Exercise 1

PROFINET IO System

Engineering with STEP7 V5.5

© Siemens AG 2012. All Rights Reserved.

Exercise 1:

PROFINET

1. Create Project in STEP7 V5.5

2. Create HW-Config

3. Assign IP Address on PC and CPU

4. Test the connection with Ping Function

5. Insert IO-Devices from your Training Kit (ET200S,

SCALANCE X)

6. Define and assign Device Names

7. Copy Error OBs

8. Download and test

9. Configure Topology

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Assign IP-Address

1

2

3

1. Open Control Panel –

Network Connection

2. Select Network Adapter for Online Access

3. Open Up Properties for

TCP/IP Protocol

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Assign IP-Address

Three Network

Classes:

Class A: 1.0 - 127.0

Subnet: 255.0.0.0

Class B: 128.0-191.255

Subnet: 255.255.0.0

Class C: 192.0-

223.255.255

Subnet: 255.255.255.0

1

1. Assign IP-Address for the Network Adapter.

2. Notice to make sure addresses are correct for the sub network, IP-

Address needs to be unique!

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Assign IP-Address

1

2

1. Call PG/PC-Interface

2. Assign Network Card

3. OK

3

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Assign IP-Address

1

3

2

1. Open Browse Dialog

2. Brose Ethernet Network

3. Identify Device and assign IP-Address

4. OK

4

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Assign IP-Address

1. Assign IP-Address

2. Use Ping for test if addresses of PC and

PLC are in the same subnet, feedback must be “Reply” from ping function

1

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

D ra g &

D ro p

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

1

1.

Select Device and configure IOs according to the real setup

2.

IO-Address, access from

User program

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

1. Double click on Device

2. Define Device Name

3. OK

2

1

3

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

1

2

1. Select IO-System or IO-Device

2. Call “Assign Device Name” Dialog

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

2

1

3

4

1. Select Device name

2. Select Online Device

3. Assign Name

4. After click “Assign Name” the

Device receives the Name.

5. IP-Address will be set by the IO-

Controller and the connection will be established automatically

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

PROFINET

Offline configuration

Every device receives a device name (e.g. sample2)

1

STEP 7 automatically assigns a

IP-Address in the Configuration

2

Online:

Write the device name to the device

IO-Controller

Start up:

IO-Controller assigns the device an IP-address

3

© Siemens AG 2012. All Rights Reserved.

MAC Adr 1

Exercise 1:

PROFINET

Copy

OB82,

OB83,

OB86

Download

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Topology

1

2

1. Right Mouse click on the

PROFINET IO System

2. Call up Topology Editor

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Topology

1

2

3

1. Start Network Detection

2. Select Ports

3. Apply Online Detection to your

Offline Configuration

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 1:

Topology

1

1. Interconnections are automatically created

2. Online Diagnostic is possible

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise

Exercise 2

Webinterface

© Siemens AG 2012. All Rights Reserved.

Exercise 2:

Web function

1. Call up Object Properties of the S7-PLC

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

Web function

1

1. Activate Web interface

2. Edit User Management

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

3

4

Exercise 2:

Web function

1

1. Goto Report System

Error

2. Tab “Diagnostic

Support”

3. Activate “Diagnostic

Status DB”

4. Generate and download

RSE one more time

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

Web function

Creating DB127 in Report System Error is Mandatory for the Function

“Module Information”

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

Web function

1

1. Right Mouse click on

Variable Table

2. Call Object Properties

“General Part 2” and

Check Web Server

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

Web function

1 2

1. „Save&Compile“ of Hardware-Configuration is necessary.

2. Download of Hardware Config

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

Web function

Enter IP address

e.g.: 172.16.0.30

Ethernet

Start Web Browser and Test functionality

© Siemens AG 2012. All Rights Reserved.

Industry Sector

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1. Create Project in TIA Portal

2. Configure CPU and IO System

3. Insert IO-Devices from your Training Kit (ET200S,

SCALANCE X)

4. Define and assign Device Names

5. Copy Error OBs

6. Download and test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

2

1. Create a new Project, click

“Create”

2. Configure a Device

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

1. Add a new Device

2. Use a CPU

3. Take the CPU which is at your

Training Kit and “Add it”

2

© Siemens AG 2012. All Rights Reserved.

3

Industry Sector

Exercise 2:

TIA Portal

1

1. Select Ethernet Port

2. Go to Ethernet addresses

3. Add New Subnet

4. Define IP-Address

2

3

4

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

3

2

1. Change to “Network View”

2. Select your Remote IO from the

Training Kit

3. Drag&Drop it into your working area

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

2

1. Drag Interface of the remote IO

2. Drop it to the Controllers

Interface and release mouse

3. Repeat this step for all IO

Devices

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

2

1. Select Device

2. Define Device Name

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

3

2

1.

Double click on IO-Device

2.

Configure IOs according to the real setup

3.

Drag&Drop them to the IO-

Industry Sector

Exercise 2:

TIA Portal

1

2

1.

Right Mouse click on the PROFINET IO System

2.

Call “Assign Device Name” dialog

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

2

3

4

1.

Select Device Name

2.

Select Online Interface

3.

Select Device you want to address

4.

“Assign Name”

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

1.

Select CPU and Download

2.

Select Network Type

3.

Select “Show all devices”

4.

Select correct CPU

5.

Load configuration

2

3

4

© Siemens AG 2012. All Rights Reserved.

5

Industry Sector

Exercise 2:

TIA Portal

3

1

2

1. Add new block

2. Add OB82, OB83, OB86

3. Download Blocks

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 2:

TIA Portal

1

1. Open OB 1 and write a little program

2. Test

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 3:

Fieldbus Integration

1. Integrate IE/PB-Link in your project

2. Configure PROFIBUS Network

3. Download and test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 3:

Fieldbus Integration

2

1

1.

Select the Gateway you want to use

2.

Drag and Drop it to your Network View

3.

Connect the Ethernet Port to the IO-Controller

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 3:

Fieldbus Integration

2

3

1

1.

Select the DP-Slave, Drag and Drop it to your Network View

2.

Connect the PROFIBUS Port to the Proxy

3.

Set PROFIBUS-Address

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 3:

Fieldbus Integration

1.

Assign device name to the Proxy

2.

Download and test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

1. Go Online, read CPU Diagnostic

2. Switch on Online mode in Network and Device view

3. Create Report System Error

4. Activate Web interface

5. Define a Watch table for the Web interface

6. Download and test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

2

1

1.

Select the PLC you wish to go Online

2.

Select “Go online” Button

3.

Read Online Information's and Functions

3

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

1

2

1&2 Change to Device View and Network view and read the diagnostic

Information.

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

2

1

1.

Select “Watch & Force Table” and add a Watch table for the

Web interface.

2.

Define variables

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

1

2

3

1.

Go to Device View and select the Controller

2.

Select “System diagnostics”

3.

Activate it and configure if necessary

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

2

1

1.

Select Web Interface

2.

Activate Web Function for the PLC

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

1

2

1.

Select Automatic Update

2.

Select at least one language for the Web interface

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

Diagnostic

2

1

1.

Select Watch table

2.

Insert it to the Web interface

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

User Defined Webpage

2

2

1

4

3

1.

Select User-defined Web pages

2.

Select Directory and Start page of the user page

3.

Define DB Number start number, HTML Code will be converted into

DB’s

4.

Generate the Datablocks

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

User Defined Webpage

1.

Web DBs are created for the Web server

© Siemens AG 2012. All Rights Reserved.

Industry Sector

1

Exercise 4:

User Defined Webpage

1.

Create Startup OB 100

2.

Call Web Server SFC (WWW)

3.

Define Ctrl DB and Status

3

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 4:

User Defined Webpage

1.

Download and test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

1. Insert the Panel in your Project

2. Insert a Screen or Screenlayout

3. Insert the Diagnostic View in your Screen

4. Test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

Possibility 1

2

1

3

1.

Select Panel

2.

Drag and Drop to your

Network View

3.

Adjust IP-

Settings if required

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

2

Possibility 2

3

4

1

1.

Change to Portal

View

2.

Add new device

3.

Select HMI

4.

Add

5.

Pre-configuration via Wizard is possible.

5

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic Standard Panel

1

Standard

Panel

3

2

1.

Select the Panel in “Project view” and add a new screen

2.

Select Alarm View

3.

Bring it to your screen

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic for Comfort Panel

Comfort

Panel

1

3

1.

Add new screen

2.

Besides “Alarm View” it is possible to select “System

Diagnostic view” (Only available on Comfort Panel)

3.

Bring it to your comfort panel screen.

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

1

2

3

1.

Go to Properties

2.

Activate for “Current Alarm States”

3.

Activate “Diagnosis events”

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

1

2

1.

Select your PLC Tags

2.

You will see them in “Details View”

3.

Drag & Drop a Variable to your screen, it will become automatically an

IO Field.

4.

The Connection between Panel and PLC is now configured!

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

Connection between PLC and Panel is configured automatically!

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 5:

Diagnostic / Panel

1

2

1.

Compile the panel application

2.

Download or start simulation for testing

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 6:

PROFINET Redundancy

1. Configure Topology

2. Define MRP-Manager and MRP-Clients

3. Test

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 6:

PROFINET Redundancy

1

2

1.

Change to topological view

2.

Configure the Port interconnections

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 6:

PROFINET Redundancy

1

2

1.

Define one of your

Devices as MRP-

Manager

2.

All the other devices in the Ring-Network as MRP-Client

2

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 6:

PROFINET Redundancy

Possibility 1

Possibility 2

1.

Adjust the time behavior of your IO-Devices in the

Ring that a Watchdog of

200ms is configured!

Reason: MRP (Media

Redundancy Protocol) max. Reconfiguration time is 200ms.

If this parameter will not be changed, the IO-Device will drop off the network when Redundancy switchover occurs!

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Exercise 6:

PROFINET Redundancy

1.

Download first!!!

2.

Connect the Ring topology

3.

Test Redundancy

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Congratulation, you made it!!

© Siemens AG 2012. All Rights Reserved.

Industry Sector

Thank you for your attention!

Bernd Lieberth

Promoter Industrial Communication

South East Asia

I IA AS

60 Mac Pherson Road

Singapore 348615

Phone: +65 6490 6464

Fax: +65 6490 6453

Cellular: +65 9150 2977

E-Mail: [email protected]

© Siemens AG 2012. All Rights Reserved.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
