Notice to Users
© 2000 Sony Electronics Inc. Reproduction in
whole or in part without written permission
is prohibited. All rights reserved. This
manual and the software described herein, in
whole or in part, may not be reproduced,
translated, or reduced to any machinereadable form without prior written
approval.
SONY ELECTRONICS INC. PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN
AND HEREBY EXPRESSLY DISCLAIMS
ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE WITH
REGARD TO THIS MANUAL, THE
SOFTWARE, OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL
SONY ELECTRONICS INC. BE LIABLE
FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING
OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR
THE USE THEREOF.
Sony Electronics Inc. reserves the right to
make any modification to this manual or the
information contained herein at any time
without notice. The software described
herein is governed by the terms of a separate
user license agreement.
This product contains software owned by
Sony and licensed by third parties. Use of
such software is subject to the terms and
conditions of license agreements enclosed
with this product. Some of the software may
not be transported or used outside the
United States. Software specifications are
subject to change without notice and may not
necessarily be identical to current retail
versions.
ii
Updates and additions to software may
require an additional charge. Subscriptions to
online service providers may require a fee
and credit card information. Financial
services may require prior arrangements
with participating financial institutions.
Sony, VAIO, the VAIO logo, VAIO Digital
Studio, and i.LINK are trademarks of Sony.
Intel, Pentium, and Celeron are trademarks
of Intel Corporation. Microsoft, Windows,
and the Windows Me logo are registered
trademarks of Microsoft Corporation. PS/2 is
a registered trademark of IBM Corporation.
i.LINK is a trademark of Sony used only to
designate that a product contains an
IEEE1394 connector. All products with an
i.LINK connector may not communicate with
each other.
All other trademarks are trademarks or
registered trademarks of their respective
owners.
Owner’s Record
The model number and serial number are
located on the back of your VAIO® computer.
Record the serial number in the space
provided here. Refer to the model and serial
number when you call your Sony Service
Center.
Model Number: PCV-RX270DS/
PCV-RX280DS
Serial Number:________________________
Safety Information and
Caution
CD-RW Laser Diode Properties
! To change the backup battery,
contact your nearest Sony
Service Center.
! Caution - The use of optical
Laser output
1.0mW(Read)
35mW (Write)
Wave Length
777–787nm
DVD Laser Diode Properties
Laser output
40mW(DVD)
0.14mW (CD)
Wave Length
650nm (DVD)
780nm (CD)
instruments with this product
will increase eye hazard. As the
laser beam used in this product is
harmful to the eyes, do not
attempt to disassemble the drive
cabinet. Refer servicing to
qualified personnel only.
! Danger - Visible and invisible
laser radiation when open. Avoid
direct exposure to beam.
! For CD-RW: Danger - Invisible
❑
To prevent fire or shock hazard, do
not expose your desktop to rain or
moisture.To avoid electrical shock,
do not open the cabinet. Refer
servicing to qualified personnel
only.
❑
Never install modem or telephone
wiring during a lightning storm.
❑
Never install telephone jacks in wet
locations unless the jack is
specifically designed for wet
locations.
❑
Never touch uninsulated telephone
wire or terminals unless the
telephone line has been
disconnected at the network
interface.
❑
Use caution when installing or
modifying telephone lines.
❑
Avoid using the modem during an
electrical storm.
❑
Do not use the modem or a
telephone to report a gas leak in the
vicinity of the leak.
❑
The socket outlet shall be installed
near the equipment and shall be
easily accessible.
laser radiation when open. Avoid
direct exposure to beam.
! Caution: For ADSL modem
models, to reduce the risk of fire,
use only No. 26 AWG or larger
telecommunication line cord.
iii
❑
Pour prévenir tout risque d’incendie
ou d’électrocution, garder cet appareil
à l’abri de la pluie et de l’humidité.
❑
Pour prévenir tout risque
d’électrocution, ne pas ouvrir le
châssis de cet appareil et ne confier
son entretien qu’à une personne
qualifiée.
❑
Ne jamais effectuer l’installation de fil
modem ou téléphone durant un orage
électrique.
❑
Ne jamais effectuer l’installation
d’une prise téléphonique dans un
endroit mouillé à moins que la prise
soit conçue à cet effet.
❑
Ne jamais toucher un fil téléphonique
à découvert ou un terminal à moins
que la ligne téléphonique n’ait été
débranché de l’interface réseau.
❑
Soyez très prudent lorsque vous
installez ou modifiez les lignes
téléphoniques.
❑
Évitez d’utiliser le modem durant un
orage électrique.
❑
N'utilisez pas le modem ni le
téléphone pour prévenir d'une fuite
de gaz vous êtes près de la fuite.
❑
L’appareil doit être le plus près
possible d’une prise murale pour en
faciliter l’accès.
! Pour changer la pile de rechange,
veuillez contacter votre centre de
service Sony le plus près.
! Avertissement - L'utilisation
d'instruments optiques avec ce
produit augmente les risques
pour les yeux. Puisque le faisceau
laser utilisé dans ce produit est
dommageable pour les yeux, ne
tentez pas de désassembler le
boîtier. Adressez-vous à un agent
de service qualifié.
! Danger : Radiation laser visible et
invisible si ouvert. Évitez
l’exposition directe au faisceau.
! Pour les CD-RW : Danger :
Radiation laser visible et invisible
si ouvert. Évitez l'exposition
directe au faisceau.
! Attention : Pour ADSL modele
modem, afin de réduire les
risques d'incendie, n'utilisez
qu'un cordon de communication
N0. 26 AWG ou plus gros.
For questions regarding your product or for
the Sony Service Center nearest you, call 1888-476-6972 in the United States or
1-800-961-7669 in Canada.
Sony Customer Support can be reached at
www.sony.com/pcsupport.
iv
Regulatory Information
Declaration of Conformity
Trade Name:
Model No.:
SONY
PCV-RX270DS/
PCV-RX280DS
Responsible Party:
Sony Electronics Inc.
Address:
1 Sony Drive
Park Ridge, NJ 07656
Telephone:
201-930-6972
This phone number is for FCC-related matters
only.
This device complies with Part 15 of FCC Rules.
Operation is subject to the two following
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures: :
❑
Reorient or relocate the receiving
antenna.
❑
Increase the separation between the
equipment and the receiver.
❑
Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
❑
Consult the dealer or an
experienced radio/TV technician
for help.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
Only peripherals (computer input/output
devices, terminals, printers, etc.) that
comply with FCC Class B limits may be
attached to this computer product.
Operation with noncompliant peripherals
is likely to result in interference to radio
and television reception.
All cables used to connect peripherals
must be shielded and grounded.
Operation with cables, connected to
peripherals, that are not shielded and
grounded, may result in interference to
radio and television reception.
v
FCC Part 68
This equipment complies with Part 68 of the
FCC rules. The FCC Ringer Equivalence
Number (REN) for this equipment is 0.7. If
requested, this information must be provided
to the telephone company.
This modem uses the USOC RJ-11 telephone
jack.
The REN is used to determine the quantity of
devices which may be connected to the
telephone line. Excessive RENs on the
telephone line may result in the devices not
ringing in response to an incoming call. In
most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of
the number of devices that may be connected
to the line, as determined by the total RENs,
contact the telephone company to determine
the maximum REN for the calling area.
If the terminal equipment causes harm to the
telephone network, the telephone company
will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice is not practical, the
telephone company will notify the customer
as soon as possible. Also, you will be advised
of your right to file a complaint with the FCC
if you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operations of
the equipment. If this happens, the telephone
company will provide advance notice in
order for you to make the necessary
modifications in order to maintain
uninterrupted service.
If trouble is experienced with this modem,
for repair or warranty information, please
contact 1-888-4SONY-PC, or write to the
Sony Customer Information Center, 12451
Gateway Blvd., Fort Myers, FL 33913. If the
trouble is causing harm to the telephone
network, the telephone company may
request that you remove the equipment from
the network until the problem is resolved.
vi
Repair of this equipment should be made
only by a Sony Service Center or Sony
authorized agent. For the Sony Service
Center nearest you, call 1-888-4SONYPC (1888-476-6972).
This equipment cannot be used on public coin
service provided by the telephone company.
Connection to Party Line Service is subject to
state and possible provincial tariffs. (Contact
the state or provincial utility service
commission, public service commission, or
corporation commission for information.)
Telephone Consumer
Protection Act of 1991
(United States)
The Telephone Consumer Protection Act of
1991 makes it unlawful for any person to use
a computer or other electronic device to send
any message via a telephone facsimile
machine unless such message clearly
contains, in a margin at the top or bottom of
each transmitted page or on the first page of
the transmission, the date and time it is sent
and an identification of the business, other
entity, or individual sending the message,
and the telephone number of the sending
machine or such business, other entity, or
individual.
In order to program this information into
your facsimile, see your fax software
documentation
Telephone Consumer
Guidelines (Canada)
Please refer to your telephone directory
under ‘Privacy Issues’ and/or ‘Terms of
Service.’ For more detailed information,
please contact:
CRTC
Terrasses de la Chaudiére, Tour centrale
1 promenade du Portage, 5 étage Hull PQ
K1A 0N2.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet àppareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
DISPOSAL OF LITHIUM ION
BATTERY
You can return your unwanted lithium ion
batteries to your nearest Sony Service
Center or Factory Service Center.
✍ In some areas the disposal of lithium
ion batteries in household or business
trash may be prohibited.
For the Sony Service Center nearest you,
call 1-888-476-6972 in the United States or
1-800-961-7669 in Canada.
! Do not handle damaged or
leaking lithium ion batteries.
! Danger of explosion if battery is
incorrectly replaced. Replace
only with the same or
equivalent type recommended
by the manufacturer. Discard
used batteries according to the
manufacturer’s instructions.
! The battery pack used in this
device may present a fire or
chemical burn hazard if
mistreated. Do not disassemble,
heat above 212°F (100°C) or
incinerate.
Dispose of used battery
promptly.
Keep away from children.
! Ne pas manipuler les batteries
au lithium-ion qui fuient ou sont
endommagées.
! Une batterie non conforme
présente un danger d'explosion.
La remplacer seulement par une
batterie identique ou de type
équivalent recommandé par le
fabricant. Évacuer les batteries
usées selon les directives du
fabricant.
! La manutention incorrecte du
module de batterie de cet
appareil présente un risque
d'incendie ou de brûlures
chimiques. Ne pas démonter,
incinérer ou exposer à une
température de plus de 100°C.
Évacuer promptement la
batterie usée. Garder hors de
portée des enfants.
vii
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label
identifies certified equipment. This
certification means that the equipment meets
certain telecommunications network
protective, operational and safety
requirements as prescribed in the
appropriate Terminal Equipment Technical
Requirements document(s). The Department
does not guarantee the equipment will
operate to the userís satisfaction.
Before installing this equipment, users
should ensure that it is permissible to be
connected to the facilities of the local
telecommunications company. The
equipment must also be installed using an
acceptable method of connection.
The customer should be aware that
compliance with the above conditions may
not prevent degradation of service in some
situations.
Repairs to certified equipment should be
coordinated by a representative designated
by the supplier. Equipment malfunctions or
any repairs or alterations made by the user to
this equipment may give the
telecommunications company cause to
request that the user disconnect the
equipment.
Users should ensure for their own protection
that the electrical ground connections of the
power utility, telephone lines and internal
metallic water pipe system, if present, are
connected together. This precaution may be
particularly important in rural areas.
CAUTION: Users should not attempt to
make such connections themselves, but
should contact the appropriate electrical
inspection authority, or electrician, as
appropriate.
NOTICE: The Ringer Equivalence Number
(REN) assigned to each terminal device
provides an indication of the maximum
number of terminals allowed to be connected
to a telephone interface. The termination on
viii
an interface may consist of any combination
of devices subject only to the requirement
that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5.
The Ringer Equivalence Number for this
equipment is 0.7.
AVIS DE L’INDUSTRIE
CANADA
AVIS: L’étiquette d’Industrie Canada
identifie le matériel homologué.
Cette étiquette certifie que le matériel est
conforme aux normes de protection,
d’exploitation et de sécurité des réseaux de
télécommunications, comme le prescrivent
les documents concernant les exigences
techniques relatives au matériel terminal. Le
Ministère n’assure toutefois pas que le
matériel fonctionnera à la satisfaction de
l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit
s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de
télécommunication. Le matériel doit
également être installé en suivant une
méthode acceptée de raccordement.
L’abonné ne doit pas oublier qu’il est possible
que la conformité aux conditions énoncées cidessus n’empêche pas la dégradation du
service dans certaines situations.
Les réparations de matériel homologué
doivent être coordonnées par un
représentant désigné par le fournisseur.
L’entreprise de télécommunications peut
demander à l’utilisateur de débrancher un
appareil à la suite de réparations ou de
modifications effectuées par l’utilisateur ou à
cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit
s’assurer que tous les fils de mise à la terre de
la source d’énergie électrique, des lignes
téléphoniques et des canalisations d’eau
métalliques, s’il y en a, sont raccordés
ensemble. Cette précaution est
particulièrement importante dans les
régions rurales.
Avertissement: L’utilisateur ne doit pas
tenter de faire ces raccordements luimême; il doit avoir recours à un service
d’inspection des installations électriques,
ou à un électricien, selon le cas.
AVIS: L’indice d’équivalence de la
sonnerie (IES) assigné à chaque dispositif
terminal indique le nombre maximal de
terminaux qui peuvent être raccordés à
une interface.
La terminaison d’une interface
téléphonique peut consister en une
combination de quelques dispositifs, à la
seule condition que la somme d’indices
d’équivalence de la sonnerie de tous les
dispositifs n’excède pas 5. L’indice
d’équivalence de la sonnerie de ce matériel
est de 0.7.
ix
x
Contents
Notice to Users .................................................................................... ii
Safety Information and Caution ..................................................... iii
Regulatory Information.......................................................................v
FCC Part 68 ......................................................................................... vi
Telephone Consumer Protection Act of 1991 (United States) ..... vi
Telephone Consumer Guidelines (Canada).................................. vii
DISPOSAL OF LITHIUM ION BATTERY .................................... vii
INDUSTRY CANADA NOTICE.................................................... viii
AVIS DE L’INDUSTRIE CANADA .............................................. viii
Chapter 1 — Identifying Components
Front View ...................................................................................................2
Drives ...................................................................................................3
Buttons and Switches .........................................................................4
Indicators ..............................................................................................5
Connectors ...........................................................................................6
Rear View ....................................................................................................7
Icons .....................................................................................................8
I/O Connectors ..................................................................................10
Expansion Slots ..................................................................................14
Chapter 2 — Configuring Your System
Accessing the BIOS Setup Utility............................................................16
Changing the Display's Power Management Settings.........................17
Configuring the System Board ...............................................................20
xi
xii
VAIO Digital Studio™ Reference Manual
Chapter 3 — Removing, Installing, and Replacing
Components
Removing the Side Cover .......................................................................22
Replacing the Side Cover ........................................................................23
Installing an Add-In Card .......................................................................24
Removing an Add-in Card .....................................................................25
Replacing the Lithium Battery ...............................................................27
Installing System Memory ......................................................................30
Removing a Memory Module ................................................................33
Removing a Slot Cover.............................................................................35
Covering an Open I/O Slot ....................................................................36
Installing a 3½” Internal Hard Disk Drive ............................................37
Removing the Power Supply...................................................................41
Replacing the Power Supply ...................................................................42
Chapter 4 — System Board
Connectors..................................................................................................44
Front Panel Header (J25)...................................................................44
Diskette Drive Connector ................................................................45
Memory Module (DIMM) Connectors ...........................................46
PCI Slot Connectors ...........................................................................47
AGP Connector ..................................................................................48
IDE Connectors .................................................................................49
Power Connector ...............................................................................49
Keyboard and Mouse Connectors ..................................................50
USB Connectors .................................................................................51
Ethernet Connector ...........................................................................53
Serial 1, Printer, and i.LINK Connectors ........................................54
Fan Connectors ..................................................................................56
Game Connector.................................................................................57
Headphones, Line In, Mic Connectors............................................58
i.LINK Header Connectors ...............................................................59
CD-IN Connector ...............................................................................60
AUX-IN Connector ............................................................................61
VIDEO Connector ..............................................................................62
Configuration Jumpers ............................................................................63
Chapter 5 — Fax/Modem Card
Connectors .................................................................................................65
xiii
Chapter 6 — Video Card
DVI Connector ..........................................................................................68
Chapter 7 — CMOS Setup Options
Main Screen ...............................................................................................71
Advanced Screen ......................................................................................74
Power Screen..............................................................................................80
Boot Screen ................................................................................................82
Exit Screen ..................................................................................................83
Chapter 8 — Miscellaneous Technical Information
About User and Supervisor Passwords ................................................86
Beep Code Error Messages .....................................................................87
PCI Configuration Status and Error Messages ....................................88
DMA Channel Assignments ...................................................................90
System I/O Address Map ......................................................................91
Memory Map ...........................................................................................93
IRQ Summary ...........................................................................................94
Chapter 9 — Specifications
Processors .................................................................................................95
Chipset ......................................................................................................95
AGP Bus .....................................................................................................95
PCI Bus ......................................................................................................95
Memory Modules (DIMMs) ..................................................................95
DIMM Configurations .............................................................................96
L2 Cache ....................................................................................................96
Graphics ....................................................................................................96
Audio .........................................................................................................96
Communications .....................................................................................97
I/O and Expansion Slots .........................................................................97
Drives and Controllers ............................................................................97
System BIOS .............................................................................................98
xiv
Chapter 1
Identifying Components
The following sections identify and describe each component that is
visible from the exterior of the VAIO Digital Studio™ Computer. Internal
components are identified in the appropriate section of this manual.
1
2
VAIO Digital Studio Reference Manual
Front View
OM04694X.VSD
3
Identifying Components
Drives
DVD-ROM
CD-RW
Diskette drive
FRNTPNLA.VSD
Drive
Description
Diskette drive
3.5-inch, 1.44 Mbyte.
DVD-ROM drive*
DVD-ROM read: 16X (maximum performance).
CD-ROM read: 40X (maximum performance).
CD-RW drive†
CD-RW read: 20X (maximum performance).
CD-RW write: 4X (maximum performance).
CD-R read: 32X (maximum performance).
CD-R write: 8X (maximum performance).
CD-ROM read: 32X (maximum performance).
* Data on a DVD-ROM is read at a variable transfer rate, ranging from 6.6X at the innermost track to 16X at
the outermost track (the data transfer standard 1X rate is 1385 kbytes/s). The average data transfer rate is
11.3X (15,255 kbytes/s). Data on a CD-ROM is read at a variable transfer rate, ranging from 17.2X at the
innermost track to 40X at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The
average data transfer rate is 28.6X (4293 kbytes/s).
† CD-RW writing speed may vary, depending on the media. The maximum writing speed of the CD-R is 8X
(1X = 150 kbytes/s) and 4x for the CD-RW. The maximum reading speed of the CD-ROM is 32X, and 20X
for the CD-RW.
4
VAIO Digital Studio Reference Manual
Buttons and Switches
Optical disc eject
Diskette eject
Power/Standby
FRNTPNLB.VSD
Button or switch
Description
Power/Standby switch
Turns system power on, off, or into standby mode.
Diskette eject button
Ejects a diskette.
Optical disc eject button
Automatically opens and closes the optical drive
tray.
5
Identifying Components
Indicators
Diskette drive access
Hard disk drive access
Optical disc drive access
Power/Standby
FRNTPNLC.VSD
Indicator
Description
Power/Standby indicator
Standby (orange) indicates the computer
is in standby mode.
On (blue) indicates the computer is out of
standby mode, ready to use.
Off (no color) indicates the computer is
turned off, or in hibernation mode.
Diskette drive access indicator
On (green) indicates diskette drive
activity.
Optical drive access indicator
On (amber) indicates CD-ROM activity.
Hard disk drive access indicator
On (orange) indicates hard disk drive
activity.
6
VAIO Digital Studio Reference Manual
Connectors
USB
i.LINK
FRNTPNLD.VSD
Connector
Description
i.LINK®
Connects to a digital device that has a 4-pin i.LINK
connector.
USB
(IEEE1394)*
Connects to USB devices.
* To connect to a 6-pin i.LINK device, use the i.LINK connector on the back of the system. A 6-pin i.LINK
connector can supply power from the computer to the device if the device also has a 6-pin i.LINK connector.
A 4-pin i.LINK connector cannot supply power to the device.
Identifying Components
7
Rear View
Mouse
Keyboard
Power
USB1, USB2
Ethernet
Serial
Printer/Parallel
i.LINK (IEEE1394)
Game/MIDI
Headphones
LINE IN
Microphone
Monitor
Line
DVI
Telephone
KY0001.VSD
8
VAIO Digital Studio Reference Manual
Icons
Icon label area
OM04692X.VSD
Icon
Description
Mouse connector
Keyboard connector
Universal Serial Bus (USB) connector
Serial port connector
Printer port connector
Game/MIDI port connector
Headphones
LINE IN jack (audio)
Microphone jack
Monitor connector
Line jack (for telephone line from primary service jack)
Identifying Components
Icon
Description
Telephone jack (for phone)
i.LINK (IEEE1394) connector
Ethernet connector (for LAN connection only)
9
10
VAIO Digital Studio Reference Manual
I/O Connectors
The following section identifies the various I/O connectors.
Keyboard and Mouse
The keyboard and mouse connectors are physically identical and have the
same pinout. They are standard 6-pin PS/2®-type female connectors.
2
3
1
4
6
5
KY0002.VS
USB Ports
The USB ports are standard 4-pin USB connectors. One USB connector is
located at the front, and two at the rear of the system.
KY0003.VS
Ethernet Connector
The Ethernet connector at the rear of the system is used to connect to a
10Base-T/100Base-TX Ethernet network.
Ethernet
On back of system
KY0100.VSD
Identifying Components
11
Serial Port
The serial port is a standard 9-pin DB-9 male connector.
6
9
1
5
KY0057.VSD
Printer/Parallel Port
The printer/parallel port is a standard 25-pin DB-25 female connector.
13
25
14
1
KY0005.VSD
Monitor
The Monitor connector is a standard 15-pin female high-density VGAtype connector.
10
15
5
11
1
6
KY0004.VSD
12
VAIO Digital Studio Reference Manual
DVI
The DVI connector is a 24-pin DVI connector that can be attached to a
Sony XGA LCD panel (PCVA-15XD2), which uses a DVI connector cable
(sold separately).
You can physically connect both a VGA and an LCD monitor at the same
time. However, you cannot use both monitors at the same time. If you
operate only one monitor to the system, the system automatically detects
which monitor is connected. If you connect both monitors, you must
choose one monitor from the Display settings.
16
24
17
9
DVI
8
1
JD001.VSD
Game Port
The Game port is a standard 15-pin DB-15 female connector. This port is
also used to connect MIDI devices.
15
9
8
1
KY0012.VSD
13
Identifying Components
Mic, Line In, and Headphones
The Mic, Line In, and Headphones jacks are physically identical, but have
different connections. They are standard 3.5 mm stereo mini-jacks.
Headphones
Line In
Mic
KY0013.VSD
Connector
Description
Headphones
1.0 Vrms (typical).
Mic
Electret condenser microphone input.
Line In
1.0 Vrms (typical), 10 Kohm impedance.
Telephone and Line
The Telephone and Line jacks are physically identical and have identical
connections. They are standard RJ-11 female phone jacks. However, the
Line jack is for connecting to a telephone line that comes from the wall,
and the Telephone jack is for connecting the computer to a telephone.
LINE
PHONE
KY0014.VSD
✍ Accidentally plugging a phone line from the wall into the modem’s Telephone jack, and a
telephone into the Line jack, will not damage the modem card or telephone equipment.
However, the modem will not work correctly.
i.LINK® (IEEE1394) Connectors
The 6-pin i.LINK connector on the back of the system can supply power
from the computer to a device if the device also has a 6-pin i.LINK
connector. The 6-pin connector supplies 10V to 12V and a maximum
power of 6 watts.
14
VAIO Digital Studio Reference Manual
The 4-pin i.LINK connector at the bottom of the front panel does not
supply power.
6-pin i.LINK
(IEEE1394)
On back of
system
4-pin i.LINK
(IEEE1394)
At bottom of
front panel
KY0087.VSD
Expansion Slots
There are three PCI slots, two of which are available for expansion. The
other PCI slot is occupied by the fax/modem card (#1).
AGP
PCI #3
PCI #2
PCI #1
OM04577B.VSD
Chapter 2
Configuring Your System
This chapter contains information on configuring your system.
Configuring your system can consist of the following:
❑
Making changes to the BIOS settings
❑
Making changes to the display's power management settings
❑
Changing the system board jumper position
15
16
VAIO Digital Studio Reference Manual
Accessing the BIOS Setup Utility
You must access the CMOS Setup Utility to make changes to the BIOS
settings (see “CMOS Setup Options” on page 69 for information on BIOS
settings).
!
1
2
3
4
5
6
7
8
Before rebooting the system, save any open files and exit Windows®.
Reboot the system.
Press F2 after the progress bar starts.
Use the arrow keys to select an item from the main menu.
Press Enter to display the options for the selected item.
Use the arrow keys to select an option.
Press Page Up or Page Down to modify the setting.
Press ESC to return to the main menu.
Select SAVE & EXIT SETUP, then press Enter. Follow the on-screen
prompts.
Configuring Your System
17
Changing the Display's Power Management
Settings
A display that has power management capability is designed to operate
on reduced power or shut itself off after the system has been idle for a
specified period of time.
1
From the Start menu, point to Settings, click Control Panel, then click
Display.
2
Click the Screen Saver tab.
If your display is Energy-Star compliant or has other energy-saving
features, the Energy saving features of the monitor dialog box appear.
Otherwise, the options in the dialog box are grayed out.
3
Click Settings.
The Power Options Properties dialog box opens, with the Power
Schemes tab displayed.
18
4
VAIO Digital Studio Reference Manual
Select the power scheme that is most appropriate for the way you use
your computer.
To change a power scheme, change the settings for Turn off monitor,
and Turn off hard disks, System standby, and System Hibernate.
The Turn off monitor option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your monitor
turns off when your computer is running on AC power. The display
reactivates when you move the mouse or press a key.
The Turn off hard disks option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your hard disks
turn off when your computer is running on AC power.
The System standby option allows you to specify the period of
inactivity (in minutes) that you want to elapse before your computer
goes on standby when your computer is running on AC power.
Power is reactivated when you click the left mouse button or press
spacebar on the keyboard.
The System hibernate option allows you to specify the period of
inactivity (in minutes) before your computer goes in the hibernate
state. Power is reactivated when you push the power button.
5
To save a new power scheme, first modify the settings, click Save As,
type a descriptive name, and then click OK.
Configuring Your System
6
Click the Advanced tab.
7
8
Select the desired settings.
9
Select the desired settings, and then click OK.
Click the Hibernate tab.
19
Configuring the System Board
The system board contains a CMOS Clear configuration jumper, and two
sets of reserved jumper blocks (do not change).
The CMOS and Non-Volatile RAM (NVRAM) settings are only cleared if
the checksum test returns false. Access to specific setup fields is
controlled by a supervisor password or user password.
The Clear CMOS mode removes the password that is stored in CMOS. No
other parameters are cleared.
✍ The configuration jumpers should never need changing unless otherwise directed by a
technical support or service technician.
!
1
2
Before opening the system, save any open files, exit the Microsoft®
Windows® operating system, turn off the power of the computer and all
attached peripherals, and unplug the power cord.
Remove the side cover (see “Removing the Side Cover” on page 22).
Set the jumpers as directed by a service technician (also see
“Configuration Jumpers” on page 63).
Reserved (do not change)
CMOS CLR
3
2
1
= default jumper
1-2
2-3
CMOS Clear Normal Clear
3
20
Reinstall the side cover (see “Replacing the Side Cover” on page 23).
OM
Chapter 3
Removing, Installing, and
Replacing Components
This chapter describes removing, installing, and replacing major
components for upgrading, reconfiguring, and troubleshooting the
components.
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
21
22
VAIO Digital Studio Reference Manual
Removing the Side Cover
You must remove the side cover to access the system board, add-in cards,
power supply, battery, memory, and internal drives.
1
From the rear of the unit, pull the metal tab shown in the next
diagram.
2
Pull the top of the cover away from the unit about two inches, then
gently lift out the cover.
Pull out tab to
release front panel
Pull out top a few inches,
then lift out
KY0064B.VSD
Removing, Installing, and Replacing Components
23
Replacing the Side Cover
1
From the rear of the unit, align the bottom of the cover so that it slips
into the lip on the bottom of the unit.
2
Push the top of the cover up against the top of the unit until the cover
snaps into position.
KY0067.VSD
24
VAIO Digital Studio Reference Manual
Installing an Add-In Card
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
1
2
3
Remove the side cover (see “Removing the Side Cover” on page 22).
4
Insert the add-in card into the PCI slot connector. Use a gentle rocking
motion, pressing down until the card is fully seated.
Locate an available expansion slot connector.
Remove the slot cover adjacent to the selected slot connector (see
“Removing a Slot Cover” on page 35).
✍ Align the card's bracket so that the bottom of the bracket fits into the slot at the
bottom of the chassis. Assure that the top of the bracket fits snugly against the
chassis lip after the card is fully inserted.
KY0070.VSD
5
6
Replace the screw that secures the card.
7
8
Replace the side cover (see “Replacing the Side Cover” on page 23).
Attach any necessary cables to the card (see the instructions that came
with the add-in card).
Turn on the computer and follow any instructions that came with the
add-in card.
Removing, Installing, and Replacing Components
25
Removing an Add-in Card
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
1
2
Remove the side cover (see “Removing the Side Cover” on page 22).
3
4
Remove the screw that secures the add-in card to the chassis.
Disconnect any cables attached to the add-in card you want to
remove.
Remove the add-in card from the PCI slot connector and store the
card in an anti-static wrapper for future use.
KY0071.VSD
✍ Grasp the card with one hand on each end, and gently pull up as you rock the card
from side to side.
!
Hold the add-in card by its edges and do not touch any components or
connector contacts on the card. Static electricity in your body may
damage sensitive components on the card. As a precaution, touch any
exposed metal part on the metal chassis (preferably the metal part on
the power supply) before handling an add-in card to discharge any static
electricity in your body.
26
VAIO Digital Studio Reference Manual
5
If you do not replace the card or install another add-in card, install a
slot cover over the vacant slot at the rear of the chassis (see “Covering
an Open I/O Slot” on page 36).
6
Replace the side cover (see “Replacing the Side Cover” on page 23).
Removing, Installing, and Replacing Components
27
Replacing the Lithium Battery
You may need to replace the lithium battery if your computer consistently
loses the date or time settings after turning it off. The lithium battery has
a typical life of three years, after which the battery may be too weak to
power the CMOS memory.
!
When you remove the lithium battery, all values stored in the CMOS memory
(BIOS setup values and Plug and Play values) may be lost. Although the
computer can hold the charge for a short time while replacing the battery, it
is safer to assume that the settings will be lost. When the values are lost, the
BIOS values revert to their factory-default settings (see “Accessing the BIOS
Setup Utility” on page 16).
Do not handle damaged or leaking batteries.
The lithium battery may explode if mistreated. Do not disassemble it or
dispose of it in fire.
1
Reboot your computer by selecting Shut Down... from the Start
menu, and then selecting Restart the computer.
2
If the error message “Error: Check date and time settings”appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. Otherwise it is not necessary to replace
the battery at this time, and you can skip all remaining steps.
3
Compare all the BIOS options to their default settings (see “CMOS
Setup Options” on page 69). Make a list of all the BIOS options that
are different from their default values. You will refer to this list when
you restore the BIOS settings later.
4
Select Exit Discarding Changes from the main menu using the right
arrow key.
5
Press Enter, type Y when prompted to discard changes, then press
Enter to exit the BIOS Setup Utility.
6
7
Turn off the computer and unplug the power cord.
Remove the side cover (see “Removing the Side Cover” on page 22).
28
8
VAIO Digital Studio Reference Manual
If necessary, remove any add-in cards (see “Removing an Add-in
Card” on page 25) to gain access to the battery. You may also need to
disconnect some cables.
!
9
Touch any exposed metal part of chassis to discharge static electricity in
your body before handling an add-in card or other sensitive electronic
component.
Use a small flathead screwdriver or your finger to push in (not down)
against the small tab at one end of the battery holder to pop out the
battery.
Push in (not down) to
pop out battery
KY0072.VSD
10
Gently lift out the battery and dispose of it according to the
instructions that came with the new battery.
11
Insert the new battery into the battery holder, with the plus (+) side
up, and press down until the battery is secure.
✍ The Sony CR2032 battery is recommended. Using a type of battery other than a
CR2032 may present a risk of fire or explosion.
12
13
14
15
Replace any add-in cards that were removed.
Reconnect any cables that were disconnected.
Replace the side cover (see “Replacing the Side Cover” on page 23).
Reconnect the power cord and turn on the computer.
Removing, Installing, and Replacing Components
29
16
If the error message “Error: Check date and time settings.” appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. If no error message displays, the
computer’s BIOS settings were retained during the battery
replacement and you can skip the remaining steps.
17
Refer to the list you made in step 3 and restore any non-default BIOS
settings (see “CMOS Setup Options” on page 69).
18
Select Exit Saving Changes from the main menu using the right arrow
key.
19
Press Enter, type Y when prompted to discard changes, then press
Enter to exit the BIOS Setup Utility.
The computer’s BIOS settings are now restored.
30
VAIO Digital Studio Reference Manual
Installing System Memory
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
1
If necessary, remove the memory module you wish to replace (see
“Removing a Memory Module” on page 33).
2
Remove the new memory module(s) from its anti-static package.
Hold the memory module only by its edges to prevent staticelectricity damage.
3
Choose the size of the memory module and configuration as shown
in the following table. Memory modules can vary in size and speed
between sockets. The minimum memory size is 8 MB. The maximum
memory size is 512 MB. The BIOS automatically detects the type, size
and speed of the memory modules.
Memory module configurations (MB)*
DIMM1
DIMM2
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
* The PCV-RX270DS/PCV-RX280DS ships with 128 MB. SDRAM is
expandable to 512 MB.
!
Touch any exposed metal part of the chassis to discharge static electricity in
your body before handling a memory module.
✍ Use only 133 MHz memory. Supports SDRAM memory. Does not support EDO memory or
buffered DIMM memory.
4
5
6
Disconnect the power cord from the computer.
Remove the side cover (see “Removing the Side Cover” on page 22).
Remove the power supply (see “Removing the Power Supply” on
page 41).
31
Removing, Installing, and Replacing Components
7
Align the module over the appropriate socket, noting the location of
pin 1 on the module and pin 1 on the socket.
Press down
here
Handles
Pin 1 side
DIMM2
DIMM1
Memory module (DIMM)
1
Indicates pin 1
8
9
OM04586.VSD
Carefully but firmly insert the edge of the module into the socket.
Press down firmly and evenly at both corners until the module is
fully seated.
✍ When the module is fully seated, the handles on each side are straight up and
locked into the slot on each side of the module. If the handles are not totally
straight upright, continue to press down on each side of the module until the
handles lock into place.
10
Replace the power supply (see “Replacing the Power Supply” on
page 42).
11
Replace the side cover (see “Replacing the Side Cover” on page 23).
32
12
VAIO Digital Studio Reference Manual
Reconnect the power cord and turn on the computer.
Your computer automatically recognizes the extra memory and will
configure itself accordingly when you turn on the computer. No further
action is required.
33
Removing, Installing, and Replacing Components
Removing a Memory Module
You may need to remove a memory module if you change the memory
configuration or replace a bad module.
!
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
1
2
Remove the side cover (see “Removing the Side Cover” on page 22).
3
Locate the memory module you wish to remove.
Remove the power supply (see “Removing the Power Supply” on
page 41).
KY0073.VSD
✍ The memory modules are located beneath the power supply.
34
4
VAIO Digital Studio Reference Manual
Reach around each side of the power supply and push down the
handle on each side of the memory module to eject the module from
its socket.
Push out
Handles
KY0042.VSD
5
Grasp one edge of the memory module and lift out. Store the module
in a static-free bag.
!
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling the memory module.
Removing, Installing, and Replacing Components
35
Removing a Slot Cover
You remove a slot cover when you install an add-in card that occupies a
previously-empty slot.
1
2
3
4
5
6
Disconnect the power cord from the computer.
Remove the side cover (see “Removing the Side Cover” on page 22).
Locate the slot whose cover you want to remove.
Lay the system on its side.
Remove the screw from the slot cover.
Remove the loose slot cover and retain it for future use.
KY0069.VSD
36
VAIO Digital Studio Reference Manual
Covering an Open I/O Slot
Slot covers prevent air from escaping through the empty hole. If air
escapes, the components inside the computer cannot be properly cooled.
This may damage some components, especially the main processor
(which generates the most heat).
1
Slide the tip of the slot cover (removed earlier) between the chassis
and system board.
KY0076.VSD
2
Push the slot cover down until it rests firmly on the lip in the chassis.
All add-in card brackets and slot covers rest on this lip.
3
Replace the screw (removed earlier) to secure the I/O slot cover.
37
Removing, Installing, and Replacing Components
Installing a 3½” Internal Hard Disk Drive
Models that have only one hard disk drive have an available bay to hold
an additional 3½” hard disk drive. The drive you install must not require
front panel access. The hard disk drive access light blinks when either
internal drive is active.
!
1
Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
Configure the jumpers on the new drive as a slave device (see your
drive’s documentation for configuration instructions).
Power connector
Jumpers
Drive connector
KY0084.VSD
2
3
Disconnect the power cord from the computer.
Remove the side cover (see “Removing the Side Cover” on page 22).
38
4
VAIO Digital Studio Reference Manual
Disconnect the drive connector (A in diagram).
Drive connector
Power supply connector
A
B
Tab
C
Disk drive holder
KY0081.VSD
5
6
Disconnect the power connector (B in diagram).
Pull out on the tab (C) that secures the drive holder to the chassis.
39
Removing, Installing, and Replacing Components
7
Slide the drive holder up and out.
KY0082.VSD
8
Slide the new drive into the bottom part of the drive holder and align
the holes on each side of the drive holder.
KY0083.VSD
9
Secure the drive to the drive holder using screws in each of the two
holes on each side of the drive holder (screws are provided with the
new drive). Do not overtighten the screws.
10
Slide the drive holder back into the chassis so that the edge of the
holder is flush with the chassis.
40
11
VAIO Digital Studio Reference Manual
Push in on the tab (A) to securely latch the holder to the chassis.
Drive connectors
C
E
B
D
Tab
A
Disk drive holder
KY0085.VSD
12
13
14
15
16
17
Connect the inner drive cable connector (B) to the first drive.
Connect the outer drive cable connector(C) to the second drive.
Connect the first power connector (D) to the first drive.
Connect the second power connector (E) to the second drive.
Replace the side cover (see “Replacing the Side Cover” on page 23).
Reconnect the power cord to the system and then turn on your
computer.
Your computer automatically recognizes the new drive and configures
itself accordingly when you turn it on. Format and partition the new
drive following the instructions provided with the drive.
Removing, Installing, and Replacing Components
41
Removing the Power Supply
You remove the power supply when you insert a memory module (see
“Installing System Memory” on page 30).
1
Remove the screw that secures the power supply to the rear of the
chassis.
2
Pull the tab (A) that latches the power supply to the chassis.
A
KY0096.VSD
3
4
Slide the power supply up until the power supply clears the chassis.
Rotate the power supply upside down and rest it on top of the chassis
where the hard drive is located.
42
VAIO Digital Studio Reference Manual
Replacing the Power Supply
1
Rotate the power supply down and slide it into the chassis until the
tab snaps into position.
2
Replace the screw that secures the power supply to the rear of the
chassis.
Chapter 4
System Board
This chapter identifies each component on the system board and provides
a detailed description of each connector, jumper, and switch on the
system board.
Processor
Memory
CPU Fan
Keyboard, Mouse
Power Supply Fan
USB1, USB2, Ethernet
Power Supply
Serial, Printer, i.LINK
1394 Header 2
Secondary IDE
Primary IDE
Game
Mic In, Line In, Line Out
Diskette
1394 Header 3
AGP
CD-In
Video
USB23 Header
Battery
Configuration Jumpers
Aux-In
Front panel header
Slot 3 (PCI)
Slot 2 (PCI)
Slot 1 (PCI)
OM04581.VSD
43
44
VAIO Digital Studio Reference Manual
Connectors
Front Panel Header (J25)
The front panel header is a 20-pin header (1 pin is removed for the key)
that provides connections to various front panel functions. A 20-pin
connector with only 10 wires is used to interface the system board to the
front panel.
Front panel header
MSG
LED
PWR
CD LED
HD
LED
PWR
LED
RESET
KY0031.VSD
Name
Description
CD-LED
Connects to the CD/DVD drive access light on the front panel.
PWR LED
Connects to the power-on indicator light on the front panel
HD LED
Connects to the hard disk drive access light on the front panel
SLEEP
(not used)
PWR
Connects to the power-on switch on the front panel
RESET
(not used)
MSG LED
Connects to the standby indicator light on the front panel.
45
System Board
Diskette Drive Connector
Key (pin 5)
33
1
34
2
OM04701H.VSD
46
VAIO Digital Studio Reference Manual
DIMM2
DIMM1
Memory Module (DIMM) Connectors
OM04710A.VSD
Both sides of each Dual Inline Memory Module (DIMM) look very
similar. The side with pin 1 has a small "1" to the left of pin 1. Be sure to
orient a DIMM correctly in the DIMM connector (a small triangle on the
connector indicates pin 1).
Memory module (DIMM)
1
Indicates pin 1
OM04908B.VSD
System Board
47
PCI Slot Connectors
There are a total of three PCI slot connectors (slot #1 to #3). Two PCI slots
connector (#2 and #3) are available. The PCI slots support 32-bit 5V and
Universal (3.3/5V) PCI add-in cards.
Slot 3 (PCI)
Slot 2 (PCI)
Slot 1 (PCI)
A1
A49 A52
A62
B1
B49 B52
B62
OM04599B.VSD
48
VAIO Digital Studio Reference Manual
AGP Connector
There is one AGP slot connector that supports a 2x/4x AGP graphics card
and an AGP retention module.
A1
A21 A26
A66
B1
B21 B26
B66
OM04599C.VSD
49
System Board
IDE Connectors
There are two IDE (Integrated Drive Electronics) connectors on the
system board: a Primary IDE and a Secondary IDE connector.
Each IDE connector supports up to two IDE drives using a ribbon cable
with two connectors.
40
39
2
1
OM04701G.VSD
Power Connector
The power supply connector on the system board connects to the power
supply connector labelled P1.
10
20
1
11
OM04701I.VSD
50
VAIO Digital Studio Reference Manual
Keyboard and Mouse Connectors
The keyboard connector and the mouse connector are 6-pin female
PS/2-type (mini-DIN) connectors. They have identical pinouts.
Mouse
1
6
1
6
Keyboard
KY0032.VSD
Keyboard and Mouse connectors
Pin
Signal Name
1
DATA
2
NC
3
LOGIC GND
4
+5V (fused)
5
CLOCK
6
NC
51
System Board
USB Connectors
There are two USB ports at the rear panel, and one USB port at the front
panel. Each permits connection of USB peripheral devices directly to the
system without having to use an external hub.
USB1 and USB2 are standard USB connectors accessible from the rear
panel. USB23 Header is a 12-pin header that connects to a standard USB
connector (USB1) accessible at the bottom of the front panel. An internal
cable connects USB23 Header to an interface board behind the front
panel.
If more USB devices are needed, connect an external hub to any USB
connector.
USB1
USB2
USB23 header
12
11
10
9
8
7
6
5
4
3
2
1
KY0033.VSD
52
VAIO Digital Studio Reference Manual
USB23 Header (connects to USB1 on front panel)
Pin
Signal Name
1
+3V
2
NP1 (NC)
3
NP3
4
Key (no mount)
5
USBVCC2
6
USBVCC3 (NC)
7
USBP2#
8
USBP3# (NC)
9
USBP2
10
USBP3 (NC)
11
GND
12
GND (NC)
USB1, USB2 connectors
Pin
Signal Name
1
USBVCC1*
2
USBP0#
3
USBP0
4
Ground
5
USBVCC2*
6
USBP1#
7
USBP1
8
Ground
* Uses over-current protector.
System Board
53
Ethernet Connector
There is one Ethernet connector at the rear panel, which permits
connection to a 10Base-T/100Base-TX Ethernet network.
Ethernet
KY0103.VSD
Ethernet connector
Pin
Signal Name
1
Tx+
2
Tx-
3
Rx+
4
N/C
5
N/C
6
Rx-
7
N/C
8
N/C
54
VAIO Digital Studio Reference Manual
Serial 1, Printer, and i.LINK Connectors
The Serial, Printer, and i.LINK connectors are mounted in a single bracket
on the system board. The Serial 1 connector is a DB-9 male connector. The
Printer connector is a DB-25 female connector. The i.LINK connector is a
6-pin standard IEEE1394 connector.
13
1
25
PRINTER
1
14
5
6
9
SERIAL 1
i.LINK
OM04701D.VSD
Serial 1 connector
Pin
Signal Name
1
DCD
2
RXD
3
TXD
4
DTR
5
LOGIC GND
6
DSR
7
RTS
8
CTS
9
RI
System Board
Printer connector
Pin
Signal Name
1
STROBE -
2
DATA BIT 0
3
DATA BIT 1
4
DATA BIT 2
5
DATA BIT 3
6
DATA BIT 4
7
DATA BIT 5
8
DATA BIT 6
9
DATA BIT 7
10
ACK -
11
BUSY
12
PE
13
SELECT
14
AUTO-FEED -
15
ERROR -
16
INIT -
17
SELECT-IN -
18
LOGIC GND
19
LOGIC GND
20
LOGIC GND
21
LOGIC GND
22
LOGIC GND
23
LOGIC GND
24
LOGIC GND
25
LOGIC GND
55
56
VAIO Digital Studio Reference Manual
i.LINK connector
Pin
Signal Name
1
Ground VP (Power)*
2
Ground
3
TPB*
4
TPB
5
TPA*
6
Ground TPA
* Uses over-current protector.
Fan Connectors
The CPU-FAN and PWR-FAN connectors are 1 x 3-pin straight header
connectors. CPU-FAN controls the cooling fan on the CPU. PWR-FAN
controls the cooling fan in the power supply.
CPU-FAN
3
1
PWR FAN
3
1
KY0034.VSD
CPU-FAN and PWR-FAN connectors
Pin
Signal Name
1
Ground
2
FAN_CTRL (+12V)
3
FAN_SEN
57
System Board
Game Connector
The Game connector is a female DB-15 connector for connecting to a
game controller/joystick or MIDI device.
Game
KY0056.VSD
Game connector
Pin
Signal Name
1
GAMEVCC
2
JPYB0
3
JOYA0
4
GND
5
GND
6
JOYA1
7
JOYA2
8
GAMEVCC
9
GAMEVCC
10
JOYB2
11
JOYA2
12
MIDI_TxD
13
JOYA3
14
JOYB3
15
MIDI_RxD
58
VAIO Digital Studio Reference Manual
Headphones, Line In, Mic Connectors
The Headphones jack is a stereo mini-jack (3.5 mm) that connects to
headphones. The Line In jack is a stereo mini-jack (3.5 mm) that connects
to a stereo audio source (not an audio source from a video device). The
Mic In jack is a stereo mini-jack (3.5 mm) that connects to a microphone.
Headphones
Line In
Mic
KY0058.VSD
Headphones
Audio Right Out
Audio Left Out
OM04713.VSD
Line In
Audio Right In
L Imbalance
Audio Left In
OM04713B.VSD
Mic
Electret Bias Voltage
Mic Imbalance
Mic Mono In
OM04713A.VSD
System Board
59
i.LINK Header Connectors
The system board has two i.LINK header connectors: 1394HEAD2 and
1394HEAD3.
A cable connects the 8-pin header connector (1394HEAD3) to an interface
unit mounted behind the front of the chassis. The interface unit connects
to the 4-pin i.LINK (IEEE1394) connector at the bottom of the front panel.
The other 8-pin header connector (1394HEAD2) is not used.
1394HEAD2
8
1394HEAD3
8
1
1
KY0099.VSD
i.LINK Header connectors (1394HEAD2 and 1394HEAD3)
Pin
Signal Name
1
Shell Ground
2
Ground
3
TPA
4
TPB*
5
TPB
6
GroundTPB*
7
Ground
8
VP (Power)*
* Uses over-current protection.
60
VAIO Digital Studio Reference Manual
CD-IN Connector
The CD-IN connector on the system board is a 1 x 4-pin header connector
that connects to the DVD-ROM drive’s audio output connector.
CD-IN
4
1
KY0062.VSD
CD-IN connector
Pin
Signal Name
1
Left Line In
2
Ground
3
Ground
4
Right Line In
61
System Board
AUX-IN Connector
The AUX-IN connector on the system board is a 1 x 4-pin 2mm inline
header connector that connects to the CD-RW drive’s audio output
connector.
AUX-IN
4
1
KY0062B.VSD
AUX-IN connector
Pin
Signal Name
1
Left Line In
2
Ground
3
Ground
4
Right Line In
VIDEO Connector
The VIDEO connector on the system board is a 1 x 4-pin 2mm inline
header connector. It is not used.
VIDEO
4
1
KY0105.VSD
VIDEO connector
Pin
Signal Name
1
Video L
2
Ground
3
Ground
4
Video R
62
System Board
63
Configuration Jumpers
There is one user-configurable jumper for CMOS Clear. The other two
jumpers are reserved (do not change).
The computer ships with CMOS Clear in the Normal position. Do not
change the position of this jumper unless directed by a technical support
person.
Reserved (do not change)
CMOS CLR
3
2
1
= default jumper
1-2
2-3
CMOS Clear Normal Clear
OM04588.VSD
64
VAIO Digital Studio Reference Manual
Chapter 5
Fax/Modem Card
The fax/modem card occupies PCI slot #1. There are two RJ-11 jacks: one
to connect a telephone line, and one to connect a phone.
Telephone
Line
KY0038.VSD
Connectors
Name
Connector Type
Description
Telephone
RJ-11
Connects to phone
Line
RJ-11
Connects to telephone line
65
66
Chapter 6
Video Card
The video card occupies the AGP slot. The video card has two connectors:
a standard VGA-style connector, and a DVI connector.
The VGA-style connector is a standard 15-pin high-density VGA-style
connector on the rear bracket.
The DVI connector is a 24-pin DVI connector that can be attached to a
Sony XGA LCD panel (PCVA-15XD2), which uses a DVI connector cable
(sold separately). The DVI connector can also be connected to any other
DVI-equipped LCD/VGA monitor.
You can physically connect both a VGA and an LCD monitor at the same
time. However, you cannot use both monitors at the same time. If you
operate only one monitor to the system, the system automatically detects
which monitor is connected. If you connect both monitors, you must
choose one monitor from the Display settings.
The video card in the PCV-RX270DS has 16 Mbytes of SDRAM and has a
64-bit wide bus. The video card in the PCV-RX280DS has 32 Mbytes of
SDRAM and has a 128-bit wide bus.
DVI LCD
Monitor
VGA
Monitor
KY0104.V
67
DVI Connector
Pin
Signal
1
TMDS data2-
2
TMDS data2+
3
TMDS data2/4 shield
4
TMDA data4-
5
TMDA data4+
6
DDC clock
7
DDC data
8
NC
9
TMDS data1-
10
TMDS data1+
11
TMDS data1/3 shield
12
TMDS data3-
13
TMDS data3+
14
+5V
15
Ground for +5V
16
Hot-plug detect
17
TMDS data0-
18
TMDS data0+
19
TMDS data0/5 shield
20
TMDS data5-
21
TMDS data5+
22
TMDS clock shield
23
TMDS clock+
24
TMDS clock-
68
Chapter 7
CMOS Setup Options
This chapter describes each screen in the Award BIOS Setup Utility (see
“Accessing the BIOS Setup Utility” on page 16).
The Award BIOS setup has five menu items on the menu bar. These are:
❑
Main
❑
Advanced
❑
Power
❑
Boot
❑
Exit
Options that you can change are enclosed in brackets. Text that is not
enclosed in brackets cannot be changed.
A small triangle ( ) indicates that there is a sub-menu with additional
information and options. Press Enter to display the sub-menu. The
information and options in a sub-menu are context-sensitive (they appear
or disappear, depending on which options you select).
The item shown in [brackets] in this guide is the default option. The
option shown in [brackets] on the screen is the option currently set for
your system.
The other available options for each item are shown without brackets
directly below the default option in this guide. The available options are
listed in the order they occur when you press the + key.
Use the left and right arrow keys to choose a menu item. Use the up and
down arrow keys to select an option. Press Enter to display a list of
options, or press the + or - key to cycle through the other options.
If you display the list of options, use the up and down arrow keys to
select an option in the list, then press Enter to choose the selection.
Press Esc to go back to the main menu.
69
70
VAIO Digital Studio Reference Manual
Press F10 to save the changes and exit, or press Esc to discard the
changes.
Follow the on-screen prompts for other choices. The bottom of the screen
presents a summary of the keys to use for navigation and control.
CMOS Setup Options
Main Screen
System Time
[00:00:00]
System Date
[01/01/2000]
Legacy Diskette A
[1.44M, 3.5 in.]
2.88M, 3.5 in.
None
360K, 5.25 in.
1.2M, 5.25 in.
720K, 3.5 in.
Legacy Diskette B
[None]
360K, 5.25 in.
1.2M, 5.25 in.
720K, 3.5 in.
1.44M, 3.5 in.
2.88M, 3.5 in.
Floppy 3 Mode Support
[Disabled]
Drive A
Drive B
Both
Primary Master (see “IDE Sub-Menus” on page 72)
Primary Slave (see “IDE Sub-Menus” on page 72)
Secondary Master (see “IDE Sub-Menus” on page 72)
Secondary Slave (see “IDE Sub-Menus” on page 72)
Keyboard Features (see “Keyboard Features Sub-Menus” on page 73)
Supervisor Password
[Disabled]
User Password
[Disabled]
Halt On
[All but Keyboard]
All but Disk
All but Disk/Keyboard
All Errors
No Error
Installed Memory
128 MB
BIOS Revision
1002
71
72
VAIO Digital Studio Reference Manual
IDE Sub-Menus
Type
[Auto]
User Type HDD
CD-ROM
LS-120
ZIP-100
MO
Other ATAPI
None
Translation Method*
[LBA]
Large
Normal
Match Partition Table
Manual
Cylinders†
[ 1024]
Heads†
[255]
Sectors
‡
[63]
CHS Capacity*
8422MB
Maximum LBA Capacity*
30735MB (depends on model)
Multi-Sector Transfers*
[Maximum]
Disabled
2 Sectors
4 Sectors
8 Sectors
16 Sectors
32 Sectors
SMART Monitoring*
[Disabled]
Enabled
PIO Mode**
[4]
ULTRA DMA
Mode†
Set Device As††
[4]
[Auto]
Floppy
Hard Disk
* This option appears when Type is set to User Type HDD.
† This option appears when Type is set to Auto or User Type HDD.
‡ This option appears when Type is set to Auto or User Type HDD.
** This option appears when Type is not set to None.
†† This option appears when Type is set to ZIP-100 or MO.
CMOS Setup Options
Keyboard Features Sub-Menus
Boot Up Numlock Status
[On]
Off
Keyboard Auto-Repeat Rate
[12/sec]
6/sec
8/sec
10/sec
15/sec
20/sec
24/sec
30/sec
Keyboard Auto-Repeat Delay
[1/4 sec]
1/2 sec
3/4 sec
1 sec
73
74
VAIO Digital Studio Reference Manual
Advanced Screen
CPU Core:Bus Freq. Multiplier
[5.5x]
6.0x
6.5x
7.0x
7.5x
8.0x
2.0x
2.5x
3.0x
3.5x
4.0x
4.5x
5.0x
CPU Level 1 Cache
[Enabled]
Disabled
CPU Level 2 Cache
[Enabled]
Disabled
CPU Level 2 Cache ECC Check
[Disabled]
Enabled
Processor Serial Number
[Disabled]
Enabled
BIOS Update
[Enabled]
Disabled
PS/2 Mouse Function Control
[Auto]
Enabled
USB Legacy Support
[Auto]
Disabled
Enabled
OS/2 Onboard Memory > 64M
[Disabled]
Enabled
Chip Configuration (see “Chip Configuration Sub-Menu” on page 75)
I/O Device Configuration (see “I/O Device Configuration Sub-Menu” on page 76)
PCI Configuration (see “PCI Configuration Sub-Menu” on page 77)
Shadow Configuration (see “Shadow Configuration Sub-Menu” on page 79)
CMOS Setup Options
Chip Configuration Sub-Menu
SDRAM Configuration
[By SPD]
User Define
SDRAM CAS Latency*
[3T]
SDRAM RAS to CAS Delay*
[3T]
SDRAM RAS Precharge Time*
[3T]
SDRAM Cycle Time (Tras, Trc)
[6T, 8T]
5T, 7T
SDRAM Page Closing Policy
[All Banks]
One Bank
CPU Latency Timer
[Enabled]
Disabled
CPC
[Enabled]
Disabled
Graphics Window Size
[64MB]
32MB
Video Memory Cache Mode
[UC]
USWC
AGP 4X Support
[Enabled]
Disabled
Memory Hole At 15M-16M
[Disabled]
Enabled
PCI 2.1 Support
[Enabled]
Disabled
High Priority PCI Mode
[Enabled]
Disabled
Onboard PCI IDE Enable
[Both]
Primary
Secondary
Disabled
* Enabled only when Configuration is set to User Define.
75
76
VAIO Digital Studio Reference Manual
I/O Device Configuration Sub-Menu
Onboard AC97 Audio Controller [Enabled]
Disabled
Onboard 1394 Controller
[Enabled]
Disabled
Onboard Lan Controller
[Enabled]
Disabled
Onboard FDC Swap A & B
[No Swap]
Swap AB
Floppy Disk Access Control
[R/W]
Read Only
Onboard Serial Port 1
[3F8H/IRQ4]
2F8H/IRQ3
3E8H/IRQ4
2E8H/IRQ10
Disabled
Onboard Parallel Port
[378H/IRQ7]
278H/IRQ5
Disabled
3BCH/IRQ7
Parallel Port Mode
[Normal]
EPP
ECP
ECP+EPP
Onboard Game Port
[200H-207H]
208H-20FH
Disabled
Onboard MIDI I/O
[330H-331H]
300H-301H
Disabled
Onboard MIDI IRQ
[10]
3
4
5
6
7
9
11
12
14
15
CMOS Setup Options
PCI Configuration Sub-Menu
Slot 1 IRQ
to
Slot 3 IRQ
[Auto]
NA
3
4
5
7
9
10
11
12
14
15
PCI/VGA Palette Snoop
[Disabled]
Enabled
PCI Latency Timer
[32]
SYMBIOS SCSI BIOS
[Auto]
Disabled
USB Function
[Enabled]
Disabled
VGA BIOS Sequence
[PCI/AGP]
AGP/PCI
Onboard LAN Boot ROM
[Disabled]
Enabled
77
78
VAIO Digital Studio Reference Manual
PCI/PNP IRQ Resource Exclusion Sub-Menu
IRQ 3 Reserved
[No/ICU]
Yes
IRQ 4 Reserved
[No/ICU]
Yes
IRQ 5 Reserved
[Yes]
No/ICU
IRQ 7 Reserved
[No/ICU]
Yes
IRQ 9 Reserved
[No/ICU]
Yes
IRQ 10 Reserved
[No/ICU]
Yes
IRQ 11 Reserved
[No/ICU]
Yes
IRQ 12 Reserved
[No/ICU]
Yes
IRQ 14 Reserved
[No/ICU]
Yes
IRQ 15 Reserved
[No/ICU]
Yes
PCI/PNP DMA Resource Exclusion Sub-Menu
DMA 1 Used By ISA
[No/ICU]
Yes
DMA 3 Used By ISA
[No/ICU]
Yes
DMA 5 Used By ISA
[No/ICU]
Yes
PCI/PNP UMB Resource Exclusion Sub-Menu
ISA/MEM Block BASE
[No/ICU]
C800
CC00
D000
D400
D800
DC00
CMOS Setup Options
Shadow Configuration Sub-Menu
Video ROM BIOS Shadow
[Enabled]
Disabled
C8000-CBFFF Shadow
[Disabled]
Enabled
CC000-CFFFF Shadow
[Disabled]
Enabled
D0000-D3FFF Shadow
[Disabled]
Enabled
D4000-D7FFF Shadow
[Disabled]
Enabled
D8000-DBFFF Shadow
[Disabled]
Enabled
DC000-DFFFF Shadow
[Disabled]
Enabled
79
80
VAIO Digital Studio Reference Manual
Power Screen
Power Management
[User Define]
Disabled
Min Saving
Max Saving
Video Off Option
[Suspend -> Off]
Always On
Video Method
[DPMS OFF]
DPMS Reduce ON
Blank Screen
V/H SYNC+Blank
DPMS Standby
DPMS Suspend
HDD Power Down
[Disabled]
1 Min
2 Min
3 Min
4 Min
5 Min
6 Min
7 Min
8 Min
9 Min
10 Min
11 Min
12 Min
13 Min
14 Min
15 Min
ACPI Mode
[S3]
S1
Suspend Mode
[Disabled]
1~2 Min
2~3 Min
4~5 Min
8~9 Min
20 Min
30 Min
40 Min
1 Hour
PWR Button < 4 Secs
[Suspend]
Soft Off
Power Up Control (see “Power Up Control Sub-Menu” on page 81)
Hardware Monitor (see “Hardware Monitor Sub-Menu” on page 81)
CMOS Setup Options
Power Up Control Sub-Menu
AC PWR Loss Restart
[Disabled]
Enabled
PWR Up On Modem Act
[Disabled]
Enabled
Wake On LAN
[Disabled]
Enabled
Hardware Monitor Sub-Menu
MB Temperature
[(displays actual temperature)]
Ignore
CPU Temperature
[(displays actual temperature)]
Ignore
CPU Fan Speed
[Ignore]
(displays actual RPM)
Power Fan Speed
[(displays actual RPM)]
Ignore
VCORE Voltage
[(displays actual voltage)]
Ignore
+3.3V Voltage
[(displays actual voltage)]
Ignore
+5V Voltage
[(displays actual voltage)]
Ignore
+12V Voltage
[(displays actual voltage)]
Ignore
-12V Voltage
[(displays actual voltage)]
Ignore
-5V Voltage
[(displays actual voltage)]
Ignore
81
82
VAIO Digital Studio Reference Manual
Boot Screen
1. ATAPI CD-ROM
[(displays installed drive)]
Disabled
2. Removable Device
[Legacy Floppy]
LS120
ZIP-100
ATAPI MO
Disabled
3. IDE Hard Drive
[(displays installed drive)]
Disabled
4. Other Boot Device
[Disabled]
Network
SCSI Boot Device
Plug & Play O/S
[No]
Yes
Boot Virus Detection
[Enabled]
Disabled
Quick Power On Self Test
[Enabled]
Disabled
Boot Up Floppy Seek
[Disabled]
Enabled
Silent Boot
[Enabled]
Disabled
CMOS Setup Options
Exit Screen
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
83
84
VAIO Digital Studio Reference Manual
Chapter 8
Miscellaneous Technical
Information
This chapter contains information on the following subjects:
❑
User and Supervisor password
❑
Beep code error messages
❑
PCI configuration status and error messages
❑
DMA channel assignments
❑
IRQ assignments
❑
System I/O address map
❑
Memory map
❑
PCI configuration space map
85
86
VAIO Digital Studio Reference Manual
About User and Supervisor Passwords
The system allows you to specify up to two passwords (a User password
and a Supervisor password) in the CMOS Setup Utility. The User
password is required; the Supervisor password is optional.
Access to the CMOS Setup Utility depends on which passwords were
previously set, as indicated next.
If you set these passwords...
...the following passwords are required:
User password only
User password is required at bootup.
Supervisor password only
No password is required at bootup.
Supervisor password is required by most
setup options.
Both passwords
User password is required at bootup.
Supervisor password is required by most
setup options.
Miscellaneous Technical Information
87
Beep Code Error Messages
During a normal bootup, a single short beep signifies that the system is
OK. Other beep patterns signify errors. The number of beeps indicates the
specific error that occurred.
The Sony Online Support technical representative will need to know how
many beeps your system produces if there is an error, so be sure to count
the number of beeps before calling for support.
88
VAIO Digital Studio Reference Manual
PCI Configuration Status and Error Messages
The following is a list of status and error messages that may appear on
your system from time to time.
Message
Meaning
Floppy Disk Controller
Resource Conflict
The diskette controller has requested a
resource that is already in use.
NVRAM Checksum Error,
NVRAM Cleared
The NVRAM data was reinitialized due to
an NVRAM checksum error.
NVRAM Cleared By Jumper
The Clear CMOS jumper block has been
changed to the clear position.
NVRAM Data Invalid,
NVRAM Cleared
Invalid entry in the NVRAM.
Parallel Port Resource Conflict
The parallel port has requested a resource
that is already in use.
PCI Error Log is Full
This message is displayed when more than
15 PCI conflict errors are detected. No
additional PCI errors can be logged.
PCI I/O Port Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI IRQ Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI Memory Conflict
Two devices requested the same resource,
resulting in a conflict.
Primary Boot Device Not
Found
The designated primary boot device (hard
disk drive, diskette drive, CD-ROM drive,
or network drive) could not be found.
Primary IDE Controller
Resource Conflict
The primary IDE controller has requested a
resource that is already in use.
Primary Input Device Not
Found
The designated primary input device
(keyboard, mouse, or other, if input is
redirected) could not be found.
Primary Output Device Not
Found
The designated primary output device
(display, serial port, or other, if input is
redirected) could not be found.
Secondary IDE Controller
Resource Conflict
The secondary IDE controller has requested
a resource that is already in use.
Serial Port 1 Resource Conflict
Serial port 1 has requested a resource that is
already in use.
Miscellaneous Technical Information
Static Device Resource Conflict
A non-Plug and Play ISA card has
requested a resource that is already in use.
System Board Device Resource
Conflict
A non-Plug and-Play ISA card has
requested a resource that is already in use.
89
90
VAIO Digital Studio Reference Manual
DMA Channel Assignments
This shows the factory default values. Windows reassigns resources to
best meet the needs of a particular configuration.
DMA
Channel
Default
Assignment
02
Standard floppy disk controller.
04
Direct memory access (DMA) controller.
Miscellaneous Technical Information
System I/O Address Map
Address Range
(hex)
Description
0000h - 000Fh
Direct memory access controller.
0010h - 001Fh
Motherboard resources.
0020h - 0021h
Programmable interrupt controller.
0022h - 002Dh
Motherboard resources.
002Eh - 002Fh
Motherboard resources.
0030h - 003Fh
Motherboard resources.
0040h - 0043h
System timer.
0044h - 005Fh
Motherboard resources.
0060h - 0060h
Standard 101/102-Key or Microsoft Natural Keyboard.
0061h - 0061h
System speaker.
0062h - 0063h
Motherboard resources.
0064h - 0064h
Standard 101/102-Key or Microsoft Natural Keyboard.
0065h - 006Fh
Motherboard resources.
0070h - 0073h
System CMOS/real time clock.
0074h - 007Fh
Motherboard resources.
0080h - 0090h
Direct memory access controller.
0091h - 0093h
Motherboard resources.
0094h - 009Fh
Direct memory access controller.
00A0h - 00A1h
Programmable interrupt controller.
00A2h - 00BFh
Motherboard resources.
00C0h - 00DFh
Direct memory access controller.
00E0h - 00EFh
Motherboard resources.
00F0h - 00FFh
Numeric data processor.
0170h - 0177h
Secondary IDE controller (dual FIFO).
0170h - 0177h
Intel 82801AA bus master IDE controller.
01F0h - 01F7h
Intel 82801AA bus master IDE controller.
01F0h - 01F7h
Primary IDE controller (dual FIFO).
0200h - 0207h
Gameport joystick.
0290h - 0297h
Motherboard resources.
0330h - 0331h
MPU-401-compatible MIDI device.
0376h - 0376h
Secondary IDE controller (dual FIFO).
0376h - 0376h
Intel 82801AA bus master IDE controller.
91
92
VAIO Digital Studio Reference Manual
Address Range
(hex)
Description
0378h - 037Fh
Printer port (LPT1).
03B0h - 03BBh
NVIDIA GeForce2 MX (Sony).
03C0h - 03DFh
NVIDIA GeForce2 MX (Sony).
03F0h - 03F1h
Motherboard resources.
03F2h - 03F5h
Standard floppy disk controller.
03F6h - 03F6h
Intel 82801AA bus master IDE controller.
03F6h - 03F6h
Primary IDE controller (dual FIFO).
03F7h - 03F7h
Standard floppy disk controller.
03F8h - 03FFh
Communications port (COM1).
04D0h - 04D1h
Motherboard resources.
0CF8h - 0CFFh
PCI bus.
B400h - B41Fh
Intel® 82801AA USB universal host controller.
B800h - B807h
Primary IDE controller (dual FIFO).
B800h - B80Fh
Intel 82801AA bus master IDE controller.
B808h - B80Fh
Secondary IDE controller (dual FIFO).
C000h - DFFFh
Intel 82801AA PCI bridge.
D400h - D4FFh
WDM communication device.
D800h - D807h
WDM communication device.
E000h - E0FFh
YAMAHA AC-XG audio device.
E100h - E13Fh
YAMAHA AC-XG audio device.
E400h - E47Fh
Motherboard resources.
E800h - E80Fh
Intel 82801AA SM bus controller.
EC00h - EC3Fh
Motherboard resources.
Miscellaneous Technical Information
93
Memory Map
✍ I/O addresses that may be used by add-in cards are not listed.
Address range
Default configuration
00000000h-0009FFFFh
System board extension for ACPI BIOS.
000A0000h-000AFFFFh
NVIDIA GeForce2 MX (Sony).
000B0000h-000BFFFFh
NVIDIA GeForce2 MX (Sony).
000C0000h-000CB7FFh
NVIDIA GeForce2 MX (Sony).
000F0000h-000FFFFFh
System board extension for ACPI BIOS.
00100000h-07FFFFFFh
System board extension for ACPI BIOS.
D4000000h-D4003FFFh
Sony OHCI i.LINK(IEEE 1394) PCI host controller.
D4000000h-D5FFFFFFh
Intel 82801AA PCI bridge.
D4800000h-D48007FFh
Sony OHCI i.LINK(IEEE 1394) PCI host controller.
D5800000h-D58000FFh
WDM communication device.
D6000000h-D7EFFFFFh
Intel® 82815 processor-to-AGP controller - 1131
D6000000h-D6FFFFFFh
NVIDIA GeForce2 MX (Sony).
D7000000h-D700FFFFh
NVIDIA GeForce2 MX (Sony).
D7F00000h-E3FFFFFFh
Intel® 82815 processor-to-AGP controller - 1131.
D8000000h-DFFFFFFFh
NVIDIA GeForce2 MX (Sony).
E4000000h-E7FFFFFFh
Intel® 82815 processor-to-AGP controller - 1130.
FFB80000h-FFBFFFFFh
System board extension for ACPI BIOS.
FFF80000h-FFFFFFFFh
System board extension for ACPI BIOS.
IRQ Summary
IRQ
Description
00
System timer.
01
Standard 101/102-Key or Microsoft Natural Keyboard.
02
Programmable interrupt controller.
03
YAMAHA AC-XG audio device.
03
Intel 82801AA SM bus controller.
03
ACPI IRQ holder for PCI IRQ steering.
04
Communications port (COM1).
06
Standard floppy disk controller.
07
Printer port (LPT1).
08
System CMOS/real time clock.
09
SCI IRQ used by ACPI bus.
09
Intel® 82801AA USB universal host controller.
09
Sony OHCI i.LINK(IEEE 1394) PCI host controller.
09
WDM communication device.
09
ACPI IRQ holder for PCI IRQ steering.
09
ACPI IRQ holder for PCI IRQ steering.
10
MPU-401-compatible MIDI device.
11
NVIDIA GeForce2 MX (Sony).
11
ACPI IRQ holder for PCI IRQ steering.
12
PS/2-compatible mouse port.
13
Numeric data processor.
14
Primary IDE controller (dual FIFO).
14
Intel 82801AA bus master IDE controller.
15
Secondary IDE controller (dual FIFO).
15
Intel 82801AA bus master IDE controller.
94
Chapter 9
Specifications
This chapter describes the technical specifications for the Sony
PCV-RX270DS/PCV-RX280DS computers.
Processors
PCV-RX270DS: 866 MHz Intel Pentium® III processor
PCV-RX280DS: 1 GHz Intel Pentium® III processor
Chipset
Intel 815 chipset
AGP Bus
AGP interface specification, version 2.0 (supports 2x/4x)
1 AGP slot
PCI Bus
PCI Level 2.2, 33 MHz zero wait state
3 PCI slots (2 open)
Memory Modules (DIMMs)
Installed memory
128 Mbytes PC-133 SDRAM (133 MHz)
Maximum memory
512 Mbytes (256 Mbytes in each socket)
Voltage
3.3 V memory only
Pins
168-pins with gold-plated contacts
SDRAM type
PC-133, 60 ns, unrestricted CAS latency 3, unbuffered,
Intel 4-clock, 64 bits (non-ECC)
95
96
VAIO Digital Studio Reference Manual
DIMM Configurations
DIMM1*
DIMM2*
0, 8, 16, 32, 64, 128, 256
0, 8, 16, 32, 64, 128, 256
* The PCV-RX270DS/PCV-RX280DS is shipped with 128 MB. SDRAM is expandable to 512 MB. Computer
SDRAM is unbuffered DIMM, specification Rev. 1.0 or later. Supports SDRAM memory. Does not support
EDO memory or buffered DIMM memory. Memory can be installed in either socket. Memory size can vary
between sockets. DIMMs can be single- or double-sided. DIMMs must be 133 MHz SDRAM module. Use
only 133 MHz memory—do not use 66 MHz or 100 MHz memory.
L2 Cache
Installed
256 kbytes of Advanced Transfer cache
Graphics
AGP Controller*
NVIDIA GeForce2 MX
Video memory
PCV-RX270DS: 16 Mbytes SDRAM @ 166 MHz
PCV-RX280DS: 32 Mbytes SDRAM @ 166 MHz
Resolution (displayed resolution depends on the graphics display you use)
True color (32 bits) Up to 1600 x 1200 at 85 Hz non-interlaced
High color (16 bits) Up to 1600 x 1200 at 100 Hz non-interlaced
256 colors (8 bits)
Up to 1600 x 1200 at 100 Hz non-interlaced
* Supports DDC-1 and DDC-2b standards for Plug and Play displays.
Audio
Sound chip
Yamaha AC-XG audio
Wave synthesis
Software synthesis
Sound effects
DirectX
Audio sampling rate
Up to 48 kHz at 16 bits
Rear panel connectors
Mic (for microphone)
Line In (from stereo audio source)
Headphones (for stereo headphone)
Specifications
97
Communications
Modem
Lucent 1648 technology V.90-compatible data/fax
modem (REN 0.7)*
Fax
14.4 kbps maximum
i.LINK (IEEE1394)
400 Mbps, OHCI chip set
* Your modem is capable of downloading at 56 Kbps using K56flex™ technology/V.90. Your phone service,
online service, or Internet Service Provider may not support this technology or operate at this speed.
I/O and Expansion Slots
Serial port
One high-speed NS16C550-compatible port
Parallel port
One high-speed bi-directional Centronicscompatible port with ECP and EPP modes
MIDI/game port
One (supports MIDI in/out or two joysticks —
adapter cable not supplied)
Modem ports
Two RJ-11 connectors (for line and phone)
USB ports
USB1 (front panel) and USB1 and USB2 (rear panel)
PCI slots
Two available slots. Maximum length for add-in
cards is 9.05 inches
IDE connectors
Primary and secondary (each supports two IDE
drives)
Drives and Controllers
Diskette controller
82077-compatible (supports up to 2.88 MByte)
Diskette drive
1.44 MByte 3.5-inch MFDD
EIDE controller
Supports up to four EIDE drives (supports PIO Mode 4
EIDE drives and Ultra DMA/66 Mode drives)
IDE hard drive*
PCV-RX270DS: 40 GByte
PCV-RX280DS: 60 GByte
DVD-ROM drive†
DVD-ROM read: 16X (maximum performance).
CD-ROM read: 40X (maximum performance).
CD-RW drive‡
CD-RW read: 20X (maximum performance).
CD-RW write: 4X (maximum perfornance).
CD-R read: 32X (maximum performance).
CD-R write: 8X (maximum performance).
CD-ROM read: 32X (maximum performance).
Expansion bays
One 3.5 inch hard disk drive bay.
* Bus-mastering EIDE driver installed.
98
VAIO Digital Studio Reference Manual
† Data on a DVD-ROM is read at a variable transfer rate, ranging from 6.6X at the innermost track to 16X at
the outermost track (the data transfer standard 1X rate is 1385 kbytes/s). The average data transfer rate is
11.3X (15,255 kbytes/s). Data on a CD-ROM is read at a variable transfer rate, ranging from 17.2X at the
innermost track to 40X at the outermost track (the data transfer standard 1X rate is 150 kbytes/s). The
average data transfer rate is 28.6X (4293 kbytes/s).
‡ CD-RW writing speed may vary, depending on the media. The maximum writing speed of the CD-R is 8X
(1X = 150 kbytes/s) and 4x for the CD-RW. The maximum reading speed of the CD-ROM is 32X, and 20X
for the CD-RW.
System BIOS
Make and model
Award-based
ROM
2Mbit flash-ROM*
Passwords
User and supervisor passwords supported
Power management
APM 1.2
Advanced features
ACPI-1.0 compliant hardware for use with APM and
PNP BIOS APIs
Plug and Play devices
Supported with steerable DMA channels and
interrupts
Special features
PC-99 compliant, multi-boot, PCI add-in card autoconfigure
* Flash-ROM update utility is available from Sony’s web site at http://www.sony.com/pcsupport.
Index
A
add-in card
installing 24
removing 25
address map, system 91
AGP slot connector 48
audio specifications 96
AUX-IN connector 61
B
battery - See lithium battery
beep codes 87
BIOS Setup Utility
See CMOS Setup Utility
BIOS setup utility
advanced screen 74
boot screen 82
exit screen 83
main screen 71
options 69
power screen 80
screens 69
BIOS specifications 98
C
card
modem 65, 67
CD-IN connector 60
CD-RW drive
location of 3
performance of discs 3, 97
specifications 97
CMOS - See Also BIOS
CMOS Setup Utility 16
codes, beeps 87
COM1 port - See Serial
communications, specifications 97
computer
lithium ion battery vii
computer safety information ii
configuration switch
password clear 63
configuration switches
CPU frequency multiplier 63
configuring
power management 17
system board 20
connectors
4-pin on modem card 65
AUX-IN 61
CD-IN 60
fan 56
game 57
headphones, line in, mic 58
i.LINK 6, 54, 59
IDE 49
keyboard 50
line 65
modem card 65
monitor 11
mouse 50
power 49
printer 54
telephone 65
USB 6, 51, 53
cover 23
removing 22
cover, slot 35
covering I/O slot 36
CPU - See processor
99
100
VAIO Digital Studio Reference Manual
D
H
DIMM - See memory module
diskette drive
connector 45
display, power management 17
disposal of lithium ion battery vii
DMA channel assignments 90
drive
CD-RW specifications 97
IDE connectors 49
installing an additional 3½" drive
header - See front panel header
headphones, line in, mic connectors 58
37
specifications 97
DVD-ROM drive
performance of discs 3, 97
E
error messages
beep codes 87
PCI configuration 88
expansion slots 14
specifications for 97
expansion slots - See Also slots
F
fan connectors 56
CPU-FAN 56
PWR-FAN 56
fax card - See modem card
fax/modem - See Also
communications
FCC Part 68 vi
front panel header 44
front view 2
buttons and switches 4
connectors 5, 6
drives 3
indicators 5
I
i.LINK connector 6, 54
i.LINK header connectors 59
I/O address map 91
I/O connectors
game port 12
i.LINK 13
keyboard and mouse 10
mic, line in, headphones 13
monitor 11
NETWORK (D-Link) port 53
printer port 11
serial port 1 11
telephone and line 13
USB ports 10, 51
I/O slot covering 36
I/O slot specifications 97
icons, description of 8
IDE
connectors 49
specifications 97
IEEE1394 - See i.LINK
installing
3½" hard disk drive 37
add-in card 24
system memory 30
interference v
J
jumper - See system board
K
keyboard connector 50
L
G
Game connector 57
graphics controller - See graphics
graphics specifications 96
L2 cache specifications 96
lithium battery, replacing 27
lithium ion battery
disposal vii
safety precautions vii
101
M
map - See Also I/O address map and
memory map
memory - See Also system memory
memory module
connector 46
removing 33
specifications 95
messages
error 87
status and error 88
microprocessor - See processor
model numbers ii
modem - See Also communications
modem card
connectors 65
view of 65, 68
monitor - See display
monitor connector 11
mouse connector 50
N
NETWORK (D-Link) connector 53
notice to users ii
P
passwords, user and supervisor 86
PCI
slot connectors 47
power connector 49
power management, configuring 17
printer connector 54
processor specifications 95
R
radio interference v
RAM - See Also system memory
rear view 7
I/O connectors 10
icons 8
recording ii
regulatory information v
removing
add-in card 25
cover 22
memory module 33
slot cover 35
replacing 23
cover 23
replacing lithium battery 27
resolution - See graphics
S
safety information ii
Serial connector 54
serial numbers ii
serial port - See Serial
slot - See Also I/O slot
slot cover, removing 35
specifications
audio 96
BIOS 98
communications 97
drives and controllers 97
graphics 96
I/O and expansion slots 97
L2 cache 96
memory module 95
processor 95
status and error messages 88
supervisor password 86
system board
AGP slot connector 48
AUX-IN connector 61
CD-IN connector 60
configuration switches 63
configuring 20
diskette drive connector 45
fan connectors 56
front panel header 44
game connector 57
headphones, line in, mic
connectors 58
i.LINK connector 54
i.LINK header connectors 59
IDE connectors 49
keyboard connector 50
memory module connector 46
mouse connector 50
PCI slot connectors 47
power connector 49
102
VAIO Digital Studio Reference Manual
printer connector 54
Serial connector 54
USB connectors 51, 53
system I/O address map 91
system memory, installing 30
T
Telephone Consumer Protection Act of
1991 vi
TV interference v
U
USB connectors 6, 51, 53
user password 86
List of Illustrations
../Amalthea/Graphics/D-Link.emf 9–
10
