Operating Instructions
1
Checking the package contents
Sony CLIÉ™ handheld components
2
Setting up your Sony
CLIÉ™ handheld
3
Basic operations of your
Sony CLIÉ™ handheld
Using your Sony CLIÉ™
handheld with your computer
Enjoying your Sony CLIÉ™
handheld
Using applications
Personal Entertainment Organizer
PEG-SJ22
© 2003 Sony Corporation
About this manual
This “Read This First” provides overview features of your CLIÉ™ handheld, such as how to
set up your CLIÉ handheld and what you can do with your CLIÉ™ handheld.
Checking the package
contents
Sony CLIÉ™ handheld
components
Setting up your Sony
CLIÉ™ handheld
Basic operations of your
Sony CLIÉ™ handheld
Using your Sony CLIÉ™
handheld with your computer
Enjoying your Sony
CLIÉ™ handheld
Page 10
Make sure that all the accessories are
supplied in the package.
Page 12
Learn about the parts of your CLIÉ
handheld.
Page 15
Make sure to charge your CLIÉ
handheld before using it for the first
time.
Page 23
Learn about the basic operations of
your CLIÉ handheld.
Page 38
Set up your CLIÉ handheld to use with
your computer.
Page 45
Learn about features of your CLIÉ
handheld.
Page 49
Using applications
2
Learn about the applications supplied
with your CLIÉ handheld.
Refer to the following together with this manual.
