IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS
v2.0 (3.0.2.0) (EN/F)
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
user manual
guide de l’utilisateur
•
ARS2i
•
OFF
-
+
AUX
Radio
iPod
EN/F
It is important to read this user manual prior to using your new product for the first time.
Nous vous recommandons de lire ce manuel avant d’utiliser votre nouveau produit
pour la première fois.
FCC Information
Before you begin
radio or television reception, which
can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician for
help.
Plugging in for power
Modifications not expressly approved
by the party responsible for compliance
could void the user’s authority to
operate the equipment.
• Connect the supplied power adapter
to the unit’s DC jack, and connect to
a convenient wall outlet.
• Slide the POWER switch at the
back of the unit to ON. The clock is
then flashing. Refer to the “Clock”
section and follow the instructions
to set the clock time.
The POWER switch is located
at the back of the unit.
Switch it to the ON position
before operating the unit.
Power failure indicator
If the the built-in Li-Polymer
rechargeable battery runs out and
AC power is disconnected for a short
Some of the following information may
not apply to your particular product;
however, as with any electronic product,
precautions should be observed during
handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near
water.
• Clean only with dry cloth.
• Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
• Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
• Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the
other. A grounding type plug has
two blades and a third grounding
•
•
•
prong. The wide blade or the third
prong is provided for your safety. If
the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
Only use attachments/accessories
specified by the manufacturer.
Use only with the
]
cart, stand, tripod,
bracket, or table
specified by the
manufacturer,
Portable Cart Warning
or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
Unplug this apparatus during
lightning storms or when unused
for long periods of time.
Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
• ADDITIONAL SAFETY
INFORMATION
• The AC/DC adapter supplied with
this product is intended to be
correctly oriented in a vertical or
floor mount position.
• Do not use unauthorized chargers
or power adapters. Use only
chargers that came with your
product or that is listed in the user’s
guide.
• Apparatus shall not be exposed to
dripping or splashing and no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
• Always leave sufficient space around
the product for ventilation. Do
not place product in or on a bed,
rug, in a bookcase or cabinet that
may prevent air flow through vent
openings.
• Do not place lighted candles,
cigarettes, cigars, etc. on the
product.
• Care should be taken so that objects
do not fall into the product.
• Do not attempt to disassemble
the cabinet. This product does
not contain customer serviceable
components.
• The marking information is located
at the bottom of apparatus.
• Caution marking is located at
bottom of apparatus.
• To be completely disconnect the
power input, the AC/DC adaptor
of apparatus shall be disconnected
from the mains.
Battery icon
period of time, the time settings
will change. After AC power is
reconnected, the clock setting icon
and the time flash to indicate that
power was interrupted and you should
readjust the time settings.
• Different battery icon reflects
different battery levels:
•
•
means full battery level.
means the battery level is
low, charge the battery soon.
•
The built-in Li-Polymer
rechargeable battery is
irreplaceable.
Replacing the battery of
the Remote Control
Before using the Remote
Control
There is an isolated sheet installed in
the battery compartment of the remote
control. Remove the sheet before using
the remote control.
1. Slide out the battery compartment.
2. Insert one battery (CR2025) making
sure the polarity (+/–) matches the
marks indicated on the remote.
3. Slide in the battery compartment.
Warning: Your product contains a
battery and charging system which is
designed to work in temperatures that
do not exceed 50°C (122°F). Leaving
this product in a closed automobile
flashing means the battery
level is very low, charge the
battery immediately or the Radio,
iPod and AUX mode can only be
continued for two mintues before
entering standby mode.
• When the unit is disconnected from
the AC power and operates by the
built-in Li-Polymer rechargeable
Back view
Remote Control
POWER – Switch on/off the power
Sound source selection
CAUTION
Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type.
iPod
AUX IN – Auxiliary input jack
RADIO
BAND
REPEAT
AM loop antenna socket –
Connect to the AM loop antenna
+
STORE
VOL – / VOL + – Adjust volume
TUNE +
VOL
FM antenna socket – Connect to
the FM antenna
OFF
REPEAT – Select repeat playback mode
for iPod/iPhone
AUX
SHUFFLE
RECALL
TUNE -
SLEEP
MUTE
STORE – Save radio stations as presets
RECALL – Recall preset radio stations
For your records
In the event that service should be
required, you may need the model
number and the serial number. In the
space below, record the date and place
of purchase and the serial number:
Model No.:
Date of Purchase:
Place of Purchase:
Serial No.:
FCC Information
FCC Information
This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
Technical information
Product: Portable audio system for
iPhone and iPod
Brand: Acoustic Research
Model: ARS2i
Electrical power
information
However, there is no guarantee
that interference will not occur in a
particular installation. If this equipment
does cause harmful interference to
AC/DC Adaptor:
Input: 100-240V ~ 50/60Hz
Output: 20 V/2.25 A
Charging the battery
Front view
Display
The unit has a built-in Li-Polymer
rechargeable battery. When the POWER
button is switched to ON and the AC/
DC adaptor is connected to the unit,
the unit will start charging if the
battery level is not full. When the unit
is charging, the battery level will be
rotating.
-
OFF
Use only the provided AC/DC charger.
Charge the battery for at least 4 hours
before first use.
OFF
Sound source selection
+
AUX
Radio
+
-
iPod
AUX
Radio
iPod
battery, the battery icon
will
be lighted to indicate the unit is
operating on battery.
• When the unit is reconnected to the
Universal dock for iPod/iPhone
OFF – Switch the unit to standby mode
The
button will not
function when you are
holding the handle at the
back of the unit. This is to prevent
opening the universal dock for iPod/
iPhone accidentally.
+ – Adjust volume
– Open or close the motorized
universal dock for iPod/iPhone. This
button will not open or close the
universal dock whenever an iPod or
iPhone is docked.
Clock
Radio
Setting clock time
Listening to the radio
1. Press CLK SET on the top of
the unit. The clock setting icon
flashes and the clock time is
displayed.
2. Press REV or FWD on the top of the
unit to set the clock time. The time
decrements or increments follow by
a faster rate when you press and
hold the button.
• AM or PM icon also lights beside
the time.
To turn on or off radio:
1. Press RADIO on the front of the
unit to turn on the radio.
• The radio mode icon (
) lights on
the display.
2. Press OFF to turn off the radio, or
press AUX or iPod to select another
sound mode.
TUNE + / TUNE - (REV or FWD) – Search
radio frequencies; skip or search music
file in iPod/iPhone; adjust clock time
OFF – Switch the unit to standby mode
SLEEP – Refer to “Sleep function”
3. To save and exit the clock setting,
wait for about 5 seconds or press
CLK SET to save the time.
MUTE – Mute the sound
To select radio band:
• In radio mode, press RADIO to
select the radio band (AM/FM).
• The selected radio band icon lights
on the display.
To tune frequency:
• Press REV or FWD. The selected
frequency shows on the display.
• Press and hold to automatically
search for the next available station.
Antenna
Top view
Built-in AFC
The Built-in Automatic Frequency
Control (AFC) works only on FM. It helps
reducing drift on FM reception and
keeping the radio locked in on the FM
station to which it is tuned.
BRIGHTNESS – Adjust display
brightness
CLK SET – Enter setting mode for
setting clock time
REV or FWD – Search radio
frequencies; skip or search music file in
iPod/iPhone; adjust clock time
STORE – Save radio stations as presets
Universal dock for iPod/iPhone
iPhone, iPod, iPod classic, iPod nano
and iPod touch are trademarks of Apple
Inc., registered in the U.S. and other
countries.
When the battery level drops even
lower, the display will be turned off and
the unit will be powered off.
SHUFFLE – Select random playback
mode for iPod/iPhone
DC IN – Connect to the power adapter
“Made for iPod” and “Made for
iPhone” mean that an electronic
accessory has been designed to
connect specifically to iPod or iPhone,
respectively, and has been certified
by the developer to meet Apple
performance standards. Apple is not
responsible for the operation of this
device or its compliance with safety and
regulatory standards.
General controls
When the built-in battery level is low,
the battery icon
will be flashing
as an indication. At the same time, the
text “Lo” and “bAt” will be flashing
alternatively. Radio, iPod and AUX
mode cannot be accessed.
AM loop FM antenna
iPod/iPhone
Listening to iPod/iPhone
AM Antenna
For AM reception, connect the AM
antenna loop to the back of the radio.
Stretch out the antenna cord to its
fullest length and rotate the antenna
for better reception.
To connect iPod/iPhone:
to open the universal dock
1. Press
for iPod/iPhone on the front of the
unit.
2. Place the appropriate adapter
provided with your iPod/iPhone and
then place your iPod/iPhone on the
universal dock for iPod/iPhone.
Station presets
To store a station as preset:
1. Tune to a radio station.
To select iPod mode:
• Press iPod on the front of the unit
to select the iPod mode.
• The iPod mode icon ( ) and the
word “iPod” light on the display.
• Playback from the iPod/iPhone starts
automatically.
• If no iPod/iPhone is connected
in the iPod mode, the unit will
exit the iPod mode and turn off
automatically.
2. Press STORE.
• An available preset location
(e.g.
) shows on the display.
3. Press REV or FWD (or RECALL) to
select a desired preset location
(01 - 20).
4. Press STORE.
shows on the display as
•
confirmation.
• You can save up to 20 preset
stations.
To recall a preset station:
1. In radio mode, press RECALL.
• The existing preset station number
shows on the display.
When tuning in FM stations, you may
notice that the station you are tuning
can be well-tuned on two or three
nearby points. Always tune carefully at
the loudest and clearest point.
2. Press REV or FWD (or RECALL) to
select a desired preset station.
RECALL – Recall preset radio stations
Sleep function
Auxiliary source
Display brightness
Troubleshooting
Warranty information
To control the playback:
1. During playback, press iPod to
pause the playback and press again
to resume.
In the sleep mode, the radio, iPod or
AUX mode can be set to operate for a
certain period of time before turning
off automatically.
To select auxiliary mode:
1. Connect your auxiliary source (e.g.
mp3 player) to the AUX input jack
at the back of the unit with an
audio cable (not supplied).
Press BRIGHTNESS repeatedly to adjust
the brightness level among bright, dim
and off.
Battery error
Limited warranty
12 Month Limited Warranty
Applies to Acoustic Research Audio/
Video Products
2. Press REV or FWD to skip to the
previous or next file.
• Press and hold REV or FWD to
search backward or forward.
To set the sleep time:
1. Press SLEEP repeatedly to cycle
among the sleep time available
(90min, 60min, 30min, 15min and
OFF. 90min is the default setting).
• The icon
flashes while selecting.
2. Press AUX to turn on the unit or to
switch to listen to AUX from other
modes and the word “AUX” is
displayed on the display.
During battery charging, “bAt 1” is
displayed.
• The temperature of the battery
exceeds the allowable charging
range. Move the unit to a location
where the temperature falls
between this range.
2. When the desired sleep time is
selected, release SLEEP and wait for
about 5 seconds, the sleep time is
now set.
lights on the display.
• The icon
• Adjust the auxiliary player to midrange volume and adjust the master
volume on the unit. Do not turn
the volume of the auxiliary player
too high as this may affect the
sound quality. For other playback
operations, control them on your
auxiliary player.
iPod/iPhone
3. Press SHUFFLE to play the files in
random order in the iPod/iPhone.
Press again to cancel the function
(shows on the iPod/iPhone display).
4. Press REPEAT to select a repeat
playback mode (repeat 1 or repeat
all). Press REPEAT until no repeat
mode is selected (shows on the
iPod/iPhone display) to cancel the
repeat playback.
To charge the iPod/iPhone:
• You may charge the battery of your
iPod/iPhone through the universal
dock for iPod/iPhone while the unit
is turned off (standby mode) or in
the AUX, Radio (FM band only) or
iPod mode. Charging control should
be operated on the iPod/iPhone. It
is not necessary to charge in iPod
mode, unless you are listening to
the iPod/iPhone.
To listen to different sources:
• In standby mode, press SLEEP to
turn on the sleep mode and your
last selected source will be started
to play.
• To listen to other sources, press the
source buttons as usual.
To change or check the remaining
time in sleep mode:
• Press SLEEP once to check the
remaining sleep time. Press SLEEP
repeatedly to select another sleep
time.
To cancel the sleep mode:
• If you decide to turn off the unit
sooner, press OFF or press SLEEP
repeatedly to select “OFF”.
Warranty information
How to make a warranty claim:
• If your product is capable of storing
content (such as an mp3 player,
digital voice recorder, etc), it is
recommended to make periodic
backup copies of content stored
on the product. If applicable,
before shipping a product, make
a back up copy of content or data
stored on the device. Also, it is
advisable to remove any personal
content which you would not want
exposed to others. IT IS LIKELY
THAT CONTENTS AND DATA ON
THE DEVICE WILL BE LOST DURING
SERVICE AND REFORMATTING.
AUDIOVOX ACCEPTS NO LIABILITY
FOR LOST CONTENT OR DATA,
OR FOR THE SECURITY OF ANY
PERSONAL CONTENT OR DATA ON
THE RETURNED DEVICE. Product
Important battery
information
Low Battery Level
General controls
Some states do not allow limitations on
how long an implied warranty lasts or
the exclusion or limitation of incidental
or consequential damage so the above
limitations or exclusions may not apply
to you. This Warranty gives you specific
legal rights and you may also have
other rights which vary from state to
state.
AC OUTLET POWER SUPPLY:
100-240 V ~ 50/60 Hz
or the trunk of an automobile where
temperatures may exceed 50°C may
result in permanent battery damage,
fire, or explosion. Please remove your
product from the automobile when
you exit, do not place your product in
the trunk of your automobile, and do
not leave your product in any location
where temperatures may exceed 50°C.
-/
2. Slide the POWER
switch to ON
ANY OTHER WARRANTY. No person or
representative is authorized to assume
for the Company any liability other than
expressed herein in connection with the
sale of this product.
Plugging in for power
AC power, the battery icon
will not be displayed to indicate the
unit is operating on AC power.
1. Plug in for power
iPod/iPhone charging is not
available when operating by
batteries.
This equipment is a Class II
or double insulated electrical
appliance. It has been designed
in such a way that it does not
require a safety connection to
electrical earth.
Battery Level
This Class B digital apparatus
complies with Canadian ICES-003.
Cet appareil numérique de la classe
B est conforme à la norme NMB-003
du Canada.
Made for:
• iPhone 3GS 16GB, 32GB
• iPhone 3G 8GB, 16GB
• iPod touch 3rd generation 32GB,
64GB
• iPod touch 2nd generation 8GB,
16GB, 32GB, 64GB
• iPod touch 1st generation 8GB,
16GB, 32GB
• iPod nano 5th generation 8GB
or 16GB
• iPod nano 4th generation
(video) 8GB, 16GB
• iPod nano 3rd generation
(video) 4GB, 8GB
• iPod classic 80GB, 120GB, 160GB
• iPod nano 2nd generation
(aluminum) 2GB, 4GB, 8GB
• iPod nano 1GB, 2GB or 4GB
• iPod 5th generation (video)
30GB, 60GB, 80GB
• iPod mini 4GB, 6GB
• iPod 4th generation 20GB, 40GB
• iPod 4th generation (color
display) 20GB, 30GB, 40GB, 60GB
• AC/DC adaptor is a disconnect
device. The AC/DC adaptor should
not be obstructed OR should be
easily accessed during intended use.
• Battery shall not be exposed to
excessive heat such as sunshine, fire
or the like.
• The ventilation should not be
impeded by covering the ventilation
openings with items such as
newspaper, table-cloths, curtains etc.
• No naked flame sources such as
lighted candled should be placed on
the apparatus.
• Attention should be drawn to the
environmental aspects of battery
disposal.
• The use of apparatus in moderate
climates.
When the unit is
• reconnected to the AC power,
• disconnected from the AC power
and operates by the built-in LiPolymer rechargeable battery,
the display backlight will be readjusted.
You can press BRIGHTNESS to adjust
the brightness level again.
Display readout:
If you have the unit on, and
an input is selected, but the
volume is turned to 0, the display will
show dn00 as a reminder. To prevent
this, simply press the volume up.
e.g. UP10.
During battery charging, “bAt 2” is
displayed.
• The battery is damaged and cannot
be charged anymore. Refer to
“Warranty information” section for
details of obtaining repair.
AUDIOVOX ELECTRONICS CORP. (the
Company) warrants to the original retail
purchaser of this product that should
this product or any part thereof, under
normal use and conditions, be proven
defective in material or workmanship
within 12 months from the date of
original purchase, such defect(s) will be
repaired or replaced with reconditioned
product (at the Company’s option)
without charge for parts and repair
labor.
To obtain repair or replacement
within the terms of this Warranty, the
product is to be delivered with proof
of warranty coverage (e.g. dated bill
of sale), specification of defect(s),
transportation prepaid, to the Company
at the address shown below.
This Warranty does not extend to the
elimination of externally generated
static or noise, to correction of
antenna problems, loss/interruptions of
broadcast or internet service, to costs
incurred for installation, removal or
reinstallation of product, to corruptions
caused by computer viruses, spyware or
other malware, to loss of media, files,
data or content, or to damage to tapes,
discs, removable memory devices or
cards, speakers, accessories, computers,
computer peripherals, other media
players, home networks or vehicle
electrical systems.
This Warranty does not apply to any
product or part thereof which, in the
opinion of the Company, has suffered
or been damaged through alteration,
improper installation, mishandling,
misuse, neglect, accident, or by removal
or defacement of the factory serial
number/bar code label(s). THE EXTENT
OF THE COMPANY’S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE
REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE
COMPANY’S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
This Warranty is in lieu of all other
express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED
TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH
OF ANY WARRANTY HEREUNDER
INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY MUST BE
BROUGHT WITHIN A PERIOD OF 24
MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR
Illustrations contained within this
publication are for representation only
and subject to change.
will be returned with factory
default settings, and without any
pre-loaded content which may have
been installed in the originally
purchased products. Consumer will
be responsible for reloading data
and content. Consumer will be
responsible to restore any personal
preference settings.
• Properly pack your unit. Include
any remotes, memory cards, cables,
etc. which were originally provided
with the product. However DO NOT
return any removable batteries,
even if batteries were included
with the original purchase. We
recommend using the original
carton and packing materials.
• Include evidence of purchase date
such as the bill of sale. Also print
your name and address and a
description of the defect. Send via
standard UPS or its equivalent to:
Audiovox Electronics Corp.
Attn: Service Department.
150 Marcus Blvd.
Hauppauge N.Y. 11788
1-877-833-3491
• Insure your shipment for loss or
damage. Audiovox accepts no
liability in case of damage or loss en
route to Audiovox.
• Pay any charges billed to you by
the Exchange Center for service not
covered by the warranty.
• A new or refurbished unit will be
shipped to you freight prepaid.
What we will do:
Provide you with a new, or at our
option, a refurbished unit. The
exchange unit is under warranty for
the remainder of the original product’s
warranty period.
The descriptions and characteristics
given in this document are given as
a general indication and not as a
guarantee. In order to provide the
highest quality product possible,
we reserve the right to make any
improvement or modification without
prior notice.
For Canada Customers, please ship
to:
Audiovox Return Centre
c/o Genco
6685 Kennedy Road,
Unit#3, Door 16,
Mississuaga, Ontario
L5T 3A5
Visit http://store.audiovox.com to find the
best accessories for your products.
© 2010 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
Trademark(s) ® Registered
Printed in China
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
