VAIO Computer System Reference Manual
NOTICE
© 2002 Sony Electronics Inc. Reproduction in whole
or in part without written permission is prohibited.
All rights reserved. This manual and the software
described herein, in whole or in part, may not be
reproduced, translated, or reduced to any machinereadable form without prior written approval.
SONY ELECTRONICS INC. PROVIDES NO
WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN AND
HEREBY EXPRESSLY DISCLAIMS ANY
IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO
THIS MANUAL, THE SOFTWARE, OR SUCH
OTHER INFORMATION. IN NO EVENT SHALL
SONY ELECTRONICS INC. BE LIABLE FOR
ANY INCIDENTAL, CONSEQUENTIAL, OR
SPECIAL DAMAGES, WHETHER BASED ON
TORT, CONTRACT, OR OTHERWISE, ARISING
OUT OF OR IN CONNECTION WITH THIS
MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR THE
USE THEREOF.
Sony Electronics Inc. reserves the right to make any
modification to this manual or the information
contained herein at any time without notice. The
software described herein is governed by the terms of
a separate user license agreement.
This product contains software owned by Sony and
licensed by third parties. Use of such software is
subject to the terms and conditions of license
agreements enclosed with this product. Some of the
software may not be transported or used outside the
United States. Software specifications are subject to
change without notice and may not necessarily be
identical to current retail versions.
Certain product(s) included with this computer may
include features such as copy protection and content
management technology. USE OF THE SOFTWARE
PRODUCT(S) REQUIRES AGREEMENT TO
APPLICABLE END USER AGREEMENTS AND
FULL COMPLIANCE WITH APPLICABLE
PRODUCT ACTIVATION PROCEDURES. Product
activation procedures and privacy policies will be
detailed during initial launch of the software
product(s), or upon certain reinstallations of the
software product(s), or reconfigurations of the
computer, and may be completed by Internet or
telephone (toll charges may apply).
Updates and additions to software may require an
additional charge. Subscriptions to online service
providers may require a fee and credit card
information. Financial services may require prior
arrangements with participating financial
institutions.
Sony, VAIO, the VAIO logo, VAIO Smart,
MovieShaker, DVgate, i.LINK, Memory Stick and
the Memory Stick logo are trademarks or registered
trademarks of Sony.
AMD, Athlon and Quantispeed are trademarks or
registered trademarks of Advanced Micro Devices.
Microsoft, Windows, and the Windows logo are
trademarks or registered trademarks of Microsoft
Corporation. PS/2 is a registered trademark of IBM
Corporation.
All other trademarks are trademarks or registered
trademarks of their respective owners.
iii
Owner’s Record
As an ENERGY STAR®
Partner, Sony
Corporation has
determined that this
product meets the
ENERGY STAR®
guidelines for energy
efficiency.
The International ENERGY STAR® Office
Equipment Program is an international program that
promotes energy saving through the use of computers
and other office equipment. The program backs the
development and dissemination of products with
functions that effectively reduce energy
consumption. It is an open system in which business
proprietors can participate voluntarily. The targeted
products are office equipment such as computers,
displays, printers, facsimiles and copiers. Their
standards and logos are uniform among participating
nations. ENERGY STAR is a U.S. registered
trademark of the Environmental Protection Agency.
The model number and serial number are located on
either the front or back panel of your Sony VAIO®
computer. Record the model and serial number in the
space provided here, and keep in a secure location.
Refer to the model and serial numbers when you call
your Sony Service Center.
Model Number:
Serial Number:
iv
VAIO Computer System Reference Manual
Safety Information and
Caution
❑
Your computer’s installed optical drives may vary,
depending on the system configuration you have
purchased. See the online specifications sheet for
details on your installed optical drives.
❑
DVD-RW Laser Diode Properties
Laser Output
0.18 mW
(DVD-Read)
0.39 mW
(CD-Read)
2.58 mW
(DVD-Write)
11.5 mW
(CD-Write)
Wave Length
650-662 nm
(DVD)
To prevent fire or shock hazard, do not expose
your desktop to rain or moisture. To avoid
electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
Never install modem or telephone wiring
during a lightning storm.
Never install telephone jacks in wet locations
unless the jack is specifically designed for
wet locations.
Never touch uninsulated telephone wire or
terminals unless the telephone line has been
disconnected at the network interface.
Use caution when installing or modifying
telephone lines.
Avoid using the modem during an electrical
storm.
Do not use the modem or a telephone to
report a gas leak in the vicinity of the leak.
The socket outlet shall be installed near the
equipment and shall be easily accessible.
❑
❑
❑
❑
❑
❑
!
To change the backup battery,
please contact your nearest Sony
Service Center.
!
Caution: The use of optical
instruments with this product will
increase eye hazard. As the laser
beam used in this product is
harmful to the eyes, do not
attempt to disassemble the drive
cabinet. Refer servicing to
qualified personnel only.
!
Danger: Visible and invisible laser
radiation when open. Avoid direct
exposure to beam.
!
For DVD-RW: Danger—Visible and
invisible laser radiation when
open. Avoid direct exposure to
beam.
!
For CD-RW: Danger—Invisible laser
radiation when open. Avoid direct
exposure to beam.
773-797 nm (CD)
DVD-ROM Laser Diode Properties
Laser Output
0.7 mW (DVD)
0.4 mW (CD)
Wave Length
635-665 nm
(DVD)
770-810 nm
(CD)
CD-RW Laser Diode Properties
Laser Output
1.0 mW (Read)
53.0 mW (Write)
Wave Length
780-787 nm
CD-ROM Laser Diode Properties
Laser Output
1.0 mW
Wave Length
760-810 nm
v
!
❑
❑
❑
❑
❑
❑
❑
❑
❑
Caution: For ADSL, HomePNA and
V.90 modem models; to reduce the
risk of fire, use only No. 26 AWG or
larger telecommunication line
cord.
Pour prévenir tout risque d’incendie ou
d’électrocution, garder cet appareil à l’abri de
la pluie et de l’humidité.
Pour prévenir tout risque d’électrocution, ne
pas ouvrir le châssis de cet appareil et ne
confier son entretien qu’à une personne
qualifiée.
Ne jamais effectuer l’installation de fil
modem ou téléphone durant un orage
électrique.
Ne jamais effectuer l’installation d’une prise
téléphonique dans un endroit mouillé à moins
que la prise soit conçue à cet effet.
Ne jamais toucher un fil téléphonique à
découvert ou un terminal à moins que la ligne
téléphonique n’ait été débranché de
l’interface réseau.
Soyez très prudent lorsque vous installez ou
modifiez les lignes téléphoniques.
Évitez d’utiliser le modem durant un orage
électrique.
N'utilisez pas le modem ni le téléphone pour
prévenir d'une fuite de gaz vous êtes près de
la fuite.
L’appareil doit être le plus près possible
d’une prise murale pour en faciliter l’accès.
!
Pour changer la pile de rechange,
veuillez contacter votre centre de
service Sony le plus près.
!
Avertissement : L'utilisation
d'instruments optiques avec ce
produit augmente les risques pour
les yeux. Puisque le faisceau laser
utilisé dans ce produit est
dommageable pour les yeux, ne
tentez pas de désassembler le
boîtier. Adressez-vous à un agent
de service qualifié.
!
Danger : Radiation laser visible et
invisible si ouvert. Évitez
l’exposition directe au faisceau.
!
Pour les DVD-RW : Danger—
Radiation laser visible et invisible
si ouvert. Évitez l'exposition
directe au faisceau.
!
Pour les CD-RW : Danger—
Radiation laser invisible si ouvert.
Évitez l'exposition directe au
faisceau.
!
Attention : Pour ADSL, HomePNA,
et V.90 modele modem; afin de
réduire les risques d'incendie,
n'utilisez qu'un cordon de
communication N0. 26 AWG ou
plus gros.
For questions regarding your product or for the Sony
Service Center nearest you, call 1-888-476-6972 in
the United States or 1-800-961-7669 in Canada.
Sony Customer Support can be reached at
http://www.sony.com/pcsupport.
vi
VAIO Computer System Reference Manual
Regulatory Information
Declaration of Conformity
Trade Name:
SONY
Model No.:
PCV-7753
Responsible Party:
Sony Electronics Inc.
Address:
680 Kinderkamack Rd
Oradell, NJ 07649
Telephone:
201-930-6972
This phone number is for FCC-related matters
only.
This device complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures:
❑
❑
❑
❑
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and the receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/
TV technician for help.
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
Only peripherals (computer input/output devices,
terminals, printers, etc.) that comply with FCC Class
B limits may be attached to this computer product.
Operation with noncompliant peripherals is likely to
result in interference to radio and television
reception.
All cables used to connect peripherals must be
shielded and grounded. Operation with cables,
connected to peripherals, that are not shielded and
grounded, may result in interference to radio and
television reception.
vii
FCC Part 68
This equipment complies with Part 68 of the FCC
rules. The FCC Ringer Equivalence Number (REN)
for this equipment is 0.8B. If requested, this
information must be provided to the telephone
company.
This modem uses the USOC RJ-11 telephone jack.
The REN is used to determine the quantity of devices
which may be connected to the telephone line.
Excessive RENs on the telephone line may result in
the devices not ringing in response to an incoming
call. In most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of the
number of devices that may be connected to the line,
as determined by the total RENs, contact the
telephone company to determine the maximum REN
for the calling area.
If the terminal equipment causes harm to the
telephone network, the telephone company will
notify you in advance that temporary discontinuance
of service may be required. But if advance notice is
not practical, the telephone company will notify the
customer as soon as possible. Also, you will be
advised of your right to file a complaint with the FCC
if you believe it is necessary.
The telephone company may make changes in its
facilities, equipment, operations or procedures that
could affect the operations of the equipment. If this
happens, the telephone company will provide
advance notice in order for you to make the
necessary modifications in order to maintain
uninterrupted service.
If trouble is experienced with this modem, for repair
or warranty information, please contact
1-888-4-SONY-PC, or write to the Sony Customer
Information Center, 12451 Gateway Blvd., Fort
Myers, FL 33913. If the trouble is causing harm to
the telephone network, the telephone company may
request that you remove the equipment from the
network until the problem is resolved.
Repair of this equipment should be made only by a
Sony Service Center or Sony authorized agent. For
the Sony Service Center nearest you, call
1-888-4-SONY-PC (1-888-476-6972).
This equipment cannot be used on public coin
service provided by the telephone company.
Connection to Party Line Service is subject to state
and possible provincial tariffs. (Contact the state or
provincial utility service commission, public service
commission, or corporation commission for
information.)
Telephone Consumer
Protection Act of 1991
(United States)
The Telephone Consumer Protection Act of 1991
makes it unlawful for any person to use a computer
or other electronic device to send any message via a
telephone facsimile machine unless such message
clearly contains, in a margin at the top or bottom of
each transmitted page or on the first page of the
transmission, the date and time it is sent and an
identification of the business, other entity, or
individual sending the message, and the telephone
number of the sending machine or such business,
other entity, or individual.
In order to program this information into your
facsimile machine, see your fax software
documentation.
Telephone Consumer
Guidelines (Canada)
Please refer to your telephone directory under
‘Privacy Issues’ and/or ‘Terms of Service.’ For more
detailed information, please contact:
CRTC
Terrasses de la Chaudiére, Tour centrale
1 promenade du Portage, 5 étage Hull PQ K1A 0N2.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet àppareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
viii
VAIO Computer System Reference Manual
Disposal of Lithium Battery
You can return your unwanted lithium batteries to
your nearest Sony Service Center or Factory Service
Center.
!
Ne pas manipuler les batteries au
lithium qui fuient ou sont
endommagées.
!
Une batterie non conforme
présente un danger d'explosion. La
remplacer seulement par une
batterie identique ou de type
équivalent recommandé par le
fabricant. Évacuer les batteries
usées selon les directives du
fabricant.
!
La manutention incorrecte du
module de batterie de cet appareil
présente un risque d'incendie ou
de brûlures chimiques. Ne pas
démonter, incinérer ou exposer à
une température de plus de 100°C.
Évacuer promptement la batterie
usée. Garder hors de portée des
enfants.
✍ In some areas the disposal of lithium batteries in
household or business trash may be prohibited.
For the Sony Service Center nearest you, call
1-888-476-6972 in the United States or
1-800-961-7669 in Canada.
!
Do not handle damaged or leaking
lithium batteries.
!
Danger of explosion if battery is
incorrectly replaced. Replace only
with the same or equivalent type
recommended by the
manufacturer. Discard used
batteries according to the
manufacturer’s instructions.
!
The battery pack used in this
device may present a fire or
chemical burn hazard if
mistreated. Do not disassemble,
heat above 212°F (100°C), or
incinerate. Dispose of used battery
promptly. Keep away from
children.
ix
Industry Canada Notice
Avis de l’Industrie Canada
NOTICE: The Industry Canada label identifies
certified equipment. This certification means that the
equipment meets certain telecommunications
network protective, operational and safety
requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements
document(s). The Department does not guarantee the
equipment will operate to the user’s satisfaction.
AVIS : L’étiquette d’Industrie Canada identifie le
matériel homologué.
Before installing this equipment, users should ensure
that it is permissible to be connected to the facilities
of the local telecommunications company. The
equipment must also be installed using an acceptable
method of connection.
The customer should be aware that compliance with
the above conditions may not prevent degradation of
service in some situations.
Repairs to certified equipment should be coordinated
by a representative designated by the supplier.
Equipment malfunctions or any repairs or alterations
made by the user to this equipment may give the
telecommunications company cause to request that
the user disconnect the equipment.
Users should ensure for their own protection that the
electrical ground connections of the power utility,
telephone lines and internal metallic water pipe
system, if present, are connected together. This
precaution may be particularly important in rural
areas.
CAUTION: Users should not attempt to make such
connections themselves, but should contact the
appropriate electrical inspection authority, or
electrician, as appropriate.
NOTICE: This equipment meets the applicable
Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration
number. The abbreviation, IC before the registration
number signifies that registration was performed
based on a Declaration of Conformity indicating that
Industry Canada technical specifications were met. It
does not imply that Industry Canada approved this
equipment.
NOTICE: The Ringer Equivalence Number (REN)
assigned to each terminal device provides an
indication of the maximum number of terminals
allowed to be connected to a telephone interface. The
termination on an interface may consist of any
combination of devices subject only to the
requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed 5. The
Ringer Equivalence Number for this equipment is
0.8B.
Cette étiquette certifie que le matériel est conforme
aux normes de protection, d’exploitation et de
sécurité des réseaux de télécommunications, comme
le prescrivent les documents concernant les
exigences techniques relatives au matériel terminal.
Le Ministère n’assure toutefois pas que le matériel
fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit
s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de
télécommunication. Le matériel doit également être
installé en suivant une méthode acceptée de
raccordement. L’abonné ne doit pas oublier qu’il est
possible que la conformité aux conditions énoncées
ci-dessus n’empêche pas la dégradation du service
dans certaines situations.
Les réparations de matériel homologué doivent être
coordonnées par un représentant désigné par le
fournisseur. L’entreprise de télécommunications peut
demander à l’utilisateur de débrancher un appareil à
la suite de réparations ou de modifications effectuées
par l’utilisateur ou à cause de mauvais
fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer
que tous les fils de mise à la terre de la source
d’énergie électrique, des lignes téléphoniques et des
canalisations d’eau métalliques, s’il y en a, sont
raccordés ensemble. Cette précaution est
particulièrement importante dans les régions rurales.
Avertissement : L’utilisateur ne doit pas tenter de
faire ces raccordements lui-même; il doit avoir
recours à un service d’inspection des installations
électriques, ou à un électricien, selon le cas.
AVIS : Le presént matériel est conforme aux
spécifications techniques d’Industrie Canada
applicables au matérial terminal. Cette conformité est
confirmée par le numéro d’enregistrement, signifie
que l’enregistrement s’est effectué conformément à
une déclaration de conformité et indique que les
specifications techniques d’Industrie Canada ont été
respectées. Il n’implique pas qu’Industrie Canada a
approuvé le matériel.
AVIS : L’indice d’équivalence de la sonnerie (IES)
assigné à chaque dispositif terminal indique le
nombre maximal de terminaux qui peuvent être
raccordés à une interface.
La terminaison d’une interface téléphonique peut
consister en une combination de quelques dispositifs,
à la seule condition que la somme d’indices
d’équivalence de la sonnerie de tous les dispositifs
n’excède pas 5. L’indice d’équivalence de la sonnerie
de ce matériel est de 0.8B.
x
VAIO Computer System Reference Manual
Contents
NOTICE ....................................................................................................... ii
Owner’s Record.................................................................................. iii
Safety Information and Caution ...................................................... iv
Regulatory Information..................................................................... vi
FCC Part 68 ........................................................................................ vii
Telephone Consumer Protection Act of 1991 (United States) .... vii
Telephone Consumer Guidelines (Canada).................................. vii
Disposal of Lithium Battery ........................................................... viii
Industry Canada Notice.....................................................................ix
Avis de l’Industrie Canada................................................................ix
Chapter 1 — Identifying Components................................ 1
Front View ...................................................................................................2
Drives.....................................................................................................3
Buttons and Switches ..........................................................................4
Indicators...............................................................................................5
Connectors ............................................................................................6
Rear View .....................................................................................................7
Icon Labels ............................................................................................8
I/O Connectors ..................................................................................10
Expansion Slots ..................................................................................14
Chapter 2 — Configuring Your System ............................ 15
Accessing the BIOS Setup Utility............................................................16
Changing Power Management Settings ................................................17
xi
xii
VAIO Computer System Reference Manual
Chapter 3 — Upgrading and Maintaining Components . 23
Removing the Side Panel ........................................................................24
Replacing the Side Panel .........................................................................25
Removing a PCI Add-in Card ................................................................26
Installing a PCI Add-In Card .................................................................28
Replacing the Lithium Battery ...............................................................30
Removing a Memory Module ................................................................33
Installing Memory Modules ....................................................................35
Removing a Slot Cover.............................................................................38
Covering an Open I/O Slot ....................................................................39
Installing an Internal Hard Disk Drive ..................................................40
To identify additional hard disk space ...........................................44
Removing the Power Supply...................................................................45
Replacing the Power Supply ...................................................................46
Chapter 4 — System Board ............................................... 47
Memory Module (DDR-DIMM) Slots ....................................................48
Power Supply Header ..............................................................................49
CLR CMOS Jumper...................................................................................50
Chapter 5 — CMOS Setup Options ................................... 51
Main Screen ...............................................................................................53
Advanced Screen ......................................................................................55
Power Screen..............................................................................................56
Boot Screen ................................................................................................57
Exit Screen ..................................................................................................58
Chapter 6 — Miscellaneous Technical Information ......... 59
User and Supervisor Passwords ............................................................60
Beep Code Error Messages .....................................................................61
PCI Configuration Status and Error Messages ....................................62
DMA Channel Assignments ...................................................................63
System I/O Address Map .......................................................................64
Memory Map ............................................................................................66
IRQ Settings ...............................................................................................67
xiii
Chapter 7 — Specifications................................................ 69
Processor ....................................................................................................69
Chipset ......................................................................................................69
PCI Bus ......................................................................................................69
Memory Modules ....................................................................................70
Memory Configurations .........................................................................70
L2 Cache ....................................................................................................70
Graphics ....................................................................................................70
Audio .........................................................................................................71
Communications .....................................................................................71
I/O and Expansion Slots .........................................................................72
Floppy Disk Drive and Controller ........................................................72
Hard Drives and Controller ...................................................................72
Optical Drives ...........................................................................................73
System BIOS .............................................................................................73
Index .................................................................................. 75
xiv
VAIO Computer System Reference Manual
Chapter 1
Identifying Components
The following sections identify and describe each component that is
visible from the exterior of the VAIO computer. For details on the
hardware confuguration of your system, see the online specifications
sheet.
To view this online information:
1
2
3
Click Start, then click Help and Support.
Click VAIO User Guide, then click the Welcome link.
Click the link in the text, “Click here to view your computer’s
hardware specifications and software information.”
1
2
VAIO Computer System Reference Manual
Front View
Identifying Components
Drives
Optical disc drive #1
Optical disc drive #2
Floppy disk drive
DRIVE
Drive
Description
Optical disc drive #1
See online specifications sheet for details.
Optical disc drive #2
See online specifications sheet for details.
Floppy disk drive
3.5-inch, 1.44 MB.
3
4
VAIO Computer System Reference Manual
Buttons and Switches
Optical disc eject
Floppy disk eject
DRIVE
Power on/off
Button or switch
Description
Optical disc eject button
Automatically opens and closes the assigned
optical drive tray.
Floppy disk eject button
Ejects a floppy disk.
Power on/off switch
Turns system power on, off, or into Stand by
mode.
Identifying Components
5
Indicators
Floppy disk drive access
Hard disk drive access
DRIVE
Optical disc drive access
Power/Stand by
Indicator
Description
Floppy disk drive access
indicator
On (green) indicates floppy disk drive
activity.
Hard disk drive access indicator
On (red) indicates hard disk drive activity.
Optical drive access indicator
On (red) indicates optical disc activity.
Power/Stand by indicator
Stand by (amber) indicates the computer
is in Stand by mode.
On (blue) indicates the computer is out of
Stand by mode, ready to use.
Off (no color) indicates the computer is
turned off or in Hibernation mode.
6
VAIO Computer System Reference Manual
Connectors
DRIVE
USB1, USB2 ports
i.LINK port
Connector
Description
i.LINK® port
(IEEE 1394)*
Connects to a digital device that has a 4-pin i.LINK
connector.
USB1, USB2 ports
Connects to USB devices.
*
To connect to a 6-pin i.LINK device, use the i.LINK port on the back of the system. A 6-pin i.LINK
connector can supply power from the computer to the device if the device also has a 6-pin i.LINK port.
A 4-pin i.LINK connector cannot supply power to the device.
Identifying Components
7
Rear View
Mouse
Keyboard
KEYBOARD MOUSE
USB3
USB4
Ethernet
USB
AC Input port
NETWORK
MONITOR
PRINTER
VGA Monitor
port
Printer/Parallel
port
i.LINK port
Serial
Headphones
Line In
Mic
i.LINK
S400
HEADPHONES
SERIAL
LINE IN
MIC
4
3
2
1 TELEPHONE
Telephone
Line
LINE
8
VAIO Computer System Reference Manual
Icon Labels
KEYBOARD MOUSE
Icon Label Area
USB
NETWORK
MONITOR
PRINTER
i.LINK
S400
HEADPHONES
SERIAL
LINE IN
MIC
4
3
Icon Label Area
2
1 TELEPHONE
Icon
LINE
Description
Mouse port
Keyboard port
Universal Serial Bus (USB) port
Ethernet port (for LAN connection only)
VGA Monitor port
Printer/Parallel port
Identifying Components
Icon
Description
i.LINK® (IEEE 1394) port
Headphones jack
Line In jack (audio)
Mic (microphone) jack
Serial port
Telephone jack
Line jack
9
10
VAIO Computer System Reference Manual
I/O Connectors
The following section identifies the various I/O connectors.
Keyboard and Mouse Ports
The keyboard and mouse ports are physically identical and have the
same pinout. They are standard 6-pin PS/2® compatible female ports.
2
3
1
4
6
5
USB Ports
The USB ports are standard 4-pin USB ports. Two USB ports are located at
the front, and two at the rear of the system.
Serial Ports
The serial port is a standard 9-pin DB-9 male port.
6
9
1
5
Identifying Components
Printer/Parallel Port
The printer/parallel port is a standard 25-pin DB-25 female port.
25
14
13
1
VGA Monitor Port
The monitor port is a standard 15-pin female high-density
VGA-type port.
10
15
5
11
1
6
11
12
VAIO Computer System Reference Manual
Mic, Line In, and Headphones Jacks
The microphone, line in, and headphones jacks are physically identical,
but have different connections. They are standard 3.5 mm stereo minijacks.
Headphones
Line In
Mic
Connector
Description
Headphones
1.0 Vrms (typical).
Mic
Electret condenser microphone input.
Line In
1.0 Vrms (typical), 10 Kohm impedance.
Telephone and Line Jacks
The telephone and line jacks are physically identical and have identical
connections. They are standard RJ-11 female phone jacks. However, the
line jack is for connecting to a telephone line that comes from the wall,
and the telephone jack is for connecting the computer to a telephone.
The modem installed on your computer may differ depending on the
configuration you purchased.
Telephone
Line
Identifying Components
13
i.LINK (IEEE 1394) Ports
The 6-pin i.LINK® port on the back of the system can supply power from
the computer to a device if the device also has a 6-pin i.LINK port. The
6-pin port supplies 10 V to 12 V and a maximum power of 6 watts.
✍ i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394
connection. The i.LINK connection may vary, depending on the software applications,
operating system and compatible i.LINK devices. All products with an i.LINK connection may
not communicate with each other.
✍ Refer to the documentation that came with your compatible i.LINK device for information on
operating conditions and proper connections. Before connecting compatible i.LINK devices to
your system, such as an optical disk or hard disk drive, confirm their operating system
compatibility and required operating conditions.
The 4-pin i.LINK port at the bottom of the front panel does not supply
power.
6-pin i.LINK port
(IEEE 1394)
4-pin i.LINK port
(IEEE 1394)
On back of
system
At bottom of
front panel
Ethernet Port
The Ethernet port on the rear of the system is used to connect to a
10BASE-T/ 100BASE-TX Ethernet network.
Ethernet
On back of
system
14
VAIO Computer System Reference Manual
Expansion Slots
There are five expansion slots (see “System Board” on page 47).
Expansion (slot No.1) is occupied by the fax/modem card. A V.90
compatible modem has two jacks (Telephone and Line).*
Expansion (slot No. 2, 3, 4, and 5) are available for expansion.
Slot No. 5
Slot No. 4
Slot No. 3
Slot No. 1/2
* Your system has five expansion slots, however, only four slots are visible from the back panel.
Chapter 2
Configuring Your System
This chapter contains information on configuring your system.
❑
Making changes to the BIOS settings.
❑
Making changes to the display's power management settings.
15
16
VAIO Computer System Reference Manual
Accessing the BIOS Setup Utility
Access the BIOS Setup Utility to make changes to the BIOS settings (see
“CMOS Setup Options” on page 51 for information on BIOS settings).
!
Before rebooting the system, save and close all open files, and exit open
applications.
1
Reboot your computer by selecting Shut Down... from the Start
menu, then selecting Restart.
2
3
When the Sony logo appears, press F2.
The AwardBIOS Setup Utility screen appears.
Each menu presents options for modifying the system configuration.
Use the left and right arrow keys to select a menu from the menu bar.
Use the up and down arrow keys to select items within a menu. Once
an item is highlighted, use the plus/minus (+/-) keys to modify a
setting.
If an item has a triangle ( ) to its left, this indicates that a sub-menu of
options is available. Press ENTER to access a sub-menu. If a submenu contains items with a triangle, there is another layer of options
from which to select.
4
Once you select an option, press ESC to back out of each menu until
you reach the top level, where the menu bar appears.
5
To exit the BIOS setup utility, press ESC from any top-level screen and
follow the prompts.
Configuring Your System
17
Changing Power Management Settings
Power Management capability is designed to enable your computer to
reduce power or shut itself off after being idle for a specified period of
time.
1
From the Start menu, point to Settings, Control Panel, then click
Power Options.
The Power Options Properties dialog box opens, with the Power
Schemes tab displayed.
2
Select the power scheme that is most appropriate for the way you use
your computer.
To change a power scheme, change the settings for Turn off monitor,
Turn off hard disks, System stand by, and System hibernates.
18
VAIO Computer System Reference Manual
The Turn off monitor option enables you to specify the period of
inactivity (in minutes) that you want to elapse before your monitor
turns off when your computer is running on AC power. The display
reactivates when you move the mouse or press a key.
The Turn off hard disks option enables you to specify the period of
inactivity (in minutes) that you want to elapse before your hard disks
turn off when your computer is running on AC power.
The System stand by option enables you to specify the period of
inactivity (in minutes) that you want to elapse before your computer
goes on Stand by when your computer is running on AC power.
Power is reactivated when you click the left mouse button or press
spacebar on the keyboard.
The System hibernates option enables you to specify the period of
inactivity (in minutes) before your computer goes into the hibernate
state. Power is reactivated when you push the power button.
3
To save a new power scheme, first modify the settings, click Save As,
type a descriptive name, and then click OK.
Configuring Your System
4
Click the Advanced tab.
5
Select the desired settings.
19
20
VAIO Computer System Reference Manual
6
Click the Hibernate tab.
7
Select the settings most appropriate for your system.
Configuring Your System
8
21
Click the UPS tab.
The UPS tab enables you to select and configure an Uninterruptible
Power Supply (UPS) device for your system.
✍ A UPS device is an optional accessory not supplied with your system.
9
Select the settings most appropriate for your system and click OK.
For more information about configuring a UPS device, refer to your
Microsoft® Windows® XP operating system Help.
22
VAIO Computer System Reference Manual
Chapter 3
Upgrading and Maintaining
Components
This chapter describes upgrade and maintenance procedures.
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
✍ System configuration may vary, depending on the model purchased. Your computer may
not include all of the hardware features shown in the illustrations of this section.
23
24
VAIO Computer System Reference Manual
Removing the Side Panel
You must remove the side panel to access the system board, add-in cards,
power supply, battery, memory, and internal drives.
1
Locate the tab on the upper right side of the rear panel, and pull it
back until the side panel releases.
2
Lift the side panel away from the unit and set aside.
Upgrading and Maintaining Components
25
Replacing the Side Panel
1
2
Align the tabs on the side panel to the chassis frame.
Press the side panel firmly against the unit until it snaps into place.
26
VAIO Computer System Reference Manual
Removing a PCI Add-in Card
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut down
the computer, and unplug the power cord.
1
2
Remove the side panel (see “Removing the Side Panel” on page 24).
3
Remove the screw that secures the add-in card to the chassis.
Disconnect any cables attached to the add-in card you want to
remove.
!
Hold the add-in card by its edges and do not touch any components or
connector contacts on the card. Static electricity in your body may
damage sensitive components on the card. As a precaution, touch any
exposed metal part on the metal chassis (preferably the metal part on
the power supply) before handling an add-in card to discharge any static
electricity in your body.
Upgrading and Maintaining Components
4
27
Remove the add-in card from the PCI slot and store the card in an
anti-static wrapper for future use.
✍ Grasp the card with one hand on each end, and gently pull up as you rock the card
from side to side.
5
If you do not replace the card or install another add-in card, install a
slot cover over the vacant slot at the rear of the chassis (see “Covering
an Open I/O Slot” on page 39).
6
Replace the side panel (see “Replacing the Side Panel” on page 25).
28
VAIO Computer System Reference Manual
Installing a PCI Add-In Card
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
2
3
Remove the side panel (see “Removing the Side Panel” on page 24).
4
Insert the add-in card into the PCI slot. Use a gentle rocking motion,
pressing down until the card is fully seated.
Locate an available expansion slot.
Remove the slot cover adjacent to the selected slot (see “Removing a
Slot Cover” on page 38).
✍ Align the card's bracket so that the bottom of the bracket fits into the slot at the
bottom of the chassis. Make sure that the top of the bracket fits snugly against the
chassis lip after the card is fully inserted.
Upgrading and Maintaining Components
29
5
6
Replace the screw that secures the card.
7
8
Replace the side panel (see “Replacing the Side Panel” on page 25).
Attach any necessary cables to the card (see the instructions that came
with the add-in card).
Turn on the computer and follow any instructions that came with the
add-in card.
30
VAIO Computer System Reference Manual
Replacing the Lithium Battery
You may need to replace the lithium battery if your computer consistently
loses the date or time settings after turning it off. The lithium battery has
a typical life of three years, after which the battery may be too weak to
power the CMOS memory.
!
When you remove the lithium battery, all values stored in the CMOS memory
(BIOS setup values and Plug and Play values) may be lost. Although the
computer can hold the charge for a short time while replacing the battery, it
is safer to assume that the settings will be lost. When the values are lost, the
BIOS values revert to their factory-default settings (see “Accessing the BIOS
Setup Utility” on page 16).
Do not handle damaged or leaking batteries.
The lithium battery may explode if mistreated. Do not disassemble it or
dispose of it in fire.
1
Reboot your computer by selecting Shut Down... from the Start
menu, and then selecting Restart.
2
If the error message “Error: Check date and time settings” appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. Otherwise it is not necessary to replace
the battery at this time, and you can skip all remaining steps.
3
Compare all the BIOS options to their default settings (see “CMOS
Setup Options” on page 51). Make a list of all the BIOS options that
are different from their default values. Refer to this list when you
restore the BIOS settings later.
4
Select Exit Discarding Changes from the main menu using the right
arrow key.
5
Press Enter, type Y when prompted to discard changes, then press
Enter to exit the BIOS Setup Utility.
6
Turn off the computer.
!
7
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Remove the side panel (see “Removing the Side Panel” on page 24).
Upgrading and Maintaining Components
8
If necessary, remove any add-in cards to gain access to the battery.
You may also need to disconnect some cables.
!
9
31
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling an add-in card or other
sensitive electronic component.
Use a small flathead screwdriver or your finger to push in (not down)
against the small tab at one end of the battery holder to pop out the
battery.
Push in (not down) on
tab to pop out battery
10
Gently lift out the battery and dispose of it according to the
instructions that came with the new battery.
11
Insert the new battery into the battery holder, with the plus (+) side
up, and press down until the battery is secure.
✍ The Sony CR2032 battery is recommended. Using a type of battery other than a
CR2032 may present a risk of fire or explosion.
12
13
14
15
Replace any add-in cards that were removed.
Reconnect any cables that were disconnected.
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and turn on the computer.
32
VAIO Computer System Reference Manual
16
If the error message “Error: Check date and time settings.” appears
during the reboot sequence, press F2 during the reboot process to
access the BIOS Setup Utility. If no error message displays, the
computer’s BIOS settings were retained during the battery
replacement and you can skip the remaining steps.
17
Refer to the list you made in step 3 and restore any non-default BIOS
settings (see “CMOS Setup Options” on page 51).
18
Select Exit Saving Changes from the main menu using the right arrow
key.
19
Press Enter, type Y when prompted to discard changes, then press
Enter to exit the BIOS Setup Utility.
The computer’s BIOS settings are now restored.
Upgrading and Maintaining Components
33
Removing a Memory Module
You may need to remove a memory module if you change the memory
configuration or replace a bad module.
!
1
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Remove the side panel (see “Removing the Side Panel” on page 24).
✍ The memory modules are located beneath the power supply. You need to remove
the power supply to reach the memory modules.
2
Remove the power supply (see “Removing the Power Supply” on
page 45).
!
3
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling the memory module.
Locate the memory module you wish to remove.
34
4
VAIO Computer System Reference Manual
Reach around each side of the power supply and push down the
handle on each side of the memory module to eject the module from
its slot.
Push out
Handles
5
Grasp one edge of the memory module and lift out. Store the module
in a static-free bag.
Upgrading and Maintaining Components
35
Installing Memory Modules
Supports SDRAM memory. Does not support EDO memory or buffered
DDR-DIMM memory. Memory can be installed in either socket. Memory
size can vary between sockets. DDR-DIMMs can be single- or doublesided.
!
1
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Choose the size of the memory module and configuration as shown
in the following table. Memory modules can vary in size and speed
between sockets. The minimum memory size is 128 MB. The
maximum memory size is 1 GB. The BIOS automatically detects the
type, size and speed of the memory modules.
Memory module configurations (MB)*
DIMM1
DIMM2
0, 128, 256, 512
0, 128, 256, 512
* Your computer ships with at least 256 MB. SDRAM is expandable to 1 GB. Your
model may ship with more than 256 MB SDRAM depending on the configuration
you purchased.
✍ Use only PC2100 memory. Your system does not support EDO, buffered DDRSDRAM, or PC100/133 SDRAM memory.
2
3
Remove the side panel (see “Removing the Side Panel” on page 24).
4
If necessary, remove the memory module you wish to replace (see
“Removing a Memory Module” on page 33).
Remove the power supply (see “Removing the Power Supply” on
page 45).
!
5
6
Touch any exposed metal part of the chassis to discharge static
electricity in your body before handling a memory module.
If necessary, remove any previously installed PCI cards.
Remove the new memory module(s) from its anti-static package.
Hold the memory module only by its edges to prevent staticelectricity damage.
36
7
VAIO Computer System Reference Manual
Align the module over the appropriate slot, noting the location of pin
1 on the module and pin 1 on the slot.
Press down
here
Handles
Pin 1 side
DDR-DIMM 2
DDR-DIMM 1
Memory module (DDR-DIMM)
1
Indicates pin 1
8
Carefully but firmly insert the edge of the module into the slot.
Upgrading and Maintaining Components
9
37
Press down firmly and evenly at both corners until the module is
fully seated.
✍ When the module is fully seated, the handles on each side are straight up and
locked into the slot on each side of the module. If the handles are not totally
straight upright, continue to press down on each side of the module until the
handles lock into place.
10
Replace the power supply (see “Replacing the Power Supply” on
page 46).
11
12
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord and turn on the computer.
Your computer automatically recognizes the extra memory and will
configure itself accordingly when you turn on the computer. No further
action is required.
38
VAIO Computer System Reference Manual
Removing a Slot Cover
You remove a slot cover when you install an add-in card that occupies a
slot.
!
1
2
3
4
5
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Remove the side panel (see “Removing the Side Panel” on page 24).
Locate the slot whose cover you want to remove.
Lay the system on its side.
Remove the screw from the slot cover.
Remove the loose slot cover and retain it for future use.
Upgrading and Maintaining Components
39
Covering an Open I/O Slot
Slot covers prevent air from escaping through the empty hole. If air
escapes, the components inside the computer cannot be properly cooled.
This may damage some components, especially the main processor,
which generates the most heat.
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
Slide the tip of the slot cover between the chassis and system board.
2
Push the slot cover down until it rests firmly on the lip in the chassis.
All add-in card brackets and slot covers rest on this lip.
3
Replace the slot cover's screw to secure the I/O slot cover.
40
VAIO Computer System Reference Manual
Installing an Internal Hard Disk Drive
Your system comes with an available bay to hold an additional 3.5-inch
hard disk drive. The drive you install must not require front panel access.
The hard disk drive access light blinks when either internal drive is
active.
✍ Some models, such as Configure-to-Order (CTO) systems, may already have a
second hard disk drive installed.
!
1
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
Configure the jumpers on the new drive as a slave device (see your
new drive’s documentation for configuration instructions).
Power connector
Jumpers
Drive connector
2
Remove the side panel (see “Removing the Side Panel” on page 24).
Upgrading and Maintaining Components
3
41
Disconnect the drive connector (A).
Drive connector
Power supply connector
A
B
Tab
C
Disk drive holder
4
5
Disconnect the power connector (B).
Pull out on the tab (C) that secures the drive holder to the chassis.
42
VAIO Computer System Reference Manual
6
Slide the drive holder up and out.
7
Slide the new drive into the bottom part of the drive holder and align
the holes on each side of the drive holder.
8
Secure the drive to the drive holder using screws in each of the two
holes on each side of the drive holder (the screws are provided with
the new drive). Do not overtighten the screws.
Upgrading and Maintaining Components
9
Slide the drive holder back into the chassis so that the edge of the
holder is flush with the chassis.
10
Push in on the tab (A) to securely latch the holder to the chassis.
43
Drive connectors
C
Power connectors
E
B
D
A
Tab
Disk drive holder
11
12
13
14
15
16
Connect the inner drive cable connector (B) to the first drive.
Connect the outer drive cable connector (C) to the second drive.
Connect the first power connector (D) to the first drive.
Connect the second power connector (E) to the second drive.
Replace the side panel (see “Replacing the Side Panel” on page 25).
Reconnect the power cord to the system and then turn on your
computer.
44
VAIO Computer System Reference Manual
To identify additional hard disk space
When you initialize the new hard disk drive, it must be configured as an
extended partition in Windows NT file system (NTFS) format.
1
2
Log on in Windows® as Administrator.
3
4
Select Manage. The Computer Management window appears.
5
Right-click on the newly installed, unformatted drive (Disk label
identified with red marking), and from the shortcut menu, select
Initialize Disk.
6
Click on the Unallocated area of the drive and then right-click to
display the shortcut menu.
7
8
Select New Partition. The New Partition wizard appears.
Click Start in the Windows taskbar and right-click on My Computer.
A shortcut menu appears.
From the file directory on the right, go to Storage and then select Disk
Management.
Follow the onscreen instructions to complete the process.
The Windows® XP operating system recognizes the new hard disk drive
and applies the NTFS format.
Upgrading and Maintaining Components
45
Removing the Power Supply
You remove the power supply when you insert a memory module (see
“Installing Memory Modules” on page 35).
!
Before opening the system unit, save and close all open files, exit all open
applications, turn off the power to all attached peripheral devices, shut
down the computer, and unplug the power cord.
1
Remove the screw that secures the power supply to the rear of the
chassis.
2
Pull the tab (A) that latches the power supply to the chassis.
A
3
4
Slide the power supply up until the power supply clears the chassis.
Rotate the power supply upside down and rest it on top of the chassis
where the hard drive is located.
46
VAIO Computer System Reference Manual
Replacing the Power Supply
1
Rotate the power supply down and slide it into the chassis along the
rails to each side of the chassis until the tab snaps into position.
2
Replace the screw that secures the power supply to the rear of the
chassis.
Chapter 4
System Board
This chapter identifies and describes components on the system board.
Processor
CPU Fan
Memory
Keyboard, Mouse
USB3, USB4
Ethernet
Printer (top)
Monitor, i.LINK
i.LINK Header
(to front panel)
Power Supply
Fan
Power Supply
Floppy Disk
Serial (top)
Mic in, Line in
Line out
Primary IDE
Secondary IDE
CMOS Clear
Aux-In
(not used)
CD-In
Front Panel
Header
Battery
Slot No. 1 (CNR)
WOL_CON
(not used)
USB Header
(to front panel)
Slot No. 5 (PCI)
Slot No. 4 (PCI)
Slot No. 3 (PCI)
Slot No. 2 (PCI)
47
48
VAIO Computer System Reference Manual
DDR-DIMM2
DDR-DIMM1
Memory Module (DDR-DIMM) Slots
Memory module (DDR-DIMM)
1
Indicates pin 1
Align pin 1 of the Dual Inline Memory Module (DDR-DIMM) to the
small triangle located on the memory module slot of the system board.
49
System Board
Power Supply Header
The power supply header on the system board connects to the power
supply connector labelled P1.
10
20
1
11
50
VAIO Computer System Reference Manual
CLR CMOS Jumper
There is one user-configurable jumper for CMOS Clear.
The computer ships with CMOS Clear in the Normal position. Do not
change the position of this jumper unless directed by a technical support
person.
CMOS Clear
1 2 3
CMOS Clear Jumper settings
Jumper Plug Position
Function
1-2
Clear
2-3
Normal
✍ The configuration jumpers should never need changing unless otherwise directed by a
technical support or service technician.
Chapter 5
CMOS Setup Options
This chapter describes each screen in the Award BIOS Setup Utility (see
“Accessing the BIOS Setup Utility” on page 16).
The Award BIOS setup has five menu items on the menu bar. These are:
❑
Main
❑
Advanced
❑
Power
❑
Boot
❑
Exit
Options that you can change are enclosed in brackets. Text that is not
enclosed in brackets cannot be changed.
A small triangle ( ) indicates that there is a sub-menu with additional
information and options. Press Enter to display the sub-menu. The
information and options in a sub-menu are context-sensitive (they appear
or disappear, depending on which options you select).
The item shown in [brackets] in this guide is the default option. The
option shown in [brackets] on the screen is the option currently set for
your system.
The other available options for each item are shown without brackets
directly below the default option in this guide. The available options are
listed in the order they occur when you press the + key.
Use the left and right arrow keys to choose a menu item. Use the up and
down arrow keys to select an option. Press Enter to display a list of
options, or press the + or - key to cycle through the other options.
If you display the list of options, use the up and down arrow keys to
select an option in the list, then press Enter to choose the selection.
Press Esc to go back to the main menu.
51
52
VAIO Computer System Reference Manual
Press F10 to save the changes and exit, or press Esc to discard the
changes.
Follow the on-screen prompts for other choices. The bottom of the screen
presents a summary of the keys to use for navigation and control.
CMOS Setup Options
53
Main Screen
System Time
[00:00:00]
System Date
[01/01/2002]
Primary Master (see “IDE Sub-Menus” on page 54)
Primary Slave (see “IDE Sub-Menus” on page 54)
Secondary Master (see “IDE Sub-Menus” on page 54)
Secondary Slave (see “IDE Sub-Menus” on page 54)
Supervisor Password
[Disabled]
User Password
[Disabled]
Installed Memory
See online specifications sheet for details.
BIOS Revision
1003
54
VAIO Computer System Reference Manual
IDE Sub-Menus
Type
[Auto]
User Type HDD
CD-ROM
LS-120
MO
Other ATAPI Device
None
Translation Method*
[LBA]
Large
Normal
Match Partition Table
Manual
Cylinders†
[1024]
Heads†
[255]
Sectors‡
CHS Capacity
[63]
*
8422 MB
Maximum LBA Capacity*
30735 MB
Multi-Sector Transfers*
[Maximum]
Disabled
2 Sectors
4 Sectors
8 Sectors
16 Sectors
32 Sectors
SMART Monitoring*
[Disabled]
Enabled
PIO Mode**
[4]
ULTRA DMA Mode†
[5]
Set Device As††
[Auto]
Floppy
Hard Disk
* This option appears when Type is set to User Type HDD. Actual capacity depends on product.
† This option appears when Type is set to Auto or User Type HDD.
‡ This option appears when Type is set to Auto or User Type HDD.
** This option appears when Type is not set to None.
†† This option appears when Type is set to MO.
CMOS Setup Options
55
Advanced Screen
CPU Speed
See online specifications sheet for details.
I/O Device Configuration
Onboard AC97 Audio Controller
Onboard AC97 Modem Controller
[Enabled]
Disabled
Onboard 1394 Controller
[Enabled]
Disabled
Onboard LAN Controller
[Enabled]
Disabled
Onboard Serial Port 1
[3F8H/IRQ4]
2F8H/IRQ3
3E8H/IRQ4
2E8H/IRQ10
Disabled
Onboard Parallel Port
[378H/IRQ7]
278H/IRQ5
Disabled
3BCH/IRQ7
Parallel Port Mode
[Normal]
EPP
ECP
ECP+EPP
PCI Configuration
Slot 1 IRQ
to
Slot 4 IRQ
[Auto]
NA
3
4
5
7
9
10
11
12
14
15
Onboard LAN Boot ROM
[Disabled]
Enabled
56
VAIO Computer System Reference Manual
Power Screen
Power Up Control
AC Power Loss Restart
[Disabled]
Enabled
Power Up On Modem Act
[Disabled]
Enabled
Wake On LAN
[Disabled]
Enabled
Hardware Monitor
MB Temperature
[(displays actual temperature)]
Ignore
CPU Temperature
[(displays actual temperature)]
Ignore
CPU Fan Speed
[(displays actual RPM)]
Ignore
Power Fan Speed
[(displays actual RPM)]
Ignore
VCORE Voltage
[(displays actual voltage)]
Ignore
+3.3V Voltage
[(displays actual voltage)]
Ignore
+5V Voltage
[(displays actual voltage)]
Ignore
+12V Voltage
[(displays actual voltage)]
Ignore
CMOS Setup Options
Boot Screen
1. ATAPI CD-ROM
[(displays installed drive)]
Disabled
2. Removable Device
[Legacy Floppy]
LS120
ATAPI MO
Disabled
3. IDE Hard Drive
[(displays installed drive)]
Disabled
4. Other Boot Device
[Disabled]
Network
SCSI Boot Device
Silent Boot
[Enabled]
Disabled
57
58
VAIO Computer System Reference Manual
Exit Screen
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Chapter 6
Miscellaneous Technical
Information
This chapter contains information on the following subjects:
❑
User and Supervisor password
❑
Beep code error messages
❑
PCI configuration status and error messages
❑
DMA channel assignments
❑
System I/O address map
❑
Memory map
❑
IRQ settings
59
60
VAIO Computer System Reference Manual
User and Supervisor Passwords
The system allows you to specify up to two passwords (a User password
and a Supervisor password) in the CMOS Setup Utility. The User
password is required; the Supervisor password is optional.
Access to the CMOS Setup Utility depends on which passwords were
previously set, as indicated next.
If you set these passwords...
...the following passwords are required:
User password only
User password is required at bootup.
Supervisor password only
No password is required at bootup.
Supervisor password is required by most
setup options.
Both passwords
User password is required at bootup.
Supervisor password is required by most
setup options.
Miscellaneous Technical Information
61
Beep Code Error Messages
During a normal bootup, a single short beep signifies that the system is
OK. Other beep patterns signify errors. The number of beeps indicates the
specific error that occurred.
If a system error occurs, the Sony Online Support technicians require the
number of beeps your system produces.
62
VAIO Computer System Reference Manual
PCI Configuration Status and Error Messages
The following is a list of status and error messages that may appear on
your system from time to time.
Message
Meaning
Floppy Disk Controller
Resource Conflict
The floppy disk controller has requested a
resource that is already in use.
CMOS Checksum Error,
CMOS Cleared
The CMOS data was reinitialized due to a
CMOS checksum error.
CMOS Data Invalid,
CMOS Cleared
Invalid entry in the CMOS.
Parallel Port Resource Conflict
The parallel port has requested a resource that
is already in use.
PCI Error Log is Full
This message is displayed when more than 15
PCI conflict errors are detected. No additional
PCI errors can be logged.
PCI I/O Port Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI IRQ Conflict
Two devices requested the same resource,
resulting in a conflict.
PCI Memory Conflict
Two devices requested the same resource,
resulting in a conflict.
Primary Boot Device Not
Found
The designated primary boot device (hard disk
drive, floppy disk drive, CD-ROM drive, or
network drive) could not be found.
Primary IDE Controller
Resource Conflict
The primary IDE controller has requested a
resource that is already in use.
Primary Input Device Not
Found
The designated primary input device
(keyboard, mouse, or other, if input is
redirected) could not be found.
Primary Output Device Not
Found
The designated primary output device (display,
serial port, or other, if input is redirected) could
not be found.
Secondary IDE Controller
Resource Conflict
The secondary IDE controller has requested a
resource that is already in use.
Serial Port 1 Resource Conflict
Serial port 1 has requested a resource that is
already in use.
Static Device Resource Conflict
A device has requested a resource that is
already in use.
System Board Device Resource
Conflict
A device has requested a resource that is
already in use.
Miscellaneous Technical Information
63
DMA Channel Assignments
This shows the factory default values. The Windows® operating system
reassigns resources to best meet the needs of a particular configuration.
DMA
Channel
Default Assignment
Channel 4
Direct memory access controller
Channel 2
Standard floppy disk controller
64
VAIO Computer System Reference Manual
System I/O Address Map
Address Range (hex)
Description
0x00000000-0x00000CF7
PCI bus
0x00000000-0x00000CF7
Direct memory access controller
0x00000D00-0x0000FFFF
PCI bus
0x0000D000-0x0000DFFF
SiS Accelerated Graphics Port
0x000003B0-0x000003BB
SiS Accelerated Graphics Port
0x000003B0-0x000003BB
SiS 650_651_M650_740
0x000003C0-0x000003DF
SiS Accelerated Graphics Port
0x000003C0-0x000003DF
SiS 650_651_M650_740
0x0000D800-0x0000D87F
SiS 650_651_M650_740
0x00000A79-0x00000A79
ISAPNP Read Data Port
0x00000279-0x00000279
ISAPNP Read Data Port
0x00000274-0x00000277
ISAPNP Read Data Port
0x0000E400-0x0000E47F
Motherboard resources
0x0000E600-0x0000E67F
Motherboard resources
0x00000480-0x0000048F
Motherboard resources
0x00000010-0x0000001F
Motherboard resources
0x00000022-0x0000002D
Motherboard resources
0x00000030-0x0000003F
Motherboard resources
0x00000044-0x0000005F
Motherboard resources
0x00000062-0x00000063
Motherboard resources
0x00000065-0x0000006F
Motherboard resources
0x00000074-0x0000007F
Motherboard resources
0x00000091-0x00000093
Motherboard resources
0x000000A2-0x000000BF
Motherboard resources
0x000000E0-0x000000EF
Motherboard resources
0x000004D0-0x000004D1
Motherboard resources
0x00000020-0x00000021
Programmable interrupt controller
0x000000A0-0x000000A1
Programmable interrupt controller
0x00000080-0x00000090
Direct memory access controller
0x00000094-0x0000009F
Direct memory access controller
0x000000C0-0x000000DF
Direct memory access controller
0x00000040-0x00000043
System timer
0x00000070-0x00000073
System CMOS/real time clock
Miscellaneous Technical Information
Address Range (hex)
Description
0x00000061-0x00000061
System speaker
0x000000F0-0x000000FF
Numeric data processor
0x000003F2-0x000003F5
Standard floppy disk controller
0x000003F7-0x000003F7
Standard floppy disk controller
0x00000378-0x0000037F
Printer Port (LPT1)
0x000003F8-0x000003FF
Communications Port (COM1)
0x00000060-0x00000060
Standard 101/102-Key or Microsoft®
Natural PS/2® Keyboard
0x00000064-0x00000064
Standard 101/102-Key or Microsoft
Natural PS/2 Keyboard
0x0000002E-0x0000002F
Motherboard resources
0x00000295-0x00000296
Motherboard resources
0x0000B800-0x0000B80F
SiS PCI IDE Controller
0x000001F0-0x000001F7
Primary IDE Channel
0x000003F6-0x000003F6
Primary IDE Channel
0x00000170-0x00000177
Secondary IDE Channel
0x00000376-0x00000376
Secondary IDE Channel
0x0000B400-0x0000B4FF
Agere Systems AC'97 Modem
0x0000B000-0x0000B07F
Agere Systems AC'97 Modem
0x0000A800-0x0000A8FF
SiS 7012 Audio Driver
0x0000A400-0x0000A47F
SiS 7012 Audio Driver
0x0000A000-0x0000A0FF
Realtek RTL8139/810X Family Fast
Ethernet NIC
✍ I/O addresses that may be used by add-in cards are not listed.
65
66
VAIO Computer System Reference Manual
Memory Map
Address range
Default configuration
0x0000-0x9FFFF
System board
0xA0000-0xBFFFF
PCI bus
0xA0000-0xBFFFF
SiS Accelerated Graphics Port
0xA0000-0xBFFFF
SiS 650_651_M650_740
0xC8000-0xDFFFF
PCI bus
0xF0000-0xFFFFF
System board
0x100000-0xDFFFFFF
System board
0xE000000-0xFFFFFFFF
PCI bus
0xE9800000-0xE9800FFF
NEC OHCI Compliant IEEE 1394 Host Controller
0xEA000000-0xEA0000FF
Realtek RTL8139/810X Family Fast Ethernet NIC
0xEA800000-0xEA800FFF
SiS 7001 PCI to USB Open Host Controller
0xEB000000-0xEB000FFF
SiS 7001 PCI to USB Open Host Controller
0xEB800000-0xEBFFFFFF
SiS Accelerated Graphics Port
0xEB800000-0xEBFFFFFF
SiS 650_651_M650_740
0xEC000000-0xEFFFFFFF
SiS Accelerated Graphics Port
0xF0000000-0xFEBFFFFF
SiS Accelerated Graphics Port
0xF0000000-0xFEBFFFFF
SiS 650_651_M650_740
0xFEC00000-0xFEC000FF
System board
0xFEE00000-0xFEE00FFF
System board
0xFFEE0000-0xFFEFFFFF
System board
0xFFEE0000-0xFFEFFFFF
Motherboard resources
0xFFFE0000-0xFFFFFFFF
Motherboard resources
Miscellaneous Technical Information
IRQ Settings
IRQ
Description
0
System timer
1
Standard 101/102-Key or Microsoft Natural PS/2
Keyboard
4
Communications Port (COM1)
6
Standard floppy disk controller
8
System CMOS/real time clock
9
Microsoft ACPI-Compliant System
12
PS/2 Compatible Mouse
13
Numeric data processor
14
Primary IDE Channel
15
Secondary IDE Channel
16
SiS 650_651_M650_740
17
Realtek RTL8139/810X Family Fast Ethernet NIC
18
Agere Systems AC'97 Modem
18
NEC OHCI Compliant IEEE 1394 Host Controller
18
SiS 7012 Audio Driver
19
SiS 7001 PCI to USB Open Host Controller
19
SiS 7001 PCI to USB Open Host Controller
67
68
VAIO Computer System Reference Manual
Chapter 7
Specifications
This chapter describes the technical specifications for your computer.
Processor
See online specifications sheet for details.
Chipset
SiS 740 chipset
PCI Bus
PCI Level 2.2, 33 MHz zero wait state
4 PCI slots, 3 open for expansion.
69
70
VAIO Computer System Reference Manual
Memory Modules
Installed memory
See online specifications sheet for details.
Maximum memory
1 GB (512 in each socket)
Voltage
2.5 V memory only
Pins
184-pins with gold-plated contacts
Memory type
2.5 V PC2100 DDR-SDRAM unrestricted, unbuffered,
64-bits (Non-ECC) DDR-SDRAM DIMM modules
Memory Configurations
DIMM1*
DIMM2*
0, 128, 256, 512
0, 128, 256, 512
*
Your computer is shipped with at least 256 MB. SDRAM is expandable to 1 GB. Computer SDRAM is
unbuffered DDR-DIMM, specification Rev. 1.0 or later. DDR-DIMMs must be 2.5 V unbuffered 4-clock,
between sockets. 64-bit or 72-bit 133 MHz SDRAM modules.
L2 Cache
Installed
256 KB
Graphics
Chipset
SiS 740 integrated graphics
Video memory
See online specifications sheet for details.
Resolution (displayed resolution depends on the video monitor you use)*
True color (24-bits) Up to 1280 x 1024 at 85 Hz non-interfaced
High color (16-bits) Up to 1280 x 1024 at 85 Hz non-interfaced
256 colors (8-bits)
*
Up to 1600 x 1200 at 75 Hz non-interfaced
The use of 1024 x 768 True color (24-bits) or High color (16-bits) at 75 Hz or lower refresh rate is
recommended for video playback applications.
Specifications
71
Audio
Sound chip
SiS 7012
Wave synthesis
Software synthesis
Audio sampling rate
Up to 48 kHz at 16-bits
Rear panel connectors
Mic (for microphone)
Line In (from stereo audio source)
Headphones (for stereo headphones)
Communications
Modem*
V.90 compatible data/fax modem†
Fax
14.4 Kbps maximum
i.LINK® (IEEE 1394)
400 Mbps, OHCI chipset
Ethernet
10BASE-T/100BASE-TX
*
†
Installed modem may vary, depending on the system configuration purchased.
This modem is capable of downloading at 56 Kbps. Your phone service, online service, or Internet Service
Provider may not support this technology or operate at this speed.
72
VAIO Computer System Reference Manual
I/O and Expansion Slots
Serial ports
One high-speed NS16C550-compatible port
Parallel port
One high-speed bi-directional Centronicscompatible port with ECP and EPP modes
Modem jacks
Two RJ-11 jacks (telephone and line)
USB
ports*
USB1 and USB2 (on front panel)
USB3 and USB4 (on rear panel)
(See online specifications sheet for details.)
PCI slots
Four available slots. Not all PCI slots are available
for expansion.
CNR slot
One slot for a CNR modem.
IDE headers
Primary and secondary
(each supports two ATA-100 IDE drives)
i.LINK® (IEEE 1394)
ports
One 4-pin port on front panel
One 6-pin port on rear panel
*
Universal Serial Port (USB) technology only supports version 1.1.
Floppy Disk Drive and Controller
Drive
Description
Floppy disk controller
82077-compatible (supports up to 2.88 MB)
Floppy disk drive
3.5-inch, 1.44 MB
Hard Drives and Controller
Drive
Description
EIDE controller
Supports up to four EIDE drives (supports PIO Mode 4
EIDE drives and Ultra DMA/100 Mode drives)
IDE hard drive*
See online specifications sheet for details.
*
Bus-mastering EIDE driver installed.
Specifications
73
Optical Drives
Drive
Description
Optical drive #1
See online specifications sheet for details.
Optical drive #2
See online specifications sheet for details.
System BIOS
Make and model
Award-based
ROM
2 Mb Flash-ROM
Passwords
User and supervisor passwords supported
Power management
APM 1.2
Advanced features
ACPI-1.0 compliant hardware for use with APM and
PNP BIOS APIs
Plug and Play devices
Supported with steerable DMA channels and
interrupts
Special features
PC-99 compliant, multi-boot, PCI add-in card
auto-configure
74
VAIO Computer System Reference Manual
Index
A
add-in card
installing 28
removing 26
address map, system 64
audio specifications 71
cover
for slot 38
removing 24
replacing 25
covering I/O slot 39
CPU - See processor
B
D
battery - See lithium battery
beep codes 61
BIOS setup utility 16
advanced screen 55
boot screen 57
exit screen 58
main screen 53
options 51
power screen 56
screens 51
BIOS specifications 73
DIMM - See memory module
display, power management 17
disposal of lithium battery vii
DMA channel assignments 63
drives
installing additional drive 40
C
CMOS - See BIOS
CMOS Clear configuration jumper 50
codes, beeps 61
communications, specifications 71
computer
lithium battery vii
configuration jumper, CMOS Clear 50
configuring
BIOS setup utility 16
power management 17
connectors
i.LINK 6
USB 6
E
Energy Star ii
error messages
beep codes 61
PCI configuration 62
expansion slots 14
specifications for 72
expansion slots - See slots
F
fax/modem - See communications
front view 2
buttons and switches 4
connectors 5, 6
drives 3
indicators 5
75
76
VAIO Computer System Reference Manual
G
M
graphics controller - See graphics
graphics specifications 70
map - See I/O address map and
memory map
memory - See system memory
memory module
connector 48
removing 33
specifications for 70
messages
error 61
status and error 62
mic connector 12
microprocessor - See processor
modem - See communications
monitor - See display
monitor connector 11
mouse connector 10
H
headphones connector 12
I
i.LINK connector 6, 13
I/O
address map 64
slot specifications 72
I/O connectors
headphones 12
i.LINK 13
keyboard 10
line 12
line in 12
mic 12
monitor 11
mouse 10
printer 11
serial 10
telephone 12
USB 10
I/O slot covering 39
icons, description of 8
IEEE 1394 - See i.LINK
installing
add-in card 28
hard disk drive 40
system memory 35
IRQ settings 67
K
keyboard connector 10
L
L2 cache specifications 70
line in connector 12
lithium battery
disposal vii
replacing 30
safety precautions vii
O
online specifications 1
Optical drive
location of 3
performance of discs 3, 73
P
passwords, user and supervisor 60
power management, configuring 17
printer connector 11
R
RAM - See system memory
rear view 7
I/O connectors 10
icons 8
removing
add-in card 26
cover 24
memory module 33
slot cover 38
replacing cover 25
replacing lithium battery 30
resolution - See graphics
Index
S
serial connector 10
setup, BIOS 16
slot - See I/O slot
slot cover, removing 38
specifications
audio 71
BIOS 73
chipset 69
communications 71
DIMM configurations 70
floppy disk drive and controller 72
graphics 70
hard drives and controllers 72
I/O and expansion slots 72
L2 cache 70
memory module 70
optical drives 73
PCI bus 69
processor 69
system BIOS 73
status and error messages 62
supervisor password 60
system board
configuration jumper 50
memory module connector 48
system I/O address map 64
system memory, installing 35
T
telephone connector 12
U
USB connectors 6, 10
user password 60
77
78
VAIO Computer System Reference Manual
Download PDF
