TECHNICAL MANUAL

2

The manufacturer declines all the responsabilities regarding inaccuracies contained in this manual, if due to printing or typing mistakes. The manufacturer reserves the right to apply changes and improvements to the products at any time without notice.

TABLE OF CONTENTS

GENERAL FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unit description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unit identification code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Control system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

TECHNICAL DATA AND PERFORMANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

NOMINAL performances - Base acoustic setting up (AB) - Radiant plants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

NOMINAL performances - Base acoustic setting up (AB) - Standard plants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

NOMINAL performances - Low noise acoustic setting up (AS) - Radiant plants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

NOMINAL performances - Low noise acoustic setting up (AS) - Standard plants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

HEATING performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

COOLING performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Plant side hydraulic performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Domestic hot water side hydraulic performances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Operating limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Noise levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Weights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Overall dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Minimum operating area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3

4

GENERAL FEATURES

Unit description

This series of air-water heat pumps satisfies the heating, cooling and domestic hot water production requirements of residential plants of small and medium size.

All the units are suitable for splitted installation (indoor unit and outdoor unit connected through refrigerant pipes) and can be applied to fan coil plants, radiant floor plants and high efficiency radiators plants.

The control system allows to manage not only the refrigerant circuit but the whole plant with the possibility to choose different solutions both for the heating and cooling plant and for the domestic hot water management. The possibility of solar panels or other heating sources integration is also available.

The heating function optimizes the flow water temperature according both to the ambient temperature and to the outdoor temperature through climatic curves adaptable to the building features. It’s possible to manage a storage tank and two independent circuits (a direct one and a mixed one).

The domestic hot water management allows to control the three way valve, the storage tank and the anti-legionella cycles (if necessary).

The cooling function can be realized through “active cooling” (refrigerant circuit inversion). When the unit is used in radiant floor plants, to avoid condensate generation, a room humidity sensor can be installed.

The internal programmer clock allows to define different daily switching programs for heating, cooling and domestic hot water production.

The heat pump is composed by an indoor unit (motocondensing unit) containing the hydraulic circuit, the electrical board, the compressor and a part of the refrigerant circuit and an outdoor unit (remote evaporator).

The refrigerant circuit, contained in an extractable box to simplify the maintenance operations, is equipped with rotary compressor mounted on damper supports, brazed plate heat exchanger, thermostatic expansion valve and reverse cycle valve and liquid receiver.

The circuit is protected by high and low pressure switches and flow switches on the plate heat exchanger.

The plate heat exchanger and all the hydraulic pipes are thermally insulated to avoid condensate generation and to reduce thermal losses.

The outdoor structure of the indoor unit and the refrigerant circuit box are both thermally and acoustically insulated in order to create a double wall against sound propagation and to allow the installation in domestic places.

To avoid vibration propagation towards the hydraulic circuit the refrigerant circuit box is placed on damper supports and the connection pipes are flexible.

The outdoor unit is composed by finned coil made of copper pipes and aluminium louvered fins and axial fan with safety protection grilles. The fan, supplied with DC motor and electronic rotational speed control, guarantees high efficiency and low noise in all the operating conditions.

All the units are supplied with an outdoor temperature sensor in order to realize the climatic control.

All the units are accurately built and individually tested in the factory. Only electric, hydraulic and refrigerant (between indoor and outdoor units) connections are required for installation.

Unit identification code

The codes that identify the units and the meaning of the letters used are described below.

Unit type

IP - Units suitable for hydronic plant installation operating as reversible heat pumps

Unit model

N° compressors

Unit version

VB - Base version

Power supply

1 - 230V - 1 - 50 Hz

Operating range

M - Medium temperature.

The unit is suitable to produce water at medium temperature

Refrigerant type

0

- R410A

Acoustic setting up

AB - Base setting up

AS - Low noise setting up

5

GENERAL FEATURES

Description of components

Indoor unit structure . Basement, lateral panels and frontal panel, are completely thermally and acoustically insulated in order to minimize thermal losses and noise emissions in the surroundings. Accessibility to internal parts is possible removing the frontal panel and the upper panel. For extraordinary manteinances also the rear panel can be removed.

hermetic filter dryer (5) to restrain impurity and moisture residuals that could be present in the circuit,

high and low

pressure switches in order to assure the compressor to operate inside the permitted limits, 4 way reverse cycle valve (6) to allow operating mode change reversing the refrigerant flow,

pressure connections SAE 5/16” - UNF 1/2” - 20 equipped with pin, gasket and blind nut, as required for the use of R410A refrigerant (they allow the complete check of the refrigerant circuit : compressor inlet pressure, compressor outlet pressure, thermostatic expansion valve upstream pressure and pressure drops accross the filter). All the pipes of the refrigerant circuit are properly insulated to avoid condensate generation and to minimize thermal losses.

The axial fan (8) is equipped with an high efficiency electronically commutated (EC) motor, is contained ia a sheet nozzle and is equipped with a safety grille.

Hydraulic circuit . All the pipes are thermally insulated to avoid condensate generation and minimize thermal losses. The circuit is equipped with a three speed glandless pump, expansion vessel, safety valve, pressure gauge and air vents.

Electrical panel. It contains all the power, control and security components necessary to guarantee the unit to work properly.

The unit is managed by a microprocessor controller to which all the electrical loads and the control devices are connected.

The user interface, placed on the frontal panel of the unit, allows to view and to modify, if necessary, all the parameters of the unit.

All the units are supplied with an outdoor temperature sensor, to be installed outside, in order to realize the climatic control.

Outdoor unit structure . Basement, supporting structure and lateral panels are made of galvanized and painted sheet-steel to guarantee good resistance to atmospheric agents. Accessibility to internal parts is possible removing the frontal panel. For extraordinary manteinances also the other panels can be removed.

Refrigerant circuit . All the components of the refrigerant circuit, except the finned coil, are contained inside an extractable box placed in the indoor unit to simplify the maintenance operations.

The box is placed on rubber vibration dampers and is connected to the hydraulic circuit through flexible pipes in order to avoid the propagation of the vibrations generated by the compressor outside the unit. The hermetic rotary compressor (1) is mounted on damper supports and is protected against overtemperatures and overcurrents. The heat exchangers on the plant side (2) is a brazed stainless steel plate heat exchanger, properly insulated to avoid condensate generation and to minimize thermal losses, and protected by a flow switch that detects whatever water flow lack. The source side heat exchanger (3) is a finned coil realized with grooved copper pipes and hydrophilic aluminium fins with waved profile to increase the heat exchange coefficient.

A tray is placed under the coil to collect the condensate generated in heating mode. The expansion device (4), an electronic expansion valve, allows the unit to adjust itself to the different operating conditions keeping steady the set superheating. The refrigerant circuit of each unit contains moreover

solid core

5

7

4

2

1

6

6

GENERAL FEATURES

Control system

The microprocessor controller is able to manage not only the unit itself but also all that components of the plant which allow to realize a complete system.

The main functions of the control system are :

- room temperature control according to the outdoor temperature (climatic control)

- domestic hot water production (management of 3 way valve, storage tank, anti legionella cycles…)

- management of a heating and/or cooling mixed circuit (pump and 3 way mixing valve)

- management of a heating direct circuit (only pump)

- management of a storage tank for heating and/or cooling

- management of electrical heaters for heating and domestic hot water (3 steps logic)

- solar panels integration

- room humidity control for cooling with radiant systems

- internal programmer clock (for heating, cooling and domestic hot water)

- digital input for electrical energy low tariff

- alarm memory management and diagnostic

- compressor and pump operating hour counter

- possibility to manage more units in cascade (maximum 16)

Besides the standard user interface present on all the units, wired or wireless remote thermostats are available which allow to control all the operating parameters of the unit and to acquire the temperature in the different zones in order to realize a more precise and comfortable control.

The unit controller is able to manage a lot of different plant solutions enabling automatically the necessary control algorythms according to the components which have been connected.

The management of such components is possible through additional expansion modules which communicate with the unit by means of an internal bus and provide all the inputs and outputs required to fulfil a complete system.

FS

FS

The controller is able to manage up to two zones in heating

(one by means of a mixed circuit and the other by means of a direct circuit) and one zone in cooling (by means of a mixed circuit).

It’s possible to realize more complex plants connecting to the heat pump controller further expansion modules in order to extend without limits the number of zones to be managed.

For each zone the following parameters can be set :

- set point

- daily or weekly operating time table

- climatic control curve

- room control sensor : it can be in common with the other zones or independent (in that case it’s necessary to install an additional room thermostat)

7

GENERAL FEATURES

Options

3 way valve

Domestic hot water production

Acoustic setting up

3 way valve with primary heat exchanger

3 way valve with secondary heat exchanger

(for integrated tank)

AS - Low noise setting up

Integrative electrical heaters

Soft starter

Plant buffer tank connections

Allow to divert the hot water produced by the heat pump from the heating circuit to the domestic hot water circuit.

The hot water is diverted by the three way valve on an internal heat exchanger.

An internal pump assures a correct domestic hot water flow through the other side of the heat exchanger.

The hot water is diverted by the three way valve in a tank integrated in the unit

(accessory). The domestic hot water is generated istantaneously by means of an internal heat exchanger and a modulating pump.

Allow to reduce the noise level of the outdoor unit modifying the rotational speed of the fan.

Integrate or replace the heating power supplied by the heat pump and are managed by the unit controller with a 3 step logic.

Reduces the compressor start current.

The hot or cold water produced by the heat pump is used to heat or cool a buffer tank integrated in the unit (accessory) assuring a higher thermal inertia for the plant.

The controller flexibility and the big number of options available allow to get, for each model, a lot of different configurations that integrate inside the heat pump many components of the plant and allow to realize compact and tested installations.

In order to select the right configuration it is necessary to define the type of plant to which the heat pump will be connected, both for what concerning the heating and cooling circuits, and for what concerning the domestic hot water management.

Reversible heat pump (IP) without options Option “Integrative electrical heaters”

FS

Option “Plant buffer tank connections"

FS

In this configuration the heat pump can heat or cool a buffer tank that increases the thermal inertia of the plant and operates as hydraulic separator.

N .B . If the integrated tank is used as buffer tank for the plant, it can not be used as tank for the domestic hot water production (see option "3 way valve and secondary heat exchanger").

8

Option “Domestic hot water production”

3 way valve

GENERAL FEATURES

In this configuration the heat pump can be coupled to a domestic hot water tank equipped with a coil designed for a maximum water temperature between

55°C and 60°C.

The anti legionella cycles have to be performed by means of electrical heaters placed on the heat pump outlet (see option “Integrative electrical heaters”) or directly inside the tank.

FS

3 way valve with primary heat exchanger

In this configuration the heat pump can be coupled to a domestic hot water tank without coil.

The anti legionella cycles have to be performed by means of electrical heaters placed on the heat pump outlet (see option “Integrative electrical heaters”) or directly inside the tank.

FS

3 way valve with secondary heat exchanger

FS

FS

4

3

In this configuration the heat pump can produce instantaneously the domestic hot water using the hot water stored in the tank integrated in the unit (see accessory “Integrated tank”).

The temperature of the domestic hot water at the unit outlet is adjusted modulating the speed of the pump on the primary side.

The anti legionella cycles are not necessary.

9

GENERAL FEATURES

Accessories

Rubber vibration dampers

(for indoor unit)

Rubber vibration dampers

(for outdoor unit)

Coil protection grille

(for outdoor unit)

Remote thermostat

Remote control

(wired or wireless)

Wireless transmitter

Allow to reduce the transmission to the unit support plane of the mechanical vibrations generated by the compressor and by the pumps in their normal operating mode.

Allow to reduce the transmission to the unit support plane of the mechanical vibrations generated by the fans in their normal operating mode.

Protects the external surface of the finned coil.

Allows operating mode selection and set point adjustment. The on board temperature sensor can be used in order to realize a climatic control.

Replicates all the control and visualization functionalities of the controller installed on the unit. The on board temperature sensor can be used in order to realize a climatic control.

Connected to the unit controller, allows to communicate with wireless remote control and wireless outdoor temperature sensor.

Wireless repeater

Extends wireless operating range.

Wireless adaptor for

outdoor temperature sensor Allows to transform the wired outdoor temperature sensor, standard for all the units, in a wireless sensor.

Condensate sensor

In cooling mode it allows the minimum flow temperature control when condensate generation occurs.

Room hygrostat

Room humidity sensor

(with or without display)

Transformer

230V / 24V - 3VA

In cooling mode it allows the minimum flow temperature control according to the room humidity.

In cooling mode it allows the minimum flow temperature control according to the room dew point, calculated from the measured room humidity.

It assures the correct power supply for the condensate sensor and for the room humidity sensor.

Integrated tank

Pipes for solar panels connection

Refrigerant circuit box

Integrated tank, to be installed under the unit. It can be used as storage tank for domestic hot water production

(coupled with units with option "Domestic hot water production" : "3 way valve and secondary heat exchanger") or as buffer tank for the plant (coupled with units with option "Plant buffer tank connections".

Inside the tank a coil for solar panels integration is contained.

Allow to move the connections of the solar integration coil, available on the tank (accessory), directly on the upper side of the unit.

If a failure occurs inside the refrigerant circuit, it permits to restart the heat pump very quickly.

10

TECHNICAL DATA AND PERFORMANCES

Technical data

Frame

Model

Power supply

3 .1

230 - 1 - 50

4 .1

230 - 1 - 50

1

5 .1

230 - 1 - 50

7 .1

230 - 1 - 50

9 .1

230 - 1 - 50

Refrigerant

Type

Compressor

Type

Quantity

Power steps

Oil charge

Plant side heat exchanger

Type

Quantity

Water volume

Fans

Type

Quantity

Diameter

Maximum rotational speed

Total installed power

Source side heat exchanger

Type

Quantity

Frontal surface

Plant side hydraulic circuit

Safety valve set point

Expansion vessel volume

Plant side pump

Type

Quantity

Installed power

Integrated tank (accessory)

Volume

1

0 - 100

0,35

1

0,53

1

450

900

0,15

1

0,44

3

10

1

0,14

120

Solar coil surface

Integrative electrical heaters (option)

Total installed power

Power steps

1,1

9,0

0 - 33 - 66 - 100

1

0 - 100

0,43

1

0,44

3

10

R410A rotary

1

0 - 100

0,67

1

0 - 100

1,13

1

0,53 stainless stee brazed plates

1

0,53

1

0,67

1 axial with high efficiency EC motor

1 1

450

900

0,15

450

900

0,15

500

900

0,21 finned coil

1

0,44

1

0,14

3 speed glandless pump

1

0,14

1

0,14

120

1,1

3

10

120

1,1

1

0,44

3

10

120

1,1

1

0 - 100

1,13

1

0,84

1

500

900

0,21

1

0,44

3

10

1

0,14

120

1,1

9,0

0 - 33 - 66 - 100

9,0

0 - 33 - 66 - 100

9,0

0 - 33 - 66 - 100

9,0

0 - 33 - 66 - 100

U.M.

V-ph-Hz

-

n° l

% kg bar l

m

2 kW

%

n° mm rpm kW

n° m

2

n° kW

11

TECHNICAL DATA AND PERFORMANCES

NOMINAL performances - Base acoustic setting up (AB) - Radiant plants

Frame

Model

Power supply

3 .1

230 - 1 - 50

4 .1

230 - 1 - 50

1

5 .1

230 - 1 - 50

IP

Heating A7W35 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C )

Heating capacity 2,42 3,85 5,24

Power input 0,85 1,35 1,88

COP

Water flow rate plant side

2,85

417

2,85

664

2,79

905

Available static head plant side 60 54 47

Heating A2W35 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 30°C out 35°C )

Heating capacity 1,99 3,15 4,33

Power input

COP

0,55

3,62

0,88

3,58

1,23

3,52

Water flow rate plant side 345 545 748

Available static head plant side 62 57 51

Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )

Cooling capacity 2,52 4,00 5,46

Power input

EER

Water flow rate plant side

Available static head plant side

0,79

3,19

435

60

1,25

3,20

690

53

1,74

3,14

943

45

Data declared according to EN 14511 . The values are referred to units without options or accessories.

7 .1

230 - 1 - 50

5,65

1,59

3,55

977

48

6,87

2,44

2,82

1186

43

7,14

2,27

3,15

1235

41

NOMINAL performances - Base acoustic setting up (AB) - Standard plants

Frame

Model

Power supply

3 .1

230 - 1 - 50

4 .1

230 - 1 - 50

1

5 .1

230 - 1 - 50

IP

Heating A7W45 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 40°C out 45°C )

Heating capacity 2,35 3,72 5,11

Power input

COP

Water flow rate plant side

0,68

3,46

409

1,09

3,41

647

1,51

3,38

887

Available static head plant side 60 54 47

Heating A2W45 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 40°C out 45°C )

Heating capacity 1,94 3,08 4,22

Power input

COP

Water flow rate plant side

Available static head plant side

0,68

2,85

337

62

1,08

2,85

535

57

1,50

2,81

732

52

Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )

Cooling capacity 1,94 3,08 4,20

Power input

EER

Water flow rate plant side

Available static head plant side

0,73

2,66

333

62

1,16

2,66

529

58

1,61

2,61

722

52

Data declared according to EN 14511 . The values are referred to units without options or accessories.

7 .1

230 - 1 - 50

6,67

1,96

3,40

1158

43

5,50

2,09

2,63

945

50

5,52

1,95

2,83

958

49

9 .1

230 - 1 - 50

U.M.

V-ph-Hz

6,90

1,96

3,52

1193

46

8,72

2,78

3,14

1507

38

8,37

3,00

2,79

1447

40 kW kW

l/h kPa kW kW

l/h kPa kW kW

l/h kPa

9 .1

230 - 1 - 50

U.M.

V-ph-Hz

8,15

2,42

3,37

1413

41

6,73

2,39

2,82

1168

47

6,71

2,57

2,61

1153

48 kW kW

l/h kPa kW kW

l/h kPa kW kW

l/h kPa

12

TECHNICAL DATA AND PERFORMANCES

NOMINAL performances - Low noise acoustic setting up (AS) - Radiant plants

Frame

Model

Power supply

3 .1

230 - 1 - 50

4 .1

230 - 1 - 50

1

5 .1

230 - 1 - 50

IP

Heating A7W35 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 30°C out 35°C )

Heating capacity 2,28 3,61 4,95

Power input 0,54 0,86 1,20

COP

Water flow rate plant side

4,22

395

4,20

625

4,13

855

Available static head plant side 61 55 48

Heating A2W35 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 30°C out 35°C )

Heating capacity 1,89 3,00 4,11

Power input

COP

0,53

3,57

0,85

3,53

1,19

3,45

Water flow rate plant side 327 519 710

Available static head plant side 62 58 53

Cooling A35W18 ( source : air in 35°C d.b. / plant : water in 23°C out 18°C )

Cooling capacity 2,42 3,85 5,24

Power input

EER

Water flow rate plant side

Available static head plant side

0,85

2,85

417

60

1,35

2,85

664

54

1,88

2,79

905

47

Data declared according to EN 14511 . The values are referred to units without options or accessories.

7 .1

230 - 1 - 50

5,37

1,54

3,49

928

50

6,47

1,56

4,15

1119

44

6,87

2,44

2,82

1186

43

NOMINAL performances - Low noise acoustic setting up (AS) - Standard plants

Frame

Model

Power supply

3 .1

230 - 1 - 50

4 .1

230 - 1 - 50

1

5 .1

230 - 1 - 50

IP

Heating A7W45 ( source : air in 7°C d.b. 6°C w.b. / plant : water in 40°C out 45°C )

Heating capacity 2,23 3,54 4,85

Power input

COP

Water flow rate plant side

0,66

3,38

388

1,05

3,37

615

1,46

3,32

841

Available static head plant side 60 55 48

Heating A2W45 ( source : air in 2°C d.b. 1°C w.b. / plant : water in 40°C out 45°C )

Heating capacity 1,85 2,92 4,00

Power input

COP

Water flow rate plant side

Available static head plant side

0,65

2,85

322

62

1,04

2,81

508

58

1,44

2,78

695

53

Cooling A35W7 ( source : air in 35°C d.b. / plant : water in 12°C out 7°C )

Cooling capacity 1,86 2,96 4,04

Power input

EER

Water flow rate plant side

Available static head plant side

0,79

2,35

319

62

1,25

2,37

508

58

1,73

2,34

693

53

Data declared according to EN 14511 . The values are referred to units without options or accessories.

7 .1

230 - 1 - 50

6,34

1,90

3,34

1101

45

5,28

2,26

2,34

908

50

5,24

1,89

2,77

909

50

9 .1

230 - 1 - 50

U.M.

V-ph-Hz

6,56

1,90

3,45

1134

48

8,37

3,00

2,79

1447

40

7,90

1,92

4,11

1366

42 kW kW

l/h kPa kW kW

l/h kPa kW kW

l/h kPa

9 .1

230 - 1 - 50

U.M.

V-ph-Hz

7,74

2,34

3,31

1344

42

6,40

2,32

2,76

1111

48

6,44

2,77

2,32

1107

49 kW kW

l/h kPa kW kW

l/h kPa kW kW

l/h kPa

13

TECHNICAL DATA AND PERFORMANCES

HEATING performances

Heating capacity

D

C

B

A

The graphs allow to get the corrective factors to be applied to the nominal performances in order to obtain the real performances in the selected operating conditions.

The reference nominal condition is :

A7W35

source : air in 7°C d.b. 6°C w.b.

plant : water in 30°C out 35°C

Outlet temperature plant side :

A = 55°C

B = 45°C

C = 35°C

D = 25°C

Inlet air temperature w.b. [°C]

Power input COP

A

B

C

D

A B

C D

Inlet air temperature w.b. [°C] Inlet air temperature w.b. [°C]

14

TECHNICAL DATA AND PERFORMANCES

COOLING performances

Cooling capacity

A B

C D

The graphs allow to get the corrective factors to be applied to the nominal performances in order to obtain the real performances in the selected operating conditions.

The reference nominal condition is :

A35W7

source : air in 35°C d.b.

plant : water in 12°C out 7°C

Outlet temperature plant side :

A = 24°C

B = 18°C

C = 12°C

D = 7°C

Inlet air temperature w.b. [°C]

Power input

A

B

EER

A

B

C

D

C

D

Inlet air temperature d.b. [°C] Inlet air temperature d.b. [°C]

15

TECHNICAL DATA AND PERFORMANCES

Plant side hydraulic performances

Available static head - unit without options

3.1

4.1

5.1

Flow rate [ l/h ]

Perdite di carico aggiuntive

A = unit with option “Domestic hot water production” : “3 way valve”

B = unit with option “Integrative electrical heaters”

7.1

9.1

B

A

Flow rate [ l/h ]

The graphs are referred to units operating with water at the temperature of 10°C (density 1000 kg/m

3

).

16

TECHNICAL DATA AND PERFORMANCES

Domestic hot water side hydraulic performances

Available static head

A = unit with option “Domestic hot water production” : “3 way valve”

B = unit with option “Domestic hot water production” : “3 way valve with primary heat exchanger”

A

9.1

11.1

B

3.1

5.1

7.1

Flow rate [ l/h ]

The graphs are referred to units operating with water at the temperature of 10°C (density 1000 kg/m

3

).

17

TECHNICAL DATA AND PERFORMANCES

Operating limits

I grafici sotto riportati indicano il campo di funzionamento entro cui è garantito il corretto funzionamento dell’unità.

HEATING

Inlet air temperature d.b. [°C]

COOLING

Temperature difference between unit inlet and outlet

D T max Maximum value

D T min Minimum value

18

Inlet air temperature d.b. [°C]

Plant side

11

3

°C

°C

TECHNICAL DATA AND PERFORMANCES

Electrical data

Frame

Model

3 .1

4 .1

1

5 .1

7 .1

Unit

Power supply

F.L.A.

Maximum total current input

F.L.I.

Maximum total power input

M.I.C.

Maximum total start current

Maximum total start current with soft starter (option)

Integrative electrical heaters

Power supply

F.L.A.

Maximum total current input

( 230V - 1 - 50Hz )

Maximum total current input

( 400V - 3N - 50Hz )

F.L.I.

Maximum total power input

230 - 1 - 50

6,7

1,4

37

33

230 - 1 - 50

400-3N-50

39,1

13,0

9,0

230 - 1 - 50

8,5

1,8

46

36

230 - 1 - 50

400-3N-50

39,1

13,0

9,0

230 - 1 - 50

10,9

2,3

53

39

230 - 1 - 50

400-3N-50

39,1

13,0

9,0

230 - 1 - 50

14,4

3,1

83

42

230 - 1 - 50

400-3N-50

39,1

13,0

9,0

Domestic hot water production pump (with option “3 way valve with primary heat exchanger”)

Power supply

F.L.A.

Maximum total current input

F.L.I.

Maximum total power input

230-1-50

0,4

0,08

230-1-50

0,4

0,08

230-1-50

0,4

0,08

230-1-50

0,4

0,08

Domestic hot water production pump (with option “3 way valve with secondary heat exchanger”)

Power supply

F.L.A.

Maximum total current input

F.L.I.

Maximum total power input

230-1-50

0,7

0,14

230-1-50

0,7

0,14

230-1-50

0,7

0,14

230-1-50

0,7

0,14

9 .1

U.M.

230 - 1 - 50

18,1

3,9

113

44

V-ph-Hz

A kW

A

A

230 - 1 - 50

400-3N-50

39,1

13,0

9,0

V-ph-Hz

A

A kW

230-1-50

0,4

0,08

230-1-50

0,7

0,14

V-ph-Hz

A kW

V-ph-Hz

A kW

19

TECHNICAL DATA AND PERFORMANCES

Noise levels

Indoor unit

Model

3 .1

4 .1

5 .1

7 .1

9 .1

Sound power levels [dB] by octave bands [Hz]

Sound power level

Sound pressure at 1 meter at 5 meters at 10 meters

63 125 250 500 1000 2000 4000 8000 [dB] [dB(A)] [dB(A)]

73,2 63,3 48,3 31,7 31,0 22,6 20,9 21,9 74

51

36

74,2 64,3 49,3 32,7 32,0 23,6 21,9 22,9

74,2 64,3 49,3 32,7 32,0 23,6 21,9 22,9

75,2 65,3 50,3 33,7 33,0 24,6 22,9 23,9

75,2 65,3 50,3 33,7 33,0 24,6 22,9 23,9

75

75

76

76

52

52

53

53

37

37

38

38

[dB(A)]

25

26

26

27

27

[dB(A)]

19

20

20

21

21

Outdoor unit - BASE acoustic setting up (AB)

Model

3 .1

4 .1

5 .1

7 .1

9 .1

Sound power levels [dB] by octave bands [Hz]

Sound power level at 1 meter at 5 meters at 10 meters

63 125 250 500 1000 2000 4000 8000 [dB] [dB(A)] [dB(A)]

73,6 71,5 69,8 66,1 62,6 58,4 52,7 45,2 77

68

54

Sound pressure

[dB(A)]

43

[dB(A)]

37

73,6 71,5 69,8 66,1 62,6 58,4 52,7 45,2

73,6 71,5 69,8 66,1 62,6 58,4 52,7 45,2

76,4 74,3 72,6 68,9 65,4 61,2 55,5 48,0

76,4 74,3 72,6 68,9 65,4 61,2 55,5 48,0

77

77

80

80

68

68

71

71

54

54

56

56

43

43

45

45

37

37

40

40

Outdoor unit - LOW NOISE acoustic setting up (AS)

Model

3 .1

4 .1

5 .1

7 .1

9 .1

Sound power levels [dB] by octave bands [Hz]

Sound power level

63 125 250 500 1000 2000 4000 8000 [dB] [dB(A)] [dB(A)]

70,6 68,5 66,8 63,1 59,6 55,4 49,7 42,2 74

65

51

70,6 68,5 66,8 63,1 59,6 55,4 49,7 42,2

70,6 68,5 66,8 63,1 59,6 55,4 49,7 42,2

74

74

65

65

51

51

73,4 71,3 69,6 65,9 62,4 58,2 52,5 45,0

73,4 71,3 69,6 65,9 62,4 58,2 52,5 45,0

77

77

68

68

53

53

Sound pressure at 1 meter at 5 meters at 10 meters

[dB(A)]

40

40

40

42

42

[dB(A)]

34

34

34

37

37

Reference conditions

Performances referred to units operating in heating mode at nominal conditions A7W35.

Unit placed in free field on reflecting surface (directional factor equal to 2).

The sound power level is measured according to ISO 3744 standard.

The sound pressure level is calculated according to ISO 3744 and is referred to a distance of 1 meter from the external surface of the unit.

20

TECHNICAL DATA AND PERFORMANCES

Weights

Frame

Model

Components weights

Indoor unit without options

Domestic hot water production

3 way valve

3 way valve with primary heat exchanger

3 way valve with secondary heat exchanger

Plant buffer tank connections

Integrative electrical heaters

Outdoor unit

Accessories

Integrated tank

Pipes for solar panels connection

Refrigerant circuit box

3 .1

10

5

5

58

118

3

9

77

2

44

4 .1

10

5

5

58

122

3

9

77

2

48

1

5 .1

10

5

5

58

124

3

9

77

2

50

7 .1

10

5

5

79

131

3

9

77

2

58

Transport weights

Indoor unit without options

Domestic hot water production

3 way valve

3 way valve with primary heat exchanger

3 way valve with secondary heat exchanger

Plant buffer tank connections

Integrative electrical heaters

Outdoor unit

Accessories

Integrated tank

Pipes for solar panels connection

Refrigerant circuit box

10

5

5

68

136

3

9

95

3

46

10

5

5

68

140

3

9

95

3

50

10

5

5

68

142

3

9

95

3

52

10

5

5

89

149

3

9

95

3

60

Operating weights

Indoor unit without options

Domestic hot water production

3 way valve

3 way valve with primary heat exchanger

3 way valve with secondary heat exchanger

Plant buffer tank connections

Integrative electrical heaters

Outdoor unit

Accessories

Integrated tank

Pipes for solar panels connection

14

7

6

58

120

5

13

202

5

14

7

6

58

124

5

13

202

5

14

7

6

58

126

5

13

202

5

14

7

6

79

134

5

13

202

5

9 .1

10

5

5

79

134

3

9

77

2

61

U.M.

kg kg kg kg kg kg kg kg kg kg

10

5

5

89

152

3

9

95

3

63 kg kg kg kg kg kg kg kg kg kg

14

7

6

79

137

5

13

202

5 kg kg kg kg kg kg kg kg kg

21

TECHNICAL DATA AND PERFORMANCES

Overall dimensions

1

2

6

7

8

3

4

5

Plant return

Plant flow

Domestic hot water return

Domestic hot water flow

Gas line (refrigerant)

Liquid line (refrigerant)

Solar panel return

Solar panel flow

1” M

1” M

1” M

1” M

5/8”

3/8”

18 mm

18 mm

H1

H2

H2 with accessory

“Integrated tank”

3.1 - 4.1 - 5.1

903 mm

852 mm

1678 mm

7 8

1 2 3 4 5 6

7.1 - 9.1

1153 mm

852 mm

1678 mm

356

754

93

53

90 90 80 81 83 86 90

394

74 72 608 71

600

Minimum operating area

Rispect the free area around the unit as shown in figure in order to guarantee a good accessibility and facilitate maintenance and control operations.

C

D

A

B

E

600 mm

300 mm

400 mm

600 mm

200 mm

Unit with accessory

“Integrated tank”

600

A

22

The manufacturer declines all the responsabilities regarding inaccuracies contained in this manual, if due to printing or typing mistakes. The manufacturer reserves the right to apply changes and improvements to the products at any time without notice.

23

24

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
