Week 06: 22 - 26 June, 2015

Week 06: 22 - 26 June, 2015

Week 06: 22 - 26 June, 2015

Tools Required for Crimping

“Modular Crimp Tool”

Tools Required for Crimping

“RJ45 Modular Plug” (Male)

Tools Required for Crimping

“Cable” (UTP)

Tools Required for Crimping

“Scissor” / “Knife” (Cutter)

Colored Wired

TIA/EIA 568A Wiring TIA/EIA 568B Wiring

White/Green

Green

White/Orange

Blue

White/Blue

Orange

White/Brown

Brown

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

TIA/EIA 568A

White/Green

Green

White/Orange

Blue

White/Blue

Orange

White/Brown

Brown

TIA/EIA 568B

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

Straight Cable

Used for PC to Hub/Switch

Crossed Cable

Used for Hub/Switch to Hub/Switch

Or PC to PC

How to Crimp RJ45

1. Cut and Strip the cable

How to Crimp RJ45

1. Cut and Strip the cable

How to Crimp RJ45

2. Separating the colored wires

How to Crimp RJ45

3. Arrange the cables as per diagram

(type B)

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

How to Crimp RJ45

4. Put the cables inside the connector

How to Crimp RJ45

4. Put the cables inside the connector

How to Crimp RJ45

5. Crimping the connector

How to Crimp RJ45

5. Crimping the connector

How Crimping tool work
