VACUUBRAND GMBH + CO KG offers worldwide the most comprehensive product range of customeroriented laboratory and instrumentation vacuum pumps, gauges and controllers for rough and fine
vacuum. The product range comprises high-performance rotary-vane pumps, oil-free diaphragm
pumps, well-proven pumping units, flexible vacuum systems and solutions for local-area networks.
The range is completed by a wide choice of KF fittings and accessories as well as vacuum gauges
and controllers for rough and fine vacuum. In recent years, local-area vacuum networks with
pumps combining high-performance mechanics and the latest electronic control technology have
gained more and more importance. The design of VACUUBRAND products is driven by our
customers’ requirements.
Rotary-Vane Pumps
VARIO Diaphragm Pumps
VACUUBRAND rotary-vane pumps are designed for
an ultimate vacuum in the range of 1 mbar to
10-1 mbar (one-stage) or 10-3 mbar (two-stage).
The wide range of models available allows to meet
both technical and economic criteria. Selection of
the appropriate pump depends upon the requirements of the application, such as volume flow
rate, pumping speed and ultimate vacuum.
VARIO diaphragm pumps automatically find the
appropriate vacuum level and independently
adjust it with precise single-point control.
The Chemistry Version offers fully automatic
adaptation of the vacuum to the actual process
parameters.
VARIO diaphragm pumps in Aluminium Version
are both modern stand-alone or backing pumps
with adaptive pumping speed, fast evacuation
times, low ultimate vacuum and long lifetime.
For reliable operation and low maintenance of
rotary-vane pumps, we recommend some useful
accessories (see page 19 ff).
The Chemistry Hybrid Pump is a combination of
a rotary-vane pump and a chemistry diaphragm
pump, specially designed for use with corrosive
and condensable gases and vapours.
6
PRODUCT OVERVIEW
Diaphragm Pumps
Diaphragm pumps are totally oil-free mechanical
vacuum pumps. VACUUBRAND diaphragm pumps
offer, depending upon model, an ultimate
vacuum from < 80 to 0.3 mbar (60 to 0.2 Torr)
and pumping speeds from approx. 1 to 12 m3/h
(0.8 to 7.6 cfm). They often are the best available vacuum system within the laboratory or as
backing pumps for modern wide-range turbo
pumps. For use with chemicals and condensates,
the gas-contacted parts of the diaphragm pump
can be made of corrosion-resistant materials.
Two basic designs are available:
The Aluminium version is designed for a wide
variety of vacuum applications not involving
corrosive media in laboratories and process
plants.
In the Chemistry version, all gas and vapour
wetted parts are made from appropriate
chemically resistant fluoroplastics.
VARIO-SP Diaphragm Pumps
VARIO-SP diaphragm vacuum pumps combine
minimum dimensions and highest performance by
using an electronically controlled brushless 24 V
DC motor. The electronically controlled direct
drive is maintenance-free and has a variable
speed over a wide range. Generally they are
dedicated as system pumps (SP = SystemPump)
for larger systems, e.g. leak detectors, gas
analysers, the regeneration of cryo pumps, and
backing pumps for wide-range turbomolecular
pumping units. The 24 V DC motor with its very
compact dimensions permits mounting in any
position and world-wide operation independent
of different mains voltages.
ATEX Diaphragm Pumps and Gauges
VACUUBRAND offers ATEX chemistry diaphragm
pumps of equipment category 2 (e.g. for zone 1).
Due to the high chemical resistance of wetted
materials, the absence of gliding surfaces, and
the hermetic sealing of the pumping chambers,
they offer an excellent basis for avoiding ignition
sources. ATEX Chemistry Vacuum Systems and
gauges complete this range of products.
PRODUCT OVERVIEW
Chemistry Vacuum Systems and
Chemistry Pumping Units
VACUUBRAND chemistry pumping units are
designed for rough, fine and high vacuum.
Thereby the most appropriate vacuum pump can
be selected as the core component for achieving
the desired vacuum level. For reaching the
maximum performance in various applications, it
makes sense to use a proven configuration, i.e. a
complete chemistry pumping unit. This ensures a
good fit of the required accessories. Chemistry
pumping units offer the advantage of being ready
for use upon receipt.
A multitude of configurations and material options provides a practical and economical solution for nearly every application.
Local-Area Vacuum Network VACUU·LAN®
VACUU·LAN® as a modern vacuum supply for
laboratories is a flexible und cost-saving multiuser solution for vacuum generation in chemistry
laboratories. The range of VACUU·LAN® modules
comprises a series of different types for shut-off,
vacuum control or air admittance.
Vacuum Gauges and Controllers
The demand-driven speed control significantly
reduces the overall work load of the diaphragm
pump. Therefore, the total lifetime of the wear
parts attains previously unmatched values. Noise
level, vibration and power consumption are also
reduced.
Vacuum Valves and
Small-Flange Fittings
The range of VACUUBRAND vacuum valves and
small-flange fittings combines appropriate
standardisation with general practical use.
Dimensions of flange fittings are according to
standards (ISO KF). The range of straight pieces,
T-pieces and cross pieces, pipe elbows, flexible
pipes, couplings, sealing- and clamping rings are
based on the small-flange sizes KF NW 10, KF
NW 16, KF NW 25 and KF NW 40 as recommended
by PNEUROP.
VACUUBRAND operates a government-approved
DKD calibration laboratory. Vacuum gauges in the
measuring range of 1000 to 10-3 mbar (760 to
10-3 Torr) can be calibrated to fulfil the major
requirements of ISO 9000 ff (quality management) and ISO 10012 (quality assurance for
measuring equipment).
Choosing Vacuum Equipment
This section is a practical guide for vacuum
applications in chemistry laboratories. It provides
advice for selecting the appropriate vacuum
system for most applications in your laboratory
including recommendations for environmental
protection.
Vacuum Performance Data
Pumping speeds stated in cfm and l/min are
determined at 60 Hz mains frequency.
Pumping speeds given of diaphragm pumps are
either averaged between 500 and 1000 mbar, or
maximum values (according to DIN 28 432).
