About this document
Purpose
This document describes various deployment methods for HP Velocity on the server side. It
contains the following sections:
• Deployment configurations — Overview of HP Velocity and its different deployment
configurations
• Installations — Installation procedures for HP Velocity on the server side
• HP Velocity management — Tools to configure, manage, and troubleshoot HP Velocity
• Troubleshooting — Basic troubleshooting information
Intended audience
This document is intended for network and IT administrators who will be installing, configuring,
and managing HP Velocity.
Document styles and conventions
In this document, the following styles are used.
Style
Description
Start > Edit > Cut
Any elements on screen such as menus, or buttons use this format.
Select directory
screen
A screen or dialog box name uses this format.
myfile.txt
Filenames, and directory names use this format
Sample Product
Links to locations inside and outside this document use this format.
Example book
Links to external published documents, books, and articles use this
format.
HP Velocity Server Side Deployment Guide
5
About this document
Document styles and conventions
In this document, the following conventions are used
Convention
Description
<sample_name>
Replace the whole text including angle brackets with the expected value.
For example, replace <exec_filename> with example.exe when
entering this command.
{option1 |
option 2}
When entering the command, choose one of the options presented.
HP Velocity Server Side Deployment Guide
6
Deployment configurations
HP Velocity server side deployments vary based on the virtualization architecture.
This chapter includes the following sections:
• HP Velocity overview
• Deployments
• Deployment considerations
HP Velocity overview
HP Velocity is a Quality of Service (QoS) system that improves overall Quality of Experience
(QoE) for real-time network applications.
Streaming real-time applications over data networks will often suffer from packet loss and
transmission latency; this results in stop-and-go behavior, loss of interactivity, and an overall
reduction of an application's throughput. Ultimately, application users are likely to find
themselves dissatisfied with the experience.
HP Velocity easily integrates with existing systems to improve a streaming application's QoE
by addressing the underlying problems found in today's networks: packet loss, transmission
latency, and jitter.
Automatic discovery, session establishment, and session management are performed by HP
Velocity-enabled endpoints.
HP Velocity continuously monitors end-to-end network conditions to select the most
appropriate data delivery mechanism. Packet loss is automatically reduced and transmission
latency is minimized, thereby improving an application's QoE and throughput.
NOTE: HP Velocity only accelerates streams between HP thin clients and
HP Velocity-enabled virtual desktops or terminal services servers.
HP Velocity Server Side Deployment Guide
7
Deployment configurations
HP Velocity overview
Benefits of HP Velocity
Adaptive
HP Velocity continuously monitors end-to-end network conditions
network analysis for individual data streams, providing adaptive optimizations and
data stream acceleration.
Packet loss
protection
HP Velocity protects against packet loss, which is key to improving
an application's QoE. Even in small amounts, packet loss will
reduce application throughput, degrade or halt streaming
applications, and introduce lag for interactive applications.
Congestion
detection
HP Velocity automatically detects network congestion and adjusts
the amount of redundancy, thus maximizing QoE over data
networks.
WiFi acceleration HP Velocity automatically reduces latency and transmission times
for wireless networks and minimizes protocol overhead, resulting in
improved QoE for WiFi applications.
Seamless
integration
HP Velocity is a transparent, “plug and play” solution, which
provides QoE benefits to all applications and users.
Lightweight
HP Velocity is delivered as a lightweight implementation, which
achieves QoE benefits while keeping system resource utilization to
a minimum.
HP Velocity Server Side Deployment Guide
8
Deployment configurations
Deployments
Deployments
HP Velocity comes pre-installed on HP thin clients. Use the following table to determine where
to install HP Velocity on the server side.
Virtualization architecture
HP thin clients are directly connected to virtual
desktops or applications.
“Direct” on page 10
HP thin clients use a connection broker as a
proxy to access virtual desktops or applications.
“Proxied” on page 11
The virtualization environment supports both
direct and proxied connections to virtual
desktops and applications.
“Direct and proxied” on page 12
HP thin clients connect to a terminal services
server.
“Terminal services” on page 13
NOTE: HP Velocity server side components are currently supported on
Microsoft operating systems.
HP Velocity Server Side Deployment Guide
9
Deployment configurations
Deployments
Direct
Virtualization architectures that allow HP thin clients to connect directly to virtual desktops
must have HP Velocity server installed on the virtual desktop. In these deployments, a
connection broker does not act as a proxy.
In Figure 1, thin clients A and B are directly connecting to their respective virtual desktops A
and B as indicated by the color of the connecting dotted lines.
Figure 1. Sample direct deployment
Accelerated stream between thin client and virtual desktop
Client Side
Server side
Virtual
desktop Application
A
HP
Velocity
Client
HP
Velocity
Server
Unmanaged
Unmanag
network
Fir
Firewalls
s
Virtual
desktop Application
B
HP
Velocity
Server
Original
Client
IP packets application
Thin Client A
Routers
Client Side
HP
Velocity
Client
Original
Client
IP packets application
Thin Client B
HP Velocity Server Side Deployment Guide
10
Deployment configurations
Deployments
Proxied
Virtualization architectures that require HP thin clients to access virtual desktops via a proxy
service provided by a connection broker (such as VMware View Manager) must have HP
Velocity installed on the connection broker.
In Figure 2, thin clients A and B are connecting to their virtual desktops via the connection
broker. HP Velocity server is installed on the connection broker. This results in HP Velocityaccelerated streams between the thin clients and the connection broker.
Figure 2. Sample proxied deployment
Accelerated stream between thin client and connection broker
Server side
Virtual
desktop Application
A
Client Side
Connection
Broker
HP
Velocity
Server
Virtual
desktop Application
B
Unmanaged
network
ne
HP
Velocity
Client
Original
Client
IP packets application
Thin Client A
Firewalls
Routers
Client Side
HP
Velocity
Client
Original
Client
IP packets application
Thin Client B
HP Velocity Server Side Deployment Guide
11
Deployment configurations
Deployments
Direct and proxied
Virtualization architectures may allow direct and proxied access to virtual desktops. In such
deployments HP Velocity server must be installed on:
• Virtual desktops that are accessed directly
• Connection brokers that provide a proxy service to access the virtual desktop
In Figure 3 thin client A connects to virtual desktop A through the connection broker, and thin
client B connects to virtual desktop B directly.
Figure 3. Sample direct and proxied deployment
Accelerated stream between thin client and connection broker
Client Side
Server side
HP
Velocity
Client
Connection
Broker
Virtual
desktop Application
A
HP
Velocity
Server
Unmanaged
network
Firewalls
s
Virtual
desktop Application
B
Thin Client A
Routers
Client Side
HP
Velocity
Client
HP
Velocity
Server
Original
Client
IP packets application
Original
Client
IP packets application
Thin Client B
Accelerated stream between thin client and virtual desktop
HP Velocity Server Side Deployment Guide
12
Deployment configurations
Deployments
Terminal services
In a terminal services deployment, multiple HP thin clients are connecting to a terminal
services server such as a Windows Server.
In such deployments, HP Velocity must be installed on the terminal services server as shown
in Figure 4.
Figure 4. Sample terminal services deployment
Accelerated streams - Multiple thin clients to terminal services server
Virtual
desktop
Word
Applications
HP
Velocity
Server
Mail
Applications
Terminal services / virtual desktop server
HP Velocity Server Side Deployment Guide
HP
Velocity
Client
I
Internet
Firewalls
s
Routers
Original
IP packets
Client Side
Client
application
Thin client A
HP
Velocity
Client
Original
IP packets
Thin client B
Client
application
Client Side
13
Deployment configurations
Deployment considerations
Deployment considerations
Maximum number of protected streams
HP thin clients currently support up to 16 simultaneous accelerated streams.
HP Velocity installed on a virtual desktop currently supports up to 16 simultaneous accelerated
streams with one or more HP thin clients.
HP Velocity installed on a terminal services server currently supports up to 256 simultaneous
accelerated streams with one or more HP thin clients.
NOTE: HP Velocity server-to-server streams are only monitored, not
accelerated. Only streams between an HP Velocity enabled server and
an HP thin client are accelerated.
Aggregated statistics for some deployment models
Dependant on where HP Velocity is installed, the statistics counters in HP Velocity can be
used to track statistics on a system-wide view, since it tracks all streams terminated on the
endpoint. As shown in Figure 5, the HP Velocity server installed on the gateway provides an
aggregated view of the data streams of all the thin clients connecting to that gateway. For
more information on statistics, see “Statistics” on page 31.
Figure 5. Aggregated statistics
750.00 kB
Server side
Virtual Application
desktop
1600.00 kB
Data Sent
100.00 kB
Gateway
Virtual Application
desktop
HP
Velocity
Server
Virtual Application
desktop
HP Velocity Server Side Deployment Guide
Unmanaged
network
750.00 kB
HP
Velocity
Client
Thin Client A
HP
Velocity
Client
Thin Client B
HP
Velocity
Client
Thin Client C
14
Installations
This section outlines the requirements of installing HP Velocity server and includes the
following sections:
• System requirements
• Server side installation
• Installing on Microsoft Hyper-V
System requirements
Before installing HP Velocity server, ensure the following resources are available. Note the
different requirements for server operating system (OS) and virtual desktop OS installations.
Requirement
Server OS
Virtual desktop OS
CPU
Any
Any
Memory
30 MB
3 MB
Disk space
10 MB
10 MB
OS
Windows Server 2003
Windows 7
Windows Server 2008
Windows Vista
Windows XP (SP3 and above)
OS variants
32-bit and 64-bit
Clients
HP thin client(s)
Server side installation
HP Velocity installs as a network driver on the following platforms:
• Virtual desktops
• Host OS of Microsoft Terminal Services
• Microsoft Hyper-V server
NOTE: HP Velocity uses an Internet Protocol (IP) ID of 0x880477FB and an
IP option of 0x420B in IP headers. Intrusion Detection Systems (IDS) and
firewall systems may require configuration to support HP Velocity-enabled
traffic. Failure to do so may result in these devices blocking HP Velocityenabled traffic. Consult the device manuals to configure these settings.
HP Velocity Server Side Deployment Guide
15
Installations
Server side installation
To install HP Velocity server:
1. Locate the correct HP Velocity server installation package for the server side operating system (see table below). Read the release notes and documentation for the version of HP
Velocity being installed.
Operating system
Windows XP
OS variants
Installation package
32-bit
HPVelocity_Server_32_R#.msi
64-bit
HPVelocity_Server_64_R#.msi
Windows 7
Windows Vista
Windows Server 2008
Windows Server 2003
Note that R# indicates the HP Velocity release number.
2. Log on to the system where HP Velocity server will be installed, using an account with
administrator privileges.
3. Select the appropriate installation package for the server side operating system and
architecture. Start the installer.
The Welcome to the HP Velocity Setup Wizard screen is displayed.
4. Select Next.
The License Agreement screen is displayed.
5. Read the end user license agreement:
•Select I Agree and select Next to continue.
•Select Cancel to end the installation.
The Select Installation Folder screen is displayed with the default location of
Files\LiveQoS\HP Velocity\.
C:\Program
6. Optionally select the location where HP Velocity will be installed, or accept the default
location.
7. Select Everyone (default) to install HP Velocity for all user accounts and administrators or
select Just me to install HP Velocity only for the current user account.
8. Select Next.
The Confirm Installation screen is displayed.
HP Velocity Server Side Deployment Guide
16
Installations
Server side installation
9. Select Next to confirm selections and start installing HP Velocity.
CAUTION: Depending on the version of Windows OS, a warning
message may be displayed about LiveQoS installing software. This
message is expected; allow the installation to proceed.
The Installation Complete screen is displayed when the installation is finished.
10. Select Close.
11. When prompted, restart the system.
NOTE: During installation, HP Velocity will reset the system’s network
interfaces, briefly interrupting network connections. If a remote services
connection is being used to install HP Velocity, the connection will be reset.
After restarting the system, the HP Velocity System Tray Application automatically launches.
However, it may also be launched from the Windows Start menu via the HP Velocity folder.
HP Velocity Server Side Deployment Guide
17
Installations
Installing on Microsoft Hyper-V
Installing on Microsoft Hyper-V
Installing HP Velocity on Microsoft Hyper-V may require the following additional steps:
If HP Velocity is installed directly on Microsoft Hyper-V and there is a “Local Area Connection Virtual Network” entry as shown in Figure 6, ensure that the LiveQoS NDIS 6 Filter Driver is
disabled for the physical network adapter, as shown in Figure 7.
Figure 6. Microsoft Hyper-V network connections
Figure 7. Disabled NDIS 6 filter driver
HP thin client installation
HP Velocity comes pre-installed on select HP thin client images since March 2012. If a reinstall
is required, the HP thin client should be re-imaged. For more information, visit http://
www.hp.com/support.
HP Velocity Server Side Deployment Guide
18
HP Velocity management
This section includes:
• Starting the HP Velocity System Tray Application
• Identifying and setting HP Velocity operational modes
• HP Velocity management
Starting the HP Velocity System Tray Application
The HP Velocity System Tray Application automatically launches on system startup. However,
it may also be launched by performing the following steps:
To start the HP Velocity System Tray Application:
1. Go to the Windows Start menu.
2. Go to HP Velocity > HP Velocity Tray Application.
3. Select HP Velocity System Tray Application as shown in Figure 8.
Figure 8. Windows Start Menu showing the HP Velocity System Tray application
HP Velocity Server Side Deployment Guide
19
HP Velocity management
Identifying and setting HP Velocity operational modes
When HP Velocity is running on an HP thin client, virtual desktop, or a terminal server, an icon
appears in the Windows System Tray, as shown in Figure 9. The icon color will change based
on the current operational mode of HP Velocity.
Figure 9. Windows System Tray with the HP Velocity icon
Identifying and setting HP Velocity operational modes
The HP Velocity System Tray Application icon is displayed in one of four colors that
correspond to different HP Velocity operational modes.
The following table describes the icon colors, operational modes, and their behaviors.
Icon
Color
Mode
Description
Green
Active
HP Velocity is actively accelerating one or more
streams.
Blue
Active
HP Velocity is active but no accelerated streams
have been established.
Orange Monitoring
HP Velocity is profiling present and trending network
conditions. In this mode HP Velocity does not
accelerate streams.
Gray
HP Velocity is disabled.
Disabled
NOTE: In the case of server-to-server connections, HP Velocity will
display the green icon but will only be monitoring the active streams.
Setting the HP Velocity mode of operation
Once the HP Velocity System Tray Application is running, select the desired HP Velocity mode
of operation using the slider, as shown in Figure 10 below.
HP Velocity Server Side Deployment Guide
20
HP Velocity management
Identifying and setting HP Velocity operational modes
An administrator should only change the HP Velocity mode of operation:
• During troubleshooting to disable HP Velocity
• After troubleshooting to re-enable HP Velocity
• As directed by HP support
To set the HP Velocity System Tray Application operational mode:
1. Select the icon in the Windows System Tray.
2. In the resulting dialog box, select the slider control shown in Figure 10.
3. Move the slider control to the new mode.
Figure 10. HP Velocity operational mode slider
NOTE: To change the HP Velocity mode of operation, administrator
privileges are required.
Displaying accelerated or monitored stream count
Position the cursor over the HP Velocity icon to display a tool tip with the number of active
connections.
HP Velocity Server Side Deployment Guide
21
HP Velocity management
HP Velocity management
Displaying HP Velocity server information
To verify that HP Velocity is a server installation and obtain the release number:
1. Right-click the HP Velocity System Tray icon.
2. Select About.
3. Confirm the word Server is displayed as shown in Figure 11.
4. Optionally record the release number, the four digit number following the “r”. In Figure 11
this is r6005, or release 6005.
NOTE: This is the HP Velocity release number. It is not the HP thin client
image release number.
Figure 11. Confirming the HP Velocity server and release number
HP Velocity management
HP Velocity is installed with pre-configured settings that require no changes in most
deployments. To make changes to the configuration of HP Velocity, use the following:
• HP Velocity Group Policy objects
• HP Velocity Management application
HP Velocity Group Policy objects
This section describes how to change HP Velocity default settings using Group Policies.
NOTE: Group Policy objects are available for all HP Velocity server
installs. See “To verify that HP Velocity is a server installation and obtain
the release number:” on page 22.
HP Velocity Server Side Deployment Guide
22
HP Velocity management
HP Velocity Group Policy objects
This section includes:
•
•
•
•
Policy Engine
Adding the HP Velocity Administrative Template to a GPO
Updating HP Velocity configuration using the Group Policy Editor
Registry keys used in HP Velocity configuration
Policy Engine
The HP Velocity Policy Engine makes use of Microsoft Group Policy.
Microsoft Group Policy
Microsoft Group Policy provides the centralized management and configuration of operating
systems, applications, and users' settings in a Windows Active Directory environment. The
Group Policy (GP) and the Active Directory (AD) infrastructures in Windows Server enable IT
administrators to automate one-to-many management of users, HP thin clients, and servers.
The Group Policy settings are contained in a Group Policy object (GPO).
To create a GPO, use the Group Policy Management Console (GPMC), which is available for
download from the Microsoft download center website.
The GPO can be used to centrally manage and propagate new settings for HP Velocity over
an entire Windows AD domain.
To configure the GPO with HP Velocity options, the HP Velocity Administrative Template must
be applied to the GPO. The HP Velocity Administrative Template
(hpvelocity_configuration-R#.adm) adds a set of options to the GPO and specifies
which registry keys will be set for each option. For more information on the HP Velocity registry
keys, see “Registry keys used in HP Velocity configuration” on page 26.
Adding the HP Velocity Administrative Template to a GPO
Choose the group policy editor based on which GPO will be edited. For local group policy
administration, use gpedit.msc. For domain group policy administration, use gpmc.msc and
select the GPO that applies. Figure 12 shows some of the steps in the following procedure.
To add the HP Velocity Group Policy administrative template to a GPO:
1. Open the appropriate group policy editor.
HP Velocity Server Side Deployment Guide
23
HP Velocity management
HP Velocity Group Policy objects
Figure 12. Adding an administrative template
2. Expand Computer Configuration.
3. Expand Policies.
4. Right-click Administrative Templates.
5. Select Add/Remove Templates....
6. Select Add....
7. Browse for hpvelocity_configuration_R#.adm. R# is the release number of the
template that matches the release number of the HP Velocity install.
8. Select Close.
The HP Velocity Group Policy Administrative Template has been applied to this GPO.
Updating HP Velocity configuration using the Group Policy Editor
Once the administrative template has been added to the group policy object, configuration
changes for HP Velocity can be made as required.
It is recommended to change the HP Velocity settings on all systems in an organizational unit
(OU). This ensures that all installations in the OU are using the same settings.
To change HP Velocity settings on all systems in an OU:
1. Open the group policy object in the Group Policy Management Editor.
2. Expand Computer Configuration > Policies.
3. Expand Administrative Templates > Classic Administrative Templates (ADM).
4. Select HP Velocity.
5. Double-click Configuration.
6. Select Enabled.
HP Velocity Server Side Deployment Guide
24
HP Velocity management
HP Velocity Group Policy objects
The dialog box, as shown in Figure 13, will be displayed.
Figure 13. HP Velocity group policy configuration
NOTE: Policy Engine configuration changes will be applied immediately
to HP Velocity endpoints that have the HP Velocity Management
application running. If the management application is not running, the
Policy Engine changes will be applied to that endpoint after a system
reboot.
HP Velocity Server Side Deployment Guide
25
HP Velocity management
HP Velocity Group Policy objects
Registry keys used in HP Velocity configuration
The following are a list of registry keys used by the HP Velocity administrative template in the
configuration of HP Velocity. Each registry key relates to a parameter that can be viewed using the HP
Velocity Management application. For more information on these parameters, see “Configuration” on
page 39.
The keys can be grouped into the following categories:
• General keys
• General filter keys
• Target loss rate (TLR) filter keys
General keys
Registry key
Parameter
Software\Policies\IPQ\CurrentVersion\Protection
Protection configuration
Software\Policies\IPQ\CurrentVersion\LinkProfiler
Link Profiler configuration
(default is enabled)
Software\Policies\IPQ\CurrentVersionBandwidthControl
Bandwidth control configuration
(default is dynamic)
Software\Policies\IPQ\CurrentVersion\TargetLossRate
Target Loss Rate (TLR) configuration
(default is 0.04%)
Software\Policies\IPQ\CurrentVersion\WifiOptimizer
WiFi Optimizer configuration
(default is enabled)
Software\Policies\IPQ\CurrentVersion\TCPOptimizer
TCP Optimizer configuration
(default is disabled)
Software\Policies\IPQ\CurrentVersion\Logging
Logging configuration
Software\Policies\IPQ\CurrentVersion\BurstLossProtection
Burst Loss Protection (BLP) configuration
Software\Policies\IPQ\CurrentVersion\MaxBLPBuffer
Max BLP Buffer configuration
Software\Policies\IPQ\CurrentVersion\MTU
Network Maximum Transmission Unit
(MTU) configuration
HP Velocity Server Side Deployment Guide
26
HP Velocity management
HP Velocity Group Policy objects
General filter keys
Registry key
Parameter
Software\Policies\IPQ\CurrentVersion\IPBlacklistFilters
Blacklist IP filter configuration
Software\Policies\IPQ\CurrentVersion\IPWhitelistFilters
Whitelist IP filter configuration
Software\Policies\IPQ\CurrentVersion\TCPTransparentFilters
Transparent TCP filter configuration
(default is 21 53 9100)
Software\Policies\IPQ\CurrentVersion\UDPTransparentFilters
Transparent UDP filter configuration
(default is 53 67 68 123 161 500 4500)
Software\Policies\IPQ\CurrentVersion\TCPSpecialFilters
Special TCP filter configuration
(default is 554 1720 5060 1723)
Software\Policies\IPQ\CurrentVersion\UDPSpecialFilters
Special UDP filter configuration
(default is 554 5060)
Software\Policies\IPQ\CurrentVersion\TCPWhiteFilters
Whitelist TCP port filter configuration
Software\Policies\IPQ\CurrentVersion\UDPWhiteFilters
Whitelist UDP port filter configuration
HP Velocity Server Side Deployment Guide
27
HP Velocity management
HP Velocity Group Policy objects
Target loss rate (TLR) filter keys
Registry key
Parameter
Software\Policies\IPQ\CurrentVersion\DefaultTLRIPFilters
Default level TLR IP filter configuration
Software\Policies\IPQ\CurrentVersion\DefaultTLRTCPFilters
Default level TLR filters, TCP
configuration
Software\Policies\IPQ\CurrentVersion\DefaultTLRUDPFilters
Default level TLR filters, UDP
configuration
Software\Policies\IPQ\CurrentVersion\HighTLRIPFilters
High level TLR IP filter configuration
Software\Policies\IPQ\CurrentVersion\HighTLRTCPFilters
High level TLR filters, UDP
configuration
Software\Policies\IPQ\CurrentVersion\HighTLRUDPFilters
High level TLR filters, TCP
configuration
Software\Policies\IPQ\CurrentVersion\LowTLRIPFilters
Low level TLR IP filters configuration
Software\Policies\IPQ\CurrentVersion\LowTLRIPFilters
Low level TLR filters, TCP
configuration
Software\Policies\IPQ\CurrentVersion\LowTLRUDPilters
Low level TLR filters, UDP
configuration
Software\Policies\IPQ\CurrentVersion\UltraLowTLRIPFilters
Ultra-low level TLR IP filters
configuration
Software\Policies\IPQ\CurrentVersion\UltraLowTLRTCPFilters
Ultra-low level TLR filters, TCP
configuration
Software\Policies\IPQ\CurrentVersion\UltraLowTLRUDPFilters
Ultra-low level TLR filters, UDP
configuration
HP Velocity Server Side Deployment Guide
28
HP Velocity management
HP Velocity Management application
HP Velocity Management application
The HP Velocity Management application is a Windows System Tray application that allows
administrators to configure and monitor HP Velocity.
This section includes:
•
•
•
•
•
•
•
Getting started
Accounts and privileges
Starting the Management Application
Statistics
Accelerated Streams
Network Monitor
Configuration
Getting started
The HP Velocity System Tray Application automatically launches on system startup. However,
it may also be launched by performing the following steps:
To start the HP Velocity System Tray Application:
1. Go to the Windows Start menu.
2. Go to HP Velocity > HP Velocity Tray Application.
3. Select HP Velocity System Tray Application.
NOTE: When the HP Velocity Management application starts, it refreshes
its configuration from the registry and applies the new settings to HP
Velocity.
HP Velocity Server Side Deployment Guide
29
HP Velocity management
HP Velocity Management application
Accounts and privileges
HP Velocity provides the following access based on user account privileges. Refer to the
tables below.
Administrator
Information
Read
Write
Export
Accelerated Stream information
X
Network Monitoring graphs
X
Statistics
X
X
X
Configuration values
X
X
X
Policy Filters configuration values
X
X
X
Read
Write
Export
Non-administrator
Information
Accelerated Stream information
X
Network Monitoring graphs
X
Statistics
X
X
Configuration values
X
X
Policy Filters configuration values
X
X
Starting the Management Application
To start the HP Velocity Management Application, right-click the HP Velocity system tray icon
and select Management. The management application will open, displaying the tabs shown in
Figure 14.
Figure 14. Management Application Tabs
HP Velocity Server Side Deployment Guide
30
HP Velocity management
HP Velocity Management application
The tabs displayed across the top of the application provide access to all the configuration and
monitoring functions of the management application. From left to right, these tabs are:
•
•
•
•
Statistics
Accelerated Streams
Network Monitor
Configuration
Statistics
This tab displays the raw statistics counters. These counters provide cumulative statistics for
HP Velocity accelerated streams.
There are standard and advanced displays for statistics. In each, there are columns for total
data since HP Velocity started and the data for the most recent 5 seconds, 1 minute, and 5
minutes.
Operations that can be performed on the statistics include:
• Logging the statistics history (up to a maximum of one week) to a file by selecting Log
History (logging must be enabled)
• Logging the current statistics to a file by selecting Log Snapshot
• Resetting the statistics by selecting Reset (administrators only)
Standard Statistics view
The Standard Statistics view displays the basic statistic counters.
As shown in Figure 15, the five columns displayed are the name of the statistic and four
interval columns — total, 5 second, 1 minute, and 5 minute. These four columns indicate the
statistic values for the specified interval. Total is the accumulated statistics since the system
was started.
HP Velocity Server Side Deployment Guide
31
HP Velocity management
HP Velocity Management application
Figure 15. Standard Statistics view
Statistic name
Description
Network Loss
The actual received packet loss rate measured by HP Velocity.
Corrected Loss
The received packet loss rate, after correction, by HP Velocity.
Encoded Data
Sent
The bytes of encoded data, in Kbps (for intervals) or MB/KB (for cumulative totals), sent by
HP Velocity to the remote HP Velocity-enabled endpoint(s).
Encoded Data
Received
The bytes of segment data, in Kbps (for intervals) or MB/KB (for cumulative totals), received
by HP Velocity from the remote HP Velocity-enabled endpoint(s).
Overage Sent
Monitored
The bytes of segment data, in Kbps (for intervals) or MB/KB (for cumulative totals), sent but
not accelerated due to resource constraints.
Overage
Received
Monitored
The bytes of segment data, in Kbps (for intervals) or MB/KB (for cumulative totals), received
but not accelerated due to resource constraints.
Total Active
Sessions
Number of currently active unique data streams detected by HP Velocity as an endpoint.
Accelerated
Streams
Number of currently active unique accelerated data streams detected by HP Velocity as an
endpoint.
System Uptime
Time since the last power cycle or reboot of the operating system. Units are HH:MM:SS.
Monitored For
Time since the management application was started. Units are HH:MM:SS.
HP Velocity Server Side Deployment Guide
32
HP Velocity management
HP Velocity Management application
Statistic name
Description
Advanced
Statistics
Select to display more in-depth statistics. See “Advanced Statistics view” on page 33.
Logging
Select the frequency with which statistics will be logged to the log file.
Log History is available only when Logging is enabled. See “Logging” on page 35.
Reset
Reset to clear statistics.
Logging History
Export the statistics log to a comma-separated (CSV) file.
Log History is available only when Logging is enabled. See “Logging” on page 35.
Log Snapshot
Save the current 5-second, 1-minute, and 5-minute interval statistics to a comma-separated
(CSV) file with the same column order as the statistics history file.
Advanced Statistics view
When viewing the Statistics tab, select Show Advanced Statistics to view more detailed
information, as shown in Figure 16.
To return to the Standard Statistics view, deselect Show Advanced Statistics.
Figure 16. Advanced Statistics view
Statistic name
Description
Packets Encoded
The number of IP packets that were encoded by HP Velocity into segments.
Segments Sent
The number of encoded segments sent by HP Velocity to the remote HP Velocity enabled
endpoint(s).
HP Velocity Server Side Deployment Guide
33
HP Velocity management
HP Velocity Management application
Statistic name
Description
Segments Received
The number of encoded segments received by HP Velocity from the remote HP Velocity
enabled endpoint(s).
Segments Lost
The number of HP Velocity encoded segments that were not received by HP Velocity due
to packet loss on the network.
Packets Decoded
The number of IP packets that HP Velocity successfully reconstructed from the received
encoded segments.
Packets Lost
The number of IP packets that HP Velocity was unable to reconstruct from the received
encoded segments due to excessive loss in the network.
Full Packets Lost
The number of IP packets that HP Velocity was unable to reconstruct because it did not
receive any of the encoded segments for the encoded packet. Note: Together with the
Packets Lost field, this counter is an indicator of burst loss.
Monitored Packets
Sent
The number of monitored (not accelerated, not encoded) IP packets sent by HP Velocity
due to resource constraints.
Monitored Packets
Received
The number of monitored IP packets received by HP Velocity due to resource constraints
on the peer HP Velocity-enabled device.
High Loss Events
The number of times that HP Velocity detected difficulty communicating with the remote
HP Velocity-enabled endpoints due to extremely high packet loss in the network.
Non-accelerated
Packets Sent
The number of non-accelerated IP packets sent.
Non-accelerated
Packets Received
The number of non-accelerated IP packets received.
Packet Flows
Monitored
The number of unique data flows detected by HP Velocity.
Accelerated Packet
Flows Monitored
The number of unique data flows protected by HP Velocity.
Accelerated
Requests Unfulfilled
The number of flows that would have been HP Velocity accelerated flows if not for
resource restrictions.
Packets Encoded
(Throughput)
The bytes of IP packet data, in Kbps (for intervals) or KB/MB (for cumulative totals),
received from the application(s) that was encoded into HP Velocity segments or
monitored by HP Velocity.
Packets Decoded
(Throughput)
The bytes of IP packet data, in Kbps (for intervals) or KB/MB (for cumulative totals),
received from the network that was successfully reconstructed or monitored by HP
Velocity.
Non-accelerated
Throughput (Tx)
The bytes of all transmitted non-accelerated IP packet data in Kbps (for intervals) or KB/
MB (for cumulative totals).
HP Velocity Server Side Deployment Guide
34
HP Velocity management
HP Velocity Management application
Statistic name
Description
Non-accelerated
Throughput (Rx)
The bytes of all received non-accelerated IP packet data in Kbps (for intervals) or KB/MB
(for cumulative totals).
Near-end
Congestion
The network congestion level detected by HP Velocity. This is displayed as a percentage.
Far-End Congestion
The network congestion level detected by the remote HP Velocity endpoints. This is
displayed as a percentage.
System Uptime
Time since the last power cycle or reboot of the operating system. Units are HH:MM:SS.
Monitored For
Time since the HP Velocity management application was started. Units are HH:MM:SS.
Advanced Statistics
Deselect to display basic statistics. See “Standard Statistics view” on page 31.
Logging
Export the statistics log to a comma-separated (CSV) file.
Log History is available only when Logging is enabled. See “Logging” on page 35.
Reset
Reset to clear statistics.
Log History
Export statistics log to a comma-separated (CSV) file.
Log History is available only when Logging is enabled. See “Logging” on page 35.
Log Snapshot
Save the current 5-second, 1-minute, and 5-minute interval statistics to a commaseparated (CSV) file with the same column order as the statistics history file.
Logging
With logging enabled, the management application can log statistics at an interval of five
minutes (by default), saving up a to a maximum of one week's worth of HP Velocity statistics to
the user's temporary files folder. The default logging interval is 5 minutes when enabled from
Group Policy, but can be set to 1 minute or 5 seconds from the statistics tab.
HP Velocity management application maintains statistics history for up to 7 days. The file
names of the log files will be in the following format:
hp_velocity_statistics_yymmdd.log.
Logfiles are created in the temporary folder for the current user. For example,
C:\Users\<username>\AppData\Local\Temp.
In order to avoid the circumstance where old log files are not deleted, the management
application automatically purges any files in the temporary files folder starting with
hp_velocity_statistics_ and ending in.log that are older than 7 days.
All logged statistics can be exported to a single comma separated value (CSV) file format. This
can be done by selecting Log History on the Statistics tab of the management application and
entering a local path and filename. The column order is outlined in the following table. The first
row of the exported file will contain the column names.
HP Velocity Server Side Deployment Guide
35
HP Velocity management
Col# Column information
HP Velocity Management application
Col# Column information
1 Timestamp
15 Non-accelerated Throughput (Rx)
2 Packets Encoded
16 Overage Sent Monitored
3 Segments Sent
17 Overage Received Monitored
4 Packets Decoded
18 High-loss Events
5 Packets Lost
19 Non-accelerated Packets Sent
6 Segments Received
20 Non-accelerated Packets Received
7 Segments Lost
21 Packet Flows Monitored
8 Monitored Packets Sent
22 Accelerated Packet Flows Monitored
9 Monitored Packets Received
23 Total Active Sessions
10 Encoded Data Received
24 Accelerated Streams
11 Encoded Data Sent
25 Far-end Congestion
12 Packets Encoded (Throughput)
26 Near-end Congestion
13 Packets Decoded (Throughput)
27 Full Packets Lost
14 Non-accelerated Throughput (Tx)
28 Accelerated Requests Unfulfilled
Additionally, by selecting Log Snapshot on the statistics tab, the user can save the current 5second, 1-minute, and 5-minute interval statistics to a comma-separated (CSV) file with the
same column order as the statistics history file. See “Standard Statistics view” on page 31.
NOTE: When Logging is enabled on the Statistics tab, it is only enabled
until the system is reset. After a reset, Logging will return to the Group
Policy setting if applied. Otherwise, it will return to the default setting of
disabled.
HP Velocity Server Side Deployment Guide
36
HP Velocity management
HP Velocity Management application
Accelerated Streams
The Accelerated Streams tab displays detailed information for each unique HP Velocity
accelerated stream.
Select Refresh in the lower-right corner to update the displayed information.
Figure 17. Accelerated Streams tab
Statistic name
Description
Destination IP
The destination IP address for the accelerated stream.
Destination Port
The destination TCP or UDP port number for the accelerated stream. If the port number is a
recognized protocol, the protocol name will be displayed as well.
Local IP
The local IP address for the accelerated stream.
Local Port
The local TCP or UDP port number for the accelerated stream. If the port number is a
recognized protocol, the protocol name will be displayed as well.
Protection Mode
Specifies whether the accelerated stream is active (protection enabled) or simply monitored.
The field will read Active for streams which are protected and Monitored for streams which
are monitored.
Protocol
The protocol (such as TCP or UDP) used by the accelerated stream.
TLR
The Target Loss Rate (TLR) applied to the accelerated stream as a percentage that HP
Velocity will attempt to achieve.
HP Velocity Server Side Deployment Guide
37
HP Velocity management
HP Velocity Management application
Network Monitor
This tab displays three network graphs — throughput, corrected loss, and network loss. The
bottom axis of the graphs indicates the time interval in seconds.
Figure 18. Network Monitor
Graph name
Color
Description
Rx Throughput
Blue line
The received throughput over the most recent interval. The right axis
indicates the throughput in Kbps.
Corrected
Green
bars
The corrected packet loss seen by applications for which HP Velocity is
accelerating the streams. The left axis indicates the loss in percentage.
Network
Red bars
The packet loss in the network. The left axis indicates the loss in
percentage.
Additionally, the values on the left-hand side represent the following.
Value
Description
Network Loss
Peak
The highest packet loss for the duration of the graph.
Network
The packet loss over the most recent interval.
Corrected
The corrected loss over the most recent interval.
HP Velocity Server Side Deployment Guide
38
HP Velocity management
Value
HP Velocity Management application
Description
Network Throughput
Peak
The highest received throughput for the duration of the graph.
Throughput
The received throughput for the most recent interval.
Configuration
HP Velocity installs with a default configuration suitable for most deployments. This section
describes how to change the HP Velocity configuration using the HP Velocity management
application.
The Configuration tab enables administrators to view and modify the current HP Velocity
configuration. Select Advanced to display or hide the Advanced and Loss Emulation
sections of the display.
Figure 19 on page 40 shows standard and Figure 20 on page 43 shows advanced
configuration fields.
To save changes to the selected configuration, select Apply. To export the current
configuration and system diagnostic information to a file, select Export.
NOTE: Non-administrators can only view or export the configuration.
NOTE: When settings are modified on the Configuration tab, they are only
in effect until the system is reset. After a reset, the settings will return to the
Group Policy setting if applied. Otherwise, they will return to the default.
CAUTION! Changing HP Velocity configuration settings can severely
impact networking performance.
HP Velocity Server Side Deployment Guide
39
HP Velocity management
HP Velocity Management application
Basic configuration
The Configuration tab displays commonly used configuration parameters, as shown in
Figure 19.
Figure 19. Configuration view
Configuration option
Description
Basic
Target Loss Rate
(TLR)
Specifies the loss rate that HP Velocity will attempt to achieve for all active HP
Velocity-accelerated streams.
NOTE: Aggressive target loss rates (TLR) may not be achievable in very high-loss
networks or bandwidth restricted environments.
Available values are 0.04%, 0.1%, 0.2%, and 0.4%. The default is 0.04%.
Link Profiler
The HP Velocity Link Profiler analyzes network links. It detects links with bandwidth
constraints and automatically adjusts HP Velocity protection to accommodate the
bandwidth constraint.
When the Link Profiler is active and bandwidth constraints are detected, the Link
Profiler will override the Bandwidth setting and may override encoding modes to
ensure the best network performance possible.
Available values are Checked and Unchecked (enable and disable Link Profiler
respectively). The default value is Checked (enabled).
HP Velocity Server Side Deployment Guide
40
HP Velocity management
Configuration option
Protection
HP Velocity Management application
Description
Enable or disable HP Velocity acceleration.
Available values are:
• Active — Enable HP Velocity acceleration for streams through this HP Velocity.
• Off — Pass through all data streams.
• One-Way Monitor — Monitor for packet loss, but do not accelerate the IP data
streams flowing in the transmit direction (towards the far-end HP Velocity) and decode
any HP Velocity data streams received from the far-end HP Velocity.
• Two-Way Monitor — Monitor for packet loss, but do not accelerate the IP flows
through the HP Velocity. When selected, HP Velocity sends a message to the far-end
HP Velocity instructing it to disable HP Velocity acceleration and enter monitor mode
for any flows destined for this HP Velocity.
The default is Active.
Bandwidth
Control
Specifies the range of protection modes that HP Velocity is able to use when encoding
HP Velocity-accelerated streams.
The protection mode defines how accelerated streams are protected from network
loss. Higher protection modes protect against a greater network loss but also require
more bandwidth.
HP Velocity constantly monitors network loss and automatically selects the protection
mode required to reduce the network loss to the specified target loss rate (TLR). The
selection process is dynamic and the mode used at any given time varies depending
on the real-time loss measured in the network.
Available values are:
Dynamic - Use this setting in situations where bandwidth is not constrained. It will
maximize performance while minimizing the required bandwidth.
Low - Use this mode in very bandwidth constrained environments to cap the
estimated HP Velocity protection overhead at or below 27%.
Medium - Use this mode in moderately bandwidth constrained environments to cap
the estimated HP Velocity protection overhead at or below 40%.
High - Use this setting to maximize performance in situations where bandwidth is not
constrained and the network loss is known to be high. This setting differs from
the Dynamic setting in that it immediately uses aggressive encoding as soon
as it detects HP Velocity at the far end, without first measuring the loss in the
network.
The default value is Dynamic.
HP Velocity Server Side Deployment Guide
41
HP Velocity management
Configuration option
HP Velocity Management application
Description
Flow Optimizers
WiFi Optimizer
Enable or Disable WiFi Optimizer.
The WiFi Optimizer ensures that HP Velocity-accelerated data streams experience
lower latency, lower jitter, and higher throughput in both directions.
Available values are Checked and Unchecked, which respectively enable and disable
WiFi Optimizer. The default value is Checked (enabled).
TCP Optimizer
Enable or Disable TCP Optimizer.
The TCP Optimizer improves the throughput of applications like multimedia streaming
and remote desktop access by modifying TCP's flow control mechanisms to perform
better in WiFi environments.
Available values are Checked and Unchecked which respectively enable and disable
TCP Optimizer. The default value is Unchecked (disabled).
Policy Filters
Configure the HP Velocity policy filters. See “Policy Filters” on page 45.
Advanced
Display or hide advanced configuration options on the Configuration tab. See
“Advanced configuration” on page 43.
Export
Export the current HP Velocity configuration to a file. For more information, see “HP
Velocity Configuration Report” on page 51.
This feature is typically used for support purposes.
Set Defaults
Return all configuration settings to their original factory default settings.
Apply
Save and apply any changes made to the configuration options displayed on this tab.
Cancel
Revert any unapplied configuration changes.
HP Velocity Server Side Deployment Guide
42
HP Velocity management
HP Velocity Management application
Advanced configuration
When Advanced is selected on the Configuration tab, additional configuration options are
displayed, as shown in Figure 20.
Figure 20. Advanced configuration options
CAUTION! Always set Loss Emulation to 0 under normal operating
conditions. Only use Loss Emulation for demonstration purposes.
HP Velocity Server Side Deployment Guide
43
HP Velocity management
HP Velocity Management application
Configuration option
Description
Basic
For Basic options, see “Basic configuration” on page 40.
Advanced
BLP
Enable or disable BLP (Burst Loss Protection) to protect against correlated loss in the
network.
NOTE: BLP may degrade performance for highly latency sensitive applications.
Available values are:
Off - Disable Burst Loss Protection for correlated loss.
On - Enable Burst Loss Protection for correlated loss.
Auto - Allow HP Velocity to determine if BLP is required and automatically turn the
feature on if required.
The default value is Auto.
BLP Buffer
Select the amount of packet buffering in milliseconds that HP Velocity is allowed to
use when protecting against bursty or correlated loss.
Available values are displayed in the drop-down menu and range from 10 to 100 ms in
increments of 10 ms.
The default value is 20 ms.
Network MTU
Specifies the network maximum transmission unit (MTU), which is the largest packet
size in bytes, that can be processed within the network.
The valid range is from 750 to 1500 bytes inclusive. A value outside this range will
generate an error message.
The default is 1492.
Flow Optimizers
For Flow Optimizers, see “Basic configuration” on page 40.
Policy Filters
Configure the HP Velocity policy filters. See “Policy Filters” on page 45.
Advanced
Uncheck to return to basic configuration options. See “Basic configuration” on
page 40.
Loss Emulation
HP Velocity Server Side Deployment Guide
44
HP Velocity management
Configuration option
Transmit Loss
Rate (%)
HP Velocity Management application
Description
Enables the network loss simulator and introduces the specified percentage of loss
into the data streams being transmitted over the network.
CAUTION! Use this feature for demonstration purposes only. Always set the rate to 0
under normal operating conditions.
Receive Loss
Rate (%)
Enables the network loss simulator and introduces the specified percentage of loss
into the data streams being received from the network.
CAUTION! Use this feature for demonstration purposes only. Always set the rate to 0
under normal operating conditions.
Export
Export the current HP Velocity configuration to a file. For more information, see “HP
Velocity Configuration Report” on page 51.
This feature is typically used for support purposes.
Set Defaults
Return all configuration settings to their original factory default settings.
Apply
Save and apply any changes made to the configuration options displayed on this tab.
Cancel
Revert any unapplied configuration changes.
Policy Filters
The Policy Filters window provides access to view, configure, or reset HP Velocity policy
filters. Administrators can use policy filters to specify the IP addresses and ports of the data
streams to be accelerated with HP Velocity and the level of protection applied to the filtered
data streams.
CAUTION! Changing the HP Velocity configuration settings can severely
impact networking performance.
The following formats must be used when configuring the policy filters. Other formats will
generate an error message.
IP Address — When entering an IP address, use a space separated list of CIDR-format IP
addresses and subnet mask pairs. For example 192.168.1.0/24 145.76.53.3/32.
Port — When entering port numbers, use a space-separated list of ports. For example 80
1750 1751 .
NOTE: For a list of commonly used port numbers and brief descriptions of
their related service names, see http://www.iana.org/assignments/servicenames-port-numbers/service-names-port-numbers.xml.
HP Velocity Server Side Deployment Guide
45
HP Velocity management
HP Velocity Management application
Figure 21. Policy Filters configuration view
To restore default settings, select Set Defaults. A prompt will be displayed asking whether or
not settings are to be applied.
This section includes:
•
•
•
•
Policy filter precedence
Port filters
Target loss rate filters
IP filters
HP Velocity Server Side Deployment Guide
46
HP Velocity management
HP Velocity Management application
Policy filter precedence
When configuring multiple HP Velocity policy filters, the filters are evaluated in the following
order:
1. Blacklist IP
2. Whitelist IP
3. Whitelist port
4. Transparent port
5. Special port
Port filters
The whitelist, transparent, and special port filters allow administrators to filter data streams
that pass through the blacklist and whitelist IP filters (see below), by destination port. This
specifies whether or not the data streams should be accelerated or require special handling by
HP Velocity. Separate filters are provided for TCP and UDP ports.
The types of port filters are:
• Whitelist port filter
• Transparent port filter
• Special port filter
Whitelist port filter
If a port number is specified in the whitelist port filter (White TCP Ports or White UDP Ports),
only data streams meeting the following criteria are HP Velocity-accelerated.
Transmit packets:
• The destination IP address for the data stream is not specified in the blacklist IP filter
• There are no addresses in the whitelist IP filter OR the destination IP address for the data
stream is specified in the whitelist IP filter
• There are no ports in the whitelist port filter OR the destination or source port for the data
stream is specified in the whitelist port filter
• The destination and source port for the data stream are not specified in the transparent port
filter
HP Velocity Server Side Deployment Guide
47
HP Velocity management
HP Velocity Management application
Receive packets:
• The source IP address for the data stream is not specified in the blacklist IP filter
• There are no addresses in the whitelist IP filter OR the source IP address for the data
stream is specified in the whitelist IP filter
• There are no ports in the whitelist port filter OR the destination or source port for the data
stream is specified in the whitelist port filter
• The destination and source port for the data stream is not specified in the transparent port
filter
• The source IP address is in the force IP filter
All other transmit or receive data stream not meeting these criteria will be passed through HP
Velocity transparently.
Transparent port filter
The transparent port filter allows administrators to specify a list of TCP/UDP ports whose data
streams will not be HP Velocity-accelerated.
Special port filter
The special port filter allows administrators to enable or disable support for specific protocols.
By default, the special port filter is pre-configured to include ports which provide special
protocol support, such as RSTP (554), H.323 (1720), PPTP (1723), and SIP (5060).
To disable support for a specific protocol, remove the corresponding port from the filter. For
example, to disable support for RTSP, remove port 554 from the special TCP and UDP port
filters.
NOTE: If a port is added to the special port filter that HP Velocity is not
aware of, it will be ignored.
CAUTION! Removing a port from the special port filter may cause
applications to fail.
Target loss rate filters
The target loss rate (TLR) filters allow administrators to specify the IP addresses and ports
that are associated with a particular target loss rate. Separate filters are provided for each
supported target loss rate.
HP Velocity Server Side Deployment Guide
48
HP Velocity management
HP Velocity Management application
NOTE: Before switching TLRs, select Apply to save any changes.
NOTE: If there are multiple matches for an accelerated stream, the most
aggressive TLR is applied.
IP filters
The IP blacklist and whitelist filters allow administrators to filter the data streams received from
application(s) by destination IP address. This tells HP Velocity whether or not to accelerate
this stream.
When an IP filter is configured, HP Velocity examines the destination IP address of each
packet received from the application(s). If the packet’s destination IP address matches an IP
address specified in one of the IP filters, HP Velocity takes the appropriate action. The action
taken by HP Velocity depends on the IP filter to which the IP address applies, as detailed in
the following subsections.
IP filter entries must include the IP address and subnet mask in CIDR format <IP_address>/
<subnet_mask>. This allows administrators to use the filter to specify a subnet of IP
addresses to process. For example, to include all of the IP addresses in the 192.168.1.x
subnet in the IP filter, add the entry 192.168.1.0/24 to the filter. This would instruct HP
Velocity to process all data streams whose destination IP address is in the range of
192.168.1.1 to 192.168.1.255. To specify a single IP address, use a subnet mask of 32,
for example 192.168.1.51/32.
The types of IP filters includes:
• Blacklist IP filter
• Whitelist IP filter
Blacklist IP filter
The first policy filter to be evaluated is the blacklist IP filter. The blacklist IP filter allows
administrators to specify a list of destination IP addresses whose data streams will not be
accelerated by HP Velocity.
If a data stream’s destination IP address matches an IP address specified in the blacklist, that
data stream will be passed on without acceleration. Administrators can use the IP blacklist in
conjunction with the IP whitelist. For example, use the blacklist to exclude a specific IP
addresses in a whitelisted IP filter subnet from being HP Velocity-accelerated.
HP Velocity Server Side Deployment Guide
49
HP Velocity management
HP Velocity Management application
Whitelist IP filter
The whitelist IP filter is evaluated after the blacklist IP filter. It applies only to those IP
addresses that are not matched in the blacklist IP filter. The whitelist IP filter allows
administrators to specify a list of destination IP addresses whose data streams will be
accelerated by HP Velocity.
The whitelist filter is exclusive. If a whitelist filter is specified, then only the data streams
meeting the following criteria will be accelerated by HP Velocity:
• The destination IP address for the data stream is not specified in the blacklist IP filter
• The destination IP address for the data stream is specified in the whitelist IP filter
All other data streams not meeting these criteria will be passed through as is.
Administrators can further filter the whitelist using the blacklist IP filter and/or the whitelist port
filter:
• The blacklist IP filter allows administrators to specify a list of destination IP addresses
whose data streams will not be HP Velocity accelerated. For example, use a whitelist to
specify a subnet of IP addresses that will be accelerated by HP Velocity and use a blacklist
to specify the destination IP addresses within the whitelisted subnet whose data streams
will not be HP Velocity accelerated. For more information, see “Blacklist IP filter” on
page 49.
• The whitelist port filter allows administrators to specify a list of destination ports whose data
streams will be accelerated by HP Velocity. For example, to accelerate a data stream
destined for port 1750, add port 1750 to the whitelist port filter. HP Velocity will then
process only the data stream that meets the following criteria:
• The destination IP address for the data stream is not specified in the blacklist IP filter
• The destination IP address for the data stream is specified in the whitelist IP filter
• The destination port for the data stream is specified in the whitelist port filter
HP Velocity Server Side Deployment Guide
50
HP Velocity management
HP Velocity Management application
HP Velocity Configuration Report
The HP Velocity Configuration Report contains extensive information about HP Velocity, its
settings, and the current accelerated streams.
To generate the HP Velocity Configuration Report, select Export on the Configuration tab of
the HP Velocity Management application. By default, the report is saved with the filename
HPVelocityConfig.txt in the temporary folder for the current user C:\Users\<username>\AppData\Local\Temp. When generated, the report is automatically
displayed in the default text editor, such as Windows Notepad.
This report has the following sections:
• Driver Configuration — Current configuration and internal driver settings of HP Velocity
• Operating System — Operating system type, configuration, and performance information
for the system on which HP Velocity is installed
• Registry Configuration — Registry key values configured by the group policy engine
• Statistics — A snapshot of the current statistics
• Accelerated Streams — Current list of accelerated and monitored streams
HP Velocity Server Side Deployment Guide
51
Troubleshooting
This section provides the following basic troubleshooting information for HP Velocity:
• Why does the “Another version of this product is already installed.” message appear?
• Why does the “Do you want to allow the following program from an unknown publisher to
make changes to your system” message appear?
• Why does a message about a driver that has not passed Windows Logo Compatibility
testing appear?
•
•
•
•
Why are there multiple protected streams for one PCoIP or RGS connection?
Why is traffic between two HP Velocity servers only monitored?
A procedure in this document doesn’t work.
This troubleshooting section does not have the solution to my problem.
Why does the “Another version of this product is already
installed.” message appear?
A previous version of HP Velocity is installed. It must be uninstalled before the new installation
can proceed. Recent HP Remote Graphics Software (RGS) versions also include HP Velocity.
If RGS is installed, before installing HP Velocity uninstall RGS, install HP Velocity, and then
reinstall RGS.
Why does the “Do you want to allow the following program from
an unknown publisher to make changes to your system” message
appear?
During installation, this message may appear on Windows 7 and Windows Vista systems. If
this message appears, select the option to allow the changes to take place. This is expected
and is required for HP Velocity installation.
Why does a message about a driver that has not passed
Windows Logo Compatibility testing appear?
During installation, this message may appear on Windows XP systems. If this message is
displayed, allow the installation to proceed. This is expected and is required for HP Velocity
installation.
HP Velocity Server Side Deployment Guide
52
Troubleshooting
Why are there multiple protected streams for one PCoIP or RGS
Why are there multiple protected streams for one PCoIP or RGS
connection?
A single RDP connection will only have one accelerated stream generated. However, for
PCoIP or RGS, there will be multiple protected streams that come and go between client and
server. This is an expected behavior.
Why is traffic between two HP Velocity servers only monitored?
HP Velocity-enabled servers are designed to connect with HP thin clients to form accelerated
streams.
Server-to-server connections will only enter monitor mode and will not actively protect and
accelerate streams.
NOTE: In the case of server-to-server connections, HP Velocity will
display the green icon but will only be monitoring the active streams.
A procedure in this document doesn’t work.
Before performing any installation, be sure to read the release notes and documentation for
the version of HP Velocity being installed. Release notes contain last minute changes or
workarounds that may not be part of the standard documentation. Carefully follow any
instructions included to prepare for the procedure, as well as all steps in the procedure.
This troubleshooting section does not have the solution to my
problem.
If a problem cannot be solved after reading the documentation, including release notes for the
installed version of HP Velocity, visit the HP support website or contact HP customer support.
HP Velocity Server Side Deployment Guide
53
Index
T
terminal services 9
V
virtual desktop 10, 15
Numerics
32-bit 16
64-bit 16
A
administrator privileges 16
available resources 15
C
connection broker 11
D
deployment
direct and proxied 12
direction connection 10
proxied connection 11
terminal services 13
G
gateway 12, 14
H
HP customer support 53
I
installation folder 16
installation package 16
L
License Agreement 16
P
physical server 15
protocol
PCoIP 53
RDP 17, 53
RGS 53
R
remote services connection 17
S
statistics counters 14
W
warning message 17
Windows 7 16
Windows Server 2008 16
Windows Vista 16
Windows XP 16
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
