Preparing
Enjoying music with the
Network Walkman
Portable IC Audio Player
Network Walkman NW-E103/E105/E107
Checking the package
contents
You can easily transfer digital audio files from your computer to your Network Walkman
using the SonicStage software to enjoy music anywhere you go.
Operating Instructions
Quick Start Guide
Import audio files to
your computer
SonicStage
• Network Walkman (1)
Headphones (1)*
Installing the SonicStage
software
Be sure to install the “SonicStage” software from the supplied CD-ROM in your computer.
(The driver for the Network Walkman, the PDF file Operating Instructions and the PDF file
SonicStage Operating Instructions will be installed.)
• Dedicated USB cable (1)
Transfer audio files to
your Network Walkman
1 Insert the supplied CD-ROM into your
computer.
The install wizard will be displayed.
Play back
a song
Refer to the PDF file “Operating Instructions”
Refer to the PDF file “Operating Instructions” for more information and for troubleshooting.
The PDF file “Operating Instructions” will be installed when the SonicStage
software is installed. Double-click
(“NW-E100 series manuals”), or
click [Start] - [All Programs] - [SonicStage] on your computer.
• Quit the virus check software (the software is
hard-pressed on your computer).
instructions on the screen.
(When the Region Selection screen is displayed, select your area and click [Next].)
Inserting the battery
Be sure to use the
SonicStage software to
playback music with
your Network Walkman.
Install SonicStage
SonicStage installer
Insert an LR03 (size AAA) alkaline battery with correct polarity.
You can play back songs in order of group
and select playback mode, Shuffle, Repeat, or
etc.
Let’s use the unit
© 2005 Sony Corporation
• Log on as administrator (in case of Windows
2000 / Windows XP).
2 Click [Install SonicStage] and follow the
Import audio files from an audio CD or the
Internet. Audio files can be organized on
SonicStage.
For other languages PDF file “Operating Instructions”
English PDF file “Operating Instructions” are contained in the supplied CDROM.
O ficheiro PDF “Instruções de funcionamento” em português está no CDROM fornecido.
Nederlands PDF-bestand "Gebruiksaanwijzing" vindt u op de bijgeleverde
CD-ROM.
Den svenska PDF-filen ”Bruksanvisning” finns på den medföljande CD
ROM-skivan.
Suomenkielinen PDF-tiedosto ”Käyttöohje” on toimitetulla CD-levyllä.
Фaйл “Инcтpyкция по экcплyaтaции” в фоpмaтe PDF нa pyccком
языкe cодepжитcя нa пpилaгaeмом диcкe CD-ROM.
• Quit all activated applications on your
computer.
* On PSYC® Model, a different type headphone
may be supplied.
How to display the PDF file “Operating Instructions”
You need Adobe Acrobat Reader 5.0 or later, or Adobe Reader software in
your computer.
Notes
• CD-ROM for the SonicStage software, PDF
file Operating Instructions and PDF file
SonicStage Operating Instructions (1)
• Quick Start Guide
Installation may take 20 to 30
minutes depending on your
computer. Restart the computer
after installing is complete.
If you cannot install the
software, check the Q&A
shown below.
➔
Proceed with steps 1 to 6
Printed in China
Remaining battery indication
The battery icon in the display changes as shown below.
