TRENDnet TE100-PCIWN 10/100Mbps PCI Adapter Quick Installation Guide

Quick Installation Guide
TE100-PCIWN
TE100-PCIWA
Table ofofContents
Table
Contents
Româna .......................................................................................... 1
1. Inainte de a incepe .................................................................. 1
2. Cum instalati ........................................................................... 2
Troubleshooting................................................................................ 3
Version 04.10.2006
1. Inainte de a incepe
Continutul Pachetului
TE100-PCIWN/TE100-PCIWA
Ghidul Rapid de Utilizare
Disketa de driver
cablu Wake-on-LAN cu 3 fire
(TE100-PCIWA numai)
Cerinte de Sistem
Slot PCI 32-bit 2.1 (2.2 pentru Wake-on-LAN)
Unitate Floppy
CPU: Intel Pentium 300Mhz sau mai bun
Memorie: 32MB RAM sau mai mult
Windows 2003 Server/XP/2000/ME/98SE
Cablu A RJ-45 Ethernet
Aplicatie
Workstations with
10/100Mbps Fast Ethernet
PCI Adapter
Workstations with
10/100Mbps Fast Ethernet
PCI Adapter
(TE100-PCIWN)
(TE100-PCIWA)
Internet
8-Port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S88Eplus)
Cable/DSL
Modem Router
Printer
10/100Mbps
Multi-Port Print Server
(TE100-P21)
1
Româna
Printer
2. Cum instalati
1. Opriti computerul iar apoi
deschideti cacasa.
2. Introduceti Placa PCI Card in slotul
PCI disponibil,iar apoi reporniti
calculatorul si asteptati pana apare
desktopul Windows.
Nota: Windows 2003 Server/XP/2000/ME va detecta si instala automat drivere
cuvenite. Pentru Windows ME, va rugam sa restartati PC-ul dupa terminarea
instalarii driverelor. Pentru Windows 98/98SE, va rugam sa apelati la
sectiunea Probleme pentru instructiuni cu privire la instalarea driverelor.
3. Conectati un cablu de retea RJ-45
de la PC la un port Ethernet
disponibil de la switchul sau
routerul dvs.
Instalarea este gata acum.
2
Româna
Troubleshooting
Q1: Windows is unable to recognize my hardware. What should I do?
A1: First, verify that your computer meets the system requirements as specified in
Section 1. Second, go to Start -> Control Panel -> System > Hardware > Device
Manager. In the list of device types, double-click on Network Adapters. If you see the
device with a yellow question mark or exclamation point next to it, double-click on it, click on
Drivers and click Update Drivers. Follow the Hardware Update Wizard instructions as
illustrated in Section 2. Third, if the device manager fails to recognize the presence of a
new network adapter, verify that the network adapter is firmly seated in the PCI Slot. Fourth,
insert the adapter into a different PCI slot on the computer.
Q2: Windows recognizes my new hardware, but I'm unable to connect to my network. What
should I do?
A2: First, verify that the RJ-45 Ethernet Cable is securely connected from your switch or
router to your network adapter. Second, verify that the LEDs on your network card are lit.
Third, verify that the TCP/IP settings are set to Obtain an IP address automatically.
Q3: How do I install the drivers on Windows 98?
A3: Follow the steps below:
1. When the Add New Hardware Wizard appears, click Next.
2. Click Search for the best driver for your device (Recommended) and then click Next.
3. Click Specify a location and then click Next.
4. Insert the Driver Floppy Disk into your computer's Floppy disk drive. Double-click the
Floppy disk drive, click on Win98, click OK and then click Next
5. If prompted to, insert your Windows 98 CD-ROM, and then click OK.
6. Click Finish.
7. Click Yes to restart your computer.
If you still encounter problems or have any questions regarding the TE100-PCIWN/TE100-PCIWA,
please contact TRENDnet Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause
undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
