VAIO Slimtop System Reference Manual
NOTICE
© 2001 Sony Electronics Inc. Reproduction in
whole or in part without written permission is
prohibited. All rights reserved. This manual and the
software described herein, in whole or in part, may
not be reproduced, translated, or reduced to any
machine-readable form without prior written
approval.
SONY ELECTRONICS INC. PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN AND
HEREBY EXPRESSLY DISCLAIMS ANY
IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO
THIS MANUAL, THE SOFTWARE, OR SUCH
OTHER INFORMATION. IN NO EVENT SHALL
SONY ELECTRONICS INC. BE LIABLE FOR
ANY INCIDENTAL, CONSEQUENTIAL, OR
SPECIAL DAMAGES, WHETHER BASED ON
TORT, CONTRACT, OR OTHERWISE, ARISING
OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR THE
USE THEREOF.
Sony Electronics Inc. reserves the right to make any
modification to this manual or the information
contained herein at any time without notice. The
software described herein is governed by the terms
of a separate user license agreement.
This product contains software owned by Sony and
licensed by third parties. Use of such software is
subject to the terms and conditions of license
agreements enclosed with this product. Some of the
software may not be transported or used outside the
United States. Software specifications are subject to
change without notice and may not necessarily be
identical to current retail versions.
Updates and additions to software may require an
additional charge. Subscriptions to online service
providers may require a fee and credit card
information. Financial services may require prior
arrangements with participating financial
institutions.
Sony, VAIO, the VAIO logo, VAIO Smart, VAIO
Slimtop, Mavica, Handycam, SonyStyle Connect,
DVgate, Media Bar, MovieShaker, VisualFlow,
PictureGear, and i.LINK are trademarks or
registered trademarks of Sony.
Memory Stick and
Sony Corporation.
are trademarks of
Intel, Pentium, and Celeron are trademarks or
registered trademarks of the Intel Corporation.
Microsoft, Windows, Windows XP, Outlook, and
the Windows logo are trademarks or registered
trademarks of Microsoft Corporation.
PS/2 is a trademark or registered trademark of IBM
Corporation.
All other trademarks are trademarks or registered
trademarks of their respective owners.
Owner’s Record
The model number and serial number are located on
either the front or back panel of your Sony VAIO®
computer. Record the model and serial number in
the space provided here, and keep in a secure
location. Refer to the model and serial numbers
when you call your Sony Service Center.
Model Number:
Serial Number:
iii
Safety Information
! To change the backup battery,
CD-RW/DVD Combo Drive
Laser Diode Properties
Laser Output
(CD-RW)
1.14 mW max.
(Read)
35 mW max. (CDR/CD-RW Write)
❑
❑
❑
❑
❑
❑
❑
❑
Laser Output
(DVD-ROM)
0.4 mW max.
(Read)
Wave Length
(CD-RW)
780-790 nm
Wave Length
(DVD-ROM)
635-665 nm
please contact your nearest Sony
Service Center.
! Caution: The use of optical
instruments with this product will
increase eye hazard. As the laser
beam used in this product is
harmful to the eyes, do not
attempt to disassemble the drive
cabinet. Refer servicing to
qualified personnel only.
! Danger: Visible and invisible laser
To prevent fire or shock hazard, do not expose
your desktop to rain or moisture.To avoid
electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Never install modem or telephone wiring
during a lightning storm.
Never install telephone jacks in wet locations
unless the jack is specifically designed for
wet locations.
Never touch uninsulated telephone wire or
terminals unless the telephone line has been
disconnected at the network interface.
Use caution when installing or modifying
telephone lines.
Avoid using the modem during an electrical
storm.
Do not use the modem or a telephone to
report a gas leak in the vicinity of the leak.
The socket outlet shall be installed near the
equipment and shall be easily accessible.
radiation when open. Avoid direct
exposure to beam.
! For CD-RW/DVD combo drive:
Danger - Visible and invisible laser
radiation when open. Avoid direct
exposure to beam
! Caution: For ADSL and V.90 modem
models, to reduce the risk of fire,
use only No. 26 AWG or larger
telcommunication line cord.
iv
❑
❑
❑
❑
❑
❑
❑
❑
❑
VAIO Slimtop System Reference Manual
Pour prévenir tout risque d’incendie ou
d’électrocution, garder cet appareil à l’abri de
la pluie et de l’humidité.
Pour prévenir tout risque d’électrocution, ne
pas ouvrir le châssis de cet appareil et ne
confier son entretien qu’à une personne
qualifiée.
Ne jamais effectuer l’installation de fil
modem ou téléphone durant un orage
électrique.
Ne jamais effectuer l’installation d’une prise
téléphonique dans un endroit mouillé à moins
que la prise soit conçue à cet effet.
Ne jamais toucher un fil téléphonique à
découvert ou un terminal à moins que la ligne
téléphonique n’ait été débranché de
l’interface réseau.
Soyez très prudent lorsque vous installez ou
modifiez les lignes téléphoniques.
Évitez d’utiliser le modem durant un orage
électrique.
N'utilisez pas le modem ni le téléphone pour
prévenir d'une fuite de gaz vous êtes près de
la fuite.
L’appareil doit être le plus près possible
d’une prise murale pour en faciliter l’accès.
! Pour changer la pile de rechange,
veuillez contacter votre centre de
service Sony le plus près.
! Avertissement : L'utilisation
d'instruments optiques avec ce
produit augmente les risques pour
les yeux. Puisque le faisceau laser
utilisé dans ce produit est
dommageable pour les yeux, ne
tentez pas de désassembler le
boîtier. Adressez-vous à un agent
de service qualifié.
! Danger : Radiation laser visible et
invisible si ouvert. Évitez
l’exposition directe au faisceau.
! Pour le lecteur Combo CD-RW/
DVD : Danger - Radiation laser
visible et invisible si ouvert. Évitez
l'exposition directe au faisceau.
! Attention : Pour ADSL et V.90
modele modem, afin de réduire les
risques d’indendie, n’utilisez qu’un
cordon de communication NO. 26
AWG ou plus gros.
For questions regarding your product or for the
Sony Service Center nearest you, call
1-888-476-6972 in the United States or
1-800-961-7669 in Canada.
Sony Customer Support can be reached at
http://www.sony.com/pcsupport.
v
Regulatory Information
Declaration of Conformity
Trade Name:
SONY
Model No.:
PCV-LX920
Responsible
Party:
Sony Electronics Inc.
Address:
680 Kinderkamack Rd
Oradell, NJ 07649
Telephone:
201-930-6972
This phone number is for FCC-related matters
only.
This device complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
❑
❑
❑
❑
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and the receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/
TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Only peripherals (computer input/output devices,
terminals, printers, etc.) that comply with FCC
Class B limits may be attached to this computer
product. Operation with noncompliant peripherals
is likely to result in interference to radio and
television reception.
All cables used to connect peripherals must be
shielded and grounded. Operation with cables,
connected to peripherals, that are not shielded and
grounded, may result in interference to radio and
television reception.
For the Pen Tablet (TA-15A)
Trade Name:
SONY
Model No.:
Tablet, model TA-15A
This device complies with Part 15 of the FCC
rules and RSS-210 of the IC standards.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Pour le Tablet de Stylo (TA-15A)
Trade Name :
SONY
Model No. :
TABLET, modèle TA15A
Ce dispositif est conforme à la section 15 des
réglementations FCC ainsi qu'au RSS-210 des
normes IC.
Son fonctionnement est sujet aux deux
conditions suivantes :
(1) Le dispositif ne peut être à l'origine
d'interférences nocives, et
(2) ce dispositif doit accepter toute réception
d'interférences, y compris les interférences qui
peuvent entraîner un fonctionnement
indésirable.
vi
VAIO Slimtop System Reference Manual
FCC Part 68
This equipment complies with Part 68 of the FCC
rules. The FCC Ringer Equivalence Number (REN)
for this equipment is 0.79B. If requested, this
information must be provided to the telephone
company.
This modem uses the USOC RJ-11 telephone jack.
The REN is used to determine the quantity of
devices which may be connected to the telephone
line. Excessive RENs on the telephone line may
result in the devices not ringing in response to an
incoming call. In most, but not all areas, the sum of
the RENs should not exceed five (5.0). To be certain
of the number of devices that may be connected to
the line, as determined by the total RENs, contact
the telephone company to determine the maximum
REN for the calling area.
If the terminal equipment causes harm to the
telephone network, the telephone company will
notify you in advance that temporary
discontinuance of service may be required. But if
advance notice is not practical, the telephone
company will notify the customer as soon as
possible. Also, you will be advised of your right to
file a complaint with the FCC if you believe it is
necessary.
The telephone company may make changes in its
facilities, equipment, operations or procedures that
could affect the operations of the equipment. If this
happens, the telephone company will provide
advance notice in order for you to make the
necessary modifications in order to maintain
uninterrupted service.
If trouble is experienced with this modem, for
repair or warranty information, please contact 1888-4-SONY-PC (1-888-476-6972), or write to the
Sony Customer Information Center, 12451
Gateway Blvd., Fort Myers, FL 33913. If the
trouble is causing harm to the telephone network,
the telephone company may request that you
remove the equipment from the network until the
problem is resolved.
Repair of this equipment should be made only by a
Sony Service Center or Sony authorized agent. For
the Sony Service Center nearest you, call 1-888-4SONY-PC (1-888-476-6972).
This equipment cannot be used on public coin
service provided by the telephone company.
Connection to Party Line Service is subject to state
and possible provincial tariffs. (Contact the state or
provincial utility service commission, public
service commission, or corporation commission for
information.)
Telephone Consumer
Protection Act of 1991
(United States)
The Telephone Consumer Protection Act of 1991
makes it unlawful for any person to use a computer
or other electronic device to send any message via a
telephone facsimile machine unless such message
clearly contains, in a margin at the top or bottom of
each transmitted page or on the first page of the
transmission, the date and time it is sent and an
identification of the business, other entity, or
individual sending the message, and the telephone
number of the sending machine or such business,
other entity, or individual.
In order to program this information into your
facsimile machine, see your fax software
documentation.
Telephone Consumer
Guidelines (Canada)
Please refer to your telephone directory under
‘Privacy Issues’ and/or ‘Terms of Service.’ For
more detailed information, please contact:
CRTC Terrasses de la Chaudiére, Tour centrale
1 promenade du Portage, 5 étage Hull PQ K1A
0N2.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet àppareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
vii
Disposal of Lithium Battery
You can return your unwanted lithium batteries to
your nearest Sony Service Center or Factory
Service Center.
✍ In some areas the disposal of lithium
batteries in household or business trash
may be prohibited.
! Une batterie non conforme
présente un danger d'explosion. La
remplacer seulement par une
batterie identique ou de type
équivalent recommandé par le
fabricant. Évacuer les batteries
usées selon les directives du
fabricant.
For the Sony Service Center nearest you, call
1-888-476-6972 in the United States or
1-800-961-7669 in Canada.
! La manutention incorrecte du
! Do not handle damaged or leaking
lithium batteries.
! Danger of explosion if battery is
incorrectly replaced. Replace only
with the same or equivalent type
recommended by the
manufacturer. Discard used
batteries according to the
manufacturer’s instructions.
! The battery pack used in this
device may present a fire or
chemical burn hazard if mistreated.
Do not disassemble, heat above
212°F (100°C) or incinerate.
Dispose of used battery promptly.
Keep away from children.
! Ne pas manipuler les batteries au
lithium qui fuient ou sont
endommagées.
module de batterie de cet appareil
présente un risque d'incendie ou
de brûlures chimiques. Ne pas
démonter, incinérer ou exposer à
une température de plus de 100°C.
Évacuer promptement la batterie
usée. Garder hors de portée des
enfants.
viii
VAIO Slimtop System Reference Manual
Industry Canada Notice
Avis de l’Industrie Canada
NOTICE: The Industry Canada label identifies
certified equipment. This certification means that
the equipment meets certain telecommunications
network protective, operational and safety
requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements
document(s). The Department does not guarantee
the equipment will operate to the user’s satisfaction.
AVIS : L’étiquette d’Industrie Canada identifie le
matériel homologué.
Before installing this equipment, users should
ensure that it is permissible to be connected to the
facilities of the local telecommunications company.
The equipment must also be installed using an
acceptable method of connection.
The customer should be aware that compliance with
the above conditions may not prevent degradation
of service in some situations.
Repairs to certified equipment should be
coordinated by a representative designated by the
supplier. Equipment malfunctions or any repairs or
alterations made by the user to this equipment may
give the telecommunications company cause to
request that the user disconnect the equipment.
Users should ensure for their own protection that
the electrical ground connections of the power
utility, telephone lines and internal metallic water
pipe system, if present, are connected together. This
precaution may be particularly important in rural
areas.
CAUTION: Users should not attempt to make such
connections themselves, but should contact the
appropriate electrical inspection authority, or
electrician, as appropriate.
NOTICE: The Ringer Equivalence Number (REN)
assigned to each terminal device provides an
indication of the maximum number of terminals
allowed to be connected to a telephone interface.
The termination on an interface may consist of any
combination of devices subject only to the
requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5. The
Ringer Equivalence Number for this equipment is
0.79B.
Cette étiquette certifie que le matériel est conforme
aux normes de protection, d’exploitation et de
sécurité des réseaux de télécommunications,
comme le prescrivent les documents concernant les
exigences techniques relatives au matériel terminal.
Le Ministère n’assure toutefois pas que le matériel
fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit
s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de
télécommunication. Le matériel doit également être
installé en suivant une méthode acceptée de
raccordement. L’abonné ne doit pas oublier qu’il est
possible que la conformité aux conditions énoncées
ci-dessus n’empêche pas la dégradation du service
dans certaines situations.
Les réparations de matériel homologué doivent être
coordonnées par un représentant désigné par le
fournisseur. L’entreprise de télécommunications
peut demander à l’utilisateur de débrancher un
appareil à la suite de réparations ou de
modifications effectuées par l’utilisateur ou à cause
de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer
que tous les fils de mise à la terre de la source
d’énergie électrique, des lignes téléphoniques et des
canalisations d’eau métalliques, s’il y en a, sont
raccordés ensemble. Cette précaution est
particulièrement importante dans les régions
rurales.
Avertissement : L’utilisateur ne doit pas tenter de
faire ces raccordements lui-même; il doit avoir
recours à un service d’inspection des installations
électriques, ou à un électricien, selon le cas.
AVIS : L’indice d’équivalence de la sonnerie (IES)
assigné à chaque dispositif terminal indique le
nombre maximal de terminaux qui peuvent être
raccordés à une interface.
La terminaison d’une interface téléphonique peut
consister en une combination de quelques
dispositifs, à la seule condition que la somme
d’indices d’équivalence de la sonnerie de tous les
dispositifs n’excède pas 5. L’indice d’équivalence
de la sonnerie de ce matériel est de 0.79B.
Contents
NOTICE ....................................................................................................... ii
Owner’s Record................................................................................... ii
Safety Information ............................................................................. iii
Regulatory Information.......................................................................v
FCC Part 68 ......................................................................................... vi
Telephone Consumer Protection Act of 1991 (United States) ..... vi
Telephone Consumer Guidelines (Canada)................................... vi
Disposal of Lithium Battery ............................................................ vii
Industry Canada Notice.................................................................. viii
Avis de l’Industrie Canada............................................................. viii
Chapter 1 — Identifying Components................................ 1
Front View....................................................................................................2
Drive ......................................................................................................3
Buttons and Switches ..........................................................................4
Indicators...............................................................................................5
Connectors ............................................................................................6
Slots ........................................................................................................7
Rear View .....................................................................................................8
I/O Connectors ..................................................................................10
Chapter 2 — Configuring Your System ............................ 15
Accessing the CMOS Setup Utility .........................................................16
Changing the Display's Power Management Settings.........................17
Configuring the System Board ..............................................................21
ix
x
VAIO Slimtop System Reference Manual
Chapter 3 — Removing, Installing, and Replacing
Components ....................................................................... 23
Removing the System Cover ..................................................................24
Replacing the System Cover ...................................................................25
Removing an Add-in Card .....................................................................26
Installing an Add-In Card .......................................................................28
Setting the Configuration Switches .......................................................29
Replacing the Lithium Battery ...............................................................30
Removing the Power Supply...................................................................33
Replacing the Power Supply ...................................................................34
Removing a Memory Module ................................................................35
Installing System Memory ......................................................................37
Replacing the Hard Drive ......................................................................40
To identify additional hard disk space ...........................................43
Removing a Slot Cover.............................................................................44
Covering an Open I/O Slot ....................................................................45
Chapter 4 — System Board ............................................... 47
Memory Module (DIMM) Slots ............................................................48
Power (ATX PWR) Header .....................................................................49
CLR CMOS Jumper...................................................................................50
Chapter 5 — CMOS Setup Options ................................... 51
Main Screen ...............................................................................................53
Advanced Screen ......................................................................................56
Power Screen..............................................................................................61
Boot Screen ................................................................................................63
Exit Screen ..................................................................................................64
Chapter 6 — Miscellaneous Technical Information ......... 65
User and Supervisor Passwords ............................................................66
Beep Code Error Messages .....................................................................67
PCI Configuration Status and Error Messages ....................................68
DMA Channel Assignments ...................................................................69
IRQ Assignments ....................................................................................70
System I/O Address Map .......................................................................71
Memory Map .............................................................................................74
xi
Chapter 7 — Specifications................................................ 75
Processor ...................................................................................................75
Chipset ......................................................................................................75
PCI Bus ......................................................................................................75
Memory Modules (DIMMs) ..................................................................75
Memory Configurations ..........................................................................76
L2 Cache ....................................................................................................76
Graphics ....................................................................................................76
Audio .........................................................................................................77
Communications .....................................................................................77
I/O and Expansion Slots ........................................................................77
i.LINK Interface ........................................................................................78
Ethernet Interface .....................................................................................78
Drives and Controllers ............................................................................78
System CMOS ..........................................................................................78
Index .................................................................................. 79
xii
VAIO Slimtop System Reference Manual
Chapter 1
Identifying Components
The following sections identify and describe each component that is
visible from the exterior of the VAIO® Computer. Internal components
are identified in the appropriate section of this manual.
1
2
VAIO Slimtop System Reference Manual
Front View
Front panel
Identifying Components
Drive
CD-RW/DVD combo drive
Drive
Description
CD-RW/DVD combo drive
See Specifications sheet for details.*
* The Specifications sheet is supplied with your computer's original documentation.
3
4
VAIO Slimtop System Reference Manual
Buttons and Switches
CD-RW/DVD combo drive disc eject
PC card eject
Power on/off
Button or switch
Description
CD-RW/DVD combo
drive disc eject button
Automatically opens the CD-RW/DVD combo
drive tray.
PC card eject button
Ejects a PC card.
Power on/off switch
Turns system power on and off.
The Power on/off switch lights in amber when
the system is in Stand by mode.
Identifying Components
5
Indicators
Sony Memory Stick media access indicator
Hard disk drive access indicator
CD-RW/DVD combo drive access indicator
Power on/Stand by indicator
Indicator
Description
Sony Memory Stick® media
access indicator
On (amber) indicates Memory Stick media
activity.
Hard disk drive access
indicator
On (amber) indicates hard disk drive
activity.
CD-RW/DVD combo drive
access indicator
On (amber) indicates optical disc activity.
Power on/Stand by indicator
Stand by (amber) indicates the computer is
in Stand by mode. On (green) indicates the
computer is out of Stand by mode, ready to
use. Off (no color) indicates the computer is
turned off.
6
VAIO Slimtop System Reference Manual
Connectors
USB1 port
i.LINK port
Connector
Description
USB1 port
Connects to USB devices.
i.LINK® port
(IEEE1394)*
Connects to digital devices that have a 4-pin
i.LINK connector.
* To connect to a 6-pin i.LINK device, use the i.LINK connector on the back of the system. A 6-pin
i.LINK connector can supply power from the computer to the device if the device also has a 6-pin
i.LINK connector. A 4-pin i.LINK connector cannot supply power to the device.
Identifying Components
Slots
PC card slot
Memory Stick media slot
Slot
Description
PC card slot
Accommodates one Type I or Type II PCMCIA
card.
Memory Stick® media slot
Accommodates Memory Stick media.
7
8
VAIO Slimtop System Reference Manual
Rear View
Power
Monitor
USB2
USB3
Ethernet
Phones
Line In
Mic
Line
i.LINK port
Phone
LCD
USB4
Connector
Description
Monitor
Connects to VGA monitor (optional).
USB2, USB3
Connects to USB devices.
Phones
Connects to headphones.
Line In
Connects to output connector on audio device.
Mic
Connects to microphone connector on audio
device.
i.LINK® port
(IEEE1394)*
Connects to digital device that has a 4-pin or
6-pin i.LINK connector.
Identifying Components
Connector
Description
LCD
Connects to Sony Pen Tablet or Sony LCD
display.
Note: Do not connect any other display to this
port.
Power
AC input power.
Ethernet
Connects to RJ-45 Ethernet connector.
Line
Connects to phone cable from wall jack.
Phone
Connects to telephone.
USB4
Connects to USB devices.
* To connect to a 6-pin i.LINK device, use the i.LINK connector on the back of the system. A 6-pin
i.LINK connector can supply power from the computer to the device if the device also has a 6-pin
i.LINK connector. A 4-pin i.LINK connector cannot supply power to the device.
9
10
VAIO Slimtop System Reference Manual
I/O Connectors
The following section identifies the various I/O connectors.
Monitor Connector
The monitor connector is a standard 15-pin female high-density
VGA-type connector and is located on the rear panel.
USB Connectors
A total of five USB connectors are available.
The first USB connector (USB1) is located on the front panel between the
i.LINK® connector and the Sony Memory Stick® media slot.
The second, third, and fourth USB connectors (USB2, USB3, and USB4)
are accessible from the rear panel. USB2 and USB3 are located next to the
Ethernet connector, and USB4 is located on the Fax/Modem plug-in card.
The fifth USB connector (USB5) is located on the Sony Pen Tablet or LCD
display on the right side of the base next to the Mouse port.
Identifying Components
11
Phone, Line In, and Mic Connectors
The phone (headphones), line in, and microphone jacks are physically
identical, but have different connections. They are standard 3.5 mm stereo
mini-jacks and are located on the rear panel.
Phone
Line In
Mic
Connector
Description
Phone
1.0 Vrms output (typical) at 31 mW (32 ohm) output (max).
Line In
2.0 Vrms input (max), 50 Kohm impedance.
Mic
Electret condenser microphone input.
12
VAIO Slimtop System Reference Manual
i.LINK (IEEE1394) Ports
The 6-pin i.LINK® port on the back of the system can supply power from
the computer to a device if the device also has a 6-pin i.LINK port. The
6-pin port supplies 10 V to 12 V and a maximum power of 6 watts.
✍ i.LINK is a trademark of Sony used only to designate that a product contains an IEEE1394
connection. The i.LINK connection may vary, depending on the software applications,
operating system and compatible i.LINK devices. All products with an i.LINK connection may
not communicate with each other.
✍ Refer to the documentation that came with your compatible i.LINK device for information on
operating conditions and proper connections. Before connecting compatible i.LINK PC
peripherals to your system, such as an optical disc drive or a hard disk drive, confirm their
operating system compatibility and required operating conditions.
The 4-pin i.LINK port at the bottom of the front panel does not supply
power.
6-pin i.LINK port
(IEEE1394)
4-pin i.LINK port
(IEEE1394)
On front panel
On rear panel
Identifying Components
13
Ethernet Connector
The Ethernet connector on the rear panel connects to a 10BASE-T/100BASE-TX
Fast Ethernet network via an RJ-45 connector.
Ethernet
LCD Connector
The LCD connector is a 32-pin female MDR-type connector and is located
on the rear panel.
!
This connector is only for the Sony Pen Tablet or the Sony LCD display. Do not
connect any other display to this port.
14
VAIO Slimtop System Reference Manual
Line and Telephone Connectors
The line and phone jacks are physically identical and have identical
connections. They are standard RJ-11 female phone jacks. However, the
line jack is for connecting to a telephone line that comes from the wall
jack, and the phone jack is for connecting the computer to a telephone.
These jacks are located on the Modem plug-in card.
These connectors are located on the Modem plug-in card and are
accessible from the rear panel.
Line
Phone
✍ Plugging a phone line from the wall into the modem’s phone jack, and a telephone into
the line jack, does not damage the modem card or telephone equipment. However, the
modem does not work correctly.
Chapter 2
Configuring Your System
This chapter contains information on configuring your system.
Configuring your system can consist of the following:
❑
Making changes to the CMOS settings.
❑
Making changes to the display's power management settings.
❑
Changing the system board jumper position.
15
16
VAIO Slimtop System Reference Manual
Accessing the CMOS Setup Utility
You must access the CMOS Setup Utility to make changes to the CMOS
settings (see “CMOS Setup Options” on page 51 for information on
CMOS settings).
!
Save and close all open files; exit all applications before rebooting the
system.
1
2
3
Reboot the system.
4
5
Press Enter to display a submenu of options for an item.
6
7
8
Press Enter to apply the new setting or Esc to cancel the submenu.
Press F2 when the Sony screen appears.
Use the left and right arrow keys to select an item from the main
menu. Use the up and down arrow keys to select an item within the
screen.
Use the up and down arrow keys to select an option within a
submenu.
Press ESC to return to the main menu.
Select F10 when done, then follow the prompts, or choose an option
from the Exit menu.
Configuring Your System
17
Changing the Display's Power Management
Settings
A display that has power management capability is designed to operate
on reduced power or shut itself off after the system has been idle for a
specified period of time.
1
From the Start menu, point to Settings, Control Panel, then click
Power Options.
The Power Options Properties dialog box opens, with the Power
Schemes tab displayed.
2
Select the power scheme that is most appropriate for the way you use
your computer.
To change a power scheme, change the settings for Turn off monitor,
Turn off hard disks, System standby, and System hibernates.
The Turn off monitor option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your monitor
turns off when your computer is running on AC power. The display
reactivates when you move the mouse or press a key.
18
VAIO Slimtop System Reference Manual
The Turn off hard disks option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your hard disks
turn off when your computer is running on AC power.
The System standby option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your computer
goes on Stand by when your computer is running on AC power.
Power is reactivated when you click the left mouse button or press
the spacebar on the keyboard.
The System hibernates option allows you to specify the period of
inactivity (in minutes) before your computer goes into the Hibernate
mode. Power is reactivated when you push the power button.
3
To save a new power scheme, first modify the settings, click Save As,
type a descriptive name, and then click OK.
4
Click the Advanced tab.
5
Select the desired settings.
Configuring Your System
6
Click the Hibernate tab.
7
8
Select the settings most appropriate for your system.
Click the UPS tab.
19
20
VAIO Slimtop System Reference Manual
The UPS tab enables you to select and configure an Uninterruptible
Power Supply (UPS) device for your system.
9
Select and configure the settings most appropriate for your system
and click OK. For more information about configuring a UPS device,
refer to your Microsoft® Windows® XP operating system online
Help.
Configuring Your System
21
Configuring the System Board
✍ The configuration should never need changing unless otherwise directed by a technical
support or service technician.
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
There are two configuration switches on the system board:
❑
CMOS Clear switch
❑
Onboard VGA Interrupt (AGP_INT) switch
When the CMOS Clear switch is in the Normal position, it provides
normal access to the BIOS Setup Utility.
The Central Processing Unit (CPU) input clock is forced to remain at 100
MHz (fast mode), and the Basic Input/Output System (BIOS) uses the
User CMOS settings (as opposed to the System CMOS settings).
The CMOS and NVRAM settings are only cleared if the checksum test
returns false. Access to specific setup fields is controlled by a supervisor
password or user password.
When the CMOS Clear switch is in the Clear position, the password that
is stored in CMOS is cleared. No other parameters are cleared. While the
CMOS switch is in the Clear position, the system does not boot up at all.
To clear your password, after setting the switch to the Clear position, wait
2-3 seconds, and then set the switch to the Normal position.
If you install a VGA PCI add-in card, use the AGP_INT switch to enable
or disable the onboard VGA controller.
22
VAIO Slimtop System Reference Manual
To enable or disable the CMOS Clear or onboard VGA Interrupt, perform
the following steps:
!
Do not change any configuration switch unless directed by an authorized Sony
technician.
1
Remove the system cover (see “Removing the System Cover” on
page 24).
2
Set the switches according to the table shown in the diagram (see also
“CLR CMOS Jumper” on page 50).
O12
N
1
O
N
Switch #
2
Configuration switches (SWI)
Name
On
Off
1
CMOS
Clear
password
Normal
2
AGP_INT
Enable
Disable
Chapter 3
Removing, Installing, and
Replacing Components
This chapter describes removing, installing, and replacing major
components for upgrading, reconfiguring, and troubleshooting the
components.
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
23
24
VAIO Slimtop System Reference Manual
Removing the System Cover
You must remove the system cover to access the system board, add-in
cards, power supply, battery, and internal drives.
1
Remove the screw that secures the panel to the chassis (see item 1 in
diagram), and set it aside for future use.
2
From the rear of the unit, hold down the system cover while you pull
on the handle located at the rear panel (see item 2 in diagram).
3
Slide the system chassis out.
1
2
Removing, Installing, and Replacing Components
25
Replacing the System Cover
1
Insert the front of the chassis into the opening at the rear of the
system cover, then slide the chassis in until it is flush with the front
and rear (see item 1 in diagram).
2
Replace the screw that secures the cover to the chassis (see item 2 in
diagram).
2
1
26
VAIO Slimtop System Reference Manual
Removing an Add-in Card
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut down
the computer, and unplug the power cord.
1
Remove the system cover (see “Removing the System Cover” on
page 24).
2
3
Disconnect any cables attached to the add-in card.
4
Remove the add-in card from the PCI slot connector, and store the
card in an anti-static wrapper for future use.
Remove the screw that secures the add-in card to the chassis, and set
it aside for future use.
✍ Grasp the card with one hand on each end, and gently pull up as you rock the card
from side to side.
Removing, Installing, and Replacing Components
!
27
Hold the add-in card by its edges and do not touch any components or
connector contacts on the card. Static electricity in your body may
damage sensitive components on the card. As a precaution, touch any
exposed metal part on the metal chassis (preferably the metal part on
the power supply) before handling an add-in card to discharge any static
electricity in your body.
5
If you do not replace the card or install another add-in card, install a
slot cover over the vacant slot at the rear of the chassis (see “Covering
an Open I/O Slot” on page 45).
6
Replace the system cover (see “Replacing the System Cover” on
page 25).
28
VAIO Slimtop System Reference Manual
Installing an Add-In Card
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
Remove the system cover (see “Removing the System Cover” on
page 24).
2
Remove the slot cover adjacent to the selected slot connector on the
system board (see “Removing a Slot Cover” on page 44).
3
Insert the add-in card into the PCI slot connector. Use a gentle
rocking motion, pushing in until the card is fully seated.
✍ Align the card's bracket so that the bottom of the bracket fits into the slot at the
bottom of the chassis. Check that the top of the bracket fits snugly against the
chassis lip after the card is fully inserted.
4
Attach any necessary cables to the card (see the instructions that came
with the add-in card).
5
Replace the system cover (see “Replacing the System Cover” on
page 25).
6
Turn on the computer and follow any instructions that came with the
add-in card.
Removing, Installing, and Replacing Components
29
Setting the Configuration Switches
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut down
the computer, and unplug the power cord.
1
2
Remove any add-in cards.
3
Replace any add-in cards removed in step 1 (see “Installing an AddIn Card” on page 28).
Set the switches as needed (see “Configuring the System Board” on
page 21).
30
VAIO Slimtop System Reference Manual
Replacing the Lithium Battery
You may need to replace the lithium battery if your computer consistently
loses the date or time settings after turning it off. The lithium battery has
a typical life of three years, after which the battery may be too weak to
power the CMOS memory.
!
Sony recommends that you use an authorized service dealer to replace the
lithium battery. However, if you wish to replace the battery yourself, read
the following cautions and procedure.
When you remove the lithium battery, all values stored in the CMOS memory
(BIOS setup values and Plug and Play values) may be lost. Although the
computer can hold the charge for a short time while replacing the battery, it
is safer to assume that the settings will be lost. When the values are lost, the
BIOS values revert to their factory-default settings (see “Accessing the
CMOS Setup Utility” on page 16).
Do not handle damaged or leaking batteries.
The lithium battery may explode if mistreated. Do not disassemble it or
dispose of it in fire.
1
Reboot your computer by selecting Shut Down... from the Start
menu, and then selecting Restart the computer.
2
If the error message “Error: Check date and time settings” appears
during the reboot sequence, press F3, then press F2 during the reboot
process to access the BIOS Setup Utility. If the error message does not
appear, you do not need to replace the battery at this time, and you
can skip all remaining steps.
3
Compare all the BIOS options to their default settings. See “CMOS
Setup Options” on page 51 to locate the BIOS default settings. Make a
list of all the BIOS options that are different from their default values.
Refer to this list when you restore the BIOS settings later.
4
Press ESC, then select Exit from the main menu using the right arrow
key. Exit Discarding Changes, the first item in the list, is
automatically selected.
5
Press Enter, type N when prompted to save, then press Enter to exit
the BIOS Setup Utility.
6
7
Turn off the computer, and unplug the power cord.
Remove the system cover (see “Removing the System Cover” on
page 24).
Removing, Installing, and Replacing Components
31
8
Remove the power supply (see 1 in diagram and “Removing the
Power Supply” on page 33).
9
Use a screwdriver or similar tool to push the tab against the battery
holder (see 2 in diagram). One side of the battery pops up.
3
1
2
10
Remove the battery (see 3 in diagram) and dispose according to the
instructions that came with the new battery.
11
Insert the new battery into the battery holder, with the plus (+) side
up, and press down until the battery snaps into position.
✍ The Sony CR2032 battery is recommended. Using a type of battery other than a
CR2032 may present a risk of fire or explosion.
12
Replace the power supply (see “Replacing the Power Supply” on
page 34).
32
VAIO Slimtop System Reference Manual
13
Replace the system cover (see “Replacing the System Cover” on
page 25).
14
15
Reconnect the power cord, and turn on the computer.
16
Refer to the list you made in step 3, and restore any non-default
CMOS settings. See “CMOS Setup Options” on page 51 to locate the
BIOS default settings.
17
Press F10, then follow the on-screen prompt to save and exit.
If the error message “Error: Check date and time settings.” appears
during the reboot sequence, press DEL to access the CMOS Setup
Utility. If no error message displays, the computer’s CMOS settings
were retained during the battery replacement and you can skip the
remaining steps.
The computer’s CMOS settings are now restored.
Removing, Installing, and Replacing Components
33
Removing the Power Supply
You must remove the power supply to replace the CMOS battery.
!
1
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Remove the screw that secures the power supply to the chassis (see 1
in diagram), and set it aside for future use.
1
2
2
Press down on the plastic lever at the bottom of the power supply
(see 2 in diagram) to release the power supply.
34
3
VAIO Slimtop System Reference Manual
Lift the power supply up and out, and rest it upside down on top of
the PCI card holder.
Replacing the Power Supply
1
Lower the power supply down into position, and press down until
the power supply latches to the chassis.
2
Replace the screw that secures the power supply to the chassis.
Removing, Installing, and Replacing Components
35
Removing a Memory Module
You may need to remove a memory module if you change the memory
configuration or replace a bad module.
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
Remove the system cover (see “Removing the System Cover” on
page 24).
2
Locate the memory module you wish to remove.
DIMM 1
DIMM 2
(empty)
✍ If the memory module you wish to remove is DIMM #2, skip steps 3 to 5. Otherwise,
continue with the next step.
3
Push out the latches on each side of the memory module to eject the
module from its socket.
36
4
VAIO Slimtop System Reference Manual
Lift the memory module out by grasping it by its edges. Store the
module in a static-free bag.
!
5
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling the memory module.
Replace the system cover (see “Replacing the System Cover” on
page 25).
Removing, Installing, and Replacing Components
37
Installing System Memory
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
If necessary, remove the memory module you wish to replace (see
“Removing a Memory Module” on page 35).
2
Remove the new memory module from its anti-static package. Hold
the memory module only by its edges to prevent static-electricity
damage.
!
3
Touch any exposed metal part of the chassis to discharge static electricity in
your body before handling a memory module.
Choose the size and configuration of the memory module as shown
in the following table. Memory modules can vary in size and speed
between sockets. The minimum memory size is 8 MB; the maximum
memory size is 512 MB. The BIOS automatically detects the type, size,
and speed of the memory modules.
Memory module configurations (MB)
DIMM1
DIMM2
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
✍ Use only 3.3 V 64-bit, PC-133 MHz SDRAM DIMM modules.
38
4
VAIO Slimtop System Reference Manual
Align the module over the appropriate socket; note the location of pin
1 on the module and pin 1 on the socket.
Memory module (DIMM)
1
Indicates pin 1
5
6
Carefully but firmly insert the edge of the module into the socket.
Press down firmly and evenly at both corners until the module is
fully seated.
✍ When the module is fully seated, the latches on each side are straight up and
locked into the slot on each side of the module. If the latches are not completely
straight upright, continue to press down on each side of the module until the
latches lock into place.
Removing, Installing, and Replacing Components
7
Replace the system cover (see “Replacing the System Cover” on
page 25).
Your computer automatically recognizes the extra memory and
configures itself accordingly when you turn it on. No further action is
required.
39
40
VAIO Slimtop System Reference Manual
Replacing the Hard Drive
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
✍ Your system supports ATA-33, ATA-66, and ATA-100 hard disk drives.
1
Back up any files on your hard drive that you want to preserve before
you replace the drive.
2
Remove the system cover (see “Removing the System Cover” on
page 24).
3
While pulling out on the tab (see 1 in diagram), push the hard drive
towards the left inside the blue plastic drive carrier to release the
drive.
2
1
4
Lift up on the left side of the drive, and gently wiggle the drive up
and out.
Removing, Installing, and Replacing Components
5
41
Unplug the ribbon cable and power supply cable (see 1 in diagram)
from the hard drive.
1
2
2
6
7
Remove the four pins (see 2 in diagram) from the hard drive.
8
Set the jumpers on the new hard drive to be the Primary Master IDE
drive (refer to the instructions that came with your new hard drive).
9
Rest the hard drive upside down on a flat surface, with the
connectors facing left.
10
Reconnect the ribbon cable and power supply cable to the new hard
drive.
Insert the four pins in the new hard drive in the same position they
were in the old hard drive.
42
VAIO Slimtop System Reference Manual
11
Align all four pins on the hard drive with the four slots in the drive
carrier, and gently press down until the drive is firmly into position.
12
Replace the system cover (see “Replacing the System Cover” on
page 25).
Removing, Installing, and Replacing Components
43
To identify additional hard disk space
When you initialize the new hard disk drive, it must be configured as an
extended partition in Windows NT file system (NTFS) format.
1
2
Log on in Windows® as Administrator.
3
4
Select Manage. The Computer Management window appears.
5
Right-click on the newly installed, unformatted drive (Disk label
identified with red marking), and from the shortcut menu, select
Initialize Disk.
6
Click on the Unallocated area of the drive and then right-click to
display the shortcut menu.
7
8
Select New Partition. The New Partition wizard appears.
Click Start in the Windows taskbar and right-click on My Computer.
A shortcut menu appears.
From the file directory on the right, go to Storage and then select Disk
Management.
Follow the onscreen instructions to complete the process.
The Windows® XP operating system recognizes the new hard disk drive
and applies the NTFS file system format.
44
VAIO Slimtop System Reference Manual
Removing a Slot Cover
You remove a slot cover when you install an add-in card that occupies a
previously-empty slot.
1
Lay the system on its side with the open side facing up and the slot
covers facing you.
2
3
4
Locate the slot of the cover you want to remove.
Remove the screw from the slot cover, and set it aside for future use.
Carefully remove the loose slot cover, and set it aside for future use.
Removing, Installing, and Replacing Components
45
Covering an Open I/O Slot
Slot covers prevent air from escaping through the empty hole. If air
escapes, the components inside the computer cannot be properly cooled.
This may damage some components, especially the main processor
(which generates the most heat).
1
Fit the bottom end of the slot cover (removed earlier) between the
chassis and system board.
2
Push the slot cover in until it rests firmly on the lip in the chassis. All
add-in card brackets and slot covers rest on this lip.
3
Replace the screw (removed earlier) to secure the I/O slot cover.
46
VAIO Slimtop System Reference Manual
Chapter 4
System Board
This chapter identifies and describes components on the system board.
Battery
Secondary IDE
Primary IDE
ATX PWR
Wake On LAN
(not used)
PWR Fan
CPU
to Modem/
USB3
VGA Monitor
USB1, USB2,
Ethernet
Line In
Line Out
Mic
PCMCIA
Socket
O12
N
Sony
Memory Stick
i.LINK
1394 i.LINK
USB4
LCD Monitor
(unused)
i.LINK
CD-IN
Memory
SWI (Config.switch)
CPU Fan
Sony Panel
1394 i.LINK
47
48
VAIO Slimtop System Reference Manual
Memory Module (DIMM) Slots
O12
N
DIMM1
DIMM2
Both sides of each Dual Inline Memory Module (DIMM) look very
similar. The side with pin 1 has a small "1" to the left of pin 1. Be sure to
orient a DIMM correctly in the DIMM connector (a small triangle on the
connector indicates pin 1).
Memory module (DIMM)
1
Indicates pin 1
System Board
49
Power (ATX PWR) Header
The ATX PWR connector is a 20-pin Molex-type header connector that
provides power to the system board.
20
11
ATX PWR
1
10
O12
N
Power connector
Pin #
Name
Pin #
Name
1
+3.3 V
11
+3.3 V
2
+3.3 V
12
-12 V
3
GND
13
GND
4
+5 V
14
PS-ON# (power supply
remote on/off control)
5
GND
15
GND
6
+5 V
16
GND
7
GND
17
GND
8
PWRGD (power good)
18
NC
9
+5 VSB
19
+5 V
10
+12 V
20
+5 V
50
VAIO Slimtop System Reference Manual
CLR CMOS Jumper
A two-switch dual-inline package (DIP) provides configuration settings
for clearing the CMOS password and enabling or disabling the onboard
VGA interrupt (VGA_INT).
The computer ships with the CMOS switch (#1) set to OFF (Normal) and
the VGA_INT switch (#2) set to OFF (Disable).
Do not change the position of any switch unless directed by a Sonyauthorized technical support person.
O12
N
1
2
O
N
Configuration switches (SWI)
Switch #
Name
1
CMOS
2
AGP_INT
On
Off
Clear
Normal
password
Enable
Disable
Chapter 5
CMOS Setup Options
This chapter describes each screen in the Award BIOS Setup Utility (see
“Accessing the CMOS Setup Utility” on page 16).
The Award BIOS setup has five menu items on the menu bar. These are:
❑
Main
❑
Advanced
❑
Power
❑
Boot
❑
Exit
Options that you can change are enclosed in brackets. Text that is not
enclosed in brackets cannot be changed.
A small triangle ( ) indicates that there is a sub-menu with additional
information and options. Press Enter to display the sub-menu. The
information and options in a sub-menu are context-sensitive (they appear
or disappear, depending on which options you select).
The item shown in [brackets] in this guide is the default option. The
option shown in [brackets] on the screen is the option currently set for
your system.
The other available options for each item are shown without brackets
directly below the default option in this guide. The available options are
listed in the order they occur when you press the + key.
Use the left and right arrow keys to choose a menu item. Use the up and
down arrow keys to select an option. Press Enter to display a list of
options, or press the + or - key to cycle through the other options.
If you display the list of options, use the up and down arrow keys to
select an option in the list, then press Enter to apply the selection.
Press Esc to go back to the main menu.
51
52
VAIO Slimtop System Reference Manual
Press F10 to save the changes and exit, or press Esc to discard the
changes.
Follow the on-screen prompts for other choices. The bottom of the screen
presents a summary of the keys to use for navigation and control.
CMOS Setup Options
Main Screen
System Time
[00:00:00]
System Date
[01/01/2001]
Legacy Diskette A
[None]
360 K, 5.25 in.
1.2 M, 5.25 in.
720 K, 3.5 in.
1.44 M, 3.5 in.
2.88 M, 3.5 in.
Primary Master (see “IDE Sub-Menus” on page 54)
Primary Slave (see “IDE Sub-Menus” on page 54)
Secondary Master (see “IDE Sub-Menus” on page 54)
Secondary Slave (see “IDE Sub-Menus” on page 54)
Keyboard Features (see xref to keyboard features)
Language
[English]
Supervisor Password
[Disabled]
User Password
[Disabled]
Halt On
[All but Keyboard]
All but Disk
All but Disk/Keyboard
All Errors
No Error
Installed Memory
128 MB (depends on model)
53
54
VAIO Slimtop System Reference Manual
IDE Sub-Menus
Type
[Auto]
User Type HDD
CD-RW/DVD combo
LS-120
ZIP-100
MO
Other ATAPI Device
None
Cylinders*
[1024]
Heads†
[255]
Sectors†
CHS Capacity
[63]
*
8422 MB
Maximum LBA Capacity*
40020 MB (actual size depends on model)
Multi-Sector Transfers*
[Maximum]
Disabled
2 Sectors
4 Sectors
8 Sectors
16 Sectors
32 Sectors
SMART Monitoring*
[Disabled]
Enabled
PIO Mode‡
[4]
0
1
2
3
ULTRA DMA Mode†
[4]
Disabled
0
1
2
3
Set Device As**
[Auto]
Floppy
Hard Disk
* This option appears when Type is set to Auto or User Type HDD.
† This option appears when Type is set to Auto or User Type HDD.
‡ This option appears when Type is not set to None.
** This option appears when Type is set to ZIP-100 or MO.
CMOS Setup Options
Keyboard Features Sub-Menu
Boot Up NumLock Status
[On]
Off
Keyboard Auto-Repeat Rate
[12/Sec]
15/Sec
20/Sec
24/Sec
30/Sec
6/Sec
8/Sec
10/Sec
Keyboard Auto-Repeat Delay
[1/4 Sec]
1/2 Sec
3/4 Sec
1 Sec
55
56
VAIO Slimtop System Reference Manual
Advanced Screen
Current CPU Internal Frequency
1B GHz (depends on model)
CPU Frequency Mutiple
[7.5x]
FSB/SDRAM Freq. (MHz)
[133/133]
CPU Level 1 Cache
[Enabled]
Disabled
CPU Level 2 Cache
[Enabled]
Disabled
CPU Level 2 Cache ECC Check
[Disabled]
Enabled
Processor Serial Number
[Disabled]
Enabled
BIOS Update
[Enabled]
Disabled
PS/2® Mouse Function Control
[Auto]
Enabled
USB Legacy Support
[Auto]
Disabled
Enabled
OS/2 Onboard Memory > 64M
[Disabled]
Enabled
Chip Configuration (see “Chip Configuration Sub-Menu” on page 57)
I/O Device Configuration (see “I/O Device Configuration Sub-Menu” on page 59)
PCI Configuration (see “PCI Configuration Sub-Menu” on page 59)
Shadow Configuration (see “Shadow Configuration Sub-Menu” on page 60)
CMOS Setup Options
Chip Configuration Sub-Menu
SDRAM Timing
[By SPD]
User Define
SDRAM CAS Latency
[3 T]
SDRAM RAS to CAS Delay
[4 T]
SDRAM RAS Precharge Time
[3 T]
Refresh RAS Assertion
[5 T]
4T
6T
7T
Refresh Queue Depth
[12]
0
4
8
SDRAM Refresh Mode
[Simultaneous]
Staggered 1T
Memory Hole At Address
[None]
15 M-16 M
14 M-16 M
12 M-16 M
Video Memory Cache Mode
[USWC]
UC
Graphics Aperture Size
[64 MB]
128 MB
256 MB
4 MB
8 MB
16 MB
32 MB
VGA Shared Memory Size
[16 MB]
8 MB
32 MB
64 MB
2 MB
4 MB
57
58
VAIO Slimtop System Reference Manual
VGA LCD TV Display Type
[Auto (BIOS Default)]
CRT1 Only
Composite NTSC
CRT1 + Composite NTSC
Composite PAL
CRT1 + Composite PAL
S-Video NTSC
CRT1 + S-Video NTSC
S-Video PAL
CRT1 + S-Video PAL
SCART
CRT1 + SCART
LCD with Scaling
CRT1 + LCD with Scaling
LCD without Scaling
CRT1 + LCD without Scaling
CRT2
CRT1 + CRT2
Hi-Vision TV
CRT1 + Hi-Vision TV
PCI 2.1 Support
[Enabled]
Disabled
ISA Bus Clock
[PCICLK/4]
7.159 MHz
Onboard PCI IDE Enable
[Both}
Primary
Secondary
Disabled
USB Function
[Enabled]
Disabled
Onboard LAN
[Enabled]
Disabled
Onboard LAN Boot ROM
[Disabled]
Enabled
Onboard 1394 Controller
[Enabled]
Disabled
Onboard PCMCIA Controller
[Enabled]
Disabled
CMOS Setup Options
I/O Device Configuration Sub-Menu
Onboard AC97 Audio Controller [Enabled]
Disabled
Onboard Serial Port 1
[Disabled]
3F8H/IRQ4
2F8H/IRQ3
3E8H/IRQ4
2E8H/IRQ10
Onboard Serial Port 2
[2F8H/IRQ3]
3E8H/IRQ4
2E8H/IRQ10
Disabled
3F8H/IRQ4
Onboard Parallel Port
[Disabled]
3BCH/IRQ7
378H/IRQ7
278H/IRQ5
PCI Configuration Sub-Menu
Slot 1 IRQ
and
Slot 2 IRQ
[Auto]
NA
3
4
5
7
9
10
11
12
14
15
PCI/VGA Palette Snoop
[Disabled]
Enabled
PCI Latency Timer
[32]
SYMBIOS SCSI BIOS
[Auto]
Disabled
ONB VGA BIOS First
[No]
Yes
59
60
VAIO Slimtop System Reference Manual
Shadow Configuration Sub-Menu
Video ROM BIOS Shadow
[Enabled]
Disabled
C8000-CBFFF Shadow
[Disabled]
Enabled
CC000-CFFFF Shadow
[Disabled]
Enabled
D0000-D3FFF Shadow
[Disabled]
Enabled
D4000-D7FFF Shadow
[Disabled]
Enabled
D8000-DBFFF Shadow
[Disabled]
Enabled
DC000-DFFFF Shadow
[Disabled]
Enabled
CMOS Setup Options
Power Screen
Power Management
[User Define]
Disabled
Min Saving
Max Saving
Video Off Option
[Suspend -> Off]
Always On
Video Method
[DPMS OFF]
DPMS Reduce ON
Blank Screen
V/H SYNC+Blank
DPMS Stand by
DPMS Suspend
HDD Power Down
[Disabled]
1 Min
2 Min
3 Min
4 Min
5 Min
6 Min
7 Min
8 Min
9 Min
10 Min
11 Min
12 Min
13 Min
14 Min
15 Min
ACPI Mode
[S3]
S1
PS/2® Mouse Wake For S1
[Disabled]
Enabled
Suspend Mode
[Disabled]
1~2 Min
2~3 Min
4~5 Min
8~9 Min
20 Min
30 Min
40 Min
1 Hour
PWR Button < 4 Secs
[Soft Off]
Suspend
61
62
VAIO Slimtop System Reference Manual
Power Up Control
AC PWR Loss Restart
[Disabled]
Enabled
Automatic PWR Up
[Disabled]
Everyday
By Date
HardWare Monitor
MB Temperature
[(displays actual temperature)]
Ignore
CPU Temperature
[(displays actual temperature)]
Ignore
Power Fan Speed
[(displays actual RPM)]
Ignore
CPU Fan Speed
[(displays actual RPM)]
Ignore
VCORE Voltage
[(displays actual voltage)]
Ignore
+3.3 V Voltage
[(displays actual voltage)]
Ignore
+5 V Voltage
[(displays actual voltage)]
Ignore
+12 V Voltage
[(displays actual voltage)]
Ignore
-12 V Voltage
[(displays actual voltage)]
Ignore
CMOS Setup Options
Boot Screen
1. ATAPI CD-ROM
[(displays installed drive)]
Disabled
2. Removable Device
[USB FDD]
USB ZIP
Disabled
Legacy Floppy
LS120
ZIP-100
ATAPI MO
3. IDE Hard Drive
[(displays installed drive)]
Disabled
4. Other Boot Device
[INT18 Device (Network)]
SCSI Boot Device
Disabled
Plug & Play O/S
[No]
Yes
Boot Virus Detection
[Enabled]
Disabled
Quick Power On Self Test
[Enabled]
Disabled
Silent Boot
[Enabled]
Disabled
63
64
VAIO Slimtop System Reference Manual
Exit Screen
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Chapter 6
Miscellaneous Technical
Information
This chapter contains information on the following subjects:
❑
User and Supervisor password
❑
Beep code error messages
❑
PCI configuration status and error messages
❑
DMA channel assignments
❑
IRQ assignments
❑
System I/O address map
❑
Memory map
65
66
VAIO Slimtop System Reference Manual
User and Supervisor Passwords
The system allows you to specify up to two passwords (a User password
and a Supervisor password) in the BIOS Setup Utility. The User password
is required; the Supervisor password is optional.
Access to the BIOS Setup Utility depends on which passwords were
previously set, as indicated next.
If you set these passwords...
...the following passwords are required:
User password only
User password is required at bootup.
Supervisor password only
No password is required at bootup.
Supervisor password is required by most
setup options.
Both passwords
User password is required at bootup.
Supervisor password is required by most
setup options.
Miscellaneous Technical Information
67
Beep Code Error Messages
During a normal bootup, a single short beep signifies that the system is
OK. Other beep patterns signify errors. The number of beeps indicates the
specific error that occurred.
The Sony Online Support technical representative needs to know how
many beeps your system produces if there is an error, so count the
number of beeps before calling for support.
68
VAIO Slimtop System Reference Manual
PCI Configuration Status and Error Messages
The following is a list of status and error messages that may appear on
your system from time to time.
Message
Meaning
Floppy Disk Controller
Resource Conflict
The floppy disk controller has requested a
resource that is already in use.
CMOS Checksum Error,
CMOS Cleared
The CMOS data was reinitialized due to a
CMOS checksum error.
CMOS Data Invalid,
CMOS Cleared
Invalid entry in the CMOS.
Parallel Port Resource Conflict
The parallel port has requested a resource
that is already in use.
PCI Error Log is Full
This message is displayed when more than
15 PCI conflict errors are detected. No
additional PCI errors can be logged.
PCI I/O Port Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI IRQ Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI Memory Conflict
Two devices requested the same resource,
resulting in a conflict.
Primary Boot Device Not
Found
The designated primary boot device (hard
disk drive, floppy disk drive, DVD-ROM
drive, or network drive) could not be
found.
Primary IDE Controller
Resource Conflict
The primary IDE controller has requested a
resource that is already in use.
Primary Input Device Not
Found
The designated primary input device
(keyboard, mouse, or other, if input is
redirected) could not be found.
Primary Output Device Not
Found
The designated primary output device
(display, serial port, or other, if input is
redirected) could not be found.
Secondary IDE Controller
Resource Conflict
The secondary IDE controller has requested
a resource that is already in use.
Serial Port 1 Resource Conflict
Serial port 1 has requested a resource that is
already in use.
Miscellaneous Technical Information
69
DMA Channel Assignments
This shows the factory default values. The Windows® operating system
reassigns resources to best meet the needs of a particular configuration.
DMA
Channel
Default
Assignment
Channel 4
Direct memory access controller
70
VAIO Slimtop System Reference Manual
IRQ Assignments
IRQ #
Default Assignment
(ISA) 0
System timer
(ISA) 1
Standard 101/102-Key or Microsoft® Natural PS/2® Keyboard
(ISA) 3
Communications Port (COM2)
(ISA) 4
Communications Port (COM1)
(ISA) 8
System CMOS/real time clock
(ISA) 9
Microsoft ACPI-Compliant System
(ISA) 12
PS/2 Compatible Mouse
(ISA) 13
Numeric data processor
(ISA) 14
Primary IDE Channel
(ISA) 15
Secondary IDE Channel
(PCI) 9
Lucent Win Modem
(PCI) 9
Ricoh R/RL/RT/RC/5C475(II), R5C520 or compatible CardBus
Controller
(PCI) 9
SiS 630/730
(PCI) 9
SiS 7001 PCI to USB Open Host Controller
(PCI) 9
SiS 7001 PCI to USB Open Host Controller
(PCI) 9
SiS 7018 Audio Driver
(PCI) 9
SiS 900 PCI Fast Ethernet Adapter
(PCI) 9
Sony Memory Stick® controller (PCI)
(PCI) 9
Texas Instruments OHCI Compliant IEEE 1394 Host Controller
✍ This shows the factory default values. Windows® XP operating system reassigns
resources to best meet the needs of a particular configuration. PCI IRQs can be shared
between several PCI devices.
Miscellaneous Technical Information
71
System I/O Address Map
Address Range (hex)
Description
00000000-0000000F
Direct memory access controller
00000000-00000CF7
PCI bus
00000010-0000001F
Motherboard resources
00000020-*00000021
Programmable interrupt controller
00000022-0000002D
Motherboard resources
00000030-0000003F
Motherboard resources
00000040-00000043
System timer
00000044-0000005F
Motherboard resources
00000060-00000060
Standard 101/102-Key or Microsoft® Natural PS/2®
Keyboard
00000061-00000061
System speaker
00000062-00000063
Motherboard resources
00000064-00000064
Standard 101/102-Key or Microsoft Natural PS/2
Keyboard
00000065-0000006F
Motherboard resources
00000070-00000073
System CMOS/real time clock
00000074-0000007F
Motherboard resources
00000080-00000090
Direct memory access controller
00000091-00000093
Motherboard resources
00000094-0000009F
Direct memory access controller
000000A0-000000A1
Programmable interrupt controller
000000A2-000000BF
Motherboard resources
000000C0-000000DF
Direct memory access controller
000000E0-000000EF
Motherboard resources
000000F0-000000FF
Numeric data processor
00000170-00000177
Secondary IDE Channel
000001F0-000001F7
Primary IDE Channel
00000274-00000277
ISAPNP Read Data Port
00000279-00000279
ISAPNP Read Data Port
00000290-00000297
Motherboard resources
000002F8-000002FF
Communications port (COM2)
00000376-00000376
Secondary IDE Channel
000003B0-000003BB
SiS 630/730
000003B0-000003BB
SIS Processor to AGP Controller
72
VAIO Slimtop System Reference Manual
Address Range (hex)
Description
000003C0-000003DF
SiS 630/730
000003C0-000003DF
SIS Processor to AGP Controller
000003F0-000003F1
Motherboard resources
000003F6-000003F6
Primary IDE Channel
000003F8-000003FF
Communications Port (COM1)
00000480-0000048F
Motherboard resources
000004D0-000004D1
Motherboard resources
00000080-0000090
Direct memory access controller
00000091-00000093
Motherboard resources
00000094-0000009F
Direct memory access controller
000000A0-000000A1
Programmable interrupt controller
000000A2-000000BF
Motherboard resources
000000C0-000000DF
Direct memory access controller
000000E0-000000EF
Motherboard resources
000000F0-000000FF
Numeric data processor
00000170-00000177
Secondary IDE Channel
000001F0-000001F7
Primary IDE Channel
00000274-00000277
ISAPNP Read Data Port
00000279-00000279
ISAPNP Read Data Port
00000290-00000297
Motherboard resources
000002F8-000002FF
Communications Port (COM2)
00000376-00000376
Secondary IDE Channel
000003B0-000003BB
SiS 630/730
000003B0-000003BB
SiS Processor to AGP Controller
000003C0-000003DF
SiS 630/730
000003C0-000003DF
SiS Processor to AGP Controller
000003F0-000003F1
Motherboard resources
000003F6-000003F6
Primary IDE Channel
000003F8-000003FF
Communciations Port (COM1)
00000480-0000048F
Motherboard resources
000004D0-000004D1
Motherboard resources
00000A79-00000A79
ISAPNP Read Data Port
00000D00-0000FFFF
PCI bus
00008400-000084FF
Lucent Win Modem
00008800-00008807
Lucent Win Modem
Miscellaneous Technical Information
Address Range (hex)
Description
00090000-00009FFF
SIS Processor to AGP Controller
00009800-0000897F
SiS 630/730
0000A800-0000A8FF
SiS 7018 Audio Driver
0000B000-0000B0FF
SiS 900 PCI Fast Ethernet Adapter
0000B400-0000B40F
SiS PCI IDE Controller
0000E400-0000E4FE
Motherboard resources
0000E4FF-0000E4FF
Mtoherboard resources
0000FD00-0000FDFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
0000FE00-0000FEFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
73
74
VAIO Slimtop System Reference Manual
Memory Map
Address Range
Description
00000000-00009FFFF
System board
000A0000-000BFFFF
PCI bus
000A0000-000BFFFF
SiS 630/730
000A0000-000BFFFF
SIS Processor to AGP Controller
000C8000-000DFFFF
PCI bus
000DF000-000DFFFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
000F0000-000FFFFF
System board
00100000-0AFFFFFF
System board
0B000000-FFFFFFFF
PCI bus
CB800000-CB8000FF
Lucent Win Modem
CC000000-CC003FFF
Texas Instruments OHCI Compliant IEEE 1394
Host Controller
CC800000-CC8007FF
Texas Instruments OHCI Compliant IEEE 1394
Host Controller
CD000000-CD0003FF
Sony Memory Stick® controller (PCI)
CD800000-CD81FFFF
SiS 630/730
CD800000-CDFFFFFF
SIS Processor to AGP Controller
CD000000-CD000FFF
SiS 7018 Audio Driver
CE800000-CD800FFF
SiS 7001 PCI to USB Open Host Controller
CF000000-CF000FFF
SiS 7001 PCI to USB Open Host Controller
CF800000-CF800FFF
SiS 900 PCI Fast Ethernet Adapter
D0000000-D3FFFFFF
SIS Processor to AGP Controller
D8000000-DFFFFFFF
SiS 630/730
D8000000-E7EFFFFF
SIS Processor to AGP Controller
FBEFE000-FFEFDFFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
FFEE0000-FFEFFFFF
System board
FFEFE000-FFEFEFFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
FFEFF000-FFEFFFFF
Ricoh R/RL/RT/RC/5C475(II), R5C520 or
Compatible CardBus Controller
FFFE0000-FFFFFFFF
System board
Chapter 7
Specifications
This chapter describes the technical specifications for your Sony
computer.
Processor
See Specifications sheet for details.*
Chipset
SiS630 chipset
PCI Bus
PCI Level 2.1, 33 MHz zero wait state
2 PCI slots (one open)
Memory Modules (DIMMs)
Installed memory
See Specifications sheet for details.*
Maximum memory
512 MB (256 MB in each socket)
Voltage
3.3 V memory only
Pins
168-pins with gold-plated contacts
SDRAM type
3.3 V PC-133 MHz unrestricted CAS latency 2,
unbuffered, 64 bits (non-ECC) SDRAM DIMM
modules
* The Specifications sheet is supplied with your computer's original documentation.
75
76
VAIO Slimtop System Reference Manual
Memory Configurations
DIMM1*
DIMM2*
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
* SDRAM is expandable to 512 MB. Computer SDRAM is unbuffered DIMM, specification Rev. 1.0 or later.
Your computer does not support EDO memory or buffered DIMM memory. Memory can be installed in
either socket. Memory size can vary between sockets. DIMMs can be single- or double-sided. DIMMs must
be 3.3 V unbuffered 4-clock, 64-bit or 72-bit, 133 MHz SDRAM module. Use only 133 MHz memory. Do not
mix 100 MHz memory with 133 MHz memory.
L2 Cache
Installed
256 KB secondary write-back cache (in processor),
direct-mapped organization, on-chip cache
Controller
SiS 630 host bridge controller
Graphics
Controller*
SiS 630 graphics hardware acceleration
Video memory
16 MB (uses system memory)
Resolution (displayed resolution depends on the graphics display you use)
True color (32 bits) Up to 1600 x 1280 at 85 Hz non-interlaced
High color (16 bits) Up to 2048 x 1536 at 70 Hz non-interlaced
256 colors (8 bits)
Up to 2048 x 1536 at 70 Hz non-interlaced
* Supports DDC-1 and DDC-2b standards for Plug and Play displays.
Specifications
77
Audio
Sound chip
SIS 630 sound controller plus AC97
Wave synthesis
SiS7018
Sound effects
Compatible with DirectSound
Audio sampling rate
Up to 48 kHz at 16 bits
Rear panel
Line In (from audio output connector)
Communications
Modem
(Installed modem may
vary depending on the
system configuration
purchased.)
V.90 compatible data/fax modem (REN 0.79B)*
Fax
14.4 Kbps maximum
* This modem is capable of downloading at 56 Kbps. Your phone service, online service, or Internet Service
Provider may not support this technology or operate at this speed.
I/O and Expansion Slots
Modem ports
Two RJ-11 connectors at rear panel for line and
phone
USB ports
USB1 at front panel, and USB2, USB3, and USB4 at
rear panel
PCI slots
One available slot. Maximum length for add-in
cards is 6.6 inches
IDE connectors
Primary and secondary
78
VAIO Slimtop System Reference Manual
i.LINK Interface
Ports
Two (one at front panel, one at rear panel)
Speed
Up to 400 Mbps
Chipset
TI TSB12LV22 and TSB41LV03 OHCI
Enable/disable function
From BIOS
Ethernet Interface
Connector
RJ-45 (on rear panel)
Type of LAN
Ethernet
Speed
10Base-T/100Base-TX
Drives and Controllers
Diskette controller
82077-compatible (supports up to 2.88 MB)
Diskette drive
1.44 MB 3.5-inch MFDD
EIDE controller
Supports PIO Mode 4 EIDE drives and Ultra
DMA/66 Mode drives
IDE hard drive*
60.0 GB†
CD-RW/DVD
combo drive
See Specifications sheet for details.**
* Bus-mastering EIDE driver installed.
† GB means one billion bytes when referring to hard drive capacity. Accessible capacity may vary.
System CMOS
Make and model
Award
ROM
2 Mb flash-ROM
Passwords
User and supervisor passwords supported
Recovery boot block
Supported
Power management
APM 1.2
Advanced features
ACPI-1.0 compliant hardware for use with APM and
PNP BIOS APIs
Plug and Play devices
Supported with steerable DMA channels and
interrupts
Special features
PC-99 compliant, multi-boot, PCI add-in card
auto-configure
**
The Specifications sheet is supplied with your computer's original documentation.
Index
A
add-in card
installing 28
removing 26, 29
address map, system 71
audio specifications 77
B
battery - See lithium battery
beep codes 67
BIOS - See Also CMOS
BIOS setup utility
advanced screen 56
boot screen 63
exit screen 64
main screen 53
options 51
power screen 61
screens 51
codes, beeps 67
communications specifications 77
computer
lithium battery vii
configuration switch 50
configuring
CMOS setup utility 16
power management 17
system board 21
connectors
i.LINK (IEEE1394) 6
power 49
USB 6
VGA MONITOR 10
cover
slot 44
system 24, 25
covering I/O slot 45
CPU
See processor
C
CD-RW/DVD combo drive
access indicator 5
disc eject button 4
emergency-eject hole 4
location of 3
performance of discs 3, 78
specifications 78
chipset specifications 75
CMOS
configuring 16
See Also BIOS
setup utility 16
specifications 78
CMOS switch 50
D
DIMM 48
See Also memory modules
display, power management 17
disposal of lithium battery vii
DMA channel assignments 69
drives
CD-RW/DVD combo drive
specifications 78
controller specifications 78
specifications 78
79
80
VAIO Slimtop System Reference Manual
E
L
error messages
beep codes 67
PCI configuration 68
Ethernet connector 13
expansion slots
specifications for 77
L2 cache specifications 76
LCD connector 13
LINE and PHONE connectors 14
lithium battery
disposal vii
safety precautions vii
lithium battery, replacing 30
F
fax/modem
See Also communications
front view 2
buttons and switches 4
connectors 5, 6
drives 3
indicators 5
M
hard drive, replacing 40
memory
See Also system memory
memory map 74
memory modules
connectors 48
removing 35
specifications 75
messages
error 67
status and error 68
microprocessor - See processor
modem - See Also communications
I
N
i.LINK (IEEE1394) connectors 6, 12
i.LINK interface, specifications 78
I/O address map 71
I/O connectors
Ethernet 13
i.LINK (IEEE1394) 12
LCD 13
LINE and PHONE 14
USB 10
VGA MONITOR 10
I/O slot covering 45
I/O slot specifications 77
IDE
specifications 78
installing
add-in card 28
system memory 37
IRQ assignments 70
notice to users ii
G
graphics controller, specifications 76
H
P
passwords, user and supervisor 66
PCI
bus specifications 75
power connector 49
power management, configuring 17
processor specifications 75
R
RAM - See Also system memory
rear view 8
I/O connectors 10
removing
add-in card 26, 29
memory module 35
slot cover 44
system cover 24
Index
replacing
hard drive 40
lithium battery 30
system cover 25
resolution - See graphics controller
specifications
S
slot - See Also I/O slot and expansion
slot
slot cover, removing 44
specifications
audio 77
chipset 75
CMOS 78
communications 77
drives and controllers 78
graphics 76
i.LINK interface 78
I/O and expansion slots 77
L2 cache 76
memory module 75
PCI bus 75
processor 75
status and error messages 68
81
supervisor password 66
switches
CMOS 50
VGA_INT 50
system board
configuring 21
memory module connector 48
power connector 49
system cover
removing 24
replacing 25
system I/O address map 71
system memory, installing 37
U
USB connectors 6, 10
user password 66
V
VGA MONITOR
I/O connector 10
See Also LCD Monitor and
display
VGA_INT switch 50
82
VAIO Slimtop System Reference Manual
