Notice to Users
© 2001 Sony Electronics Inc. Reproduction in
whole or in part without written permission
is prohibited. All rights reserved. This
manual and the software described herein, in
whole or in part, may not be reproduced,
translated, or reduced to any machinereadable form without prior written
approval.
SONY ELECTRONICS INC. PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN
AND HEREBY EXPRESSLY DISCLAIMS
ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE WITH
REGARD TO THIS MANUAL, THE
SOFTWARE, OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL
SONY ELECTRONICS INC. BE LIABLE
FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING
OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR
THE USE THEREOF.
Sony Electronics Inc. reserves the right to
make any modification to this manual or the
information contained herein at any time
without notice. The software described
herein is governed by the terms of a separate
user license agreement.
This product contains software owned by
Sony and licensed by third parties. Use of
such software is subject to the terms and
conditions of license agreements enclosed
with this product. Some of the software may
not be transported or used outside the
United States. Software specifications are
subject to change without notice and may not
necessarily be identical to current retail
versions.
ii
Updates and additions to software may
require an additional charge. Subscriptions to
online service providers may require a fee
and credit card information. Financial
services may require prior arrangements
with participating financial institutions.
Sony, VAIO, the VAIO logo, and i.LINK are
registered trademarks of Sony. AMD and
Duron are trademarks or registered
trademarks of Advanced Micro Devices.
Microsoft, Windows, and the Windows logo
are registered trademarks of Microsoft
Corporation. PS/2 is a registered trademark
of IBM Corporation.
All other trademarks are trademarks or
registered trademarks of their respective
owners.
Owner’s Record
The model number and serial number are
located on the back of your VAIO® computer.
Record the serial number in the space
provided here. Refer to the model and serial
number when you call your Sony Service
Center.
Model Number: PCV-J150
Serial Number:________________________
Safety Information and Caution
CD-RW Laser Diode Properties
❑
Laser output
1.0mW(Read)
35mW (Write)
Wave Length
777-787nm
To prevent fire or shock hazard, do
not expose your desktop to rain or
moisture.To avoid electrical shock,
do not open the cabinet. Refer
servicing to qualified personnel
only.
❑
Never install modem or telephone
wiring during a lightning storm.
❑
Never install telephone jacks in wet
locations unless the jack is
specifically designed for wet
locations.
❑
Never touch uninsulated telephone
wire or terminals unless the
telephone line has been
disconnected at the network
interface.
❑
Use caution when installing or
modifying telephone lines.
❑
Avoid using the modem during an
electrical storm.
❑
Do not use the modem or a
telephone to report a gas leak in the
vicinity of the leak.
❑
The socket outlet shall be installed
near the equipment and shall be
easily accessible.
! To change the backup battery,
contact your nearest Sony
Service Center.
! Caution - The use of optical
instruments with this product
will increase eye hazard. As the
laser beam used in this product
is harmful to the eyes, do not
attempt to disassemble the drive
cabinet. Refer servicing to
qualified personnel only.
! For CD-RW: Danger - Invisible
laser radiation when open. Avoid
direct exposure to beam.
! Caution: For ADSL modem
models, to reduce the risk of fire,
use only No. 26 AWG or larger
telecommunication line cord.
iii
❑
Pour prévenir tout risque d’incendie
ou d’électrocution, garder cet appareil
à l’abri de la pluie et de l’humidité.
❑
Pour prévenir tout risque
d’électrocution, ne pas ouvrir le
châssis de cet appareil et ne confier
son entretien qu’à une personne
qualifiée.
❑
Ne jamais effectuer l’installation de fil
modem ou téléphone durant un orage
électrique.
❑
Ne jamais effectuer l’installation
d’une prise téléphonique dans un
endroit mouillé à moins que la prise
soit conçue à cet effet.
❑
Ne jamais toucher un fil téléphonique
à découvert ou un terminal à moins
que la ligne téléphonique n’ait été
débranché de l’interface réseau.
❑
Soyez très prudent lorsque vous
installez ou modifiez les lignes
téléphoniques.
❑
Évitez d’utiliser le modem durant un
orage électrique.
❑
N'utilisez pas le modem ni le
téléphone pour prévenir d'une fuite
de gaz vous êtes près de la fuite.
❑
L’appareil doit être le plus près
possible d’une prise murale pour en
faciliter l’accès.
! Pour changer la pile de
rechange, veuillez contacter
votre centre de service Sony le
plus près.
! Avertissement - L'utilisation
d'instruments optiques avec ce
produit augmente les risques
pour les yeux. Puisque le
faisceau laser utilisé dans ce
produit est dommageable pour
les yeux, ne tentez pas de
désassembler le boîtier.
Adressez-vous à un agent de
service qualifié.
! Pour les CD-RW : Danger :
Radiation laser visible et
invisible si ouvert. Évitez
l'exposition directe au faisceau.
! Attention : Pour ADSL modele
modem, afin de réduire les
risques d'incendie, n'utilisez
qu'un cordon de communication
N0. 26 AWG ou plus gros.
For questions regarding your product or for
the Sony Service Center nearest you, call 1888-476-6972 in the United States or
1-800-961-7669 in Canada.
Sony Customer Support can be reached at
http://www.sony.com/pcsupport.
iv
Regulatory Information
Declaration of Conformity
Trade Name:
Model No.:
SONY
PCV-J150
Responsible Party:
Address:
Sony Electronics Inc.
680 Kinderkamack Rd
Oradell, NJ 07649
Telephone:
201-930-6972
This phone number is for FCC-related matters
only.
This device complies with Part 15 of FCC Rules.
Operation is subject to the two following
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures: :
❑
Reorient or relocate the receiving
antenna.
❑
Increase the separation between the
equipment and the receiver.
❑
Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
❑
Consult the dealer or an
experienced radio/TV technician
for help.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
Only peripherals (computer input/output
devices, terminals, printers, etc.) that
comply with FCC Class B limits may be
attached to this computer product.
Operation with noncompliant peripherals
is likely to result in interference to radio
and television reception.
All cables used to connect peripherals
must be shielded and grounded.
Operation with cables, connected to
peripherals, that are not shielded and
grounded, may result in interference to
radio and television reception.
v
FCC Part 68
This equipment complies with Part 68 of the
FCC rules. The FCC Ringer Equivalence
Number (REN) for this equipment is 0.7. If
requested, this information must be provided
to the telephone company.
This modem uses the USOC RJ-11 telephone
jack.
The REN is used to determine the quantity of
devices which may be connected to the
telephone line. Excessive RENs on the
telephone line may result in the devices not
ringing in response to an incoming call. In
most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of
the number of devices that may be connected
to the line, as determined by the total RENs,
contact the telephone company to determine
the maximum REN for the calling area.
If the terminal equipment causes harm to the
telephone network, the telephone company
will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice is not practical, the
telephone company will notify the customer
as soon as possible. Also, you will be advised
of your right to file a complaint with the FCC
if you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operations of
the equipment. If this happens, the telephone
company will provide advance notice in
order for you to make the necessary
modifications in order to maintain
uninterrupted service.
If trouble is experienced with this modem,
for repair or warranty information, please
contact 1-888-4SONY-PC, or write to the
Sony Customer Information Center, 12451
Gateway Blvd., Fort Myers, FL 33913. If the
trouble is causing harm to the telephone
network, the telephone company may
request that you remove the equipment from
the network until the problem is resolved.
vi
Repair of this equipment should be made
only by a Sony Service Center or Sony
authorized agent. For the Sony Service
Center nearest you, call 1-888-4SONYPC (1888-476-6972).
This equipment cannot be used on public
coin service provided by the telephone
company. Connection to Party Line Service is
subject to state and possible provincial tariffs.
(Contact the state or provincial utility service
commission, public service commission, or
corporation commission for information.)
Telephone Consumer Protection
Act of 1991 (United States)
The Telephone Consumer Protection Act of
1991 makes it unlawful for any person to use
a computer or other electronic device to send
any message via a telephone facsimile
machine unless such message clearly
contains, in a margin at the top or bottom of
each transmitted page or on the first page of
the transmission, the date and time it is sent
and an identification of the business, other
entity, or individual sending the message,
and the telephone number of the sending
machine or such business, other entity, or
individual.
In order to program this information into
your facsimile, see your fax software
documentation.
Telephone Consumer Guidelines
(Canada)
Please refer to your telephone directory
under ‘Privacy Issues’ and/or ‘Terms of
Service.’ For more detailed information,
please contact:
CRTC
Terrasses de la Chaudiére, Tour centrale
1 promenade du Portage, 5 étage Hull PQ
K1A 0N2.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet àppareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
DISPOSAL OF LITHIUM
BATTERY
You can return your unwanted lithium
batteries to your nearest Sony Service
Center or Factory Service Center.
✍ In some areas the disposal of
lithium batteries in household or
business trash may be prohibited.
For the Sony Service Center nearest you,
call 1-888-476-6972 in the United States or
1-800-961-7669 in Canada.
! Do not handle damaged or
leaking lithium batteries.
! Danger of explosion if battery is
incorrectly replaced. Replace
only with the same or
equivalent type recommended
by the manufacturer. Discard
used batteries according to the
manufacturer’s instructions.
! The battery pack used in this
device may present a fire or
chemical burn hazard if
mistreated. Do not disassemble,
heat above 212°F (100°C) or
incinerate.
Dispose of used battery
promptly.
Keep away from children.
! Ne pas manipuler les batteries
au lithium qui fuient ou sont
endommagées.
! Une batterie non conforme
présente un danger d'explosion.
La remplacer seulement par
une batterie identique ou de
type équivalent recommandé
par le fabricant. Évacuer les
batteries usées selon les
directives du fabricant.
! La manutention incorrecte du
module de batterie de cet
appareil présente un risque
d'incendie ou de brûlures
chimiques. Ne pas démonter,
incinérer ou exposer à une
température de plus de 100°C.
Évacuer promptement la
batterie usée. Garder hors de
portée des enfants.
vii
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label
identifies certified equipment. This
certification means that the equipment meets
certain telecommunications network
protective, operational and safety
requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements
document(s). The Department does not
guarantee the equipment will operate to the
userís satisfaction.
Before installing this equipment, users
should ensure that it is permissible to be
connected to the facilities of the local
telecommunications company. The
equipment must also be installed using an
acceptable method of connection.
The customer should be aware that
compliance with the above conditions may
not prevent degradation of service in some
situations.
Repairs to certified equipment should be
coordinated by a representative designated
by the supplier. Equipment malfunctions or
any repairs or alterations made by the user to
this equipment may give the
telecommunications company cause to
request that the user disconnect the
equipment.
Users should ensure for their own protection
that the electrical ground connections of the
power utility, telephone lines and internal
metallic water pipe system, if present, are
connected together. This precaution may be
particularly important in rural areas.
CAUTION: Users should not attempt to
make such connections themselves, but
should contact the appropriate electrical
inspection authority, or electrician, as
appropriate.
NOTICE: The Ringer Equivalence Number
(REN) assigned to each terminal device
provides an indication of the maximum
number of terminals allowed to be connected
to a telephone interface. The termination on
viii
an interface may consist of any combination
of devices subject only to the requirement
that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5.
The Ringer Equivalence Number for this
equipment is 0.7.
AVIS DE L’INDUSTRIE CANADA
AVIS: L’étiquette d’Industrie Canada
identifie le matériel homologué.
Cette étiquette certifie que le matériel est
conforme aux normes de protection,
d’exploitation et de sécurité des réseaux de
télécommunications, comme le prescrivent
les documents concernant les exigences
techniques relatives au matériel terminal. Le
Ministère n’assure toutefois pas que le
matériel fonctionnera à la satisfaction de
l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit
s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de
télécommunication. Le matériel doit
également être installé en suivant une
méthode acceptée de raccordement.
L’abonné ne doit pas oublier qu’il est possible
que la conformité aux conditions énoncées cidessus n’empêche pas la dégradation du
service dans certaines situations.
Les réparations de matériel homologué
doivent être coordonnées par un
représentant désigné par le fournisseur.
L’entreprise de télécommunications peut
demander à l’utilisateur de débrancher un
appareil à la suite de réparations ou de
modifications effectuées par l’utilisateur ou à
cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit
s’assurer que tous les fils de mise à la terre de
la source d’énergie électrique, des lignes
téléphoniques et des canalisations d’eau
métalliques, s’il y en a, sont raccordés
ensemble. Cette précaution est
particulièrement importante dans les régions
rurales.
Avertissement: L’utilisateur ne doit pas
tenter de faire ces raccordements luimême; il doit avoir recours à un service
d’inspection des installations électriques,
ou à un électricien, selon le cas.
AVIS: L’indice d’équivalence de la
sonnerie (IES) assigné à chaque dispositif
terminal indique le nombre maximal de
terminaux qui peuvent être raccordés à
une interface.
La terminaison d’une interface
téléphonique peut consister en une
combination de quelques dispositifs, à la
seule condition que la somme d’indices
d’équivalence de la sonnerie de tous les
dispositifs n’excède pas 5. L’indice
d’équivalence de la sonnerie de ce matériel
est de 0.7.
ix
x
Contents
Notice to Users .................................................................................... ii
Safety Information and Caution ...................................................... iii
Regulatory Information.......................................................................v
FCC Part 68 ......................................................................................... vi
Telephone Consumer Protection Act of 1991 (United States) ..... vi
Telephone Consumer Guidelines (Canada).................................. vii
DISPOSAL OF LITHIUM BATTERY ............................................. vii
INDUSTRY CANADA NOTICE.................................................... viii
AVIS DE L’INDUSTRIE CANADA .............................................. viii
Chapter 1 — Identifying Components
Front View ...................................................................................................2
Drives ..................................................................................................3
Buttons and Switches .........................................................................4
Indicators ..............................................................................................5
Rear View ....................................................................................................6
Icons .....................................................................................................7
I/O Connectors ....................................................................................9
Expansion Slots ..................................................................................13
Chapter 2 — Configuring Your System
Accessing the BIOS Setup Utility............................................................16
Changing the Display's Power Management Settings.........................17
Configuring the System Board ...............................................................20
Chapter 3 — Removing, Installing, and Replacing Components
Removing the Side Panel ........................................................................22
Removing the Front Panel .......................................................................23
Replacing the Front Panel ........................................................................24
Replacing the Side Panel .........................................................................25
xi
xii
VAIO® Reference Manual
Installing an Add-In Card .......................................................................26
Removing an Add-in Card .....................................................................28
Replacing the Lithium Battery ...............................................................30
Removing a Memory Module ................................................................33
Installing System Memory ......................................................................36
Removing a Slot Cover.............................................................................40
Covering an Open I/O Slot ....................................................................41
Installing a 3½” Internal Hard Disk Drive ............................................42
Chapter 4 — System Board
Connectors..................................................................................................48
Front Panel Header............................................................................48
Diskette Drive Connector ................................................................49
Memory Module (DIMM) Connectors ...........................................50
PCI Slot Connectors ...........................................................................51
IDE Connectors .................................................................................52
Power Connector ...............................................................................52
KEYBOARD and MOUSE Connectors ..........................................53
USB Connectors .................................................................................54
PRINTER, i.LINK, and MONITOR Connectors ............................55
SERIAL, HEADPHONES, LINE IN, MIC Connectors .................57
Fan Connector ...................................................................................59
CD-IN Connector ...............................................................................60
AUX-IN Connector ............................................................................61
Configuration Jumper .............................................................................62
Chapter 5 — Fax/Modem Card
Chapter 6 — Ethernet Card
Chapter 7 — CMOS Setup Options
Main Screen ...............................................................................................69
Advanced Screen ......................................................................................71
Power Screen..............................................................................................72
Boot Screen ................................................................................................73
Exit Screen ..................................................................................................74
Chapter 8 — Miscellaneous Technical Information
About User and Supervisor Passwords ................................................76
xiii
Beep Code Error Messages .....................................................................77
PCI Configuration Status and Error Messages ....................................78
DMA Channel Assignments ...................................................................79
System I/O Address Map ......................................................................80
Memory Map ............................................................................................82
IRQ Settings ..............................................................................................83
Chapter 9 — Specifications
Processor ...................................................................................................85
Chipset ......................................................................................................85
PCI Bus ......................................................................................................85
Memory Modules (DIMMs) ..................................................................85
DIMM Configurations .............................................................................86
Cache Memory ..........................................................................................86
Graphics ....................................................................................................86
Audio .........................................................................................................87
Communications .....................................................................................87
I/O and Expansion Slots .........................................................................87
Drives and Controllers ...........................................................................88
System BIOS .............................................................................................88
xiv
Chapter 1
Identifying Components
The following sections identify and describe each component that is
visible from the exterior of the VAIO® Computer. Internal components are
identified in the appropriate section of this manual.
1
2
VAIO® Reference Manual
Front View
Front panel
OM04694X.VSD
Identifying Components
3
Drives
CD-RW drive
Diskette drive
FRNTPNLA.VSD
Drive
Description
Diskette drive
CD-RW
CD-RW read†
CD-RW write‡
CD-R read**
CD-R write††
CD-ROM read‡‡
*
†
3.5-inch, 1.44 Mbyte.
drive*
20X maximum performance
4X maximum performance
32X maximum performance
8X maximum performance
32X maximum performance
The CD-RW/CD-R/CD-ROM data transfer standard 1X rate is 150 kbytes/s.
Data on a CD-RW is read at a variable transfer rate, ranging from 8X at the innermost track to 20X
at the outermost track. The average data transfer rate is 14X (2100 kbytes/s).
‡ Data on a CD-RW is written at a constant transfer rate of 1X, 2X, or 4X, depending on the speed
you select.
** Data on the CD-R is read at a variable transfer rate, ranging from 13X at the innermost track to 32X
at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The average data transfer
rate is 22.5X (3375 kbytes/s).
†† Data on a CD-R is written at a constant transfer rate of 1X, 2X, 4X, or 8X, depending on the speed
you select.
‡‡ Data on the CD-ROM is read at a variable transfer rate, ranging from 13X at the innermost track to
32X at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The average data
transfer rate is 22.5X (3375 kbytes/s).
4
VAIO® Reference Manual
Buttons and Switches
Eject hole
CD-RW disc eject
Diskette eject
Power/Standby
FRNTPNLB.VSD
Button or switch
Description
Power/Standby switch
Turns system power on, off, or into standby mode.
Diskette eject button
Ejects a diskette.
CD-RW disc eject button
Automatically opens and closes the CD-RW drive
tray.
5
Identifying Components
Indicators
Diskette drive access
Power/Standby
Hard disk drive access
FRNTPNLC.VSD
Indicator
Description
Power/Standby indicator
Standby (amber) indicates the computer is
in standby mode.
On (green) indicates the computer is out
of standby mode, ready to use.
Off (no color) indicates the computer is
turned off or in hibernate mode.
Diskette drive access indicator
On (green) indicates diskette drive
activity.
Hard disk drive access indicator
On (amber) indicates hard disk drive
activity.
6
VAIO® Reference Manual
Rear View
MOUSE
KEYBOARD
USB1-USB3
Power
i.LINK (IEEE1394)
PRINTER
MONITOR
SERIAL
HEADPHONES
LINE IN
MIC
Ethernet
LINE
TELEPHONE
KY0001.VSD
Identifying Components
Icons
Icon labels
OM04692X.VSD
Icon
Description
MOUSE connector
KEYBOARD connector
USB (Universal Serial Bus) connector
SERIAL connector
PRINTER connector
HEADPHONES connector
LINE IN jack (audio)
MIC (microphone) jack
7
8
Icon
VAIO® Reference Manual
Description
MONITOR connector
LINE (for telephone line from primary service jack)
TELEPHONE (for phone)
i.LINK® (IEEE1394) interface
Ethernet connector (10Base-T/100Base-TX)
(This connector is for LAN use only. Do not plug a phone into
this connector.)
9
Identifying Components
I/O Connectors
The following section identifies the various I/O connectors.
KEYBOARD and MOUSE
The KEYBOARD and MOUSE connectors are physically identical and
have the same pinout. They are standard 6-pin PS/2®-type female
connectors.
KEYBOARD
MOUSE
2
2
3
1
3
1
4
6
4
6
5
5
KY0002.VS
USB Connectors
The USB connectors are standard 4-pin USB connectors. The USB
connectors are located at the rear of the system.
USB1 USB2 USB3
KY0003.VS
SERIAL Connector
The SERIAL connector is a standard 9-pin DB-9 male connector.
6
9
1
5
KY0057.VSD
10
VAIO® Reference Manual
PRINTER Connector
The PRINTER connector is a standard 25-pin DB-25 female connector.
13
25
14
1
KY0005.VSD
MONITOR
The MONITOR connector is a standard 15-pin female high-density VGAtype connector.
10
15
5
11
1
6
KY0004.VSD
Identifying Components
11
MIC, LINE IN, and HEADPHONES
The MIC, LINE IN, and HEADPHONES jacks are physically identical,
but have different connections. They are standard 3.5 mm stereo minijacks.
HEADPHONES
LINE IN
MIC
KY0013.VSD
Connector
Description
HEADPHONES
1.0 Vrms (typical).
MIC
Electret condenser microphone input.
LINE IN
1.0 Vrms (typical), 10 Kohm impedance.
TELEPHONE and LINE
The TELEPHONE and LINE jacks are physically identical and have
identical connections. They are standard RJ-11 female phone jacks.
However, the LINE jack is for connecting to a telephone line that comes
from the wall, and the TELEPHONE jack is for connecting the computer
to a telephone.
LINE
PHONE
KY0014.VSD
✍ Accidentally plugging a phone line from the wall into the modem’s
TELEPHONE jack, and a telephone into the LINE jack, will not damage the
modem card or telephone equipment. However, the modem will not work
correctly.
12
VAIO® Reference Manual
i.LINK® (IEEE1394) Connector
The 6-pin i.LINK connector on the back of the system can supply power
from the computer to a device if the device also has a 6-pin i.LINK
connector. The 6-pin connector supplies 10V to 12V and a maximum
power of 6 watts.
✍ i.LINK is a trademark of Sony used only to designate that a product contains an
IEEE 1394 connection. The i.LINK connection may vary, depending on the software
applications, operating system and i.LINK-compatible devices. All products with an
i.LINK connection may not communicate with each other.
✍ Refer to the documentation that came with your i.LINK-compatible device for
information on operating conditions and proper connections. Before connecting
i.LINK compatible PC peripherals to your system, such as a CD-RW or Hard Disk
Drive, confirm their operating system compatibility and required operating
conditions.
6-pin i.LINK
(IEEE-1394)
On back of
system
KY0087.VSD
Ethernet Connector
The Ethernet connector is a standard RJ-45 modular jack that connects to
a 10Base-T/100Base-TX Ethernet LAN connection.
Ethernet
On back of system
!
This connector is for LAN use only. Do not plug a phone cord into this
connector.
KY0100.VSD
Identifying Components
13
Expansion Slots
There are four PCI slots, two of which are available for expansion (PCI #3
and #4). The other two PCI slots are occupied by the Ethernet card
(PCI #2) and fax/modem card (PCI #1).
PCI #4
PCI #3
PCI #2
PCI #1
OM04577B.VSD
14
Chapter 2
Configuring Your System
This chapter contains information on configuring your system.
Configuring your system can consist of the following:
❑
Making changes to the BIOS settings
❑
Making changes to the display's power management settings
❑
Changing the system board jumper position
15
16
VAIO® Reference Manual
Accessing the BIOS Setup Utility
You must access the BIOS Setup Utility to make changes to the BIOS
settings (see “CMOS Setup Options” on page 67 for information on BIOS
settings).
!
1
2
Before rebooting the system, save any open files and exit the Microsoft®
Windows® operating system.
Reboot the system.
When the Sony logo appears, press F3. The following message
appears at the bottom of the screen.
Press <F2> for setup.
3
Press F2.
Each menu presents options for modifying the system configuration.
Use the left and right arrow keys to select a menu from the menu bar.
Use the up and down arrow keys to select items within a menu. Once
an item is highlighted, use the plus/minus (+/-) keys to modify a
setting.
If an item has a triangle ( ) to its left, this indicates that a sub-menu of
options is available. Press ENTER to access a sub-menu. If a submenu contains items with a triangle, there is another layer of options
from which to select.
4
Once you select an option, press ESC to back out of each menu until
you reach the top level, where the menu bar appears.
5
To exit the BIOS setup utility, press ESC from any top-level screen and
follow the prompts.
Configuring Your System
17
Changing the Display's Power Management Settings
A display that has power management capability is designed to operate
on reduced power or shut itself off after the system has been idle for a
specified period of time.
1
From the Start menu, point to Settings, Control Panel, then click
Power Options.
The Power Options Properties dialog box opens, with the Power
Schemes tab displayed.
2
Select the power scheme that is most appropriate for the way you use
your computer.
To change a power scheme, change the settings for Turn off monitor,
and Turn off hard disks, System standby, and System Hibernate.
The Turn off monitor option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your monitor
turns off when your computer is running on AC power. The display
reactivates when you move the mouse or press a key.
The Turn off hard disks option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your hard disks
turn off when your computer is running on AC power.
18
VAIO® Reference Manual
The System standby option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your computer
goes on standby when your computer is running on AC power.
Power is reactivated when you press spacebar on the keyboard.
The System hibernate option allows you to specify the period of
inactivity (in minutes) before your computer goes in the hibernate
state. Power is reactivated when you push the power button.
3
To save a new power scheme, first modify the settings, click Save As,
type a descriptive name, and then click OK.
4
Click the Advanced tab.
5
Select the desired settings.
Configuring Your System
6
Click the Hibernate tab.
7
Select the desired settings, and then click OK.
19
Configuring the System Board
The system board contains a CMOS Clear configuration jumper, and two
sets of reserved jumper blocks (do not change).
The CMOS and Non-Volatile RAM (NVRAM) settings are only cleared if
the checksum test returns false. Access to specific setup fields is
controlled by a supervisor password or user password.
The Clear CMOS mode removes the password that is stored in CMOS. No
other parameters are cleared.
✍ The configuration jumpers should never need changing unless otherwise
directed by a technical support or service technician.
!
1
2
Before opening the system, save any open files, exit the Microsoft®
Windows® operating system, turn off the power of the computer and all
attached peripherals, and unplug the power cord.
Remove the side panel (see “Removing the Side Panel” on page 22).
Set the jumpers as directed by a service technician (also see
“Configuration Jumper” on page 62).
1 2 3
CMOS CLR
= default jumper
1-2
2-3
CMOS Clear Normal Clear
OM04588.VSD
3
20
Reinstall the side panel (see “Replacing the Side Panel” on page 25).
Chapter 3
Removing, Installing, and Replacing
Components
This chapter describes removing, installing, and replacing major
components for upgrading, reconfiguring, and troubleshooting the
components.
!
Before opening the system unit, save any open files, exit the Windows®
operating system, turn off the power of the computer and all attached
peripherals, and then unplug the power cord.
21
22
VAIO® Reference Manual
Removing the Side Panel
You must remove the side panel to access the system board, add-in cards,
power supply, battery, memory, and internal drives.
1
2
From the rear of the unit, remove the single screw on the right side.
Slide back the panel about ½ inch, then lift out.
KY0064B.VSD
Removing, Installing, and Replacing Components
23
Removing the Front Panel
You must remove the front panel to install, remove, or replace internal
components such as a drive, diskette drive, or CD-RW drive.
1
2
Lay the system down on its side.
Pull up and out on the two plastic tabs (1 in diagram) at the bottom of
the chassis to release the bottom end of the front panel.
Front panel
1
KY0091.VSD
3
Pull out the top end of the front panel to remove it.
24
VAIO® Reference Manual
Replacing the Front Panel
1
Insert the two flat plastic tabs (located on the top of the front panel)
into the slots at the top of the chassis.
2
Push the bottom of the front panel in until the tabs snap into place.
Front panel
1
KY0093.VSD
Removing, Installing, and Replacing Components
25
Replacing the Side Panel
1
Align the bottom of the side panel with the bottom of the chassis,
with the side panel extending about ½ inch from the rear of the unit.
2
Slide the side panel forward until the lip on the side panel is flush
with the rear of the chassis.
KY0067.VSD
3
Insert the screw (removed earlier) to secure the panel.
26
VAIO® Reference Manual
Installing an Add-In Card
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug
the power cord.
1
2
3
Remove the cover (see “Removing the Side Panel” on page 22).
4
Insert the add-in card into the PCI slot connector. Use a gentle rocking
motion, pressing down until the card is fully seated.
Locate an available expansion slot connector.
Remove the slot cover adjacent to the selected slot connector (see
“Removing a Slot Cover” on page 40).
✍ Align the card's bracket so that the bottom of the bracket fits into the slot at
the bottom of the chassis. Ensure that the top of the bracket fits snugly
against the chassis lip after the card is fully inserted.
KY0070.VSD
5
6
Replace the screw that secures the card.
7
8
Replace the cover (see “Replacing the Side Panel” on page 25).
Attach any necessary cables to the card (see the instructions that came
with the add-in card).
Turn on the computer and follow any instructions that came with the
add-in card.
27
Removing, Installing, and Replacing Components
Removing an Add-in Card
!
Before opening the system unit, save any open files, exit the Windows®
operating system, turn off the power of the computer and all attached
peripherals, and then unplug the power cord.
1
2
Remove the cover (see “Removing the Side Panel” on page 22).
3
4
Remove the screw that secures the add-in card to the chassis.
Disconnect any cables attached to the add-in card you want to
remove.
Remove the add-in card from the PCI slot connector and store the
card in an anti-static wrapper for future use.
KY0071.VSD
✍ Grasp the card with one hand on each end, and gently pull up as you rock the
card from side to side.
!
Hold the add-in card by its edges and do not touch any components or
connector contacts on the card. Static electricity in your body may
damage sensitive components on the card. As a precaution, touch any
exposed metal part on the metal chassis (preferably the metal part on
the power supply) before handling an add-in card to discharge any
static electricity in your body.
28
VAIO® Reference Manual
5
If you do not replace the card or install another add-in card, install a
slot cover over the vacant slot at the rear of the chassis (see “Covering
an Open I/O Slot” on page 41).
6
Replace the cover (see “Replacing the Side Panel” on page 25).
Removing, Installing, and Replacing Components
29
Replacing the Lithium Battery
You may need to replace the lithium battery if your computer consistently
loses the date or time settings after turning it off. The lithium battery has
a typical life of three years, after which the battery may be too weak to
power the CMOS memory.
!
When you remove the lithium battery, all values stored in the CMOS
memory (BIOS setup values and Plug and Play values) may be lost.
Although the computer can hold the charge for a short time while replacing
the battery, it is safer to assume that the settings will be lost. When the
values are lost, the BIOS values revert to their factory-default settings (see
“Accessing the BIOS Setup Utility” on page 16).
Do not handle damaged or leaking batteries.
The lithium battery may explode if mistreated. Do not disassemble it or
dispose of it in fire.
1
Reboot your computer by selecting Shut Down... from the Start
menu, and then selecting Restart the computer.
2
If the error message “Error: Check date and time settings”appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. Otherwise it is not necessary to replace
the battery at this time, and you can skip all remaining steps.
3
Compare all the BIOS options to their default settings (see “CMOS
Setup Options” on page 67). Make a list of all the BIOS options that
are different from their default values. You will refer to this list when
you restore the BIOS settings later.
4
Select Exit Discarding Changes from the main menu using the right
arrow key.
5
Press Enter, type Y when prompted to discard changes, then press
Enter to exit the BIOS Setup Utility.
6
7
Turn off the computer and unplug the power cord.
Remove the side panel (see “Removing the Side Panel” on page 22).
30
8
VAIO® Reference Manual
If necessary, remove any add-in cards (see “Removing an Add-in
Card” on page 28) to gain access to the battery. You may also need to
disconnect some cables.
!
9
Touch any exposed metal part of chassis to discharge static electricity
in your body before handling an add-in card or other sensitive
electronic component.
Use a flathead screwdriver to push in on the small tab inside the
battery holder to pop out the battery.
KY0072.VSD
✍ The battery is located just beneath the hard drive holder. Although you do not
have to remove the hard drive holder, this illustration shows the battery with the
drive holder removed for clarity.
10
Use your fingers to lift out the battery and dispose of it according to
the instructions that came with the new battery.
11
Insert the new battery into the battery holder, with the plus (+) side
up, and gently press down until the battery snaps into place.
✍ The Sony CR2032 battery is recommended. Using a type of battery other
than a CR2032 may present a risk of fire or explosion.
12
13
14
15
Replace any add-in cards that were removed.
Reconnect any cables that were disconnected.
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and turn on the computer.
Removing, Installing, and Replacing Components
31
16
If the error message “Error: Check date and time settings.” appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. If no error message displays, the
computer’s BIOS settings were retained during the battery
replacement and you can skip the remaining steps.
17
Refer to the list you made in step 3 and restore any non-default BIOS
settings (see “CMOS Setup Options” on page 67).
18
Select Exit Saving Changes from the main menu using the right arrow
key.
19
Press Enter, type Y when prompted to save configuration changes,
then press Enter to exit the BIOS Setup Utility.
The computer’s BIOS settings are now restored.
32
VAIO® Reference Manual
Removing a Memory Module
You may need to remove a memory module if you change the memory
configuration or replace a bad module.
!
Before opening the system unit, save any open files, exit the Windows®
operating system, turn off the power of the computer and all attached
peripherals, and then unplug the power cord.
1
Remove the left side cover (see “Removing the Side Panel” on
page 22).
2
Remove the power supply by lifting it up and resting it upside down
over the corner of the chassis where the CD-RW and floppy drives are
located.
AUR001.VSD
✍ The screw that secures the power supply to the chassis is the same screw that
secures the side panel to the chassis.
33
Removing, Installing, and Replacing Components
3
Locate the memory module you wish to remove.
KY0073.VSD
4
Push down the handle on each side of the memory module to eject
the module from its socket.
Push out
Handles
KY0042.VS
✍ Gently push the power supply cables and ribbon cables aside as you reach
inside the system to access the module connector.
34
5
VAIO® Reference Manual
Grasp one edge of the memory module and lift out. Store the module
in a static-free bag.
!
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling the memory module.
6
To install system memory, see “Installing System Memory” on
page 36.
7
Replace the power supply by sliding it down the rails on each side of
the chassis opening until the metal tab on the power supply slips into
the slot in the CD-RW drive.
Tab fits into slot in CD-RW drive
AUR002.VSD
8
9
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and turn on the computer.
Your computer automatically recognizes any change in memory and will
configure itself accordingly when you turn on the computer. No further
action is required.
Removing, Installing, and Replacing Components
35
Installing System Memory
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug
the power cord.
1
Remove the new memory module(s) from its anti-static package.
Hold the memory module only by its edges to prevent staticelectricity damage.
2
Choose the size of the memory module and configuration as shown
in the following table. Memory modules can vary in size and speed
between sockets. The minimum memory size is 8 MB. The maximum
memory size is 512 MB. The BIOS automatically detects the type, size
and speed of the memory modules.
Memory module configurations (MB)*
DIMM1
DIMM2
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
* The PCV-J150 ships with 64 MB. SDRAM is expandable to 512
MB.
!
Touch any exposed metal part of the chassis to discharge static electricity in
your body before handling a memory module.
✍ Use only 3.3V 64-bit PC-133 SDRAM DIMM modules. Do not mix 66 MHz or
100MHz memory with 133 MHz memory. Supports SDRAM memory. Does not
support EDO memory or buffered DIMM memory.
3
4
5
Disconnect the power cord from the computer.
Remove the side panel (see “Removing the Side Panel” on page 22).
Remove the front panel (see “Removing the Front Panel” on page 23).
36
6
VAIO® Reference Manual
Remove the power supply by lifting it up and rest it upside down
over the corner of the chassis where the CD-RW and floppy drives are
located.
AUR001.VSD
✍ The screw that secures the power supply to the chassis is the same screw that
secures the side panel to the chassis.
7
If necessary, remove the memory module you wish to replace (see
“Removing a Memory Module” on page 33).
Removing, Installing, and Replacing Components
8
37
Align the memory module over the appropriate socket, noting the
location of pin 1 on the module and pin 1 on the socket.
Press down
here
Handles
Memory module (DIMM)
1
9
Carefully but firmly insert the edge of the module into the socket.
✍ Gently push the power supply cables and ribbon cables aside as you slip your
hands into the system to reach the module connector.
10
Press down firmly and evenly at both corners until the module is
fully seated.
✍ When the module is fully seated, the handles on each side are straight up
and locked into the slot on each side of the module. If the handles are not
totally straight upright, continue to press down on each side of the module
until the handles lock into place.
38
11
VAIO® Reference Manual
Replace the power supply by sliding it down the rails on each side of
the chassis opening until the metal tab on the power supply slips into
the slot in the CD-RW drive.
Tab fits into slot in CD-RW drive
AUR002.VSD
12
13
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and turn on the computer.
Your computer automatically recognizes the extra memory and will
configure itself accordingly when you turn on the computer. No further
action is required.
Removing, Installing, and Replacing Components
39
Removing a Slot Cover
You remove a slot cover when you install an add-in card that occupies a
previously-empty slot.
1
2
3
4
5
6
Disconnect the power cord from the computer.
Lay the system on its side.
Remove the side panel (see “Removing the Side Panel” on page 22).
Locate the slot whose cover you want to remove.
Remove the screw from the slot cover.
Remove the loose slot cover and retain it for future use.
KY0069.VSD
40
VAIO® Reference Manual
Covering an Open I/O Slot
Slot covers prevent air from escaping through the empty hole. If air
escapes, the components inside the computer cannot be properly cooled.
This may damage some components, especially the main processor
(which generates the most heat).
1
Slide the tip of the slot cover (removed earlier) between the chassis
and system board.
KY0076.VSD
2
Push the slot cover down until it rests firmly on the lip in the chassis.
All add-in card brackets and slot covers rest on this lip.
3
Replace the screw (removed earlier) to secure the I/O slot cover.
41
Removing, Installing, and Replacing Components
Installing a 3½” Internal Hard Disk Drive
Your system comes with an available bay to hold an additional 3½” IDE
hard disk drive. Some models, such as Configure-to-Order (CTO)
systems, may already have a second hard disk drive.
Your system can support ATA-33, ATA-66, or ATA-100 hard disk drives.
The drive you install must not require front panel access. The hard disk
drive access light blinks when either internal drive is active.
!
1
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug
the power cord.
Configure the jumpers on the new drive as a slave device (see your
drive’s documentation for configuration instructions).
Power connector
Jumpers
Drive connector
KY0084.VSD
2
3
4
Disconnect the power cord from the computer.
Remove the side panel (see “Removing the Side Panel” on page 22).
Lift the tab adjacent to the drive holder.
42
5
VAIO® Reference Manual
Slide the drive holder forward (towards the diskette drive) about a ½
inch, and then lift out.
Disk drive holder
KY0081.VSD
6
Place the drive holder upside down on top of the power supply.
Disk drive holder
KY0081B.VSD
Removing, Installing, and Replacing Components
7
43
Slide the new drive into the drive holder and align the holes on each
side of the drive holder.
Align
holes
KY0083.VSD
8
Secure the drive to the drive holder using the two holes on each side
of the drive holder (screws are provided with the new drive). Do not
overtighten the screws.
9
Connect the second drive connector to the new drive (see next
diagram).
10
Connect the second power connector to the new drive.
Second power connector
Second drive connector
KY0085.VSD
11
Make sure the drive connector is connected securely to the
motherboard.
44
12
VAIO® Reference Manual
Lower the drive holder down and slide it back against the chassis
(item 1 in diagram). Be sure the drive holder feels secure against the
chassis.
Disk drive holder
2
1
KY0086.VSD
13
14
15
Push the tab down (item 2 in diagram) to secure the drive holder.
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and then turn on your computer.
Your computer automatically recognizes the new drive and configures
itself accordingly when you turn it on. Format and partition the new
drive following the instructions provided with the drive.
Chapter 4
System Board
This chapter identifies each component on the system board and provides
a detailed description of each connector, jumper, and switch on the
system board.
CPU
Memory
CPU Fan
Keyboard, Mouse
Power Supply Fan
USB1/2/3
Parallel (top),
i.Link, Monitor
Power Supply
IEEE 1394 Header
(not used)
Serial (top)
Mic In, Line In, Line Out
Diskette
Secondary IDE
Primary IDE
Video (not used)
VIRQ
Battery
CD-In (to CD-RW drive)
Aux-In (not used)
Front panel header
Wake-On-LAN (not used)
PCI slot 4
PCI slot 3
PCI slot 2
PCI slot 1
CMOS Clear
Normal 1-2
Clear 2-3
OM04581.VS
47
48
VAIO® Reference Manual
Connectors
Front Panel Header
The front panel header is a 20-pin header (one pin is removed for the key)
that provides connections to various front panel functions. A 20-pin
connector with only eight wires is used to interface the system board to
the front panel.
Front panel header
MSG
LED
PWR
SPKR
(not used)
HD
LED
PWR
LED
RESET
KY0031.VSD
Name
Description
SPEAKER
(not used)
PWR LED
Connects to the power-on indicator light on the front panel
HD LED
Connects to the hard disk drive access light on the front panel
PWR
Connects to the power-on switch on the front panel
RESET
(not used)
MSG LED
Connects to the standby indicator light on the front panel.
49
System Board
Diskette Drive Connector
Key (pin 5)
33
1
34
2
OM04701H.VSD
50
VAIO® Reference Manual
DIMM2
DIMM1
Memory Module (DIMM) Connectors
OM04710A.VSD
Both sides of each Dual Inline Memory Module (DIMM) look very
similar. The side with pin 1 has a small "1" to the left of pin 1. Be sure to
orient a DIMM correctly in the DIMM connector (a small triangle on the
connector indicates pin 1).
Memory module (DIMM)
1
Indicates pin 1
OM04908B.VSD
System Board
51
PCI Slot Connectors
There are a total of four PCI slot connectors (slot #1 to #4). Two PCI slot
connectors (slot #3 and #4) are available. The other PCI slots are occupied
by the Ethernet card (slot #2) and fax/modem card (slot #1). The PCI slots
support 32-bit 5V and Universal (3.3/5V) PCI add-in cards.
Slot 4 (PCI)
Slot 3 (PCI)
Slot 2 (PCI)
Slot 1 (PCI)
PCI slot connector
A1
A49 A52
A62
B1
B49 B52
B62
OM04599B.VSD
52
VAIO® Reference Manual
IDE Connectors
There are two IDE (Integrated Drive Electronics) connectors on the
system board: a Primary IDE and a Secondary IDE connector.
Each IDE connector supports up to two IDE drives using a ribbon cable
with two connectors.
40
39
2
1
OM04701G.VSD
Power Connector
The power supply connector on the system board connects to the power
supply connector labelled P1.
10
20
1
11
OM04701I.VSD
System Board
53
KEYBOARD and MOUSE Connectors
The KEYBOARD connector and the MOUSE connector are 6-pin female
PS/2-type (mini-DIN) connectors. They have identical pinouts.
MOUSE
1
6
1
6
KEYBOARD
KY0032.VSD
KEYBOARD and MOUSE
Pin
Signal Name
1
DATA
2
NC
3
LOGIC GND
4
+5V (fused)
5
CLOCK
6
NC
54
VAIO® Reference Manual
USB Connectors
There are three USB ports that permit connection of USB peripheral
devices directly to the system without having to use an external hub.
USB1
USB2
USB3
KY0033.VSD
USB1, USB2, USB3
Pin
Signal Name
1
USBVCC1*
2
USBP0#
3
USBP0
4
Ground
5
USBVCC2*
6
USBP1#
7
USBP1
8
Ground
5
USBVCC3*
6
USBP2#
7
USBP2
8
Ground
* Uses over-current protector.
System Board
55
PRINTER, i.LINK, and MONITOR Connectors
The PRINTER, i.LINK (IEEE 1394), and MONITOR connectors are
mounted in a single bracket on the system board.
The PRINTER connector is a DB-25 female connector.
The 6-pin i.LINK connector can supply power from the computer to a
device if the device also has a 6-pin i.LINK (IEEE 1394) connector. The
6-pin connector supplies 10V to 12V and a maximum power of 6 watts.
The MONITOR connector is a standard 15-pin female high-density VGAtype connector.
13
1
PRINTER
25
14
5
1
15
i.LINK (IEEE 1394)
11
MONITOR
OM04701D.VSD
PRINTER connector
Pin
Signal Name
Pin
Signal Name
1
STROBE -
13
SELECT
2
DATA BIT 0
14
AUTO-FEED -
3
DATA BIT 1
15
ERROR -
4
DATA BIT 2
16
INIT -
5
DATA BIT 3
17
SELECT-IN -
6
DATA BIT 4
18
LOGIC GND
7
DATA BIT 5
19
LOGIC GND
8
DATA BIT 6
20
LOGIC GND
9
DATA BIT 7
21
LOGIC GND
10
ACK -
22
LOGIC GND
11
BUSY
23
LOGIC GND
12
PE
24
LOGIC GND
25
LOGIC GND
56
VAIO® Reference Manual
MONITOR connector
Pin
Signal Name
1
RED
2
GREEN
3
BLUE
4
GND
5
DDC GND
6
RED GND
7
GREEN GND
8
BLUE GND
9
NC
10
GND
11
GND
12
SDA
13
HORIZONTAL SYNC
14
VERTICAL SYNC
15
SCL
System Board
57
SERIAL, HEADPHONES, LINE IN, MIC Connectors
The SERIAL connector is a DB-9 male connector. The HEADPHONES
jack is a stereo mini-jack (3.5 mm) that connects to headphones. The LINE
IN jack is a stereo mini-jack (3.5 mm) that connects to a stereo audio
source (not an audio source from a video device). The MIC In jack is a
stereo mini-jack (3.5 mm) that connects to a microphone.
SERIAL
1
5
6
9
HEADPHONES
LINE IN
MIC
KY0058.VSD
SERIAL
SERIAL connector
Pin
Signal Name
1
DCD
2
RXD
3
TXD
4
DTR
5
LOGIC GND
6
DSR
7
RTS
8
CTS
9
RI
58
VAIO® Reference Manual
HEADPHONES
Audio Right Out
Audio Left Out
OM04713.VSD
LINE IN
Audio Right In
L Imbalance
Audio Left In
OM04713B.VSD
MIC
Electret bias voltage
MICimbalance
MICmono in
OM04713A.VSD
System Board
59
Fan Connector
The PWR-FAN connector is a 1 x 3-pin straight header connector.
PWR-FAN connects to the power supply and controls the power supply
cooling fan.
PWR-FAN
3
1
KY0034.VSD
PWR-FAN Connector
Pin
Signal Name
1
Ground
2
FAN_CTRL (+12V)
3
FAN_SEN
60
VAIO® Reference Manual
CD-IN Connector
The CD-IN connector on the system board is a 1 x 4-pin header connector
that connects to the CR-RW drive’s audio output connector.
CD-IN
4
1
KY0062.VSD
CD-IN
Pin
Signal Name
1
Left Line In
2
Ground
3
Ground
4
Right Line In
System Board
61
AUX-IN Connector
The AUX-IN connector on the system board is a 1 x 4-pin header
connector.
AUX-IN
4
1
KY0062B.VSD
AUX-IN
Pin
Signal Name
1
Left Line In
2
Ground
3
Ground
4
Right Line In
62
VAIO® Reference Manual
Configuration Jumper
There is one user-configurable jumper for CMOS Clear.
The computer ships with CMOS Clear in the Normal position. Do not
change the position of this jumper unless directed by a technical support
person.
1 2 3
CMOS CLR
= default jumper
1-2
2-3
CMOS Clear Normal Clear
OM04588.VSD
Chapter 5
Fax/Modem Card
The fax/modem card occupies PCI slot #1. There are two RJ-11 jacks: one
to connect a telephone line, and one to connect a phone.
TELEPHONE
LINE
KY0038.VSD
Connectors
Name
Connector Type
Description
TELEPHONE
RJ-11
Connects to phone
LINE
RJ-11
Connects to telephone line
63
64
Chapter 6
Ethernet Card
The Ethernet card occupies PCI slot #2. The Ethernet card has one
connector that is accessible from the rear panel.
(not used)
JP1
Ethernet
VOY002.VSD
Name
Connector Type
Description
Ethernet
RJ-45
Connects to 10Base-T/100Base-TX
Ethernet LAN cable.
65
66
Chapter 7
CMOS Setup Options
This chapter describes each screen in the Award BIOS Setup Utility (see
“Accessing the BIOS Setup Utility” on page 16).
The Award BIOS setup has five menu items on the menu bar. These are:
❑
Main
❑
Advanced
❑
Power
❑
Boot
❑
Exit
Options that you can change are enclosed in brackets. Text that is not
enclosed in brackets cannot be changed.
A small triangle ( ) indicates that there is a sub-menu with additional
information and options. Press Enter to display the sub-menu. The
information and options in a sub-menu are context-sensitive (they appear
or disappear, depending on which options you select).
The item shown in [brackets] in this guide is the default option. The
option shown in [brackets] on the screen is the option currently set for
your system.
The other available options for each item are shown without brackets
directly below the default option in this guide. The available options are
listed in the order they occur when you press the + key.
Use the left and right arrow keys to choose a menu item. Use the up and
down arrow keys to select an option. Press Enter to display a list of
options, or press the + or - key to cycle through the other options.
If you display the list of options, use the up and down arrow keys to
select an option in the list, then press Enter to choose the selection.
Press Esc to go back to the main menu.
67
68
VAIO® Reference Manual
Press F10 to save the changes and exit, or press Esc to discard the changes.
Follow the on-screen prompts for other choices. The bottom of the screen
presents a summary of the keys to use for navigation and control.
CMOS Setup Options
Main Screen
System Time
[00:00:00]
System Date
[01/01/2000]
Primary Master (see “IDE Sub-Menus” on page 70)
Primary Slave (see “IDE Sub-Menus” on page 70)
Secondary Master (see “IDE Sub-Menus” on page 70)
Secondary Slave (see “IDE Sub-Menus” on page 70)
Supervisor Password
[Disabled]
User Password
[Disabled]
Installed Memory
64 MB
BIOS Revision
1002
69
70
VAIO® Reference Manual
IDE Sub-Menus
Type
[Auto]
User Type HDD
CD-ROM
LS-120
ZIP-100
MO
Other ATAPI
None
Translation Method*
[LBA]
Large
Normal
Match Partition Table
Manual
Cylinders†
[1024]
Heads†
[255]
Sectors‡
[63]
CHS Capacity*
8422MB
Maximum LBA Capacity*
30020MB
Multi-Sector
Transfers*
[Maximum]
Disabled
2 Sectors
4 Sectors
8 Sectors
16 Sectors
32 Sectors
SMART Monitoring*
[Disabled]
Enabled
PIO Mode**
[4]
ULTRA DMA Mode†
[5]
Set Device
As††
[Auto]
Floppy
Hard Disk
* This option appears when Type is set to User Type HDD.
† This option appears when Type is set to Auto or User Type HDD.
‡ This option appears when Type is set to Auto or User Type HDD.
** This option appears when Type is not set to None.
†† This option appears when Type is set to ZIP-100 or MO.
CMOS Setup Options
Advanced Screen
CPU Speed
800Mhz
Chip Configuration
VGA Shared Memory Size
[8MB]
16MB
I/O Device Configuration
Onboard AC97 Audio Controller [Enabled]
Disabled
Onboard 1394 Controller
[Enabled]
Disabled
Onboard Serial Port 1
[3F8H/IRQ4]
2F8H/IRQ3
3E8H/IRQ4
2E8H/IRQ10
Disabled
Onboard Parallel Port
[378H/IRQ7]
278H/IRQ5
Disabled
3BCH/IRQ7
Parallel Port Mode
[Normal]
EPP
ECP
ECP+EPP
PCI Configuration
Slot 1 IRQ
to
Slot 3 IRQ
[Auto]
NA
3
4
5
7
9
10
11
12
14
15
71
72
VAIO® Reference Manual
Power Screen
Power Up Control
AC PWR Loss Restart
[Disabled]
Enabled
PWR Up On Modem Act
[Disabled]
Enabled
Wake On PME
[Disabled]
Enabled
Wake On USB
[Enabled]
Disabled
Hardware Monitor
MB Temperature
[(displays actual temperature)]
Ignore
CPU Temperature
[(displays actual temperature)]
Ignore
CPU Fan Speed
[Ignore]
(displays actual RPM)
Power Fan Speed
[(displays actual RPM)]
Ignore
VCORE Voltage
[(displays actual voltage)]
Ignore
+3.3V Voltage
[(displays actual voltage)]
Ignore
+5V Voltage
[(displays actual voltage)]
Ignore
+12V Voltage
[(displays actual voltage)]
Ignore
-12V Voltage
[(displays actual voltage)]
Ignore
CMOS Setup Options
Boot Screen
1. ATAPI CD-ROM
[(displays installed drive)]
Disabled
2. Removable Device
[Legacy Floppy]
LS120
ZIP-100
ATAPI MO
Disabled
3. IDE Hard Drive
[(displays installed drive)]
Disabled
4. Other Boot Device
[Disabled]
INT18 Device (Network)
SCSI Boot Device
Silent Boot
[Enabled]
Disabled
73
74
VAIO® Reference Manual
Exit Screen
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Chapter 8
Miscellaneous Technical
Information
This chapter contains information on the following subjects:
❑
User and Supervisor password
❑
Beep code error messages
❑
PCI configuration status and error messages
❑
DMA channel assignments
❑
IRQ assignments
❑
System I/O address map
❑
Memory map
❑
PCI configuration space map
75
76
VAIO® Reference Manual
About User and Supervisor Passwords
The system allows you to specify up to two passwords (a User password
and a Supervisor password) in the CMOS Setup Utility. The User
password is required; the Supervisor password is optional.
Access to the CMOS Setup Utility depends on which passwords were
previously set, as indicated next.
If you set these passwords...
...the following passwords are required:
User password only
User password is required at bootup.
Supervisor password only
No password is required at bootup.
Supervisor password is required by most
setup options.
Both passwords
User password is required at bootup.
Supervisor password is required by most
setup options.
Miscellaneous Technical Information
77
Beep Code Error Messages
During a normal bootup, a single short beep signifies that the system is
OK. Other beep patterns signify errors. The number of beeps indicates the
specific error that occurred.
The Sony Online Support technical representative will need to know how
many beeps your system produces if there is an error, so be sure to count
the number of beeps before calling for support.
78
VAIO® Reference Manual
PCI Configuration Status and Error Messages
The following is a list of status and error messages that may appear on
your system from time to time.
Message
Meaning
Floppy Disk Controller
Resource Conflict
The diskette controller has requested a
resource that is already in use.
CMOS Checksum Error,
CMOS Cleared
The CMOS data was reinitialized due to a
CMOS checksum error.
CMOS Data Invalid,
CMOS Cleared
Invalid entry in the CMOS.
Parallel Port Resource Conflict
The parallel port has requested a resource
that is already in use.
PCI Error Log is Full
This message is displayed when more than
15 PCI conflict errors are detected. No
additional PCI errors can be logged.
PCI I/O Port Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI IRQ Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI Memory Conflict
Two devices requested the same resource,
resulting in a conflict.
Primary Boot Device Not
Found
The designated primary boot device (hard
disk drive, diskette drive, CD-ROM drive,
or network drive) could not be found.
Primary IDE Controller
Resource Conflict
The primary IDE controller has requested a
resource that is already in use.
Primary Input Device Not
Found
The designated primary input device
(keyboard, mouse, or other, if input is
redirected) could not be found.
Primary Output Device Not
Found
The designated primary output device
(display, serial port, or other, if input is
redirected) could not be found.
Secondary IDE Controller
Resource Conflict
The secondary IDE controller has requested
a resource that is already in use.
Serial Port 1 Resource Conflict
Serial port 1 has requested a resource that is
already in use.
Static Device Resource Conflict
A device has requested a resource that is
already in use.
System Board Device Resource
Conflict
A device has requested a resource that is
already in use.
Miscellaneous Technical Information
79
DMA Channel Assignments
This shows the factory default values. The Microsoft® Windows®
Millenium Edition operating system reassigns resources to best meet the
needs of a particular configuration.
DMA
Channel
Default Assignment
2
Standard diskette controller
4
Direct memory access controller
80
VAIO® Reference Manual
System I/O Address Map
Address Range
(hex)
Description
0000h-000Fh
Direct memory access controller
0010h-001Fh
Motherboard resources
0020h-0021h
Programmable interrupt controller
0022h-002Dh
Motherboard resources
002Eh-002Fh
Motherboard resources
0030h-003Fh
Motherboard resources
0040h-0043h
System timer
0044h-005Fh
Motherboard resources
0060h-0060h
Standard 101/102-Key or Microsoft Natural Keyboard
0061h-0061h
System speaker
0062h-0063h
Motherboard resources
0064h-0064h
Standard 101/102-Key or Microsoft Natural Keyboard
0065h-006Fh
Motherboard resources
0070h-0073h
System CMOS/real time clock
0074h-007Fh
Motherboard resources
0080h-0090h
Direct memory access controller
0091h-0093h
Motherboard resources
0094h-009Fh
Direct memory access controller
00A0h-00A1h
Programmable interrupt controller
00A2h-00BFh
Motherboard resources
00C0h-00DFh
Direct memory access controller
00E0h-00EFh
Motherboard resources
00F0h-00FFh
Numeric data processor
0170h-0177h
Secondary IDE controller (dual FIFO)
0170h-0177h
SiS 5513 dual PCI IDE controller
01F0h-01F7h
Primary IDE controller (dual FIFO)
01F0h-01F7h
SiS 5513 dual PCI IDE controller
0290h-029Eh
Motherboard resources
0376h-0376h
Secondary IDE controller (dual FIFO)
0376h-0376h
SiS 5513 dual PCI IDE controller
0378h-037Fh
Printer Port (LPT1)
03B0h-03BBh
SiS 730s
Miscellaneous Technical Information
Address Range
(hex)
Description
03C0h-03DFh
SiS 730s
03F0h-03F1h
Motherboard resources
03F2h-03F5h
Standard floppy disk controller
03F6h-03F6h
Primary IDE controller (dual FIFO)
03F6h-03F6h
SiS 5513 dual PCI IDE controller
03F7h-03F7h
Standard floppy disk controller
03F8h-03FFh
Communications port (COM1)
0480h-048Fh
Motherboard resources
04D0h-04D1h
Motherboard resources
0CF8h-0CFFh
PCI bus
B000h-B0FFh
WDM communication device
B400h-B407h
WDM communication device
B800h-B8FFh
Realtek RTL8139 (A/B/C/8130) PCI Fast Ethernet NIC
C000h-CFFFh
SiS Accelerated Graphics Port
C800h-C87Fh
SiS 730s
D400h-D4FFh
SiS 7018 audio driver
D800h-D807h
Primary IDE controller (dual FIFO)
D800h-D80Fh
SiS 5513 dual PCI IDE controller
D808h-D80Fh
Secondary IDE controller (dual FIFO)
E400h-E47Fh
Motherboard resources
E480h-E4FFh
Motherboard resources
✍ I/O addresses that may be used by add-in cards are not listed.
81
82
VAIO® Reference Manual
Memory Map
Address range
Default configuration
00000000h-0009FFFFh
System board extension for ACPI BIOS
000A0000h-000AFFFFh
SiS 730s
000B0000h-000BFFFFh
SiS 730s
000C0000h-000CBFFFh
SiS 730s
000F0000h-000FFFFFh
System board extension for ACPI BIOS
00100000h-037FFFFFh
System board extension for ACPI BIOS
E8800000h-E8803FFFh
Texas Instruments OHCI-compliant IEEE 1394 host
controller
E9000000h-E90007FFh
Texas Instruments OHCI-compliant IEEE 1394 host
controller
E9800000h-E98000FFh
WDM communication device
EA000000h-EA0000FFh
Realtek RTL8139 (A/B/C/8130) PCI Fast Ethernet
NIC
EA800000h-EAFFFFFFh
SiS Accelerated Graphics Port
EA800000h-EA81FFFFh
SiS 730s
EB000000h-EB000FFFh
SiS 7018 audio driver
EB800000h-EB800FFFh
SiS 7001 PCI to USB open host controller
EC000000h-EFFFFFFFh
PCI standard host CPU bridge
F0000000h-FEBFFFFFh
SiS Accelerated Graphics Port
F0000000h-F7FFFFFFh
SiS 730s
FFEE0000h-FFEFFFFFh
Motherboard resources
FFFE0000h-FFFFFFFFh
Motherboard resources
Miscellaneous Technical Information
83
IRQ Settings
IRQ
Settings
00
System timer
01
Standard 101/102-Key or Microsoft Natural Keyboard
02
Programmable interrupt controller
03
Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet NIC
03
Texas Instruments OHCI-compliant IEEE 1394 host controller
03
ACPI IRQ holder for PCI IRQ steering
04
Communications port (COM1)
05
Printer Port (LPT 2)
06
Standard floppy disk controller
07
Printer Port (LPT1)
08
System CMOS/real time clock
09
SiS 7001 PCI to USB open host controller
09
WDM communication device
09
ACPI IRQ holder for PCI IRQ steering
09
SCI IRQ used by ACPI bus
10
ACPI IRQ holder for PCI IRQ steering
10
SiS 7018 audio driver
11
SiS 730s
11
ACPI IRQ holder for PCI IRQ steering
12
PS/2® compatible mouse port
13
Numeric data processor
14
Primary IDE controller (dual FIFO)
14
SiS 5513 dual PCI IDE controller
15
Secondary IDE controller (dual FIFO)
15
SiS 5513 dual PCI IDE controller
84
Chapter 9
Specifications
This chapter describes the technical specifications for the Sony
PCV-J150 computer.
Processor
800 MHz* AMD Duron™ processor
*
MHz denotes microprocessor internal clock speed. Other factors may affect application
performance.
Chipset
SiS730S
PCI Bus
PCI Level 2.2, 33 MHz zero wait state
4 PCI slots (2 open)
Memory Modules (DIMMs)
Installed memory
64 MB PC-133 SDRAM (133 MHz)
Maximum memory
512 Mbytes (256 Mbytes in each socket)
Voltage
3.3 V memory only
Pins
168-pins with gold-plated contacts
SDRAM type
PC-133, 60 ns, unrestricted CAS latency 2, unbuffered,
Intel 4-clock, 64 bits (non-ECC)
85
86
VAIO® Reference Manual
DIMM Configurations
DIMM1*
DIMM2*
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
*
The PCV-J150 is shipped with 64 MB. SDRAM is expandable to 512 MB. Computer SDRAM is
unbuffered DIMM, specification Rev. 1.0 or later. Supports SDRAM memory. Does not support
EDO memory or buffered DIMM memory. Memory can be installed in either socket. Memory size
can vary between sockets. DIMMs can be single- or double-sided. DIMMs must be 3.3V unbuffered
4-clock, 64-bit or 72-bit 133 MHz SDRAM module.
Cache Memory
Integrated
L1: 128Kbytes
L2: 64Kbytes (exclusive)
Graphics
Chipset
SiS730S
Video memory
Shared with system memory
Resolution (displayed resolution depends on the video monitor you use)*
True color (24 bits) Up to 1280 x 1024 at 85 Hz non-interlaced
High color (16 bits) Up to 1280 x 1024 at 85 Hz non-interlaced
256 colors (8 bits)
*
Up to 1600 x 1200 at 75 Hz non-interlaced
It is recommended to use 1024x768 True color (24 bits) or High color (16 bits) when at 75 Hz or
lower refresh rate for video playback applications.
Specifications
87
Audio
Sound chip
SiS7018
Wave synthesis
64-voice Polyphony wave table synthesizer
Audio sampling rate
Up to 48 kHz at 16 bits
Rear panel connectors
MIC (for microphone)
LINE IN (from stereo audio source)
HEADPHONES (for stereo headphones)
Communications
Modem
V.90-compatible data/fax modem*
Fax
14.4 kbps maximum
®
i.LINK (IEEE-1394)
400 Mbps, OHCI chipset
Ethernet
10Base-T/100Base-TX
*
Due to FCC limitations, the maximum permissible data speed is 53 kbps during download
transmissions. Actual data speeds may vary, depending on line conditions.
I/O and Expansion Slots
Serial ports
One high-speed NS16C550-compatible port
Parallel port
One high-speed bi-directional Centronicscompatible port with ECP and EPP modes
Modem ports
Two RJ-11 connectors (for line and phone)
USB ports
USB1, USB2, USB3 (on rear panel)
PCI slots
Two available slots. Maximum length for add-in
cards is 7.75 inches
IDE connectors
Primary and secondary (cable for primary supports
two ATA-100 IDE drives)
i.LINK (IEEE-1394) port
One 6-pin connector on rear panel
Ethernet
One RJ-45 connector on rear panel
88
VAIO® Reference Manual
Drives and Controllers
Drive
Description
Diskette drive
3.5-inch, 1.44 Mbyte.
CD-RW drive*
CD-RW read†
CD-RW write‡
CD-R read**
CD-R write††
CD-ROM read‡‡
20X maximum performance
4X maximum performance
32X maximum performance
8X maximum performance
32X maximum performance
*
†
The CD-RW/CD-R/CD-ROM data transfer standard 1X rate is 150 kbytes/s.
Data on a CD-RW is read at a variable transfer rate, ranging from 8X at the innermost track to 20X
at the outermost track. The average data transfer rate is 14X (2100 kbytes/s).
‡ Data on a CD-RW is written at a constant transfer rate of 1X, 2X, or 4X, depending on the speed
you select.
** Data on the CD-R is read at a variable transfer rate, ranging from 13X at the innermost track to 32X
at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The average data transfer
rate is 22.5X (3375 kbytes/s).
†† Data on a CD-R is written at a constant transfer rate of 1X, 2X, 4X, or 8X, depending on the speed
you select.
‡‡ Data on the CD-ROM is read at a variable transfer rate, ranging from 13X at the innermost track to
32X at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The average data
transfer rate is 22.5X (3375 kbytes/s).
System BIOS
Make and model
Award-based
ROM
2Mbit CMOS Flash memory
Passwords
User and supervisor passwords supported
Recovery boot block
Supported
Power management
APM 1.2
Advanced features
ACPI-1.0 compliant hardware for use with APM and
PNP BIOS APIs
Plug and Play devices
Supported with steerable DMA channels and
interrupts
Special features
PC-99 compliant, multi-boot, PCI add-in card autoconfigure
Index
A
add-in card
installing 26
removing 28
address map, system 80
audio specifications 87
AUX-IN connector 61
B
battery - See lithium battery
beep codes 77
BIOS Setup Utility 16
BIOS setup utility 16
advanced screen 71
boot screen 73
exit screen 74
main screen 69
options 67
power screen 72
screens 67
BIOS specifications 88
C
card, modem 63
cards
Ethernet 65, 87
CD-IN connector 60
CD-RW drive
location of 3
performance of discs 3, 88
specifications for 88
CMOS - See Also BIOS
CMOS Clear configuration jumper 62
codes, beeps 77
COM1 port - See SERIAL connector
communications, specifications 87
computer lithium battery vii
computer safety information ii
configuration jumper, CMOS Clear 62
configuring
BIOS setup utility 16
power management 17
system board 20
connectors
4-pin on modem card 63
AUX-IN 61
CD-IN 60
Ethernet 12, 65
fan 59
IDE 52
KEYBOARD 53
LINE 63
modem card 63
MONITOR 55
MOUSE 53
PCI 51
power 52
PRINTER 55
TELEPHONE 63
USB 54
cover, for slot 40
covering I/O slot 41
CPU - See processor
D
DIMM - See memory module
diskette drive
connector 49
specifications for 88
display, power management 17
89
90
VAIO® Reference Manual
disposal of lithium battery vii
DMA channel assignments 79
drives
IDE connectors 52
installing additional 3½" drive 42
specifications for 88
E
error messages
beep codes 77
PCI configuration 78
Ethernet card 65, 87
Ethernet connector 12, 65
expansion slots 13
specifications for 87
expansion slots - See Also slots
F
fan connectors 59
CPU-FAN 59
PWR-FAN 59
fax card - See modem card
fax/modem - See Also
communications
FCC Part 68 vi
front panel
removing 23
replacing 24
front panel header 48
front view 2
buttons and switches 4
connectors 5
drives 3
indicators 5
address map 80
slot covering 41
slot specifications 87
I/O connectors
HEADPHONES 11, 57
i.LINK 12, 55
KEYBOARD 9
LINE 11
LINE IN 11, 57
MIC 11, 57
MONITOR 10
MOUSE 9
PRINTER 10
SERIAL 9
TELEPHONE 11
USB 9, 54
icons, description of 7
IDE
connectors 52
specifications for 88
IDE drive
specifications for 88
installing
3½" hard disk drive 42
add-in card 26
system memory 36
interference v
IRQ settings 83
J
jumper - See system board
K
KEYBOARD connector 9, 53
G
L
graphics controller - See graphics
graphics specifications 86
L2 cache specifications 86
LINE connector 11
LINE IN connector 11, 57
lithium battery
disposal vii
replacing 30
safety precautions vii
H
header - See front panel header
HEADPHONES connector 11, 57
I
i.LINK connector 55
I/O
M
map - See Also I/O address map and
91
memory map
memory - See Also system memory
memory module
connector 50
removing 33
specifications for 85
messages
error 77
status and error 78
MIC connector 11, 57
microprocessor - See processor
model numbers ii
modem - See Also communications
modem card 63
connectors 63
view of 63
monitor - See Also display
MONITOR connector 10, 55
MOUSE connector 9, 53
N
notice to users ii
P
panel, front 23, 24
passwords, user and supervisor 76
PCI slot connectors 51
power connector 52
power management, configuring 17
PRINTER connector 10, 55
processor specifications 85
processor, specifications for 85
R
radio interference v
RAM - See Also system memory
rear view 6
I/O connectors 9
icons 7
recording ii
regulatory information v
removing
add-in card 28
front panel 23
memory module 33
side panel 22
slot cover 40
replacing 25
front panel 24
lithium battery 30
side panel 25
resolution - See graphics specifications
S
safety information ii
SERIAL connector 9, 57
serial numbers ii
serial port - See SERIAL
setup, BIOS 16
side panel 25
removing 22
slot - See Also I/O slot
slot cover, removing 40
specifications
audio 87
BIOS 88
communications 87
drives and controllers 88
graphics 86
I/O and expansion slots 87
L2 cache 86
memory module 85
processor 85
status and error messages 78
supervisor password 76
system board
AUX-IN connector 61
CD-IN connector 60
configuration jumper 62
configuring 20
diskette drive connector 49
fan connectors 59
front panel header 48
HEADPHONES connector 57
i.LINK connector 55
IDE connectors 52
KEYBOARD connector 53
LINE IN connector 57
memory module connector 50
MIC connector 57
MONITOR connector 55
MOUSE 53
92
VAIO® Reference Manual
PCI slot connectors 51
power connector 52
PRINTER connector 55
SERIAL connector 57
USB connectors 54
system I/O address map 80
system memory, installing 36
T
TELEPHONE connector 11
Telephone Consumer Protection Act of
1991 vi
TV interference v
U
USB connectors 9, 54
user password 76
