EZ Patch - Legrand
NEW
EZ Patch
™
PATC H C O R D
DISPENSING
SOLUTION
Installation Made EZ!
The Ortronics® patent pending EZ Patch solution is
a revolutionary way to dispense and manage patch
cords, reducing installation time and waste. There are
no bags to open, tie wraps to undo or straightening
necessary; the cords dispense one after another, ready
to install. With EZ Patch, staging areas are clean, neat
and completely organized.
FEATURES & BENEFITS
■■
Dispenses patch cords quickly and easily,
reducing staging and installation time
■■
Significantly reduces the amount of trash
typically generated from the opening of bagged
patch cords, creating a greener, friendlier
approach to patch cord packaging
■■
Provides a more organized staging area for
patch cords, eliminating the errors and tangles
from traditional staging
■■
100% recyclable
EZ Patch uses an innovative clip to connect patch cords
together, allowing cords to be distributed over
an internal cardboard reel and fed through the front
box opening. The corrugated cardboard box and
internal dispensing reel are made from 100% recyclable
materials, and the clip is made from 25% regrind
plastic. Each of these components is fully recyclable
after use, making the EZ Patch solution a
contributor towards LEED certification.
EZ Patch
™
ORDERING INFORMATION
The EZ Patch solution contains our Clarity 6A, 6 or 5E patch cords in standard
lengths and colors. All Clarity cords are factory tested to TIA/EIA 568C.2
component specifications for Category 6a, 6 and 5e.
Clarity 6A
PART NUMBER
DESCRIPTION
CONTAINS
PART NUMBER
QTY PER
CARTON
EZC6A03Q50-XX
EZ Patch Clarity 10G modular patch cord, 3'
OR-MC61003-XX
50
EZC6A05Q50-XX
EZ Patch Clarity 10G modular patch cord, 5'
OR-MC61005-XX
50
EZC6A07Q40-XX
EZ Patch Clarity 10G modular patch cord, 7'
OR-MC61007-XX
40
EZC6A09Q30-XX
EZ Patch Clarity 10G modular patch cord, 9'
OR-MC61009-XX
30
EZC6A15Q20-XX
EZ Patch Clarity 10G modular patch cord, 15'
OR-MC610015-XX
20
To order standard colors, replace xx suffix: -06 = blue, -05 = green, and EZC6A15Q20-XX, 15’, is only
available in -06 = blue
Clarity 6
PART NUMBER
DESCRIPTION
CONTAINS
PART NUMBER
QTY PER
CARTON
EZC603Q50-XX
EZ Patch Clarity 6 modular patch cord, 3'
OR-MC603-XX
50
EZC605Q50-XX
EZ Patch Clarity 6 modular patch cord, 5'
OR-MC605-XX
50
EZC607Q50-XX
EZ Patch Clarity 6 modular patch cord, 7'
OR-MC607-XX
50
EZC609Q40-XX
EZ Patch Clarity 6 modular patch cord, 9'
OR-MC609-XX
40
EZC610Q40-XX
EZ Patch Clarity 6 modular patch cord, 10'
OR-MC610-XX
40
EZC615Q25-XX
EZ Patch Clarity 6 modular patch cord, 15'
OR-MC615-XX
25
To order standard colors, replace xx suffix: -09 = white, -08 = gray, -06 = blue, -05 = green, -04 = yellow, -02 = red
EZC610Q40-XX, 10’, is available in -06 = blue, -05 = green, -04 = yellow
EZC615Q25-XX, 15’, is available in -06 = blue, -05 = green, -04 = yellow, -02 = red
Clarity 5E
PART NUMBER
DESCRIPTION
CONTAINS
PART NUMBER
QTY PER
CARTON
EZC5E03Q50-XX
EZ Patch Clarity 5E modular patch cord, 3'
OR-MC5E03-XX
50
EZC5E05Q50-XX
EZ Patch Clarity 5E modular patch cord, 5'
OR-MC5E05-XX
50
EZC5E07Q50-XX
EZ Patch Clarity 5E modular patch cord, 7'
OR-MC5E07-XX
50
EZC5E09Q40-XX
EZ Patch Clarity 5E modular patch cord, 9'
OR-MC5E09-XX
40
EZC5E10Q40-XX
EZ Patch Clarity 5E modular patch cord, 10'
OR-MC5E10-XX
40
EZC5E15Q25-XX
EZ Patch Clarity 5E modular patch cord, 15'
OR-MC5E15-XX
25
To order standard colors, replace xx suffix: -09 = white, -08 = gray, -06 = blue, -05 = green, -04 = yellow
EZC5E10Q40-XX, 10’, and EZC5E15Q25-XX, 15’, are available in -06 = blue, -05 = green, -04 = yellow only
