G6

– The New

Generation.

In association with HP & Intel

G6

– The New Generation

Contents.

Introducing the new HP Proliant G6 servers

Spend less for power

Uniting physical and virtual worlds

Make your money count

G6 to G5 Comparison

HP Proliant DL320

HP Proliant DL360

HP Proliant DL380

HP Proliant DL120

HP Proliant DL180

HP Proliant BL280c

HP Proliant BL460c

New models

HP Proliant Multi-Node G6

HP Proliant BL490c G6

3

7

14

G6

– The New Generation

Introducing the new HP Proliant G6 servers

10 new platforms, including racks, towers and blades, designed with three goals in mind:

Spend less for power

Maximise virtualisation

Potential

Make your money count

Minimize power consumption:

Allowing you to spend less for power and have more for your business

Maximize virtualization potential:

Enabling you to squeeze every bit of productivity out of your server infrastructure

Get the most out of your budget:

Make every server purchase count, demand performance and durability and deliver a resilient, optimized infrastructure.

G6

– The New Generation

Spend Less for More power.

The new line of Proliant server uses HP’s exclusive Thermal Logic Technology to deliver up to double the power efficiency.

Triple the capacity of your data center

with Dynamic Power Capping.

Continuously optimize efficiency

with Sea of Sensors.

Tailor configuration for maximum energy savings

with Common Power

Supplies.

Half the power consumption of the previous generation.

G6 is the world’s most energy efficient server.

G6

– The New Generation

Uniting Physical and Virtual

Worlds.

Given the tough economy, HP recognis es that you don’t have all the resources you need. This new generation of servers comes with a unique set.

Simplify setup and operations

with Proliant Onboard Administrator.

Reduce operational expenses

with Insight Control (Discounted bundle on selected models).

Decrease virtualisation complexity

with Insight Dynamics-VSE and Flex-10

G6

– The New Generation

Make your money count.

Make every server purchase count.

In today’s world, content does not have a downturn and downtime is not an option. You need to be able to handle increased demands and deliver a resilient infrastructure all while spending less money. It’s a seemingly impossible challenge that requires a new approach for success. The HP

Proliant G6 was designed for these challenges.

Double productivity

with half the servers.

Simplify transition

with Insight Server Migration.

Quickly resolve problems

with Insight Remote Support.

Customise service

with Proactive Select.

Upgrade within budget

with HP Financial Services.

G6

– The New Generation

HP Proliant DL320.

DL320 G5p DL320 G6

Processor

Memory

1P Xeon (Yorkfield/Wolfdale)

4 Sockets, DDR2 800MHz

Drive Bays

Storage Controller

Slots

Networking

Ports

Management

Security

Redundancy

4 LFE SATA/SAS HP

SW RAID embedded; SAS HBA or Controller for SAS

2 Available slots

1 full length PCIE x8

1 half length low profile PCI-E x1

Dual-port Gigabit NIC (1

Broadcom 5715)

USB: 2 front, 1 internal, 2 rear video, Serial, PS/2 iLO 2

Non-RPS

1P Xeon (Nehalem)

9 Sockets, DDR3 1067/1333

Unbuff and Reg ECC

2 or 4 LFF SATA/SAS HP (8FF optional)

HP SW RAID embedded; SAS

HBA or Controller for SAS

2 Available slots

1 full length PCI-E gen 2x16

1 half length low profile PCI-E gen 2 x4

1 Optional PCI-X 133 replaces full length PCI-E

Dual Port Gigabit NIC (1

Broadcom 5715)

USB: 2 front, 1 internal, 4 rear video, Serial PS/2

Proliant Onboard

Administrator powered by

Integrated Lights-Out 2

TPM option

RPS

G6

– The New Generation

HP Proliant DL360.

DL360 G5 DL360 G6

Processor

Intel Xeon 5000 Sequence

Intel Nehalem - EP

Memory

8 Sockets, DDR2 667MHz

64GB max.

18 Sockets, DDR3 800Mhz to

1333MHz 144GB max.

Drive Bays

Storage Controller

Slots

Networking

6 SFF SAS/SATA

P400i/E200i

2 Available Slots

-1full length x16 PCI-e /-1 low profile PCI-e x8

-1 optional PCI-x 133 replace full length PCI-

8 SFF SAS/SATA

P410i

2 Available Slots

-1full length x16 PCI-e Gen2/-1 low profile x8 PCI-e Gen2

-1 optional PCI-x 133 replace full length PCI-e

2 NIC ports, NC382i

Ports

2 NIC ports [NC373i

Multifunction (Broadcom)

Front: USB (1), video

Rear: USB (2), Video, NIC /

Internal: USB (1)

ILO 2

Management

Security

Redundancy

Fan: N+1

Power:1

Front: USB (1), video

Rear: USB (2), Video, NIC /

Internal: USB (1)/ SD slot (1)

Onboard Administrator w/ ILO

2

TPM option

Fan: N+1

Power:1

G6

– The New Generation

HP Proliant DL380.

DL380 G5 DL380 G6

Processor

Memory

Intel Xeon 5000 Sequence

8 Sockets, DDR2 667MHz

64GB max.

Intel Nehalem - EP

18 Sockets, DDR3 800Mhz to

1333MHz 144GB max.

Drive Bays

Storage Controller

Slots

Networking

Ports

Management

Security

Redundancy

8 SFF SAS/SATA

P400/E200

PCI-E Gen 1:

Embedded: 2X4 PCI-E

Standard Riser: 1X4 and 2 X8

PCI-E Optional

Riser: PCI-X/PCI-E (2 PCI-X,

1X8 PCI-E)

(Max. PCI-E slots: 4)

2 NIC ports,NC373i

Front: USB (2), video

Rear: USB (2), Video, NIC

Internal: USB (1)

ILO 2

Fans: Hot plug with optional redundancy

Power: 1

Up to 16 SFF SAS/SATA or 6

LFF SAS/SATA

(Different drive cages for SFF and LFF)

P410i

PCI-E Gen 2:

Standard Riser: 1X8 and 2 X4

PCI-E

Optional Risers: X16 PCI-E;

PCI-X/PCI-E (2 PCI-X/133, 1X8,

1 X4 PCI-E (Max. PCI-E slots:

6)

4 NIC ports, NC382i

Front: USB (2), video

Rear: USB (2), Video, NIC

Internal: USB (1)/ SD slot (1)

Onboard Administrator w/

ILO 2

TPM option

Fans: Hot plug with optional redundancy

Power: 1

G6

– The New Generation

HP Proliant DL120.

DL120 G5 DL120 G6

Processor

Memory

Drive Bays

Storage Controller

Slots

Networking

Ports

Management

Security

Redundancy

1P Xeon (Yorkfield/Wolfdale)

4 Sockets, DDR2 800MHz

Unbuff ECC

2 LFF SATA/SAS NHP

SW RAID embedded;

SAS HBA or Controller for SAS

2 Available slots

1 full-length PCI-E x8

1 half length low-profile PCI-E x4

1 optional PCI-X 133 replaces full-length PCI-E

Single Gigabit NIC

(1x Broadcom 5722)

USB: 2 front, 1 internal, 2 rear

Video, Serial, PS/2

LO100c

Non-RPS

1P Xeon (Lynnfield/Clarkdale)

6 Sockets, DDR3 1067/1333

Unbuff and Reg ECC

2 or 4 LFF SATA/SAS

NHP/HP

HP SW RAID embedded;

SAS HBA or Controller for

SAS and/or HP

2 Available slots

1 full-length PCI-E gen 2 x16

1 half length low-profile PCI-E gen 2 x4

1 optional PCI-X 133 replaces full-length PCI-E

Dual Gigabit NICs

(1x Broadcom 5723)

USB: 2 front, 1 internal, 4 rear

Video, Serial, PS/2

LO100i; System setup and update, health agents, SIM support (Polaris &

Lighthouse)

TPM option; IPMI ready

400W; Non-RPS

G6

– The New Generation

HP Proliant DL180.

DL180 G5 DL180 G6

Processor

Memory

Drive Bays

Storage Controller

Slots

Networking

Ports

Management

Security

Redundancy

Xeon Quad/Dual Core

6 Sockets, DDR2 667 FBD

4/8/12 LFF SATA/SAS

SATA RAID embedded with entry models;

SA E200 or P400 on other models;

3 Available slots

2 full-length PCI-e x4

1 low-profile PCI-e x8

2 optional PCI-X 133 replaces full-length PCI-E slots

1 Gigabit NIC

USB: 2 front, 1 internal, 2 rear

Video, Serial, PS/2

LO100

HP RPS

2P Xeon (Nehalem EP)

12 Sockets , DDR3 1067/1333

4/8/12/14 LFF SATA/SAS

(4/8/12 standard +2 rear upgrade) 8/25 SFF

HP SATA RAID with entry models (ICH-9);

P212 and P410 on other models

3 Available slots

2 full-length PCI-E x8 Gen 2

1 low-profile PCI-E x16 Gen 2

2 optional PCI-X 133 replaces full-length PCI-E OR

1 optional PCI-E x16 Gen 2

2 Gigabit NICs

USB: 2 front, 1 internal, 2 rear

Video, Serial, PS/2

LO100; System setup and update, health agents, SIM support (Polaris &

Lighthouse)

TPM option

HP RPS

G6

– The New Generation

HP Proliant BL280c.

HP ProLiant BL260c G5 HP ProLiant BL280c G6

Processors

Memory

Internal Storage

Network Ports

I/O Slots

Integrated Management

Additional Features

Density

Two quad-, dual-, or single-core

Intel® Xeon®, Core™2 Duo or

Celeron® processors

Two dual- or quad-core

Intel® Nehalem-EP Series

48GB

6 Sockets

DDR2 533/667MHz

96GB

12 Sockets

Registered or Unbuffered

DDR3

SATA

2 SFF non hot-plug drive bays

HP Embedded SATA RAID

Controller*

Two 1Gb Ethernet ports

One PCI Express mezzanine slot

SATA, SAS, SSD

2 SFF non hot-plug drive bays

HP Embedded SATA RAID

Controller*

Two 1Gb Ethernet ports

Two PCI Express mezzanine slots

iLO-2 Standard Blade Edition

iLO-2 Standard Blade Edition

Internal USB 2.0 connector

16 blades in 10U; 8 blades in

6U

Internal USB 2.0 connector

Internal SD card slot

TPM support

16 blades in 10U; 8 blades in

6U

G6

– The New Generation

HP Proliant BL460c.

HP ProLiant BL460c G5 HP ProLiant BL460c G6

Processors

Memory

Internal Storage

Network Ports

I/O Slots

Integrated Management

Additional Features

Density

Two dual- or quad-core

Intel® Xeon®

64GB

8 Sockets

Fully-Buffered DDR2

667MHz

Twp dual- or quad-core

Intel® Nehalem-EP Series

96GB

12 Sockets

Registered or Unbuffered

DDR3

SATA, SAS

2 SFF hot-plug drive bays

Smart Array E200i

Optional 128MB batterybacked write cache

RAID 0,1

Two multifunction 1Gb

Ethernet ports

Two PCI Express mezzanine slots iLO-2 Standard Blade

Edition

SATA, SAS

2 SFF hot-plug drive bays

Smart Array P410i

Optional cache and battery-backed write cache

RAID 0,1

Embedded dual-port Flex-

10 10GbE Multifunction server adapter

Two PCI Express mezzanine slots

Internal USB 2.0 connector

16 blades in 10U; 8 blades in 6U

iLO-2 Standard Blade

Edition

Internal USB 2.0 connector

Internal SD card slot

TPM support

16 blades in 10U; 8 blades in 6U

G6

– The New Generation

HP Proliant BL460c G6.

HP ProLiant BL460c G5 HP ProLiant BL460c G6

Processor

Drive Bays

Memory

Storage Controller

Slots

Internal Storage

Networking

Network Ports

Management

Two dual- or quad-core Intel®

Xeon®

Two dual- or quad-core

Up to 12 LFF or 24 SFF HDDs

64GB

Intel® Nehalem-EP Series

96GB

Hot plug SAS/SATA optional

8 Sockets

12 Sockets

HP SW RAID embedded

Smart Array PCI-E Upgrade

Registered or Unbuffered

DDR3

Without I/O expansion

SATA, SAS

2 SFF hot-plug drive bays

RAID 0,1 ports

support

Smart Array P410i

Optional cache and batterybacked write cache

RAID 0,1

Embedded dual-port Flex-10

10GbE Multifunction server

Redundancy

Integrated Management

Additional Features

slots

Two PCI Express mezzanine slots

iLO-2 Standard Blade Edition

iLO-2 Standard Blade Edition

Internal USB 2.0 connector

Internal USB 2.0 connector

Internal SD card slot

TPM support

G6

– The New Generation

HP Proliant BL490c G6.

Processor Up to two Quad-Core Intel® Xeon® processor 5500 series (Nehalem-EP)

Memory 18 DIMM Sockets

DDR3 Registered or Unbuffered DIMMs

144 GB max

Internal Storage

Networking

Mezzanine Slots

2 SFF non hot-plug drive bays (SSD only)

HP Embedded SATA Controller

Direct-Attached and Shared Storage connect options

Embedded dual-port Flex-10 10GbE Multifunction server adapter

2mezzanine slots x8 PCIe Type-1 Mezzanine expansion slot x8 PCIe Type-2 Mezzanine expansion slot

Additional Features

Management

Density

Internal USB 2.0 connector

Internal SD Card slot

TPM support iLO-2 Standard Blade Edition

Power Meter, Power Regulator, Power Capping

16 server blades in 10U enclosure

8 server blades in 6U enclosure

G6 is available NOW!

For more information and to get the best available pricing contact your CAE Account Manager.

Head Office - Watford

Tel: 0845 643 0033

Email: [email protected]

Web: www.caeuk.com

CAE Technology Services

Colonial Way, CAE House, Watford

Hertfordshire, WD24 4PT

London Office

Tel: 020 7618 8535

Email: [email protected]

Web: www.caeuk.com

CAE Technology Services

20-06 City Tower, 40 Basinghall Street

London, EC2V 5DE

Cardiff Office

Tel: 0292 0375 080

Email: [email protected]

Web: www.caeuk.com

CAE Technology Services

The Old Brewery Quarter, St Mary Street

Cardiff, CF10 1AD

Oxford Office (Education)

Tel: 08708 500 510

Email: [email protected]

Web: www.caeuk.com

CAE Technology Services

Unit 9 Wheatley Business Centre

Old London Rd, Wheatley, Oxon, OX33 1YW

Bracknell Office

Tel: 0871 704 1805

Email: [email protected]

Web: www.caeuk.com

CAE Technology Services

Venture House, Drownshire Way

Arlington Square, Bracknell, Berkshire, RG12 1WA

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
