Safety Information
EN
For UK Only
CONNECT THE MAIN LEAD INTO A MAINS
POWER SOCKET
POWER SUPPLY 230V. It must not be
connected to D.C. mains.
Note: The mains lead of the set is fitted with a
molded plug. If the mains socket are not
compatible or if for any reason the plug is
removed please follow the directions below. The
molded plug cannot be rewired and if removed
must be disposed of safely.
Safety Information
BLUE = NEUTRAL / BROWN = LIVE
If the colors of the wires in the mains lead of this
apparatus may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows:
BLUE wire to the terminal coded N (Neutral) or
colored black.
BROWN wire to the terminal coded L (Live) or
colored red.
DO NOT make any connection to
the terminal in the plug which is
marked by the letter E or by the
earth symbol or colored green or
green and yellow.
DO NOT under any circumstances plug the
severed plug into any mains socket as this could
result in electric shock.
A fused plug must be fitted
with a 3A fuse approved by
ASTA or BS1362 and fuse
covers must be always be
securely replaced. If you set
does not work, the fuse may
be blown.
Important: If the plug is removed, rewire the
new plug as follow:
The wires in the mains plug are colored in
accordance to the following code:
Main plug is used as the disconnect device,it shall remain operable and should not be obstructed during intended
used.To be completely disconnected the apparatus from supply mains,the main plug of the apparatus shall be
disconnected from the mains socket outlet completely.
CAUTION!
Invisible laser radiation when open. Avoid
exposure to beam. Class 1 laser product. This
system must be opened only by qualified
technicians to prevent accidents caused by the
laser beam.
LASER λ = 780 nm, P max = 5 mW
Rating Information: At bottom/rear of the unit.
This unit comply with the existing requirements
ADVARSEL!
USYNLIG LASERSTRÅLNING VED ÅBNING NAR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.
UNGDÅ UDSAETTELSE FOR STRÅLNING.
VORSICHT!
UNSICHTBARE LASERSTRALUNG
WENN ABDECKUNG GEÖFFNET UND SICHERHEITS–
VERRIEGELUNG ÜBERBRÜCKT.
NICHT DEM LASERSTRAHL AUSSETZEN!
CAUTION – INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS FAILED OR
DEFEATED. AVOID EXPOSURE TO BEAM.
ATTENTION – RAYONNEMENT LASER INVISIBLE
DANGEREUX EN CAS D'OUVERTURE ET LORSQUE
LA SECURITE EST NEUTRALISEE.
EXPOSITION DANGEREUSE AU FAISCEAU.
In accordance with the rating plate of
the unit, this unit complies with
current standards concerning electrical
safety and electromagnetic
compatibility.
Please respect the environment Before
throwing any batteries away, consult
your distributor who may be able to
take them back for specific recycling.
Have a Blast- Just Not in Your
Eardrums
Make sure you turn down the volume
on the unit before you put on
headphones. Increase the volume to
the desired level only after headphone
are in place.
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A LASER DE CLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPP ARAT
VARNING–
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD OCH SPÄRRAN ÄR URKOPPLADE.
BETRAKTA EJ STRÅLEN.
VARO!
AVATTAESSA JA SOUJALUKITUS OHITETTAESSA
OLET ALTTIINA NÄKYMÄTTÖMÄLLE.
LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WA R N I N G S I G N
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERS E RV I C E A B L E PA R T S I N S I D E . R E F E R S E RV I C I N G
TO QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING
SIGN
ALERTING YOU OF
I M P O R TA N T
INSTRUCTIONS
A C C O M PA N Y I N G
T H E P R O D U C T.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
WARNING: TO PREVENT FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
Portions based upon Microsoft Windows Media Technologies. Copyright © 1999 Microsoft
Corporation. All Rights Reserved. Microsoft, Windows Media, and the Windows Logo are trademarks
or registered trademarks of Microsoft Corporation in the United States and/or other countries.
The descriptions and characteristics given in this document are given as a general indication and not as a guarantee.
In order to provide the highest quality product possible, we reserve the right to make any improvement or
modification without prior notice. The English version serves as the final reference on all products and operational
details should any discrepancies arise in other languages.
EN
CS606_EN
6/12/06
2:08 PM
Page 6
Important Information
EN
Safety Precautions
• Never open the cabinet under any
circumstances. Any repairs or internal
adjustments should be made only by a trained
technician.
• Never operate this product with the cabinet
removed.
• Do not use your System immediately after
transporting it from a cold place to a warm
place, as condensation may cause the system
to malfunction.
• Keep your unit away from humid areas and
abnormally hot places.
• Do not touch the player with wet hands. If
any liquid enters the player cabinet, take the
player to a trained technician for inspection.
• This compact disc player uses a laser to read
the music on the disc. The laser mechanism
corresponds to the cartridge and stylus of a
record player. Although this product
incorporates a laser pick-up lens, it is
completely safe when operated according to
directions.
• Discs rotate at high speed inside the player.
Do not use damaged, warped, or cracked
discs.
• Do not touch the pick-up lens which is located
inside the disc compartment. To keep dust
from collecting on the pick-up lens, do not
leave the compartment door open for an
extended period of time. If the lens becomes
dirty, clean it with a soft brush, or use an air
blower brush designed for camera lenses.
• The apparatus shall not be exposed to
dripping or splashing and that no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
• Minimum distances around the apparatus for
sufficient ventilation .
• The ventilation should not be impeded by
covering the ventilation opening with items,
such as newspaper,table-cloths,curtains,etc.
• No naked flame sources,such as lighted
candles,should be placed on the apparatus.
• Attention should be drawn to the
environmental aspects of battery disposal .
Important Information
Important Battery Information
Please Respect the Environment!
• Remove the batteries to avoid leakage if you
do not use your remote control for more than
one month.
• Discard leaky batteries immediately as leaking
batteries may cause skin burns or other
personal injuries. Dispose of batteries in the
proper manner, according to provincial and
local regulations.
• Any battery may leak electrolyte under the
following circumstances:
- if mixed with a different battery type,
- if inserted incorrectly,
- if all batteries are not replaced at the same
time,
- if disposed of in fire, or
- if an attempt is made to charge a battery
not intended to be recharged.
Before throwing any batteries away, consult your
distributor who may be able to take them back
for specific recycling.
Headset Safety
• Do not play your headset at high volume.
Hearing experts warn against extended highvolume play.
• If you experience ringing in your ears, reduce
volume or discontinue use.
• You should use with extreme caution or
temporarily discontinue use in potentially
hazardous situations.
Even if your headset is an open-air designed
to let you to hear outside sounds, do not turn
up the volume so high that you are unable to
hear what is around you.
Caution While Driving
Use of headphones while operating an
automobile or moving vehicle is not
recommended and is unlawful in some states and
areas. Be careful and attentive on the road. Stop
operation of the unit if you find it disruptive or
distracting while driving.
Don’t Infringe
This product should only be used for the purposes
for which it is sold, that is, entertainment,
violating no copyright law. Any attempts to use
this product for which it is not intended is
unlawful and therefore not condoned by
Thomson.
This symbol means that your
inoperative electronic appliance must
be collected separately and not mixed
with the household waste. The
European Union has implemented a
specific collection and recycling
system for which manufacturers are responsible.
This appliance has been designed and
manufactured with high quality materials and
components that can be recycled and reused.
Electrical and electronic appliances are liable to
contain parts that are necessary in order for the
system to work properly but which can become a
health and environmental hazard if they are not
handled or disposed of in the proper way.
Consequently, please do not throw out your
inoperative appliance with the household waste.
If you are the owner of the appliance, you must
deposit it at the appropriate local collection point
or leave it with the vendor when buying a new
appliance.
• If you are a professional user, please follow your
supplier’s instructions.
• If the appliance is rented to you or left in your
care, please contact your service provider.
Help us protect the environment in which we
live!live in!
EN
CS606_EN
EN
6/12/06
2:08 PM
Page 8
Table of Contents
Table of Contents
Safety Information
CD and mp3 Disc Playback . . . . . . 11
Advanced Playback Controls . . . . .18
Loading Discs . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Play and Pause Discs . . . . . . . . . . . . . . . . . . . .12
Stop Playback . . . . . . . . . . . . . . . . . . . . . . . . . .12
Selecting a Disc . . . . . . . . . . . . . . . . . . . . . . . . .12
Searching Through a Disc . . . . . . . . . . . . . . . .12
Program Playback . . . . . . . . . . . . . . . . . . . . . . .12
Sampling Tracks . . . . . . . . . . . . . . . . . . . . . . . .18
Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Random Playback . . . . . . . . . . . . . . . . . . . . . . .18
Setting Up a Program List . . . . . . . . . . . . . . . .18
Renaming Tracks . . . . . . . . . . . . . . . . . . . . . . . .19
USB Playback . . . . . . . . . . . . . . . . .13
File Navigation . . . . . . . . . . . . . . . . . . . . . . . . .20
Tips on Playback Sequence of Disc . . . . . . . . .21
Important Information
Table of Contents . . . . . . . . . . . . . .1
Getting Started . . . . . . . . . . . . . . . 3
Content of Box . . . . . . . . . . . . . . . . . . . . . . . . . .3
Connections of Antennas and Speakers . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
General Controls . . . . . . . . . . . . . . . 5
Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . .6
Connecting USB device to the Main Unit . . .13
Selecting USB Mode . . . . . . . . . . . . . . . . . . . . .13
USB Playback Features . . . . . . . . . . . . . . . . . . .13
Memory Usage . . . . . . . . . . . . . . . . . . . . . . . . .13
Radio . . . . . . . . . . . . . . . . . . . . . . .14
Display . . . . . . . . . . . . . . . . . . . . . .8
Showing Demonstration . . . . . . . . . . . . . . . . . .8
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . .9
Program Recording . . . . . . . . . . . . . . . . . . . . . .9
Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Selecting Tuner Band . . . . . . . . . . . . . . . . . . . .14
Tuning to a Station . . . . . . . . . . . . . . . . . . . . . .14
Using Presets . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Auto Preset Programming . . . . . . . . . . . . . . . .14
Manually Setting Presets . . . . . . . . . . . . . . . . .14
Suppressing Stereo Signal . . . . . . . . . . . . . . . .14
Tuning to an RDS Station . . . . . . . . . . . . . . . . .15
Searching by Program Type (PTY) . . . . . . . . . .15
Sound Features . . . . . . . . . . . . . . .10
Recording to USB device . . . . . . . .16
Volume Control . . . . . . . . . . . . . . . . . . . . . . . . 10
Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Muting Audio . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using Preset Equalizer Curves . . . . . . . . . . . . .10
Recording CD to USB device . . . . . . . . . . . . . .16
Recording Turner/AUX to USB device . . . . . .17
Deleting Files from USB device . . . . . . . . . . . .17
Deleting All Files . . . . . . . . . . . . . . . . . . . . . . . .17
Settings . . . . . . . . . . . . . . . . . . . . . . 8
1
EN
Advanced Navigation Controls . . .20
Troubleshooting Tips . . . . . . . . . . .22
Maintenance . . . . . . . . . . . . . . . . .23
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Handling CDs . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CD Lens Care . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Technical Specification . . . . . . . . . . . . . . . . . . .23
2
CS606_EN
EN
6/12/06
2:08 PM
Page 10
Getting Started
Getting Started
Content of Box
Using the FM and MW Antennas
Installation
Before you use your audio system, you’ll want to
make sure both the FM and MW antennas are
positioned properly. Uncoil the FM antenna at
the back of the unit, making sure it is fully
extended (you may even want to tape it to the
wall behind the unit if possible. The higher the
better.) You’ll also need to connect the MW
antenna loop to the back of the unit if you listen
to MW stations. Rotate the MW loop antenna for
better reception.
To ensure sufficient ventilation, keep the spacings
shown below free from other surfaces:
•
•
•
•
•
one main unit (with 2 main speakers);
one remote control;
one MW loop antenna;
one user’s guide;
Guarantee card
Connections of Antennas and
Speakers
3
!
1
Warning:
Use of this product is for your personal use
only. Unauthorized recording or duplication
of copyrighted material may infringe upon the
rights of third parties and may be contrary to
copyright laws.
EN
10cm
10cm Front View 10cm
Connecting the Speakers
4
2
Each speaker has a black (negative) and a red
(positive) jack. When connecting the speakers,
match the red wires to the red jacks and the
black wires to the black jacks.
10cm
5cm
Speaker Wire Connection
Note:
Make sure the tracks are encoded in mp3 or
Windows Media formats and supported
bitrates. Bitrates supported by the player:
mp3 – 32 to 320kbps
1. FM Antenna.
2. Main Speaker Jacks.
3. MW Loop antenna Jacks.
4. AUX IN
Side View
Push Speaker terminal tab
down to insert wire.
Release tab to lock wire in
the terminal.
NOTE: Make sure the insulation is completely removed from the
ends of the speaker wires at all connection points.
wma – 48 to 160kbps
3
4
CS606_EN
6/12/06
2:08 PM
Page 12
General Controls
Main Unit - Front View
EN
ON/ECO - Press and hold in standby mode to
enter ECO (power saving, without clock display)
mode. Press briefly to turn on and off the unit.
Tips:
In STANDBY mode, press ON/ECO to
turn the system on in the previously used
mode. Press SOURCE to select the
corresponding mode. Look at the display icons
to identify the current mode.
SOURCE - selects among CD player, USB, tuner
and AUX.
DISC 1 / DISC 2 / DISC 3 / DISC 4 / DISC 5 direct access to the corresponding disc tray for
playback.
(PLAY/PAUSE)- starts and pauses playback
for CD and USB.
5
- stops CD and USB operations.
In Recording mode - stops recording;
In Tuner mode - selects tune or preset mode;
(OPEN/CLOSE)- Opens or closes the disc tray.
(SKIP BACKWARD) - In CD mode - goes to
the previous CD track and setting options;
searches backward through CD/file;
In USB mode - skips to the previous file;
In Tuner mode - tunes down radio frequency.
(SKIP FORWARD) - In CD mode - goes to
the next CD track and setting options; searches
forward through CD/file;
In USB mode - skips to the next file;
In Tuner mode - tunes up radio frequency.
INFO/BAND - In CD mode - selects display options
to show track elapse time, track remain time or
disc remain time. During recording, selects display
options to show record time and remaining time.
In mp3 / WMA mode - shows ID3 tag.
In USB mode - shows memory usage.
In Tuner mode - selects radio band.
VOLUME CONTROL - adjusts volume (except in
navigation mode).
In mp3 / WMA / USB navigation mode - rotate
clockwise to navigate downwards and rotate
counter-clockwise to navigate upwards.
SELECT - In mp3 / WMA / USB stop mode - enters
navigation mode.
In navigation mode - navigates forward.
BACK - In navigation mode - navigates
backwards.
RECORD - starts and stops recording to USB
device.
DELETE - removes track from the Program mode.
In USB mode - deletes file from the connected
mp3 player.
General Controls
Remote Control
Main Unit - Top View
EN
PHONES
DEMO
PHONES - Jack for connecting headphones.
DEMO - Activates and deactivates demonstration.
- USB Connector for connecting Mass
Storage Class USB device (e.g. mp3 player).
ON/ECO - turns power on or off (STANDBY
mode).
SOURCE - selects among CD player, tuner, USB
and AUX.
BAND - In Tuner mode - selects radio band.
FM ST - Selects between stereo and mono sound
in FM tuner mode.
INFO - In CD mode - selects display options to
show track elapse time, track remain time or disc
remain time.
In mp3 / WMA mode - shows ID3 tag.
In USB mode - shows memory usage.
OPEN/CLOSE - opens and closes disc
compartment.
B. BOOST - turns on or off Bass Boost.
6
CS606_EN
6/12/06
2:08 PM
Page 14
General Controls
EQ - selects equalizer presets.
(MUTE) - mutes audio output.
VOL
or
- decreases or increases volume
level.
(PLAY/PAUSE) - In CD / USB mode - starts
and pauses playback.
(SKIP BACKWARD) - In clock and timer
setting mode - goes to the previous setting
option.
In CD / USB mode - Goes to the previous track;
searches backward through CD;
In Preset Programming mode - selects channel
number;
In Tuner mode - tunes down radio frequency.
(SKIP FORWARD) - In clock and timer
setting mode - goes to the next setting option.
In CD / USB mode - goes to the next track;
searches forward through CD;
In Preset Programming mode - selects channel
number;
In Tuner mode - tunes up radio frequency.
RECORD - starts and stops recording to USB
device.
- In CD / USB mode - stops playback.
In Recording mode - stops recording.
DISC SKIP - skips to the next disc in CD mode.
PROG - In CD / USB and Tuner mode - enters
program mode.
INTRO/CT - In CD / USB mode - turns intro mode
on or off to play the first 10 seconds of each track
/ file.
In RADIO mode - shows RDS time.
CLOCK - displays clock time. Press and hold to
enter clock setting mode.
ADD - In CD / USB mode - adds track / file to the
Program List.
/PTY - In CD / USB mode - turns on/off random
playback.
In RADIO mode - Selects search by program type
in tune mode.
TIMER - enters timer setting mode. Activates and
deactivates timer.
DEL - In CD / USB navigation mode - removes
track / file from the Program List.
In USB mode - removes file from the connected
mp3 player.
REPEAT/RDS - In CD mode - repeats a track, CD
or all CDs.
EN
7
Display
In RADIO mode - displays RDS information.
In USB mode - Selects repeat one file, repeat all
files mode.
SLEEP - selects the time interval in minutes
before the unit turns off.
(UP) - In navigation mode - navigates
upwards and move up a list.
In tuner mode - selects the next preset number.
(DOWN) - In navigation mode - navigates
downwards and move down a list.
In tuner mode - selects the previous preset
number.
(LEFT/BACK) - In navigation mode - navigates
backwards.
(RIGHT /ENTER) - In navigation mode navigates forward.
Installing Batteries
The remote control must be inserted with 2
"AAA" or "UM-4" or "R03" batteries prior to use.
Follow the steps below to ensure correct
installation.
1. Open the battery compartment door by
pressing down on the tab and then lifting the
door out.
2. Insert “AAA”(UM4) batteries in the
compartment.
3. Replace the battery compartment door in
place.
CD / TUNER / USB / AUX - indicates the current
mode.
- Random playback is activated in CD mode.
ROCK / POP / JAZZ / CLASSIC / CUSTOM current equalizer setting.
INTRO - In CD mode, intro is activated so the first
10 seconds of each track will be played.
REPEAT 1 / REPEAT 1 DISC / REPEAT ALL DISC /
ALL DISC - In CD mode, indicates the repeat
option that is activated.
REPEAT 1 - repeats current track.
REPEAT 1 DISC - repeats current disc.
REPEAT ALL DISC - repeats all discs.
ALL DISC - plays all discs once.
MP3 / WMA - current CD format.
- currently in playback mode.
II - currently in pause mode.
STEREO - In FM tuner mode, indicates stereo
sound is selected.
RECORD - recording is activated.
RDS - RDS signal received.
BASS BOOST - bass boost is activated.
PROGRAM - in program mode.
- timer is activated.
SLEEP - sleep is activated.
- the corresponding disc icon lights to
1
2
show which disc compartment is
3
4
5
loaded. The current playing disc will
flash.
- the item is a music file.
- the item is a folder.
EN
Settings
Showing Demonstration
Press DEMO to turn on/off demonstration mode.
The demonstration scrolls through all display
operations.
Note:
When system is ON, you can press CLOCK to
display the current time for about 2 seconds.
Setting the Clock
1. Press and hold CLOCK on the remote control
until the hour flashes on the display.
2. Press
or
to set the hour and then
press CLOCK to shift to minute digits.
3. Press
or
to set the minute.
4. Press CLOCK to save settings and to quit
setting.
8
CS606_EN
6/12/06
2:08 PM
Page 16
Settings
Settings
Setting the Timer
EN
You can turn on/off the unit or record TUNER at
preset times by setting the timer.
6. Press TIMER to set volume. Adjust VOLUME
CONTROL to select desired volume level.
Timer
Volume
10
1. Press and hold TIMER on the remote control
until Timer On and the clock hour flashes on
the display.
View Remaining Sleep Time
You can select the time interval in minutes before
the unit turns off automatically.
Press SLEEP to select among OFF, 120, 90, 60, 45,
30, 15 and 5 minutes.
The SLEEP icon lights on the display when sleep
timer is activated.
Adjust Sleep Time
7. Press TIMER to save settings.
Press
to quit setting.
The timer is automatically activated once
timer setting is saved
Timer
On 00:00A
2. For setting time, press
or
to set the
hour and then press TIMER to shift to minute
digits.
3. Press
or
to set the minute.
4. Press TIMER to change to Timer Off setting
with clock time flashing. Repeat steps 2 & 3
for timer off time setting.
Activating the Timer
Use Program Recording to preset the unit to
record your favorite radio program.
Choose TUNER REC as the source to record radio
at the preset time. Make sure the mp3 player is
connected and have enough memory space.
Timer
Source
Tuner
or
to
Press SLEEP again when the remaining sleep time
is displayed to change sleep time.
Note:
Sleep is automatically de-activated
when the unit is turned off.
“TUNER REC” settings are for Program
Recording. For more information, see
paragraph below.
Program Recording
5. Press TIMER to select source. Press
or
to select TUNER / TUNER REC / DISC / USB.
EN
When sleep is activated, press SLEEP once to
view remaining sleep time.
Tips:
Press and release TIMER to turn on/off the alarm.
The timer icon
is displayed when timer is
activated.
Timer
On 00:00A
Off 00:00P
If TUNER REC is selected, press
select the preset station.
Sleep Timer
Sound Features
Volume Control
Using Preset Equalizer Curves
Rotate the volume control on the main unit or
press VOL
or
on the remote control to
adjust volume level. The volume level shows
briefly on the display.
Press EQ to toggle among FLAT, ROCK, POP, JAZZ,
CLASSIC and CUSTOM. The display shows your
selection briefly and the relative icon lights on
the display.
Bass Boost
Creating a Custom Curve
Press B.BOOST to turn on/off boosting the bass
frequency. The BASS BOOST icon lights on the
display when it is activated.
1. Press EQ to select CUSTOM mode.
2. While CUSTOM is displayed, press
or
to cycle among displayed bass and treble
range levels.
3. While BAS and TRE is displayed, adjust volume
control to set the associated gain between
-10 - +10.
4. Press EQ to exit.
Muting Audio
Press
on the remote to cut the sound
(Remote Only). MUTE flashes on the display.
Custom
BAS +02
TRE 00
9
10
CS606_EN
EN
6/12/06
2:08 PM
Page 18
CD and mp3 Disc Playback
CD and mp3 Disc Playback
Important CD and mp3/WMA
Information
Play and Pause Discs
CD-R / RW
This unit is compatible with
CD-RW/ CD-R discs for
playback.
Notes on CD-R/RW Disc:
• Do not affix any type of labels to either
side (recordable or labeled side) of a
CD-R/RW disc as this may result in the
unit malfunctioning.
• To avoid damages to the CD-R/RW disc, do
not open the disc compartment door while
the disc is being read.
• Do not load an unrecorded CD-R/RW disc
into the unit. This may take a longer time
to read the disc.
• Playback capability for CD-RW discs
may vary due to variations in the
quality of the CD-RW disc and the
recorder used to create the disc.
Loading Discs
1. Press SOURCE repeatedly to select CD mode.
2. Press OPEN/CLOSE
to open the disc
compartment.
3. Insert up to 5 discs with label face up.
4. Press OPEN/CLOSE
again to close the disc
compartment.
The occupied disc tray icons lights on the display
and the current disc icon flashes on the display.
If the disc is a mp3 / WMA CD, the respective MP3
and WMA icon lights on the display.
11
Notes on mp3/WMA Disc:
• Use .mp3 as the extension when converting
audio files into mp3 for saving onto
CD-R(W) or CD-ROM, e.g. Abc08.mp3.
Do not use any other extension e.g. .doc,
.pdf.
• Do not use the .mp3 extension for other
text or non-audio data files as this may
result in serious malfunction and harmful
noise interference.
• For better quality in mp3/WMA disc
playback, the CD quality should be
recorded 128kbps or above.
• Disc data size > 650MB is not
recommended.
• Total files and folders in the disc should
not exceed 250, it also depends on the
length of the file/folder names.
• For mixed mode discs, only one mode will
be selected for playback depending on the
recording format.
• To ensure good performance, wait until
the disc changer completely reads the disc
before proceeding.
• mp3 files in CD ROM EXTRA format disc
cannot be recognized.
Note:
Be sure to remove all discs from the
disc compartment before moving or
transporting the unit!
• To play all discs in the disc compartment,
- press
in stop mode to begin playback.
• To play a specific disc in the disc
compartment, - press DISC 1 - DISC 5 to
play the corresponding disc. During mp3 /
WMA playback, the display show ID3 tags
(Title, Artist and Album).
Audio CD
01 0:50
mp3 / WMA CD
0:00
File Nm
ID3 tag
• Press
during playback to pause disc. Press
again to resume.
• To play a specific track in the disc
Press
or
to select a track and then
press
to start playback.
Stop mode:
Audio CD
EN
mp3 / WMA CD
Audio CD
10 Tracks
74:30
MP3/WMA
300Tracks
Selecting a Disc
Press DISC 1, DISC 2, DISC 3, DISC 4 or DISC 5
on the main unit or DISC SKIP on the remote
control to skip discs.
Searching Through a CD
• Press
or
to skip to the previous or
next track.
• Press and hold
or
to search through a
CD while it is playing.
Program Playback
Refer to page 18 for details.
Play and load simultaneously by:
1. Press OPEN/CLOSE
to open the disc tray
while a CD is playing.
2. Load/change discs for available trays.
3. Press OPEN/CLOSE
again to close the tray.
Attention:
Do not push to force closing of the
tray during CD playback or tray
opening.
Stop Playback
During playback, press to stop playback.
The unit returns to navigation mode briefly
(approx. 10 seconds) before entering stop mode.
Navigation mode:
Audio CD
01 3:31
02 3:50
03 4:08
mp3 / WMA CD
ROOT
Folder 1
Folder 2
Tips:
In CD stop mode, press to enter navigation
mode and show disc menu.
In CD navigation mode, press
to stop mode.
or
to return
For advanced navigation controls, see p.2021.
12
CS606_EN
EN
6/12/06
2:08 PM
Page 20
USB Playback
Radio
Connecting USB device to the
Main Unit
Selecting Tuner Band
1. Uncover the USB connector on the top of the
unit.
2. Insert the USB plug of the USB device to the
USB connector.
Selecting USB Mode
Press SOURCE repeatedly to select USB mode.
Tips:
In stop mode, press
to enter navigation
mode and show disc menu.
In navigation mode, press
stop mode.
or
1. Press SOURCE to enter Tuner mode.
2. Press BAND to select between FM or MW
Radio band.
to return to
For advanced navigation controls, see p.2021.
Tips:
Your audio system has 32 preset stations.
USB Playback Features
Tuning to a Station
Start and Pause Playback
Press
hold
Press
to start and pause playback.
Stop Playback
Press
to stop playback operations.
The unit enters navigation mode for 10 seconds
before entering stop mode.
Stop Mode
Navigation Mode
MP3/WMA
10 Tracks
- ROOT
RECORD
Song 1
or
or
to select frequencies. Press and
to scan frequecies.
Memory Usage
Press BAND/INFO on the main unit or INFO on the
remote to view memory usage on the USB device.
Mem Usage
141M Used
115M Free
13
Auto Prog
87.50MHz
Manually Setting Presets
The tuner can be in either TUNE or PRESET mode.
• Press
to toggle TUNE and PRESET mode.
• Press
or
to access the previous or next
preset station.
1. Press
to enter TUNE mode.
2. Press
or
to access the desired
frequency.
3. Press the PROG button once and the most
recently accessed program location flashes on
the display.
Preset 01
87.50MHz
Tips: Under PRESET mode, press
or
can only access the preset
stations. Manually tuning is not accessible in
this mode.
EN
Press and hold the BAND button for 2 seconds to
scan stations in FM band. The stations will then
be stored as preset channels. A maximum of 32
stations can be stored. Beware of your preset
channels being erased accidentally because the
scanning and storing process is automatic upon
pressing the button. You can stop the automatic
scan by pressing any button, but the erased
stations cannot be recovered.
Using Presets
Skipping Files
• Press
or
to skip to the previous or
next file.
• Press and hold
or
to search through a
file while it is playing.
Auto Preset Programming
(FM only)
Preset 02
90.50MHz
4. If a different program location is preferred,
press
or
to move to the desired
preset number (1-32).
5. Press PROG to store the selected frequency at
that preset.
Suppressing Stereo Signal
Press FM ST to toggle between FM mono and
stereo mode. (Remote Only) “STEREO” is
displayed in stereo mode.
14
CS606_EN
6/12/06
2:08 PM
Page 22
Recording to USB Device
Radio
EN
Tuning to an RDS Station
Note:
RDS stations broadcast on FM only. When the
tuner detects an RDS signal, the RDS icons
turns on.
1. Press
or
to go to your desired
frequency.
2. If a RDS station found, RDS lights on display
with station name shown.
Displaying RDS Station Information
Press REPEAT/RDS on the remote control
repeatedly to display the following:
• frequency,
• station name (PS),
• station type (PTY),
• clock time (CT), or
• radio text (RT).
In CT mode, press the INTRO/CT key to replace
the displayed time with RDS station time.
Searching by Program Type (PTY)
(Remote Only)
1. Press
/ PTY to enter PTY selection
2. Press
/ PTY repeatedly to select a PTY
mode.
3. Within 5 seconds, press
or
to search
for a station broadcasting the selected type of
program.
15
You can search for stations using one of the
following program types:
• NEWS (news),
• AFFAIR ( news and documentaries),
• INFO (weather, medical),
• SPORT (sports),
• EDUCAT (education),
• DRAMA (series and plays),
• CULTUR (religion),
• SCIENC (science and technology),
• VARIED (miscellaneous),
• POP M (pop music),
• ROCK M (rock music),
• MOR M (middle-of-the road music),
• LIGHTM (light music),
• CLASS (classical music),
• OTHERM (unclassified music),
• WEATHE (weather, medical),
• FINANC (stock market reports),
• CHILD (children’s programs),
• SOCIAL (sociology, history, geography,
psychology, society),
• RELIGI (any aspect of beliefs, faith and God or
Gods),
• PHONE (public forum b phone),
• TRAVEL (feature and programs concerning
travelling),
• HOBBY (recreational activities and leisure),
• JAZZ (jazz music),
• COUNTR (country music),
• NATION (national music),
• OLDIES (oldies music),
• FOLK M (folk music),
• DOCUME (documentaries),
• TEST,
• ALARM (alarm).
You can record CD, Tuner or Aux to the USB
mode (eg. mp3 player).
Recording CD to USB Device
1. Connect the USB device to the USB port, “USB
Connected” will show on the display.
2. Press SOURCE to select CD mode.
3. Press RECORD to start recording.
4. Press RECORD on the main unit or to stop
recording.
EN
Tips:
If CD playback is already started, recording
will begin instanly when RECORD is pressed.
Tips:
Recording stops automatically when CD
stops (For example: end of disc is
reached).
Tips:
To view elapsed recording time and
remaining time, press BAND/INFO on
the main unit or INFO on the remote in
recording mode.
Elapsed
recording
time
0:22
146:14
Remaining
Time
16
CS606_EN
EN
6/12/06
2:08 PM
Page 24
Recording to USB device
Advanced Playback Controls
Recording Tuner/AUX to USB
Device
In CD / USB mode, advanced playback controls
allow you to sample, repeat, randomly playback
files and set up a Program List. In USB mode,
allow you to rename tracks.
In Tuner or AUX mode, press RECORD to start
recording. Press or RECORD to stop recording.
In Tuner mode
Recording
FM
90.50MHz
FM
90.50MHz
Deleting Files from USB Device
1. In navigation mode, select the file to delete
using the navigation buttons (Refer to
“Advanced Navigation Controls” on page 20
for details.)
Example:
1. In Tuner mode, select the station to record
(refer to page 14 for details).
2. Press RECORD to start recording.
3. Press or RECORD to stop recording.
Press INTRO on the remote control to play the
first 10 seconds of each track on the current disc,
all discs in the tray, or turn intro mode off.
INTRO is displayed when sampling is activated.
Song 1
Song 2
Song 3
RECORD
Sampling Tracks
2. Press DELETE on the main unit or DEL on the
remote control.
Delete 1
No
> Yes
Press REPEAT on the remote control to toggle
repeat options:
Repeat the current track (REPEAT 1),
Repeat current disc (REPEAT 1 DISC) ,
Repeat all discs (REPEAT ALL DISC), or
Normal playback (ALL DISC).
Note:
The encoding bitrate for tuner, CD
and AUX signal are as below:
CD / Aux : 128 kbps
Tuner : 96 kbps
3. Rotate the Volume button on the main unit or
press or
on the remote control to select
“Yes” to delete or “No” to cancel.
4. Press SELECT on the main unit or on the
remote control to confirm selection.
If Yes is selected, the display shows memory
usage information after deleting selected file
for a few seconds, then returns to navigation
menu.
Mem Usage
141M Used
115M Free
- Folder 2
Folder 2.1
Folder 2.2
Note:
You can create a program of up to 32 tracks.
Random Playback
Press
on the remote control to turn on/off
random playback. The SHUFFLE icon is displayed
when it is activated.
All the tracks on one disc will be shuffled and
played once before shuffling and playing tracks
from the next disc.
Tips:
Song 1
Song 3
EN
1. In navigation mode, press DISC SKIP to select
disc.
2. Use the navigation buttons to select the track
/ file to add to Program List.
2. Press ADD to save the selected track into the
next available program location.
3. Repeat steps 1 to 3 to store more tracks into
program memory.
Repeat
Program Recording
Use Program Recording to preset the unit to
record your favorite radio program. Refers to
”Program Recording” on page 9.
Setting Up a Program List
Random playback can be activated
simultaneously with repeat 1 disc (randomly
play tracks from one disc repeatedly) or
repeat all discs (randomly play tracks from
all discs repeatedly).
Tips:
mode.
In CD stop mode, press PROG to toggle
between program mode and normal
Note:
Each source mode has an individual My
Selection playlist.
Deleting All Files
In navigation mode, press and hold DELETE on
the main unit or DEL on the remote control to
delete all the files on the USB device.
17
18
CS606_EN
6/12/06
2:08 PM
Page 26
Advanced Playback Controls
EN
Playing a Program List
Renaming Tracks
While in PROGRAM stop mode , press
.
If you are not currently in program mode, press
PROG to enter program mode. Program playback
begins automatically.
You can rename tracks in USB device or mp3
player.
Display Program List
1. While the CD player is stopped, press
PROG to enter PROGRAM mode. Program
playback begins automatically after entering
program mode.
To display program list, press
.
PROG 30
2. Press
/
repeatedly to view each track
assignment in the program list.
Deleting from Program List
1. While in PROGRAM mode, press or
to
select the program to delete.
2. Press DEL.
3. Press
or
to select between No and Yes.
4. Press
to confirm selection.
Deleting the Entire Program List
1. While in PROGRAM mode, press
select the program to delete.
2. Press and hold DEL.
19
or
to
1. In USB navigation mode, press PROG on the
remote control to enter rename mode.
2. Press
or
to select alphabets.
3. Press SELECT to confirm the current alphabet
and move to the next alphabet.
4. Press PROG to confirm and store the new file
name after editing the last alphabet.
5. Press BACK to edit the previous alphabet.
6. Press DELETE to delete the alphabet.
Advanced Navigation Controls
File Navigation
Remote Control
EN
Main Unit
SELECT - enters navigation mode from mp3 /
WMA / USB stop mode.
Enters selected folder in navigation mode.
Begins playback of the selected file in navigation
mode.
BACK - goes back up one level in navigation
mode; returns to stop mode from navigation
mode when at root level.
DELETE - In mp3 / WMA / USB navigation mode removes the selected file from the Program List.
In USB mode - deletes selected file.
Volume Control - rotate clockwise to navigate
downwards.
Rotate counter-clockwise to navigate upwards.
(LEFT / BACK)- navigates backwards.
Returns to the previous navigation menu level.
Returns to stop mode from navigation mode.
(RIGHT / ENTER) - navigates forward.
Enters navigation mode from mp3 / WMA / USB
stop mode.
Enters current folder and shows the first
file/folder from current folder.
(UP) - navigates upwards.
Enters navigation mode from mp3 / WMA / USB
stop mode.
Selects previous file/folder on the navigation
menu.
(DOWN) - navigates downwards.
Enters navigation mode from mp3 / WMA / USB
stop mode.
Selects next file/folder from the navigation menu.
ADD - In mp3 / WMA / USB navigation mode adds the selected file into the Program List.
DEL - In mp3 / WMA / USB navigation mode removes the selected file from the Program List
when reviewing program.
In USB mode - removes file from the connected
mp3 player.
20
CS606_EN
6/12/06
2:08 PM
Page 28
Advanced Navigation Controls
EN
Tips on Playback Sequence of Disc
• Check that the mp3/WMA disc is created with a single folder structure. Refer to the
diagram below for playback sequence details on multi-level folder structure.
• For example, folders and songs from level 2 are played before moving on to play folders
and songs from level 3.
LEVEL 1
A
LEVEL 2
LEVEL 3
LEVEL 4
Troubleshooting Tips
Problem Solution
Problem
Solution
System will • Check power cord for a secure
not turn
connection.
on
• Unplug the unit for a moment,
and then plug into power
source again.
• Check the outlet by plugging in
another device.
CD sound
skips
• Clean the disc.
• Check disc for warping,
scratches, or other damage.
• Check if something is causing
the system to vibrate. If so,
move the system.
• Make sure the speakers are
at least 3 feet away or on a
different surface from the
main unit.
CD button
will not
respond, or
does not
change
discs when
you press
DISC SKIP
• Switch to another function
(Tuner) and then back to CD.
Remote
control
does not
work
• Check that the batteries are
properly installed.
• Replace weak batteries.
• Check the system is plugged
into power source.
• Point the remote directly at
the system’s front panel.
• Move closer to the system.
• Remove any obstacles
between the remote and the
system.
D
10
E
No sound
8 Song 1.1.1
9 Song 1.1.2
Folder 1.1
Folder 1
Song 1.1.3
G
Folder 1.2
Folder 1.2.1
13
14
15
B
Song 1.2.1.1
Song 1.2.1.2
Song 1.2.1.3
• Increase the volume setting.
• Check connection to speakers.
• Check that you have selected
the appropriate function: CD,
Tuner.
• Make sure mute is off.
• Make sure headphones are not
plugged in.
F
Folder 2
Folder 2.1
11
12
Song 2.1.1
Song 2.1.2
Poor radio
reception
• Check antenna connection.
• Move antenna.
• Turn off nearby electrical
appliances, such as hair dryer,
vacuum cleaner, microwave,
fluorescent lights.
CD does
not play
• Check that CD is in the tray.
• Check that CD label is facing
up.
• Check that PAUSE mode is not
on.
• Check that CD function is
selected.
• Use CD lens cleaner.
• Clean the disc.
• Try another CD.
3 Song 2.2
4 Song 2.3
5 Song 2.4
C
Folder 3
6 Song 3.1
7 Song 3.2
1 Song 4
2 Song 5
EN
Note:
• Folder playback sequence is indicated by the letters A to G.
• Song playback sequence is indicated by the numbers (1 to 15) in front of the song name.
21
22
CS606_EN
6/12/06
2:08 PM
Page 30
Maintenance
EN
Disconnect the audio system from the power
source before performing any maintenance.
Cleaning
Clean the exterior of the system using a soft dust
cloth.
CD Lens Care
When your CD lens gets dirty it can also cause the
system to output poor sound quality. To clean the
lens you will need to purchase a CD lens cleaner
which can maintain the output sound quality of
your system. For instructions on cleaning the CD
lens, refer to the ones accompanying the lens
cleaner.
CD Player
CAUTION! This system operates with a laser. It
must be opened by only a qualified technician.
Handling CDs
• Do not touch the signal surfaces. Hold CDs by
the edges, or by one edge and the hole.
• Do not affix labels or adhesive tapes to the
label surfaces.
• Do not scratch or damage the label.
CDs rotate at high speeds inside the player.
• Do not use damaged (cracked or warped) CDs
Cleaning CDs
• Dirty CDs can cause poor sound quality.
Always keep CDs clean by wiping them gently
with a soft cloth from the inner edge toward
the outer perimeter.
• If a CD becomes dirty, wet a soft cloth in
water, wring it out well, wipe the dirt away
gently, and then remove any water drops with
a dry cloth.
• Do not use record cleaning sprays or antistatic
agents on CDs. Also, never clean CDs with
benzene, thinner, or other volatile solvents
which may cause damage to disc surface
23
Technical Specification
Power supply: 230V~50Hz
Dimensions ( H x W x D mm):
Unit size - 280 x 185 x 305
Speaker - 292 x 198 x 218
Unit Weight: 12.5 kg
CD player: Response curve (+/- 2dB): 60Hz to 5kHz
Rating Plate: Look for it at the back of the set.
Maximum size of Mass Storage Class device
supported: 20 GB
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
