Sony Walkman SRF-M37V User's manual
3-249-146-21(1) TV/WEATHER/FM Stereo/AM PLL Synthesized Radio Operating Instructions “WALKMAN” is a registered trademark of Sony Corporation to represent is a registered trademark of Sony Headphone Stereo products. Corporation. TV/WEATHER/FM/AM WALKMAN SRF-M37V Sony Corporation ©2003 Printed in China For customers in the USA Please register this product on line at http://www.sony.com/productregistration. Proper registration will enable us to send you periodic mailings about new products, services, and other important announcements. Registering your product will also allow us to contact you in the unlikely event that the product needs adjustment or modification. Thank you. WARNING You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Trade Name: Model name: SONY SRF-M37V Tested To Comply With FCC Standards FOR HOME OR OFFICE USE If you have any questions about this product, you may call: Sony Direct Response Center 1-(800)-222-7669 or write to: Sony Direct Response Center 12451 Gateway Blvd. Fort Myers, FL 33913 Declaration of Conformity SONY SRF-M37V Sony Electronics Inc. 680 Kinderkamack Road, Oradell, NJ 07649 USA Telephone Number: 201-930-6972 Trade Name: Model: Responsible Party: Address: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Before You Begin Thank you for choosing the Sony radio! It will give you many hours of reliable service and listening pleasure. Before operating the radio, please read these instructions thoroughly and retain them for future reference. Features • TV/WEATHER/FM/AM 4 band PLL (phase locked loop) synthesized radio. • Easy Preset Digital Tuning with 25 memory presets. • 5 direct presets calls and 1 direct weather-band button. • Ergonomic Design for belt-holder use. Notes on AM Channel Step The AM channel step differs depending on areas. See “Changing AM Channel Step”. Precautions • Operate the unit only on 1.5 V DC with one size AAA (R03) battery. • Avoid exposure to temperature extremes, direct sunlight, moisture, sand, dust or mechanical shock. Never leave the unit in a car parked under the sun. • Should any solid object or liquid fall into the unit, remove the battery and have the unit checked by qualified personnel before operating it any further. • In vehicles or buildings, radio reception may be difficult or noisy. Try listening near a window. • To clean the casing, use a soft cloth dampened with a mild detergent solution. Notes on Headphones Road safety Do not use headphones while driving, cycling, or operating any motorized vehicle. It may create a traffic hazard and is illegal in many areas. It can also be potentially dangerous to play your headphones at high volume while walking, especially at pedestrian crossings. You should exercise extreme caution or discontinue use in potentially hazardous situations. Preventing hearing damage Avoid using headphones at high volume. Hearing experts advise against continuous, loud and extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Battery Life (Approx. hours) When using TV Sony alkaline 31 size AAA (LR 03) Sony size AAA (R03) 12 FM (JEITA*) AM To attach the battery compartment lid if it is accidentally detached (See Fig. A– ) The battery compartment lid is designed to come off when opened with excessive force. To put it back on, see the illustration. 31 34 54 12 13 24 * Measured by JEITA (Japan Electronics and Information Technology Industries Association) standards. The actual battery life may vary depending on the circumstance of the unit. When to replace the battery You can check the remaining battery power that appears in the display. The indicators are as follows: Indicator Full strength* Caring for others Keep the volume at a moderate level. This will allow you to hear outside sounds and to be considerate to people around you. x Warning x If there is lightning when you are using the unit, take off the headphones immediately. WEATHER When the battery becomes exhausted, the unit will turn off. Replace with new battery. When you press POWER after installing the new battery, the indicator changes to “ ”. * Displayed only when the radio is turned on. Troubleshooting Note Do not take more than 3 minutes to replace the battery, otherwise, your clock settings and preset stations will be initialized. Should that happen, reset the functions again. All buttons do not operate at all. • “-” is displayed. Slide the HOLD switch so that “-” disappears. Very weak or interrupted sound, or unsatisfactory reception • Weak battery. • In a vehicle or in a building, move closer to a window. Display is dim, or no indication is displayed. • Weak battery. • The unit is being used in extremely high or low temperatures or in a place with excessive moisture. The station cannot be received when a PRESET TUNING (1 to 5) button is pressed. • You chose the wrong preset number. • The memory of the station has been initialized. Preset the station again. The power cannot be turned on, and “ ” is flashing in the display. • The battery have been completely exhausted. The preset stations may be initialized, if a maintenance service is performed. Please note down your settings in case you want to preset them again. Specifications Time display: 12-hour system Frequency range Band TV WEATHER FM Range 2 - 13 ch 1 - 7 ch 87.5 – 108 MHz Channel step 1 channel 1 channel 0.1 MHz AM 530 – 1 710 kHz 10 kHz Output i (headphones) jack (ø 3.5 mm, stereo minijack) load impedance 24 Ω Power output 2.8 mW + 2.8 mW (at 10 % harmonic distortion) Power requirements 1.5 V DC, one size AAA (R03) battery Dimensions Approx. 83 × 63 × 32 mm (w/h/d) (3 3/8 × 2 1/2 × 1 5/16 inches) incl. projecting parts and controls Approx. 83 × 63 × 25 mm (w/h/d) (3 3/8 × 2 1/2 × 1 inches) not incl. projecting parts and controls Mass Approx. 94 g (3.32 oz.) incl. battery and belt clip. Accessories Supplied Stereo headphones (1) Belt Clip (1) Design and specifications are subject to change without notice. Installing the Battery (See Fig. A– ) 1 Open the battery compartment lid and install one size AAA (R03) battery (not supplied) with correct polarity. When battery is first installed, “AM 12:00” flashes in the display. Once the current time is set, the flashing stops. 2 Close the lid. Insert one side of the lid as illustrated. Push the other side to attach. A Insert the # side of the battery first. Weakening* If you have any questions or problems concerning your unit, please consult your nearest Sony dealer. Should any problem persist after you have made the following checks, consult your nearest Sony dealer. 1 2 Notes on battery • Do not charge the dry battery. • Do not carry the dry battery together with coins or other metallic objects. It can generate heat if the positive and negative terminals of the battery are accidentally come into contact with metallic objects. • When you are not going to use the unit for a long time, remove the battery to avoid damage from battery leakage and corrosion. Size AAA (R03) x 1 y ; y;y;y; y; Preventing Accidental Change Slide HOLD in the direction of the arrow. “-” is displayed, indicating that all the function buttons are locked. To cancel HOLD, slide HOLD in the opposite direction of the arrow so that “-” disappears. The display will flash “AM 12:00” when the battery is first inserted. Belt clip 1 CLOCK 2 3 TUNE/TIME SET* Press TUNE/TIME SET + or – until the correct hour appears in the display. Each press changes the digit(s) by one. When you keep the button pressed, the digit(s) change rapidly. Press CLOCK. The beep sounds and the minute starts to flash. Repeat step 2 to set the minute. After setting the minute, press CLOCK again. The two beeps sound and the clock starts from 0 seconds. WB TV/WB/FM SENS DX LOCAL Hold down CLOCK for more than 2 seconds. The beep sounds and the hour flashes in the display. i (headphones) jack 12-hour system: PRESET TUNING 1-5* BAND * There is a tactile dot on/beside Vol, TUNE/TIME SET +, and the number 2 button. “AM 12:00” = midnight “PM 12:00” = noon Changing AM Channel Step The AM channel step differs depending on areas. The channel step of this unit is factory-set to 10 kHz. Change the settings as shown below to be able to listen to the radio. Area North and South American countries Other countries B Channel step 10kHz 9kHz Note When the AM channel step is changed, the preset stations for AM will be initialized. 1 2 Press POWER to turn off the power. While holding down CLOCK, keep pressing POWER for more than 5 seconds. Two short beeps sound, and the AM channel step will be changed. “AM 9” (or “AM 10”) is displayed for about 2 seconds. If you proceed to step 2 again, the channel step changes again. Improving the Reception C TV/WEATHER/FM: Extend the headphones cord which functions as the TV/ WEATHER/FM antenna (See Fig. B- ). AM: Rotate the unit horizontally for optimum reception. A ferrite bar antenna is built-in the unit (See Fig.B- ). Using the Belt Clip Set TV/WB/FM SENS to LOCAL if interference is prevalent and reception is too strong. Under normal conditions, set it to DX. Playing the Radio — Manual Tuning 1 Connect the headphones to the i (headphones) jack. 2 Press POWER to turn on the radio. 3 Press BAND to select the band. Each press changes the band as follows: To detach AM FM1 FM2 TV To change the band to WEATHER, press WB. You can return to the previous frequency by pressing BAND. FM1 and FM2 are differentiated only for Preset tuning. For Manual tuning of FM stations, select either band. 4 5 Each band memorizes the frequency you had tuned previously. Press TUNE/TIME SET + or – to tune in to the desired station. Two short beeps sound when the minimum frequency of each band is received during tuning. Adjust the volume using VOL. To turn off the radio, press POWER. To attach Presetting Your Favorite Station — Preset Tuning You can preset up to 10 stations in FM (5 stations in FM1, 5 stations in FM2), and 5 stations in each AM, TV, WEATHER. Presetting a station 1 Follow steps 1 to 4 in “Playing the Radio” and manually tune in to the station you wish to preset. To preset another station, repeat these steps. To change the preset station, tune in to the desired station and hold down the preset tuning 1 to 5 button. The new station will replace the previous station on the preset button. Example: Display window when you preset FM 90.0 MHz in the preset tuning 2 button for FM2. POWER HOLD Press the preset tuning 1 to 5 button you wish to preset for more than a few seconds. You will hear two confirmation beeps and preset number appears in the display. — HOLD Function Setting the Clock VOL* 2 Tuning in a Preset Station 1 Press POWER. 2 Press BAND or WB to select the band. 3 Press the desired preset tuning button. 4 Adjust the volume using VOL. Note Holding down the desired preset tuning button for more than a few seconds will replace the previous station on the preset tuning button with the station you tuned in to. Using the Belt Clip (See Fig. C) Use the belt clip when attaching the unit to your belt. To detach the belt clip, see fig. C- . To attach the belt clip, see fig. C- .
