PRE-TERMINATED
MULTI-FIBER CABLES
P R E - T E R M I N AT E D M U LT I - F I B E R C A B L E S
Berk-Tek offers a comprehensive line
of pre-terminated multi-fiber cables in a
variety of cable configurations and connector
types. Berk-Tek’s pre-terminated cables
feature GIGAliteTM, GIGAlite-10 and
GIGAlite-10XB Enhanced Multimode,
as well as our standard 62.5 micron
multimode fibers and singlemode fibers.
AdventumTM, ArmorTekTM, Premise Distribution
and Ribbon cable constructions are also
available. Each pre-terminated multi-fiber
cable is custom built to the customer’s
specific performance requirement, application
migration plan and installation environment.
þ
F E AT U R E S & B E N E F I T S
þ
þ
þ
þ
þ
þ
Lower installation cost.
Lower cost of ownership.
No consumables, termination tool kits or
specialized termination training required.
No cable preparation necessary.
No cable or connector scrap.
SC CONNECTOR
LC CONNECTOR
þ
þ
þ
þ
No installer termination errors.
Cables arrive ready for installation and are
available with factory installed pulling eyes.
Fully tested, labeled and documented.
Higher performing factory terminated
connectors provide improved end-to-end
attenuation, throughput and application
migration.
Improved link loss budgets.
A P P L I C AT I O N S
þ
þ
Interbuilding and Intrabuilding backbones
for Local Area Network (LAN) Premise
and Campus applications.
Data center main, horizontal, zone
and equipment distribution area trunk
cables for Storage Area Network (SAN)
applications.
Extended Multimode distance
guarantees for:
• 1000Base-SX Ethernet LAN applications
• 1000Base-LX Ethernet LAN applications
ST CONNECTOR
MT-RJ CONNECTOR
•
•
•
•
•
10GBase-SR Ethernet LAN applications
1.06 Gb/s Fibre Channel SAN applications
2.12 Gb/s Fibre Channel SAN applications
4.25 Gb/s Fibre Channel SAN applications
10 Gb/s Fibre Channel SAN applications
C O N S IS T E N T Q UA L I T Y
High quality polishing processes have
been developed to meet and exceed industry
standards and specifications for insertion loss,
return loss, and end-face geometry. Attention
to process control ensures high-yields and
consistent quality. Performance testing at our
ISO registered facilities is one of Berk-Tek’s
strengths. Connector and cable materials are
extensively inspected prior to assembly.
Every terminated fiber optic cable receives
100% inspection for both insertion loss
and visual defects (under 1200X video
magnification). Interferometers are used
for accurate end-face geometry testing.
MTP CONNECTOR
FC CONNECTOR
C O N N E C T O R S P E C I F I C AT I O N S
TYPE
IL
TYPICAL
IL
MAXIMUM
RL
TYPICAL
RL
MAXIMUM
DURABILITY
FERRULE
CONSTRUCTION
BODY
COLOR
Beige
MULTIMODE
SC/PC
.35 dB
.50 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Ceramic
LC/PC
.35 dB
.50 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Ceramic
Beige
*ST/PC
.35 dB
.50 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Ceramic
Metallic
MT-RJ
.35 dB
.75 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Composite
Black
**MTP
.35 dB
.75 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Composite
Beige
FC/PC
.35 dB
.50 dB
N/A
N/A
<0.2dB change, 500 mating cycles
Ceramic
Metallic
SC/UPC
.14 dB
.30 dB
-61 dB
-55 dB
<0.2dB change, 500 mating cycles
Ceramic
Blue
LC/UPC
.14 dB
.30 dB
-61 dB
-55 dB
<0.2dB change, 500 mating cycles
Ceramic
Blue
SINGLEMODE
MTP
.25 dB
.75 dB
-55 dB
-55 dB
<0.3dB change, 500 mating cycles
Composite
Green
FC/UPC
.14 dB
.30 dB
-61 dB
-55 dB
<0.3dB change, 500 mating cycles
Ceramic
Metallic
SC/APC
.23 dB
.50 dB
-70 dB
-65 dB
<0.3dB change, 500 mating cycles
Ceramic
Green
FC/APC
.23 dB
.50 dB
-70 dB
-65 dB
<0.3dB change, 500 mating cycles
Ceramic
Metallic
*ST IS A REGISTERED TRADEMARK OF AT & T.
**MTP IS A REGISTERED TRADEMARK OF US CONEC, LTD.
H IG H Q UA L I T Y T E R M I N AT IO N S
In order to produce high quality, reliable
pre-terminated multi-fiber cables, there are
a number of physical characteristics that
must be addressed. Many of these issues
have been thoroughly outlined in TIA/EIA,
IEC and Telcordia standards. They include
acceptable parameters for Intermateability,
Insertion Loss (IL), Return Loss (RL), Radius
of Curvature, Apex Offset and Fiber Height.
Other issues that attribute to long-term
reliability are Ferrule/Fiber Fit, Ferrule
Concentricity and Ferrule Surface Defects.
F I B E R C O N N E C T O R D E TA I L I N G
Fiber
Apex Offset
Apex
Radius of Curvature
IMPROVED LINK LOSS BUDGET
Fiber Height
Berk-Tek’s family of 50 micron GIGAlite
fibers offers considerably improved link loss
budgets over the current industry minimum
standards compliant fibers. By utilizing
superior Differential Mode Delay (DMD)
performance inherent to the fiber and
cable manufacturing process, minimal Inter
Symbol Interference (ISI) loss is attained
and can be allocated to significantly
increased link loss budgets as shown in the
chart below. This added budget can be used
to achieve longer distances or to increase
the number of corrector pairs in the link.
5.5
5.0
10G EHTERNET
4.5
4.0
3.5
3.0
2.5
2.0
1.5
0
20
40
60
80 100
LENGTH (m)
GIGAlite-10XB
GIGAlite-10
Applicable to 10 Gb applications.
120
140
GIGAlite 50µm
Conventional 50µm
Apex Offset—Physical contact connectors
feature a radius on the end-face. The peak
of the radius is known as the apex. The
relationship from the apex to the “perfect”
center of the ferrule, is known as the apex
offset. Strict control of this specification is
mandatory in order to precisely control the
distance of each fiber from the surface of
the connector and to ensure physical
contact upon mating.
Misalignment—Fiber Core Alignment is critical
to a terminated cable’s ability to transmit light.
Main causes of misalignment are typical
mechanical issues associated with low quality
connectors or fiber: ferrule concentricity, hole
tolerances, fiber eccentricity and variations
in core diameter.
Surface Defects—Visual defects are one
of the most common causes of latent failures.
Scratches, pits and chips in the ferrule endface can change over time, becoming more
pronounced and migrating to critical areas
of the fiber core, thus affecting performance.
They are also prime sources of deposits of
dust, moisture and other contaminants.
SUPERIOR OPTICAL LINK
LOSS BUDGETS
LINK LOSS BUDGET (dB)
Illustration not to scale. Features exaggerated for readability.
Fiber Height—Physical contact of the
fiber is necessary for proper light transfer.
The end-face geometry has strict fiber
protrusion limits, as well as fiber undercut
limits. These limits are based exclusively on
the mathematical calculation of the radius
of curvature. If the fiber is too low and the
physical contact may never occur, causing
increased attenuation and reflectance.
Radius of Curvature—The end-face of the
connector is given a specific radius during
the polishing process. This radius provides
the basis for ensuring that both fibers make
contact. Both the apex offset and the fiber
heights are dependent on the radius of
curvature being within the predetermined
parameters.
Berk-Tek’s pre-terminated cables feature
GIGAliteTM, GIGAlite-10 and GIGAlite-10XB
Enhanced Multimode, as well as our
standard 62.5 micron multimode fibers
and singlemode fibers. AdventumTM,
ArmorTekTM, Premise Distribution and Ribbon
cable constructions are also available.
BERK-TEK QUALITY AND PERFORMANCE
Value Added Solutions l Flex
MANUFACTURING EXPERTISE &
DELIVERY PRECISION
CABLE SHOP DIRECT
Berk-Tek delivers. You specify your cable
and connectivity requirements and our optical
engineers develop and manufacture your endto-end pre-terminated cable solution. Berk-Tek
knows quality volume manufacturing. Meticulous
attention to capacity and material planning
allows us to meet our committed ship dates
on time. Every time. Standard product offerings
are able to ship in days not weeks to your
project site. By working with our sales engineers
we can also provide rapid ramp-up capabilities
ensuring on time delivery for your special
cabling needs. Let Berk-Tek pre-terminated
multi-fiber cables contribute to your ability to
complete your project on time and on budget.
VA L U E A D D E D S O L U T I O N S
Berk-Tek pre-terminated multi-fiber cables
feature GIGAlite Enhanced Multimode fiber.
GIGAlite facilitates network agility by enabling
network planners the ability to migrate from
1 to 10 Gb/s in their LAN and SAN utilizing
SW 850nm optical transceivers. The ability
to leverage SW 850nm transceivers in network
switches, servers, storage devices, HBAs and
NICs provides the lowest cost of ownership
and fastest return on investment (ROI).
www.cableshopdirect.com/berktek
Berk-Tek’s dedicated pre-terminated multi-fiber cable website enables customers
to configure all their product needs online. Cable Shop Direct ensures product description
and part numbering accuracy. Access product specifications online as well as purchased
products test reports. Cable Shop Direct enables customers the ability to instantly
configure their pre-term products and at the click of a mouse request a quotation.
www.cableshopdirect.com/berktek
Pre-term with pulling eye.
x ible Solutions l Adventum Innovation
FLEXIBLE SOLUTIONS
S TA N D A R D P R E - T E R M C A B L E S P E C I F I C AT I O N S
Adventum (6-144 fiber) and Adventum ArmorTek (6-72 fiber)
available with SC, LC, ST and MT-RJ Connectors
39” Break-out
HEAT SHRINK
Berk-Tek
Side A or B
Assembly S/N
Assembly Label
<
FURCATION
<
4” Sub-unit
35” 900 µm fibers
Berk-Tek offers the Industry’s premier
fiber optic cable line. Our complete line
of indoor, outdoor and indoor/outdoor cable
constructions ensure you have the flexibility
to select the proper cable for your application.
Our AdventumTM, ArmorTekTM, Premise
Distribution and Ribbon Interconnect lines
enable you to design the highest performing
most reliable solution that ultimately
contributes to lowest cost of ownership.
A D V E N T U M I N N O VAT I O N
Adventum (12-144 fiber) and Adventum ArmorTek (12-72 fiber)
available with MTP Connectors
Berk-Tek
Side A or B
Assembly S/N
<HEAT SHRINK
39” 3.0 mm Sub-unit
Assembly Label
Premise Distribution (48-144 fiber) and Premise Distribution Armor-Tek (6-72 fiber)
available with SC, LC, ST and MT-RJ Connectors
39” Break-out
HEAT SHRINK
Berk-Tek
Side A or B
Assembly S/N
Assembly Label
<
<
FURCATION
4” Sub-unit
35” 900 µm fibers
Premise Distribution Single Pass (6-24 fiber) and Premise Interconnect Round (2-4 fiber)
available with SC, LC, ST and MT-RJ Connectors
Berk-Tek
Side A or B
Assembly S/N
Also available in 12-fiber ribbon cable with MTP Connectors.
NEW! ADVENTUM™ LC
Ask about Berk-Tek’s DuPont™
certified limited combustible
ADVENTUM™ LC cables
<HEAT SHRINK
Assembly Label
Adventum is not just for outdoor or
indoor/outdoor applications. With Berk-Tek’s
pre-terminated multi-fiber cable line you
can now take advantage of Adventum in
indoor LAN & SAN installation environments.
In most cases Adventum offers better
mechanical performance, smaller OD,
better flexibility and better attenuation
characteristics than tight buffered or ribbon
cables. Now that Adventum is available preterminated you can take advantage of the
lower cable cost, improved reliability and
better performance characteristics without
having to field terminate a loose tube cable
design. Adventum with DryGelTM Technology is
available in riser or plenum constructions up
to 144 fiber including optional interlocking
armor. Adventum cables are available in all
connector options to include MTP.
39” 900 µm fibers
1-800-BERK-TEK
www.berktek.com
THE WORLD’S BEST PERFORMING NETWORK CABLES
Berk-Tek is a leader in network cabling with over 100 different optical fiber, UTP, FTP, and coaxial
cable products. State-of-the-art engineering enables Berk-Tek to deliver guaranteed product
performance beyond industry standards that are independently verified.
I T ' S W H AT ' S I N S I D E Y O U R
OPTICAL FIBER CABLE
T H AT M AT T E R S .
Designed for extraordinary performance and
scalability for LAN and SAN applications,
GIGAlite optical fiber technology delivers
premium performance and reliability beyond
industry standards.
Berk-Tek's GIGAlite family of multimode
optical fibers is a true performance breakthrough. Available in 62.5-micron and laser
optimized 50-micron that has the tightest
Differential Mode Delay (DMD) performance
in the industry.
AT T E N UAT I O N A N D B A N D W I D T H S P E C I F I C AT I O N S
WAVELENGTH
(nm)
MAXIMUM
ATTENUATION
(dB/km)
62.5/125 µm-Standard
850/1300
3.5/1.0
200/500*
62.5/125 µm-GIGAlite™
850/1300
3.5/1.0
200/500**
FIBER TYPE
50/125 µm-GIGAlite
850/1300
3.5/1.5
700/500**
50/125 µm-GIGAlite-10
850/1300
3.5/1.5
2000***/500*
50/125 µm-GIGAlite-10XB
850/1300
3.0/1.5
4900***/500*
Contact customer service for more information.*Overfilled Bandwidth Measurement per EIA FOTP 204—Paragraph 3.2.1. **Restricted Mode Launch per EIA FOTP
204—Paragraph 3.2.2. ***Differential Mode Delay per EIA FOTP-220 DMD Test Measurement.Also available with singlemode fiber. For the most current optical fiber
specifications, please visit our website at www.berktek.com. Berk-Tek reserves the right to modify optical performance specifications without prior notice.
A P P L I C AT I O N T O D I S TA N C E G UA R A N T E E
APPLICATION
GIGAlite extends the reach of low cost
850 nm VCSEL transceivers used in today's
high-speed LAN and SAN networks.
F E AT U R E S
þ
þ
þ
þ
Laser-optimized 62.5-micron and
50-micron optical fiber technology
Enhanced DMD profile for superior
performance
Extended distance guarantees that enable
seamless migration from 1 to 10 Gb/s
Ethernet and Fibre Channel applications
Higher bandwidth products that improve
system link loss budgets
BENEFITS
þ
þ
þ
þ
10 Gb/s Ethernet and Fibre Channel
performance to 600-meters for campus
applications
10 Gb/s Link loss budgets to 5.15 dB at
82-meters for Data Center Applications
Fully compatible with legacy 62.5-micron
and 50-micron fiber
Premium performance without the
premium price
Call 1-800-BERK-TEK for GSA Schedule Number.
BANDWIDTH
(MHz/km)
BERK-TEK FIBER TYPE
OPERATING
WAVELENGTH
DISTANCE
GUARANTEE
ETHERNET (LAN)
1000BASE-SX (1 Gb/s)
Standard (62.5/125)
850nm
300-meters
1000BASE-SX (1 Gb/s)
GIGAlite (62.5/125)
850nm
500-meters
1000BASE-SX (1 Gb/s)
GIGAlite (50/125)
850nm
750-meters
1000BASE-SX (1 Gb/s)
GIGAlite-10 (50/125)
850nm
1000-meters
1000BASE-SX (1 Gb/s)
GIGAlite-10XB (50/125)
850nm
1100-meters
10GBASE-SR (10 Gb/s)
Standard (62.5/125)
850nm
33-meters
10GBASE-SR (10 Gb/s)
GIGAlite (62.5/125)
850nm
66-meters
10GBASE-SR (10 Gb/s)
GIGAlite (50/125)
850nm
150-meters
10GBASE-SR (10 Gb/s)
GIGAlite-10 (50/125)
850nm
300-meters
10GBASE-SR (10 Gb/s)
GIGAlite-10XB (50/125)
850nm
600-meters†
FIBRE CHANNEL (SAN)
200-M6-SN-I (2 Gb/s)
Standard (62.5/125)
850nm
150-meters
200-M6-SN-I (2 Gb/s)
GIGAlite (62.5/125)
850nm
220-meters
200-M5-SN-I (2 Gb/s)
GIGAlite (50/125)
850nm
390-meters
200-M5-SN-I (2 Gb/s)
GIGAlite-10 (50/125)
850nm
500-meters
200-M5-SN-I (2 Gb/s)
GIGAlite-10XB (50/125)
850nm
600-meters
1200-M6-SN-I (10 Gb/s)
Standard (62.5/125)
850nm
33-meters
1200-M6-SN-I (10 Gb/s)
GIGAlite (62.5/125)
850nm
66-meters
1200-M5-SN-I (10 Gb/s)
GIGAlite (50/125)
850nm
150-meters
1200-M5E-SN-I (10 Gb/s)
GIGAlite-10 (50/125)
850nm
300-meters
1200-M5E-SN-I (10 Gb/s)
GIGAlite-10XB (50/125)
850nm
600-meters†
†600 m for 10GBASE-SR: 3.0 dB/km cable attenuation and 0.65 dB connection loss utilizing two mated LC connector pairs.
For more information on Berk-Tek cabling
solutions, OASIS or any of the more than
100 different Berk-Tek cabling products, call
1-800-BERK-TEK or visit www.berktek.com.
HAVE BERK-TEK WRITTEN ALL OVER THEM.
B E R K - T E K P R E - T E R M I N AT E D M U LT I F I B E R C A B L E PA R T N U M B E R I N G S Y S T E M
B
1
1
2
3
4
5
6
7
8
9
Select Cable Type
LT = Adventum
LK = Adventum Interlocking Armor
PD = Premise Distribution
PK = Premise Distribution Interlocking Armor
RD = Ribbon Interconnect
I2 = Interconnect Round
(Horizontal Cabling)
I4 = Interconnect Round
(Horizontal Cabling)
10
10
Select Length of Cable in Feet
Example: 090 = 90-ft, 300 = 300-ft
Standard Cable Lengths Available up to
300-m (984-ft)
Cable Lengths are Measured from break-out
transition to break-out transition
Tolerances –0/+4-ft <20-m (65-ft),
-0/+8-ft >20 to 300-m (65 to 984-ft)
Reel chart available for put-up configurations
2
3
4
Select Cable Flame Rating
P = Plenum (OFNP)
R =Riser (OFNR)
Select Number of Fiber Strands
02 = 2-fiber (I2)
04 = 4-fiber (I4)
06 = 6-fiber (LT, LK, PD, PK)
12 = 12-fiber (LT, LK, PD, PK, RD)
24 = 24-fiber (LT, LK, PD, PK)
48 = 48-fiber (LT, LK, PD, PK)
72 = 72-fiber (LT, LK, PD, PK)
44 = 144-fiber (LT, PD)
9
for hybrids select MMF Type only
5
Select Connector Type for Side A (Outside/Pulling End)
MULTIMODE
1 = Simplex SC/PC
2 = Duplex SC/PC
(With Addable/Removable Clip)
3 = Simplex LC/PC
4 = Duplex LC/PC
(With Addable/Removable Clip)
5 = ST/PC
6 = MT-RJ Female (2-fiber)
7 = MTP Female (12-fiber)
8 = FC/PC
N = No Connector Side A
SINGLEMODE
A = Simplex SC/UPC
B = Duplex SC/UPC
(With Addable/Removable Clip)
C = Simplex LC/UPC
D = Duplex LC/UPC
(With Addable/Removable Clip)
Pulling eye available for 6 to 72-Fiber configurations
Connector stagger: 2.5-in nominal
HYBRIDS (MMF/SMF)
A = 06
B = 12
C = 24
D = 48
E = 72
F = 96
example: 48 MMF/24 SMF = DC
Select Fiber Type
C = 62.5/125 (200/500MHz) Multimode-CB3510/25
G = 62.5/125 (200/500MHz) GIGAlite Multimode-GB3510/25
L = 50/125 (700/500MHz) GIGAlite Multimode-LB3515/75
E = 50/125 (2000/500MHz) GIGAlite-10 Multimode-EB3515/25
X = 50/125 (4900/500MHz) GIGAlite-10XB Multimode-XB3015/X5
A = Singlemode-AB1010 when PD & PK, AB0707 when RD, I2 & I4,
AB0505 when LT & LK
Select the Pre-terminated Configuration
N = No Pulling Eye
P = Pulling Eye Side A (Outside End)
Pulling eye OD:
8
Select Break-out Length Side B (Inside End)
S = Standard=39-in. (If no sub-unit=39-in 900 micron.
With sub-unit=4-in sub-unit +35-in 900 micron)
C = Custom (Contact Customer Service)
custom break-outs require a descriptor
N = N/A Because no Connectors Side B
Tolerances: +/- 2.0-in
7
Select Break-out Length Side A (Outside End)
S = Standard=39-in (If no sub-unit=39-in 900 micron.
With sub-unit=4-in sub-unit +35-in 900 micron)
F = 2.0 mm Furcation with standard break-out
C = Custom (Contact Customer Service)
custom break-outs require a descriptor
N = N/A Because no Connectors Side A
Tolerances: +/- 2.0-in
E = MTP Female (12-fiber)
F = FC/UPC
G = Simplex SC/APC
H = Duplex SC/APC
(With Addable/Removable Clip)
I = FC/APC
N = No Connector Side A
HYBRIDS (MMF/SMF)
Z = Simplex SC (PC/UPC)
Y = Duplex SC (PC/UPC)
(With Addable/Removable Clip)
W= Simplex LC (PC/UPC)
V = Duplex LC (PC/UPC)
(With Addable/Removable Clip)
U = MTP
T = FC (PC/UPC)
N = No Connector Side A
BERK-TEK CABLE
S TA N D A R D C O L O R C O D E S
CABLE
Select Connector Type for Side B (Inside End)
Use same options from section 5
N = No Connector Side B
FIBER
JACKET
COLOR
C, G, L, A,
Blue
E, X
Aqua
C, G, L, A,
Black
E, X
Aqua
PD, PK, RD, I2 and I4
C, G, L
Orange
(Tight Buffered,
Ribbon Interconnect,
Horizontal Interconnect
2 or 4 fiber)
E, X
Aqua
A
Yellow
LT and LK
(Loose Tube
Indoor/Outdoor)
Other colors available upon request.
6
2.0-in
FLAME
RATING
Plenum
Riser
Riser
and
Plenum
Corporate Headquarters
132 White Oak Road
New Holland, PA 17557
USA
TEL: 717-354-6200
TEL: 800-237-5835
FAX: 717-354-7944
www.berktek.com
In Canada, please contact:
Nexans Canada Inc.
140 Allstate Parkway
Markham, Ontario
L3R 0Z7 Canada
TEL: 905-944-4300
TEL: 800-237-5835
FAX: 905-944-4390
www.berktek.com
PRETERMFIBER 02/05
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
