4-081-775-22
TM
Operating Instructions
KV-32FV27
© 2001 by Sony Corporation
KV-36FV27
WARNING
NOTIFICATION
To reduce the risk of fire or shock hazard, do not expose the TV to
rain or moisture.
This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference with radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
❑
❑
❑
❑
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
Reorient or relocate the receiving antennas.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Safety
❑ Operate the TV only on 120 V AC.
❑ The plug is designed, for safety purposes, to fit into the wall
❑
outlet only one way. If you are unable to insert the plug fully
into the outlet, contact your dealer.
If any liquid or solid object should fall inside the cabinet,
unplug the TV immediately and have it checked by qualified
service personnel before operating it further.
Installing
❑ To prevent internal heat buildup, do not block the ventilation
❑
❑
openings.
Do not install the TV in a hot or humid place, or in a place
subject to excessive dust or mechanical vibration.
The AC power cord is attached to the rear of the TV with
hooks. Do not attempt to remove the cord from these hooks.
Doing so could cause damage to the TV
CAUTION
When using TV games, computers, and similar products with your
TV, keep the brightness and contrast functions at low settings. If a
fixed (non-moving) pattern is left on the screen for long periods of
time at a high brightness or contrast setting, the image can be
permanently imprinted onto the screen. Continuously watching
the same program can cause the imprint of station logos onto the
TV screen. These types of imprints are not covered by your
warranty because they are the result of misuse.
Note on Caption Vision
This television receiver provides display of television closed
captioning in accordance with §15.119 of the FCC rules.
Note on Cleaning the TV
Clean the TV with a soft dry cloth. Never use strong solvents such
as thinner or benzine, which might damage the finish of the
cabinet.
As an ENERGY STAR® Partner,
Sony has determined that this
product or product models meets
the ENERGY STAR® guidelines
for energy efficiency.
ENERGY STAR® is a U.S. registered mark.
The SRS (z) (SOUND RETRIEVAL SYSTEM)
is manufactured by Sony Corporation under
license from SRS Labs, Inc. It is covered by
U.S. Patent No. 4,748,669. Other U.S. and
foreign patents pending. The word “SRS” and
the SRS symbol (z) are registered trademarks of SRS Labs, Inc.
Licensed by BBE Sound, Inc. under USP 4638258.4482866. BBE and
BBE symbol are trademarks of BBE Sound, Inc.
FD Trinitron and the Wega logo are trademarks of Sony
Corporation.
Note to CATV System Installer
Owner’s Record
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.
The model and serial numbers are provided on the front of this
instruction manual and at the rear of the TV. Refer to them
whenever you call upon your Sony dealer regarding this product.
Use of this television receiver for other than private viewing of
programs broadcast on UHF or VHF or transmitted by cable
companies for the use of the general public may require
authorization from the broadcaster/cable company and/or
program owner.
This manual is for models KV-32FV27 and KV-36FV27. The menu
and illustrations shown are for model KV-36FV27 to show the
maximum features available. Differences in operation will be
indicated in the text, for example, “For KV-36FV27 only.”
About this Manual
Important Safeguards
For your protection, please read these instructions completely, and
keep this manual for future reference.
Carefully observe and comply with all warnings, cautions and
instructions placed on the set or described in the operating
instructions or service manual.
WARNING
Cleaning
Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampened with water for cleaning the exterior
of the set.
To guard against injury, the following basic safety precautions
should be observed in the installation, use and servicing of the set.
Installation
Use
Do not use attachments not recommended by the
manufacturer, as they may cause hazards.
Power Sources
This set should be operated only from the type
of power source indicated on the serial/model
plate. If you are not sure of the type of electrical
power supplied to your home, consult your
dealer or local power company. For those sets
designed to operate from battery power, refer
to the operating instructions.
Grounding or Polarization
Attachments
Water and Moisture
Do not use power-line operated sets near
water — for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
This set is equipped with a polarized AC power cord plug (a plug
having one blade wider than the other), or with a three-wire
grounding type plug (a plug having a third pin for grounding).
Follow the instructions below:
For the set with a polarized AC power cord plug
This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing
the plug. If the plug still fails to fit, contact your electrician to have
a suitable outlet installed. Do not defeat the safety purpose of the
polarized plug by forcing it in.
Alternate Warning
Accessories
Do not place the set on an unstable cart, stand,
table or shelf. The set may fall, causing serious
injury to a child or an adult and serious damage
to the set. Use only a cart or stand recommended
by the manufacturer for the specific model of TV.
An appliance and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and
cart combination to overturn.
For the set with a three-wire grounding type AC plug
This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact
your electrician to have a suitable outlet installed.
Do not defeat the safety purpose of the grounding plug.
Overloading
Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity,
since this can result in fire or electric shock.
Always turn the set off when it is not being
used. When the set is left unattended and
unused for long periods of time, unplug it
from the wall outlet as a precaution against
the possibility of an internal malfunction that
could create a fire hazard.
If a snapping or popping sound from a TV set is
continuous or frequent while the TV is operating,
unplug the TV and consult your dealer or service
technician. It is normal for some TV sets to make
occasional snapping or popping sounds,
particularly when being turned on or off.
Object and Liquid Entry
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on the set.
Ventilation
The slots and openings in the cabinet and in the back or bottom are
provided for necessary ventilation. To ensure reliable operation of
the set, and to protect it from overheating, these slots and openings
must never be blocked or covered.
❑
Never cover the slots and openings with a
cloth or other materials.
❑
Never block the slots and openings by
placing the set on a bed, sofa, rug or other
similar surface.
❑
Never place the set in a confined space, such
as a bookcase or built-in cabinet, unless
proper ventilation is provided.
❑
Do not place the set near or over a radiator
or heat register, or where it is exposed to
direct sunlight.
Power-Cord Protection
Service
Do not allow anything to rest on or roll over the
power cord, and do not place the set where the
power cord is subject to wear or abuse.
Damage Requiring Service
Antennas
Unplug the set from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
❑
When the power cord or plug
is damaged or frayed.
❑
If liquid has been spilled into
the set.
❑
If the set has been exposed to
rain or water.
❑
If the set has been subject to
excessive shock by being
dropped, or the cabinet has
been damaged.
❑
If the set does not operate
normally when following the
operating instructions. Adjust
only those controls that are
specified in the operating
instructions. Improper
adjustment of other controls
may result in damage and
will often require extensive
work by a qualified technician
to restore the set to normal operation.
❑
When the set exhibits a distinct change in performance, it
indicates a need for service.
Outdoor Antenna Grounding
If an outdoor antenna is installed, follow the precautions below. An
outdoor antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or
where it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code (NEC) in USA and
Section 54 of the Canadian Electrical Code in Canada provides
information with respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
Antenna Grounding According to the NEC
Refer to section 54-300 of Canadian Electrical Code for Antenna
Grounding.
Antenna lead-in wire
Servicing
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Electrical wire
equipment
Ground clamps
Antenna lead-in wire
NEC: National Electrical Code
Power service grounding electrode
system (NEC Art 250 Part H)
Lightning
For added protection for this television receiver during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna.
This will prevent damage to the receiver due to lightning and
power-line surges.
Do not attempt to service the set yourself since
opening the cabinet may expose you to dangerous
voltage or other hazards. Refer all servicing to
qualified service personnel.
Replacement Parts
When replacement parts are required, be sure the service
technician certifies in writing that he has used replacement parts
specified by the manufacturer that have the same characteristics as
the original parts.
Unauthorized substitutions may result in fire, electric shock or
other hazards.
Safety Check
Upon completion of any service or repairs to the
set, ask the service technician to perform routine
safety checks (as specified by the manufacturer) to
determine that the set is in safe operating
condition, and to so certify. When the set reaches
the end of its useful life, improper disposal could
result in a picture tube implosion. Ask a qualified
service technician to dispose of the set.
Contents
Introducing the FD Trinitron Wega
Overview................................................................1
Presenting the FD Trinitron Wega......................2
Package Contents ..................................................3
Using the Remote Control ...................................3
Installing the TV
Overview................................................................7
TV Controls and Connectors ...............................8
Basic Connections (Connecting a Cable
or Antenna) ..................................................10
Connecting a VCR and Cable............................14
Connecting a VCR and Cable Box ....................15
Connecting Two VCRs for Tape Editing .........18
Connecting a Satellite Receiver.........................19
Connecting a Satellite Receiver with a VCR ...20
Connecting an Audio Receiver .........................22
Connecting a DVD Player with
Component Video Connectors..................23
Connecting a DVD Player with
A/V Connectors ..........................................24
Connecting a Camcorder ...................................25
Using the CONTROL S Feature ........................26
Setting Up the TV Automatically .....................27
Using the Features
Overview..............................................................29
Using Favorite Channels....................................30
Using Picture in Picture (PIP) ...........................31
Using Wireless Headphones .............................34
Using the Menus
Overview..............................................................37
Using the Video Menu ......................................38
Using the Audio Menu .....................................40
Using the Channel Menu ..................................42
Using the Parent Menu .....................................44
Using the Timer Menu ......................................47
Using the Setup Menu.......................................48
Using the Basic Menu........................................50
Other Information
Overview..............................................................51
Programming the Remote Control ...................52
Operating Other Components with Your TV
Remote Control ...........................................54
Troubleshooting ..................................................56
Specifications .......................................................58
Index .....................................................................61
Introducing the FD Trinitron Wega
Overview
This chapter defines the contents of your Wega TV and provides an
overview of how to set up and use basic features.
Topic
Page
Presenting the FD Trinitron Wega
2
Package Contents
3
Using the Remote Control
3
1
Introducing the FD Trinitron Wega
Presenting the FD Trinitron Wega
The FD Trinitron Wega (pronounced VAY-GAH) is characterized by
outstanding contrast, uncompromising accuracy, and corner-tocorner detail.
You’ll recognize the superiority of Wega technology almost
immediately. The first thing you probably will notice is minimal glare
from the flat picture tube. This flat-screen technology improves
picture detail without distortion, unlike conventional curved screens.
The FD Trinitron delivers outstanding image detail not only at the
screen center, but also at the corners — so you can enjoy a bright,
clear picture from any location in a room.
Features
2
Some of the features that you will enjoy with your new TV include:
❑
16:9 Enhancement: Vertical Compression technology that
maximizes picture resolution on “anamorphic” or “enhanced for
widescreen” sources, including selected DVDs.
❑
Velocity Modulation: Vertical line enhancement that sharpens
picture definition.
❑
Steady Sound: Equalizes volume levels so there is consistent
output between programs and commercials.
❑
Parental Control: V-Chip technology allows parents to block
unsuitable programming for younger viewers.
❑
Component Video Inputs: Offers the best video quality for DVD
player connections.
❑
S-VIDEO Inputs: Provides a high-quality image for connected
equipment.
❑
Dual Tuner Picture in Picture (PIP): Allows you to watch two
programs at once.
❑
Favorite Channel Preview: Preview up to eight favorite channels
without leaving the current channel.
❑
Wireless Infrared Headphones: Enjoy listening to programs
without disturbing anyone else.
Introducing the FD Trinitron Wega
Package Contents
Along with your new Trinitron TV, the packing box contains a remote
control, a pair of wireless headphones, and three AA batteries (two
for the remote control, one for the headphones). These items are all
you need to set it up and operate the TV in its basic configuration.
Most peripherals come with the necessary cables to connect them. If
you want to set up special configurations, you may need to buy extra
cables or connectors. It is best to ensure that you have all needed
materials on hand before beginning a special-connection project.
Using the Remote Control
The remote control is the primary mechanism for controlling your TV.
Handle the remote control with care; avoid dropping it, getting it wet,
placing it in direct sunlight, near a heater, or where the humidity is
high.
Inserting Batteries
Insert two size AA (R6) batteries (supplied) by matching the + and –
on the batteries to the diagram inside the battery compartment.
✍ Remove the batteries to avoid damage from possible battery leakage whenever
you anticipate that the remote control will not be used for an extended period.
3
Introducing the FD Trinitron Wega
Button Descriptions
The POWER button on the remote control (no. 13 in the illustration
below) activates both the remote control and the TV.
Outside Panel
Button
1 MUTING
1
qd
2 SYSTEM OFF
qf
2
3
4
3 SLEEP
qg
qh
qj
4 DISPLAY
5
6
qk 5 JUMP
7
ql
8
w;
6
Description
Press to mute the sound. Press again or press VOL + to
restore the sound.
Powers off all Sony equipment at once. (This feature may
not work with older Sony equipment.)
Press repeatedly until the TV displays the time in minutes
(15, 30, 45, 60, or 90) that you want the TV to remain on
before shutting off automatically. Cancel by pressing until
SLEEP OFF appears. While Sleep feature is set, press once to
view remaining time
Press once to display the current time and channel label (if
set) and channel number. Press again to turn Display off.
See page 47 for details on setting the time.
Press to jump back and forth between two channels. The
TV alternates between the current channel and the last
channel that was selected.
Turns the headphones on/off.
9
q;
wa 7 PICTURE MODE
qa
ws
qs
wd 8 TV/SAT
9 MENU
q; VOL +/qa
RM-Y182
z To scan rapidly through the
channels, press and hold down the
CH+ or CH- button.
qs CODE SET
qd POWER buttons
(GREEN)
qf FUNCTION
buttons
4
Press repeatedly to step through the available video picture
modes: Vivid, Standard, Movie, Sports. Also available in the
Video menu. For details, see “Selecting Video Options” on
page 38.
Switches between the TV and SAT (satellite) inputs when in
SAT FUNCTION mode.
Provides quick access for changing available audio settings.
For details, see “Using the Audio Menu” on page 40.
Press to display the TV on-screen menu. Press again to exit
from the menus.
Adjusts the volume.
Joystick allows for movement of the on-screen cursor.
Pressing down on the center of the joystick selects the item.
Used for programming the remote control to operate nonSony video equipment. For details, see “Programming the
Remote Control” on page 52.
Turn on and off the TV and other audio/video equipment
you have programmed into the remote control. For
instructions, see “Programming the Remote Control” on
page 52.
Select the equipment (TV, VCR/DVD, SAT/CABLE) that
you want to operate. The indicator lights up momentarily
when pushed to show which device the remote control is
operating.
Introducing the FD Trinitron Wega
Button
qg TV/VIDEO
qh
qj
qk
ql
w;
wa
ws
wd
Description
Cycles through the video equipment connected to the TV’s
video inputs: TV, VIDEO 1, VIDEO 2, VIDEO 3, VIDEO 4.
ANT
Changes between the VHF/UHF input to the AUX input.
0 – 9 and ENTER Press 0 - 9 to select a channel, the channel changes after 2
seconds. Press ENTER to select immediately.
SWAP
Switches the position of the main picture with the window
picture.
Turns on/off PIP. For details, see “Using Picture in Picture
(PIP)” on page 31.
GUIDE
Displays the program guide of your satellite antenna.
CH +/Scan through channels.
RESET
Press when in a menu to reset the settings to the factory
defaults.
Use to switch control for connected video equipment. You
AV 1 2 3 DVD
can program one video source for each switch position. For
details, see “Programming the Remote Control” on page 52.
Inside Panel
1 TV/VCR
1
2
3
4
5
6
2 m
REC
M
N
7
x
8
X
9 3 DVD MENU
4 TITLE
q; 5 AUDIO
6 POSITION
7 MTS/SAP
8 FREEZE
9 CH +/–
q; TV/VIDEO
Switch between TV and VCR mode. If you have a
non-Sony VCR, you will need to program the remote
control to recognize your VCR. For details, see
“Programming the Remote Control” on page 52.
Rewind
Record (press the blank button – above, left – at the same
time)
Fast-forward
Play
Stop
Pause (Press again to resume normal playback)
Displays the DVD’s menu.
Displays the DVD’s Title menu.
Alternates sound between the main picture and the
window picture.
Moves the location of the PIP window picture.
Cycles through the Multi-channel TV Sound (MTS) options:
Stereo, Auto-SAP, Mono.
Freezes the window picture. Press again to restore the
picture.
Changes the channel in the PIP window picture.
The PIP window picture, cycles through the video equipment
connected to your TV’s video inputs: TV, VIDEO 1, VIDEO 2, VIDEO
3, VIDEO 4. This allows you to select different sources for the
PIP display.
5
Installing the TV
Overview
This chapter includes illustrated instructions for setting up your TV.
Note About the AC
Power Cord
Topic
Page
TV Controls and Connectors
8
Basic Connections (Connecting a Cable or Antenna)
10
Connecting a VCR and Cable
14
Connecting a VCR and Cable Box
15
Connecting Two VCRs for Tape Editing
18
Connecting a Satellite Receiver
19
Connecting a Satellite Receiver with a VCR
20
Connecting an Audio Receiver
22
Connecting a DVD Player with Component Video
Connectors
23
Connecting a DVD Player with A/V Connectors
24
Connecting a Camcorder
25
Using the CONTROL S Feature
26
Setting Up the TV Automatically
27
The AC power cord is attached to the rear of the TV with hooks. Use
caution when removing the AC plug from its holder. Gently slide the
cord in the upward direction without removing the cord from the two
lower hooks.
You can detach
the cord from
this hook
Do not remove the cord from the hooks.
AC Power cord
7
Installing the TV
TV Controls and Connectors
Front Panel Menu
Controls
The front panel menu controls allow access to the on-screen menus
without the use of a remote control. Pressing the MENU button brings
up the on-screen menus. The arrow buttons (Vv) move the on-screen
cursor in the menus and the ( ) button selects the menu item.
TV Rear Panel
Model KV-36FV27
4
9
1
2
5
3
7
8
6
Back Panel Descriptions
Connection
8
Description
1AUX
Allows you to view local and cable channels if your cable
provider does not feature local channels. You can switch
between local and cable channels easily by pressing ANT
on the remote control. Devices connected to the AUX
input cannot be viewed in PIP.
2TO CONVERTER
This is a VHF/UHF out jack that lets you set up your TV
to switch between scrambled channels (through a cable
box) and normal cable channels (CATV). Use this jack
instead of a splitter to get better picture quality when
needing to switch between scrambled and unscrambled
cable channels.
3VHF/UHF
Connects to your VHF/UHF antenna or cable.
Installing the TV
Connection
Description
4S VIDEO
Connects to the S VIDEO OUT jack of your VCR or other
S VIDEO-equipped video component. Provides better
picture quality than the VHF/UHF jacks or the Video IN
jack.
5MONITOR OUT
Lets you record the program you are watching to a VCR.
When two VCRs are connected (see page 18), you can
use your TV as a monitor for tape-to-tape editing.
6AUDIO (L/R)/
VIDEO
Connects to the audio and video OUT jacks on your VCR
or other video component. A third video input (VIDEO
2) is located on the front panel of the TV. The Audio and
Video IN jacks provide better picture quality than the
VHF/UHF jack.
7AUDIO OUT
(VAR/FIX)
L (MONO)/R
Connects to the left and right audio inputs of your audio
or video component. You can use these outputs to listen
to your TV’s audio through your stereo system.
8CONTROL S IN/OUT Allows the TV to receive (IN) and send (OUT) remote
control signals (via wire) to other Sony infraredcontrolled audio or video components.
9Y, PB, PR, L, R
Connects to your DVD player’s or Digital Set-top box’s
component video (Y, PB, PR) and audio (L/R) jacks.
9
Installing the TV
Basic Connections (Connecting a Cable or Antenna)
Connecting Directly
to Cable or to an
Antenna
The connection you choose depends on the cable found in your
home.
Newer homes usually have standard coaxial cable:
VHF Only or VHF/UHF or Cable
75-ohm
coaxial
cable
VHF/UHF
Rear of TV
Older homes may have 300-ohm, twin-lead cable:
VHF Only or UHF Only or VHF/UHF
300-ohm twin
lead cable
VHF/UHF
Rear of TV
Antenna connector
Other homes may have both:
VHF and UHF
75-ohm
coaxial cable
VHF/UHF
Rear of TV
U/V Mixer
(not supplied)
300-ohm twin
lead cable
10
Installing the TV
Cable and Antenna
If your cable provider does not feature local channels, you may find
this set-up convenient.
CATV cable
(No connection to
TO CONVERTER)
AUX
Rear of TV
TO CONVERTER
VHF/UHF
Antenna cable
To receive channels using an antenna, instead of using the CATV cable
1 Select antenna mode by pressing the ANT button on the remote
control. (This is a toggle: pressing the button once selects antenna
mode; pressing the button again selects cable mode.)
2 Turn the Cable to OFF (see page 42).
3 Perform the Auto Program function (see page 42).
Basic Cable Box
Connections
Cable Box and Cable
This is the preferred basic cable TV hookup to use if your cable TV
company scrambles some channels, but not all of them (pay channels
vs. regular cable channels), and you need to use a cable box.
With this setup you can:
❑ Use the TV remote control to change channels on your cable box
when the signal is scrambled.
❑ Use the TV remote control to change channels using your TV
when the signal is not scrambled. (Your TV’s tuner provides a
better signal than the cable box.)
❑ Use the PIP feature normally with the CATV input.
❑ Use the PIP feature partially with the cable box. (When you
switch the TV input to AUX — to use the cable box — the
scrambled picture will display only in the main window. If you
turn on the PIP, you will be able to see any of the regular channels
in the PIP window, but you cannot SWAP the pictures between
the main and PIP windows.)
(Continued on the next page)
11
Installing the TV
(Continued from the previous page)
1 Connect the Cable TV cable to the TV’s VHF/UHF jack.
2 Using a coaxial cable, connect the TV’s TO CONVERTER jack to
the cable box’s IN jack. The TV’s internal converter allows you to
switch between unscrambled signals coming straight into the TV
and scrambled signals coming in through the cable box,
eliminating the need for an external splitter.
3 Using a coaxial cable, connect the cable box’s OUT jack to the
TV’s AUX jack.
Cable box
IN
75-ohm coaxial cable
(not supplied)
AUX
Rear of TV
OUT
3
2
TO CONVERTER
Rear of TV
75-ohm coaxial cable (not supplied)
1
VHF/UHF
Rear of TV
CATV cable (unscrambled channels)
To switch between channels from cable box and channels from regular cable
❑ Press the ANT button on the TV remote control. (This is a toggle:
pressing the button once selects the cable box; pressing the button
again selects regular cable.)
To use the cable box
❑ Have your TV tuner set to channel 3 or 4 (as appropriate) and
then use the cable box to switch channels.
To use the TV remote control to switch channels on the cable box
❑ Program the remote control as necessary. (See “Programming the
Remote Control” on page 52.) Then use the remote control to
switch cable box channels.
To use the TV remote control to switch channels on the VCR
❑ Program the remote control as necessary. (By default, the remote
control is set for a Sony VCR; to change to another brand see
“Programming the Remote Control” on page 52.) Then use the
VCR buttons on the remote control to switch channels on the
VCR.
To prevent the accidental switching of TV channels
❑ When using the cable box, you need your TV to stay on a
required channel (usually channel 3 or 4). You can use the TV’s
Channel Fix feature to lock in a specific channel. The Channel Fix
feature is under the Channel menu. For details, see “Using the
Channel Menu” on page 42.
12
Installing the TV
Cable Box only
Use this hookup if:
❑ You subscribe to a cable TV system that scrambles or encodes all
signals, requiring a cable box to view all channels, and
❑ You do not intend to hook up any other audio or video
equipment to your TV.
When all channels are routed through your cable box, only one
unscrambled signal is sent to the TV, so you cannot use the PIP
feature. If some of your channels are scrambled, but others are not,
consider using the hookup “Cable Box and Cable” on page 11
instead.
1 Connect the coaxial connector from your cable service to the
cable box’s IN jack.
2 Using a coaxial cable, connect the cable box’s OUT jack to the
TV’s VHF/UHF jack.
VHF/UHF
Rear of TV
Cable
1
2
IN
OUT
Cable box
13
Installing the TV
Connecting a VCR and Cable
Use this hookup if you subscribe to a cable TV (CATV) system that
does not require a cable box.
1 Connect the CATV cable to the VCR’s IN jack.
2 Using a coaxial cable, connect the VCR’s OUT jack to the TV’s
VHF/UHF jack.
3 Using an A/V cable, connect the VCR’s Audio and Video OUT
jacks to the TV’s Audio and Video IN jacks.
✍ If the VCR you are connecting has an S VIDEO jack, you can use an S VIDEO
cable for improved picture quality (compared to a combination audio/video
cable). Because S VIDEO cables carry only the video signal, you will need audio
cables for sound.
TV
Coaxial cable
VCR
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
CATV
A/V cable
14
Installing the TV
Connecting a VCR and Cable Box
Use this hookup if:
❑ Your cable TV company scrambles some channels, but not all of
them (pay channels vs. regular cable channels) and you therefore
need to use a cable box, and
❑
You want to use the PIP feature.
With this setup you can:
Use the TV remote control to change cable box channels when the
signal is scrambled.
❑
❑
❑
❑
Use the TV remote control to change TV channels when the
signal is not scrambled. (Your TV’s tuner provides a better signal
than the cable box.)
Use the PIP feature.
Record both regular CATV and scrambled channels.
To connect a cable box and a VCR, you will need:
A small, inexpensive device known as a splitter.
Three coaxial cables.
Either a combination audio/video cable, or an S VIDEO cable
and audio cables.
❑
❑
❑
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the two output jacks of the
splitter to the TV’s VHF/UHF jack.
3 Use a coaxial cable to connect the other output jack of the splitter
to the input jack of the cable box.
4 Use a coaxial cable to connect the output jack of the cable box to
the input jack of the VCR.
5 Use the video line (yellow) of a combination audio/video (A/V)
cable to connect the video output jack of the VCR to the video
input jack of the TV.
✍ If the VCR has an S VIDEO jack, you can use an S VIDEO cable to improve
picture quality; replace the yellow video cable of the combination A/V
cable with the S VIDEO cable. You will still need audio cables for sound.
Connect the left (white) and right (red) audio output channels of
the VCR to the respective input channels on the TV.
(Continued on the next page)
15
(Continued from the previous page)
Installing the TV
TV
Coaxial
cable
CATV
cable
Splitter
(not supplied)
Cable box
Coaxial
cable
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VCR
A/V cable
To view cable box channels
❑ Turn on the VCR and set it to the channel the cable box uses
(channel 3 or 4). Set the TV to VIDEO 1. Use the cable box to
switch channels.
To use the TV remote control to switch channels on the cable box
❑ Program the remote control as necessary. (See “Programming the
Remote Control” on page 52.) Then use the remote control to
switch cable box channels.
To use the TV remote control to switch channels on the VCR
❑ Program the remote control as necessary. (By default, the remote
control is set for a Sony VCR; to change to another brand see
“Programming the Remote Control” on page 52.) Then use the
VCR buttons on the remote control to switch VCR channels.
16
Installing the TV
To use PIP with the Cable Box
❑ Turn on the cable box and VCR. Use the remote control’s TV/VIDEO
(yellow) button to set the PIP output to VIDEO 1. Change the PIP
channel via the cable box. (The cable box’s tuner is used as the
PIP video source; if you do not turn on the cable box, the PIP will
not work.)
✍ This system is needed because the cable box unscrambles only one channel at
a time (unlike regular cable, which makes all channels available concurrently).
17
Installing the TV
Connecting Two VCRs for Tape Editing
If you connect two VCR’s together, so you can record from one to the
other, you may want to monitor the recording process. You can
connect the recording VCR into your TV and then view what is being
recorded. The procedure below shows you how to do this.
1 Using an A/V cable, connect the playback VCR’s Audio and
Video OUT jacks to the recording VCR’s Audio and Video IN
jacks.
2 Using an A/V cable, connect the recording VCR’s Audio and
Video OUT jacks to the TV’s Audio and Video IN jacks.
TV
VCR (recording)
VCR (playback)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
A/V cable
A/V cable
To change the video input of the VCR.
❑ See your VCR’s user’s guide for instructions.
To view what is being recorded
❑ Use the remote control to set the TV to the video input that the
recording VCR is connected to. (VIDEO 1 in the illustration
above.)
✍ If the VCRs you are connecting have S VIDEO jacks, you can use S VIDEO
cables to improve picture quality; replace the yellow video cable of the
combination A/V cable with the S VIDEO cable. You will still need audio cables
for sound.
18
Installing the TV
Connecting a Satellite Receiver
1 Connect the satellite antenna cable to the satellite receiver’s
SATELLITE IN jack.
2 Using an A/V cable, connect the satellite receiver’s Audio and
Video OUT jacks to the TV’s Audio and Video IN jacks.
3 Connect a coaxial cable from your cable or antenna to the TV’s
VHF/UHF jack.
✍ If the satellite receiver has an S VIDEO jack, you can use an S VIDEO cable to
improve picture quality; replace the yellow video cable of the combination A/V
cable with the S VIDEO cable. You will still need audio cables for sound.
TV
Coaxial
cable
Satellite antenna
cable
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Satellite receiver
A/V cable
19
Installing the TV
Connecting a Satellite Receiver with a VCR
1 Connect the satellite antenna cable to the satellite receiver’s
SATELLITE IN jack.
2 Connect the CATV cable to the VCR’s VHF/UHF IN jack.
3 Using a coaxial cable, connect the VCR’s OUT jack to the TV’s
VHF/UHF jack.
4 Using an A/V cable, connect the satellite receiver’s Audio and
Video OUT jacks to the VCR’s Audio and Video IN jacks.
5 Using an A/V cable, connect the VCR’s Audio and Video OUT
jacks to the TV’s Audio and Video IN jacks.
Satellite antenna
cable
Satellite receiver
VCR
TV
CATV
Coaxial
cable
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Coaxial
cable
A/V cable
✍ If the satellite receiver and VCR have S VIDEO jacks, you can use an S VIDEO
cable to improve picture quality; replace the yellow video cable of each
combination A/V cable with the S VIDEO cable. You will still need audio cables
for sound.
20
Installing the TV
To change VCR video input
❑ See your VCR’s user’s guide for instructions.
To watch satellite TV, or the VCR
❑ Use the TV/VIDEO on the remote control to select video source.
To watch cable TV
❑ Use the TV/VIDEO on the remote control to select VHF/UHF
source.
21
Installing the TV
Connecting an Audio Receiver
For improved sound quality, you may want to send the TV’s audio
signals to your stereo system. The procedure below tells you how.
1 Using audio cables, connect the TV’s Audio OUT jacks to the
audio receiver’s Audio LINE IN jacks.
AUDIO-L
(white)
AUDIO-R
(red)
Line input
22
Installing the TV
Connecting a DVD Player with Component
Video Connectors
This is the preferred hookup to use if your DVD player has
component video (Y, PB, PR) jacks.
1 Using three separate component video cables, connect the DVD
player’s Y, PB and PR jacks to the Y, PB and PR jacks on the TV. Use
the VIDEO 4 connections.
✍ The Y, PB and PR jacks on your DVD player are sometimes labeled Y, CB and
CR, or Y, B-Y and R-Y. If so, connect the cables to like colors.
2 Using an audio cable, connect the DVD player’s Audio OUT jacks
to the TV’s Audio IN jacks. Be sure to use the same column
(VIDEO 4) of inputs that you used for the video connection.
Component video cables
TV
DVD player
AUDIO-R (red)
AUDIO-L (white)
Audio cable
✍ You cannot record the signal from any equipment connected into the Y, PB, PR
jacks.
23
Installing the TV
Connecting a DVD Player with A/V Connectors
Use this hookup if your DVD player does not have component video
(Y, PB, PR) jacks.
✍ An S VIDEO connection will give a good quality video signal, but if your DVD
player has component video, that connection (described on the previous page)
will give an even better video signal.
1 Using audio cables, connect the DVD player’s Audio OUT jacks
to the TV’s Audio IN jacks.
2 Using an S VIDEO cable, connect the DVD player’s S VIDEO jack
to the TV’s S VIDEO jack.
TV
S VIDEO
cable
DVD player
AUDIO-R (red)
AUDIO-L (white)
Audio cable
To switch between your TV and DVD
❑ Use the TV/VIDEO button on the remote control to switch from one
input device to another.
24
Installing the TV
Connecting a Camcorder
For easy connection of a camcorder, the TV has front Audio and
Video inputs (shown below). If you prefer, however, you can connect
the camcorder to the TV’s rear Audio and Video IN jacks.
1 Using A/V cables, connect the camcorder’s Audio and Video
OUT jacks to the TV’s Audio and Video IN jacks.
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
A/V output
If you have a mono camcorder, connect its audio output to the TV’s
AUDIO L jack.
✍ If the camcorder has an S VIDEO jack, you can use an S VIDEO cable to
improve picture quality; replace the yellow video cable of the combination A/V
cable with the S VIDEO cable. You will still need audio cables for sound.
To view the camera’s output
❑ Use the TV’s remote control to set the appropriate input on the
TV (VIDEO 2, in the illustration).
25
Installing the TV
Using the CONTROL S Feature
The CONTROL S feature allows you to control other equipment
through your TV. Pointing the remote control at your TV, rather than
at the equipment, allows you to keep other equipment hidden or out
of direct line of sight.
To control your other Sony equipment with your TV’s remote control,
use a CONTROL S cable (not supplied) to connect the equipment’s
CONTROL S IN jack to the TV’s CONTROL S OUT jack.
TV
26
Installing the TV
Setting Up the TV Automatically
After you finish connecting your TV, you need to run Auto Setup to
set up your channels. The Auto Setup screen appears when you turn
your TV on for the first time after installing it. If you do not want to
set up the channels at this time, you can do it later by using the Auto
Program feature in the Channel menu (see pages 42 and 43).
✍ The Auto Setup feature does not apply for installations that use a cable box for
all channel selection.
Using Auto Setup
1 Press POWER to turn on the TV.
2 Press the TV function button on the remote control.
3 Press CH+ on the front of your TV to run the Auto Setup or press
CH– to exit. If you use the channel buttons on your remote control,
be sure to use the main set of buttons.
To reset TV to factory settings
1 Turn the TV on.
2 Hold down the RESET button on the remote control.
3 Press and release the POWER button on the TV. (The TV will turn
itself off, then back on.)
4 Release the RESET button.
27
Using the Features
Overview
This chapter describes how to use special features of your TV.
Topic
Page
Using Favorite Channels
30
Using Picture in Picture (PIP)
31
Using Wireless Headphones
34
29
Using the Features
Using Favorite Channels
The Favorite Channel feature lets you select programs from a list of
favorite channels that you specify.
To display a list of your favorite channels
1 If you have not already done so, create a list of favorite channels.
(See the Favorite Channels section of “Selecting Channel
Options” on page 42.)
2 If any menus are open, close them.
3 Press . (The Favorite Channels options appear.)
4 Press V or v to highlight the channel you want to watch. The
program on that channel appears in the preview window.
Press to select.
30
Using the Features
Using Picture in Picture (PIP)
Picture in Picture (PIP) allows you to watch two channels
simultaneously — one in the main window and another in a
secondary (PIP) window.
Displaying Picture in
Indicates which picture is
currently receiving sound
Main
9
6
2
Main picture channel
number in green
Window picture channel
number in white
Window picture
To use PIP:
1 Make sure your TV is tuned to a channel that you know is airing
programming.
2 Press the
button (or the button labeled PIP). The window
picture appears.
3 Use the yellow-labeled buttons on your remote control (see
diagram) to control the PIP features (which are listed on the next
page).
To check your PIP:
1 Tune your TV to a channel that you know is airing programming.
2 Press SWAP and select that same channel as the main window.
You should now have the same program playing in both your
main window and your picture window.
3 Use the PIP (yellow) CH+/- buttons to change the channel in the
picture window.
✍ You must press TV (FUNCTION) before you can control PIP with the yellowlabeled buttons.
The AUX input cannot be viewed in the PIP window.
(Continued on the next page)
31
(Continued from the previous page)
Using the Features
4 Now use the main CH+/- buttons of your remote control to
change the channel in the main window. If this does not work,
check “Troubleshooting” on page 56 for potential solutions.
PIP Functions
Yellow-labeled
PIP Button
3
1
1 AUDIO
Alternates sound between the main picture and the
window picture. The sound symbol (9) appears for
3 seconds, indicating whether you are hearing
sound from the main picture or the window picture.
2 POSITION
Moves the location of the window picture among
the four corners of the screen.
3 FREEZE
Freezes the window picture. Press again to restore
the picture. The main window continues to play as
usual.
4 CH +/–
Changes the channel in the window picture. To
change the channel in the main window, use the
main CH+/- buttons at the bottom of the remote
control.
5 TV/VIDEO
Cycles through available video equipment you have
connected to the TV.
6 SWAP
Switches the main picture with the window picture.
Press again to change them back.
7
Turns the PIP feature on and off. Press repeatedly to
change the window size (1/9, 1/16, OFF).
4
2
5
6
7
RM-Y182
32
Description
Using the Features
To change channels/programs in the PIP window
❑ Use the yellow PIP CH+/- button to scroll through the TV
channels.
❑
Use the yellow TV/VIDEO button to cycle through your other video
equipment connected to the TV, such as your VCR, DVD player
or Satellite Receiver.
Setups that affect your ability to use PIP
❑ Any video equipment you have connected to the AUX input
z Be sure to label your
video sources to make
them easier to find in the
Display. See “Video Label”
on page 49 for labeling
instructions.
cannot be viewed in the PIP window.
❑
If you are viewing all channels through a cable box, the PIP
feature will not work. The cable box only unscrambles one signal
at a time, so the window picture will be the same as the main
picture.
❑
You can use PIP to see pictures from different sources on your TV.
For example, you can have a regular (CATV) channel and the
output from a VCR or DVD player or satellite receiver on screen
at the same time using PIP. To do this:
1 Connect the CATV cable to the UHF/VHF input on the back
of the TV.
2 Connect the peripheral (VCR or DVD player or satellite
receiver) to any of the VIDEO IN inputs on the the back of the
TV.
3 Tune to one image in the main picture.
4 Tune to a second image in the PIP window.
You can then SWAP the images on the TV screen.
✍ You cannot use a signal from the AUX connection with PIP.
33
Using the Features
Using Wireless Headphones
✍ Wireless headphones are included and can be used only with Sony TV models
KV-32FV27 and 36FV27.
Installing the Battery
Install the supplied size AA (R6) battery into the headphones.
1 Open the battery compartment lid by pressing and sliding the lid
as illustrated.
2 Insert the battery into the compartment with the positive side up
and then close the lid.
When used continuously, the battery lasts:
up to 40 hours
with an alkaline battery
up to 20 hours
with a manganese battery
Replace the battery with a new one when the sound becomes weak.
34
Using the Features
Using the
Headphones
1 Press
. (The i icon and channel number display.)
i
6
2 Turn on the power by placing the headphones securely onto your
head.
Power indicator
Volume control
To listen to sound only from wireless headphones
❑ Turn down the TV speaker level, or press MUTING on the remote
control.
To turn off headphones,
❑ Put down the headphones and press
.
To ensure optimal sound reception with headphones
❑ Be sure that the infrared transmitter on the TV and the infrared
sensors on the headphones have a clear (unobstructed) line of
sight to one another.
To protect the TV’s infrared transmitter from possible damage
❑ Press
to turn off the headphone feature when the
headphones are not in use.
To protect your hearing from sudden or prolonged excessive volume
❑ Set the headphone volume just high enough to hear comfortably.
Infrared sensors
Infrared transmitter
✍ For optimal sound quality, be sure that the infrared transmitter on the TV, and
the infrared sensors on the headphones, are not obstructed and can “see” one
another.
35
Using the Features
Listening to Sound
from PIP Main and
Window Pictures
To use your headphones to listen to the sound from the main or
window picture (when using PIP), select the audio source.
1 If PIP is not already started, press
to display a PIP window.
6
2
2 Press
.
The i icon and channel number appear for about three seconds.
(The i is level with the channel number of the main picture.)
i
6
2
Main picture audio
again to switch the audio to the PIP window.
Press
(The i changes - drops down - to the level of the PIP channel.)
i
6
2
Window picture audio
3 When you are finished using the headphones, press
to turn
them off.
i
OFF
2
Headphones off
✍ Exiting from PIP returns the sound to the main picture.
The audio to the headphones automatically turns off when the TV is powered
off.
SAP (Second Audio Programs) are not available in the PIP window.
36
Using the Menus
Overview
Opening and choosing a menu:
Move
1 Press MENU to display the Menu screen.
Select
2 Use the joystick to move to the desired menu icon. Press
Joystick
to
select it.
3 Use the joystick to scroll up and down through the features.
4 See the specific menu page for instructions on moving through
the menu.
The Menu gives you access to the following features:
Menu Icon Description
Page
Allows you to make adjustments to your picture
38
settings. It also allows you to customize the Picture
Mode based on the type of program you are viewing.
Offers enhanced audio options such as listening to
second audio programming (SAP) or customizing
the Effect of the sound on your TV.
40
Press MENU again
Allows you to set up a Favorite Channel list, run the
Auto Program function, and more.
42
To end one menu session
and move to another:
Lets you control the viewing of programs based on
their ratings.
44
Lets you set the clock on your TV and allows you to
program your TV for scheduled viewing using the
Timers.
47
Provides several options for setting up your
channels, labeling your video inputs, and
selecting the language of the on-screen menus.
48
Provides quick access to frequently used settings.
50
To end a menu session:
Press F to return to the
menu icons.
Move the joystick to
choose a menu icon and
press
to select it.
37
Using the Menus
Using the Video Menu
To select the Video Menu
1 Press MENU.
2 Use the joystick to move to the
Video icon
and press
.
3 Use the joystick to scroll up
and down through the options.
4 Press
to select a feature.
That feature’s adjustment
appears.
5 Use the joystick to make the desired adjustments.
6 Press to select/set.
7 Press MENU to exit the menu screen.
To restore the factory default settings for Picture, Brightness, Color, Hue,
Sharpness, Color Temp and VM.
❑ Press RESET on the remote control when in the Video menu.
Selecting Video
Options
z To change from one Video
Mode to another, use the
PICTURE MODE button on the
remote control.
The Video Menu includes the following options.
Option
Mode
Customized
viewing
Description
Vivid
Standard
Movie
Sports
Select for enhanced picture contrast and
sharpness.
Select for standard picture settings.
Select to display a softer picture.
Select to display a brighter, more intense picture.
✍ You can alter the Video Menu settings (Picture, Brightness,
Color, etc.) for each Mode.
Brightness
Color
Hue
Sharpness
38
Adjust to increase picture contrast and deepen the color, or
decrease picture contrast and soften the color.
Adjust to brighten or darken the picture.
Adjust to increase or decrease color intensity.
Adjust to increase or decrease the green tones.
Adjust to sharpen or soften the picture.
Using the Menus
Option
Color Temp
White
intensity
adjustment
VM
Velocity
Modulation
Description
Choose from three color temperatures:
Cool
Select to give the white colors a blue tint.
Neutral
Select to give the white colors a neutral tint.
Warm
Select to give the white colors a red tint
(NTSC-Standard).
Sharpens picture definition to give every object a sharp, clean
edge. Select from High, Low, OFF.
39
Using the Menus
Using the Audio Menu
To select the Audio Menu
1 Press MENU.
2 Use the joystick to move to the
Audio icon
and press
.
3 Use the joystick to scroll up
and down through the options.
4 Press
to select an option.
That option’s settings appear.
5 Use the joystick to scroll
through the settings.
6 Press to select the desired setting.
7 Press MENU to exit the menu screen.
✍ The TV set has a Standby/Stereo LED. The LED flashes when the set is first
turned on. It glows steadily when:
● The TV is standing by for a command (no picture on screen);
● A program has stereo sound
To restore the factory default settings for Treble, Bass, and Balance
❑ Press RESET on the remote control when in the Audio menu.
Selecting Audio
Options
z As a shortcut to using the
menus, use the
button on
the remote control to access
the Steady Sound function.
The Audio Menu includes the following options:
Option
Treble
Bass
Balance
Steady Sound
Effect
Description
Adjust to decrease or increase higher-pitched sounds.
Adjust to decrease or increase lower-pitched sounds.
Adjust to emphasize left or right speaker balance.
ON
Select to stabilize the volume.
OFF
Select to turn off Steady Sound.
Simulated Adds a surround-like effect to mono programs.
SRS
Produces a dynamic three-dimensional sound
for stereo signals.
OFF
40
Normal stereo or mono reception.
Using the Menus
Option
MTS
Enjoy stereo,
bilingual and
mono programs
Speaker
Audio Out
Easy control of
volume
adjustments
Description
Stereo
Select for stereo reception when viewing a
program broadcast in stereo.
Auto-SAP
Select to automatically switch the TV to second
audio programs when a signal is received. (If no
SAP signal is present, the TV remains in Stereo
mode.)
Mono
Select for mono reception. (Use to reduce noise
during weak stereo broadcasts.)
ON
Select to turn on the TV speakers.
OFF
Select to turn off the TV speakers and listen to
the TV's sound only through your external
audio system speakers.
This option can be set only when the Speaker option is set
to OFF.
Variable
The TV’s speakers are turned off, but the
volume output from your audio system can still
be controlled by the TV’s remote control.
Fixed
The TV’s speakers are turned off and the
volume output of the TV is fixed. Use your
audio receiver’s remote control to adjust the
volume through your audio system.
41
Using the Menus
Using the Channel Menu
To select the Channel Menu
1 Press MENU.
2 Use the joystick to move to the
Channel icon
press .
and
3 Use the joystick to scroll up
and down through the options.
4 Press
to select a feature.
That feature’s options appear.
5 Use the joystick to scroll through the options.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
Selecting Channel
Options
The Channel Menu includes the following options:
Option
Favorite Channel
Cable
Description
1 Press to select a favorite channel number.
2
Use the joystick to scroll through the channels until
you find the channel you want to add to your
favorites.
3
Press
ON
OFF
to select it.
Select if you are receiving cable channels
with a CATV cable.
Select if you are using an antenna.
✍ You should run Auto Program after changing the cable
setting.
Channel Fix
2-6
Useful when you
have a cable box or
satellite receiver
connected
AUX 2-6
Auto Program
42
“Fix” your TV’s channel setting to 2 – 6 and
use the cable box or Satellite receiver to
change channels. Select one of these
settings if you have connected the device to
the VHF/UHF jack.
Same as 2 – 6, except you select one of these
settings if you have connected the device to
the AUX jack (see page 8).
VIDEO 1
Use this setting if you have connected the
device to the Audio and Video IN jacks.
Automatically programs the TV for all receivable
channels.
Using the Menus
Option
Channel
Skip/Add
z Channels that you set to
be skipped can be accessed
only with the 0-9 buttons.
Channel Label
Description
Removes and adds viewable channels.
1
Use the joystick to scroll through the channels until
you find the channel you want to skip/add.
2
3
4
Press
to select it.
Press the joystick to toggle between “Add” or “Skip.”
Press
to select.
Label up to 40 channels with their station call letters.
43
Using the Menus
Using the Parent Menu
The Parent menu allows you to set up the TV to block programs
according to their content and rating levels.
To select the Parent Menu
1 Press MENU.
2 Use the joystick to move to the
Parent icon
and press
.
3 Use the 0-9 buttons on the
remote control to enter your
four-digit password.
4 Confirm your password by
entering it again. (The Parent
menu options appear.)
5 Use the joystick to scroll through the settings.
6 Press to select the desired setting.
7 Press MENU to exit the menu screen.
✍ You need your password for any future access into the Parent menu. If you
lose your password, see “Lost password” on page 57.
Using the Parent
Menu
z If you are not familiar with
the Parental Guideline rating
system, you should select Child,
Youth, or Young Adult to help
simplify the rating selection. To
set more restrictive ratings,
select Custom.
The Parent menu includes the following options.
Option
Parental Lock
Parental lock is off. No programs are
blocked from viewing.
Maximum ratings permitted are:
❏ US: TV-Y, TV-G, G
❏ Canada: C, G
Youth
Maximum ratings permitted are:
❏ US: TV-PG, PG
❏ Canada: 8 ans+
Young Adult
Maximum ratings permitted are:
❏ US: TV-14, PG-13
❏ Canada: 14+, 13 ans+
Custom
Select to set ratings manually.
❏ US: See page 45 for details.
❏ Canada: See page 46 for details.
For changing your password.
Turn ratings on/off
and select a rating Child
system
z For descriptions of Child,
Youth, and Young Adult
ratings, see page 45.
Change Password
44
Description
OFF
Using the Menus
US Models:
Selecting Custom
Rating Options
z The content ratings will
increase depending on the level
of the age-based rating. For
example, a program with a TVPG V (Violence) rating may
contain moderate violence,
while a TV-14 V (Violence)
rating may contain more intense
violence.
For US models, the Custom Rating Menu includes the following
options. (For Canadian models, see page 46.)
Option
Movie Rating
TV Rating
Block programs
by their rating,
content or both
z To ensure maximum
blocking capability, the agebased ratings should be
blocked.
z If you block unrated TV
programs, be aware that the
following types of programs
may be blocked: emergency
broadcasts, political programs,
sports, news, public service
announcements, religious
programs and weather.
Viewing Blocked
Programs
Unrated
Block programs
or movies that
are broadcast
without a rating
Description
G
All children and General Audience.
PG
Parental Guidance suggested.
PG-13
Parental Guidance for children under 13.
R
Restricted viewing, parental guidance is
suggested for children under 17.
NC-17
No one 17 or under allowed.
and X
Age-Based Options
TV-Y
All children.
TV-Y7
Directed to older children.
TV-G
General Audience.
TV-PG
Parental Guidance suggested.
TV-14
Parents Strongly cautioned.
TV-MA
Mature Audience only.
Content-Based Options
FV
Fantasy Violence.
D
Suggestive Dialogue.
L
Strong Language.
S
Sexual situations.
V
Violence.
Block
Blocks all programs and movies that are
broadcast without a rating.
Allow
Allows programs and movies that are broadcast
without a rating.
You can view blocked programs by entering the password. Press the
ENTER button when tuned to a blocked program, then enter the
password. This temporarily switches off the Parental Lock. To
reactivate the Parental Lock settings, turn off the TV. When the TV is
turned on again, your Parental Controls settings are reactivated.
(Continued on the next page)
45
Using the Menus
Canadian Models:
Selecting Custom
Rating Options
(Continued from the previous page)
For Canadian models, the Custom Rating Menu includes the
following options. (For US models, see page 45.)
Option
English Rating
French Rating
USA Rating
Viewing Blocked
Programs
46
Description
C
All children.
C8
Children 8 years and older.
G
General programming.
PG
Parental Guidance.
14+
Viewers 14 and older.
18+
Adult programming.
G
General programming.
8 ans+
Not recommended for young children.
13 ans+
Not recommended for ages under 13.
16 ans+
Not recommended for ages under 16.
18 ans+
Programming restricted to adults.
See “US Models” on page 45 for details.
You can view blocked programs by entering the password. Press the
ENTER button when tuned to a blocked program, then enter the
password. This temporarily switches off the Parental Lock. To
reactivate the Parental Lock settings, turn off the TV. When the TV is
turned on again, your Parental Controls settings are reactivated.
Using the Menus
Using the Timer Menu
To select the Timer Menu
1 Press MENU.
2 Use the joystick to move to the
Timer icon
and press
.
To set the Current Time
1 Use the joystick to select
“Current Time”, then press
.
2 If your location is currently in
Daylight Saving Time, be sure to set the mode to “ON”. (Daylight
Saving Time starts in the Spring, and ends in the Fall.)
3 Use the joystick to enter the correct time, then press
4 Press MENU to exit the menu screen.
.
To set the Timer
Before setting the timer, be sure to set your TV’s clock to the current
time (and, if appropriate, to Daylight Saving mode).
1 Use the joystick to move to “Timer 1” or
“Timer 2”, then press
.
2 Use the joystick to enter your date, time and channel preferences,
then press
to select each one.
3 Press MENU to exit the menu screen. An LED on the front panel
will light, indicating the timer has been set.
To reset the Clock or Timers
❑ Press RESET on the remote control, when in the Timer menu, to
reset to the factory defaults.
Selecting Timer
Options
The Timer Menu includes the following options:
Option
Timer 1
Timer 2
Current Time
Daylight Saving
Description
Program
Select to set the Timer by day, time, duration,
and channel.
OFF
Select to turn off the Timer. (Your previous
settings will be saved.)
Set the current time.
ON
Select in the Spring to turn on this mode
during Daylight Saving Time.
OFF
Select in the Fall to turn off this mode at the
end of Daylight Saving Time.
47
Using the Menus
Using the Setup Menu
To select the Setup Menu
1 Press MENU.
2 Use the joystick to move to the
Setup icon
and press
.
3 Use the joystick to scroll
through the features.
4 Press
to select a feature.
(That feature’s options appear.)
5 Use the joystick to scroll
through the options.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
Selecting
Setup Options
48
The Setup Menu includes the following options:
Option
Caption Vision
Description
Allows you to select from three closed-caption modes (for
programs that are broadcast with closed caption).
CC1, CC2,
Displays a printed version of the
CC3, CC4
dialog or sound effects of a
program. (Should be set to CC1 for
most programs.)
TEXT1, TEXT2,
Displays network/station
TEXT3, TEXT4
information presented using either
half or the whole screen (if
available). For closed captioning,
set to CC1.
XDS
Displays a network name, program
(Extended Data
name, program length, and time of
Service)
the show (if the broadcaster offers
this service).
OFF
Turns off Caption Vision.
Using the Menus
Option
Video Label
Description
Allows you to label the audio/video components you
connected to the TV, so you can identify them when using
the TV/VIDEO button. When in the Setup menu’s Video
Label feature, use the joystick to highlight an input to
label, then press
to select it. Use the joystick to scroll
through the labels. Press
to select the component you
connected to each of the input jacks on the back of your TV.
Select “Skip” if you do not have a component connected to
a particular set of input jacks.
VIDEO 1/2/3
Choose VHS, 8mm, Beta, LD,
Game, SAT, DVD, Web, Receiver,
DTV, Skip
VIDEO 4
Choose DVD, DTV, Skip
✍ If you select “Skip”, your TV skips this connection when
you press the TV/VIDEO button.
Tilt Correction
Language
z To use this feature with
widescreen DVDs, set your
DVD player to 16:9 aspect
ratio.
16:9 Enhanced
Demo
Allows you to correct any tilt of the picture.
Select to display all on-screen menus in your language of
choice.
Provides enhanced picture resolution for widescreen
(anamorphic) sources, such as selected DVD titles (only
available when the TV is in VIDEO mode). Press TV/VIDEO
and select from one of the following options:
ON
To activate.
OFF
To turn off 16:9.
Runs a demonstration of on-screen menus.
49
Using the Menus
Using the Basic Menu
To select the Basic Menu
1 Press MENU.
2 Use the joystick to move to the
Basic icon
and press
.
3 Use the joystick to scroll
through the features.
4 Press
to select a feature.
(That feature’s options appear.)
5 Use the joystick to scroll through the options.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
Selecting
Basic Options
The Basic Menu includes the following options:
z As a shortcut to using the
menus, use the
button on
the remote control to access
Steady Sound option.
Effect
Option
Caption Vision
Advanced Menu
50
Description
Adjust the picture contrast.
Displays your current advanced-menu setting:
(CC1–4, TEXT 1–4, or XDS) and OFF.
Simulated Adds a surround-like effect to mono programs.
SRS
Produces a dynamic three-dimensional sound
for stereo signals.
OFF
Normal stereo or mono reception.
Select to return to the advanced menus.
Other Information
Overview
This chapter includes the following topics:
Topic
Page
Programming the Remote Control
52
Operating Other Components with
Your TV Remote Control
54
Troubleshooting
56
Specifications
58
Index
61
51
Other Information
Programming the Remote Control
The remote control is preset to operate Sony-brand video equipment.
Sony
Equipment
Switch Position
on Remote Control
Programmable
Code Number
Beta, ED Beta VCRs
AV1
303
8 mm VCR
AV2
302
VHS VCR
AV3
301
DVD Player
DVD
751
If you have video equipment other than Sony brand that you want to
control with the TV’s remote control, use the following procedure to
program the remote control.
✍ The equipment must have infrared (IR) remote capability in order to be used
with the remote control.
1 Check the list of “Manufacturer’s Codes” on page 53, and find
z
❑
❑
❑
❑
52
If more than one code
number is listed, try
entering them one by
one until you come to
the correct code for
your component.
If you enter a new code
number, the code
number you
previously entered at
that setting is erased.
In some cases, you may
not be able to operate
your component with
the supplied remote
control. In such cases,
use the component’s
own remote control
unit.
Whenever you remove
the batteries to replace
them, the code
numbers may revert to
the factory setting and
must be reset.
the three-digit code number for the manufacturer of your
component. (If more than one code number is listed, use the
number listed first.)
✍ You must do step 4 within 10 seconds of step 3, or you must redo
steps 2 and 3.
2 Press CODE SET.
3 Press the function button for the type of component you want to
control with the TV’s remote control (VCR/DVD or SAT/
CABLE).
4 Enter the three-digit manufacturer’s code number.
5 Press ENTER.
6 To check if the code number works, aim the TV’s remote control
at the component and press the green POWER button that
corresponds with that component. If it responds, you are done. If
not, try using another code listed for that manufacturer.
Other Information
Manufacturer’s Codes
Manufacturer
Code
DVD Players
Olympic
Optimus
Panasonic
309, 308
327
308, 309, 306,
307
305, 304
308, 309
308, 309, 310
308
308, 309, 306
304, 305, 308,
309, 311, 312,
313, 310, 329
309, 330, 328,
335, 324, 338
314
322, 313, 321
330, 335
312, 313, 321,
335, 323, 324,
325, 326
327, 328
315
338, 327
Manufacturer
Code
VCRs
Sony
Hitachi
JVC
Magnavox
Mitsubishi
Oritron
Panasonic
Philips
Pioneer
RCA
Samsung
Toshiba
Zenith
751
758
756
757
761
759
753
757
752
755
758
754
760
Manufacturer
Code
Sony
Admiral
(M. Ward)
Aiwa
Audio
Dynamic
Broksonic
Canon
Citizen
Craig
Criterion
Curtis Mathes
Daewoo
DBX
Dimensia
Emerson
301, 302, 303
327
Fisher
Funai
General
Electric
Go Video
Goldstar
Hitachi
338, 344
314, 337
319, 317
309, 308
332
302, 332
315
304, 338, 309
341, 312, 309
314, 336, 337
304
319, 320, 316,
317, 318, 341
330, 335
338
329, 304, 309
322, 339, 340
332
306, 304,
305,338
Instant Replay 309, 308
JC Penney
309, 305, 304,
330, 314, 336,
337
JVC
314, 336, 337,
345, 346, 347
Kenwood
314, 336, 332,
337
LXI (Sears)
332, 305, 330,
335, 338
Magnavox
308, 309, 310
Marantz
314, 336, 337
Marta
332
Memorex
309, 335
Minolta
305, 304
Mitsubishi/
323, 324, 325,
MGA
326
Multitech
325, 338, 321
NEC
314, 336, 337
Pentax
Philco
Philips
Pioneer
Quasar
RCA/
PROSCAN
Realistic
Sansui
Samsung
Sanyo
Scott
Sharp
Shintom
Signature
2000 (M.
Ward)
SV2000
Sylvania
Symphonic
Tashiro
Tatung
Teac
Technics
Toshiba
Wards
Yamaha
Zenith
338
308, 309, 338,
310
338
332
314, 336, 337
314. 336, 338,
337
309, 308
312, 311
327, 328, 335,
331, 332
314, 330, 336,
337
331
Laserdisc Players
Manufacturer
Code
Sony
Panasonic
Pioneer
701
704, 710
702
Cable Boxes
Manufacturer
Code
Sony
Hamlin/Regal
230
222, 223, 224,
225, 226
201, 202, 203,
204, 205, 206,
207, 208, 218
227, 228, 229
219, 220, 221
214, 215
209, 210, 211
Jerrold/G. I.
Oak
Panasonic
Pioneer
Scientific
Atlanta
Tocom
Zenith
216, 217
212, 213
Satellite Receivers
Manufacturer
Code
Sony
Dish Network
Echostar
General
Electric
Hitachi
Hughes
Mitsubishi
Panasonic
RCA/
PROSCAN
Toshiba
801
810
810
802
805
804
809
803
802, 808
806, 807
53
Other Information
Operating Other Components with Your TV Remote Control
Operating a VCR
Operating a DVD
Player
54
Move the slide switch to the AV input you coded for the VCR.
To Do This ...
Press
Turn on/off
VCR/DVD (green POWER button)
Select VCR
VCR/DVD (FUNCTION button)
Change channels
CH +/-
Record
z and a simultaneously.
Play
N
Stop
x
Fast forward
M
Rewind the tape
m
Pause
X (press again to resume normal playback)
Search the picture forward
or backward
M or m during playback
(release to resume normal playback)
Change input mode
TV/VCR
Move the slide switch to the AV input you coded for the DVD Player.
To Do This ...
Press
Turn on/off
VCR/DVD (green POWER button)
Select DVD
VCR/DVD (FUNCTION button)
Play
N
Stop
x
Pause
X (press again to resume normal playback)
Step through different
tracks of an audio disc
M to step forward, or m to step backward
Step through different
chapters of a video disc
CH+ to step forward, or CH- to step backward
Select tracks directly
0-9 buttons
Display the menu
(Setup)
MENU
Other Information
Operating a Cable
Box
Operating a Satellite
Receiver
To Do This ...
Press
Turn on/off
SAT/CABLE (green POWER button)
Select Cable Box
SAT/CABLE (FUNCTION button)
Select a channel
0-9 buttons, ENTER
Change channels
CH +/-
Back to previous channel
JUMP
To Do This ...
Press
Turn on/off
SAT/CABLE (green POWER button)
Select Satellite Receiver
SAT/CABLE (FUNCTION button)
Select a channel
0-9 buttons, ENTER
Change channels
CH +/-
Back to previous channel
JUMP
Change input mode
TV/SAT
Display channel number
DISPLAY
Display DBS guide
GUIDE
Display DBS menu
MENU
Move highlight (cursor)
Joystick
Select item
Operating an MDP
(Laserdisc Player)
button
Move the slide switch to the AV input you coded for the selected
switch position.
To Do This ...
Press
Turn on/off
VCR/DVD (green POWER button)
Select AV 1, 2, 3 or DVD
switch position
VCR/DVD (FUNCTION button)
Play
N
Stop
x
Pause
X (press again to resume normal playback)
Search the picture forward
or backward
M or m during playback
(release to resume normal playback)
Search a chapter forward or
backward
CH +/-
55
Other Information
Troubleshooting
Problem
Possible Remedies
Reset TV to factory settings ❏
No picture
(screen not lit), no sound
❏
❏
❏
❏
Remote control
does not operate
Dark, poor or no
picture (screen lit),
good sound
Good picture,
no sound
Cannot receive upper
channels (UHF) when
using an antenna
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
❏
Dotted lines
or stripes
❏
❏
❏
❏
❏
❏
TV is fixed to one channel
❏
Double images or ghosts
❏
❏
No color
Only snow and noise
appear on the screen
Cannot operate menu
❏
Cannot receive any channels ❏
when using cable TV
❏
❏
56
Turn on the TV. While holding down the RESET button on the remote
control, press the POWER button on the TV. (The TV will turn itself off,
then back on again.) Release the RESET button.
If your TV does not turn on, and a red light keeps flashing, your TV may
need service. Call your local Sony Service Center.
Make sure the power cord is plugged in.
Push the power button on the front of the TV.
Check to see if the TV/VIDEO setting is correct: when watching TV, set to
TV. When watching connected equipment, set to VIDEO 1, 2, 3, or 4, as
appropriate.
Try another channel, it could be station trouble.
Batteries could be weak. Replace the batteries.
Press TV (FUNCTION) when operating your TV.
Make sure the TV’s power cord is connected securely to the wall outlet.
Locate the TV at least 3-4 feet away from fluorescent lights.
Check the orientation of the batteries.
Adjust the Picture setting in the Video menu (see page 38).
Adjust the Brightness setting in the Video menu (see page 38).
Check antenna/cable connections.
Press MUTING so that “MUTING” disappears from the screen (see page 4).
Make sure Speaker is set to ON in the Audio menu (see page 40).
Change Cable to OFF (see page 42).
Use Auto Program in the Channel menu to add receivable channels that are
not presently in the TV’s memory (see page 42).
Adjust the Color settings in the Video menu (see page 38).
Check the antenna/cable connections.
Try another channel; it could be station trouble.
Press ANT to change the input mode (see page 5).
Adjust the antenna.
Move the TV away from noise sources such as cars, neon signs, or hairdryers.
Use Auto Program in the Channel menu to add receivable channels that are
not presently in the TV’s memory (see page 42).
Check your Channel Fix settings (see page 42).
Using a highly directional outdoor antenna or a cable may solve the
problem.
If the item you want to choose appears in gray, you cannot select it.
Use Auto Program in the Channel menu to add receivable channels that are
not presently in the TV’s memory (see page 42).
Check your cable settings.
Make sure Cable is set to ON in the Channel menu (see page 42).
Other Information
Problem
Possible Remedies
Cannot gain enough volume ❏
when using a cable box
Cannot receive channels
❏
Unable to select a channel
❏
Lost password
❏
Cannot change channels
with the remote control
❏
❏
❏
Cannot cycle through the
other video equipment
connected to the TV
There is a black box on
the screen
❏
❏
The remote control will
❏
not work in PIP mode
There is no window picture ❏
or it is just static
❏
❏
I get the same program in
the window picture as in
the main picture
❏
I cannot get anything but
TV in my window picture
❏
❏
Increase the volume of the cable box using the cable box’s remote control.
Then press TV (FUNCTION) and adjust the TV’s volume.
Use Auto Program in the Channel menu to add receivable TV channels that
are not presently in TV memory (see page 42).
Use Auto Program in the Channel menu to add receivable TV channels that
are not presently in TV memory (see page 42).
In the password screen (see page 44), enter the following master password:
4357. The master password clears your previous password; it cannot be
used to temporarily unblock channels.
If you are using the TV to change channels, be sure the TV FUNCTION
button is selected.
If you are using another device to change channels, be sure you have not
inadvertantly switched your TV from the channel 3 or 4 setting. Use the
Channel Fix feature to “fix” the channel based on the hookup you used (see
page 42).
If you are using another device to change channels, be sure to press the green
“FUNCTION” button for that device. For example, if you are using your
VCR to change channels, be sure to press the VCR/DVD FUNCTION button.
Be sure the Video Label feature has not been set to “Skip” (see page 49).
You have selected a text option in the Setup menu and no text is available.
(See page 48 to reset Setup selections.) To turn off this feature, select OFF in
the Caption Vision option. If you were trying to select closed captioning,
select CC1 instead of TEXT 1-4.
Press the TV FUNCTION button. You may have inadvertantly pressed the
VCR/DVD FUNCTION button, which changes the PIP buttons to VCR mode.
Be sure your window picture is set to a video source/channel that has a
program airing.
You may be tuned to a video input with nothing connected to it. Try
cycling through your video inputs using the PIP TV/VIDEO button.
PIP is not set to receive a signal from the AUX input. If you connected a
VCR, DVD player or Satellite Receiver to the AUX input on the TV, it will
not show in the small window picture.
Both may be set to the same channel. Try changing channels in either the
main picture or the window picture.
You may using a cable box for all your channels. If you must have a cable
box to unscramble all channels, then you are limited to only one picture
(because that is all that the cable box allows - one channel at a time). But if
you need the cable box only part time (to unscramble premium channels),
then you can use PIP when you are not using the cable box (when you use
the CATV cable without going through the box).
Be sure the video label has not been set to skip your video inputs. (See the
Setup menu on page 49.)
If, after reading these operating instructions, you have additional questions related to the use of your Sony
television, please call our Direct Response Center at 1-800-222-SONY (7669) (U.S. residents only) or
(416) 499-SONY (7669) (Canadian residents only).
57
Other Information
Specifications
All Models (General)
Picture Tube
Antenna
Television System
Channel Coverage
VHF
UHF
CATV
Power Requirements
Number of Inputs/Outputs
Video (IN)
S Video (IN)
FD Trinitron® tube
75 ohm external terminal for VHF/UHF
NTSC, American TV Standard
2-13
14-69
1-125
120V, 60 Hz
3
2
Audio (IN)
4
Variable/Fixed Audio (OUT)
1
Monitor Out
1
CONTROL-S (IN/OUT)
Component Video Input
1
1 (Y, PB, PR)
1 Vp-p, 75 ohms unbalanced, sync negative
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
500 mVrms (100% modulation)
Impedance: 47 kilohm
More than 408 mVrms at the maximum
volume setting (Variable)
More than 408 mVrms (Fixed)
Impedance (output): 2 kilohms
1 Audio/Video output (1 Vp-p, 75 ohms
unbalanced, sync negative)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative; PB: 0.7 Vp-p, 75 ohms
PR: 0.7 Vp-p, 75 ohms
KV-32FV27
Supplied Accessories
Remote Control
AA (R6) Batteries
Wireless Stereo Headphones
Optional Accessories
AV Cable
Audio Cable
Component Video Cable
TV Stand
Visible Screen Size
Actual CRT Size
Speaker Output
Dimensions (W x H x D)
Mass
Power Consumption
In Use
In Standby
58
RM-Y182
2 supplied for remote control, 1 supplied for wireless headphones
MDR-IF0230
VMC-810/820/830 HG
RKC-515HG
VMC-10/30 HG
SU-32FD4
32 in (812.8 mm) picture measured diagonally
34 in (863.6 mm) picture measured diagonally
15 W x 2
882 x 687 x 592 mm (34 3/4 x 27 x 23 1/4 in)
80 kg (176 lbs)
210 W
2W
Other Information
KV-36FV27
Supplied Accessories
Remote Control
AA (R6) Batteries
Wireless Stereo Headphones
Optional Accessories
AV Cable
Audio Cable
Component Video Cable
TV Stand
Visible Screen Size
Actual CRT Size
Speaker Output
Dimensions (W x H x D)
Mass
Power Consumption
In Use
In Standby
RM-Y182
2 supplied for remote control, 1 supplied for wireless headphones
MDR-IF0230
VMC-810/820/830 HG
RKC-515HG
VMC-10/30 HG
SU-36FD4
36 in (914.4 mm) picture measured diagonally
38 in (965.2 mm) picture measured diagonally
15 W x 2
975 x 757 x 633 mm (38 3/8 x 29 3/4 x 24 7/8 in)
107 kg (236 lbs)
210 W
2W
59
Index
16:9 (widescreen) 2, 49
Channel Skip/Add 43
channels
A
Activating a PIP screen 31
Adding channels to the channel list 42, 43
Adjusting the picture definition 39
Adjusting the audio 40, 50
ANT button 5
Aspect ratio, 16:9 49
Audio menu 37, 40
audio receiver, connecting 22
Auto Program (channel setup) 27, 42
Auto-SAP 41
Auto setup 27
B
balance, adjusting 40
Basic menu 37, 50
bass, adjusting 40
batteries
inserting in remote 3
inserting in wireless headphones 34
bilingual audio 41
blocking programs. See ratings.
brightness, adjusting 38
C
cable
creating labels 43
setting up 27
closed caption modes 48
Code Set Button 4, 52
color temperature, adjusting 39
color, adjusting 38
Connecting:
Audio Receiver 22
Cable or antenna 10-13
Cable box 11-13
Camcorder 25
DVD player 23, 24
Satellite receiver 19
VCR 14-18
VCR with satellite receiver 20
Contents of box 3
CONTROL S 26
Controls and connections 8
Converter 12
D
Demo, menus 49
Display
button 4
turning off 4
DVD player
using with TV remote control 54
with A/V connectors, connecting 24
with component video connectors, connecting
23
box, connecting with VCR 15
connecting 10-13
setting ON/OFF 42
with VCR, connecting 14
cable box, using with TV remote control 55
camcorder, connecting 25
Caption Vision 48, 50
CATV. see cable
Channel List
E
Enhanced picture resolution 49
Extended Data Service 48
Adding channels to 43
Removing channels from 43
Channel menu 37, 42
Channel Setup menu 42
(Continued on the next page)
61
Index
(Continued from the previous page)
F
P
Favorite Channel
Parent menu 37, 44
parental control, described 2
password
setting up 42
using 30
features 2
Front Panel controls 8
changing 44
headphones, see wireless headphones
Hookups 10-26
hue, adjusting 38
picture contrast, adjusting 38
picture definition, adjusting 39
Picture in Picture (PIP), using 31
picture, adjusting 50
Picture Mode 4
Picture size, adjusting in PIP 32
power cord, removing from holder 7
presetting channels 42
problems, troubleshooting 56-57
I
R
inputs, labeling 49
ratings, setting 44-45
ratings, viewing blocked programs 45, 46
Rear panel controls and connections 8-9
remote control
G
Guide button 5
H
J
Jump button 4
described 4-5
inserting batteries 3
programming 52
L
label
channels 43
video inputs 49
Languages, closed captioning menu 49
LED
Remote control, buttons inside cover 5
Remote control, operating other components
with
VCR 54
MDP 55
Satellite receiver 55
DVD 54
Cable box 55
Standby/Stereo 40
Timer 47
Locking programs 44
M
Manufacturer’s Codes 53
MDP, using with TV remote control 55
Menu button 4
menus
Audio 37, 40
Basic 37, 50
Channel 37, 42
Channel Setup 42
Parent 37, 44
Parental Control 44
Setup 37, 48
Timer 37, 47
Video 37, 38
MTS 5, 41
Muting 4
62
Removing channels from the channel list 42
Reset button 5
resetting
Audio options 40
Timer options 47
Video options 38
S
SAT/CABLE power button 4
SAT/CABLE function button 4
satellite receiver, using with TV remote control
55
Setting favorite channels 42
setting up channels 27, 42
Setup menu 37, 48
sharpness, adjusting 38
Index
Simulated 40, 50
Sleep timer/button 4
sound effect (3-D), adjusting 40, 50
speakers
turning on/off 41
using external speakers 41
specifications 58-59
Standby/Stereo LED 40
Steady Sound
adjusting 40
described 2
T
tape-to-tape editing 18
tilt, correcting 49
Time
set current 47
set daylight saving 47
Timer
LED 47
menu 37, 47
Timer setting 47
treble, adjusting 40
troubleshooting 56-57
TV function button 4
TV power button 4
TV/VIDEO button 5
V
VCR
connecting two, for tape editing 18
using with TV remote control 54
with cable box, connecting 15
with cable, connecting 14
with satellite receiver, connecting 20
VCR/DVD power button 4
VCR/DVD function button 4
Velocity Modulation 2, 39
video inputs, labeling 49
Video menu 37, 38
Video Modes, selecting 38
W
Wega, described 2
widescreen 49
widescreen, described 2
wireless headphones 34-36
63
Printed in U.S.A.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
