TRENDnet TPE-224WS Owner's manual

Quick Installation Guide
TPE-224WS
Table ofofContents
Table
Contents
English ......................................................................................................
1. Before You Start ................................................................................
2. Hardware Installation ........................................................................
3. Web Management Utility ....................................................................
1
1
2
3
Troubleshooting ........................................................................................ 6
Version 03.13.2006
1. Before You Start
Package Content
TPE-224WS
Quick Installation Guide
Utility CD-ROM
2 mounting brackets with screws
AC Power Cord
System Requirements
Web Browser: Internet Explorer (5.0 or above), Netscape (6.0 or above)
Computer with Network adapter installed
Application
Advanced Wireless Pan & Tilt
Internet Camera Server
(TV-IP400W)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
108Mbps 802.11g
Hot-Spot Access Point
(TEW-453APB)
108Mbps 802.11g
Hot-Spot Access Point
(TEW-453APB)
26-Port 10/100/1000Mbps
Gigabit Web Smart
PoE Switch
(TPE-224WS)
Advanced Day/Night
Internet Camera Server
(TV-IP300)
108Mbps 802.11g
Wireless Access Point
(TEW-450APB)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power over Ethernet
(PoE) Splitter
(TPE-102S)
Power + Ethernet Data
1
English
Advanced Wireless Day/Night
Internet Camera Server)
(TV-IP300W)
2. Hardware Installation
1. Connect the Power Cord to the
rear of the TPE-224WS and then to
a power outlet.
2. Connect a CAT-5 network
cable from the computer to an
available Ethernet port of the
TPE-224WS.
2
English
3. Web Management Utility
Note: If you would like to easily discover all the Web Management Switches on
the network, assign IP Address, change the password, and upgrade to new
firmware, then install the Web Management Utility. Follow the steps below.
For Windows User
1. Insert the Utility CD-ROM into
your computer's CD-ROM Drive
and then click Install Utility.
2. Follow the Installation Wizard
instructions. Click OK.
3. Click Start > Programs >
web_management_utility, and then
click web_management_utility.
3
English
4. Click Discovery, and then doubleclick the Switch that appears in
the Discovery List.
5. Click the Switch in the Monitor
List and then click Configuration
setting.
6. Configure the IP Address, Subnet
mask, Gateway, and Password.
Click Set.
4
English
7. Click OK.
8. Click Web access.
9. Type in your Password and then
click Login.
For more information regarding the TPE-224WS configuration and advanced
settings, please refer to the User's Guide included on the Utility CD-ROM or
TRENDnet's website at www.trendnet.com
5
English
Troubleshooting
Q1: After connecting the TPE-224WS to a power outlet, the LEDs do not turn on.
A1: Check the connection of the power cord to the TPE-224WS and the power outlet. Also
check that the power outlet is receiving power.
Q2: After installing the Web-Management Utility, I clicked Discovery and the Utility is unable to
discover the TPE-224WS. What should I do?
A2: Make sure that the TPE-224WS is powered on and that all connections are secure. Also
check that your computer's IP Address is on the same network segment as the TPE-224WS.
The default IP Address of the TPE-224WS is http://192.168.0.1 and the default password is
"admin".
Q3: When I access the TPE-224WS using a web browser, I get a screen that tells me “only one
user can login”. What should I do?
A3: Another computer is configuring the TPE-224WS. Please wait until the user logs off. If the
other user has already logged off and you still get the same screen, then disconnect the power
cord from the TPE-224WS, wait for 5 seconds, reconnect the power cord to the TPE-224WS,
allow 5 seconds for the switch to power on, and then attempt to access the web configuration
page to login.
Q4: When I connect a computer to the switch's port, the LINK/ACT LED turns on, but the
100Mbps LED remains off.
A4: When the 100Mbps LED remains off, the computer's connection speed is 10Mbps.
Q5: I connected a Power-over-Ethernet (PoE) device into the switch's PoE port, but the PoE
Status LED remains off.
A5: Check the connections between the PoE port and the PoE device. Make sure that the
CAT-5 cable is properly inserted into the PoE port and PoE device.
If you still encounter problems or have any questions regarding the TPE-224WS, please refer to the
User's Guide included on the Utility CD-ROM or contact Trendnet's Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause
undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
6
Limited Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TPE-224WS - 5-Year Warranty
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be preauthorized by TRENDnet with RMA number marked on the outside of the package, and
sent prepaid, insured and packaged appropriately for safe shipment.
7
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1-Year Warranty
