Super G3 Fax and Email
Quick Memory
Transmission
As soon as the first page of a multi-page
fax has been scanned, the DP-180 starts
dialing. Transmission takes place as the
additional pages are being scanned, saving
time as well as increasing productivity.
200-Station Auto Dialler
You can store up to 200 phone numbers or email addresses for
rapid access via 40 One-Touch keys, or 160 abbreviated numbers.
* Up to 1,000 stations with optional Hard Disk Drive Unit.
Internet Fax
(Send-to-Email)
The DP-180 can send documents as TIFF
images or PDF files, and transmit them as
email attachments to PCs or other
Internet fax machines, saving time and
money.
Network Panafax® Desktop
Software
DP-180
Panafax Desktop
The Panafax® Desktop software allows
users to send a fax directly from their PC
without having to print it before
transmitting. The PC fax capability
increases productivity while decreasing
paper consumption.
G3 FAX
d into
work
to
be
ork or
Of
3 fax
-
Result Notice is
automatically sent to the
sender's IP address
SMTP
ent
ment
o
g to
e
A smart
for your
office…
LAN
Network Colour Scanner
Scan-to-PC
Remote Copy
Scan-to-PC lets you digitise virtually any
kind of document — even handwritten
notes or sketches — and convert it to a
PDF, TIFF or JPEG file and send it to a
networked PC.
When you press the Remote Copy key, the DP-180 automatically
sends the scanned data through the PC to a network printer for
printing. This allows you to easily make colour copies of a colour
document when a colour printer is connected to the LAN.
Remote Copy
Document Management
System software
Panasonic Document Management
System software allows efficient
document management, flexible editing
and convenient sharing at the user’s
fingertips. Users can manage and edit
documents right from their desktop with
simple “drag and drop” operation.
Colour
Original
Colour
Copy
LAN
KX-CL500
DP-180
The DP-180’s
chassis and in
allow front op
paper loading
PC
Standard Network Printer
Built-in Network Printing
Capability
The DP-180 comes standard with a built-in
network board and an Ethernet LAN port, so you
can set it up as a network printer that can be
used by PCs on your LAN network. No special
options are required. In addition, the standard
USB 1.1 interface allows direct connection to a
dedicated PC.
Automated Network Installation Capability*
The DP-180 allows simple network installation. Simply plug the network
cable into the DP-180’s Ethernet port, and the network information is
automatically acquired from the server. No complex setup required.
*Requires a DHCP server on the network.
High-resolution of 1200-equivalent x 600 dpi
In addition to standard 600 x 600 dpi print resolution, you can boost print
resolution to 1200 dpi-equivalent x 600 dpi (in PCL/PS mode) by adding
our optional printer controller. This gives crisp, clean printouts with
superior legibility and halftone gradations — even with very tiny
characters or complex images.
Standard Duplex Printing and Copying
For added convenience, the DP-180 comes standard with a duplex
printing unit that enables you to easily print on both sides of the sheet.
To keep your paper consumption to a minimum, you can also use duplex
printing when printing out faxes or copying.
Sup
Fast P
Powered
micropr
DP-180’
enable h
operatio
MGC441EE.qx4
04.5.21
3:01 PM
Page 2 (3,1)
smart fit
r your
fice…
Intuitive control with easy-to-use GUI software
GUI Printer Driver
Completion Notice
Easy-to-install graphical printer driver
empowers users with full control of
versatile printing functions right from
the desktop. From the intuitive tabbed
interface to on-screen graphic preview
of job settings, everything is designed
to maximise ease of use, and eliminate
errors.
As soon as a print job is completed,
the DP-180 automatically sends a
Completion Notice to the user’s
desktop to notify them that the job
has been completed, eliminating
needless trips to check the
machines.
Security Print/Mailbox*
Network Status Monitor
Status monitor lets the user monitor the DP-180’s status directly from
their desktop, including print job status, paper jams, machine
configuration, and much more. So, for instance, you’ll always know
before paper or toner runs out.
Security printing for up to 100 users
is available. Simply print directly to
the Security Print Mailbox* and the
DP-180 stores that data until the
user retrieves it at the machine by
entering an 8-digit user ID and
4-digit password. This is extremely
useful when generating sensitive and
confidential documents.
*Only available if the optional hard disk unit is
installed.
Copying Versatility
Double Exposure for Double Savings
WORKiO Original
By selecting the Double Exposure key located on the control panel, users can make quality copies of
small double-sided documents on a single sheet of paper without the black borders — even if the platen
cover is open. This is especially convenient for copying small double-sided originals such as ID and
insurance cards, cheques, and receipts.
The DP-180’s “wingless” compact
chassis and inner paper exit design
allow front operations, including
paper loading.
Scanning Area
First Pass-Image#1
Scanning Area
Second Pass-Image#2
Print
N-in-1 Print/Copy
N-in-1 enables copying of multiple
originals onto a single sheet of paper,
accelerating document production
while reducing paper consumption.
Also, the double-sided copying and
printing capability comes standard
with the DP-180.
x 600 dpi
ou can boost print
mode) by adding
rintouts with
very tiny
ng
th a duplex
es of the sheet.
n also use duplex
Superior Performance
Fast Processing
Extended Reliability
Powered by a high-performance 200-MHz
microprocessor and custom-developed LSIs, the
DP-180’s high-speed image processing and quality
enable high-speed printing and multi-task
operations.
The Check & Call function automatically reports low
toner status and certain mechanical problems to a
service centre while the Remote Diagnostic System
enables expert technicians to quickly troubleshoot and
provide solutions via a telephone line or the internet.
These functions are not available in certain destinations.
MGC441EE.qx4
04.5.21
2:59 PM
Page 1 (2,1)
Printer/Network Printer
Options
Expansion Board
DA-EM600
(Optional expansion board is not
required in certain destinations)
Flash Memory
4MB Flash Memory
UE-410047
8MB Flash Memory
UE-410048
Image Memory
Image Memory
(16MB)
DA-SM16B
(64MB)
DA-SM64B
(128MB) DA-SM28B
(Not available in certain destinations)
550-sheet
2nd Paper Feed
Module
DA-DS188
pi. The
a such
and
Power Requirements
Power Consumption
Max.:
Power Saver mode:
Sleep mode:
Dimensions (W x D x H)*1
Weight*1
per
Software
Accounting Software
DA-WA10
Drum
cartridge
DQ-UH34H
Desktop
Laser Indirect Electrostatic
Dry Single Component
50 sheets (A4, 75 g/m2)
Std. 250 sheets paper tray unit x 1
+ 1-sheet bypass
Max. 800 sheets with option
Paper Tray: 60 to 105 g/m2
Bypass: 60 to 165 g/m2
AC 220 – 240 V, 50/60 Hz
Network Printer function
Printer Interface
Local Printer Interface
Printer Language
Standard
Option
Toner
cartridge
DQ-UG16H
Printing Speed*5
Paper Size
Printing Resolution
Ethernet 10Base-T/100Base-TX
USB1.1
523
Panasonic Printing System for Windows®
PCL 6 Emulation,
Adobe® PostScript® 3™
18 ppm
A4 – A5, Foolscap*9, Envelope*9
1,200 dpi equivalent x 600 dpi (PCL, PS)
600 dpi x 600 dpi,
300 dpi x 300 dpi (GDI, PCL, PS)
20 MB
Windows® XP/2000/Server 2003*10/98/Me,
Windows NT® 4.0
MacOS 8.6 – 10.2 (PS only)
1 kW
Approx. 20 Wh
Approx. 12 Wh
462 x 506 x 523 mm
Printer Memory
Compatible Operating
Systems
Approx. 22 kg
Network Scanner function
Network Scanner Interface Ethernet 10Base-T/100Base-TX
Scanning Size
A4 – A5, Foolscap*7
Scanning Resolution
Colour :
75 x 75 dpi, 150 x 150 dpi,
300 x 300 dpi
Black & White :
150 x 150 dpi,
300 x 300 dpi, 600 x 600 dpi
Scanning Speed
Colour :
Approx. 12 sec
Black & White :
Approx. 2.9 sec
Coding Scheme
Colour :
JPEG
Black & White :
JBIG/MMR/MR/MH
Data Format
Colour :
JPEG, PDF
Black & White :
TIFF, PDF
(Excluding optional equipment)
e
Hard Disk Drive Unit
Hard Disk Drive Unit
DA-HD19
DP-180 Specifications
General function
Type
Print Process
Developing Process
Automatic Document Feeder
Paper Feed
Paper Weight
and
PS/PCL Multi Page Description
Language Controller Module
DA-MC188
Consumables
Handset Kit
UE-403172
(Not available in certain destinations)
ADF,
PCL Printer Controller Module
DA-PC188
(Excluding optional equipment)
G3 Fax function
Compatibility
Modem Speed
Coding Scheme
Transmission Speed*2
Scanning Speed*3
Scanning Resolution
Standard:
Fine:
Super Fine:
600 dpi:
Effective Scanning Width
Recording Resolution
Standard Memory*4
Optional Memory*4 *6
No. of Auto Dialers
Digital Copier function
First Copy Time
Resolution
Gray Scale
Multi Copy Speed*5
Maximum Original Size
Copy Size
Copy Ratio
Zoom (variable)
Multiple Copy
Exposure Controller
Sort Memory
Standard
Optional*6
ITU-T Group 3, ECM
33.6 kbps
JBIG/MMR/MR/MH
Approx. 2.9 sec.
2.9 sec. (A4 portrait in Standard or Fine mode)
8 dots/mm x 3.85 lines/mm
8 dots/mm x 7.7 lines/mm
16 dots/mm x 15.4 lines/mm
600 x 600 dpi
207 mm (A4)
Max. 600 x 600 dpi
2 MB (approx. 120 pages)
Base memory plus 4 MB (320 pages)/
8 MB (640 pages)
200 (Max. 1,000 with optional HDD)
Approx. 10 sec. (A4)
600 x 600 dpi
256 steps
18 cpm
A4, Foolscap*7
A4 – A5*8, Foolscap*9
Enlargement (fixed) 141 %, 137 %
Reduction (fixed) 97 %, 90 %, 71 %, 64 %
50 – 200 % (in 1 % increments)
1 to 999, Automatic reset to 1
Text, Text/Photo, Photo
16 MB
Base Memory plus 16 MB/64 MB/128 MB,
12 GB (with optional HDD)
663
506
462
Dimensions
(unit:mm)
Microsoft® Windows® and Windows NT® are registered
trademarks of Microsoft Corporation.
Adobe®, PostScript®, PostScript®3, PDF and PostScript logo®
are trademarks of Adobe Systems, Inc.
PCL is an either trademark or registered trademark of HewlettPackard Company and/or its subsidiaries.
WORKiO™ is a trademark of Matsushita Electric Industrial Co., Ltd.
All other brand or product names are the property of their
respective holders.
As an Energy Star® partner, Panasonic
has determined that this product
meets the Energy Star® guidelines for
energy efficiency.
ISO 9001 Quality Management System
Our business processes which produce document, information and network
products, from manufacturing to marketing, conform to ISO9001 Quality
Management Systems standard. Design, development, manufacture, installation,
repair and maintenance of document, information and network products, their
associated devices and consumables.
In addition, the plants outside Japan have acquired ISO 9001 certification.
Send to Email / Internet Fax function
Compatibility
IETF RFC 2305, ITU-T T.37
Communication Protocol
TCP/IP, SMTP, POP3, MIME, LDAP*6
Network Connectivity
10BASE-T Ethernet/100BASE-TX
(IEEE802.3)
Data Format*11
TIFF-FX (Profile S/F/J), PDF, JPEG
Notes
*1 Dimensions and weight are approximate.
*2 Transmission time applies to memory transmission of text data using only ITU-T Image No.1 between
the same models at maximum modem speed. Transmission time may vary in actual usage. Usually
public telephone lines can only support communication speeds of 28.8 Kbps or lower. Via PBX,
transmission speed may fall back to a lower speed.
*3 Scanning speed applies to the feeding process from the top to the end of a single page test chart. The
time for the feeding process does not include the time that it takes for the top edge of the page to
reach the scanning point and page ejection. Time for entire storing process is not applied.
*4 Based on ITU-T Image No.1 scanned in Standard mode.
*5 Speeds are contingent upon applications, machine configuration, and status. Individual speeds may vary.
*6 May not be available in certain destinations.
*7 from ADF only
*8 Standard paper tray and Bypass only
*9 Bypass only
*10 Available in the 3rd quarter of 2004
*11 Internet Fax only supports TIFF-FX format.
Design and specification are subject to change without notice. Not all options may be available at the
time of notification.
This brochure is printed on recycled paper.
MG-C441EE 0405 Printed in Japan
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
