UPS technology for every aPPlication

Mains voltage variations occur more often than expected. The consequences of this are crashes, loss of data and cost intensive downtime. The solution is an uninterruptible power supply (UPS) which offers a variety of levels of protection.

Uninterruptible power supply

There are three different

UPS topologies offering different protection levels against all types of mains disruption and variation.

VFD technology

“Voltage and Frequency

Dependent” in compliance with IEC 62040-3, also referred to as offline, protects against many problems in your network. Under normal conditions it conducts the input current to its outlet.

When the power supply fails it switches over to a built in battery to compensate for any variations in the mains supply.

Benefits

• Smallest size

• Highest efficiency

• Lowest operating costs

VI technology

“Voltage Independent” in compliance with IEC 62040-3, also known as line interactive, protects against the most common power problems experienced in a network.

Here the UPS also monitors the voltage level and balances under and over voltages.

The VI technology offers a good compromise between reasonable security and moderate operating costs.

Benefits

• Extremely wide input voltage window

• Rugged design

• High efficiency

• Low operating costs

Outage-blackouts

Sags / brownouts

Dynamic overvoltage

Undervoltage (continuous)

Overvoltage (continuous)

Transients /surges

Frequency variations

Voltage distortions (bursts)

Voltage harmonics

Optimum protection for every application

VFD VI VFI

Offline

Line interactive

Online

VFI technology

“Voltage and Frequency

Independent” in compliance with IEC 62040-3, as well as online or double conversion offers superior protection against problems in the power supply. Here, the input voltage is fed to a rectifier, with output being supplied by an inverter.

Under normal operating conditions, the inverter receives its supply directly from the rectifier, when the power supply fails it is supplied directly from the batteries.

Consumers have no direct connection to mains AC power supply; the UPS protects them from all power grid problems.

In critical situations and with sensitive equipment, protection by VFI technology is highly reccomended.

Benefits

• Sinusoidal input current and output voltage

• No switching times, therefore no gaps in coverage

• Frequency converter operation possible

• Additional internal redundancy switch over

• Optimum protection against power disturbances

3

4

Protect home

Uninterruptible security for PCs and multimedia

Protect yourself with an uninterruptible power supply against data loss. With an output of 600 VA, Protect

Home protects. It measures and protects against the consequences of power outages, voltage fluctuations and dangerous power spikes.

Appropriate protection

Protect Home is especially designed for domestic multimedia applications.

It provides complete surge protection for telephone, fax and modem.

Consumers are connected directly to protected sockets directly through the UPS.

Protect Home has all of the features that current technology can provide to protect your valuable equipment from short circuit and power overload.

Easy to use

The clear “one board” design and LED indicators let you know about the most important operating conditions. This ease of use is complemented by an audible alarm.

Easy to control

Protect Home can be connected quickly and easily with a PC or Mac via the

USB or RS232 interfaces.

Through the included

AEG shutdown software

“CompuWatch”, the unit allows you to control the most important operations as well as providing automatic shutdown during longer power outages.

Main characteristics

• Rugged UPS technology for power outages, voltage fluctuations and spikes

• USB and RS232 interface for control and management for PC and Mac

• Fully fledged “CompuWatch”

“plug&play” software

• Data line protection

(telephone, fax and modem)

• User friendly battery design

(access to the battery compartment on the underside of the equipment)

• Individual operation, wall mountable

• 1 output for connecting consumers with high power requirements such as laser printers

Best features:

Comprehensive protection for telephone, fax or modem, USB and serial port for communication with your PC or Mac.

Mains input cord

Input circuit breaker

Overload protection telephone / fax / modem

RS232 USB

Classification VFD SY 322 acc. to IEC 62040-3

Power type rating

Part number

UPS InPUt

Input voltage

Voltage range without battery supply

Frequency

Current consumption

UPS oUtPUt

Rated output voltage

Rated output voltage in battery mode

Frequency in battery mode output current transfer time at mains outage

Voltage waveform overload /short circuit protection

BAttERY type

Rated voltage (linked)

Autonomy time for 1 PC with 17" tFt overload / deep discharge protection

Recharge time (to 90 % of rated capacity)

CoMMUnICAtIon

Interfaces

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Data line protection outputs

Equipment color

Dimensions approx. W x H x D (mm)

Weight approx.

Shipment

Conformity

Protect Home

600 VA

300 W

600 001 1844 (UK)

600 001 2013 (FR)

230 VAC

+6 % / -10 %

50 Hz / 60 Hz ±5 Hz

3 A

230 VAC

±10 %

50 Hz / 60 Hz ±1 Hz

2.6 A

2 – 6 ms (typical)

Modified sine wave

Yes

Sealed, maintenance free (proprietary brand)

12 VDC

~ 10 min.

Yes

8 h

USB and RS232 for status and measurement levels

Included for all mainstream operating systems (e.g. Windows, Linux, Mac)

Mains failure, overload, battery low, fault

<40 dB(A) (fanless)

0° – 40 °C

20 – 90 %

Up to 1000 m at nominal load

EN 62040-2 Class C2, EN 61000-3-2, EN 61000-3-3

EN 62040-1

RJ11 (telephone, fax, modem)

4 shock proof sockets

(4 x surge protection, 3 x UPS protection)

Blackline, high gloss finish

137 x 96 x 310

3.5 kg

Mains input cord, management software “CompuWatch” (CD),

USB and RS232 communication cable, operating instructions

CE

5

6

Protect alPha

Uninterruptible security for applications in the SoHo sector

Protect yourself using an uninterruptible power supply for optimal protection against loss of data wherever you need it. Available in the 450 VA to

1200 VA power range the series stands for solid, yet affordable, protection for numerous applications in the small and home office environment.

Protect alpha uses robust line interactive technology and therefore guarantees a stable power supply to the connected loads over a wide power input voltage range and without strain on the internal battery system.

Flexibility in our lineup

The fanless design combined with compact dimensions and a low weight are capable of accommodating even the most difficult conditions.

Easy to use

All models are characteristically easy to use and are equipped with an audible alarm and automatic grid frequency detection (50 / 60 Hz). An LED display on the front panel provides information about the current operating status.

Immediate operational readiness with the supplied cable set contributes to the ease of use.

All functions are microprocessor controlled and monitored; measurement values and messages are always available because Protect A communicates via a USB interface to your PC. Through the included

AEG shutdown software

“CompuWatch”, the unit allows you to control the most important operations as well as providing automatic shutdown during longer power outages.

Main characteristics

• Modern VI (line interactive) technology for power outages and dangerous over voltage

• Automatic voltage regulation against voltage fluctuations

(AVR)

• Silent operation due to fanless design

• Easy installation with the supplied cables and easy handling

• Sealed, maintenance-free branded lead acid batteries with discharge protection

• USB interface for PC connection

• Data line protection for telephone, fax and modem

(RJ11)

• Compact dimensions, low weight

Overvoltage protection for data interface, fax, modem

UPS input

Protect alpha 450 / 600 / 800 – rear view

UPS input

UPS outputs with battery backup and overvoltage protection

USB port on the front panel

Protect alpha 1200 – rear view

USB

Overvoltage protection for data interface, fax, modem and network

UPS outputs with battery backup and overvoltage protection

Classification VI SY 322 acc. to IEC 62040-3 type rating

Part number

UPS InPUt nominal connection voltage

Voltage range without battery operation

Frequency (automatic selection)

UPS oUtPUt

Rated output voltage / AVR technology

Rated output voltage in battery operation

Frequency in battery operation nominal output current (at 230 VAC)

Changeover time in the event of mains failure

Voltage curve overload protection

BAttERY type

Autonomy time at 120 W

Exhaustive discharge protection / protection against excess load

Charging time (to 90 % of rated capacity)

CoMMUnICAtIon

Interfaces

Indicator

Audible alarms

Status display

GEnERAl DAtA

Inherent noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety overvoltage protection for data lines

Mains input load outputs

Housing color

Dimensions approx. W x H x D (mm)

Weight approx.

Scope of delivery

Conformity

alpha 450

450 VA

240 W

600 001 4746 alpha 600

600 VA

360 W

600 001 4747 alpha 800

800 VA

480 W

600 001 4748

220 VAC / 230 VAC / 240 VAC

170 – 280 VAC

50 Hz / 60 Hz ±5 Hz alpha 1200

1200 VA

600 W

600 001 4749

2 A

~5 min.

220 VAC / 230 VAC / 240 VAC

±10 %

50 Hz / 60 Hz ±1 Hz

2.6 A 3.5 A

4 – 8 ms (typical)

Modified sine wave

Yes

Sealed, maintenance free (proprietary brand)

~10 min.

~15 min.

Yes

6 h

USB (with status messages and measured values)

AC mode, battery mode

Backup mode, low battery, overload, fault

LED display

5.2 A

~20 min.

mains / battery use failure warning

3.7 kg

<40 dB(A)

Fanless

0° – 40 °C

0 – 90 % (without condensation)

Up to 1000 m at nominal load

EN 62040-2 class C2, EN 61000-3-2, EN 61000-3-3

EN 62040-1

RJ11 (phone, fax, modem)

IEC 320 C14

4 x IEC 320 C13

Blackline

100 x 143 x 278 139 x 195 x 365

4.4 kg 5.2 kg

Mains connection, management software “CompuWatch” (CD),

1 device connecting cable, 1 USB cable, operating instructions

CE

6 x IEC 320 C13

8.6 kg

7

8

Protect a

Uninterruptible security for PCs, workstations and telephone systems

The Protect A series protects your data efficiently and cost effectively against the consequences of power outages, voltage fluctuations and power surges.

Thanks to the increased range of services it is suitable for consumers with increased input current requirements.

The attractive modern design is characterized by the high technical standards that are in place.

Protect A proves itself in critical situations with its high availability thanks to modern line-interactive (VI) technology, robust network overload and surge protection, as well as a very wide power input voltage range.

Easy to use

The reliable “one-board design” and the clear LCD display (A. 1000 / A. 1400) on the front clearly informs you about the most important operating conditions. All models benefit from ease of use, an audible alarm and automatic frequency detection

(50 / 60 Hz). Immediate use with the supplied cable set contributes to the ease of use.

Simple to control

All functions are microprocessor controlled and are constantly monitored as measured values and messages are available at all times because Protect

A communicates via RS232 or USB interface to the PC or

Mac. The included special AEG

“CompuWatch” shutdown software enables the most important operating systems to automatically shut down during longer power failure.

Main characteristics

• Modern VI (line-interactive) technology for power outages and dangerous over voltage

• Automatic voltage against voltage fluctuations (AVR)

• Double mains filter against voltage spikes

• Easy installation with the supplied cables and easy handling

• Sealed, maintenance-free branded lead acid batteries with discharge protection

• USB and RS232 interface for monitoring and control of PC or Mac

• Data Line Protection

• Connectors (n) for the direct supply of consumers with high power requirements, e.g. laser printer

Overvoltage protection for data interface, fax, modem

UPS outputs with battery backup and overvoltage protection

Protect A. 500 / A. 700 – rear view

RS232 USB

UPS output with overvoltage protection

UPS input

Mains input fuse

UPS outputs with battery backup and overvoltage protection

UPS input

Protect A. 1000 / A. 1400 – rear view

USB

Overvoltage protection for data interface, fax, modem and network

RS232

UPS outputs with overvoltage protection

Mains input fuse

Classification VI SY 322 acc. to IEC 62040-3

Power type rating

Part number

UPS InPUt

Input voltage

Voltage range without battery mode

Frequency (automatic selection)

UPS oUtPUt

Rated output voltage / AVR technology

Rated output in battery mode

Frequency in battery mode nominal output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload protection

BAttERY type

Autonomy time (intermediate circuit)

Autonomy time for 1 PC with 17" tFt overload / deep discharge protection

Charging time (to 90 % of rated capacity)

CoMMUnICAtIon

Interfaces

Shutdown software (on CD)

Alarm messages (acoustic /visual)

GEnERAl DAtA

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Data line protection

Mains input outputs

Equipment color

Dimensions approx. W x H x D (mm)

Weight approx.

Shipment

Conformity

Fault indication display

Autonomy time

(min.)

A. 500

500 VA

300 W

600 000 6435

2.2 A

~10 min.

A. 700

700 VA

420 W

600 000 6436

A. 1000

1000 VA

600 W

600 000 6437

220 VAC / 230 VAC / 240 VAC

170 – 280 VAC

50 Hz / 60 Hz ±5 Hz

220 VAC / 230 VAC / 240 VAC

230 VAC ±10 %

50 Hz / 60 Hz ±1 Hz

3 A

2 – 6 ms (typical)

Approximated sinusoidal

4.3 A

Yes

12 VDC

Sealed, maintenance free (proprietary brand)

~15 min.

~25 min.

Yes

8 h

24 VDC

A. 1400

1400 VA

840 W

600 000 6438

6.1 A

~30 min.

USB and RS232 (with status messages and measured values)

Included in delivery for all major operating systems (e.g. Windows, Linux, Mac)

Mains failure, overload, battery discharged, replace battery, fault

LED Display

LCD display for input and output voltage [V] / efficiency [%] / autonomy time [min.]

<40 dB(A)

Fanless

<45 dB(A) (AC-operation <40 dB(A))

Speed controlled fan

0° – 40 °C

0 – 90 % (without condensation)

Up to 1000 m at nominal load

EN 62040-2 Class C2, EN 61000-3-2, EN 61000-3-3

RJ11 (telephone, fax, modem)

EN 62040-1

RJ11 / RJ45 (add. network), Ethernet 10 and 100 Mbit/s

IEC 320 C14

3 + 1 x IEC 320 C13

Blackline with silver colored front cover

4 + 2 x IEC 320 C13

100 x 140 x 330 145 x 205 x 405

6 kg 6.5 kg 9.5 kg 10 kg

Mains input cord, 2 device connecting cables, management software “CompuWatch” (CD) incl. 1 network license

USB and RS232 communication cable, operating instructions

CE

Operating status display

UPS input voltage

UPS output voltage

Protect A. 1000 / A. 1400 – display screen

Consumer load (%)

Battery voltage

9

10

Protect B. Pro

Rotary screen

Efficient and innovative UPS solutions for servers and networks

With its high power factor of

0.9lag, Protect B. PRO is one of the most efficient systems with VI protection technology.

Many ways of communication are possible, thanks to parallel operation of the

RS232 or USB interfaces and the extension slot.

Also, the adaptation of the

UPS to the requirements of modern IT environments is reflected by the design.

The UPS can be configured directly with the control panel.

Batteries can be easily replaced by means of the innovative flap mechanism at the front.

By means of the included accessories and the rotary screen, the UPS can be operated in the rack as well as in the tower mode.

Main characteristics

• Modern VI (line interactive) protection technology with sinus-shaped output voltage

• Low operating costs through high efficiency, power factor 0.9lag

• Compact shape, flexible use through combined design tower / rack, rotary screen

• Surge protection

(RJ11 / RJ45) for telephone, fax, modem and network

• Configuration directly on the LCD

LED operating status display

• Full display of the essential parameters on the screen, e.g. the remaining runtime in minutes

• Intelligent monitoring system with USB and

RS232 interface; parallel operation of USB / RS232 and extension slot is possible

• Additional battery packs available for B.1000 PRO,

B.1800 PRO and B.3000

PRO models for ease of scaling of autonomy times

Load display

Operating mode

Display for settings, remaining runtime

Display for UPS values

Battery status display

Control panel

Easy battery replacement through front flap

Included pedestals

Protect B.



PRO – LCD control panel

RS232 & USB communication interfaces Network protection

Extension slot

Network input

EPO Cooling fan

Protect B. 1000 PRO – rear view

8 x IEC 320 C13 outputs,

4 of them switchable

Classification VI SS 211 acc. to IEC 62040-3

Power type rating

Part number

Part number (battery pack)

UPS InPUt

Input voltage

Voltage range without battery mode

Frequency (auto selection)

Current consumption at nominal load (max.)

UPS oUtPUt

Rated output voltage / AVR technology

Frequency in battery mode output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response (VI operation) overload response (battery operation)

BAttERY type

Integrated

Rated voltage

Battery management

Autonomy time in min.

(full / half-load, cos j = 0.7lag)

Ditto UPS incl. battery expansion unit

Charging time (to 90 % rated capacity)

CoMMUnICAtIon

User interface

Interface (dual monitoring)

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency (in ECo mode)

Efficiency (at whole AVR range)

Audible noise (1 m distance)

Ditto in ECo mode and max. 70 % load operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Data line protection

Mains input number of outputs / controllable via connectors

Equipment color

Dimensions approx. W x H x D (mm)

Weight approx.

UPS incl. battery system

Battery expansion unit

Shipment

Conformity

B. 750 PRO

750 VA

675 W

600 000 8422

4 A

3.2 A

B. 1000 PRO

1000 VA

900 W

600 001 3872

600 001 3876

B. 1400 PRO

1400 VA

1260 W

600 000 8426

B. 1800 PRO

1800 VA

1620 W

600 001 3873

600 001 3874

220 VAC / 230 VAC / 240 VAC

±20 %

50 Hz / 60 Hz ±5 Hz

7.5 A 9.7 A

B. 2300 PRO

2300 VA

2070 W

600 000 8431

5.4 A 12.4 A

208 VAC / 220 VAC / 230 VAC (default) / 240 VAC ±10 % (±3 % free running)

50 Hz / 60 Hz ±1 Hz

4.3 A 6.1 A 7.8 A

2 – 6 ms (typical), 8 ms max.

10 A sinusoidal

<120 % for 5 min. / 120 – 150 % for 10 s / >150 % for 1 s

<110 % for 1 min. / 110 – 150 % for 10 s / 150 – 200 % for 500 ms

B. 3000 PRO

3000 VA

2700 W

600 001 3875

600 001 3877

16.1 A

13 A

5.5 / 15

Sealed, maintenance free (proprietary brand), hot swappable

Yes

48 VDC 24 VDC 72 VDC

Temperature compensated with overload and deep discharge protection; automatic battery test; battery pack detection

5.5 / 15

19.5 / 48

7 / 19 7 / 20

23 / 63

6 / 20

8 h

6 / 15

21 / 48

LCD display with digital indication of relevant UPS values

RS232 and USB (with status notification and UPS data), additional communication slot in parallel mode

(SNMP / relay card); input contact for emergency power off

5 network licenses for all common OS (e.g. Windows, Linux, Mac)

3 LED indicators show UPS status, detailed indication via LCD display

(mains failure, overload, battery discharge, battery replace, fan failure)

>97 %

>90 %

≤45 dB(A) ≤55 dB(A)

≤40 dB(A)

0° – 40 °C

0 – 90 % (without condensation)

≤45 dB(A)

Up to 1000 m at nominal load

EN 62040-2 Class C2, EN 61000-3-2, EN 61000-3-3

EN 62040-1

RJ11 (telephone, fax, modem) / RJ45 (Ethernet 10 Mbit/s / 100 Mbit/s)

IEC 320 C14

8 / 4

8 x IEC 320 C13

482.6 (19") x 88 (2 U) x 420

Black metal case / silver front

482.6 (19") x 88 (2 U) x 520

IEC 320 C20

7 / 3

6 x IEC 320 C13, 1 x IEC 320 C19

482.6 (19") x 88 (2 U) x 640

14.5 kg 15 kg

16 kg

24 kg 25 kg

26.5 kg

29 kg 29.5 kg

39 kg

Mains input cord, 2 x device connection cables (10 A), additional cable (16 A) for Protect B. 2300 PRO and Protect B. 3000 PRO, 2 x mounting brackets, 2 x base feet,

1 x management software “CompuWatch” (CD), 5 network licenses, RS232 and USB cable, operating instructions

CE

11

12

Protect c

Display of current UPS mode

Display of

UPS input

Indicator

UPS mode

Display of UPS output

Control panel

Protect C – LCD & control panel

Uninterruptible security for applications in the SMB sector

Real VFI / double conversion online technology suitable for safe supply application-critical consumers in the IT environment such as workstations, servers, storage systems, as well as in the area of sensitive switching and control systems.

The new Protect C models in the performance levels in

1000, 2000 and 3000 VA range represent consistent further development of the well-proven and highly reliable series.

With the lag increased to 0.8, the power factor was taken into account for the demand for higher performance active consumers. The ECO and frequency inverter for operation mode highlights the requirements for a modern versatile UPS.

optimal control and information

“Dual-monitoring” enabled interfaces extend communication opportunities. The universally usable communication slot also allows for the integration of SNMP network interface cards that allow for monitoring and management options, particularly multi-server shutdown.

The AEG “CompuWatch” shutdown software is always included.

The multilingual graphical LCD display provides all the important operating states and values that can be stored and retrieved in addition to realtime data storage in plain text.

Main characteristics

• VFI topology (online / double conversion) protection against all mains network problems

• Extremely wide input voltage window of 110 VAC to

300 VAC without stress on the internal battery system and with a stable output voltage

• ECO and frequency operating voltage possible

• Expansion slot for SNMP, potential free contacts, remote display

• Graphic LCD display with interactive multilingual user interface

• Configuration options

(password protected) via the operator terminal

• Internal hardware data logger with plain text display and date / time stamp

• Emergency power off on terminal block (potential-free)

(EPO) Emergency Power

Off

Expansion slot for communication cards

USB

RS232

Monitored ventilator with intelligent revolution regulation

Fused mains input

IEC 320 C20

Protect C. 3000 – rear view

Connection for additional battery modules

IEC 320 C19 outlet for access to full power output

4 X IEC 320 C13 ouputs with 10A fuses for each IEC output pair

Connection for UPS output voltage via internal terminal strip

PRotECt C

(cos j = 0.7lag)

Default autonomy time

1 additional battery module

2 additional battery module

Autonomy time (full / half load) (min.)

1000 VA

6/21

38/97

76/170

Autonomy time – battery units resemble UPS

2000 VA

10/30

55/130

106/237

3000 VA

5/16

30/85

60/149

Classification VFI SS 111* acc. to IEC 62040-3

Power type rating

Part number

(UPS including integrated battery system)

Part number (additional battery pack)

UPS InPUt

Input voltage

Voltage range without battery mode

(load dependent)

Frequency (auto selection)

Mains current (system reaction)

Current consumption at nominal load (max.)

(at 230 VAC incl. max. battery charging current)

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery / frequency converter mode nominal output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response

(double conversion & battery mode)

Crest factor

Short circuit response

BAttERY type

Rated voltage (linked)

Battery management

Charging time (to 90 % rated capacity)

CoMMUnICAtIon

Interfaces (dual monitoring)

Shutdown software (on CD)

User interface / failure indication

(acoustic /visual)

GEnERAl DAtA

Efficiency (ECo mode)

Efficiency at nominal load (double conversion mode)

Audible noise (1 m distance) temperature range

Humidity operation altitude

EMC conformity

Product safety

Mains input number of outputs

Equipment color

Dimensions approx. W x H x D (mm) UPS

Dimensions approx. W x H x D (mm) battery

Weight approx. UPS

Weight approx. battery

Shipment

Conformity

C. 1000

1000 VA

800 W

600 001 6103

600 001 6106

C. 2000

2000 VA

1600 W

600 001 6104

600 001 6107

220 VAC / 230 VAC / 240 VAC

110 – 300 VAC

50 Hz / 60 Hz ±10 Hz

λ ≥0.99 (THDi <5%)

8.5 A

C. 3000

3000 VA

2400 W

600 001 6105

12.5 A 4.6 A

200 VAC / 208 VAC / 220 VAC / 230 VAC (default setting) / 240 VAC ±2 %

50 Hz / 60 Hz ±0.2 Hz

4.3 A 8.7 A

0 ms (without interruption)

13 A

Sinusoidal, distortion <3 %

<110 % for 60 s / 110 % up to <125 % for 30s / 125 % up to 150 % for 10s

Subsequent, transfer to bypass mode (if bypass available)

3 : 1

Short circuit proof (3 x I

N

for 100 ms)

36 VDC

Sealed, maintenance-free (proprietary brand), integrated

96 VDC

Exhaustive discharge protection / Protection against excess load

Automatic battery test (daily, weekly, monthly)

5 h

RS232, USB, communication slot (can be used parallel with RS232 / USB), input contact for emergency power off

5 network licenses for all common OS (e.g. Windows, Linux, Mac, Unix)

3 LED’s with traffic light display, detailed indication via LCD display

(alarms: at mains failure, overload, battery charging, battery replacement, fan fault data logger – with clear text display incl. Date and time history)

>93 %

>87%

≤44 dB(A)

4 x IEC 320 C13

≤49 dB(A) with intelligent fan speed control and fan monitoring

0 – 45 %

>94 %

>88 %

0 – 95 % (no condensation)

Up to 1000 m at nominal load

EN 62040-2 Class C1, EN 61000-3-2, EN 61000-3-3

EN 62040-1

IEC 320 C14

6 x IEC 320 C13

IEC 320 C20

4 x IEC 320 C13

1 x IEC 320 C19 + terminal

145 x 220 x 400

Blackline with silver colored front cover

190 x 345 x 460

Integrated (additional battery pack same dimensions as UPS)

13 kg

19 kg

31 kg

52 kg

Mains input cord, 2 device cords, communication cable (USB), management software

“CompuWatch” (CD), incl. 5 network licences, operating instructions

CE

*

excl. ECO / Bypass mode

13

14

Protect c.

6000 /10000

High-performance

UPS system for

It applications

Thanks to genuine VFI technology (online / double conversion), Protect C is suitable for all critical business applications.

The proven VFI topology of

Protect C protects against all network problems as a matter of principle. A sinus-shaped power feed is achieved under all load conditions at the input.

PRotECt C

Default autonomy time

1 additional battery module

2 additional battery modules

3 additional battery modules

4 additional battery modules

Autonomy time – battery units resemble UPS

Autonomy time (full / half-load) (min.)

6000 VA 10000 VA

8/26

26/67

5/16

16/42

47/112

67/157

94/203

27/60

42/97

53/118

Cooling fans RS232

Communication slot for optional communication cards:

SNMP, remote panel and potential free contacts

Port for parallel operation

Port unit for external battery module(s)

Network input security device

Manual bypass switch

Connector clamps for network in and output, additional clamp pair for the setting of individual or parallel operation

Highly integrated switches and a robust IGBT module reduce the number of electrical connections and components and therefore provide for increased reliability. A Static

Bypass Switch (SBS) and / or an automated bypass ensure additional safety in case of overload.

Maximum control

The bar displays for UPS load and battery capacity, as well as the clear pictogram of the system components provide information on the essential operating conditions.

Data is transmitted through an RS232 interface. With an optional SNMP (PRO) adapter, remote monitoring via a web browser and multi-server shutdown are possible.

The special AEG shutdown software “CompuWatch” is of course included.

Switchable in parallel

Protect C. 6000 and C. 10000 offer the possibility of parallel operation. Both active redundancy and higher availability are achieved with higher power requirements being taken into account.

Also, the combination of power increase and active redundancy is possible, as up to 3 devices can be switched in parallel.

Protect C meets the highest security and availability requirements and allows for an economical implementation.

Main characteristics

• VFI topology (online / double conversion) protects against all network problems

• Micro processor control / digital signal processors for maximum availability

• Sinus-shaped power feed

(high-frequency pulse width modulation with IGBTs)

• n+x technology for redundancy and performance increase

• Extension slot for SNMP, potential-free contacts, remote panel

• Also available as an

S-version with reinforced charging rectifier

• Space saving design with integrated battery system

• Integrated fault operation security for manual bypass switch

Protect C. 10000 – rear view

Classification VFI SS 111 acc. to IEC 62040-3

Power type rating

Part number

(UPS including integrated battery system)

Part number (battery pack)

Part number (UPS S–version)

UPS InPUt

Input voltage

Voltage range without battery mode

Frequency (auto selection)

Mains current (system reaction)

Current consumption at nominal load (max.)

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery mode output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response (online operation)

Crest factor

Short circuit response

BAttERY type

Rated voltage (linked) overload / deep discharge protection

Charging time (to 90 % rated capacity)

CoMMUnICAtIon

Interfaces

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency AC – AC (at nominal load)

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Mains input

Consumer outputs

Equipment color

Dimensions approx. W x H x D (mm) UPS

Dimensions approx. W x H x D (mm) battery

Weight approx. UPS

Weight approx. battery

Shipment

Conformity

C. 6000

6000 VA

4200 W

Parallel connection

600 000 5877

600 000 5879

600 000 4340

C. 10000

10000 VA

7000 W

Parallel connection

600 000 5878

600 000 5880

600 000 4341

220 VAC / 230 VAC / 240 VAC

176 – 276 VAC

50 Hz / 60 Hz ±4 Hz

λ ≥0.98

31 A 50 A

26 A

220 VAC / 230 VAC (default) / 240 VAC ±1 %

50 Hz / 60 Hz ±0.1 %

43.4 A

0 ms (without interruption)

Sinusoidal, distortion THD <4 %

<130 % for 10 min. / 130 % for 1 s

Subsequent, transfer to bypass mode

3 : 1

Short circuit proof (3 x I

N

for 140 ms)

Sealed, maintenance free, integrated (proprietary brand)

240 VDC

Yes

7 h

RS232 (with status display and data), communications slot for SNMP, potential free relay contact

5 network licenses for all common OS (e.g. Windows, Linux, Mac)

LED display for UPS summary / battery capacity display, status display

Indicators for mains failure, overload, battery charging, battery replacement, failure

≥90 %

<55 dB(A)

0° – 40 °C

0 – 90 % (without condensation)

Up to 1000 m at nominal load

EN 62040-2 Class C3

EN 62040-1

Secured terminal block

Secured terminal block

Blackline with silver colored front cover

260 x 720 x 570

Integrated (not S-version battery pack same dimensions as UPS)

90 kg 93 kg

65 kg 68 kg

Parallel connection cable, management software “CompuWatch” (CD), communications cable, operating instructions

CE

15

16

Protect d

Display of current UPS mode

Display of

UPS input

Indicator

UPS mode

Display of UPS output

Extension slot Locking outputs Easy battery replacement

Efficient high-performance

UPS for rack use

With a high power factor of 0.9lag the Protect D series exceeds the power of conventional UPS systems by

20 %. Efficiency is significantly increased during normal operation as well as in the energy-efficient ECO and

ECO+ operating modes.

Compact and flexible

The height of the UPS electronics and battery together is only 2 U. With the flap front cover, battery replacement is very easy.

The autonomy times can be increased with additional battery packs; connected battery packs are automatically detected.

All batteries can be replaced during operation (hotswappable). Our advanced battery charging technology allows for short charging times and battery-preserving charging characteristics at the same time.

Many interfaces (RS232 /

USB / Slot / EPO) as well as a potential-free contact within the series ensure outstanding communication capacity.

Secure and easy to use

An innovative locking mechanism at the UPS outputs prevents accidental separation of the loads.

The multilingual graphic screen is very easy to read, even from a longer distance, thanks to its large format.

Together with three LEDs at the top, it displays the essential operating conditions. The UPS can be directly administered with the control panel.

A real-time event logger ensures careful observation and analysis of events as they occur. In addition, a regular automated battery test can be planned.

Main characteristics

• VFI topology (online /double conversion) protects against all network problems

• An increase of the available performance by approx. 20 % through a 0.9lag power factor

• Increased efficiency through the ECO and ECO+ mode

• Advanced battery charging technology for maximum durability of the battery

• Hot-swappable batteries, easy replacement through hinged front

• Additional battery packs for easy scaling of the autonomy times

• Extension slot for communication cards, communication in parallel is possible through the

RS232 / USB interface and SNMP

• Low height (2 U) including integrated batteries

• Switchable UPS outputs with innovative locking mechanism

• Display of the UPS parameters on a graphic LCD, direct configuration is possible with the control panel

• Freely programmable potential-free contact plus emergency shutdown contact

• May also be used as a frequency converter

Control panel

Protect D – LCD & control panel

4 x IEC 320 C13 outputs

EPO

Cooling fan

USB & RS232 communication ports

Network input

2 x 2 switchable

IEC 320 C13 outputs

Protect D. 2000 – rear view

Potential-free contact

Extension slot for communication cards

PRotECt D

(cos j = 0.7lag)

Default autonomy time

1 additional battery module

2 additional battery modules

3 additional battery modules

4 additional battery modules

Autonomy time (full / half-load) (min.)

1000 VA

9/24

35/71

63/130

94/194

126/261

Autonomy time – battery units resemble UPS

1500 VA

8/18

31/65

56/119

83/178

112/240

2000 VA

10/21

37/77

67/141

99/210

134/283

3000 VA

6/14

24/51

44/92

64/137

87/185

Classification VFI SS 111* acc. to IEC 62040-3

Power type rating

Part number

(UPS including integrated battery system)

Part number (additional battery pack)

UPS InPUt

Input voltage

Voltage range without battery mode

(load dependent)

Frequency (auto selection)

Mains current (system reaction)

Current consumption at nominal load (max.)

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery- / frequency converter mode output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response (double conversion mode) overload response (battery mode)

Crest factor

Short circuit response

BAttERY type

Rated voltage (linked)

Battery management

Charging time (to 90 % rated capacity)

CoMMUnICAtIon

Interfaces (dual monitoring)

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency (ECo+ mode)

Efficiency at nominal load

(double conversion mode)

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Mains input number of outputs (switchable) automatically locked

Housing

Dimensions approx. W x H x D (mm) UPS

Dimensions approx. W x H x D (mm) battery

Weight approx. UPS incl. integrated battery

Weight approx. battery extension unit

Shipment

Conformity

D. 1000

1000 VA

900 W

600 000 8434

600 000 8441

120 – 276 VAC

D. 1500

1500 VA

1350 W

600 000 8436

600 000 8442

D. 2000

2000 VA

1800 W

600 000 8437

220 VAC / 230 VAC / 240 VAC

600 000 8443

D. 3000

3000 VA

2700 W

600 000 8438

140 – 276 VAC

4.8 A 7.2 A

50 Hz / 60 Hz ± 5 Hz

λ ≥0.99 (THDi ≤8 %)

9.6 A 13.7 A

4.3 A

200 VAC / 208 VAC / 220 VAC / 230 VAC (default) / 240 VAC ±2%

50 Hz / 60 Hz ±0.25 Hz

6.5 A 8.7 A

0 ms (without interruption)

Sinusoidal, distortion THD <3 %

<130 % for 5 min. / 130 % – 150 % for 15 s

<130 % for 12 s / 130 % – 150 % for 2 s

3 : 1

Short circuit proof (4 x I

N

for 100 ms)

36 VDC

Sealed, maintenance free (proprietary brand), integrated, hot swappable

48 VDC 72 VDC

Temperature compensated with discharge protection, automatic battery test (programmable) and battery pack detection

3 h

13 A

RS232, USB, communication slot (can be used parallel with RS232 / USB), input contact for emergency shutdown, programmable potential free contact

5 network licenses for all common OS (e.g. Windows, Linux, Mac, Unix, Sun etc.)

3 LED’s with traffic light display, detailed indication via LCD display

(alarms: at mains failure, overload, battery charging, battery replacement, fan fault, data logger – with clear text display incl. date and time history)

>95 % >98 %

≥88 % >88 % >89 % ≥90 %

<44 dB(A) < 45 dB(A) <52 dB(A)

0°– 40 °C

0 – 95 % (without condensation)

Up to 3000 m at nominal load

EN 62040-2 Class C1, EN 61000-3-2, EN 61000-3-3

EN 62040-1

IEC 320 C14

6 x IEC 320 C13 (2+2) 8 x IEC 320 C13 (2+2)

IEC 320 C20

6 x IEC 320 C13 (3+3)

+ 1 x IEC 320 C19

Blackline metal case with aluminum front

482.6 (19") x 88 (2 U) x 430 482.6 (19") x 88 (2 U) x 600

482.6 (19") x 88 (2 U) x 430

16 kg 19.5 kg

482.6 (19") x 88 (2 U) x 600

19 kg 29.5 kg

23 kg 28 kg 41 kg 41 kg

Mains input cord, UPS management software “CompuWatch” (CD), communications cables (RS232 & USB), operating instructions, rack rails, device cables: 3 x IEC 320 C13 (D. 1000 – D. 2000), 3 x IEC 320 C13 +1 x IEC 320 C19 (D. 3000)

CE

*

excl. ECO/Bypass mode usage

17

18

Protect d.

6000 /10000

top performance in rack format

Protect D. 6000 and D. 10000 compliment the range of the successful Protect D series.

With Protect D. 10000, a power level of 10 kVA in rack design is available for the first time.

Protect D. 6000 and

Protect D. 10000 have the same advantages and characteristics as the smaller models, including the high power factor of 0.9lag.

Compact housing dimensions

Thanks to their compact design, the devices can also be used in IT cabinets with a depth of only 800 mm.

Protect D. 6000 including battery, connection unit and manual bypass unit fits within

3 standard height units. The

10 kVA version, with a complete battery system, connection unit and integrated manual maintenance bypass fits within

5 standard height units.

The sophisticated design with removable connection unit and battery systems with plug-in technology make the assembly in the rack and the electrical installation as easy as possible.

The weight is unimportant as the batteries can be mounted at the end of the installation.

Flexible and maintenance friendly

The equipment offers separate feed for the rectifiers and bypass, Protect D. 6000 and

10000 can also be operated with only one feed. Both options are provided to deliver highest flexibility and security.

To increase power or to be able to serve the demand for active redundancy, Protect

D. 6000 and Protect D. 10000 are prepared for parallel operation.

In order to ease maintenance work, a manual bypass is already integrated into the removable connection unit.

Special characteristics

• Suitable for IT cabinets with a depth of 800 mm

• High power density in a compact housing

• Very easy assembly through removable connection unit and batteries with plug-in technology

• Dual or single input

• Prepared for parallel operation

• Integrated manual maintenance bypass

(foolproof operation)

Protect D. 6000 with open battery compartment

Protect D. 10000 – rear view: flexible, removable connection unit with manual bypass and integrated IEC output distribution with automated locking mechanism

PRotECt D

(cos j = 0.7lag)

Default autonomy time

1 additional battery module

2 additional battery modules

3 additional battery modules

4 additional battery modules

Autonomy time (full / half-load) (min.)

6000 VA

Autonomy time – battery units resemble UPS

5/13

15/39

26/67

38/98

51/132

10000 VA

5.5/10.5

12/25

20/41

28/59

36/78

Classification VFI SS 111 acc. to IEC 62040-3

Power type rating (Ready for redundant or increased performance parallel operation)

Part number

(UPS incl. internal battery system)

Part number (additional battery pack)

UPS InPUt

Input voltage

Voltage range without battery mode

Voltage range bypass input

Frequency (auto selection)

Mains current (system reaction)

Current consumption at nominal load (max.)

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery / frequency converter mode output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response (double conversion mode)

Crest factor

Short circuit response

BAttERY type

Rated voltage (linked)

Battery management

Charging time (to 90 % rated capacity)

CoMMUnICAtIon

Interfaces (dual monitoring)

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency (ECo mode)

Efficiency at nominal load

(double conversion mode)

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

AC input number of outputs automatically locked

Housing

Dimensions approx. W x H x D (mm) without front panel

Dimensions approx. W x H x D (mm) battery extension unit incl. front panel

Weight approx. without batteries

Weight approx. with batteries

Weight approx. battery extension unit

Shipment

Conformity

D. 6000

6000 VA

5400 W

600 000 8439

600 001 1042

D. 10000

10000 VA

9000 W

600 000 8440

600 001 1044

29 A

220 VAC / 230 VAC / 240 VAC

176 VAC (120 VAC to 50 % utilization) – 276 VAC

184 – 264 VAC

50 Hz / 60 Hz ±10 %

λ ≥0.99 (THDi <5 %)

47 A

200 VAC / 208 VAC / 220 VAC / 230 VAC (default) / 240 VAC ±1%

50 Hz / 60 Hz ±0.5 %

26 A 43.4 A

0 ms (without interruption)

Sinusoidal, distortion THD <2 %

<130 % for 2 min. / 130 – 150 % for 30 s, then automatically switches over to electronic bypass: 0 ms

3 : 1

Short circuit proof (3 x I

N

for 100 ms)

Sealed, maintenance free (proprietary brand), integrated, hot swappable

180 VDC 240 VDC

Temperature compensated with discharge protection, automatic battery test (programmable) and battery pack detection

3 h

RS232, USB, communication slot (can be used parallel with RS232 / USB), input contact for emergency shutdown, programmable potential free contact

5 network licenses for all common OS (e.g. Windows, Linux, Mac, Unix, Sun etc.)

3 LED’s with traffic light display, detailed indication via LCD display

(alarms: at mains failure, overload, battery charging, battery replacement, fan fault, data logger – with clear text display incl. date and time history)

>96 %

>92 %

>97 %

>93 %

<55 dB(A)

0° – 40°C

0 – 95 % (without condensation)

Up to 1000 m at nominal load

EN 62010-2 Class C2

EN 62040-1

Permanent connection via terminals, separate power option from rectifier and bypass connector unit with removable integrated manual bypass (for installation or subsequent maintenance of UPS) with optional cable entry from top or rear

1 x fixed connection on terminal block plus

2 x IEC 320 C13, 1 x IEC 320 C19

1 x fixed connection on terminal block plus

4 x IEC 320 C19

Metal casing, blackline with aluminum cabinet front

48.6 (19") x 132 (3 U) x 715 depth with front panel plus 35 mm

48.6 (19") x 220 (5 U) x 715 depth with front panel plus 35 mm

482.6 (19") x 132 (3 U) x 595

20 kg 32.5 kg

46 kg

44.5 kg

82.5 kg

63 kg

Rack rails kit, 16 A IEC device cable, UPS management software “CompuWatch” (CD) incl. 5 network licenses, RS232 and USB cable, operating instructions

CE

19

20

Protect 1

LV main distributor

UPS feed

Parallel field / manual bypass plus UPS sub-distributor

Protect 1 during parallel operation

online UPS systems for networks and data centers

Protect 1 offers you a highpower UPS system for all critical business applications. Among other fields of use, Protect 1 is suitable for networks, data centers, cash desk systems or building technology.

The VFI topology of Protect 1 protects reliably against all network problems.

Switchable in parallel

A compact parallel switch panel ensures the flexible and easy development of a parallel system.

Up to 3 devices can be switched in parallel. Hence, a power increase up to 60 kVA is possible in addition to the combination of power improvement and redundancy.

Control and monitoring

The clearly structured screen provides detailed information on all important operating conditions and events.

Data is transmitted through an RS232 interface.

With the extension slot, devices such as SNMP (PRO) adapter cards or potential-free contacts can be retrofitted.

This supports remote monitoring via web browser and multi-server shutdown.

The special AEG shutdown software “CompuWatch” is included.

Main characteristics

• VFI topology (online /double conversion) protects against all network problems

• Static bypass switch

(SBS) and foolproof maintenance bypass

• 10, 15 or 20 kVA with spaceefficient, modern design

• n+x technology for active redundancy and /or performance increase

• Performance increase up to 60 kVA through parallel operation of up to 3 devices

• RS232 interface, extension slot e.g. for

SNMP adapter card

• Battery systems with an expected lifespan of

10 – 12 years, according to

EUROBAT, are available

• State-of-the-art technology for maximum reliability

(DSP, CAN-Bus) and maximum efficiency

(high-frequency IGBT)

Expansion slot

Cooling fans

Protect 1.200 – rear view

Parallel port

RS232

Input fuse

Manual bypass

Connector clamps with cable clamping unit

PRotECt 1

Coupled battery cabinets

1 x Protect 1.100 BP

2 x Protect 1.100 BP

3 x Protect 1.100 BP

1 x Protect 1. BP 20

2 x Protect 1. BP 20

3 x Protect 1. BP 20

4 x Protect 1. BP 20

5 x Protect 1. BP 20

Autonomy time (full / half-load) (min.)

Protect 1.100

16/42

42/97

60/134

19/47

47/103

78/177

103/243

138/312

Autonomy times – battery cabinets resemble UPS

Protect 1.150

-

-

-

10/29

29/68

47/103

68/153

85/202

Protect 1.200

-

-

-

6/19

19/47

34/62

47/103

63/138

Port “plug & play” with battery connection wire protected against polarity reversal

Battery cabinets, pre-assembled and ready to be connected

Protect 1. BP 20

Period of use of the integrated rechargeable batteries:

10 – 12 years according to

EUROBAT

Classification VFI SS 111 acc. to IEC 62040-3

Power type rating

Part number (UPS without battery)

Part number (battery pack 1.100 BP)

Part number (battery pack 1. BP 20)

UPS InPUt

Input voltage

Voltage range without battery mode

Frequency (automatic selection)

Mains current (system reaction)

Current consumption at nominal load (max.)

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery mode output current (at 230 VAC) transfer time at mains outage

Voltage waveform overload response

Crest factor

Short circuit response

BAttERY

Rated voltage (linked)

Charging characteristics

Autonomy time overload / deep discharge protection

CoMMUnICAtIon

Interfaces

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency AC – AC (at nominal load)

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Equipment color

Dimensions approx. W x H x D (mm) UPS

Dimensions approx. W x H x D (mm) battery extension unit

Weight approx. UPS

Weight approx. battery extension unit

Shipment

Conformity

Protect 1.100

Protect 1.150

Protect 1.200

10 kVA

7 kW n+x - technology scalable (parallel switching capacity up to 3 units)

15 kVA

600 000 4434

600 000 5097

10.5 kW

600 000 4435

20 kVA

14 kW

600 000 4436

100 000 1991 100 000 1991 100 000 1991

13 A / 46 A (bypass)

400 / 230 VAC (3 ph~/N/PE)

304 – 478 VAC (Bypass: 176 – 261 VAC)

50 Hz / 60 Hz ±4 Hz

λ ≥0.95

19 A / 68 A (bypass) 25 A / 91 A (bypass)

43.4 A

220 VAC / 230 VAC (default) / 240 VAC ±1 %

50 Hz / 60 Hz ±0.1 %

65.2 A

0 ms (without interruption)

Sinusoidal, distortion THD <2 %

<130 % for 10 min. / 130 % for 1 s, then automatic transfer to bypass mode: 0 ms (without interruption)

3 : 1

Short circuit proof (2.5 x I

N

for 100 ms)

86.9 A

240 VDC

IU – characteristic curve (charging voltage 274 VDC / charging current max. 4.2 A)

Expandable with external battery modules

Yes

RS232 (with status display and data values)

Communication slot (for potential free contact, SNMP)

5 network licenses for all common OS (e.g. Windows, Linux, Mac, Unix, Sun etc.)

Mains failure, overload, battery charging, battery replacement, failure

LED bar graph for summary / battery capacity

<55 dB(A)

>90 %

<60 dB(A)

0° – 40 °C

0 – 95 % (without condensation)

Up to 1000 m at nominal load

EN 62040-2 Class C3

EN 62040-1

Blackline with silver colored front cover

260 x 720 x 670 plus interception unit (90)

260 x 720 x 670

(Protect 1.100 BP)

260 x 720 x 810

(Protect 1. BP 20)

39 kg

260 x 720 x 810

(Protect 1. BP 20)

55 kg

260 x 720 x 810

(Protect 1. BP 20)

55 kg

135 kg

(Protect 1.100 BP)

170 kg

(Protect 1. BP 20)

170 kg

(Protect 1. BP 20)

Parallel connection cable, communication cable,

UPS management software “CompuWatch” (CD), operating instructions

CE

170 kg

(Protect 1. BP 20)

21

22

Protect 1.m

Front view with swappable module unit technology

Expansion slot for relay card with potential-free contacts or SNMP card

RS485

RS485

RS232

Modular high-performance

UPS for the It sector

Protect 1.M is a UPS system with maximum reliability and power.

The VFI topology of

Protect 1.M protects its systems reliably against all network problems.

Modular structure

The compact module structure of Protect 1.M allows you to flexibly upgrade the UPS power up to 24 kVA. The individual 4 kVA modules are hot-swappable, connected modules are automatically detected.

In this way, you can perform system extensions during runtime.

Each individual module is a separate UPS and works independently of a central control mechanism.

Intelligent control and monitoring

The powerful communication module of Protect 1.M collects the information of the self-sufficient UPS modules.

The clearly designed screen informs you about all important operating conditions.

n

+ x

tECHnoloGY – lEVEl oF REDUnDAnCY

Load

4 kVA

8 kVA

12 kVA

16 kVA

20 kVA

24 kVA

Number of UPS modules

1 module 2 modules 3 modules 4 modules 5 modules 6 modules no redundancy n+1

(4 kVA) no redundancy n+2

(8 kVA) n+1

(4 kVA) n+3

(12 kVA) n+2

(8 kVA) n+4

(16 kVA) n+3

(12 kVA) n+5

(20 kVA) n+4

(16 kVA) no redundancy n+1

(4 kVA) no redundancy n+2

(8 kVA) n+1

(4 kVA) n+3

(12 kVA) n+2

(8 kVA) no redundancy n+1

(4 kVA) no redundancy

Dual monitoring interface

ClASSIFICAtIon oF tHE BAttERY CABInEtS AVAIlABlE Ex WAREHoUSE – In tHE PRotECt 1.M RAnGE

15 min.

20 min.

30 min.

40 min.

60 min.

75 min.

90 min.

4 kVA

8 kVA

12 kVA

16 kVA

20 kVA

-

1 x 1.M BP28

-

-

1 x 1.M BP42 1 x 1.M BP65

1 x 1.M BP56 -

-

1 x 1.M BP28 1 x 1.M BP42 1 x 1.M BP56

1 x 1.M BP42 1 x 1.M BP56 1 x 1.M BP84 2 x 1.M BP65 1 x 1.M BP84

1 x 1.M BP84 2 x 1.M BP65 -

1 x 1.M BP42

3 x 1.M BP65

1 x 1.M BP84 1 x 1.M BP84 2 x 1.M BP84 3 x 1.M BP65 4 x 1.M BP65

1 x 1.M BP42

1 x 1.M BP84 1 x 1.M BP84 3 x 1.M BP65 2 x 1.M BP84 4 x 1.M BP65 5 x 1.M BP65

24 kVA

1 x 1.M BP42 1 x 1.M BP42

1 x 1.M BP84 2 x 1.M BP65 1 x 1.M BP84 2 x 1.M BP84 4 x 1.M BP65 5 x 1.M BP65 6 x 1.M BP65

1 x 1.M BP42

Further versions available upon request

You can also retrieve and control all technical parameters with the included AEG software “CompuWatch”.

Main characteristics

• High power reserves through a total performance of max. 24 kVA

• Wide security margins through n+x technology

• Static bypass switch

(SBS) and foolproof maintenance bypass

• 3 or 1-phase connection of the entire installation with an automated detector, 1-phase output

• Long autonomy periods available in case of power failure

• Battery cabinets in the

Protect 1.M range supplied with 10 to 12 year battery life according to EUROBAT

• Intelligent battery management

• Hot-swappable module for easy replacement during operation

• Module structure to be plugged into a compact tower, assembly in

19" rack possible

• Communication module with LCD, “Dual Monitoring” interface with expansion slot

Classification VFI SS 111 acc. to IEC 62040-3

Power type rating

Part number

UPS InPUt

Input voltage

(auto. detection)

Voltage range without battery mode

Frequency

Current consumption (max.)

Power factor

UPS oUtPUt

Rated output voltage (adjustable)

Frequency in battery mode output current transfer time at mains outage

Voltage waveform overload response (online mode)

Crest factor

Short circuit response

BAttERY

Rated voltage (linked)

Charging characteristics

Autonomy time overload / deep discharge protection

CoMMUnICAtIon

Interfaces (dual monitoring)

Shutdown software (on CD)

Failure indicators (acoustic /visual)

GEnERAl DAtA

Efficiency AC – AC (at nominal load)

Audible noise (1 m distance) operating temperature range

Humidity operation altitude

EMC conformity

Product safety

Mains input

Consumer outputs

Equipment color

Dimensions approx. W x H x D (mm) UPS

Dimensions approx. W x H x D (mm) battery extension unit

Weight approx. UPS

Weight approx. battery cabinet

Shipment

Conformity

Protect 1.040

UPS Module

4 kVA

2.8 kW

600 000 3928 n+x technology

Protect 1.M

System cabinet (max. 6 x 4 kVA)

24 kVA

16.8 kW

600 000 3930

230 VAC (1 ph~/N/PE) or 400 / 230 VAC (3 ph~/N/PE)

160 – 300 VAC (1 ph~) or 277 – 520 VAC (3 ph~)

50 Hz / 60 Hz ±4 Hz

22 A (1 ph~) or 7.3 A (3 ph~) 132 A (1 ph~) or 44 A (3 ph~)

λ ≥0.98

220 VAC / 230 VAC / 240 VAC ±2 %

50 Hz / 60 Hz ±0.2 Hz

17.4 A 104.4 A

0 ms (without interruption)

Sinusoidal, distortion THD <3 %

125 % for 30 s / 130 % for 2 s, then automatic transfer to bypass mode: 0 ms (without interruption)

3 : 1

Short circuit proof (3 x I

N

for 100 ms)

120 VDC

IU – characteristic curve (charging voltage 137 VDC / charging current max. 3.5 A/ module)

Freely selectable and expandable with external battery modules

(available modules with 28, 42 or 65 Ah)

Service life: 10 – 12 years acc. to EUROBAT

Yes

RS232 / RS485 (with status display and data values) communication slot (for potential free contacts, SNMP)

5 network licenses for all common OS (e.g. Windows, Linux, Mac, Unix, Sun etc.)

Graphical LCD display with digital display of the input and output parameters (voltage, frequency, capacity etc.), battery parameters incl. password protected detailed failure diagnostics,

LED display for status notification / central failure display

>89 %

<55 dB (A)

>88 %

<62 dB(A)

0° – 40 °C

20 % – 90 %

Up to 1000 m at nominal load

EN 62040-2 Class C3

EN 62040-1

Secured terminal block

Secured terminal block

Blackline

442 x 965 x 700 (chassis) / module each: 405 x 87 x 530

442 x 965 x 700

75 kg (chassis) + 15 kg per module

1.M BP28: 160 kg, 1.M BP42: 200 kg, 1.M BP56: 255 kg, 1.M BP65: 270 kg, 1.M BP84: 335 kg

Communications cable, UPS management- software “CompuWatch” (CD), operating instructions

CE

23

AEG Power Solutions

Approach your local AEG Power Solutions representative for further support.

Contact details can be found on:

www.aegps.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
