The following are trademarks or registered trademarks of the Sony
Corporation Japan: ‘Sony’, ‘make.believe’, ‘Walkman’, ‘QuickBrowZer’, ‘ZAPPIN’, ‘SensMe’ and ‘Xplod’.
Please note that Quick-BrowZer™ and SensMe™ technologies are
only compatible with selected MP3 players.
MapShare™, HD Traffic™, IQ Routes™, LIVE QuickGPSfix™ and
LIVE Services are trademarks owned by TomTom N.V. or one of its
subsidiaries. All rights reserved.
Google™ is a trademark of Google Inc. All rights reserved.
Microsoft Windows Media and the Windows logo are trademarks or
registered trademarks of Microsoft Corporation in the United States
and/or other countries.
“Made for iPod” and “Made for iPhone” means that an electronic
accessory has been designed to connect specifically to iPod or iPhone
respectively, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod or iPhone may
affect wireless performance.
iPod and iPhone are trademarks of Apple Inc. registered in the USA and
other countries.
MirrorLink™ and the MirrorLink™ logo are certification marks of the
Car Connectivity Consortium LLC. Unauthorized use is strictly prohibited.
Bluetooth is a trademark owned by Bluetooth SIG. Inc. USA and
licensed by Sony Corporation. All other trademarks are acknowledged.
Whilst the information is true at the point of printing, small production
changes in the course of the Company’s policy of improvement
through research and design might not necessarily be indicated in the
specification. Subject to errors, design and technical changes. Some
images shown are for illustration purposes only.
Sony [insert the division name],
a division of Sony Europe Limited.
Registered Office:
The Heights, Brooklands,
Weybridge, Surrey KT13 0XW.
Company No. 2422874.
Registered in England & Wales
D
CAR ENTERTAINMENT
CAR ENTERTAINMENT
A
CONTENTS
CAR ENTERTAINMENT USER BENEFITS
You’re always connected
Your smartphone’s a big part of your world. But once you’re behind the wheel your music collection, contacts and
navigation apps are hard to access.
Now Sony helps you reach your destination while staying in touch with your digital world. The XAV-601BT is the first
Audio Visual Centre head unit from Sony that connects your smartphone and your vehicle to enhance every journey.
Climb aboard and hook up your MirrorLink™ compatible device with a USB cable.. The XAV-601BT instantly
recognises your smartphone, launching an optimised view of the phone screen on the head unit’s large, high-resolution
touchscreen.
As well as making and receiving calls safely, you can interact with your phone’s media collection and compatible
apps. Easily call up contacts from your phonebook with voice recognition and make hands-free calls. Hear Tweets and
other social media updates read out as you drive with automatic text-to-speech conversion. Get directions from your
smartphone’s navigation app displayed on the head unit’s screen1.
1Voice recognition, text readout, navigation and other in-car services depend on supported functions of smartphone.
AV Center
Control
About MirrorLink™
MirrorLink™ is a technology standard developed by the Car Connectivity Consortium (CCC) that unites many of the
world’s major electronics, automotive and mobile communications companies.
With MirrorLink™, drivers can safely access many of their smartphone’s capabilities from behind the wheel, without
looking at or touching the phone itself.
MirrorLink™ seamlessly connects your phone with your vehicle’s information and entertainment system. Approved
applications and content are ‘mirrored’ from the mobile device onto the display of your in-dash head unit. This
connectivity allows you to interact safely with your smartphone via the car’s head unit display, steering wheel buttons
and audio system.
Car Entertainment User Benefits
3
Visual Products
6
Optional TomTom hide-away navigation module
7
Digital Music Receivers
8
CD Receivers
10
In-car components
16
Smartphone
Mirroring
1. See your smartphone’s screen on the AV head unit
2. Enjoy in-car apps with less driver distraction
3. Future proof access to a growing world of applications
4. Charge as you drive.
Interact with your smartphone’s media and apps from the large (15.5cm/6.1”) touchscreen of the XAV-601BT
AV Centre. The phone’s display is re-formatted for clearer, safer viewing on the head unit.
Many smartphone manufacturers now offer a ‘Car Mode’ application. This customised app optimises your phone’s
user interface and functions for in-vehicle operation, with large, easy-to-use buttons to minimize driver distraction.
Speakers16
Subwoofers21
Amplifiers23
Glossary24
Accessories25
Marine Products
2
26
CAR ENTERTAINMENT
The XAV-601BT offers guaranteed and future proof compatibility with all certified MirrorLink™ devices from
a range of phone manufacturers.
The XAV-601BT charges your smartphone’s battery while it’s connected to the head unit. Charging doesn’t
interfere with operation of your smartphone, so you can make calls and use other phone apps while the battery
charges as you drive.
CAR ENTERTAINMENT
3
CAR ENTERTAINMENT USER BENEFITS
CAR ENTERTAINMENT USER BENEFITS
TomTom navigation expandability
Connecting easily to the head unit by USB, the optional XA-NV200TL/XA-NV100TL TomTom navigation module offers:
• More powerful processing for quicker route calculation
• Improved GPS signal reception with supplied external GPS antenna
• Pre-loaded TomTom database for richer, more detailed mapping
Multi-format playback
See clearly with high resolution screens
Enjoy music and video stored in a wide range of popular file formats. Play DVDs, CDs, or CD-RWs loaded with
hundreds of MP3, AAC or WMA songs, plus Xvid, JPEG and Simple Profile MPEG-4 video files.
Enjoy a wealth of visual entertainment with double-DIN head units that integrate easily into your vehicle’s
centre console. Sony’s ultra-bright 15.5cm (6.1”) wide VGA screen displays videos, album artwork and more
with an extra-high resolution of 800×480 pixels.
Rear view camera compatible
Connect the XA-R800C rear view camera (available separately) for peace of mind when manoeuvring,
especially with larger vehicles or where rear visibility is restricted. Wide viewing area and adjustable parking
guidelines give extra convenience while reversing.
Dual USB for extra connectivity
Connect your MP3 player, smartphone or flash drive to the easily-accessible front panel USB connector. There’s a
second rear-mounted USB port to hook up another media player or optional TomTom navigation module.
Connect and play
Easily connect a wide range of digital music players to your in-car unit, including iPod, iPhone and Walkman®
as well as USB drives, everything’s controlled from the touch screen interface.
Zone by Zone entertainment
Let front seat passengers enjoy their own choice of music, while rear passengers are entertained with a DVD
on optional rear screens.
Match your mood with SensMe™
Fully removable anti-theft front panel
Passenger Control mode for iPhone/iPod
Integrated Bluetooth® technology
Dynamic Colour Illuminator
The front panel detaches easily, helping keep your head unit safe from prying eyes.
It’s never been easier to take calls safely and enjoy streaming audio while you’re at the wheel. Connect
compatible devices wirelessly to the head unit and easily choose between hands-free calling or audio
streaming.
4
CAR ENTERTAINMENT
Let front seat passengers control music and video streaming, navigation and other iPod/iPhone apps while
you drive safely. The screen of a connected iPod/iPhone is displayed on the head unit. Hands-free telephone
functions are also supported if your iPhone is connected to the Bluetooth-enabled XAV-601BT head unit.
Pick from 35,000 head unit panel illumination colours and co-ordinate perfectly with your vehicle’s in-dash
lighting.
Intuitive application that intelligently analyses your music collection. SensMe™ automatically groups tracks
into themed channels: just choose a favourite to suit driving conditions or your mood. It’s the smarter, simpler
way to manage and enjoy all your music collection.
More control over perfect sound
Stress-free fingertip control
Touch the high-resolution screen and a virtual control panel pops up for safer, simpler control of play, pause, shuffle and
other functions. Choose albums and change tracks by sliding your finger from side to side or up and down the screen.
Advanced Sound Engine (ASE) combines advanced digital audio technologies by Sony to give you
unprecedented power over creating perfect in-car sound with any music source. Centre Speaker
Organiser recreates the power and precision of 5.1 channel surround sound by placing an additional ‘virtual’
speaker right in the centre of your dashboard.
CAR ENTERTAINMENT
5
VISUAL PRODUCTS
OPTIONAL TOMTOM HIDE-AWAY NAVIGATION MODULE
XAV-601BT
Compatible with the XAV-601BT head unit, the optional XA-NV200TL (or XA-NV100T) opens up the world of advanced navigation by TomTom. Stowing discreetly in a glove box or under seat, this compact module lets you
take full advantage of the exciting range of intelligent mapping and traffic information services by TomTom. You’ll also make every journey safer and more satisfying with local searches, route advice, safety alerts and more.
MirrorLink™ compatible Bluetooth® Audio Visual Centre with 15.5cm
(6.1”) WVGA touchscreen and Dual USB
TomTom expandable
Supplied accessories
•Compatible with MirrorLink™ certified smartphones
•Passenger App Control mode for iPhone/iPod
•TomTom navigation expandable
•Removable front panel for anti-theft security
•Dynamic Colour Illuminator to match your dashboard
XA-MC10
RM-X271
•Bluetooth® for hands-free talking and music streaming
•External microphone for better voice capture
•Dual USB for direct control of connected smart-phone, iPod/iPhone/Walkman®, plus playback
Recommended
compatibility with USB flash drives
accessories
•MP3/WMA/AAC/WAV/WMV/H.264/Xvid/JPEG
and MPEG-4 Simple Profile codec compatible
•High resolution 15.5cm/6.1” WVGA touchscreen
•Dynamic Reality Amplifier with 4 x 52W high power output
•Digital Clarity Tuner for improved FM stereo reception
XA-R800C
•SensMe™ organises your music into different moods
•Quick, easy searches through all your music tracks with ZAPPIN™
•Centre Speaker Organiser and Intelligent Time Alignment technologies
for high quality sound
•Low-pass and high-pass filters for flexible sound customisation
RC-202IPV
•Zone by Zone function for rear seat entertainment
•3 × 5 Volt pre-out for system expandability
The best traffic information with HD Smarter journeys with IQ Routes™
Only TomTom uses actual speed data collected from millions of users
to calculate the quickest routes at any instant. IQ Routes™ factors in
Traffic™
Get the most sophisticated, up-to-date traffic information available
with High Definition Traffic™. Updated every few minutes, you’ll learn
about delays and other incidents almost as soon as they happen. HD
Traffic™ is a revolution in traffic information that offers the broadest
coverage plus the most updates from the best sources.
rush-hour delays, zebra crossings, school drop-offs, traffic lights and
even shopping hotspots at 5-minute intervals throughout the day. You’ll
benefit from the most accurate route planning possible, saving you time
and money.
Drive Europe
You’re ready to explore the continent with intelligent maps covering 45
European countries. Advanced graphics and IQ Routes™ speed profiles
suggest the quickest route at any time of day. Detailed information on
local points of interest puts the answers you need at your fingertips.
See for yourself!
Scan this QR code with your smartphone
to see MirrorLink™ in action with the
XAV-601BT AV Centre Head Unit.
Drive safer with Safety Alerts
XAV-63
Safety Alerts give you advanced, real time warning of fixed safety
cameras, mobile safety cameras and accident black spots. You’ll get
more time to adjust your speed and anticipate road conditions for safer
driving.*
Audio Visual Centre with 15.5cm (6.1”) WVGA touchscreen
and Front USB
•Passenger App Control mode for iPod/iPhone
•MP3/WMA/AAC/Xvid/JPEG and MPEG-4 Simple Profile codec compatible
•High resolution 15.5cm/6.1” WVGA touchscreen
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback compatibility
with USB flash drives
•Dynamic Reality Amplifier with 4 x 52W high power output
•Digital Clarity Tuner for improved FM stereo reception
•SensMe™ organises your music into different moods
•Quick, easy searches through all your music tracks with ZAPPIN™
•Centre Speaker Organiser and Intelligent Time Alignment technologies for high quality sound
•Low-pass and high-pass filters for flexible sound customisation
•2 × 2 Volt pre-out for system expandability
Local Search with Google™
Imagine you’ve just arrived in town and need to find the best Thai
restaurant. Or perhaps you want to buy some flowers on the way home.
Local Search with Google™ lets you tap into the world’s largest local
search database, straight from your in-dash navigation unit. Enter any
search term, find matching locations and you’re on your way.
Stay up to date with MyTomTom
Download the latest navigation software updates, get new maps,
access free content and more. Just remove the TomTom Navigation
Module from your vehicle and connect to your computer via USB.
Supplied
accessory
XA-NV200TL
Optional TomTom hide-away navigation module with LIVE services and
external GPS antenna for XAV-601BT
RM-X170
•HD Traffic™ delivers the most up-to-date traffic information on the road live to your dashboard
•Safety Alerts keeps you aware of traffic cameras and accident black spots*
•Tap into the world’s largest database of shops and businesses, wherever you go by using Local Search with Google™
•TomTom Map puts routes across 45 European countries at your fingertips
•IQ Routes™ suggests the fastest and smartest routes using actual speed data from millions of users
•MyTomTom Home future-proofs your in-dash navigation with map and content updates plus new services
•Supplied GPS antenna for improved signal reception
Recommended
accessories
XA-R800C
RC-202IPV
6
CAR ENTERTAINMENT
*NOTE: it’s illegal in France to receive speed camera alerts.
CAR ENTERTAINMENT
7
DIGITAL MUSIC RECEIVER
DIGITAL MUSIC RECEIVERS
DSX-S300BTX
Stay connected with great sounding music
Forget the days of messy cables connecting to your car’s head unit and loose players rattling around in the glove compartment. The DSX-S range cleverly eliminates these problems with Tune Tray,
the smartest way to connect with your music on the move. Tune Tray stows your player neatly inside the head unit. No fuss, no untidy wires. Just great sounding music that you’re in control of.
Bluetooth Digital Music Receiver with Tune Tray and Double USB
®
Tune Tray
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•Built-in microphone for hands free calls
•Tune Tray behind front panel securely stores your music player
•Double (Front + Inside) USB connection for iPod, iPhone, Walkman® and other MP3 players*
•Easy to read, informative 4-line Full-Dot OEL display
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•SensMe™ Channels organises your music into different moods
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•’Device Inside Alert’ gives visual and audible reminder when digital music player is left in vehicle
•Blue/Red key illumination
•Steering Wheel Control Adapter Ready
•Supplied XA-50IP iPod adapter and RM-X305 card remote control
•Optional XA-50WM Walkman® adapter and XA-MC10 external microphone
Cut down on cabin clutter while you enjoy great-sounding music. Hidden behind the head
unit’s front panel, Tune Tray discreetly stores your music player or USB memory. Connect
directly with a huge range of popular music players including iPod Classic, iPod Touch, iPod
nano and WALKMAN®. Then say goodbye to messy wires while protecting your player from
accidental damage.
Recommended
accessories
XA-MC10
XA-50WM
DSX-S100
Digital Music Receiver with Tune Tray and Inside USB
High contrast display
The sleek, detachable faceplate of the DSX-S100 features a 2-line high contrast LCD display.
The DSX-S300BTX offers a clear, bright OEL 4-line display that shows the same information
you’re used to seeing on your digital music player.
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Tune Tray behind front panel securely stores your music player
•Inside USB connection for iPod, Walkman® and other MP3 players
•Front Auxiliary input for easy MP3 player connection
•Informative 2-line high contrast LCD display
•’Device Inside Alert’ gives visual and audible reminder when digital music player
is left in vehicle
•Blue key illumination
•Steering Wheel Control Adapter Ready
•Supplied XA-50IP iPod adapter
•Optional XA-50WM Walkman® adapter
Dual USB connection
Stay connected with even more music. An extra USB port lets you hook up a portable player,
phone or flash drive while your other player stays connected in the Tune Tray.
(DSX-S300BTX only)
Recommended
accessory
XA-50WM
DSX-A50BT
Bluetooth Digital Music Receiver with Front USB
®
Device Inside Alert
Never forget your digital music player again. After the vehicle engine’s switched off, an
audible and visual warning signals that your music player is still inside the Tune Tray. You’ll
also get a clear visual alert if your player is still inside when the head unit’s faceplate is
removed.
SensMe™
Intuitive application that intelligently analyses your music collection. SensMe™ automatically groups tracks into themed channels: just choose a favourite to suit driving conditions or
your mood. It’s the smarter, simpler way to manage and enjoy all your music collection.
*Do not place a cellular phone or a device with wireless communication functions
on the Tune Tray, as it may not receive phone signals or communication may be terminated.
8
CAR ENTERTAINMENT
•Bluetooth® for hands-free talking and music streaming
•Built-in microphone for hands free calls
•Dynamic Reality Amp with 4 × 50W high power output
•Digital Clarity Tuner for improved FM stereo reception
•Front USB for connection to Walkman®, USB flash drives and other compatible devices
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ for easy music searches
•Partial Detachable Panel
•Blue key illumination
•2 x 2 Volt pre-outs for system expandability
•Steering Wheel Control Adapter Ready
CAR ENTERTAINMENT
9
CD RECEIVERS - DAB
CD RECEIVERS
Automatic Level Optimiser
Easy-fit high-sensitivity DAB antenna
With Automatic
Level Optimiser
The receiver comes supplied with a compact, highly sensitive DAB antenna that adheres
discreetly inside the windscreen to offer excellent signal reception. The powerful
adhesive film allows quick, easy installation, with no need to drill holes or make other
modifications to your vehicle.
Without Automatic
Level Optimiser
Sudden jumps in sound level can be distracting when you switch between CD, FM tuner or MP3 music sources. Automatic Level Optimiser keeps everything smooth and even, for more
comfortable listening without having to keep reaching for the volume control.
DAB/DAB+/DMB-R radio reception
Enjoy an even wider range of digital radio entertainment. The CDX-DAB700U pulls in
your favourite digital stations and analogue broadcasts (FM/AM) for clear reception
while you’re on the road. It’s the first head unit from Sony that’s compatible with regular
DAB transmissions as well as newer DAB+ and DMB-R standards that offer improved
transmission efficiency.
Music source A
Music source B
Music source C
Music source A
Music source B
Music source C
Digital Clarity Tuner
Enjoy improved stereo channel separation if you’re driving in areas with weak FM signal reception. The new Digital Clarity Tuner ensures a natural, satisfying stereo soundstage even when
you’re further away from a radio transmitter.
Informative 2-line display
Get even more from your radio listening experience. The generously-sized, high-contrast
display offers detailed information including radio station name and DAB Dynamic Label
messages. To maximise display size, the head unit’s front panel flips down to reveal the
CD loading slot.
CDX-DAB700U
Variable illumination in-car CD receiver with Front USB for iPod/iPhone/
Walkman® connection and DAB/DAB+/DMB-R tuner
•DAB/DAB+/DMB-R and FM/MW/LW radio reception
•Easy-fit high-sensitivity DAB antenna included
•2-line flip-down display
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4 x 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between
different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback
compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•SensMe™ channels organizes your music into different moods
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•3 x 2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
•Supplied card remote control RM-X211
Analog Tuner
Mono area Stereo area
Digital Clarity Tuner
Mono area Wider Stereo area
Dynamic Reality Amp
This advanced new power amplifier design produces a highly detailed soundstage inside your vehicle. You’ll enjoy even more involving, natural reproduction of all music sources.
Supplied
accessories
RM-X211
DAB antenna
Intuitive search features:
Quick-BrowZer™ and ZAPPIN™
Quick-BrowZer™ helps you track down music by artist, album, genre, song or playlist.
Jump Mode fast forwards through your library, while ZAPPIN™ plays a short snatch of
each track to help you find your favourite songs.
10
CAR ENTERTAINMENT
Advanced Sound Engine
Combines Automatic Level Optimizer, EQ7 equalizer, adjustable LPF/HPF crossovers, Listener
Position calibration, DM+ advanced sound restoration, Rear Bass Enhancer and Dynamic
Loudness volume leveller to create an ideal in-car listening environment.
CAR ENTERTAINMENT
11
CD RECEIVERS
CD RECEIVERS
MEX-BT4000U
Variable illumination Bluetooth in-car CD receiver with Front USB for
iPod/iPhone/Walkman® connection
•Bluetooth® for hands-free talking and music streaming
Supplied
•Phone Book Access and built-in phone book memory
accessories
•External microphone for better voice capture
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
External microphone
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•2 x 2 Volt pre-outs for system expandability
•Low-pass and high-pass filters for improved sound customisation
RM-X231
•Steering wheel remote adapter ready
•With supplied card remote control
MEX-BT3900U
Bluetooth in-car CD receiver with Front USB
for iPod/iPhone/Walkman® connection
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•Built-in microphone for hands free calls
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback
compatibility with USB flash drives
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•2 x 2 Volt pre-out for system expandability
•Low-pass and high-pass filters for improved sound customisation
•Steering wheel remote adapter ready
•Blue/Red key illumination
•Supplied card remote control RM-X174
Supplied
accessory
RM-X211
Recommended
accessories
XA-MC10
MEX-BT3000
Supplied
accessory
RM-X174
CDX-GT660UV
•2-line flip-down display
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between
different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback
compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•SensMe™ channels organizes your music into different moods
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•3 x 2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
•Supplied card remote control RM-X211
Supplied
accessory
RM-X211
CDX-GT565UV
Bluetooth in-car CD receiver with Front AUX-IN connection
Variable illumination in-car CD receiver with Front USB
for iPod/iPhone/Walkman® connection
•Bluetooth® for hands-free talking and music streaming
•Phone Book Access
•Built-in microphone for hands free calls
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•2 Volt pre-out for system expandability
•Low-pass and high-pass filters for improved sound customisation
•Steering wheel remote adapter ready
•Blue key illumination
•Variable illumination to colour match your dash
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between
different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback
compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•2 x 2 Volt pre-outs for system expandability
•Steering wheel remote adapter ready
®
CAR ENTERTAINMENT
•3-line flip-down fluorescent display
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback
compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•3 x 4 Volt pre-out for system expandability
•Steering wheel remote adapter ready
•Blue/Red/Green key illumination
•Supplied card remote control RM-X174
Flip-down variable illumination in-car CD receiver with Front USB for
iPod/iPhone/Walkman® connection
®
12
CDX-GT740UI
Flip-down fluorescent display in-car CD receiver with Front USB
for iPod/iPhone/Walkman® connection
®
CAR ENTERTAINMENT
13
CD RECEIVERS
CD RECEIVERS
CDX-GT560UI
CDX-GT260MP
In-car CD receiver with Front USB for iPod/iPhone/Walkman
connection
In-car CD receiver with Front AUX-IN connection
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between different music sources
•Front USB for direct control of connected iPod/iPhone/Walkman®, plus playback compatibility with USB flash drives
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
Also available in red key illumination
•2 Volt Rear/Sub switchable pre-out for system expandability
CDX-GT564UI
•Blue key illumination
•Steering wheel remote adapter ready
•Dynamic Reality Amp with 4 × 45W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•MP3/WMA compatible CD player
•Front Auxiliary input to connect compatible MP3 player
•2 Volt Rear/Sub switchable pre-out for system expandability
•Low-pass and high-pass filters for improved sound customisation
•Red key illumination
Also available in green key illumination
•Steering wheel remote adapter ready
CDX-GT264MP
®
CDX-GT450U
CDX-GT26
In-car CD receiver with Front USB and AUX-IN connection
In-car CD receiver with Front AUX-IN connection
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Front USB for connection to Walkman®, USB flash drives
and other compatible devices
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks
•2 Volt Rear/Sub switchable pre-out for system expandability
•Low-pass and high-pass filters for improved sound customisation
•Red key illumination
•Steering wheel remote adapter ready
•Dynamic Reality Amp with 4 × 52W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•MP3/WMA compatible CD player
•Front Auxiliary input to connect compatible MP3 player
•2 Volt Rear/Sub switchable pre-out for system expandability
•Low-pass and high-pass filters for improved sound customisation
•Amber key illumination
•Steering wheel remote adapter ready
DAB
DAB
CDX-GT40U
In-car CD receiver with Front USB and AUX-IN connection
•Dynamic Reality Amp with 4 × 45W high power output
•Advanced Sound Engine with digital signal processing for perfect in-car sound
•Digital Clarity Tuner for improved FM stereo reception
•Automatic Level Optimiser reduces sudden jumps in playback volume between different music sources
•Front USB for connection to Walkman®, USB flash drives and other compatible devices
•Front Auxiliary input to connect compatible MP3 player
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•DM+ restores lost frequencies from compressed digital music tracks Also available in green key illumination
•2 Volt Rear/Sub switchable pre-out for system expandability
CDX-GT44U
•Low-pass filter for improved sound customisation
•Red key illumination
•Steering wheel remote adapter ready
14
CAR ENTERTAINMENT
DSX-S300BTX
DSX-S100
DSX-A50BT
MEX-BT4000U
MEX-BT3900U
MEX-BT3000U
CDX-GT740UI
CDX-DAB700U
CDX-GT660UV
CDX-GT565UV
CDX-GT560UI
CDX-GT564UI
CDX-GT450U
CDX-GT40U
CDX-GT44U
CDX-GT260MP
CDX-GT264MP
CDX-GT26
•
Bluetooth
Design
Connectivity
Bluetooth
Microphone Phone Illumina- iPod, Walkman USB
Hands-free
Book
tion
iPhone
(HFP) and
Access
Music streaming
(A2DP)
•
Built-in +
•
Blue/Red
•
•
Dual
optional
external
Blue
•
•
Inside
•
Built-in
•
Blue
•
Front
•
External
•
Variable
•
•
Front
•
Built-in
•
Blue/Red
•
•
Front
•
Built-in
•
Blue
Blue/Red/
•
•
Front
Green
Variable
•
•
Front
Variable
•
•
Front
Variable
•
•
Front
Blue
•
•
Front
Red
•
•
Front
Red
•
Front
Red
•
Front
Green
•
Front
Red
Green
Amber
AUX
SensMe
•
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
Front
•
•
User interface
Codec
Quick- ZAPPIN CD-R/RW MP3
WMA
BrowZer
AAC
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Radio
Digital
RDS
Calrity
Tuner
•
•
•
•
•
•
•
•
•
•
•
•
•
Sound
Output Advanced EQ7/EQ3 Pre Out Steering
power Sound
wheel
Engine
adopter
ready
•
52
•
•
•
•
•
•
52
50
52
52
52
52
•
•
•
•
•
•
•
•
•
•
•
52
52
52
52
52
52
45
45
45
45
45
CAR ENTERTAINMENT
•
•
•
•
•
•
•
•
•
•
•
EQ7
3PRE 4V
•
EQ3
EQ3
EQ7
EQ7
EQ3
EQ3
parametr
EQ7
EQ7
EQ7
EQ7
EQ7
EQ7
EQ7
EQ7
EQ3
EQ3
EQ3
2 PRE OUT
2 PRE OUT
2 PRE OUT
2 PRE OUT
PRE SUB
3PRE 4V
•
•
•
•
•
•
3PRE OUT
3PRE OUT
2PRE OUT
PRE SUB
PRE SUB
PRE SUB
PRE SUB
PRE SUB
PRE SUB
PRE SUB
PRE SUB
•
•
•
•
•
•
•
•
•
•
•
15
IN-CAR COMPONENTS
SPEAKERS
XS-GTX6932
6 x 9” 3-Way Coaxial Speaker
Dimensions
153mm
222mm
74mm
•Peak power: 500W
•Rated power: 85W
•Frequency response: 30-30KHz
•Stroke stabiliser surround
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
XS-GTR6920
6 x 9” 2-Way Coaxial Speaker
•Peak power: 400W
•Rated power: 100W
•Frequency response: 35-27KHz
•Mica reinforced cellular woofer cone for tight, deep bass
•Soft dome tweeter for smooth and natural highs
•Bi-amp: dual speaker terminals allow separate connection
of woofer and tweeter
Dimensions
236.9mm
152.6mm
Nobody wants sudden shut-downs spoiling their soundtrack when the volume’s turned up high. Active Thermal Control is an advanced new protection system that constantly monitors amplifier
temperature. Output power levels are smoothly maintained within safe limits, keeping things cooler if there’s a momentary risk of over-heating. You’ll enjoy uninterrupted listening without
annoying dips in volume.
88mm
Keep your cool
XS-GTX1741
17cm 4-Way Coaxial Speaker
Larger woofer cone area than normal (6 × 12” / 15.24 x 30.48 cm
as compared to 6 × 9” / 15.24 x 22.86 cm)
Louder, deeper bass without compromising additional cargo space
Rated power/peak power of 100W/400W (for XS-GTF6120)
XS-GTF6120
16
CAR ENTERTAINMENT
16cm 2-Way Separate Speaker
Dimensions
292.2mm
168mm
78mm
•Peak power: 400W
•Rated power: 100W
•Frequency response: 32-22KHz
•Stroke stabiliser surround
•Mica reinforced cellular cone woofer for rich deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
XS-GTX1622S
•Peak power: 260W
•Rated power: 60W
•Frequency response: 50-30KHz
•Surface, angle and flush mounting tweeter
installation options
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•Soft-dome tweeter for smooth, natural highs
Dimensions
38mm
23mm
6 x 12” 3-Way Coaxial Speaker
165mm
166mm
55mm
Light cone weight and higher sound pressure level
Dimple alignment optimised to maintain rigidity
High output 6x12” speaker
Dimensions
54mm
Dimpled subwoofer cones
•Peak power: 300W
•Rated power: 75W
•Frequency response: 50-24KHz
•Easy-fit design for simple installation with wide range of vehicles
•Stroke stabiliser surround
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
CAR ENTERTAINMENT
17
SPEAKERS
SPEAKERS
XS-GTX1341
6 × 9” 3-Way Coaxial Speaker
130mm
45mm
Dimensions
•Peak power: 300W
•Rated power: 60W
•Frequency response: 40-22KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
Dimensions
XS-GTR1720
XS-F6927SE
6 × 9” 2-Way Coaxial Speaker
65mm
160mm
•Peak power: 280W
•Rated power: 60W
•Frequency response: 40-22KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) tweeter for smooth, clear highs
Dimensions
XS-GTR1720S
17cm 3-Way Coaxial Speaker
47mm
160mm
65mm
Dimensions
28mm
•Peak power: 350W
•Rated power: 75W
•Frequency response: 45-36KHz
•Mica reinforced cellular woofer cone for tight, deep bass
•Aluminium dome tweeter for crystal clear highs
•Surface, angle and flush mounting tweeter installation
options
•High quality crossover network with bi-amp (woofer/
tweeter) connection capability
XS-F1737SE
•Peak power: 200W
•Rated power: 40W
•Frequency response: 50-24KHz
•Easy-fit design for simple installation
with wide range of vehicles
•H.O.P. + aramid fibre cone woofer
for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth,
clear highs
Dimensions
XS-H20S
18
CAR ENTERTAINMENT
17cm 2-Way Coaxial Speaker
Dimensions
23mm
•Peak power: 130W (Crossover network connected)
•Rated power: 40W (Crossover network connected)
•Frequency response: 5k-36KHz
•Tetron fibre soft dome tweeter
•Neodymium magnet
•Multiple mounting options
•6 dB/octave inline crossover
XS-F1727SE
38mm
•Peak power: 190W
•Rated power: 40W
•Frequency response: 50-24KHz
•Easy-fit design for simple installation with wide range of vehicles
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) tweeter for smooth, clear highs
Dimensions
165mm
45mm
Component tweeter
165mm
45mm
17cm 2-Way Separate Speaker
237mm
168mm
Dimensions
•Peak power: 320W
•Rated power: 75W
•Frequency response: 45-32KHz
•Mica reinforced cellular woofer cone for tight, deep bass
•Aluminium dome tweeter for crystal clear high
•Bi-amp: dual speaker terminals allow separate connection of woofer
and tweeter
75mm
17cm 2-Way Coaxial Speaker
237mm
168mm
•Peak power: 220W
•Rated power: 50W
•Frequency response: 60-24KHz
•Stroke stabiliser surround
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
75mm
13cm 4-Way Coaxial Speaker
XS-F6937SE
CAR ENTERTAINMENT
19
SPEAKERS
SUBWOOFERS
XS-F1337SE
13cm 3-Way Coaxial Speaker
Dimensions
130mm
45mm
XS-F1327SE
13cm 2-Way Coaxial Speaker
Dimensions
Type
Peak power
Rated power
Stroke stabilizer
Cone woofer
Mid
100W
85W
100W
75W
60W
Frequency
response
32-22KHz
30-30KHz
35-27KHz
50-24KHz
50-30KHz
XS-GTF6120
XS-GTX6932
XS-GTR6920
XS-GTX1741
XS-GTX1622S
6 x 12 inch
6 x 9 inch
6 x 9 inch
17cm
16cm
3-Way
3-Way
2-Way
4-Way
2-Way
Coaxial
Coaxial
Coaxial
Coaxial
Separate
400W
500W
400W
300W
260W
yes
yes
Mica reinforced cellular
H.O.P. + aramid fibre
Mica reinforced cellular
H.O.P. + aramid fibre
H.O.P. + aramid fibre
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
XS-GTX1341
XS-GTR1720
XS-GTR1720S
XS-H20S
13cm
17cm
17cm
4-Way
2-Way
2-Way
Coaxial
Coaxial
Separate
Component tweeter
220W
320W
350W
130W
50W
75W
75W
40W
60-24KHz
45-32KHz
45-36KHz
5k-36KHz
yes
H.O.P. + aramid fibre
Mica reinforced cellular
Mica reinforced cellular
PEN (Polyethylene naphthalate)
XS-F6937SE
XS-F6927SE
XS-F1737SE
XS-F1727SE
XS-F1337SE
XS-F1327SE
XS-F1037SE
XS-F1027SE
6 x 9 inch
6 x 9 inch
17cm
17cm
13cm
13cm
10cm
10cm
3-Way
2-Way
3-Way
2-Way
3-Way
2-Way
3-Way
2-Way
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
Coaxial
300W
280W
200W
190W
160W
150W
140W
130W
60W
60W
40W
40W
40W
35W
30W
30W
40-22KHz
40-22KHz
50-24KHz
50-24KHz
60-24KHz
60-24KHz
60-24KHz
60-24KHz
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre
H.O.P. + aramid fibre cone
PEN (Polyethylene naphthalate)
yes
Tweeter
Other
Soft dome
Bi-amp: dual speaker terminals
Easy-fit design
Surface, angle and flush mounting
installation options
PEN (Polyethylene naphthalate)
Soft dome
Aluminium dome
Aluminium dome
Tetron fibre soft dome
Bi-amp: dual speaker terminals
High quality crossover network
Neodymium magnetand 6 dB/
octave inline crossover
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
Easy-fit design
Easy-fit design
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
PEN (Polyethylene naphthalate)
XS-GTX121LC
12” Compact Size Boxed Subwoofer
XS-F1037SE
10cm 3-Way Coaxial Speaker
Dimensions
•Peak power: 1000W
•Rated power: 300W
•Frequency response: 32Hz-1000Hz
•5-sided polypropylene capless cone for lower distortion and louder,
deeper bass
•Stroke stabiliser
•Rubber surround
•Compact design for installation flexibility
Dimensions
430mm
185,4mm
270mm
102.5mm
43mm
•Peak power: 140W
•Rated power: 30W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
Ways
130mm
45mm
•Peak power: 150W
•Rated power: 35W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) tweeter for smooth, clear highs
Size
370mm
•Peak Power: 160W
•Rated Power: 40W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) mid for smooth, clear highs
Product name
XS-GTX121LS
12” Slim Size Boxed Subwoofer
10cm 2-Way Coaxial Speaker
20
CAR ENTERTAINMENT
Dimensions
102.5mm
Dimensions
445mm
175mm
43mm
•Peak power: 130W
•Rated power: 30W
•Frequency response: 60-24KHz
•H.O.P. + aramid fibre cone woofer for rich, deep bass
•PEN (Polyethylene naphthalate) tweeter for smooth, clear highs
•Peak power: 1000W
•Rated power: 300W
•Frequency response: 42Hz-1000Hz
•5-sided polypropylene capless cone for lower distortion and louder,
deeper bass
•Stroke stabiliser
•Rubber surround
•Shallow design for Installation flexibility
364.5mm
XS-F1027SE
CAR ENTERTAINMENT
21
SUBWOOFERS
AMPLIFIERS
XM-GTR4A
XS-GTR100L
10” Dimpled Cone Subwoofer
Dimensions
278.8mm
•Peak power: 1200W
•Rated power: 60W × 2 (4Ω) + 125W × 2 (4Ω) , 60W × 2 (4Ω) + 340W × 1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•High-pass filter: 50-300Hz, variable
•Subsonic filter for rear channel: 15Hz
•Low boost (40Hz, +10dB)
148.7mm
•Peak power: 1200W
•Rated power: 330W
•Frequency response: 35Hz-1000Hz
•Dimpled woofer cone for light weight
and high sound pressure level bass
•5-sided polypropylene capless cone
for lower distortion and louder, deeper bass
•Injected Polypropylene diaphragm
•Stroke stabiliser
•Rubber surround
Asymmetric 4/3 Channel Stereo Power Amplifier
XM-GTR7040
4/3/2 Channel Stereo Power Amplifier
XS-GTR120L
12” Dimpled Cone Subwoofer
Dimensions
329.8mm
XM-GTR2202
162.5mm
•Peak power: 1300W
•Rated power: 380W
•Frequency response: 30Hz-1000Hz
•Dimpled woofer cone for light weight
and high sound pressure level bass
•5-sided polypropylene capless cone
for lower distortion and louder, deeper bass
•Injected Polypropylene diaphragm
•Stroke stabiliser
•Rubber surround
•Peak power: 700W
•Rated power: 70W × 4 (4Ω), 70W x 2 (4Ω)+160W x 1 (4ΩBTL),
160W x 2(4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•High-pass filter: 50-300Hz, variable
•Subsonic filter for front and rear channel: 6-70Hz, variable
•Low boost (40Hz, +10dB)
2/1 Channel Stereo Power Amplifier
•Peak power: 1400W
•Rated power: 220W x 2 (4Ω, 540W x1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•Subsonic filter: 6-70Hz, variable
•Low boost (40Hz, +10dB)
XS-GTX121L
12” Dimpled Cone Subwoofer
22
CAR ENTERTAINMENT
Dimensions
XM-GTR3301D
326mm
280mm
147mm
•Peak power: 1000W
•Rated power: 300W
•Frequency response: 30Hz-1000Hz
•Dimpled woofer cone for light weight and high sound pressure level bass
•5-sided polypropylene capless cone for lower distortion
and louder, deeper bass
•Injected Polypropylene diaphragm
•Stroke stabiliser
•Rubber surround
Class D Mono Power Amplifier
•Peak power: 1100W (2Ω)
•Rated power: 600W (2Ω), 330W (4Ω), 220W x 2 (4Ω, 540W x1 (4ΩBTL)
•Low-pass filter: 50-300Hz, variable
•Subsonic filter: 6-70Hz, variable
•Low boost (40Hz, +10dB)
CAR ENTERTAINMENT
23
ACCESSORIES
AMPLIFIERS
XM-GTX6041
XA-R800C
XA-MC10
4/3/2 Channel Stereo Power Amplifier
Rear view camera
Hands-free external microphone for
enhanced sound quality
•Peak power: 600W
•Rated Power: 60W x 2 (4Ω) + 140W x 1(4ΩBTL) , 140W x 2 (4ΩBTL)
•Low-pass filter: 80Hz
•High-pass filter: 80Hz
•Adjustable parking guidelines
•Colour CCD sensor lens with 16:9 aspect ratio
•Flexible mounting options with adjustable tilt
•3m camera cable supplied
•138 degrees horizontal and 92 degrees vertical
viewing area
•Optional external unidirectional microphone for
DSX-S300BTX and MEX-BT3900U
•Also compatible with XAV-601BT •4m cable and mounting clip
XM-GTX6021
2/1 Channel Stereo Power Amplifier
•Peak power: 350W (4Ω)
•Rated power: 60W × 2 (4Ω) , 150W x 1 (4ΩBTL)
•Low-pass filter: 80Hz
RC-202IPV
XA-50WM
USB and Video connection cable
for iPod and iPhone
Walkman adaptor for DSX
®
•Supports on-screen audio/video playback from
iPod/iPhone, including album artwork
•Provides device control and charging
•0.9m extended cable length for easy
connectivity and placement of iPod/iPhone
•Connects your Walkman® directly to any
Xplod™ DSX-S series head unit
•Compact size with no messy cables
•Fits inside Xplod™ DSX-S series Tune Tray
GLOSSARY
Advanced Audio Distribution Profile (A2DP)
Industry standard protocol enables wireless music streaming from mobile
phones and other Bluetooth® devices to compatible head unit.
Advanced Audio Coding (AAC)
AAC is a standardised compression method for digital audio. AAC achieves
better quality sound with smaller file sizes when compared to the MP3 format at the same bit rate. AAC is used as the standard audio format for many
popular entertainment devices including the Sony PlayStation® 3.
Advanced Sound Engine
Includes features like Intelligent Time Alignment (ITA), Center Speaker Organizer (CSO) and three selectable levels of Rear Bass Enhancer to enable
you to enjoy multi-channel sound to the fullest.
Xvid
Efficient digital video codec that permits high quality video compression at
low bit-rates. Allows near-DVD quality video playback with smaller file size
than conventional formats.
24
GLOSSARY
Dual USB
For those end-users who keep for example a USB drive in the Tune Tray
while carrying around another portable player or smart phone such as the
iPhone that’s constantly updated with new tunes, the front and second USB
connections come quite handy.
Hands-Free Profile (HFP)
Industry standard connection supports hands-free mobile calls with Bluetooth® phone and compatible head units.
High-pass and low-pass filters
High-pass filters only allow high frequencies to pass through, suppressing
low-end frequencies for a lighter bass sound. Low-pass filters attenuate
high frequencies for a more powerful bass sound.
Intelligent Time Alignment
Adjusts timing of sound reaching the driver from different amplifier channels
for an optimum listening experience.
3-band equaliser (EQ3)
The EQ3 graphic equalizer features 7 preset modes (Xplod, Vocal, Club,
Jazz, New Age, Rock and Custom). Custom mode allows adjustment of 3
frequency bands to suit your taste in music.
CAR ENTERTAINMENT
7-band equaliser (EQ7)
EQ7 offers 7 equalizer options, and 7 preset modes (Xplod, Vocal, Edge,
Cruise, Space, Gravity and Custom) to create the perfect listening environment for your music. Custom mode lets you adjust music to fit your individual listening preference.
Made for iPod/iPhone
Confirms that an electronic device or accessory has been designed to connect specifically to iPod or iPhone and has been certified by the developer to
meet Apple performance standards. Apple is not responsible for operation of
the device or its compliance with safety and regulatory standards.
Phone Book Access Profile (PBAP)
Allows wireless access to mobile phone’s contact list via Bluetooth®
directly from head unit. Phone book contacts are listed alphabetically for
quick, easy searches.
Windows Media Audio (WMA)
WMA files can be easily played through the new and improved head unit
technologies.
W-VGA
With over three times the resolution of previous LCD Screens, W-VGA combines the high-resolution of a TFT display with an improved high-brightness
backlight that provides up to 190% the colour purity of previous models.
Class D
Class D Amplifiers distribute power with the use of output transistors as
switches. These transistors switch between “off” and “on” when too much
or little voltage runs through them. By effectively managing and controlling the
flow of power, Class D Amplifiers deliver higher power output with reduced
current and less heat dissipation, ensuring outstanding audio performance.
Dual Voice Coils
Offers greater flexibility during installation by giving the choice of parallel
or series connection.
Highly Oriented Polyolefin (HOP)
The HOP diaphragm achieves a much broader playback frequency bandwidth and improved transition characteristics – which means clearer,
distortion-free sound is reproduced.
Marine Series
The seaborne can now customise their sound experience with the new
range of Marine Series speakers, designed for the boat/yacht interiors.
Furnished from special materials like stainless steel screws and customised waterproof coating, you will be able to enjoy quality sound experience
anywhere.
Gold plated terminals
Offer superior electrical connection and cleaner signal transfers, while also
eliminating corrosion.
CAR ENTERTAINMENT
25
MARINE
MARINE
Marine CD/MP3/WMA/AAC player with Rear USB for iPod/iPhone and
Walkman® connection
Recommended
accessories
6” Marine 2-Way Coaxial Speaker
•Peak power: 160W
•Rated power: 45W
•Frequency response: 35Hz – 26kHz
•Sensitivity: 91dB/W/m
•Water resistant design - IPx5 certified
•UV resistant – tested under ASTM G154
•Salt resistant – tested under ASTM B117
Dimensions
174mm
RM-X60M
XS-MP1611W
6” Marine Dual Cone Speaker
•Peak power: 140W
•Rated power: 40W
•Frequency response: 40Hz – 20kHz
•Sensitivity: 90dB/W/m
•Water resistant design - IPx5 certified
•UV resistant – tested under ASTM G154
•Salt resistant – tested under ASTM B117
Dimensions
174mm
51mm
Audio features
•Powerful sound with 4 × 52W S-MOSFET amplifier
•Rear USB for direct control of connected iPod/iPhone/Walkman®, plus playback compatibility
with USB flash drives
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
•Aux-In (Rear / RCA)
Marine Features
•Conformal coating for circuit board
•Plastic cover for chassis
•Anti-rust reinforcement (anti-rust screw for front and sub panel)
•Splash-proof (IPx5)
•UV exposure resistant (ASTM G154)
•Salt fog exposure resistant (ASTM B117)
•Memory backup feature
•Direct sunlight viewable display (white LCD)
XS-MP1621W
61mm
CDX-HR910UI
CDX-MR60UI
Marine CD/MP3/WMA/AAC player with Rear USB for iPod/iPhone and
Walkman® connection
GMD-616
Waterproof Car Stereo Cover
Audio features
•4 × 52W S-MOSFET high power output
•Rear USB for direct control of connected iPod/iPhone/Walkman®, plus playback compatibility
with USB flash drives
•Flip-down, detachable faceplate with 2-line, direct sunlight white LCD display
•Quick-BrowZer™ and ZAPPIN™ for easy music searches
Marine Features
•Conformal coating for circuit board
•Plastic cover for chassis
•Anti-rust reinforcement (anti-rust screw for front and sub panel)
•UV exposure resistant (ASTM G154)
•Memory backup feature
•Direct sunlight viewable display (white LCD)
Recommended
accessories
•Front mask opening type DIN
•Compatible with all single DIN head units
•Durable injection moulded polycarbonate frame
•Weatherproofed with O-ring seal
RM-X60M
GMD-616
RM-X60M
Marine Remote Commander
•10.1cm (4”) mounting diameter with scrolling LCD display
•Compatible with iPod control-ready head units
•Splash-proof IPX7 compliant design
26
CAR ENTERTAINMENT
CAR ENTERTAINMENT
27
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
