlatformConfiguration.xml file.
2. Open the SP2010PlatformConfiguration.xml file with Notepad.
3. Find the </SDMConfig> node.
For detailed information, refer to the screen shot below:
Figure 3: Finding the </SDMConfig> node in the SP2010PlatformConfiguration.xml file.
<SDMAnalyzeConfig tempDBCount=" " /> – Specify the maximum number of temporary
databases. The default value is 5. When the number of temporary databases is larger than 5, the
action will be taken according to the settings in the Priority Settings section. For more
information on Priority Settings section, see the Configuring Staging Policies section of this guide.
4. Find the <PlatformItemRestore ContentTypeFieldLinksOption="merge" > node, and insert the
parameter SDMSourceWebAppUrl=" " to this node.
Figure 4: Inserting the SDMSourceWebAppUrl parameter.
5. Enter the desired Web application URL.
DocAve 6: SQL Server Data Manager
31
Index
All Jobs, 16
Analyze SQL Backup Builder, 14
Append a New Version, 19
Append an Item/Document Name with a Suffix, 19
Attach, 18
Backup jobs start within, 16
Cancel, 9, 12, 13
Clear Filter, 12
Close, 9, 12
Configure the schedule myself, 15, 21
Create, 10, 12
Create Container, 18
Day, 16
Delete, 9, 12
Do not restore item-dependent columns and content types, 20
Domain Mapping, 18
Edit, 9, 12, 21
Fail Current Job, 11
Fail Others, 11
Filter, 16
Filter Icon, 12
Filter Policy, 9, 12
Finish, 15, 21
Global setting for container configuration, 17
Global setting for restoring content, 17
Hide the column, 9
Include Recycle Bin Data, 19
Include workflow definition, 20
Include workflow instance, 20
Language Mapping, 18
Manage columns, 9
Merge, 17, 18, 19
Minimum amount of free space to leave, 10
Month, 16
New Filter Policy, 14
New Notification Profile, 15, 21
New Staging Policy, 14
Next, 16, 18, 19, 21
No, 20, 21
No schedule, 15
OK, 9, 11, 12, 13, 14
Only restore security, 17, 18
Overwrite, 19
Overwrite by Last Modified Time, 19
32
DocAve 6: SQL Server Data Manager
Property, 17
Replace, 17, 19
Reset, 16
Restore, 16
Restore all versions, 21
Restore at the end of the wizard, 21
Restore Granular Content, 21, 22
Restore the item-dependent columns and content types to maintain item integrity, 20
Restore the latest version(s), 21
Search all pages, 9
Search current page, 9
Security, 17
Skip, 19
Specify Location, 11
SQL authentication, 10
Staging Policy, 10
Temp database file location, 10
Temp log file location, 11
User Mapping, 18
View Details, 12
Week, 16
Windows authentication (recommended), 10
Yes, 20, 21
DocAve 6: SQL Server Data Manager
33
Notices and Copyright Information
Notice
The materials contained in this publication are owned or provided by AvePoint, Inc. and are the property
of AvePoint or its licensors, and are protected by copyright, trademark and other intellectual property
laws. No trademark or copyright notice in this publication may be removed or altered in any way.
Copyright
Copyright © 2013 AvePoint, Inc. All rights reserved. All materials contained in this publication are
protected by United States and international copyright laws and no part of this publication may be
reproduced, modified, displayed, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent
of AvePoint, 3 Second Street, Jersey City, NJ 07311, USA or, in the case of materials in this publication
owned by third parties, without such third party’s consent. Notwithstanding the foregoing, to the extent
any AvePoint material in this publication is reproduced or modified in any way (including derivative
works and transformative works), by you or on your behalf, then such reproduced or modified materials
shall be automatically assigned to AvePoint without any further act and you agree on behalf of yourself
and your successors, assigns, heirs, beneficiaries, and executors, to promptly do all things and sign all
documents to confirm the transfer of such reproduced or modified materials to AvePoint.
Trademarks
®
®
AvePoint , DocAve , the AvePoint logo, and the AvePoint Pyramid logo are registered trademarks of
AvePoint, Inc. with the United States Patent and Trademark Office. These registered trademarks, along
with all other trademarks of AvePoint used in this publication are the exclusive property of AvePoint and
may not be used without prior written consent.
Microsoft, MS-DOS, Internet Explorer, Microsoft Office SharePoint Servers 2007/2010, SharePoint Portal
Server 2003, Windows SharePoint Services, Windows SQL server, and Windows are either registered
trademarks or trademarks of Microsoft Corporation.
Adobe Acrobat and Acrobat Reader are trademarks of Adobe Systems, Inc.
All other trademarks contained in this publication are the property of their respective owners and may
not be used without such party’s consent.
Changes
The material in this publication is for information purposes only and is subject to change without notice.
While reasonable efforts have been made in the preparation of this publication to ensure its accuracy,
AvePoint makes no representation or warranty, expressed or implied, as to its completeness, accuracy,
or suitability, and assumes no liability resulting from errors or omissions in this publication or from the
use of the information contained herein. AvePoint reserves the right to make changes in the Graphical
User Interface of the AvePoint software without reservation and without notification to its users.
AvePoint, Inc.
3 Second Street
Jersey City, NJ 07311
USA
34
DocAve 6: SQL Server Data Manager
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
