Yamaha | AG03 | Specifications | Yamaha AG03 Specification

ZN43270
MIXING CONSOLE
Analog Input Characteristics
0 dBu = 0.775 Vrms
Technical Specifications
GAIN
Trim/SW
Position
PAD
26 dB
Input Jack
Input Level
For Use
with
Nominal
Actual
Load
Impedance
Sensitivity *1
Nominal
Max. Before
Clip
10
-72 dBu
(0.195 mV)
-60 dBu
(0.775 mV)
-50 dBu
(2.451 mV)
0
-26 dBu
(38.84 mV)
-14 dBu
(154.6 mV)
-4 dBu
(489.0 mV)
-46 dBu
(3.884 mV)
-34 dBu
(15.46 mV)
-24 dBu
(48.90 mV)
0
0 dBu
(775.0 mV)
+12 dBu
(3.085 V)
+22 dBu
(9.757 V)
HIGH
-32 dBu
(19.5 mV)
-20 dBu
(77.5 mV)
-10 dBu
(245.1 mV)
LOW
-12 dBu
(194.7 mV)
0 dBu
(775.0 mV)
+10 dBu
(2.451 V)
HIGH
-20 dBu
(77.5 mV)
-8 dBu
(308.5 mV)
+2 dBu
(973.7 mV)
-10 dBu
(245.1 mV)
+2 dBu
(975.7 mV)
+12 dBu
(3.085 V)
-14 dBu
(154.6 mV)
-8 dBu
(308.5 mV)
+2 dBu
(975.7 mV)
OFF
General Specifications
MIC/LINE 1
HEADSET MIC
10
0 dBu = 0.775 Vrms, Output impedance of signal generator (Rs) = 150 Ω
Total Harmonic Distortion *1
(THD+N)
Hum&Noise *2
(20 Hz to 20 kHz)
Input (MIC) to MONITOR OUT
via USB IN/OUT
+0.5 dB/-1.5 dB (20 Hz to 48 kHz @ Fs = 192 kHz),
refer to the nominal output level @ 1 kHz, GAIN knob: Min, TO PC: DRY CH1-2G
Input to MONITOR OUT
0.05% @ 0 dBu (20 Hz to 20 kHz), GAIN knob: Min
0.01% @ +4 dBu (1 kHz), GAIN knob: Min
Equivalent Input Noise
-128 dBu (Mono Input Channel, Rs: 150 Ω, GAIN knob: Max)
Residual Output Noise
-103 dBu (MONITOR OUT, MONITOR knob: Min)
Crosstalk (1 kHz) *3
-80 dB
Input Channels
Mono (MIC/LINE): 1 including HEADSET MIC (Plug-in Power)
(CH1 MIC and HEADSET MIC cannot be used simultaneously.),
Stereo (LINE) / Mono (GUITAR) :1, USB IN:1, AUX IN:1
Output Channels
MONITOR OUT: 2, PHONES: 2 including HEADSET PHONES
(PHONES and HEADSET PHONES cannot be used simultaneously.)
Bus
Stereo: 1
PAD
26 dB
DSP
COMP/EQ, EFFECT (SPX Reverb)
PEAK LED
LED turns on when the signal reaches 3 dB below clipping level.
Level Meter
USB Output Level
2x2 point LED meter [PEAK, SIG]
USB Audio
2 IN / 2 OUT
USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit
Input Channel Function
(CH1)
50–600 Ω
Mics/Lines
ON
All level controls are nominal if not specified.
Frequency Response
3 kΩ
1.5 kΩ*4
Phantom Power Voltage
+48 V
FOOT SW
EFFECT Mute on/off
Power Requirements
DC 5 V, 500 mA
Power Consumption
Max. 2.5 W
Dimensions (WxHxD)
129 mm x 63 mm x 202 mm (5.1” x 2.5” x 8.0”)
Net Weight
0.8 kg (1.8 lbs)
Included Accessory
USB Cable (1.5 m), CUBASE AI DOWNLOAD INFORMATION, Owner’s Manual,
Technical Specifications (this leaflet)
Optional Accessory
Foot Switch: FC5, Mic Stand Adaptor: BMS-10A
Operating Temperature
0 to +40°C
*1 THD+N is measured with 22 kHz LPF.
*2 Noise is measured with A-weighting filter.
*3 Crosstalk is measured with 1 kHz band pass filter.
The contents of this manual apply to the latest specifications as of the printing date. Since Yamaha makes continuous improvements to the product, this manual may not apply to the
specifications of your particular product. To obtain the latest manual, access the Yamaha website then download the manual file. Since specifications, equipment or separately sold
accessories may not be the same in every locale, please check with your Yamaha dealer.
GUITAR 2G
-
LINE 2/3
1 MΩ
-
-
10 kΩ
600 Ω Lines
10 kΩ
600 Ω Lines
LOW
AUX
-
-
Connector
Combo jack *2
(Balanced)
3.5 mm Phone jack
for HEADSET MIC
(Plug-in-Power/
Unbalanced)
Phone jack *3
(Unbalanced)
Phone jack *3
(Unbalanced)
Stereo mini jack
*1 Sensitivity is the lowest level that will produce an output of +0 dBu (0.775 V) or the nominal output level when the unit is set to maximum gain.
(All level controls are at their maximum position.)
*2 1&Sleeve = GND, 2&Tip = HOT, 3&Ring = COLD
*3 Tip = Signal, Sleeve = GND
*4 For CH1, HEADSET MIC
Analog Output Characteristics
0 dBu = 0.775 Vrms
Output Terminal
Actual Source
Impedance
Output Level
For Use with Nominal
Connecter
Nominal
Max. Before Clip
Phone jack *5
(Impedance Balanced)
MONITOR OUT [L, R]
150 Ω
10 kΩ Lines
0 dBu (0.775 V)
+10 dBu (2.451 V)
RCA pin
(Unbalanced)
PHONES
120 Ω
40 Ω Phones
1.5 mW + 1.5 mW
6 mW + 6 mW
Stereo phone jack
Stereo mini jack
*5 Tip = HOT, Ring = COLD, Sleeve = GND
Digital Input / Output Characteristics
Terminal
Format
Data Length
Sampling Frequency
Connector
USB
USB Audio Class 2.0/ Yamaha Steinberg USB Driver
24-bit
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
USB Standard-B
Block and Level Diagrams
Dimensions
Unit: mm
L
MONITOR MUTE
+48V
MONITOR
56
129
OFF⇔ON
INPUT 1
[MIC/LINE]
PAD=off: -60 ~ -14dBu
PAD=on: -34 ~ +12dBu
PAD
GAIN
26dB
HA
PEAK
COMP/EQ
LEVEL
2.3
R
L
R
63
+48V
MONITOR
OUT (L/R)
EFFECT
[MONITOR OUT L/R]
Nominal Output: 0dBu (@10kΩ)
Maximum Output: +10dBu (@10kΩ)
HPF/COMP/EQ
PUSH
PUSH
OFF⇔ON
[MONITOR MUTE]
CH1-2G MUTE
REVERB
HEADSET
(Mic)
TO PC
201
AMP
SIM
GAIN
GUITAR
LEVEL
PHONES
INPUT 2/3
[GUITAR]
-20dBu/+0dBu
GUITAR
Hi-Z
PHONES
(L/R)
[TO PC]
TOP: DRY CH1-2G
MID: INPUT MIX
BOT: LOOPBACK
HIGH⇔LOW
[LINE]
-8dBu/+2dBu
202
[MIC (Plug in power)]
HEADSET
(Phones)
(L/MONO)
[PHONES L/R]
Nominal Output: 1.5mW (@40Ω)
Maximum Output: 6.0mW (@40Ω)
HIGH⇔LOW
(R)
28
METER
HIGH⇔LOW
L
R
28
[METER]
PEAK
SIG
Jack and Plug List
USB
FOOT SW
[USB AUDIO]
from PC
[FOOT SW]
Fx On-Off
POWER
LEVEL
L
R
AUX INPUT
USB AUDIO
IN
5V DC
POWER
R
DETECT
+10dBu
0dBu
Maximum Input Level: [+22dBu]
-26dB
-2dB +10dB
+14dB
MONO INPUT MIC: [-14dBu] @GAIN=min
+60dB
MONO INPUT LINE: [-34dBu] @GAIN=max
-2dB
MONO INPUT MIC: [-60dBu] @GAIN=max
Clip Level: [+10dBu]
Maximum Input
Level: [+2dBu]
Clip Level: [+10dBu]
USB Audio
from PC: [+7dBu]
+8dB
AUX INPUT: [-8dBu]
Hi-Z: [+0dBu]
@GAIN=LOW
Maximum Input Level: +20dB
[-10dBu] @GAIN=HIGH
-6dB
+6dB
Level Control
Maximum Output Level: [+10dBu]
-2dB
-10dB
+3dB
USB Audio Level Control
-16dB
MONITOR OUTPUT: [0dBu]
-12dB
+20dB
PHONES Level Control
Maximum Output Level: [6mW] @40Ω
PHONES: [1.5mW] @40Ω
-6dB
+6dB
MONITOR Level Control
+10dBu
0dBu
-10dBu
MIC/LINE*
MONITOR OUT*
Tip: Hot (+)
Ring: Cold (-)
Sleeve: Ground
Balanced
HEADSET MIC
Tip: Signal
Ring: Sleeve: Ground
Unbalanced
PHONES
AUX
Tip: L
Ring: R
Sleeve: Ground
-
LINE 2/3
GUITAR
Tip: Signal
Sleeve: Ground
INPUT
TRS Phone Plug
Ring
Sleeve
Tip
TS Phone Plug
Unbalanced
Sleeve
Tip
-20dBu
-30dBu
-40dBu
-26dB
-50dBu
-60dBu
STEREO INPUT LINE:
[-8dBu]@GAIN=HIGH
[-8dBu]
@GAIN=HIGH
STEREO INPUT LINE:
[+2dBu] @GAIN=LOW
Hi-Z: [-20dBu] @GAIN=HIGH
-30dBu
-40dBu
Maximum Input Level: [+2dBu]
Maximum Input Level: [-4dBu]
-10dBu
-20dBu
Balanced
+20dBu
Maximum Input Level:
[+10dBu] @GAIN=LOW
Maximum Input Level: [+12dBu]
Clip Level: [+10dBu]
Configurations
XLR Jack
MIC/LINE
+30dBu
MONO INPUT LINE: [+12dBu] @GAIN=min
Balanced/
Unbalanced
Pin 1: Ground
Pin 2: Hot (+)
Pin 3: Cold (-)
USB 2.0
L/R
+20dBu
Polarities
L
OUT
[LINE]
-8dBu
+30dBu
Jacks and Plugs
-50dBu
* These jacks also can be connected with TS phone plugs. If you use TS phone plugs, the connection will
be unbalanced.
-60dBu
Manual Development Department
©2015 Yamaha Corporation
Published 01/2015 MWZC*.*-01A0
Printed in Indonesia
