Innovative Technology
Precision Engineering
Accurate Dispensing
Control
Handles
Control Handles
Automotive | Commercial | Industrial
Digital Register DR Meter
Introducing the Doctor! The new DR (Digital Registry)
meter from Balcrank. “The cure for the common meter”
The DR meter carries with it new innovative technology in a digital meter. Our new meter is
precision balanced, lightweight and ergonomically designed. Simple, accurate and efficient,
this meter combines new features with proven oval gear technology.
NEW memory-flex
extension; bend the
extension to the
desired angle and it
retains its shape.
1
www.balcrank.com
•
No field calibration required: Precision machined aluminum die-cast fluid chamber
maintains the tight tolerances required for repeatable accuracy. Each meter is individually
tested for performance and accuracy which guarantees precise dispensing regardless of
fluid viscosity, system pressure or changes in outside temperature.
•
Meter housing: unique totally encased polycarbonate housing with TP Elastomer over
mold provides superb impact resistance while isolating the electronic register module
(ERC) from the environment which provides an airtight seal with the meter body.
•
Sealed battery compartment: battery clips are mounted directly on the ERC, no cables for
battery contact, which ensures protection against the environment, impact, or vibrations.
•
Low power consumption: ERC with auto-sleep function for improved battery life.
•
Trip mode function: resettable totalizer function can operate as an economical, simple
fluid inventory control system.
•
Non-resettable totalizer function: shows total fluid flow through the meter from day one
and is unaffected by low or dead batteries.
•
All new handle: aluminum body with lightweight ergonomic soft grip handle for comfort
and precision balance.
•
Unique 1/4 turn manual tip: effective and very fast, high flow, no splash and very easy
to use.
•
Flange coupling at the control valve: eliminates the use of connection adaptors which can
become loose, providing superior integration of the meter and handle.
•
Swivel cover protects automobiles from nicks and scratches.
•
Large ported swivel: for comfort even at high pressures, includes durable inlet filter which
protects meter from debris.
•
Trigger lock button: prevents accidental dispense and also allows the gun to be locked in
the open position.
•
Affordable repairability: ERC can be changed easily.
product specifications are subject to change without prior notice
Digital Register DR Meter
Sealed battery
compartment.
Battery clips mounted on PCB, no cables for
battery contact which ensures protection against
impact or vibrations.
Neodymium magnets ensure
long life and reliable pulses
transmission to reed switch.
LCP gears and stainless steel
shaft provide excellent product
compatibility and fatigue
resistance.
Polycarbonate housing with
TP Elastomer over mold
provides superb impact
resistance while isolating the
PCB from the environment
providing an air tight seal
with the meter body.
Low power consumption PCB
with auto-sleep function for
improved battery life.
Cable-less mechanical
buttons to avoid
contact failures.
2 x 1.5v "AAA" standard batteries
Five digit display.
Readout in 0.01 increments.
Measure units:
Quarts, Pints, Gallons, and Liters
Non-resettable totalizer function
Battery charge indicator
Batch, trip and total select button
On / Reset button
Trip mode function: resettable
totalizer function can operate
as an economical simple fluid
inventory control system
Automotive | Commercial | Industrial
2
DR (Digital Registery) Meter
AVAILABLE MODELS
Model
Extension Type & Nozzle
3330-162
Rigid
Auto
3332-098
3330-161
Flex
Auto
3332-095
3330-160
Flex 90
Auto
3332-094
3330-167
Flex-memory
Auto
3332-099
3330-157
Rigid
1/4 turn - OIL
3332-091
3330-168
Flex
1/4 turn - OIL
3332-100
3330-158
Flex 90
1/4 turn - OIL
3332-092
3330-159
Flex-memory
1/4 turn - OIL
3332-093
3330-169
Rigid
1/4 turn - ATF
3332-101
3330-171
Flex
1/4 turn - ATF
3332-103
3330-170
Flex 90
1/4 turn - ATF
3332-102
3330-172
Flex-memory
1/4 turn - ATF
3332-104
Verify ID of ATF fill port for compatibility.
SPECIFICATIONS
Units of measure
Batch: Quarts, Pints, Gallons, and Liters
(in 0.01 increments).
Accuracy
+/- 0.5% of reading (lubricating oils)
Flow Range
0.26-8 gal/m (1-30 l/m)
Max pressure
1,450 psi (100 bar)
Swivel inlet
1/2” NPT(F)
Dispense
Nozzle OD
Auto = 0.605”
Manual ¼ turn for OIL = 0.705”
Manual ¼ turn for ATF= 0.315”
Verify ID of ATF fill port for compatibility
Operating temp
14ºF -160ºF (-10ºC - 70ºC)
Weight
3.2 lb (1.55 kg)
Battery
2 x 1.5v alkaline “AAA”
Compatible Fluids
Lubricants (up to SAE 140), ATF,
Anti-freeze (Glycol), and Anti-freeze
water solution
Wetted Materials
Liquid Crystal Polymer (LCP),
Aluminium, Buna-N™, Zinc Plated Steel,
Stainless Steel, Neodymium, and Brass
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
3
www.balcrank.com
SB3095
product specifications are subject to change without prior notice
Non-Metered
FEATURES
• Large port, ball bearing, inlet swivel included
• Easy access fluid inlet screen included at swivel.
• Included swivel hose-end cover, protects vehicle or
machine surfaces from scratches.
• Easy access for service of the rotary-piston
mechanism.
• Trigger lock button prevents accidental control
valve opening and allows the control valve to be
locked in open position for large volumes dispense.
• Cam & Piston valve design optimized for superb
control and minimum flow resistance
• Ergonomically designed grip handle for optimum
comfort.
AVAILABLE MODELS
3320-022
Model
Extension Type & Nozzle
3320-027
Rigid
Auto
3332-098
3320-025
Flex 90
Auto
3332-094
3320-026
Flex
Auto
3332-095
3320-033
Flex-memory
Auto
3332-099
3320-022
Rigid
1/4 turn - OIL
3332-091
3320-023
Flex 90
1/4 turn - OIL
3332-092
3320-028
Flex
1/4 turn - OIL
3332-100
3320-024
Flex Memory
1/4 turn - OIL
3332-093
3320-029
Rigid
1/4 turn - ATF
3332-101
3320-030
Flex 90
1/4 turn - ATF
3332-102
3320-031
Flex
1/4 turn - ATF
3332-103
3320-032
Flex Memory
1/4 turn - ATF
3332-104
Verify ID of ATF fill port for compatibility.
SPECIFICATIONS
3320-033
Flow Range
0.26-8 gal/m (1-30 l/m)
Max pressure
1,450 psi (100 bar)
Swivel inlet:
1/2” NPT(F) Swivel
Dispense
Nozzle OD
Auto = 0.605”
Manual ¼ turn for OIL = 0.705”
Manual ¼ turn for ATF= 0.315”
Verify ID of ATF fill port for
compatibility
Operating temp
14˚F -158˚F (-10˚C - 70˚C)
Weight
3.2 lb (1.55 kg)
Compatible Fluids
Lubricants, gear oil, automatic
transmission, Anti-freeze (Glycol)
Wetted Materials
Aluminum, Zinc Plated Steel, and
Buna-N™
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
Automotive | Commercial | Industrial
SB3095
4
MR (Mechanical Registry) Meter
Introducing the new MR (Mechanical Registry)
meter from Balcrank
The Balcrank mechanical-metered control valves have been specifically designed to measure and
dispense fluids using improved technology and innovation. Balcrank manufactures a full range
of rotary-piston mechanical meters, graduated in quarts, gallons or liters to cover the needs of
production lines, filling engines, gear boxes and transmissions; or when dispensing lubricants in
fleet service shops, off-road vehicles, mining, or marine equipment maintenance facilities.
Our line of mechanical meters are well suited for tough jobs and extreme environmental conditions.
ROBUST
• Polycarbonate based integral register housing and single molded pointer knob will
guarantee maximum integrity of the meter against drops and impacts.
• One piece molded register housing gives extra protection against humidity. The
meter is ideal for outdoor use.
• The one-piece molded pointer knob, which encloses a very robust and unique
reset mechanism, is protruding for easy resetting and reading, but is resistant to
impacts.
• The reset mechanism incorporates a safety clutch for integrity and can be turned
backwards without damaging the meter.
• A simple and easy to read dial can be read at any time regardless of the ambient
temperature or in direct sunlight.
• Full metal meter for long life and maximum durability.
ACCURATE
• Precision machining and tight tolerances maintains accuracy with no calibration
necessary.
• Meter accuracy is maintained across a broad viscosity range and/or extreme
temperature variations.
EXTRA PERFORMANCE
• Larger measuring chamber improves delivery rate up to 33% compared to other
rotary-piston mechanical meters.
• 5-digit totalizer keeps lifetime record of fluid dispensed.
• Large ported swivel: for comfort even at high pressures, includes durable inlet filter
which protects meter from debris.
• Easy access fluid inlet screen included at swivel.
• Included swivel hose-end cover protects vehicle or machine surfaces from
scratches.
• Easy access for service of the rotary-piston mechanism.
• Trigger lock button: prevents accidental dispense and also allows the gun to be
locked in the open position for high volume dispenses.
• Cam & Piston valve optimized for superb control and minimum flow resistance.
• All new handle: aluminum body with lightweight ergonomic soft grip handle for
comfort and precision balance.
• Unique 1/4 turn manual tip: effective and very fast, high flow, no splash and very
easy to use.
5
www.balcrank.com
product specifications are subject to change without prior notice
MR (Mechanical Registry) Meter
DIMENSIONS
AVAILABLE MODELS
Model
Extension Type & Nozzle
3330-185
Rigid
Auto
3332-098
U/M
Qt
3330-186
Flex 90
Auto
3332-094
Qt
3330-187
Flex
Auto
3332-095
Qt
3330-188
Flex Memory
Auto
3332-099
Qt
3330-189
Rigid
1/4 turn-OIL
3332-091
Qt
3330-190
Flex 90
1/4 turn-OIL
3332-092
Qt
3330-191
Flex
1/4 turn-OIL
3332-100
Qt
3330-192
Flex Memory
1/4 turn-OIL
3332-093
Qt
3330-193
Rigid
1/4 turn-ATF
3332-101
Qt
3330-194
Flex 90
1/4 turn-ATF
3332-102
Qt
3330-195
Flex
1/4 turn-ATF
3332-103
Qt
3330-196
Flex Memory
1/4 turn-ATF
3332-104
Qt
3330-173
Rigid
Auto
3332-098
L
3330-174
Flex 90
Auto
3332-094
L
3330-175
Flex
Auto
3332-095
L
3330-176
Flex Memory
Auto
3332-099
L
3330-177
Rigid
1/4 turn-OIL
3332-091
L
3330-178
Flex 90
1/4 turn-OIL
3332-092
L
3330-179
Flex
1/4 turn-OIL
3332-100
L
3330-180
Flex Memory
1/4 turn-OIL
3332-093
L
3330-181
Rigid
1/4 turn-ATF
3332-101
L
3330-182
Flex 90
1/4 turn-ATF
3332-102
L
3330-183
Flex
1/4 turn-ATF
3332-103
L
3330-184
Flex Memory
1/4 turn-ATF
3332-104
L
Verify ID of ATF fill port for compatibility.
SPECIFICATIONS
Flow Range
0.5-5.3 gal/min (2-20 l/min)
Max pressure
1,450 psi (100 bar)
Dispense
Nozzle OD
Auto = 0.605”
Manual ¼ turn for OIL = 0.705”
Manual ¼ turn for ATF= 0.315”
Verify ID of ATF fill port for compatibility
Swivel inlet:
1/2” NPT(F) Swivel
Operating temp
110 to 160 ºF (-23 to 70 ºC). Suitable for
extreme temperature conditions
Weight
3.75 lb (1.7 kg)
Compatible Fluids
Low to high viscosity lubricants, ATF, and
Antifreeze (Glycol)
Wetted Materials
Aluminum, stainless steel, zinc alloy,
Buna-N™, zinc plated steel, and brass.
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
Automotive | Commercial | Industrial
SB3096
6
Nozzles & Extensions
NOZZLES
(for use with the DR handles)
Item
Inlet
Tip OD
Max. Flow
Nozzle
3332-097
1/4” BSPP
0.605”
Verify ID of
ATF fill port for
compatibility.
2.1 gal/m
(8 l/m)
Auto
3332-096
1/4” BSPP
0.705”
Verify ID of
ATF fill port for
compatibility.
3332-105
1/4” BSPP
0.315”
Verify ID of
ATF fill port for
compatibility.
0.605 OD
0.705 OD
0.315 OD
Model
www.balcrank.com
3.7 gal/m
(14 l/m)
1/4 Turn
Manual
for OIL
ports
1/4 Turn
Manual
for ATF
ports
Verify ID of ATF fill port for compatibility.
DR EXTENSIONS & NOZZLES
7
3.7 gal/m
(14 l/m)
Inlet
Ext. Type
Nozzle
3332-098
1/2” NPT(M)
Rigid 60
Auto
Tip OD = 0.605”
3332-095
1/2” NPT(M)
Flex
Auto
Tip OD = 0.605”
3332-094
1/2” NPT(M)
Flex 90
Auto
Tip OD = 0.605”
3332-099
1/2” NPT(M)
Flex with Metal
Memory
Auto
Tip OD = 0.605”
product specifications are subject to change without prior notice
Extensions
Verify ID of ATF fill port for compatibility.
DR EXTENSIONS & NOZZLES
3332-091
1/2” NPT(M)
Rigid 60
For OIL ports
1/4 Turn Manual
Tip OD = 0.705”
3332-100
1/2” NPT(M)
Flex
For OIL ports
1/4 Turn Manual
Tip OD = 0.705”
3332-092
1/2” NPT(M)
Flex 90
For OIL ports
1/4 Turn Manual
Tip OD = 0.705”
3332-093
1/2” NPT(M)
Flex with Metal
Memory
For OIL ports
1/4 Turn Manual
Tip OD = 0.705”
3332-101
1/2” NPT(M)
Rigid 60
For ATF ports
1/4 Turn Manual
Tip OD = 0.315”
3332-103
1/2” NPT(M)
Flex
For ATF ports
1/4 Turn Manual
Tip OD = 0.315”
3332-102
1/2” NPT(M)
Flex 90
For ATF ports
1/4 Turn Manual
Tip OD = 0.315”
3332-104
1/2” NPT(M)
Flex with Metal
Memory
For ATF ports
1/4 Turn Manual
Tip OD = 0.315”
Automotive | Commercial | Industrial
8
Hi-Flow Metered
Introducing the new HF (High Flow) Metered Control
Handle from Balcrank
The Balcrank electronic-meter control valves have been specifically designed to measure and
dispense volumes of all kind of synthetic and mineral oils and to lead the competition in technology
and innovation. Balcrank manufactures a range of oval-gear electronic meters, which can be
programmed to register in either liters, quarts, pints or gallons to cover the needs of fluid dispensing
ranging in truck, fleet, off-road, mining and marine maintenance facilities.
ACCURACY
•
•
•
•
•
•
•
•
•
•
•
No calibration required. Precision machined fluid chamber keeping tight tolerances
together with individual wet test for performance and accuracy, guarantees accurate
dispensing regardless the fluid viscosity, outside temperature and system pressure.
Oval gear meter technology is adequate high count precision and low flow
resistance.
Multiple units of measure: liters, quarts, pints or gallons. Readout in 0,01 increments
for precise fillings.
Trip mode function: re-settable totalizer function can operate as an economical
simple fluid inventory control system.
Non-re-settable totalizer function.
Polycarbonate housing provides superb impact resistance for durability even in the
toughest environments.
Tough Thermo Plastic Elastomer boot surrounds the entire meter for even greater
durability.
Sealed battery compartment: battery clips mounted on PCB, no cables for battery
contact that ensures protection against impact or vibrations.
Fluid chamber is isolated from electronic chamber to prevent leaks.
Extensively and rigorously field tested for reliable performance in all shop situations.
Meter mounted to a Heavy Duty control valve.
TOUGHNESS AND EXTRA PERFORMANCE
•
Flow rate up to 18.5 gpm (70 lpm) with a non-drip tip.
•
Maximum working pressure up to 1,450 psi (100 bar).
•
Full metal control valve manufactured in durable aluminum die cast body to stand
the toughest working conditions.
•
High flow pressure balanced valve for comfortable use. Manufactured in brass for
long life operation.
•
Safety guard avoids accidental openings.
•
Lockable valve lever for easy delivery of large volumes.
•
High port (1” or 3/4”) ball bearing inlet swivel, with easy removable filter.
9
www.balcrank.com
product specifications are subject to change without prior notice
Hi-Flow Metered
DIMENSIONS
FEATURES
High Flow Control Handle is designed for service where
larger volume deliveries are required.
• High volume rigid or flexible outlets with non-drip tip.
• Outlet with 3/4” or 1” BSPP(M) connection thread and
bonded seal to assure a leak free operation.
• Used where metered fast delivery is required
• Ideal for bulk fill, transfer, and high flow dispense
• Heavy duty rigid design
APPLICATIONS
• High volume lubricants dispensing and bulk oil transfer
on busy truck garages
• Mining and construction vehicles
• Lube and service trucks
• Manufacturing plants
AVAILABLE MODELS
3330-197
Rigid - Metered
3/4” BSPP(F) Inlet
3330-198
Flex - Metered
3/4” BSPP(F) Inlet
3330-199
Rigid - Metered
1” BSPP(F) Inlet
3330-200
Flex - Metered
1” BSPP(F) Inlet
SPECIFICATIONS
Units of
measure
Batch: Liters, quarts, pints, gallons
Accuracy
+/-0,5% of reading
Flow Range
0.26-18 gal/min) (2-70 l/min)
Max pressure
1,450 psi (100 bar)
Swivel inlet:
3/4” & 1” BSPP (F) Inlet
Operating Temp
-10 to 158 ºF (-23 to 70 ºC)
Weight
4.4 lbs (2kg)
Compatible Fluids
Lubricants, Diesel, Oil, ATF, Antifreeze,
Gear Oil Maximum viscosity SAE 140
Wetted Materials
Liquid Crystal Polymer (LCP), aluminium,
stainless steel, Buna-NTM, zinc plated,
steel, and brass
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
Automotive | Commercial | Industrial
SB3097-Handle
SB3098-Meter
10
Hi-Flow Non-Metered
Introducing the new HF (High Flow) Non-Metered Control
Handle from Balcrank
The Balcrank mechanical-metered control valves have been specifically designed to measure and dispense
volumes of all kinds of synthetic and mineral oils and to lead the competition in technology and innovation.
Balcrank manufactures a full range of rotary-piston mechanical meters, graduated in Quarts, Gallons or Liters
to cover the needs of production lines, when filling engines, gear boxes and transmissions; or when dispensing
lubricants in fleet service shops, off-road vehicles, mining, or marine equipment maintenance facilities.
Our line of mechanical meters is especially suitable for tough jobs and extreme environmental conditions.
ACCURACY
•
•
•
•
•
•
•
•
•
•
•
No calibration required. Precision machined fluid chamber keeping tight tolerances
together with individual wet test for performance and accuracy, guarantees accurate
dispensing regardless the fluid viscosity, outside temperature and system pressure.
Oval gear meter technology is adequate high count precision and low flow resistance.
Multiple units of measure: liters, quarts, pints or gallons. Readout in 0.01 increments for
precise fillings.
Trip mode function: re-settable totalizer function can operate as an economical simple
fluid inventory control system.
Non-re-settable totalizer function
Polycarbonate housing provides superb impact resistance for durability even in the
toughest environments.
Tough Thermo Plastic Elastomer boot surrounds the entire meter for even greater
durability.
Sealed battery compartment: battery clips mounted on PCB, no cables for battery
contact that ensures protection against impact or vibrations.
Fluid chamber is isolated from electronic chamber to prevent leaks.
Extensively and rigorously field tested for reliable performance in all shop situations.
Meter mounted to a Heavy Duty control valve.
TOUGHNESS AND EXTRA PERFORMANCE
•
Flow rate up to 18.5 gpm (70 lpm) with a non-drip tip
•
Maximum working pressure up to 1,450 psi (100 bar).
•
Full metal control valve manufactured in durable aluminum die cast body to stand the
toughest working conditions.
•
High flow pressure balanced valve for comfortable use.
•
Manufactured in brass for long life operation.
•
Safety guard avoids accidental openings.
•
Lockable valve lever for easy delivery of large volumes.
•
High port (1” or 3/4”) ball bearing inlet swivel, with easy removable filter.
11
www.balcrank.com
product specifications are subject to change without prior notice
Hi-Flow Non-Metered
FEATURES
High Flow Control Handle is designed for service where
larger volume deliveries are required.
• High volume rigid or flexible outlets with non-drip tip.
• Outlet with 3/4” or 1” BSPP (M) connection thread and
bonded seal to assure a leak free operation.
• Ideal for bulk fill, transfer, and high flow dispense
• Heavy duty rigid design
APPLICATIONS
• High volume lubricants dispensing and bulk oil transfer
on busy truck garages
• Mining and construction vehicles
• Lube and service trucks
• Manufacturing plants
AVAILABLE MODELS
3320-051
Rigid - Non-Metered
3/4” BSPP (F) Inlet
3320-052
Flex - Non-Metered
3/4” BSPP (F) Inlet
3320-053
Rigid - Non-Metered
1” BSPP (F) Inlet
3320-054
Flex - Non-Metered
1” BSPP (F) Inlet
SPECIFICATIONS
Max pressure
1,450 psi (100 bar)
Swivel inlet:
3/4” & 1” BSPP (F) Inlet
Compatible Fluids
Lubricants, Diesel, Oil, ATF, Antifreeze,
Gear Oil Maximum viscosity SAE 140
Wetted Materials
Aluminum, Carbon Steel, Brass, and
Buna-NTM
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
Automotive | Commercial | Industrial
SB3097
12
Grease - Comfort Grip
FEATURES
• Precision-machined, all steel handle and forged body
provides reliable service
• Precise, proportional trigger action
• Balanced and knurled grip for less fatigue
• Easily repaired for extended life
• For use with pneumatic grease pumps with a
50:1 ratio or less
AVAILABLE MODELS
3310-030
Comfort Grip Grease Handle
3310-031
Grease Handle with 18” Whip Hose
and Z-swivel
3310-032
Grease Handle with 36” Whip Hose
and Z-swivel
CONTROL HANDLE SPECIFICATIONS
Max pressure
Handle
7,250 psi (500 bar)
Whip Hose
5,000 psi (345 bar)
Z-Swivel
5,000 psi (345 bar)
Swivel inlet:
1/4” NPT(F)
Compatible Fluids
NLGI #2 Grease
Wetted Materials
Steel and Aluminum
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
13
www.balcrank.com
SB3094
product specifications are subject to change without prior notice
Grease - Pro-series
FEATURES
• Precision-machined, all steel handle and forged
body provides reliable service
• Precise, proportional trigger action
• Balanced and knurled grip for less fatigue
• Inlet screen included
• For use with pneumatic grease pumps with a 50:1
ratio or less
AVAILABLE MODELS
3310-008
Pro Series Grease Handle
3310-010
Pro Series Grease Handle
with Z-swivel
3310-020
Pro Series Grease Handle
with 36” Whip Hose and Z-swivel
3310-025
Pro Series Grease Handle
with 18” Whip Hose and Z-swivel
SPECIFICATIONS
3310-010
Max pressure
5,000 psi (345 bar)
Swivel inlet
1/4” NPT(M)
Compatible Fluids
NLGI #2 Grease
Wetted Materials
Steel
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
SB3018
FEATURES
The Premium Booster Series High Pressure Control
Handle is designed for use as a standard control
handle and as a “Booster” when extreme pressures are
required. A single shot of lubricant is delivered when
the trigger is pulled from the forward position and then
immediately released. A continuous flow of lubricant
is delivered when the trigger is pulled from the forward
position and held against the body of the handle. When
higher pressures are required, just squeeze or pump
the trigger as needed up to approximately ten times to
increase pressure up to 10,000 psi (689.5 bar).
AVAILABLE MODELS
3310-009
3310-007
Pro Series Booster Grease Handle
3310-009
Pro Series Booster Grease Handle
with Z-swivel
SPECIFICATIONS
Max pressure
5,000 psi (345 bar) building to
10,000 psi (690 bar)
Swivel inlet
1/4” NPT(M)
Compatible Fluids
NLGI #2 Grease
Wetted Materials
SERVICE BULLETIN & ACCESSORIES
Service Bulletin
Automotive | Commercial | Industrial
SB3006
14
Customer Support
Technical Support
800-747-5300 or 828-645-4261
800-747-5300 or 828-645-4261
(Mon. - Fri., 8 am - 5 p.m. ET)
(Mon. - Fri., 8 am - 5 p.m. ET)
• Repair advice
• Product application recommendations
• Warranty claims and returns
• Service bulletins
• Order entry
• Product availability and information
• Pricing
• Shipping dates and delivery information
• Return Merchandise Authorization
E-mail Ordering & Online Support
Order by fax
800-763-0840 or 828-658-0840
• Fax orders day or night
• Free-up phone lines
• Order confirmed next business day by fax or e-mail
Website:
E-mail:
E-mail Ordering:
www.balcrank.com
[email protected]
[email protected]
Members of
Distributor:
Product group from well-managed forests,
controlled sources, and recycled wood
or fiber.
Forest Stewardship Council
Balcrank Corporation | 115 Reems Creek Rd. Weaverville, NC 28787 | 800-747-5300 | www.balcrank.com | [email protected] | F5307 Rev A
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
