Professional Flat Panel Displays
PFM Series
PFM-50C1E
PFM-42B2E/S
PFM-32C1E
Sony breathes life into the
Flat Panel Display.
Sony unveils a striking lineup of 16:9 Professional Flat Panel Displays.
State-of-the-art technology enables these new models to deliver
outstanding picture quality from slim, lightweight, flat panels.
The PFM Series includes three models* : the 32-inch PFM-32C1E,
with a resolution of 852 X 1024 pixels, the 42-inch PFM-42B2E/S,
with a resolution of 1024 X 1024 pixels, and the 50-inch PFM-50C1E,
with a resolution of 1365 x 768 pixels.
All three models include a range of versatile features for unsurpassed
usability, and combine their superb performance with stylish design.
The 32-inch and 50-inch include a stereo digital amplifier to power
optional external loudspeakers.
These new Flat Panel Displays are ideal for use in A/V presentations,
as information displays in malls and airports,
as background video monitors in restaurants,
and for many other space-limited applications where high-brightness,
high-quality images are essential.
PFM-50C1E
PFM-50C1/50C1E
PFM-42B2E/S
PFM-42B2/42B2E
PFM-32C1E
PFM-32C1/32C1E
*The bezel of the PFM-42B2E/S is warm silver in colour.
*The bezels of the PFM-50C1E and PFM-32C1E are cool silver.
Brilliant Picture Quality
Real Digital System
With the unique Sony digital signal processing technology of the Real Digital
System, all signals are both input and processed digitally to give highly accurate
image reproduction.
A new bi-pixel I/P (Interlace/Progressive) conversion circuit, developed
exclusively for Sony flat panel displays, converts interlaced signals to
progressive images of effectively higher definition. For film-originated sources,
the Cinema Drive function (3-2 pull-down technology) is incorporated to help
reproduce scene movement more naturally.
* The PFM-42B2E/S delivers excellent, clear, smooth images thanks to the
combination of its high-quality panel and Sony original I/P conversion technology.
Multi-Layer, AR-Coated, Protection panel
The anti-reflection (AR) coating on the glass protection panel reduces light reflection for clear, high-contrast
pictures.
Multiple Inputs and High-performance Scan Converter
PFM Series displays utilize high-definition, 16:9 flat panels that provide smooth, high-quality images across
the screen. They accept signals ranging from standard composite video* to HDTV, DTV and RGB computer
signals at up to UXGA resolution. A range of optional input adaptors is available, providing superb system
flexibility. A built-in, high-performance scan converter offers optimum image quality whatever the signal
format, providing accurate pixel-by-pixel image reproduction.
* An optional BKM-B10 Adaptor is required to accept composite video signals.
Versatile and stylish
With their simple, yet sophisticated appearance, the PFM Series of displays offer a stylish, high impact, way
to convey messages. A silver bezel gives a sharp and sophisticated look that is right for any environment*.
With excellent installation flexibility, these slim, lightweight displays provide large, superb quality images in
minimal space.
*The bezel of the PFM-42B2E/S is warm silver in colour.
*The bezels of the PFM-50C1E and PFM-32C1E are cool silver.
Network Capability (with the optional BKM-B30NW Adaptor)
The optional BKM-B30NW Network Adaptor provides an Ethernet 10BaseT/100Base-TX interface, plus a PC Card slot, to provide network connection for
the PFM Series. Wired or wireless, these two PFM Series displays are ready to
interface with the expanding world of visual network communications. This
adaptor also provides a Y/C and a composite analog input.
• File sharing through a network
When these displays are connected to a network, files shared in that network can
be retrieved and opened for display*.
* Microsoft® PowerPoint® (PPT, PPS), Excel (XLS), JPEG, GIF, BMP and PNG files are supported.
• Remote control from networked PCs
Any PC within a network can communicate with the 42-inch or 50-inch display
via a web browser*. Operating presentations, organizing files and controlling
both the display’s functions and its setup parameters can all be done with a
simple operation.
* System requirements
OS: Microsoft Windows® 98, Windows 98 SE, Windows Me or Windows 2000
Web browser: Internet Explorer 4.0 or later or Netscape® Communicator 4.5x or 4.7x
NOTE:These icons indicate which features are available for each model.
High-quality Digital Audio Amplifiers
These two models incorporate high-quality digital amplifiers for clear audio
reproduction.
These amplifiers feed Speaker Out (L/R) connectors so that optional speakers
can be connected to enhance the effectiveness and quality of presentations.
Other Features
• Choice of remote control operation
• Selectable aspect ratio
Operational functions can be controlled from the
supplied remote control unit* or via RS-232C.
• Dot phase adjustment
Aspect ratios for Widescreen 16:9, Wide Zoom,
Letter Box Zoom or Standard 4:3 displays are
selectable.
* RM-971 for the PFM-32C1E and PFM-50C1E, RM-42B
for the PFM-42B2E/S
This function optimizes the scan converter
sampling phase to the input signal.
• Memory save/load
• Choice of color temperature setting
Stores up to twenty picture settings.
Up to three color temperature setting can be
registered with the PFM-32C1E and PFM-50C1E,
and up to six settings with the PFM-42B2E/S.
• Six-language on-screen display
Quick and simple setup in English, French,
German, Italian, Spanish and Japanese.
• Size control
Picture size can be adjusted both vertically and
horizontally.
• Closed Caption decoder
• Screen Saver functions
• Shift control
RM-971
The center of the picture can be adjusted both
vertically and horizontally.
RM-42B
Picture Orbiting mode and Picture Inversion mode
can be selected.
• Power Saving function
• Mounting freedom
• Picture zoom
All models can be mounted horizontally or
vertically, fixed on an optional stand, on a wall or
hung from the ceiling.
• Picture Mode function
A section of the picture can be zoomed in for a
closer look. This feature also allows up to 4x4
units to be used in video wall applications.
• 24-hour on/off timer
• Worldwide power supply range
• Auto Wide function
Three user presets and two fixed sets of display
parameters are available.
The Auto Wide function automatically enlarges the
video image to fill the 16:9 wide screen
Flat Panel Advantages
Slim, lightweight design for
large, superb images in
minimal space
Accurate image geometry
from the linear alignment of
the light-emitting pixels
The Sony PFM range adopts Plasma
Display Panels (PDP). The versatility
and flexibility of PDP technology is
ideal for many applications.
Wide, 160° viewing angle for
large-audience appeal
Resistance to magnetic fields
for drift-free color uniformity
Optional Accessories
Video Input Adaptor
D4 Input Adaptor
Component Video Input Adaptor
Composite Video Input and Control S Adaptor
BKM-B10
BKM-B11
BKM-B12
BKM-B13
• Composite input/output
• Y/C input
• Audio input (x1)
• Analog composite input (D4)
• Analog composite input (pin jack)
• Y/C input
• Audio input (X2)
• Analog component input (pin jack)
• Control-S input/output
• Composite input/output
• Y/C input
• Control-S input/output
Network Adaptor
Speaker System
Monitor Stand
BKM-B30NW
SS-SP10A
SU-P32C
• Y/C input
• Analog composite input (pin jack)
• Ethernet 10Base-T/100Base-TX interface
• PC Card slot Type II
• USB port (A type) (x 2)
Connector Panel
This picture
shows SU-P32C.
WM-PFM01
Monitor Stand
Monitor Stand
TS-PFM42
SU-P50C
Dimensions
Control Panel
The control panel is located
on the top of the unit.
The control panel is located
on the rear of the unit.
Note:
The power switch is equipped on the front of the display.
Monitor Wallmount
Specifications
Picture Performance
Panel
Resolution
Pixel pitch
Active area (W/H)
Viewable picture area
Colors
Type
Color system
Sampling rate
Input/Output
INPUT1/INPUT2
RGB
YUV
AUDIO
1
VIDEO*
COMPOSITE IN
Y/C IN
Y
C
AUDIO IN
COMPOSITE OUT
CONTROL S IN/OUT
REMOTE (RS-232C)
Audio OUT
SPEAKER OUT (L/R)
General
Power requirements
Power consumption
Operating temperature
Storage temperature
Humidity
Dimensions*2 (W/H/D)
Mass
Supplied Accessories
PFM-32C1E
852 x 1024 pixels
0.84 x 0.39 mm
715.68 x 399.36 mm
32-inch/820 mm (diagonal)
PFM-42B2E/S
1024 x 1024 pixels
0.90 x 0.51 mm
921.60 x 522.24 mm
42-inch/1,058 mm (measured diagonally)
16.8 million colors simultaneously
AC-type Plasma Display Panel with anti-reflection screen
NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL 60, PAL-N NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL 60
13.5 to 140 MHz
PFM-50C1E
1365 x 768 pixels
0.81 x 0.81 mm
1106 x 622 mm
50-inch/1270 mm (diagonal)
NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL 60, PAL-N
D-sub 15-pin
0.714 Vp-p/non-composite, 1.0 Vp-p/composite, 75 Ω
0.7 Vp-p/non-composite (U/V), 1.0 Vp-p/composite (Y), 75 Ω
Stereo mini jack, 500 mV rms, high impedance
BNC, 1.0 Vp-p ±2 dB sync negative, 75 Ω automatic termination
Mini DIN 4-pin
1.0 Vp-p ±2 dB sync negative, 75 Ω
0.286 Vp-p ±2 dB sync negative (NTSC), 75 Ω
0.3 Vp-p ±2 dB sync negative (PAL), 75 Ω
Stereo mini jack, 500 mV rms, high impedance
Loop-through BNC
Stereo mini jack, 5.0 Vp-p
Stereo mini jack, 5.0 Vp-p
D-sub 9-pin
Stereo mini jack, 500 mV rms, high impedance
7 W + 7 W (impedance: 6 Ω)
7 W + 7 W (impedance: 6 Ω)
AC 100 to 240 V, 50/60 Hz, 3.2 to 1.6 A
270 W
838 x 521 x 97 mm (33 x 20 5/8 x 3 7/8 inches)
22 kg (48 lb 8 oz)
AC 100 to 240 V, 50/60 Hz, 4.5 to 1.8 A
360 W
0 to 35 °C (32 to 95 °F)
-10 to 40 °C (14 to 104 °F)
20 to 90 %, no condensation
1033 x 631 x 83 mm (40 3/4 x 24 7/8 x 3 3/8 inches)
28.4 kg (62 lb 10 oz)
AC Power Cord, AC Plug Holder (2),
AA size Battery (2), Cable Holder A (2), Cable Holder B (4),
Operating Instructions
Remote Commander RM-42B
Remote Commander RM-971
AC 100 to 240 V, 50/60 Hz, 5.4 to 2.2 A
490 W
1246 x 755 x 100 mm (49 1/8 x 29 3/4 x 4 inches)
46.7 kg (103 lb 9 oz)
Remote Commander RM-971
Regulation Compliance
UL1950, CSA No.950 (c-UL), CE LVD (EN60950),
FCC Class B, IC Class B, VCCI Class B, CE EMC (EN55022 Class-B,
EN55024, EN61000-3-2, EN61000-3-3),
C-Tick (AS/NZS 3548/95, AS/NZS 4252.1), CCIB, JEIDA, CB, KTL, MIC
*1 The PFM-32C1E, PFM-42B2E and PFM-50C1E require an optional BKM-B10 adaptors to accept video signals.
*2 Excluding protruding parts.
Preset Signals
VIDEO
NTSC
PAL
SECAM
NTSC4.43
PAL60
PAL-M
PAL-N*2
575/50I
480/60I
1080/24PsF
1080/50I
576/50P
480/60P
1080/60I
720/60P
COMPUTER INPUT
VGA-1 (VGA 350)
640 x 350 @85 (VESA STD)
640 x 400 @85 (VESA STD)
640 x 480 @60 (VESA STD)
Mac 13"
640 x 480 @72 (VESA STD)
640 x 480 @75 (VESA STD)
640 x 480 @85 (VESA STD)
852 x 480 @60 (I-O DATA)*3
fH (kHz) Frame rate*1 (Hz)
15.734
60
15.625
50
15.625
50
15.734
60
15.734
60
15.734
60
15.734
60
15.625
50
15.734
60
27.000
24
28.125
50
31.250
50
31.469
60
33.750
60
45.000
60
fH (kHz) fV (Hz)
31.5
70.1
37.9
85.1
37.9
85.1
31.5
59.9
35.0
66.7
37.9
72.8
37.5
75.0
43.3
85.0
31.7
60.0
Resolution (Active)
480 lines
575 lines
575 lines
480 lines
480 lines
480 lines
480 lines
575 lines
480 lines
1080 lines
1080 lines
576 lines
480 lines
1080 lines
720 lines
Resolution (Active)
640 x 480 dots
640 x 350 dots
640 x 400 dots
640 x 480 dots
640 x 480 dots
640 x 480 dots
640 x 480 dots
640 x 480 dots
852 x 480 dots
VGA (VGA TEXT)
720 x 400 @85 (VESA STD)
800 x 600 @56 (VESA STD)
800 x 600 @60 (VESA STD)
800 x 600 @72 (VESA STD)
800 x 600 @75 (VESA STD)
800 x 600 @85 (VESA STD)
Mac 16"
1024 x 768 @60 (VESA STD)
1024 x 768 @70 (VESA STD)
1024 x 768 @75 (VESA STD)
1024 x 768 @85 (VESA STD)
1152 x 864 @75 (VESA STD)
Mac 21"
1280 x 960 @60 (VESA STD)
1280 x 960 @85 (VESA STD)
1280 x 1024 @60 (VESA STD)
1280 x 1024 @75 (VESA STD)
1280 x 1024 @85 (VESA STD)*4
1600 x 1200 @60 (VESA STD)*5
856 x 480 @60 (Matrox)*6
856 x 480 @59.6 (Matrox)*6
856 x 480 @60.1 (Matrox)*6
*1
*2
*3
*4
*5
*6
31.5
37.9
35.2
37.9
48.1
46.9
53.7
49.7
48.4
56.5
60.0
68.7
67.5
68.7
60.0
85.9
64.0
80.0
91.1
75.0
30.2
30.1
30.1
70.1
85.0
56.3
60.3
72.2
75.0
85.1
74.6
60.0
70.1
75.0
85.0
75.0
75.1
60.0
85.0
60.0
75.0
85.0
60.0
60.0
59.6
60.1
Compatible with 1/1.001.
Acceptable to the PFM-32C1E and PFM-50C1E
With the graphic accelerator board of I-O DATA DEVICE, INC.
Acceptable to the PFM-42B2E and PFM-50C1E
Dot phase adjustment not applicable to UXGA (1600 x 1200).
With the graphic card of Matrox Graphics Inc.
720
720
800
800
800
800
800
832
1024
1024
1024
1024
1152
1152
1280
1280
1280
1280
1280
1600
856
856
856
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
400
400
600
600
600
600
600
624
768
768
768
768
864
870
960
960
1024
1024
1024
1200
480
480
480
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
dots
©2002 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
Microsoft, PowerPoint and Windows are registered trademarks of Microsoft Corporation.
Netscape is a registered trademark of Netscape Communications Corporation.
Distributed by
MOD2002-007(7819V1)WEL0020
Printed in Hong Kong
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
