Data Sheet 6407125

Data Sheet 6407125
Data Sheet 6407125
Product:
El-number:
Mat.no:
EAN:
Packing:
Color:
ELKO Sound utehøytt IP44 PH
6407125
EKO06089
7020160608918
1
Polarwhite
Product description:
Set of 2 pcs two-way outside loudspeakers. Delivered with bracket for
surface mounting.
Technical specifications: Dimentions:
WxHxD (measures in mm): 163 x 237 x 160
Spesifications:
5 1/4 bass element in polypropylen.
Tweeter in PEI.
Effect: Max 120W/35W RMS
Frequency response: 50-20.000 Hz
Sensitivity: [email protected]/1M
Impedance: 8 Ohm
Material / Color: White RAL 9010, ABS.
Weight: 1,9 Kg pr loudspeaker
Size
Wiring diagram
