SIMATIC Field PG M3

SIMATIC Field PG M3
SIMATIC Field PG M3
SIMATIC Programming device
Technical Presentation
For internal use only / © Siemens AG 2010. All Rights Reserved.
SIMATIC Field PG M3
Perfect for
Project engineering
Commissioning
Service
Maintenance
Highlights
Rugged, high-performance hardware Intel Core i
processor technology
15,6“ Widescreen Display, 16:9 size, Full HD
(1920x1080), LED Backlight
2x Gigabit Ethernet
Bluetooth
SIMATIC Engineering Software pre installed
Mobility due to powerful rechargeable battery (power
for up to 3,5 h)
All interfaces integrated
Easy-to-replace hard disk unit
Integrated Cardreader
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Interfaces
2x Gigabit
Ethernet
2 full-fledged network access with high data transfer rate
(10 / 100 / 1000 MBit)
COM 1
Combined serial V.24 and TTY interface for connecting S5 modules
MPI/Profibus
Standard connection to current S7 controllers or panels via Profibus
DVI-I
Terminal for external monitor or projector; transfer of analogue and digital pictures
simultaneously possible; high quality of display in combination with digital flat screens
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Interfaces
Programming
interfaces
For programming SIMATIC Micro Memory Cards, Memory Cards of S7-300, S7-400
and S7-1200 controllers and EPROMs of S5 controllers
USB 2.0
(5x)
480 MBit/sec. maximum data transfer rate for peripheral devices and external data
storage devices
USB 2.0
High current-carrying capacity: Ideally suited for external data carriers such as hard
disks etc.
USB 2.0
Two interfaces on the side of the device – Even USB sticks with a "strange shape"
can be connected
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Interfaces & drives
Express Card/
PC Card
Perfect for ISDN modem, Compact Flash Reader, interface cards, etc.
MODEM
Can be connected to any telephone network in the world, for faxing and access to
Internet
Audio
Headphone output and microphone input of the high-definition audio interface. Optimal
for Voice-over-IP headsets.
Bluetooth
Fast wireless data transfer to PDA, mobile phones or digital cameras
DVD-RW
DVD-RW drive included
Harddisk
lateral HDD-slot for quick change of hard disk drive.
Cardreader
Adapted for SMC and Multimedia cards (SDHC, MMC, xD, Memory Stick)
(Express Card/54 / PC Card Types I,II )
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Wireless LAN
Industrial WLAN
Wireless Local Area Network
IEEE Standard
802.11a (5 GHz)
802.11b (2,4 GHz)
802.11g (2,4 GHz)
802.11n (2,4GHz/5GHz)
802.11a
Few faults – perfect with Scalance Industrial
WLAN products (11 MBit/s)
802.11b, g
Standard – Optimal for hotspots and
corporate networks
(11/54 MBit/s)
802.11n
Up to 6x higher data tranfer than 802.11g
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Keyboard and touchpad
Keyboard
Ergonomically designed keyboard. It corresponds to the key distance of a Standard
desktop keyboard. Resistant-to-wear laser inscriptions
Touchpad
Rugged, high-quality touchpad with adjustable sensitivity, scrolling capability etc.
Status LED
Easy to read status LED inform about device status independent to closed or open
display e. g. battery or power supply operation, WLAN on/off or adjustment of display
brightness
Hotkeys
Fast access to important functions such as locking the programming, displaying onscreen menu, WLAN on/off, touchpad on/off, hibernation, standby, display brightness
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Mainboard – chipset – memory
Brand new Intel Core i processors
Intel Core i5-520 processor (2,4 GHz)
QM57 Chipset
DDR3 memory with 1066MHz
PCIe V2.0
Turbo Boost
max. 8GByte* RAM
Specials
2 TCPI/IP interfaces for parallel
working in 2 different networks
Brand new PC HW combined with
SIMATIC interfaces
*) if 64bit-operating system is used
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Intel i5-M520 CPU
brand new Intel Core i processor technology
Intel Core i5 processor
2 physical cores
Intel® Hyper-Threading-technic provides
intelligent quadruple multitasking – each
core can run two tasks simultaneously
TurboBoost / Powersharing Technology
Effective to applications, which are not
using multithreading or Multicore
Depending on load the cores increase
their perfomance (up to 2,66GHz in Dual
Core mode, up to 2,93GHz in single core
mode)
Increase of integrated garphics frequency
is possible, if both cores are not working
to capacity
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Performance
PassMark® Rating
mit CD- und Disk-Mark
1000
986
800
+69%
+42%
750
600
583
530
400
200
0
Field PG M 2
Standard
Field PG M 3
Standard
Field PG M 2
Pre mium
Fie ld PG M 3
Premium
Significantly increased performance compared to Field PG M2. Significant
positioning of Standard u. Premium version.
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Mainboard – Graphics
Integrated
graphics
Brand new Intel shared memory graphics with high 2D and 3D performance. Support of
DirectX 10 and Ready for Windows 7
Dual Display
Control of the integrated display and an external display with different resolutions (e.g.
desktop via both screens)
Resolution
15,6“ widescreen-display (16:9 formate), anti-glare with high luminance density
Full HD resolution with up to 1920 x 1080 pixels
Optimized for working with SIMATIC Software based on TIA Portal.
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Replaceable hard disk
Easy-to-replace hard disk unit
Project engineering
Commissioning
Service
Maintenance
Use Cases:
Fast alteration of software
Software version factory hall A
Software version factory hall B
Separation of service and office
Service – hard disk (administrator)
Office – hard disk (standard user)
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Replaceable hard disk– optional accessory
SIMATIC Field PG M3 accessories Hard disk
kit and serial ATA adapter
For simple changing between different software
versions
For creating a duplicate of the existing system
Separation of office and service environment
Use Cases
Simple creation of different software versions
Office environment or service software installation
Rapid creation of duplicates of the hard disk
If necessary, immediate continuation of work with
the duplicate is possible
In combination with SIMATIC IPC Image & Partition Creator the perfect backup of
data in industrial automation.
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Other special features
Ruggedness
Magnesium injection molding housing
Body completely made of Magnesium
palmrest made of plastics
Stable and torsion-resistant keyboard
assembly for optimized ergonomics
The tool for the SIMATIC
Ergonomic, stable handle
SIMATIC interfaces „on board“
15,6“ 16:9 display in HD ready or Full HD
resolution enables optimum, fatigue-free
working
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
SIMATIC Field PG M3 Software
Operating systems
Windows XP Professional (32-bit)
Windows 7 Ultimate* (32-bit)
As MUI versions easy to change between
diverse languages
Application software
(for Win XP)
Windows 7
Nero Essential 7
Perfect creation of DVDs/CDs
Power DVD V7
Optimum replay of films on DVD
*) Windows 7 Ultimate 64 bit in preparation
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
SIMATIC Field PG M3 Engineering Software
SIMATIC Software
Already preinstalled:
STEP 7 Professional
STEP 7 Basic
STEP 7-Micro/WIN
WinCC flexible Advanced
STEP 5
(XP only)
Ready for immediate use
Optimally matching software – For
immediate productive use
Licenses for enabling the SIMATIC
software can be ordered with the Field
PG M3
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Data backup concept
SIMATIC IPC Image & Partition Creator
SIMATIC IPC Image & Partition Creator V3.0
Backups may be made during operation („hot processing“)
Differential partition backups or incremental file backups
Installation on HDD isn‘t necessary
Direct start in running operation w/o installation from USB-flash drive or CD
OS independent use
Scheduled/cyclical backup
“1ClickImage”
Wizard for backup / recovery / deletion of data
Irretrievable, final deletion of data
Increasing/decreasing the size of existing system and data partitions w/o data loss
Hardware
Field PG M3
SIMATIC IPC (since C-generation)
Support of Solid-State Drives and compact flash
Compatible to 64-Bit operating systems
SIMATIC IPC Image & Partition Creator is orderable as optional Field PG M3
accessory.
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
Optimal integration in the SIMATIC
All automation interfaces on
board
Industrial ruggedness for
professional applications
Outstanding SIMATIC quality
Selected components
Preinstalled SIMATIC software
Licenses for enabling the
SIMATIC
software can be ordered with the
Field PG M3
Field PG M3 in tune with SIMATIC in 3 ways
. SIMATIC Controller
.. SIMATIC Software
... SIMATIC PGs
For internal use only / © Siemens AG 2010. All Rights Reserved.
Industry Sector
