StruxureWare Power Monitoring 7.0.1 Installation Guide Introduction

Introduction

This guide is intended for Application Engineers, third-party integrators, or other qualified personnel who are responsible for configuring and installing StruxureWare™ Power

Monitoring software and preparing the servers on which it is installed. Experience using previous versions of the software is preferable.

The guide contains information about installing SQL Server 2008 editions and a StruxureWare

Power Monitoring system, incorporating best practices and factory-recommended procedures to help reduce the need for ongoing support and to improve the reliability of the installation.

A typical installation consists of a computer or network of computers running StruxureWare

Power Monitoring software and one or more networks of devices (such as basic energy meters, multi-function monitoring/analysis/control devices, and/or intelligent relays).

Review the StruxureWare Power Monitoring System Design Guide for information about planning for and setting up your system.

Note

Services personnel and fully-commissioned StruxureWare Power Monitoring servers are also available — please contact Schneider Electric for details.

Summary of topics in this guide

The topics in this guide provide the following information:

• Supported operating systems and SQL Server editions

Summarizes the combinations of 32-bit and 64-bit Windows operating systems and SQL

Server editions on which StruxureWare Power Monitoring can be installed. (See the

System Design Guide at www.schneider-electric.com for information about hardware requirements.)

• Preparing the server

Describes the steps required to install a supported Windows operating system and SQL

Server edition, and the settings required for each. Note that this information is common for

StruxureWare Power Monitoring installations of a Standalone Server, a Database Server, a Primary Server, a Secondary Server, and for an Engineering Client.

• Standalone installation

Describes the steps required to install StruxureWare Power Monitoring software on a single Standalone Server.

• Distributed installation

Describes the steps required to install StruxureWare Power Monitoring's databases on a

Database Server, and its configuration files and services on a Primary Server.

Page 7 of 66

Introduction StruxureWare Power Monitoring 7.0.1 Installation Guide

• Additional Power Monitoring software

Describes the steps required to install graphical user interfaces on an Engineering Client, the steps for installing a Reporting Client, how to access the Web Applications component of the product from a Web Client, and provides information about installing a Secondary

Server.

• Post-installation tasks

Describes the tasks that you need to perform after completing the installation of the software.

StruxureWare Power Monitoring 7.0.1 Installation Guide Supported operating systems and SQL Server editions

Supported operating systems and SQL Server editions

The following tables summarize the supported combinations of 32-bit and 64-bit versions of

Microsoft Windows operating systems and SQL Server editions.

32-bit Windows Operating Systems

Windows 7 Professional/Enterprise

Editions, SP1

Windows 7 Professional/Enterprise

Editions, SP1

Windows Server 2008

Standard/Enterprise Editions, SP2

Windows Server 2008

Standard/Enterprise Editions, SP2

Windows Server 2008

Standard/Enterprise Editions, SP2

32-bit Microsoft SQL Server

Editions

SQL Server 2008 R2 Express Edition

SQL Server 2008 R2 Standard

Edition, SP1

SQL Server 2008 R2 Express Edition

SQL Server 2008

Standard/Enterprise Editions, SP2

SQL Server 2008 R2

Standard/Enterprise Editions, SP1

Standalone

Server

Yes

Distributed

Database

Server

Yes

64-bit Windows Operating Systems

Windows 7 Professional/Enterprise

Editions, SP1

Windows 7 Professional/Enterprise

Editions, SP1

Windows Server 2008

Standard/Enterprise Editions, SP2

Windows Server 2008

Standard/Enterprise Editions, SP2

Windows Server 2008

Standard/Enterprise Editions, SP2

Windows Server 2008 R2

Standard/Enterprise Editions, SP1

Windows Server 2008 R2

Standard/Enterprise Editions, SP1

Windows Server 2008 R2

Standard/Enterprise Editions, SP1

64-bit Microsoft SQL Server

Editions

SQL Server 2008 R2 Express Edition

SQL Server 2008 R2 Standard

Edition, SP1

SQL Server 2008 R2 Express Edition

SQL Server 2008

Standard/Enterprise Editions, SP2

SQL Server 2008 R2

Standard/Enterprise Editions, SP1

SQL Server 2008 R2 Express Edition

SQL Server 2008

Standard/Enterprise Editions, SP2

SQL Server 2008 R2

Standard/Enterprise Editions, SP1

Standalone

Server

Yes

Distributed

Database

Server

Yes

StruxureWare Power Monitoring can be installed in virtual environments with a supported combination of Windows operating system and SQL Server edition. It is recommended that you copy the content of the StruxureWare Power Monitoring DVD to a local drive in your virtual environment and double-click MainSetup.exe to start the installation process.

The following operating system versions, SQL Server editions, and Internet Explorer versions are not supported on StruxureWare Power Monitoring servers or on Engineering Client computers:

• Windows XP, Windows Vista, and Windows Server 2003.

• SQL Server 2005 editions.

Page 9 of 66

Supported operating systems and SQL Server editions StruxureWare Power Monitoring 7.0.1 Installation Guide

• Internet Explorer 6.0 and 7.0 (also not supported on Web Clients).

Web Client computers provide access to the Web Applications component of StruxureWare

Power Monitoring. Web Client computers require a Microsoft Windows operating system,

Internet Explorer version 8.0, or 9.0, Silverlight version 4.0 or later, and network connectivity to a StruxureWare Power Monitoring primary server.

To access Web Applications from a Web Client, enter an address in the following format in your browser: http://domain_name/Web where domain_name is the fully-qualified name of the server hosting StruxureWare Power

Monitoring, and Web is the default root directory, which can be changed during installation.

For example, for server name srv1, company name MyCompany, and a root directory of

Web

, enter the address in the browser as: http://srv1.MyCompany.com/Web

StruxureWare Power Monitoring 7.0.1 Installation Guide Preparing the server

Preparing the server

The StruxureWare Power Monitoring Installer performs many of the setup and configuration tasks during installation to ensure that the prerequisites for your StruxureWare Power

Monitoring network are met. Complete the following before proceeding with a StruxureWare

Power Monitoring installation.

Configuring your operating system

Ensure that you log on to Windows 7 or Windows Server 2008 as the Administrator of the system and not just as a user with administrator privileges.

Naming your server

Assign a computer name for the server that conforms to Windows naming conventions. A computer name can be up to 15 alphanumeric characters with no blank spaces, and it must not contain any prohibited characters such as:

\ * + = | : ; < > ? , _

For compatibility with StruxureWare Power Monitoring software, use only letters and numbers, starting the name with a letter for the first character in the name.

Additional information for consideration

• A Standalone Server installation with a SQL Server 2008 Express edition includes the

Reporter component of the product for generating and managing reports. See the

"Reporter" topic in the online StruxureWare Power Monitoring Help for more information.

For installations using a supported edition of SQL Server 2008 Standard or Enterprise,

Reporting Services and Reports(in the Web Applications component) are included in the product.

• If you install a SQL Server 2008 Express edition, alarm notification for database size is configured to generate an alert notification when 85% of a database size of 9GB is reached. See the "Alarm Configuration" topic in Database Manager's online help.

• Scheduled jobs (backup, maintenance, trim) for the Application Modules database are only available through Windows Task Scheduler and not through Database Manager. In addition, when your product installation uses a SQL Server 2008 Express edition, scheduled database backup, maintenance, and trim jobs are only available through Task

Scheduler.

• The ION™ DDE Service does not function because the required NetDDE service is not a component of Windows 7 or Windows Server 2008 operating systems.

Page 11 of 66

Preparing the server StruxureWare Power Monitoring 7.0.1 Installation Guide

• Install and configure the Terminal Server component if Terminal Server connection to the

StruxureWare Power Monitoring Primary Server is required. Refer to the “Terminal Server

Licensing Overview” topic in your Microsoft Windows documentation to learn about

Terminal Server Licence requirements. Perform typical setup such as ending a disconnected or stale session and installing programs.

Configure Remote Desktop Connection if you require remote connection to the

StruxureWare Power Monitoring Primary Server.

• If you plan to use TAPI modem drivers for Windows (WinModems) in your StruxureWare

Power Monitoring network, install and configure the WinModems. Additional WinModem information is available in the StruxureWare Power Monitoring Help.

• Use Windows Update service to install the latest security patches and hotfixes from

Microsoft.

Firewall configuration

Use the Microsoft knowledgebase to learn about Well Known Ports and Registered Ports required for certain networks.

StruxureWare Power Monitoring TCP port assignments

The following tables contain the TCP port assignments that StruxureWare Power Monitoring and associated applications or services use to communicate with PowerLogic™ devices,

StruxureWare Power Monitoring clients, and other StruxureWare Power Monitoring servers.

TCP ports for device communications

Port

Protocol

Telnet (used for meter diagnostics)

Port

7701 Modbus™ RTU

Protocol

SMTP (Required for email communications) 7800

EtherGate simultaneously through available COM ports

502 Modbus™ TCP

3721 Ethernet access for the 3720 ACM meter

7700 ION

7801 EtherGate through the meter's COM1

7802 EtherGate through the meter's COM2/COM4

7803 EtherGate through the meter's COM3

Note

Some networks may contain devices that require the use of alternate ports (for example, third-party Ethernet gateway devices).

StruxureWare Power Monitoring 7.0.1 Installation Guide Preparing the server

Other required ports

Port

13666

13670

Purpose

StruxureWare Power Monitoring services use these ports. These ports are used if a client machine needs to access the Designer and/or Vista components of

StruxureWare Power Monitoring.

13668

This port is used when the StruxureWare Power Monitoring system contains a

Secondary Server.

Microsoft SQL Server uses this port.

1433

1434

3389

139

Microsoft SQL Monitor uses this port to identify named database instances.

Terminal Server uses this port.

NetBIOS and Windows “File and Printer Sharing” use this port.

HTTP (required for Diagrams, Reports and Internet access) uses this port.

57777

Real-time Data Service uses this port to transfer real-time data to StruxureWare

Power Monitoring clients.

SQL Server uses this port if you use the default instance when you install StruxureWare Power

Monitoring. If you use a named instance when you install StruxureWare Power Monitoring, it is recommended that you configure the named instance to use port 1433.

You can configure the ION Real Time Data Service to use a different port.

Page 13 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

Installing SQL Server

The following information describes the settings that are required when you install one of the prerequisite SQL Server editions prior to installing the StruxureWare Power Monitoring software.

SQL Server 2008 R2 Express is can be selected for installation with a Standalone Server.

See

"Installing a Standalone Server with SQL Server Express" on page 33

for more information.

The topics described in this section are:

•

"Installing SQL Server 2008 R2 from the available DVD" on page 16 .

•

"Installing SQL Server 2008 R2 Standard Edition" on page 24

•

"Adding an instance to an existing SQL Server installation" on page 27 .

•

"Adding an instance to an existing SQL Server Express installation" on page 31 .

SQL Server 2008 must be installed before installing StruxureWare Power Monitoring.

Running anti-virus software on your SQL Server

It is recommended that you assess the software security requirements of your organization, and specifically the potential risks to your SQL Server installation. If you determine that you need to run anti-virus software on your SQL Server as a result of your assessment, follow the recommendations described in Microsoft Support article (ID: 309422) at http://support.microsoft.com/kb/309422.

Setting SQL Server memory options

Note the following recommendations for setting SQL server memory options after you install a supported edition of SQL Server 2008 SP2, 2008 R2 SP1, or 2008 R2 Express.

For installations using a supported edition of SQL Server 2008 SP2 or 2008 R2 SP1:

• Where only the SQL Server is running on the host server, set the SQL Server maximum memory at the system physical memory less at least 2GB for the Windows operating system. For example, if your server has 8GB of memory, set the SQL Server maximum memory to no more than 6GB. This leaves at least 2GB for the operating system.

• Where the SQL Server is sharing the host server with other server processes, including

Reporting Services, IIS, and ION services, set the SQL Server maximum memory to no more than half the physical memory on the server. For example, if you server has 8GB of memory, set the SQL Server memory to no more that 4GB. This leaves at least 4GB for the operating system and all other server processes.

For installations using a supported edition of SQL Server 2008 R2 Express:

• Where the Standalone Server has 4GB of memory, set the SQL Server maximum memory to 2GB.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

• Where the Standalone Server has 2GB of memory, set the SQL Server maximum memory to 1.5GB.

In addition to setting the maximum memory option, consult with your site administrator to determine whether or not to enable the Lock pages in memory permission setting in

Windows for the SQL service account on all SQL Server 2008 SP2 or 2008 R2 SP1 instances.

To set the maximum memory setting for your SQL Server:

1. Start SQL Server Management Studio and log in to your SQL Server instance.

2. Right-click the SQL Server name and click Properties in the menu to open the Server

Properties dialog.

3. Select Memory in the left pane and adjust the value in the Maximum server memory field.

4. Click OK to apply the changes and close the dialog.

5. Close SQL Server Management Studio.

6. Reboot your server.

To enable the lock pages in memory option:

1. Click Start > Run and type gpedit.msc in the Run dialog to open the Local Group

Policy Editor.

2. In the left pane, navigate to Computer Configuration > Windows Settings > Security

Settings > Local Policies.

3. Expand Local Policies and select User Rights Assignment.

The policies are listed in the right pane.

4. Locate Lock pages in memory in the list and double click the policy name to open the

Lock pages in memory Properties dialog.

5. Click Add User or Group on the Local Security Setting tab.

6. Add an account with the privileges to run sqlserver.exe and click OK to close the dialog.

Page 15 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

7. Click OK to close the Local Group Policy Editor.

8. Reboot your server.

Installing SQL Server 2008 R2 from the available DVD

The DVD available from Schneider Electric installs Microsoft SQL Server 2008 R2 Standard

Edition (English) with Service Pack 1. If you intend to use a supported SQL Server Express edition, it will be installed at the same time as StruxureWare Power Monitoring. Otherwise, a

SQL Server 2008 edition must be installed before StruxureWare Power Monitoring.

Before starting the installation, ensure that you are logged in as the Administrator and not just as a user with administrator privileges. Make sure that no other programs are running, save your work, and close any open applications.

Complete the following steps to install the software:

1. Insert the SQL Server 2008 R2 Installation DVD in your DVD drive, then navigate to and double-click setup.exe in the root directory on the DVD to open the SQL Server

Installation Center.

2. Select Installation in the left pane and New installation or add features to an existing

installation on the right.

A message indicates that the process is starting followed by the Setup Support Rules page showing validation results. If validation is not successful, follow the instructions on the page and click Rerun. Click OK when the validation is successful.

Page 16 of 66

The Product Key page with the default product key opens. Click Next.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

3. Read the license agreement on the License Terms page, then select I accept the

license terms and click Next to continue.

Note that this is a "Per Processor" license and that this SQL server can only be used with

StruxureWare Power Monitoring software.

4. Click Install on the Setup Support Files page to install the setup support files listed under the Feature Name column on the page.

The Setup Support Rules page opens after the installation of the files showing the validation results. You can click Show details to view a list of the rules that were validated. If validation is not successful, follow the instructions on the page and click

Rerun. Click Next when the validation is successful.

Page 17 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

5. Leave SQL Server Feature Installation selected on the Setup Role page and click Next.

6. On the Feature Selection page under Instance Features, select Database Engine

Services and Reporting Services. Under Shared Features, select Management Tools

- Basic and Management Tools - Complete.

• Database Engine Services and Reporting Services are required if you are installing on a server that is used as a Standalone Server.

• You can install both options on a Database Server in a distributed system. In this case you should not install reporting services on the Primary Server to avoid conflicts.

• You can install Database Engine Services on a Database Server, and Reporting

Services on a Primary Server in a distributed system. Note that you need an additional

SQL Server license for this configuration.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

Click Next when you complete your selections. The setup process validates that the installation can proceed and shows the results on the Installation Rules page.

If validation is not successful, follow the instructions on the page and click Rerun. Click

Next to proceed to the Instance Configuration page when the validation is successful.

7. Select Named instance and enter a name in the Instance Name field, for example ION.

(Do not use an underscore character ( _ ) within the instance name.) The same name is automatically added to the Instance ID field and it should not be changed. Click Next.

8. Review the information on the Disk Space Requirements page and click Next.

The disk space required for the installation is summarized in the Disk Usage Summary area on this page.

Page 19 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

9. Select Use the same account for all SQL Server services to open the dialog.

Page 20 of 66

10. Select your local system account in the Account Name list, for example

NT AUTHORITY\SYSTEM. A password is not required. Click OK to apply your selection and close the dialog.

11. Click Next to proceed to the Database Engine Configuration page.

12. On the Account Provisioning tab of the Database Engine Configuration page, select

Mixed Mode. Type a password for the SQL Server system administrator (sa) account in the Enter password and Confirm password fields. Click Add Current User to add the

SQL Server Administrator, then click the Data Directories tab.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

NOTICE

LOSS OF DATA

• Use a strong password for the System Administrator account consisting of at least 6 characters that are a combination of uppercase and lowercase letters, numbers, and symbols such as @, #, $, %.

• Only allow users with advanced knowledge of SQL Server databases access to the

SQL Server.

Failure to follow these instructions can result in unauthorized access to SQL

Server databases.

13. If additional drives are available on your server, you can specify a different drive for the

TempDB directory and Temp DB log directory fields. Click Next to proceed to the

Reporting Services Configuration page.

The specification of different drives is for performance reasons. If all of the files are located on the same drive, data that is being inserted, updated, or deleted can potentially result in slower write operations than if the Temp DB directories are located on a separate drive.

The specification of different drives is dependent on your hardware configuration and may not be possible in all cases.

Page 21 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

14. Select Install the native mode default configuration if it is not already selected on the

Reporting Services Configuration page and then click Next.

15. Selections are optional on the Error and Usage Reporting page.

16. Click Next to validate that the installation can proceed. The results are shown on the

Installation Configuration Rules page. If validation is not successful, follow the instructions on the page and click Rerun. Click Next when the validation is successful.

Page 22 of 66

17. Click Install on the Ready to Install page.

The Ready to Install page shows the SQL Server features that are about to be installed.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

The Installation Progress page provides a visual indication of the progress of the installation.

When the installation finishes, the Complete page opens.

Page 23 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

The Complete page contains a link to the Summary log. It also provides information about the Setup operations or possible next steps, as well as supplemental information related to your installation.

18. Click Close on the Complete page to close the setup dialog.

You can select Search for product updates in the SQL Server Installation Center.

Close the dialog after any updates are installed,

Next step

You can now install StruxureWare Power Monitoring software on a Standalone Server or in a distributed configuration consisting of a Database Server and Primary Server. For descriptions of the installation processes, see

"Standalone installation" on page 33

"Distributed installation" on page 47

Installing SQL Server 2008 R2 Standard Edition

Before starting the Microsoft SQL Server installation, ensure that you are logged in as the

Administrator and not just as a user with administrator privileges. Make sure that no other programs are running, save your work, and close any open applications.

The steps for installing SQL Server 2008 R2 are the same as those for

"Installing SQL Server

2008 R2 from the available DVD" on page 16 . The exceptions are the steps for the following

Setup pages:

• Product Key page, which provides a default product key or requires that you enter a product key.

• Complete page, which contains a link for the Microsoft Update Web site where checking for updates identifies Microsoft SQL Server 2008 R2 Service Pack 1 for installation.

The input required for the Setup pages listed above is described in more detail where the pages occur in the following sequence of steps.

1. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following Setup pages:

• SQL Server Installation Center.

• Setup Support Rules page.

2. If the product key is applied by default, click Next. Otherwise, select Enter the product

key, type the product key in the field and click Next.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

3. Read the license agreement on the License Terms page, then select I accept the

license terms and click Next to continue.

4. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following Setup pages:

• Setup Support Files and Setup Support Rules pages.

• Setup Role page.

• Feature Selection and Installation Rules pages.

• Instance Configuration and Disk Space Requirements pages.

• Server Configuration page.

• Database Engine Configuration page – Account Provisioning and Data

Directories tabs.

• Reporting Services Configuration page.

• Error and Usage Reporting page.

• Installation Configuration Rules page.

• Ready to Install and Installation Progress pages.

When the installation finishes, the Complete page opens.

Page 25 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

5. To install Service Pack 1 for your SQL Server 2008 R2 installation, select the link on the

Complete page for the Microsoft Update Web site and follow the instructions for checking for updates.

Microsoft SQL Server 2008 R2 Service Pack 1 should be identified as one of the optional updates. Select it and any other updates that you want, and proceed with their installation. (Alternatively, you can search the Internet for Microsoft SQL Server 2008 R2

SP1 software, and download and install it.)

Page 26 of 66

6. After the updates are installed, click Close on the Complete page and then close the SQL

Server Installation Center.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

Next step

"Standalone installation" on page 33

"Distributed installation" on page 47

Adding an instance to an existing SQL Server installation

To configure a specific SQL Server instance for use by StruxureWare Power Monitoring, you need to rerun the SQL Server 2008 R2 Setup wizard.

Before starting the Microsoft SQL Server installation, ensure that you:

• Make sure that no other programs are running, save your work, and close any open applications.

• Are logged in as the Administrator and not just as a user with administrator privileges.

• Have the SQL Server 2008 R2 installation media.

The steps to add and configure a new server instance are the same as those for

"Installing

SQL Server 2008 R2 from the available DVD" on page 16

. The exceptions are the steps related to the following SQL Server 2008 Setup pages:

• Installation Type page.

• Feature Selection page.

• Instance Configuration page.

• Database Engine Configuration page.

The input required for the Setup pages listed above is described in more detail where the pages occur in the following sequence of steps.

1. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following SQL Server 2008 Setup pages:

• SQL Server Installation Center.

• Setup Support Rules page.

2. When you click Next on the initial Setup Supports Rules page, a Setup Support Files page opens. Click Install to install the setup support files listed under the Feature Name column on the page.

Rerun. Click Next when the validation is successful.

Page 27 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

3. Select New installation or add shared features on the Installation Type page and click

Next.

Page 28 of 66

4. If the product key is displayed by default, click Next. Otherwise, select Enter the product

key, type the product key in the field and click Next.

5. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following SQL Server 2008 Setup pages:

• License Terms page.

• Setup Role page.

6. On the Feature Selection page under Instance Features, select Database Engine

Services and Reporting Services. Under Shared Features, select Management Tools

- Basic and Management Tools - Complete if they are not already selected. Select any of the other shared features that you want to install.

• Database Engine Services and Reporting Services are required if you are installing on a server that is used as a Standalone Server.

• You can install both options on a Database Server in a distributed system. In this case you should not install reporting services on the Primary Server to avoid conflicts.

• You can install Database Engine Services on a Database Server, and Reporting

Services on a Primary Server in a distributed system. Note that you need an additional

SQL Server license for this configuration.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

Click Next when you complete your selections. The setup process validates that the installation can proceed and shows the results on the Installation Rules page. If validation is not successful, follow the instructions on the page and click Rerun. Click

Next to proceed to the Instance Configuration page when the validation is successful.

7. Select Named instance and enter a name in the Instance Name field, for example ION.

(Do not use an underscore character ( _ ) within the instance name.) The same name is automatically added to the Instance ID field and it should not be changed. Click Next.

Any existing instance names appear in the Installed Instances area on the page.

8. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following SQL Server 2008 Setup pages:

• Disk Space Requirements page.

• Server Configuration page.

Page 29 of 66

Installing SQL Server StruxureWare Power Monitoring 7.0.1 Installation Guide

9. On the Account Provisioning tab of the Database Engine Configuration page, select

Mixed Mode. Type a password for the SQL Server system administrator (sa) account in the Enter password and Confirm password fields. Click Add Current User to add the

SQL Server Administrator, then click the Data Directories tab.

NOTICE

LOSS OF DATA

• Use a strong password for the System Administrator account consisting of at least 6 characters that are a combination of uppercase and lowercase letters, numbers, and symbols such as @, #, $, %.

• Only allow users with advanced knowledge of SQL Server databases access to the

SQL Server.

Failure to follow these instructions can result in unauthorized access to SQL

Server databases.

Page 30 of 66

10. If additional drives are available on your server, you can specify a different drive for the

TempDB directory and Temp DB log directory fields. Click Next to proceed to the

Reporting Services Configuration page.

The specification of different drives is dependent on your hardware configuration and may not be possible in all cases.

StruxureWare Power Monitoring 7.0.1 Installation Guide Installing SQL Server

11. See

"Installing SQL Server 2008 R2 from the available DVD" on page 16

for the directions for the following SQL Server 2008 Setup pages:

• Reporting Services Configuration page.

• Error Reporting page.

• Installation Configuration Rules page.

• Ready to Install page.

• Installation Progress page.

• Complete page.

12. Close the SQL Server Installation Center.

Next step

"Standalone installation" on page 33

"Distributed installation" on page 47

Adding an instance to an existing SQL Server Express installation

If you have previously installed SQL Server 2008 R2 Express, you can add a SQL Server

Express instance for use with StruxureWare Power Monitoring by following the directions for

"Installing a Standalone Server with SQL Server Express" on page 33

Page 31 of 66

Tasks performed by the product Installer StruxureWare Power Monitoring 7.0.1 Installation Guide

Tasks performed by the product Installer

Depending on your operating system version, your SQL Server edition, and the setup type

(server or client) that you select for installation, the StruxureWare Power Monitoring Installer performs some or all of the following tasks prior to the installation of the software:

• Checks for the appropriate version of .NET Framework and initiates its installation if required.

• Validates the Product Key.

• Checks that adequate disk space is available for the files that are written to the hard disk.

• Verifies that the SQL Server Agent is installed.

• Validates that a supported SQL Server edition and service pack level are installed.

• Verifies the connection to the SQL Server.

• Checks for 32-bit SQL Server edition.

• Checks for the presence of ASP.NET.

• Validates that a supported Windows operating system version and service pack level are installed.

• Verifies that the appropriate account permissions are defined, for example, that the SQL

Server system administrator (sa) account is set with Administrator as the user.

• Checks that the appropriate edition of Reporting Services is installed.

The Installer performs configuration tasks during the installation process. Some of these tasks are listed below. See the Installation log that is available at the conclusion of the installation process to view all of the actions performed by the Installer.

• Installs SQL Server backwards compatibility.

• Configures the SQL Server Agent.

• Configures ASP.NET.

• Configures SQL Server.

• Adds Report Server roles.

• Registers, verifies the registration of, and starts services.

• Installs and configures Internet Information Services (IIS).

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

Standalone installation

A Standalone Server hosts StruxureWare Power Monitoring configuration files, the services that are required for the system to function, Microsoft Reporting Services, and a connection to a SQL Server instance for the StruxureWare Power Monitoring databases. It can also aggregate data from all Secondary Servers (if they exist).

A Standalone Server installation with a SQL Server 2008 Express edition includes the

Reporter component of the product for generating and managing reports. See

"Additional information for consideration" on page 11

for more information.

Make sure your computer meets the operating system and SQL Server requirements summarized in

"Supported operating systems and SQL Server editions" on page 9 .

Perform the software installation directly on the server. Remote installation is not recommended.

Standalone installation considerations

Before proceeding with the Standalone Server installation, ensure that you completed the tasks described in the following topics:

•

"Configuring your operating system" on page 11 .

•

"Installing SQL Server" on page 14

, or if applicable,

"Adding an instance to an existing

SQL Server installation" on page 27

If you intend to use a supported SQL Server Express edition, it is installed at the same time as StruxureWare Power Monitoring on a Standalone Server.

Installing a Standalone Server with SQL Server Express

Start the installation process by inserting the StruxureWare Power Monitoring DVD into the

DVD drive. If it does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

1. Install Microsoft .NET Framework if prompted.

2. Select the Application Language from the list and click Next.

Page 33 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

3. Click Next on the Welcome page to proceed to the License Agreement page.

The Welcome page provides reminders for tasks to complete before continuing with the installation.

4. Read the End User License Agreement (EULA) on the License Agreement page.

Page 34 of 66

If you accept the terms of the license agreement, click I Agree to proceed to the Setup

Type page.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

5. Select Standalone Server from the list if it is not already selected, and click Next.

6. Enter the user-related information and the product key for the product in the appropriate fields on the User Information page and click Next.

Page 35 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

7. Use the Web Application page to change the default URL path for the Web Applications component of the product or use the default values and click Next.

8. Click Next to accept the default installation location on the File Destination page, or browse to select a specific location and then click Next.

Click Yes if you are prompted to create the folder.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

9. The contents of the Database Software page is dependent on the following:

• If a SQL Server Instance is not found on your Standalone Server, the Database

Software page indicates that SQL Server Express will be installed. Click Next to continue with the installation.

• If a SQL Server instance is found on your Standalone Server, it is not the instance that you should use for this installation. You need to select Install SQL Server Express on

this computer to specifically indicate that you are installing SQL Server Express and then click Next.

Page 37 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

The SQL Server 2008 R2 Setup wizard opens at the Setup Support Files page and the files are installed automatically.

Page 38 of 66

The installation of SQL Server Express begins automatically after the Setup Support files are installed. The Installation Progress page visually indicates the progress of the installation.

Upon completion of the SQL Server Express installation, a system check is performed to verify that the mandatory prerequisites have been met. The results of the verification are shown on the Check System page.

If a problem occurs during the system check, the item is identified and clicking on it displays additional information about the situation.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

10. Click Next to proceed to the Ready to Configure page, which summarizes your configuration for the installation of the software.

Page 39 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

11. Click Install to begin the installation.

The Copy Files page indicates the progress as files are copied to the server as part of the installation.

When the copying operation is complete, the Configure System page opens.

Page 40 of 66

The Configure System page indicates each of the configuration actions taking place during the installation. If a configuration step is not successful, an X appears in a column to the left of the item and you are given an option to continue with the installation or to cancel the install process. You can also click the link on the message text on the right of the item to display instructions for resolving the error.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

12. Click Next when the configuration process completes to open the Complete page.

The Complete page contains links that open the Installation Log and start the Web

Applications component, respectively.

The Installation Log summarizes the processing that took place during the installation process. Click the Web Application link to verify that Web Applications component launches successfully in a browser.

13. Click Close to close the installer.

An HTML page opens with instructions for completing your StruxureWare Power

Monitoring system setup – specifically about setting up your supervisor account to prevent unauthorized access to the system.

Page 41 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

Verify that IIS is working

Ensure that IIS is working by typing the URL http://localhost/ in the address field of

Internet Explorer.

The following is displayed in the browser:

Installing the Standalone Server

Start the installation process by inserting the StruxureWare Power Monitoring DVD into the

DVD drive. If it does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

The steps for installing a Standalone Server are the same as those for

"Installing a

Standalone Server with SQL Server Express" on page 33

. The exceptions are the steps related to the following Installer pages:

• Database Software page.

• Report Server page.

The input required on the Installer pages listed above is described in more detail where the pages occur in the following sequence of steps.

1. Install Microsoft .NET Framework if prompted.

2. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Application Language page.

• Welcome page.

• License Agreement page.

• Setup Type page.

• User Information page.

• Web Application page.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

• File Destination page.

3. Select the database instance for your SQL Server on the Database Software page, provide the necessary authentication values, and click Next.

Note that this step assumes that you have a supported SQL Server 2008 Standard or

Enterprise edition installed on your Standalone Server. For information about installing a

SQL Server 2008 Express edition, see

"Installing a Standalone Server with SQL Server

Express" on page 33 .

The SQL Server instance that you want to select is the one that you specified for use with

StruxureWare Power Monitoring when you installed or reconfigured the SQL Server.

4. Select the Reporting Services instance on the Report Server page and click Next.

If you click Test on this page, the status of the selected Report Server is checked. If you click Configure, the Report Server is configured if it has not yet been configured or it is reconfigured if configuration problems have been encountered.

Note

If you select Configure, the configuration of the report server is reset and reconfigured, whether or not it is working during the Report Server configuration phase. This action deletes any report server databases and saved report data.

NOTICE

LOSS OF DATA

Backup report server databases and saved report data before you reconfigure the report server.

Failure to follow these instructions can result in loss of data.

Page 43 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

The Reporting Server is automatically verified, then a system check is performed to verify that the mandatory prerequisites have been met. The results of the verification are shown on the Check System page.

If a problem occurs during the system check, the item is identified and clicking on it displays additional information about the situation.

StruxureWare Power Monitoring 7.0.1 Installation Guide Standalone installation

5. Click Next to proceed to the Ready to Configure page, which summarizes your selections for the configuration and installation of the software.

6. Click Install to begin the installation.

The Copy Files page indicates the progress as files are copied to the server as part of the installation.

Page 45 of 66

Standalone installation StruxureWare Power Monitoring 7.0.1 Installation Guide

When the copying operation is complete, the Configure System page opens.

7. Follow the same directions for the Complete page as those for

"Installing a Standalone

Server with SQL Server Express" on page 33 .

See the previous description to

"Verify that IIS is working" on page 42

StruxureWare Power Monitoring 7.0.1 Installation Guide Distributed installation

Distributed installation

A distributed installation is comprised of a Database Server and a Primary Server.

A Database Server in a distributed installation hosts an edition of Microsoft SQL Server and your StruxureWare Power Monitoring databases. It can also host Reporting Services if they are not selected for installation on the Primary Server. This network configuration requires that you install the Database Server on your network before installing the Primary Server.

A Primary Server in a distributed installation hosts StruxureWare Power Monitoring configuration files and the services that are required for the system to function. The Primary

Server communicates with a separate Database Server to access StruxureWare Power

Monitoring databases.

Review the System Design Guide for information about planning for and setting up your system.

Distributed installation considerations

Before proceeding with the installation of your distributed system, ensure that you completed the tasks described in the following topics:

•

"Configuring your operating system" on page 11 .

•

"Installing SQL Server" on page 14

, or if applicable

"Adding an instance to an existing SQL

Server installation" on page 27

• Prior to beginning the installation, ensure that the all of the servers on the network can communicate with each other. For example, to test for this, open a command prompt on each server and type ping computer_name, where computer_name is the name of the computer you want to contact. A successful response shows 4 attempts to contact the computer, lists the IP Address, indicates Packets: Sent = 4. Received = 4,

Lost = 0 (0% loss)

, plus timing data. If this is not the case, it indicates that the computers cannot communicate and that you need to resolve the connectivity situation.

• For a distributed installation, you need to install the Database Server on your network before installing the Primary Server.

Page 47 of 66

Distributed installation StruxureWare Power Monitoring 7.0.1 Installation Guide

Installing a Database Server

A Database Server in a distributed installation hosts an edition of a SQL Server and your

StruxureWare Power Monitoring databases. This network configuration requires that you install the Database Server on your network before installing the Primary Server for a distributed installation.

The installation process installs databases, creates login accounts, and adds numerous stored procedures to the databases attached to the SQL Server instance that you defined when you installed the SQL Server edition.

Start the installation process by inserting the StruxureWare Power Monitoring DVD into the

DVD drive. If the Installer does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

The steps for installing a Database Server are the same as those for

"Installing a Standalone

Server with SQL Server Express" on page 33 . The exceptions are the steps related to the

following Installer pages:

• Setup Type page.

• User Information page.

• Report Server page.

The input required on these Installer pages is described in more detail where the pages occur in the following sequence of steps.

1. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Application Language page.

• Welcome page.

• License Agreement page.

2. Select Database Instance on the Setup Type page and click Next.

StruxureWare Power Monitoring 7.0.1 Installation Guide Distributed installation

3. Enter the user-related information in the appropriate fields on the User Information page and click Next.

4. The File Destination page indicates the default location for the installation. Click Next.

Click Yes if you are prompted to create the folder.

Page 49 of 66

Distributed installation StruxureWare Power Monitoring 7.0.1 Installation Guide

5. Select the database instance on the Database Software page, provide the necessary authentication values, and click Next.

The database instance that you want to select is the one that you specified for use with

StruxureWare Power Monitoring when you installed or reconfigured the SQL Server.

6. Select the checkbox for Reporting Services instances have been found... if you want to use this Database Server to host the report server.

If you choose to use the Database Server to host the Report Server, a Reporting Services instance field and additional options open on the page. The Reporting Services instance that you want to choose is the one that you specified for use with StruxureWare Power

Monitoring when you installed or reconfigured the SQL Server.

StruxureWare Power Monitoring 7.0.1 Installation Guide Distributed installation

If you installed the Report Server as part of your SQL Server installation on this Database

Server, and you:

• Click Test on this page, the status of the selected Report Server is checked.

• Click Configure, the Report Server is configured if it has not yet been configured or it is reconfigured if configuration problems have been encountered.

Note

NOTICE

LOSS OF DATA

Backup report server databases and saved report data before you reconfigure the report server.

Failure to follow these instructions can result in loss of data.

If you did not install the Report Server on this Database Server, and you click either Test or Configure, a message indicates that the verification or the configuration only takes place on the server on which the Report Server has been installed.

7. Click Next.

The Reporting Server is automatically verified if the Report Server has been installed on this Database Server. Then a system check is performed to verify that the mandatory prerequisites have been met. The results of the verification are shown on the Check

System page.

If a problem occurs during the system check, the item is identified and clicking on it displays additional information about the situation.

Page 51 of 66

Distributed installation StruxureWare Power Monitoring 7.0.1 Installation Guide

8. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Ready to Configure page.

• Copy Files page.

• Configure System page.

• Complete page.

Next step

You can now install the StruxureWare Power Monitoring software on a Primary Server in the distributed configuration.

Installing a Primary Server

A Primary Server in a distributed installation hosts StruxureWare Power Monitoring configuration files and the services that are required for the system to function. The Primary

Server communicates with a separate Database Server to access StruxureWare Power

Monitoring databases.

Before installing the Primary Server, ensure that a Database Server has been installed. (See

"Installing a Database Server" on page 48

for further information.)

Start the installation process by inserting the StruxureWare Power Monitoring DVD into the

DVD drive. If the Installer does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

The steps for installing a Primary Server are the same as those for

"Installing a Standalone

Server with SQL Server Express" on page 33 . The exceptions are the steps related to the

following Installer pages:

• Setup Type page.

• Database Instance page.

• Report Server page.

The input required on these Installer pages is described in more detail where the pages occur in the following sequence of steps.

1. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Application Language page.

• Welcome page.

• License Agreement page.

StruxureWare Power Monitoring 7.0.1 Installation Guide

2. Select Primary Server on the Setup Type page and click Next.

Distributed installation

The Primary Server installation excludes the installation of the StruxureWare Power

Monitoring databases.

3. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• User Information page.

• Web Application page.

• File Destination page.

4. On the Database Instance page, select the database server and instance in the dropdown list that you want to use and click Next to proceed to the Report Server page.

The dropdown list is populated with the server name and instance name. If the instance name is not included, click the field and append \instance_name to the server name, where instance_name is the one that you specified for use with StruxureWare Power

Monitoring when you installed or reconfigured the SQL Server. For example, if the server name is APPSRV1 and the instance name is ION, then the complete entry in the field is

APPSRV1\ION

Page 53 of 66

Distributed installation StruxureWare Power Monitoring 7.0.1 Installation Guide

5. Select the Reporting Services instance on the Report Server page.

If Reporting Services has been installed on the Database Server, you need to add the server name and Reporting Services instance name in the field. Click Next.

If you installed the Report Server on this Primary Server, and you:

• Click Test on this page, the status of the selected Report Server is checked.

• Click Configure, the Report Server is configured if it has not yet been configured or it is reconfigured if configuration problems have been encountered.

Note

NOTICE

LOSS OF DATA

Backup report server databases and saved report data before you reconfigure the report server.

Failure to follow these instructions can result in loss of data.

If you did not install the Report Server on this Primary Server, and you click either Test or

Configure, a message indicates that the verification or the configuration only takes place on the server on which the Report Server has been installed.

Page 54 of 66

The Reporting Server is automatically verified if the Report Server has been installed on this Primary Server. Then a system check is performed to verify that the mandatory prerequisites have been met. The results of the verification are shown on the Check

System page.

If a problem occurs during the system check, the item is identified and clicking on it displays additional information about the situation.

StruxureWare Power Monitoring 7.0.1 Installation Guide Distributed installation

6. Click Next on the Check System page to proceed to the Ready to Configure page, which summarizes your selections for the configuration and installation of the software.

Click Install.

7. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Copy Files page.

• Configure System page.

• Complete page.

See the previous description to

"Verify that IIS is working" on page 42

Page 55 of 66

Additional Power Monitoring software StruxureWare Power Monitoring 7.0.1 Installation Guide

Additional Power Monitoring software

The StruxureWare Power Monitoring Installer also gives you options to install Engineering

Clients, Reporting Clients, and Secondary Servers.

To ensure that client computers and Secondary Servers can be installed and will operate successfully, the Primary Server must meet the following requirements :

• Exists on the Local Area Network (LAN).

• Shares full Read and Write permissions on the ION Enterprise folder.

• Enables file and printer sharing on the LAN properties.

You can also use Web Clients to access the Web Applications component.

The following topics describe each of these in more detail.

Installing an Engineering Client

An Engineering Client workstation provides administrators and power users access to the

StruxureWare Power Monitoring graphical user interfaces (Management Console, Vista,

Designer) that you can use to add and configure devices, troubleshoot your system, edit graphics, or perform ION programming tasks. An Engineering Client needs to be installed after a Standalone Server or a Primary Server is installed and running.

1. Use Windows Explorer to navigate to the Standalone Server or Primary Server and verify that the permissions on the share folder (ION-Ent) are set to Full Control for the

Engineering Client username or group.

Note that the Standalone Server or the Primary Server must exist on the Local Area

Network (LAN).

2. If you have made any configuration changes to the operating system or SQL Server (such as installing a service pack or upgrading the server), reboot the computer before you install

StruxureWare Power Monitoring.

3. Start the installation process by inserting the StruxureWare Power Monitoring DVD into the DVD drive. If the Installer does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

The steps for installing an Engineering Client are the same as those for

"Installing a

Standalone Server with SQL Server Express" on page 33

. The exceptions are the steps related to the following Installer pages:

• Setup Type page.

• User Information page.

• Ready to Configure page.

StruxureWare Power Monitoring 7.0.1 Installation Guide Additional Power Monitoring software

The input required on these Installer pages is described in more detail where the pages occur in the following sequence of steps.

1. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Application Language page.

• Welcome page.

• License Agreement page.

2. Select Engineering Client on the Setup Type page and click Next.

3. Enter the user-related information in the appropriate fields on the User Information page and click Next.

4. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer page:

• File Destination page.

Page 57 of 66

Additional Power Monitoring software StruxureWare Power Monitoring 7.0.1 Installation Guide

5. Select the Primary Server in the list that hosts the StruxureWare Power Monitoring software and click Next.

A system check is performed to verify that the mandatory prerequisites of a primary server are met. The results of the verification are shown on the Check System page.

If a problem occurs during the system check, the item is identified and clicking on it displays additional information about the situation.

6. Click Next on the Check System page to proceed to the Ready to Configure page, which summarizes your selections for the configuration and installation of the software.

Click Install.

Page 58 of 66

7. See

"Installing a Standalone Server with SQL Server Express" on page 33

for the directions for the following Installer pages:

• Copy Files page.

• Configure System page.

• Complete page.

IMPORTANT

StruxureWare Power Monitoring 7.0.1 uses .NET Remoting (a component of the Microsoft

.NET framework) to exchange real-time data between the server and client machines. The server and client computers are identified by their full computer name — the name of the machine with the domain appended (for example:

StruxureWare Power Monitoring 7.0.1 Installation Guide Additional Power Monitoring software

MyComputerName.MyCompanyDomainName.com).

Contact Technical Support if you encounter problems displaying real-time data on your client computers.

Installing a Reporting Client

A Reporting Client workstation provides administrators and power users with the ability to generate reports using the Reporter component of StruxureWare Power Monitoring. A

Reporting Client needs to be installed after a Standalone Server or a Primary Server is installed and running.

1. If you have made any configuration changes to the operating system or SQL Server (such as installing a service pack or upgrading the server), reboot the computer before you install

StruxureWare Power Monitoring.

2. Start the installation process by inserting the StruxureWare Power Monitoring DVD into the DVD drive. If the Installer does not open automatically, use Windows Explorer to navigate to the DVD drive and double-click MainSetup.exe.

The steps for installing a Reporting Client are the same as those for

"Installing an Engineering

Client" on page 56 . The only exception is your selection of Reporting Client Only on the

Setup Type page of the Installer, as shown below.

Installing a Secondary Server

Secondary Server installations are not common, and are used only in exceptional circumstances. For example, an intermediary Secondary Server may be required when you have a large number of devices that use software-based logging. Secondary Server installations require advanced network configuration.

For additional information about Secondary Servers, see the System Design Guide.

Using a Web Client

A Web Client can be used by operators and others to access the Web Applications component of StruxureWare Power Monitoring on a day-to-day basis. Web Applications encompass Dashboards, Diagrams, Tables, Alarms, and Reports. The computer requires

Microsoft Internet Explorer version 8.0 or 9.0, and network connectivity to a StruxureWare

Power Monitoring Standalone Server or Primary Server. Web Clients can use Windows XP,

Windows Vista, Windows 7, Windows Server 2003, or Windows Server 2008 operating systems for this purpose.

Page 59 of 66

Additional Power Monitoring software StruxureWare Power Monitoring 7.0.1 Installation Guide

Monitoring and Web is the default root directory, which can be changed during installation. For example, for server name srv1, company name MyCompany,and a root directory of Web, enter the address in the browser as: http://srv1.MyCompany.com/Web

By default, the first application on the Navigation Bar in Web Applications opens in the browser. To specify which application should open first, add one of the following application query parameters to the Web address. Note that /?application is case-sensitive.

/?application=Dashboards

/?application=Diagrams

/?application=Tables

/?application=Alarms

/?application=Reports

Silverlight support

Any computer that you use to access the browser-based Web Applications component requires Silverlight version 4.0 or later. If Silverlight is not installed, a Web page indicates that you need to install it before you can proceed. Click Click now to install to download and install it over the Internet.

Page 60 of 66

If your site restricts access to the Internet, you should contact your System Administrator, as indicated when you click Unable to install Silverlight?.

StruxureWare Power Monitoring 7.0.1 Installation Guide Additional Power Monitoring software

Your System Administrator can use an Internet-enabled computer to review the Silverlight deployment methods described in the Microsoft Silverlight Deployment Guide at http://download.microsoft.com/download/C/D/5/CD5AAAE3-21F7-47A8-B7D5-

39E36BAF9AC8/Silverlight_Deployment_Guide.docx

Page 61 of 66

Post-installation tasks StruxureWare Power Monitoring 7.0.1 Installation Guide

Post-installation tasks

Perform the following procedures after you install StruxureWare Power Monitoring.

Check ION Enterprise services

Open the Windows Services dialog and ensure that all of the necessary ION Enterprise services are started. The services run under the Local System account, by default. You can change the Log On As attribute of a service by specifying the account and password. Use the Log On tab on the service properties dialog to do this. The Log On As account must have read/write permissions on the ION_Ent shared directory, which is typically

...\Schneider Electric\ION Enterprise

For more information see the "ION Services" topic in the online StruxureWare Power

Monitoring Help.

Create local user groups

Create the following Microsoft Windows local user groups on the StruxureWare Power

Monitoring primary server (that is, on the Standalone Server or the Primary Server) and grant access as follows:

Group Name

Access to

...\ION Enterprise\system

Full Control ION Enterprise_Administrators

ION Enterprise_Users Read

This is the path under ...\Program Files\Schneider Electric\

Access to

...\ION Enterprise\config

Full Control

Change

Review Database Manager

Database Manager has preconfigured schedules for performing archives (disabled by default), backups, and trims on your ION Enterprise databases. For the Application Modules database, use Windows Task Scheduler to access the preconfigured schedules. Review these schedules and make any modifications that you require. You can also configure alarming to notify you when you are reaching your database or hard disk space limits.

If you installed the product with a SQL Server 2008 Express edition, scheduled jobs for the

ApplicationModules, ION_Data, ION_Network, and ION_SystemLog databases are only available through Windows Task Scheduler and not through Database Manager.

For more information refer to the Database Manager section in the online StruxureWare

Power Monitoring Help.

StruxureWare Power Monitoring 7.0.1 Installation Guide Post-installation tasks

Security considerations

This section outlines specific security considerations after the StruxureWare Power

Monitoring installation.

StruxureWare Power Monitoring software security

A supervisor account, with a user name of "supervisor" and a password of "0" (zero), is created by default. This account has the highest level of access to the StruxureWare Power

Monitoring system.

It is recommended that you change the initial password for the supervisor account to prevent unauthorized access to the system before deploying the StruxureWare Power Monitoring system to users.

1. Double-click the StruxureWare Power Monitoring folder on your desktop and then doubleclick Management Console.

A signon prompt opens with "supervisor" in the User name field.

2. Enter "0" for the password and click OK.

A product registration reminder opens. Complete the registration or dismiss the reminder to continue.

3. Select Tools > User Manager.

4. Click supervisor under Username in the display grid of User Manager.

5. Enter a unique password for the supervisor account in the Edit User Account area and click OK to save your update.

NOTICE

LOSS OF DATA

• Use a strong password for the supervisor account consisting of at least 6 characters that are a combination of uppercase and lowercase letters, numbers, and symbols such as @, #, $, %.

• Only allow users with advanced knowledge of site administration supervisor account access.

Failure to follow these instructions can result in unauthorized access to

StruxureWare Power Monitoring system components.

6. Add additional users, assign passwords, and select the appropriate access level for each user as required.

Select Help in User Manager for further information about creating users and groups, and in setting system access levels.

For more information refer to the "User Manager" section under "Management Console Tools" in StruxureWare Power Monitoring Help.

Page 63 of 66

Post-installation tasks StruxureWare Power Monitoring 7.0.1 Installation Guide

Setting up an HTTP SSL connection

The Secure Socket Layer (SSL) protocol allows you to establish an encrypted link between your Web server and a browser. To create an SSL connection, your Web server requires an

SSL Certificate. Contact Technical Support for assistance in setting up the SSL protocol for

StruxureWare Power Monitoring Web applications.

Default passwords for SQL Server

The default user identification and password for some of the database accounts need to be preserved for the proper operation of StruxureWare Power Monitoring. Contact Technical

Support for details before you attempt to modify user IDs and passwords.

NTFS and Share permissions on the ION Enterprise directory

All share permissions are automatically set to “Read” permissions for the “Everyone” group; this includes the StruxureWare Power Monitoring share (ION-Ent).

Change the ION-Ent share permission to Read/Write for users of Engineering Client computers who need to modify files, such as Vista diagrams, and for users of Reporting

Client computers who need to generate reports.

StruxureWare™ Power Monitoring 7.0.1

Installation Guide

Schneider Electric

2195 Keating Cross Road

Saanichton, BC V8M 2A5

Contact your local Schneider Electric sales representative for assistance or go to www.schneider-electric.com

ION, ION Enterprise, Modbus, PowerLogic, StruxureWare and Schneider Electric are either trademarks or registered trademarks of Schneider Electric in France, the USA and other countries.

Other trademarks used are the property of their respective owners.

7EN02-0308-01 07/2012

Replaces Document 7EN02-0308-00 03/2012

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Schneider Electric StruxureWare Power Monitoring Expert 7.2 Installation Guide

StruxureWare Power Monitoring Expert System Design Guide

StruxureWare Power Monitoring Expert IT Guide

StruxureWare Power Monitoring Expert System Design Guide

Schneider Electric StruxureWare Power Monitoring Expert 7.2.2 System Design User Guide

StruxureWare Power Monitoring Expert Installation Guide

Schneider Electric StruxureWare Power Monitoring Expert 7.2.2 Data Center Edition User Guide
