Sony PEG-NR70V/U User manual

Sony PEG-NR70V/U User manual
4-662-642-11(1)
Chapter 1
What is the Sony
CLIÉ Handheld?
Chapter 2
Setting up your Sony
CLIÉ Handheld
– Basics
Read
This
First
Personal Entertainment Organizer
PEG-NR70V/U
PEG-NR70/U
© 2002 Sony Corporation
Chapter 3
Setting up your Sony
CLIÉ Handheld
– Advanced
WARNING
To prevent fire or shock hazard, do
not expose the unit to rain or
moisture. To avoid electrical shock,
do not open the cabinet. Refer
servicing to qualified personnel
only.
For customers in the U.S.A and
Canada
Owner’s Record
The model number and serial number are
located on the back of the product. Record
the model number and the serial number in
the space provided below. Refer to them
whenever you call upon your Sony dealer
regarding this product.
Model No._____________
Serial No.______________
The socket-outlet shall be installed near the
equipment and shall be easily accessible.
CAUTION
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numerique de la classe B est
conforme a la norme NMB-003 du Canada.
NOTE
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates, uses,
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
2
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
rotating the equipment off and on, the user
is encouraged to try to correct the
interference using one or more of the
following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
If you have a question about this product,
call the Sony Customer Information Center
at keep on next line 1-877-760-7669; or write
to the Sony Customer Information Center at
12451 Gateway Boulevard, Fort Myers, FL
33913. The number below is for FCC-related
matters only.
Declaration of Conformity
Trade Name: SONY
Model No.: PEG-NR70V/U
PEG-NR70/U
Responsible Party: Sony Electronics Inc.
Address: 680 Kinderkamack Road,
Oradell, NJ 07649 USA
Telephone No.: 201-930-6972
This device complies with part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any
interference received, including
interference that may cause
undesired operation.
The supplied interface cable must be used
with the equipment in order to comply with
the limits for a digital device pursuant to
Subpart B of Part 15 of FCC Rules.
Notes
RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are
recyclable.
You can help preserve our
environment by returning
your used rechargeable
batteries to the collection and recycling
location nearest you.
For more information regarding
recycling of rechargeable batteries, call
toll free 1-800-822-8837, or visit
http://www.rbrc.org/
Caution: Do not handle damaged or
leaking lithium-ion batteries.
On the supplied software
• Copyright laws prohibit reproducing
the software or the software manual in
whole or in part or renting the software
without the permission of the copyright
holder.
• In no event will SONY be liable for any
financial damage or loss of profits,
including claims made by third parties,
arising out of the use of the software
supplied with this player.
• In the event a problem occurs with this
software as a result of defective
manufacturing, SONY will replace it at
SONY’s option or issue a refund.
However, SONY bears no other
responsibility.
• The software provided with this
product cannot be used with equipment
other than that which it is designated
for use with.
• Please note that, due to continued
efforts to improve quality, the software
specifications may be changed without
notice.
• The software library incorporated in
CLIÉ™ handheld is based in part on the
work of the Independent JPEG Group.
Program © 2002 Sony Corporation, © 2002
Palm, Inc., or its subsidiaries. All rights
reserved.
Documentation © 2002 Sony Corporation
CAUTION
Please contact your nearest Sony dealer
regarding any problems you are
experiencing with your Sony product.
• Sony does not support third-party add-on
applications. If you are having a problem
with a third-party application, please contact
the developer or publisher of that software.
• The illustrations in this manual may
differ from the actual software.
• Explanations in this manual assume that
you are familiar with basic operations of
Windows®. For how to use your
computer and operating system, please
refer to their respective manuals.
Before using your CLIÉ handheld, be sure to
read the accompanying End-User’s License
Agreement.
Sony, Memory Stick, the Memory Stick logo,
Jog Dial, OpenMG, and PictureGear are
trademarks of Sony Corporation.
Graffiti, HotSync, and Palm OS are
registered trademarks, and the HotSync logo
and Palm are trademarks of Palm, Inc. or its
subsidiaries.
IBM and PC/AT are registered trademarks
of International Business Machines
Corporation.
Microsoft, Windows, Windows NT,
Outlook, DirectX, and the Windows 98 logo
are registered trademarks of Microsoft
Corporation.
MMX and Pentium are registered
trademarks of Intel Corporation.
Pumatech, the Pumatech logo, Intellisync
and Intellisync Lite are trademarks of
Pumatech, Inc., that may be registered in
some jurisdictions.
Adobe and Adobe Acrobat Reader are
trademarks of Adobe Systems Incorporated.
PrimoSDK for CD
Partial software replication technology by
VERITAS Software Corporation.
QuickTime and the QuickTime logo are
trademarks used under license. QuickTime
is registered in the U.S. and other countries.
This product includes fonts owned by
TypeBank Co., Ltd. under license.
All other trademarks are trademarks of their
respective owners.
Sample movies and music: cocoro~.prc
(from DVD Hawaiian Breeze - KOHALA
Collection (CCBN-27013))
Music: Mango Cooler (Composed by Charles
Michael Brotman. Performed by KOHALA)
Copyright © 2001 cocoronetworks, inc.
Copyright © 1998, 2001 Palm Records, Inc.
All rights reserved.
http://www.cocoronet.com/en/
3
Table of Contents
About the manuals ........................... 5
Which manual to read? .................... 7
Chapter 1
What is the Sony CLIÉ Handheld?
What can you do with your Sony CLIÉ
Handheld? ...................................... 10
System requirements ..................... 12
Sony CLIÉ Handheld components .. 13
Locating the display and keyboard
panel controls .................................. 13
Locating back panel components .... 15
Changing the operating style .......... 17
Locating cradle components ............ 18
Elements of the CLIÉ interface ......... 19
What is on the CLIÉ Installation
CD-ROM? ........................................ 22
CD-ROM contents ............................ 22
How to read the PDF manuals on the
CD-ROM .......................................... 23
Chapter 2
Setting up your Sony CLIÉ
Handheld – Basics
Step 1: Charging your Sony CLIÉ
Handheld .................................... 26
Step 2: Turning on your Sony CLIÉ
Handheld for the first time ........ 27
Opening the display panel ............... 27
Making the initial setting ................ 28
Step 3: Entering data into your
Sony CLIÉ Handheld ................... 32
Step 4: Installing the Palm™
Desktop for CLIÉ software
on your computer ....................... 35
Step 5: Connecting your Sony CLIÉ
Handheld and your computer
via the cradle .............................. 39
Step 6: Performing a HotSync®
operation for the first time ........ 40
Chapter 3
Setting up your Sony CLIÉ
Handheld – Advanced
Checking the bundled applications
on your Sony CLIÉ Handheld .......... 44
Overview of basic Palm OS®
applications ..................................... 45
Overview of Sony applications ......... 48
Installing the supplied applications
on your computer .......................... 53
Installing SonicStage™ LE ................ 53
Installing PictureGear™ 4.5Lite ........ 54
Installing QuickTime® 5 ................... 54
Installing Memory Stick Export ........ 55
Installing Sound Converter .............. 55
Installing other third-party
applications ..................................... 56
Installing Acrobat Reader® 5.0 ........ 56
Uninstalling the supplied
applications ..................................... 57
Installing add-on applications on your
Sony CLIÉ Handheld or Memory Stick
media ............................................. 58
Installing add-on applications from the
Palm™ Desktop for CLIÉ software .... 59
Installing add-on applications by
beaming them from another
Palm OS® device .............................. 62
Installing add-on applications
directly from the Installation
CD-ROM menu ................................ 64
Removing add-on applications ........ 65
Customer registration .................... 66
4
About the manuals
Welcome to the Sony Personal Entertainment Organizer (referred to as
the “CLIÉ handheld” or “Sony CLIÉ Handheld” in this manual).
Your CLIÉ handheld comes with three manuals:
■ Read This First (this guide)
■ Operating Instructions (as a PDF file on the CD-ROM)
■ Add-on Application Guide
Before using your CLIÉ handheld, read this guide for an overview of
features, setup and installation instructions, and other important
details.
After you set up your CLIÉ handheld and become familiar with its
basic functions, you can use the other two manuals (Operating
Instructions and Add-on Application Guide) as references for detailed
features, less common tasks, and maintenance of your CLIÉ handheld.
These manuals can also serve as a source of information if you have
problems operating your CLIÉ handheld.
The contents of the three manuals are as follows.
Read This First (this guide)
This guide is designed to help you quickly get your CLIÉ handheld up
and running.
This guide shows you how to:
■ Identify all the parts of your CLIÉ handheld
■ Set up your CLIÉ handheld
■ Install supplied applications on your CLIÉ handheld and your
computer
■ View and enter data
Continued on next page
5
About the manuals
Operating Instructions
The Operating Instructions manual is available on the supplied CDROM as a PDF file; you can view or print the file as necessary.
The manual describes how to use your CLIÉ handheld and the
Personal Information Management (PIM) applications that come with
your CLIÉ handheld.
Additionally, the manual shows you how to:
■ View and enter data in greater detail
■ Use your CLIÉ handheld with your computer
■ Use Personal Information Management applications (Date Book,
Address Book, To Do List, Memo Pad, and Calculator)
■ Personalize your CLIÉ handheld with your own preference settings
■ Back up the data on your CLIÉ handheld
■ Maintain your CLIÉ handheld
Add-on Application Guide
The Add-on Application Guide describes how to install and use the
supplied add-on applications, including:
■ Audio Player and SonicStage LE
■ CLIÉ Camera (PEG-NR70V/U only)
■ PictureGear™ Pocket, PhotoStand, and PictureGear 4.5Lite
■ CLIÉ Paint
■ gMovie™
■ CLIÉ Mail
■ World Alarm Clock
■ CLIÉ Remote Commander
■ Sound Utility and Sound Converter
■ Memory Stick Autorun (MS Autorun)
■ Memory Stick Import (MS Import) and Memory Stick Export (MS Export)
The three manuals all describe operations of two models of the CLIÉ
handheld (PEG-NR70V/U and PEG-NR70/U). All illustrations of the
unit are of PEG-NR70V/U, unless specified otherwise. Differences
between the two models are described in their relative sections.
6
Which manual to read?
After you set up your CLIÉ handheld and become familiar with its
basic functions, you can refer to the rest of the manuals as follows:
When you want to:
Read:
Manage your personal
information using your
CLIÉ applications.
Operating Instructions
Chapter 2
Using basic applications
Synchronize data between
your CLIÉ handheld and
your computer.
Operating Instructions
Chapter 3
Exchanging and updating data
using a HotSync® operation
Exchange and share
information with other
handheld users.
Operating Instructions
Chapter 4
Communicating using your
Sony CLIÉ Handheld
Enjoy music on your CLIÉ
handheld.
Add-on Application Guide
Chapter 1
Playing audio files
(Audio Player)
Take pictures with your
CLIÉ handheld.
(PEG-NR70V/U only)
Add-on Application Guide
Chapter 2
Recording still images
(CLIÉ Camera)
View images on your CLIÉ
handheld.
Add-on Application Guide
Chapter 3
Viewing image files
(PictureGear Pocket)
Draw on image files on
your CLIÉ handheld.
Add-on Application Guide
Chapter 4
Drawing on image files (CLIÉ Paint)
Watch movies on your
CLIÉ handheld.
Add-on Application Guide
Chapter 5
Playing a movie (gMovie player)
Continued on next page
7
Which manual to read?
8
Exchange e-mail using
your CLIÉ handheld.
Add-on Application Guide
Chapter 6
Exchanging e-mail
(CLIÉ Mail)
View the World Alarm
Clock on your CLIÉ
handheld.
Add-on Application Guide
Chapter 7
Viewing the World Alarm Clock
(World Alarm Clock)
Use your CLIÉ handheld as
a remote control for TV,
VCR, or DVD player.
Add-on Application Guide
Chapter 8
Using your CLIÉ handheld as a
remote control
(CLIÉ Remote Commander)
Import your favorite
sound files from your
computer to your CLIÉ
handheld.
Add-on Application Guide
Chapter 9
Importing your favorite sound files
(Sound Utility/Sound Converter)
Set your favorite
application to start
automatically whenever
you insert a Memory Stick
media.
Add-on Application Guide
Chapter 10
Setting the Memory Stick automatic
start function
(Memory Stick Autorun)
Transfer data between your
CLIÉ handheld and your
computer using a Memory
Stick media.
Add-on Application Guide
Chapter 11
Copying data to the Memory Stick
media in your CLIÉ handheld
(Memory Stick Import/Export)
Chapter 1
Chapter 1
What is the Sony CLIÉ Handheld?
This chapter describes the features of your CLIÉ handheld, its
system requirements, its buttons and controls, and the
contents of the Installation CD-ROM.
Contents
What can you do with your Sony CLIÉ Handheld? ..................... 10
System requirements ................................................................. 12
Sony CLIÉ Handheld components ..............................................
Locating the display and keyboard panel controls .................
Locating back panel components .........................................
Changing the operating style ...............................................
Locating cradle components ................................................
Elements of the CLIÉ interface .............................................
13
13
15
17
18
19
What is on the CLIÉ Installation CD-ROM? ............................... 22
CD-ROM contents ............................................................... 22
How to read the PDF manuals on the CD-ROM .................... 23
What can you do with your Sony CLIÉ Handheld?
Once you familiarize yourself with the basic workings of your CLIÉ
handheld, you’ll easily be able to:
■ Enter all your schedule details in the Date Book and view them by
the day, week, or month, and even set an alarm to remind you of an
important event.
■ Keep all your contact names, addresses, phone numbers, and other
details in the Address Book. In addition, you can paste an image to
an address record using the supplied PictureGear™ Pocket
application.
■ Add your tasks to the To Do List, prioritize them, and assign them
a due date.
■ Synchronize your data with the Palm™ Desktop for CLIÉ software
on your computer so you always have a backup copy of your
important information.
■ Customize your CLIÉ handheld and set different levels of security
to prevent unauthorized users from viewing your data.
■ Exchange data with your computer, other Sony CLIÉ handhelds,
digital cameras, and other portable devices with Sony’s Memory
Stick™ media.
Beyond the basic features, your CLIÉ handheld offers many
entertaining and unique convieniences. For example, you can:
■ Take music (MP3 or ATRAC3 audio files) wherever you go, playing
them back with the Audio Player application.
■ Use your CLIÉ handheld as a digital still camera, recording still
images with the CLIÉ Camera application (PEG-NR70V/U only).
The recorded images can be edited with the CLIÉ Paint application,
and managed with the PictureGear Pocket application. You can
view the images on your computer using the PictureGear® Lite
software (if you convert the images to DCF format with the
PictureGear Pocket or the CLIÉ Paint application, you can use other
browsers to view them as well).
10
■ Watch a movie with the gMovie™ application.
■ Write, send, and receive e-mail with the CLIÉ Mail application. You
can also attach and send image files managed with the PictureGear
Pocket application and receive those sent to you. Received images
in PGP or DCF format can be viewed on your CLIÉ handheld with
the PictureGear Pocket application.
Note
If your CLIÉ handheld is not connected to a network, you cannot directly
send or receive e-mails with it, but must perform a HotSync operation with a
computer connected to the network.
■ Keep track of time around the world with the World Alarm Clock
application, which also works as an alarm clock.
■ Replace the remote controls of your TV, VCR, DVD player, or other
device with your CLIÉ handheld using the CLIÉ Remote
Commander application.
■ Use other add-on applications for the Palm OS®.
■ Enjoy Web Clipping*.
* Web Clipping is a system provided by Palm, Inc. and its subsidiaries for
Palm OS handhelds, which enables easy access to information provided on
the Web. If you install various Web Clipping applications on your CLIÉ
handheld, you can retrieve specific information such as news, weather, or
restaurant guides and display them on your CLIÉ handheld. Web clipping
applications require Internet connections. For details on its use, or for
answers to your questions, refer to the following Web site:
http://www.palm.com/wireless/
11
What is the Sony CLIÉ Handheld?
■ Make original drawings or edit image files with the CLIÉ Paint
application.
Chapter 1
■ Create a slideshow of images, including transition effects, using the
PhotoStand feature of the PictureGear Pocket application.
System requirements
To install and operate the Palm™ Desktop software on your computer,
your computer system must meet the following requirements:
■ OS:
-Microsoft® Windows® 98 Second Edition
-Windows® Millennium Edition
-Windows® 2000 Professional
-Windows® XP Home Edition
-Windows® XP Professional
■ CPU: MMX Pentium® 233 MHz or faster
(Pentium III 450MHz or faster recommended)
■ RAM: 64MB or more
(128MB or more recommended for Windows® XP)
■ Hard disk drive: 150MB or more available space
(350MB or more recommended)
■ Display: High Color or better (800 × 600 pixels or more)
■ CD-ROM drive
■ Mouse or similar pointing device
■ One available USB connector
Notes
• To install the Palm Desktop for CLIÉ software on Windows® 2000 Professional
or Windows® XP , log on as “Administrator.”
• Macintosh computers are not compatible with the Sony CLIÉ Handheld.
12
Sony CLIÉ Handheld components
Chapter 1
Locating the display and keyboard panel controls
What is the Sony CLIÉ Handheld?
1 Display panel
Open, or open and rotate to use the CLIÉ handheld in various
“styles.” For details, see “Changing the operating style” on page 17.
2 Camera (PEG-NR70V/U only)
Rotates to face the subject of your photograph.
When not in use, rotate the camera towards the keyboard panel
until it clicks into place.
3 CAPTURE Button (PEG-NR70V/U only)
Press to capture still images with the camera.
4 Headphone jack
Plug into the supplied headphones jack with a remote control unit
or stereo mini jack. For details, see “Connecting/attaching the
supplied headphones” in the Add-on Applications Guide.
5 Jog Dial™ Navigator
Used to select and run applications or items. Depending on the
application you use, specific functions are assigned to the navigator.
For details, see “Using the Jog Dial™ navigator” in the Operating
Instructions manual.
Continued on next page
13
Sony CLIÉ Handheld components
6 BACK Button
Deselects an item or cancels the operation. Depending on the
application you use, returning to the previous screen or other
specific functions are assigned to this button.
7 HOLD Switch
Protects your CLIÉ handheld from accidental tapping on the screen
or pressure on the POWER button when you are carrying your
CLIÉ handheld. If you slide this switch while the power is on, the
screen display turns off, even during an operation.
Sliding the switch again deactivates HOLD and resumes normal
operation.
8 Screen
Displays the applications and information stored in your CLIÉ
handheld. It is touch-sensitive and responds to the stylus. For
details, see “Elements of the CLIÉ interface” on page 19.
9 LED indicator
Flashes to notify you at a given time if you set an alarm in Date
Book or the World Alarm Clock application. Also lights while
charging the battery and turns off when charging is complete.
0 POWER Button
Turns your CLIÉ handheld on or off. Also, press the POWER button
and hold it down for two seconds or longer to turn the backlight of
the LCD display on or off.
The power indicator lights while the power is on.
Tip
If your CLIÉ handheld is turned off, pressing any application button
activates your CLIÉ handheld and opens the corresponding application.
qa Application Buttons
Activates the individual applications that correspond to the icons on
the buttons:
Date Book,
Address Book,
To Do List, and
Memo Pad. See “Assigning applications to buttons” in the
Operating Instructions manual for details on reassigning these
buttons to activate any application on your CLIÉ handheld.
14
qd Hardware Keyboard
Used to enter texts and other commands.
Locating back panel components
1 Stylus
Used to tap icons and buttons on the screen or to write characters
on the Graffiti writing area.
For details, see “Using the stylus” in the Operating Instructions
manual.
Continued on next page
15
What is the Sony CLIÉ Handheld?
Displays text and other information that extends beyond the area of
the screen. Pushing the scroll button downwards scrolls down to
display information below the current viewing area, and pushing
the button upwards scrolls up to display the information above the
current viewing area. Depending on the application you use,
specific functions are assigned to the scroll button.
Chapter 1
qs Scroll Button
Sony CLIÉ Handheld components
2 Infrared Communication Port (IR port)
Uses infrared technology to:
- transmit data to and receive data from other CLIÉ or Palm OS®
handhelds and to perform HotSync® operations.
For details, see “Beaming between your Sony CLIÉ Handheld
and another Palm OS® PDA” in the Operating Instructions
manual.
- remotely control devices with the CLIÉ Remote Commander
application. For details, see Chapter 8 in the Add-on Application
Guide.
3 Memory Stick Access Indicator
Lights in orange while your CLIÉ handheld is reading data from or
writing data to Memory Stick media.
4 Memory Stick™ Slot
Insert Memory Stick media into this slot.
5 Reset Button
Resets your CLIÉ handheld when it freezes. Under normal use, you
should not have to use this button.
For details, see “Resetting your Sony CLIÉ Handheld” in the
Operating Instructions manual.
6 Speaker
Speaker for the beep, sound alarm, and audio.
7 Interface Connector
Used to connect your CLIÉ handheld to the cradle or to other
accessories for the CLIÉ handheld (not supplied).
16
Chapter 1
Changing the operating style
What is the Sony CLIÉ Handheld?
Your CLIÉ handheld can be used with the display panel set in three
different styles:
– the convienient “opened style”
– the compact “turned style”
– the screen-guarding “carrying style.”
Turned style
Carrying style
Opened style
When using the CLIÉ handheld, set it to either the “opened style” (to
enter data with the hardware keyboard) or the “turned style” (to enter
data with the stylus), whichever you prefer.
In this and other supplied manuals, the operation steps will usually be
described with the CLIÉ handheld in the “turned style.”
When carrying your CLIÉ handheld around in your bag or pocket, set
it to the “carrying style.” You cannot enter data, but will be able to
continue listening to music, operating with the remote controller.
Notes
• The display panel in the “opened style” will not open wider than 160 degrees.
• When you have a camera module inserted in your CLIÉ handheld's Memory
Stick slot, take care not to hit the module when opening the display panel.
17
Sony CLIÉ Handheld components
Locating cradle components
1 Stylus holder
When you place your CLIÉ handheld on the cradle, keep the stylus
here.
2 Interface Connector
Connect your CLIÉ handheld here.
3 HotSync®
Button
Synchronizes data in your CLIÉ handheld with the data saved on
your computer.
For details, see “Exchanging and updating data using a HotSync®
operation” in the Operating Instructions manual.
4 USB Connector
Connects to your computer’s USB port.
5 AC Adapter Connector
Connect the supplied AC adapter here.
18
Chapter 1
Elements of the CLIÉ interface
What is the Sony CLIÉ Handheld?
1 Battery Icon
Displays the remaining charge in the battery. When your CLIÉ
handheld is placed in the cradle or operates on the AC power
source, the battery charging icon (
) is displayed. Tapping the
icon shows the battery’s remaining charge by percentage and the
amount of unused memory available in your CLIÉ handheld.
2 Graffiti Writing Area
This area is for hand writing input with the Graffiti alphabet. When
you use the software keyboard, the keyboard display will replace
the Graffiti writing area.
3 Home Icon
Tap this icon and the Application Launcher screen appears,
displaying a list of applications.
Continued on next page
19
Sony CLIÉ Handheld components
4 Menu Icon
Tap this icon to display the menus of the current application.
5 Brightness Adjustment Icon
Tap this icon to adjust the brightness level of the LCD screen of
your CLIÉ handheld.
Note
If the digitizer preferences are not set correctly, you cannot adjust the
brightness level properly. For details, see “Adjusting the screen” in the
Operating Instructions manual.
6 Status Bar
Displays the following icons for all applications. Additional icons
appear according to the applications in use.
: Tap to show or hide the Graffiti writing area (for Graffiti
compatible applications only).
: Tap this icon to display the Application Launcher screen.
: Tap this icon to display the menus of the current application.
: Tap this icon to open the Find screen.
: Appears when a Memory Stick media is inserted.
: Displays the battery’s remaining charge.
7 Application Icon
Tap an icon to activate the corresponding application.
8 Scroll Bar
Drag the slider up or down or tap the scroll arrows (v or V) on the
ends of the bar to scroll the screen.
9 Calculator Icon
Tap this icon to display the on-screen Calculator.
0 Find Icon
Tap this icon to open the Find screen.
qa Software Keyboard Icon
Tap this icon to switch the display between the Graffiti writing area
and the software keyboard.
20
Chapter 1
Tip
When the tip i icon is displayed, you can tap the icon to display online
operational tips on the screen.
Note on display resolutions
Your CLIÉ handheld uses a Sony original technology to provide a
320×480 dot high-resolution display. When you start an application
supporting the high-resolution, the screen switches automatically to
the high-resolution mode. When you start an application that does not
support high resolution, the screen returns to the standard 160×240 dot
resolution mode.
Notes
• When you enable the High-resolution Assist function, the screen may not be
displayed properly in some third-party applications.
• When switching applications with the High-resolution Assist function
disabled, the Graffiti writing area momentarily returns to the standard 160×240
dot resolution mode.
21
What is the Sony CLIÉ Handheld?
Tip i icon
What is on the CLIÉ Installation CD-ROM?
CD-ROM contents
The Installation CD-ROM that comes with your CLIÉ handheld
contains the following applications and manuals:
■ PC applications
You can install the following PC applications and related online
help files from the installer’s main launcher window:
– Palm Desktop for CLIÉ 4.0.1
(including Intellisync Lite 4.0)
– Sonic Stage™ LE
– PictureGear™ 4.5Lite
– QuickTime® 5
– Memory Stick™ Export
– Sound Converter
– CLIÉ Mail Conduit
– Documents to Go
The following PC application has a separate installer package:
– Adobe Acrobat Reader® 5.0
■ Palm OS applications
You can install the following Palm OS® applications on your CLIÉ
handheld:
– CLIÉ Mail
– World Alarm Clock
– CLIÉ Remote Commander
The following sample data and demonstration files are also
available:
– CLIÉ Demo
– Sample data for gMovie and PictureGear Pocket
– Sample sound files
– Sample Skin files for Audio Player
22
Tip
You can view the manuals by clicking Manuals in the installation launcher
window that appears when you insert the CLIÉ Installation CD-ROM into your
computer.
How to read the PDF manuals on the CD-ROM
To view the PDF manuals available on the Installation CD-ROM, you
need the Acrobat Reader software installed on your computer. To
install the Acrobat Reader software, see “Installing Acrobat Reader®
5.0” on page 56.
To open a PDF manual, do either of the following:
• Double-click a PDF file on the CD-ROM.
The Acrobat Reader software starts and the selected PDF manual is
displayed. You can read and print the file.
• Start the Acrobat Reader software, and select Open from the File
menu. In the Open dialog box, select a PDF file, and click Open.
The selected PDF manual is displayed. You can read and print the file.
23
What is the Sony CLIÉ Handheld?
The following manuals are available as PDF files on the CD-ROM:
– Read This First (this guide)
– Operating Instructions
– Add-on Application Guide
Chapter 1
■ Manuals
24
Chapter 2
Setting up your Sony CLIÉ Handheld – Basics
Contents
Step 1: Charging your Sony CLIÉ Handheld ............................... 26
Step 2: Turning on your Sony CLIÉ Handheld for the first time .. 27
Opening the display panel ................................................... 27
Making the initial setting ..................................................... 28
Step 3: Entering data into your Sony CLIÉ Handheld ................. 32
Step 4: Installing the Palm™ Desktop for CLIÉ software
on your computer ...................................................................... 35
Step 5: Connecting your Sony CLIÉ Handheld and
your computer via the cradle ..................................................... 39
Step 6: Performing a HotSync® operation for the first time ....... 40
Chapter 2
This chapter describes basic hardware setup procedures that
you should perform before you start using your CLIÉ
handheld. These procedures include: charging your CLIÉ
handheld with the cradle, synchronizing data with your
computer, and entering data.
Step 1: Charging your Sony CLIÉ Handheld
Note
Before you use your CLIÉ handheld for the first time, make sure to charge it.
First connect the supplied cradle to an AC power source in advance.
Charging will start as soon as you place your CLIÉ handheld on the
cradle. The battery icon on the screen changes to the battery charging
icon (
).
It takes about four hours for your CLIÉ handheld to be fully charged
for the first time. Subsequent charges, if your CLIÉ handheld is
charged frequently, will require less time.
To the wall
outlet
Insert your CLIÉ handheld at an
angle to the cradle and lay it
back to fit into place.
When you place your CLIÉ handheld on the cradle, the LED indicator
of your CLIÉ handheld turn on, and charging starts.
When charging is completed
The LED indicator of your CLIÉ handheld turns off. When you remove
your CLIÉ handheld from the cradle, the battery charging icon changes
to the battery icon (
).
Note
If the battery in your CLIÉ handheld is fully discharged, all data stored on
the DRAM (memory) is lost. Performing another HotSync® operation once the
battery is recharged can restore information saved from the last HotSync
operation.
26
Step 2: Turning on your Sony CLIÉ
Handheld for the first time
Opening the display panel
To operate on your CLIÉ handheld, set your CLIÉ handheld to the
“opened style” or the “turned style.” Here, the steps guide you to the
“turned style.”
Open the display panel until it clicks into place.
Chapter 2
1
The “carrying style” changes to the “opened style.”
2
Setting up your Sony CLIÉ Handheld – Basics
b
Rotate the display clockwise until it clicks into place,
then fold it over the keyboard.
b
Your CLIÉ handheld is now in the “turned style.”
27
Step 2: Turning on your Sony CLIÉ Handheld for the first time
Making the initial setting
The first time you turn on your CLIÉ handheld, setup instructions
appear on the screen. Follow the on-screen instructions to configure
the initial settings, including caliberating the digitizer and setting the
current time, date, and year. (This configuration is necessary for
operation of the CLIÉ handheld).
1
Press the POWER button.
Your CLIÉ handheld turns on, and the Welcome screen appears.
After a while, the Setup screen appears.
Press the
POWER
button.
b
2
Take out the Stylus.
You can use the stylus to tap or drag on the screen to open
applications, choose options or menu commands, and select text or
move objects, just as you do with a mouse on your computer.
Note
28
Always use the point of the stylus for tapping or making strokes on the
handheld screen. Never use a real pen, pencil, or other sharp object to write
on the screen.
3
Press lightly on the screen with the stylus.
Setting up your Sony CLIÉ Handheld – Basics
4
Chapter 2
This action is called “tapping.”
The digitizer calibration screen appears. Calibration aligns the
internal circuitry of the handheld with its touch-sensitive screen so
your CLIÉ handheld can detect the task you want to perform when
you tap an element on the screen.
Tap anywhere on the screen.
The following screen is displayed.
Continued on next page
29
Step 2: Turning on your Sony CLIÉ Handheld for the first time
5
Following the on-screen instruction, tap the center of
the displayed mark.
Note
If the digitizer is not configured correctly, the scroll bar may not operate
properly, “tapping” may not work as expected, or other problems may
occur. If this happens, please re-configure the digitizer manually. You can
also re-configure the digitizer in the Digitizer Preferences screen. For details,
see “What you can do with Preferences” in the Operating Instructions
manual.
After calibration completes, a screen for setting the time and date
appears.
6
Tap the Set Date box.
The Set Date screen appears.
7
Tap the arrow b or B next to the year to select the
current year.
8
Tap the current month, then tap the current date.
The Set Date screen closes.
30
9
Tap the Set Time box.
The Set Time screen appears.
v or V to set the minutes to the current time.
Setting up your Sony CLIÉ Handheld – Basics
12 Tap AM or PM.
13 Tap OK.
Chapter 2
10 Tap the arrow v or V to set the hour to the current time.
11 Tap each number of the minute, and then tap the arrow
The Set Time screen closes.
14 Tap Next.
The Setup Complete screen appears.
15 Tap Next.
The Enter Data screen appears.
16 Tap Done.
The initial settings are complete, and the Application Launcher
screen (Home screen) appears.
Your CLIÉ handheld is now ready for use!
31
Step 3: Entering data into your Sony CLIÉ
Handheld
There are five ways to enter data into your CLIÉ handheld:
– Using the hardware keyboard
– Using Graffiti® writing
– Using the software keyboard (replaces the Graffiti writing area)
– Using the on-screen keyboard (appears additionally to the Graffiti
writing area)
– Using your computer keyboard
Hardware keyboard
The hardware keyboard on your CLIÉ handheld closely resembles
your computer keyboard and can be used in the same way.
,39sgeld:4
32
Software keyboard
After the display switches to the alphabetic keyboard, you can tap to
switch to the international keyboard or the symbol keyboard. For
details, see “Using the software keyboard” in the Operating
Instructions manual.
On-screen keyboard
When you use an application such as Date Book or Address Book, you
can open a keyboard on-screen above the Graffiti writing area to enter
data.
To open the on-screen alphabetic or numeric keyboard, tap the
following icon on the Graffiti writing area.
Tap here for
alphabetic keyboard
Tap here for numeric
keyboard
After a keyboard is open, you can tap to open any of the other
keyboards, including the international keyboard. For details, see
“Using the on-screen keyboard” in the Operating Instructions manual.
Continued on next page
33
Setting up your Sony CLIÉ Handheld – Basics
Tap here to switch between
the software keyboard and
the Graffiti writing area
Chapter 2
When you use an application such as Date Book or Address Book, you
can switch the Graffti writing area to the software keyboard to enter
data.
To swich to the software keyboard, tap the software keyboard icon on
the Graffiti writing area.
Step 3: Entering data into your Sony CLIÉ Handheld
Computer keyboard
If you have a lot of data to enter or prefer to use the computer keyboard,
you can use the Palm™ Desktop for CLIÉ software or any supported
PIM (Personal Information Management) applications to enter
information. You can then perform a HotSync ® operation to synchronize
the information on your computer with the information on your CLIÉ
handheld. All the main applications on your CLIÉ handheld are also
available in the Palm Desktop for CLIÉ software and in most PIM
applications, so you don't need to learn different applications.
Refer to the Palm Desktop for CLIÉ online Help for more information
on entering data using your computer.
34
Step 4: Installing the Palm™ Desktop for
CLIÉ software on your computer
The Palm™ Desktop for CLIÉ software extends many of the functions
of your CLIÉ handheld to your computer and featuring the same main
applications as those on your CLIÉ handheld: Address Book, Date
Book, To Do List, Memo Pad, and desktop e-mail connectivity. You can
use the HotSync® Manager feature of this software to back up and
exchange data between your CLIÉ handheld and your computer.
1
Exit all applications running on Windows®.
You should quit all applications that automatically run at startup,
such as fax communication software, anti-virus tools, screensavers,
and the Microsoft® Office Shortcut Bar.
2
Insert the Installation CD-ROM into the CD-ROM drive of
your computer.
The installation launcher window appears.
Continued on next page
35
Setting up your Sony CLIÉ Handheld – Basics
• Do not connect the cradle to a USB connector of your computer before
installing the Palm Desktop for CLIÉ software. The installation of the software
might not be performed correctly.
• If you are already using a Sony CLIÉ Handheld (PEG-S300/S320/S360/
N610C/N710C/N760C/T415/T615C) or other Palm™ OS PDA device, and the
Palm Desktop software is installed on your computer, uninstall it, and reinstall
the Palm Desktop for CLIÉ software using the supplied Installation CD-ROM.
For details, see “Upgrading the existing Palm Desktop software” on page 38.
• The Palm Desktop for CLIÉ software supplied with this CLIÉ handheld
(PEG-NR70V/U, PEG-NR70/U) does not support the Expense application.
• Do not simply copy the Palm Desktop for CLIÉ software files to your
computer’s hard disk. You must use the installer and follow the procedures
described in this section to place the files in their proper locations and to
decompress the files.
• To introduce the CLIÉ data of your old CLIÉ handheld into the new one, see
“Using data of another Sony CLIÉ Handheld” in the Operating Instructions
manual.
Chapter 2
Notes
Step 4: Installing the Palm™ Desktop for CLIÉ software
on your computer
3
Click Install Palm Desktop for CLIÉ.
The setup program starts and the Welcome screen is displayed.
4
Click Next.
The Palm Desktop for CLIÉ 4.0.1 software installation begins.
Follow the on-screen instructions until the following dialog box
appears.
5
Select the software you will use to synchronize your CLIÉ
handheld with your computer.
If you select “Synchronize with Palm Desktop for CLIÉ,” Intellisync
Lite will not be installed. If you select “Synchronize with Microsoft
Outlook or Lotus Organizer,” Palm Desktop and Intellisync Lite
will be installed.
36
6
Click Next.
The Setup Type window is displayed.
Chapter 2
Select the setup type (Typical or Custom) and the
destination folder.
If you wish to synchronize PEG-S300 or PEG-N710C with your
CLIÉ handheld (PEG-NR70V/U, PEG-NR70/U), follow the steps
below:
1 Select Custom for the setup type, and click Next.
2 On the select components screen, make sure that USB Switcher
is selected.
3 Follow the on-screen instructions until setup is complete.
When you follow the on-screen instructions, the Create User
Account screen is displayed.
8
9
Fill in the user name in the Create User Account screen.
Click Next.
The Install Tool dialog box closes, then the Mail Setup dialog box
appears.
10 Set up Mail.
Follow the on-screen instructions until Mail setup is complete.
Continued on next page
37
Setting up your Sony CLIÉ Handheld – Basics
7
Step 4: Installing the Palm™ Desktop for CLIÉ software
on your computer
11 Fill in the customer registration following the
instructions shown on the screen.
You must have Internet access for the online customer registration.
You can take advantage of Sony’s commitment to quality customer
support and nine-month extension of the limited warranty (for a
total of 12months from the original date of purchase) when you
register your CLIÉ handheld.
12 Click Finish.
Note
Make sure you perform a HotSync operation before installing any thirdparty applications. (See pages 39 - 41)
Upgrading the existing Palm Desktop software
Multiple versions of Palm Desktop software cannot be installed on one
computer. If an older version of Palm Desktop for CLIÉ software
already exists, it is recommended that you uninstall it prior to the new
installation. All handheld user data is preserved when upgrading the
Palm Desktop for CLIÉ software.
About Intellisync Lite
The Intellisync Lite software allows you to synchronize your Date
Book, Address Book, To Do List, and Memo Pad data in your CLIÉ
handheld with the data of a variety of popular Windows® applications
including:
– Microsoft Outlook 97/98/2000/2002
– Lotus Organizer 5.0/6.0
During a HotSync operation, the Intellisync Lite software compares
each record of information in your CLIÉ handheld to the information
stored in the PIM (Personal Information Management) applications
and then makes necessary changes to both systems to make sure that
they both contain the same data.
38
Step 5: Connecting your Sony CLIÉ Handheld
and your computer via the cradle
The cradle that comes with your CLIÉ handheld enables you to
synchronize the information on your CLIÉ handheld with the Palm™
Desktop for CLIÉ software on your computer using HotSync®
technology.
2
Place your CLIÉ handheld on the cradle.
Setting up your Sony CLIÉ Handheld – Basics
Connect the USB connector of the cradle to a USB
connector on your computer.
Chapter 2
1
Your CLIÉ handheld can be in either the “turned style,” “opened
style,” or “carrying style” when you place it into the cradle.
39
Step 6: Performing a HotSync® operation
for the first time
What is a HotSync operation?
HotSync, which is a technology particular to a Palm OS® platform
device, is the one-step operation that allows you to synchronize data
between your CLIÉ handheld and your computer and back up the
CLIÉ data on your computer. For details, see “Exchanging and
updating data using a HotSync® operation” in the Operating
Instructions manual.
When performing a HotSync® operation for the first time, you must
enter your user information both into your CLIÉ handheld and into the
Palm Desktop for CLIÉ software. After the user name is recognized,
you do not have to enter the same information again.
1
Press the HotSync
button on the cradle.
Press the HotSync button.
The USB Driver Installation Wizard starts automatically.
2
When the New User dialog box is displayed on your
computer screen, select your user name.
Select the same user name you entered in step 8 on page 37.
Note
Every handheld should have a unique name. To prevent loss of a user’s
records, never try to synchronize more than one handheld to the same user
name.
40
3
Click OK on your computer screen.
A beep sounds and the HotSync operation starts. When the HotSync
process is complete, a message showing the HotSync operation
completion is displayed on your CLIÉ handheld.
Notes
Chapter 2
If the HotSync operation does not start
• Make sure that the HotSync
icon is displayed in the Windows task
tray on your computer screen.
• If the HotSync
icon is not shown in the task tray, click Start, point to
Programs (All Programs in Windows® XP), Sony Handheld, and then
click HotSync Manager. Then click the HotSync button on your CLIÉ
handheld to start the HotSync operation.
4
To open the Palm™ Desktop for CLIÉ software, doubleclick the Palm Desktop for CLIÉ icon on the Windows®
desktop, or click Start, point to Programs (All Programs
in Windows® XP), Sony Handheld, and click Palm
Desktop for CLIÉ.
The Palm Desktop for CLIÉ software starts. All the main
applications on your CLIÉ handheld are also available in the Palm
Desktop for CLIÉ software. You can synchronize the information on
your computer with the information on your CLIÉ handheld.
41
Setting up your Sony CLIÉ Handheld – Basics
• Do not remove or move your CLIÉ handheld from the cradle during a
HotSync operation.
• Do not push the HotSync button during a HotSync operation. It might
cause errors and interruption of the operation.
• Do not enter power saving mode during a HotSync operation. If your
computer enters power saving mode during a HotSync operation, the
HotSync Manager will quit.
Chapter 3
Setting up your Sony CLIÉ Handheld
– Advanced
Contents
Checking the bundled applications
on your Sony CLIÉ Handheld ..................................................... 44
Overview of basic Palm OS® applications ............................. 45
Overview of Sony applications ............................................. 48
Installing the supplied applications
on your computer ...................................................................... 53
Installing SonicStage™ LE .................................................... 53
Installing PictureGear™ 4.5Lite ............................................ 54
Installing QuickTime® 5 ....................................................... 54
Installing Memory Stick Export ............................................. 55
Installing Sound Converter ................................................... 55
Installing other third-party applications ................................ 56
Installing Acrobat Reader® 5.0 ............................................ 56
Uninstalling the supplied applications .................................. 57
Installing add-on applications on your Sony CLIÉ Handheld or
Memory Stick media ................................................................. 58
Installing add-on applications from the
Palm™ Desktop for CLIÉ software ........................................ 59
Installing add-on applications by beaming them from another
Palm OS® device ................................................................. 62
Installing add-on applications directly from the
Installation CD-ROM menu .................................................. 64
Removing add-on applications ............................................. 65
Customer registration ............................................................... 66
Chapter 3
This chapter describes advanced software setup procedures
for your CLIÉ handheld and your computer. These procedures
include: checking the bundled applications on your CLIÉ
handheld, installing applications from the Installation
CD-ROM on your computer, and installing add-on
applications on your CLIÉ handheld.
Checking the bundled applications
on your Sony CLIÉ Handheld
After you make your CLIÉ handheld ready for use, start the
Application Launcher to display all the available applications on your
CLIÉ handheld.
To open an application from the Application Launcher screen
1
Tap the on-screen Home
icon.
The Application Launcher screen appears.
b
Tap the Home icon
2
Do either of the following:
• Tap the desired application icon in the Application Launcher
screen.
If you have many applications installed on your CLIÉ handheld,
tap the scroll bar to see all the available applications.
• For the four main applications, you can press the application
button on the keyboard panel to display the selected application
immediately (only in the “opened style”):
Date Book
Address Book
Memo Pad
To Do List
To quit the application and open another application
Tap the Home
icon (or press the BACK button repeatedly), and
then perform step 2 to open the desired application. The next time you
open the application, the last screen resumes.
44
Overview of basic Palm OS® applications
Your CLIÉ handheld comes with the following Palm OS basic
applications: Date Book, Address Book, To Do List, Memo Pad, and
Calculator. This section gives an overview of these basic applications.
Date Book
Date Book lets you quickly and easily schedule
appointments or any kind of activity associated with a time
and date.
In Date Book, you can do the following:
• Display a chart of your appointments for an entire week. The Week
view makes it easy to spot available times and any potential
scheduling overlaps or conflicts.
• Set an alarm to sound prior to the scheduled activity.
• Create reminders for events that are based on a particular date,
rather than time of day. Birthdays and anniversaries are easy to track
with your CLIÉ handheld.
• Attach notes to individual events for a description or clarification of
the entry in your Date Book.
Address Book
Address Book enables you to keep names, addresses, phone
numbers, and other information about your personal or
business contacts.
In Address Book, you can do the following:
• Quickly look up or enter names, addresses, phone numbers, and
other information.
• Enter up to five phone numbers (home, work, fax, and so on) or email addresses for each name.
Continued on next page
45
Setting up your Sony CLIÉ Handheld – Advanced
• Display a monthly calendar to quickly spot days where you have
morning, lunch, or afternoon appointments.
Chapter 3
• Enter a description of your appointments and assign them specific
dates and times.
Checking the bundled applications on your
Sony CLIÉ Handheld
• Define which phone number appears in the Address List for each
Address Book entry.
• Attach a note to each Address Book entry, in which you can enter
additional information about the entry.
• Assign Address Book entries to categories so that you can organize
and view them in logical groups.
• Paste a PictureGear™ Pocket image to an address entry.
To Do List
To Do List is a convenient place to create reminders and
prioritize the things that you have to do.
In To Do List, you can do the following:
• Make a quick and convenient list of things to do.
• Assign a priority level to each task.
• Assign a due date for any or all of your To Do List items.
• Assign To Do List items to categories so that you can organize and
view them in logical groups.
• Sort your To Do List items either by due date, priority level, or
category.
• Attach notes to individual To Do List items for a description or
clarification of the task.
Memo Pad
Memo Pad provides a place to take notes that are not
associated with records in Date Book, Address Book, or To
Do List.
In Memo Pad, you can do the following:
• Take notes or write any kind of message on your CLIÉ handheld.
• Drag and drop memos into popular computer applications like the
Microsoft® Word software when you synchronize using the Palm™
Desktop for CLIÉ software and HotSync® technology.
• Assign memos to categories so that you can organize and view them
in logical groups.
• Write down phone numbers and other types of information. Later,
you can copy and paste this information to other applications.
46
Calc (Calculator)
Calculator enables you to perform addition, subtraction,
multiplication, division, and calculate square roots.
In Calculator, you can do the following:
• Perform basic calculations.
• Store and retrieve values.
• Display the last series of calculations, which is useful for confirming
a series of “chain” calculations.
Chapter 3
Setting up your Sony CLIÉ Handheld – Advanced
47
Checking the bundled applications on your
Sony CLIÉ Handheld
Overview of Sony applications
In addition to the basic Palm OS applications, your CLIÉ handheld also
contains original Sony applications. This section describes them.
Note
The applications provided with this CLIE handheld (PEG-NR70V/U or PEGNR70/U) are not guaranteed to work on other devices.
Audio Player
Audio Player is used to play back ATRAC3 audio files
(created and controlled by the SonicStage LE software on
your computer), and MP3 audio files.
In Audio Player, you can do the following:
• Playback ATRAC3 and MP3 audio files stored in the Memory Stick®
media inserted in your CLIÉ handheld.
• Listen to music with the supplied headphones.
• Check-Out your favorite ATRAC3 audio file from the SonicStage LE
software using the cradle.
CLIÉ Camera (PEG-NR70V/U only)
CLIÉ Camera is used to capture and record still images on
your CLIÉ handheld and Memory Stick media.
In CLIÉ Camera, you can do the following:
• Record images in five different sizes (side-long: 320x240 or 160x120,
Address book size: 88x88, vertically long: 240x320, 120x160).
• Capture images with added effects and/or the date and time. The
white balance and brightness are adjustable as well.
• Jump to the PictureGear Pocket application to view the captured
image.
PictureGear Pocket
The PictureGear Pocket application is an image
management software for your CLIÉ handheld.
In the PictureGear Pocket application, you can do the
following:
48
• View images.
• Beam your favorite image files to another CLIÉ handheld.
• Paste an image to your Address Book entry.
• Save DCF images in PGP format on your CLIÉ handheld, or convert
PGP format images to DCF format and saving it on an inserted
Memory Stick media.
• Select full-screen images to be displayed from the original image or
its thumbnail image.
PhotoStand
Chapter 3
The PhotoStand application allows you to display
PictureGear Pocket images one by one like a slide show.
Placed on the cradle, your CLIÉ handheld functions as a
digital picture frame, displaying your chosen images.
In the PhotoStand application, you can do the following:
• Perform a slide show of the PictureGear Pocket images one by one.
Setting up your Sony CLIÉ Handheld – Advanced
• Display the time with the picture so that you can use it as a clock.
• Choose effect patterns or the time display mode.
• Have music play in the background during the slide show.
CLIÉ Paint
The CLIÉ Paint application is used to draw shapes, letters,
or patterns on PGP or DCF format images. You can also
draw from scratch on a white background.
In the CLIÉ Paint application, you can do the following:
• Draw on a PGP or DCF format image data (or a white background)
using various drawing tools.
• Save edited images on your CLIÉ handheld (in PGP format) or a
Memory Stick media.
• Attach DCF- or PGP-format images to e-mail via the CLIÉ Mail
application.
• View, draw on, and save the image in different sizes.
Continued on next page
49
Checking the bundled applications on your
Sony CLIÉ Handheld
gMovie
The gMovie application is used to play a movie clip created
using the PictureGear 4.5Lite software.
In the gMovie application, you can do the following:
• Play a movie file copied from your computer to your CLIÉ
handheld.
• Play a movie file directly from Memory Stick media.
• Beam a movie file to another CLIÉ handheld.
CLIÉ Mail
The CLIÉ Mail application is the e-mail management
software for your CLIÉ handheld.You need to install the
CLIÉ Mail application from the installation CD-ROM to
your CLIÉ handheld.
In the CLIÉ Mail application, you can do the following:
• Read, write, send* and recieve* e-mail.
* Only when your CLIÉ handheld is connected to a network.
•Manage e-mails sent or received by your computer.
• Manage multiple e-mail accounts.
• Assign e-mails to categories so that you can organize and view them
in logical groups.
• Attach data such as Address Book entries and image files to e-mail.
MS Gate
The Memory Stick Gate (MS Gate) application is used to
exchange Memory Stick data to and from your CLIÉ
handheld.
In the MS Gate application, you can do the following:
• Copy or move data between your CLIÉ handheld and Memory Stick media.
• Delete data in Memory Stick media and in your CLIÉ handheld.
• Format Memory Stick media.
MS Autorun
50
The Memory Stick Autorun (MS Autorun) application is
used to start a specified application when Memory Stick
media is inserted into your CLIÉ handheld.
In the MS Autorun application, you can do the following:
• Automatically start game software or other applications stored in
Memory Stick media.
• Display specified data immediately by automatically starting the
associated application stored in Memory Stick media or your CLIÉ
handheld.
MS Import
• View and handle the contents of the Memory Stick media inserted in
your CLIÉ handheld as a removable device.
• Copy files between your computer’s hard disk and the Memory Stick
media with the Windows® Explorer.
• Choose folders other than the default folder to store CLIÉ handheld data.
MS Backup
The Memory Stick Backup (MS Backup) application is used
to back up your CLIÉ data on a Memory Stick media, unlike
the HotSync operation that backs up data to your computer.
In the MS Backup application, you can do the following:
• Backup CLIÉ data on a Memory Stick media inserted in your CLIÉ
handheld.
• Restore the backed up data from Memory Stick media on the CLIÉ
handheld once again.
Continued on next page
51
Setting up your Sony CLIÉ Handheld – Advanced
• Install CLIÉ applications directly on the Memory Stick media
inserted in your CLIÉ handheld without performing a HotSync
operation.
Chapter 3
The Memory Stick Import (MS Import) application is used
in combination with the Memory Stick Export (MS Export)
software to transfer computer data between your computer
and CLIÉ handheld by using a Memory Stick media rather
than by performing a HotSync operation. You need to install
the MS Export software from the Installation CD-ROM on
your computer (The MS Import application is pre-installed
on your CLIÉ handheld).
In MS Import/Export, you can do the following:
Checking the bundled applications on your
Sony CLIÉ Handheld
World Alarm Clock
The World Alarm Clock application is software to use your
CLIÉ handheld as a world clock. You need to install the
World Alarm Clock application from the Installation CDROM to your CLIÉ handheld.
In the World Alarm Clock application, you can do the
following:
• View the date and time of multiple regions on a single screen.
Daylight Saving Time settings are also available.
• Use your CLIÉ handheld as an alarm clock to alert you at a
particular day and time. You can also set your favorite sound as its
alarm.
CLIÉ Remote Commander
The CLIÉ Remote Commander application is used to
operate various multiple remote-controlled devices such as
a TV, VCR, DVD player, or AV amplifier with just your
CLIÉ handheld. You need to install the CLIÉ Remote
Commander application from the Installation CD-ROM to
your CLIÉ handheld.
In the CLIÉ Remote Commander application, you can do
the following:
• Use your CLIÉ handheld as a remote control for up to four devices,
switching among them with just a single tap on the short-cut button.
You can also control more devices by selecting from the Select menu.
Sound Utility
The Sound Utility application is used to play back and
manage sound files imported from your computer.
In the Sound Utility application, you can do the following:
• Play back, delete, and change the name of the sound data.
52
Installing the supplied applications
on your computer
From the installation launcher window of the supplied CLIÉ
Installation CD-ROM, you can install the following software on your
computer’s hard disk.
Installing SonicStage™ LE
The SonicStage LE software utilizes Sony’s copyright protection
technology (OpenMG) and allows you to store and play digital audio
files on your computer’s hard disk, and then transfer them (CheckOut) as ATRAC3 files to a Sony digital music player such as your CLIÉ
handheld for portable listening.
Note
1
Insert the Installation CD-ROM into your computer’s CDROM drive.
2
Click Install CLIÉ Utilities.
The CLIÉ utilities window is displayed.
3
Click Install CLIÉ Audio Software.
The Audio Software installation window is displayed.
4
Click SonicStage LE.
The SonicStage LE software installation starts. Follow the on-screen
instructions.
5
After the installation is complete, click Restart.
The installation ends and your computer restarts.
Note
Do not delete, move, or edit the installed folders using Windows® Explorer or
any other application, or the SonicStage LE database may become unstable or
damaged.
53
Setting up your Sony CLIÉ Handheld – Advanced
The installation launcher window is displayed.
Chapter 3
Do not simultaneously press the Alt key and the Tab key of your computer
during the installation process.
Installing the supplied applications on your computer
Installing PictureGear™ 4.5Lite
The PictureGear 4.5Lite software allows you to transfer image or
movie files between your computer and your CLIÉ handheld. You can
use the PictureGear Pocket or the gMovie application to view the
transferred movie or image files on your CLIÉ handheld.
1
Insert the Installation CD-ROM into your computer’s
CD-ROM drive.
The installation launcher window is displayed.
2
Click Install CLIÉ Utilities.
The CLIÉ utilities window is displayed.
3
4
Click Install CLIÉ Image Software.
Click Install PictureGear Lite.
The PictureGear 4.5Lite software installation starts.
Follow the on-screen instructions to complete the installation.
Installing QuickTime® 5
The QuickTime 5 software allows you to view QuickTime movies and
is required for PictureGear Lite software to convert QuickTime movies
for use on your CLIÉ handheld.
1
Insert the Installation CD-ROM into your computer’s
CD-ROM drive.
The installation launcher window is displayed.
2
Click Install CLIÉ Utilities.
The CLIÉ utilities window is displayed.
3
4
Click Install CLIÉ Image Software.
Click Install QuickTime.
The QuickTime 5 software installation starts.
Follow the on-screen instructions to complete the installation.
54
Installing Memory Stick Export
Chapter 3
Setting up your Sony CLIÉ Handheld – Advanced
55
Installing the supplied applications on your computer
Installing other third-party applications
You can install other add-on applications on your computer and then
install them on your CLIÉ handheld at the next HotSync® operation.
For details, see “Installing add-on applications from the Palm™
Desktop for CLIÉ software” on page 59.
1
Insert the Installation CD-ROM into your computer’s
CD-ROM drive.
The installation launcher window is displayed.
2
Click Third-party Software.
The Third-party Software installation window is displayed.
3
Click the application of your choice.
The installation starts.
Follow the on-screen instructions to complete the installation.
Installing Acrobat Reader® 5.0
The Acrobat Reader 5.0 software allows you to view, navigate, and
print Adobe Portable Document Format (PDF) documents. To open
and read the PDF manuals in the CLIÉ Installation CD-ROM, you need
the Acrobat Reader software installed in your computer’s hard disk.
1
Insert the Installation CD-ROM into your computer’s
CD-ROM drive.
The installation launcher window is displayed.
2
3
Click Exit to close the installation launcher window.
Click Start from the taskbar, then click Run.
The Run window is displayed.
4
Type or select “D:\PC\Acrobat\ar500enu.exe” in the text
box, and click Run. (“D:” substitutes the drive letter of
your CD-ROM drive.)
You can also use Browse to select the setup program.
The Acrobat Reader 5.0 software installation starts.
Follow the on-screen instructions to complete the installation.
56
Uninstalling the supplied applications
In the event that you no longer need an application you installed, you
can remove an application from your computer’s hard disk as follows:
1
Click Start from the taskbar, point to Settings, and click
Control Panel.
The Control Panel window is displayed.
2
Double-click Add/Remove Programs.
The Add/Remove Programs Properties window is displayed.
In the Install/Uninstall tab, select the software that you
want to remove.
4
Click Add/Remove.
Chapter 3
3
The confirmation dialog box is displayed.
5
Click OK to remove the software.
Tip
Some applications have their own uninstaller program. To remove the
QuickTime software, for example, click Start on the taskbar, point to Programs
(All Programs in Windows® XP), QuickTime, and then click Uninstall QuickTime.
57
Setting up your Sony CLIÉ Handheld – Advanced
Follow the on-screen instructions to remove the application from
your computer’s hard disk.
Installing add-on applications on your Sony
CLIÉ Handheld or Memory Stick media
Your CLIÉ handheld comes with various applications, such as Date
Book, Address Book, To Do List, Memo Pad, Calculator, and the e-mail
application.
In addition to these applications, you can install additional
applications called “add-on applications” from the Installation
CD-ROM on your CLIÉ handheld. You can also install add-on
applications on Memory Stick media (sold separately) if you want to
save your CLIÉ handheld’s memory space. A variety of third-party
applications are also available for your CLIÉ handheld, such as games
and other software that run on the Palm OS®. For information on the
latest third-party applications, see the Sony official CLIÉ Web site
(http://www.sony.com/clie/).
Notes
• Add-on applications reside in the RAM memory of your CLIÉ handheld.
Performing a hard reset deletes all the add-on applications. However, if, before
performing a hard reset, you back up the data in your CLIÉ handheld by
performing a HotSync® operation or by using the MS Backup application, you
can restore the add-on applications afterwards.
• The add-on applications available on the CLIÉ Installation CD-ROM are copied
on your computer’s hard disk when you install the Palm™ Desktop for CLIÉ
software. To install these applications from the Palm Desktop for CLIÉ
software on your CLIÉ handheld, follow the procedures described in the next
section.
58
Installing add-on applications from the Palm™
Desktop for CLIÉ software
This section describes how to install add-on applications on your CLIÉ
handheld or to the Memory Stick media using the Install Tool during a
HotSync® operation.
1
Copy or download the application you want to install
into the Add-on folder in the Sony CLIÉ Handheld folder
on your computer (example : C:\Program Files\Sony
Handheld\Add-on).
If you want to copy to a different folder, specify the folder in step 5.
Double-click the Palm Desktop for CLIÉ software icon on
the Windows® desktop, or click Start, point to Programs
(All Programs in Windows® XP), Sony Handheld, and click
Palm Desktop for CLIÉ.
Chapter 3
2
The Palm Desktop for CLIÉ software starts.
Setting up your Sony CLIÉ Handheld – Advanced
3
Click Install.
The Install Tool dialog box appears.
Continued on next page
59
Installing add-on applications on your Sony CLIÉ
Handheld or Memory Stick media
4
5
From the User drop-down list, select a user name to use.
Click Add.
The Open File dialog box appears. The supplied add-on
applications are stored in the Add-on folder.
6
Select the application(s) you want to install on your CLIÉ
handheld.
In the Install Tool dialog box, the list of applications you selected is
displayed.
If you do not want to install an application, select it, and then click
Remove. (The application is deleted from the list but remains on
your computer’s hard disk.)
7
8
9
Click Done.
Click OK.
Perform a HotSync operation.
The application(s) you selected in step 6 will be installed on your
CLIÉ handheld. See page 40 (Step 6: Performing a HotSync®
operation for the first time) for details on performing a local
HotSync operation.
60
To access the Install Tool dialog box
Do either of the following to display the Install Tool dialog box
immediately:
• Click Start on the taskbar, point to Programs (All Programs
in Windows® XP), Sony Handheld, and then click Install
Tool.
• Double-click any file with a PRC, or PDB file extension.
To install applications to the Memory Stick media
You can install applications to the Memory Stick media by performing
one of the following:
Chapter 3
• Use the MS Import/Export applications to install
applications directly on an inserted Memory Stick media
(See the Add-on Applications Guide for details).
• Install applications through the Palm Desktop for CLIÉ
software by clicking Change Destination after performing
step 6 on page 60. Click the file name(s) to select the file(s),
then click the arrow (>> or <<) button to select Memory
Stick as the destination, and click OK. Then proceed to step
7.
When installing add-on applications to the Memory Stick media, be sure to
perform the HotSync operation with the Memory Stick media inserted in
your CLIÉ handheld.
If you installed applications to the Memory Stick media through Palm
Desktop for CLIÉ software
With some applications, your CLIÉ handheld may not be able to display data if
you installed the application in the Memory Stick media.
This is because the Palm Desktop for CLIÉ software installs application data in
the /PALM/Launcher directory when Memory Stick is selected. As a result,
some application data cannot be started through normal process.
If the application you installed in the Memory Stick media fail to start, copy the
data again, this time to your CLIÉ handheld. For details, see “Copying data in
Memory Stick media to your CLIÉ handheld” in the Operating Instructions
manual.
61
Setting up your Sony CLIÉ Handheld – Advanced
Note
Installing add-on applications on your Sony CLIÉ
Handheld or Memory Stick media
Installing add-on applications by beaming them
from another Palm OS® device
Your CLIÉ handheld is equipped with an IR (infrared) port that you
can use to beam an application to another Palm OS® device that is
close by and that also has an IR port. You can beam applications that
are either installed in your CLIÉ handheld or stored in inserted
Memory Stick media. The IR port is located at the top of your CLIÉ
handheld, behind the small dark shield.
IR port
1
Tap the Home
icon.
The Application Launcher screen appears.
2
Tap the Menu
icon.
The menu is displayed.
3
Tap Beam.
The Beam screen appears.
4
62
Tap the arrow V next to Beam From, and select
Handheld or Card.
5
Tap the application you want to transfer.
Note
6
7
Chapter 3
Some applications are copy-protected and cannot be beamed. These are
listed with the lock
icon next to them.
Tap Beam.
When the Beam dialog box appears, point the IR port
directly at the IR port of the receiving handheld.
8
Wait for the Beam dialog box to indicate that the
transfer is complete before you continue using your CLIÉ
handheld.
63
Setting up your Sony CLIÉ Handheld – Advanced
Tip
For best results, the handhelds should be 4 to 8 inches (approximately 10 to
20 centimeters) apart, and the path between the two handhelds must be clear
of obstacles. Beaming distance to other Palm OS PDA devices may be
different.
Installing add-on applications on your Sony CLIÉ
Handheld or Memory Stick media
Installing add-on applications directly from the
Installation CD-ROM menu
You can also install applications directly from the supplied Installation
CD-ROM menu to your CLIÉ handheld. You do not have to start the
Palm Desktop for CLIÉ software.
1
Insert the Installation CD-ROM into the CD-ROM drive of
your computer.
2
3
Click Install CLIÉ Add-on Applications.
Click CLIÉ Add-ons.
InstallShield Wizard starts and the Select Components window
appears.
4
Click the check box to select the add-on applications you
wish to install.
5
6
Click Next.
7
8
9
Click OK.
From the User name drop-down list, select your CLIÉ
handheld’s user name.
Click Done.
Perform a HotSync operation.
The application(s) you selected in step 3 will be installed on your
CLIÉ handheld. See page 40 (Step 6: Performing a HotSync®
operation for the first time) for details on performing a local
HotSync operation.
64
Removing add-on applications
If the memory of your CLIÉ handheld or Memory Stick media is full,
or you decide that an add-on application is no longer needed, you can
remove it from your CLIÉ handheld or the Memory Stick media.
Note
You can remove only add-on applications, patches, and extensions that you have
installed. You cannot remove the standard applications provided with your CLIÉ
handheld, such as Address Book or Memo Pad.
1
Tap the Home
icon.
The Application Launcher screen appears.
Tap the Menu
Chapter 3
2
icon.
The menu is displayed.
3
Tap Delete.
The Delete screen appears.
Tap the arrow V next to Delete From, and select
Handheld or Card.
5
Tap the application you want to delete, and tap Delete.
A confirmation message for Delete Application is displayed.
6
Tap Yes.
The application you selected in step 5 is deleted.
To cancel deletion, tap No.
7
Tap Done.
The Application Launcher screen appears again.
65
Setting up your Sony CLIÉ Handheld – Advanced
4
Customer registration
If you did not fill in the customer registration after installing the
Palm™ Desktop for CLIÉ software, follow the instructions in this
section to complete the registration.
Note
Your computer needs to be connected to the internet to complete the registration.
1
Double-click the Sony CLIÉ Registration icon on the
Windows® desktop, or click Start on the taskbar, point
to Programs (All Programs in Windows® XP), Sony
Handheld, and then click Sony CLIÉ Registration.
The Sony CLIÉ Handheld Registration screen appears.
2
Click Start your registration process.
Your computer connects to the Internet, and the user registration
Web page at the following URL is displayed:
http://www.sony.com/clie/register/
3
66
Follow the on-screen instructions.
Chapter 3
Setting up your Sony CLIÉ Handheld – Advanced
67
For the latest support information,
check our official Sony CLIÉ Web site
http://www.sony.com/clie/
